Toshiba 24AF46 User Manual

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

24AF46

2006

J3M61021A(E)_COVER 12/1/06, 9:59 AM1

Appendix

Dear Customer,

Thank you for purchasing this Toshiba TV. This manual will

Important

help you use the many exciting features of your new TV.

Safeguards

Before operating the TV, please read this manual completely, and keep it nearby for future reference.

Child Safety

It Makes A Difference Where Your TV Stands

Safety Precautions

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning symbol in the triangle tells you that the voltage inside this product may be strong enough to cause an electric shock. DO NOT TRY TO SERVICE THIS PRODUCT YOURSELF.

The exclamation mark in the triangle tells you that important operating and maintenance instructions follow this symbol.

CAUTION: To reduce the risk of electric shock, do not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

Congratulations on your purchase! As you enjoy your new TV, keep these safety tips in mind:

The Issue

 If you are like most consumers, you have a TV in your home.

Many homes, in fact, have more than one TV.

 The home theater entertainment experience is a growing

trend, and larger TVs are popular purchases; however, they are not always supported on the proper TV stands.

 Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio speakers, chests, or carts. As a result, TVs may fall over, causing unnecessary injury.

Toshiba Cares!

 The consumer electronics industry

is committed to making home

entertainment enjoyable and safe.

 The Consumer Electronics

Association formed the Home

Entertainment Support Safety

Committee, comprised of TV and consumer electronics furniture

manufacturers, to advocate

children’s safety and educate

consumers and their families about

television safety.

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 25 and 26 on page 4.

NOTICE OF POSSIBLE ADVERSE EFFECTS

ON TV PICTURE DISPLAY

If a fixed (non-moving) pattern or image remains on the TV screen for extended periods of time, the image can become permanently ingrained in the cathode ray tube(s) of the TV and cause subtle but permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. (See item 33 on page 4 for details.)

Tune Into Safety

 One size does NOT fit all! Use appropriate

furniture large enough to support the weight of your

TV (and other electronic components).

 Use appropriate angle braces, straps, and anchors to secure

your furniture to the wall (but never screw anything directly into the TV).

 Carefully read and understand the other enclosed

instructions for proper use of this product.

 Do not allow children to climb on or play with furniture

and TVs.

 Avoid placing any item on top of your TV (such as a VCR,

remote control, or toy) that a curious child may reach for.

 Remember that children can become excited while watching

a program and can potentially push or pull a TV over.

 Share our safety message about this hidden hazard of

home with your family and friends. Thank you!

2500 Wilson Blvd. Arlington, VA 22201 U.S.A. Tel. 703-907-7600 Fax 703-907-7690 www.CE.org

CEA is the Sponsor, Producer and

0303

Manager of the International CES

the

J3M61021A(E)_P02-06 12/1/06, 10:00 AM2

Important Safety Instructions

QUALIFIED

SERVICE

TECHNICIAN

Installation, Care, and Service

Safeguards

Important

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near

water.

6) Clean only with a dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

Wide plug

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

16) Never modify this equipment. Changes or modifications may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

17) DANGER: RISK OF SERIOUS PERSONAL

INJURY, DEATH, OR EQUIPMENT DAMAGE! Never place the TV on

an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

18) Never place or store the TV in direct sunlight; hot, humid areas; areas subject to excessive dust or vibration; or locations with temperatures at or below 41°F (5°C).

19) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the unit.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

10) Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where it exits the apparatus.

11) Only use attachments/accessories specified by the

manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during

lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) CAUTION: To reduce the risk of electric shock, do

not use the polarized plug with an extension cord, receptacle, or other outlet unless the blades can

be inserted completely to prevent blade exposure.

20) Never place items such as vases, aquariums, or candles on top of the TV.

21) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains,

or walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any other place with poor ventilation.

The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV.

22) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

23) Never overload wall outlets and extension cords.

0303

Setting up

your TV

Using the TV’s

Features

Appendix

J3M61021A(E)_P02-06 12/1/06, 10:00 AM3

24) Always operate this equipment from

Ground clamp

Antenna discharge unit (NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

Power service grounding electrode system (NEC Art 250 Part H)

Ground clamps

Antenna lead-in wire

Electric service equipment

QUALIFIED

SERVICE

TECHNICIAN

Important

Safeguards

a 120V AC, 60 Hz power source only.

30) [This item applies to projection TVs only.] If the air temperature rises suddenly (for example, when the TV is first delivered), condensation may form on the lenses. This can make the picture appear distorted or the color appear faded. If this happens, turn off the TV for 6 to 7 hours to allow the condensation to evaporate.

25) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

26) DANGER: RISK OF SERIOUS PERSONAL

INJURY OR DEATH!

• Use extreme care to make sure you are never in

a position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

Care

For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions:

27) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen. Turn the TV off to check for reflections on the screen, and then remove the source of reflections while viewing the TV.

28) Always unplug the TV before cleaning. Never use liquid or aerosol cleaners.

31) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

32) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the unit is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.

33) Possible Adverse Effects on TV Picture Display: If a fixed (non-moving) pattern or image remains on the TV screen for extended periods of time, the image can become permanently ingrained in the cathode ray tube(s) of the TV and cause subtle but permanent ghost images.

This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave the TV on for extended periods

of time while it is displaying the following images or formats:

• Fixed Images, including but not limited to PIP/POP

windows, closed captions, video game patterns, TV station logos, stock tickers, and websites.

• Special Formats

that do not use the entire screen, including but not limited to widescreen or letterbox format media viewed on a 4:3 aspect ratio display (with gray or black bars at the top and bottom of the screen); or 4:3 aspect ratio format media viewed on a widescreen/16:9 aspect ratio display (with gray or black bars on the left and right sides of the screen).

Service

34) WARNING: RISK OF ELECTRIC SHOCK! Never attempt to service the

TV yourself. Opening and

removing the covers may expose you to dangerous voltage or other hazards. Refer all servicing to a Toshiba Authorized Service Center.

35) If you have the TV serviced:

• Ask the service technician to use only replacement parts

specified by the manufacturer.

• Upon completion of service, ask

the service technician to perform routine safety checks to determine that the TV is in safe operating condition.

29) WARNING: RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of any kind into the TV cabinet slots.

J3M61021A(E)_P02-06 12/1/06, 10:01 AM4

36) When the TV reaches the end of its useful life, ask a

qualified service technician to properly dispose of the TV. Improper disposal may result in a picture tube implosion and possible personal injury.

0303

Important Safeguards ...................................................................................................... 2-4

Welcome to Toshiba ............................................................................................................ 6

Exploring your new TV ................................................................................................................................6

Selecting a location for the TV ....................................................................................................................6

Connecting your TV ............................................................................................................ 7

Connecting a VCR .......................................................................................................................................7

Connecting a cable converter box ............................................................................................................... 8

Connecting a DVD player/satellite receiver and a VCR ..............................................................................9

Connecting a DVD player with ColorStream® (component video) and a VCR............................................ 9

Connecting two VCRs ...............................................................................................................................10

Connecting a camcorder ........................................................................................................................... 10

Connecting an audio amplifier ................................................................................................................... 10

Using the remote control.................................................................................................. 11

Installing the remote control batteries .......................................................................................................11

Learning about the remote control ............................................................................................................ 11

Setting up your TV ............................................................................................................. 12

Changing the on-screen display language ................................................................................................ 12

Adding channels to the TV’s memory ........................................................................................................ 13

Programming channels automatically ................................................................................................13

Adding and erasing channels manually ............................................................................................. 13

Changing channels .................................................................................................................................... 13

Using the TV’s features ..................................................................................................... 14

Adjusting the channel settings................................................................................................................... 14

Switching between two channels ....................................................................................................... 14

Programming your favorite channels ..................................................................................................14

Using theV-Chip (parental control) feature (U.S. V-Chip system only) ......................................................15

Selecting a PIN code ..........................................................................................................................15

Blocking programs by ratings .............................................................................................................16

Blocking unrated movies or programs ................................................................................................ 19

Using the LOCK menu ............................................................................................................................... 19

Locking channels ................................................................................................................................19

Locking video input .............................................................................................................................20

Setting the GameTimerTM..........................................................................................................................20

Labeling channels ...................................................................................................................................... 21

Setting the clock ........................................................................................................................................22

Setting the ON/OFF timer ..........................................................................................................................22

Setting the on timer ............................................................................................................................22

Setting the off timer ............................................................................................................................23

Adjusting the picture quality ......................................................................................................................24

Watching video input .................................................................................................................................24

Specifying the ColorStream® setting .........................................................................................................24

Displaying on-screen information ..............................................................................................................24

Setting the sleep timer ...............................................................................................................................25

Using the closed caption feature ...............................................................................................................25

Changing the picture size ..........................................................................................................................25

Adjusting the sound ...................................................................................................................................26

Muting the sound ................................................................................................................................26

Selecting stereo/SAP broadcasts ....................................................................................................... 26

Adjusting the sound quality ................................................................................................................27

Using the BBE sound feature .............................................................................................................27

Using the surround sound feature ......................................................................................................28

Using the StableSound® feature ......................................................................................................... 28

Auto power off............................................................................................................................................28

Understanding the Power Return feature ..................................................................................................28

Appendix ............................................................................................................................ 29

Troubleshooting ......................................................................................................................................... 29

Specifications.............................................................................................................................................30

Limited United States Warranty .................................................................................................................31

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

Appendix

J3M61021A(E)_P02-06 12/1/06, 10:01 AM5

16:9

Welcome to Toshiba

Congratulations! You have purchased one of the finest color TVs on the market. The goal of this manual is to guide you through setting up and operating your Toshiba TV as quickly as possible. You may need to purchase other audio or video cables to connect your equipment. See “Connecting your TV” on page 7 for more information.

Please read all the safety and operating instructions carefully before you begin.

Exploring your new TV

You can operate your TV by using the buttons on the front panel or the

Toshiba

Welcome to

remote control. The front and back panels provide all the inputs you will need to connect other equipment to your TV.

POWER

Remote

sensor

POWER

Power

indicator

TV front panel

ANT (75Ω)

CHANNEL VOLUME

Channel

Volume

IN OUT

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

VIDEO L/MONO

AUDIO

R PHONES

VIDEO-3 IN

Audio(L/R)/Video In

Phones

VIDEO

L/MONO

AUDIO

TV back panel

Selecting a location for the TV

• Place the TV on the floor or on a sturdy platform in a location where

light does not directly hit the screen.

• Place the TV far enough from the walls to allow proper ventilation.

Inadequate ventilation may cause overheating, which may damage the TV.

J3M61021A(E)_P02-06 12/1/06, 10:01 AM6

Connecting your TV

• A coaxial cable is the standard cable that comes in from your

antenna or cable converter box. Coaxial cables use “F” connectors.

• Standard A/V (audio/video) cables are usually color coded accord-

ing to use: yellow for video and red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel. If you look at the rear panel of the TV, you will see that the terminals are color coded in the same manner as the cables.

• S-video cables provide better picture performance. S-video cables

can only be used with S-video compatible components.

• Component video cables come in sets of three and provide the best

picture performance. Component video cables can only be used with component video compatible components.

Caution:

Do not plug the TV in until you have finished connecting all of your equipment.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

ANTENNA

Coaxial Cable

AUDIO Cables

VIDEO

Cable

S-Video

Cable

Component video

Cables

Connecting a VCR

This connection allows you to watch local channels and video programs, play or record on the VCR while watching TV, and record from one channel while watching another channel.

ANT (75Ω)

IN OUT

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

VIDEO

L/MONO

AUDIO

You will need:

• two coaxial cables

• one set of standard A/V cables

Note:

If using a mono VCR, connect L/Mono to VCR Audio OUT using only one audio cable. For better picture quality, if your VCR has S-video, you can use an S-video cable instead of the standard video cable. Do not connect a standard video cable and an S-video cable to VIDEO1 simultaneously.

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

Cable Lead-in from cable box or antenna

IN from ANT

CH 3 CH 4

J3M61021A(E)_P07-13 12/1/06, 10:01 AM7

OUT to TV

OUT

VIDEO

Stereo VCR

AUDIO

The unauthorized recording, use, distribution or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Appendix

Connecting a cable converter box

This television has an extended tuning range and can tune most cable channels without using a cable company supplied converter box. Some cable companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device, which is generally provided by the cable company.

For Subscribers to Basic Cable TV Service

For basic cable service not requiring a Converter/Descrambler box, connect the CATV 75 ohm Coaxial Cable directly to the Antenna Jack on the back of the television.

For Subscribers to Scrambled Cable TV Service

If you subscribe to a cable service that requires the use of a Converter/ Descrambler box, connect the incoming cable to the Converter/ Descrambler box and connect the output of the box to the Antenna Jack on the back of the television. Follow the connections shown below. Set the television to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.

your TV

Connecting

For Subscribers to Unscrambled Basic Cable with Scrambled Premium Channels

If you subscribe to a cable service in which basic cable channels are unscrambled and premium channels require the use of a Converter/ Descrambler box, you may wish to use a two-set signal splitter (sometimes called a “two-set coupler”) and an A/B Switch box from the cable installer or an electronics supply store. Follow the connections shown below. With the switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the box to tune scrambled channels.

Note:

When you use a converter box with your TV, there may be features that you cannot program using the remote control, such as labeling channels, blocking channels, and programming your favorite channels.

Incoming CATV

Converter/Descrambler

B SwitchSplitter

IN OUT

ANT (75Ω)

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

VIDEO

L/MONO

AUDIO

J3M61021A(E)_P07-13 12/1/06, 10:02 AM8

Connecting a DVD player/satellite receiver and a VCR

This connection allows you to watch DVD/satellite, VCR, or TV programs. You can record from the satellite receiver and TV, as well as record one TV channel while watching another channel.

To satellite

DVD player/ Satellite Receiver

OUT

Satellite IN

S-VIDEO

AUDIO

IN OUT

ANT (75Ω)

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

VIDEO

L/MONO

AUDIO

You will need:

• three coaxial cables

• two sets of standard A/V cables

• one S-video cable

• one pair of standard audio cables

Note:

You can use a standard video cable instead of the S-video cable, but the picture quality will decrease. If you use an S-video cable between the TV and DVD player/satellite receiver, make the audio connections only and remove the standard video cable.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

To antenna

Connecting a DVD player with ColorStream

Stereo VCR

IN from ANT

CH 3 CH 4

OUT to TV

OUT

VIDEO

AUDIO

(component video) and a VCR

This connection allows you to watch DVD, VCR, or TV programs and record TV programs. You can record from one source while watching a program from another source. Your TV is capable of using ColorStream (component video). Connecting your TV to a component video compatible DVD player, such as a Toshiba DVD player with ColorStream greatly enhance picture quality and performance.

OUT

VIDEO

AUDIO

OUT

IN OUT

OUT

VIDEO

AUDIO

COLORSTREAM

YCbCr

VIDEO

L/MONO

AUDIO

To antenna

DVD player with ColorStream

S-VIDEO

ANT (75Ω)

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

Stereo VCR

IN from ANT

CH 3 CH 4

OUT to TV

, can

You will need:

• two coaxial cables

• one set of standard A/V cables

• one set of component video cables

• one pair of standard audio cables

Note:

The ColorStream inputs on this TV are for use with devices that output 480i interlaced signals ONLY. This TV will not accept or display 480p or 720p progressive scan signals or 1080i interlaced high-definition signals. If you connect a high-definition settop receiver, 480p progressive scan DVD player, or other similar device to the TV’s ColorStream inputs, YOU MUST SWITCH THE DEVICE’S OUTPUT TO 480i INTERLACED MODE FIRST. Failure to do this will cause a poor picture or no picture to display.

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

Appendix

J3M61021A(E)_P07-13 12/1/06, 10:02 AM9

Connecting two VCRs

This connection allows you to record (dub/edit) from one VCR to another VCR. You will also be able to record from one TV channel while watching another channel.

To antenna

your TV

Connecting

Connecting a camcorder

This connection allows you to watch video materials recorded on a camcorder.

Stereo VCR / Playback

IN from ANT

OUT to TV

CH 3 CH 4

ANT (75Ω)

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

Stereo VCR/ Recording

IN from ANT

OUT to TV

CH 3 CH 4

OUT

VIDEO

AUDIO

IN OUT

OUT

VIDEO

AUDIO

Camcorder

VIDEO

L/MONO

AUDIO

You will need:

• two coaxial cables

• two sets of standard A/V cables

Note:

Do not connect the same VCR to the output and input jacks on the TV at the same time. For better picture quality, if your VCR has Svideo, you can use an S-video cable instead of the standard video cable. Do not connect a standard video cable and an S-video cable to VIDEO1 simultaneously.

You will need:

• one set of standard A/V cables

AUDIO

VIDEO

OUT

AUDIO

VIDEO 3 L/MONO

R PHONESR

Front Panel of TV

Connecting an audio amplifier

This connection allows you to use an audio amplifier to enjoy high quality sound. This also allows you to use external speakers. To control the audio, turn on the TV and the stereo amplifier.

Audio Amplifier

AUDIO

OUT

To cable,

cable box or

antenna

ANT (75Ω)

VIDEO

L/MONO

AUDIOS-VIDEO

VIDEO 1 VIDEO 2

IN OUT

VIDEO

L/MONO

AUDIO

Note:

For better picture quality, if your camcorder has S-video, you can connect an S-video (and standard audio cables) to VIDEO1 on the back of the TV. Do not connect a standard video cable and an S-video cable to VIDEO1 simultaneously.

You will need:

• one coaxial cable

• one pair of audio cables

J3M61021A(E)_P07-13 12/1/06, 10:02 AM10

Using the remote control

Installing the remote control batteries

To install the batteries:

1. Open the battery cover on the back of the remote control.

Caution:

• Never throw batteries into a fire.

Safeguards

Important

2. Install two “AAA” size batteries. Match the + and – signs on the batteries to the signs on the battery compartment.

3. Close the battery cover on the remote control until the lock snaps.

Learning about the remote control

POWER turns the TV on and off CHANNEL NUMBERS allow direct access to channels (page 13)

Notes:

• Be sure to use AAA size batteries.

• Dispose of batteries in a designated

disposal area.

• Batteries should always be disposed of with the environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace batteries with new ones.

• When necessary to replace batteries in the remote control, always replace both batteries with new ones. Never mix battery types or use new and used batteries in combination.

• Always remove batteries from remote control if they are dead or if the remote control is not to be used for an extended period of time. This will prevent battery acid from leaking into the battery compartment.

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

RECALL displays status information on-screen (page 24) SLEEP programs the TV to turn off at a set time (page 25) MUTE turns off the sound (page 26) CH + / – cycles through programmed channels (page 13) VOLUME + / – adjusts the volume level MENU/ENTER allows access to programming menus, and sets

programmed menu information (page 14)

EXIT closes on-screen menus (page 14) CAP/TEXT turns closed captions or text on and off (page 25) 1/2 selects closed caption/text channel 1 or 2 (page 25) RESET returns settings to preset factory formats (pages 24 and 27) CH RTN (Channel Return) returns to the last viewed channel

(page 14)

MTS switches among STEREO, SAP, and MONO sound (page 26) TV/VIDEO selects the video input source (page 24) FAV ▲/▼ (Favorite Channels) cycle through favorite channels

(page 14)

16:9 toggles the aspect ratio between 4:3 (letterbox) and 16:9 (wide

screen) modes (page 25)

POWER

Channel

Numbers

Sleep

CH +/-

Menu/Enter

CAP/TEXT

Reset

TV/Video

16:9

Recall

Mute

Volume +/Exit

1/2 MTS

CH RTN (Channel Return) FAV ▲/▼ (Favorite Channels)

Setting up

your TV

Using the TV’s

Features

Appendix

J3M61021A(E)_P07-13 12/1/06, 10:02 AM11

Setting up your TV

After you have installed the batteries and programmed the remote control, you need to set some preferences on the TV using the menu system. You can access the menu system with the buttons on the remote control.

• When you make a menu selection, your changes occur immediately.

You do not have to press MENU or EXIT to see your changes.

• After five seconds, the menu screen will automatically close if you

do not make a selection. Your changes will still be saved.

• When you are finished programming the menus, press EXIT.

Changing the on-screen display language

You can choose from three different languages (English, French, and Spanish) for the on-screen display of adjustment menus and messages.

To select a language:

1. Press MENU, then press

PICTURE AUDIO SETUPCHOPTION

LANGUAGE CH LABEL START

FAVORITE CH V-CHIP LOCK ON/OFF TIMER COLORSTREAM

SELECT ADJUST

2. Press

c or d to highlight LANGUAGE.

ENGLISH

START START START OFF DVD

a or b until the OPTION menu appears.

c d a b

Exit Menu

your TV

Setting up

PICTURE AUDIO SETUPCHOPTION

LANGUAGE

CH LABEL START FAVORITE CH V-CHIP LOCK ON/OFF TIMER COLORSTREAM SELECT ADJUST

3. Press

a or b to highlight your desired language.

ENGLISH FRANCAIS ESPANOL

START START START OFF DVD

J3M61021A(E)_P07-13 12/1/06, 10:03 AM12

Adding channels to the TV’s memory

When you press CH +/- on the remote control or CHANNEL ▲/▼ on the TV front panel, your TV will stop only on the channels stored in the TV’s channel memory. Follow the steps below to program channels into the memory.

Safeguards

Important

Programming channels automatically

Your TV can automatically detect all active channels and store them in its memory. After the TV has stored the channels in its memory automatically, you can add or erase specific channels manually.

To add channels automatically:

1. Press MENU, then press a or b to display the SETUP menu.

2. Press

3. Press a or b to highlight either TV

4. Press

c or d until the TV/CABLE

selection is highlighted.

or CABLE, depending on which you use.

If you use an antenna, choose TV. If you use cable, choose CABLE.

d to select CH PROGRAM.

PICTURE AUDIO SETUP OPTION

TV / CABLE TV CABLE

CH PROGRAM ADD / ERASE

SELECT ADJUST

START ADD

Press a or b to start channel programming. The TV will automatically cycle through all the TV or Cable channels (depending on which you selected), and store all active channels in the channel memory. While the TV is cycling through the channels, the message “PROGRAMMING NOW-PLEASE WAIT” appears.

6. When channel programming is complete, the message “COMPLETED” appears.

7. Press CH + or – to view the programmed channels.

Adding and erasing channels manually

After you have programmed the channels automatically, you can add or erase specific channels manually.

To add or erase channels manually:

1. Select the channel you want to add or erase. If you are adding a channel, you must select the channel using the Channel Number buttons.

2. Press MENU, then press display the SETUP menu.

3. Press c or d to highlight ADD/ ERASE.

4. Press

a or b to select ADD or

ERASE, whichever function you

a or b to

PICTURE AUDIO SETUP OPTION

TV / CABLE CABLE CH PROGRAM START

ADD / ERASE ADD ERASE

want to perform.

5. Repeat steps 1–4 for other

SELECT ADJUST

channels you want to add or erase.

Changing channels

Channel Numbers

Channel +/–

c d a b

Welcome to

Toshiba

Connecting

your TV

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

To change to the next programmed channel:

Press CHANNEL ▲/▼ on the TV front panel or CH +/– on the remote control.

To change to a specific channel (programmed or unprogrammed):

Press the Channel Number buttons (0–9 and 100) on the remote control. For example, to select channel 125, press 100, 2, 5.

J3M61021A(E)_P07-13 12/1/06, 10:03 AM13

Appendix

Using the TV’s features

Adjusting the channel settings

Switching between two channels

You can switch between two channels without entering an actual channel number each time.

To switch between two channels:

1. Select the first channel you want to view.

2. Select a second channel using the Channel Number buttons (0–9,

100).

3. Press CH RTN. The previous channel will be displayed. Each time you press CH RTN, the TV will switch back and forth between the two channels.

Programming your favorite channels

You can preset up to 12 of your favorite channels using the Favorite Channel Programming feature. Because this feature scans through only your favorite channels, it allows you to skip other channels you do not normally watch. You can still use Channel + / – to scan through all the channels you programmed in the TV’s memory.

To program your favorite channels:

1. Select a channel you want to program as a favorite channel.

2. Press MENU, then press a or b to display the OPTION menu.

3. Press c or d to highlight FAVORITE CH.

Channel Numbers

CH RTN

Features

Using the TV’s

PICTURE AUDIO SETUPCHOPTION

CH LABEL START

FAVORITE CH

V-CHIP LOCK ON/OFF TIMER COLORSTREAM

SELECT START

ENGLISHLANGUAGE

START START START OFF DVD

4. Press a or b to display the FAVORITE CH menu. SET/CLEAR will be highlighted.

PICTURE AUDIO SETUPCHOPTION

FAVORITE CH : CH 012

SET/CLEAR SET CLEAR

SET UP CH

TV CABLE SELECT END EXIT

0000 0000 0000

SET ENTER

5. Press a or b to highlight SET and press ENTER.

6. Press EXIT to close the screen.

7. Repeat steps 1–6 for up to 11 other channels.

To select your favorite channels:

Press the FAV ▲▼ buttons on the remote control to select your favorite channels. The FAV ▲▼ buttons will not work until you have programmed your favorite channels.

16:9

Channel Numbers

c d a b

Exit Menu/

Enter

FAV

J3M61021A(E)_P14-25 12/1/06, 10:03 AM14

To clear your favorite channels:

1. Select a channel you want to clear.

2. Press MENU, then press a or b to display the OPTION menu.

3. Press c or d to highlight FAVORITE CH.

4. Press a or b to display the FAVORITE CH menu. SET/CLEAR will be highlighted.

PICTURE AUDIO SETUPCHOPTION

FAVORITE CH : CH 012

SET/CLEAR SET CLEAR

SET UP CH

TV CABLE SELECT END EXIT

736 4 1 12 125 63 40 13 28 97 112

SET ENTER

Channel Numbers

c d a b

Safeguards

Important

Welcome to

Toshiba

5. Press a or b to highlight CLEAR.

PICTURE AUDIO SETUPCHOPTION

FAVORITE CH : CH 012

SET/CLEAR SET CLEAR

SET UP CH

TV CABLE SELECT END EXIT

736 4 1 12 125 63 40 13 28 97 112

CLEAR ENTER

6. Press ENTER until “0” replaces the channel number you want to erase.

7. Press EXIT to clear the screen.

8. Repeat steps 1–6 for the other channels.

Using the V-Chip (parental control) feature

The V-Chip feature is available only for the U.S. V-Chip system. The Canadian V-Chip system is not supported.

You can prevent others from viewing certain programs or channels by blocking them using the V-Chip feature.

Selecting a PIN code

Before you can block programs and channels, you must select a personal identification number (PIN) code. The PIN code you select prevents others from changing the rating limits you set.

To select your PIN code and access the V-Chip menus:

1. Press MENU, then press a or b to highlight the OPTION menu.

2. Press c or d to highlight V-CHIP.

Exit Menu/

Enter

Connecting

your TV

Remote Control

Using the

Setting up

your TV

PICTURE AUDIO SETUPCHOPTION

CH LABEL START FAVORITE CH

V-CHIP

LOCK ON/OFF TIMER COLORSTREAM SELECT START

ENGLISHLANGUAGE

START START START OFF DVD

Note:

The PIN code you programmed is also used in the LOCK menu; see pages 19 and 20.

J3M61021A(E)_P14-25 12/1/06, 10:03 AM15

c d a b

Using the TV’s

Features

Appendix

3. Press a or b to display the V-CHIP menu.

PICTURE AUDIO SETUPCHOPTION

V-CHIP BLOCKING RESET

PIN CODE

SELECT END EXIT

SET ENTER

[0-9]

4. Use the Channel Number buttons (0–9) to enter your PIN code. If you are accessing the V-Chip menus for the first time, select a four-digit number to be your PIN code. Press ENTER. The BLOCKING menu appears.

PICTURE AUDIO SETUPCHOPTION

V-CHIP

ENABLE BLOCKING ON OFF

SET RATING BLOCKING OPTION NEW PIN CODE

START START START

ADJUSTSELECT

5. You may now enable blocking. See “Blocking programs by ratings” (below), “Locking channels” (page 19), “To change your PIN code” (below), or “Blocking unrated movies or programs” (page 19).

Note:

If you forget your PIN code, press RECALL four times within five seconds from the V-CHIP menu. This allows you to proceed to the BLOCKING menu and resets your PIN code.

Features

Using the TV’s

To change your PIN code:

1. Press MENU, then press a or b to display the OPTION menu.

2. Press c or d to highlight V-CHIP.

3. Press a or b to display the V-CHIP menu.

4. Use the Channel Number buttons (0–9) to enter your PIN code. Press ENTER. The BLOCKING menu appears.

5. Press c or d to highlight NEW PIN CODE and press a or b to display the NEW PIN CODE menu.

6. Use the Channel Number buttons (0–9) to enter a new code. Press ENTER.

7. Press EXIT to return to normal viewing.

Blocking programs by ratings

The Motion Picture Association of America (MPAA) uses a rating system to qualify motion picture content. Television broadcasters employ a rating system to qualify the content of television programs, as well. The MPAA, Youth TV, and TV ratings work with the V-Chip feature and allow you to block programs according to the rating limits you set.

Channel Numbers

Recall

c d a b

Exit Menu/

Enter

J3M61021A(E)_P14-25 12/1/06, 10:04 AM16

MPAA Ratings

X For adults only. NC17 Not intended for anyone 17 or under. R Restricted. Under 17 requires an accompanying

parent or adult guardian.

PG13 Parents strongly cautioned. Some material may be

inappropriate for children under 13.

PG Parental guidance suggested. Some material may

not be appropriate for children.

G General audience. Appropriate for all ages.

Youth TV Ratings

Y7FV, Y7 Directed to older children. This program is designed

for children age 7 and above. Programs in which fantasy violence may be more intense or combative than other programs in this category are designated TV-Y7-FV.

Y All children. This program is designed to be appropri-

ate for all children.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

TV Ratings

MA Mature audience only. This program is specifically

designed to be viewed by adults and therefore may be unsuitable for children under 17.

Language Crude or indecent language. Sex Explicit sexual activity. Violence Graphic violence.

14 Parents strongly cautioned. This program contains

some material that many parents would find unsuitable for children under 14 years of age.

Dialog Intensely suggestive dialog. Language Strong, coarse language. Sex Intense sexual situations. Violence Intense violence.

PG Parental guidance suggested. This program contains

material that parents may find unsuitable for younger children. Dialog Some suggestive dialog. Language Infrequent coarse language. Sex Some sexual situations. Violence Moderate violence.

G General audience. Most parents would find this

program suitable for all ages.

Note:

To see the rating of the program you are viewing, press RECALL at any time.

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

No DLSV Programs not rated according to Dialog, Language,

Sex or Violence.

J3M61021A(E)_P14-25 12/1/06, 10:04 AM17

Appendix

To use the V-Chip to block programs by rating:

1. Press MENU, then press a or b to display the OPTION menu.

2. Press c or d to highlight V-CHIP.

3. Press a or b to display the V-CHIP menu.

PICTURE AUDIO SETUPCHOPTION

V-CHIP

ENABLE BLOCKING ON OFF

SET RATING BLOCKING OPTION NEW PIN CODE

START START START

ADJUSTSELECT

5. Press c or d to highlight ENABLE BLOCKING.

• Press a or b to highlight ON to enable V-Chip program blocking

by rating.

• Press a or b to highlight OFF to disable V-Chip program blocking

by rating.

6. Press c or d to highlight SET RATING. Then, press a or b to display the SET RATING menu.

Channel Numbers

c d a b

Exit Menu/

Enter

Features

Using the TV’s

PICTURE AUDIO SETUPCHOPTION

SET RATING

MPAA

RATING

YOUTH TV

RATING MORE

SELECT

NC17 R

Y7FV Y7 Y

ADJUST

PG13

PG G

PICTURE AUDIO SETUPCHOPTION

TV RATING

DIALOG

LANGUAGE SEX VIOLENCE NO DLSV V-CHIP MENU

SELECT

MA 14 PG G

START

ADJUST

7. Press c or d to highlight MPAA Rating, Youth TV Rating or individual TV Ratings.

8. Press a or b to select the ratings that will be blocked. Blocked ratings are signified by a red “X.” Unblocked ratings are signified by a green “

✓.” As you block ratings, all ratings higher than the

ones you select are blocked, as well. For example, if you choose to block the MPAA rating R, the higher ratings NC17 and X are automatically blocked too.

9. When you are done selecting the ratings to be blocked, press EXIT to return to normal viewing.

When you try to view a program with a ratings block, a message will appear listing the program’s ratings. The program can still be viewed if you press MUTE and then enter your PIN code to temporarily bypass the block.

Note:

Not all programs are rated. To block programs or movies that are unrated, see “Blocking unrated movies or programs,” page 19.

J3M61021A(E)_P14-25 12/1/06, 10:04 AM18

Blocking unrated movies or programs

Some movies and programs are not rated. You can block these movies and programs using the V-Chip.

To block unrated movies or programs:

1. Press MENU, then press a or b to display the OPTION menu.

2. Press c or d to highlight V-CHIP.

3. Press a or b to display the V-CHIP menu.

5. Press c or d

6. Press a or b to display the BLOCKING OPTION menu.

7. Press c or d to highlight MPAA UNRATED.

• Press a or b to highlight ON to block unrated movies.

• Press a or b to highlight OFF to unblock unrated movies.

8. Press c or d to highlight TV NONE RATING.

• Press a or b to highlight ON to block programs with a rating of

“TV NONE.” When you select ON, the message “NOTICE: ENABLING THIS OPTION MAY BLOCK EMERGENCY MESSAGES” appears.

• Press a or bto highlight OFF to unblock programs with a rating

of “TV NONE.”

9. Press EXIT to return to normal viewing.

highlight BLOCKING OPTION.

Note:

Blocking television programs with a rating of “TV NONE” may block emergency messages.

Safeguards

Important

Welcome to

Toshiba

Connecting

your TV

Using the LOCK menu

The LOCK menu includes the CH LOCK, VIDEO LOCK, GAME TIMER, and NEW PIN CODE functions. You can use these functions after entering the correct PIN code. (This PIN code is the same one selected under “Selecting a PIN code” on page 15.)

Locking channels

With the CH LOCK feature, you can lock specific channels. You will not be able to tune locked channels unless you clear the setting. You can choose to lock up to nine TV channels and nine cable channels.

To lock channels:

1. Use the Channel Number buttons (0–9, 100) to display the television channel you wish to lock.

2. Press MENU, then press a or b to display the OPTION menu.

3. Press c or d to highlight LOCK.

4. Press a or b to display the LOCK menu.

5. Use the Channel Number buttons (0–9) to enter your PIN code, then press ENTER. The LOCK menu appears.

6. Press c or d to highlight CH LOCK and press a or b to display the CH LOCK menu.

7. Press a or b to select the following:

• SET– to set the channel as one to be

locked. Then press ENTER.

• CLEAR– to clear all channels from

the list of locked channels. Then press ENTER.

8. Repeat steps 1 through 7 to lock other channels. When you are finished locking channels, press EXIT to return to normal viewing. If you try to tune a locked channel, the TV will not display it, but will display the nearest unlocked channel.

PICTURE AUDIO SETUPCHOPTION

LOCK

CH LOCK START

VIDEO LOCK

GAME TIMER NEW PIN CODE SELECT ADJUST

PICTURE AUDIO SETUPCHOPTION

CH LOCK : CH 12

SET/CLEAR SET CLEAR

LOCKED CH

TV CABLE SELECT END EXIT

OFF OFF

START

000 000 000

SET ENTER

Channel Numbers

c d a b

Exit Menu/

Enter

Note:

After programming CH LOCK, change channels before turning off the television.

Remote Control

Using the

Setting up

your TV

Using the TV’s

Features

Appendix

J3M61021A(E)_P14-25 12/1/06, 10:05 AM19

Features

Using the TV’s

To unlock channels:

1. Press MENU, then press a or b to display the OPTION menu.

2. Press c or d to highlight LOCK and then press a or b to display the LOCK menu.

3. Use the Channel Number buttons (0–9) to enter your PIN code, then press ENTER. The LOCK menu appears.

4. Press c or d to highlight CH LOCK and press a or b to display the CH LOCK menu.

5. Press a or b to highlight CLEAR, and then press ENTER. This clears all channels from the list of locked channels.

6. Press EXIT to return to normal viewing.

Locking video input

With the VIDEO LOCK feature, you can lock out the input sources (VIDEO1, VIDEO2, VIDEO3, COLORSTREAM) and channels 3 and 4. You will not be able to select the input sources with the TV/VIDEO button or Channel buttons unless you clear the setting.

To set up the video lock:

1. Press MENU, then press a or b to display the OPTION menu.

2. Press c or d to highlight LOCK.

3. Press a or b to display the LOCK menu.

4. Use the Channel Number buttons (0–9) to enter your PIN code, then press ENTER. The LOCK menu appears.

5. Press c or d to highlight VIDEO LOCK.

6. Press a or b to select:

• OFF: Unlocks all video input

sources. VIDEO: Locks VIDEO1, VIDEO2,

•

VIDEO3 and COLORSTREAM.

• VIDEO +: Locks VIDEO1, VIDEO2,

VIDEO3, COLORSTREAM, channel 3 and channel 4. This option should be used if you use the antenna terminal to play a video tape.

7. Press EXIT to return to normal viewing.

Setting the GameTimer

With the GameTimerTM feature, you can automatically activate the VIDEO LOCK feature (VIDEO setting)

to set a time limit for playing a

TV game (30, 60, 90 or 120 minutes).

To set up the GameTimer:

1. Press MENU, then press a or b to display the OPTION menu.

2. Press c or d to highlight LOCK.

3. Press a or b to display the LOCK menu.

4. Use the Channel Number buttons (0–9) to enter your PIN code, then press ENTER. The LOCK menu appears.

5. Press c or d to highlight GameTimer.

6. Press a or b to select a time limit (30 minutes, 60 minutes, 90 minutes, 120 minutes or OFF).

7. Press EXIT to return to normal viewing. After the GameTimer is programmed, the display will appear briefly every ten minutes to remind you that the GameTimer is operating. When the programmed time is reached, the display will change the channel automatically.

PICTURE AUDIO SETUPCHOPTION

LOCK CH LOCK START

VIDEO LOCK

GAME TIMER NEW PIN CODE SELECT ADJUST

PICTURE AUDIO SETUPCHOPTION

LOCK CH LOCK START

VIDEO LOCK

GAME TIMER

NEW PIN CODE SELECT ADJUST

OFF VIDEO VIDEO+ OFF START

OFF

OFF 30 60 90 120 START

Channel Numbers

c d a b

Exit Menu/

Enter

Note:

After programming VIDEO LOCK, change channels or activate the TV/VIDEO key before turning off the television.

Channel Numbers

c d a b

Exit Menu/

Enter

J3M61021A(E)_P14-25 12/1/06, 10:05 AM20

+ 44 hidden pages
