Toshiba 32XV503D, 42XV503D User Manual
XV50*
DIGITAL
Series
Contents
SETTING UP
Safety Precautions ..................................................4
Installation and important information ....................5
The remote control .................................................6
Inserting batteries and effective range of the
remote ..........................................................7
Connecting external equipment ..............................8
Connecting an HDMI™ or DVI device to the HDMI
input ...................................................................9
To connect an HDMI device ..............................9
To connect a DVI device ...................................9
REGZA-LINK connection .......................................10
Connecting a computer ........................................11
To connect a PC to the RGB/PC terminal ........11
To connect a PC to the HDMI terminal ............11
Controls and input connections .............................12
Switching on ..................................................12
Using the remote control ...............................12
Using the controls and connections ................12
TUNING THE TELEVISION
Tuning Digital television .......................................13
Tuning for the first time ..................................13
Digital auto tuning .......................................14
Analogue switch-off .....................................14
Digital programme sorting ............................15
Digital manual tuning ...................................15
Tuning Analogue mode ........................................16
Quick Setup ...................................................16
Manual tune ..................................................17
Programme skip ............................................18
Sorting programme positions .........................19
Using Auto tuning ..........................................19
CONTROLS AND FEATURES
General controls ...................................................20
Selecting programme positions ......................20
The Time Display – analogue only ................20
Stereo and Bilingual transmissions .................20
Sound controls .....................................................20
Volume controls and mute sound ...................20
Bass, Treble and Balance ...............................20
Bass boost .....................................................20
SRS WOW® sound effects ..............................21
Dual – analogue only ...................................21
Stable sound® ...............................................21
Headphone Mode ..........................................21
Widescreen viewing ..............................................22
Picture controls .....................................................24
Picture position – analogue only ...................24
Backlight .......................................................24
Picture preferences ........................................25
Black/White Level ..........................................25
Cinema mode ................................................25
Colour temperature .......................................25
Reset .............................................................25
3D Colour management ................................26
Base colour adjustment ..................................26
Active Backlight Control .................................26
Auto Contrast ................................................26
MPEG NR – Noise Reduction ..........................26
DNR – Digital Noise Reduction .......................27
Automatic format (Widescreen) ......................27
4:3 stretch .....................................................27
Blue screen ....................................................27
Side panel adjustment ...................................27
Picture still .....................................................27
Panel lock ............................................................27
The timers ............................................................28
Programme timer – digital only ....................28
Sleep timer ....................................................28
Digital on-screen information and
Programme Guide .............................................29
Information ...................................................29
Guide ...........................................................29
Digital settings – parental control ........................30
Setting the PIN ..............................................30
Mode ............................................................30
Digital settings – other features ...........................31
Selecting favourite programmes .....................31
Locking programmes .....................................31
Encrypted programmes ..................................31
Audio languages ...........................................32
Optical audio output .....................................32
Subtitles ........................................................32
Audio description ..........................................32
Reset TV ........................................................32
Common interface .........................................33
Digital settings – software upgrade ......................33
Version .........................................................33
Auto Upgrade ...............................................33
Searching for new software ...........................33
PC settings – picture position, clock phase,
sampling clock, reset .........................................34
Picture position ..............................................34
Clock phase ..................................................34
Sampling clock ..............................................34
Reset .............................................................34
Input selection and AV connections ......................35
Input selection ...............................................35
INPUT signal selection ...................................35
PC audio .......................................................36
HDMI1 audio ................................................36
Lip Sync Latency ............................................36
Using REGZA-LINK ...............................................37
Enable REGZA-LINK ......................................37
TV Auto Input Switch .....................................37
TV Auto Power ...............................................37
Auto Standby ................................................37
Speaker Preference .......................................37
REGZA-LINK input source selection ................37
REGZA-LINK playback device control .............38
REGZA-LINK one touch play ..........................38
REGZA-LINK system standby ..........................38
REGZA-LINK system audio control ..................38
REGZA-LINK PC link ......................................38
TEXT SERVICES
Text services .........................................................39
Selecting modes ............................................39
Text information ............................................39
Navigating pages using Auto. ........................39
Navigating pages using LIST ..........................39
Control buttons .............................................40
Digital interactive services ...................................40
PROBLEM SOLVING
Questions and Answers ......................................41
INFORMATION
Notes ...................................................................44
Information ..........................................................46
Specifications and accessories ..............................48
3
SETTING UP
Safety Precautions
This equipment has been designed and manufactured
to meet international safety standards but, like any
electrical equipment, care must be taken to obtain the
best results and for safety to be assured. Please read
the points below for your own safety. They are of a
general nature, intended to help with all electronic
consumer products and some points may not apply to
the goods you have just purchased.
Air Circulation
Leave more than 10cm clearance around the television
to allow adequate ventilation. This will prevent
overheating and possible damage to the television.
Dusty places should also be avoided.
Heat Damage
Damage may occur if the television is left in direct
sunlight or near a heater. Avoid places subject to
extremely high temperatures or humidity. Place in a
location where the temperature remains between 5°C
(41°F) min. and 35°C (94°F) max.
Mains Supply
The mains supply required for this equipment is 220240v AC 50/60Hz. Never connect to a DC supply or
any other power source. DO ensure that the television
is not standing on the mains lead.
DO NOT cut off the mains plug from this equipment,
this incorporates a special Radio Interference Filter, the
removal of which will impair its performance. In the
UK, the fuse fitted in this plug is approved by ASTA or
BS1362
BSI to
rated and approved type and the fuse cover must be
refitted.
IF IN DOUBT PLEASE CONSULT A COMPETENT
ELECTRICIAN.
DO
read the operating instructions before you attempt
to use the equipment.
DO
ensure that all electrical connections (including the
mains plug, extension leads and inter-connections
between pieces of equipment) are properly made and
in accordance with the manufacturers’ instructions.
Switch off and withdraw the mains plug before making
or changing connections.
DO
consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.
DO
be careful with glass panels or doors on
equipment.
. It should only be replaced by a correctly
Do
DO NOT REMOVE ANY FIXED COVERS AS THIS WILL
EXPOSE DANGEROUS AND 'LIVE' PARTS.
THE MAINS PLUG IS USED AS A DISCONNECTING
DEVICE AND THEREFORE SHOULD BE READILY
OPERABLE.
Do not
DO NOT
equipment with items such as newspapers, tablecloths,
curtains, etc. Overheating will cause damage and
shorten the life of the equipment.
DO NOT
dripping or splashing or objects filled with liquids, such
as vases, to be placed on the equipment.
DO NOT
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to fires.
DO NOT
wood screws. To ensure complete safety, always fit the
manufacturers’ approved stand, bracket or legs with
the fixings provided according to the instructions.
DO NOT
unattended, unless it is specifically stated that it is
designed for unattended operation or has a standby
mode. Switch off by withdrawing the plug, make sure
your family know how to do this. Special arrangements
may need to be made for people with disabilities.
DO NOT
in any doubt about it working normally, or it is
damaged in any way – switch off, withdraw the mains
plug and consult your dealer.
WARNING
earphones or headphones can cause hearing loss.
ABOVE ALL – NEVER let anyone, especially
children, push or hit the screen, push anything
into holes, slots or any other openings in the
case.
NEVER guess or take chances with electrical
equipment of any kind – it is better to be safe
than sorry.
obstruct the ventilation openings of the
allow electrical equipment to be exposed to
place hot objects or naked flame sources,
use makeshift stands and NEVER fix legs with
leave equipment switched on when it is
continue to operate the equipment if you are
– excessive sound pressure from
4
SETTING UP
Installation and important information
Where to install
Locate the television away from direct sunlight and
strong lights, soft, indirect lighting is recommended for
comfortable viewing. Use curtains or blinds to prevent
direct sunlight falling on the screen.
Place on a sturdy platform, the mounting surface should
be flat and steady. It should be secured to the wall with
a sturdy tie using the clip on the back of the stand, or
secured to the platform using the fixing strap located
Clip
underneath the table top stand, this will prevent it from
falling over.
The LCD display panels are manufactured using an
extremely high level of precision technology, however
sometimes some parts of the screen may be missing
Side View Top View
picture elements or have luminous spots. This is not a
sign of a malfunction.
Make sure the television is located in a position where it cannot be pushed or hit by objects, as pressure will break
or damage the screen, and that small items cannot be inserted into slots or openings in the case.
Please take note
EXCLUSION CLAUSE
Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:
i) fire;
ii) earthquake;
iii) accidental damage;
iv) intentional misuse of the product;
v) use of the product in improper conditions;
vi) loss and/or damage caused to the product whilst in the possession of a third party;
vii) any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the owner’s
manual ;
viii) any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with
associated equipment;
Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not limited
to the following, loss of profit, interruption of business, the loss of recorded data whether caused during normal operation or
misuse of the product.
NOTE:
A Toshiba wall bracket or stand, where available, must be used. If a non Toshiba wall bracket or stand is used the product’s
BEAB approval will become void and the equipment is then used at the consumers own risk.
Sturdy tie
(as short as possible)
Clip
Clip
• The digital reception function of this television is only effective in the countries listed in the “COUNTRY SET UP” section of the
“DIGITAL MENU”. Depending on country/area, some of this television's functions may not be available. Reception of future
additional or modified services can not be guaranteed with this television.
• If stationary images generated by 4:3 broadcasts, text services, channel identification logos, computer displays, video games, on
screen menus, etc. are left on the television screen for any length of time they could become conspicuous, it is always advisable
to reduce both the brightness and contrast settings.
• Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3 outlines, this
is not a defect of the LCD TV and is not covered under the manufacturers warranty. Regular use of other size modes (eg:
Superlive) and varying the “side panel” brightness (if available on the model) will prevent permanent retention.
5
SETTING UP
The remote control
Simple at-a-glance reference of your remote
control.
1
3
4
8
9
10
14
15
16
17
1
To select device mode (T/R/D)*
2
For On/Standby mode (T/R/D)
3
Number buttons (T/R/D)
4
To select Audio Description mode on/off (T)
5
To select external input sources (T)
To select line input (R/D)
6
To switch between ATV (analogue television) and DTV
(digital television) (T)
To display Contents menu (R)
7
To change programme positions (T/R)
To change text pages (T)
2
5
6
7
11
12
13
18
19
20
8
To alter the TV volume (T/R/D)
9
To mute the TV sound (T/R/D)
10
To display the
To access Top Menu (R/D)
11
To exit Menus (T)
To return to previous Menu (R/D)
12
When using menus the arrows move the cursor on the
screen up, down, left or right.
(T/R/D)
13
To switch between TV, Radio and Favourite programmes
when in
To access Setup menu (R/D)
14
On-screen Menus (T)
DVD Menus (R/D)
15
Text and interactive service control buttons (T)
To work interactive service control on device (R)
16
Selectable picture preferences (T)
17
Widescreen viewing (T)
18
To display on-screen information (T/R/D)
To access index page in Text mode (T)
19
To call up text services in
services in
20
When in TV mode:
D
r
s
SUBTITLE Digital Subtitles or Analogue TEXT Subtitle
When in Text mode:
l
A
B
C
D
When using the Programme Guide:
Z
– 24 hours
z
+ 24 hours
CC
– 1 page
cc
+ 1 page
REGZA-LINK or DVD mode:
press W/w to PAUSE/STEP
press
press
press
press
press
press
press
* T=TV mode, R=REGZA-LINK mode, D=DVD mode
digital
on-screen Programme Guide (T)
Q
to confirm your selection
digital
mode
mode (T)
analogue
digital
Analogue time display
Picture still
Stereo/bilingual transmissions
pages if available
To access Sub pages
To reveal concealed text
To hold a wanted page
To enlarge text display size
To select a page whilst viewing a normal
c
to PLAY
CC
to REWIND
cc
to FAST FORWARD
V
to EJECT
v
to STOP
Z
to SKIP-REWIND
z
to SKIP-FORWARD
mode and interactive
6
SETTING UP
Inserting batteries and effective range of
the remote
Remove the back cover to reveal
the battery compartment and
make sure the batteries are
inserted the right way round.
Suitable battery types for this
remote are AAA, IEC R03 1.5V.
Do not combine a used, old
battery types. Remove dead batteries immediately to prevent
acid from leaking into the battery compartment. Dispose of
them in a designated disposal area.
not be exposed to excessive heat such as sunshine, fire or the
like.
The performance of the remote control will deteriorate beyond
a distance of five metres or outside an angle of 30 degrees
from the centre of the television. If the operating range
becomes reduced the batteries may need replacing.
battery with a new one or mix
Warning:
batteries must
7
SETTING UP
Connecting external equipment
Before connecting any external equipment, turn off all main power switches. If there is no switch
remove the mains plug from the wall socket.
OPTICAL DIGITAL AUDIO OUTPUT (DTV MODE ONLY)
HDMI™ INPUT
SOCKETS
COMPONENT VIDEO INP UT (EXT3)
SCART 2 (EXT2)
SCART 1 (EXT1)
*a decoder could
be Digital Satellite or
any other compatible
decoder.
decoder*
media recorder
Aerial cables:
Connect the aerial to the socket on the rear of the television.
If you use a decoder* and/or a media recorder it is essential
- - - - - - - - - - - - - - - - - - - - - -
that the aerial cable is connected through the decoder and/or
through the media recorder to the television.
SCART leads:
Connect the video recorder
Connect the decoder
media recorder
Before running
recorder to
The phono sockets alongside the COMPONENT VIDEO INPUT
sockets will accept L and R audio signals.
. . . . . . . . . . . . . . . . . . . . . . . . . .
IN/OUT
TV
SAT
socket to the decoder
Auto tuning
Standby
.
socket to the television. Connect the
socket to the television.
put your decoder and media
MEDIA REC
. socket.
The Digital Audio Output socket enables the connection of a
suitable surround sound system.
NOTE: this output is always
active.
HDMI™ (High-Definition Multimedia Interface) is for use with
a DVD, decoder or electrical equipment with digital audio and
video output. It is designed for best performance with 1080i
and 1080p high-definition video signals but will also accept
and display VGA, 480i, 480p, 576i, 576p and 720p signals.
FIXING STRAP
POWER switch
NOTE:
Although this television is able to connect to HDMI
equipment it is possible that some equipment may not operate
correctly.
A wide variety of external equipment can be connected
to the back of the television, therefore the relevant
owners manuals for
referred to.
We recommend
all
additional equipment must be
SCART 1
for a decoder and
SCART 2
for a
media recorder.
If connecting S-VIDEO equipment, set the
See
page 35
.
If the television automatically switches over to monitor external
equipment, return to normal television by pressing the desired
INPUT
for
EXT2
.
programme position button. To recall external equipment,
press
o
to select between
HDMI2, HDMI3, PC
DTV, EXT1, EXT2, EXT3, HDMI1
or
ATV
.
,
HDMI, the HDMI logo, and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC.
8
SETTING UP
Connecting an HDMI™ or DVI
device to the HDMI input
The HDMI input on your television receives digital
audio and uncompressed digital video from an
HDMI source device, or uncompressed digital video
from a DVI (Digital Visual Interface) source device.
This input is designed to accept HDCP (High-Bandwidth
Digital-Content Protection) program material in digital form
from EIA/CEA-861-D–compliant
devices (such as a set-top box or DVD player with HDMI or DVI
output). For acceptable video signal formats, see page 47.
NOTE:
• Some early HDMI equipment may not work properly with
your latest HDMI TV, due to the adoption of a new standard.
Please unplug your HDMI cable first and then try setting the
Lip Sync
to “
Off
”. Your early HDMI source should operate
properly with your television. See page 36.
• Supported Audio format: Linear PCM, sampling rate 32/
44.1/48kHz.
To connect an HDMI device
Connect an HDMI cable (type A connector) to the HDMI
terminal.
For proper operation, it is recommended that you use an HDMI
cable with the HDMI Logo ( ).
• If your HDMI connection is capable of 1080p and/or your
television is capable of refresh rates greater than 60Hz, you
will need a Category 2 cable. Conventional HDMI/DVI cable
may not work properly with this mode.
• HDMI cable transfers both video and audio. Separate analog
audio cables are not required (see illustration).
• See “HDMI1 audio” on page 36.
The HDMI3 terminal is located at the side of the television.
[1]
consumer electronic
To connect a DVI device
Connect an HDMI-to-DVI adapter cable (HDMI type A
connector) to HDMI1 terminal and audio cables to the PC/
HDMI1 (AUDIO) socket (see illustration).
• The recommended HDMI-to-DVI adapter cable length is 6.6
ft (2m).
• An HDMI-to-DVI adapter cable transfers video only.
Separate analog audio cables are required.
• See “HDMI1 audio” on page 36.
Audio cable for HDMI to
television connection
(not supplied)
HDMI-to- DVI adapter Cable
DVI device
VIDEO AUDIO
LR
IN
OUT
R
L
NOTE:
To ensure that the HDMI or DVI device is reset properly, it is
recommended that you follow these procedures:
• When turning on your electronic components, turn on the
television first, and then the HDMI or DVI device.
• When turning off your electronic components, turn off the
HDMI or DVI device first, and then the television.
DVI/HDCP
OUT
HDMI cable
HDMI device
VIDEO AUDIO
LR
IN
OUT
R
L
To view the HDMI device video, press the
HDMI2 or HDMI3 mode.
HDMI OUT
o
to select HDMI1,
[1] EIA/CEA-861-D compliance covers the transmission of uncompressed
digital video with high-bandwidth digital content protection, which is
being standardized for reception of high-definition video signals. Because
this is an evolving technology, it is possible that some devices may not
operate properly with the television.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered t rademarks of HDMI Licensing LLC.
9
SETTING UP
REGZA-LINK connection
You can control the basic functions of connected audio/video devices using the televisions remote control
if you connect a REGZA-LINK compatible AV amplifier or playback device. For an explanation of setup and
operations, see pages 37–38.
AV amplifier
VIDEO
AUDIO
LR
R
L
IN
OUT
HDMI OUTHDMI
IN
Playback device
VIDEO
AUDIO
LR
R
L
IN
OUT
HDMI OUT
For the setup shown above, you will need three HDMI cables
(see page 9).
NOTE:
• If several devices are connected, the REGZA-LINK feature
may not operate properly.
• For proper operation, it is recommended that you use HDMI
cables with the HDMI Logo ( )
• The HDMI3 terminal is located at the side of the television.
Playback device
VIDEO
AUDIO
LR
R
L
IN
OUT
HDMI OUT
Before controlling the device(s):
• After completing the above connections, set the REGZA-LINK
menu as you desire (see page 37).
• The connected devices must also be set. For details, see the
operation manual for each device.
• The REGZA-LINK feature uses CEC technology as regulated
by the HDMI standard.
• This feature is limited to models incorporating Toshiba’s
REGZA-LINK. However, Toshiba is not liable for those
operations. Refer to individual instruction manuals for
compatibility information.
10
SETTING UP
Connecting a computer
With either the RGB/PC or HDMI connection, you
