The model number and serial number are on the back
of your TV. Record these numbers in the spaces below.
Refer to these numbers whenever you communicate
with your Toshiba dealer about this TV.
Model:
Serial No.:
your TV
Setting up
Features
Using the TV’s
Appendix
Index
52,62HMX84(E)01_R19/30/04, 5:09 PM1
23566348
Dear Customer,
Thank you for purchasing this Toshiba TV. This manual will help
you use the many exciting features of your new TV. Beforeoperating the TV, please read this manual completely,
and keep it nearby for future reference.
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning symbol in the triangle tells you that
the voltage inside this product may be strong
enough to cause an electric shock. DO NOT TRY
TO SERVICE THIS PRODUCT YOURSELF.
The exclamation mark in the triangle tells you
that important operating and maintenance
instructions follow this symbol.
NOTICE OF POSSIBLE TV STAND INSTABILITY
CAUTION: This television is for use only with
the Toshiba stand listed below. Use with other
carts or stands is capable of resulting in instability
causing possible injury.
TelevisionStand Model
52HMX84ST5284, ST5294
62HMX84ST6284, ST6294
In Canada, please contact your authorized Toshiba dealer
or visit the Toshiba Canada web site at www.toshiba.ca
to determine the appropriate stand for your television.
NOTE TO CATV INSTALLERS IN THE U.S.A.
This is a reminder to call the CATV system installer’s attention to Article
820-40 of the NEC, which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical. For additional antenna grounding information, see items 27
and 28 on page 4.
Child Safety
It Makes A Difference
Where Your TV Stands
Congratulations on your purchase!
As you enjoy your new TV, keep these safety tips in mind:
Lamp Unit Replacement
CAUTION: HOT SURFACE!
The temperature of the lamp
immediately after use
exceeds 392°F (200°C).
cooled will result in severe burns. ALLOW THE LAMP TO
COOL FOR AT LEAST ONE (1) HOUR BEFORE REPLACING IT.
The lamp in this product has a limited service life. The length of
service life varies depending on product use and user settings. If
you use the lamp beyond its service life:
• you may notice a reduction in the colors and/or brightness of the
picture, at which time you should replace the lamp unit; and
• the strength of the quartz glass in the lamp will be reduced and
the lamp may rupture. If the lamp ruptures, the TV will not
operate until the lamp unit is replaced.
Note: The lamp unit is designed so broken lamp glass
remains securely inside the lamp unit.
See “Appendix” on pages 60–64.
• Dispose of the used lamp unit by the approved method for your
area.
disposal or recycling information, contact your local authorities or the
Electronics Industries Alliance (www.eiae.org).
Touching the lamp before it has
Note:
The lamp unit contains mercury. Disposal of mercury
may be regulated due to environmental considerations. For
ENERGY STAR® qualified TV. Products that earn the ENERGY
STAR prevent green house gas emissions by meeting strict energy
efficiency guidelines set by the U.S. Environmental Protection
Agency and the U.S. Department of Energy. ENERGY STAR and
the ENERGY STAR mark are registered U.S. marks.
NOTE: NEVER CONNECT THIS TV
TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
The Issue
If you are like most consumers, you have a TV in your home. Many homes,
in fact, have more than one TV.
The home theater entertainment experience is a growing trend, and larger
TVs are popular purchases; however, they are not always supported on
the proper TV stands.
Sometimes TVs are improperly secured or inappropriately
situated on dressers, bookcases, shelves, desks, audio speakers,
chests, or carts. As a result, TVs may fall over, causing
unnecessary injury.
We Care!
The consumer electronics industry is committed to
making home entertainment enjoyable and safe.
The Consumer Electronics Association formed the
Home Entertainment Support Safety Committee, comprised
of TV and consumer electronics furniture manufacturers, to
advocate children’s safety and educate consumers and their
families about television safety.
Tune Into Safety
One size does NOT fit all! Use appropriate furniture large enough to
support the weight of your TV (and other electronic components).
Use appropriate angle braces, straps, and anchors to secure your furniture
to the wall (but never screw anything directly into the TV).
Carefully read and understand the other enclosed instructions for proper
use of this product.
Do not allow children to climb on or play with furniture and TVs.
Avoid placing any item on top of your TV (such as a VCR, remote control,
or toy) that a curious child may reach for.
Remember that children can become excited while watching a program
and can potentially push or pull a TV over.
Share our safety message about this hidden hazard of
your family and friends. Thank you!
2500 Wilson Blvd.
Arlington, VA 22201 U.S.A.
Tel. 703-907-7600 Fax 703-907-7690
www.CE.org
CEA is the Sponsor, Producer and
Manager of the International CES
the home with
®
2
52,62HMX84(E)02-05_R19/30/04, 5:56 PM2
Important Safety Instructions
Installation, Care, and Service
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized orgrounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete outlet.
10) Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where it exits the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, or the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped. This applies to all items except those
specified on pages 60–64 of this manual.
15) CAUTION: To reduce the risk of electric shock, do not
use the polarized plug with an extension cord, receptacle,
or other outlet unless the blades can be inserted completely
to prevent blade exposure.
16) WARNING: This product contains a lamp to project
the picture, and requires special safety precautions:
• See pages 60–64 for instructions on lamp unit
replacement.
• DO NOT attempt to service this product except as
specified on pages 60–64. The only user-serviceable
item in this product is the lamp unit.
Wide plug
Installation
Follow these recommendations and precautions and heed all
warnings when installing your TV:
17) Never modify this equipment. Changes or modifications
may void: a) the warranty, and b) the user’s authority to
operate this equipment under the rules of the Federal
Communications Commission.
18)DANGER: RISK OF SERIOUS PERSONAL
INJURY, DEATH, OR EQUIPMENT
DAMAGE! Never place the TV on
an unstable cart, stand, or table. The TV
may fall, causing serious personal injury,
death, or serious damage to the TV.
19) Never place or store the TV in direct sunlight; hot, humid
areas; areas subject to excessive dust or vibration; or
locations with temperatures at or below 41°F (5°C).
20) Always place the TV on the floor or a sturdy, level, stable
surface that can support the weight of the unit.
21) Never expose the apparatus to dripping or splashing or
place items such as vases, aquariums, any other item filled
with liquid, or candles on top of the TV.
22) Always place the back of the television at least one (1)
inch away from any vertical surface (such as a wall) to
allow proper ventilation.
23) Never block or cover the slots or openings in the TV
cabinet back, bottom, and sides. Never place the TV:
• on a bed, sofa, rug, or similar surface;
• too close to drapes, curtains, or walls; or
• in a confined space such as a bookcase, built-in cabinet,
or any other place with poor ventilation.
The slots and openings are provided to protect the TV
from overheating and to help maintain reliable operation
of the TV.
24) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.
25) Never overload wall outlets and extension cords.
26) Always operate this equipment from a 120 VAC, 60 Hz
power source only.
(continued on next page)
3
Ground clamp
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part H)
Ground clamps
Antenna lead-in wire
Electric service equipment
Installation
(cont. from previous page)
Care
(cont. from previous column)
27) Always make sure the antenna system is properly
grounded to provide adequate protection against voltage
surges and built-up static charges (see Section 810 of the
National Electric Code).
28)DANGER: RISK OF SERIOUS PERSONAL
INJURY OR DEATH!
• Use extreme care to make sure you are never in
a position where your body (or any item you are in contact
with, such as a ladder or screwdriver) can accidentally
touch overhead power lines. Never locate the antenna
near overhead power lines or other electrical circuits.
• Never attempt to install any of the following during
lightning activity:
a) an antenna system; or b) cables, wires, or any home
theater component connected to an antenna or phone
system.
Care
For better performance and safer operation of your TOSHIBA
TV, follow these recommendations and precautions:
33) For added protection of your TV from lightning and power
surges, always unplug the power cord and disconnect the
antenna from the TV if you leave the TV unattended or
unused for long periods of time.
34
) During normal use, the TV may make occasional snapping
or popping sounds. This is normal, especially when the
unit is being turned on or off. If these sounds become
frequent or continuous, unplug the power cord
and contact a Toshiba Authorized Service Center.
35)
Special care for DLP
•
Lamp—The lamp in this product has a limited service life.
TM
(digital light processing) units:
The length of service life varies depending on product
use or user settings. If you use the lamp beyond its
service life:
- you may notice a reduction in the colors and/or
brightness of the picture, at which time you should
replace the lamp unit; and
- the strength of the quartz glass in the lamp will be
reduced and the lamp may rupture. If the lamp ruptures,
the TV will not operate until the lamp unit is replaced.
See “Appendix” on page
Note:
• The lamp unit is designed so broken lamp glass remains
securely inside the lamp unit.
• The lamp unit contains mercury. Disposal of
mercury may be regulated due to environmental
considerations. For disposal or recycling
information, please contact your local authorities or the
Electronics Industries Alliance (www.eiae.org).
• Dispose of the used lamp unit by the approved method for
your area.
s 60–64.
29) Always sit approximately 10–25 feet away from the TV and
as directly in front of it as possible. The picture can appear
dull if you sit too far to the left or right of the TV, or if
sunlight or room lights reflect on the screen. Turn the TV
off to check for reflections on the screen, and then remove
the source of reflections while viewing the TV.
30) Always unplug the TV before cleaning. Never use liquid or
aerosol cleaners. Clean only with a dry cloth.
Do not spray volatile compounds such as insecticide on
the cabinet. This may cause a discoloration or damage of
the cabinet.
31)WARNING: RISK OF ELECTRIC SHOCK!
Never spill liquids or push objects of any
kind into the TV cabinet slots.
32) If the air temperature rises suddenly (for example, when
the TV is first delivered), condensation may form on the
lenses. This can make the picture appear distorted or the
color appear faded. If this happens, turn off the TV for 6 to
7 hours to allow the condensation to evaporate.
4
Service
36
)WARNING: RISK OF ELECTRIC SHOCK!
Never attempt to service the TV yourself,
except as specified on pages 60–64.
Opening and removing the covers may expose you to
dangerous voltage or other hazards. Failure to follow this
WARNING may result in death or serious injury. Refer all
servicing not specified in this manual to a Toshiba Authorized
Service Center.
37) If you have the TV serviced:
• Ask the service technician to use only replacement parts
specified by the manufacturer.
• Upon completion of service, ask the service technician to
perform routine safety checks to determine
that the TV is in safe operating condition.
38) When the TV reaches the end of its useful life, ask a
qualified service technician to properly dispose of the TV.
Note: The lamp unit contains mercury. Disposal of mercury may
be regulated due to environmental considerations. Dispose of
the used lamp unit by the approved method for your area.
For disposal or recycling information, please contact your local
authorities or the Electronics Industries Alliance (www.eiae.org).
Important notes about your DLP™ projection TV
1) The light source for this TV is a projection lamp unit with a
limited service life. When the lamp wears out, the picture
may become dark or black, or the lamp may fail, at which
time you must replace the lamp unit. See “Lamp unit
replacement” on pages 60-64.
2) Each time you turn on the TV, it may take up to several
seconds to go from no picture to full picture brightness.
3) The display on this TV is manufactured using a chip that may
contain up to 1.3 million microscopic mirrors. Each of these
micromirrors measures less than one-fifth the width of a
human hair and represents a single pixel on the television
display. These micromirrors are mounted on tiny hinges that
enable them to tilt either toward the light source (ON) or
away from it (OFF). Occasionally, one of these mirrors may
become inoperative, creating a light or dark pixel on the
projection surface. This is a structural property of DLP™
projection TV technology, and is not a sign of malfunction.
Such pixels are not visible when the picture is viewed from a
normal viewing distance (see item 29 on page 4).
4) Depending on the media you are viewing, it is possible,
although unlikely, that a limited number of viewers may
see a “rainbow effect” on the screen, which can, in rare
instances, result in eye fatigue. This is a rare occurrence
related to technology of this type, and is not a sign of TV
malfunction.
5) Always sit approximately 10–25 feet away from the TV and
as directly in front of it as possible. The picture quality may
be affected by your viewing position and length of viewing
time. If you sit too closely to the TV for too long, you may
suffer from eye fatigue. See item 29 on page 4.
6)This TV contains several cooling fans to moderate
the internal temperature. You may be able to hear
the fans for several minutes after the TV is turned
off. This is a function of the Quick Restart standby mode
and is not a sign of TV malfunction. You can set the Quick
Restart feature to stop the fans as soon as the TV is
turned off. See “Selecting the Quick Restart” on page 28.
7) The green and red LED lights on the control touchpad (on
the lower right corner of the TV screen) indicate your TV’s
current status. If either light flashes, see “LED indications”
on page 64 for details.
8) Review all safety and operating information in this owner’s
manual before you use your TV.
The DLP logo and DLP medallion are trademarks of Texas Instruments.
52,62HMX84(E)02-05_R19/30/04, 5:54 PM5
5
Important Safety Information............................. 2-5
Index .......................................................................... 69
6
Introduction
Welcome to Toshiba
Thank you for purchasing this Toshiba TV, one of the most
innovative DLP
manual is to guide you through setting up and operating your Toshiba
TV as quickly as possible.
This manual applies to models 52HMX84 and 62HMX84. The
model and serial numbers are on the back of your TV. Write these
numbers in the space provided on the front cover of this manual for
your records.
Instructions in this manual are based on using the remote control.
You can also use the controls on the TV if they have the same name as
those on the remote control.
Please read all the safety and operating instructions carefully, and keep
the manual for future reference.
Exploring your new TV
TM
projection TVs on the market. The goal of this
See “Important notes about
your DLPTM projection TV” on
page 5.
Introduction
your TV
Connecting
You can operate your TV using the control touchpad on the TV front
or the remote control. The back panel and side panel (behind the
door) provide terminals for connecting other equipment to your TV.
See “Connecting your TV” on page 8.
Model 52HMX84 is used in this manual for illustration purpose.
Front
MENUVOLUMECHANNELEXITTV/VIDEOPOWER
Remote control sensor
(Behind the screen)
Side
Push to open.
Control touchpad on TV front (Gently touch the printed keys.)
EXIT
zyx•
TV/VIDEO
Volume x •
Channel zy
* Green ON = Touchpad key being pressed;
Red ON = Power ON.
See page 64 for additional LED indications.
VIDEO 3
eo
Vid
/audio inputs
ANT OUTAUDIO
IN
ANT-2
ANT-1
IN
IN
MENU
POWER
MENUVOLUMECHANNELEXITTV/VIDEOPOWER
Green and Red
LED indicators*
Remote control
TV
LIGHTSLEEP
CABLE/SAT
VCR
DVD
123
AUDIO1
AUDIO2
456
MODE
789
PIC SIZE
+10
100/
N
I
P
U
INPUT
PAUSE/STEP
AM/FM
DISC
SPLIT
SWAP
O
F
S
E
L
T
I
T
FAV
ENTER
FAV
EXIT
DVD CLEAR
POP DIRECT CH
0
F
A
V
O
R
I
T
E
U
B
T
I
T
L
E
RECALL
SKIP/SEARCH
PLAYREWFF
STOP
CH SCAN
ACTION
MENU
E
D
I
U
G
E
S
CH
DVD RTN
CH RTN
SLOW/DIR
TV/
VCR
POP CH
T
POWER
ENT
A
U
D
I
O
VOL
MUTE
REC
FREEZE
SOURCE
Using the
Remote Control
your TV
Setting up
T
H
E
A
T
L
E
I
N
R
K
Features
Using the TV’s
Back
120 VAC
60 Hz
VIDEO 1/2
ColorStream
HD-1/HD-2
Video/Audio OUT
Variable
Audio OUT
Appendix
CT-90164
Index
HDMI IN
7
Connecting your TV
Note: Cables are not supplied with your TV.
Introduction
your TV
Connecting
Using the
Remote Control
●
●
●
●
●
Connecting an antenna or cable TV
This connection allows you to watch TV programs or basic cable
channels.
Coaxial cable is the cable that comes in from your antenna, cable TV
service, or cable converter box. Coaxial cable uses “F” connectors.
Standard A/V (audio/video) cables usually come in sets of three, and
are typically color-coded according to use: yellow for video, red for
stereo right audio, and white for stereo left (or mono) audio.
On your TV’s back panel, the standard A/V inputs are color-coded in
the same manner as the cables.
S-Video cable is for use with video equipment that has S-Video output.
Component video cables come in sets of three, and are for use with
video equipment that has component video output. (ColorStream
®
is
Toshiba’s brand of component video.)
HDMI is for use with video equipment that has HDMI output (type
A connector) (see page 15).
NOTE:
NEVER CONNECT THIS TV TO A PERSONAL COMPUTER (PC).
THIS TV IS NOT INTENDED FOR USE WITH A PC.
Coaxial (antenna) cable
Standard A/V cables (red/white/yellow)
S-video cable
Component video cables
HDMI cable
CAUTION: RISK OF
EQUIPMENT DAMAGE !
Never plug in any power cords
until you have finished connecting all
equipment.
your TV
Setting up
Features
Using the TV’s
Appendix
From Antenna or Cable
TV
Index
8
Connecting a VCR
This connection allows you to watch local channels and video
programs, play or record on the VCR while watching TV, and record
from one channel while watching another channel.
You will need:
• two coaxial cables
• one set of standard A/V cables
From Cable Box or Antenna
Stereo VCR
IN from ANT OUT to TV
CH 3
CH 4
TV
VIDEO
IN
OUT
LR
AUDIO
Note:
If you have a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.
If you have a VCR with S-video, use an
S-video cable (in the S-video jacks) instead of
a standard video cable.
Do not connect a standard video cable and
an S-video cable to Video-1 (or Video-2) at
the same time, or the picture performance
will be unacceptable.
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Introduction
your TV
Connecting
Using the
Remote Control
Connecting a cable converter box
This connection allows you to watch basic and premium cable channels
To watch basic cable and use the TV’s features, select ANT-1. To view
premium channels, select ANT-2, tune the TV to channel 3 or 4
(whichever channel is vacant in your area), and use the converter box
to change channels.
You will need:
• three coaxial cables
TV
From Cable
INOUT
Note:
.
When you use a converter box with your TV,
the remote control will not operate some
features, such as programming your favorite
channels, labeling channels, and locking
channels.
your TV
Setting up
Features
Using the TV’s
Appendix
Cable converter box
Index
9
Connecting a cable converter box and VCR
This connection allows you to watch and record basic and premium
cable channels, watch videotapes, and record one channel while
Introduction
your TV
Connecting
Using the
Remote Control
watching another channel. To watch basic cable and use the TV’s
features, select ANT-1.
To view premium channels or record with the VCR, select ANT-2,
tune the TV and VCR to channel 3 or 4 (whichever channel is vacant
in your area), and use the converter box to change channels.
You will need:
• four coaxial cables
• one set of standard A/V cables
TV
Note:
If you have a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.
If you have a VCR with S-video, use an
S-video cable (in the S-video jacks) instead of
a standard video cable. Do not connect a
standard video cable and an S-video cable to
Video-1 (or Video-2) at the same time, or the
picture performance will be unacceptable.
When you use a converter box with your TV,
the remote control will not operate some
features, such as programming your favorite
channels, labeling channels, and locking
channels.
From Cable
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
your TV
Setting up
Features
Using the TV’s
Appendix
IN from ANT OUT to TV
CH 3
CH 4
Stereo VCR
VIDEO
IN
OUT
LR
AUDIO
INOUT
Cable converter box
Index
10
Connecting a DVD player or satellite receiver
and a VCR
This connection allows you to watch DVD/satellite, VCR, and TV
programs, and record one TV channel while watching another
channel.
You will need:
• two (or three, if satellite receiver is used) coaxial cables
• one set of standard A/V cables
• one S-video cable
• one pair of standard audio cables
Stereo VCR
IN
OUT
LR
AUDIO
From
Antenna
IN from ANT OUT to TV
CH 3
CH 4
TV
VIDEO
Note:
For the highest possible picture quality from a
DVD player or satellite receiver without
component video or HDMI, use an S-video
cable. (If your DVD player has component
video, see page 12. If your DVD player or
satellite receiver has HDMI or DVI, see page
15.)
Do not connect both an S-video cable and a
standard video cable between the TV and
DVD player/satellite receiver at the same time
or the picture performance will be
unacceptable.
Do not connect the DVD player/satellite
receiver and VCR to the same set of Video
inputs on the TV. (See the illustration, which
shows the DVD player/satellite receiver
connected to VIDEO 1 on the TV, and the
VCR connected to VIDEO 2 on the TV.)
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
From
Satellite
Dish
IN from ANT
S-VIDEO
S-VIDEO
VIDEO
OUTOUT
VIDEO
OUTOUT
DVD Player
AUDIO
OUT
L
R
Satellite Receiver
AUDIO
OUT
L
R
Features
Using the TV’s
Appendix
Index
11
Connecting a DVD player with ColorStream
(component video) and a VCR
This connection allows you to watch DVD, VCR, and TV programs,
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
and record TV programs.
Your TV has ColorStream
your TV to a DVD player with component video (such as a Toshiba
DVD player with ColorStream
and realism.
– To record one TV program while watching another TV program,
– To record a TV program while watching a DVD, tune the VCR to
You will need:
®
®
(component video) inputs. Connecting
®
) can greatly enhance picture quality
tune the VCR to the channel to record, and tune the TV to the
channel to watch.
the channel to record, and select ColorStream HD1 on the TV (see
“Selecting the antenna input” on page 26).
• two coaxial cables
• one set of standard A/V cables
• one pair of standard audio cables
• one set of component video cables
From
Antenna
Stereo VCR
IN from ANT OUT to TV
CH 3
CH 4
TV
VIDEO
IN
OUT
LR
AUDIO
Note:
For the highest possible picture quality, use
component video cables (or an HDMI cable)
between the TV and DVD player.
You can connect the component video cables
to either set of ColorStream inputs on the TV
(HD1 or HD2).
For HDMI or DVI connection, see page 15.
The ColorStream HD1/HD2 and HDMI1/2
inputs can be used with Progressive (480p,
720p) and Interlaced (480i, 1080i) scan
systems; however, a 1080i signal will provide
the best picture performance.
If your DVD player is not compatible with
component video, HDMI, or DVI, use the
S-video connections (plus the standard audio
connections) instead (see page 11).
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Features
Using the TV’s
Appendix
Index
12
P
Y
S-VIDEO
COMPONENT VIDEO
DVD player with component video
RPB
VIDEO
OUT
AUDIO
L
R
OUT
L
R
Connecting a DTV receiver/set-top box with
®
ColorStream
This connection allows you to watch DTV (digital TV), VCR, and
TV programs, and record DTV (composite video only) and TV
programs.
Your TV has ColorStream (component video) inputs. Connecting
your TV to a DTV receiver with component video can greatly
enhance picture quality and realism.
– To record and watch a DTV program, select LINE IN on the
VCR, and select ColorStream HD2 (or VIDEO 1 for a nonColorStream connection) on the TV (see “Selecting the antenna
input” on page 26).
– To record a TV program while watching a DTV program, tune the
VCR to the channel to record, and select ColorStream HD2 on the
TV.
– To record and watch the same TV program, tune the VCR to the
channel to record, and select VIDEO 1 on the TV.
– To record one TV program while watching another TV program,
tune the VCR to the channel to record, and tune the TV to the
channel to watch.
You will need:
• three coaxial cables
• two sets of standard A/V cables
• one pair of standard audio cables
• one set of component video cables
From Antenna
(component video) and a VCR
Stereo VCR
Note:
For the highest possible picture quality, use
component video cables (or an HDMI cable)
between the TV and DTV receiver/set-top
box.
You can connect component video cables to
either set of ColorStream inputs on the TV
(HD1 or HD2).
For HDMI or DVI connection, see page 15.
The ColorStream HD1/HD2 and HDMI1/2
inputs can be used with Progressive (480p,
720p) and Interlaced (480i, 1080i) scan
systems; however, a 1080i signal will provide
the best picture performance.
If your DTV receiver or set-top box is not
compatible with component video or HDMI,
use the S-video connections (plus the
standard audio connections) instead (see
page 11).
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
From
DTV Antenna
IN from ANT OUT to TV
CH 3
CH 4
TV
Satelite IN
DTV Receiver with component video
S-VIDEO
VIDEO
Y
COMPONENT VIDEO
OUT
LR
AUDIO
P
RPB
IN
VIDEO
OUT
AUDIO
L
R
OUT
Features
Using the TV’s
Appendix
L
R
Index
13
Connecting two VCRs
This connection allows you to record (dub/edit) from one VCR to
another VCR while watching a videotape. You also can record from
Introduction
your TV
Connecting
one TV channel while watching another TV channel.
You will need:
• two coaxial cables
• two sets of standard A/V cables
From
Antenna
VCR1
IN from ANT OUT to TV
CH 3
CH 4
TV
VIDEO
IN
OUT
LR
AUDIO
Note:
If you have VCRs with S-video, use S-video
cables instead of standard video cables for
better picture performance. Do not connect
both a standard video cable and an S-video
cable to Video-1 (or Video-2) at the same
time, or the picture performance will be
unacceptable.
Do not connect the same VCR to the output
and input jacks on the TV at the same time.
To dub or edit, VCR 2 must select Line IN,
and the TV must select VIDEO 1 (see
“Selecting the antenna input” on page 26).
* The VIDEO OUT jack does not output the
POP picture.
** The AUDIO OUT jacks can output the
sound of either the Main or POP picture
(see “Selecting the AUDIO OUT sound” on
page 58).
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
VCR2
CH 3
CH 4
*
VIDEO AUDIO
LR
**
IN
OUT
Connecting a camcorder
This connection allows you to watch video materials recorded on a
camcorder.
You will need:
• one set of standard A/V cables
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States and
other countries, and may subject you to
civil and criminal liability.
Note:
If you have a camcorder with S-video, use an
S-video cable instead of a standard video
cable for better picture performance. Do not
connect both a standard video cable and an
S-video cable at the same time, or the picture
performance will be unacceptable.
Appendix
Index
14
VIDEO
AUDIO
L
R
OUT
Camcorder
Video-3 (side panel)
Connecting an HDMI™ or a DVI device to the HDMI inputs
The HDMI
and uncompressed digital video from an HDMI
device or uncompressed digital video from a DVI
device.
These inputs are designed to accept HDCP
material in digital form from EIA/CEA-861/861B–
compliant
top box or DVD player with HDMI or DVI output).
The HDMI inputs are designed for best performance
