Toshiba 32WL68A, 32WL68E, 37WL68A, 37WL68T, 32WL68T User Manual

...

WNER'S

ANUAL

LCD Color TV

32WL68A 32WL68E 32WL68T 37WL68A 37WL68E 37WL68T

Owner's Record

You will find the model number and serial number on the back of the TV. Record these numbers in the spaces provided below. Refer to them whenever you call upon your TOSHIBA dealer regarding this product.

Model number:

Serial number:

Contents

Introduction

Welcome to Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Important information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Getting started

Connecting an antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Exploring your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing the remote control batteries . . . . . . . . . . . . 7

TV top, front and side panel controls . . . . . . . . . . . . . . . . 8

TV back panel connections. . . . . . . . . . . . . . . . . . . . . . . . 9

Learning about the remote control . . . . . . . . . . . . . . . . . 10

Location of controls . . . . . . . . . . . . . . . . . . . . . . . . . 10

Learning about the menu system . . . . . . . . . . . . . . . . . . 10

Displaying the menu chart . . . . . . . . . . . . . . . . . . . . 11

Turning the TV on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Switching on the TV . . . . . . . . . . . . . . . . . . . . . . . . 11

Switching off the TV . . . . . . . . . . . . . . . . . . . . . . . . 11

Watching TV programs . . . . . . . . . . . . . . . . . . . . . . . . . 12

Selecting the menu language . . . . . . . . . . . . . . . . . . 12

Changing the program position . . . . . . . . . . . . . . . . 12

Switching between two program positions . . . . . . . 12

Displaying the on-screen information . . . . . . . . . . . 12

Programming channels into the TV’s channel

memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Programming channels automatically . . . . . . . . . . . 12

Manually setting channels in the channel

memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Sorting program position . . . . . . . . . . . . . . . . . . . . . 13

Using the TV’s features

Picture adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Selecting the picture size . . . . . . . . . . . . . . . . . . . . . 14

Using the picture still . . . . . . . . . . . . . . . . . . . . . . . . 15

Adjusting the picture position . . . . . . . . . . . . . . . . . 15

Resetting the picture position. . . . . . . . . . . . . . . . . . 15

Selecting the picture mode . . . . . . . . . . . . . . . . . . . . 15

Adjusting the basic picture quality. . . . . . . . . . . . . . 15

Activating the black stretch . . . . . . . . . . . . . . . . . . . 16

Activating the MPEG NR (Noise Reduction) . . . . . 16

Activating the DNR (Digital Noise Reduction) . . . . 16

Selecting the color temperature . . . . . . . . . . . . . . . . 16

Adjusting the color management . . . . . . . . . . . . . . . 16

Resetting the base color adjustment . . . . . . . . . . . . . 16

Using the active backlight control . . . . . . . . . . . . . . 16

Using the cinema mode . . . . . . . . . . . . . . . . . . . . . . 17

Using the meta brain PRO 100. . . . . . . . . . . . . . . . . 17

Sound adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the MTS (Multi-channel TV Sound) . . . . . . 17

Selecting the dual 1 or dual 2 mode . . . . . . . . . . . . . 17

Selecting the stereo programs . . . . . . . . . . . . . . . . . 18

Selecting the bilingual programs . . . . . . . . . . . . . . . 18

Adjusting the sound quality . . . . . . . . . . . . . . . . . . . 18

Using the SRS WOW surround sound . . . . . . . . . . . 18

Using the stable sound . . . . . . . . . . . . . . . . . . . . . . . 18

Activating the speaker . . . . . . . . . . . . . . . . . . . . . . . 18

Selecting the woofer internal/external mode . . . . . . 19

Using the bass boost. . . . . . . . . . . . . . . . . . . . . . . . . 19

Using an external woofer system . . . . . . . . . . . . . . . 19

Selecting the audio output . . . . . . . . . . . . . . . . . . . . 19

Other features settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Selecting the timer menu. . . . . . . . . . . . . . . . . . . . . . 19

Using the auto format . . . . . . . . . . . . . . . . . . . . . . . . 20

Activating blue screen. . . . . . . . . . . . . . . . . . . . . . . . 20

Adjusting the brightness of side panel . . . . . . . . . . . 20

Selecting the video input source to view. . . . . . . . . . . . . 20

Setting the manual setting menu . . . . . . . . . . . . . . . . 21

Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Setting up the teletext mode . . . . . . . . . . . . . . . . . . . 21

Adjusting the teletext SW . . . . . . . . . . . . . . . . . . . . . 21

Teletext general information. . . . . . . . . . . . . . . . . . . 22

Using Auto mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Using LIST mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Teletext buttons on the remote control . . . . . . . . . . . 23

Using the double-window . . . . . . . . . . . . . . . . . . . . . . . . 23

Displaying the double-window . . . . . . . . . . . . . . . . . 23

Selecting the headphone mode . . . . . . . . . . . . . . . . . 24

Adjusting the headphone volume (Mode 2) . . . . . . . 24

Using a headphone . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connecting your TV

Side connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Connection example . . . . . . . . . . . . . . . . . . . . . . . . . 25

Back connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Connection example . . . . . . . . . . . . . . . . . . . . . . . . . 25

Connecting an HDMI and a DVI device . . . . . . . . . . . . . 26

Connecting an HDMI and a DVI device. . . . . . . . . . 26

Connecting an HDMI device . . . . . . . . . . . . . . . . . . 26

Connecting a DVI device . . . . . . . . . . . . . . . . . . . . . 26

Selecting the PC/HDMI audio mode. . . . . . . . . . . . . . . . 27

Setting the HDMI1 audio mode . . . . . . . . . . . . . . . . . . . 27

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the PC setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Adjusting the picture size/position . . . . . . . . . . . . . . 28

Adjusting the clock phase of the picture . . . . . . . . . . 28

Adjusting the sampling clock . . . . . . . . . . . . . . . . . . 28

Resetting the PC setting . . . . . . . . . . . . . . . . . . . . . . 28

Reference section

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Symptom and solution . . . . . . . . . . . . . . . . . . . . . . . 29

Broadcast system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Broadcast transmission systems of each country or

region . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

LCD color television. . . . . . . . . . . . . . . . . . . . . . . . . 30

Introduction

Welcome to Toshiba

• Thank you for purchasing this Toshiba LCD Color Television. This manual will help you use the exciting features of your new TV.

• Instructions in this manual are based on using the remote control.

• You also can use the controls on the TV if they have the same name as those referred to on the remote control.

• Please read all safety and operating instructions in this manual carefully, and keep this manual for future reference.

Important Safety Instructions

Be sure to observe the following instructions and precautions to ensure safe use of this TV.

Installation

1) Always connect the power plug to an appropriate

electrical outlet equipped with A model: 220-240V, AC 50Hz, E model: 220-240V, AC 50/60Hz and T model: 110-240V, AC 50/60Hz.

Never use the TV outside the specified voltage range. It may cause a fire or an electric shock.

WARNING ABOUT THREE-WIRE GROUNDINGTYPE PLUG:

• This product shall be connected to a main socket outlet with a protective earthing connection.

• Never remove the earthing pin on the power plug. This system is equipped with a three pin earthingtype power plug. This plug will only fit an earthingtype power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact an electrician to replace the wall outlet.

• Never defeat the purpose of the earthing plug.

Ex. 220-240V AC, 50/60Hz

3) Never place the TV in an unstabilized location such as on a shaky table, incline or location subject to vibration.

The TV may drop or fall off which may cause an injury or damage.

4) Never block or cover the slots and openings in the cabinet.

• Never place the TV so that it is facing upward or on

its side.

• Never place the TV in a closet, bookcase or other

similar area where the ventilation is poor.

• Never drape a newspaper, tablecloth or curtain on the

TV.

• When installing the TV against a wall, always keep

the TV at least 10 cm away from the wall.

• Never place the TV on a soft unstable surface, such

as a carpet, or a cushion. The inside of this TV will overheat if the ventilation holes are covered, blocked or sealed, which may result in a fire.

5) Never place the TV near a heater or in direct sunlight.

The surface of the cabinet or power cord may melt and result in a fire or an electric shock.

Check!

About the fuse

In a three pin earthing-type, the fuse fitted in this plug is approved by ASTA or BSI to BS1362. It should only be replaced by a correctly rated and approved type and the fuse cover must be refitted.

2) Never insert or remove the power plug with wet hands.

This may cause an electric shock.

6) Never place the TV in an area exposed to high humidity levels, such as in a bathroom or close to a humidifier.

This may cause a fire or an electric shock.

Introduction

7) Never place the TV next to a stove where it will be exposed to oil, smoke, or steam, or in a location where there is a large quantity of dust.

This may cause a fire or an electric shock.

8) Install the TV in a horizontal, stable location. Connect between two clips on the back of the TV and a wall, pillar, etc., with a sturdy tie and clip of supplied accessories (- page 30).

• Use as short a tie as possible to ensure the TV is

stable.

• If the TV is not installed securely, it may lean or fall

over and cause an injury.

• To prevent injury, use the exclusive optional stand or

wall-hanging bracket to install this TV on the floor or wall securely in accordance with a qualified technician.

Sturdy tie (as short as possible)

10) Precautions for installing on outdoor antenna

An outside antenna system should not be located in the vicinity of overhead power lines, or other electric light or power circuits. If the antenna falls down or drops, it may cause an injury or an electric shock.

Use

1) Never place hot objects or open flame sources, such as lighted candles or nightlights, on or close to the TV.

High temperatures can melt plastic and lead to fires.

Clip

Side view op view

9) Precautions for moving the TV

• When moving the TV, be sure to remove the plug from the wall outlet and disconnect the antenna cable and audio/video cables, any steady ties. A fire or an electric shock may result if the power cord is damaged.

• When carrying the TV, at least two people are needed. Be sure to carry it upright.

• Never carry the TV with the screen facing up or down.

Clip

2) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

When liquids are spilled or small items are dropped inside the TV, this may cause a fire or an electric shock. If small objects drop inside the TV, turn off the TV and remove the power plug from the outlet immediately and contact a service technician.

3) Never insert objects (metal or paper) or pour water inside the TV through ventilation holes and other openings.

These items may cause a fire or an electric shock. If these objects are inserted inside the TV, turn off the TV and remove the power plug from the outlet immediately and contact a service technician. Be especially careful that children do not insert objects in the TV.

Clip

Introduction

4) Never stand or climb on the TV.

Be especially careful in households with children to prevent them through climbing on top of the TV. It may move, fall over, break, become damaged or cause an injury.

5) When the TV will not be used for a long period of time, such as during vacation or travel, remove the power plug from the wall outlet for safety.

• The TV is not completely disconnected from the

power supply line, as minute current is consumed even when the ! Power switch is turned off.

• The Mains plug or an appliance coupler is used as the

disconnect device, therefore the disconnect device shall remain readily operable.

6) Never pull on the power cord when removing the plug from the wall outlet.

Always hold the plug firmly when removing it. If the power cord is yanked, the cord may become damaged and a fire or an electric shock may occur.

8) If there is thunder or lightning, never touch the antenna cable or other connected cables.

You may suffer an electric shock.

Service

1) Never repair, modify or disassemble the TV by yourself.

It may cause a fire or an electric shock. Consult a service technician for inspection and repairs.

2) When a malfunction occurs, or if smoke or an unusual odor comes from the TV, turn off the TV and remove the power plug from the outlet immediately.

Make sure that the smoke or smell has stopped, then contact a service technician. If the TV is still used in this condition, it may cause a fire or an electric shock.

7) Never cut, break, modify, twist, bunch up or bent the cord or apply excessive force or tension to it.

Never place heavy objects on the cord or allow it to overheat as this may cause damage, a fire or an electric shock. Contact a service technician if the power cord is damaged.

3) If the TV is dropped or the cabinet is broken, turn off the TV and remove the power plug from the outlet immediately.

If the TV is still power used in this condition, it may cause a fire or an electric shock. If the cabinet is broken, be careful when handling the TV to prevent an injury. Contact a service technician for inspection and repair.

Introduction

4) When the TV reaches the end of its useful life, ask a qualified service technician to properly dispose of the TV.

Note: The lamp unit contains a small amount of mercury. Disposal of mercury may be regulated due to environmental considerations. Dispose of the used lamp unit by the approved method for your area. For disposal or recycling information, please contact your local authorities.

Cleaning

1) Remove the power plug before cleaning.

Never use solvents such as benzine or thinner to clean the TV.

• These solvents may distort the cabinet or damage its

finish.

• If rubber or vinyl products remain in contact with the

TV for a long time, a stain may result. If the cabinet becomes dirty, clean it with a soft, dry cloth. When cleaning the surface of the LCD display, wipe the panel surface gently with a soft, dry cloth.

Important information

1) About LCD screen

• If you have the LCD screen facing to the sun, the LCD screen will be damaged. Be aware of locating the TV in the place such as window side or outside of the room.

• Never press the LCD screen strongly or scratch it, and never put anything on it. These actions will damage the LCD screen.

2) About cabinet

Never spray volatile compounds such as insecticide on the cabinet. This may cause a discoloration or damage the cabinet.

3) Some pixels of the screen do not light up

The LCD display panel is manufactured using an extremely high level of precision technology, however sometimes some pixels of the screen may be missing picture elements or have luminous spots. This is not a sign of a malfunction.

4) About Interference

The LCD display may cause interference in image, sound, etc. of other electronic equipment that receives electromagnetic waves (e.g. AM radios and video equipment).

5) About using under the low temperature places

If you use the TV in the room of 0°C or less, the picture brightness may vary until the LCD monitor warms up. This is not a sign of a malfunction.

2) Periodically disconnect the power plug from the outlet and check it. If dust has collected on the power plug connectors, clean off the dust with a dry cloth.

This dust may cause a fire due to reduced insulation on the plug.

Clean here

6) About afterimage

If a still picture is displayed, an afterimage may remain on the screen, however it will disappear. This is not a sign of malfunction.

Exemptions

• Toshiba is not liable for any damage caused by fires, natural disaster (such as thunder, earthquake, etc.), acts by third parties, accidents, owner’s misuse, or uses in other improper conditions.

• Toshiba is not liable for incidental damages (such as profit loss or interruption in business, modification or erasure of record data, etc.) caused by use or inability to use of product.

• Toshiba is not liable for any damage caused by neglect of the instructions described in the owner’s manual.

• Toshiba is not liable for any damage caused by misuse or malfunction through simultaneous use of this product and the connected equipment.

Getting started

Connecting an antenna

Optimum reception of color requires a good signal and will generally mean that an outdoor antenna must be used.

The exact type and positioning of the antenna will depend upon your particular area.

Your Toshiba dealer or service personnel can best advise you on which antenna to use in your area.

Before connecting the antenna cable, turn off all main power switches.

VHF and/or UHF antenna

Media Recorder

OUT

Antenna cable (75 7 coaxial) (not supplied)

300 7 twin-lead feeder

TV back view

Exploring your new TV

Installing the remote control batteries

Remove the battery cover.

Insert two R03 (AAA) batteries matching the –/+ polarities of the battery to the –/+ marks inside the battery compartment.

Cautions:

• Dispose of batteries in a designated disposal area. Never throw batteries into a fire.

• Attention should be drawn to the environmental aspects of battery disposal.

• Never mix battery types or combine used batteries with new ones.

Notes:

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace both batteries with new ones.

• If the batteries are dead or if you will not use the remote control for a long time, remove the batteries to prevent battery acid from leaking into the battery compartment.

Antenna adaptor (not supplied)

75 7 coaxial cable

Plug (not supplied)

75 7 antenna terminal

Effective range

within 5 m

Getting started

TV top, front and side panel controls

• You can operate your TV using the buttons on the side panel or the remote control. The back and side of the panel provide the

terminal connections to connect other equipment to your TV (- “Connecting your TV” pages 25, 26, 27).

• For the use of each control, see the pages in brackets.

TV top view

TV front view

You can swivel the TV screen. Swivel angle:

15 degrees to left and right.

Right side view

Control panel

Headphones (Not supplied)

1 ! (Power switch) — Press to turn the TV on and off

(- page 11).

2 4 (Timer LED) — Timer indicator (- page 19). 3 ! (Power LED) — Power indicator (- page 11). 4 (Remote sensor) — Point the remote control toward

this remote sensor (- page 7).

5 1 (Power on/Standby) — Press to turn the TV on/

standby (- page 11).

6 pBb (Program position) — When no menu is on-

screen, these buttons select the program position. (- page 12).

Uu (MENU up/down) — When a menu is on-screen, these buttons function as up/down menu navigation buttons (- page 10).

7 2 – + (Volume) — When no menu is on-screen, these

buttons adjust the volume level (- page 10). I i (MENU left/right) — When a menu is on-screen,

these buttons function as left/right menu navigation buttons or adjust settings (- page 10).

8 MENU — Press to access the menu system (- page 10). 9 o (Input source selection) — When no menu is on-

screen, this button selects the input source (- page 20). OK — When a menu is on-screen, this button functions

as the next menu navigation button (- page 10, 20).

10 o (2) (Video 2 input terminals) — Optional S-video

or standard video and standard audio inputs (- page 25).

11 D (Headphone jack) — For use with headphones.

TV back panel connections

Getting started

16 17

TV back view

You can use the cable holder to hold antenna cable, video and audio cables etc.

When moving the TV, never hold this holder.

Power cord

Cable holder*

19 20 21 22

12 o (C1) (COMPONENT VIDEO INPUT terminals)

—High-definition component video and standard audio inputs (- page 25).

13 o (1) (Video 1 input terminals) — Optional S-video

or standard (composite) video and standard (analog) stereo audio inputs (- page 25).

14 o (C2) (COMPONENT VIDEO INPUT terminals)

— High-definition component video and standard audio inputs (- page 25).

15 O MONITOR (output terminals) — Standard video

and standard audio outputs (- page 25).

16 O WOOFER (output terminal) — For use when

connecting woofer system (variable) (- page 25).

17 O AUDIO (output terminals) — Standard audio

outputs (fixed/variable) (- page 25).

18 o PC/HDMI1 (AUDIO) (input terminals) — For use

when connecting a personal computer (PC) or a DVI device with standard audio output (- page 26, 27).

19 A (Antenna input terminal) — Analog antenna signal

input (- page 7).

20 o RGB/PC (input terminal) — For use when

connecting a personal computer (PC) (- page 27).

21 o HDMI1 (input terminal) — High-Definition

Multimedia Interface input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device (- page

26).

22 o HDMI2 (input terminal) — High-Definition

Multimedia Interface input receives digital audio and uncompressed digital video from an HDMI device (- page 26).

Getting started

Learning about the remote control

Location of controls

• CALL (- pages 12, 13)

• Initial/index function for Teletext (- page 23)

Number buttons (0-9) (- pages 12, 19)

To return to the previous program (- page 12)

Picture size selection (- page 14)

• MENU

• DVD Menu

OK (- page 20)

• Menu left/right (- page 11)

• Volume – + (These buttons adjust the volume level.)

Double-window picture/sound selection (- page 23)

Double-window on/off (- page 23)

Mode switch

o control TV

TV : T STB : To control Set Top Box DVD : To control DVD

Stereo/bilingual selection (- page 18)

When in STB or DVD mode: (Only for Toshiba DVD players)

V W / w c CC cc X v Z z

: to OPEN/CLOSE : to STILL/STEP : to PLAY : to REWIND : to FAST FORWARD : to SLOW : to STOP : to SKIP-REWIND : to SKIP-FORWARD

Power on/Standby (- page 11)

• Input source selection (o1, o2, oC1, oC2, HDMI1, HDMI2, PC) (- page 20)

• To access sub-pages when in teletext (- page 22)

Picture mode selection (- page 15) EXIT (- page 11)

• Menu down/up (- page 11)

• Program position Bb (- page 12)

• Teletext Bb (- page 22)

Picture still (- page 15)

• Bass boost on/off (- page 19)

• External woofer on/off (- page 19)

Sound mute (This button turns off/on the sound.)

When in Teletext mode:

E : •

•

mode and a normal broadcast picture mode) (- pages 22, 23)

A : B : C : To enlarge teletext display size

(- page 23) D : To select a page while viewing

a normal picture (- page 23)

When in TV mode:

D : To select the time display (- page 23)

Teletext control buttons (Four colored buttons: Red, Green, Yellow, Blue) (-

Teletext on/off

Text media mode (The teletext

To reveal concealed text (- page 23) To hold a wanted page (- page 23)

page 22)

Learning about the menu system

We suggest you familiarize yourself with the display charts before using the menu system:

•Press M to display menu, then press Y or y to select main menu headings.

•Press < or > to select an item.

•Press Y or y to select or adjust setting.

•Press Q to display the next menu.

+ 22 hidden pages
