Toshiba 32WL66A, 32WL66E, 32WL66T User Manual

Download

Asia_32WL66AET.book Page 1 Tuesday, April 11, 2006 4:41 PM

WNER'S

ANUAL

LCD Color TV

32WL66A 32WL66E 32WL66T

Owner's Record

You will find the model number and serial number on the back of the TV. Record these numbers in the spaces provided below. Refer to them whenever you call upon your TOSHIBA dealer regarding this product.

Model number:

Serial number:

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 2 Tuesday, April 11, 2006 4:41 PM

Contents

Introduction

Welcome to Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Important information. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Getting started

Connecting an antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Exploring your new TV . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Installing the remote control batteries . . . . . . . . . . . . 7

TV top and front panel controls . . . . . . . . . . . . . . . . . . . . 8

TV side and back panel connections . . . . . . . . . . . . . . . . 9

Learning about the remote control . . . . . . . . . . . . . . . . . 10

Location of controls . . . . . . . . . . . . . . . . . . . . . . . . . 10

Learning about the menu system . . . . . . . . . . . . . . . . . . 11

Displaying the menu chart . . . . . . . . . . . . . . . . . . . . 11

Turning the TV on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Switching on the TV . . . . . . . . . . . . . . . . . . . . . . . . 12

Switching off the TV . . . . . . . . . . . . . . . . . . . . . . . . 12

Watching TV programs . . . . . . . . . . . . . . . . . . . . . . . . . 12

Selecting the menu language . . . . . . . . . . . . . . . . . . 12

Changing the program position . . . . . . . . . . . . . . . . 12

Switching between two program positions . . . . . . . 12

Displaying the on-screen information . . . . . . . . . . . 12

Programming channels into the TV’s channel

memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Programming channels automatically . . . . . . . . . . . 13

Manually setting channels in the channel

memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Setting the program sorting . . . . . . . . . . . . . . . . . . . 14

Using the TV’s features

Picture adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Selecting the picture size . . . . . . . . . . . . . . . . . . . . . 15

Using the picture still . . . . . . . . . . . . . . . . . . . . . . . . 16

Adjusting the picture position . . . . . . . . . . . . . . . . . 16

Resetting the picture position. . . . . . . . . . . . . . . . . . 16

Selecting the picture mode . . . . . . . . . . . . . . . . . . . . 16

Adjusting the basic picture quality . . . . . . . . . . . . . . 16

Activating the black stretch . . . . . . . . . . . . . . . . . . . 17

Activating the MPEG NR (Noise Reduction) . . . . . 17

Activating the DNR (Digital Noise Reduction) . . . . 17

Selecting the color temperature . . . . . . . . . . . . . . . . 17

Adjusting the color management . . . . . . . . . . . . . . . 17

Resetting the base color adjustment . . . . . . . . . . . . . 17

Using the cinema mode . . . . . . . . . . . . . . . . . . . . . . 18

Using the auto format . . . . . . . . . . . . . . . . . . . . . . . . 18

Sound adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Setting the MTS (Multi-channel TV Sound) . . . . . . 18

Selecting the dual 1 or dual 2 mode . . . . . . . . . . . . . 18

Selecting the stereo programs . . . . . . . . . . . . . . . . . 19

Selecting the bilingual programs . . . . . . . . . . . . . . . 19

Adjusting the sound quality . . . . . . . . . . . . . . . . . . . 19

Using the SRS WOW surround sound . . . . . . . . . . . 19

Using the stable sound . . . . . . . . . . . . . . . . . . . . . . . 20

Using the bass boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Activating blue screen . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Other features settings . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting the timer menu . . . . . . . . . . . . . . . . . . . . . 20

Adjusting the brightness of side panel . . . . . . . . . . . 20

Selecting the video input source to view. . . . . . . . . . . . . 21

Setting the manual setting menu . . . . . . . . . . . . . . . . 21

Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Setting up the teletext mode . . . . . . . . . . . . . . . . . . . 22

Teletext general information . . . . . . . . . . . . . . . . . . . 22

Using Auto mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Using LIST mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Teletext buttons on the remote control . . . . . . . . . . . 23

Connecting your TV

Side connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connection example . . . . . . . . . . . . . . . . . . . . . . . . . 24

Back connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connection example . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connecting an HDMI or a DVI device . . . . . . . . . . . . . . 25

Connecting an HDMI or a DVI device . . . . . . . . . . . 25

Connecting an HDMI device . . . . . . . . . . . . . . . . . . 25

Connecting a DVI device . . . . . . . . . . . . . . . . . . . . . 25

Selecting the PC/HDMI audio mode. . . . . . . . . . . . . . . . 26

Setting the HDMI audio mode . . . . . . . . . . . . . . . . . . . . 26

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Using the PC setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Adjusting the picture size/position . . . . . . . . . . . . . . 27

Adjusting the clock phase of the picture . . . . . . . . . . 27

Adjusting the sampling clock . . . . . . . . . . . . . . . . . . 27

Resetting the PC setting . . . . . . . . . . . . . . . . . . . . . . 27

Reference section

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Symptom and solution . . . . . . . . . . . . . . . . . . . . . . . 28

Broadcast system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Broadcast transmission systems of each country or region

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

LCD color television . . . . . . . . . . . . . . . . . . . . . . . . . 29

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 3 Tuesday, April 11, 2006 4:41 PM

Introduction

Welcome to Toshiba

• Thank you for purchasing this Toshiba LCD Color Television. This manual will help you use the exciting features of your new TV.

• Instructions in this manual are based on using the remote control.

• You also can use the controls on the TV if they have the same name as those referred to on the remote control.

• Please read all safety and operating instructions in this manual carefully, and keep this manual for future reference.

Important Safety Instructions

Be sure to observe the following instructions and precautions to ensure safe use of this TV.

Installation

1) Always connect the power plug to an electrical

outlet equipped with A model: 220-240V, AC 50Hz, E model: 220-240V, AC 50/60Hz and T model: 110240V, AC 50/60Hz.

Never use the TV outside the specified voltage range. It may cause a fire or an electric shock.

WARNING ABOUT THREE-WIRE GROUNDINGTYPE PLUG:

• This product shall be connected to a main socket outlet with a protective earthing connection.

• Never remove the earthing pin on the power plug. This system is equipped with a three pin earthingtype power plug. This plug will only fit an earthingtype power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact an electrician to replace the wall outlet.

• Never defeat the purpose of the earthing plug.

Ex. 220-240V AC, 50/60Hz

3) Never place the TV in an unstabilized location such as on a shaky table, incline or location subject to vibration.

The TV may drop or fall down which may cause injury or damage.

4) Never block or cover the slots and openings in the cabinet.

• Never place the TV so that it is facing upward or on

its side.

• Never place the TV in a closet, bookcase or other

similar area where the ventilation is poor.

• Never drape a newspaper, tablecloth or curtain on the

TV.

• When installing the TV against a wall, always keep

the TV at least 10 cm away from the wall.

• Never place the TV on a soft unstable surface, such

as a carpet, or a cushion. The inside of this TV will overheat if the ventilation holes are covered, blocked or sealed, which may result in a fire.

5) Never place the TV near a heater or in direct sunlight.

The surface of the cabinet or power cord may melt and result in fire or electric shock.

Check!

About the fuse

In a three pin earthing-type, the fuse fitted in this plug is approved by ASTA or BSI to BS1362. It should only be replaced by a correctly rated and approved type and the fuse cover must be refitted.

2) Never insert or remove the power plug with wet hands.

This may cause electric shock.

6) Never place the TV in an area exposed to high humidity levels, such as in a bathroom or close to a humidifier.

This may cause a fire or an electric shock.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 4 Tuesday, April 11, 2006 4:41 PM

Introduction

7) Never place the TV next to a stove where it will be exposed to oil, smoke, or steam, or in a location where there is a large quantity of dust.

This may cause a fire or electric shock.

8) Install the TV in a horizontal, stable location. Connect between two clips on the back of the TV and a wall, pillar, etc., with a sturdy tie and clip of supplied accessories (- page 29).

• Use as short a tie as possible to ensure the TV is

stable.

• If the TV is not installed securely, it may lean or fall

over and cause an injury.

• To prevent injury, use the exclusive optional stand or

wall-hanging bracket to install this TV on the floor or wall securely in accordance with a qualified technician.

Sturdy tie (as short as possible)

10) Precautions for installing on outdoor antenna

An outside antenna system should not be located in the vicinity of overhead power lines, or other electric light or power circuits. If the antenna falls down or drops, it may cause injury or electric shock.

Use

1) Never place hot objects or open flame sources, such as lighted candles or nightlights, on or close to the TV.

High temperatures can melt plastic and lead to fires.

Clip

Side view op view

9) Precautions for moving the TV

• When moving the TV, be sure to remove the plug from the wall outlet and disconnect the antenna cable and audio/video cables, any steady ties. Fire or electric shock may result if the power cord is damaged.

• When carrying the TV, at least two people are needed. Be sure to carry it upright.

• Never carry the TV with the screen facing up or down.

Clip

2) The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

When liquids are spilled or small items are dropped inside the TV, this may cause a fire or an electric shock. If small objects drop inside the TV, turn off the TV and remove the power plug from the outlet immediately and contact a service technician.

3) Never insert objects (metal or paper) or pour water inside the TV through ventilation holes and other openings.

These items may cause a fire or an electric shock. If these objects are inserted inside the TV, turn off the TV and remove the power plug from the outlet immediately and contact a service technician. Be especially careful that children do not insert objects in the TV.

Clip

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 5 Tuesday, April 11, 2006 4:41 PM

Introduction

4) Never stand or climb on the TV.

Be especially careful in households with children to prevent them through climbing on top of the TV. It may move, fall over, break, become damaged or cause an injury.

5) When the TV will not be used for a long period of time, such as during vacation or travel, remove the power plug from the wall outlet for safety.

• The TV is not completely disconnected from the

power supply line, as minute current is consumed even when the ! Power switch is turned off.

• The Mains plug or an appliance coupler is used as the

disconnect device, therefore the disconnect device shall remain readily operable.

6) Never pull on the power cord when removing the plug from the wall outlet.

Always hold the plug firmly when removing it. If the power cord is yanked, the cord may become damaged and fire or electric shock may occur.

8) If there is thunder or lightning, never touch the antenna cable or other connected cables.

You may suffer an electric shock.

Service

1) Never repair, modify or disassemble the TV by yourself.

It may cause a fire or an electric shock. Consult a service technician for inspection and repairs.

2) When a malfunction occurs, or if smoke or an unusual odor comes from the TV, turn off the TV and remove the power plug from the outlet immediately.

Make sure that the smoke or smell has stopped, then contact a service technician. If the TV is still used in this condition, it may cause a fire or an electric shock.

7) Never cut, break, modify, twist, bunch up or bent the cord or apply excessive force or tension to it.

Never place heavy objects on the cord or allow it to overheat as this may cause damage, fire or electric shock. Contact a service technician if the power cord is damaged.

3) If the TV is dropped or the cabinet is broken, turn off the TV and remove the power plug from the outlet immediately.

If the TV is still power used in this condition, it may cause a fire or an electric shock. If the cabinet is broken, be careful when handling the TV to prevent an injury. Contact a service technician for inspection and repair.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 6 Tuesday, April 11, 2006 4:41 PM

Introduction

4) When the TV reaches the end of its useful life, ask a qualified service technician to properly dispose of the TV.

Note: The lamp unit contains a small amount of mercury. Disposal of mercury may be regulated due to environmental considerations. Dispose of the used lamp unit by the approved method for your area. For disposal or recycling information, please contact your local authorities.

Cleaning

1) Remove the power plug before cleaning.

Never use solvents such as benzine or thinner to clean the TV.

• These solvents may distort the cabinet or damage its

finish.

• If rubber or vinyl products remain in contact with the

TV for a long time, a stain may result. If the cabinet becomes dirty, clean it with a soft, dry cloth. When cleaning the surface of the LCD display, wipe the panel surface gently with a soft, dry cloth.

Important information

1) About LCD screen

• If you have the LCD screen facing to the sun, the LCD screen will be damaged. Be aware of locating the TV in the place such as window side or outside of the room.

• Never press the LCD screen strongly or scratch it, and never put anything on it. These actions will damage the LCD screen.

2) About cabinet

Never spray volatile compounds such as insecticide on the cabinet. This may cause a discoloration or damage the cabinet.

3) Some pixels of the screen do not light up

The LCD display panel is manufactured using an extremely high level of precision technology, however sometimes some pixels of the screen may be missing picture elements or have luminous spots. This is not a sign of a malfunction.

4) About Interference

The LCD display may cause interference in image, sound, etc. of other electronic equipment that receives electromagnetic waves (e.g. AM radios and video equipment).

5) About using under the low temperature places

If you use the TV in the room of 0°C or less, the picture brightness may vary until the LCD monitor warms up. This is not a sign of a malfunction.

2) Periodically disconnect the power plug from the outlet and check it. If dust has collected on the power plug connectors, clean off the dust.

This dust may cause a fire due to reduced insulation on the plug.

Clean here

6) About afterimage

If a still picture is displayed, an afterimage may remain on the screen, however it will disappear. This is not a sign of malfunction.

Exemptions

• Toshiba is not liable for any damage caused by fires, natural disaster (such as thunder, earthquake, etc.), acts by third parties, accidents, owner's misuse, or uses in other improper conditions.

• Toshiba is not liable for incidental damages (such as profit loss or interruption in business, modification or erasure of record data, etc.) caused by use or inability to use of product.

• Toshiba is not liable for any damage caused by neglect of the instructions described in the owner's manual.

• Toshiba is not liable for any damage caused by misuse or malfunction through simultaneous use of this product and the connected equipment.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 7 Tuesday, April 11, 2006 4:41 PM

Getting started

Connecting an antenna

Optimum reception of color requires a good signal and will generally mean that an outdoor antenna must be used.

The exact type and positioning of the antenna will depend upon your particular area.

Your Toshiba dealer or service personnel can best advise you on which antenna to use in your area.

Before connecting the antenna cable, turn off all main power switches.

VHF and/or UHF antenna

Media Recorder

OUT

Antenna cable (75 7 coaxial) (not supplied)

300 7 twin-lead feeder

TV back view

Exploring your new TV

Installing the remote control batteries

Remove the battery cover.

Insert two R03 (AAA) batteries matching the –/+ polarities of the battery to the –/+ marks inside the battery compartment.

Cautions:

• Dispose of batteries in a designated disposal area. Never throw batteries into a fire.

• Attention should be drawn to the environmental aspects of battery disposal.

• Never mix battery types or combine used batteries with new ones.

Notes:

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace both batteries with new ones.

• If the batteries are dead or if you will not use the remote control for a long time, remove the batteries to prevent battery acid from leaking into the battery compartment.

Antenna adaptor (not supplied)

75 7 coaxial cable

Plug (not supplied)

75 7 antenna terminal

Effective range

within 5 m

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 8 Tuesday, April 11, 2006 4:41 PM

Getting started

TV top and front panel controls

• You can operate your TV using the buttons on the front panel or the remote control. The back and side of the panel provide the

terminal connections to connect other equipment to your TV (- “Connecting your TV” pages 24, 25, 26).

• For the use of each control, see the pages in brackets.

TV top view

You can swivel the TV screen. Swivel angle: 15 degrees to

left and right.

234

TV front view

987

1 o (Input source selection) — When no menu is on-

screen, this button selects the input source (- page 21). OK — When a menu is on-screen, this button functions

as the next menu navigation button (- page 11, 21).

2 MENU — Press to access the menu system (- page 11). 3 2 – + (Volume) — When no menu is on-screen, these

buttons adjust the volume level (- page 10). I i (MENU left/right) — When a menu is on-screen,

these buttons function as left/right menu navigation buttons or adjust settings (- page 11).

4 pBb (Program position) — When no menu is on-

screen, these buttons select the program position. (- page 13).

Uu (MENU up/down) — When a menu is on-screen, these buttons function as up/down menu navigation buttons (- page 11).

5 1 (Power on/Standby) — Press to turn the TV on/

standby (-page 12).

6 ! (Power switch) — Press to turn the TV on and off

(- page 12).

7 (Remote sensor) — Point the remote control toward

this remote sensor (- page 7).

8 / (Power LED) — Power indicator (- page 12). 9 4 (Green LED) — Timer indicator (- page 20).

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 9 Tuesday, April 11, 2006 4:41 PM

TV side and back panel connections

Getting started

Right side view

TV back view

Cable holder*

Power cord

Headphones (Not supplied)

You can use the cable holder to hold antenna cable, video and audio cables etc.

When moving the TV, never hold this holder.

10 O MONITOR (output terminals) — Standard video

and standard audio outputs (- page 24).

11 o (3) (Video 3 input terminals) — High-definition

component video and standard audio inputs (- page 24).

12 o PC/HDMI (AUDIO) (input terminals) — For use

when connecting a personal computer (PC) or a DVI device with standard audio output (- page 25, 26).

13 o (1) (Video 1 input terminals) — High-definition

component video or standard (composite) video and standard (analog) stereo audio inputs (- page 24).

14 o (2) (Video 2 input terminals) — Optional S-video

or standard video and standard audio inputs (- page 24).

15 D (Headphone jack) — For use with headphones.

Note:

When the Headphone jack is being used, the sound from all speakers will be muted, and normal sound will be output to the headphones only.

16 A (Antenna input terminal) — Analog antenna signal

input (- page 7).

17 o RGB/PC (input terminal) — For use when

connecting a personal computer (PC) (- page 26).

18 o HDMI (input terminal) — High-Definition

Multimedia Interface input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device (- page

25).

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 10 Tuesday, April 11, 2006 4:41 PM

Learning about the remote control

Location of controls

Teletext on/off (- pages 22, 23)

Getting started

• CALL (- pages 12, 14)

• Initial/index function for Teletext (- page 23)

To return to the previous program (- page 12)

Picture mode selection (- page 16)

MENU (- page 11)

• Menu

• Volume – +

I i (- page 11)

(These buttons adjust the volume level.)

OK (- pages 11, 21)

Power on/Standby

(- page 12)

Number buttons (0-9)

(- pages 12, 20)

• Input source selection

(O1 - O3, HDMI, PC)

(- page 21)

• To access sub-pages when in teletext

Picture size selection

(- page 15)

EXIT (- page 11)

• Menu U u (- page 11)

• Program position

(- page 12)

• Teletext Bb (- page 22)

Teletext control buttons

(Four colored buttons: Red, Green, Yellow, Blue) (- pages 22, 23)

(- page 22)

Stereo/bilingual selection (- page 19)

Picture still (- page 16)

To reveal concealed text when in teletext

To hold a wanted page when in teletext

(- page 23)

Bass boost on/off (- page 20)

Sound mute (This button turns off/on the sound.)

• To select a page while viewing a normal picture when in teletext

(- page 23)

• To select the time display

(- page 23)

To enlarge teletext display size

(- page 23)

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 11 Tuesday, April 11, 2006 4:41 PM

Learning about the menu system

We suggest you familiarize yourself with the display charts before using the menu system:

•Press M to display menu, then press I or i to select main

menu headings.

•Press u or U to select an item.

•Press I or i to select or adjust setting.

•Press Q to display the next menu.

Displaying the menu chart

PICTURE menu

Picture settings 3D Color management

Base color adjustment

Cinema mode


EXIT

Back Watch TV

Off

Picture settings

3D Color management

Base color adjustment

Cinema mode


EXIT

Back Watch TV

Getting started

Off

Notes:

• In the video input mode (o1 - o3), Auto tuning and

Manual tuning are not available. Instead, Manual setting appears in the SET UP menu (

- page 21).

• If you connect external equipment via component video source to external input, Color system selection in the Manual setting menu is not available.

• If you do not make a selection for a while, the menu display disappears automatically.

• If you want to close the menu display instantly, press P.

• To return to the previous menu, press M.

• The u / U function as the Program position >/ < when there

is no menu display on the screen.

• The I / i function as the Volume 2+/2– when there is no menu display on the screen.

• In the PC input mode, PC Setting appears in the SET UP

- page 27).

menu (

• In the 480i or 576i input signals mode, you can select the Cinema mode in the PICTURE menu (

• When you use the color management function (

- page 18).

- page 17),

you can select the Base color adjustment in the PICTURE menu.

SOUND menu

MTS Dual Bass Tre bl e Balance WOW

EXIT

Back Watch TV

SET UP menu

Language Auto tuning Manual tuning AV connection Picture position

EXIT

Back Watch TV

TIMER menu

Sleep timer On timer On timer Position

Stable sound

SOUND 1/ 2

SET UP

TIMER

Auto

Dual 1

0 0 0

English

OK OK OK OK

00:00 00:00

MTS

Dual Bass Tre bl e Balance WOW

Language

Auto tuning Manual tuning AV connection Picture position

Sleep timer

On timer On timer Position

SOUND 2/ 2

SOUND 1/ 2

EXIT

Back Watch TV

SET UP

EXIT

Back Watch TV

TIMER

Off

Auto

Dual 1

0 0 0

English

OK OK OK OK

00:00

EXIT

Back Watch TV

FUNCTION menu

Teletext Auto format Blue screen Side panel

FUNCTION

EXIT

Back Watch TV

Auto

On On

Teletext

Auto format Blue screen Side panel

EXIT

Back Watch TV

FUNCTION

EXIT

Back Watch TV

Auto

On On

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 12 Tuesday, April 11, 2006 4:41 PM

Turning the TV on

Getting started

3 Press I or i to select the desired language.

Switching on the TV

Connect the power cord to a wall outlet.

1 Press ! on the TV left side until it clicks.

The / Power indicator lights in red. Press remote control or 1 on the TV front panel if no picture appears.

Note:

If you watch black and white programs when the color system mode is set to Auto, color noise may appear on the screen. In this case select the appropriate Color system (For the system of each country or region, refer to pages 13 and 28).

Mono

J on the

Switching off the TV

Press J on the remote control or 1 on the TV front panel to switch to the standby mode.

2 To switch the TV off, press ! on the TV left side.

Power indicator will be turned off.

Notes:

• This TV is not fully disconnected from the main supply, as

minute current is consumed even when ! is turned off. When the TV will not be used for a long period of time, such as during vacation or travel, remove the power plug from the wall outlet.

• The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day. This function does not work in external input or Blue screen Off mode. The TV will automatically turn itself off after approximately 2 hours if you do not operate the TV after turned on by on timer function.

• If power is cut off while you are viewing the TV, the Last Mode Memory function turns on the TV automatically when power is applied again. If power is going to be off for a long time and you are going to be away from your TV, unplug the power cord to prevent the TV from turning on in your absence.

Language

Auto tuning Manual tuning AV connection Picture position

Back Watch TV

SET UP

EXIT

English

OK OK OK OK

Changing the program position

Enter the desired program position number using the Number buttons on the remote control. For program positions below 10, use 0 and the required number e.g., for program position 1.

2 You can also change the program position by using > or

<. The program position will be displayed on the screen with the Mono/Stereo/Dual audio status.

Note:

The program position selection change between different format channels takes several seconds.

Switching between two program positions

You can switch two program positions without entering actual position number each time.

1 Select the first program position you want to view. 2 Select the second program position with the Number

buttons (0-9).

3 Press :. The previous channel will be displayed.

Each time you press :, the TV will switch back and forth between the two program positions.

Displaying the on-screen information

Press K to display the following on-screen information.

ABCD4

Stereo

Watching TV programs

Selecting the menu language

Choose from 9 different languages (English, Chinese (CS), Malay, Thai, Vietnamese, Russian, Arabic, Persian or French) for the on-screen display.

1 Press M, then press I or i to display SET UP menu. 2 Press u or U to select Language.

The information will disappear in 6 seconds.

• Program position or external input mode selected

• Program skip on/off information

• Label (if set)

• Mono/Stereo/Dual audio status

2 To erase the display instantly, press K again.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 13 Tuesday, April 11, 2006 4:41 PM

Getting started

Programming channels into the TV’s channel memory

• First, use the Auto tuning function to preset all the active channels in your area automatically. Then, arrange the preset channels with the Manual tuning function so that you can tune into only desired channels.

• Use the Manual tuning operation if desired channels cannot be preset with the Auto tuning or if you would like to preset channels to specific position numbers one by one.

Programming channels automatically

Press M, then press I or i to display the SET UP menu.

2 Press u or U to select Auto tuning.

Language

Auto tuning

Manual tuning AV connection Picture position

SET UP

EXIT

Back Watch TV

3 Press Q to display the Auto tuning menu.

Press OK key to start.

EXIT for no change.

Auto tuning

EXIT

Back Watch TV

4 Press Q to start the automatic search.

The search will begin for all available stations.

Searching Pos :2

EXIT

Auto tuning

Stop

The slide bar will move along the line as the search progresses. If you make a mistake, simply repeat steps 1-4 to start again from the beginning.

5 When the automatic search is completed, the TV will

automatically return to the first program position.

6 Press > or < to view the programmed position.

Note:

When you preset the program channel which sound of broadcast transmission system adopts "M" system, the sound system may not be tuned correctly if the radio waves transmit badly. At that time, preset the channel by Manual tuning. The countries such as Myanmar, Brazil, Chile, Colombia apply to this case. See page 28 for more details.

English

OK OK OK OK

Manually setting channels in the channel memory

From the SET UP menu, press u or U to select Manual tuning.

2 Press Q to display the Manual tuning menu.

Press u or U to select the program position you want to arrange.

Prog. Label

OK MENU

Manual tuning

2 3 4 5 6

Select

Back Watch TV

EXIT

Sort

3 Press Q to display the breakdown menu.

Press I or i to select an item, then press u or U to select the item as shown below.

Manual tuning

Program

B/G

Store

Back Watch TV

ACE

BDF

A. Program position selection B. Sound system (- page 28) C. Color system (- page 28)

A : Automatic (factory set), P : PAL, S : SECAM N4 : NTSC 4.43 (MHz), N3 : NTSC 3.58 (MHz)

If the color of a certain channel is abnormal, the automatic color system selection (A) may have malfunctioned, or sound system selection is wrong. In such a case, select another color and/or sound system (- page 28).

D. Program position skip selection

Press u or U to turn the program position skip option on “8” or off “(”. The program position will then be skipped when you select channels with > or <. The “8” mark will appear beside a program position number when you use the Number button on the remote control.

E. Channel search operation

Press U to search up the band or u to search down the band. Press u or U repeatedly until your desired channel is displayed. When a station/satellite is found, it will be displayed. NEVER PRESS ANY OTHER BUTTONS WHILE THE SET IS TUNING.

F. Auto Fine Tuning

Press u or U to turn the Auto Fine Tuning option on “9” or off “0”. The Auto Fine Tuning function automatically corrects slight fluctuations when receiving signals.

Manual Fine Tuning

While the Auto Fine Tuning turn off “0”, press u or U so that the better picture and sound are obtained.

EXIT

(continued)

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 14 Tuesday, April 11, 2006 4:41 PM

Getting started

G. Label

Station labels appear under the program position display each time you turn on the TV, select a channel, or press K.

To change or create station labels:

1) Press u or U repeatedly to select a character for the first space, then press i.

*(blank space)

2) Repeat step 1) to enter the rest of the characters. If you would like a blank space in the label name, you must choose a blank space from the list of characters.

Press Q to store your settings.

Setting the program sorting

• The TV is capable of receiving a number of different channels depending upon where you live.

• Program sorting is an easy way of storing each channel on the program position of your choice.

Ex.: To swap channel ABCD (Prog.1) for channel MNOP (Prog.4):

1 Press M, then press I or i to display the SET UP menu.

Language Auto tuning Manual tuning AV connection Picture position

Back Watch TV

SET UP

EXIT

English

OK OK OK OK

2 Press u or U to select Manual tuning menu, then press

3 Press u or U to select the channel ABCD, then press i.

Prog. Label

OK MENU

Manual tuning

1 2 3 4 5 6

Select

Back Watch TV

EXIT

ABCD

EFGH IJKL MNOP

Sort

4 Press u to select the new position “4”, then press I.

Prog.

Manual tuning

Label

EXIT

EFGH IJKL MNOP

1 2 3 4 5 6

Store

Back Watch TV

ABCD

5 Press U to select the channel MNOP, then press i. 6 Press U to select the new position “1”, then press I.

7 Confirm new Manual tuning menu.

Prog. Label

OK MENU

Manual tuning

EXIT

MNOP

EFGH IJKL ABCD

1 2 3 4 5 6

Select Sort

Back Watch TV

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 15 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Picture adjustment

Selecting the picture size

Press and hold O until the picture size list appears on the screen, then press u or U to select the appropriate picture size (or press O repeatedly to select required picture size directly).

The antenna input signal

Wide Super Live 2 Cinema 2 4:3

Super Live 1

Cinema 1 Subtitle 14:9

2 Press Q.

Wide

Use this setting when watching a wide-screen DVD, widescreen video tape or a 16:9 broadcast (when available). Due to the range of wide-screen formats (16:9, 14:9, 20:9 etc.), you may see bars on the top and bottom of the screen.

Super Live 2

When receiving “side panel format” signal, this setting will enlarge the image to fit the screen by stretching the image vertically and horizontally, holding the better proportions at the center of the image. Also the black bars on the both sides of the screen will eliminate or reduce.

Super Live 1

When receiving “4:3 format” signal, this setting will enlarge the image to fit the screen by stretching the image vertically and horizontally, holding the better proportions at the center of the image.

Cinema 1

When watching “letterbox format” films/video tapes, this setting will eliminate or reduce the black bars at the top and bottom of the screen by zooming in and selecting the image without distortion.

Subtitle

When subtitles are included on a letterbox format broadcast, this setting will raise the picture so that the most of text is displayed.

Subtitle

14:9

Use this setting when watching a 14:9 broadcast.

Cinema 2

When watching “all sides panel format” films/video tapes, this setting will eliminate or reduce the black bars on all the sides of the screen by zooming in and selecting the image without distortion.

4:3

Use this setting to view a true 4:3 broadcast.

Notes:

• Using the special functions to change the size of the displayed image (e.g. changing the height/width ratio) for the purpose of public display or commercial gain may infringe on copyright laws.

• If the aspect ratio of the selected format is different from the one of the TV transmission or video program, it can cause a difference in vision. Change to the correct aspect ratio picture size.

• In the PC input mode (- page 21), the picture size selection is wide or normal only.

• In the 1080i or 720p input signal mode, the picture size selections are Super Live 1, Cinema 1, Wide, Super Live 2, Cinema 2 and 4:3.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 16 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Using the picture still

•Press R to freeze the picture. Even if an image is frozen on the TV screen, the pictures are

running on the input source. Audio continues to be output as well.

To return to a moving picture, press R again.

(Moving) (Still)

Notes:

• If you use this function except for the purpose of your private viewing and listening, it may infringe the copyright protected by the copyright laws.

• In the PC input mode (- page 21), this function is not available.

Adjusting the picture position

Adjustment to the position of the picture may be made to suit your viewing preferences.

1 Press M, then press I or i to display the SET UP menu. 2 Press the u or U to select Picture position.

Selecting the picture mode

You can select the picture quality instantly among three preset modes and one user-set mode.

• Press N to select the desired picture quality.

Dynamic

Mode Picture quality

q Dynamic bright and dynamic picture

q Standard standard picture

q Mild soft picture

q Memory the picture quality you set

Note:

In the PC input mode (- page 21), this mode is not available.

Adjusting the basic picture quality

Press M, then press I or i to display the PICTURE menu.

Picture settings 3D Color management

Base color adjustment

Cinema mode


Off

Language Auto tuning Manual tuning AV connection

Picture position

Back Watch TV

SET UP

EXIT

English

OK OK OK OK

3 Press Q, then press u or U to select an item you want to

adjust.

Horizontal position

Vertical position Reset

Picture position

EXIT

Back Watch TV

4 Press I or i to adjust the settings as required.

Horizontal position 0

Note:

When the picture format is in Wide or 4:3 mode, only the Horizontal position can be adjusted.

Resetting the picture position

This function resets your picture position settings to the factory settings.

1 From the Picture position menu, press u or U to select

Reset.

2 Press Q.

EXIT

Back Watch TV

2 Press u or U to select the Picture settings menu, then

press Q.

Back light

Contrast Brightness Color Tint Sharpness

Back Watch TV

Picture settings 1/ 2

EXIT

100

50 50

0 0

3 Press u or U to select an item you want to adjust, then

press I or i to adjust the settings as required.

Contrast 100

Selection I

Back light darker lighter

Contrast lower higher

Brightness darker lighter

Color paler deeper

Tint reddish greenish

Sharpness softer sharper

Notes:

• The Tint may only be adjusted on a tape which has been recorded and played back on an NTSC VCR.

• In the PC input mode (- page 21), Color, Tint and Sharpness modes are not available.

Pressing

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 17 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Activating the black stretch

This function increases the strength of dark areas of the picture which improves definition.

1 From the Picture settings menu, press u or U to select

Black stretch on the 2nd page.

Black stretch

MPEG NR DNR Color Temperature

Picture settings 2/ 2

EXIT

Back Watch TV

Low Auto Cool

2 Press I or i to select On or Off.

Black stretch

Note:

In the PC input mode (- page 21), this mode is not available.

Activating the MPEG NR (Noise Reduction)

If the receiving signal of MPEG is a mosquito (grained) noise depending on the compression and conversion, the noise may be reduced when using this function.

1 From the Picture settings menu, press u or U to select

MPEG NR on the 2nd page.

2 Press I or i to select Off, Low, Middle or High.

MPEG NR

Note:

In the PC input mode (- page 21), this mode is not available.

High

Activating the DNR (Digital Noise Reduction)

If the receiving signal is weak and the picture is blurry, the picture may be improved when using this function.

1 From the Picture settings menu, press u or U to select

DNR on the 2nd page.

2 Press I or i to select Auto, Off, Low, Middle or High.

DNR

Note:

This function is available for 480i and 576i signals.

Auto

Adjusting the color management

You can adjust the picture color quality by selecting from 6 base color adjustments : Red, Green, Blue, Yellow,

Magenta or Cyan.

1 Press M, then press I or i to display the PICTURE menu. 2 Press u or U to select 3D Color management, then

press I or i, then press I or i to select On.

3D Color management

3 Press Q, then press u or U to select Base color

adjustment.

4 Press Q, then press u or U to select an item you want to

adjust.

5 Press i, then press I or i to select Hue, Saturation or

Brightness.

Base color adjustment

Hue

Red

Green Blue Yellow Magenta Cyan

Reset

Back Watch TV

0 0 0 0 0

EXIT

Saturation Brightness

6 Press u or U to adjust the settings as required.

Hue0Saturation

Red

Notes:

• If you select color management Off mode, this mode is not available.

• In the PC input mode (- page 21), this mode is not available.

Brightness

Resetting the base color adjustment

The Reset function adjusts the base color adjustment to the factory settings.

1 From the Base color adjustment menu, press u or U

to select Reset.

2 Press Q.

Selecting the color temperature

You can change the tone of the picture by selecting from three preset color temperatures: Cool, Normal or Warm.

1 From the Picture settings menu, press u or U to select

Color Temperature on the 2nd page.

2 Press I or i to select mode you prefer.

Color Temperature

Cool: Lends a blue hue to the picture. Normal: Neutral Warm: Lends a red hue to the picture.

Cool

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 18 Tuesday, April 11, 2006 4:41 PM

s (small cap)

Using the TV’s features

Using the cinema mode

A movie film’s picture runs at 24 frames a second, whereas movie software such as DVD, etc., that you enjoy watching on television at home runs at 30 (NTSC) or 25 (PAL) frames a second. To convert this signal to reproduce a smooth motion and picture quality, select the On mode.

Effective signal and setup conditions:

• When the Video input mode is selected.

• When the input signal format is 480i and 576i signals.

1 Press M, then press I or i to display the PICTURE menu.

Picture settings 3D Color management

Base color adjustment

Cinema mode


EXIT

Back Watch TV

Off

2 Press u or U to select Cinema mode, then press I or i

to select On or Off.

Note:

When a DVD movie with subtitle is playing back, this mode may not work correctly.

Using the auto format

When the TV receives a true HDMI signal picture and the auto format is On, it will automatically be displayed in HDMI signal format, irrespective of the TV’s previous setting.

1 Press M, then press I or i to display the FUNCTION

menu.

Sound adjustment

Setting the MTS (Multi-channel TV Sound)

Auto mode

The MTS Auto mode automatically recognize stereo/bilingual programs depending on the broadcast signal.

1 Press M, then press I or i to display the SOUND menu.

MTS

Dual Bass Treble Balance WOW

SOUND 1/ 2

EXIT

Back Watch TV

2 Press u or U to select MTS, then press I or i to select

Auto or Mono.

Mono mode

If you experience noise or poor reception of any stereo/ bilingual program, set the MTS mode to Mono. Noise will be reduced and reception may improve.

Note:

If you experience noise with a particular program on whose channel reception is usually good, try setting MTS mode to Auto, then switch S to e Mono (monaural) (- page 19).

Selecting the dual 1 or dual 2 mode

You can hear only dual 1 or dual 2 sound selected, whenever bilingual programs are received.

Auto

Dual 1

0 0 0

Teletext Auto format

Blue Screen Side panel

FUNCTION

EXIT

Back Watch TV

Auto

2 Press u or U to select Auto format, then press I or i to

select On or Off.

1 Press M, then press I or i to display the SOUND menu. 2 Press u or U to select Dual, then press I or i to select

Dual 1 or Dual 2.

Notes:

• When the MTS setting is in Mono mode, the Dual menu is not selectable.

• The Dual menu setting status remains even if the TV is turned off.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 19 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Selecting the stereo programs

When a stereo program is received, d Stereo appears.

2 Press S to select the stereo/monaural mode. d Stereo

and e Mono appear cyclically on the screen.

Stereo

Selecting the bilingual programs

When a bilingual program is received, e Dual appears.

2 Press S to select the sound to be heard. The sound

differs according to the transmission system: NICAM or German stereo/bilingual broadcast.

Dual 1

Sound to be heard

Display

NICAM

German stereo/ bilingual broadcast

j Dual 1 Sub I sound Main sound J Dual 2 Sub II sound Sub sound e Mono Main sound —

Note:

These settings are not stored in the TV memory.

Adjusting the sound quality

From the SOUND menu, press u or U to select an item you want to adjust.

2 Press I or i to adjust the settings as required.

Bass 0

Using the SRS WOW surround sound

SRS WOW is a special combination of SRS Labs audio technologies that creates a thrilling surround sound experience with deep, rich bass from stereo sound sources. Your TV’s audio will sound fuller, richer and wider.

WOW consists of three features; SRS 3D, FOCUS, and TruBass, being turned on.

1 From the SOUND menu, press u or U to select WOW,

then press Q.

MTS

Dual Bass Treble Balance

WOW

Back Watch TV

SOUND 1/ 2

EXIT

Auto

Dual 1

0 0 0

2 Press u or U to select an item you want to adjust, then

press I or i to adjust the settings as required.

SRS 3D

FOCUS TruBass

WOW

EXIT

Back Watch TV

SRS 3D: To turn the surround effect On or Off. FOCUS: To turn the vocal emphasis effect On or Off. TruBass: To select the desired bass expansion level

(Off, Low or High).

Notes:

• If the broadcast is monaural, the SRS 3D effect does not work.

• WOW, SRS and l Inc.

• WOW technology is incorporated under license from SRS Labs, Inc.

• The SRS WOW effect is active only when the sound outputs from the speaker.

symbol are trademarks of SRS Labs,

Off

High

Selection I Pressing i

Bass weaker stronger

Treble weaker stronger

Balance decreases the right

channel

decreases the left channel

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 20 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Using the stable sound

The Stable sound function limits the highest volume level to prevent extreme changes in volume when the signal source changes (for example, to prevent the sudden increase in volume that often happens when a TV program switches to a commercial).

1 Press M, then press I or i to display the SOUND menu. 2 Press u or U to select Stable sound on the 2nd page.

Stable sound

Back Watch TV

SOUND 2/ 2

EXIT

Off

3 Press I or i to select On or Off.

Note:

The Stable sound effect is active only when the sound outputs from the speaker.

Using the bass boost

1 Press T to display Bass boost level.

Bass boost 70

2 While the Bass boost display is on the screen, press I

or i to adjust the Bass boost level.

3 To turn off the Bass boost, press T to display Bass

boost Off.

Bass boost Off

Note:

The Bass boost effect is active only when the sound outputs from the speaker.

Activating blue screen

With the blue screen function On, the screen will automatically turn blue and the sound will be muted when no signal is being received.

1 Press M, then press I or i to display the FUNCTION

menu.

2 Press u or U to select Blue screen.

Teletext Auto format

Blue Screen

Side panel

FUNCTION

Auto

3 Press I or i to select On or Off.

Note:

In the PC input mode (- page 21), this function is not available.

Other features settings

Selecting the timer menu

The Timer is especially useful if you want the TV to turn itself on or off after a selected period of time.

1 Press M, then press I or i to display the TIMER menu.

Sleep timer

On timer

On timer Position

TIMER

EXIT

Back Watch TV

2 Press u or U to select the required timer mode (Sleep

timer (Turn off the TV) or On timer).

The timer display will set by 10 minutes, up to 12 hours and 50 minutes.

3 Press the Number buttons (0-9), I or i to set the On or

Off delay time, e.g. on in 30 minutes and On timer Position 3 selected.

4 Press P to exit the menu. When setting the On timer,

press u or U to select the On timer Position and enter the program position number you want to watch. Set the Standby mode by pressing J on the remote control or 1 on the TV. Activation of the Timer is indicated by the green “Ontimer indicator”, on the front of the TV (- page 8).

Notes:

• The TV will automatically turn itself off after approximately 2 hours if you do not operate the TV after turned on by on timer function.

• If you press and hold I or i to set the On or Off delay time, the timer display will set by 30 minutes, up to 12 hours 30 minutes.

Adjusting the brightness of side panel

You can adjust the brightness of side panel in 14:9 or 4:3, etc. mode.

1 From the FUNCTION menu, press u or U to select Side

panel.

2 Press I or i to adjust the settings as required.

Side panel

00:00

00:30

Back Watch TV

EXIT

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 21 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Selecting the video input source to view

1 Press and hold o or press Q on the remote control until

the video input mode list appears on the screen, then press u or U to select appropriate input source (or press o on the TV front panel or o on the remote control repeatedly to select required input source directly).

OK:

5 4 3 2 1 0 PC HDMI

Ex. PC VGA mode

PC VGA

2 Press Q.

o 1 (o (1), video 1 input) or o 1C (component video input),

o 2 (o (2), video 2 input) or o 2S (S-video input), o 3 (o (3), component video input),

HDMI (o HDMI, HDMI input), PC (o RGB/PC, PC input)

Note:

When the component video input, PC input mode or HDMI input mode is selected, the MONITOR OUT output terminals (- page 24) output audio signal only.

(Press and hold)

1 1 PC HDMI

Setting the manual setting menu

Press M, then press I or i to display the SET UP menu.

Language Manual setting AV connection Picture position

Back Watch TV

SET UP

EXIT

English

OK OK OK

2 Press u or U to select Manual setting, then press Q. 3 Press I or i to select an item, then press u or U to select

the item as shown below.

Manual setting

Color system:Auto

EXT1

Store

Back Watch TV

A. Color System

Confirm that color system is set to “A” (Auto). If not, select “A” with u or U.

B. Video label

The video label allows you to label each input source for your TV. To change or create video labels:

1) Press u or U repeatedly to select a character for the first space, then press i.

2) Repeat step 1) to enter the rest of the characters. If you would like a blank space in the label name, you must choose a blank space from the list of characters.

3) Press Q to store your settings.

EXIT

*(blank space)

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 22 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Teletext

This TV has a multi-page teletext memory, which takes a few moments to load and it offers two ways of viewing Teletext Auto and LIST which are explained below.

Setting up the teletext mode

To select teletext mode:

Select a channel position with the desired teletext service.

1 Press M, then press I or i to display the FUNCTION

menu.

Teletext Auto format

Blue Screen Side panel

2 Press u or U to select Teletext, then press I or i to select

Auto or LIST mode.

Teletext

Auto format

Blue Screen Side panel

Note:

When you are watching the teletext program, SET UP menu and FUNCTION menu are not selectable.

FUNCTION

EXIT

Back Watch TV

FUNCTION

EXIT

Back Watch TV

Auto

LIST

On On

Teletext general information

E button:

Pressing E once will bring up the teletext screen. Press again to superimpose the teletext over a normal broadcast picture. Press again to return to normal TV mode. You need to return to normal viewing if you wish to change channels.

When you first press E to access the text service, the first page you see will be the initial page.

In Auto mode, this displays the main subjects available and their relevant page numbers.

In LIST mode, you will see the page numbers currently stored on the each color button.

Sub-pages:

Once in this chosen page, if there are sub-pages they will automatically load into memory without changing the one you are reading. If there are many sub-pages, it will take a long time for them all to load and this will depend on the speed with which the broadcaster transmits them.

To access the sub-pages in memory, press l, then use u and U to view them.

Note:

If you press r while the picture mode is activated, this mode will be cancelled.

Using Auto mode

There are two Modes: Auto will display FASTEXT, if available. LIST will display your four favorite pages. In either mode, as an alternative to the colored buttons, you can access a page by entering a 3-digit number, using the Number buttons on the remote control, or to advance to the next page, press >, to go back to the previous page press <.

To change between Auto and LIST, see above.

• Press E to access teletext.

100 Spor t 14:57:55

SwimmingRacingBaseballFootball

Red

Green

Yellow

Blue

If FASTEXT is available, you will see 4 colored titles at the base of the TV screen. To access any given subject, simply press the relevant colored button on the remote control.

If FASTEXT is not available, you can access any page simply by entering a 3-digit page number or pressing the corresponding colored button.

For further information on your particular text system(s), see the broadcast teletext index page or consult your local Toshiba dealer.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 23 Tuesday, April 11, 2006 4:41 PM

Using the TV’s features

Using LIST mode

Press E to access teletext.

100 TEXT M00 14:58:55

100 200 300 400

Red

Green

Yellow

Blue

The four choices at the bottom of the screen are now number – 100, 200, 300 and 400, which have been programmed into the TV’s memory.

2 To view these pages, use the colored prompt buttons.

e.g. press the Green button to view page 200.

3 If you want to change these stored pages, press the

colored button for the color you want to change. e.g. Press the Green button and enter the 3-digit number.

100 TEXT M00 14:58:59

100 250 300 400

This number will change in the top left of the screen and in the colored highlight.

4 Press Q to store your choice. The bars at the bottom of

the screen will flash white.

5 You may view other pages by simply entering the 3-digit

page number – but NEVER press Q or you will lose the favorite already stored.

Teletext buttons on the remote control

Below is an introduction to the teletext buttons on your remote control and their functions.

E To display a page of teletext:

Press E to display teletext. Press again to superimpose the teletext over a normal broadcast picture. Press again to return to normal TV mode.

k To display an index/initial page:

In Auto-mode

Press k to access the index page. The one displayed is dependant on the broadcaster.

In LIST-mode

Press k to return to the 100 page or initial page.

A To reveal concealed text:

Some pages cover topics such as quizzes and jokes. To discover the solutions, press A.

B To hold a wanted page:

This function is included as it is part of the broadcast teletext system but you will not need it as this TV allows you to control the display of sub-pages.

C To enlarge the teletext display size:

Press C once to enlarge the top half of the page, press again to enlarge the bottom half of the page. Press again to revert to the normal size.

D To select a page while viewing a normal picture:

When in teletext mode, if a page selection is made and then D is pressed, a normal picture will be displayed. The TV will indicate when the page is present by displaying the title bar of the text page at the top of the screen. Press E to view the page.

Note:

It will not be possible to change program position while in Teletext mode, you will have to cancel the teletext first by pressing E to return to a normal TV picture.

To select the time display:

If you press D while watching a normal TV broadcast, you will see a time display from the broadcaster. It will remain on the screen for about 5 seconds.

9:56 and 25 seconds p.m.

21:56:25

Note:

If you press r while this mode is activated, this mode will be cancelled.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 24 Tuesday, April 11, 2006 4:41 PM

Connecting your TV

Side connections

You can connect a wide variety of auxiliary equipment via the terminals located on the right side of the panel o (2).

Please always refer to the owner’s manual of the equipment to be connected for full details.

Connection example

TV right side view

Back connections

Connection example

TV back view

VCR (Recording)

DVD video player

(with component video outputs)

Set Top Box

HDMI or DVI device

Camcorder Camcorder with

• To select the side inputs, press and hold o until the video input mode list appears on the screen, then press u or U to select o2 (- page 21), then press Q.

• Before connecting any external equipment, turn off all main power switches.

• If you connect both of the S-VIDEO input terminal and VIDEO input terminal, the S-VIDEO signal will appear on the screen (display changes to o 2S).

• If you connect mono sound equipment to o (2), connect the audio output of the equipment to the L/MONO jack on the TV.

• You can enjoy Video Games with this TV. However shooting games, where the player shoots at a target on the TV screen with a light gun, may not work because of the LCD Color TV properties.

Video Games

S-Video

• Before connecting any external equipment, turn off all main power switches.

• The unauthorized recording of television programs, DVDs, video tapes and other materials may infringe upon the provisions of copyright law.

• If you connect both of the COMPONENT VIDEO INPUT terminal and VIDEO input terminal, the COMPONENT VIDEO signal will appear on the screen (display changes to o 1C).

• The COMPONENT VIDEO INPUT consists of three component video signals (Y, P the best picture performance. These terminals can only be used with the component video compatible equipment e.g. DVD video player, etc.

• Additional equipment and cables shown are not supplied with this TV.

B/CB, PR/CR) and provides

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 25 Tuesday, April 11, 2006 4:41 PM

Connecting your TV

Connecting an HDMI or a DVI device

• This TV is not intended for connection to and should not be used with a PC.

• When turning on your electronic components, turn on the TV first, and then the HDMI or DVI device.

• When turning off your electronic components, turn off the HDMI or DVI device first, and then the TV.

• This TV may not be compatible with features and/or specifications that may be added in the future.

• This TV is only operable with L-PCM on 32/44. 1/48 kHz and 16/20/24 bits. If there is no sound when using HDMI, use the analog audio cables to connect the TV and the HDMI device, and select Analog in HDMI audio of the AV connection menu (- page 26)

Connecting an HDMI or a DVI device

The HDMI input on your TV receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device.

This input is designed to accept HDCP program material in digital from EIA/CEA-861/861B compliant consumer electronic devices (such as a set top box or DVD player with HDMI or DVI output).

The HDMI input is designed for best performance with 1080i (50 Hz/60 Hz) high-definition video signals, but will also accept and display 480i, 480p, 576i, 576p, 720p (50 Hz/60 Hz (60Hz: except for the E-EDID)) and VGA signals.

• HDMI: High-Definition Multimedia Interface

• DVI: Digital Video Interface

• HDCP: High-bandwidth Digital Content Protection

• EIA/CEA-861/861B compliance covers the transmission of uncompressed digital video with high-bandwidth digital content protection, which is being standardized for reception of high-definition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.

• E-EDID: Enhanced-Extended Display Identification

• VGA: VESA 640 5 480 @ 60 Hz

• L-PCM: Linear-Pulse Code Modulation

Connecting an HDMI device

One HDMI cable (type A connector)

TV back view

HDMI device

VIDEO AUDIO

OUT

HDMI OUT

For proper operation, it is recommended that you use a short HDMI cable.

HDMI cable transfers both video and audio.

Connecting a DVI device

One HDMI (type A connector)-to-DVI adapter cable and audio cables

TV back viewTV back view

DVI device

VIDEO AUDIO

OUT

HDMI (type A connector)-to-DVI adapter cable

For proper operation, the length of an HDMI-to-DVI adapter cable should not exceed 3m. The recommended length is 2m.

DVI

OUT

Standard analog audio cables

An HDMI-to-DVI adapter cable transfers only video.

Separate analog audio cables are required.

Note:

HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 26 Tuesday, April 11, 2006 4:41 PM

Connecting your TV

Selecting the PC/HDMI audio mode

You can select PC audio or HDMI audio when using this function (- page 25).

1 Press M, then press I or i to display the SET UP menu. 2 Press u or U to select AV connection, then press Q to

display the AV connection menu.

AV connection

PC/HDMI audio

HDMI audio

Back Watch TV

EXIT

Digital

3 Press u or U to select PC/HDMI audio, then press I or i

to select PC or HDMI.

Setting the HDMI audio mode

You can select sound of an HDMI or DVI device connected to the HDMI input terminals (- page 25) from three modes: Auto, Digital or Analog.

Note:

This function is available only when the PC/HDMI audio mode is set to

1 From the AV connection menu, press u or U to select

2 Press I or i to select Auto, Digital or Analog.

HDMI.

HDMI audio.

PC/HDMI audio

HDMI audio

Back Watch TV

AV connection

EXIT

HDMI

Auto

Connecting a computer

An analog RGB (15 pin) computer cable can be connected.

TV back view TV back view

Mini D-sub 15 pin

Computer

RGB PC cable

Conversion adapter (if necessary)

Audio cable for PC-to-TV connection

Connect a PC cable from the computer to the o RGB/PC terminal on the back of the TV.

The following signals can be displayed:

• VGA: VESA 640 5 480 @ 60 Hz

• SVGA: VESA 800 5 600 @ 60 Hz

• XGA: VESA 1024 5 768 @ 60 Hz

• S-XGA: VESA 1280 5 1024 @ 60 Hz However, these signal formats are converted to match the

number of pixels of the LCD panel.

Therefore, the TV may not display small text properly.

If you connect this unit to your PC, the compressed image is displayed in S-XGA mode, therefore the picture quality may deteriorate and characters may not be read.

Notes:

• Some PC models cannot be connected to this TV.

• There is no need to use an adapter for computers with DOS/

V compatible mini D-sub 15 pin terminal.

• A bar may appear in the upper, lower, right or left side of the screen, or parts of the picture may be obscured depending on some signals. This is not the malfunction.

• If the edges of the picture are stretched, readjust the picture position adjustments in the PC Setting menu.

• Depending on the specification of the PC you are playing the DVD-Video on, and the DVD’s title, some scenes may be skipped, or you may not be able to pause during multi-angle scenes.

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 27 Tuesday, April 11, 2006 4:41 PM

Connecting your TV

Signal names for mini D-sub 15 pin connector

Pin assignment for RGB/PC terminal

5 10

15 11

Pin No. Signal name Pin No. Signal name

1R9NC

2 G 10 Ground

3B11NC

4 NC (not

12 NC

connected)

5 NC 13 H-sync

6 Ground 14 V-sync

7 Ground 15 NC

8 Ground

Using the PC setting

• In the PC input mode, you cannot select the Color, Tint, Sharpness, Black stretch, MPEG NR and DNR in the Picture setting menu and Cinema mode (- page 18).

• In the PC input mode, the Manual setting (- page 21) is not displayed.

• First press and hold o until the video input mode list appears on the screen, then press u or U and Q in order to select the PC input mode (- page 21).

• This function may not be available for some signal or if no signal is received.

• The optimum points of the clock phase and sampling clock adjustments may be incomprehensible according to the input signals.

Adjusting the clock phase of the picture

If the clock phase, which synchronize the PC signal and LCD display, is not optimized, the picture will blur.

This function enables you to adjust clock phase and display a clear picture.

1 From the PC Setting menu, press u or U to select Clock

phase.

2 Press I or i to obtain a clear picture.

Clock phase 0

Adjusting the sampling clock

If the sampling clock does not match with the dot clock frequency of the PC, blurred picture detail will occur, or screen width will change, or drift patterns in vertical lines may be apparent.

This function enables you to adjust it and optimize the picture.

1 From the PC Setting menu, press u or U to select

Sampling clock.

2 Press I or i to optimize the picture.

Sampling clock 0

Resetting the PC setting

The Reset function adjusts the PC Setting to the factory settings.

1 From the PC Setting menu, press u or U to select Reset

on the 2nd page.

Reset

PC Setting 2 /2

Adjusting the picture size/position

Press M, then press I or i to display the SET UP menu.

2 Press u or U to select PC Setting.

Language AV connection

PC Setting

Back Watch TV

SET UP

EXIT

English

OK OK

3 Press Q to display the PC Setting menu.

Horizontal position

Horizontal width Vertical position Vertical height Clock phase Sampling clock

PC Setting 1 /2

EXIT

Back Watch TV

0 0 0 0 0

4 Press u or U to select an option you want to adjust. Press

I or i to adjust the settings as required.

Horizontal position 0

2 Press Q.

Back Watch TV

EXIT

Toshiba 32WL66A/E/T

Asia_32WL66AET.book Page 28 Tuesday, April 11, 2006 4:41 PM

Reference section

Troubleshooting

Before calling a service technician, please check the following table for a possible cause of the symptom and some solutions.

Symptom and solution

TV will not turn on

• Make sure the power cord is plugged in, then press ! and 1.

• The remote control batteries may be dead. Replace the batteries.

No picture, no sound

• Check the antenna connections.

No sound, picture OK

• The sound may be muted. Press 2+, 2– or U.
