EQUIUM 6200M Product Specifications
Equium 6200M
4.24 GB: PV1026U-01A
PROCESSOR
Intel Pentium Pro 200Mhz (3.3v) w/VRT
Integrated Coprocessor Yes
Processor Cache 32KB: (16KB code; 16KB data)
Socketed Processor Yes
Dual Processor Support Yes
LEVEL 2 (L2) CACHE
Data Bus Width/Address Bus Width 64-bit/32-bit
Local Clock Bus Speed 66 MHz
DATA RAM:
1 Mbit PBS SRAM (3.3V) Yes
Access time 8 nsec
SYSTEM ARCHITECTURE
PCI BUS (V2.1): (32-bit, 33mhz) Connecting devices: Video, PCI card slots
MEMORY:
Standard 32 MB (1*32 DIMM)
Maximum 512 MB (416MB without removing memory)
Speed 60ns
Hyper Page mode memory access Yes
Data Bus Width/Address Bus Width 64-bit/32-bit
Local Clock Bus Speed 66 MHz
Socket Type (4) DIMM sockets: Accepts 16MB, 32MB, 64MB or 128MB chips
BIOS (256KB FLASH EPROM, )
PnP 1.0a SUPPORT Yes
Advanced Power Management 1.2 Support Yes
EPA energy Star Compliant Yes
DMI 2.0 Compliant Yes
DPMS Yes
DDC Yes
NLS Yes
VIDEO
Video Memory: SGRAM 2 MB expandable to 4MB
Speed 40 ns
PCI Bus Architecture Yes: 33 MHz Bus Clock Speed
Controller Chip ATI Rage II+
Full motion video at 30 fps support Yes
VESA support Yes
YUV to RGB conversion Off-loads conversio n from CPU for higher perfo rmance full motion video
Graphics Accellerator Support Includes 64-bit BitBLT, Hardware Cursor, DirectDraw, Direct3D
Supported Resolutions Colors/Pallette Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors/16.7M colors 100 Hz
800 x 600 16.7M colors/16.7M colors 100 Hz
1024 x 768 64K colors/64K colors 100 Hz
1280 x 1024 256 colors/256 colors 75 Hz
SOUND SYSTEM
Chipsets: Crystal CS4236
16 bit stereo audio
Sound formats supported:
ETHERNET SUPPORT
IEEE802, 3µ auto-negotiation
full duplexed
Yes
Yes: 256KB Pipeline Burst Integrated into CPU
32Mbit ECC EDO DRAM (Error Correcting Code)
Yes
without compromising picture quality or frame rate.
Yes
SoundBlaster Pro, .WAV, MIDI, CD-ROM audio
Board Integrated: Intel EtherExpress PRO/100B LAN Adapter
Yes: provide s hardware selectio n of the highest operating speed
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 6200m.doc Rev. 4 04/04/00 nmm. Page 1 of 3
EQUIUM 6200M Product Specifications
Equium 6200M
4.24 GB: PV1026U-01A
STORAGE
CONTROLLER TYPE Dual Channel, Bus Mastering PCI-EIDE (supports 4 IDE devices)
PIO Mode 4 (up to 16Mb/sec transfer rate) Yes
HDD ( 3.5”Half-height Ultrawide SCSI) 4.55 billion bytes (=4.24 GB)
Access Time <10msec
Burst Data Transfer Rate PIO Mode 4 (16.7MB/sec)
Controller Integrated Adaptec AIC-7880 Ultra Wide SCSI
FDD 3.5” Floppy Disk Drive
CD-ROM: Toshiba XM-5702B 12X- speed
PCI Bus Master support Yes
Interface ATAPI ( Enhanced IDE ) w/256KB Buffer
Random Access Time 115 ms
Sustained Transfer Rate 1.8 MB/sec
Supported Disk Formats Red Book, Yellow Book, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Extra, CD-E)
EXPANSION SLOTS
Number of PCI Slots ( Available/Total ) 3/4
Number of ISA Slots ( Available/Total ) 1/1
EXPANSION BAY
Internal Bay One open - One occupied with HDD
External 5.25” Bay Two open - Two occupied with FDD, 12X CD-ROM
EXTERNAL INTERFACES
One RJ-45 port for ethernet card (supplied) Yes
One 9-Pin Serial (16550 UART compliant) Yes
Universal Serial Bus ports Supports 2 USB peripherals without external hub
One 25-Pin Parallel (IEEEP1284 compliant) Yes: Multimode bi-directional (EPP, ECP)
One 15-Pin RGB (SVGA video) Yes
One (PS/2) Mouse Port Yes
One (PS/2) 101 Keyboard Yes
Joystick/MIDI Port (15 pin D-sub) Yes
Microphone (3.5mm mini jack, monaural) Yes
Speaker-out (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
AC IN (Standard 2 prong ) Yes
KEYBOARD
104-key keyboard with the Windows 95 keys Yes
3.8mm Travel Yes
12 dedicated function keys Yes
Numeric keypad Yes
POINTING DEVICE
PS/2 Mouse Yes
POWER SUPPLY( 200Watts )
Input (Voltage/Frequency) 115-230V; 50-60Hz, Switch Selectable
Supported Safety Standards UL/CSA, NRTL/C, VDE 0805, IEC 950, EN 60950, NEMKO
DIMENSIONS: (L x W x D)
WEIGHT
BUNDLED SOFTWARE:
Microsoft Windows NT Workstation v4.x; Plug and Play drivers; Ethernet drivers (DOS, Window95, NTW, OS/2, Netware)
Disk Creation utility; Intel LanDesk Client Manager, Mouse drivers
WARRANTY: 3 Yr. Parts & Labor (First Yr. On-site); Dedicated technical support, business hours nationwide
1. Both ports operate from a single controller allowing 128 devices total, not per port. Throughput for the Universal Serial
Bus (UBS) is 12Mbits/sec.
20.5” x 9.5” x 17”
31 LBS
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 6200m.doc Rev. 4 04/04/00 nmm. Page 2 of 3
EQUIUM 6200M Product Specifications
PRICING
6200M 200MHz Pentium Pro, 4.24GB HDD, 12X CD-ROM PV1026U-01A $1,799
EQUIUM MONITORS
17” (15.8” viewable image)TekBright Multimedia Monitor (DC786MF) PV2003U-01 $649
Toshiba TekBright
Toshiba TekBright
17” (16.23”viewable image) Autoscan Monitor DP782M-01 $599
15” (13.78”viewable image) Autoscan Monitor DP566M-01 $299
EQUIUM ACCESSORIES
16MB Kingston Noteworthy EDO ECC memory upgrade module KTT-EQ/16 $99
32MB Kingston Noteworthy EDO ECC memory upgrade module KTT-EQ/32 $171
64MB Kingston Noteworthy EDO ECC memory upgrade module KTT-EQ/64 $364
128MB Kingston Noteworthy EDO ECC memory upgrade module KTT-EQ/128 $710
2MB Video memory upgrade module
17” (15.8” viewable image) Monitor -- 700P
15” (13.7” viewable image) Monitor -- 500V
(For 6200M)
(For 5160D, 5200D, 5230D, 6200M)
PART # PRICE
PART # PRICE
PV2006U-01 $649 NEW!!
PV2005U-01 $349 NEW!!
PART #
KTT-VATI/2 $50
PRICE
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 6200m.doc Rev. 4 04/04/00 nmm. Page 3 of 3
