Toshiba 22LV505 User Manual

Introduction

J50S0101A.indb 1

08.1.9 4:44:32 PM

4

19/22-inch* Diagonal LCD TV/DVD
COMBINATION

19LV505
19LV506
22LV505

OWNER’S MANUAL

Connections

Basic setup

TV operation

Basic playback

Advanced playback

Function setup

Others

14

21

26

44

47

60

66

IIIustration of 19LV505

©2008 Toshiba Corporation
Before operating the unit, please read this manual thoroughly.
*Screen size is approximate.

J50S0101A.indb 1

Owner·s Record

The model number and serial number
are on the back of your TV/DVD.
Record these numbers in the spaces
below. Refer to these numbers
whenever you communicate with your
Toshiba dealer about this TV/DVD.

Model number:
Serial number:

08.1.9 4:44:32 PM

Introduction

J50S0101A.indb 2

08.1.9 4:44:39 PM

Dear Customer,

Thank you for purchasing this Toshiba LCD TV or TV/DVD
Combination television.

This manual will help you use the many exciting features of
your new LCD TV. Before operating your LCD TV or TV/DVD
Combination, please read this manual completely, and keep it
nearby for future reference.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.

The exclamation point within an equilateral triangle,
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.

CAUTION: To reduce the risk of electric shock,

do not use the polarized plug with an extension
cord, receptacle, or other outlet unless the blades
can be inserted completely to prevent blade
exposure.

WARN ING: If you decide to wall mount this television,
always use a UL Listed wall bracket appropriate for the
size and weight of this television. The use of any wall bracket
other than a UL Listed wall bracket appropriate for the size
and weight of this television for wall mounting this television
could result in serious bodily injury and/or property damage.

ENE RGY STAR® qualified TV. Products that earn
the ENE RGY STAR prevent green house gas
emissions by meeting strict energy efficiency
guidelines set by the U.S. Environmental
Protection Agency and the U.S. Department of
Energy. ENERGY STAR and the EN ERGY STAR
mark are registered U.S. marks.

This is a reminder to call the CATV system installer’s attention
to Article 820-40 of the NEC, which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to grounding system of the building, as close to the point of
cable entry as practical. For additional antenna grounding information,
see item 27 on page 5.

Child Safety

It Makes A Difference
Where Your TV Stands

Congratulations on your purchase!
As you enjoy your new TV, keep these safety tips in mind:

The Issue

If you are like most consumers, you have a TV in your home. Many homes,
in fact, have more than one TV.

The home theater entertainment experience is a growing trend, and larger
TVs are popular purchases; however, they are not always supported on
the proper TV stands.

Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio

speakers, chests, or carts. As a result, TVs may fall over,

causing unnecessary injury.

Toshiba Cares!

The consumer electronics industry is committed to

making home entertainment enjoyable and safe.

The Consumer Electronics Association formed the

Home Entertainment Support Safety Committee,

comprised of TV and consumer electronics furniture

manufacturers, to advocate children’s safety and educate

consumers and their families about television safety.

Tune Into Safety

One size does NOT fit all! Use appropriate furniture large enough to
support the weight of your TV (and other electronic components).

Use appropriate angle braces, straps, and anchors to secure your furniture
to the wall (but never screw anything directly into the TV).

Carefully read and understand the other enclosed instructions for proper
use of this product.

Do not allow children to climb on or play with furniture and TVs.
Avoid placing any item on top of your TV (such as a VCR, remote control,

or toy) that a curious child may reach for.
Remember that children can become excited while watching a program

and can potentially push or pull a TV over.

NOTE TO CATV INSTALLERS

Share our safety message about this hidden hazard of
your family and friends. Thank you!

2500 Wilson Blvd.
Arlington, VA 22201 U.S.A.
www.CE.org

CEA is the Sponsor, Producer and
Manager of the International CES

the home with

®

2

J50S0101A.indb 2

08.1.9 4:44:39 PM

FCC compliance information

J50S0101A.indb 3

08.1.9 4:44:41 PM

CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD, RECEPTACLE

OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

FCC Declaration of Conformity Compliance Statement (Part 15):

The Toshiba 19LV505, 19LV506, 22LV505, LCDTV/DVD Combination complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

The party responsible for compliance to these rules is:
Toshiba America Consumer Products, L.L.C.

82Totowa Rd. Wayne, NJ 07470.
Ph: [phone] or visitTACP·s website at www.tacp.Toshiba.com

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by removing and applying power to the equipment, the user is encouraged to
try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and the receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modifications to this equipment not expressly approved by Toshiba could void the user·s authority to operate this

equipment.

Introduction

CAUTION:

THIS DIGITAL VIDEO PLAYEREMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ

THIS OWNER'S MANUAL CAREFULLYAND RETAIN FOR
FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE
LOCATION.

USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAYRESULT IN HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO LASER BEAM, NEVER
OPEN THE ENCLOSURE. VISIBLE LASER RADIATION MAY BE
PRESENT WHEN THE ENCLOSURE IS OPENED. NEVER STARE
INTO BEAM.

Location of the required Marking

The rating sheet and the safety caution are the rear of the unit.

Illustration of
19LV505

CERTIFICATION: COMPLIES WITH FDA RADIATION
PERFORMANCE STANDARDS, 21 CFR SUBCHAPTER J.

ON DISPOSAL

The lamp(s) inside this product contain mercury. Disposal may be regulated due to environmental
considerations. For disposal or recycling information, contact your local authorities or the
Electronic Industries Alliance (www.eiae.org).

J50S0101A.indb 3

3

08.1.9 4:44:41 PM

Introduction

J50S0101A.indb 4

08.1.9 4:44:43 PM

SAFETY INSTRUCTIONS

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings.
Install in accordance with the manufacturer·s instructions.

8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus

(including amplifi ers) that produce heat.

Do not defeat the safety purpose of the polarized or

9)
grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong.

The wide blade or the third prong

are provided for your safety. If
the provided plug does not fi t into
your outlet, consult an electrician for

replacement of the obsolete outlet.

10)

Protect the power cord from being walked
on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.

11) Only use attachments/accessories specifi ed by the

manufacturer.

Use only with the cart, stand, tripod,

12)

bracket, or table specifi ed by the
manufacturer, or sold with the
apparatus.

caution when moving the cart/
apparatus combination to avoid

injury from tip-over.

13)

Unplug this apparatus during
lightning storms or when unused

for long periods of time.

14) Refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been damaged
in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

When a cart is used, use

Wide plug

Additional Safety Precautions

14a) CAUTION: If the TV is dropped and the cabinet or
enclosure surface has been damaged or the TV does

not operate normally, take the following precautions:

• ALWAYS turn off the TV and unplug the power

cord to avoid possible electric shock or fi re.

• NEVER allow your body to come in contact with

any broken glass or liquid from the damaged
television. The LCD panel inside the TV contains

glass and a toxic liquid. If the liquid comes in contact

with your mouth or eyes, or your skin is cut by

broken glass, rinse the affected area thoroughly

water and consult your doctor.

15) To avoid damage to this product, never place or

store the TV in direct sunlight; hot, humid areas;
or areas subject to excessive dust or vibration.

with

Installation, Care, and Service

Installation

Follow these recommendations and precautions and
heed all warnings when installing your TV:

16)

Never modify this equipment. Changes or modifi cations
may void: a) the warranty, and b) the user·s authority
operate this equipment under the rules of the
Federal Communications Commission.

17) DANGER: RISK OF SERIOUS

stand, or table. The TV may fall, causing
serious personal injury, death, or serious
damage to the TV.

18) Never place items such as vases, aquariums, or
candles on top of the TV.

19) WARNING: To prevent injury, this apparatus must be
securely attached to the fl oor/wall in accordance with
the installation instructions. Always place the TV on
the fl oor or a sturdy, level, stable surface that can

support the weight
of the unit. Use a
sturdy tie between
the TV·s rear hook

and the rear wall, pillar,

etc., to secure
If you use a TV stand,
fasten the TV to the
stand
attached band (under the TV pedestal).

20)

Never expose the apparatus to dripping or splashing
liquid or place items such as vases, aquariums, any
other item fi lled with liquid, or candles on top of the TV.

21)

Never block or cover the slots or openings in the TV
cabinet back, bottom, and sides.

Never place the TV:

•

on a bed, sofa, rug, or similar surface;

• too close to drapes, curtains,
or walls; or

• in a confi ned space such as
a bookcase, built-in cabinet,
or any other place with poor ventilation.

The slots and openings are provided to protect the TV from
overheating and to help maintain reliable operation of the TV.
Leave a space of at least 4 inches around the TV.

22) Always place the back of the television at least one
(1) inch away from any vertical surface (such as a
wall) to allow proper ventilation.

23) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord
is subject to wear or abuse.

24) Never overload wall outlets and extension cords.
Always operate the TV with a 120V AC, 60Hz power source only.

25)

CAUTION: To reduce the risk of electric shock, do not use
the polarized plug with an extension cord, receptacle, or
other outlet unless the blades can be inserted completely
with three-wire grounding type to prevent blade exposure.

PERSONAL INJURY, DEATH, OR
EQUIPMENT DAMAGE! Never place

the TV on an unstable cart,

Sturdy tie (as short as possible; min. 1 in.)

Hooks

the TV .

using the

TV side

Band

TV top

to

Clip

Screw

4

J50S0101A.indb 4

08.1.9 4:44:43 PM

SAFETY INSTRUCTIONS

J50S0101A.indb 5

08.1.9 4:44:45 PM

(Continued)

Installation (cont. from previous page)

26) Always make sure the antenna system is properly
grounded to provide adequate protection against
voltage surges and built-up static charges (see
Section 810 of the National Electric Code.)

Antenna

Ground clamp

Electric service

equipment

Power service grounding

electrode system

(NEC Art 250 Part H)

27) DANGER: RISK OF SERIOUS

PERSONAL INJURY OR DEATH!

• Use extreme care to make sure you

(or any item
such
accidentally touch overhead power lines.

Never locate the antenna near overhead

power lines or other electrical circuits.

•

Never attempt to install any of the following during
lightning activity: a) an antenna system; or b) cables,
wires, or any home theater component connected

to an antenna or phone system.

are never in a position where your body

you are in contact with,

as a ladder or screwdriver) can

lead-in wire

Antenna discharge unit
(NEC Section 810-20)

Grounding conductors
(NEC Section 810-21)

Ground clamps

Care

For better performance and safer operation of your
TOSHIBA TV, follow these recommendations and precautions:

28)

Always unplug the TV before cleaning.

Wipe the display panel surface

gently using only a soft cloth
(supplied.) A hard clo t h m a y
damage the surface of the
panel. Avoid contact with
alcohol, thinner, benzene,
acidic or and alkaline solvent
cleaners, abrasive cleaners,
surface may be impaired.

29)

any kind into the TV cabinet slots.

WARNING: RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of

or chemical cloths, as the

Care (cont. from previous column)

33)

Keep your fi ngers well clear of the disc slot as it is closing.

Failure to do so may cause serious personal injury.

34) When you use headphones, keep the volume at a
moderate level. Using headphones continuously

at a high volume may cause hearing damage.

35)

NEVER look directly into the disc slot or ventilation
slots at the source of the laser beam. Doing so
may cause sight damage.

36) NEVER use a cracked, deformed, or repaire disc.
Such discs are easily broken and may cause serious
personal injury or product damage. SUCH DAMAGE
IS NOT COVERED UNDER YOUR WARRANTY.

37) WARNING: RISK OF SERIOUS PERSONAL

INJURY OR EQUIPMENT DAMAGE!

• Never strike the screen with a sharp or heavy

object.

• Never touch, press, or place anything on the

LCD screen. These actions will damage the LCD
screen If you need to clean the LCD screen,
follow the instructions in item 28 on this page.

Service

38)
Never attempt to service the TV

expose you to dangerous voltage or other hazards.

Refer all servicing to a Toshiba Authorized Service Center.

39) If you have the TV serviced:

•

Ask the service technician to use only replacement

parts specifi ed by the manufacturer.

• Upon completion of service, ask the service

technician to perform routine safety checks to

determine that the TV is in safe operating condition.

40) When the TV reaches the end of its useful life,

ask a qualifi ed service technician to properly
dispose of the TV.

WARNING: RISK OF ELECTRIC SHOCK!

yourself.
Opening and removing the covers may

Introduction

30)

While it is thundering, do not touch the connecting

cables or apparatus.

31)

For added protection of your TV from lightning and
power surges, always unplug the power cord and
disconnect the antenna from the TV if you leave the
TV unattended or unused for long periods of time.

32)

During normal use, the TV may make occasional snap
ping or popping sounds. This is normal, especially when

the unit is being turned on or off. If these sounds become
frequent or continuous, unplug the power cord and

contact a Toshiba Authorized Service Center.

J50S0101A.indb 5

5

08.1.9 4:44:45 PM

Introduction

J50S0101A.indb 6

08.1.9 4:44:46 PM

Precautions

Choosing a location for your LCD TV

Q Retractable pedestal stand and locating the LCD TV

Observe the following safety precautions:

1) Ensure that unpacking and transfer of the unit is carried out by
two or more people.

2) Put the LCD TV on a large level area in a recumbent posture.

3) Grab the pedestal stand and lift the display up. Confi rm the pivot
is locked.

4) Place the TV on a sturdy, level surface that
can support the weight of the TV.

5) Be sure to secure the TV to a wall, pillar,
surface, or other immovable structure.
To secure the TV in this manner, use the
included strap located at the rear of
pedestal stand. (see item 19, page 4).

Q To fold the pedestal stand

1) Slide the lever on the back side of the pedestal stand to the left.

2) Lay the display down.
Slide the lever to the left

Back side of the pedestal stand

NOTE: Do not operate the LCD TV while the pedestal stand
is folded.

Q To Display your LCD TV using a Wall Bracket:

If you decide to wall mount your LCD TV, always use a UL Listed
wall bracket appropriate for the size and weight of the LCD TV (see
page 2):

1) CAUTION: Two people are required for installation.

2) Unplug and remove any cables and/or other component

connectors from the rear of the TV.

3) Follow the instructions provided with your wall bracket.

Before proceeding, make sure the appropriate bracket(s) are
attached to the wall and the back of the TV as described in the
instructions provided with the wall bracket.

4) After attaching the appropriate bracket(s) to the wall and the back

of the TV, remove the pedestal stand from the TV as described
below.

Q Removing the Pedestal Stand

1) Carefully lay the front of the unit face down on a fl at, cushioned

surface such as a quilt or blanket. Leave the stand protruding
over the edge of the surface.

NOTE: Extreme care should always be used when removing

the pedestal stand to avoid damage to the LCD panel.

2) Remove the two screws shown in the diagram below.

This will allow removal of the pedestal stand.

3) Once you have removed all two screws holding the pedestal

stand in place, remove the pedestal stand from the TV by sliding
the pedestal stand away from the TV.

Important notes about your LCD TV

The following symptoms are technical limitations
Display technology and are not an indication of malfunction;
therefore, Toshiba is not responsible
resulting from these symptoms.

1) An after image (ghost) may appear on the screen if a fi xed,
non-moving image is displayed for a long period of time.
The after image is not permanent and will disappear in a short
period of time.

2) The LCD panel contained in this TV is manufactured using an
extremely high level of precision technology;
be an occasional pixel (dot of light)
(does not light, remains constantly lit, etc.). This is a structural
property of LCD
not covered under your warranty. Such pixels are not visible
when the picture is viewed from a normal viewing distance.

Note: Interactive video games that involve shooting a “gun” type
of joystick at an on-screen target may not work on this TV.

technology, is not a sign of malfunction, and is

for perceived defects

that does not operate properly

of LCD

however, there may

Notes on handling

Q Do not subject the LCD panel to physical shock, such
it. It may cause unit damage and malfunction.
Q When shipping the unit, the original shipping carton and packing
materials come in handy. For fully protection, repack the unit as it
was originally packed at the factory.
Q Do not use volatile liquids, such as insecticide, near the unit.
Do not leave rubber or plastic products in contact with the unit for
prolonged periods of time.
Doing so will leave marks on the fi nish.

The top and rear panels of the unit may become warm

Q

period of use. This is not a malfunction.
Q When the unit is not in use, always remove the disc and turn off
the power.

as dropping

after a long

Notes on locating the unit

Q When you place this unit near a TV, radio, or VCR, the playback

picture may become poor and the sound may be distorted. In this
case, place the unit away from the TV, radio, or VCR.

Q To avoid damage to this product, never place or store the

TV/DVD in direct sunlight; hot, humid areas; or areas subject to
excessive dust or vibration.

6

J50S0101A.indb 6

Two screws

08.1.9 4:44:46 PM

Prcautions (Continued)/Notes on discs

J50S0101A.indb 7

08.1.9 4:44:50 PM

Notes on moisture condensation

Moisture condensation damages the unit. Please
read the following carefully.

Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day and drops
of water form on the outside of the glass. In the same
way, moisture may condense on this unit·s internal optical
pick-up lens, one of the most crucial internal parts of the unit.

f

o

m

e

o

l

p

i

s

m

a

x

E

n

o

c

Q Moisture condensation may occur in the following

situations:

When you move the unit from a cold area to a warm area.
When you use the unit in a room in which the heat

was just turned on.

When you use the unit in an area where cold air from

an air conditioner directly hits the unit.

When you use the unit in a humid area.

t

u

r

e

s

n

a

e

t

i

d

o

n

!

Optical pick-up

lens

On handling discs

Do not touch the playback side of the disc.

For example, handle the disc so that it is shown in
fi gure below.

Do not attach paper or tape to discs.

Playback side

On cleaning discs

Fingerprints and dust on the disc cause picture and

sound deterioration. Wipe the disc from the center
outwards with a soft cloth. Always keep the disc
clean.

Do not use any type of solvent such as thinner,

benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.

On storing discs

Do not store discs in a place subject to direct sunlight

or near heat sources.

Do not store discs in places subject to moisture and

dust such as a bathroom or near a humidifi er .

Store discs vertically in a case. Stacking or placing

objects on discs outside of their case may cause
warping.

Introduction

Q Never use the unit when moisture condensation
may occur

Using the unit when moisture condensation exists may
damage discs and internal parts. Connect the power
cord of the unit to the wall outlet, turn on the unit,
remove the disc, and leave it for two or three hours.
After two or three hours, the unit will have warmed up
and evaporated any moisture. Leaving the TV
connected to the wall outlet will help prevent moisture
condensation in the TV or DVD Player.

Wait!

Wall outlet

J50S0101A.indb 7

Structure of disc contents

Normally, DVD video discs are divided into titles, and
the titles are sub-divided into chapters. Video CDs and
Audio CDs are divided into tracks.

DVD video disc

DVD video disc

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3

Video CD/Audio CD

Video CD/Audio CD

Track 1 Track 2 Track 3 Track 4 Track 5

Each title, chapter or track is assigned a number, which
is called “title number”, “chapter number” or “track
number” respectively.
There may be discs that do not have these numbers.

7

08.1.9 4:44:50 PM

Introduction

J50S0101A.indb 8

08.1.9 4:44:50 PM

Notes on discs (Continued)

Notes on copyright

The unauthorized recording, use, distribution, or revision
of copyrighted materials including, without limitation,
television programs, videotapes, and DVDs, is prohibited
under the Copyright Laws of the United States and other
countries, and may subject you to civil and criminal liability.

This product incorporates copyright protection technology
that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by
Macrovision Corporation.
Reverse engineering or disassembly is prohibited.

About this owner·s manual

This owner·s manual explains the basic instructions of this
unit. Some DVD video discs are produced in a manner
that allows specifi c or limited operation during playback. As
such, the unit may not respond to all operating command.
This is not a defect in the unit. Refer to instruction notes of
discs.

The following symbol may appear on the TV screen during
operation.

It means that the operation is not permitted by the TV/DVD
or the disc.
For example, sometimes it is unable to stop the playback
of copyright message of the disc when the STOP (Q)
button is pressed. Alternatively, this symbol may also
indicate that the feature is not available for the disc.

Notes on region numbers

The region number of this unit is 1. If region numbers,
which stand for their playable area, are printed on your

ALL

1

or

DVD video disc and you do not fi nd

, disc
playback will not be allowed by the player. (In this case,
the unit will display a message on-screen.)
Some DVDs that have no region code label may still be
subject to area restrictions and therefore not playable.

On Video CDs

This unit supports Video CDs equipped with the PBC
(Version 2.0) function. (PBC is the abbreviation of
Playback Control.) You can enjoy two playback variations
depending on types of discs.

•

Video CD not equipped with PBC function (Version 1.1)

Sound and movie can be played on this unit in the same
way as a DVD.

•

Video CD equipped with PBC function (Version 2.0)

In addition to operation of a Video CD not equipped with
the PBC function, you can enjoy playback of interactive
software with search function by using the menu
displayed on the TV screen (Menu Playback). Some of
the functions described in this owner·s manual may not
work with some discs.

8

Playable discs

This unit can play the following discs.

Disc Mark Contents

DVD
video
discs

Video

CDs

DIGITAL VIDEO

Audio

CDs

®

DivX

The following discs are also available.

DVD-R/RW discs of DVD video format
CD-R/CD-RW discs of CD-DA, Video CD, MP3, WMA,

JPEG or DivX® format

Kodak Picture CD and FUJICOLOR CD format

Some of these discs may be incompatible.

Audio
Video

(moving

pictures)

Audio
Video

(moving

pictures)

Audio

Audio
Video

(moving

pictures)

Disc
Size

12 cm

+

8 cm

12 cm

+

8 cm

12 cm

8 cm

12 cm

+

8 cm

• You cannot play discs other than those listed above.

• You cannot play discs of DVD-RAM, DVD-ROM, CD­ ROM, Photo CD, etc., or non standardized discs even
if they may be labeled as above.

• Some CD-R/RWs cannot be played back depending
on the recording conditions.

• This unit uses the NTSC color system, and cannot
play DVD video discs recorded in any other color
system (PAL, SECAM, etc.).

• This unit can play an 8cm disc. Please do not use a
disc adapter. It may cause trouble.

• Please do not insert any disc of an irregular shape into
the unit, as it may interfere with the function of the unit.

You may not be able to remove it.

• Please do not use after market accessories, such as a

ring protector, as this may cause trouble with the
operation of the unit.

Because of problems and errors that can occur during the
creation of DVD and CD Software and/or the manufacture
of DVD and CD discs, Toshiba cannot assure that the
DVD player contained in this TV will successfully play
every disc bearing the DVD and CD logos.
If you happen to experience any diffi culty playing a DVD
and/or CD disc on the DVD player contained in this TV,
please contact Toshiba Customer Service.

is a trademark of DVD Format/Logo Licensing

Corporation.

Maximum

playback time

Approx. 4 hours

(single sided disc)

Approx. 8 hours

(double sided disc)

Approx. 80 minutes

(single sided disc)

Approx. 160 minutes

(double sided disc)

Approx. 74 minutes

(single sided disc)

Approx. 20 minutes

(single sided disc)

Approx. 74 minutes

(single sided disc)

Approx. 20 minutes

(single sided disc)

It depends on DivX

quality

®

J50S0101A.indb 8

08.1.9 4:44:50 PM

Contents

J50S0101A.indb 9

08.1.9 4:44:51 PM

Introduction

SAFETY INSTRUCTIONS ................................4

Precautions.......................................................6

Notes on discs ..................................................7

Contents ...........................................................9

Identifi cation of controls ..................................10

Connections

Antenna connections ......................................14

Cable TV connections ....................................15

Connecting to optional equipment ..................16

Power source..................................................20

Basic setup

Auto setup ......................................................21

Setting the language.......................................22

To memorize channels.................................... 23

TV operation

TV operation ...................................................26

Labeling channels...........................................28

Labeling video inputs ......................................29

Setting the V-Chip...........................................30

Setting the closed captions.............................34

CC advanced ..................................................35

Adjusting the picture preference .....................36

Picture settings ...............................................36

Viewing the wide-screen picture formats ........37

Film Mode .......................................................38

DNR ................................................................38

Picture control adjustment in the PC mode .... 39

Sound control adjustment ...............................40

Selecting Stereo/Second Audio Program (SAP) ....40

Selecting the audio language ......................... 41

Selecting the HDMI audio input source .......... 41

Using the aspect feature.................................42

Adjusting the back lighting ..............................42

Setting the Auto Shut Off ................................ 43

Resetting your settings ...................................43

Basic playback

Playing a disc .................................................44

Advanced playback

Zooming.......................................................... 47

Locating desired scene................................... 47

Marking desired scenes..................................48

Repeat playback ............................................. 49

A-B Repeat playback ...................................... 49

Program playback........................................... 50

Random playback ........................................... 50

Changing angles..............................................51

Title selection ...................................................51

DVD menu .......................................................51

Changing soundtrack language .......................52

Subtitles ...........................................................52

Disc status .......................................................53

To turn off the PBC ..........................................53

MP3/WMA/JPEG/DivX

and Audio CD operation ..................................54

Repeat, random and program playback

using fi le browser.............................................58

®

Function setup

Customizing the function settings ....................60

Temporary cancel the rating level

by DVD disc .....................................................65

Others

Understanding the Power Return feature ........66

Troubleshooting ...............................................66

Reception disturbances ...................................68

Language code list ..........................................69

Specifi cations ..................................................70

Limited United States Warranty .......................71

Introduction

J50S0101A.indb 9

9

08.1.9 4:44:51 PM

Introduction

J50S0101A.indb 10

08.1.9 4:44:52 PM

Identifi cation of controls

Front

Side

Disc slot

Speaker

Remote sensor

Left Side

44

13

POWER indicator

21

EJECT button

VOLUME (+/–) buttons
CHANNEL

PLAY button

CHANNEL
QSTOP button

MENU button

INPUT/ENTER button

45

26

44

26

44

22 60

Illustration of 19LV505

Adjusting the angle of the base

Approx. 10°

26

16

Approx. 3°

You can adjust the
angle of the
TV-screen for 3°
forward or for 10°
backward from
vertical angle.
Hold the base of the
TV while adjusting
the angle.

10

J50S0101A.indb 10

POWER button

21

Illustration of 19LV505

08.1.9 4:44:52 PM

Rear

J50S0101A.indb 11

08.1.9 4:44:54 PM

Introduction

AC INLET

20

HEAD PHONE jack

COMPONENT VIDEO/AUDIO IN jacks

VIDEO/S-VIDEO/AUDIO IN jack

J50S0101A.indb 11

Antenna jack

14 15

COAXIAL DIGITAL AUDIO

27

17

HDMI IN jack

PC AUDIO IN jack

OUT jack

16 17

PC MONITOR IN jack

20

18 19

19

20

Illustration of 19LV505

11

08.1.9 4:44:54 PM

Introduction

J50S0101A.indb 12

08.1.9 4:44:56 PM

Identifi cation of controls (Continued)

Remote control

The instructions in this manual describe the function on the remote control. See the page in for details.

EJECT button

TV/DVD button

Direct channel selection
buttons (0

-

Numbered buttons (0

DISPLAY button

CH / button

SUBTITLE button

INPUT button
ZOOM button

PLAY MODE button

PLAY button

MENU button

SETUP button

PAUSE button

CH RTN button

SKIP ( ) button

REV button

SLOW ( ) button

TOP MENU button

RETURN button

GAME button

9)

26

49 53

FF button

50

45

44

30

-

9)

5327

26

52

POWER button
SLEEP button

JUMP button
Direct channel selection button ( )

AUDIO SELECT button
VOL +/– button

16
47

MUTE button

*DVD MENU button

ENTER button

44

22

60

45

27
46

46
46

46

51

6055

16

Direction buttons ( / / / )

EXIT/CANCEL button

STOP button
CLOSED CAPTION button

SKIP ( )button

SLOW ( ) button
MARKER button
ANGLE button

REPEAT A-B button

PIC SIZE button

21

27

47

26

52

26

27

51

21

21

21

44

34

46

46

48

51

49

37

*DVD MENU button

Use the DVD MENU button to
display the menu included on
many DVD video discs.
To operate a menu, follow the
instructions in “DVD menu.”

12

J50S0101A.indb 12

SE-R0305

51

08.1.9 4:44:56 PM

Inserting batteries

J50S0101A.indb 13

08.1.9 4:44:57 PM

Introduction

Open the battery compartment

1

cover in the direction of the
arrow.

Install two “R03/AAA” batteries

23

(supplied), paying attention to
the polarity indicated in the
battery compartment.

Replace the compartment
cover.

Operation

• Aim the remote control at the remote sensor and press control buttons to operate.

•

Operate the remote control within 30° angle on either side of the remote sensor, up to a distance of approx. 5 meters.

Approx. 5 meters

Caution:

• Never throw batteries into a fi re.

Note:

• Be sure to use AAA size batteries.

• Dispose of batteries in a designated disposal area.

•

Batteries should always be disposed of with the environment in mind. Always dispose of batteries in accordance with
applicable laws and regulations.

• If the remote control does not operate correctly, or if the operating range becomes reduced, replace batteries with
new ones.

• When necessary to replace batteries in the remote control, always replace both batteries with new ones.

Never mix battery types or use new and used batteries in combination.

•

Always remove batteries from remote control if they are dead or if the remote control is not to be used for an extended

period of time. This will prevent battery acid from leaking into the battery compartment.

J50S0101A.indb 13

13

08.1.9 4:44:57 PM

Connections

J50S0101A.indb 14

08.1.9 4:44:57 PM

Antenna connections

If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system.
If you are using a cable TV service (CABLE), see page 15 for Cable TV connections.

Combination VHF/UHF antenna (Single 75 ohm cable or 300 ohm twin-lead wire)

Antenna

jack

Antenna

jack

Connect the 75 ohm cable from the combination
VHF/UHF antenna to the antenna jack on the back
of the TV/DVD.

If your combination VHF/UHF antenna has a 300

75 ohm coaxial cable
(not supplied)

300-75 ohm matching
transformer (not supplied)

ohm twin-lead wire, use the 300-75 ohm matching
transformer (not supplied).

Combination VHF/UHF antenna (Separate VHF and UHF 300 ohm twin-lead wires)

Antenna

jack

Combiner
(not supplied)

300-75 ohm matching
transformer (not supplied)

Connect the UHF 300 ohm twin-lead wire to the
combiner (not supplied). Connect the VHF 300 ohm
twin-lead wire to the 300-75 ohm matching transformer
(not supplied). Attach the transformer to the combiner ,
then attach the combiner to the antenna jack on the
back of the TV/DVD.

Separate VHF/UHF antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)

14

J50S0101A.indb 14

UHF 300 ohm
twin-lead wire
(not supplied)

Antenna

jack

Combiner
(not supplied)

UHF 300 ohm
twin-lead wire
(not supplied)

VHF 300 ohm
twin-lead wire
(not supplied)

VHF 75 ohm
(not supplied)

Connect the VHF 75 ohm cable and UHF 300 ohm
twin-lead wire to the combiner (not supplied).
Attach the combiner to the antenna jack on the back
of the TV/DVD.

08.1.9 4:44:57 PM

Cable TV connections

J50S0101A.indb 15

08.1.9 4:44:58 PM

This TV/DVD has an extended tuning range and can tune most cable channels without using a Cable TV converter box.
Some cable companies offer “premium pay channels” in which the signal is scrambled. Descrambling these signals for
normal viewing requires the use of a descrambler device which is generally provided by the cable company.

For subscribers to basic cable TV service

Antenna

jack

75 ohm
coaxial cable

For basic cable service not requiring a converter/descrambler
box, connect the Cable TV 75 ohm coaxial cable directly to the
Antenna jack on the back of the TV/DVD.

For subscribers to scrambled cable TV service

If you subscribe to a cable TV service which requires the use of a converter/descrambler box, connect the
incoming 75 ohm coaxial cable to the converter/descrambler box. Using another 75 ohm coaxial cable, connect
the output jack of the converter/descrambler box to the antenna jack on the TV/DVD. Follow the connections
shown below. Set the TV/DVD to the output channel of the converter/descrambler box (usually channel 3 or 4)
and use the converter/descrambler box to select channels.

Incoming 75 ohm

Cable TV

Converter/

descrambler

75 ohm cable to

TV/DVD

Antenna

jack

Connections

For subscribers to unscrambled basic cable TV service with scrambled
premium channels

If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require
the use of a converter/descrambler box, you may wish to use a signal splitter and an A/B Switch box (available
from the cable company or an electronics supply store). Follow the connections shown below. With the switch in
the “B” position, you can directly tune any nonscrambled channels on your TV/DVD. With the switch in the “A”
position, tune your TV/DVD to the output of the converter/descrambler box (usually channel 3 or 4) and use the
converter/descrambler box to tune scrambled channels.

Converter/

descrambler

A/B switch

75 ohm cable

A

to TV/DVD

B

Antenna

jack

J50S0101A.indb 15

Incoming
75 ohm
Cable TV

Splitter

15

08.1.9 4:44:58 PM

Connections

J50S0101A.indb 16

08.1.9 4:44:59 PM

Connecting to optional equipment

Y ou can enjoy VCR, camcorder or TV game with connection to external input.

Using the audio/video inputs

Press INPUT to view a signal from another device connected to your TV/DVD, such
as a VCR player. You can select TV, Video, ColorStream HD, HDMI or PC depending
on which input jacks you used to connect your devices.

Press INPUT on the remote control to display the current signal source.
To change the input source, press INPUT again or press 0-4. (5 is for selection DVD
mode.)

Connecting to a VCR

To playback from the VCR, connect the VCR to the TV/DVD as shown.
Select the “Video” by pressing INPUT repeatedly.

: Signal fl ow

VCR

T o Audio/Video OUT

Audio/Video cable (not supplied)

(yellow)

(white)

(red)

Back side

0-5
CH /

INPUT

GAME

Source Selection

0.TV

1.Video

2.ColorStream HD

3.HDMI

4.PC

5.DVD

[0-5]:Select

To VIDEO/AUDIO(L/R) IN

Connecting to a camcorder

To playback from the camcorder, connect the camcorder to the TV/DVD as shown.
Select the “Video” by pressing INPUT repeatedly.

: Signal fl ow

Camcorder

T o Audio/Video OUT

Audio/Video cable (not supplied)

(yellow)

(white)

(red)

Back side

To VIDEO/AUDIO(L/R) IN

Connecting to a TV Game

You can enjoy playing a TV game on the screen by adjusting to the suitable brightness for your eyes.

1. Connect a TV Game to the TV/DVD.

2. Select the Game mode by pressing GAME. The Game mode screen appears.

• If GAME is pressed during standby mode, the unit turns on automatically and the Game mode screen
appears on the screen.

: Signal fl ow

T o Audio/Video OUT

Audio/Video cable (not supplied)

Note:

• You can also change the TV/DVD screen to the desired mode by pressing the CH / .

• The TV/DVD can also be used as a display device for many video games. However, due to the wide variety of

different types of signal generated by these devices and subsequent hook-up variations required, they have not all
been included in the suggested connection diagrams. You·ll need to consult each component·s Owner·s Manual
for additional information.

• Interactive video games that involve shooting a “gun” type of joystick at on-screen target may not work on this

TV/DVD.

(yellow)

(white)

(red)

Back side

To VIDEO/AUDIO(L/R) IN

16

J50S0101A.indb 16

08.1.9 4:44:59 PM

Connecting to an optional equipment with S-video output

J50S0101A.indb 17

08.1.9 4:45:00 PM

If you connect a VCR with an S-Video cable to the S-VIDEO IN jack on the left side of the TV/DVD, you must
also connect the audio cables to the AUDIO IN jacks as shown below. The S-Video cable only carries the video
signal. The audio signal is separated.
Select the “Video” by pressing INPUT repeatedly.

: Signal fl ow

Ex. VCR with S-Video

To S-VIDEO IN

(white)

To AUDIO (L/R) IN

Back side

(playback)

To S-VIDEO OUT

To Audio (L/R) OUT

S-Video cable (not supplied)

Audio cable (not supplied)

(red)
To S-VIDEO/AUDIO(L/R) IN

Note:

When the S-Video cable and the standard video cable are connected at the same time, the S-video cable takes

•

precedence.

Connecting an optional equipment with ColorStream

Your TV/DVD is capable of using ColorStream® (component video). Connecting your TV/DVD to a component
video compatible DVD player, such as a Toshiba DVD player with ColorStream

®

(Component video) output

®

can greatly enhance picture
quality and performance.
Select the “ColorStream HD” by pressing INPUT repeatedly.

Connections

(white)

Back side

(red)

To COMPONENT
AUDIO (L/R) IN

: Signal fl ow

To Audio (L/R) OUT

Ex. DVD player with Component video

To COMPONENT

(Y, PB, PR) IN

To Component Video OUT

Component video cable

(not supplied)
Audio cable (not supplied)

When using the Component video cable,
an Audio cable must be connected to
COMPONENT AUDIO(L/R) IN jacks.

Note:

• The ColorStream

®

(COMPONENT) inputs on this unit are for use with devices that output 480i, 1080i inter-

laced signals and 480p, 720p progressive signals.

• Refer to the owner·s manual of the connected equipment as well.

• When you connect the unit to other equipment, be sure to turn off the power and unplug all of the equipment

from the wall outlet before making any connections.

• If you place the unit near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the

unit away from the tuner and radio.

17

J50S0101A.indb 17

08.1.9 4:45:00 PM

Connections

J50S0101A.indb 18

08.1.9 4:45:02 PM

Connecting to optional equipment (Continued)

You can enjoy high quality dynamic sounds by connecting the
TV/DVD to optional audio equipment.

Connecting to an amplifi er equipped with a Dolby® Digital decoder

Dolby Digital

Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce
this realistic effect in the home. You can enjoy motion picture and live concert DVD video discs encoded via the Dolby Digital
recording system with this dynamic realistic sound by connecting the TV/DVD to a 6 channel amplifi er equipped with a Dolby
Digital decoder or Dolby Digital processor. If you have a Dolby Surround Pro Logic decoder, you will obtain the full benefi t of
Pro Logic from the same DVD movies that provide full 5.1-channel Dolby Digital soundtracks, as well as from titles with the
Dolby Surround mark.

Amplifi er equipped with a

Dolby Digital decoder

This section uses the following reference mark.

*

: Front speaker
: Rear speaker

: Center speaker
: Signal fl ow

: Sub woofer

Back side

To COAXIAL DIGITAL
AUDIO OUT

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

Manufactured under license
from Dolby Laboratories.
Dolby and the double-D symbol
are trademarks of Dolby
Laboratories.

Connecting to an amplifi er equipped with a DTS® decoder

Digital Theater Systems (DTS)

DTS is a high quality surround technology used in theaters and now available for home use, on DVD video discs or audio CDs.
If you have a DTS decoder or processor, you can obtain the full benefi t of 5.1 channel DTS encoded sound tracks on DVD
video discs or audio CDs.

Amplifi er equipped with

a DTS decoder

To COAXIAL
type digital
audio input

75 Ω coaxial cable (not supplied)

Back side

To COAXIAL DIGITAL
AUDIO OUT

Manufactured under license
under U.S. Patent #: 5,451,942 &
other U.S. and worldwide
patents issued & pending. DTS
and DTS Digital Out are
registered trademarks and the
DTS logos and Symbol are
trademarks of DTS, Inc.
© 1996-2007 DTS, Inc. All Rights
Reserved.

Connecting to an amplifi er equipped with an MPEG audio decoder

MPEG2 sound

You can enjoy motion picture and live concert DVD video discs encoded via the MPEG2 recording system with dynamic
realistic sound by connecting an amplifi er equipped with an MPEG2 audio decoder or MPEG2 audio processor.

18

J50S0101A.indb 18

Amplifi er equipped with an

MPEG2 audio decoder

To COAXIAL
type digital
audio input

Back side

75 Ω coaxial cable (not supplied)

To COAXIAL DIGITAL
AUDIO OUT

08.1.9 4:45:02 PM

Connecting to an amplifi er equipped with a digital audio input

J50S0101A.indb 19

08.1.9 4:45:03 PM

2 channel digital stereo

You can enjoy the dynamic sound of 2 channel digital stereo by connecting an amplifi er equipped with a digital audio input and speaker
system (right and left front speakers).
Note: PCM audio is limited to DVD or CD playback.

Amplifi er equipped with a

Digital audio input

To COAXIAL
type digital
audio input

Back side

To COAXIAL DIGITAL
AUDIO OUT

75 Ω coaxial cable (not supplied)

Note:

• DO NOT connect the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD to the AC-3 RF input of a Dolby Digital Receiver.
This input on your A/V Receiver is reserved for Laserdisc use only and is incompatible with the COAXIAL DIGITAL AUDIO OUT jack
of the TV/DVD.

• Connect the COAXIAL DIGITAL AUDIO OUT jack of the TV/DVD to the “COAXIAL” input of a Receiver or Processor.

• Refer to the owner·s manual of the connected equipment as well.

• When you connect the TV/DVD to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet
before making any connections.

The output sound of the TV/DVD has a wide dynamic range. Be sure to adjust the receiver·s volume to a moderate listening level.

•
Otherwise, the speakers and your hearing may be damaged by a sudden high volume sound.

• Turn off the amplifi er before you connect or disconnect the TV/DVD·s power cord. If you leave the amplifi er·s power on, the speakers
may be damaged.

Connecting to an HDMI or a DVI device

About HDMI

HDMI (High Defi nition Multimedia Interface) supports both video
and audio on a single digital connection for use with DVD players,
DTV, set-top boxes, and other AV devices. HDMI was developed
to provide the technologies of High Bandwidth Digital Content
Protection (HDCP) as well as Digital Visual Interface (DVI) in one
specifi cation. HDCP is used to protect digital content transmitted
and received by DVI-compliant or HDMI-compliant displays.

HDMI has the capability to support standard, enhanced, or high­defi nition video plus standard to multi-channel surround-sound
audio. HDMI features include uncompressed digital video, a
bandwidth of up to 2.2 gigabytes per second (with HDTV signals),
one connector (instead of several cables and connectors), and
communication between the AV source and AV devices such as
DTVs.

HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI licensing LLC.

Back side

Connections

DVI device

HDMI device

To DVI output

Audio cord (not supplied)

or

To HDMI out

To PC AUDIO IN

HDMI - to - DVI adapter cable

(HDMI type A connector)

(not supplied)

HDMI cable (type A connector)

(not supplied)

To HDMI IN

Note:

You must select the corresponding audio input source (HDMI or DVI) on the menu screen (see ”Selecting the HDMI audio

•

input source” on page 41). Otherwise you will only see the image with no sound.

J50S0101A.indb 19

19

08.1.9 4:45:03 PM

Connections

J50S0101A.indb 20

08.1.9 4:45:03 PM

Connections

Connecting to optional equipment (Continued)/
Power source

Connecting to a PC (Personal Computer)

Before you connect this TV/DVD to your PC, change the adjustment of your PC’s Resolution and Refresh rate (60 Hz).
Connect one end of a (male to male) VGA cable to the video card of the computer and the other end to the
MONITOR on the rear of the
connect the audio cord to the audio output of your Multimedia computer and to the AUDIO connector of the PC AUDIO IN jack of
the TV/DVD .
Select “PC” by pressing INPUT repeatedly.
Switch on the computer. The TV/DVD can operate as the computer monitor

To PC
MONITOR IN

Note:

The on-screen displays will have a different appearance in PC mode than in TV mode.

•
If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV/DVD-screen.

•

TV/DVD

Back side

To PC AUDIO IN jack

Audio cord (not supplied)

VGA cable (not supplied)

. Attach the connectors firmly with the screws on the plug.

Monitor Display modes

MODE Resolution Refresh rate
VGA 640x480 60Hz
VGA 720x400 70Hz
SVGA 800x600 60Hz
XGA 1024x768 60Hz
WXGA 1280x768 60Hz
WXGA 1280x720 60Hz
WXGA 1360x768 60Hz

To return to normal mode

Press INPUT again.

In case of a Multimedia computer,

VGA connector PC

Power source

To use AC power source

Connect the AC cord plug into this TV/DVD’s AC INPUT jack.

1.
Connect the AC cord into an AC outlet.

2.

Illustration of
19LV505

Wider Hole
and Blade

AC 120V, 60Hz

AC cord (supplied)

Note:

Never connect the AC line cord plug to other than the specified voltage (120V 60Hz). Use the attached power cord only.

•
If the polarized AC cord does not fit into a non-polarized AC outlet, do not attempt to file or cut the blade. It is the user’s

•
responsibility to have an electrician replace the obsolete outlet.
If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from the AC outlet

•
and plug it back in. The unit should return to normal operation.
If the AC cord plug is plugged in for the first time, wait for approx. 5 seconds before pressing POWER.

•

AC Outlet

20

J50S0101A.indb 20

08.1.9 4:45:03 PM

Basic setup

J50S0101A.indb 21

08.1.9 4:45:05 PM

Auto Setup

The Auto Setup function helps to install your TV/DVD easily.
It leads you the Language selection, Air/Cable selection and Automatic
channel search.

IMPORTANT: Make sure that the antenna or cable TV system
connection is made!

Auto Setup

To turn on the TV/DVD, press POWER.

POWER indicator on the front of the unit

•

1

2

changes green. It may take approx. 10 seconds
for a picture to appear on screen.

Auto Setup menu appears on the screen.
Press ϳ or ϴ to select “Language”, then
press ϵ or ϶ to select your desired language.

Auto Setup

Language

Signal Type Air

Automatic Search

English

Start

Now the “Automatic Search” starts.

5

If you press EXIT/CANCEL, the Automatic

•
Search stops and changes to the TV screen.
After the starting setup is completed, the TV

•

channel appears on the screen.

Auto Setup

Language

Signal Type Air

Automatic Search

Analog Channel Found : 0

Digtal Channel Found :

POWER

ENTER

/ / /

EXIT/CANCEL

Basic setup

English

Start

0

EXIT : End

: Select

Press ϳ or ϴ to select “Signal Type”, then
press ϵ or ϶ to select “Air” or “Cable”.

3

Auto Setup

Language

Signal Type Air

Automatic Search

: Select

Air - VHF/UHF channels
Cable

- Cable TV channels

Press ϳ or ϴ to select “Automatic Search”,
then press ENTER.

4

Auto Setup

Language

Signal Type Air

Automatic Search

: Adjust

: Adjust

English

Start

English

Start

Note:

The Auto Setup function will work only when you

•
press POWER for the first time.
The process of “Automatic Search” may take 15 to

•
30 minutes to complete, depending on your regional
cable service.

J50S0101A.indb 21

: Select

: Adjust

21

08.1.9 4:45:05 PM

Basic setup

J50S0101A.indb 22

08.1.9 4:45:06 PM

Setting the language

This TV/DVD can display the on screen language in English, French or
Spanish.
Select the language you prefer fi rst, then proceed with the other menu options.

Setting the language

To turn on the TV/DVD, press POWER.

POWER indicator on the front of the unit

•

1

2

changes green. It may take approx. 10 seconds
for a picture to appear on screen.

Press MENU. The TV menu screen will
appear. Press ϳ or ϴ to select “Setup”, then
press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Language”.

3

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off

Aspect

Reset >>

: Select

16

: Adjust

Off
On

Press ϵ or ϶ to select the desired language:
English, French (Français) or Spanish

4

(Español).

Press EXIT/CANCEL to return to the normal
screen.

5

Note:

If the unit does not operate properly, or No key

•
operation (by the unit and/or the remote control):

Static electricity, etc., may affect the TV/DVD’s
operation. In such case, disconnect the AC cord once,
then connect it again.

•

If no buttons are pressed for more than about 60
seconds, the MENU screen will return to normal
operation automatically.

POWER

MENU
ENTER

/ / /

EXIT/CANCEL

22

J50S0101A.indb 22

08.1.9 4:45:06 PM

To memorize channels

J50S0101A.indb 23

08.1.9 4:45:07 PM

This TV/DVD is equipped with a channel memory feature which allows channels
to skip up or down to the next channel set into memory, skipping over unwanted
channels. Before selecting channels, they must be programmed into the
TV/DVD·s memory. To use this TV/DVD with an antenna, set the Tuning Band
menu option to the Air mode. When shipped from the factory, this menu option
is in the Cable mode.

ENTER

/ / /

EXIT/CANCEL
MENU

Air/Cable selection

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Channel”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Auto Ch Memory”,
then press ϶ or ENTER.

2

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

Press ϳ or ϴ to select “Signal Type”.

3

Auto Ch Memory

Signal Type Cable

Automatic Search Start

Automatic search

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Channel”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Auto Ch Memory”,
then press ϶ or ENTER.

2

Channel

Add/Delete >>

Auto Ch Memory

>>

Press ϳ or ϴ to select “Automatic Search”,
then press ENTER.

3

Ch Label >>

: Select ENTER:Set

Auto Ch Memory

Signal Type Cable

Automatic Search Stop

>>

Basic setup

Press ϵ or ϶ to select “Air” or “Cable”.

4

Press EXIT/CANCEL to return to the normal
screen.

5

J50S0101A.indb 23

Auto Ch Memory

Signal Type Air

Automatic Search Start

Air - VHF/UHF channels
Cable

- Cable TV channels

Analog Channel Found : 0

Digital Channel Found : 0

: Select

The TV/DVD will begin memorizing all the
channels available in your area.

4

ENTER:Cancel

23

08.1.9 4:45:07 PM

Basic setup

J50S0101A.indb 24

08.1.9 4:45:09 PM

To memorize channels (Continued)

Add/Delete channel

You can select the channel that you want to skip.

ENTER

/ / /

EXIT/CANCEL
MENU

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Channel”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Add/Delete”, then
press ϶ or ENTER.

2

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

: Select ENTER:Set

Press ϳ or ϴ to select “Add/Delete”, then
press ϶ or ENTER.

3

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

Press ϳ or ϴ to select the channel that you
want to skip.

4

Add/Delete

CH Signal

2 Analog

3 Analog Add

3-001 Digital Delete

3-002 Digital Add

4 Analog Delete

: Select

Press ϵ or ϶ to select “Add” or “Delete”,
whichever function you want to perform.

5

Add/Delete

CH Signal

2 Analog

3 Analog Add

>>

Repeat steps 4 - 5 for other channels you
want to add or delete.

6

Press EXIT/CANCEL to return to the normal
screen.

7

3-001 Digital Delete

3-002 Digital Add

4 Analog Delete

: Select

Add

: Adjust

Delete

: Adjust

24

J50S0101A.indb 24

: Select ENTER:Set

08.1.9 4:45:09 PM

ENTER

J50S0101A.indb 25

08.1.9 4:45:10 PM

/ /

EXIT/CANCEL
MENU

Adding Channel

If you find a new channel unregistered, you can add the
new channel into the channel memory.

Tune in the new channel.

1

Press MENU. The TV menu screen will appear.
Press ϳ or ϴ to select “Channel”, then press

2

϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Add/Delete”, then
press ϶ or ENTER.

3

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

>>

Clear All

All channels are deleted from the channel memory.

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Channel”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Add/Delete”, then
press ϶ or ENTER.

2

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

: Select ENTER:Set

>>

Basic setup

Press ϳ or ϴ to select “Adding Channel”,
then press ϶ or ENTER. The new channel will

4

be added into the channel memory.

Press EXIT/CANCEL to return to the normal
screen.

5

J50S0101A.indb 25

: Select ENTER:Set

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Press ϳ or ϴ to select “Clear All”, then press
϶ or ENTER.

3

Add/Delete

Adding Channel >>

Add/Delete >>

Clear All >>

: Select ENTER:Set

Press EXIT/CANCEL to return to the normal
screen.

4

25

08.1.9 4:45:10 PM

TV operation

J50S0101A.indb 26

08.1.9 4:45:12 PM

TV operation

TV operation

To turn on the TV/DVD, press POWER.
(POWER indicator on the front of the unit changes

1

green. It may take approx. 10 seconds for a picture
to appear on screen.)

Adjust the volume level by pressing VOL + or – .
The volume level will be indicated on the screen

2

by blue bars. As the volume level increases, so do
the number of bars. If the volume decreases, the
number of blue bars also decreases.

Set the Signal Type option to the appropriate
position (see “Air/Cable selection” on page 23).

3

Air - VHF/UHF channels
Cable

- Cable TV channels

Press the Direct Channel Selection (0-9, –)
buttons or CH / to select the channel.

4

(If you press only channel number, channel
selection will be delayed for a few seconds.)

POWER
0–9, –

VOL +/–
CH /

TO SELECT ANALOG CHANNELS

1-9: Press 1-9 as needed. Example, to

select channel 2, press 2.

10-99: Press the 2 digits in order. Example, to

select channel 12, press 1, 2.

100-125: Press the 3 digits in order. Example, to

select channel 120, press 1, 2, 0.

TO SELECT DIGITAL CHANNELS

Press the first 3 digits, then press the – button,
followed by the remaining number.
Example, to select channel 015-001, press 0, 1,
5, –, 1.

•

If a channel is selected with only audio content,
“Audio only” will be displayed on the screen.

•

If a channel is selected with a weak digital
signal, “Digital channel signal strength is low”
will be displayed on the screen.
The same program may be available on either
an analog channel or a digital channel. You may
choose to watch either format.

•

If a channel is selected to which you have not
subscribed,
be displayed on the screen.

VHF/UHF/CABLE CHANNELS

Air Cable

VHF
2-13

UHF

14-69

“Digital channel is encrypted” will

VHF
2-13

STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-125 (100) (125)
01 (5A)

26

J50S0101A.indb 26

Note:

If a channel with no broadcast is selected, the sound

•
will automatically be muted.

•

It may take a few seconds for a digital channel picture
to appear on screen after being selected.

08.1.9 4:45:12 PM

TV operation (continued)

J50S0101A.indb 27

08.1.9 4:45:13 PM

SLEEP

DISPLAY
VOL +/–
MUTE

CH RTN

Ϯ DISPLAY

Press DISPLAY to display the current information on the
screen.

62-001 HDTV Moving Picture1

CH-1

Digital Cable Mar 01 00:10 am

No Program Information is available

Sleep Timer

Off

English

When the TV/DVD
receives a digital signal,
the digital information
will appear.

•

Channel number • Station name

•

Channel label (if preset) •

•

V-Chip rating • Signal type

•

Sleep timer • Audio language

•

Program guide • Picture size

•

Resolution • Clock

Full

1080i

Broadcast program name

14

Analog Cable

Sleep Timer

Off

When the TV/DVD
receives a analog signal,
the analog information
will appear.

Channel number • Channel label (if preset)

•
V-Chip rating • Signal type

•
Sleep timer •

•
Picture size • Resolution

•

Full

480i

Audio information (Stereo or SAP)

Press DISPLAY again to clear the call display.

Note:

After a few seconds, DISPLAY screen will return to

•
normal TV-oper ation automatically .

Ϯ CH RTN

This button allows you to go back to the last channel
selected by pressing CH RTN. Press CH RTN again to
return to the last channel you were watching.

Ϯ SLEEP

To set the TV/DVD to

Sleep Timer

0h 10m

turn off after a preset
amount of time, press
SLEEP on the remote
control. The clock will
count up 10 minutes for
each
press of the SLEEP button (Off, 0h 10m, 0h 20m, ...,
2h 0m). After the sleep time is programmed, the display
will appear briefly every ten minutes to remind you that
the sleep timer is operating. To confirm the sleep timer
setting, press SLEEP and the remaining time will be
displayed for a few seconds. To cancel the sleep timer,
press SLEEP repeatedly until the display turns to Off.

Ϯ HEAD PHONES

Insert a stereo headphones (not supplied) with a 1/8” mini
plug into the HEAD PHONE jack on the front panel.
If you connect headphones, the sound from TV/DVD
speakers is muted.

TV operation

Ϯ MUTE

Press MUTE to switch off the sound. The TV/DVD’s
sound will be silenced and “Mute” will appear on the
screen. The sound can be switched back on by pressing
this button again or the VOL + or –.

J50S0101A.indb 27

27

08.1.9 4:45:13 PM

TV operation

J50S0101A.indb 28

08.1.9 4:45:14 PM

Labeling channels

Channel label appear with the channel number display each time you turn on the
TV/DVD, select a channel, or press DISPLAY.
You can choose any four characters to identify a channel.

Labeling channels

ENTER

/ / /

EXIT/CANCEL
MENU

Press MENU in the TV mode. The TV menu
screen will appear. Press then press ϳ or ϴ

1

to select “Channel” menu, then press ϶ or
ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Ch Label”, then
press ϶ or ENTER.

2

The “Ch Label” menu will appear.

Channel

Add/Delete >>

Auto Ch Memory

Ch Label >>

: Select ENTER:Set

Press ϵ or ϶ to select a channel you want to
label, then press ϴ.

3

Ch Label

Channel Number 15-1

Ch Label

Label Clear >>

Press ϵ or ϶ repeatedly until the character
you want appears in the first space.

4

Ch Label

Channel Number 15-1

Ch Label A

Label Clear >>

: Adjust

: Select

The characters rotation as follows:

, () @ / + =

-

SPACE

If the character which you desire appears, press
ENTER.
Repeat this step to enter the rest of the

>>

characters.
If you would like a blank space in the label name,
you must choose the empty space from the list of
characters.

When you finish inputting the label name,
press EXIT/CANCEL to return to the normal

5

screen.

Repeat steps 3-5 for other channel. You can
assign a label to each channel.

6

-

ENTER:Set

28

J50S0101A.indb 28

: Select

: Adjust

To clear a Ch Label

After step 3 above, press ϳ or ϴ to select “Label Clear”,
then press ϶ or ENTER.

Note:

The channel labels will be reset after “Automatic

•
Search” on page 23.

08.1.9 4:45:14 PM

Labeling video inputs

J50S0101A.indb 29

08.1.9 4:45:16 PM

The Video Label feature allows you to label each input source for your TV/DVD.

Labeling video inputs

ENTER

/ / /

EXIT/CANCEL
MENU

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Setup”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Video Label”, then
press ϶ or ENTER.

2

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

Press ϳ or ϴ to select an input which you
want to label.

3

Video Label

Video -

ColorStream HD -

HDMI -

Press ϵ or ϶ to select the desired label for that
input source.

4

Video Label

Video -

ColorStream HD SAT

HDMI -

: Select

: Adjust

TV operation

– : Uses the default label name

VCR : Video cassette recorder
DVD : DVD video
DTV : Digital TV set-top box
SAT : Satellite box
CBL : Cable box
HD : HDMI (only for HDMI input)

16

On

ENTER:Set

Press EXIT/CANCEL to return to the normal
screen.

5

J50S0101A.indb 29

: Select

: Adjust

29

08.1.9 4:45:16 PM

TV operation

J50S0101A.indb 30

08.1.9 4:45:17 PM

Setting the V-Chip

An age limitation can be set to restrict children from viewing or hearing
violent scenes or pictures that you may choose to exclude. The restriction
applies to “TV Rating” and “Movie Rating” if this data is transmitted. You may
set this restriction separately. To use the V-Chip function, you must register
a password.

Notes:
If you forget the password, press DISPLAY four times within

fi ve seconds while the TV is in password entering mode. This
allows you to reset your password.

0–9

ENTER

/ /

MENU

To register a password

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Lock”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Select and enter your password (4 digits)
using Number buttons (0-9), then press

2

ENTER.

Lock

New Password

[0-9]

: Select ENTER:Set

To change a password

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Lock”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Change Password”,
then press ϶ or ENTER.

2

The Change Password screen will appear.

Lock

----

V-Chip On

V-Chip Set >>

V-Chip Set (DTV) >>

Update >>

Change Password >>

: Select ENTER: Set

3

Note:

The V-Chip feature is available only for the U.S. V-Chip

•
system. The Canadian V-Chip system is not supported.

30

J50S0101A.indb 30

Enter the same password again to confirm,
then press ENTER.
The password is now registered.

Lock

Confirm Password

[0-9]

: Select ENTER:Set

----

Enter a new password using Number buttons
(0-9), then press ENTER.

3

Change Password

New Password

Confirm Password

[0-9]

: Select ENTER:Set

Enter the same password again to confirm,
then press ENTER.

4

The new password is now registered.

----

----

08.1.9 4:45:17 PM

To set the V-Chip

J50S0101A.indb 31

08.1.9 4:45:19 PM

0–9

ENTER

/

MENU

/ /

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Lock”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Use Number buttons (0-9) to enter your pass­word, then press ENTER. Then Lock menu will

2

appear.

Lock

Passwo rd

[0-9]

: Select ENTER:Set

Press ϳ or ϴ to select “V-Chip”, then press
ϵ or ϶ to select “On” .

3

Lock

V-Chip On

V-Chip Set >>

V-Chip Set (DTV) >>

Update >>

Change Password >>

: Select

: Adjust

Press ϳ or ϴ to select “V-Chip Set”, then
press ϶ or ENTER.

4

The V-Chip Set Menu appears.

Lock

V-Chip On

V-Chip Set >>

V-Chip Set (DTV) >>

Update >>

Change Password >>

: Select ENTER: Set

TV operation

Press ϳ or ϴ to select which rating will be
used, then press ϶ or ENTER. Each rating

5

below will appear.

V-Chip Set

TV Rating >>

----

Movie Rating >>

: Select ENTER: Set

TV Rating

TV Rating

ALL D L S V FV

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

: Select

ENTER:Set

You can set the rating using age level and genre.

Age:
TV-Y : All children
TV-Y7 : 7 years old and above
TV-G : Gener al audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above

Genre:
ALL : All
D: Dialogue
L: Language
S: Sex
V: Violence
FV : Fantasy Violence

J50S0101A.indb 31

31

08.1.9 4:45:19 PM

TV operation

J50S0101A.indb 32

08.1.9 4:45:20 PM

Setting the V-Chip (continued)

To set the V-Chip (Continued)

Movie Rating

Movie Rating

G

PG

PG-13

R

NC-17

X

MUTE
ENTER

/ / /

EXIT/CANCEL

: Select

G : All ages
PG : Parental guidance
PG-13 : Parental guidance less than 13 years old
R : Under 17 years old parentalguidance

suggested

NC-17 : 17 years old and above
X : Adult only

Press ϳ/ϴ/ϵ/϶ to select the desired rating,
then press ENTER.

6

Press EXIT/CANCEL to return to the normal
screen.

7

To use the TV/DVD after it is protected.

When a program is received that is blocked by the V­Chip, press MUTE, then enter your password.
The protection will be temporarily overridden. If the TV/
DVD is turned off or the channel is changed, the V-Chip
restriction will be reactivated.

ENTER:Set

Note:

•

The V-Chip function is activated only on programs and
input sources that include a rating signal.

32

J50S0101A.indb 32

08.1.9 4:45:20 PM

As a supplement to the standard V-Chip rating system, your television will

J50S0101A.indb 33

08.1.9 4:45:21 PM

be able to download an additional rating system, if such a system becomes
available in the future.

0–9

ENTER

/ /

MENU

To download the additional V-Chip rating system (when available)

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Lock”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Use Number buttons (0-9) to enter your pass­word, then press ENTER. Then Lock menu will

2

appear.

Lock

Passwo rd

[0-9]

: Select ENTER:Set

Press ϳ or ϴ to select “V-Chip Set (DTV)”,
then press ϶ or ENTER.

3

Lock

V-Chip On

V-Chip Set >>

V-Chip Set (DTV) >>

Update >>

Change Password >>

You also need “Update” procedure to update
rating information.

6

TV operation

Note:

You can only download the additional V-Chip rating

•
system when your TV/DVD is receiving a digital signal.
When you download the additional rating system, it

•
may take some time for the download to occur.
The V-Chip rating information and system are not

•
determined or controlled by the TV/DVD.
The standard V-Chip rating system is available

•
whether your TV/DVD is receiving a digital signal or
not, and will block both analog and digital programs.
To set the restriction level using the standard V-Chip
rating system, select “V-Chip Set” in step 3.
The downloadable V-Chip rating system is an evolving

•
technology, and availability, content, and format may
vary.

•

----

You cannot select this feature if the TV/DVD is not
receiving a digital signal for the current station.

If the TV/DVD is not storing the additional
rating system, the TV/DVD will begin down-

4

loading it, which may take some time to be
completed.

Set your preferred content rating limits for the
additional rating system.

5

J50S0101A.indb 33

: Select

: Adjust

33

08.1.9 4:45:21 PM

TV operation

J50S0101A.indb 34

08.1.9 4:45:22 PM

Setting the closed captions

WHAT IS CLOSED CAPTIONING?

This television has the capability to decode and display closed captioned
television programs. Closed captioning will display text on the screen for
hearing impaired viewers or it will translate and display text in another
language.

Setting the closed captions

ENTER

/ / /

EXIT/CANCEL
MENU
CLOSED CAPTION

Press MENU in the TV mode. Press ϳ or ϴ to
select “Setup”, then press ϶ or ENTER.

1

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Closed Caption”,
then press ϶ or ENTER.

2

The Closed Caption menu will appear.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect
Reset >>

: Select

Press ϳ or ϴ to select “CC Setting”, then
press ϵ or ϶ to select “On”.

3

On: Captions will be displayed on the screen.
Off: Captions will not be displayed on the screen.

Closed Caption

CC Setting Off

CC Priority

Analog Caption

Digital Caption

Digital CC Preset
CC Advanced

16

On

ENTER:Set

Digital CC
C1

CS1

Default

>>

Press ϳ or ϴ to select “Analog Caption” or
“Digital Caption”, then press ϵ or ϶ to select

4

the desired Closed Caption mode.

When you select “Analog Caption”, you can
choose C1, C2, C3, C4, T1, T2, T3 and T4.

When you select “Digital Caption”, you can
choose from CS1, CS2, CS3, CS4, CS5 and CS6.

Closed Caption

CC Setting On

CC Priority

Analog Caption

Digital Caption

Digital CC Preset
CC Advanced

: Select

: Adjust

Press ϳ or ϴ to select “CC Priority”, then
press ϵ or ϶ to select “Digital CC” or “Analog

5

CC”.

Note:

Depending on the broadcast signal, some

•
Analog Captions will function with a Digital
broadcast signal. This step prevent that two kind
of captions are overlapping.

Press EXIT/CANCEL to return to the normal
screen.

6

Digital CC
C1

CS1

Default

>>

Note:

You can also display the Closed Caption menu screen by pressing CLOSED CAPTION on the remote control.

•
Digital caption feature is not available for analog channel.

•

Important Note:
If text is not available in your viewing area, a black rectangle may appear on-screen. If this happens, set
“CC Setting” to “Off”.

34

J50S0101A.indb 34

: Select

: Adjust

08.1.9 4:45:22 PM

CC advanced

J50S0101A.indb 35

08.1.9 4:45:23 PM

When you have selected Custom as the display method, you can adjust the
various setting listed below as follows:

This feature is designed to customize Digital Captions only.

CC advanced

ENTER

/ / /

EXIT/CANCEL
MENU

Press MENU in the TV mode. Press ϳ or ϴ to
select “Setup”, then press ϶ or ENTER.

1

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Closed Caption”,
then press ϶ or ENTER.

2

The Closed Caption menu will appear.

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

Press ϳ or ϴ to select “Digital CC Preset”,

then press ϵ or ϶ to select “Custom”.

3

Closed Caption

CC Setting On

CC Priority

Analog Caption

Digital Caption

Digital CC Preset
CC Advanced

: Select

Press ϳ or ϴ to select “CC Advanced”, then
press ϶ or ENTER.

4

The CC Advanced menu will appear.

Closed Caption

CC Setting On

CC Priority

Analog Caption

Digital Caption

Digital CC Preset
CC Advanced

: Select

16

: Adjust

: Adjust

On

ENTER:Set

Digital CC
C1

CS1

Custom
>>

Digital CC
C1

CS1

Custom
>>

Press ϳ or ϴ to select the desired item,
then press ϵ or ϶ to change the setting.

5

CC Advanced

Text Size Auto

Text Type Auto

Text Edge Auto

Text Color Auto

Text Opacity Auto

Background Color Auto

Background Opacity Auto

: Select

: Adjust

You can select from among the following items
and parameters.

Text Size:

Auto, Small, Standard, Large

Text Type: Auto, Style1, Style2, Style3,

Style4, Style5, Style6, Style7

Text Edge:

Auto, None, Raised, Depressed,
Uniform, Left Shadow, Right
Shadow

Text Color:

Auto, Black, White, Red, Green,
Blue, Yellow, Magenta, Cyan

Text Opacity:

Auto, Transparent, T r anslucent,
Solid, Flashing

Background
Color:

Background
Opacity:

Auto, Black, White, Red, Green,
Blue, Yellow, Magenta, Cyan

Auto, Transparent, T r anslucent,
Solid, Flashing

Press EXIT/CANCEL to return to the normal
screen.

6

Note:

You cannnot select “CC Advanced” in the menu

•
before set “Digital CC preset” to “Custom”.
You cannot set the Closed Caption “Text Color” and

•
“Background Color” as the same color.

TV operation

J50S0101A.indb 35

35

08.1.9 4:45:23 PM

TV operation

J50S0101A.indb 36

08.1.9 4:45:24 PM

Adjusting the picture preference/
Picture settings

You can select four picture modes—Sports, Standard, Movie and Memory—
as described in the following table:

Picture settings are factory preset but you can adjust them individually as
follows:

ENTER

/ / /

EXIT/CANCEL
MENU

Adjusting the picture preference

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Picture”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Picture Preference”.

2


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode
PC Setting >>
DNR On

: Select

Press ϵ or ϶ to select a mode you want to
adjust.

3


Picture Setting >>
Picture Preference Standard
Picture Size >>
Film Mode
PC Setting >>
DNR On

: Select

Mode Picture Quality

Sports
Standard Standard picture quality (factory-set)
Movie Movie-like picture setting (factory-set)
Memory Your personal preferences (set by

Bright and dynamic picture (factory-set)

you; see “Picture settings” at right).

On

: Adjust

On

: Adjust

Picture settings

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Picture”, then press ϶ or ENTER.
Press ϳ or ϴ to select “Picture Setting”.

2


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode
PC Setting >>
DNR On

: Select

Press ϳ or ϴ to select the item you want to
adjust. Press ϵ or ϶ to adjust the setting.

3

Picture Setting

Brightness
Contrast
Sharpness
Color
Tint
Color Temperature Cool

: Select ENTER:Set

ϵ϶

Brightness
Contrast decrease
Sharpness makes picture
Color be pale color be brilliant color

Tint be reddish color be greenish

Color T emperatur e

Cool Bluish
Standard Neutral
Warm Reddish

After your desired setting, press EXIT/
CANCEL to return to the normal screen.

5

decrease
brightness

contrast
softer

Picture Quality

increase
brightness

increase
contrast

makes picture
clearer

color

: Adjust

25
50
25
25

0

: Adjust

On

4

36

J50S0101A.indb 36

After your desired setting, press EXIT/
CANCEL to return to the normal screen.

Note:

The Contrast default setting is set to maximum at the

•
factory.

08.1.9 4:45:24 PM

Viewing the wide-screen picture formats

J50S0101A.indb 37

08.1.9 4:45:26 PM

You can view programs in a variety of picture sizes— Natural, Theather
Wide1, Theather Wide2, Theather Wide3 and Full.

Viewing the wide-screen picture formats

0-4

ENTER

/ /

EXIT/CANCEL
PIC SIZE

Press MENU. Press ϳ or ϴ to select “Picture”,
then press ϶ or ENTER.

1

Press ϳ or ϴ to select “Picture Size”, then
press ϶ or ENTER to display Picture Size

2

menu. Press ϳ/ϴ or corresponding Number
button (0-4) to select the desired picture size,
as described below and on the next page.

Picture Size

0.Natural

1.Theater Wide1

2.Theater Wide2

3.Theater Wide3

4.Full

[0-4]:Select

Note:

•

Selectable picture sizes may vary depending on the
input source or broadcast signal.

•

Picture Size menu also can be displayed by pressing

PIC SIZE on the remote control.

Press EXIT/CANCEL to return to the normal
screen.

3

Natural picture size

In some cases, this image will display the size of
standard 4:3 with a gray side bar.

Theater Wide2 picture size (for letter box
programs)

The entire picture is uniformly enlarged—it is stretched
the same amount both wider and taller (retains its
original proportion).

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

Note:

This picture size is not available on 22LV505.

•

Theater Wide3 picture size (for letter box programs
with subtitles)

To fill the width of the screen, it is extended horizontally.
However; it is only slightly extended at the top and the
bottom.

The top and bottom edges of the picture may be hidden.

A B C D E F G - - - - - - - - - - - - - - - -

Note:

To select this picture size on 22LV505, select

•
“Theater Wide2”.

Full picture size (for 16:9 source programs)

Full will display the picture at the maximum size.

A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -

TV operation

Theater Wide1 picture size (for 4:3 format
programs)

To fill the screen, the right and left edges are extended,
however; the center of the picture remains near its
former ratio.
The top and bottom edges of the picture may be hidden.

J50S0101A.indb 37

Note:

•

Some High Definition and/or Digital broadcasts may
not allow you to change the picture size.

•

19LV505/19LV506: In COMPONENT/HDMI mode
with a scanning rate of 720p or 1080i, only the
Theater Wide2 and Full picture size features are
available.

•

22LV505: In COMPONENT/HDMI mode with a
scanning rate of 720p or 1080i, picture size feature
will not work.

•

In PC Mode, only the Natural and Full picture size
features are available. Additionally this feature will not
work when display mode is WXGA.

37

08.1.9 4:45:26 PM

TV operation

J50S0101A.indb 38

08.1.9 4:45:27 PM

Film Mode/DNR

A smoother motion may be obtained by setting the Film Mode to “On” when
you view a DVD.

DNR (Digital Noise Reduction) can reduce the roughness of the picture.
(This function is available only for analog broadcast.)

ENTER

/ / /

EXIT/CANCEL
MENU

Film Mode

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Picture”, then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Film Mode”.

2


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode On
PC Setting >>
DNR On

: Select

Press ϵ or ϶ to select “On” or “Off”.

3


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode Off
PC Setting >>
DNR On

: Select

Press EXIT/CANCEL to return to the normal
screen.

4

: Adjust

: Adjust

DNR

Note:

The PC settings are not effective for other input

•
modes.

Press MENU in the TV mode. Then press ϳ or
ϴ to select “Picture”, then press ϶ or ENTER.

1

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “DNR”.

2


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode On
PC Setting >>
DNR On

: Select

Press ϵ or ϶ to select “On” or “Off”.

: Adjust

3


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode On
PC Setting >>
DNR Off

: Select

: Adjust

Note:

A smoother motion may be obtained by setting the Film

•
Mode to “On” when you view a DVD from the DVD player
connected with ColorStream (component video) inputs.

38

J50S0101A.indb 38

08.1.9 4:45:27 PM

Picture control adjustment in the PC mode

J50S0101A.indb 39

08.1.9 4:45:29 PM

You can adjust to optimize the performance of the TV/DVD in the PC mode.

Picture control adjustment in the PC mode

ENTER

/ / /

EXIT/CANCEL
MENU

Press INPUT, then press ϳ/ϴ or 4 to select
the PC mode.

1

Press MENU. Then press ϳ or ϴ to select
“Picture”, then press ϶ or ENTER.

2

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “PC Setting”, then

press ϶ or ENTER.

3


Picture Setting >>
Picture Preference Sports
Picture Size >>
Film Mode On
PC Setting >>
DNR On

: Select

Press ϳ or ϴ to select the desired item you

want to adjust.

4

PC Setting

Hor Position

Ver Position

Clock

Phase

: Adjust

25

25

0

25

Press ϵ or ϶ to adjust the setting.

5

Hor Position: To adjust the horizontal position of

the image on the PC mode.

Ver Position: To adjust the vertical position of

the image on the PC mode.

Clock: To minimize any vertical bars

or stripes visible on the screen

Phase: This must be adjusted after the

After adjusting, press ENTER to return to the
PC Setting menu. Then continue to adjust the

6

other items.

Press EXIT/CANCEL to return to the normal
screen.

7

background.
frequency of the PC mode has

been set to 60Hz to optimize
picture quality (page 14).

TV operation

J50S0101A.indb 39

: Select ENTER:Set

: Adjust

39

08.1.9 4:45:29 PM

TV operation

J50S0101A.indb 40

08.1.9 4:45:30 PM

Sound control adjustment/
Selecting Stereo/Second Audio Program (SAP)

The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound.
MTS also can transmit a second audio program (SAP) containing a second
language or other audio information.
When the TV/DVD receives a stereo or SAP broadcast, the word “Stereo” or
“SAP” displays on-screen every time you press DISPLAY.

ENTER

/ / /

EXIT/CANCEL
MENU

Sound control adjustment

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Audio” , then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select the item you want to
adjust. Then press ϵ or ϶ to adjust each

2

setting.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English
HDMI Audio HDMI

: Select

15
15

0

: Adjust

Selecting Stereo/Second
Audio Program (SAP)

Press MENU in the TV mode. Press ϳ or ϴ to
select “Audio”, then press ϶ or ENTER.

1

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “MTS”, then press ϵ or
϶ to select “Stereo”.

2

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English
HDMI Audio HDMI

: Select

15
15

0

: Adjust

3

40

J50S0101A.indb 40

Bass: Press ϵ or ϶ to adjust the bass sound.
Treble: Press ϵ or ϶ to adjust the treble

sound.

Balance: Press ϵ or ϶ to obtain an equal sound

level from both speakers.

After you desired setting, press EXIT/CANCEL
to return to the normal screen.

Press EXIT/CANCEL to return to the normal
screen.

3

Note:

Generally you can leave your TV in stereo mode

•
because the TV automatically outputs the type of
sound being broadcast (stereo or mono).
If the stereo sound is noisy, select “Mono” to reduce

•
the noise.

To listen to a second audio program (SAP)

Press ϵ or ϶ to select “SAP” in step 2 above. The TV
speakers will output the second audio program instead
of normal audio.

08.1.9 4:45:30 PM

Selecting the audio language/

J50S0101A P36-43.indd 41

08.1.9 5:12:15 PM

Selecting the HDMI audio input source

When two or more audio languages are included in a digital signal, you can
select one of the audio language. (This function is available only for digital
broadcast.)

When you use PC AUDIO IN jacks with HDMI or DVI device, you must select
HDMI audio input source from “HDMI” or “DVI”.

0-6

ENTER

/ / /

EXIT/CANCEL
MENU

Selecting the audio language

Press MENU in the TV mode. Then press ϳ or
ϴ to select “Audio” , then press ϶ or ENTER.

1

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Audio Language”,
then press ϶ or ENTER to display the Audio

2

Language menu.

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English
HDMI Audio HDMI

: Select

Press ϳ/ϴ or Number buttons (0-6) to select

your desired language.

3

15
15

0

: Adjust

Audio Language

0. English

1. Language 1

2. Language 2

3. French

4. Language 3

5. Spanish

6. No Info

[0-6]: Select

Selecting the HDMI audio input
source

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Audio” , then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “HDMI Audio”. Then
press ϵ or ϶ to select “HDMI” or “DVI”.

2

Audio

Bass

Treble

Balance

MTS Stereo

Audio Language English
HDMI Audio HDMI

: Select

HDMI: When you connect the HDMI device to

the TV, select this setting.

DVI: When you connect the DVI device to the

Press EXIT/CANCEL to return to the normal
screen.

3

TV with analog audio cords, select this
setting.

15
15

0

: Adjust

TV operation

After you desired setting, press EXIT/CANCEL
to return to the normal screen.

4

J50S0101A P36-43.indd 41

41

08.1.9 5:12:15 PM

TV operation

J50S0101A.indb 42

08.1.9 4:45:33 PM

Using the aspect feature/
Adjusting the back lighting

When the Aspect feature is set to On and the TV receives a 480i signal, the
picture size is automatically selected (as described in the following table).

The Backlight feature adjusts the screen brightness for improved picture
clarity.

ENTER

/ / /

EXIT/CANCEL
MENU

Adjusting the back lightingUsing the aspect feature

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Setup” , then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Aspect”.
Press ϵ or ϶ to select “On” or “Off”.

2

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

After you desired setting, press EXIT/CANCEL
to return to the normal screen.

3

Aspect ratio of signal

source

Automatic aspect size

(When Aspect is On)

16

4:3 Normal Natural

16:9 Full Full

4:3 Letter box Theater Wide2

Not defi ned User-set mode

On

ENTER:Set

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Setup” , then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Backlight”.

2

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

Press ϵ or ϶ to adjust the setting.

16

3

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

After you desired setting, press EXIT/CANCEL
to return to the normal screen.

4

8

On

ENTER:Set

On

ENTER:Set

42

J50S0101A.indb 42

08.1.9 4:45:33 PM

Setting the Auto Shut Off/

J50S0101A P36-43.indd 43

08.1.9 5:12:17 PM

Resetting your settings

If the Auto Shut Off feature is On, a station being viewed stops broadcasting
and the TV is not operated, the TV will automatically shut itself off after 15
minutes.

The Reset function returns your settings to the factory settings.

Resetting your settingsSetting the Auto Shut Off

ENTER

/ / /

EXIT/CANCEL
MENU

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Setup” , then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Auto Shut Off”.
Press ϵ or ϶ to select “On” or “Off”.

2

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

After you desired setting, press EXIT/CANCEL
to return to the normal screen.

3

16

On

ENTER:Set

Press MENU in the TV mode. The TV menu
screen will appear. Press ϳ or ϴ to select

1

“Setup” , then press ϶ or ENTER.

Main Menu


Audio

Channel

Lock

Setup

: Select ENTER:Set

Press ϳ or ϴ to select “Reset”.

2

Press ϶ or ENTER to return your settings to

the factory settings.

3

Setup

Closed Caption >>

Language English

Video Label >>

Backlight

Auto Shut Off Off

Aspect

Reset >>

: Select

TV operation

16

On

ENTER:Set

J50S0101A P36-43.indd 43

“Reset” will appear on the screen approx. 3

seconds, then it returns to the normal

4

Note:

The Reset function returns your picture quality

•
adjustments to the following factory settings:

Picture Setting

Brightness ......center (25)

Contrast ............ max (50)

Sharpness......center (25)

Color ..............center (25)

Tint ...................center (0)

Color Temperature ... Cool

Picture Preference ....Sports

Audio

Bass ...............center (15)

Treble .............center (15)

Balance ............center (0)

Film Mode .......................On

PC Setting

Hor Position ...center (25)

Ver Position....center (25)

Clock ................center (0)

Phase.............center (25)

43

08.1.9 5:12:17 PM

Basic playback

J50S0101A.indb 44

08.1.9 4:45:36 PM

Playing a disc

This section shows you the basics on how to play a disc.

CAUTION

Keep your fi ngers well clear of the disc slot when disc is
loading or unloading. Neglecting to do so may cause serious
personal injury.

DVD
VCD

Basic playback

CD

Preparations:

• When connecting to other equipment, turn the power off.

EJECT
VOLUME+/–

PLAY
STOP

POWER

TV/DVD

POWER

+

VOL

/–

ENTER

/ / /

PLAY
STOP

Press POWER on the unit or on the remote con­trol to turn on the unit.

1

• POWER indicator on the front of the unit changes
green. It may take approx. 10 seconds for a picture
to appear on screen.

• Every time you press POWER, the TV/DVD starts
from TV mode.

• When using an amplifi er, switch on the amplifi er.

Press TV/DVD on the remote control to select DVD
mode.

2

The DVD startup screen will appear on the TV screen.

Load a disc in the disc slot.

3

• Load the disc in the disc slot with the label side fac-

ing forward. (If the disc has a label.) Hold the disc
without touching either of its surfaces, align it with
the guides, and place it in position.

• If a disc is inserted during some modes other than

DVD mode, it may switch to DVD mode and then
playback may be begun automatically.

On the TV screen, “ ” changes to “Reading” and
then playback commences.

4

Reading

A menu screen will appear on the TV screen if the
disc has a menu feature.

Press / or / on the remote control to
select title, then press ENTER. Title is selected and
play commences.

Press VOLUME + or – to adjust the volume.

5

Press STOP to end playback.

6

Q To start playback in the stop mode

Press PLAY.

QResuming facility

• The unit records the stopped
point, depending on the disc.

“ ” appears on the screen.

Press PLAY to resume playback
(from the scene point).

• If you press STOP again

(“Q” appears on the TV screen.),

the unit will clear the stopped
point.

Volume : 25

44

J50S0101A.indb 44

Note:
If the unit does not operate properly:

Static electricity, etc., may affect the TV/DVD·s operation. In such
case, disconnect the AC cord, then connect it again.

08.1.9 4:45:36 PM

To obtain a higher quality picture

J50S0101A.indb 45

08.1.9 4:45:39 PM

Occasionally, some picture noise may appear on the TV screen while playing a

DVD video disc because the high resolution pictures on these discs include a
lot of information. In such case, you may reduce the Sharpness with the Picture
Setting menu (see page 36).

About

The

DVD VCD CD

DVD VCD CD

icons on the heading bar show the playable discs for the

function described under that heading.

: You can use this function with DVD video discs.

VCD

: You can use this functio n with Video CDs.

CD

: You can use this function with Audio CDs and CD-R/RW CDs.

DVD
VCD

Basic playback (continued)

CD

To pause playback (still mode)

Press PAUSE during playback.

To resume normal playback,
press PLAY.

• The sound is muted during still
mode.

To remove the disc

Press EJECT.

Remove the disc after the disc comes
out.

To stop playback

Press STOP.

EJECT

PLAY
STOP

PAUSE

Basic playback

Note:

• If a non-compatible disc is loaded, “Incorrect Disc”, “Region Code Error” or “Parental Error” will appear on the TV screen

according to the type of loaded disc. In this case, check your disc again (see pages 7 and 64).

• Some discs may take a minute or so to start playback.

• When you set a single-faced disc label downwards (ie. the wrong way up), “Reading” will appear on the display for a few

minutes and then “Incorrect Disc” will continue to be displayed.

• Some discs may not work the resuming facility.

• Resuming cannot function when you play a PBC-featured Video CD while the PBC is on. To turn off the PBC, see page 53.

• Some playback operations of DVDs may be intentionally fi xed by software producers. Since this unit plays DVDs according

to the disc contents the software producers designed, some playback features may not be available. Also refer to the
instructions supplied with the DVDs.

• Do not move the unit during playback. Doing so may damage the disc.

• Use the EJECT to unload and eject the disc.

• Do not put any objects other than discs on the disc slot. Doing so may cause the unit to malfunctions.

• In many instances, a menu screen will appear after playback of a movie is completed. Prolonged display of an on-screen

menu may damage your television set, permanently etching that image onto its screen. To avoid this, be sure to press

POWER on the remote control once the movie is completed.

• There may be a slight delay between the button is pressed and the function activates.

J50S0101A.indb 45

45

08.1.9 4:45:39 PM

Basic playback

J50S0101A.indb 46

08.1.9 4:45:41 PM

Playing a disc (Continued)

DVD
VCD

Playing in fast reverse or fast forward directions

CD

Press REV or FF during playback.

REV: Fast reverse playback
FF: Fast forward playback

Each time you press REV or FF
button, the playback speed changes.

DVD

Playing frame by frame

VCD

To resume normal playback

Press PLAY.

Note:

• The TV/DVD mutes sound during reverse and forward scan
of DVD/VCD/Audio CD discs.

• The playback speed may differ depending on the disc.

• You can use fast reverse/fast forward playback for DivX® CD.

PAUSE
PLAY

SKIP /
REV / FF

SLOW /

Press PAUSE during still playback.

Each time you press PAUSE, the

To resume normal playback

Press PLAY.

picture advances one frame.

Note:

• The sound is muted during frame by frame playback.

• You can use frame by frame playback for DivX® CD.

DVD

Playing in slow-motion

VCD

Press SLOW (REVERSE) or (FORWARD)
during playback.

To resume normal playback

Press PLAY.

Each time you press the button, the
slow-motion speed changes.

DVD
VCD

Locating a chapter or track

CD

Note:

• The sound is muted during slow-motion playback.

• The Video CD cannot play Reverse Slow.

Press SKIP or repeatedly to display the chapter or track number you want.

Playback starts from the selected chapter or track.

To locate succeeding chapters or tracks.

Playback starts from the beginning of
the current chapter or track.
When you press twice in quick successions,
playback starts from the beginning of
the preceding chapter or track.

Note:

• A “Prohibition” symbol “” may appear at the upper right of the screen. This symbol means either the feature you tried is not
available on the disc, or the TV/DVD cannot access the feature at this time. This does not indicate a problem with the

TV/DVD.

46

J50S0101A.indb 46

08.1.9 4:45:41 PM

Advanced playback

J50S0101A P47-54.indd 47

08.1.9 5:13:04 PM

Zooming/Locating desired scene

This unit will allow you to zoom in on the frame image. Y ou can then make
selections by switching the position of the frame.

Use the title, chapter and time recorded on the DVD disc to locate the
desired point to playback. In the case of VCD/Audio CD discs, time and
track are used to locate the desired point to playback.
To check the title/track, chapter/track and time, press DISPLAY.

DVD
VCD

Zooming

CD

DVD
VCD

Locating desired scene

CD

0–9
JUMP

DISPLAY
ZOOM

/ / /

ENTER
EXIT/CANCEL

Press ZOOM during playback.

1

Press / / / to view a different part of the
frame.

2

In the zoom mode, press ZOOM repeatedly to
return to a 1:1 view ( Off).

3

The center part of the image will be
zoomed in.
Each press of ZOOM will change
the ZOOM
and 3 (x 2.0).

1 (x 1.3), 2 (x 1.5)

You may move the frame from
the center position to UP , DOWN,
LEFT or RIGHT direction.

Press JUMP during playback or resume stop mode.

1

Jump

Titl e
Chapter
Time

1

Press or to select the “Title/Track”,
ter” or

“Time”

2

Press Number buttons (0–9) to input the number.

.

Jump

Titl e
Chapter
Time

“Chap-

Advanced playback

3

Jump

Title
Chapter 12
Time

• If you input a wrong number, press
EXIT/CANCEL.

• Refer to the package supplied with
the disc to check the numbers.

Note:

• You can select the Pause, Slow or Search playback in the
zoom mode.

• Some discs may not respond to zoom feature.

• Zoom function can be used for DivX® CD.

J50S0101A P47-54.indd 47

Press ENTER. Playback starts.

4

Note:

• In case of the Audio CD and Video-CD, only Track and Time

can be selected.

• In case of the Video-CD playback with PBC, the JUMP does
not work. To turn off PBC, see page 53.

• Only Time search function can be used for DivX® CD.

• When you change the title,
playback starts from Chapter 1 of
the selected title.

• Some discs may not work in the
above operation.

47

08.1.9 5:13:04 PM

Advanced playback

J50S0101A.indb 48

08.1.9 4:45:45 PM

Marking desired scenes

The unit stores the points that you want to watch again up to 3 points.
You can resume playback from each scene.

ENTER

/

EXIT/CANCEL

MARKER

DVD

Marking the scenes

VCD

Press MARKER during playback.

1

Select the blank Marker using or .
Then press ENTER to mark the desired scene.

2

• Repeat this procedure to mark the
other 2 scenes.

Press MARKER to clear the display.

3

Note:

• Some discs may not work with the marking operation.

• The marking is cancelled when you eject the disc or turn the
power off.

• Some subtitles recorded around the marker may fail to

appear.

• In case of Video CD with PBC, Marker function is prohibited.

DVD

Returning to the scenes

VCD

Press MARKER during playback or stop mode.

1

Press or to select the Marker 1-3.

2

Press ENTER.

3

Playback starts from the marked
scene.

Q To cancel the Marker

Follow the above steps 1~2, then press EXIT/CANCEL.

48

J50S0101A.indb 48

08.1.9 4:45:45 PM

Repeat playback/A-B Repeat playback

J50S0101A.indb 49

08.1.9 4:45:46 PM

PLAY MODE
ENTER

PLAY
SKIP /

REPEAT A-B

DVD

Repeat playback

VCD

Press PLAY MODE during playback or stop
mode.

1

[DVD]
Press ENTER repeatedly to select “Chapter”

2

or “Title”.

The unit automatically starts
repeat playback after fi nishing
the current title or chapter.

Play Mode

Repeat : Off

[Video CD]
Press
Press ENTER repeatedly to select “Track” or

“All”.

to select “Repeat”.

The unit automatically starts
repeat playback after fi nishing
the current track.

Play Mode

Mode : Off

Repeat : Off

DVD
VCD

A-B Repeat playback

CD

A-B repeat playback allows you to repeat a section between
two selected points.

Press REPEAT A-B during playback.

1

Press REPEAT A-B again.

2

The start point is selected.

A

The end point is selected. Playback
starts at the point that you selected.
Playback stops at the end point and
returns to Point A automatically, then
starts again.

AB

Advanced playback

• If you set the repeat mode during stop mode,
press PLAY to start Repeat playback.

Press PLAY MODE again to clear the screen.

3

To resume normal playback

Select Repeat : “Off” in step 2.

Note:

• Some discs may not work with the repeat operation.

• In case of Video CD with PBC, Repeat function is
prohibited during playback.

• Chapter/Track repeat function is canceled whenever SKIP

or is pressed.

J50S0101A.indb 49

To resume normal playback

Press REPEAT A-B again.
“

Note:

• In A-B Repeat mode, subtitles near the A or B locations
may not be displayed.

• You cannot set the A-B Repeat for the scenes that include
multiple angles.

• A-B Repeat playback does not work when Repeat playback
is activated.

• You may not be able to set A-B Repeat during certain
scenes of the DVD.

• A-B Repeat does not work with an interactive DVD and
MP3/WMA/JPEG CD.

• In case of Video CD with PBC, A-B Repeat is prohibited.

” appears on the screen.

Off

49

08.1.9 4:45:46 PM

Advanced playback

J50S0101A.indb 50

08.1.9 4:45:48 PM

Program playback/Random playback

You can arrange the playback order of tracks on the disc. And the
unit can also select tracks at random and playback them. These
features work for Video CD.

For Audio CD and MP3/WMA CD, please see “Random playback”
(Audio CD/MP3/WMA/JPEG/DivX
(Audio CD/MP3/WMA/JPEG/DivX

VCD

VCD

Program playback

®

)58 and “Program playback”

®

)59.

0–9

PLAY MODE
ENTER

/ /

/

EXIT/CANCEL
PLAY

Press PLAY MODE in the stop mode.

1

Mode : Off

Repeat : Off

Play Mode

Program Playback

Press or to select “Mode”, then press
ENTER repeatedly to select “Program”.

2

Mode : Program

Repeat : Off

Play Mode

Program Playback

Press / to select the programming position.
Press

3

to input the track.

/ and then use

To program others, repeat this step.

•

Number buttons (0–9)

• If you input a wrong number, press

EXIT/CANCEL.

Play Mode

Program Playback

CD

VCD

Random playback

Mode : Program

Repeat : Off

1 – – –

2 – – –

3 – – –

1 – – –

2 – – –

3 – – –

1 9

2 – – –

3 – – –

Press
press

4

and press ENTER.

/

to return to the left column, then

/

to select the “Program Playback”

The programs you selected will start to playback in order.

• To resume normal playback,
select Mode: “Off” in step 2.

Mode : Program

Repeat : Off

Play Mode

Program Playback

1 9

2 3

3 11

Q To change the program

1. Select Mode to “Program” (as step 2), press
to select the track number you want to change, then
press EXIT/CANCEL.

2. Press Number buttons (0–9) to input the new track
number.

/ / /

Q To clear the program one by one

Select Mode to “Program”, press

track number. Then press EXIT/CANCEL.

/ / /

to select the

Q To clear all the programs

At the left column, press

Then press ENTER.

Note:

• In playing back the Video CD with PBC, you cannot set

Program playback.

• The program is cancelled when you eject the disc or turn the

power off.

/

to select “Clear Program”.

1
2

50

J50S0101A.indb 50

Press PLAY MODE during playback or stop
mode.

Press / to select “Mode”, then press
ENTER repeatedly to select “Random”.

Mode : Random

Repeat : Off

Play Mode

Program Playback

1 – – –

2 – – –

3 – – –

Press PLAY

3

.

The Random Playback will start.

• If you set “Random” during playback mode,
Random playback will begin after the track that is
currently being played has ended.

• To resume normal playback,
select Mode: “Off” in step 2.

Note:

• In case of Video CD with PBC, you cannot set Random
function during playback.

08.1.9 4:45:48 PM

Changing angles/Title selection/DVD menu

J50S0101A.indb 51

08.1.9 4:45:49 PM

DVD MENU

/ / /
ENTER
PLAY

ANGLE
TOP MENU

Changing angles

When playing back a disc recorded with multi-angle facility, you can change the angle that you are viewing the scene from.

Press ANGLE during playback.

The current angle will appear.

1

1/2

Press ANGLE repeatedly until the desired angle
is selected.

2

Note:

• Depending on the DVD, you may not be able to change the
angle even if multi-angles are recorded on the DVD.

Title selection

Two or more titles are recorded on some discs. If the title menu is recorded on the disc, you can select the desired title.

Press TOP MENU during playback.

1

Press / / / to select the desired title.

Title menu appears on the screen.

Press ENTER or PLAY.

3

The playback of the selected title will
start.

2

Note:

•

Depending on the DVD, you may not be able to select the title.

•

Depending on the DVD, a “title menu” may simply be called a

“menu” or “title” in the instructions supplied with the disc.

Advanced playback

DVD menu

Some DVDs allow you to select the disc contents using the menu.
When you playback these DVDs, you can select the subtitle language, soundtrack language, etc, using the menu.

Press DVD MENU during playback.

1

Press / / / to select the desired item.

2

J50S0101A.indb 51

The DVD menu appears on the TV
screen.

• Press DVD MENU again to resume
playback at the scene when you
pressed DVD MENU.

Press ENTER.

3

Note:

• Depending on the DVD, you may not be able to resume

playback from the scene point when you press DVD MENU.

The menu continues to another
screen. Repeat steps 2 and 3 to set
the item completely.

51

08.1.9 4:45:49 PM

Advanced playback

J50S0101A.indb 52

08.1.9 4:45:50 PM

Changing soundtrack language/Subtitles

DVD

Changing soundtrack language

VCD

You can select the language when you play a multilingual disc.

Press AUDIO SELECT during playback.

1

Press AUDIO SELECT repeatedly until the
desired language is selected.

2

The current soundtrack language will
appear.

1/2 Eng Dolby Digital

2/2 Fre Dolby Digital

Subtitles

When playing back a disc recorded with subtitles, you can
select the subtitle language or turn the subtitle off.

Press SUBTITLE repeatedly during playback until
the desired language is selected.

1

To turn off the subtitle, press SUBTITLE until
“Off” appears.

2

AUDIO SELECT
SUBTITLE

1/5 Eng

Off

• The on screen display will disappear after a few
seconds.

In case of Video CD playback

Audio type changes as follows each time you press AUDIO
SELECT.

LR L R

Note:

• If the desired language is not heard after pressing the
button several times, the language is not recorded on
the disc.

• The selected soundtrack language is cancelled when

you eject the disc. The initial default language or
available language will be heard if the disc is played

back again.

• If you select DTS in playing DTS-encoded disc, no
sound will be heard from the TV/DVD·s speakers.

• The on screen display will disappear after a
few seconds.

Note:

• Depending on the DVD, you may not be able to change
subtitles, or to turn subtitles on or off.

• While playing a DVD, the subtitle may change when
you loaded or eject the disc.

• In some cases, a selected subtitle language may not
be changed immediately.

52

J50S0101A.indb 52

08.1.9 4:45:50 PM

Disc status/To turn off the PBC

J50S0101A.indb 53

08.1.9 4:45:51 PM

DISPLAY

PLAY MODE

/

ENTER

DVD

Disc status

VCD

With press of DISPLAY, the status of the disc
will appear on the screen.
To cancel the display, press DISPLAY again.

DVD

DISC OPERATION

TITLE NO.

ANGLE NO.

AUDIO LANGUAGE A KIND OF AUDIO

DVD 00:15:25 01:41:39
Title 1/3 Chapter 2/24

1/1 Eng Dolby Digital 1/2 Eng
1/1

ELAPSED
TIME

TOTAL
TIME

SUBTITLE LANGUAGE

CHAPTER
NO.

Video CD

DISC OPERATION

ELAPSED
TIME

TOTAL
TIME

VCD

To turn off the PBC (see page 7)

Press PLAY MODE in the stop mode.

1

Press / to select “Mode”, then press
ENTER repeatedly until “Off” appear.

2

Mode : Off

Repeat : Off

Play Mode

Program Playback

1 – – –

2 – – –

3 – – –

Press PLAY MODE again to clear the screen.

3

Q To turn on the PBC

Follow the above steps 1~2, then press ENTER repeatedly
until “PBC” appear.

Advanced playback

J50S0101A.indb 53

VCD 00:08:32 00:51:03
Track 3/15

TRACK NO.

53

08.1.9 4:45:51 PM

Advanced playback

J50S0101A.indb 54

08.1.9 4:45:52 PM

MP3/WMA/JPEG/DivX® and Audio CD operation

This unit can playback the MP3/WMA/JPEG/DivX®-data which has been recorded on CD-R or CD-RW. To produce
the MP3/WMA/JPEG/DivX®-data, you need a Windows-PC with CD-RW drive and a MP3/WMA/JPEG/DivX®-encoding
Software (not supplied). The Apple-HFS-System cannot be played.

This player requires discs/recordings to meet certain technical standards in order to achieve optimal playback quality.
There are many different types of recordable disc formats (including CD-R containing MP3/WMA fi les). Not all recordable
discs will produce optimal playback quality. The technical criteria set forth in this owner·s manual are meant only as a
guide. Use of CD-RW for MP3 fi les is not recommended.

You must obtain any required permission from copyright owners to download or use copyrighted content.
Toshiba cannot and does not grant such permission.

CD

Audio CD/MP3/WMA/JPEG/DivX® CD information

Limitations on MP3/WMA/JPEG/DivX® CD playback

• MP3/WMA/JPEG/DivX® CD is the disc that is standardized by ISO9660, its fi le name must include 3-digits extension
letters, “.mp3”, “.wma”, “.jpg”, “.div”, “.divx”, “.avi”.

• MP3/WMA/JPEG/DivX® CD must be correspond to the ISO standardized fi les.

• This unit can read 2000 fi les per disc. If one disc has more than 2000 fi les, it reads up to 2000 fi les, the remaining fi les
will be omitted.

• MP3/WMA/JPEG/DivX® CDs cannot be used for the purpose of recording.

• If the CD has both audio tracks and MP3/WMA/JPEG/DivX®fi les, only audio tracks will be played.

• It may take more than one minute for this unit to read MP3/WMA/JPEG/DivX®fi les depending on its structure.

• Music recorded by “Joliet Recording Specifi cation” can be played back, the fi le name is displayed (within 15 letters) on
the screen. Long fi le names will be condensed.

• The music fi les recorded by “Hierarchical File System” (HFS) cannot be played.

Limitations on display

• The maximum number for display is 15 letters.

Available letters for display are the following:
capital or small alphabets of A through Z, numbers of 0 through 9, and _ (under score).

• Other letters than those above are replaced in hyphen.

Notes on MP3/WMA/JPEG/DivX®fi les

To playback MP3/WMA/JPEG/DivX® CD in the recorded order,

1. Use MP3/WMA/JPEG/DivX® software that records data alphabetically or numerically.

2. Name each fi le including two-digit or three-digit number (ex. “01” “02” or “001” “002”).

3. Refrain from making too many sub-folders.

CAUTION:

• Some MP3/WMA/JPEG/DivX® CDs cannot be played back depending on the recording conditions.

• The CD-R/RW that has no music data or non MP3/WMA/JPEG/DivX®fi les cannot be played back.

Standard, sampling frequency and the bit rate:

MP3 CD
MPEG-1 Audio
32kHz, 44.1kHz, 48kHz
32kbps ~ 320kbps (constant bit rate or variable bit rate)
The recommend recording setting for a high-quality sound is 44.1kHz of sampling frequency and 128kbps of constant

bit rate.

WMA CD
WMA version 7 and 8
32kHz/48kbps, 44.1kHz/48kbps~192kbps, 48kHz/128kbps~192kbps
The fi le recorded by mono, 48kHz, 48 kbps is not available to this unit.
DivX® video
DivX® version: DivX® 3, 4, 5, and 6 (specifi cally 3.1.1, 4.1.2, 5.0.2, 5.0.5, 5.1.1, 5.2.1, 6.0 at Home Theater profi le).
Audio format: MPEG1 Layer2 (MP2), MPEG1 Layer3 (MP3)
Sampling frequencies: 32kHz, 44.1kHz, 48kHz
Bit rate: 32kbps ~ 320kbps
Resolution: Max 720 x 576 (at 25fps), Max 720 x 480 (at 30fps)

Microsoft, Windows Media, and Windows Logo are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
DivX, DivX Certifi ed, and associated logos are trademarks of DivX, Inc. and are used under license.

54

J50S0101A.indb 54

08.1.9 4:45:52 PM

CD

J50S0101A.indb 55

08.1.9 4:45:52 PM

MP3/WMA and Audio CD playback

/ / /

ENTER
STOP

PLAY
RETURN

TOP MENU

Load an Audio CD or a disc on which MP3
or WMA fi les have been recorded in the disc

1

slot.

A fi le browser screen will appear on the screen.

2

Press / to select fi le.

3

/MP3-2.MP3

Folder-1

Folder-2

MP3-1

MP3-2

MP3-3

WMA-1

WMA-2

WMA-3

Select Files

Repeat :Off

Mode :Off

JPEG Preview

• In case the current directory includes more than 8
fi les, press

or to scroll in the fi le list.

• To see contents in folder, select the folder and then
press ENTER. To return to the parent directory, press
RETURN or select “

Go Up ...” then press ENTER.

• When PLAY is pressed after the fi le browser
displayed, playback begins automatically starting
from the fi rst fi le. In this case, if the fi rst fi le is an
MP3/WMA fi le, only MP3/WMA fi les are played back
in order. If the fi rst fi le is a JPEG fi le, the fi rst JPEG

fi le is played back. If the fi rst fi le is a DivX
fi rst DivX

®

fi le is played back. If there is no fi le at a

®

fi le, the

root directory, playback does not begin automatically.

Press ENTER.

The selected fi le starts playing back.

4

Press STOP to end playback.

5

About fi le menu

3/15 00:00:00

/WMA-11.WMA

MP3-5

MP3-6

WMA-11

WMA-12

Picture-1

Picture-2

Movie-1

Movie-2

Note:

• In the case of a CD containing a mixture of MP3, WMA,
JPEG and DivX®fi les, the fi les are played back by
selecting them from the fi le browser.

• MP3 or WMA fi le on the Kodak Picture CD is not
recognized on this unit.

Note:

• During MP3/WMA playback, you cannot use Jump and A-B
Repeat functions.

• You can use Repeat (Track or All), Random functions and
Program playback for Audio CD/MP3/WMA/JPEG/DivX
playback

58 59

.

Select Files

Repeat :Off

Mode :Off

Music Playing

QSelect Files

The fi le type to make it display in the fi le browser can
be chosen.

1.Press or to highlight “Select Files” at right column

in the fi le browser.

2. Press ENTER, then press or to select fi le type

from the list (Music, Picture or Movie).

3. Press ENTER to add/remove check mark. Checked

fi le type will be displayed in the fi le browser.

4. Press RETURN to save the setting.

Advanced playback

®

• The unit records the stopped point. “ ” appears
on the TV screen. Press PLAY to resume playback
(from the scene point).

• If you press STOP again or unload the disc, the unit
will clear the stopped point.

J50S0101A.indb 55

55

08.1.9 4:45:52 PM

Advanced playback

J50S0101A.indb 56

08.1.9 4:45:54 PM

Advanced playback

MP3/WMA/JPEG/DivX® and Audio CD
operation (Continued)

ZOOM
DVD MENU

ENTER

/ / /

PAUSE
STOP
PLAY

SKIP
ANGLE
TOP MENU

CD

JPEG playback

Load a JPEG disc in the disc slot.

1

A fi le browser screen
will appear on the

2

screen.

Press / to select the fi le.
To display a thumbnail list, press DVD MENU.

3

Press
(To return to the fi le browser, press TOP MENU.)

• When PLAY is pressed after the fi le browser

Press ENTER or PLAY. The selected picture
appears on the screen.

4

/ //to select the desired fi le.

displayed, playback begins automatically
starting from the fi rst fi le. In this case, if the
fi rst fi le is a JPEG fi le, the fi rst JPEG fi le is
played back. If the fi rst fi le is a DivX
fi rst DivX
is an MP3/WMA fi le, only MP3/WMA fi les
are played back in order. If there is no fi le
at a root directory, playback does not begin
automatically.

®

fi le is played back. If the fi rst fi le

/Picture-01.JPG

Picture-01

Picture-02

Picture-03

Picture-04

Picture-05

Picture-06

Picture-07

Picture-08

Select Files

Repeat :Off

Mode :Off

JPEG Preview

W: 2048 H: 1536

®

fi le, the

CD

Slide show playback

The slide show enables you to view pictures (fi les) one after
another automatically.

Preparation:

• Set “JPEG Interval” setting to “5 Seconds”, “10 Seconds”
or “15 Seconds”

Select your desired starting fi le for the slide
show in the step 3 on left.

1

Press ENTER or PLA Y to start slide show from
the selected fi le.

2

• If you press PAUSE during the slide show, the slide

show stops temporary. “
screen.

Press PLAY or SKIP again to resume the slide show.

• If the picture appears upside down or sideways, press

ANGLE repeatedly until it·s right side up.

”, “ ”, “ ” or “ ” appears on the TV screen.

“

• When the slide show playback fi nished, the fi le list

appears.

• To stop the slide show, press ST OP. The fi le browser

appears.

Note:

• During JPEG playback, you cannot use Jump and A-B

Repeat functions.

• When an image exceeds 5760 x 3840 pixels, the entire

image may not be displayed on a screen, preview window
or thumbnail list.

• It may have a longer interval due to the size of data.

63

.

\\” appears briefl y on the TV

5

56

J50S0101A.indb 56

Rotating an image

You can rotate an image by 90 degrees.
Press ANGLE during playback of the image.

“ ”, “ ”, “ ” or “ ” appears on the screen.

Zooming an image

Zoom function also can be used in viewing JPEG

fi les. Press ZOOM (See “Zooming”
Press STOP to end playback.

The fi le browser appears on the
screen. If you want to watch the
other fi le, repeat steps 3 ~ 4.

47

).

08.1.9 4:45:54 PM

ENTER

J50S0101A.indb 57

08.1.9 4:45:55 PM

/
STOP
PLAY

CD

DivX® playback

Load a disc on which DivX®fi les have been
recorded in the disc slot.

1

A fi le browser screen will appear on the TV
screen.

2

Press / to select fi le.

/Movie-01.DIVX

Movie-01

Movie-02

Movie-03

Movie-04

Movie-05

Movie-06

Movie-07

Movie-08

3

• When PLAY has been pressed after the

fi le browser displayed, playback begins
automatically starting from the fi rst fi le. In this
case, if the fi rst fi le is a JPEG fi le, the fi rst JPEG

fi le is played back. If the fi rst fi le is a DivX
fi le, the fi rst DivX®fi le is played back. If the
fi rst fi le is an MP3/WMA fi le, only MP3/WMA
fi le are played back in order. If there is no fi le

at a root directory, playback does not begin
automatically.

Select Files

Repeat :Off

Mode :Off

JPEG Preview

®

CD

Playing DivX® VOD content

DivX® VOD content is protected by DRM (Digital Rights
Management) system. This restricts playback of content
to specifi c registered devices.

If the incorrect DRM fi le
is loaded, “Authorization
Error This player is not
authorized to play this
video.” will appear on the
screen.
When you attempt to play

®

VOD, the number

DivX
of plays is limited and the
right message will appear on the screen. If you wish to
play it, select “Yes”.

• If the number of plays goes over the limit, then “Rental
Expired” will be displayed. In this case, the fi le will not
be played.

Note:

• In order to play DivX
need to register the unit with registration code. See page

.

64

• Depending on the recording conditions of DivX®fi le, you
may not be able to use FF, REV or JUMP function.

®

VOD content on this unit, you fi rst

View DivX® VOD Rental

This rental has 5 views left.

Do you want to use one

of your 5 views now?

NoYes

Advanced playback

Press ENTER or PLAY. The selected DivX
movie will be played back on the TV screen.

4

Press STOP to end playback.

5

J50S0101A.indb 57

®

• The unit records the stopped
point. “
screen. Press PLAY to resume
playback (from the scene

point).

• If you press STOP again or un
load the disc, the unit will clear
the stopped point. To want to
watch the other fi le, repeat steps

3 ~ 4.

” appears on the TV

57

08.1.9 4:45:55 PM

Advanced playback

F

F

M

M

F

F

M

M

J50S0101A.indb 58

08.1.9 4:45:56 PM

Repeat, random and program playback
using fi le browser

CD CD

Repeat playback (Audio CD/
MP3/WMA/JPEG/DivX

®

)

Random playback (Audio CD/
MP3/WMA/JPEG/DivX

/ / /
ENTER
PLAY

SKIP /

®

)

In the fi le browser, press / / / to select
“Repeat” during stop mode.

1

older-1

older-2

P3-1

P3-2

Press ENTER repeatedly to select “Track” or
“All”.

2 2

older-1

older-2

P3-1

P3-2

Press PLAY.

3

To resume normal playback

Select Repeat : “Off” in step 2.

The unit automatically starts repeat
playback after fi nishing the current
track.

Select Files

Repeat :Off

Mode :Off

Select Files

Repeat :Track

Mode :Off

Select Mode : “Off” in step 2.

In the fi le browser, press /// to select
“Mode” during stop mode.

1

Press ENTER to select “Random”.

Press PLAY.

3

To resume normal playback

The random playback will start.

Note:

• The repeat function is cancelled when you eject the disc
or turn the power off.

• Track repeat function is canceled whenever SKIP or

is pressed.

• The function of A-B Repeat can be used for DivX® CD. See

“A-B Repeat playback” 49.

Note:

• The random function is cancelled when you eject the disc
or turn the power off.

58

J50S0101A.indb 58

08.1.9 4:45:56 PM

CD

w

J50S0101A.indb 59

08.1.9 4:45:57 PM

Program playback (Audio CD/MP3/WMA/JPEG/DivX®)

In the fi le browser, press / / / to select
“Edit Mode”, then press ENTER.

1

Press
ENTER. Program View shows only the

4

programmed fi les that you have added in step 2.

/

to select “Program View”, then press

/ / /

ENTER
PLAY

Folder-1

Folder-2

MP3-1

MP3-2

Repeat :Off

Mode :Off

When “Edit Mode” is black
color, you can mark the fi les
which you want to add into
Program list.

Press

/ / /

add into the program list.

2

to select fi le you want to

Folder-1

Folder-2

MP3-1

MP3-2

MP3-3

WMA-1

Press ENTER. Selected fi le
was marked.
Repeat this procedure to
select the other fi les.

Press

/ / /

Then press ENTER. All marked fi les are added

3

into the program list.

to select “Add To Program”.

Folder-1
Folder-2
MP3-1
MP3-2
MP3-3
WMA-1

Add To Program

JPEG Preview

When you fi nish storing the fi les
which you want into the Program
list, select “Edit Mode” and press
ENTER to release edit mode.

Edit Mode

Repeat :Off

Mode :Off

Edit Mode

JPEG Previe

Edit Mode

Program View

MP3-1

MP3-2

MP3-3

WMA-3

Edit Mode

Browser View

Clear Program

JPEG Preview

Program View

Browser View

Folder-1

Folder-2

MP3-1

MP3-2

MP3-3

WMA-1

WMA-2

WMA-3

Edit Mode

Program View

Add To Program

JPEG Preview

In the Program View, press PLAY. The fi les
start to playback in programed order that were

5

added by you.

To remove fi le from program list in stop mode

In the Edit Mode, switch to Program View. Select fi le

you want to remove, then press ENTER. Select “Clear
Program” and press ENTER. Marked fi le is removed
from program list.

Note:

•

The program function is cancelled when you eject the disc
or turn the power off.

Advanced playback

J50S0101A.indb 59

59

08.1.9 4:45:57 PM

Function setup

J50S0101A.indb 60

08.1.9 4:45:58 PM

Customizing the function settings

You can change the default settings of the DVD mode to customize
performance to your preference.

DVD
VCD

Setting procedure

CD

/ / /
ENTER
SETUP

RETURN

Press SETUP during stop mode.

1

The following on-screen display appears.

Parental : Off

DRC : Off

E.B.L. : Off

Menu : English

Set Password

QSound : On

TV Screen : 4:3

Subtitle : English

Output : Interlace

Display : On

Audio : English

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Press or to select the desired section, then

2

press

or .

Parental : Off

DRC : Off

Menu : English

TV Screen : 16:9

Set Password

QSound : On

Subtitle : English

Display : On

Output : Interlace

Audio : English

Picture Mode : Auto

DivX(R) VOD

JPEG Interval : Off

First option will be highlighted. Press or
to select the desired option.

3

Parental : Off

DRC : Off

Menu : English

TV Screen : 16:9

Set Password

QSound : On

Subtitle : English

Display : On

Output : Interlace

Audio : English

Picture Mode : Auto

DivX(R) VOD

JPEG Interval : Off

Then press or ENTER. The selectable
settings will appear.

4

Parental : Off

DRC : Off

Menu : English

TV Screen 4:3

Set Password

QSound : On

Subtitle : English

Display

Output : Interlace

Audio : English

Picture Mode : Auto

DivX(R) VOD

JPEG Interval : Off

Change the selection using or , by referring
to the corresponding pages 61 ~ 64.

5

Press ENTER to save the setting.

• Repeat steps 3 and 5 to change

other option.

• To select another section, go

back to step 2 by pressing
repeatedly.

To clear SETUP screen, press SETUP once or
press RETURN repeatedly.

6

4:3
16:9

60

J50S0101A.indb 60

08.1.9 4:45:58 PM

Setting details

J50S0101A.indb 61

08.1.9 4:45:59 PM

Section Option Details Page

Menu
Subtitle
Audio

TV Screen

Display

Picture Mode
JPEG Interval To select a preferred setting for the slide show playback.

To select the language of “Menu”, “Subtitle” and “Audio”
if more than one language are available on the disc.

To select a picture size according to the aspect ratio of
your TV .

To turn On or Off the operational status display on the TV
screen.

To select a preferred picture mode from “Video”, “Film” or
“Auto”.

Night Mode To select On or Off for Night Mode.

Digital Out

Parental
Password To change the password.
DivX(R) VOD To display your 8-character registration code.

To select a digital output sound format corresponding to
your system connection.

To select a preferred parental level for the parental setting.

62

62

63

63

64

Function setup

J50S0101A.indb 61

61

08.1.9 4:45:59 PM

Function setup

J50S0101A.indb 62

08.1.9 4:46:00 PM

Customizing the function settings (Continued)

Setting details

Parental : Off

DRC : Off

E.B.L. : Off

Menu : English

Set Password

QSound : On

TV Screen : 4:3

Subtitle : English

Output : Interlace

Display : On

Audio : English

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Parental : Off

DRC : Off

Menu : English

TV Screen : 16:9

Set Password

QSound : On

Subtitle : English

Display : On

Output : Interlace

Audio : English

Picture Mode : Auto

DivX(R) VOD

JPEG Interval : Off

Menu, Subtitle, Audio

You can select the language of “Menu”, “Subtitle” and
“Audio” if more than one languages are recorded onto
the disc.

English, Francais, Espanol:

The selected language will be heard or seen.

Other:

Other language can be selected (see “Language

69

code list”

).

Original (Audio):

The unit will select the fi rst priority language of
each disc.

Off (Subtitle):

Subtitles do not appear.

Note:

• If the selected language is not recorded on the disc, the
fi rst-priority language is selected.

• If you want to change the OSD language, you can perform

22

it by “Language” in the TV menu

.

TV Screen

You have the following screen sizes to choose from:

4:3

(Letter box):

When playing back a wide screen-DVD disc, it
displays the wide picture with black bands at the
top and bottom of screen.

4:3

(Pan & scan):

It displays the wide picture on the whole screen
with left and right edges automatically cut off.

16:9

(Wide):

A wide screen picture is displayed full size.

Note:

• If the DVD disc is not formatted in the Pan & scan style, it
will display 4:3 style.

Display

On screen display can be switched on or off when you
press any buttons.

Off: On screen displays do not appear when you
press any buttons.
On: On screen displays appear when you press
the buttons (factory setting).

62

J50S0101A.indb 62

08.1.9 4:46:00 PM

Setting details (continued)

J50S0101A.indb 63

08.1.9 4:46:00 PM

Picture Mode

There are two types of source content in pictures
recorded in DVD video discs: fi lm content (pictures
recorded from fi lms at 24 frames per second) and
video content (video signals recorded at 30 frames per
second). Make this selection according to the type of
content being viewed.

Auto: Select this selection normally.
The DVD player automatically detects

source content, fi lm or video of
playback source, and converts that
signal in an appropriate method.

Film: The DVD player converts fi lm content

pictures appropriately. Suitable for
playback of fi lm content pictures.

Video: The DVD player fi lters video signal and

converts it appropriately.

Suitable for playback of video content

pictures.

Note:

• Depending on the disc, pictures may be cut off or
doubled. In this case, select “Video”.

JPEG Interval

You can continuously playback all JPEG fi les
automatically.
After the selection below, the disc will start playback on
JPEG fi les which have been recorded.

Off:

Plays back one fi le at a time.

5 Seconds:

Plays back images in the form of a slide show at
5 second intervals.

Parental : Off

Menu : English

E.B.L. : Off

Night Mode : Off

Set Password

Subtitle : English

TV Screen : 4:3

Digital Out : Bitstream

Output : Interlace

Audio : English

Display : On

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Ϯ Night Mode

Night Mode enables you to control the dynamic range so as
to achieve a suitable sound for your equipment.

Off: It plays back at the recording level on the disc.
On: Loud sound such as explosion is toned down

slightly when played back. This is suitable when
it is connected to a stereo.

Note:

This function works only when the disc recorded with

•
Dolby Digital is played back.
The level of Night Mode may differ depending on DVD

•
video disc.

Ϯ Digital Out

You can select the digital output sound format corresponding
to your system connection.

Off:

There is no sound output from DIGITAL AUDIO OUT
jack.

PCM:

Change Dolby Digital to PCM for the output.
Select when connected to a 2 channel digital stereo
amplifier.

Bitstream:

Disc audio bitstream data will be output.

Note:

Even if you select “Bitstream”, MPEG Audio will be output

•
in PCM format.

Function setup

10 Seconds:

Plays back images in the form of a slide show at
10 second intervals.

15 Seconds:

Plays back images in the form of a slide show at
15 second intervals.

J50S0101A.indb 63

63

08.1.9 4:46:00 PM

Function setup

J50S0101A.indb 64

08.1.9 4:46:01 PM

Customizing the function settings (Continued)

Setting details (continued)

DRC : Off

Menu : English

E.B.L. : Off

Parental : Off

QSound : On

Subtitle : English

TV Screen : 4:3

Password : Change

Audio : English

Display : On

DivX(R) VOD : Display

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Parental control setting

Some discs are specifi ed as not suitable for children. Such
discs can be limited not to playback with the unit.

1) Press or to select “Parental”, then press
ENTER. “Enter Password” screen will appear.

2) Press “0000” using Number buttons (0–9).
(Please note, this is pre-setting password of this
unit). Then press ENTER. The parental level list
will appear.

• Level Off: The parental control setting does not

function.

• Level 8:

Virtually all DVD software can be

played back.

• Level 1: DVD software for adults cannot be

played back.

3) Press

or to select from the level 1 to level 8.
The limitation will be more severe as the level
number is lower. Then press ENTER.

Note:

• The parental control level is equivalent to the following

USA movie ratings.

Level 1: G Level 5:
Level 2: Level 6: R
Level 3: PG Level 7: NC-17
Level 4: PG-13 Level 8:

The parental control levels for other countries/area
than U.S. are included for future use. Check the
appropriate parental control level when you buy a DVD

video disc equipped with the parental control feature
in the future.

•

Depending on the discs, the unit cannot limit playback.

• Some discs may not be encoded with specifi c rating
level information though its disc jacket says “adult.”
For those discs, the age restriction will not work.

• The password is required every time when you

change the parental level.

• If you input a wrong number, press EXIT/CANCEL.

QSet the new password

1) Press

or to select “Password”, then press
ENTER. “Enter Current Password” screen will
appear.

2) Press Number buttons (0–9) to input the current
password (If the password has not been set yet
after you purchase this unit, it is “0000”).

3) Then press ENTER. “Enter New Password” screen
will appear. Press Number buttons (0–9) to input
the new password.

4) Press ENTER. Now your new password has been
set. Be sure to remember this number!

If you forget the password

1) Press EJECT to remove the disc.

2) While holding 7 down on the remote control and

then press STOP on the unit. “Password Clear”
appears on the screen. Now the password
has been returned to the initial value (“0000”).

®

QDivX

In order to play DivX
on this unit, you fi rst need to register the unit with your
DivX
a DivX

VOD

®

VOD (Video On Demand) content

®

VOD content provider. You do this by generating

®

VOD registration code, which you submit to

your provider.

Press

or to select “DivX(R) VOD”. Then press

ENTER. Your 8-character registration code is

displayed. Make a note of the code as you will need

it when you register with a DivX

®

VOD provider.

Then press ENTER to select Done.

Note:

• If each setup (pages 62 ~ 64) has completed, the unit
can always work under the same condition (especially with
DVD discs).

Each setup will be retained in the memory even if you turn

the power off.

64

J50S0101A.indb 64

08.1.9 4:46:01 PM

Temporary cancel the rating level by DVD disc

J50S0101A.indb 65

08.1.9 4:46:01 PM

Depending on the DVD disc, the disc may try to temporarily cancel the rating level
that you have set.
It is up to you to decide whether to cancel the rating level or not.

DVD

Temporary cancel the rating level by DVD disc

EJECT
0–9

ENTER

RETURN

Load a DVD disc.

1

If the DVD disc has been designed to
temporarily cancel the Rating level, the screen

2

which follows the “Reading” screen will
change, depending on which disc is played.
If you select “YES” with the ENTER key,
password input screen will then appear.

• If “NO” is selected, press EJECT to remove
the disc.

Enter the password with Number buttons (0–9).
Then press ENTER.

3

To exit from the entry, press
RETURN.

Enter Password

Note:

• This temporary cancellation of rating level will be kept until
the disc is ejected.

When the disc is ejected, the original rating level will be

set again automatically.

Function setup

Playback will commence if the entered
password is correct.

4

J50S0101A.indb 65

65

08.1.9 4:46:01 PM

Others

J50S0101A.indb 66

08.1.9 4:46:02 PM

Understanding the Power Return feature

If the power is cut off while you are viewing the TV/DVD and the power is resupplied, the Power Return feature will
turn the TV/DVD on automatically. If the power is going to be off for a long time or you are going to be away from the
TV/DVD for a long time, unplug the power cord from the wall outlet to prevent the TV/DVD from turning on in your
absence.

Troubleshooting

Use the following check list for troubleshooting when you have problems with your unit. Consult your local dealer or
service outlet if problems persist.
Be sure all connections are properly made when using with other units.

SYMPTOMS POSSIBLE SOLUTIONS PAGE

POWER

• Make sure the connection of AC cord is secured.

TV/DVD does not operate.

TV BROADCAST RECEPTION

Poor sound or No sound.

Poor picture or No picture.

Poor reception on some
channels.

Poor color or no color.

Picture wobbles or drifts.

No CATV reception.

Horizontal or diagonal bars on
screen.

No reception above channel 13.

TV shuts off.

Closed - Caption is not
activated.

Display is not shown in your
language.

• Try another AC outlet.

• Unplug unit, then plug it back in.

• Station or Cable TV may have problems, try another station.

• Check Volume adjustments or mute.

• Check for sources of possible interference.

• Station or Cable TV may have problems, try another station.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Check Picture setting.

• Station or Cable TV may have problems, try another station.

• Station signal is weak, reorient antenna to receive weaker station.

• Check for sources of possible interference.

• Station or Cable TV may have problems, try another station.

• Make sure channels are set into memory.

• Check Picture setting.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Station or Cable TV may have problems, try another station.

• Make sure channels are set into memory.

• Cable TV company is scrambling signal.

• Check antenna or Cable TV connections, reorient antenna.

• Check all Cable TV connections.

• Set Air/Cable selection to the Cable position.

• Station or Cable TV system problems, try another station.

• Check antenna or Cable TV connections, reorient antenna.

• Check for sources of possible interference.

• Make sure Air/Cable selection is in the appropriate position.

• If antenna is used, check UHF antenna connections.

• Auto shut off feature worked.

• Sleep Timer is set.

• Power interrupted.

• TV station experiencing problems or program tuned is not closed
captioned. Try another channel.

• Check Cable TV connection or VHF/UHF antenna, reposition or
rotate antenna.

• Set “CC Setting” to “On” to turn on the closed caption decoder.

• Select proper language in the menu options. 22

20

26

26, 27

68
26

14, 15

68
36

26
14
68

26
23
36

14, 15

68
26

23

-

14, 15

15
23
26

14, 15

68
23

14
43

27

-

26

14, 15

34

66

J50S0101A.indb 66

08.1.9 4:46:02 PM

SYMPTOMS POSSIBLE SOLUTIONS PAGE

J50S0101A.indb 67

08.1.9 4:46:03 PM

DVD

Playback doesn·t start.

• No disc is loaded.

• The disc may be dirty. Clean up the disc.

44

• The unit cannot play CD-ROMs, etc.

No picture. • TV/DVD selector is not set correctly. 44

• Check the input selector of the amplifi er is set properly.

No sound.

Picture is distorted during fast
reverse/forward playback.

• The unit is in the special playback mode.

• Select the correct Audio Input/Output position on AV amplifi er.

18, 19

• The picture will be distorted occasionally. -

46

Stopping playback, search,
slowmotion play, repeat play, or
program play, etc. cannot be

• Some discs may not do some of the functions. ­performed.
No on-screen display. • Set Display to On. 62
The unit or remote operation key

is not functioning.
Playback does not start when

the title is selected.

• Turn off the unit and unplug the AC power cord for several minutes,

then replug it.

• Check the Parental setup. 64
Audio soundtrack and/or subtitle

language is not changed when

• Multilingual language is not recorded on the DVD disc. 52
you playback a DVD.

No subtitle.

• Some discs have no subtitles.

• Subtitles are cleared. Press SUBTITLE.

52

Angle cannot be changed. • Multi-angles are not recorded on the DVD disc. 51
“” appears on the screen. • The function is prohibited with the unit or the disc. 46

REMOTE CONTROL

• Aim the remote control at the remote sensor.
The remote control does not

function.

• Operate within approx. 5 meters or reduce the light in the room.

• Clear the path of the beam.

• The batteries are weak. Replace the batteries.

13

• Check the batteries are inserted correctly.

7
8

-

-

Others

J50S0101A.indb 67

67

08.1.9 4:46:03 PM

Others

J50S0101A.indb 68

08.1.9 4:46:03 PM

Reception disturbances

Most types of television interference can be remedied by adjusting the height and position of the VHF/UHF antenna.
Outdoor antennas are recommended for best results. The most common types of television interference are shown
below. If one of these symptoms appear when the TV/DVD is connected to a Cable TV system, the disturbance may
be caused by the local Cable TV company broadcast.

IGNITION

Black spots or horizontal streaks may appear, the picture may fl utter or
drift. Usually caused by interference from automobile ignition systems,
neon lamps or AC powered tools and appliances such as drills or hair
dryers.

GHOSTS

Ghosts are caused by the television signal following two paths. One is
the direct path and the other is refl ected by tall buildings, hills or other
large objects. Changing the direction or position of the antenna may
improve the reception.

SNOW

If the TV/DVD is located far from the TV station, in a fringe reception
area where the signal is weak, small dots may appear in the picture.
If the signal is extremely weak, the installation of a larger external
antenna may be necessary.

RADIO FREQUENCY INTERFERENCE (RFI)

Caused by two-way radios, this type of interference produces moving
ripples or diagonal streaks in the picture. Some cases may cause a
loss of contrast in the picture. Changing the direction and position of
the antenna or installing an RFI fi lter may improve the picture.

CARE AND MAINTENANCE

To prevent fi re or shock hazard, disconnect the TV/DVD from the power source before cleaning.
Use caution when cleaning or wiping the plastic parts.

68

J50S0101A.indb 68

08.1.9 4:46:03 PM

Others

J50S0101A.indb 69

08.1.9 4:46:05 PM

Language code list

Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” 62.

Language Name Code Language Name Code Language Name Code Language Name Code

Abkhazian 1112 Fiji 1620 Lingala 2224 Singhalese 2919
Afar 1111 Finnish 1619 Lithuanian 2230 Slovak 2921
Afrikaans 1116 French 1628 Macedonian 2321 Slovenian 2922
Albanian 2927 Frisian 1635 Malagasy 2317 Somali 2925
Amharic 1123 Galician 1722 Malay 2329 Spanish 1529
Arabic 1128 Georgian 2111 Malayalam 2322 Sundanese 2931
Armenian 1835 German 1415 Maltese 2330 Swahili 2933
Assamese 1129 Greek 1522 Maori 2319 Swedish 2932
Aymara 1135 Greenlandic 2122 Marathi 2328 Tagalog 3022
Azerbaijani 1136 Guarani 1724 Moldavian 2325 Tajik 3017
Bashkir 1211 Gujarati 1731 Mongolian 2324 Tamil 3011
Basque 1531 Hausa 1811 Nauru 2411 Tatar 3030
Bengali; Bangla 1224 Hebrew 1933 Nepali 2415 Telugu 3015
Bhutani 1436 Hindi 1819 Norwegian 2425 Thai 3018
Bihari 1218 Hungarian 1831 Oriya 2528 Tibetan 1225
Breton 1228 Icelandic 1929 Panjabi 2611 Tigrinya 3019
Bulgarian 1217 Indonesian 1924 Pashto, Pushto 2629 Tonga 3025
Burmese 2335 Interlingua 1911 Persian 1611 Turkish 3028
Byelorussian 1215 Irish 1711 Polish 2622 Turkmen 3021
Cambodian 2123 Italian 1930 Portuguese 2630 Twi 3033
Catalan 1311 Japanese 2011 Quechua 2731 Ukrainian 3121
Chinese 3618 Javanese 2033 Rhaeto-Romance 2823 Urdu 3128
Corsican 1325 Kannada 2124 Romanian 2825 Uzbek 3136
Croatian 1828 Kashmiri 2129 Russian 2831 Vietnamese 3219
Czech 1329 Kazakh 2121 Samoan 2923 Volapük 3225
Danish 1411 Kirghiz 2135 Sanskrit 2911 Welsh 1335
Dutch 2422 Korean 2125 Scots Gaelic 1714 Wolof 3325
English 1524 Kurdish 2131 Serbian 2928 Xhosa 3418
Esperanto 1525 Laothian 2225 Serbo-Croatian 2918 Yiddish 2019
Estonian 1530 Latin 2211 Shona 2924 Yoruba 3525
Faroese 1625 Latvian, Lettish 2232 Sindhi 2914 Zulu 3631

Others

J50S0101A.indb 69

69

08.1.9 4:46:05 PM

Specifi cations

J50S0101A.indb 70

08.1.9 4:46:05 PM

Model 19LV505 / 19LV506 22LV505

General

Power supply AC 120V 60Hz
Power consumption Operation: 60 W, Stand by: 1 W Operation: 65 W, Stand by: 1 W
Weight 11.5 lbs (5.1 kg) 13.5 lbs (6.1 kg)

Dimensions

Operating temperature 5°C-40°C (41°F-104°F)
Operating humidity Less than 80% RH (No condensation)

Television

LCD panel (Screen size is approximate.) 19-inch diagonal 22-inch diagonal
Display method Color TFT LCD
Number of pixels 1440 (Horizontal) x 900 (Vertical) 1680 (Horizontal) x 1050 (Vertical)
Television system NTSC standard, ATSC standard (8VSB), QAM

Receiving channels

Antenna input VHF/UHF 75 
Speaker 1-3/16 x 2-13/16 inches (30.5 x 71.1 mm), 8  x 2
Audio output power 1.5W + 1.5W

DVD/CD player

Signal system NTSC
Applicable disc
Pickup 1-Lens, 2-Beams System

Input/Output

S-Video input

ColorStream video input
Video input 1.0 V (p-p), 75 , negative sync., pin jack x 1

Audio input –8dBm, 50 k, negative sync., pin jack (L/R) x 2

HDMI input

PC input MONITOR: Mini-Dsub 15pin x 1, AUDIO: 3.5ø mm Stereo jack x 1
Digital audio output (Coaxial) 0.5 V (p-p), 75 , pin jack x 1
Headphone ø3.5mm stereo mini jack x 1

Accessories

Remote control (SE-R0305) ......................................................... 1

Batteries (R03/AAA) .................................................................... 2

AC cord ........................................................................................ 1

Cleaning cloth .............................................................................. 1

Owner·s manual (this booklet) ..................................................... 1

Quick setup guide (Spanish) ..................................................... 1

Width: 18-9/16 inches (472 mm)
Height: 15-13/16 inches (401 mm)
Depth: 8-1/8 inches (207 mm)

VHF: 2-13
UHF: 14-69
CATV: 1-125 (4A, A-5~A-1, A~I, J~W, W+1~W+84)

1. DVD (12cm, 8cm)

2. CD (12cm, 8cm)

(Y) 1.0 V (p-p), 75 , negative sync., Mini DIN 4-pin x 1
(C) 1.0 V (p-p), 75 

(Y) 1.0 V (p-p), 75 , negative sync., pin jack x 1
(PB, PR) 0.7 V (p-p), 75 , pin jack x 2

HDMI compliant (type A connector), HDCP compliant, E-EDID compliant
Suggested scan rates: 1080i, 480p, 720p
HDMI Audio: 2-channel PCM, 32/44.1/48 kHz sampling frequency, 16/20/24 bits per
sample

Width: 21-1/8 inches (536.5 mm)
Height: 17-5/16 inches (439.5 mm)
Depth: 8-1/8 inches (207 mm)

• This model complies with the above specifi cations.

• Designs and specifi cations are subject to change without notice.

• This model may not be compatible with features and/or specifi cations that may be added in the future.

70

J50S0101A.indb 70

08.1.9 4:46:05 PM

Others

J50S0101A.indb 71

08.1.9 4:46:06 PM

Limited United States Warranty
LCD TV/DVD Combination - Depot Repair Warranty

Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original
consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER
PURCHASER OR ANY PERSON RECEIVING THIS LCD TV/DVD COMBINATION AS A GIFT FROM THE
ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.

LCD TV/DVD COMBINATIONS PURCHASED IN THE U.S.A. AND USED ANYWHERE OUTSIDE
OF THE U.S.A., INCLUDING, WITHOUT LIMITATION, CANADA AND MEXICO, ARE NOT COVERED
BY THESE WARRANTIES.

LCD TV/DVD COMBINATIONS PURCHASED ANYWHERE OUTSIDE OF THE U.S.A., INCLUDING,
WITHOUT LIMITATION, CANADA AND MEXICO, AND USED IN THE U.S.A., ARE NOT COVERED
BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor

TACP warrants this LCD TV/DVD Combination
and its parts against defects in materials or
workmanship for a period of one (1) year after
the date of original retail purchase. DURING
THIS PERIOD, TACP WILL, AT TACP·S OPTION,
REPAIR OR REPLACE A DEFECTIVE PART WITH
A NEW OR REFURBISHED PART WITHOUT
CHARGE TO YOU.

Rental Units

The warranty for LCD TV/DVD Combination rental
units begins on the date of the fi rst rental or thirty
(30) days after the date of shipment to the rental
fi rm, whichever comes fi rst.

Commercial Units

LCD TV/DVD Combinations sold and used for
commercial purposes have a limited warranty for all
parts and labor, which warranty begins on the date
of original retail purchase and ends on the date that
is ninety (90) days thereafter.

Owner·s Manual and Product Registration Card

Read this owner·s manual thoroughly before operating
this LCD TV/DVD Combination.

Complete and mail the enclosed product registration
card or register your LCD TV/DVD Combination
online at www.tacp.toshiba.com/service as soon as
possible. By registering your LCD TV/DVD
Combination you will enable TACP to bring you
new products specifi cally designed to meet your
needs and help us to contact you in the unlikely
event a safety notifi cation is required under the
U.S. Consumer Product Safety Act. Failure to
complete and return the product registration card
does not diminish your warranty rights.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO
THE FOLLOWING CONDITIONS:

(1) You must retain your bill of sale or provide

other proof of purchase.

(2) All warranty servicing of this LCD TV/DVD

Combination must be made by the Depot
Warranty Repair Center specifi ed by the TACP
Consumer Solutions Center.

(3) The warranties from TACP are effective only

if the LCD TV/DVD Combination is purchased
and operated in the Continental U.S.A. or
Puerto Rico.

(4) Labor service charges for set installation,

setup, adjustment of customer controls, and
installation or repair of antenna systems are not
covered by this warranty. Reception problems
caused by inadequate antenna systems are
your responsibility.

(5) Warranties extend only to defects in materials

or workmanship as limited above, and do not
extend to any LCD TV/DVD Combination or
parts that have been lost or discarded by you
or to damage to the LCD TV/DVD Combination
or parts caused by fi res, misuse, accident,
Acts of God (such as lightning or fl uctuations in
electric power), improper installation, improper
maintenance, or use in violation of instructions
furnished by TACP; use or malfunction
through simultaneous use of this LCD TV/DVD
Combination and connected equipment; or to
units that have been modifi ed or had the serial
number removed, altered, defaced, or rendered
illegible.

Others

J50S0101A.indb 71

71

08.1.9 4:46:06 PM

How to Obtain Warranty Services

J50S0101A.indb 72

08.1.9 4:46:06 PM

If, after following all of the operating instructions
in this manual and checking the section
“Troubleshooting,” you fi nd that service is needed:

(1) For instructions on how to obtain warranty

service for your LCD TV/DVD Combination,
contact T ACP·s Consumer Solution Center toll
free at 1-800-631-3811.

(2) You must include a copy or original bill of

sale or other proof of purchase along with
the entire LCD TV/DVD Combination to the
Depot Warranty Repair Center specifi ed by
the TACP Consumer Solutions Center. You
are responsible for all inbound transportation
and insurance charges for the LCD TV/DVD
Combination to the Depot Warranty Repair
Center specifi ed by the TACP Consumer
Solutions Center.

For additional information, visit TACP·s website:
www.tacp.toshiba.com

ALL WARRANTIES IMPLIED BY THE LAW OF
ANY STATE OF THE U.S.A., INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE,
ARE EXPRESSLY LIMITED TO THE DURATION
OF THE LIMITED WARRANTIES SET FORTH
ABOVE. WITH THE EXCEPTION OF ANY
WARRANTIES IMPLIED BY THE LAW OF ANY
STATE OF THE U.S.A. AS HEREBY LIMITED,
THE FOREGOING WARRANTY IS EXCLUSIVE
AND IN LIEU OF ALL OTHER WARRANTIES,
GUARANTEES, AGREEMENTS, AND SIMILAR
OBLIGATIONS OF TACP WITH RESPECT TO
THE REPAIR OR REPLACEMENT OF ANY
PARTS. IN NO EVENT SHALL TACP BE LIABLE
FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES (INCLUDING, BUT NOT LIMITED TO,
LOST PROFITS, BUSINESS INTERRUPTION, OR
MODIFICATION OR ERASURE OF RECORDED
DATA CAUSED BY USE, MISUSE OR INABILITY
TO USE THIS LCD TV/DVD COMBINATION).

No person, agent, distributor, dealer, or company
is authorized to change, modify, or extend
the terms of these warranties in any manner
whatsoever. The time within which an action must
be commenced to enforce any obligation of TACP
arising under the warranty or under any statute
or law of the United States or any state thereof is
hereby limited to ninety (90) days from the date
you discover, or should have discovered, the
defect. This limitation does not apply to implied
warranties arising under state law.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH MAY VARY FROM STATE TO
STATE IN THE U.S.A. SOME STATES OF THE
U.S.A. DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, WHEN
AN ACTION MAY BE BROUGHT, OR THE
EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE PROVISIONS MAY NOT APPLY TO YOU
UNDER SUCH CIRCUMSTANCES.

ColorStream is registered trademark of Toshiba America Consumer Products, L.L.C.

J50S0101A SH 08/02

72

J50S0101A.indb 72

N

Printed in Thailand

08.1.9 4:46:06 PM
