Published in Japan Sep. 2005 (YC) TOSHIBA CORPORATION 2005
TABLE OF CONTENTS
SERVICE SAFETY PRECAUTIONS .................................................................................................................................... 3
HANDLING THE LCD MODULE .......................................................................................................................................... 5
SERVICE MODE .................................................................................................................................................................. 7
LOCATION OF CONTROLS ...............................................................................................................................................12
LAYOUT OF MAJOR BOARDS .......................................................................................................................................... 14
CHASSIS AND CABINET REPLACEMENT PARTS LIST ................................................................................................. 20
PC BOARDS TOP & BOTTOM VIEW ................................................................................................................................ 30
• The caution items shown here describe major safety issues and should always be observed.
• The meanings of the various indications are as follows.
WARNING
CAUTION
* Physical damage means major damage to a home, furnishings and other possessions.
Examples of marks
SHOCK HAZARD
PROHIBIT DISASSEM-
BLING
UNPLUG
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users due to a product defect after the service operation is completed, could possibly be in
danger of injury or even death in the event of operational error.
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users after the service operation is completed, could possibly be in danger of injury, or
where there could be physical damage in the event of operational error.
The" indicates caution (including danger and warning).
The actual meaning of this caution is indicated inside the
The example shown to the left indicates the danger of "electrical shock".
The
indicates a forbidden action.
The actual meaning of this caution is indicated inside the
The example shown to the left indicates that disassembly is forbidden.
The
-
indicates a forced action (an action that must be performed).
The actual meaning of this forced action is indicated by
The example shown to the left indicates that the power plug must be disconnected.
"
or nearby illustrations or text.
or nearby illustrations or text.
-
or nearby illustrations or text.
– 3 –
KEEP CHILDREN
AWAY
UNPLUG
SHOCK HAZARD
USE SPECIFIED
PARTS
CAUTION FOR
WIRING
CAUTION FOR
ASSEMBLING /
WIRING
WARNING
• Always advise users to keep children away.
There is danger of injury to children from tools, disassembled products, etc.
• Always disconnect the power plug before starting work whenever power is not required.
Failure to disconnect the power plug before starting work can result in electrical shock.
• Depending on the model, use an insulation transformer or wear gloves when servicing with the
power on, and disconnect the power plug to avoid electrical shock when replacing parts.
In some cases, alternating current is also impressed in the chassis, so electrical shock is possible if the chassis is contacted with the power on.
• Always use the replacement parts specified for the particular model when making repairs.
The parts used in products have the necessary safety characteristics such as inflammability,
voltage resistance, etc.; therefore, use only replacement parts that have these same characteristics.
Use only the specified parts when the
• Parts mounting and routing of the wiring should be the same as that used originally.
For safety purposes, insulating materials such as tubing or tape is sometimes used and printed
circuit boards are sometimes mounted floating.
Also make sure that wiring is routed and clamped to avoid parts that generate heat and which
use high voltage. Always follow the original scheme.
• After a repair has been completed, reassemble all disassembled parts, and route and reconnect the wiring, in accordance with the original scheme.
Do not allow internal wiring to be pinched by cabinets, panels, etc.
Any error in reassembly or wiring can result in electrical leakage, flame, etc., and may be
hazardous.
mark is included in a circuit diagram or parts list.
CHECK INSULATION
RESISTANCE
PROHIBIT
REMODELING
• After completing the work, disconnect the power plug from the outlet, remove the antenna, turn
on the power switch. Then, use a 500V insulation resistance meter to check the insulation
resistance of the antenna terminal, other metallic parts and between the prongs of the power
plug to make sure that the insulation resistance is 1M 1 or more.
The set will require inspection and repair if the insulation resistance is below this value.
• Never remodel the product in any way.
Remodeling can result in improper operation, malfunction, or electrical leakage and flame,
which may be hazardous
– 4 –
GENERALADJUSTMENTSSPECIFICINFORMATIONS
HANDLING THE LCD MODULE
Safety Precautions
In the event that the screen is damaged or the liquid crystal
(fluid) leaks, do not breathe in or drink this fluid. Also, never
touch this fluid.
Such actions could cause toxicity or skin irritation. If this fluid
should enter the mouth, rinse the mouth thoroughly with water. If the fluid should contact the skin or clothing, wipe off
with alcohol, etc., and rinse thoroughly with water. If the fluid
should enter the eyes, immediately rinse the eyes thoroughly
with running water.
Precautions for Handling the LCD Module
The LCD module can easily be damaged during disassembly
or reassembly; therefore, always observe the following precautions when handling the module.
1. When attaching the LCD module to the LCD cover, position it appropriately and fasten at the position where the
display can be viewed most conveniently.
3. If the panel surface becomes soiled, wipe with cotton or a
soft cloth. If this does not remove the soiling, breathe on
the surface and then wipe again.
If the panel surface is extremely solied, use a CRT cleaner
as a cleaner. Wipe off the panel surface by drop the cleaner
on the cloth. Do not drop the cleaner on the panel. Pay
attention not to scratch the panel surface.
4. Leaving water or other fluids on the panel screen for an
extended period of time can result in discoloration or
stripes. Immediately remove any type of fluid from the
screen.
2. Carefully align the holes at all four corners of the LCD
module with the corresponding holes in the LCD cover
and fasten with screws. Do not strongly push on the module because any impact can adversely affect the performance. Also use caution when handling the polarized screen
because it can easily be damaged.
The metal edges of the LCD module
CAUTION
are sharp, so use caution to avoid injury.
5. Glass is used in the panel, so do not drop or strike with
hard objects. Such actions can damage the panel.
6. CMOS-LSI circuitry is used in the LCD module, so avoid
damage due to static electricity. When handling the module, use a wrist ground or anchor ground.
– 5 –
7. Do not expose the LCD module to direct sunlight or strong
ultraviolet rays for an extended period of time.
8. Do not store the LCD module below the temperature conditions described in the specifications. Failure to do so
could result in freezing of the liquid crystal due to cold air
or loss of resilience or other damage.
9. Do not disassemble the LCD module. Such actions could
result in improper operation.
10. When transporting the LCD module, do not use packing
containing epoxy resin (amine) or silicon resin (alcohol or
oxim). The gas generated by these materials can cause
loss of polarity.
– 6 –
SERVICE MODE
1. ENTERING SERVICE MODE
1) Pressbutton once on 2) Pressbutton again and3) While pressing thebutton,
Remote Control.keep pressing.press MENU button on TV set.
or Sound Mute
2.DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
Service modeAdjustment mode
Press
Press
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
(Service mode display)
Test signal selection :a button (on Remote)
Selection of the adjustment items :Channel s/t (on TV or Remote)
Change of the data value :Volume ; +/– (on TV or Remote)
Adjustment menu mode ON/OFF :MENU button (on TV)
Initialization of the memory : CALL + Channel button on TV (s)
Reset the count of operating protect
CAUTION : Never try to perform initialization unless you have changed the memory IC.
: 7 button
Color thickness correction
note: Displayed differently as shown below, de-
pending on the setting of the receiving color
system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
– 7 –
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL s button in the service mode changes the adjustment items in the order of table-2.
(t button for reverse order)
5. ADJUSTING THE DATA
1) Pressing of VOLUME ; +/– button will change the value of data in the range from 00H to FFH. The variable range
depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■ INITIALIZATION OF MEMORY DATA
After replacing EEPROM IC, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL s button on theTV.The initialization of EEPROM IChas been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto tune” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless EEPROM IC has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of a button on the Remote Control changes the built-in test patterns on screen as described below
in SERVICE MODE.
R
All BlackAll White
BSignal offG
SignalsPicture
• Red raster
• Green raster
• Blue raster
• All Black
• All White
– 8 –
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s is executed properly.
2) During diagnosis, the following displays are shown.
1
2
3
4
5
6
78
1
Firmware :
Version information of microprocessor
In case of file name : WL58_EU and Version : 0100 indicates[WL58_EU_0100].
2
Time : Total hour of turn the TV on. (Unit : H)
3
Power : Operation number of protecting circuit ----"000" is normal.
When indication is other than "000", overcurrent apt to flow, and circuit parts may possibly be damaged.
4
Bus line : --"OK" is normal
"SCL-GND"(Red indication) : SCL-GND short circuit
"SDA-GND"(Red indication) : SDA-GND short circuit
"SCL-SDA"(Red indication) : SCL-SDA short circuit
5
Bus cont : --- "OK" is normal.
NG is abnormal(Red indication), when type name of semiconductor indicates.
1) Press “9” button twice on Remote Control during display of adjustment menu in the service mode. The version of main
MPU will begin to check.
2) During Version Check, the following displays are shown.
M
N
O
P
Q
R
ST
M
MAIN MPU :
Version information of microprocessor
In case of file name : WL58 _EU, Version 0100 for Code Program Version
and (E16) for OSD Version indicates [WL58_EU_0100(E16)]
N
EEPROM :
Version information of EEPROM : Display 1 byte data.
O
SUB MPU :
Version information of SUB MPU : Display 1 byte data.
P
OPTION :
Option information : Display six numbers of 1 byte data.
Q
HDMI ID :
HDMI ID information : Display 4 byte data.
R
CD number : Display 8 digit number
S
Model name : Display 7 digit number
T
Panel Vender information display
The following Panel Vender and screen size are displayed.
Panel
PDP
Example : SHP-32 indicates that Vender is SHP and Screen Size is 32 inch.
Panel VenderScreen Size(Inch)
LPLLCD
SHP-26
CMO
LG
-23
-32
-37
-42
-42
– 10 –
10. STATUS CHECK MODE
1) Press “9” button thrice on Remote Control during display of adjustment menu in the service mode. The status of this model
will begin to check.
2) During Status Check, the following displays are shown.
1
2
3
EXT1
1080i-50
C6 38 54 CE 08
4
5
M
MAIN :
Main source information :
Display RF position number (0 - 99) on the main screen, or Input Source (EXT1/2/3/HDMI etc.)
N
MAIN FORMAT :
Display Video and PC format information
O
MAIN PLL :
Main PLL information : Display five numbers of 1 byte data.
P
SCREEN SIZE :
Display the screen size as follows.
Super live
Cinema
Subtitle
14:9
Wide
4:3
0000 0000 0000
Q
OTHER STATUS :
Other status information : Display three numbers of 2 byte data.
– 11 –
Standby
GREEN – Active standby
RED – Power on
INPUT 5
(EXT5)
Front
media recorder
decoder*
CABLE HOLDER
FIXING STRAP
HDMI™ INPUT SOCKETS
SCART 1
(EXT1)
SCART 2
(EXT2)
SCART 3
(EXT3)
IN/OUT
MEDIA REC.
TV
SAT
COMMON INTERFACE
COMMON INTERFACE
The Common Interface is
for a Conditional Access
Module (CAM). There is
access for two CAMs.
Contact a service provider.
LOCATION OF CONTROLS
Back
– 12 –
Remote control
INFO button –
To display digital on-screen information
To display analogue on-screen
information and analogue text
initial/index function
Number buttons
To return to the previous programme
To display the digital on-screen
To change programme positions and
When using a TOSHIBA VCR or DVD:
to PAUSE
press
m
press
to EJECT
w
press
press
press
press
press
press
to SKIP-REWIND
l
q
to SKIP-FORWARD
l
s
to PLAY
r
to STOP
p
to REWIND
q
to FAST FORWARD
s
Programme Guide
On-screen Menus
Widescreen viewing
text pages
To select mode
To call up text services in analogue mode
and interactive services in digital mode
For On/Standby mode
To select input from external sources
To access sub-pages when in analogue
text mode
Selectable picture preferences
To exit Menus
When using menus the arrows move the
cursor on the screen up, down, left or
right. OK to confirm your selection
Text and interactive service control
buttons
Stereo/Bilingual reception
To alter the volume
To mute the sound
When in TV mode:
uStill picture
ATV/DTV
TV/FAV RADIO
SUBTITLE
8/9
When in Text mode:
r
q
s
8/9
Analogue/Digital mode selection
No function on this model
Digital Subtitles
Time display
To reveal concealed text
To hold a wanted page
To enlarge text display size
To select a page whilst viewing a
normal picture
– 13 –
LAYOUT OF MAJOR BOARDS
U003B
FRONT AV BOARD
U003E
PC HDMI BOARD
U003A
TN AV BOARD
U005
INTERFACE BOARD
U004
LOW B BOARD
B002
DVB T MODULE
U003F
KEY BOARD
U001
SIGNAL BOARD
U003C
RMT LED BOARD
U002A
POWER BOARD
U002B
AC IN BOARD
– 14 –
MECHANICAL DISASSEMBLY
(Representative of 32WLT58)
1. Remove the stand (foot) and back cover.
A420
A450
PP 5×16 SW+W SBN
×5
A445
PP3×8
+SW+W SBN
×5
BITTB4×16 SBN
×10
A401
2. Remove the boards (FRONT AV,PC HDMI, KEY) and back center cover.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SERVICE SAFETY PRECAUTIONS" ON PAGE 3 OF
THIS MANUAL.
CAUTION: The international hazard symbols "" in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety
of the receiver through improper servicing.
NOTICE:
••
•
The part number must be used when ordering parts, in order to assist in processing, be sure to include the
••
Model number and Description.
••
•
The PC board assembly with * mark is no longer available after the end of the production.
±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
LocationParts No. Description
No.
#1 : [32WLT58]
#2 : [37WLT58]
CAPACITORS
C10176109103 CERAMIC CHIP, 50V B 0.01UF K
C10276073019 ELECTROLYTIC, 10V 470UF M 3A
C10376109102 CERAMIC CHIP, 50V B 1000PF K
C10476619143 ELECTROLYTIC CHIP, 50V 4.7UF M
C10576073019 ELECTROLYTIC, 10V 470UF M 3A
C11376109102 CERAMIC CHIP, 50V B 1000PF K
C11776109103 CERAMIC CHIP, 50V B 0.01UF K
C11876109103 CERAMIC CHIP, 50V B 0.01UF K
C16276105101 CERAMIC CHIP, 50V CH 100PF J
C16476100103 CERAMIC CHIP, 50V F 0.01UF Z
C19076092730 CERAMIC CHIP, 16V B 0.1UF K
C50176100104 CERAMIC CHIP, 25V F 0.1UF Z
C50276100104 CERAMIC CHIP, 25V F 0.1UF Z
C50376619046 ELECTROLYTIC CHIP, 16V 470UF
C50476109103 CERAMIC CHIP, 50V B 0.01UF K
C50576619046 ELECTROLYTIC CHIP, 16V 470UF
C50676109103 CERAMIC CHIP, 50V B 0.01UF K
C51476665221 ELECTROLYTIC, 10V 220UF M 3A
C51676105110 CERAMIC CHIP, 50V CH 11PF J
C51776092785 CERAMIC CHIP, 10V B 0.47UF K
C51976619048 ELECTROLYTIC CHIP, 25V 4.7UF M
C52176092733 CERAMIC CHIP, 50V B 0.022UF K
C52476109103 CERAMIC CHIP, 50V B 0.01UF K
C52676109103 CERAMIC CHIP, 50V B 0.01UF K
C52776619071 ELECTROLYTIC CHIP, 50V 2.2UF
C52976100104 CERAMIC CHIP, 25V F 0.1UF Z
C53076619157 ELECTROLYTIC CHIP, 16V 100UF
C60576109102 CERAMIC CHIP, 50V B 1000PF K
C60676109102 CERAMIC CHIP, 50V B 1000PF K
C61276664102 ELECTROLYTIC, 6.3V 1000UF M 3A
C63176619102 ELECTROLYTIC CHIP, 16V 47UF M
C63276092731 CERAMIC CHIP, 16V B 1UF K
C65176092463 CERAMIC CHIP, 16V B 0.22UF K
C65276092463 CERAMIC CHIP, 16V B 0.22UF K
C65376092538 CERAMIC CHIP, 10V F 1UF Z
C65576109103 CERAMIC CHIP, 50V B 0.01UF K
C66176109102 CERAMIC CHIP, 50V B 1000PF K
C66276109102 CERAMIC CHIP, 50V B 1000PF K
C66376619100 ELECTROLYTIC CHIP, 16V 10UF M
C66576669479 ELECTROLYTIC, 50V 4.7UF M
C66676669479 ELECTROLYTIC, 50V 4.7UF M
C67176669100 ELECTROLYTIC, 50V 10UF M
LocationParts No. Description
No.
C67476669100 ELECTROLYTIC, 50V 10UF M
C67776109681 CERAMIC CHIP, 50V B 680PF K
C67876109681 CERAMIC CHIP, 50V B 680PF K
C68076668102 ELECTROLYTIC, 35V 1000UF M 3A
C68176668102 ELECTROLYTIC, 35V 1000UF M 3A
C68276668102 ELECTROLYTIC, 35V 1000UF M 3A
C69076815103 CERAMIC CHIP, 50V B 0.01UF K
C69476285104 CERAMIC CHIP, 50V B 0.1UF K
C69676285104 CERAMIC CHIP, 50V B 0.1UF K
C80176168007 MT PLA AC275V 1UF M
C80276503508 MT PLA PCX2 337 11474
C80676092555 CERAMIC DISC, AC250V E 1000PF M
C80776092555 CERAMIC DISC, AC250V E 1000PF M
C80876092553 CERAMIC DISC, AC250V B 470PF K
C80976092553 CERAMIC DISC, AC250V B 470PF K
C81276109102 CERAMIC CHIP, 50V B 1000PF K
C81476109102 CERAMIC CHIP, 50V B 1000PF K
C81576073037 ELECTROLYTIC, 16V 47UF M 3A
C815A23960136 ADHESIVE, SILICONE, TSE3843-W
C81676109102 CERAMIC CHIP, 50V B 1000PF K
C81776109102 CERAMIC CHIP, 50V B 1000PF K
C81876669010 ELECTROLYTIC, 50V 1UF M
C81976539684 PLASTIC FILM, 50V 0.68UF J
C82076125010 CHEMICON CE69R 450V 270UF M 3H
C82176125011 CHEMICON CE04R 450V 82UF M 4A
C82276214103 CERAMIC DISC, 500V B 0.01UF K
C82476168008 MT PLA 450V 1UF K
C82576168008 MT PLA 450V 1UF K
C82676092339 CERAMIC DISC, 2KV 330PF K
C82776092339 CERAMIC DISC, 2KV 330PF K
C84076125009 CHEMICON 450V 47UF M
C84376166001 CERAMIC DISK CC45 SL 3.15KV 47PF J
C84476669479 ELECTROLYTIC, 50V 4.7UF M
C84576073196 ELECTROLYTIC, 50V 22UF M 3A
C84676073140 ELECTROLYTIC CE04P 10V 680UF M 3A
C84776665471 ELECTROLYTIC, 10V 470UF M
C84876214471 CERAMIC DISC, 500V B 470PF K
C849A23960136 ADHESIVE, SILICONE, TSE3843-W
C86076214103 CERAMIC DISC, 500V B 0.01UF K
C86176503053 PLASTIC FILM, 63V 1UF J
C86276669229 ELECTROLYTIC, 50V 2.2UF M
C86376503049 PLASTIC FILM, 63V 0.47UF J
C86476567224 PLASTIC FILM, 50V 0.22UF J
C86576567224 PLASTIC FILM, 50V 0.22UF J
C86676092341 CERAMIC DISC, 2KV R 470PF K
C86876435221 CERAMIC DISC, 500V SL 220PF J
– 20 –
LocationParts No. Description
No.
C86976435221 CERAMIC DISC, 500V SL 220PF J
C87076503425 PLASTIC FILM CQ92 3D2J473J-K5
C87276073189 ELECTROLYTIC, 35V 1000UF M
C87376073189 ELECTROLYTIC, 35V 1000UF M
C87676073204 ELECTROLYTIC CE04P 50V 330UF M 3A
C87776669229 ELECTROLYTIC, 50V 2.2UF M
C87876503041 PLASTIC FILM , 63V 0.1UF J
C88076503229 PLASTIC FILM, 1250VH 1000PF H
C88176092337 CERAMIC DISC, 2KV 220PF K
C88276567334 PLASTIC FILM, 50V 0.33UF J
C88376212221 CERAMIC DISC, 50V B 220PF K
C88476073196 ELECTROLYTIC, 50V 22UF M 3A
C88576214471 CERAMIC DISC, 500V B 470PF K
C88676212152 CERAMIC DISC, 50V B 1500PF K
C88776214471 CERAMIC DISC, 500V B 470PF K
C88876073189 ELECTROLYTIC, 35V 1000UF M
C88976073189 ELECTROLYTIC, 35V 1000UF M
C89076796102 ELECTROLYTIC, 35V 1000UF M
C89176214471 CERAMIC DISC, 500V B 470PF K
C89276676100 ELECTROLYTIC, 100V 10UF M 3A
C89376747220 ELECTROLYTIC, 50V 22UF M 7L 3A
C89476214471 CERAMIC DISC, 500V B 470PF K
C89576073188 ELECTROLYTIC, 35V 680UF M
C89676073188 ELECTROLYTIC, 35V 680UF M
C89776796102 ELECTROLYTIC, 35V 1000UF M
C89876669010 ELECTROLYTIC, 50V 1UF M
C817176092730 CERAMIC CHIP, 16V B 0.1UF K
C819176092730 CERAMIC CHIP, 16V B 0.1UF K
C821076105331 CERAMIC CHIP, 50V CH 330PF J
C821176815473 CERAMIC CHIP, 50V B 0.047UF K
C821276092178 CERAMIC CHIP, 25V B 0.1UF K
C821376109102 CERAMIC CHIP, 50V B 1000PF K
C824176073196 ELECTROLYTIC, 50V 22UF M 3A
C825076092341 CERAMIC DISC, 2KV R 470PF K
C825176434100 CERAMIC DISC, 500V SL 10PF D
C839076109102 CERAMIC CHIP, 50V B 1000PF K
C840176092733 CERAMIC CHIP, 50V B 0.022UF K
C840276092733 CERAMIC CHIP, 50V B 0.022UF K
C840376669470 ELECTROLYTIC, 50V 47UF M
C849076669010 ELECTROLYTIC, 50V 1UF M
C860176591682 PLASTIC FILM, 50V 6800PF J
C860276212101 CERAMIC DISC, 50V B 100PF K
C860576285104 CERAMIC CHIP, 50V B 0.1UF K
C870176567224 PLASTIC FILM, 50V 0.22UF J
C870276287224 CHIP CER 50V F 224Z GRM319F11H224ZA01D
C870376109102 CERAMIC CHIP, 50V B 1000PF K
C880176092730 CERAMIC CHIP, 16V B 0.1UF K
C880276092883 CERAMIC CHIP, 50V B 0.1UF K
C889176503049 PLASTIC FILM, 63V 0.47UF J
CB0176202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB0276202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB0376100104 CERAMIC CHIP, 25V F 0.1UF Z
CB0476100104 CERAMIC CHIP, 25V F 0.1UF Z
CB0576202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB3876100104 CERAMIC CHIP, 25V F 0.1UF Z
CC0176105100 CERAMIC CHIP, 50V CH 10PF D
CC0276105100 CERAMIC CHIP, 50V CH 10PF D
CC0376105100 CERAMIC CHIP, 50V CH 10PF D
CC0476105100 CERAMIC CHIP, 50V CH 10PF D
CC0576105100 CERAMIC CHIP, 50V CH 10PF D
CC0676105100 CERAMIC CHIP, 50V CH 10PF D
CC0776105100 CERAMIC CHIP, 50V CH 10PF D
CC0876105100 CERAMIC CHIP, 50V CH 10PF D
CC0976105100 CERAMIC CHIP, 50V CH 10PF D
CC1076105100 CERAMIC CHIP, 50V CH 10PF D
CC1176109102 CERAMIC CHIP, 50V B 1000PF K
CC1276109102 CERAMIC CHIP, 50V B 1000PF K
CC1476109102 CERAMIC CHIP, 50V B 1000PF K
CC1576109102 CERAMIC CHIP, 50V B 1000PF K
CC1676109102 CERAMIC CHIP, 50V B 1000PF K
CC1776109102 CERAMIC CHIP, 50V B 1000PF K
CC2176109102 CERAMIC CHIP, 50V B 1000PF K
CC3176105100 CERAMIC CHIP, 50V CH 10PF D
76109472 CERAMIC CHIP, 50V B 4700PF K
CC3276105100 CERAMIC CHIP, 50V CH 10PF D
CC3376109102 CERAMIC CHIP, 50V B 1000PF K
LocationParts No. Description
No.
CC4076109102 CERAMIC CHIP, 50V B 1000PF K
CC4176109102 CERAMIC CHIP, 50V B 1000PF K
CC5976109102 CERAMIC CHIP, 50V B 1000PF K
CC6076109102 CERAMIC CHIP, 50V B 1000PF K
CC6176109102 CERAMIC CHIP, 50V B 1000PF K
CC6276109102 CERAMIC CHIP, 50V B 1000PF K
CC6376109102 CERAMIC CHIP, 50V B 1000PF K
CC6476109102 CERAMIC CHIP, 50V B 1000PF K
CC6576109102 CERAMIC CHIP, 50V B 1000PF K
CC6676109102 CERAMIC CHIP, 50V B 1000PF K
CC6776109102 CERAMIC CHIP, 50V B 1000PF K
CC6876109102 CERAMIC CHIP, 50V B 1000PF K
CC6976109102 CERAMIC CHIP, 50V B 1000PF K
CC7076109102 CERAMIC CHIP, 50V B 1000PF K
CC7476109102 CERAMIC CHIP, 50V B 1000PF K
CC7576109102 CERAMIC CHIP, 50V B 1000PF K
CC7976109102 CERAMIC CHIP, 50V B 1000PF K
CC8276109102 CERAMIC CHIP, 50V B 1000PF K
CD8076666470 ELECTORLYTIC, 16V 47UF M 3A
CD8276669100 ELECTROLYTIC, 50V 10UF M
CD8376109103 CERAMIC CHIP, 50V B 0.01UF K
CD8476109103 CERAMIC CHIP, 50V B 0.01UF K
CD8576109103 CERAMIC CHIP, 50V B 0.01UF K
CD8676109103 CERAMIC CHIP, 50V B 0.01UF K
CD8776109103 CERAMIC CHIP, 50V B 0.01UF K
CD23076109103 CERAMIC CHIP, 50V B 0.01UF K
CD23376092628 CERAMIC CHIP, 6.3V B 10UF K
CD23476092573 CERAMIC CHIP, 16V B 0.47UF K
CD23576100104 CERAMIC CHIP, 25V F 0.1UF Z
CE1076666470 ELECTORLYTIC, 16V 47UF M 3A
CE1176539474 PLASTIC FILM, 50V 0.47UF J
CE1276666470 ELECTORLYTIC, 16V 47UF M 3A
CE3076073186 ELECTROLYTIC, 35V 470UF M
CE3176125012 ELECTROLYTIC 04CQ 25V 2700UF M A
CE3276073007 ELECTROLYTIC, 6.3V 3300UF M 3A
CE3376539104 PLASTIC FILM, 50V 0.1UF J
CE3476539104 PLASTIC FILM, 50V 0.1UF J
CE3576539334 PLASTIC FILM, 50V 0.33UF J
CE3676666470 ELECTORLYTIC, 16V 47UF M 3A
CE6076073186 ELECTROLYTIC, 35V 470UF M
CE6176617028 ELECTROLYTIC, 16V 1200UF M
CE6276073020 ELECTROLYTIC, 10V 1000UF M 3A
CE6376539104 PLASTIC FILM, 50V 0.1UF J
CE6476539104 PLASTIC FILM, 50V 0.1UF J
CE6576666470 ELECTORLYTIC, 16V 47UF M 3A
CE6676539474 PLASTIC FILM, 50V 0.47UF J
CE6776666470 ELECTORLYTIC, 16V 47UF M 3A
CE9076073186 ELECTROLYTIC, 35V 470UF M
CE9176617028 ELECTROLYTIC, 16V 1200UF M
CE9276666471 ELECTROLYTIC, 16V 470UF M
CE9376539104 PLASTIC FILM, 50V 0.1UF J
CE9476539104 PLASTIC FILM, 50V 0.1UF J
CE9576668101 ELECTROLYTIC, 35V 100UF M 3A
CR0176092730 CERAMIC CHIP, 16V B 0.1UF K
CR0276100104 CERAMIC CHIP, 25V F 0.1UF Z
CR0376619157 ELECTROLYTIC CHIP, 16V 100UF
CR2676100104 CERAMIC CHIP, 25V F 0.1UF Z
CR2776619157 ELECTROLYTIC CHIP, 16V 100UF
CS0176092731 CERAMIC CHIP, 16V B 1UF K
CS0276092515 CERAMIC CHIP, 16V F 4.7UF Z
CS0376092726 CERAMIC CHIP, 10V B 2.2UF K
CS0476092726 CERAMIC CHIP, 10V B 2.2UF K
CS0576092726 CERAMIC CHIP, 10V B 2.2UF K
CS0676092726 CERAMIC CHIP, 10V B 2.2UF K
CS0876092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS0976092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS1076092628 CERAMIC CHIP, 6.3V B 10UF K
CS1176092628 CERAMIC CHIP, 6.3V B 10UF K
CS1276109473 CERAMIC CHIP, 25V B 0.047UF K
CS1376092628 CERAMIC CHIP, 6.3V B 10UF K
CS1476092628 CERAMIC CHIP, 6.3V B 10UF K
CS1576092628 CERAMIC CHIP, 6.3V B 10UF K
CS1676092628 CERAMIC CHIP, 6.3V B 10UF K
CS2676619100 ELECTROLYTIC CHIP, 16V 10UF M
CS3176092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS3276092611 CERAMIC CHIP, 6.3V B 2.2UF K
– 21 –
LocationParts No. Description
No.
CS3376092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS3476092731 CERAMIC CHIP, 16V B 1UF K
CS3976092573 CERAMIC CHIP, 16V B 0.47UF K
CS4076092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4176092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4276092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4376092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4476092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4576092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4676092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4776092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4876092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS4976092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5076092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5176092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5276092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5376092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5476092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5576092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5676092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS5776619102 ELECTROLYTIC CHIP, 16V 47UF M
CS6276092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS6476619101 ELECTROLYTIC CHIP, 16V 22UF M
CS8276092609 CERAMIC CHIP, 10V B 4,7UF K
CS8376092609 CERAMIC CHIP, 10V B 4,7UF K
CS8576092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS8676092611 CERAMIC CHIP, 6.3V B 2.2UF K
CS8876092609 CERAMIC CHIP, 10V B 4,7UF K
CS8976105101 CERAMIC CHIP, 50V CH 100PF J
CS9076092609 CERAMIC CHIP, 10V B 4,7UF K
CS9176105101 CERAMIC CHIP, 50V CH 100PF J
CS9376092515 CERAMIC CHIP, 16V F 4.7UF Z
CT0176092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT0476105151 CERAMIC CHIP, 50V CH 150PF J
CT0576092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT0676092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT0776092790 CERAMIC CHIP CK732B 6.3V 10UF K
CT0876100104 CERAMIC CHIP, 25V F 0.1UF Z
CT0976109103 CERAMIC CHIP, 50V B 0.01UF K
CV0176666471 ELECTROLYTIC, 16V 470UF M
CV0276100104 CERAMIC CHIP, 25V F 0.1UF Z
CV0376100104 CERAMIC CHIP, 25V F 0.1UF Z
CV0476100104 CERAMIC CHIP, 25V F 0.1UF Z
CV1276092731 CERAMIC CHIP, 16V B 1UF K
CV1376092731 CERAMIC CHIP, 16V B 1UF K
CV1476092731 CERAMIC CHIP, 16V B 1UF K
CV1576100104 CERAMIC CHIP, 25V F 0.1UF Z
CV1676092731 CERAMIC CHIP, 16V B 1UF K
CV1776092731 CERAMIC CHIP, 16V B 1UF K
CV1876100104 CERAMIC CHIP, 25V F 0.1UF Z
CV1976092731 CERAMIC CHIP, 16V B 1UF K
CV2076092731 CERAMIC CHIP, 16V B 1UF K
CV2176092731 CERAMIC CHIP, 16V B 1UF K
CV2276092731 CERAMIC CHIP, 16V B 1UF K
CV2376092731 CERAMIC CHIP, 16V B 1UF K
CV2476092731 CERAMIC CHIP, 16V B 1UF K
CV2576092731 CERAMIC CHIP, 16V B 1UF K
CV2676092731 CERAMIC CHIP, 16V B 1UF K
CV2776092731 CERAMIC CHIP, 16V B 1UF K
CV2876092731 CERAMIC CHIP, 16V B 1UF K
CV2976092731 CERAMIC CHIP, 16V B 1UF K
CV3376100104 CERAMIC CHIP, 25V F 0.1UF Z
CV3476100104 CERAMIC CHIP, 25V F 0.1UF Z
CV3576619157 ELECTROLYTIC CHIP, 16V 100UF
CV3676100104 CERAMIC CHIP, 25V F 0.1UF Z
CV4076100104 CERAMIC CHIP, 25V F 0.1UF Z
CV4176100104 CERAMIC CHIP, 25V F 0.1UF Z
CV5076619102 ELECTROLYTIC CHIP, 16V 47UF M
CV5176619102 ELECTROLYTIC CHIP, 16V 47UF M
CV5276619102 ELECTROLYTIC CHIP, 16V 47UF M
CV5376100104 CERAMIC CHIP, 25V F 0.1UF Z
CV5476100104 CERAMIC CHIP, 25V F 0.1UF Z
CV5576100104 CERAMIC CHIP, 25V F 0.1UF Z
CV5676619157 ELECTROLYTIC CHIP, 16V 100UF
CV5776619157 ELECTROLYTIC CHIP, 16V 100UF
CV5876619157 ELECTROLYTIC CHIP, 16V 100UF
LocationParts No. Description
No.
CV5976666471 ELECTROLYTIC, 16V 470UF M
CV6076666471 ELECTROLYTIC, 16V 470UF M
CV6176666471 ELECTROLYTIC, 16V 470UF M
CV6276100104 CERAMIC CHIP, 25V F 0.1UF Z
CV6376666471 ELECTROLYTIC, 16V 470UF M
CV7276619101 ELECTROLYTIC CHIP, 16V 22UF M
CV12176109103 CERAMIC CHIP, 50V B 0.01UF K
CV12276105101 CERAMIC CHIP, 50V CH 100PF J
CY0176100104 CERAMIC CHIP, 25V F 0.1UF Z
CY0276100104 CERAMIC CHIP, 25V F 0.1UF Z
CY0376100104 CERAMIC CHIP, 25V F 0.1UF Z
CY65076109103 CERAMIC CHIP, 50V B 0.01UF K
