Toshiba DLP 52HM95, DLP 62HM95 User Manual

O
WNER’S
ANUAL
Integrated High Definition
DLP
Projection Television
For an overview of steps for setting up
and using your new TV, see page 8.
Note: To display a High Definition picture, the TV must be receiving a High Definition signal (such as an over-the-air High Definition TV broadcast, a High Definition digital cable program, or a High Definition digital satellite program). For details, please contact your TV antenna installer or your cable or satellite provider.
Note: If the TV is powered off and then on again quickly when the lamp unit is hot, it may take several minutes for the picture to appear on-screen. This is a property of DLP TV lamp technoplogy and is not a sign of malfunction. For details, see “IMPORTANT NOTICE ABOUT HOT LAMP RESTART” on page 8.
HIGH-DEFINITION TELEVISION
Compatible with the new Toshiba
TM
Audio/Video Hard Drive Recorder!
See pages 23 and 50 for details.
U
S
M
N
E
O
R
C
A
C
I
R
E
M
A
A
B
I
H
S
O
T
I
S
O
1
4
0
P
R
O
D
U
C
T
S
,
L
.
L
.
C
.
5
4
6
9
0
A
.
1
o
N
F
E
I
L
Owner’s Record
46HM95
The model number and serial number are on the back of your TV. Record these numbers in the spaces below. Refer to these numbers whenever you communicate
52HM95
with your Toshiba dealer about this TV.
Model number:
62HM95
© 2005 TOSHIBA CORPORATION All Rights Reserved [A-PDFO]
HM95_R1_001_061505 6/24/05, 7:44 PM
Serial number:
23566650A
Dear Customer,
Thank you for purchasing this Toshiba TV. This manual will help you use the many exciting features of your new TV.
Before operating the TV, please read this manual completely, and keep it nearby for future reference.
Safety Precautions
WARNI NG: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING
RISK OF ELECTRIC SHOCK!
DO NOT OPEN.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER­SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
unit replacement and care" on pages 103-105 of this manual.)
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Lamp Unit Replacement
CAUTION: HOT SURFACE!
The temperature of the lamp immediately after use exceeds
392°F (200°C). Touching the lamp before it has cooled will result in severe burns. ALLOW THE LAMP TO COOL FOR AT LEAST ONE (1) HOUR BEFORE REPLACING IT.
The lamp in this product has a limited service life. The length of service life varies depending on product use and user settings. If you use the lamp beyond its service life:
you may notice a reduction in the colors and/or brightness of the picture, at which time you should replace the lamp unit; and
the strength of the quartz glass in the lamp will be reduced and the lamp may rupture. If the lamp ruptures, the TV will not åoperate until the lamp unit is replaced.
Dispose of the used lamp unit by the approved method for your area.
See “Lamp unit replacement and care”
on pages 103–105.
Note: The lamp unit contains mercury.
Disposal of mercury may be regulated due to environmental considerations. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance (www.eiae.org).
NOTE: NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
(This does not apply to "Lamp
NOTICE OF POSSIBLE TV STAND INSTABILITY
CAUTION: This television is for use only with the Toshiba stand listed below. Use with other
causing possible injury.
carts or stands is capable of resulting in instability
Television Stand Model 46HM95 ST4665 52HM95 ST5265 62HM95 ST6265
NOTE TO CATV INSTALLERS IN THE U.S.A.
This is a reminder to call the CATV system installers attention to Article 820-40 of the U.S. NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 27 and 28 on page 4.
Child Safety
It Makes A Difference Where Your TV Stands
Congratulations on your purchase! As you enjoy your new TV, keep these safety tips in mind:
The Issue
If you are like most consumers, you have a TV in your home. Many homes,
in fact, have more than one TV.
The home theater entertainment experience is a growing trend, and larger
TVs are popular purchases; however, they are not always supported on the proper TV stands.
Sometimes TVs are improperly secured or inappropriately
situated on dressers, bookcases, shelves, desks, audio speakers,
chests, or carts. As a result, TVs may fall over, causing
unnecessary injury.
Toshiba Cares!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
The Consumer Electronics Association formed the
Home Entertainment Support Safety Committee, comprised
of TV and consumer electronics furniture manufacturers, to
advocate childrens safety and educate consumers and their
families about television safety.
Tune Into Safety
One size does NOT fit all! Use appropriate furniture large enough to
support the weight of your TV (and other electronic components).
Use appropriate angle braces, straps, and anchors to secure your furniture
to the wall (but never screw anything directly into the TV).
Carefully read and understand the other enclosed instructions for proper
use of this product.
Do not allow children to climb on or play with furniture and TVs.Avoid placing any item on top of your TV (such as a VCR, remote control,
or toy) that a curious child may reach for.
Remember that children can become excited while watching a program
and can potentially push or pull a TV over.
Share our safety message about this hidden hazard of
your family and friends. Thank you!
2500 Wilson Blvd. Arlington, VA 22201 U.S.A. Tel. 703-907-7600 Fax 703-907-7690 www.CE.org
CEA is the Sponsor, Producer and Manager of the International CES
the home with
®
2
HM95_R1_002-04_061505 6/24/05, 7:45 PM2
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturers instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being
walked on or pinched, particularly at plugs, convenience receptacles, and the point where it exits the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14a) Item 14 does not apply to Lamp unit replacement and
care on pages 103-105 of this manual.
14b) CAUTION: If the TV is dropped and the cabinet or
enclosure surface has been damaged or the TV does not operate normally, take the following precautions:
ALWAYS turn off the TV and unplug the power cord to
avoid possible electric shock or fire.
To prevent personal injury, never handle the damaged
television.
ALWAYS contact a service technician to inspect the TV
any time it has been damaged or dropped.
Wide blade
16) WARNING: This product contains a lamp to project
the picture, and requires special safety precautions:
See pages 103–105 for instructions on lamp unit replacement and care.
DO NOT attempt to service this product except as specified on pages 103–105. The only user-
serviceable item in this product is the lamp unit.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and heed all warnings when installing your TV:
17) Never modify this equipment. Changes or modifications may void: a) the warranty, and b) the users authority to operate this equipment under the rules of the Federal Communications Commission.
18) DANGER: RISK OF SERIOUS PERSONAL
INJURY, DEATH, OR EQUIPMENT DAMAGE! Never place the TV on
an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.
19) Never place or store the TV in direct sunlight; hot, humid areas; areas subject to excessive dust or vibration; or locations with temperatures at or below 41°F (5°C).
20) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit.
21) Never expose the apparatus to dripping or splashing or place items such as vases, aquariums, any other item filled with liquid, or candles on top of the TV.
22) Always place the back of the television at least one (1) inch away from any vertical surface (such as a wall) to allow proper ventilation.
23) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:
on a bed, sofa, rug, or similar surface;
too close to drapes, curtains, or walls; or
in a confined space such as a bookcase, built-in cabinet,
or any other place with poor ventilation.
The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV.
24) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.
25) Never overload wall outlets and extension cords.
15) CAUTION: To reduce the risk of electric shock, do not
use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.
HM95_R1_002-04_061505 6/24/05, 7:45 PM3
26) Always operate this equipment from a 120 VAC, 60 Hz power source only.
(continued on next page)
3
Ground clamp
Antenna discharge unit (NEC Section 810-20)
Grounding conductors (NEC Section 810-21)
Power ser vice grounding electrode system (NEC Art 250 Par
Ground clamps
Antenna lead-in wire
Electric ser vice equipment
Installation
(continued from previous page)
Care
(continued from previous column)
27) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).
28) DANGER: RISK OF SERIOUS PERSONAL
INJURY OR DEATH!
Use extreme care to make sure you are never in
a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.
Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.
Care
33) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.
34
) During normal use, the TV may make occasional snapping
or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.
Special care for Texas Instruments Digital Light
35)
Processing™ (DLP) lamp units:
The lamp in this product has a limited service life. The length of service life varies depending on product use or user settings. If you use the lamp beyond its service life:
you may notice a reduction in the colors and/or
brightness of the picture, at which time you should replace the lamp unit; and
the strength of the quartz glass in the lamp will be
reduced and the lamp may rupture. If the lamp ruptures, the TV will not operate until the lamp unit is replaced.
See Lamp unit replacement and care on pages 103–105.
Dispose of the used lamp unit by the approved method for
your area.
The lamp unit contains mercury. Disposal of
information, please contact your local authorities or the Electronic Industries Alliance (www.eiae.org).
mercury may be regulated due to environmental considerations. For disposal or recycling
For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:
29) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen. Turn the TV off to check for reflections on the screen, and then remove the source of reflections while viewing the TV.
30) Always unplug the TV before cleaning. Never use liquid or aerosol cleaners. Clean only with a soft, dry cloth. Do not spray volatile compounds, such as insecticide, on the cabinet. This may discolor or damage the cabinet.
31) WARNING: RISK OF ELECTRIC SHOCK!
Never spill liquids or push objects of any kind into the TV cabinet slots.
32) If the air temperature rises suddenly (for example, when the TV is first delivered), condensation may form on the lenses. This can make the picture appear distorted or the color appear faded. If this happens, turn off the TV for 6 to 7 hours to allow the condensation to evaporate.
4
Service
36
) WARNING: RISK OF ELECTRIC SHOCK!
Never attempt to service the TV yourself,
except as specified on pages 103–105. Opening and removing the covers may expose you to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury. Refer all servicing not specified in this manual to a Toshiba Authorized Service Center.
37) If you have the TV serviced:
Ask the service technician to use only replacement parts
specified by the manufacturer.
Upon completion of service, ask the service technician to
perform routine safety checks to determine that the TV is in safe operating condition.
38) When the TV reaches the end of its useful life, ask a qualified service technician to properly dispose of the TV.
Note: The lamp unit contains mercury. Disposal of mercury may be regulated due to environmental considerations. Dispose of the used lamp unit by the approved method for your area. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance (www.eiae.org).
__________
Digital Light Processing, DLP™ and the DLP medallion are trademarks of Texas Instruments.
HM95_R1_002-04_061505 6/24/05, 7:45 PM4
Important notes about your DLPTM projection TV
1) The light source for this TV is a projection lamp unit with a limited service life. When the lamp wears out, the picture may become dark or black or the lamp may fail, at which time you must replace the lamp unit. See Lamp unit replacement and care on pages 103105.
2) If you set the lamp mode to Low Power, each time you turn on the TV, the lamp will start out in High Bright mode but will switch to Low Power mode in approximately 1 minute. You will notice a change in screen brightness when this happens. This is normal and is not a sign of malfunction. (See page 75 for details.)
3) Each time you turn on the TV, it may take several minutes for the picture to obtain full brightness.
4) This TVs display is manufactured using an extremely high level of precision technology; however, an occasional pixel (dot of light) may show constantly on the screen. This is a structural property of DLP (Digital Light Processing) technology in the TV and is not a sign of malfunction. Such pixels are not visible when the picture is viewed from a normal viewing distance (see item 29 on page 4).
5) Depending on the media you are viewing, it is possible, although unlikely, that a limited number of viewers may see a rainbow effect on the screen, which can, in rare instances, result in eye fatigue. This is a rare occurrence related to technology of this type and is not a sign of TV malfunction.
6) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture quality may be affected by your viewing position and length of viewing time. If you sit too closely to the TV for too long, you may suffer from eye fatigue. See item 29 on page 4.
7) This TV contains several cooling fans to moderate the
internal temperature. You may be able to hear the fans
for several minutes after the TV is turned off. This is a function of the Quick Restart feature and is not a sign of TV malfunction. You can set the Quick Restart feature to stop the fans as soon as the TV is turned off. See Setting the Quick Restart feature on page 51.
8) The green and red LED lights at the bottom center of the TV front indicate your TVs current status. If either light flashes, see LED indications on page 99 for details.
9) If you unplug the power cord, when you plug the power cord in again the message Now Booting…” will display on-screen until the picture appears, or the green LED will blink until the
TV enters standby mode (plugged in but not powered on). This is normal and is not a sign of malfunction.
10) When connecting an external A/V device, if you connect the
devices video output to the TV and the devices audio output to a separate audio system, the picture and sound may not synchronize completely.
11) When playing a video game on this TV, there may be a slight
delay between your command (e.g., joystick, keyboard) and the picture movement on the screen.
Contents
Important Safety Information ............................................. 2-4
Important notes about your DLP™ projection TV ............... 5
Chapter 1: Introduction .......................................................... 7
Welcome to Toshiba ........................................................... 7
Features of your new TV .................................................... 7
Overview of steps for installing, setting up, and
using your new TV ...................................................... 8
Chapter 2: Connecting your TV ............................................ 9
TV front touchpad and side panel controls
and connections ............................................................. 9
TV back panel connections ................................................ 10
Overview of cable types ...................................................... 11
About the connection illustrations ...................................... 12
Connecting a digital CableCARD Connecting a VCR and antenna or Cable TV
(no Cable box) ............................................................... 13
Connecting a camcorder ..................................................... 13
Connecting a VCR and Cable box ..................................... 14
Connecting a VCR and satellite receiver ............................. 15
Connecting a DVD player with S-video, a VCR,
and a Cable box .............................................................. 16
Connecting a DVD player with ColorStream
(component video) and a VCR ....................................... 17
Connecting two VCRs ....................................................... 18
Connecting an HDMI
or a DVI device to the
HDMI input .................................................................. 19
Connecting a digital audio system ...................................... 20
Connecting an analog audio system .................................... 20
.................................... 12
®
Controlling infrared remote-controlled devices
through the TV (IR pass-through).................................. 21
Connecting IEEE1394 video devices .................................. 22
Using analog-compatible IEEE1394 devices ................... 22
Supported signals ........................................................... 22
Using TheaterNet
on-screen device control .................. 22
Connecting an AVHD or D-VHS recorder .................... 23
IEEE1394 device initialization ....................................... 23
IEEE1394 device management ....................................... 24
®
G-LINK
connection ......................................................... 25
Chapter 3: Using the remote control ................................. 26
Learning about the remote control ..................................... 26
Installing the remote control batteries................................. 28
Using the remote control MODE button to control
your other devices........................................................... 28
Remote Control functional key chart ................................. 29
Programming the remote control to operate
your other devices........................................................... 31
Multi-brand remote control device codes............................ 33
Chapter 4: Menu layout and navigation ........................... 35
Main menu layout .............................................................. 35
Setup/Installation menu layout........................................... 36
Navigating the menu system............................................... 36
Chapter 5: TV Guide On Screen
Setting up the TV Guide On Screen TV Guide On Screen
®
Turning off the TV Guide On Screen
®
setup ............................. 37
®
system ..................... 37
Reminder ....................................... 40
®
automatic display feature ................................................ 40
(Continued on next page)
HM95_R1_005-06_061505 6/24/05, 7:48 PM5
5
Contents
(Continued from previous page)
Chapter 6: Setting up your TV ............................................. 41
Selecting the menu language............................................... 41
Configuring the antenna input sources ............................... 41
Programming channels into the TVs channel memory ....... 42
Programming channels automatically .......................... 42
Manually adding and deleting channels in the
channel memory ..................................................... 43
Programming your favorite channels .................................. 44
Setting up and using TheaterNet
on-screen
device control ................................................................. 45
Setting up TheaterNet ................................................. 45
Using the TheaterNet control icons............................. 46
TheaterNet IR device codes .................................. 47–49
Setting the AVHD device skip time .................................... 50
Setting the HDMI
Setting the time and date .................................................... 50
Viewing the CableCARD
audio mode ........................................ 50
menu ...................................... 51
Setting the Quick Restart feature ........................................ 51
Viewing the digital signal meter ......................................... 52
Viewing the system status ................................................... 52
Chapter 7: Using the TV Guide On Screen
interactive program guide ............................................... 53
Setting up the TV Guide On Screen Navigating the TV Guide On Screen
TV Guide On Screen
®
remote control functions ......... 54
®
®
system ..................... 53
®
system..................... 54
Video Window ........................................................... 55
Panel Menus ............................................................... 55
Info Box ...................................................................... 56
TV Guide On Screen
TV Guide On Screen
®
Icons ....................................... 56
®
Services .......................................... 57
LISTINGS screen ....................................................... 57
SEARCH screen.......................................................... 58
RECORDINGS screen ............................................... 60
SCHEDULE screen .................................................... 61
Record features ........................................................... 61
Remind features .......................................................... 63
SETUP screen ............................................................. 65
Change system settings .......................................... 65
Change channel display ......................................... 65
Change default options .......................................... 66
Chapter 8: Using the TV’s features .....................................67
Selecting the video input source to view ............................. 67
Labeling the video input sources ......................................... 68
Tuning channels ................................................................. 69
Using the channel browser .......................................... 69
Tuning your favorite channels ..................................... 71
Tuning to the next programmed channel .................... 71
Tuning to a specific channel (programmed or
unprogrammed) ...................................................... 71
Switching between two channels using
Channel Return ...................................................... 71
Switching between two channels using SurfLock
............................................................... 71
Selecting the picture size ..................................................... 72
Natural picture size ..................................................... 72
TheaterWide 1 picture size.......................................... 73
TheaterWide 2 picture size.......................................... 73
TheaterWide 3 picture size.......................................... 73
Full picture size ........................................................... 73
Scrolling the TheaterWide
®
picture .................................... 74
Using the auto aspect ratio feature ...................................... 74
Selecting the cinema mode (480i signals only) .................... 75
Selecting the lamp mode .................................................... 75
Using the POP features ...................................................... 76
Using the POP double-window feature ....................... 76
Switching the speaker audio (main or POP) ................ 77
POP double-window aspect ratio ................................ 77
Using the FREEZE feature ................................................. 78
Using the favorite channel scan feature ............................... 78
Adjusting the picture .......................................................... 79
Selecting the picture mode .......................................... 79
Adjusting the picture quality ....................................... 79
Using CableClear
®
DNR (digital noise reduction) ...... 80
Selecting the color temperature ................................... 80
Using MPEG Noise Reduction ................................... 81
Using Dynamic Contrast ............................................ 81
Using the closed caption mode ........................................... 82
Advanced closed captions ............................................ 82
Digital closed captions ................................................ 83
Adjusting the audio ............................................................ 84
Muting the sound ....................................................... 84
Using the digital audio selector ................................... 84
Selecting stereo/SAP broadcasts................................... 84
Adjusting the audio quality ......................................... 85
Using the sub-bass system (SBS) ................................. 85
Using the StableSound Using the SRS WOW
®
feature ................................... 85
surround sound feature .......... 86
Turning off the built-in speakers ................................. 86
Selecting the optical audio output format ................... 86
Using the memory card JPEG picture viewer/MP3 audio
player ............................................................................. 87
Memory card specifications ......................................... 87
Using the JPEG picture viewer.................................... 88
Using the MP3 audio player ....................................... 89
Memory card care and handling .................................. 90
Setting the ON/OFF timer ................................................ 91
Setting the sleep timer ........................................................ 91
Displaying the channel banner ........................................... 92
Understanding the auto power off feature........................... 92
Understanding the last mode memory feature .................... 92
Using the gray level feature ................................................. 92
Chapter 9: Using the Locks menu ...................................... 93
Entering the PIN code ....................................................... 93
If you cannot remember your PIN code ............................. 93
Changing your PIN code ................................................... 93
Blocking TV programs and movies by rating (V-Chip) ......... 94
Blocking channels............................................................... 95
Unlocking programs temporarily ........................................ 95
Locking video inputs .......................................................... 95
Using the GameTimer
..................................................... 96
Using the front panel lock feature....................................... 96
Chapter 10: Troubleshooting ................................................ 97
General troubleshooting ..................................................... 97
LED indications ................................................................. 99
TV Guide On Screen
®
FAQs.................................... 100102
Chapter 11: Appendix ......................................................... 103
Lamp unit replacement ............................................ 103–105
Specifications ................................................................... 106
Limited United States Warranty ....................................... 107
Index .............................................................................. 110, 111
6
HM95_R1_005-06_061505 6/24/05, 7:48 PM6
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
1
Introduction
Welcome to Toshiba
Thank you for purchasing this Toshiba TV, one of the most innovative DLP™ projection TVs on the market. The goal of this manual is to guide you through setting up and operating your TV as quickly as possible.
See “Important notes about your
projection TV” on page 5.
DLP
• This manual applies to models 46HM95, 52HM95, and 62HM95. Before you start reading, check the model number on the back of your TV.
• Instructions in this manual are based on using the remote control. You also can use the controls on the TV front touchpad if they have the same name as those referred to on the remote control. (MENU on the front touchpad functions as ENTER when a menu is on-screen or when the TV Guide On Screen
®
system is open.)
• The side panel and back panel provide terminals for connecting other equipment to your TV. See page 9 for front touchpad and side panel details. See page 10 for back panel details. See pages 12–25 for instructions on connecting other devices to your TV.
Please read all safety and operating instructions in this manual carefully, and keep this manual for future reference.
Features of your new TV
The following are just a few of the many exciting features of your new Toshiba widescreen, integrated HD DLP™ projection TV:
Integrated digital tuning (8VSB ATSC and QAM)
TV Guide On Screen
Digital CableCARD™ slot
Digital recording
®
no-fee interactive program guide (Chapters 5 and 7).
for viewing encrypted digital Cable TV programs (page 12).
by connecting a D-VHS digital recording device or a Toshiba Symbio™ Audio/Video Hard Drive Recorder to
one of the IEEE1394 jacks. You can record high definition and standard definition material from either tuner (page 23).
eliminates the need for a separate digital converter set-top box (in most cases).
Memory card slots
[SD Memory Card, MultiMediaCard, MemoryStick, CompactFlash, xD-PictureCard™] for viewing JPEG files
as a “slide show” (page 88) and for playing MP3 files (page 89).
TheaterNet™
Two IEEE1394 ports
Two HDMI (DVI)
Two sets of ColorStream® HD
Dolby Digital*
Digital Audio Out
CableClear® DNR
• Double-window
______________ In the United States, TV Guide and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates. The TV Guide On Screen system is manufactured under license from Gemstar-TV Guide International, Inc. and/or one of its affiliates. The TV Guide On Screen system is protected by one or more of the following issued United States patents 6,498,895; 6,418,556; 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121.
GEMSTAR-TV GUIDE INTERNATIONAL INC. AND/OR ITS RELATED AFFILIATES ARE NOT IN ANY WAY LIABLE FOR THE ACCURACY OR AVAILABILITY OF THE PROGRAM SCHEDULE INFORMATION OR OTHER DATA IN THE TV GUIDE ON SCRE EN SYSTEM AND CANNOT GUARANTEE SERVICE AVAILABILITY IN YOUR AREA. IN NO EVENT SHALL GEMSTAR-TV GUIDE INTERNATIONAL, INC. AND/OR ITS RELATED AFFILIATES BE LIABLE FOR ANY DAMAGES IN CONNECTION WITH THE ACCURACY OR AVAILABILITY OF THE PROGRAM SCHEDULE IN FORMATION OR OTHER DATA IN THE TV GUI DE ON SCREEN SYSTEM.
• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision and is intended for home and other limited pay-per-view uses only, unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
icons for on-screen control of external IR and
IEEE1394
for multi-device connection and control (page 22).
digital, high-definition multimedia interfaces (page 19).
high-resolution component video inputs (pages 15 and 17).
(page 20) and
SRS WOW™
(page 86) audio technologies.
optical audio connection (page 20).
digital picture noise reduction (page 80).
POP
(page 76) and multi-window
Favorites
(page 78) features.
devices (page 45).
Note: After you set up the TV Guide
On Screen
automatically by default when you turn on the TV. You can turn off the automatic program guide (page
40) and instead press the TV GUIDE button on the remote control to
manually open the program guide.
®
system (Chapter 5),
the program guide opens
HM95_R1_007-08_061505 6/24/05, 8:46 PM7
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
7
Chapter 1: Introduction
Overview of steps for installing, setting up, and using your new TV
Follow these steps to set up your TV and begin using its many exciting features.
1. Carefully read the important safety, installation, care, and service information on pages 2–5. Keep this manual for future reference.
2. Observe the following when choosing a location for the TV:
Place the TV on the floor or on the optional TV stand listed in
the “Specifications” section (page 106).
NOTICE OF POSSIBLE TV STAND INSTABILITY
DANGER: RISK OF SERIOUS PERSONAL INJURY OR DEATH! Use this TV only with the TOSHIBA TV
stand listed in the “Specifications” section (page 106). Use with other stands may result in instability, causing possible injury or death.
• Place the TV in a location where light does not reflect on the
screen.
• Place the TV far enough from walls and other objects to allow
proper ventilation. Inadequate ventilation may cause overheating, which will damage the TV. THIS TYPE OF
DAMAGE IS NOT COVERED UNDER THE TOSHIBA WAR RANTY.
• Read “Installation” on pages 3–4.
• Read “Important notes about your DLP™ TV” on page 5.
3. Do not plug in any power cords until AFTER you have connected all cables and devices to your TV.
4. BEFORE connecting cables or devices to the TV, learn the functions of the TV’s connections and controls (pages 9 and 10).
5. Connect your other electronic device(s) to the TV (pages 12–25).
®
6. Connect the G-LINK blaster cables) from your VCR and/or Cable box (if applicable) to the G-LINK
®
terminal so you can use the TV Guide On Screen
features (applies to VCRs and cable boxes only). See page 25.
7. Install the batteries in the remote control (page 28).
cable (either one of the enclosed IR
8. See “Learning about the remote control” (page 26) for
an overview of the buttons on the remote control.
9. Program the remote control to operate your other device(s) (pages 28–34).
10. AFTER connecting all cables and devices, plug in the power cords for your TV and other devices.
11. After you plug in the TV power cord, the green LED (on the TV front touchpad, to the left of the POWER button) will blink while the TV is booting until the remote control is usable. When the green LED stops blinking, press POWER to turn on the TV.
See “LED indications” on page 99.
12. See “Menu layout and navigation” for a quick overview of navigating the TV’s menu system (pages 35–36).
13. See Chapter 5 for details on setting up the TV Guide On Screen
14. See Chapter 7 for details on using the TV Guide On Screen
®
system (if available in your area).
®
program guide (if available in your area).
15. Program channels into the TV’s channel memory (page 42).
16. Set up the TheaterNet™ on-screen device control feature (if applicable to your particular home theater system components) (page 45).
17. For details on using the memory card JPEG picture
viewer and MP3 audio player, see page 87.
18. For details on using the TV’s features, see Chapter 8.
19. For help, refer to the Troubleshooting Guide (Chapter
10).
®
20. For technical specifications and warranty information,
see Chapter 11.
21. Enjoy your new TV!
When the TV has been powered on long enough for the lamp unit to get hot, it may take several minutes for the picture to appear on-screen in the following situations:
When the Quick Restart feature is set to OFF and you turn the TV off and then on again within a few minutes.
If the TV is on when a short-term power failure, power surge, or other similar power failure occurs, such that the TV loses and regains
power within a few minutes.
If this occurs, the green LED on the TV front panel will blink (and the red LED will be lit solid) until the TV is finished restarting the lamp and the normal picture appears. If BOTH green and red LEDs are blinking at a one-second rate, you will need to turn the TV off and then on again to restart the lamp.
8
HM95_R1_007-08_061505 6/24/05, 8:46 PM8
IMPORTANT NOTICE ABOUT HOT LAMP RESTART
This is a property of DLP TV lamp technology and is NOT a sign of malfunction.
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
2
Connecting your TV
TV front touchpad and side panel controls and connections
Front of TV
MENUVOLUMECHANNELEXITTV/VIDEO POWER
Remote sensor
1
Front touchpad*
EXIT
GUIDE
9
*Gently touch the printed keys on the touchpad. **The MENU button on the TV front touchpad functions as the
ENTER button when a menu is on-screen.
3
TV/VIDEO
2
Channel
zyx
4
zy7Volume
8
MENU (ENTER)**
5
x
Green/Red LEDs
0
POWER
6
Side of TV
Side panel
{
VIDEO-3 IN
Memory card
{
slots
!™
1
Remote sensor
control toward this area of the TV screen. See “Remote control effective range” on page 27.
2
TV/VIDEO
viewing (ANT 1, ANT 2, VIDEO 1, VIDEO 2, VIDEO 3, HDMI 1, HDMI 2, ColorStream HD1, ColorStream HD2).
3
EXIT
— Press to close an on-screen menu instantly.
4
ARROWS
buttons function as up/down/left/right menu navigation buttons.
MENU (ENTER)
5
page 35). When a menu is on-screen or the TV Guide On Screen the front touchpad functions as the ENTER button.
6
POWER
7
CHANNEL
buttons change the channel (programmed channels only; see page 42). When a menu is on-screen, these buttons function as up/down menu navigation buttons.
— Press to turn the TV on and off.
Note: If the TV stops responding to the controls on the remote control or TV front panel and you cannot turn off the TV, press and hold the POWER button on the TV front panel for 5 or more seconds to reset the TV.
(behind the screen) — Point the remote
— Repeatedly press to change the source you are
yzx — When a menu is on-screen, these
— Press to access the menu system (see
®
program guide is open, the MENU button on
yz — When no menu is on-screen, these
8
VOLUME
buttons adjust the volume level. When a menu is on-screen, these buttons function as left/right menu navigation buttons.
9
GUIDE
program guide. (See page 53 for details on using the program guide.)
Green and Red LEDs
0
When the green LED lights solid (not blinking), it indicates that recording is in progress.
When the red LED lights solid (not blinking), it indicates that the TV power cord is plugged in.
See “LED indications” on page 99 for additional information.
VIDEO-3
as “VIDEO 3” and include standard A/V connections plus optional S-video. (The VIDEO 1 and VIDEO 2 A/V connections are on the TV’s back panel; see page 10.
!™
Memory card slots
the memory card slots to view JPEG files (such as photos) as a “slide show” on your TV or listen to MP3 audio files (see page 87).
x — When no menu is on-screen, these
— Press to access the TV Guide On Screen
— The side panel A/V connections are referred to
— Insert a memory card into one of
®
HM95_R2_009-11_061505 6/27/05, 6:44 PM9
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
9
Chapter 2: Connecting your TV
TV back panel connections
For an explanation of cable types, see page 11.
OUT
1 ANT-1 (CABLE) IN and ANT-2 IN — Two inputs that
support analog (NTSC) and digital (ATSC) off-air antenna signals and analog and digital (QAM) Cable TV signals.
Note: If you have an antenna only, connect it to ANT-1. If you have both cable TV and an antenna, connect the cable TV to ANT-1 and the antenna to ANT-2.
2 VIDEO 1 IN and VIDEO 2 IN — Two sets of standard
(composite) video and standard audio inputs plus optional S-video inputs for connecting devices with composite video or S-video output.
NOTE: Standard (composite) video and S-video cables carry only video information; separate audio cables are required for a complete connection.
3 ColorStream® HD-1 and ColorStream® HD-2 — Two sets
of ColorStream standard stereo audio inputs for connecting devices with component video output, such as a Toshiba DVD player with ColorStream
Note: Component video cables carry only video information; separate audio cables are required for a complete connection.
4 A/V OUT — Standard composite video and analog audio
outputs for connecting a VCR for editing and dubbing. See page 18 for details.
5 Variable Audio OUT — Standard analog audio outputs for
connecting an analog amplifier with external speakers. See page 20.
6 Digital Audio OUT — Optical audio output in Dolby
Digital or PCM (pulse-code modulation) format for connecting an external Dolby Digital decoder, amplifier, A/V receiver, or home theater system with optical audio input. See page 20.
7 G-LINK
G-LINK recording features. See page 25.
®
high-definition component video and
®
. See pages 15 and 17.
®
— For use with one of the enclosed IR blaster/
®
cables to enable the TV Guide On Screen
23549
®
8
}
}
OUT
{
1
8 TheaterNet
remote-controlled devices through the TV. You can connect up to two devices with either one of the enclosed IR blaster cables, and then control the devices using the TV’s IR pass­through or TheaterNet See pages 21 and 45.
9 Standard Audio IN — For use when connecting a DVI
device with analog audio output to one of the HDMI inputs. See page 19. Also see item 10 below.
0 (2) HDMI
Multimedia Interface inputs receive digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device. See page 19.
NOTE: NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC). This TV is not intended for use with a PC.
(2) IEEE1394 — Two bi-directional digital IEEE1394
ports for connecting multiple devices with compressed digital video. Because these ports are bi-directional, they can be used for playback and recording. You can control your IEEE1394 devices using the TV’s TheaterNet on-screen device control icons. See pages 21–24 and 46.
NOTE:
IEEE1394 cable carries both audio and video information;
separate audio cables are not required.
• NEVER CONNECT THIS TV TO A PERSONAL
COMPUTER (PC). This TV is not intended for use with a PC.
!™ CableCARD™ slot — For use with a digital security card
and digital cable TV service (provided by your local cable operator) to view encrypted digital programming. See pages 12 and 51.
___________
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
CableCARD™ is a trademark of Cable Television Laboratories, Inc.
07 6 !™
(IR) OUT — For controlling infrared
(on-screen device control) features.
IN 1 and 2 — Two High-Definition
10
HM95_R2_009-11_061505 6/27/05, 6:44 PM10
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Chapter 2: Connecting your TV
Overview of cable types
NOTE: NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
Note: Two dual-wand IR blaster/G-LINK® cables are included with your TV. All other required cables, if not provided with your other devices, can be purchased at many electronics accessory suppliers.
Coaxial (F-type) cable is used for connecting your antenna, cable TV service, and/or cable converter box to the ANT-1 and/or ANT-2 RF inputs on your TV.
Standard A/V cables (composite video) usually come in sets of three, and are for use with video devices with standard audio and standard (composite) video output. These cables (and the related inputs on your TV) are typically color-coded according to use: yellow for video, red for stereo right audio, and white for stereo left (or mono) audio.
S-video cable is for use with video devices with S-video output. Separate audio cables are required for a complete connection.
Note: An S-video cable provides better picture performance than a composite video cable. If you connect an S-video cable, be sure to disconnect the standard (composite) video cable or the picture performance will be unacceptable.
Component video cables come in sets of three and are for use with video devices with component video output. (ColorStream These cables are typically color-coded red, green, and blue. Separate audio cables are required for a complete connection.
Note: Component video cables provide better picture performance than a standard (composite) video or S-video cable.
HDMI cable is for use with devices with HDMI (High-Definition Multimedia Interface) output. HDMI cable delivers digital audio and video in its native format. This cable carries both video and audio information; therefore, separate audio cables are not required for a complete HDMI device connection. See page 19 for further details.
Note: HDMI cable provides better picture performance than a standard (composite) video or S-video cable.
IEEE1394 cable is for use with video devices with compressed digital video output that meet CEA specifications for IEEE1394. This cable carries both video and audio information; therefore, no separate audio cables are required for a complete connection. See pages 22–24.
Note:
The transmission capability of IEEE1394 cable used with this TV must be S400 (400 Mbps maximum).
IEEE1394 cable provides better picture performance than a standard (composite) video or S-video cable.
Dual-wand IR blaster/G-LINK® cable is for use with video devices with IR (infrared) remote control. Two of these cables are included with your TV. One is for connection to the G-LINK (Chapters 5 and 7). The other can be used with the TV’s IR pass-through feature (page
21) and TheaterNet
Note: The two IR blaster/G-LINK® cables included with your TV have specific characteristics that allow them to work properly with this TVs IR OUT and G-LINK
aftermarket IR blaster or G-LINK
properly and can cause damage. THIS TYPE OF DAMAGE IS NOT COVERED BY YOUR TOSHIBA WARRANTY.
Optical audio cable is for connecting receivers with Dolby Digital or PCM
®
terminal (page 25) to enable TV Guide On Screen® recording features
on-screen device control feature (page 45).
(pulse-code modulation) optical audio input to the TV’s DIGITAL AUDIO OUT terminal. See page 20.
®
is Toshiba’s brand of component video.)
®
®
cables with this TV. Other cables may not function
ports. Never use other
Coaxial (F-type) cable
Standard A/V cables (red/white/yellow)
S-video cable
Component video cables (red/green/blue)
HDMI cable
IEEE1394 cable (4-pin)
Dual-wand IR blaster/G-LINK® cable (2 included)
Optical audio cable
Note: Although your TV includes both HDMI and IEEE1394 connections, it may not operate with another device you have that includes such a connection. For example, the IEEE1394 ports are not intended to operate with current model Mini DV camcorders, and the HDMI input is not intended for connection to a computer. Copyright protection requirements may also prohibit or limit connectivity. See page 19 for details about the HDMI input. See pages 22–24 for details about the IEEE1394 ports.
HM95_R2_009-11_061505 6/27/05, 6:44 PM11
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
11
Chapter 2: Connecting your TV
About the connection illustrations
You can connect different types and brands of devices to your TV in several different configurations. The connection illustrations in this manual are representative of typical device connections only. The input/output terminals on your devices may differ from those illustrated herein. For details on connecting and using your specific devices, refer to each device’s owner’s manual.
Connecting a digital CableCARD™
This digital television is capable of receiving analog basic, digital basic, and digital premium cable television programming by direct connection to a cable system providing such programming.
A security card (such as a digital CableCARD™), provided by your cable operator, is required to view encrypted digital programming.
Certain advanced and interactive digital cable services (such as video-on-demand, a cable operator’s enhanced program guide, and data-enhanced television services) will not work with the use of a CableCARD
and may require the use of a separate set-
top box from your cable operator. For more information, call your local cable operator.
You will need:
one digital CableCARD
(contact your cable operator)
digital cable subscription service (contact your cable
operator)
TV back panel
OUT
To view encrypted digital channels:
1. Connect your digital Cable TV cable to ANT-1.
2. With the front of the CableCARD the CableCARD
slot on the back of the TV (see
facing up, insert it into
illustration below left).
3. After the CableCARD appears in the Applications menu, with informational screens provided by your digital CableCARD
is inserted, a CableCARD™ option
service. See
page 51 for additional information.
CableCard Connected -- Acquiring channel information.
CableCard services will only operate with cable signal connected to Antenna 1.
Note:
• Always use the EJECT button to remove the CableCARD™. Never
remove the CableCARD™ carelessly.
• Never insert any object or card (including, without limitation, a
PCMCIA card) other than a CableCARD™ into the CableCARD™ slot.
• Always make sure the CableCARD™ is facing the correct direction.
• Connect the cable for your digital cable TV service to ANT-1 only.
• When using a CableCARD™, channel programming is unnecessary
because the CableCARD™ automatically loads the cable channel list into the TV’s channel memory (page 42).
• The CableCARD™ may take up to 5 minutes to “pair” with the TV
and download channel information. CableCARD™ information and channels will not be available until this process is completed.
Applications
TV Guide On Screen
Audio Player
Picture Viewer
Digital CC/Audio Selector
CableCARD
Navigate
IP Service
Conditional Access
CableCARD(tm) Status
Network Setup
CableCARD(tm) Pairing
Back Exit
CH RTN
Select
EXIT
From digital Cable service (connect to ANT 1 only)
This cable should be connected to ANT 1 terminal directly. If you connect the cable via a VCR, the TV may not receive the signals correctly.
________
CableCARD is a trademark of Cable Television Laboratories, Inc.
12
HM95_R1_012-25_061505 6/24/05, 9:12 PM12
CableCARD™ technology, like all new and emerging technology, may from time to time experience compatibility issues due to the different ways in which television manufacturers and cable system operators implement the CableCARD™ specifications. Most issues can be easily resolved. If you experience any performance-related CableCARD™ issues with your Toshiba television, please contact Toshiba Consumer Solutions by calling (800) 631-3811 or by visiting
http://www.tacp.com/customersupport/contact.asp.
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Chapter 2: Connecting your TV
Connecting a VCR and antenna or Cable TV (no Cable box)
You will need:
one signal splitterthree coaxial cablestwo sets of standard A/V cables
• For better picture performance, if your VCR has S-video, use an S-video cable (plus the audio cables) instead of the standard video cable. However, do not connect both types of video cables to VIDEO 1 (or VIDEO 2) at the same time or the picture performance will be unacceptable.
• If you have a mono VCR, connect L/MONO on the TV to your VCR’s audio out terminal using the white audio cable only.
To view the antenna or Cable signal:
Select the ANT 1 video input source on the TV.*
To view the VCR:
Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*
To use the TV Guide On Screen® recording features:
1. Connect the G-LINK
®
cable according to the instructions
on page 25.
2. Make sure the VCR is connected to the A/V OUT terminals on the TV (see illustration).
3. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details), and then turn OFF the VCR.
4. See Chapter 5 for details on setting up the TV Guide On Screen
5. See Chapter 7 for details on using the TV Guide On Screen
®
system.
®
system.
From Cable TV or antenna
Signal splitter
OUT
IN
OUT
Stereo VCR
VIDEO AUDIO
IN from ANT
OUT to TV
CH 3 CH 4
LR
OUT
LR
IN
TV
OUT
Note: The VIDEO/AUDIO OUT terminals output signals from the ANT 1, ANT 2, VIDEO 1, VIDEO 2, and VIDEO 3 terminals when the appropriate input mode is selected.
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
Connecting a camcorder
You will need:
one set of standard A/V cables
• For better picture performance, if your camcorder has S-video, use an S-video cable (plus the audio cables) instead of the standard video cable. Do not connect both an S-video cable and a standard video cable to VIDEO 3 at the same time or the picture performance will be unacceptable.
To view the camcorder video:
Select the VIDEO 3 video input source on the TV.*
______________
* To select the video input source, press INPUT on the remote control (see page 67).
To program the TV remote control to operate other devices, see Chapter 3.
HM95_R1_012-25_061505 6/24/05, 9:12 PM13
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Camcorder
VIDEO
AUDIO
OUT
L
R
VIDEO 3 inputs on TV right side panel
13
Chapter 2: Connecting your TV
Connecting a VCR and Cable box
You will need:
one signal splitterfive coaxial cablestwo sets of standard A/V cables
• For better picture performance from your VCR: If your VCR has S-video, connect an S-video cable (plus the audio cables) instead of the standard video cable. Do not connect an S-video cable and a standard video cable to VIDEO 1 (or VIDEO 2) at the same time or the picture performance will be unacceptable.
• If you have a mono VCR, connect L/MONO on the TV to your VCR’s audio out terminal using the white audio cable only.
• When you use a Cable box, you may not be able to use the remote control to program or access certain features on the TV.
To view basic Cable channels and use the TV’s features:
Select the ANT 1 video input source on the TV.* Use the TV controls (front panel or remote control) to change channels and access the TV’s features.
To view basic and premium Cable channels:
Turn OFF the VCR. Select the ANT 2 video input source on the TV.* Tune the TV to channel 3 or 4 (whichever channel the Cable box output is set to). Use the Cable box controls to change channels.
Cable box Signal splitter
OUT
CH 3 CH 4
IN
OUT
OUT
Stereo VCR
IN from ANT
OUT to TV
CH 3 CH 4
VIDEO AUDIO
TV
From Cable TV
IN
LR
IN
OUT
LR
OUT
To view the VCR:
Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*
Note: A VIDEO 1 connection with an S-Video cable (instead of a standard video cable) will provide better picture performance (as mentioned in the first bulleted item at the top of this page).
_____________
Note: The VIDEO/AUDIO OUT terminals output signals from the ANT 1, ANT 2, VIDEO 1, VIDEO 2, and VIDEO 3 terminals when the appropriate input mode is selected.
* To select the video input source, press INPUT on the remote control
(see page 67). To program the TV remote control to operate other devices, see Chapter 3.
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
To enable the TV Guide On Screen® system to work
with your cable box and to use the TV Guide On Screen
1. Connect the G-LINK
®
recording features:
®
cable according to the instructions
on page 25.
2. Make sure the VCR is connected to the A/V OUT terminals on the TV (see illustration).
3. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details), and then turn OFF the VCR.
4. See Chapter 5 for details on setting up the TV Guide On Screen
®
system.
5. See Chapter 7 for details on using the TV Guide On Screen
®
system.
14
HM95_R1_012-25_061505 6/24/05, 9:12 PM14
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Chapter 2: Connecting your TV
Connecting a VCR and satellite receiver
You will need:
one signal splitterfour coaxial cablesone set of component video cables (if your
satellite receiver does not have component video, connect the standard A/V cables only)
one pair of standard audio cablestwo sets of standard A/V cables
• For better picture performance, if your satellite receiver and VCR have S-video, connect S-video cables (plus the audio cables) instead of the standard video cables. Do not connect both types of video cable to VIDEO 1 (or VIDEO 2) at the same time or the picture performance will be unacceptable.
• If you have a mono VCR, connect L/MONO on the TV (VIDEO 1) to your VCR’s AUDIO OUT terminal using the white audio cable only.
To view satellite programs using the component video
connections:
Select the ColorStream HD-1 video input source on the TV.*
To view satellite programs using the standard
video connections or to record satellite programs:
Turn on all three devices. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details). Select the VIDEO 2 video input source on the TV.*
From antenna
Signal splitter
OUT
OUT
IN from ANT
OUT to TV
TV
From satellite dish
S-VIDEO
OUT
Y
COMPONENT VIDEO
Satellite
IN
IN
Stereo VCR
CH 3 CH 4
PBP
R
VIDEO AUDIO
OUT
Satellite receiver
VIDEO
OUT
LR
OUT
LR
AUDIO
OUT
LRL
R
IN
To view the VCR or view and record antenna channels:
Turn ON the VCR. Tune the VCR to the channel you want to watch. Select the VIDEO 1 video input source on the TV.*
Note: The VIDEO/AUDIO OUT terminals output signals from the ANT 1, ANT 2, VIDEO 1, VIDEO 2, and VIDEO 3 terminals when the appropriate input mode is selected.
_____________
* To select the video input source, press INPUT on the remote control
(see page 67). To program the TV remote control to operate other devices, see Chapter 3.
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
To use the TV Guide On Screen® recording features:
1. Connect the G-LINK
®
cable according to the instructions
on page 25.
2. Make sure the VCR is connected to the A/V OUT terminals on the TV (see illustration).
3. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details), and then turn OFF the VCR.
4. See Chapter 5 for details on setting up the TV Guide On Screen
5. See Chapter 7 for details on using the TV Guide On Screen
Note: The TV Guide On Screen® system does not receive program listings from or for any satellite service.
®
system.
®
system.
HM95_R1_012-25_061505 6/24/05, 9:12 PM15
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
15
Chapter 2: Connecting your TV
OUT
Connecting a DVD player with S-video, a VCR, and a Cable box
You will need:
one signal splitterfive coaxial cablestwo sets of standard A/V cables
Note: If you have a mono VCR, connect L/MONO on the TV (VIDEO 1) to your VCR’s audio out terminal using the white audio cable only.
one S-video cableone pair of standard audio cables
Note:
• If your DVD player does not have S-video, use a standard video cable instead. Do not connect an S-video cable and a standard video cable to VIDEO 1 (or VIDEO 2) at the same time or the picture performance will be unacceptable.
• If your DVD player has component video, see page 17.
• Do not connect the DVD player and VCR to the same set of A/V inputs on the TV. (See the illustration, which shows the VCR connected to VIDEO 1 on the TV, and the DVD player connected to VIDEO 2.)
To view basic channels and access the TV’s features:
Select the ANT 1 video input source.* Use the TV controls to change channels and access the TV’s features.
To view premium Cable channels:
Turn OFF the VCR. Select the ANT 2 video input source on the TV.* Tune the TV to channel 3 or 4 (whichever channel the Cable box output is set to). Use the Cable box controls to change channels.
Note: When you use a Cable box, you may not be able to use the remote control to program or access certain features on the TV.
From antenna or Cable TV
Cable box
OUT
CH 3 CH 4
IN
Signal splitter
OUT
IN
OUT
Stereo VCR
IN from ANT
OUT to TV
CH 3 CH 4
VIDEO AUDIO
R
L
IN
OUT
L
R
TV
AUDIO
OUT
S-VIDEO
OUT
VIDEO
OUT
L
R
DVD player with S-video
Note: The VIDEO/AUDIO OUT terminals output signals from the ANT 1, ANT 2, VIDEO 1, VIDEO 2, and VIDEO 3 terminals when the appropriate input mode is selected.
To view the DVD player:
Turn ON the DVD player. Select the VIDEO 2 video input source on the TV.*
To view the VCR:
Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*
_____________
* To select the video input source, press INPUT on the remote control
(see page 67). To program the TV remote control to operate other devices, see Chapter 3.
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
16
HM95_R1_012-25_061505 6/24/05, 9:12 PM16
To enable the TV Guide On Screen® system to work with
your cable box and to use the TV Guide On Screen recording features:
1. Connect the G-LINK page 25.
2. Make sure the VCR is connected to the A/V OUT terminals on the TV (see illustration).
3. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details), and then turn OFF the VCR.
4. See Chapter 5 for details on setting up the TV Guide
®
On Screen
system.
5. See Chapter 7 for details on using the TV Guide On Screen system.
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
®
®
cable according to the instructions on
®
Chapter 2: Connecting your TV
Connecting a DVD player with ColorStream® (component video) and a VCR
Your TV has ColorStream® (component video) inputs.
You will need:
one signal splitterthree coaxial cablestwo sets of standard A/V cables
• For better picture performance, if your VCR has S-video, use an S-video cable (plus the audio cables) instead of the standard video cable. However, do not connect both types of video cable to VIDEO 1 (or VIDEO 2) at the same time or the picture performance will be unacceptable.
• If you have a mono VCR, connect L/MONO on the TV (VIDEO 1) to your VCR’s audio out terminal using the white audio cable only.
one pair of standard audio cablesone set of component video cables
• You can connect the component video cables (plus audio cables) from the DVD player to either set of ColorStream terminals on the TV (HD-1 or HD-2). The ColorStream HD-1 and HD-2 terminals can be used with Progressive (480p, 720p) and Interlaced (480i, 1080i) scan systems. A 1080i signal will provide the best picture performance.
• If your DVD player does not have component video, see page
16. If your DVD player has HDMI video, see page 19.
To view antenna or Cable channels:
Select the ANT 1 video input source on the TV.*
To view the DVD player:
Turn ON the DVD player. Select the ColorStream HD-1 video input source on the TV.*
To view the VCR:
Turn ON the VCR. Select the VIDEO 1 video input source on the TV.*
From antenna or Cable
Signal splitter
OUT
IN
OUT
Stereo VCR
VIDEO AUDIO
IN from ANT
OUT to TV
CH 3 CH 4
LR
OUT
LR
IN
TV
OUT
AUDIO
OUT
L
R
S-VIDEO
OUT
Y
PB PR
COMPONENT VIDEO
VIDEO
OUT
DVD player with component video
Note: The VIDEO/AUDIO OUT terminals output signals from the ANT 1, ANT 2, VIDEO 1, VIDEO 2, and VIDEO 3 terminals when the appropriate input mode is selected.
To record a TV program while watching a DVD:
Turn ON the VCR. Tune the VCR to the channel to record. Select the ColorStream HD-1 video input source on the TV* to view the DVD.
_____________
* To select the video input source, press INPUT on the remote control
(see page 67). To program the TV remote control to operate other devices, see Chapter 3.
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
HM95_R1_012-25_061505 6/24/05, 9:12 PM17
To use the TV Guide On Screen® recording features:
1. Connect the G-LINK on page 25.
2. Make sure the VCR is connected to the A/V OUT terminals on the TV (see illustration).
3. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details), and then turn OFF the VCR.
4. See Chapter 5 for details on setting up the TV Guide On Screen
5. See Chapter 7 for details on using the TV Guide On Screen
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
®
system.
®
system.
®
cable according to the instructions
17
Connecting two VCRs
Chapter 2: Connecting your TV
You will need:
one signal splitterthree coaxial cablestwo sets of standard A/V cables
• For better picture performance, if VCR 1 has S-video, use an S-video cable (plus the audio cables) instead of the standard video cable. However, do not connect both types of video cable to VIDEO 1 (or VIDEO 2) at the same time or the picture performance will be unacceptable.
• If VCR 1 has mono audio, connect L/MONO on the TV (VIDEO 1) to the audio out terminal on VCR 1 using the white audio cable only.
• Do not connect the same VCR to the output and input terminals on the TV at the same time.
To view the antenna or Cable signal:
Select the ANT-1 video input source on the TV.*
To view VCR 1:
Turn ON VCR 1. Select the VIDEO 1 video input source on the TV.*
To dub or edit from VCR 1 to VCR 2:
Turn ON both VCRs. Set VCR 2 to the appropriate line input (refer to your VCR owner’s manual for details). Select the VIDEO 1 video input source on the TV.*
Note:
• If you have a Cable box, connect the Cable box and splitter to VCR1 as shown on page 14.
®
• The VIDEO OUT signal incorporates Macrovision
copyright protection technology, which may prevent you from recording certain copy-restricted video materials.***
_________________________________________________________________
* To select the video input source, press INPUT on the remote control
(see page 67). To program the TV remote control to operate other devices, see Chapter 3.
** Do not connect the unit through a VCR. Video signals fed through VCRs may be affected by copyright protection systems and the picture will be distorted on the TV.
*** This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision and is intended for home and other limited pay-per-view uses only, unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited. Macrovision is a registered trademark of Macrovision Corporation.
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
From antenna or Cable
**
Signal splitter
OUT
IN
OUT
VCR1 (plays)
VIDEO AUDIO
IN from ANT
OUT to TV
CH 3 CH 4
LR
LR
IN
OUT
TV
OUT
a
b
VCR2 (records)
VIDEO AUDIO
IN from ANT
OUT to TV
a
The VIDEO OUT terminal does not output the POP picture.
b
When POP mode is active, the AUDIO OUT terminals output the sound of the active window (main or POP). For additional information, see “Notes about recording” on page 76.
Note: The VIDEO/AUDIO OUT terminals output signals from the ANT 1, ANT 2, VIDEO 1, VIDEO 2, and VIDEO 3 terminals when the appropriate input mode is selected.
To use the TV Guide On Screen® recording features:
1. Connect the G-LINK on page 25.
2. Make sure the VCR is connected to the A/V OUT terminals on the TV (see illustration).
3. Set the VCR to the appropriate line input (refer to your VCR owner’s manual for details), and then turn OFF the VCR.
4. See Chapter 5 for details on setting up the TV Guide On Screen
5. See Chapter 7 for details on using the TV Guide On Screen
®
system.
®
system.
CH 3 CH 4
®
cable according to the instructions
L
R
L
R
LR
IN
OUT
18
HM95_R1_012-25_061505 6/24/05, 9:12 PM18
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Chapter 2: Connecting your TV
Connecting an HDMI™ or a DVI device to the HDMI input
The HDMI uncompressed digital video from an HDMI device or uncompressed digital video from a DVI
This input is designed to accept HDCP digital form from EIA/CEA-861/861B–compliant
[1]
input on your TV receives digital audio and
[2]
device.
[3]
program material in
[4]
consumer electronic devices (such as a set-top box or DVD player with HDMI or DVI output).
The HDMI input is designed for best performance with 720p signals but will also accept and display 1080i, 480i, and 480p signals.
NOTE: NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
To connect an HDMI device, you will need:
• one HDMI cable (type A connector) per HDMI device
For proper operation, it is recommended that you use as short an HDMI cable as possible. You should not encounter difficulty if you use an HDMI cable shorter than
16.4 ft (5m).
HDMI cable transfers both video and audio. Separate analog audio cables are not required (see illustration below). Some CDVs (video CDs) may not output digital audio signals. In that case, you may hear sound by connecting analog audio cables.
See “Setting the HDMI audio mode” on page 50.
HDMI device
HDMI OUT
TV
VIDEO AUDIO
L
R
L
R
OUT
IN
OUT
__________________________________________________________________
[1]
HDMI = High-Definition Multimedia Interface.
[2]
DVI = Digital Video Interface.
[3]
HDCP = High-bandwidth Digital Content Protection.
[4]
EIA/CEA-861/861B compliance covers the transmission of uncompressed digital video with high-bandwidth digital content protection, which is being standardized for reception of high-definition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.
NOTE: To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:
• When turning on your electronic components, turn on the TV first, and then the HDMI or DVI device.
• When turning off your electronic components, turn off the HDMI or DVI device first, and then the TV.
To connect a DVI device, you will need:
• one HDMI-to-DVI adapter cable (HDMI type A connector) per DVI device
For proper operation, the length of an HDMI-to-DVI adapter cable should not exceed 9.8 ft (3m). The recommended length is
6.6 ft (2m).
• one pair of standard analog audio cables per DVI device
An HDMI-to-DVI adapter cable transfers video only. Separate analog audio cables are required (see illustration below).
See “Setting the HDMI audio mode” on page 50.
DVI device
DVI/HDCP
OUT
TV
VIDEO AUDIO
L
R
L
R
OUT
IN
OUT
R
___________
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
HM95_R1_012-25_061505 6/24/05, 9:12 PM19
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
19
Chapter 2: Connecting your TV
Connecting a digital audio system
The TV’s DIGITAL AUDIO OUT terminal outputs a Dolby* Digital
or 2-channel down-mixed PCM (pulse-code modulation) signal for use with an external Dolby Digital decoder or other external audio system with optical audio input.
You will need:
one optical audio cable (Use an optical audio cable that has
the larger “TOSlink” connector and not the smaller “mini-optical” connector.)
To control the audio:
Turn on the TV and the digital audio device. Press MENU on the TV’s
remote control and open the AUDIO menu.
Highlight Audio Setup and press ENTER.
Audio
Audio Settings
Advanced Audio Settings
Audio Setup
In the Optical Output Format field, select either Dolby Digital or PCM, depending on your device (see “Selecting the optical audio output format” on page 86).
Audio Setup
MTS Stereo
Language English
Speakers On
Optical Output Format
Reset
Dolby Digital
Done
Turn off the TV’s built-in speakers in the same Audio Setup menu (above). Also see “Turning off the built-in speakers” on page 86.
Dolby Digital decoder or
other digital audio system
Optical
Audio IN
LINE IN LR
TV
Note:
• Some audio systems may not be compatible with Dolby Digital bitstream signals. Older audio systems that are not compatible with standard optical out signals may not work properly, creating a high noise level that may damage speakers or headphones. THIS DAMAGE IS NOT COVERED BY YOUR WARRANTY.
• The DIGITAL AUDIO OUT terminal outputs signals only when receiving digital broadcasts with the TV in single-window mode.
• The DIGITAL AUDIO OUT terminal may not output some digital audio sources because of copy restrictions.
___________
Manufactured under license from Dolby Laboratories. “Dolby” and
*
the double-D symbol are trademarks of Dolby Laboratories.
Connecting an analog audio system
This connection allows you to use external speakers with an external audio amplifier to adjust the sound level.
You will need:
one pair of standard audio cables
To control the audio:
Turn on the TV and the stereo amplifier. Turn off the TV’s built-in speakers (see “Turning off the built-in
speakers” on page 86).
Note: To hear sound when using an external audio amplifier, the volume of both the TV and the amplifier must be set to a reasonable listening level.
20
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
TV
Analog audio amplifier
LINE IN LR
OUT
HM95_R1_012-25_061505 6/24/05, 9:12 PM20
Chapter 2: Connecting your TV
Controlling infrared remote-controlled devices through the TV (IR pass-through)
Front of IR-controlled DVD player (for example)
You can use the TV’s IR OUT terminal (infrared pass-through) to remotely operate (through the TV) many infrared remote­controlled devices (such as a Toshiba infrared remote-controlled VCR or DVD player) enclosed within an entertainment center or similar cabinet. Without the IR OUT connection, the device typically would need to be visible to operate it remotely.
You will need:
one dual-wand IR blaster cable (included with your TV)
other audio/video cables as required to connect the device(s)
to the TV (see pages 13–20)
To connect the IR blaster cable:
1. Locate the infrared sensor on the front of your device. This sensor is marked on some devices.*
2. Align one of the IR blaster cable’s wands about 1 inch away from the infrared sensor on the front of the device and attach it using double-sided mounting tape. If you have a second device, attach the second wand in a similar manner.
(See illustration at right.)
Note: If you do not have a second device, coil the second wand with a rubber band and leave it behind the TV.
3. Plug the IR blaster cable’s plug into one of the TV’s TheaterNet OUT terminals.
Infrared
sensor
Back of TV
Front of IR-controlled audio device (for example)
IR blaster cable wand (approx. 1 inch from device)
OUT
To control the device(s):
Point the TV remote control (programmed to operate the device; see Chapter 3) or the device’s remote control at the front of the TV and press the button for the desired function. The signal
MENUVOLUMECHANNELEXITTV/VIDEO POWER
passes from the remote control through the TV to the device via the IR blaster cable.
Note:
• If you use the device’s remote control to operate the device, you also will need to use the TV’s remote control to operate the TV.
• For additional control options, see “TheaterNet on-screen device control” at right.
*
If you cannot locate the device’s infrared sensor:
1. Turn OFF the device.
2. Starting at the lower left corner of the device, place the end of the device’s remote control (with the infrared emitter) so it touches the front of the device and press POWER. (Do not use the TV’s remote control for this step.)
3. If the device turns on, the point at which the remote control touched the device is the location of the sensor.
4. If the device does not turn on, move the remote control slightly to the right and press POWER again.
5. Repeat step 4 until you locate the device’s infrared sensor.
TheaterNet™ on-screen device control
For additional control options for your home theater system, set up the TheaterNet on­screen device control feature. You can use this feature to control many IR remote­controlled devices and IEEE1394 devices using the on-screen control icons.
See pages 45–49 for details on setting up and using TheaterNet.
See pages 22–24 for details on connecting IEEE1394 devices.
Note: The TheaterNet on-screen icons are the only device functions available when the icons are on-screen. To access other device functions, close the TheaterNet icon window.
Toshiba Video 3
ENTER
EXITTOP MENU
MENUVOLUMECHANNELEXITTV/VIDEO POWER
HM95_R1_012-25_061505 6/24/05, 9:13 PM21
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
21
Chapter 2: Connecting your TV
Connecting IEEE1394 video devices
You can use the two bi-directional IEEE1394 ports on the back of your TV to connect digital video devices that meet CEA specifications for IEEE1394.
Because these ports are bi-directional, they can be used for both playback and recording.
• Because IEEE1394 is an evolving technology, it is possible that some or all of the connectivity features of a device you connect to the TV through the IEEE1394 ports may not operate. You should confirm that the devices you want to use with the IEEE1394 ports will operate with those ports.
• This TV does not support all possible IEEE1394 signal types. For information on signals supported by the IEEE1394 ports, see “Supported signals” at right.
• IEEE1394 cable carries both audio and video information; separate audio cables are not required.
You will need:
one (or two) IEEE1394 cables
Note: The transmission capability of IEEE1394 cable used with this TV must be S400 (400 Mbps maximum).
additional A/V cables if your device is analog-compatible
(see “Using analog-compatible IEEE1394 devices” below).
TV back panel
}
Two bi-directional
From IEEE1394 devices (such as AVHD or D-VHS)
Using analog-compatible IEEE1394 devices
Some digital IEEE1394 devices are compatible with analog signals. For example, some D-VHS VCRs can record and play
VHS or S-VHS format videos. Such devices allow you to play analog tapes that you rented or recorded, or record analog programs from antenna or Cable TV systems. To use the
IEEE1394 device’s analog features, you need to connect the device to the TV using standard A/V cables (or S-video plus audio cables) in addition to connecting the IEEE1394 cable.
Note: If you have an IEEE1394 device connected to both digital and analog inputs on the TV, the TV automatically switches between digital and analog modes, as needed, when the initial device access is initiated using the TheaterNet button.
See page 45 for details on using the TheaterNet feature.
22
IEEE1394 ports
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
NOTE: NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
Supported signals
The IEEE1394 ports support only the signals listed below. Even though incompatible video, audio, and digital control signals cannot be decoded by the TV, these signals may be passed through the IEEE1394 cable to other compatible devices. Incompatible devices may not appear in the TheaterNet
• MPEG-2 digital video signals
Other digital video signals—such as DV video—are incompatible and must be decoded by the source device and sent to the TV as analog video (composite or S-video).
• Dolby Digital and MPEG digital audio signals
Other digital audio signals (such as DPM, MP3, and DTS) are incompatible and cannot be decoded by the TV.
• EIA-775 and AV/C digital control
menu.
Your TV can serve as the control center for many devices that are compatible with EIA-775 or AV/C IEEE1394 control standards (described below).
The TV cannot control IEEE1394 devices that use any other control standards.
EIA-775 digital control allows tuning devices (such as
Cable boxes) to send simple graphics; however, this standard does not allow the TV to control the Cable box through IEEE1394.
AV/C (audio/video control) provides basic control (such
as power, play, stop rewind, fast-forward, pause, and record), as applicable to the specific device.
Using TheaterNet™ on-screen device control
You can use the TheaterNet feature to control some IEEE1394 devices using on-screen control icons. See page 45 for details on setting up and using the TheaterNet feature.
Note: If the TheaterNet feature does not control your IEEE1394 device, you can either use the device’s remote control or try using IR pass-through with the TV’s remote control (page 21).
HM95_R1_012-25_061505 6/24/05, 9:13 PM22
Chapter 2: Connecting your TV
Connecting IEEE1394 video devices (continued)
Connecting an AVHD (external hard drive) or D-VHS digital recorder
IEEE1394 device initialization
When you connect a new IEEE1394 device to the TV and turn it on, the device immediately announces its presence to the TV
You can connect an IEEE1394 compatible D-VHS or AVHD (audio/video hard drive) digital recorder (such as Toshiba’s
Symbio
AVHD Recorder) to record high definition and
(and other networked IEEE1394 devices, if any), and the following device initialization screen automatically appears.
standard definition material from either tuner and control live TV (pause, rewind, etc.).
When you connect a D-VHS or AVHD device to the TV:
• The remote control keys (LIVE, REW, PAUSE, PLAY, FF, etc.) are automatically activated to allow control of live TV.
• The TV Guide On Screen
®
system is automatically configured to allow recording to the device.* See Chapters 5 and 7 for details. Also see page 50 for details on setting the AVHD device skip time.
• Some programs may not be recorded due to copy protection restrictions.
This TV is compatible with the new Toshiba
TM
Audio/Video Hard Drive Recorder!
Toshiba’s Symbio™ AVHD Recorder is designed specifically for high definition television (HDTV) and offers control over digital video recording and playback.
Think of it as a “tapeless VCR” for digital television. You can pause, rewind, or use instant replay, so you’ll never miss a thing!
Symbio also offers one-touch recording* of both standard and High Definition programs through the no-fee TV Guide On Screen
The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.
*Note: first set up the TV Guide On Screen® system (see Chapter 5). Full Symbio AVHD Recorder benefits, including Intelligent One Touch recording, will not be available unless the TV Guide On Screen® system is fully operational. However, when the TV Guide On Screen® system is not fully operational, manual recording is available as long as the TV Guide On Screen® system has acquired the necessary date and time data. If you experience any issues with your Symbio AVHD Recorder, please contact Toshiba Consumer Solutions by calling (800) 631-3811 or visiting
http://www.tacp.com/customersupport/contact.asp.
®
interactive program guide built in to this TV.
NOTE: NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
To enjoy the full benefits of your Symbio AVHD Recorder, you must
Note: With some devices, it may take up to one minute for this screen to appear.
1. If you also connected your IEEE1394 device to an analog input, use the
yzx
buttons to select the input in the ANALOG INPUT USED field; otherwise, leave it set to “None.” (See “Using analog-compatible IEEE1394 devices” on page 22.)
2. If you want to label the device, highlight Edit Label and press ENTER.
New IEEE1394 Device Initilization
Manufacturer
Device Type
Custom Label
3. Press the
Edit Label Done
yzx •
TOSHIBA
AVHD
buttons to select a character for the first
space and then press ENTER.
4. Repeat step 3 to enter the rest of the characters.
5. Highlight Done and press ENTER to save the information.
IEEE1394 Device Label Edit
MY DEVICE_
ABCDEFG
HI JKLMN
OPQRS TU
VWX Y Z 0 1
2345678
9
SPC CLR BS
Done Exit
Note:
• The TV may not recognize incompatible or non-A/V IEEE1394 devices; however, these devices may still be available to other compatible IEEE1394 devices on the network.
• You may be able to use the TV’s remote control to operate some compatible IEEE1394 devices. You must first program the remote control to recognize the device (see Chapter 3). If you have an IEEE1394 Cable box or satellite receiver, you may need to use the remote control that came with the device.
• Toshiba is not liable for the operation of any IEEE1394 device other than the Toshiba Symbio AVHD recorder.
HM95_R1_012-25_061505 6/24/05, 9:13 PM23
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
23
Chapter 2: Connecting your TV
Connecting IEEE1394 video devices (continued)
IEEE1394 device management
The IEEE1394 device information is saved in the TV’s memory. You can edit this device information (for example, edit the device name, change the analog input information, or delete the device information from the TV’s memory if you no longer use that device).
To edit the IEEE1394 device information:
1. Press MENU and open the Setup menu.
2. Highlight Installation and press ENTER. (A new set of Installation menu icons will appear on-screen, as shown in step 3 below).
Setup
Installation
Sleep Timer
On/Off Timer
HDMI 1 Audio
HDMI 2 Audio
Slide Show Interval
AVHD Skip Time
Navigate
3. Open the Devices menu, highlight IEEE1394 Devices, and press ENTER.
Devices
IEEE1394 Devices
TheaterNet Devices
Select
Auto
Auto
2 Sec
15 min
CH RTN
Back Exit
EXIT
Important information regarding IEEE1394
device interconnection
Never loop the last device in the chain back to the TV. If the device chain is looped, the TV may not work properly with the other devices in the chain.
Always place devices with the slowest communication speed at the end of each chain. If a device with a slower communication speed is placed ahead of a faster device in the chain, the signal from the slower device will interfere with the signal from the faster device. To determine the communication speed of an IEEE1394 device, look for an “S” number near the device’s IEEE1394 connector. The higher the “S” number, the faster the device. If your device is not marked with an “S” number, look in the device’s user manual or call the device manufacturer’s technical support number.
If your IEEE1394 device has a two-position power
switch, always place the device at the end of the chain and turn ON the power switch when any device is used.
If the power switch is OFF, it will interfere with signals from devices behind it in the chain.
The maximum length for an IEEE1394 cable between
each device is 15 feet.
• This TV is an IEEE1394A device. The IEEE1394B protocol is faster and intended to allow for longer distances between devices and multi-room systems. IEEE1394A–to–IEEE1394B converters (available at some electronics suppliers) may allow compatibility of IEEE1394B devices with your existing IEEE1394A devices.
• The transmission capability of IEEE1394 cable used with this TV must be S400 (400 Mbps maximum).
Navigate
Select
Back Exit
CH RTN
EXIT
4. Highlight the device you want to edit and press ENTER.
IEEE1394 Device Management
Brand Type Label Analog Input Used Connected
TOSHIBA AVHD None No
MY DEVICE
Reset
Done
5. Follow the on-screen prompts to modify the device information.
24
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
HM95_R1_012-25_061505 6/24/05, 9:13 PM24
G-LINK® connection
Chapter 2: Connecting your TV
• This connection is necessary for the TV Guide On Screen® system to work with your cable box to receive program listings and to enable the TV Guide On Screen
• This connection is not necessary for AVHD or D-VHS recording devices. See pages 23 and 50 for further details.
After you connect your devices to the TV, you will need to connect the G-LINK® cable (either of the dual-wand IR blaster cables included with your TV) from your VCR and Cable box (if applicable) to the G-LINK
Note: TV Guide On Screen® program data is available through the ANT-1 and ANT-2 antenna inputs and also through the VIDEO 1 inputs if you have a cable box connected to VIDEO 1. TV Guide On Screen connection information on pages 13–25.
®
recording features with your VCR.
®
program data is not available through any other inputs on this TV. See the
®
terminal on the TV.
The G-LINK® connection is necessary to enable the following features of your TV Guide On Screen® system:
• If you have a Cable box, you need to connect the G-LINK TV Guide On Screen
• If you have a VCR, you need to connect the G-LINK On Screen
®
recording features.
®
program listings for your Cable service.
To connect to the G-LINK® terminal:
®
cable from the Cable box to the G-LINK® terminal to receive the
®
cable from the VCR to the G-LINK® terminal to use the TV Guide
Front of Cable box
1. Locate the infrared sensor on the front of your VCR or Cable box. The sensor is marked on some devices.*
2. Align one of the G-LINK
®
(IR blaster) cable’s wands about 1 inch away from the infrared sensor on the front of the VCR and attach it using double-sided mounting tape.
If you have a Cable box, attach the other wand in a similar
Front of VCR
manner. (See illustration at right.)
Note: If you do not have a Cable box, coil the second wand with a rubber band and leave it behind the TV.
3. Plug the G-LINK® (IR blaster) cable’s plug into the TV’s G-LINK
For details on setting up the TV Guide On Screen
®
terminal.
®
system:
See Chapter 5.
For details on using the TV Guide On Screen
®
interactive
Infrared
sensor
G-LINK® (IR blaster) cable wand (approx. 1 inch from device)
Back of TV
OUT
program guide:
See Chapter 7.
*
If you cannot locate the device’s infrared sensor:
1. Turn OFF the device.
2. Starting at the lower left corner of the device, place the end of the device’s remote control (with the infrared emitter) so it touches the front of the device and press POWER. (Do not use the TV’s remote control for this step.)
3. If the device turns on, the point at which the remote control touched the device is the location of the sensor.
4. If the device does not turn on, move the remote control slightly to the right and press POWER again.
5. Repeat step 4 until you locate the device’s infrared sensor.
HM95_R1_012-25_061505 6/24/05, 9:13 PM25
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
25
3
Using the remote control
Learning about the remote control
The buttons used for operating the TV only are described here. For a complete list of the remote control’s functions, see the remote control functional key chart on pages 29–30.
For a list of the buttons that operate the TV Guide On Screen see page 54.
POWER
turns the TV on and off.
Note: The Quick Restart setting will affect the amount of time it takes for the picture to appear when you turn on the TV. See page 51 for details.
SLEEP
accesses the sleep timer (page 91).
LIGHT
The first press of the LIGHT button lights the keypad and turns on the Illumination mode. With the Illumination mode on, pressing any key lights the keypad for 5 seconds (10 seconds if you’re in programming mode). Subsequent presses of the LIGHT button toggle between turning the Illumination mode on and off.
Channel Numbers (0–9, –/100)
directly tune channels. The “–” button is used to tune digital channels (page 71) or to display the favorite channel list (page 44).
INPUT
selects the video input source (page 67).
®
system,
MODE
cycles through the six remote control device modes: TV, CBL/SAT, VCR/PVR, DVD, AUDIO1, and AUDIO2. The mode indicator light will remain lit for a few seconds (page 28).
PIC SIZE
cycles through the five pictures sizes: Natural, TheaterWide 1/2/
3, and Full (page 72).
TheaterNet™ DEVICE
displays a list of available TheaterNet devices (page
45).
TheaterNet™ CTRL
MENU
accesses the main TV menu system (pages 35 and 36) or opens a
menu in the TV Guide On Screen
TV GUIDE
INFO
opens the TV Guide On Screen® system (Chapter 7).
provides detailed information on highlighted items in the TV Guide
On Screen
ENTER
activates highlighted items in the main menu system and the
TV Guide On Screen
Arrow buttons (yz x )
adjust programming menus. (Also see
CH yz
cycles through programmed channels when no menu is on-screen (42) and functions as page up/down when a menu is on-screen or when the TV Guide On Screen
VOL yz
adjusts the volume level.
accesses the on-screen IR device control icons (page 46).
®
system (Chapter 7).
®
system (Chapter 7).
®
system.
When a menu is on-screen, these buttons select or
x / on the next page.)
®
system is open (Chapter 7).
Note: The error message “Not Available” will appear if you press a key for a function that is not available
26
HM95_R1_026-34_061505 6/24/05, 9:26 PM26
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Chapter 3: Using the remote control
Learning about the remote control (continued)
EXIT
closes on-screen menus and the TV Guide On Screen® system.
CH RTN
returns to the last viewed channel (page 71), or stops the picture viewer slide show
(page 88).
Live
returns viewing of the TV back to the live program, while continuing to record to the
Toshiba Symbio™ AVHD recorder (pages 23 and 50).
RECALL
MUTE
TV/VCR
SKIP/SEARCH SS
TV Guide On Screen
LIST
FAV C H yz
HOME ( )
displays TV setting information on-screen (page 92).
reduces or turns off the sound (page 84).
selects TV mode to view one program while recording another.
|
|
TT
and
jump forward and backward one day in the
®
listings (Chapter 7).
displays the Toshiba Symbio™ AVHD recorder play list (if available) (page 23).
tunes to the next higher/lower favorite channel (page 44).
accesses the home function of the channel browser feature (page 69)
x /
While watching TV, these buttons open the channel browser banner and tune to the previous/next channel in the channel history (page 69). (Also see “Arrow buttons” on previous page.)
SPLIT
turns the POP feature on and off (page 76) or locks/unlocks the TV Guide On Screen
video window.
PIC MODE
FAV SCAN
FREEZE
selects the picture mode (page 79).
accesses the favorite channel search function (page 78).
accesses the freeze feature (page 78).
®
Remote control
effective range
For optimum performance, aim the remote control directly at the TV and make sure there is no obstruction between the remote control and the TV.
HM95_R1_026-34_061505 6/24/05, 9:26 PM27
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Point remote control toward remote sensor on front of TV.
16.4 ft (5m)
27
Chapter 3: Using the remote control
Installing the remote control batteries
To install the remote control batteries:
CAUTION: Always dispose of batteries in a designated disposal location. Never throw batteries into a fire.
1. Slide the battery cover off the back of the remote control.
2. Install two “AA” size alkaline batteries. Match the + and – symbols on the batteries to the symbols on the battery compartment.
3. Slide the battery cover on to the remote control until the lock snaps.
Caution:
Never throw batteries into a fire.
Note:
Be sure to use AA size batteries.
Dispose of batteries in a designated disposal area.
Batteries should always be disposed of with the
environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.
If the remote control does not operate correctly, or if the
operating range becomes reduced, replace batteries with new ones.
When necessary to replace batteries in the remote
control, always replace both batteries with new ones. Never mix battery types or use new and used batteries in combination.
Always remove batteries from remote control if they are
dead or if the remote control is not to be used for an extended period of time. This will prevent battery acid from leaking into the battery compartment.
Using the remote control MODE button to control your other devices
Your TV remote control has one dedicated TV mode and five programmable multi-brand modes: CBL/SAT, VCR/PVR, DVD, AUDIO 1, and AUDIO 2. The default device modes and programmable device modes are listed below.
Note: The TV remote control is preprogrammed to operate most Toshiba devices. If you own a non-Toshiba device or a Toshiba device that the remote control is not preprogrammed to operate, you will need to program the remote control. See “Programming the remote control to operate your other devices” on page 31.
MODE Default device mode control (before programming)
1) TV Toshiba TV
2) CBL/SAT Toshiba Satellite receiver
3) VCR/PVR Toshiba VCR
4) DVD Toshiba DVD
5) AUDIO 1 Pioneer Audio receiver
6) AUDIO 2 Pioneer LD
MODE Device mode control after programming
1) TV Toshiba TV
2) CBL/SAT
3) VCR/PVR
4) DVD Multi-brand video/audio devices
5) AUDIO 1
6) AUDIO 2
You can directly select the device mode by pressing the corresponding number button (1-6) while pressing the MODE button.
Number (1-6)
MODE
Note:
Although your new TV’s remote control includes codes for many devices, it may not include codes for some or all of the features on certain devices you wish to control. If you are unable to program the TV’s remote control to operate your device or some of the features on that device, use the device’s remote control or the controls on the device.
28
HM95_R1_026-34_061505 6/24/05, 9:27 PM28
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Chapter 3: Using the remote control
Remote Control functional key chart
Key Label
Toshiba TV Cable Satellite VCR DVD/LD Receiver CD PVR
(TV) (CBL/SAT) (CBL/SAT) (AUDIO) (AUDIO) (VCR)
MODE Remote control device mode selection
LIGHT Lights the remote key, and toggles between enabled and disabled Illumination mode.*
1
SLEEP Sleep timer --- --- --- --- --- --- --­POWER Power Power Power Power Power Power Power Power 1 Digit 1 Digit 1 Digit 1 Digit 1 Digit 1 AV input 1 Digit 1 Digit 1 2 Digit 2 Digit 2 Digit 2 Digit 2 Digit 2 AV input 2 Digit 2 Digit 2 3 Digit 3 Digit 3 Digit 3 Digit 3 Digit 3 AV input 3 Digit 3 Digit 3 4 Digit 4 Digit 4 Digit 4 Digit 4 Digit 4 AV input 4 Digit 4 Digit 4 5 Digit 5 Digit 5 Digit 5 Digit 5 Digit 5 CD Digit 5 Digit 5 6 Digit 6 Digit 6 Digit 6 Digit 6 Digit 6 Tuner Digit 6 Digit 6 7 Digit 7 Digit 7 Digit 7 Digit 7 Digit 7 Phono Digit 7 Digit 7 8 Digit 8 Digit 8 Digit 8 Digit 8 Digit 8 Cassette Digit 8 Digit 8 9 Digit 9 Digit 9 Digit 9 Digit 9 Digit 9 Aux Digit 9 Digit 9 0 Digit 0 Digit 0 Digit 0 Digit 0 Digit 0 --- Digit 0, 10 Digit 0 100/– – (digital --- – (sub 100 +10 --- --- ---
- separator) channel)
INPUT TV/Video TV TV TV TV TV TV TV
select
PIC SIZE Selects the TV TV TV TV TV TV TV
image shape.
MENU/ Menu/ --- Action, --- Menu --- --- Menu ACTION Guide Menu Menu
TV GUIDE/SETUP
TV Guide --- Guide --- DVD setup --- --- Guide
INFO/TITLE Guide Info --- INFO --- TITLE= --- --- INFO
Top menu
TheaterNet DEVICE/SUBTITLE
TheaterNet CTRL/AUDIO
TheaterNet Device
TheaterNet Control
--- --- --- Subtitle --- ---
ADVANCE
--- --- --- Audio --- --- ---
ENTER Enter --- Enter, Select --- Enter --- --- Enter
y Menu select --- Menu select --- Menu select --- --- Menu select
up up up up
z Menu select --- Menu select --- Menu select --- --- Menu select
down down down down
x • Menu select --- Menu select --- Menu select --- --- Menu select
left/right left/right left/right left/right
EXIT/ Exit --- Exit --- DVD clear --- --- EXIT DVD CLEAR
CH
yz Channel Channel Channel Channel --- Channel --- Channel
PAGE +/– up/down, up/down up/down up/down up/down up/down
Page up/down
VOL yz Volume Volume Volume Volume Volume Volume Volume Volume
up/down*2up/down*2up/down*2up/down*2up/down*2up/down*2up/down*2up/down*
CH RTN/ Previous Previous Previous --- DVD --- --- --­DVD RTN channel channel channel return
Live Live --- --- --- --- --- --- Live TV RECALL On-screen
--- --- ---
On-screen --- --- ---
display display
2
HM95_R1_026-34_061505 6/24/05, 9:27 PM29
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
29
Chapter 3: Using the remote control
Remote Control functional key chart (continued)
Key Label
MUTE SLOW/
DIR SKIP/
SEARCH REW Rewind --- --- Rewind Rewind PAUSE/STEP Pause --- --- Pause Pause PLAY Play --- --- Play Play
Toshiba TV Cable Satellite VCR DVD/LD Receiver CD PVR
(TV) (CBL/SAT) (CBL/SAT) (AUDIO) (AUDIO) (VCR)
Sound mute*2Sound mute*2Sound mute*2Sound mute*2Sound mute*2Sound mute*2Sound mute*2Sound mute*
x
------ ------ ------
x Skip FWD
Skip REW
------ ------ ------
Slow FWD Slow FWD
--- Slow REW --­Skip FWD
Skip REW Skip REW
------ ------
------
---
---
---
Skip FWD
Rewind Rewind Pause Pause Play Play
Slow FWD
------
FF Fast FWD --- --- Fast FWD Fast FWD --- Fast FWD Fast FWD TV/VCR
--- ---
TV/SAT TV/VCR --- --- --- Reverse DISC/AM/FM --- --- --- --- Disc shift AM/FM Disc shift Replay STOP Stop
--- ---
Stop Stop --- Stop Stop
REC REC Menu --- --- Record --- --- --- Record
(Single Click) LIST LIST FAV CH
yz
FAV channel --- --- --- --- --- --- ---
--- --- --- --- --- --- ---
(Double Click) (Double Click)
up/down HOME HOME --- --- --- --- --- --- --­SPLIT
Split
TV TV TV TV TV TV TV PIC MODE PIC MODE TV TV TV TV TV TV TV FAV SCAN FAV SCAN --- --- --- --- --- --- --­FREEZE
Freeze
TV TV TV TV TV TV TV
2
Notes:
• “---” = key does not send a signal.
• “ TV” = key will operate the TV.
• “ VCR” = key will operate the last active VCR or DVD. (“Last active VCR/DVD” is the mode that remains for a minimum of 5 seconds or if a key is pressed in that mode.)
1
*
Backlight key is a toggle key and does not send an IR signal.
2
*
Volume will punch through to TV by default. When the volume is unlocked, all the devices will have their own volume if their ID has volume data. The AUD modes (receiver, CD) will have their own volume if volume lock is set on TV, CBL/SAT, VCR/PVR, or DVD mode. See “Using the volume lock feature” on page 32.
30
HM95_R1_026-34_061505 6/24/05, 9:27 PM30
Copyright © 2005 TOSHIBA CORPORATION. All rights reserved.
Loading...
+ 82 hidden pages
