Toshiba 37AV500U Schematic
LCD Color Television
Стр. 1 из
1
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\toshiba_37av500u\37AV500
...
37AV500U
Ver. 2.00
FUNCTION AND OPERATION
Стр. 1 из
2
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\toshiba_37av500u\37AV500
...
TV Front and Side Panel Controls and Connections
Стр. 2 из
2
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
FUNCTION AND OPERATION
Стр. 1 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\toshiba_37av500u\37AV500
...
Learning about the Remote Control
Стр. 2 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
Стр. 3 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
FUNCTION AND OPERATION
Стр. 1 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\toshiba_37av500u\37AV500
...
Programming Channels into the TV's Channel Memory
Programming Channels Automatically
Стр. 2 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
Manually Adding Channels in the Channel Memory
Стр. 3 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
SAFETY INSTRUCTION
should enter the mouth, rinse the mouth thoroughly with water. If the fluid should contact the
When attaching the LCD module to the LCD cover, position it appropriately and fasten
Стр. 1 из 4Handling the LCD Module
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\toshiba_37av500u\37AV500
...
Handling the LCD Module
Safety Precaution
In the event that the screen is damaged or the liquid crystal (fluid) leaks, do not breathe in or
drink this fluid.
Also, never touch this fluid. Such actions could cause toxicity or skin irritation. If this fluid
skin or clothing, wipe off with alcohol, etc., and rinse thoroughly with water. If the fluid
should enter the eyes, immediately rinse the eyes thoroughly with running water.
Precautions for Handling the LCD Module
CAUTION: The metal edges of the LCD module are sharp, handle it with
care.
The LCD module can easily be damaged during disassembly or reassembly; therefore,
always observe the following precautions when handling the module.
1.
at the position where the display can be viewed most conveniently.
2. Carefully align the holes at all four corners of the LCD module with the corresponding
holes in the LCD cover and fasten with screws. Do not strongly push on the module
because any impact can adversely affect the performance. Also use caution when
handling the polarized screen because it can easily be damaged.
Стр. 2 из 4Handling the LCD Module
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
3. If the panel surface becomes soiled, wipe with cotton or a soft cloth. If this does not
remove the soiling, breathe on the surface and then wipe again.
If the panel surface is extremely solied, use a CRT cleaner as a cleaner. Wipe off the
panel surface by drop the cleaner on the cloth. Do not drop the cleaner on the panel.
Pay attention not to scratch the panel surface.
4. Leaving water or other fluids on the panel screen for an extended period of time can
result in discoloration or stripes. Immediately remove any type of fluid from the screen.
5. Glass is used in the panel, so do not drop or strike with hard objects. Such actions can
damage the panel.
6. CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static
Стр. 3 из 4Handling the LCD Module
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
electricity. When handling the module, use a wrist ground or anchor ground.
7. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for an
extended period of time.
8. Do not store the LCD module below the temperature conditions described in the
specifications. Failure to do so could result in freezing of the liquid crystal due to cold
air or loss of resilience or other damage.
9. Do not disassemble the LCD module. Such actions could result in improper operation.
Стр. 4 из 4Handling the LCD Module
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
10. When transporting the LCD module, do not use packing containing epoxy resin
(amine) or silicon resin (alcohol or oxim). The gas generated by these materials can
cause loss of polarity.
SAFETY INSTRUCTION
Always keep tools, components of the product, etc away from the children, These items
Стр. 1 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\toshiba_37av500u\37AV500
...
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SAFETY
PRECAUTION" AND "PRODUCT SAFETY NOTICE" INSTRUCTIONS BELOW.
Safety Precaution
WARNING: SERVICING SHOULD NOT BE ATTEMPTED BY ANYONE
UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER.
THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED
BEFORE SERVICING THIS CHASSIS.
1. An isolation transformer should be connected in the power line between the receiver
and the AC line before any service is performed on the receiver.
2. Always disconnect the power plug before any disassembling of the product. It may
result in electrical shock.
3. When replacing a chassis in the cabinet, always be certain that all the protective
devices are put back in place, such as nonmetallic control knobs, insulating covers,
shields, isolation resistor-capacitor network, etc.
4.
may cause injury to children.
5. Depending on the model, use an isolation transformer or wear suitable gloves when
servicing with the power on, and disconnect the power plug to avoid electrical shock
when replacing parts. In some cases, alternating current is also impressed in the
chassis, so electrical shock is possible if the chassis is contacted with the power on.
6. Always use the replacement parts specified for the particular model when making
repairs. The parts used in products require special safety characteristics such as
inflammability, voltage resistance, etc. therefore, use only replacement parts that have
NEVER remodel the product in any way. Remodeling can result in improper operation,
cabinet such as antennas, terminals, screw heads, metal overlays, control shafts and etc.
The leakage current checking. (After completing the work, measure the leakage current
Стр. 2 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
these same characteristics. Use only the specified parts when the mark is indicated
in the circuit diagram or parts list.
7. Parts mounting and routing dressing of wirings should be the same as that used
originally. For safety purposes, insulating materials such as isolation tube or tape are
sometimes used and printed circuit boards are sometimes mounted floating. Also make
sure that wirings is routed and clamped to avoid parts that generate heat and which use
high voltage. Always follow the manufactured wiring routes / dressings.
8. Always ensure that all internal wirings are in accordance before re-assembling the
external casing after a repairing completed. Do not allow internal wiring to be pinched
by cabinets, panels, etc. Any error in reassembly or wiring can result in electrical
leakage, flame, etc., and may be hazardous.
9.
malfunction, or electrical leakage and flame, which may be hazardous.
10. Always perform an AC leakage current checking on the exposed metallic parts of the
to be sure that the set is safe to operate without any dangerous of electrical shocks
before returning the set to the customer.
11.
to prevent an electrical shock.)
Plug the AC line cord directly into a 120V AC outlet. Do not use an isolation
transformer for this check.
Use an AC voltmeter having 5000 ohms per volt or more sensitivity in the following
manner.
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15 µF, AC type capacitor,
between a known good earth ground (water pipe, conduit, etc.) and the exposed
metallic parts, one at a time. Measure the AC voltage across the combination of 1500
ohm resistor and 0.15 µF capacitor. Reverse the AC plug at the AC outlet and repeat
AC voltage measurements for each exposed metallic part. Voltage measured must not
exceed 0.3 volts rms. This corresponds to 0.2 milliamp. AC. Any value exceeding this
limit constitutes a potential shock hazard and must be corrected immediately.
Стр. 3 из
3
07.05.2015
file://D:\Documents and Settings\Admin\
Рабочий стол
\
toshiba_37av500u\37AV500
...
Product Safety Notice
Many electrical and mechanical parts in this chassis have special safety-related
characteristics. These characteristics are often passed unnoticed by a visual inspection and
the protection afforded by them cannot necessarily be obtained by using replacement
components rated for higher voltage, wattage, etc. Replacement parts which have these
special safety characteristics are identified in this manual and its supplements; electrical
components having such features are identified by the international hazard symbols on the
schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The
use of substitute replacement parts which do not have the same safety characteristics as
specified in the parts list may create electrical shock, fire, or other hazards.
S
et serial Number structure
Y W K X X X * * * * * *
8 0 1 1 0 1 0 0 0 0 0 1 Total digits YWK SET_ID SERIAL
12 YWK xxx ******
3 digits 3 digits 6 digits(000001~999999)
32AV500U 1st set Ｙ：Year 8 2008
Manufactured in 2008-week 1 9 2009
A 2010
B 2011
C 2012
… …
ＷＫ：Week 1 WK01
2 WK02
3 WK03
4 WK04
… …
53 WK53
SET ID: XXX
101
102
103
104
105
106
32AV500U
26AV500U
37AV500U
42AV500U
19AV500U
19AV501U
