The model number and serial number are on the back
of your TV. Record these numbers in the spaces below.
Refer to these numbers whenever you communicate
with your Toshiba dealer about this TV.
TO REDUCE THE R ISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
The lightning symbol in the triangle tells you that the
voltage inside this product may be strong enough to
cause an electric shock. DO NOT TRY TO SERVICE
THIS PRODUCT YOURSELF.
The exclamation mark in the triangle tells you that
important operating and maintenance instructions
follow this symbol.
CAUTION
TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS
POLARIZED PLUG WITH AN EXTENSION CORD
RECEPTACLE OR OTHER OUTLET UNLESS THE
PRONGS CAN BE FULLY INSERTED INTO THE
OUTLET TO PREVENT ANY EXPOSURE OF THE
PRONGS ON THE POLARIZED PLUG.
ATTENTION
POUR PRÉVENIR LES CHOCS ÉLECTRIQUES NE PAS
UTILISER CETTE FICHE POLARISÉE AVEC UN
PROLONGATEUR, UNE PRISE DE COURANT OU UNE
AUTRE SORTIE DE COURANT, SAUF SI LES LAMES
PEUVENT ÊTRE INSÉRÉS À FOND SANS EN LAISSER
AUCUNE PARTIE À DÉCOUVERT.
CAUTION
The plug has one prong wider than the other and will fit only
one way into a standard
electrical outlet (120 volt AC,
wide prong
60 Hz). If the plug does not fit
into the outlet, try turning it
around. If the plug still does
not fit, the outlet is probably
non-standard and must be
replaced by a qualified electrician. Do not tamper with the plug
or try to force it into a non-standard outlet.
Note to CATV system installers in the USA
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC, which provides
guidelines for proper grounding, and, in particular, specifies that
the cable ground shall be connected to the grounding system of
the building, as close to the point of cable entry as practical.
Installing your TV
• Place the TV on the floor or on a sturdy platform. The
mounting surface should be flat and steady. If you install the
TV on a soft floor, make sure that the floor is not damaged
by the weight of the TV.
• This TV set may be used only with the Toshiba stands shown
on page 48. Use with other stands may result in instability,
causing possible injury.
• Place the TV far enough away from the walls to allow proper
ventilation. This will prevent the TV from overheating and
avoid possible damage to the TV. Avoid dusty areas too.
Using your TV
• Do not stand or climb on the TV.
• Do not put any heavy object on top of the TV.
• Do not place containers with liquids such as drinks or
cosmetics on the TV. If any foreign material or water leaks
into the TV, unplug the power cord and contact your dealer.
• Avoid displaying stationary images on your TV screen for
extended periods of time. Stationary patterns generated by a
Multi-Window display, computer displays, video games,
stock market reports, etc., can become permanently
engrained on the picture tube. This damage is not protected
by your warranty because it is the result of misuse. If you wish
to use your TV to display still images, reduce brightness and
contrast settings. Never leave a Multi-Window, computer, or
video game display unattended.
Cleaning your TV
• To clean the TV screen:
1. First remove the plug from the power outlet to avoid
possible shock hazard.
2. Use a clean cellulose sponge or chamois cloth dampened
with a solution of mild detergent and warm water to clean
the TV screen and trim. Do not use too much water on the
TV screen. Water spills into the cabinet and may cause
damage to the TV. Avoid excess water.
3. Remove any extra moisture with the same cloth or a dry
one.
CAUTION
Never use strong solvents such as thinner, benzene or other
chemicals on or near cabinet, as they might damage the finish of
the cabinet.
Limited United States Warranty ..................................... 50
Index .......................................................................... 51
32/36AFX61(E)
3
Introduction
Introduction
Welcome to Toshiba
Congratulations! You have purchased one of the finest TVs on the
market. The goal of this manual is to guide you through setting up
and operating your Toshiba TV as quickly as possible.
This manual applies to models 32AFX61 and 36AFX61. Before you
start reading, check your model number by looking at the rear of
the TV.
your TV
Connecting
Instructions in this manual are based on using the remote control.
You can also use the controls on the TV if they have the same name as
those on the remote control.
Please read all the safety and operating instructions carefully, and keep
the manual for future reference.
Exploring your new TV
You can operate your TV by using the buttons on the front panel or
Using the
Remote Control
the remote control. The back panel and front panel (behind the door)
provide all the terminal connections you will need to connect other
equipment to your TV.
TV front
Video/Audio inputs
(Video 3)
MENU
VOLUME zy
CHANNEL zy
your TV
Setting up
Features
Using the TV’s
Appendix
TV rear
VIDEO-3 IN
S-VIDEO
VIDEO
ANT( 75
ANT-1OUTANT- 2
AUDIO
L/MONO R
CHANNEL
VOLUMETV/VIDEOMENUDEMO
TV/VIDEODEMO
POWER
POWER
Remote sensor
POWER indicator
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
OUT
VAR
AUDIO
VIDEO
L/
MONO
AUDIO
R
OUT
CT-90047
)
AUDIO CENTER
CHANNEL IN
ONOFF
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
IN
Index
4
32/36AFX61(E)
Connecting your TV
VIDEO
Cable
Color Stream
Cable
If you have not connected electronic equipment before, or you have
been frustrated in the past, you may wish to read this section. (Cables
are not supplied.)
•A coaxial cable is the standard cable that comes in from your
antenna or cable converter box. Coaxial cables use “F”
connectors.
•Audio and video cables are usually color-coded according to use:
yellow for video and red and white for audio. The red audio cable
is for the stereo right channel, and the white audio cable is for
the stereo (or mono) left channel. If you look at the rear panel of
the TV, you will see that the terminals are color-coded in the
same manner as the cables.
• S-video cables provide better picture performance. S-video cables
can only be used with S-video compatible components.
• ColorStream
®
cables come in sets of three. A ColorStream
connection will provide the best picture performance.
Connecting a VCR
This connection allows you to watch local channels and video
programs, play or record on the VCR while watching TV, and record
from one channel while watching another channel.
You will need:
• one coaxial cable
• one pair of audio cables (one single audio cable for a mono VCR)
• one video cable (one S-video cable for an S-VHS VCR)
Cable lead-in from Cable or Antenna
Stereo VCR
VIDEO AUDIO
LR
ONOFF
IN
OUT
S-VIDEO
VIDEO
MONO
AUDIO
L/
R
VIDEO 1 VIDEO 2
IN
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
OUT
OUT
VAR
AUDIO
VIDEO
L/
MONO
AUDIO
R
IN from ANT
CH 3
CH 4
TV
ANT( 75
ANT-1OUTANT- 2
OUT to TV
)
AUDIO CENTER
CHANNEL IN
ANTENNA
Coaxial Cable
AUDIO
Cables
S-VIDEO
Cable
Caution:
Do not plug the TV in until you have finished
connecting all of your equipment.
Caution:
If you have a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.
If you have an S-VHS VCR, use an S-video
cable (in the S-Video inputs) instead of a
regular video cable.
Do not connect a regular video cable and an
S-video cable to Video-1 (or Video-2) at the
same time. Doing so will distort the picture.
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States
and other countries, and may subject
you to civil and criminal liability.
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
Appendix
Index
532/36AFX61(E)
Introduction
Connecting a cable converter box
This connection allows you to watch cable and premium channels.
To use the TV’s features, select ANT-1. To view premium channels,
select ANT-2 and tune the TV to channel 3 or 4 (whichever channel is
vacant in your area), then use the converter box to change channels.
You will need:
• two coaxial cables
From Cable
your TV
Connecting
Using the
Remote Control
Connecting a cable converter box and VCR
This connection allows you to watch and record basic and premium
cable channels, watch videotapes, and record one TV channel while
watching another TV channel. To use the TV’s features, select ANT-1.
your TV
Setting up
Features
Using the TV’s
Appendix
Index
To view premium channels or record with the VCR, select ANT-2,
change the TV channel to 3 or 4 (whichever channel is vacant in your
area), and then use the converter box to change channels.
You will need:
Cable converter box
632/36AFX61(E)
TV
Y
C
C
DVD IN
B
AUDIO
R
OUT
VAR
RL
AUDIO
VIDEO
L/
L
MONO
AUDIO
R
R
OUT
)
ANT( 75
ANT-1OUTANT- 2
IN OUT
Cable converter box
AUDIO CENTER
CHANNEL IN
ONOFF
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
COLOR
STREAM
IN
• one two-way cable signal splitter
• three coaxial cables
• one pair of audio cables (one single audio cable for a mono VCR)
• one video cable (one S-video cable for an S-VHS VCR)
From Cable
OUT
IN
splitter
OUT
TV
)
ANT( 75
ANT-1OUTANT- 2
IN
OUT
Stereo VCR
IN from ANT OUT to TV
CH 3
CH 4
AUDIO CENTER
VIDEO
CHANNEL IN
S-VIDEO
ONOFF
VIDEO
L/
MONO
AUDIO
R
LR
IN
OUT
AUDIO
VIDEO 1 VIDEO 2
IN
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
OUT
AUDIO
OUT
two-way cable signal
Note:
When you use a converter box with your TV,
the remote control will not operate some
features, such as programming your favorite
channels, labeling channels, and locking
channels.
Note:
If you have a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.
If you have an S-VHS VCR, use an S-video
cable (in the S-video jacks) instead of a
regular video cable. Do not connect both a
regular video cable and an S-video cable to
Video-1 (or Video-2) at the same time. Doing
so will distort the picture.
VAR
AUDIO
When you use a converter box with your TV,
the remote control will not operate some
VIDEO
features, such as programming your favorite
L/
MONO
channels, labeling channels, and locking
channels.
R
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States
and other countries, and may subject
you to civil and criminal liability.
Connecting a DVD player or satellite receiver
and a VCR
This connection allows you to watch DVD/satellite, VCR, and TV
programs. You can record one TV channel while watching another
channel.
You will need:
• one coaxial cable
• two pairs of audio cables (one single and one pair of audio cables
for a mono VCR)
• one video cable (between the TV and VCR)
• one S-video cable (between the TV and DVD player/satellite
receiver
From Antenna
Stereo VCR
VIDEO AUDIO
LR
IN from ANT
CH 3
CH 4
TV
)
ANT( 75
ANT-1OUTANT- 2
OUT to TV
AUDIO CENTER
CHANNEL IN
ONOFF
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
IN
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
OUT
OUT
VIDEO
MONO
AUDIO
R
IN
OUT
VAR
AUDIO
L/
Note:
For the highest possible picture quality from a
DVD player or satellite receiver that does not
have component video connections, use an
S-video cable between the TV and DVD
player or satellite receiver. If your DVD
player or satellite receiver is
component video compatible, see
“Connecting a DVD player with
ColorStream
®
(component video) and
a VCR” below and on page 8.
Do not connect both an S-video cable and a
regular video cable to Video-1 (or Video-2) at
the same time. Doing so will distort the
picture.
Do not connect the DVD player/satellite
receiver and VCR to the same video channel
on the TV. (See the illustration at left, which
shows the DVD player/satellite receiver
connected to Video-1 and the VCR
connected to Video-2.)
Introduction
your TV
Connecting
Using the
Remote Control
DVD Player/Satellite Receiver
AUDIO
From Satellite Dish
(for Satellite
Receiver only)
IN from ANT
S-VIDEO
VIDEO
OUTOUT
Connecting a DVD player with ColorStream
L
R
OUT
®
(component video) and a VCR
This connection allows you to watch DVD, VCR, and TV programs,
and record from one source while watching a program from another
source.
Your TV has ColorStream (component video) inputs. Connecting
your TV to a component video compatible DVD player (such as a
Toshiba DVD player with ColorStream
quality and realism.
You will need:
• one coaxial cable
• three pairs of audio cables (two single and one pair of audio
cables for a mono VCR)
• two video cables
• one set of ColorStream (component video) cables (For a nonColorStream DVD player, use an S-video cable; see notes on
page 8.)
(Continued on next page)
™
) can greatly enhance picture
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States
and other countries, and may subject
you to civil and criminal liability.
your TV
Setting up
Features
Using the TV’s
Appendix
Index
732/36AFX61(E)
From Antenna
Introduction
your TV
Connecting
Using the
Remote Control
(Continued from previous page)
Stereo VCR
VIDEO AUDIO
IN from ANT OUT to TV
CH 3
CH 4
TV
)
ANT( 75
ANT-1OUTANT- 2
Satelite IN
DVD Player with ColorStream™
AUDIO CENTER
CHANNEL IN
S-VIDEO
ONOFF
Y
COMPONENT VIDEO
LR
IN
OUT
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
IN
C
RCB
VIDEO
OUT
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
AUDIO
OUT
L
R
Note:
For the highest possible picture quality, you must use
the ColorStream (component video) connections between
the TV and DVD player. Connect the ColorStream cables
from the DVD player to the jacks marked “ColorStream”
on the TV.
The ColorStream input on the TV is for use with DVD
players that offer interlaced (480i) scanning ONLY. If you
have a progressive scan (480p) DVD player, you
must switch the DVD player to interlaced (480i)
OUT
VAR
AUDIO
VIDEO
L/
MONO
AUDIO
R
OUT
mode first, and then connect it to the TV’s ColorStream
jacks. Failure to do this will cause unacceptable
picture performance.
Connection of a high definition set-top receiver box is
permitted only if the output is switched to the interlaced
(480i) scan mode. This TV will not accept or display
progressive scan (480p/720p) signals or 1080i
interlaced high definition signals.
If your DVD player is not component video compatible,
use the S-video connections (both audio and video)
instead of the ColorStream connections.
L
R
Do not connect both S-video and ColorStream cables
between the TV and DVD player at the same time. Doing
so will distort the picture.
To record, set the VCR to Line IN. To monitor recording,
set the VCR to Line IN and the TV to Video-1.
your TV
Setting up
Features
Using the TV’s
Appendix
Index
Connecting two VCRs
This connection allows you to record (dub/edit) from one VCR to
another VCR while watching a videotape. You can also record from
one TV channel while watching another channel.
You will need:
• one coaxial cable
• two pairs of audio cables (two single audio cables for mono
VCRs)
• two video cables (two S-video cables for S-VHS VCRs)
VCR 1
VIDEO AUDIO
From Antenna
ANT-1OUTANT- 2
TV
ANT( 75
IN from ANT OUT to TV
)
VCR 2
CH 3
CH 4
AUDIO CENTER
CHANNEL IN
LR
S-VIDEO
ONOFF
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
VIDEO AUDIO
LR
IN
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
CH 3
CH 4
OUT
VAR
AUDIO
VIDEO
L/
MONO
AUDIO
R
OUT
OUT
IN
IN
OUT
The unauthorized recording, use,
distribution, or revision of television
programs, videotapes, DVDs, and other
materials is prohibited under the
Copyright Laws of the United States
and other countries, and may subject
you to civil and criminal liability.
Note:
Do not connect the same VCR to the output
and input jacks on the TV at the same time.
**
If you have S-VHS VCRs, use S-video cables
(in the S-video jacks) instead of regular video
*
cables. Do not connect both a regular video
cable and an S-video cable to Video-1 (or
Video-2) at the same time.
To dub or edit, VCR 2 must select Line IN,
and the TV must select Video-1.
The Audio OUT jacks can output the sound
*
of either the Main or PIP picture (see
“Selecting the Audio OUT sound” on page
45).
The Video OUT jack does not output the
**
PIP picture.
832/36AFX61(E)
Connecting a camcorder
This connection allows you to watch video materials recorded on a
camcorder.
You will need:
• one pair of audio cables
• one video cable (one S-video cable for an S-VHS camcorder)
Camcorder
VIDEO
AUDIO
OUT
L
R
TV
S-VIDEO
VIDEO-3 IN
AUDIO
VOLUMETV/VIDEOMENUDEMO
Note:
If you have an S-VHS camcorder, the picture
quality will increase if you use an S-video
cable (in the S-video jacks) instead of a
regular video cable.
Do not connect both a regular video cable
and an S-video cable to at the same time.
Introduction
your TV
Connecting
Using the
Remote Control
L/MONO R
VIDEO
Connecting an audio system
This connection allows you to use an audio amplifier to adjust the
audio level. This also allows you to use external speakers.
To control the audio, turn on the TV and the stereo amplifier, and
turn off the built-in speakers. (See“Turning off the built-in speakers”
on page 45.)
You will need:
• one pair of audio cables
Amplifier
LINE IN
LR
TV
STREAM
DVD IN
Y
C
C
OUT
RL
L
B
AUDIO
R
R
OUT
VAR
AUDIO
VIDEO
L/
MONO
AUDIO
R
)
ANT( 75
ANT-1OUTANT- 2
AUDIO CENTER
CHANNEL IN
ONOFF
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
COLOR
IN
Note:
To hear sound when using an external audio
amplifier, the volume of both the TV and
amplifier must be set above 0 (zero).
For example, if the volume of the TV is set
to 0, you will not be able to hear any sound,
even if the volume of the amplifier is at its
highest level.
your TV
Setting up
Features
Using the TV’s
Appendix
From Cable, Cable Box
or Antenna
Index
932/36AFX61(E)
Connecting an A/V receiver
This connection allows you to use an A/V (audio/video) receiver to
enhance your TV’s sound.
Introduction
your TV
Connecting
If you have a system with Dolby Pro Logic
add to the realism of the sound by using the TV speakers as center
channel speakers.
You will need:
®
surround sound, you can
• one pair of audio cables
• one single audio cable for the audio center channel
• one video cable
To A/V receiver
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
From Antenna
TV
ANT( 75
ANT-1OUTANT- 2
Dolby Pro Logic* surround sound system
Center
out
)
ONOFF
connection example
AudioVideo
VCR
Video
AUDIO CENTER
CHANNEL IN
ONOFF
TV
in
Audio
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 1 VIDEO 2
IN
LDP/DVD
Video
out
COLOR
STREAM
DVD IN
RL
Y
L
C
B
AUDIO
C
R
R
OUT
OUT
VAR
AUDIO
VIDEO
L/
MONO
AUDIO
R
Caution:
To avoid damaging the speakers, turn the TV
off before connecting or disconnecting the
Audio Center Channel cable.
Note:
Refer to the instructions provided with your
A/V receiver for details about your sound
system.
When the Audio Center Channel ON/OFF
switch is in the ON position, the TV speakers
will function only as center channel speakers.
To adjust the volume of the center channel
speakers, use the center level control on
the A/V receiver.
To use the TV speakers as normal speakers,
set the Audio Center Channel ON/OFF switch
to the OFF position.
Appendix
Index
1032/36AFX61(E)
A/V receiver
Audio
Video
Audio
center
channel
T V
Left
speaker
Surround
speaker L
*
Dolby Pro Logic is a registered trademark of Dolby Laboratories Licensing Corporation.
Right
speaker
Surround
speaker R
Using the remote control
AM/FM
DISC
Preparing the remote control for use
Your Toshiba TV remote control has one dedicated TV mode and five
universal modes: VCR, Cable/SAT, DVD, Audio1, and Audio2. The
target and default devices being programmed for each mode are as
follows:
ModeDefault device
TVToshiba TV
CABLE/SAT Toshiba Satellite receiver
VCRToshiba VCR
DVDToshiba DVD
AUDIO1Pioneer Audio receiver
AUDIO2Pioneer LD
Note:
Your TV remote control may not operate
certain features on your VCR, DVD player,
cable TV converter, or other electronic device.
Refer to the owner’s manuals for your other
devices to determine their available features.
If your TV remote control does not operate a
specific feature on another device, use the
remote control that came with the device.
MODE
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
Repeatedly press MODE to cycle among the modes. If you own
different brands of audio/video devices, you first have to program
your remote control (see “Programming the remote control for use
with your audio/video devices” on page 14).
Installing the remote control batteries
To install the batteries:
1. Slide the battery cover off the back of the remote control.
2. Install two “AA” size alkaline batteries. Match the + and - signs
on the batteries to the signs on the battery compartment.
3. Slide the battery cover back on the remote control until the lock
snaps.
Note:
• Battery life expectancy is about one year
with normal use.
Caution:
• Dispose of batteries in a designated
disposal area. Do not throw batteries into
a fire.
• Do not mix battery types or combine used
batteries with new ones.
• If the batteries are dead or you do not
intend to use the remote control for a long
time, remove the batteries to prevent
battery acid from leaking into the battery
compartment.
Features
Using the TV’s
Appendix
Index
1132/36AFX61(E)
Remote Control functional key chart
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
Appendix
Index
LIGHTIlluminates the remote. Toggles the Illumination mode on and off.
SLEEPSleep timer --------------------POWERPowerPowerPowerPowerPowerPowerPowerPower
1/MOVIEDigit 1Digit 1Digit 1Digit 1Digit 1AV input 1 Digit 1Digit 1
2/SPORTSDigit 2Digit 2Digit 2Digit 2Digit 2AV input 2 Digit 2Digit 2
3/NEWSDigit 3Digit 3Digit 3Digit 3Digit 3AV input 3 Digit 3Digit 3
4/SERVICESDigit 4Digit 4Digit 4Digit 4Digit 4AV input 4 Digit 4Digit 4
5/LISTDigit 5Digit 5Digit 5Digit 5Digit 5CDDigit 5Digit 5
6Digit 6Digit 6Digit 6Digit 6Digit 6TunerDigit 6Digit 6
MODEDevice mode selection for the remote control
PIC SIZEThis button is not available for this TV model or any other device connected to this TV.
7Digit 7Digit 7Digit 7Digit 7Digit 7PhonoDigit 7Digit 7
8Digit 8Digit 8Digit 8Digit 8Digit 8CassetteDigit 8Digit 8
9Digit 9Digit 9Digit 9Digit 9Digit 9AuxDigit 9Digit 9
ACTION---Menu
100/–100100100100100100100100
0Digit 0Digit 0Digit 0Digit 0Digit 0Digit 0Digit 0Digit 0
ENT---CH EnterCH EnterCH Enter-----------GUIDE/SETUP
INFO/TITLE TV preview TV INFO TV TITLE= TV TV TV
yzMenu select Menu select Menu select Menu select Menu select ---------
x •/FAV x •Menu select/ Menu select Menu select Menu select Menu select ---------
PIPPIP on/off TV TV TV TV TV TV TV
MULTIStrobe
STILLPIP Still TV TV TV TV TV TV TV
SWAPPIP Swap TV TV TV TV TV TV TV
LOCATEPIP Locate TV TV TV TV TV TV TV
SOURCEPIP Source TV TV TV TV TV TV TV
Notes:
•“---” will send nothing.
•“ TV” will jump to TV.
•“VCR ” will jump to last active VCR or DVD. Active VCR/DVD is defined as the mode that remains for a minimum of 5
*
yz
seconds, or if a key is pressed in that mode.
The VOLUME and MUTE will jump to “TV” by default. When the volume is unlocked, all the devices will have their own volume.
The AUDIO1/2 (Receiver, CD) modes will have their own volume even if Volume Lock is on TV, CABLE/SAT, VCR, or DVD. See
“Using the Volume Lock feature” on page 15.
PIP Channel TV TV TV TV TV TV TV
up/down
TV TV TV TV TV TV TV
Introduction
your TV
Connecting
Using the
Remote Control
your TV
Setting up
Features
Using the TV’s
Appendix
Index
1332/36AFX61(E)
Programming the remote control for use with
your audio/video devices
Introduction
Device code setup
your TV
Connecting
Using the
Remote Control
Searching and sampling the code of a device (991)
If you do not know the device code for a particular target unit, you
your TV
Setting up
can cycle the remote through the available codes for that device mode
and sample functions in order to find the code that properly operates
the desired target device. The keys available to be sampled, provided
they are applicable to that mode, are 0, 1, 2, 3, POWER, VOL y,
CH y, PLAY and STOP. Invalid keys will be ignored while in
program mode.
To cycle through each available device code and sample its functions:
Features
Using the TV’s
Appendix
1. Refer to the device code table on pages 16–19 to find the code for
the brand of your device.
If more than one code is listed, try each one separately until you
find one that works.
2. Repeatedly press MODE until the device mode indicator
(CABLE/SAT, VCR, DVD, AUDIO1, AUDIO2) lights up.
3. While holding down the RECALL button, press the Channel
Number buttons to enter the four-digit code for your device.
If a valid code is entered, the mode indicator will blink two times.
If an invalid code is entered, the mode indicator will blink one
long blink.
4. Point the remote control at the device and press POWER to test
the code.
If the device responds to the remote control, you have entered the
correct code.
If the device does not respond to the remote control, you may
have entered the wrong code. Repeat steps 3 and 4 using another
code.
5. To control the TV, repeatedly press MODE until the TV mode
indicator lights up.
1. Press MODE to select the mode you want to set up.
2. While holding down RECALL, press 9–9–1.
The remote control will enter program mode.
3. Point the remote control at the target device and press POWER
(or other function buttons that are available to be sampled).
4. If the device responds to the remote control:
Press RECALL to store the device code.
The mode indicator will blink two times and the remote
control will exit program mode.
If the device does not respond to the remote control:
Press y, and then press POWER.
Repeat this step until the device responds to the remote
control, and then press RECALL.
POWER
Channel
Numbers
MODE
y
RECALL
Note:
• Every time you replace the batteries, you
must reprogram the remote control.
• Some newer VCRs are capable of working
on either of two remote codes. These VCRs
have a switch labeled “VCR1/VCR2.” If
your VCR has this kind of switch and does
not respond to any of the codes for your
VCR brand, set the switch to the other
position (VCR1 or VCR2) and reprogram
the remote control.
Index
1432/36AFX61(E)
Note: When a search cycle is complete, the mode indicator will blink three
times. The remote control will begin to cycle through the available codes
again. If no key is pressed within 10 seconds while programming, the
remote control will exit the program mode and return to the previous
code.
Verifying the device code (990)
Use this feature to verify the codes for your other electronic devices.
The number of blinks after pressing the 1, 2, 3, and 4 buttons is the
4-digit code set up for that mode.
For example, to verify the device code of the VCR mode:
1. Repeatedly press MODE to select VCR mode.
2. While holding down RECALL, press 9–9–0.
3. Press 1 ➝ 2 blinks.
4. Press 2 ➝ 3 blinks.
5. Press 3 ➝ 4 blinks.
6. Press 4 ➝ 5 blinks.
This verifies that the device code of the VCR mode is “2345.”
Using the Volume Lock feature (993)
For the TV, CABLE/SAT, VCR, and DVD modes, the volume
controls (VOL yz and MUTE) can be programmed (locked) to the
selected device mode. This feature does not apply to the AUDIO1/2
modes.
For example, to lock the volume controls to always jump to the
CABLE/SAT mode:
1. Repeatedly press MODE to select the CABLE/SAT mode.
2. While holding down RECALL, press 9–9–3.
3. Press VOL y. The Mode indicator will blink two times (locked).
Introduction
Number
MODE
your TV
Connecting
VOL yz
RECALL
Using the
Remote Control
The following table describes in more detail the Volume Lock
implementation.
