Toshiba

Welcome to

your TV

Connecting

Using the

Remote Control

Color Television

27AF41 / 32AF41 / 36AF41

your TV

Setting up

Features

Using the TV’s

Appendix

© 2001 TOSHIBA CORPORATION
All Rights Reserved.

Owner’s Manual

©

SAFETY PRECAUTIONS

WARNI NG
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

IMPORTANT SAFETY
INSTRUCTIONS

INSTRUCCIONES DE

ADVERTENCIA RIESGO DE

DESCARGA ELÉCTRICIA - NO ABRIR

The lightning symbol in the triangle tells you that the
voltage inside this product may be strong enough to
cause an electric shock. DO NOT TRY TO SERVICE
THIS PRODUCT YOURSELF.

The exclamation mark in the triangle tells you that
important operating and maintenance instructions
follow this symbol.

CAUTIONS

TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS
POLARIZED PLUG WITH AN EXTENSION CORD RECEP­TACLE OR OTHER OUTLET UNLESS THE PRONGS CAN BE
FULLY INSERTED INTO THE OUTLET TO PREVENT ANY
EXPOSURE OF THE PRONGS ON THE POLARIZED PLUG.

PRECAUCIONES

PARA EVITAR DESCARGAS ELÉCTRICAS, NO UTILICE ESTE
ENCHUFE POLARIZADO CON UN RECEPTÁCULO DE
CABLE DE EXTENSIÓN U OTRA TOMA SALVO QUE LA
CLAVIJA ESTÉ COMPLETAMENTE INSERTADA EN LA
TOMA PARA EVITAR CUALQUIER EXPOSICIÓN DE LOS
VÁSTAGOS DEL ENCHUFE POLARIZADO.

WARNI NG

To avoid personal injury:

• Do not stand or climb on the TV.

• Do not put a VCR or any heavy object on top of the TV.

ADVERTENCIA

Para evitar daños personales:

• No se ponga de pie en el TV ni suba a él.

• No coloque el vídeo (p. ej. VCR) ni otro objeto pesado en la parte
superior del TV.

Avoid displaying stationary images on your TV screen for extended
periods of time. Stationary patterns generated by a picture-in-picture
(PIP) display, computer displays, video games, stock market reports,
etc., can become permanently engrained on the picture tube. This
damage is not protected by your warranty because it is the result of
misuse. If you wish to use your TV to display still images, reduce
brightness and contrast settings. Never leave a PIP, computer, or video
game display unattended.

Use this TV set with the Toshiba stand listed

on page 36 only. Use with other stands may result in

instability, causing possible injury or death.

Note to CATV system installers in the USA

This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC, which provides guidelines
for proper grounding, and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building,
as close to the point of cable entry as practical.

SEGURIDAD

CAUTION

PLEASE READ AND OBSERVE ALL WARNINGS AND
INSTRUCTIONS CONTAINED IN THIS SECTION AND
THOSE ON YOUR TV SET.

RETAIN THIS SECTION FOR REFERENCE.

PRECAUCIÓN

LEA Y TENGA EN CUENTA TODAS LAS ADVERTENCIAS E
INSTRUCCIONES QUE SE ENCUENTRAN EN ESTE
PANFLETO Y LAS DE LOS APARATOS DE TELEVISIÓN.

MANTENGA ESTE PANFLETO PARA FUTURAS
REFERENCIAS.

Electrical energy can perform many useful functions. This TV set has
been engineered and manufactured to assure your personal safety.
However, improper use can result in potential electrical shock or fire
hazards. In order not to defeat the safeguards incorporated in this TV
set, observe the following basic rules for antenna/TV installation, use
and servicing.

Do not remove the cabinet cover. This may expose you to dangerous
voltages. Refer all servicing to qualified service personnel.

La energía eléctrica puede realizar funciones muy útiles. Este televisor
ha sido diseñado y fabricado para asegurar su seguridad personal. Sin
embargo, la utilización inadecuada del mismo puede resultar en
descargas eléctricas o en el riesgo de incendios. Para no anular las
protecciones incorporadas en este televisor, tenga en cuenta las reglas
básicas de instalación de la antena/televisor, y en caso de proplemas
póngase en contacto con un centro de reparaciones.

No extraiga de la cubierta de la caja. Esto podría dejarle expuesto a
tensiones peligrosas. En caso de averia, consulte los servicios de
personal cualificado.

INSTALLATION / INSTALACIÓN

Power Sources — The TV set should be operated only from the type of
power source indicated on the TV set or as indicated in the Owner’s
Manual. If you are not sure of the type of power supply in your home,
consult your sales person or your local power company. For TV sets
designed to operate from battery power, refer to the operating
instructions.

Fuentes de alimentación — Este televisor solamente deberá alimentarse
con la fuente de alimentación indicada en la etiqueta de características.
Si no está seguro del tipo de fuente de alimentación de su hogar,
consulte al proveedor de su televisor o a la compañia eléctrica local.
Para productos destinados a alimentarse con pilas, u otras fuentes,
consulte las instrucciones de operación.

Grounding or Polarization — The TV set is equipped with one of the
following type plugs. If the plug should fail to fit the power outlet,
contact your electrician to replace your obsolete outlet. DO NOT
defeat the safety purpose of the type plug on the TV set.

Puesta a tierra o polarización — Este televisor puede poseer un enchufe
de los tipos siguinetes. Si el enchufe no entra en la toma de la red, póngase
en contacto con un electricista para que le cambie la toma anticuada. NO
anule el fin de seguirdad de sete tipo de enchufe del televisor.

27/32/36AF41(E)

2

A polarized alternating current line plug — having one blade wider
than the other. This plug will fit into the power outlet only one way. If
you are unable to insert the plug into the outlet, try reversing the plug.

Un enchufe de línea de corriente alterna polarizado — posee una
cuchilla más ancha que la otra. Este enchufe entrará en la toma de la
red de una sola forma. Si no puede inertar el enchufe en la toma de la
red, trate de invertirlo.

Alternate Warnings — A three-wire grounding-type plug — a plug
having a third (grounding) pin. This plug will only fit into grounding­type power outlet.

Advertencias alternativas — Enchufe de tippo puesta a tierra de tres
conductores — enchufe que posee un tercer terminal (de puesta a
tierra). Este enchufe solamente encajará en una toma de la red de tipo
puesta a tierra.

Water and Moisture — Do not use the TV set near water — for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.

Agua y humedad — No utilice el televisor cerca del agua — por
ejemplo, cerca de una bañera, un lavabo, un fregadero, una lavadora, en
un sótano húmedo, cerca de una piscina, ni lugares por el estilo.

Ventilation — The slots and openings in the cabinet and in the back or
bottom are provided for necessary ventilation. Never block or cover
these slots and openings to ensure reliable operation of the TV set and
to protect it from overheating.

Ventilación — Las ranuras y aberturas de la caja y de la parte posterior
o de la base son para proporcionar la ventilación necesaria. Para
asegurar la operación fiable del televisor para protegerlo contra el
recalentamiento. No bloquee ni cubra nunca estas ranuras y aberturas.

a. Never cover the slots and openings with a cloth or other materials.
a. No cubra nunca las ranuras ni las aberturas con paños ni otros

materiales.

b. Never block the slots and openings by placing the TV set on a bed,

sofa, rug or other similar surface.

b. No bloquee nunca las ranuras ni las aberturas colocando el televisor

sobre una cama, un sofá, una alfombra, ni demás superficies similares.

c. Never place the TV set in a confined space such as a bookcase, built-

in cabinet, or any other place of poor ventilation.

c. No coloque nunca el televisor en un espacio cubierto, como una

librería o un estante empotrados, nien un lugar de mala ventilación.

Heat — Do not place the TV set near or over a radiator or heat
register, or where it is exposed to direct sunlight.

Calor — No coloque el televisor cerca ni sobre un radiador ni un
registro de calor, ni expuesto a la luz solar directa.

Power-Cord Protection — Do not allow anything to rest on or roll
over the power cord, and do not place the TV set where the power cord
is subject to wear or abuse.

Protección del cable de alimentación — No coloque ni pase sobre el
cable de alimentación, ni coloque el telivisor donde su cable de
alimentación pueda sufir cualquier tipo de daños.

Accessories — Do not place the TV set on an unstable cart, stand,
tripod, bracket, or table. The TV set may fall, causing serious injury to
a child or adult, and serious damage to the TV set. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or
sold with the TV set, and should use a mounting accessory recom­mended by the manufacturer.

Accesorios — No coloque el televisor sobre un carrito, una base, un
trípode, un soporte ni una mesea inestable. El televisor podría caerse,
causando serios daños a niños o adultos, o al propio televisor. Utilice
solamente el carrito, la base, el trípode, el soporte, o la mesa que
recomiende el fabricante, o que se venda con el televisor, y utilice un
accesorio de montaje recomendado por el fabricante.

A product and cart combination
should be moved with care. Quick
stops, excessive force, and uneven
surfaces may cause the product
and cart combination to overturn.

La combinación de un producto y
un carrito deberá moverse con
cuidado. Las paradas repentinas,
la fuerza excesiva, y las superficies
desiguales pondrían hacer que
volcase la combinación del carrito
y del producto.

USE / UTILIZACIÓN

Overloading — Do not overload wall outlets, extension cords or
convenience receptacles beyond their capacity, since this can result in
fire or electric shock.

Sobrecarga — No sobrecargue las tomas de la red, los cables
prolongadores, ni los adaptadores para múltiples tomas, ya que esto
supondría el riesgo de incendios o de descargas eléctricas.

During lightning storms, or when the TV set will be left unattended
and unused for a long period of time, unplug the power cord from the
wall outlet and disconnect the antenna or cable system. This will
prevent damage to the TV set due to lightning and power-line surges.

Durante tormentas eléctricas, o cuando no vaya a utilizar el televisor
durante mucho tiempo, desenchufe el cable de alimentación de la toma
de la red y desconecte la antena o el sistema de cablevisión. Esto evitará
que se dañe el televisor debido a rayos y a sobretensiones repentinas en
la red.

Object and Liquid Entry — Never push objects of any kind into the
TV set through the cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the TV set.

Entrada de objetos y líquidos — No introduzca nunca objetos de
ningún tipo en este televisor a través de las aberturas, ya que podrían
tocar puntos de tensión peligrosa o cortocircuitar piezas, lo que podría
resultar en incendio o descarga eléctrica. No vierta nunca liquidos de
ningún tipo sobre este televisor.

Cleaning — Unplug the TV set from the wall outlet before cleaning or
polishing it. Do not use liquid cleaners or aerosol cleaners. Use a cloth
lightly dampened with water for cleaning the exterior of the TV set.

Limpieza — Desenchufe el televisor de la toma de la red antes de
limpiarlo. No utilice limpiadores líquidos ni aerosoles. Para limpiar el
exterior del televisor, utilice un paño ligeramente humedecido en agua.

Attachments — Never add accessories that have not been specifically
designed for the TV set. Never remodel the TV set by yourself as this
can result in a fire hazard or electric shock.

Aditamentos — No utilice aditamentos no recomendados por el
fabricante del televisor, ya que podrían suponer un peligro. No
remodele nunca el televisor usted mismo, ya que esto podría causar el
riesgo de incendios o descargas eléctricas.

If a snapping or popping sound from a TV set is heard continuously or
frequently while the TV set is operated, unplug the TV set and consult
your dealer or service technician. It is normal for some TV sets to make
occasional snapping or popping sounds, particularly when being turned
on or off.

Si se oye un sonido seco de un televisor continuo o frecuente mientras
el televisor esté funcionando, desenchúfelo y consulte a su proveedor o
a un técnico de servicio. Es normal que algunos televisores produzcan
sonidos secos, particularmente cuando conecte o desconecte su
alimentación.

3

27/32/36AF41(E)

SERVICE / SERVICIO DE REPARACIÓN

Damage Requiring Service — Unplug the TV set from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:

Daños que requieren el servicio de reparación — En los casos
siguientes, desenchufe el televisor de la toma de la red y solicite los
servicios de personal de reparación especializado:

a. When the power cord or plug is damaged or frayed.
a. Cuando se haya dañado el cable de alimentación o el enchufe.
b. When liquid has been spilled into the TV set.

b. Cuando se haya vertido líquido dentro del televisor.

c. When the TV set has been exposed to rain or water.

c. Cuando el televisor haya estado expuesto a la lluvia o al agua.

d. When the TV set has been subject to excessive shock by being

dropped, or the cabinet has been damaged.

d. Cuando el televisor haya estado expuesto a golpes excesivos o haya

caído, o su caja se haya dañado.

e. When the TV set does not operate normally even though you follow

the operating instructions. Adjust only those controls that are
specified in the operating instructions. Improper adjustment of
other controls may result in damage and will often require extensive
work by a qualified technician to restore the TV set to normal
operation.

When the TV set exhibits a distinct change in performance. This
indicates a need for service.

e. Cuando el televisor no funcione normalmente incluso al seguir las

instrucciones de operación. Ajuste solamente los controles indicados
en las instrucciones de operación, ya que un ajuste inadecuado de
otros controles podría resultar en daños y a menudo requerirán un
trabajo difícil por un técnico cualificado para devolver el televisor a
su funcionamiento normal.

Cuando el funcionamiento del televisor haya cambiado
notablemente — esto indica la necesidad del servicio de reparación.

Servicing — Do not attempt to service the TV set yourself. To open or
remove the covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.

Reparación — No intente nunca reparar el televisor por sí mismo. La
apertura o extracción de cubiertas podría exponerle a tensiones
peligrosas u otros peligros. En caso de avería solicite los servicios de
personal de reparación cualificado.

Replacement Parts — When replacement parts are required, be sure
the service technician certifies in writing that he has used replacement
parts specified by the manufacturer that have the same characteristics as
the original parts. Unauthorized substitutions may result in fire, electric
shock, or other hazards.

Reemplazo de piezas — Cuando sea necesario reemplazar piezas,
cerciórese de que el técnico de reparación utilice las piezas de reemplazo
especificadas por el fabricante u otras que posean las mismas
características que las originales. Las substituciones no autorizadas
podrían resultar en incendios, descargas eléctricas, u otros peligros.

Safety Check — Upon completion of any service or repairs to the TV
set, ask the service technician to perform routine safety checks (as
specified by the manufacturer) to determine that the TV set is in safe
operating condition, and to so certify.

Comprobación de seguridad — Al finalizar cualquier reparación de
este televisor, solicite al técnico de reparación que realice las
comprobaciones de sguridad (especificadas por el fabricante) para
determinar y certificar si el producto se encuentra en las condiciones de
operación apropiadas.

When the TV set reaches the end of its useful life, improper disposal
could result in a picture tube implosion. Ask a qualified service
technician to dispose of the TV set.

Cuando el televisor llegue al final de su vida útil, si se deshace de él de
forma inapropiada, el tubo de imagen puede explotar. Cuando desee
deshacerse de un televisor, solicite este servicio a un técnico de
reparación especializado.

ANTENNA / ANTENA

Outdoor Antenna Grounding — If an outdoor antenna is installed,
follow the precautions below.

An outdoor antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where
it can come in contact with such power lines or circuits.

WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS
CONTACT WITH THEM IS ALMOST INVARIABLY FATAL.

Be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code in the USA and Section 54 of the
Canadian Electrical Code in Canada provides information with respect
to proper grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.

Puesta a tierra de la antena exterior — Cuando instale una antena
exterior, tenga en cuenta las precauciones siguientes.

Un sistema de antena esterior no deberá colocarse cerca de líneas de alta
tensión ni otros circuitos de iluminación o alimentación, ni donde
pueda entrar en contacto con tales líneas o circuitos.

CUANDO INSTALE UN SISTEMA DE ANTENA EXTERIOR,
TENGA EXTREMADO CUIDADO PARA EVITAR QUE ENTRE
EN CONTACTO CON TALES LÍNEAS DE ALIMENTACIÓN O
CIRCUITOS, YA QUE TAL CONTACTO PODRÍA RESULTAR
INVARIABLEMENTE FATAL.

Cerciórese de que el sistema de antena esté puesto a tierra a fin de que
proporcione cierta protección contra sobretensiones y cargas estáticas.
La Sección 810 del Código Eléctrico Nacional (NEC) de EE.UU. y la
Sección 54 del Código Eléctrico Canadiense ofrecen informacón con
respecto a la puesta a tierra adecuada de una unidad de descarga de
antena, el tamaño de los conductores de puesta a tierra, la ubicación de
la unidad de descarga de la antena, la conexión de los electrodos de
puesta a tierra, y los requisitos de tales electrodos.

27/32/36AF41(E)

4

Welcome to Toshiba ............................................ 6

Exploring your new TV .............................................6

Selecting a location for the TV................................... 6

Notice of possible TV stand instability .................. 6

Connecting your TV ............................................. 7

Note regarding picture quality .............................. 7

Connecting a VCR .................................................... 7

Connecting a cable converter box .............................. 8

Connecting a cable converter box and VCR............... 8

Connecting a DVD player or satellite receiver

and a VCR ................................................................. 9

Connecting a DVD player with ColorStream™

(component video) and a VCR ................................10

Connecting two VCRs ............................................. 10

Connecting a camcorder ..........................................11

Connecting an audio amplifier................................. 11

Using the remote control ................................. 12

Preparing the remote control for use ........................12

Installing the remote control batteries ......................12

Using the remote control with a Toshiba VCR or

cable TV converter ...................................................12

Programming the remote control for use with

a non-Toshiba VCR or cable TV converter .............. 13

VCR code table...................................................13

Cable TV converter code table ............................14

Learning about the remote control ........................... 15

Setting up your TV ............................................. 16

Changing the on-screen display language .................16

Selecting the signal source ........................................17

Programming channels into the TV’s memory .........17

Programming channels automatically.................. 17

Adding and erasing channels manually................ 18

Changing channels...................................................18

Image tilt correction.................................................18

Using the TV’s features..................................... 19

Adjusting the channel settings.................................. 19

Switching between two channels ..............................19

Programming your favorite channels........................ 19

Using the V-Chip Control (blocking) feature ...........20

Selecting a PIN code ...........................................20

Changing your PIN code ....................................21

Blocking programs by ratings .............................. 22

Ratings definitions (MPAA, Youth TV, TV)........ 22

Unblocking programs temporarily ...................... 23

Blocking unrated movies and programs...............23

Blocking channels ...............................................24

Locking video inputs ............................................... 25

Channel labels ......................................................... 26

Video labels ............................................................. 27

Adjusting the picture ............................................... 28

Adjusting the picture quality ............................... 28

Selecting the color temperature ...........................28

Adjusting the picture preference..........................29

Displaying on-screen information ............................29

Setting the off timer .................................................29

Auto power off......................................................... 29

Using the closed caption feature...............................30

Adjusting the sound .................................................31

Muting the sound ...............................................31

Selecting stereo/SAP broadcasts .......................... 31

Adjusting the sound quality ................................32

Using the surround sound feature .......................32

Selecting variable audio OUT .............................33

Turning off the built-in speakers .........................33

Using the sub-bass system (SBS) .........................34

Viewing the demonstration (DEMO) mode ............ 34

Understanding the last mode memory feature .......... 34

Appendix .............................................................. 35

Troubleshooting .......................................................35

Cleaning and care .................................................... 36

Specifications ...........................................................36

Limited United States warranty................................37

Attention Canadian customers .................................37

5

27/32/36AF41(E)

Toshiba

wide prong

Welcome to

Welcome to Toshiba

Congratulations! You have purchased one of the finest color TVs on
the market. The goal of this manual is to guide you through setting
up and operating your Toshiba TV as quickly as possible. Please make
sure you have received the following items: TV, remote control,
batteries, owner’s manual, registration card, and extended service plan
literature. If you did not receive all of the items or if any of the items
are damaged or broken, please contact your Toshiba dealer. In
addition, you may need to purchase other audio or video cables to

your TV

Connecting

connect your equipment. See “Connecting your TV” on page 7 for
more information.

Please read all safety and operating instructions carefully before you
proceed.

Exploring your new TV

You can operate your TV using the buttons on the front panel or the
remote control. The back panel provides all the terminal connections
you will need to connect other equipment to your TV.

Using the

Remote Control

36AF61

36AF41 – Front

Demo

TV/Video

Volume

Channel

Note:

This manual applies
to models 27AF41,
32AF41, and
36AF41, and there
are slight differences
among them. Check
the model of your
TV before using this
manual. Model
36AF41 is used for
illustration purposes.
Instructions in this
manual are based
on using the remote
control.

POWER

RECALL MUTE

o

1

4

5

8

7

100

0

CH

MENU/

VOL VOL

ENTER

CH

TV
CABLE
VCR

EXIT

TV/VCR

REC

SLOW

PIP CH LOCATE SWAP

CT-90037

POWER

3

2

6

9

CH RTN

ENT

TV/VIDEOFAV CH

A

PLAY

STOP

PIP

SOURCESTILL

REWPAUSE

FF

Setting up

Using the TV’s

Appendix

your TV

Features

DEMO MENU TV/VIDEO VOLUME CHANNEL

R

Menu

ANT (75Ω)

ANT-1

DVD IN

COLOR
STREAM

Y

INPUT

Pb

L

AUDIO

Pr

R

Video 2

IN

VIDEO 1VIDEO 2

Video 1

S-VIDEO

VIDEO

L/MONO

AUDIO

R

DEMO MENU TV/VIDEO VOLUME CHANNEL

VIDEO

R
L/MONO
AUDIO

VIDEO-3 IN

36AF41 – Rear

ANT (75Ω)

ANT-1

IN

OUT

DVD IN

S-VIDEO
COLOR
STREAM

Y

INPUT

VIDEO

VIDEO

Pb

L/MONO

L/MONO

L

AUDIO

AUDIO

AUDIO

Pr

R

R

R

VIDEO 1VIDEO 2

VIDEO

L/MONO

AUDIO

POWER

VIDEO-3 IN

Video 3

(behind door)

OUT

VIDEO

L/MONO

AUDIO

R

ColorStream

(component video)

Selecting a location for the TV

• Place the TV on the floor or on the recommended TV stand (see
“Notice of Possible TV Stand Instability” at right).

• Place the TV in a location where light does not directly hit the

screen.

• Place the TV far enough from the walls to allow proper ventilation.
Inadequate ventilation may cause overheating, which may damage
the TV.

The serial number is on the back of your TV. Record the number in
the space below. Refer to the model and serial numbers whenever you
communicate with your Toshiba dealer about this TV.

Model number: ________________________
Serial number: ________________________

POWER

Note:

Model 27AF41 does not have
a DEMO button on the front

Remote Sensor

panel (see “Viewing the
demonstration mode” on
page 34).

Caution:

The plug has one prong wider than the other
and will fit only one way into a standard
electrical outlet (120 volt AC, 60 Hz). If the
plug does not fit into the outlet, try turning it
around. If the
plug still does
not fit, the
outlet is
probably non­standard and
must be
replaced by a qualified electrician. Do not

tamper with the plug or try to force it
into a non-standard outlet.

NOTICE OF POSSIBLE

TV STAND INSTABILITY

WARNING: RISK OF
SERIOUS PERSONAL
INJURY OR DEATH!

TV stand recommended below only!
Use with other

stands may result
in instability,
causing possible
injury or death.

Use this TV with the Toshiba

TV Model TV Stand

27AF41 None
32AF41 ST3261
36AF41 ST3661

27/32/36AF41(E)

6

Connecting your TV

If you have not connected electronic equipment before, or you have
been frustrated in the past, you may wish to read this section.

Note: Cables are not supplied.

• A coaxial cable is the standard cable that comes in from your

antenna or cable converter box. Coaxial cables use “F” connectors.

• Audio and video cables are usually color coded according to use:

yellow for video; red and white for audio. The red audio cable is for
the stereo right channel; the white audio cable is for the stereo (or
mono) left channel. If you look at the rear panel of the TV, you will
see that the terminals are color coded in the same manner as the
cables.

• S-video cables provide better picture performance than standard

video cables. S-video cables can be used only with S-video compat­ible components.

• ColorStream

A ColorStream (component video) connection will provide the best
picture performance.

Cable Types

TM

(component video) cables come in sets of three.

Regular

Video Cable

NOTE REGARDING
PICTURE QUALITY

When connecting video equipment,
such as a VCR or DVD player:

• For GOOD picture quality: Use

regular video cables.

• For BETTER picture quality: If your

equipment has S-video connections,
use S-video cables instead of regular
video cables.

• For BEST picture quality: If your

equipment has ColorStream
(component video) connections,
use component video cables
instead of regular or S-video cables.
Component video cables come in
sets of three.

Note: Do not connect a regular video
cable and an S-Video cable to VIDEO-1
(or VIDEO-2) at the same time. Doing
so will distort the picture.

Toshiba

Welcome to

your TV

Connecting

Using the

Remote Control

Coaxial

(Antenna)

Cable

Audio
Cable

S-Video

Cable

ColorStream
(Component
Video) Cables

Connecting a VCR

This connection allows you to watch local channels and video pro­grams, play or record on the VCR while watching TV, and record
from one channel while watching another channel.

You will need:

• one coaxial cable

• one pair of audio cables (one single audio cable for a mono VCR)

• one video cable

TV

From Cable or Antenna

ANT (75Ω)

ANT-1

OUT

VIDEO

L/MONO

AUDIO

R

L

AUDIO

R

DVD IN

COLOR
STREAM
INPUT

IN

S-VIDEO

Y

Pb

Pr

VIDEO

L/MONO

AUDIO

R

VIDEO 1VIDEO 2

Caution:

Do not plug in any power cords until you have
finished connecting all of your equipment.

Note:

If you have a mono VCR, connect L/Mono to
VCR Audio OUT using only one audio cable.

If you have an S-VHS VCR, use an S-video
cable instead of a regular video cable.

Do not connect a regular video cable and an
S-video cable to Video-1 (or Video-2) at the
same time. Doing so will distort the picture.

your TV

Setting up

Features

Using the TV’s

Appendix

Stereo VCR

VIDEO AUDIO

LR

IN

OUT

IN from ANT

OUT to TV

CH 3
CH 4

7

27/32/36AF41(E)

Connecting a cable converter box

This connection allows you to watch basic and premium cable
channels. To view premium channels, tune the TV to channel 3 or 4
(whichever channel is vacant in your area), and use the converter box
to change channels.

You will need:

• one coaxial cable

Note:

When you use a converter box with your TV,
the remote control may not operate certain
features, such as channel y z, channel
block, favorite channels, or channel labels.

your TV

Connecting

Connecting a cable converter box and VCR

This connection allows you to watch and record basic and premium
cable channels, as well as watch videotapes. Set the TV signal source
to Video 1 (see “Selecting the signal source” on page 17). Tune the
VCR to channel 3 or 4 (the same channel as the converter box output
switch), and use the cable converter box to change channels.

You will need:

Stereo VCR

TV

VIDEO

L/MONO

AUDIO

R

OUT

ANT (75Ω)

ANT-1

L

AUDIO

R

DVD IN

COLOR
STREAM
INPUT

Y

Pb

Pr

From Cable

IN

S-VIDEO

VIDEO

L/MONO

AUDIO

R

VIDEO 1VIDEO 2

IN

OUT

Cable Converter Box

• one coaxial cable

• one pair of audio cables (one single audio cable for a mono VCR)

• one video cable

TV

ANT (75Ω)

OUT

VIDEO

L/MONO

AUDIO

R

VIDEO AUDIO

ANT-1

DVD IN

COLOR
STREAM
INPUT

L

AUDIO

R

LR

Y

Pb

Pr

IN

OUT

IN from ANT

IN

VIDEO 1VIDEO 2

S-VIDEO

VIDEO

L/MONO

AUDIO

R

OUT to TV

CH 3
CH 4

From Cable

IN

OUT

Cable
Converter Box

Note:

When you use a converter box with your
TV, the remote control may not operate
certain features, such as channel y z,
channel block, favorite channels, or
channel labels.

If you have a mono VCR, connect
L/Mono to VCR Audio OUT using only
one audio cable.

If you have an S-VHS VCR, use an
S-video cable instead of a regular video
cable.

Do not connect a regular video cable
and an S-video cable to Video-1 (or
Video-2) at the same time.

27/32/36AF41(E)

8

Connecting a DVD player or satellite receiver
and a VCR

This connection allows you to watch DVD/satellite, VCR, or TV
programs. You can record from the DVD player/satellite receiver or
TV. You can also record one TV channel while watching another
channel.

Note: If your DVD player has component video connections, follow
the connection instructions under “Connecting a DVD player with
ColorStream

You will need:

• one coaxial cable

• three pairs of audio cables (one pair and two single audio cables

for a mono VCR)

• two regular video cables

• one S-video cable

™

(component video) and a VCR” on page 10.

Toshiba

Welcome to

your TV

Connecting

DVD / Satellite Receiver

AUDIO

OUT

L

VIDEO

OUT

R

TV

Stereo VCR

OUT

ANT (75Ω)

ANT-1

OUT

VIDEO

L/MONO

AUDIO

R

VIDEO AUDIO

IN

To Satellite

DVD IN

COLOR
STREAM
INPUT

Pb

L

AUDIO

Pr

R

LR

Note:

Satellite IN

S VIDEO

You can use a regular video cable instead of
an S-video cable between the TV and DVD
player/satellite receiver, but the picture quality
will decrease.

Using the

Remote Control

The illustration at left shows one S-video
cable and one pair of audio cables connected
from the DVD player/satellite receiver to
Video-1 on the TV.

Do not connect a regular video cable and an

IN

S-VIDEO

Y

VIDEO

L/MONO

AUDIO

R

VIDEO 1VIDEO 2

To Antenna

S-video cable to Video-1 (or Video-2) at the
same time. Doing so will distort the picture.

When recording, set Audio Out to FIX
(see “Selecting variable audio OUT”
on page 33). With Audio Out set to
FIX, the TV’s volume setting during
recording will not affect the sound

your TV

Setting up

level being recorded.

IN from ANT

OUT to TV

CH 3
CH 4

Features

Using the TV’s

Appendix

9

27/32/36AF41(E)

Connecting a DVD player with
ColorStream™ (component video) and
a VCR

This connection allows you to watch DVD, VCR, or
TV programs, and record DVD or TV programs
(when authorized). You can record from one source
while watching a program from another source.

Your TV has ColorStream (component video) connec-

your TV

Connecting

tions. Connecting your TV to a component video
compatible DVD player (such as a Toshiba DVD
player with ColorStream
picture quality and performance.

You will need:

Note:

For the best picture performance, use ColorStream
(component video) cables between the TV and DVD
player. To record from the DVD player, the DVD player
and TV must select VIDEO 1.

™

) can greatly enhance

• one coaxial cable

• three pairs of audio cables (one pair and two

single audio cables for a mono VCR)

• two regular video cables

• one set of ColorStream (component) video cables

DVD Player with ColorStreamTM (component video)

AUDIO

OUT

VIDEO

OUT

Stereo VCR

LRL

TV

R

OUT

VIDEO

L/MONO

AUDIO

R

YPb Pr

ANT (75Ω)

ANT-1

AUDIO

VIDEO AUDIO

ColorStream

(Component Video)

DVD IN

COLOR
STREAM

Y

INPUT

Pb

L

Pr

R

LR

TM

IN

OUT

S VIDEO

IN

S-VIDEO

VIDEO

L/MONO

AUDIO

R

VIDEO 1VIDEO 2

IN from ANT OUT to TV

CH 3
CH 4

To Antenna

Connecting two VCRs

This connection allows you to record from one VCR to another VCR
while watching a video program. You can also record from one TV
channel while watching another channel.

You will need:

• one coaxial cable

• two pairs of audio cables (two single audio cables for mono VCRs)

• two video cables

Stereo VCR [Playback]

Stereo VCR
[Recording]

VIDEO AUDIO

TV

OUT

VIDEO

L/MONO

AUDIO

R

VIDEO AUDIO

ANT (75Ω)

ANT-1

L

AUDIO

R

LR

DVD IN

COLOR
STREAM

Y

INPUT

Pb

Pr

LR

OUT

OUT

IN

IN

IN from ANT

VIDEO 1VIDEO 2

IN from ANT

IN

OUT to TV

CH 3
CH 4

S-VIDEO

VIDEO

L/MONO

AUDIO

R

OUT to TV

CH 3
CH 4

To Antenna

Note:

When recording, set Audio Out to
FIX (see “Selecting variable audio
OUT” on page 33). With Audio Out
set to FIX, the TV’s volume setting
during recording will not affect the
sound level being recorded.

Caution:
The unauthorized recording of

television programs, videotapes,
DVDs, and other materials may
infringe upon the provisions of
copyright laws.

Note:

If you have S-VHS VCRs, use S-video cables
instead of regular video cables.

Do not connect a regular video cable and an
S-video cable to Video-1 (or Video-2) at the
same time.

Do not connect the same VCR to the output
and input jacks on the TV at the same time.

27/32/36AF41(E)

10

Connecting a camcorder

This connection allows you to watch videos recorded on a camcorder.

You will need:

• one pair of audio cables

• one video cable

Note:

If your camcorder has an S-video connection,
an S-video cable will provide better picture
performance than a regular video cable.

Do not connect a regular video cable and an
S-video cable to Video-1 (or Video-2) at the
same time.

Toshiba

Welcome to

S-VHS Camcorder

TV Back

OUT

VIDEO

L/MONO

AUDIO

R

ANT (75Ω)

ANT-1

AUDIO

DVD IN

COLOR
STREAM
INPUT

L

R

S-VIDEO

Y

Pb

Pr

AUDIOVIDEO

OUT

L

R

IN

S-VIDEO

VIDEO

L/MONO

AUDIO

R

VIDEO 1VIDEO 2

Camcorder

TV Front

Connecting an audio amplifier

This connection allows you to use an audio amplifier to adjust the
audio level. This connection also allows you to use external speakers.

You will need:

• one pair of audio cables

To Cable, Cable Box,

Audio Amplifier

or Antenna

AUDIO

LR

OUT

IN

AUDIOVIDEO

OUT

L

R

VIDEO L/MONO R

AUDIO

VIDEO-3 IN

Note:

To control the audio, both the TV and the
amplifier must be turned on, and the volume
of both must be set above 0, or you will not
hear any sound. See “Selecting variable audio
OUT” on page 33 for additional details.

your TV

Connecting

Using the

Remote Control

your TV

Setting up

Features

Using the TV’s

TV

ANT (75Ω)

ANT-1

OUT DVD IN

VIDEO

L/MONO

AUDIO

AUDIO

R

COLOR
STREAM
INPUT

L

R

IN

S-VIDEO

Y

Pb

Pr

VIDEO

L/MONO

AUDIO

R

VIDEO 1VIDEO 2

11

27/32/36AF41(E)

Appendix

Using the

Remote Control

Using the remote control

Preparing the remote control for use

The remote control will operate your TV, most VCR models, and
most cable TV converters together, even if they are different brands.

• If you will be using your TV with a Toshiba VCR or cable TV
converter, your remote control is already programmed and ready
to use. See “Using the remote control with a Toshiba VCR or
cable TV converter” below.

• If you own a non-Toshiba VCR or converter and want to use your
TV remote control to operate it, you will need to program the
remote control. See “Programming the remote control for use
with a non-Toshiba VCR or cable TV converter” on page 13.

Installing the remote control batteries

To install the batteries:

1. Slide the battery cover off the back of the remote control.

Note:

The remote control provided with your TV
may or may not operate certain features on
your VCR, cable TV converter, or other
electronic equipment. Refer to the owner’s
manuals provided with your other equipment
to see which features are available. In
addition, the other remote controls may have
buttons not available on your TV’s remote
control. If you would like to use those features
or buttons, you may need to use the original
remote controls provided with your other
equipment.

Caution:

• Dispose of batteries in a designated
disposal area. Do not throw batteries
into a fire.

• Do not mix battery types or combine used
batteries with new ones.

• Remove dead batteries immediately to
prevent battery acid from leaking into the
battery compartment.

• If you do not intend to use the remote
control for a long time, remove the
batteries.

2. Install two “AA” size batteries. Match the + and – symbols on
the batteries to the symbols on the battery compartment.

3. Slide the battery cover back onto the remote control until the
lock snaps.

Using the remote control with a Toshiba VCR
or cable TV converter

To control a Toshiba VCR:

Set the TV/CABLE/VCR switch to the VCR position. The
shaded buttons in the illustration at right will then control the
VCR. The unshaded buttons will operate the TV as usual.

To control a Toshiba cable TV converter:

Set the TV/CABLE/VCR switch to the CABLE position. The
shaded buttons in the top portion of the illustration at right will
then control the cable TV converter.

RECALL MUTE

o

1

2

4

5

8

7

100

0

CH

MENU/

VOL VOL

ENTER

CH

TV
CABLE
VCR

EXIT

TV/VCR

REC

SLOW

PIP CH LOCATE SWAP

CT-90037

POWER

3

6

9

CH RTN

ENT

TV/VIDEOFAV CH

A

PLAY

STOP

PIP

SOURCESTILL

REWPAUSE

FF

CHANNEL
NUMBERS

ENT (Used for the
“Enter” command with
some VCRs and cable
TV converters

CHANNEL

TV/CABLE/VCR
switch

VCR buttons (set
TV/CABLE/VCR
switch to “VCR”)

y z

27/32/36AF41(E)

12
