User’s Manual

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

computers.toshiba-europe.com

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Chapter 1 Getting Started

Equipment checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

System Recovery Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

System Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12

Chapter 2 The Grand Tour

Front with the display closed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Left side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Right side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Underside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Front with the display open. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8

Optical disc drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9

Chapter 3 Hardware, Utilities and Options

Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Special features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Utilities and Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8

Optional devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12

Bridge media slot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13

Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24

User’s Manual ii

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Chapter 4

Operating Basics

Using the Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

Web Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2

Using the TOSHIBA Face Recognition . . . . . . . . . . . . . . . . . . . . . . . . 4-3

Using optical disc drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

Writing CD/DVDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9

TOSHIBA VIDEO PLAYER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15

Media care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17

Sound System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18

Wireless communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19

LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21

Computer Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23

Heat dispersal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-24

Chapter 5 The Keyboard

Function keys: F1 … F9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Soft keys: FN key combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1

Hot keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2

Windows special keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Generating ASCII characters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3

Chapter 6 Power and Power-Up Modes

Power conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

Monitoring of power condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3

Password Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8

Starting the computer by password . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9

Power-up modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

Panel power on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10

System automatic Sleep/Hibernation . . . . . . . . . . . . . . . . . . . . . . . . 6-10

Chapter 7 HW Setup

Accessing HW Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

HW Setup window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1

Chapter 8 Troubleshooting

Problem solving process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1

Hardware and system checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3

TOSHIBA support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-17

User’s Manual iii

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Appendix A

Appendix B Display Controller and Video mode

Appendix C Information for Wireless Devices

Appendix D AC Power Cord and Connectors

Appendix E Legal Footnotes

Appendix F If your computer is stolen

Specifications

Glossary

Index

User’s Manual iv

Disclaimer

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

© 2011 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.

First edition March 2011 Copyright authority for music, movies, computer programs, databases and

other intellectual property covered by copyright laws belongs to the author or to the copyright owner. Copyrighted material can be reproduced only for personal use or use within the home. Any other use beyond that stipulated above (including conversion to digital format, alteration, transfer of copied material and distribution on a network) without the permission of the copyright owner is a violation of copyright or author's rights and is subject to civil damages or criminal action. Please comply with copyright laws in making any reproduction from this manual.

This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for your computer at the time of this manual’s production. However, succeeding computers and manuals are subject to change without notice. TOSHIBA assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manual.

Trademarks

Intel, Intel SpeedStep, Intel Core and Centrino are trademarks or registered trademarks of Intel Corporation.

AMD, the AMD Arrow logo, AMD Athlon, AMD Turion, PowerPlay, VariBright and combinations thereof are trademarks of Advanced Micro Devices, Inc.

Windows, Microsoft and Windows logo are registered trademarks of Microsoft Corporation.

Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Photo CD is a trademark of Eastman Kodak Company. ConfigFree is a trademark of Toshiba Corporation. Wi-Fi is a registered trademark of the Wi-Fi Alliance. Secure Digital and SD are trademarks of SD Card Association. MultiMediaCard and MMC are trademarks of MultiMediaCard Association. Labelflash is a trademark of YAMAHA CORPORATION. WinDVD is a trademark of the Corel Corporations. Atheros is a registered trademark of Atheros Communication, Inc.

User’s Manual v

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Realtek is a registered trademark of Realtek Semiconductor Corporation. Broadcom is a registered trademark of Broadcom Corporation. Other trademarks and registered trademarks not listed above may be used

in this manual.

FCC information

FCC notice "Declaration of Conformity Information"

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■ Reorient or relocate the receiving antenna.

■ Increase the separation between the equipment and receiver.

■ Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

■ Consult the dealer or an experienced radio/TV technician for help.

Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s external monitor port, Universal Serial Bus (USB 2.0) ports and microphone jack. Changes or modifications made to this equipment, not expressly approved by TOSHIBA or parties authorized by TOSHIBA could void the user’s authority to operate the equipment.

User’s Manual vi

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

Contact

Address: TOSHIBA America Information Systems, Inc.

9740 Irvine Boulevard Irvine, California 92618-1697

Telephone: (949) 583-3000

EU Declaration of Conformity

This product is carrying the CE-Mark in accordance with the related European Directives. Responsible for CE-Marking is TOSHIBA Europe GmbH, Hammfelddamm 8, 41460 Neuss, Germany. The complete and official EU Declaration of Conformity can be found on TOSHIBA’s web site

http://epps.toshiba-teg.com on the Internet.

CE compliance

This product is labelled with the CE Mark in accordance with the related European Directives, notably Electromagnetic Compatibility Directive 2004/108/EC for the notebook and the electronic accessories including the supplied power adaptor, the Radio Equipment and Telecommunications Terminal Equipment Directive 1999/5/EC in case of implemented telecommunication accessories and the Low Voltage Directive 2006/95/EC for the supplied power adaptor. Furthermore the product complies with the Ecodesign Directive 2009/125/EC (ErP) and its related implementing measures.

This product and the original options are designed to observe the related EMC (Electromagnetic Compatibility) and safety standards. However, TOSHIBA cannot guarantee that this product still observes these EMC standards if options or cables not produced by TOSHIBA are connected or implemented. In this case the persons who have connected/implemented those options/cables have to provide assurance that the system (PC plus options/cables) still fulfils the required standards. To avoid general EMC problems, the following guidance should be noted:

■ Only CE marked options should be connected/implemented

■ Only best shielded cables should be connected

User’s Manual vii

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Working environment

This product was designed to fulfil the EMC (Electromagnetic Compatibility) requirements to be observed for so-called "Residential, commercial and light industry environments". TOSHIBA do not approve the use of this product in working environments other than the above mentioned "Residential, commercial and light industry environments".

For example, the following environments are not approved:

■ Industrial Environments (e.g. environments where a mains voltage of

380 V three-phase is used)

■ Medical Environments

■ Automotive Environments

■ Aircraft Environments

Any consequences resulting from the use of this product in working environments that are not approved are not the responsibility of TOSHIBA.

The consequences of the use of this product in non-approved working environments may be:

■ Interference with other devices or machines in the near surrounding

area.

■ Malfunction of, or data loss from, this product caused by disturbances

generated by other devices or machines in the near surrounding area.

Therefore TOSHIBA strongly recommend that the electromagnetic compatibility of this product should be suitably tested in all non-approved working environments before use. In the case of automobiles or aircraft, the manufacturer or airline respectively should be asked for permission before use of this product.

Furthermore, for general safety reasons, the use of this product in environments with explosive atmospheres is not permitted.

Canadian regulatory information (Canada only)

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulation of the Canadian Department of Communications.

Note that Canadian Department of Communications (DOC) regulations provide, that changes or modifications not expressly approved by TOSHIBA Corporation could void your authority to operate this equipment.

This Class B digital apparatus meets all requirements of the Canadian Interference-Causng Equipment Regulations.

Cet appareil numérique de la class B respecte toutes les exgences du Règlement sur le matériel brouileur du Canada.

User’s Manual viii

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

GOST

VCCI Class B Information

Video Standard notice

THIS PRODUCT IS LICENSED UNDER THE AVC, THE VC-1 AND MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (I) ENCODING VIDEO IN COMPLIANCE WITH THE ABOVE STANDARDS ("VIDEO") AND/OR (II) DECODING AVC, VC-1 AND MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE SUCH VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE

HTTP://WWW.MPEGLA.COM.

User’s Manual ix

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Following information is only valid for EU-member States:

Disposal of products

The crossed out wheeled dust bin symbol indicates that products must be collected and disposed of separately from household waste. Integrated batteries and accumulators can be disposed of with the product. They will be separated at the recycling centres.

The black bar indicates that the product was placed on the market after August 13, 2005.

By participating in separate collection of products and batteries, you will help to assure the proper disposal of products and batteries and thus help to prevent potential negative consequences for the environment and human health.

For more detailed information about the collection and recycling programmes available in your country, please visit our website (http://eu.computers.toshiba-europe.com) or contact your local city office or the shop where you purchased the product.

Disposal of batteries and/or accumulators

The crossed out wheeled dust bin symbol indicates that batteries and/or accumulators must be collected and disposed of separately from household waste.

If the battery or accumulator contains more than the specified values of lead (Pb), mercury (Hg), and/or cadmium (Cd) defined in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or cadmium (Cd) will appear below the crossed out wheeled dust bin symbol.

By participating in separate collection of batteries, you will help to assure the proper disposal of products and batteries and thus help to prevent potential negative consequences for the environment and human health.

These symbols may not stick depending on the country and region where you purchased.

User’s Manual x

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Disposing of the computer and the computer's batteries

■ Discard this computer in accordance with applicable laws and

regulations. For further information, contact your local government.

■ This computer contains rechargeable batteries. After repeated use, the

batteries will finally lose their ability to hold a charge and you will need to replace them. Under certain applicable laws and regulation, it may be illegal to dispose of old batteries by placing them in the trash.

■ Please be kind to our shared environment. Check with your local

government authority for details regarding where to recycle old batteries or how to dispose of them properly.

REACH - Compliance Statement

The new European Union (EU) chemical regulation, REACH (Registration, Evaluation, Authorization and Restriction of Chemicals), entered into force on 1 June 2007. Toshiba will meet all REACH requirements and is committed to provide our customers with information about the chemical substances in our products according to REACH regulation.

Please consult the following website

http://www.toshiba-europe.com/computers/info/reach for information about

the presence in our articles of substances included on the candidate list according to article 59(1) of Regulation (EC) No 1907/2006 ("REACH") in a concentration above 0.1% weight by weight.

Following information is only for Turkey:

■ Compliant with EEE Regulations: Toshiba meets all requirements of

Turkish regulation 26891 "Restriction of the use of certain hazardous substances in electrical and electronic equipment".

■ The number of possible pixel failures of your display is defined

according to ISO 13406-2 standards. If the number of pixel failures is less than this standard, they will not be counted as defect or failure.

■ Battery is a consumption product, since the battery time depends on the

usage of your computer. If the battery can not be charged at all, then it is a defect or failure. The changes in battery time is not a defect or failure.

User’s Manual xi

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Optical disc drive safety instructions

Be sure to check the precautions at the end of this section.

■ The DVD Super Multi drive model employs a laser system. To ensure

proper use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.

■ Use of controls, adjustments or the performance of procedures other

than those specified may result in hazardous radiation exposure.

■ To prevent direct exposure to the laser beam, do not try to open the

enclosure.

Panasonic System Networks

■ DVD Super Multi UJ8A0

User’s Manual xii

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

HITACHI-LG Data Storage, Inc.

■ DVD Super Multi GT30N/GT30F

Hitachi-LG Data Storage, Inc. 22-23,KAIGAN 3-CHOME, MINATO-KU,TOKYO,108-0022 JAPAN

TOSHIBA SAMSUNG STORAGE TECHNOLOGY

■ DVD Super Multi TS-L633F/TS-L633W

TOSHIBA SAMSUNG STORAGE TECHNOLOGY KOREA CORPORATION 416, MEATAN-3 DONG, YEONGTONG-GU, SUWON CITY, GYEONGGI, 443-742, KOREA

User’s Manual xiii

Precautions

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

CAUTION: This appliance contains a laser system and is classified as a "CLASS 1 LASER PRODUCT." To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest "AUTHORIZED service station." To prevent direct exposure to the laser beam, do not try to open the enclosure.

User’s Manual xiv

Preface

Congratulations on your purchase of this computer. This powerful notebook computer provides excellent expansion capability, includes multimedia functionality, and is designed to provide years of reliable, high-performance computing.

This manual tells how to set up and begin using your computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.

If you are a new user of computers or if you’re new to portable computing, first read over the Chapter 1, Getting Started and Chapter 3, Hardware,

Utilities and Options chapters to familiarize yourself with the computer’s

features, components and accessory devices. Then read Chapter 1,

Getting Started for step-by-step instructions on setting up your computer.

If you are an experienced computer user, please continue reading the preface to learn how this manual is organized, then become acquainted with this manual by browsing through its pages. Be sure to read the Special

features section in Chapter 3, Hardware, Utilities and Options to learn

about features that are uncommon or unique to this computer, as well as the section on Chapter 7, HW Setup, to understand how to setup and configure these features.

Read Chapter 3, Hardware, Utilities and Options if connecting optional products or external devices.

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Conventions

This manual uses the following formats to describe, identify, and highlight terms and operating procedures.

Abbreviations

On first appearance, and whenever necessary for clarity, abbreviations are enclosed in parentheses following their definition. For example: Read Only Memory (ROM). Acronyms are also defined in the Glossary.

User’s Manual xv

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Icons

Icons identify ports, dials, and other parts of your computer. The indicator panel also uses icons to identify the components it is providing information on.

Keys

The keyboard keys are used in the text to describe many computer operations. A distinctive typeface identifies the key top symbols as they appear on the keyboard. For example, ENTER identifies the ENTER key.

Key operation

Some operations require you to simultaneously use two or more keys. We identify such operations by the key top symbols separated by a plus sign (+). For example, CTRL + C means you must hold down CTRL and at the same time press C. If three keys are used, hold down the first two and at the same time press the third.

ABC When procedures require an action such as

clicking an icon or entering text, the icon's name or the text you are to type in is represented in the typeface you see to the left.

Display

ABC

Names of windows or icons or text generated by the computer that appears on its display screen is presented in the type face you see to the left.

Messages

Messages are used in this manual to bring important information to your attention. Each type of message is identified as shown below.

Indicates a potentially hazardous situation, which could result in death or serious injury, if you do not follow instructions.

Pay attention! A caution informs you that improper use of equipment or failure to follow instructions may cause data loss or damage your equipment.

Please read. A note is a hint or advice that helps you make best use of your equipment.

User’s Manual xvi

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Terminology

This term is defined in this document as follows:

Start The word "Start" refers to the " " button in

Windows

HDD or Hard disk drive

Some models are equipped with a "Solid State Drive (SSD)" instead of a hard disk drive.

In this manual, the word "HDD" or "Hard disk drive" also refers to the SSD unless otherwise stated.

User’s Manual xvii

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

General Precautions

TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer.

Be certain to read the general precautions below and to note the cautions included in the text of the manual.

Provide adequate ventilation

■ Always make sure your computer and AC adaptor have adequate

ventilation and are protected from overheating when the power is turned on or when an AC adaptor is connected to a power outlet (even if your computer is in Sleep Mode). In this condition, observe the following:

■ Never cover your computer or AC adaptor with any object.

■ Never place your computer or AC adaptor near a heat source, such

as anelectric blanket or heater.

■ Never cover or block the air vents including those located at the

base of the computer.

■ Always operate your computer on a hard flat surface. Using your

computer on a carpet or other soft material can block the vents.

■ Always provide sufficient space around the computer.

■ Overheating your computer or AC adaptor could cause system failure,

computer or AC adaptor damage or a fire, possibly resulting in serious injury.

Creating a computer-friendly environment

Place the computer on a flat surface that is large enough for the computer and any other items you are using, such as a printer.

Leave enough space around the computer and other equipment to provide adequate ventilation. Otherwise, they may overheat.

User’s Manual xviii

To keep your computer in prime operating condition, protect your work area from:

■ Dust, moisture, and direct sunlight.

■ Equipment that generates a strong electromagnetic field, such as

■ Rapid changes in temperature or humidity and sources of temperature

■ Extreme heat, cold, or humidity.

■ Liquids and corrosive chemicals.

Stress injury

Carefully read the Instruction Manual for Safety and Comfort. It contains information on the prevention of stress injuries to your hands and wrists that can be caused by extensive keyboard use. Instruction Manual for Safety and Comfort also includes information on work space design, posture and lighting that can help reduce physical stress.

Heat injury

■ Avoid prolonged physical contact with the computer. If the computer is

■ If the computer has been used for a long time, avoid direct contact with

■ The surface of the AC adaptor can become hot when in use but this

■ Do not lay the AC adaptor on a material that is sensitive to heat as the

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

stereo speakers (other than speakers that are connected to the computer) or speakerphones.

change such as air conditioner vents or heaters.

used for long periods, its surface can become very warm. While the temperature will not feel hot to the touch, if you maintain physical contact with the computer for a long time, for example if you rest the computer on your lap or if you keep your hands on the palm rest, your skin might suffer a low-heat injury.

the metal plate supporting the various interface ports as this can become hot.

condition does not indicate a malfunction. If you need to transport the AC adaptor, you should disconnect it and let it cool before moving it.

material could become damaged.

Pressure or impact damage

Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction.

User’s Manual xix

Satellite C660/C665/C660D/C665D Satellite Pro C660/C660D Series

Mobile phones

Please be aware that the use of mobile phones can interfere with the audio system. The operation of the computer will not be impaired in any way, but it is recommended that a minimum distance of 30cm is maintained between the computer and a mobile phone that is in use.

Instruction Manual for Safety and Comfort

All important information on the safe and proper use of this computer is described in the enclosed Instruction Manual for Safety and Comfort. Be sure to read it before using the computer.

User’s Manual xx

Getting Started

This chapter provides an equipment checklist, and basic information to start using your computer.

Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA.

Equipment checklist

Carefully unpack your computer, taking care to save the box and packaging materials for future use.

Hardware

Check to make sure you have all the following items:

■ TOSHIBA Portable Personal Computer

■ AC adaptor and power cord (2-pin plug or 3-pin plug)

■ Battery pack (installed in the computer)

Getting Started

Chapter 1

Documentation

■ Quickstart

■ Instruction Manual for Safety and Comfort

■ Warranty Information

If any of the items are missing or damaged, contact your dealer immediately.

Software

The following Windows® operating system and utility software are preinstalled.

■ Windows 7

■ TOSHIBA Value Added Package

■ TOSHIBA Recovery Media Creator

■ TOSHIBA VIDEO PLAYER (Is preinstalled with some models)

■ Corel Label@Once (Is preinstalled with some models.)

User’s Manual 1-1

■ TOSHIBA Assist

■ TOSHIBA ConfigFree™

■ TOSHIBA Disc Creator

■ TOSHIBA Face Recognition (Is preinstalled with some models)

■ TOSHIBA Bulletin Board

■ TOSHIBA ReelTime

■ TOSHIBA Resolution+ Plug-in For Windows Media Player

■ TOSHIBA Speech System (Is preinstalled with some models.)

■ TOSHIBA Media Controller

■ Online Manual

■ TOSHIBA Portable Personal Computer User's Manual (This

*You may not have all the softwares listed above depending on the model

you purchased.

Getting Started

■ All users should be sure to read the section Starting up for the first

time.

■ Be sure to read the enclosed Instruction Manual for Safety and

Comfort for information on the safe and proper use of this computer. It is intended to help you be more comfortable and productive while using a notebook computer. By following the recommendations in it you may reduce your chance of developing a painful or disabling injury to your hand, arms, shoulders or neck.

This section provides basic information to start using your computer. It covers the following topics:

■ Connecting the AC adaptor

■ Opening the display

■ Turning on the power

■ Starting up for the first time

■ Turning off the power

■ Restarting the computer

■ System Recovery Options

■ Creating Recovery Media

■ Restoring the pre-installed software from the Recovery hard disk drive

■ Restoring the pre-installed software from your created Recovery Media

Getting Started

manual)

User’s Manual 1-2

■ Use a virus-check program and make sure it is updated regularly.

■ Never format storage media without checking its content - formatting

destroys all stored data.

■ It is a good idea to periodically back up the internal hard disk drive or

other main storage device to external media. General storage media is not durable or stable over long periods of time and under certain conditions may result in data loss.

■ Before you install a device or application, save any data in memory to

the hard disk drive or other storage media. Failure to do so may result in the loss of data.

Connecting the AC adaptor

Attach the AC adaptor when you need to charge the battery or you want to operate from AC power. It is also the fastest way to get started, because the battery pack will need to be charged before you can operate from battery power.

The AC adaptor can automatically adjust to any voltage ranging from 100 to 240 volts and to a frequency of either 50 or 60 hertz, enabling you to use this computer in almost all country/region. The adaptor converts AC power to DC power and reduces the voltage supplied to this computer.

Getting Started

User’s Manual 1-3

Getting Started

■ Always use the TOSHIBA AC adaptor that was included with your

computer, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor could cause fire or damage to the computer possibly resulting in serious injury. TOSHIBA assumes no liability for any damage caused by use of an incompatible adaptor.

■ Never plug the AC adaptor into a power source that does not

correspond to both the voltage and the frequency specified on the regulatory label of the unit. Failure to do so could result in a fire or electric shock, possibly resulting in serious injury.

■ Always use or purchase power cables that comply with the legal

voltage and frequency specifications and requirements in the country of use. Failure to do so could result in a fire or electric shock, possibly resulting in serious injury.

■ The supplied power cord conforms to safety rules and regulations in

the region the product is bought and should not be used outside this region. For use in other regions, please buy power cords that conform to safety rules and regulations in the particular region.

■ Do not use a 3-pin to 2-pin conversion plug.

■ When you connect the AC adaptor to the computer, always follow the

steps in the exact order as described in the User’s Manual. Connecting the power cable to a live electrical outlet should be the last step otherwise the adaptor DC output plug could hold an electrical charge and cause an electrical shock or minor bodily injury when touched. As a general safety precaution, avoid touching any metal parts.

■ Never place your computer or AC adaptor on a wooden surface,

furniture, or any other surface that could be marred by exposure to heat since the computer base and AC adaptor's surface increase in temperature during normal use.

■ Always place your computer or AC adaptor on a flat and hard surface

that is resistant to heat damage.

Refer to the enclosed Instruction Manual for Safety and Comfort for detailed precautions and handling instructions.

1. Connect the power cord to the AC adaptor.

Connecting the power cord to the AC adaptor (2-pin plug)

User’s Manual 1-4

Getting Started

Connecting the power cord to the AC adaptor (3-pin plug)

Either a 2-pin or 3-pin adaptor/cord will be included with the computer depending on the model.

2. Connect the AC adaptor’s DC output plug to the DC IN 19V jack on the right of the computer.

1. DC IN 19V jack 2. DC output plug

Connecting the DC output plug to the computer

3. Plug the power cord into a live wall outlet - the DC IN/Battery indicator on the front of the computer should glow.

User’s Manual 1-5

Opening the display

The display panel can be opened to a wide range of angles for optimal viewing.

While holding down the palm rest with one hand so that the main body of the computer is not raised, slowly lift the display panel - this will allow the angle of the display panel to be adjusted to provide optimum clarity.

1. Display panel

Opening the display panel

Use reasonable care when opening and closing the display panel. Opening it vigorously or slamming it shut could damage the computer.

Getting Started

■ Be careful not to open the display panel too far as this could put stress

on the display panel’s hinges and cause damage.

■ Do not press or push on the display panel.

■ Do not lift the computer by the display panel.

■ Do not close the display panel with pens or any other objects left in

between the display panel and the keyboard.

■ When opening or closing the display panel, place one hand on the

palm rest to hold the computer in place and use the other hand to slowly open or close the display panel (Do not use excessive force when opening or closing the display panel).

User’s Manual 1-6

Turning on the power

This section describes how to turn on the power - the Power indicator will then indicate the status. Please refer to the Monitoring of power condition section in Chapter 6, Power and Power-Up Modes for more information.

■ After you turn on the power for the first time, do not turn it off until you

have set up the operating system. Please refer to the section Starting

up for the first time for more information.

■ Volume cannot be adjusted during Windows Setup.

1. Open the display panel.

2. Press and hold the computer's power button for two or three seconds.

Getting Started

1. Power button

Turning on the power

Starting up for the first time

The Windows 7 Startup Screen will be the first screen displayed when you turn on the power. Follow the on-screen instructions on each screen in order to properly install the operating system.

When it is displayed, be sure to read the Software License Terms carefully.

Turning off the power

The power can be turned off in one of three modes, either Shut Down Mode, Hibernation Mode or Sleep Mode.

User’s Manual 1-7

Getting Started

Shut Down Mode

When you turn off the power in Shut Down Mode no data will be saved and the computer will boot to the operating system's main screen the next time it is turned on.

1. If you have entered data, either save it to the hard disk drive or to other storage media.

2. Make sure all disk/disc activity has stopped before removing the CD/DVD or floppy diskette.

■ Never turn off the power while an application is running. Doing so

could cause loss of data.

■ Never turn off the power, disconnect an external storage device or

remove storage media during data read/write. Doing so can cause data loss.

3. Click Start.

4. Click the Shut down button ( ).

5. Turn off any peripheral devices connected to your computer.

Do not turn the computer or peripheral devices back on immediately - wait a short period to avoid any potential damage.

Sleep Mode

If you have to interrupt your work, you are able to turn off the power without exiting from your software by placing the computer into Sleep Mode. In this mode data is maintained in the computer's main memory so that when you turn on the power again, you can continue working right where you left off.

When you have to turn off your computer aboard an aircraft or in places where electronic devices are regulated or controlled, always completely shut down the computer. This includes turning off any wireless communication functionalities or devices, and cancelling settings that reactivate the computer automatically, such as a timer recording function. Failure to completely shut down the computer in this way could allow the operating system to reactivate and run pre-programmed tasks or preserve unsaved data, which could interfere with aviation or other systems, possibly causing serious injury.

■ Before entering Sleep Mode, be sure to save your data.

■ Do not install or remove a memory module while the computer is in

Sleep Mode. The computer or the memory module could be damaged.

■ Do not remove the battery pack while the computer is in Sleep Mode

(unless the computer is connected to an AC power source). Data in memory could be lost.

User’s Manual 1-8

Getting Started

■ When the AC adaptor is connected, the computer will go into Sleep

Mode according to the settings in the Power Options (to access it, click Start  Control Panel  System and Security  Power Options).

■ To restore the operation of the computer from Sleep Mode, press and

hold the power button or any key on the keyboard for a short amount of time. Please note that keyboard keys can only be used if the Wake-up on Keyboard option is enabled within the HW Setup utility.

■ If the computer enters Sleep Mode while a network application is

active, the application might not be restored when the computer is next turned on and the system returns from Sleep Mode.

■ To prevent the computer from automatically entering Sleep Mode,

disable Sleep Mode within the Power Options (to access it, click Start  Control Panel  System and Security  Power Options).

■ To use the Hybrid Sleep function, configure it in the Power Options.

Benefits of Sleep Mode

The Sleep Mode feature provides the following benefits:

■ Restores the previous working environment more rapidly than does the

Hibernation Mode feature.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the time period set by the System Sleep Mode feature.

■ Allows the use of the panel power off feature.

Executing Sleep Mode

You can also enable Sleep Mode by pressing FN + F3 - please refer to Chapter 5, The Keyboard, for further details.

You can enter Sleep Mode in one of the following ways:

■ Click Start, point to the arrow icon ( ) and then select

Sleep from the menu.

■ Close the display panel. Please note that this feature must be enabled

within the Power Options (to access it, click Start  Control Panel  System and Security  Power Options).

■ Press the power button. Please note that this feature must be enabled

within the Power Options (to access it, click Start  Control Panel  System and Security  Power Options).

When you turn the power back on, you can continue where you left when you shut down the computer.

■ When the computer is in Sleep Mode, the power indicator will blink

green.

■ If you are operating the computer on battery power, you can lengthen

the overall operating time by turning it off into Hibernation Mode Sleep Mode will consume more power while the computer is off.

User’s Manual 1-9

Getting Started

Sleep Mode limitations

Sleep Mode will not function under the following conditions:

■ Power is turned back on immediately after shutting down.

■ Memory circuits are exposed to static electricity or electrical noise.

Hibernation Mode

The Hibernation Mode feature saves the contents of memory to the hard disk drive when the computer is turned off so that, the next time it is turned on, the previous state is restored. Please note that the Hibernation Mode feature does not save the status of any peripheral devices connected to the computer.

■ Save your data. While entering Hibernation Mode, the computer saves

the contents of memory to the hard disk drive. However, for safety sake, it is best to save your data manually.

■ Data will be lost if you remove the battery or disconnect the AC

adaptor before the save is completed.

■ Do not install or remove a memory module while the computer is in

Hibernation Mode. Data will be lost.

Benefits of Hibernation Mode

The Hibernation Mode feature provides the following benefits:

■ Saves data to the hard disk drive when the computer automatically

shuts down because of a low battery condition.

■ You can return to your previous working environment immediately when

you turn on the computer.

■ Saves power by shutting down the system when the computer receives

no input or hardware access for the time period set by the System Hibernate feature.

■ Allows the use of the panel power off feature.

Starting Hibernation Mode

You can also enable Hibernation Mode by pressing FN + F4 - please refer to Chapter 5, The Keyboard, for further details.

To enter Hibernation Mode, follow the steps below.

1. Click Start.

2. Point to the arrow icon ( ) and then select

Hibernate from the menu.

User’s Manual 1-10

Automatic Hibernation Mode

The computer can be configured to enter Hibernation Mode automatically when you press the power button or close the lid. In order to define these settings, you can follow the steps as described below:

1. Click Start and click the Control Panel.

2. Click System and Security and click Power Options.

3. Click Choose what the power button does or Choose what closing the lid does.

4. Enable the desired Hibernation Mode settings for When I press the power button and When I close the lid.

5. Click the Save changes button.

Data save in Hibernation Mode

When you turn off the power in Hibernation Mode, the computer will take a moment to save the current data in memory to the hard disk drive. After you turn off the computer, and the content of memory has been saved to the hard disk drive, turn off the power to any peripheral devices.

Do not turn the computer or devices back on immediately. Wait a moment to let all capacitors fully discharge.

Restarting the computer

Certain conditions require that you reset the computer, for example if:

■ You change certain computer settings.

■ An error occurs and the computer does not respond to your keyboard

commands.

If you need to restart the computer, there are three ways this can be achieved:

■ Click Start, point to the arrow icon ( ) and then select

Restart from the menu.

■ Press CTRL, ALT and DEL simultaneously (once) to display the menu

window, then select Restart from the Shut down options.

■ Press the power button and hold it down for five seconds. Once the

computer has turned itself off, wait between ten and fifteen seconds before turning the power on again by pressing the power button.

Getting Started

System Recovery Options

There is a hidden partition allocated on the hard disk drive for the System Recovery Options. This partition stores files which can be used to repair the system in the event of a problem.

The System Recovery Options feature will be unusable if this partition is deleted.

User’s Manual 1-11

System Recovery Options

The System Recovery Options feature is installed on the hard disk when shipped from the factory. The System Recovery Options menu includes tools to repair startup problems, run diagnostics or restore the system. See the Windows Help and Support content for more information about Startup Repair.

The System Recovery Options can also be run manually to repair problems.

The procedure is as follows. Follow the instructions shown on the onscreen menu.

1. Turn off the computer.

2. While holding the F8 key, turn on the computer.

3. The Advanced Boot Options menu will be displayed. Use the arrow keys to select Repair Your Computer and press ENTER.

4. Follow the on-screen instructions.

Check your Windows® manual for more information on backing up your system (including the system image backup feature).

System Recovery

This section describes the creation of Recovery Media and their use.

Creating Recovery Media

This section describes how to create Recovery Media.

■ Be sure to connect the AC adaptor when you create Recovery Media.

■ Be sure to close all other software programs except the Recovery

Media Creator.

■ Do not run software such as screen savers which can put a heavy load

on the CPU.

■ Operate the computer at full power.

■ Do not use power-saving features.

■ Do not write to the media when the virus check software is running.

Wait for it to finish, then disable virus detection programs including any software that checks files automatically in the background.

■ Do not use utilities, including those intended to enhance hard disk

drive access speed. They may cause unstable operation and damage data.

■ Do not shut down/log off or Sleep/Hibernate while writing or rewriting

the media.

■ Set the computer on a level surface and avoid places subjected to

vibrations such as airplanes, trains, or cars.

■ Do not use on an unstable surface such as a stand.

Getting Started

User’s Manual 1-12

Getting Started

A recovery image of the software on your computer is stored on the hard disk drive, and can be copied to either DVD or USB Flash Memory by using the following steps:

1. Select either blank DVD or USB Flash Memory.

The application will allow you to choose from a variety of different media onto which the recovery image can be copied including DVD-R, DVD-R DL, DVD-RW, DVD+R, DVD+R DL, DVD+RW and USB Flash Memory.

■ Please note that some of the above media may not be compatible with

the optical disc drive installed into your computer. You should therefore verify the optical disc drive supports the blank media you have chosen before proceeding.

■ USB Flash Memory will be formatted and all the data in the USB Flash

Memory will be lost when proceeding.

2. Turn on your computer and allow it to load the Windows 7 operating system from the hard disk drive as normal.

3. Insert the media into the computer.

■ Insert the first blank disc into the optical disc drive tray, or Insert the

USB Flash Memory into one available USB port

4. Double click the Recovery Media Creator icon on the Windows 7 desktop, or select the application from Start Menu.

5. After Recovery Media Creator starts, select the type of media and the title you wish to copy, and then click the Create button.

Restoring the pre-installed software from the Recovery hard disk drive

A portion of the total hard disk drive space is configured as a hidden recovery partition. This partition stores files which can be used to restore pre-installed software in the event of a problem.

If you subsequently set up your hard disk drive again, do not change, delete or add partitions in a manner other than specified in the manual, otherwise you may find that space for the required software is not available.

In addition, if you use a third-party partitioning program to reconfigure the partitions on your hard disk drive, you may find that it becomes impossible to setup your computer.

When the sound mute feature has been activated by pressing the FN + ESC key, be sure to disable this to allow sounds to be heard before starting the restore process. Please refer to Chapter 5, The Keyboard, for further details.

You can not use System Recovery Options if restoring the pre-installed software without System Recovery Options.

User’s Manual 1-13

Getting Started

When you reinstall the Windows operating system, the hard disk will be reformatted and all data will be lost.

1. Turn off your computer.

2. Turn on the computer and when the TOSHIBA screen appears repeatedly press the F8 key.

3. The Advanced Boot Options menu will be displayed. Use the arrow keys to select Repair Your Computer and press ENTER.

4. Select your preferred keyboard layout and press Next.

5. To access the recovery process please log on as an enabled user with sufficent rights.

6. Click TOSHIBA HDD Recovery on the System Recovery Options screen.

7. Follow the on-screen instructions on the TOSHIBA HDD Recovery dialog. The computer will be restored to its factory state.

Please set your BIOS to default before you recover your computer to the factory state!

Restoring the pre-installed software from your created Recovery Media

If the pre-installed files are damaged, you are able to either use the Recovery Media you have created or the hard disk drive recovery process to restore the computer to the state it was in when you originally received it. To perform this restoration, follow the steps below:

You can not use System Recovery Options if restoring the pre-installed software without System Recovery Options.

When you reinstall the Windows operating system, the hard disk will be reformatted and all data will be lost.

1. Load the Recovery Media into the computer and turn off the computer's power.

2. While holding down F12 key on the keyboard, turn on your computer when the appears, release the F12 key.

3. Use the up and down cursor key to select the appropriate option from the menu according to your actual recovery media. Please refer to the

Boot Setting section in Chapter 7, HW Setup for further information.

4. A menu will be displayed from which you should follow the on-screen instructions.

User’s Manual 1-14

TOSHIBA Leading Innovation >>> logo screen

Ordering Recovery Discs from TOSHIBA*

You can order Product Recovery discs for your notebook from the TOSHIBA Europe Backup Media Online Shop.

* Please note that this service is not free-of-charge.

1. Visit https://backupmedia.toshiba.eu on the Internet.

2. Follow the on-screen instructions.

You will receive your Recovery Discs within two weeks after placing your order.

Getting Started

User’s Manual 1-15

The Grand Tour

This chapter identifies the various components of the computer - it is recommended that you become familiar with each before you operate the computer.

Legal Footnote (Non-applicable Icons)

For more information regarding Non-applicable Icons, please refer to the Legal Footnotes section in Appendix E.

Please handle your computer carefully to avoid scratching or damaging the surface.

Front with the display closed

The following figure shows the computer’s front with its display panel in the closed position.

The Grand Tour

Chapter 2

1. System indicators 2. Bridge media slot

Front of the computer with display panel closed

System indicators These LED indicators allow you to monitor the

status of various computer functions and are described in more detail within the System

indicators section.

Bridge media slot This slot lets you insert an

SD™/SDHC™/SDXC™ memory card, miniSD™/microSD™ Card, and MultiMediaCard™. Refer to the Optional devices section in Chapter 3, Hardware, Utilities and

Options.

User’s Manual 2-1

Left side

The Grand Tour

Keep foreign metal objects, such as screws, staples and paper clips, out of the Bridge media slot. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury.

The following figures show the computer’s left side.

1 32 5 64

1 32 4 5 6

1. Cooling vents 5. Microphone jack

2. External monitor port 6. Headphone jack

3. LAN jack 7. HDMI out port*

4. Universal Serial Bus (USB 2.0) port(s)

The left side of the computer

* Provided with some models. Product appearance depends on the model you purchased.

Cooling vents The cooling vents help keep the processor to

avoid overheating.

Do not block the cooling vents. Keep foreign metal objects, such as screws, staples and paper clips, out of the cooling vents. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury.

External monitor port This port provides 15-pin, analog VGA port. This

port allows you to connect an external monitor to the computer.

User’s Manual 2-2

The Grand Tour

LAN jack This jack lets you connect to a LAN. The adaptor

has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX). Some models are equipped with a Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T). Refer to Chapter 4, Operating

Basics, for details.

■ Do not connect any cable other than a LAN cable to the LAN jack. It

could cause damage or malfunction.

■ Do not connect the LAN cable to a power supply. It could cause

damage or malfunction.

HDMI out port HDMI out port can connect with Type A

connector HDMI cable. HDMI cable can send video and audio signals. In

addition to this, it can send and receive control signals.

Some models are equipped with an HDMI out port.

Universal Serial Bus (USB 2.0) port(s)

Universal Serial Bus ports, which comply to the USB 2.0 standard, are provided on the left hand side of the computer.

Keep foreign metal objects, such as screws, staples and paper clips, out of the USB connectors. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury.

Please note that it is not possible to confirm the operation of all functions of all USB devices that are available. In view of this it may be noted that some functions associated with a specific device might not operate properly.

Microphone jack A 3.5 mm mini microphone jack enables

connection of a three-conductor mini jack for monaural microphone input.

Headphone jack A 3.5 mm mini headphone jack enables

connection of stereo headphones.

User’s Manual 2-3

Right side

The Grand Tour

The following figure shows the computer’s right side.

1 2 34

1. Optical disc drive 3. Security lock slot

2. DC IN 19V jack 4. Universal Serial Bus (USB 2.0) port*

The right side of the computer

* Provided with some models. Product appearance depends on the model you purchased.

Optical disc drive The computer is configured with a DVD Super

Multi drive.

DC IN 19V jack The AC adaptor connects to this jack in order to

power the computer and charge its internal batteries. Please note that you should only use the model of AC adaptor supplied with the computer at the time of purchase - using the wrong AC adaptor can cause damage to the computer.

Security lock slot A security cable can be attached to this slot and

then connected to a desk or other large object in order to deter theft of the computer.

Universal Serial Bus (USB 2.0) port

One Universal Serial Bus port, which complies to the USB 2.0 standard, might be provided on the right hand side of the computer.

Back

The following figure shows the computer’s back.

The back of the computer

User’s Manual 2-4

Underside

The following figure shows the underside of the computer. You should ensure that the display is closed before the computer is turned over to avoid causing any damage.

The Grand Tour

1 2 3

1. Battery lock 4. Memory module slot

2. Battery pack 5. Cooling vents

3. Battery release latch

The underside of the computer

Battery lock Slide the battery lock to release the battery pack

ready for removal.

Battery pack The battery pack provides power to the computer

when the AC adaptor is not connected. For more detailed information on the use and operation of the battery pack please refer to Chapter 6, Power

and Power-Up Modes.

Battery release latch Slide and hold this latch into its "Unlock" position

in order to release the battery pack for removal. For more detailed information on removing the battery pack please refer to Chapter 6, Power

and Power-Up Modes.

Memory module slot The memory module slot allows for the

installation, replacement and removal of additional memory module.

Refer to the Additional memory module section in Chapter 3, Hardware, Utilities and Options.

User’s Manual 2-5

Front with the display open

This section shows the computer with the display panel open. In order to open the display, lift the display panel up and position it at a comfortable viewing angle for you.

The Grand Tour

1. Web Camera* 7. Display hinges

2. Web Camera LED* 8. Stereo speakers

3. Microphone* 9. Keyboard

4. Wireless LAN antennas (not shown)* 10. Touch Pad

5. Display screen 11. Touch Pad control buttons

6. Power button

The front of the computer with the display panel open

* Provided with some models. Product appearance depends on the model you purchased.

User’s Manual 2-6

The Grand Tour

Web Camera Web Camera is a device that allows you to

record video or take photographs with your computer. You can use it for video chatting or video conferences using a communication tool such as Windows Live Messenger. TOSHIBA Web Camera Application will help you to add various video effects to your video or photograph.

Enables the transmission of video and use of video chat via the internet using specialized applications.

Some models are equipped with a Web Camera. Please refer to the Web Camera section in

Chapter 4, Operating Basics.

Web Camera LED The Web Camera LED glows when the Web

Camera is operating.

Microphone A built-in microphone allows you to import and

record sounds for your application - please refer to the Sound System section in Chapter 4,

Operating Basics for more information.

Some models are equipped with a built-in microphone.

Wireless LAN antennas

Some computers in this series are equipped with the Wireless LAN antennas.

Display screen Please be aware that, when the computer is

operating on the AC adaptor, the image displayed on the internal screen will be somewhat brighter than when it operates on battery power. This difference in brightness levels is intended to save power when operating on batteries. For more information on the computer's display, please refer to the Display Controller and Video mode section in Appendix B.

Power button Press this button to turn the computer's power on

and off.

Display hinges The display hinges allow the display panel to be

position at a variety of easy-to-view angles.

Stereo speakers The speakers emit sound generated by your

software as well as audio alarms, such as low battery condition, generated by the system.

Keyboard The internal keyboard provides dedicated

numeric keys, dedicated cursor control keys, and

and Keys. Refer to Chapter 5, The

Keyboard, for details.

User’s Manual 2-7

Indicators

System indicators

The Grand Tour

Touch Pad The Touch Pad located in the palm rest is used to

control the movement of the on-screen pointer. For more information, please refer to the Using

the Touch Pad section in Chapter 4, Operating Basics.

Touch Pad control buttons

This section explains indicator functions.

LED system indicators next to their respective icons, glow when specific computer operations are in progress.

DC IN/Battery The DC IN/Battery indicator shows the condition

Power The Power indicator normally glows green when

The control buttons located below the Touch Pad allow you to select menu items or manipulate text and graphics as designated by the on-screen pointer.

System indicators

of the DC IN and the battery's charge - green indicates the battery is fully charged while the power is being correctly supplied from the AC power adaptor. Please refer to Chapter 6, Power

and Power-Up Modes for more information on

this feature.

the computer is turned on. However, if you turn the computer off into Sleep Mode, this indicator will flash green - approximately two seconds on, two seconds off - both while the system is shutting down and while it remains turned off.

User’s Manual 2-8

Keyboard indicators

The following figures show the positions of the CAPS LOCK indicator and the NUM LOCK indicator which show the following conditions:

■ When the CAPS LOCK indicator glows, the keyboard will produce

capitals when any letter is typed.

■ When the NUM LOCK indicator glows, the ten key allows you to enter

numbers.

1. CAPS LOCK indicator 2. NUM LOCK indicator

Keypad indicators

The Grand Tour

CAPS LOCK This indicator glows green when letter keys are

locked into their uppercase format.

NUM LOCK When the NUM LOCK indicator glows, you can

use the number keys on the keyboard for number entry.

Optical disc drives

The computer is installed with a DVD Super Multi drive. A Serial ATA interface controller is used for optical disc operation. When the computer is accessing a optical disc, an indicator on the drive glows.

For information on loading and unloading discs refer to the Using optical

disc drives section in Chapter 4, Operating Basics.

User’s Manual 2-9

Region codes for DVD drives and media

DVD Super Multi drives and their associated media are manufactured according to the specifications of six marketing regions. When you purchase DVD-Video, make sure it matches your drive, otherwise it will not play properly.

Code Region

1 Canada, United States

2 Japan, Europe, South Africa, Middle East

3 Southeast Asia, East Asia

4 Australia, New Zealand, Pacific Islands, Central

America, South America, Caribbean

5 Russia, Indian Subcontinent, Africa, North

Korea, Mongolia

6 China

Writable discs

This section describes the types of writable CD/DVD discs. Check the specifications of your drive to see the types of discs it can write. Use TOSHIBA Disc Creator to write compact discs. Refer to Chapter 4,

Operating Basics.

The Grand Tour

CDs

■ CD-R discs can be written only once. The recorded data cannot be

erased or changed.

■ CD-RW discs including multi speed CD-RW discs, high-speed CD-RW

discs and ultra-speed CD-RW discs can be recorded more than once.

DVDs

■ DVD-R, DVD+R, DVD-R (Dual Layer) and DVD+R (Double Layer) discs

can be written only once. The recorded data cannot be erased or changed.

■ DVD-RW, DVD+RW and DVD-RAM discs can be recorded more than

once.

User’s Manual 2-10

DVD Super Multi drive

The full-size DVD Super Multi drive module lets you record data to rewritable CD/DVDs as well as run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs without using an adaptor.

The read speed is slower at the center of a disc and faster at the outer edge.

DVD read 8 speed (maximum)

DVD-R write 8 speed (maximum)

DVD-R DL write 6 speed (maximum)

DVD-RW write 6 speed (maximum)

DVD+R write 8 speed (maximum)

DVD+R DL write 6 speed (maximum)

DVD+RW write 8 speed (maximum)

DVD-RAM write 5 speed (maximum)

CD read 24 speed (maximum)

CD-R write 24 speed (maximum)

CD-RW write 24 speed (maximum, Ultra-speed media)

The Grand Tour

User’s Manual 2-11

Hardware, Utilities and Options

Chapter 3

Hardware, Utilities and Options

Hardware

This section describes the hardware of your computer. The actual specifications may vary depending on the model you purchased.

Processor

CPU Your computer is equipped with one processor

and processor type varies depending on model. To check which type of processor is included in

your model, open the TOSHIBA PC Diagnostic Tool Utility by clicking Start  All Programs  TOSHIBA  Utilities  PC Diagnostic Tool.

Legal Footnote (CPU)

For more information on the CPU, please refer to the Legal Footnotes section in Appendix E.

Memory

Memory slots 1 GB, 2 GB or 4 GB memory modules can be

installed in the computer's two memory slots for a maximum of 8 GB system memory.

This computer can be equipped with memory modules of a maximum size of 8 GB. The actual amount of useable system memory will be less than the installed memory modules.

It depends on the model you purchased.

User’s Manual 3-1

Hardware, Utilities and Options

Video RAM The memory in a computer's graphics adaptor,

used to store the image displayed on a bitmap display.

The amount of Video RAM available is dependent on the computer's system memory.

Start  Control Panel  Appearance and Personalization  Display  Adjust resolution.

The amount of Video RAM can be verified by clicking the Advanced Settings button in the Screen Resolution window.

If your computer is configured with more than 3 GB memory, the memory might be displayed as approximately 3 GB only (depending on the computer’s hardware specifications).

This is correct because the operating system usually displays the available memory instead of the physical memory (RAM) built into the computer.

Various system components (like the video adaptor’s GPU and PCI devices like Wireless LAN, etc.) require their own memory space. Since a 32-bit operating system cannot address more than 4 GB of memory, these system resources overlap the physical memory. It is a technical limitation that the overlapped memory is not available to the operating system. Even though some tools might display the actual physical memory built into your computer, the memory available to the operating system will still be approximately 3 GB only.

Computers configured with a 64-bit operating system can address 4 GB or more of system memory.

Legal Footnote (Memory (Main System))

For more information regarding Memory (Main System), please refer to the Legal Footnotes section in Appendix E.

Power

Battery pack The computer is powered by one rechargeable

lithium-ion battery pack.

Legal Footnote (Battery Life)

For more information regarding Battery Life, please refer to the Legal Footnotes section in Appendix E.

RTC battery The internal RTC battery backs up the Real Time

Clock (RTC) and calendar.

User’s Manual 3-2

Hardware, Utilities and Options

AC adaptor The AC adaptor provides power to the system

and recharges the batteries when they are low. It comes with a detachable power cord which will either have a 2-pin or 3-pin plug enclosure.

As the AC adaptor is universal, it can receive a range of AC voltages from 100 to 240 volts, however you should note that the output current varies among different models. Using the wrong adaptor can damage your computer.

Disks

Hard disk drive or Solid state drive

■ In this manual, the word "HDD" or "Hard disk drive" also refers to the

SSD unless otherwise stated.

■ SSD is a large-capacity storage media which uses Solid-State Memory

in place of a magnetic disk of the hard disk.

Under certain unusual conditions of prolonged non-use and/or exposure to high temperatures, the SSD may be vulnerable to data retention errors.

The size of the hard disk drive or Solid State Drive varies depending on the model.

To check which type of HDD/SSD is included in your model, open the TOSHIBA PC Diagnostic Tool Utility by clicking Start  All Programs  TOSHIBA  Utilities  PC Diagnostic Tool.

Please note that part of the hard disk or Solid state drive's overall capacity is reserved as administration space.

Legal Footnote (Hard Disk Drive (HDD) Capacity)

For more information regarding Hard Disk Drive (HDD) Capacity, please refer to the Legal Footnotes section in Appendix E.

Optical disc drive

Drive The following optical disc drives may be pre-

installed in this computer.

■ DVD Super Multi drive

2.6GB and 5.2GB DVD-RAM media cannot be read from or written to.

User’s Manual 3-3

Hardware, Utilities and Options

Display

The computer's internal display panel supports high-resolution video graphics and can be set to a wide range of viewing angles for maximum comfort and readability.

Display panel 39.6cm (15.6") TFT LCD screen, 16 million

colors, with the following resolution:

■ HD, 1366 horizontal x 768 vertical pixels

Intel® Display Power Saving Technology

Intel GPU model may include the Display Power Saving Technology feature that can save the computer's power consumption by optimizing picture contrast on the internal LCD.

This feature can be used if the computer is:

■ running under battery mode

■ using the internal LCD display only

The Display Power Saving Technology feature can be enabled in the Intel Graphics and Media Control Panel.

You can access this control panel in one of the following ways:

■ Click Start  Control Panel. Select Large icons or Small icons in

View by, and then click Intel(R) Graphics and Media.

■ Right-click on the desktop and click Graphics Properties....

In this control panel,

1. Select Basic Mode and click OK.

2. Click Power.

3. Select On battery from the drop-down menu in Power Source and then select the Display Power Saving Technology check box.

If you want to improve the picture quality under the conditions mentioned above, adjust the setting towards Maximum Quality or disable this feature.

AMD® Vari-Bright

™

AMD GPU model may include the AMD® Vari-Bright™ feature that can save the computer's power consumption by optimizing picture contrast on the internal LCD.

This feature can be used if the computer is:

■ running under battery mode

■ using the internal LCD display only

™

The Vari-Bright

feature is disabled at factory default. If you want to

expand computer’s battery life, you can enable this feature. The Vari-Bright

User’s Manual 3-4

™

feature can be enabled in the Catalyst Control Center.

Hardware, Utilities and Options

To access this center, go to

Start  All Programs  Catalyst Control Center  CCC

In this control center,

1. Select Power, and then select PowerPlay

2. Select the Enable Vari-Bright

3. Click OK.

If you want to disable this feature under the conditions mentioned above, clear the Enable Vari-Bright™ check box.

™

check box.

™

Legal Footnote (LCD)

For more information regarding the LCD, please refer to the Legal Footnotes section in Appendix E.

Graphics controller The graphics controller maximizes display

performance. Refer to Display Controller and

Video mode section in Appendix B for more

information.

Legal Footnote (Graphics Processing Unit ("GPU"))

For more information regarding the Graphics Processing Unit ("GPU"), please refer to the Legal Footnotes section in Appendix E.

Sound

Sound system The integrated sound system provides support

for the computer's internal speakers and microphone, as allowing an external microphone and headphones to be connected via the appropriate jacks.

Multimedia

Web Camera Web Camera is a device that allows you to

Please refer to the Web Camera section in Chapter 4, Operating Basics.

User’s Manual 3-5

Hardware, Utilities and Options

Communications

LAN Some computers in this series have built-in

support for Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX) and Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T).

Bluetooth Some computers in this series have Bluetooth

wireless communication function which eliminates the need for cables between electronic devices such as computers, printers and mobile phones. When it is enabled, Bluetooth provides the wireless personal area network environment which is safe and trustworthy, that is quick and easy.

Wireless LAN Some computers in this series are equipped with

a Wireless LAN module that is compatible with other Wireless LAN systems based on Direct Sequence Spread Spectrum/Orthogonal Frequency Division Multiplexing radio technology that complies with the IEEE 802.11 Standard.

Legal Footnote (Wireless LAN)

For more information regarding Wireless LAN, please refer to the Legal Footnotes section in Appendix E.

Special features

The following features are either unique to TOSHIBA computers or are advanced features which make the computer more convenient to use.

Access each function using the following procedures. *1 To access the Power Options, click Start  Control Panel  System

and Security  Power Options.

Hot keys Hot keys are specific key combinations that let

you quickly change the system configuration directly from the keyboard without running a system program.

Display automatic power off

User’s Manual 3-6

This feature automatically cuts off power to the computer's display panel when there is no keyboard input for a specified time, with power being restored the next time a key is pressed. This can be specified in the Power Options.

Hardware, Utilities and Options

HDD automatic power

off

This feature automatically cuts off power to the hard disk drive when it is not accessed for a specified time, with power being restored when the hard disk drive is next accessed. This can be specified in the Power Options.

System automatic Sleep/Hibernation

Mode

This feature automatically shuts down the system into either Sleep Mode or Hibernation Mode when there is no input or hardware access for a specified time. This can be specified in the Power Options.

Power on password Two levels of password security, supervisor and

user, are available to prevent unauthorized access to your computer.

Instant security A specific hot key function automatically locks the

system providing data security.

Intelligent power supply

A microprocessor in the computer's intelligent power supply detects the battery's charge, automatically calculates the remaining battery capacity and protects electronic components from abnormal conditions such as a voltage overload from the AC adaptor. This can be specified in the Power Options.

Battery save mode

This feature lets you configure the computer in order to save battery power. This can be specified in the Power Options.

Panel power on/off

This feature automatically turns power to the computer off when the display panel is closed, and turns it back on when the display panel is opened. This can be specified in the Power Options.

Low battery automatic Hibernation Mode

When battery power is exhausted to the point that computer operation cannot be continued, the

system automatically enters Hibernation Mode and shuts itself down. This can be specified in the Power Options.

User’s Manual 3-7

Hardware, Utilities and Options

Heat dispersal

Hibernation Mode This feature lets you turn off the power to the

Sleep Mode If you have to interrupt your work, you can use

USB Wakeup function This function restores the computer from Sleep

To protect against overheating, the processor has an internal temperature sensor so that, if the computer's internal temperature rises to a certain level, the cooling fan is turned on or the processing speed is lowered. This can be specified in the Power Options.

Maximum Performance

Battery Optimized Turns on fan first, then if

computer without exiting from your software. The contents of main memory are automatically saved to the hard disk drive so that when you next turn the power on again, you can continue working right where you left off. Refer to the Turning off

the power section in Chapter 1, Getting Started,

for more details.

this feature to allow you to turn off power to the computer without exiting from your software. Data is maintained in the computer's main memory so that when you next turn on the power, you can continue working right where you left off.

Mode depending on the external devices connected to the USB ports.

For example, if a mouse or USB keyboard is connected to a USB port, clicking the mouse button or pressing the keyboard will wakeup the computer.

Turns on fan first, then if necessary lowers the processing speed.

necessary lowers the processing speed early than Maximum Performance mode for battrey life saving.

Utilities and Applications

This section describes the pre-installed utilities that come with the computer and details how to start them. For further information on their operation, you may refer to each utility's online manual, help files or README.TXT file (if applicable).

You may not have all the utilities or applications listed below depending on the model you purchased.

TOSHIBA Power Saver

User’s Manual 3-8

TOSHIBA Power Saver provides you with the features of more various power supply managements.

Hardware, Utilities and Options

TOSHIBA PC Diagnostic Tool

The TOSHIBA PC Diagnostic Tool will display basic system configuration information and allow the functionality of some of the computer's builtin hardware devices to be tested.

TOSHIBA Flash Cards The TOSHIBA Flash Cards provide a quick way

to modify selected system functions.

■ Hot key function

HW Setup This utility allows you to customize your

hardware settings according to the way you work with the computer and the peripherals you use.

TOSHIBA Accessibility

The TOSHIBA Accessibility utility provides support to movement impaired users when they need to use the TOSHIBA Hot-key functions. In use, the utility allows you to make the FN key 'sticky', that is you can press it once, release it, and they press one of the "Function" keys in order to access its specific function. When set, the FN key will remain active until another key is pressed.

TOSHIBA Face Recognition

TOSHIBA Face Recognition uses a face verification library to verify the face data of users when they log in to Windows. If the verification is successful, the user will be logged into Windows automatically. The user can thus avoid having to enter a password or the like, which makes the login process easier.

For more information, please refer to the Using

the TOSHIBA Face Recognition section in

Chapter 4, Operating Basics.

TOSHIBA VIDEO PLAYER

This software is provided for playback of DVD Video.

It has an on-screen interface and functions. Click

Start  All Programs  TOSHIBA VIDEO PLAYER  TOSHIBA VIDEO PLAYER.

For more information, please refer to the

TOSHIBA VIDEO PLAYER section in Chapter 4, Operating Basics.

TOSHIBA Assist TOSHIBA Assist is a graphical user interface that

provides access to specific tools, utilities and applications that make the use and configuration of the computer easier.

User’s Manual 3-9

Hardware, Utilities and Options

TOSHIBA ConfigFree TOSHIBA ConfigFree is a suite of utilities that

improve the ease and control of communication devices and network connections, help in the identification of communication problems and allow the creation of profiles if you need to switch between different locations and communication networks. To access this utility, click Start  All

Programs  TOSHIBA  ConfigFree.

TOSHIBA Disc Creator

You can create CDs and DVDs in a number of formats including audio CDs that can be played on a standard CD player, and data CDs/DVDs which can store copies of the files and folders on your computer's hard disk drive. This software can be used on models with a DVD Super Multi drive.

To start this utility, click Start  All Programs 

TOSHIBA  CD&DVD Applications  Disc Creator.

TOSHIBA DVD-RAM Utility

This utility has the function of Physical Format and Write-Protect to DVD-RAM. This utility is contained the setup module of TOSHIBA Disc Creator. To start this utility, click Start  All

Programs  TOSHIBA  CD&DVD Applications  DVD-RAM Utility.

TOSHIBA HDD/SSD Alert Utility

This utility includes wizard functions to monitor the Disk Drive operating status and execute the system backup.

To access the utility, click Start  All

Programs  TOSHIBA  Utilities  HDD SSD Alert.

TOSHIBA Service Station

This application allows your computer to automatically search for TOSHIBA software updates or other alerts from TOSHIBA that are specific to your computer system and its programs. When enabled, this application periodically transmits to our servers a limited amount of system information, which will be treated in strict accordance with the rules and regulations as well as applicable data protection law.

To access this utility, click Start  All

Programs  TOSHIBA  Utilities  Service Station.

User’s Manual 3-10

Hardware, Utilities and Options

Corel Label@Once Label@Once allows users to design and print the

label of discs. The Labelflash feature is also supported which

allows text and images to be printed on the label surface of Labelflash compatible media without using a printer.

Labelflash features cannot be used in models that do not have a DVD Super Multi drive with Labelflash.

In order to determine if the optical disc drive installed in your computer supports Labelflash follow the steps as detailed below:

1. Launch Corel Label@Once (the operation varies depending on the

models you purchased):

■ Click Start  All Programs  Corel Label@Once  Corel

Label@Once.

2. Click the General tab.

3. Choose optical disc drive for Printer.

If the drive name is displayed in Step 3, your computer's optical disc drive supports Labelflash.

TOSHIBA Bulletin Board

Bulletin Board is a convenient place to pin things to visually organize in a fun and creative way.

Simply drag and drop your favorite pictures, files or notes to pin them on the Board. You can use it to create thumbnail shortcuts, reminders, to-do list and so on according to your personal style.

To access this utility, click Start  All

Programs  TOSHIBA  TOSHIBA Bulletin Board.

TOSHIBA ReelTime This application is a graphical history/indexing

tool that enables you to view recently accessed files in a fun and easy-to-use format. View and scroll through your history of opened or imported

files via thumbnails in an intuitive user interface. To access this utility, click Start  All

Programs  TOSHIBA  TOSHIBA ReelTime.

TOSHIBA Resolution+ Plug-in For Windows Media Player

The plug-in lets you upconverts wmv and mp4 videos on Windows Media Player.

For more information, please refer to the TOSHIBA Resolution+ Plug-in for Windows Media Player Help.

To access it, click Start  All Programs 

TOSHIBA  TOSHIBA Resolution+ Plug-in for Windows Media Player  TOSHIBA Resolution+ Plug-in for Windows Media Player Help.

User’s Manual 3-11

Hardware, Utilities and Options

TOSHIBA Media Controller

TOSHIBA Speech System

Optional devices

Optional devices can expand the computer's capabilities and its versatility. This section describes the connection or installation of the following devices:

This application allows you to control your music, pictures and videos by streaming content to any compatible device in your home.

To access this utility, click Start  All

Programs  TOSHIBA  TOSHIBA Media Controller  TOSHIBA Media Controller.

For more information, please refer to the TOSHIBA Media Controller Help.

The TOSHIBA Speech System consists of a voice-composition application (text-to-speech) that analyzes documents and reads them aloud, and a speech-recognition application that recognizes the words you speak into a microphone. This allows you to control and operate various Windows programs by voice command rather than using the keyboard or a mouse.

To access this utility, click Start  All Programs  TOSHIBA  Speech System.

For more information, please refer to the TOSHIBA Speech System Help.

Cards/memory

■ Bridge media slot

■ Secure Digital™ (SD) Card (SD memory card, SDHC memory card,

SDXC memory card, miniSD Card, microSD Card)

■ MultiMediaCard

■ Additional memory module

Peripheral devices

■ Hard disk drive pack

■ External monitor

■ HDMI Device

Other

■ Security lock

User’s Manual 3-12

Bridge media slot

The computer is equipped with a Bridge media slot that can accommodate some kinds of memory media with various memory capacities so that you can easily transfer data from devices, such as digital cameras and Personal Digital Assistants.

Keep foreign objects out of the Bridge media slot. Never allow metal objects, such as screws, staples and paper clips, to enter the computer or Keyboard. Foreign metal objects can create a short circuit, which can cause computer damage and fire, possibly resulting in serious injury.

■ This Bridge media slot supports the following memory media.

■ Secure Digital (SD) Card (SD memory card, SDHC memory card,

SDXC memory card, miniSD Card, microSD Card)

■ MultiMediaCard (MMC™)

■ Please note that an adaptor is required to use miniSD/microSD Card.

■ Please note that not all memory media have been tested and verified

to work correctly. Therefore, it is not possible to guarantee that all memory media will operate properly.

■ The slot does not support Magic Gate functions.

Hardware, Utilities and Options

Secure Digital (SD) Card

Examples of memory media

microSD card adaptor and microSD card

MultiMediaCard (MMC)

Memory media

This section provides the important safety precautions in order to handle your memory media.

Points to note about the SD/SDHC/SDXC memory card

SD/SDHC/SDXC memory cards comply with SDMI (Secure Digital Music Initiative), which is a technology adopted to prevent unlawful copy or playback of digital music. For this reason, you cannot copy or playback protected material on another computer or other device, and you may not reproduce any copyrighted material except for your personal enjoyment.

Below is a simple explanation for distinguishing SD memory cards from SDHC and SDXC memory cards.

User’s Manual 3-13

Hardware, Utilities and Options

■ SD, SDHC and SDXC memory cards appear the same externally.

However, the logo on SD, SDHC and SDXC memory cards is different, so pay careful attention to the logo when purchasing.

■ The SD memory card logo is ( ).

■ The SDHC memory card logo is ( ).

■ The SDXC memory card logo is ( ).

■ The maximum capacity of SD memory cards is 2GB. The maximum

capacity of SDHC memory cards is 32GB. The maximum capacity of SDXC memory cards is 64GB.

Card Type Capacities

SD 8MB, 16MB, 32MB, 64MB, 128MB, 256MB,

512MB, 1GB, 2GB

SDHC 4GB, 8GB, 16GB, 32GB

SDXC 64GB

Memory media format

New media cards are formatted according to specific standards. If you wish to reformat a media card, be sure to do so with a device that uses media cards.

Formatting an SD/SDHC/SDXC memory card

SD/SDHC/SDXC memory cards are sold already formatted in conformity to specific standards. If you reformat an SD/SDHC/SDXC memory card, be sure to reformat it with a device such as digital camera or digital audio player that uses the SD/SDHC/SDXC memory cards, not with the format command provided within Windows.

Should you need to format all areas of the memory card, including the protected area, you will need to obtain an appropriate application that applies the copy protection system.

Media care

Observe the following precautions when handling the card.

Card care

■ Do not twist or bend cards.

■ Do not expose cards to liquids or store in humid areas or lay media

close to containers of liquid.

■ Do not touch the metal part of a card or expose it to liquids or let it get

dirty.

■ After using card, return it to its case.

User’s Manual 3-14

Hardware, Utilities and Options

■ The card is designed so that it can be inserted only one way. Do not try

to force the card into the slot.

■ Do not leave a card partially inserted in the slot. Press the card until you

hear it click into place.

Memory card care

■ Set the write-protect switch to the lock position, if you do not want to

record data.

■ Memory cards have a limited lifespan, so it is important to backup

important data.

■ Do not write to a card if the battery power is low. Low power could affect

writing accuracy.

■ Do not remove a card while read/write is in progress.

For more details on using memory cards, see manuals accompanying the cards.

About the write-protect

The following memory media have a function for protect.

■ SD Card (SD memory card, SDHC memory card, SDXC memory card)

■ MultiMediaCard (MMC)

Set the write-protect switch to the lock position, if you do not want to record data.

Inserting a memory media

The following instructions apply to all types of supported media devices. To insert a memory media, follow the steps as detailed below:

1. Turn the memory media so that the contacts (metal areas) are face down.

2. Insert the memory media into the Bridge media slot on the side of the computer.

3. Press the memory media gently to ensure a firm connection is made.

1. Bridge media slot 2. Memory media

Inserting a memory media

User’s Manual 3-15

Hardware, Utilities and Options

■ Make sure memory media is oriented properly before you insert it. If

you insert the media in wrong direction, you may not be able to remove it.

■ When inserting memory media, do not touch the metal contacts. You

could expose the storage area to static electricity, which can destroy data.

■ Do not turn the computer off or switch to Sleep Mode or Hibernation

Mode while files are being copied - doing so may cause data to be lost.

Removing a memory media

The following instructions apply to all types of supported media devices. To remove a memory media, follow the steps as detailed below:

1. Open the Safely Remove Hardware and Eject Media icon on the Windows Taskbar.

2. Point to memory media and click the left Touch Pad control button.

3. Pull the memory media to partially extend it out of the computer.

4. Grasp the media and remove it.

1. Bridge media slot 2. Memory media

Removing memory media

■ If you remove the memory media or turn off the power while the

computer is accessing the memory media, you may lose data or damage the media.

■ Do not remove the memory media while the computer is in Sleep or

Hibernation Mode. The computer could become unstable or data in the memory media could be lost.

■ Do not remove only the miniSD/microSD Card while leaving the

adaptor in the Bridge Media slot.

User’s Manual 3-16

Hardware, Utilities and Options

Additional memory module

You can install additional memory into the computer in order to increase the amount of system memory that is available. This section describes how to install and remove optional memory modules.

■ You should place a mat beneath the computer in order to prevent the

computer's lid from becoming scratched or damaged when you are installing/replacing the memory module. In this instance you should avoid mats that are made of materials that hold or generate static electricity.

■ When installing or removing a memory module, you must ensure that

you do not touch any other internal areas of the computer.

■ Insert the two memory modules into Slot A and Slot B respectively.

The computer will operate in dual channel mode. You can access the inserted memory modules efficiently in dual channel.

■ Use a point size 0 Phillips screwdriver to remove and fasten the

screws - the use of an incorrect screwdriver can damage the screw heads.

■ Use only memory modules approved by TOSHIBA.

■ Do not try to install or remove a memory module under the following

conditions. a. The computer is turned on. b. The computer was shut down in either Sleep or Hibernation Mode. c. Wake-up on LAN is enabled. d. The wireless communication function is on.

■ Be careful not to let screws or other foreign matter fall into the

computer. It could cause malfunction or electric shock.

■ Additional memory module is a precision electronic component that

may be fatally damaged by static electricity. Since the human body can carry static electricity, it is important that you discharge yourself before touching or installing any additional memory modules. To discharge your body’s static electricity, simply touch any metal close to you with bare hands.

Installing a memory module

To install a memory module, follow the steps as detailed below:

1. Shut down the computer - make sure the Power indicator is off (refer to the Turning off the power section in Chapter 1, Getting Started if required).

2. Remove the AC adaptor and all cables and peripherals connected to the computer.

3. Close the display panel.

4. Turn the computer upside down and remove the battery pack (refer to

Replacing the battery pack section in Chapter 6, Power and Power-Up Modes, if required).

User’s Manual 3-17

Hardware, Utilities and Options

5. Loosen the screws securing the memory module cover in place - please note that this screw is attached to the cover in order to prevent it from being lost.

Use a point size 0 Phillips screwdriver.

6. Slide your fingernail or a thin object under the cover and lift it off.

1. Memory module cover 2. Screws

Removing the memory module cover

7. Align the notch of the memory module with that of the memory slot and gently insert the module into the slot at about a 45 degree angle before holding it down until the latches on either side snap into place.

1. Notch 3. Slot B

2. Slot A

Seating the memory module

User’s Manual 3-18

Hardware, Utilities and Options

■ Never allow metal objects, such as screws, staples and paper clips, to

enter the computer. Foreign metal objects can create a short circuit, which can cause computer damage and fire, possibly resulting in serious injury.

■ Do not touch the connectors on the memory module or on the

computer. Debris on the connectors may cause memory access problems.

■ The slot A is reserved for the first memory module. Use the slot B for

expanded memory. If only one module is installed, use the slot A. When inserting or removing memory modules, use the A and B marked on the computer chassis to determine which slot is A and which is B.

■ Align the grooves along the edges of the memory module with the

locking tabs on the connector and insert the module into the connector firmly - if you find it difficult to install the memory module, gently prise the locking tabs outwards using the tip of your finger.

■ Please also ensure that you hold the memory module along its left and

right hand edges - the edges with the grooves in.

8. Seat the memory module cover in place and secure it with the screws.

Take care to ensure that the memory module cover is firmly closed.

1. Memory module cover 2. Screws

Seating the memory module cover

9. Install the battery pack - refer to Replacing the battery pack section in Chapter 6, Power and Power-Up Modes, if required.

10. Turn your computer over.

11. Turn the computer on and make sure the added memory is recognized to confirmed it, Start  Control Panel  System and Security  System icon.

User’s Manual 3-19

Hardware, Utilities and Options

Removing a memory module

To remove the memory module, follow the steps as detailed below:

1. Shut down the computer - make sure the the

Turning off the power

section in Chapter 1,

required).

2. Remove the AC adaptor and all cables and peripherals connected to the computer.

3. Close the display panel.

4. Turn the computer upside down and remove the battery pack (refer to

Replacing the battery pack section in Chapter 6, Power and Power-Up Modes, if required).

5. Loosen the screw securing the memory module cover in place - please note that this screw is attached to the cover in order to prevent it from being lost.

6. Slide your fingernail or a thin object under the cover and lift it off.

7. Push the latches away from the module in order to release it - a spring will force one end of the module up at an angle.

8. Grasp the module by its edges and remove it from the computer.

■ If you use the computer for a long time, the memory modules and the

circuits locating close to the memory modules will become hot. In this case, let them cool to room temperature before you replace them. Or you will get burnt if you touch any of them.

■ Do not touch the connectors on the memory module or on the computer.

Debris on the connectors may cause memory access problems.

Power

indicator is off (refer to

Getting Started

1. Latches

Removing the memory module

9. Seat the memory module cover in place and secure it with the screw.

Take care to ensure that the memory module cover is firmly closed.

10. Install the battery pack - refer to Replacing the battery pack section in Chapter 6, Power and Power-Up Modes, if required.

11. Turn your computer over.

User’s Manual 3-20

Hardware, Utilities and Options

External monitor

An external analog monitor can be connected to the external monitor port on the computer. To connect a monitor, follow the steps as detailed below:

Connecting the monitor cable

1. Turn the computer's power off.

2. Connect the monitor cable to the external monitor port.

1. External monitor port 2. Monitor cable

Connecting the monitor cable to the external monitor port

3. Turn the external monitor's power on.

4. Turn the computer's power on.

When you turn on the power, the computer will automatically recognize the monitor and determine whether it is a color or monochrome device. In the event that you find that there are issues getting an image displayed on the correct monitor, you should consider using the FN + F5 hot key to change the display settings (if you then disconnect the external monitor before you turn the computer's power off, be sure to press FN + F5 hot key again to switch to the internal display).

Please refer to Chapter 5, The Keyboard, for further details on using hot keys to change the display setting.

Do not disconnect the external monitor while in Sleep or Hibernation Mode. Turn off the computer before disconnecting the external monitor.

When displaying desktop at external analog monitor, desktop is sometimes displayed on the center of the monitor with black bars around desktop (with small size).

At that time, please read the manual of the monitor and set the display mode which is supporting at the monitor. Then it will be displayed with suitable size with correct aspect ratio.

User’s Manual 3-21

Hardware, Utilities and Options

HDMI Devices

An HDMI monitor can be connected to the HDMI out port on the computer. To connect monitor, follow the steps as detailed below:

As the port operation of all HDMI (High-Definition Multimedia Interface) monitors have not been confirmed, some HDMI monitors may not function properly.

Connecting the HDMI out port

1. Plug one end of the HDMI cable into the HDMI out port of the HDMI device.

2. Plug the other end of the HDMI cable into the HDMI out port on your computer.

Please connect or disconnect an HDMI device to or from the computer under the following conditions:

■ The computer is turned on.

■ The computer is completely turned off.

Do not do so when the computer is in Sleep Mode or Hibernation Mode.

■ When you connect a television or external monitor to the HDMI port,

the display output device is set to HDMI.

■ When you unplug the HDMI cable and re-plug it, please wait at least 5

seconds before you re-plug the HDMI cable again.

■ When you change the display output device by hot key like FN + F5,

the playback device may not switch automatically. In this case, in order to set the playback device to the same device as the display output device, please adjust the playback device manually by the following steps:

a. Click Start  Control Panel  Hardware and Sound  Sound. b. In the Playback tab, select the playback device which you want to

switch to.

c. To use the internal speakers on your computer, select Speakers.

To use the television or the external monitor that you have connected to the computer, select a different playback device.

d. Click the Set Default button. e. Click OK to close the Sound dialog.

User’s Manual 3-22

Hardware, Utilities and Options

Settings for display video on HDMI

To view video on the HDMI device,be sure to configure the following settings otherwise you may find that nothing is displayed.

■ Be sure to use the FN + F5 HotKey to select the display device before

starting to play video. Do not change the display device while playing video.

■ Do not change the display device under the following conditions.

■ While data is being read or written.

■ While communication is being carried out.

Select HD Format

To select the display mode, follow the steps as detailed below:

1. Click Start and click Control Panel.

2. Click Appearance and Personalization.

3. Click Display.

4. Click Change display settings.

5. Click Advanced settings.

6. Click List All Modes.

7. Select the one of the below selection at "List All Modes".

Display mode at "List All Modes"

1920 by 1080, True Color (32bit), 60Herts

1920 by 1080, True Color (32bit), 30Herts (Interlaced)

1280 by 720, True Color (32bit), 60Herts

720 by 576, True Color (32bit), 50Herts

720 by 480, True Color (32bit), 60Herts

HD Format

1080p

1080i

720p

576p

480p

The above display mode is a typical HDMI display mode. The selectable display modes will vary for different HDMI monitors.

Security lock

A security locks enable you to anchor your computer a desk or other heavy object in order to help prevent unauthorized removal or theft. The computer has a security lock slot on its right side into which you can attach one end of the security cable, while the other end attaches to a desk or similar object. The methods used for attaching security cables differ from product to product. Please refer to the instructions for the product you are using for more information.

User’s Manual 3-23

Connecting the security lock

In order to connect a security cable to the computer, follow the steps as detailed below:

1. Turn the computer so its right side faces you.

2. Align the security cable with the lock slot and secure it in place.

1. Security lock slot

Optional accessories

You are able to add a number of options and accessories in order to make your computer even more powerful and convenient to use. For reference, the following list details some of the items that are available from your reseller or TOSHIBA dealer:

DDR3-1066/1333 Memory Kit

Universal AC Adaptor If you frequently use your computer at more than

Battery Pack An additional battery pack can be purchased for

High Capacity Battery Pack

Hardware, Utilities and Options

Security lock

A 1 GB, 2 GB or 4 GB memory module (DDR31066/1333) can easily be installed in the computer.

one site, it may be convenient to purchase an additional AC adaptor to be kept at each site in order to remove the need to always carry the adaptor with you.

use as either a spare or replacement. Please refer to Chapter 6, Power and Power-Up Modes for further information.

An additional battery pack can be purchased for use as either a spare or replacement.

User’s Manual 3-24

Operating Basics

This chapter describes the basic operations of your computer, highlights the precautions that should be taken when using it.

Using the Touch Pad

To use the Touch Pad, simply touch and move your fingertip across it in the direction you want the on-screen pointer to go.

Operating Basics

Chapter 4

1. Touch Pad 2. Touch Pad control buttons

Touch Pad and Touch Pad control buttons

The two buttons below the Touch Pad are used like the buttons on a standard mouse - press the left button to select a menu item or to manipulate text or graphics designated by the pointer, and press the right button to display a menu or other function depending on the software you are using.

You can also tap the Touch Pad to perform functions similar to those of the left button on a standard mouse.

Click: Tap once Double-click: Tap twice Drag and drop: Tap to select the item(s) you want to move, leave your

finger on the Touch Pad after the second tap and then move the item(s) to their new destination.

User’s Manual 4-1

Web Camera

Web Camera is a device that allows you to record video or take

photographs with your computer. You can use it for video chatting or video conferences using a communication tool such as Windows Live Messenger. TOSHIBA Web Camera Application will help you to add various video effects to your video or photograph.

Enables the transmission of video and use of video chat via the internet using specialized applications.

The effective pixel count for this web camera is 0.3 million (maximum photograph size: 640x480 pixels) or 1.3 million (maximum photograph size: 1280x1024 pixels).

Some models are equipped with a Web Camera. Please refer to the Web Camera Application Online Help for details.

1. Web Camera 3. Microphone

2. Web Camera LED

Web Camera

Operating Basics

■ Do not point the web camera directly at the sun.

■ Do not touch or press strongly on the web camera lens. Doing so may

reduce image quality. Use an eyeglass cleaner (cleaner cloth) or other soft cloth to clean the lens if it becomes dirty.

■ Setting the [Size] to more than "800x600" will cause a larger amount of

data to be written to the hard disk drive and may interfere with smooth recording.

■ When recording in dimly lit environments, select "Night Mode" which

allows for brighter images with less noise.

User’s Manual 4-2

Using the TOSHIBA Face Recognition

TOSHIBA Face Recognition uses a face verification library to verify the face data of users when they log in to Windows. The user can thus avoid having to enter a password or the like, which makes the login process easier. This software is preinstalled with some models.

■ TOSHIBA Face Recognition does not guarantee the correct

identification of a user. Changes to the likeness of a registrant, such as hair style changes, wearing a cap, or wearing glasses may effect the recognition rates when such changes occur after the registrant had registered.

■ TOSHIBA Face Recognition may incorrectly recognize faces that are

similar to a registrant.

■ For high security purposes, TOSHIBA Face Recognition is not a

suitable substitute for Windows passwords. When security is a high priority, use your established Windows passwords to log in.

■ Bright background light and/or shadows may prevent a registrant from

being recognized correctly. In that case, log in using your Windows password. If recognition of a registrant fails repeatedly, refer to your computer documentation to learn ways to improve recognition performance.

■ TOSHIBA Face Recognition records face data in a log when face

recognition fails. When transferring ownership or disposing of your computer, please uninstall the application or delete all the logs created by the application. For details on how to do this, see help file.

■ TOSHIBA Face Recognition can be used only in Windows Vista and

Windows 7.

Operating Basics

Disclaimer

Toshiba does not guarantee that the face recognition utility technology will be completely secure or error-free. Toshiba does not guarantee that the face recognition utility will accurately screen out unauthorized users at all times. Toshiba is not liable for any failure or damage that might arise out of the use of the face recognition software or utility.

TOSHIBA, ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS, PROFITS, PROGRAMS, DATA, NETWORK SYSTEMS OR REMOVABLE STORAGE MEDIA ARISING OUT OF OR RESULTING FROM THE USE OF THE PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY THEREOF.

User’s Manual 4-3

How to register the Face Recognition Data

Take a picture for facial verification purposes, and register the data needed when you log in. To register the data needed when you log in, follow the steps as described below:

1. To launch this utility, click Start  All Programs  TOSHIBA  Utilities  Face Recognition.

■ The Registration screen is displayed for a logged-in user whose

face has not been registered.

■ The Management screen is displayed for a logged-in user whose

face has already been registered.

2. Click the Register button. The Registration screen is displayed.

■ If you wish to practice, click on the Next button in the Registration

screen.

■ If you do not wish to practice, click on the Skip button in the

Registration screen.

3. Click the Next button to start the guide. Please follow the guide to practice.

■ Click the Back button to practice the guide once more.

4. Click the Next button to start image-capturing process. Adjust the position of your face so that it fits within the face-shaped frame.

5. Once your face has been positioned properly, the recording will commence. Start moving your neck very slightly to the left and right, and then move your neck down and up.

6. Registration will end after you have repeatedly moved your neck left, right, down and up. When the register succeeds, below message will be displayed on the screen:

"Registration successful. Now we’ll do the verification test. Click the Next button."

Click the Next button to perform the verification test.

7. Perform the verification test. Face the screen as you do when you register.

■ If verification fails, click the Back button and re-register. Please refer

to step 6 from step 4.

8. If verification is successful, click the Next button and register an account.

9. Register the account. Fill in all the fields.

10. The Management screen is displayed. The registered account name will be displayed. Clicking on it will cause the captured image of your face to be displayed on the left.

Operating Basics

User’s Manual 4-4

How to Delete the Face Recognition Data

Delete image data, account information, and personal record data created during registration. To delete the Face Recognition Data, follow the steps as described below:

1. To launch this utility, click Start  All Programs  TOSHIBA  Utilities  Face Recognition. The Management screen is displayed.

2. Select a user which is displayed in the Management screen.

3. Click the Delete button. "You are about to delete the user data. Would you like to continue?" will be displayed on the screen.

■ If you do not want the data to be deleted, click the No button and

you will then be returned to the Management screen.

■ Clicking on the Yes button will remove the selected user from the

Management screen.

How to launch the help file

For further information on this utility, please refer to help file.

1. To launch the help file, click the Help button in the Management screen.

Windows Logon via TOSHIBA Face Recognition

This section explains how to login to Windows with TOSHIBA Face Recognition. Two authentication modes are provided.

■ 1:N Mode Login screen: If the face authentication tile is selected by

default, you can log in without using the keyboard or mouse.

■ 1:1 Mode Login screen: This mode is essentially the same as AUTO

mode, but the Select Account screen will appear before the Display Captured Image screen, and you will need to select the user account to be authenticated in order to start the authentication process.

Operating Basics

1:N Mode Login screen

1. Turn on the computer.

2. The Select Tiles screen will be displayed.

3. Select Start face recognition ().

4. "Please face the camera" will be displayed.

5. Verification will be performed. If the authentication is successful, the image data taken in step 4 will be faded in and placed over one another.

■ If an error occurs during authentication, you will be returned to the

Select Tiles screen.

6. The Windows Welcome screen will be displayed, and will be logged in automatically to Windows.

User’s Manual 4-5

1:1 Mode Login screen

1. Turn on the computer.

2. The Select Tiles screen will be displayed.

3. Select Start face recognition ().

4. The Select Account screen will be displayed.

5. Select the account, and click the arrow button.

6. "Please face the camera" will be displayed.

7. Verification will be performed. If the authentication is successful, the image data taken in step 6 will be faded in and placed over one another.

■ If an error occurs during authentication, you will be returned to the

Select Tiles screen.

8. The Windows Welcome screen will be displayed, and will be logged in automatically to Windows.

■ If authentication was successful, but an authentication error

subsequently occurred during the login to Windows, you will be asked to provide your account information.

Using optical disc drives

The full-size drive provides high-performance execution of CD/DVD-based programs. You can run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs without an adaptor. A Serial ATA interface controller is used for CD/DVD operation.

Use the DVD playback application to view DVD-Video discs.

For precautions on writing to CD/DVDs, refer to the Important message section.

Operating Basics

Loading discs

To load a disc, follow the steps as detailed below:

1. When the computer’s power is on, press the eject button to open the disc tray slightly.

2. Grasp the disc tray gently and pull until it is fully opened.

User’s Manual 4-6

1. Disc tray 2. Eject button

Pressing the eject button and pulling the disc tray open

3. Lay the disc, label side up, in the disc tray.

Operating Basics

1. Laser lens

Inserting a disc

When the disc tray is fully opened, the edge of the computer will extend slightly over the disc tray. Therefore, you will need to turn the disc at an angle when you place it in the disc tray. After seating the disc, however, make sure it lies flat.

■ Do not touch the laser lens or any portion of its surrounding casing as

this could cause misalignment.

■ Prevent foreign objects from entering the drive. Check the surface of

the disc tray, especially the area behind the front edge of the disc tray, to make sure there are no such objects before closing the drive.

User’s Manual 4-7

4. Press gently at the center of the disc until you feel it click into place. The disc should lie below the top of the spindle, flush with the spindle base.

5. Push the center of the disc tray to close it. Press gently until it locks into place.

If the disc is not seated properly when the disc tray is closed, the disc might be damaged. Also, the disc tray might not open fully when you press the eject button.

How to remove discs when the disc tray will not open

Pressing the eject button will not open the disc tray when the computer power is off. If the power is off, you can open the disc tray by inserting a slender object (about 15 mm) such as a straightened paper clip into the eject hole near the eject button.

Operating Basics

1. Eject hole

Manual release with the eject hole

Turn off the power before you use the eject hole. If the disc is spinning when you open the disc tray, the disc could fly off the spindle and cause injury.

User’s Manual 4-8

Writing CD/DVDs

You can use the DVD Super Multi drive to write data to either CD-R, CDRW, DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer), DVD+RW or DVD-RAM discs.

TOSHIBA Disc Creator is provided as writing software with this computer. TOSHIBA Disc Creator can be used to write data.

■ Please refer to the Writable discs, Chapter 2 for details about the types

of writable CD and DVD discs that can be supported by this computer.

■ Do not turn off the power to the optical disc drive while the computer is

accessing it as this may cause you to lose data.

■ CD-R/RW media cannot be accessed using the burn cd/dvd option in

Media Center.

■ To write data to CD-R/-RW media, use the TOSHIBA Disc Creator

feature that is installed on your computer.

When writing information to media using an optical drive, you should always ensure that you connect the AC adaptor to a live power socket. It is possible that, if data is written while powered by the battery pack, the write process may sometimes fail due to low battery power - in these instances data loss may occur.

Important message

Before you write or rewrite to any of the media supported by the DVD Super Multi drive, please read and follow all of the setup and operating instructions in this section. If you fail to do so, you may find that the DVD Super Multi drive may not function properly, and you may fail to write or rewrite information successfully - this may cause you to either lose data or incur other damage to the drive or media.

Operating Basics

Disclaimer

TOSHIBA does not bear responsibility for the following:

■ Damage to any CD-R, CD-RW, DVD-R, DVD-R (Dual Layer), DVD-RW,

DVD+R, DVD+R (Double Layer), DVD+RW or DVD-RAM disc that may be caused by writing or rewriting with this product.

■

Any change or loss of the recorded contents of CD-R, CD-RW, DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer), DVD+RW or DVD-RAM media that may be caused by writing or rewriting with this product, or for any business profit loss or business interruption that may be caused by the change or loss of the recorded contents.

■ Damage that may be caused by using third party equipment or software.

Given the technological limitations of current optical disc writing drives, you may experience unexpected writing or rewriting errors due to disc quality or problems with hardware devices. In view of this, it is good practice to make two or more copies of important data, in case of any undesired change or loss of the recorded contents.

User’s Manual 4-9

Operating Basics

Before writing or rewriting with the DVD Super Multi drive

■ Based on TOSHIBA's limited compatibility testing, we suggest the

following manufacturers of CD-R, CD-RW, DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer), DVD+RW or DVDRAM media, however, it must be noted that disc quality can affect write or rewrite success rates. Please also be aware that in no event does TOSHIBA guarantee the operation, quality or performance of any disc.

CD-R:

TAIYO YUDEN CO., Ltd. MITSUBISHI KAGAKU MEDIA CO., LTD. Hitachi Maxell,Ltd.

CD-RW: (Multi-Speed and High-Speed)

MITSUBISHI KAGAKU MEDIA CO., LTD.

CD-RW: (Ultra-Speed)

MITSUBISHI KAGAKU MEDIA CO., LTD.

DVD-R:

DVD Specifications for Recordable Disc for General Version 2.0

TAIYO YUDEN Co.,Ltd. (for 8x and 16x speed media) MITSUBISHI KAGAKU MEDIA CO.,LTD. (for 8x and 16x speed media) Hitachi Maxell,Ltd. (for 8x and 16x speed media)

DVD-R (Dual Layer):

MITSUBISHI KAGAKU MEDIA CO., LTD. (for 4x and 8x speed media)

DVD-R for Labelflash:

FUJIFILM CORPORATION (for 16x speed media)

DVD+R:

MITSUBISHI KAGAKU MEDIA CO., LTD. (for 8x and 16x speed media)

TAIYO YUDEN Co.,Ltd. (for 8x and 16x speed media)

DVD+R (Double Layer):

MITSUBISHI KAGAKU MEDIA CO., LTD. (for 2.4x and 8x speed media)

DVD+R for Labelflash:

FUJIFILM CORPORATION (for 16x speed media)

DVD-RW:

DVD Specifications for Recordable Disc for Version 1.1 or version

1.2

Victor Company of Japan, Ltd. (JVC) (for 4x and 6x speed media) MITSUBISHI KAGAKU MEDIA CO.,LTD. (for 4x and 6x speed media)

User’s Manual 4-10

Operating Basics

DVD+RW:

MITSUBISHI KAGAKU MEDIA CO., LTD. (for 4x and 8x speed media)

DVD-RAM:

DVD Specifications for DVD-RAM Disc for Version 2.0, Version 2.1 or Version 2.2

Panasonic Corporation (for 3x and 5x speed media) Hitachi Maxell,Ltd. (for 3x and 5x speed media)

■ Some types and formats of DVD-R (Dual Layer) and DVD+R (Double

Layer) discs may be unreadable.

■ 2.6GB and 5.2GB DVD-RAM media cannot be read from or written to.

■ Disc created in DVD-R (Dual Layer) format4 (Layer Jump Recording)

cannot be read.

■ If the disc is poor in quality, or is dirty or damaged, writing or rewriting

errors may be noted - ensure that you check all discs for dirt or damage before you use them.

■ The actual number of rewrites to CD-RW, DVD-RW, DVD+RW or DVD-

RAM media will be affected by the quality of the disc itself and the way in which it is used.

■ There are two types of DVD-R media available, authoring discs and

general use discs. Do not attempt to use authoring discs as only general use discs can be written to by a computer drive.

■ You can use both DVD-RAM discs that can be removed from a cartridge

and DVD-RAM discs designed without a cartridge.

■ You may find that other computer DVD-ROM drives or other DVD

players may not be able to read DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer) or DVD+RW discs.

■ Data written to a CD-R, DVD-R, DVD-R (Dual Layer), DVD+R or

DVD+R (Double Layer) discs cannot be deleted either in whole or in part.

■ Data deleted/erased from a CD-RW, DVD-RW, DVD+RW or DVD-RAM

disc cannot be recovered. You must check the content of the disc carefully before you delete it, taking care that, if multiple drives that can write data to discs are connected, you do not delete data from the wrong one.

■ In writing to DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R

(Double Layer), DVD+RW or DVD-RAM media, some space is required for file management, so you may not be able to write to the full capacity of the disc.

■ Since the disc is based on the DVD standard, it might be filled with

dummy data if the written data is less than about 1GB. Therefore, in these circumstance, even if you write only a small amount of data, it might take additional time to fill in the dummy data.

■ When multiple drives that can write data to discs are connected, be

sure that you do not write to or delete data from the wrong drive.

User’s Manual 4-11

Operating Basics

■ Be sure to connect the AC adaptor to the computer before you write or

rewrite any information.

■ Before you enter either Sleep Mode or Hibernation Mode, take care to

ensure that any DVD-RAM writing has been completed. In this instance, writing is finished if you can eject the DVD-RAM media.

■ Be sure to close all other software programs except for the writing

software itself.

■ Do not run software such as a screen saver which can put a heavy load

on the processor.

■ Operate the computer at its full power settings - do not use any power-

saving features.

■ Do not write information while virus checking software is running,

instead wait for it to finish, then disable the virus protection applications, including any software that checks files automatically in the background.

■ Do not use any hard disk utilities, including those that are intended to

enhance hard disk drive access speeds, as they may cause unstable operation and damage data.

■ CD-RW (Ultra Speed +) media should not be used as data may be lost

or damaged.

■ You should always write from the computer's hard disk drive onto the

CD/DVD - do not try to write from shared devices such as a server or any other network device.

■ Writing with software other than TOSHIBA Disc Creator has not been

confirmed, therefore operation with other software applications cannot be guaranteed.

When writing or rewriting

Please observe the following points while you write or rewrite data to CD-R, CD-RW, DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer), DVD+RW or DVD-RAM media:

■ Always copy data from the hard disk drive to the optical media - do not

use the cut-and-paste function as the original data will be lost if there is a write error.

■ Do not perform any of the following actions:

■ Change users in the Operating System.

■ Operate the computer for any other function, including such tasks as

using a mouse or Touch Pad, or closing/opening the display panel.

■ Start a communication application.

■ Apply impact or vibration to the computer.

■ Install, remove or connect external devices, including such items as a

SD/SDHC/SDXC memory card, miniSD/microSD Card, MultiMediaCard, USB device, external monitor, or an optical digital device.

■ Use the audio/video control button to reproduce music or voice.

User’s Manual 4-12

■ Open the optical disc drive.

■ Do not use shut down, log off, Sleep Mode or Hibernation Mode

functions while writing or rewriting.

■ Make sure that the write/rewrite operation is completed before going

into either Sleep Mode or Hibernation Mode (writing is completed if you can remove an optical media on the DVD Super Multi drive).

■ If the media is of poor quality, or is dirty or damaged, writing or rewriting

errors may occur.

■ Set the computer on a level surface and avoid places subject to

vibration such as airplanes, trains or cars. In addition, do not use the computer on an unstable surface such as a stand.

■ Keep mobile phones and other wireless communication devices away

from the computer.

TOSHIBA Disc Creator

Please be aware of the following limitations when you use the TOSHIBA Disc Creator:

■ DVD Video cannot be created using TOSHIBA Disc Creator.

■ DVD Audio cannot be created using TOSHIBA Disc Creator.

■ You cannot use TOSHIBA Disc Creator's "Audio CD" function to record

music to DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer) or DVD+RW media.

■ Do not use the "Disc Backup" function of TOSHIBA Disc Creator in

order to copy DVD Video or DVD-ROM material that has copyright protection.

■ DVD-RAM discs cannot be backed up using the "Disc Backup" function

of TOSHIBA Disc Creator.

■ You cannot back up CD-ROM, CD-R or CD-RW media to DVD-R, DVD-

R (Dual Layer) or DVD-RW media using the "Disc Backup" function of TOSHIBA Disc Creator.

■ You cannot back up CD-ROM, CD-R or CD-RW media to DVD+R,

DVD+R (Double Layer) or DVD+RW media using the "Disc Backup" function of TOSHIBA Disc Creator.

■ You cannot back up DVD-ROM, DVD Video, DVD-R, DVD-R (Dual

Layer), DVD-RW, DVD+R, DVD+R (Double Layer) or DVD+RW to CDR or CD-RW media using the "Disc Backup" function of TOSHIBA Disc Creator.

■ TOSHIBA Disc Creator cannot record in packet format.

■ You might not be able to use the "Disc Backup" function of TOSHIBA

Disc Creator to back up a DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer) or DVD+RW disc that was made with other software on a different optical media recorder.

Operating Basics

User’s Manual 4-13

Operating Basics

■ If you add data to a DVD-R, DVD-R (Dual Layer), DVD+R or DVD+R

(Double Layer) disc that you have already recorded to, you might not be able to read the added data under some circumstances. For example, it cannot be read under 16-bit operating systems, such as Windows 98SE and Windows Me, while in Windows NT4 you will need Service Pack 6 or later, and in Windows 2000, you will need Service Pack 2. In addition to this, some DVD-ROM and DVD-ROM / CD-R/RW drives cannot read this added data regardless of the operating system.

■ TOSHIBA Disc Creator does not support recording to DVD-RAM discs -

to achieve this you should use Windows Explorer or another similar utility.

■ When you back up a DVD disc, be sure that the source drive supports

recording to DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R, DVD+R (Double Layer) or DVD+RW media - if this is not the case then the source disc might not be backed up correctly.

■ When you back up a DVD-R, DVD-R (Dual Layer), DVD-RW, DVD+R,

DVD+R (Double Layer) or DVD+RW disc, be sure to use the same type of disc.

■ You cannot partially delete any data written to a CD-RW, DVD-RW or

DVD+RW disc.

Data Verification

To verify that data has been written or rewritten correctly to a data CD/DVD you should follow the steps below before you begin the write/rewrite process:

1. Display the setting dialog box by one of the following two steps:

■ Click the Recording settings button ( ) for writing on the main

toolbar in the Data CD/DVD mode.

■ Select Settings for Each Mode  Data CD/DVD in the Settings

menu.

2. Mark the Verify Written Data check box.

3. Select File Open or Full Compare mode.

4. Click the OK button.

How to learn more about TOSHIBA Disc Creator

Please refer to the Help files for additional TOSHIBA Disc Creator information.

User’s Manual 4-14

TOSHIBA VIDEO PLAYER

Please be aware of the following limitations when you use the TOSHIBA VIDEO PLAYER:

Notes on use

■ "TOSHIBA VIDEO PLAYER" software is supported for playback of

DVD-Video and DVD-VR.

■ Frame dropping, audio skipping or out of synch audio and video may

occur during playback of some DVD-Video titles.

■ Close all other applications when using the "TOSHIBA VIDEO

PLAYER". Do not open any other applications or carry out any other operations during DVD-Video playback. Playback may stop or not function properly in some situations.

■ Unfinalized DVDs created on home DVD recorders may not be playable

on the computer.

■ Use DVD-Video discs with a region code which is either "the same as

the factory default setting" or "ALL".

■ Do not playback DVD discs Video while watching or recording television

programs using other applications. Doing so may cause DVD-Video playback or television program recording errors. In addition, if prescheduled recording starts during DVD-Video playback it may cause DVD-Video playback or television program recording errors. Please view DVD-Video during times when there is no recording prescheduled.

■ The resume function cannot be used with some discs on the "TOSHIBA

VIDEO PLAYER".

■ It is recommended the AC adaptor be connected when playing DVD-

Video. Power saving features may interfere with smooth playback. When playing DVD-Video using battery power, set the Power Options to "Balance".

■ Screen savers will not display while playing a movie in the "TOSHIBA

VIDEO PLAYER". The computer will also not go into Sleep Mode, Hibernation Mode or shutdown while using "TOSHIBA VIDEO PLAYER".

■ Do not configure the Display automatic power off function to run while

the "TOSHIBA VIDEO PLAYER" is running.

■ Do not switch to Hibernation or Sleep Mode when running the

"TOSHIBA VIDEO PLAYER".

■ Do not lock the computer using the Windows logo () + L keys or the

FN + F1 keys when running the "TOSHIBA VIDEO PLAYER".

■ Do not change Windows Users while "TOSHIBA VIDEO PLAYER" is

running.

■ The "TOSHIBA VIDEO PLAYER" does not have a parental control

function.

Operating Basics

User’s Manual 4-15

■ In order to protect copyrights, the Windows Print Screen function is

disabled when "TOSHIBA VIDEO PLAYER" is running.

■ (Print Screen functions are disabled even when running other

applications besides "TOSHIBA VIDEO PLAYER" and when "TOSHIBA VIDEO PLAYER" is minimized.) Please close the "TOSHIBA VIDEO PLAYER" to use the Print Screen function.

■ For some DVD-Video discs, using the control window to change the

audio track will also change the subtitle track.

■ Carry out the installation/uninstallation of the "TOSHIBA VIDEO

PLAYER" under a user account with administrator rights.

■ If you see the screen blinking while playing DVD with subtitle on at

Media Player, please use "TOSHIBA VIDEO PLAYER" or "Media Center" to play DVD.

Display Devices & Audio

■ "TOSHIBA VIDEO PLAYER" will only run when "Colors" is set to "True

color (32 bit)". Click Start  Control Panel  Appearance and Personalization  Display  Adjust resolution, click "Advanced

settings", select "Monitor" tab, set "colors" to "True color (32 bit)".

■ If the DVD-Video image is not displayed on an external display or

television, stop the "TOSHIBA VIDEO PLAYER", and change the screen resolution. To change the screen resolution, click Start 

Control Panel  Appearance and Personalization  Display  Adjust resolution. However, video cannot be output to some external

displays and televisions due to output or playback conditions.

■ When viewing DVD-Video on an external display or TV, change the

display device before playing. DVD-Video cannot be displayed simultaneously (in clone mode) on both the computer's display panel and an external display.

■ Do not change the screen resolution while running the "TOSHIBA

VIDEO PLAYER".

■ Do not change the display device while running the "TOSHIBA VIDEO

PLAYER".

Operating Basics

Starting TOSHIBA VIDEO PLAYER

Use the following procedure to start "TOSHIBA VIDEO PLAYER".

1. Insert a DVD-Video in the DVD Super Multi drive while Windows 7 is running. When a DVD-Video disc is set in the DVD drive, if the application selection screen appears, select Play DVD movie (using TOSHIBA VIDEO PLAYER) to launch the TOSHIBA VIDEO PLAYER.

2. Select Start  All Programs  TOSHIBA VIDEO PLAYER  TOSHIBA VIDEO PLAYER to start "TOSHIBA VIDEO PLAYER".

User’s Manual 4-16

Operating TOSHIBA VIDEO PLAYER

Notes on Using "TOSHIBA VIDEO PLAYER".

■ Screen display and available features may vary amongst DVD-Videos

and scenes.

■ If the menu is opened in the Display Area using the Control window's

Top Menu or Menu buttons, touch pad and mouse menu operations may not be able to be used.

Open TOSHIBA VIDEO PLAYER HELP

TOSHIBA VIDEO PLAYER features and instructions are also explained in detail in "TOSHIBA VIDEO PLAYER Help".

Use the following procedure to open "TOSHIBA VIDEO PLAYER Help".

■ Click the "Help" button ( ) in the Display Area.

Media care

This section provides tips on protecting data stored on your CDs and DVDs. Handle your media with care. Following the simple precautions listed below will increase the lifetime of your media and protect the data stored on it.

1. Store your CD/DVDs in the containers they originally came in to protect them and keep them clean.

2. Do not bend the CD/DVDs.

3. Do not write on, apply a sticker to, or otherwise mar the surface of the CD/DVD that contains the data.

4. Hold the CD/DVD by its outside edge or the edge on the center hole any fingerprints on the surface of the disc can prevent the drive from properly reading data.

5. Do not expose the CD/DVD to direct sunlight, extreme heat or cold.

6. Do not place heavy objects on your CD/DVDs.

7. If your CD/DVDs become dusty or dirty, wipe them with a clean dry cloth from the center hole outwards - do not wipe in a circular direction. If necessary, you can use a cloth that has been lightly dampened in water or a neutral cleaner but you must not use benzine, thinner or any similar cleaning solution.

Operating Basics

User’s Manual 4-17

Sound System

This section describes some of the audio control functions.

Adjusting System Volume

You can control the overall level of sound using Windows Volume Mixer. To launch Volume Mixer, follow the steps below.

1. Right-click the Speakers icon on the Taskbar.

2. Select Open Volume Mixer from the menu.

Adjust speaker volume by moving the slider up or down under Device to raise or lower the volume of your speakers. Click the Mute button to mute the volume.

You may see another control under Applications in Vol u m e M i x e r. It is the control for an application which is currently running. The System Sounds is always displayed since it controls the volume of the system sounds.

Changing System Sounds

System sounds are assigned to inform you when certain events happen. This section explains how to select an existing scheme or save one you

have modified. To launch the configuration dialog window for system sounds, follow the

steps below.

1. Right-click the Speakers icon on the Taskbar.

2. Select Sounds from the menu.

Operating Basics

Adjusting Microphone Level

Follow the steps below to change the microphone recording level.

1. Right-click on the speaker icon on the Taskbar, and select Recording devices from the sub menu.

2. Select Microphone, and click Properties.

3. On the Levels tab move the Microphone slider to increase or decrease the microphone volume level.

If you feel the microphone volume level is inadequate, move the Microphone Boost slider to a higher level.

User’s Manual 4-18

Notes on Using the Microphone

You can use the built-in or an external microphone that connects to the microphone jack to record monaural sounds into your applications. It can also be used to issue voice commands to applications that support such functions (built-in microphone is provided with some models).

Since your computer has a microphone and speaker, "feedback" may be heard under certain conditions. Feedback occurs when sound from the speaker is picked up in the microphone and amplified back to the speaker, which amplifies it again to the microphone.

This feedback occurs repeatedly and causes a very loud, high-pitched noise. It is a common phenomenon that occurs in any sound system when the microphone input is output to the speaker (throughput) and the speaker volume is too loud or too close to the microphone. You can control throughput by adjusting the volume of your speaker or through the Mute function in the Master Volume panel. Refer to your Windows documentation for details on using the Master Volume panel.

Wireless communications

The computer’s wireless communication function supports some wireless communication devices.

Only some models are equipped with both Wireless LAN and Bluetooth functions.

■ Do not use the Wireless LAN (Wi-Fi) or Bluetooth functionalities near a

microwave oven or in areas subject to radio interference or magnetic fields. Interference from a microwave oven or other source can disrupt Wi-Fi or Bluetooth operation.

■ Turn all wireless functionalities off when near a person who may have

a cardiac pacemaker implant or other medical electric device. Radio waves may affect pacemaker or medical device operation, possibly resulting in serious injury. Follow the instruction of your medical device when using any wireless functionality.

■ Always turn off wireless functionality if the computer is near automatic

control equipment or appliances such as automatic doors or fire detectors. Radio waves can cause malfunction of such equipment, possibly resulting in serious injury.

■ It may not be possible to make a network connection to a specified

network name using the ad hoc network function. If this occurs, the new network (*) will have to be configured for all computers connected to the same network in order to re-enable network connections. * Please be sure to use new network name.

Operating Basics

User’s Manual 4-19

Wireless LAN

The Wireless LAN is compatible with other LAN systems based on Direct Sequence Spread Spectrum / Orthogonal Frequency Division Multiplexing radio technology that complies with the IEEE802.11 Wireless LAN standard.

■ Frequency Channel Selection of 5GHz for IEEE 802.11a or/and

IEEE802.11n

■ Frequency Channel Selection of 2.4GHz for IEEE 802.11b/g or/and

IEEE802.11n

■ Roaming over multiple channels

■ Card power management

■ Wired Equivalent Privacy (WEP) data encryption based on an 128-bit

encryption algorithm

■ Wi-Fi Protected Access™ (WPA™)

The transmission speed over the wireless LAN, and the distance over which the wireless LAN can reach, may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, client design and software/hardware configurations. The transmission rate described is the theoretical maximum speed as specified under the appropriate standard - the actual transmission speed will be lower than the theoretical maximum speed.

Setting

1. Please make sure that the Wireless Communication function is on.

2. Click Start  Control Panel  Network and Internet  Network and Sharing Center.

3. Click Set up a new connection or network.

4. Follow the wizard. You will need the name of the wireless network together with security settings. Consult the documentation accompanied with your router or ask your wireless network administrator for the settings.

Operating Basics

Security

■ TOSHIBA strongly recommend that you enable encryption functionality,

otherwise your computer will be open to illegal access by an outsider using a wireless connection. If this occurs, the outsider may illegally access your system, eavesdrop, or cause the loss or destruction of stored data.

■ TOSHIBA is not liable for the loss of data due to eavesdropping or

illegal access through the wireless LAN and the damage thereof.

User’s Manual 4-20

Bluetooth wireless technology

Bluetooth wireless technology eliminates the need for cables, such as desktop computers, between your PC and other electronic devices, example of printers and mobile phones.

You cannot use the computer's built-in Bluetooth functions and an external Bluetooth adaptor simultaneously. For reference, Bluetooth wireless technology has the following features:

Worldwide operation

The Bluetooth radio transmitter and receiver operate in the 2.4GHz band, which is license-free and compatible with radio systems in most countries in the world.

Radio links

You can easily establish links between two or more devices, with these links being maintained even if the devices are not within a line-of-sight of each other.

Security

Two advanced security mechanisms ensure a high level of security:

■ Authentication prevents access to critical data and makes it impossible

to falsify the origin of a message.

■ Encryption prevents eavesdropping and maintains link privacy.

Operating Basics

Enable/Disable Wireless communication

You can enable or disable Wireless communication functions by pressing FN + F8. No transmissions are sent or received when wireless communication is turned off.

LAN

The computer has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T), Fast Ethernet LAN (100 megabits per second, 100BASE-TX) and Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T).

This section describes how to connect/disconnect to a LAN.

Do not install or remove a memory module while Wake-up on LAN is enabled.

User’s Manual 4-21

■ The Wake-up on LAN function consumes power even when the

system is off. Leave the AC adaptor connected while using this feature.

■ The Link speed (10/100/1000 megabits per second) changes

automatically depending on the network conditions (connected device, cable or noise and so on).

LAN cable types

The computer must be configured properly before connecting to a LAN. Logging onto a LAN using the computer’s default settings could cause a malfunction in LAN operation. Check with your LAN administrator regarding set-up procedures.

If you are using Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T), be sure to connect with a CAT5E cable or higher. You cannot use a CAT3 or CAT5 cable.

If you are using Fast Ethernet LAN (100 megabits per second, 100BASETX), be sure to connect with a CAT5 cable or higher. You cannot use a CAT3 cable.

If you are using Ethernet LAN (10 megabits per second, 10BASE-T), you can connect with a CAT3 or higher cable.

Connecting the LAN cable

To connect the LAN cable, follow the steps as detailed below:

■ Connect the AC adaptor before connecting the LAN cable. The AC

adaptor must remain connected during LAN use. If you disconnect the AC Adaptor while the computer is accessing a LAN, the system may hang up.

■ Do not connect any other cable to the LAN jack except the LAN cable.

Otherwise, malfunctions or damage may occur.

■ Do not connect any power supplying device to the LAN cable that is

connected to the LAN jack. Otherwise, malfunctions or damage may occur.

1. Turn off the power to the computer and to all external devices connected to the computer.

2. Plug one end of the cable into the LAN jack. Press gently until you hear the latch click into place.

Operating Basics

User’s Manual 4-22

1. LAN jack 2. LAN cable

Connecting the LAN cable

3. Plug the other end of the cable into a LAN hub connector or router. Check with your LAN administrator and hardware or software vendor before using or configuring a network connection.

Disconnecting the LAN cable

To disconnect the LAN cable, follow the steps as detailed below:

1. Pinch the lever on the connector in the computer’s LAN jack and pull out the connector.

2. Disconnect the cable from the LAN hub or router in the same manner. Check with your LAN administrator and hardware or software vendor before disconnecting from the hub.

Operating Basics

Computer Handling

This section explains computer handling and maintenance.

Cleaning the computer

To help ensure long, trouble-free operation, keep the computer free of dust and dirt, and use care with all liquids around it.

■ Be careful not to spill liquids into the computer. If the computer does get

wet, turn the power off immediately and let the computer dry completely

- in these circumstance you should get the computer inspected by an authorized service provider in order to assess the scope of any damage.

■ Clean the plastics of the computer using a slightly water dampened cloth.

■ You can clean the display screen by spraying a small amount of glass

cleaner onto a soft, clean cloth and then wiping the screen gently with the cloth.

Never spray cleaner directly onto the computer or let liquid run into any part of it. Never use harsh or caustic chemical products to clean the computer.

User’s Manual 4-23

Moving the computer

While the computer is designed for flexible day-to-day usage you should exercise a few simple precautions when moving it in order to help ensure trouble-free operation.

■ Make sure all disk/disc activity has ended before moving the computer -

check that the HDD and other indicators on the front of the computer are off.

■ Turn off (shut down) the computer.

■ Disconnect the AC adaptor and all peripherals before moving the

computer.

■ Close the display panel.

■ Do not pick up the computer by its display panel.

■ Before carrying your computer, shut it down, disconnect the AC adaptor

and allow it to cool down - a failure to follow this instruction may result in minor heat injury.

■ Be careful not to subject the computer to impact or shock - a failure to

follow this instruction could result in damage to computer, computer failure or loss of data.

■ Never transport your computer with any cards installed - this may cause

damage to either the computer and/or the card resulting in product failure.

■ Always use a suitable carry case when transporting the computer.

■ When carrying your computer, be sure to hold it securely so that it does

not fall or hit anything.

■ Do not carry your computer by holding any of its protruding elements.

Operating Basics

Heat dispersal

To protect against overheating, the processor is equipped with an internal temperature sensor which activates a cooling fan or lowers the processing speed if the computer's internal temperature rises to a certain level. You are able to select whether to control this temperature by either turning on the fan first, then if necessary lowering the processor speed, or by lowering the processor speed first, then if necessary turning on the fan. Both of these functions are controlled through the Power Options.

When the processor's temperature falls within normal range, the fan will be turned off and the processor operation returned to its standard speed.

If the processor's temperature reaches an unacceptably high level with either setting, the computer automatically shuts down to prevent any damage. In this instance all unsaved data in memory will be lost.

User’s Manual 4-24

The Keyboard

The computer’s keyboard layouts are compatible with a 104/105-key enhanced keyboard - by pressing some keys in combination, all of the 104/105-key enhanced keyboard functions can be performed on the computer.

The number of keys available on your keyboard will depend on which country/region your computer is configured for, with keyboards being available for numerous languages.

In use there are six different types of keys, specifically typewriter keys, function keys, soft keys, Hot keys, Windows special keys and the keypad overlay.

Never remove the key caps on your keyboard. Doing so could cause damage to the parts under the key caps.

The Keyboard

Chapter 5

Function keys: F1 … F9

The function keys (not to be confused with the special FN key) are the nine keys at the top of your keyboard - these keys function differently from other keys.

F1 through F9 are called function keys because they execute programmed functions when pressed and, when used in combination with the FN key, those keys marked with icons also execute specific functions on the computer.

Soft keys: FN key combinations

The FN (function) is used in combination with other keys to form soft keys. Soft keys are key combinations that enable, disable or configure specific features.

Please note that some software may disable or interfere with soft-key operations, and that the soft-key settings are not restored when the computer returns from Sleep Mode.

User’s Manual 5-1

Hot keys

The Keyboard

This computer's keyboard is designed to provide all the features of the 104key enhanced keyboard.

Since the keyboard is smaller and has fewer keys, some of the enhanced keyboard functions must be simulated using two keys instead of one on the larger keyboard.

The FN key can be combined with the following keys to simulate functions similar to those of keys on the 104/105 key enhanced keyboard which are not on this computer's keyboard.

Hot keys (pressing FN + a function or ESC key) let you enable or disable certain features of the computer.

■ Mute

Pressing FN + ESC turns the sound on and off.

■ Lock

Pressing FN + F1 enters ''Lock computer mode''. To restore your desktop, you need to log on again.

■ Power Plan

Pressing FN + F2 changes the power settings.

■ Sleep

Pressing FN + F3 switches the system to Sleep Mode.

■ Hibernate

Pressing FN + F4 switches the system to Hibernation Mode.

■ Output

Pressing FN + F5 changes the active display device.

To use a simultaneous mode, you must set the resolution of the internal display panel to match the resolution of the external display device.

■ Brightness Down

Pressing FN + F6 decreases the computer's display panel brightness in individual steps.

■ Brightness Up

Pressing FN + F7 increases the computer's display panel brightness in individual steps.

■ Wireless

Pressing FN + F8 switches the active wireless devices.

If no wireless communication device is installed, no dialog box will appear.

■ Tou c h P ad

Pressing FN + F9 enables or disables the Touch Pad function.

■ Zoom (Display resolution)

Pressing FN + Space changes the display resolution.

■ Reduce

Pressing FN + 1 reduces the icon size on the desktop or the font sizes within one of the supported application windows.

User’s Manual 5-2

■ Enlarge

Pressing FN + 2 enlarges the icon size on the desktop or the font sizes within one of the supported application windows.

■ Volume down

Pressing FN + 3 decreases the volume in increment .

■ Volu m e u p

Pressing FN + 4 increases the volume in increment.

FN Sticky key

You can use the TOSHIBA Accessibility Utility to make the FN key sticky, that is, you can press it once, release it, and then press an "F Number" key. To start the TOSHIBA Accessibility utility, click Start  All

Programs  TOSHIBA  Utilities  Accessibility.

Windows special keys

The keyboard provides two keys that have special functions in Windows, the Windows Start Button key activates the Start menu while the application key has the same function as the secondary (right) mouse button.

This key activates the Windows Start menu.

The Keyboard

This key has the same function as the secondary (right) mouse button.

Generating ASCII characters

Not all ASCII characters can be generated using normal keyboard operation, but you are able to generate these characters using their specific ASCII codes.

1. Hold down ALT key.

2. Using the numeric keypad, type the ASCII code of the character you require.

3. Release ALT - the ASCII character will appear on the display screen.

User’s Manual 5-3

Power and Power-Up Modes

Chapter 6

Power and Power-Up Modes

The computer's power resources include the AC adaptor, battery pack and any internal batteries. This chapter provides details on making the most effective use of these resources, and includes information on charging and changing batteries, tips for saving battery power, and information on the different power-up modes.

Power conditions

The computer's operating capability and battery charge status are affected by different power conditions, including whether an AC adaptor is connected, whether a battery pack is installed and what the charge level is for that battery.

The LED in the table below refers to the DC IN/Battery indicator.

Power on Power off

(no operation)

AC adaptor connected

User’s Manual 6-1

Battery fully charged

Battery partially charged or no charge

No battery installed

• Operates

• No charge

• LED: green

• Operates

• Charge

• LED: amber

• Operates

• No charge

• LED: green

• No charge

• LED: green

• Quick charge

• LED: amber

• No charge

• LED: green

Power and Power-Up Modes

AC adaptor not connected

Remaining battery capacity is above low battery trigger point

Remaining battery capacity is below low battery trigger point

Remaining battery capacity is exhausted

No battery installed

• Operates

• LED: off

• Operates

• LED: flashes amber

Computer shuts down

• No operation

• LED: off

Table 6-1 Power conditions

Monitoring of power condition

As shown in the below table, the DC IN/Battery and Power indicators on the system indicator alert you to the computer’s operating capability and battery charge status.

DC IN/Battery indicator

Check the DC IN/Battery indicator to determine the status of the battery pack and the power status with the AC adaptor connected. The following indicator conditions should be noted:

Green Indicates the AC adaptor is connected while

correctly supplying power to the computer and the battery is fully charged.

Amber Indicates the AC adaptor is connected and the

Flashing amber The battery charge is low, the AC adaptor must be

No light Under any other conditions, the indicator does not

battery is charging.

connected in order to recharge the battery. Or, indicates a problem with the power supply. You

should initially try plugging the AC adaptor into another power outlet - if it still does not operate properly, you should contact your reseller or dealer.

light.

If the battery pack becomes too hot while it is being charged, the charge will stop and the DC IN/Battery indicator will go out. When the battery pack's temperature falls to a normal range, charging will resume - this process will occur regardless of whether the computer's power is on or off.

User’s Manual 6-2

Power indicator

Battery

Battery types

Power and Power-Up Modes

Check the Power indicator to determine the power status of the computer - the following indicator conditions should be noted:

Green Indicates power is being supplied to the computer

and the computer is turned on.

Blinking green Indicates that the computer is in Sleep Mode and

that there is sufficient power available (AC adaptor or battery) to maintain this condition. In Sleep Mode, this indicator will turn on for two seconds and off for two seconds.

No light Under any other conditions, the indicator does not

light.

This section explains battery types, use, recharging methods and handling.

The computer has different types of batteries.

Battery pack

When the AC adaptor is not connected, the computer's main power source is a removable lithium ion battery pack, also referred to in this manual as the main battery. You can purchase additional battery packs for extended use of the computer away from an AC power source although you should not change the battery pack while the AC adaptor is connected.

Before you remove the battery pack, save your data and shut down the computer, or place the computer into Hibernation Mode. Please be aware that, when placing the computer into Hibernation Mode, the contents of memory will be saved to the hard disk drive, although for safety sake, it is best to also save your data manually.

Real Time Clock (RTC) battery

The Real Time Clock (RTC) battery provides power for the internal real time clock and calendar function and also maintains the system configuration while the computer is turned off. If the RTC battery becomes completely discharged, the system will lose this information and the real time clock and calendar will stop working - in this instance the following message will be displayed when you turn on the power:

S ERROR 0271: Check data and time settings

WARNING 0251: System CMOS checksum bad Default configuration used Press <F1> to resume, <F2> to Setup
