Toshiba 15CV100U, 22CV100U, 19CV100U, 26CV100U, 32CV100U User Manual

...

15CV100U 15CV101U 19CV100U 22CV100U 26CV100U 32CV100U

For an overview of steps for setting up your new TV, see page 12.

Note: To display a High Definition picture, the TV must be receiving a High Definition signal (such as an over-the-air High Definition TV broadcast, a High Definition digital cable program, or a High Definition digital satellite program). For details, please contact your TV antenna installer, cable provider, or satellite provider.

Owner’s Record

The model number and serial number are on the back of your TV/DVD. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this TV/DVD. Model number: Serial number:

Dear Customer,

Thank you for purchasing this Toshiba LCD TV/DVD. This manual will help you use the many exciting features of your new LCD TV/DVD. Before operating your LCD TV/DVD, please read this manual completely, and keep it nearby for future reference.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing)

instructions in the literature

accompanying the appliance.

WARNING

To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. See item 25 on page 4.

WARNING: If you decide to wall mount this

television, always use a UL Listed wall bracket appropriate for the size and weight of this television. The use of any wall bracket other than a UL Listed wall bracket appropriate for the size and weight of this television for wall mounting this television could result in serious bodily injury and/or property damage. See “Removing the Pedestal Stand” ( page 6).

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer’s attention to Article 820-40 of the U.S. NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. For additional antenna grounding information, see items 32 and 33 on page 4.

CHILD SAFETY:

It Makes A Difference How and Where You Use Your Flat Panel Display

Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:

The Issue

• The home theater entertainment experience is a growing trend and larger flat panel displays are popular purchases. However, flat panel displays are not always supported on the proper stands or installed according to the manufacturer’s recommendations.

Tune Into Safety

• One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of your flat panel display.

• Carefully read and understand all enclosed instructions for proper use of this product.

• Don’t allow children to climb on or play with furniture and television sets.

• Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.

• Remember that children can become excited while watching a program, especially on a “larger than life” flat panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or knocked down.

• Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be pulled or grabbed by curious children.

Wall Mounting: If you decide to wall mount your flat panel display, always:

• Use a mount that has been recommended by the display manufacturer and/or listed by an independent laboratory (such as UL, CSA, ETL).

• Follow all instructions supplied by the display and wall mount manufacturers.

• If you have any doubts about your ability to safely install your flat panel display, contact your retailer about professional installation.

• Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure, contact a professional installer.

• A minimum of two people are required for installation. Flat panel displays can be heavy.

• Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and cause injury.

TOSHIBA Cares!

• The consumer electronics industry is committed to making home entertainment enjoyable and safe.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety

purpose of the polarized or grounding type plug. A

polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by

the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/ apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or

when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Additional Safety Precautions

14a) CAUTION: If the TV is dropped and the cabinet or

enclosure surface has been damaged or the TV does not operate normally, take the following precautions:

• ALWAYS turn off the TV and unplug the power

cord to avoid possible electric shock or fire.

• NEVER allow your body to come in contact with

any broken glass or liquid from the damaged television. The LCD panel inside the TV contains glass and a toxic liquid. If the liquid comes in contact with your mouth or eyes, or your skin is cut by broken glass, rinse the affected area thoroughly with water and consult your doctor.

• ALWAYS contact a service technician to inspect

the TV any time it has been damaged or dropped.

15) CAUTION:

• To reduce the risk of electric shock, do not use the

polarized plug with an extension cord, receptacle, or other outlet unless the blades can be inserted completely to prevent blade exposure.

• To prevent electric shock, match wide blade of

plug to wide slot; fully insert.

16) CAUTION:

Do not let children swallow the product or play with the plastic bag. Keep the product and the plastic bag out of the reach of children.

17) CAUTION:

Do not let water or other liquids come into contact with the product, as it may result in damage.

18) WARNING:

• To prevent the spread of fire, keep candles or

other open flames away from this product at all times.

• Keep the product away from direct sunlight, fire or

a heat source such as a heater. This may reduce the product lifetime or result in fire.

• The mains plug is used as the disconnect device,

and therefore install the TV/DVD near the wall outlet so that the mains plug can be accessed easily at all times.

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all warnings when installing your TV:

19) WARNING: NEVER expose batteries to excessive

heat such as sunshine, fire or the like.

20)

21) NEVER route the product’s power cord inside a wall

22) Never modify this equipment. Changes or

23)

24) To avoid damage to this product, never place or

ALWAYS plug the product into an outlet that is located in such a manner that it can be easily unplugged in case the product requires service.

or similar enclosed area.

modifications may void: a) the warranty, and b) the user’s authority to operate this equipment under the rules of the Federal Communications Commission.

DANGER: RISK OF SERIOUS PERSONAL INJURY, DEATH, OR EQUIPMENT DAMAGE!

Never place the TV on an unstable cart, stand, or table. The TV may fall, causing serious personal injury, death, or serious damage to the TV.

store the TV in direct sunlight; hot, humid areas; or areas subject to excessive dust or vibration.

25) Always place the TV on the floor or a sturdy, level, stable surface that can support the weight of the TV. In order to maintain stability and prevent the TV falling over, secure the TV with a sturdy strap from the hooks on the rear of the TV pedestal to a wall stud, pillar, or other immovable structure. Make sure the strap is tight, secure, and parallel to the floor.

(The sturdy tie and hooks are applicable to 15CV100U, 15CV101U, 26CV100U and 32CV100U; the band is applicable to 15CV100U,15CV101U and 26CV100U.)

26) The apparatus shall not be exposed to dripping or splashing, and no objects filled with liquids, such as vases, shall be placed on the apparatus.

27) Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV:

• on a bed, sofa, rug, or similar

surface;

• too close to drapes, curtains, or

walls; or

• in a confined space such as a

bookcase, built-in cabinet, or any other place with poor

ventilation. The slots and openings are provided to protect the TV from overheating and to help maintain reliable operation of the TV. Leave a space of at least 4 (four) inches around the TV.

28) Always place the back of the television at least 4 (four) inches away from any vertical surface (such as a wall) to allow proper ventilation.

29) Never allow anything to rest on or roll over the power cord, and never place the TV where the power cord is subject to wear or abuse.

30) Never overload wall outlets and extension cords.

31) Always operate this equipment from a 120 V AC, 60 Hz power source only.

32) Always make sure the antenna system is properly grounded to provide adequate protection against voltage surges and built-up static charges (see Section 810 of the National Electric Code).

Antenna lead-in wire

Ground clamp

Electric service equipment

Power service grounding electrode system (NEC Article 250 Part H)

Antenna discharge unit (NEC Section 810-20)

Grounding conductors (NEC Section 810-21)

Ground clamps

33)

DANGER: RISK OF SERIOUS PERSONAL INJURY OR DEATH!

• Use extreme care to make sure you are never in a

position where your body (or any item you are in contact with, such as a ladder or screwdriver) can accidentally touch overhead power lines. Never locate the antenna near overhead power lines or other electrical circuits.

• Never attempt to install any of the following during

lightning activity: a) an antenna system; or b) cables, wires, or any home theater component connected to an antenna or phone system.

Care

For better performance and safer operation of your TOSHIBA TV/DVD, follow these recommendations and precautions:

34) If you use the TV in a room whose temperature is 32 °F (0°C) or below, the picture brightness may vary until the LCD warms up. This is not a sign of malfunction.

35) Always unplug the TV before cleaning. When cleaning your TV, please first remove any dirt or dust from the surface. Gently wipe the cabinet and the display panel surface (the TV screen) with a dry, soft cloth only (cotton, flannel, etc.). The enclosed cleaning cloth is for cabinet cleaning. Harsh rubbing or use of a dirty or stiff cloth will scratch the TV surface. Avoid contact with alcohol, thinner, benzene, acidic or alkaline solvent cleaners, abrasive cleaners, or chemical cloths, which may damage the TV surface. Never spray volatile compounds such as insecticide on the TV surface. Such products may damage or discolor the TV.

36)

Never spill liquids or push objects of any kind into the TV cabinet slots.

37) While it is thundering, do not touch the connecting cables or apparatus.

38) For added protection of your TV from lightning and power surges, always unplug the power cord and disconnect the antenna from the TV if you leave the TV unattended or unused for long periods of time.

39) ALWAYS unplug the TV to completely disconnect from mains power. When the TV is turned off using the on/off switch, it is not completely disconnected from power and a minute amount of current is still consumed.

40) During normal use, the TV may make occasional snapping or popping sounds. This is normal, especially when the TV is being turned on or off. If these sounds become frequent or continuous, unplug the power cord and contact a Toshiba Authorized Service Center.

WARNING:

RISK OF ELECTRIC SHOCK!

41)

WARNING: RISK OF SERIOUS PERSONAL INJURY OR EQUIPMENT

DAMAGE!

Never strike the screen with a sharp or heavy object.

42) • The LCD screen of this product can be damaged by ultraviolet radiation from the sun. When selecting a location for the television, avoid locations where the screen may be exposed to direct sunlight, such as in front of a window.

• Never touch, press, or place anything on the LCD screen. These actions will damage the LCD screen. If you need to clean the LCD screen, follow the instructions in item 35 on page 4.

Service

43)

Never attempt to service the TV yourself. Opening and removing the covers may expose you to dangerous voltage or other hazards. Failure to follow this WARNING may result in death or serious injury. Refer all servicing not specified in this manual to a Toshiba Authorized Service Center.

44) If you have the TV serviced:

• Ask the service technician to use only replacement

parts specified by the manufacturer.

• Upon completion of service, ask the service

technician to perform routine safety checks to determine that the TV is in safe operating condition.

45) The fluorescent lamp(s) in the LCD panel contains a small amount of mercury. When the TV reaches the end of its useful life, dispose of the used TV by the approved method for your area, or ask a qualified service technician to properly dispose of the TV.

Note: The lamp(s) inside this product contains mercury. Disposal may be regulated due to environmental considerations. For disposal or recycling information, contact your local authorities or the Electronics Industries Alliance (www.eiae.org).

WARNING:

RISK OF ELECTRIC SHOCK!

Choosing a location for your LCD TV

To Display your LCD TV on the included Pedestal Stand:

Observe the following safety precautions:

1) Read and Follow the pedestal assembly instructions included with the pedestal.

CAUTION: Before beginning pedestal assembly, carefully lay the front of the LCD Panel face down on a flat, cushioned surface such as a quilt or blanket. Leave the bottom of the TV protruding over the edge of the surface and assemble the pedestal as indicated below.

Note: Extreme care should always be used when attaching the pedestal stand to avoid damage to the LCD panel.

2) Place the TV on a sturdy, level surface that can support the weight of the TV.

3) Be sure to secure the TV to a wall, pillar, surface, or other immovable structure. ( item 25, page 4).

To Fold the Pedestal Stand (Applicable to 19CV100U/22CV100U)

1) Slide the lever on the back side of the pedestal stand to the left.

2) Lay the display down.

IMPORTANT: Do not operate the LCD TV while the pedestal stand is folded.

To Display your LCD TV using a Wall Bracket:

If you decide to wall mount your LCD TV, always use a UL listed wall bracket appropriate for the size and weight of the LCD TV ( page 2):

1) CAUTION: Two people are required for installation.

2) Unplug and remove any cables and/or other component connectors from the rear of the TV.

3) Follow the instructions provided with your wall bracket. Before proceeding, make sure the appropriate bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the wall bracket.

4) IMPORTANT: Always use the screws supplied or recommended by the wall mount manufacturer.

5) After attaching the appropriate bracket(s) to the wall and the back of the TV, remove the pedestal stand from the TV as described below.

Removing the Pedestal Stand

1) Carefully lay the front of the TV face down on a flat, cushioned surface such as a quilt or blanket. Leave the stand protruding over the edge of the surface.

Note: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD panel.

2) Remove the screws shown in the diagram below. This will allow removal of the pedestal stand.

3) Once you have removed all screws holding the pedestal stand in place, remove the pedestal stand from the TV by sliding the pedestal stand away from the TV.

15CV100U/15CV101U

Two screws

19CV100U/22CV100U

Hooks

Sturdy strap

(as short as possible)

Notes on moisture condensation

Moisture condensation damages the unit. Please read the following carefully.

Moisture condensation occurs, for example, when you pour a cold drink into a glass on a warm day and drops of water form on the outside of the glass. In the same way, moisture may condense on this unit’s internal optical pick-up lens, one of the most crucial internal parts of the unit.

Example of moisture

condensation!

Optical pickup

lens

Moisture condensation may occur in the following situations:

• When you move the unit from a cold area to a warm

area.

• When you use the unit in a room in which the heat was

just turned on.

• When you use the unit in an area where cold air from

an air conditioner directly hits the unit.

• When you use the unit in a humid area.

’

26CV100U/32CV100U

Note:

• 15CV100U, 22CV100U and 26CV100U are used for

illustration purposes.

• The hooks for sturdy strap are not applicable to

19CV100U and 22CV100U.

Never use the unit when moisture condensation may occur.

Using the unit when moisture condensation exists may damage discs and internal parts. Connect the power cord of the unit to the wall outlet, turn on the unit, remove the disc, and leave it for two or three hours. After two or three hours, the unit will have warmed up and evaporated any moisture. Leaving the TV connected to the wall outlet will help prevent moisture condensation in the unit.

Wall outlet

Notes on discs

On handling discs

• Do not touch the playback side of the disc. Handle the

disc as shown in the figure below.

Playback side

• Do not attach paper or tape to discs.

On cleaning discs

• Fingerprints and dust on the disc cause picture and

sound deterioration. Wipe the disc from the center outwards with a soft cloth. Always keep the disc clean.

• Do not use any type of solvent such as thinner,

benzine, commercially available cleaners or antistatic spray for vinyl LPs. It may damage the disc.

On storing discs

• Do not store discs in a place subject to direct sunlight

or near heat sources.

• Do not store discs in places subject to moisture and

dust such as a bathroom or near a humidifier.

• Store discs vertically in a case. Stacking or placing

objects on discs outside of their case may cause warping.

Structure of disc contents

Normally, DVD video discs are divided into titles, and the titles are sub-divided into chapters. Video CDs and Audio CDs are divided into tracks.

DVD

Title 1 Title 2

Chapter 1

Video CD/Audio CD

Chapter 2

Track 1 Track 2 Track 3 Track 4 Track 5

Chapter 1

Video CD/Audio CD

Chapter 2

Chapter 3

Notes on copyright

The unauthorized recording, use, distribution, or revision of copyrighted materials including, without limitation, television programs, videotapes, and DVDs, is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

About this owner’s manual

This owner’s manual explains the basic instructions of this TV/DVD. Some DVD video discs are produced in a manner that allows specific or limited operation during playback. As such, the TV/DVD may not respond to all operating command. This is not a defect of the TV/DVD. Refer to the instruction notes of discs. The following symbol may appear on the TV screen during operation.

It means that the operation is not permitted by the TV/ DVD or the disc. For example, sometimes it is unable to stop the playback of copyright message of the disc when the Stop button is pressed. Alternatively, this symbol may also indicate that the feature is not available for the disc.

Notes on region numbers

The region number of this TV/DVD is 1. If region numbers, which stand for their playable area, are printed on your DVD and you do not find or , disc playback will not be allowed by the player. (In this case, the TV/ DVD will display a message on-screen.). Some DVDs that have no region code label may still be subject to area restrictions and therefore not playable.

On Video CDs

This TV/DVD supports Video CDs equipped with the Playback Control (PBC) function, version 2.0. You can enjoy two playback variations depending on types of discs.

• Video CD not equipped with PBC function (Version 1.1)

Sound and movie can be played on this TV/DVD in the same way as a DVD.

• Video CD equipped with PBC function (Version 2.0)

In addition to operation of a Video CD not equipped with the PBC function, you can enjoy playback of interactive software with search function by using the on-screen playback menu. Some of the functions described in this owner’s manual may not work with some discs.

Each title, chapter or track is assigned a number, which is called “title number”, “chapter number” or “track number” respectively. There may be discs that do not have these numbers.

Playable discs

This TV/DVD can play the following discs.

Disc

Contents

mark

DVD

Video

disc

Video

DIGITAL VIDEO

Audio

The following discs are also supported.

• DVD-R/RW discs containing files of DVD video

format.

• CD-R/CD-RW discs containing CD-DA, Video CD,

MP3, WMA, or JPEG files.

• Kodak Picture CD and FUJICOLOR CD. Some of these discs may be incompatible.

• You cannot play discs other than those listed above.

• You cannot play discs of DVD-RAM, DVD-ROM, CD-

ROM, Photo CD, etc., or non-standardized discs even if they may be labeled as above.

• Some CD-R/RWs cannot be played back depending

on the recording conditions.

• This TV/DVD uses the NTSC color system, and

cannot play DVD video discs recorded in any other color system (PAL, SECAM, etc.).

• This TV/DVD can play an 8 cm disc. Please do not

use a disc adapter. It may cause trouble.

• Please do not insert any disc of an irregular shape into

the TV/DVD, as it may interfere with the function of the TV/DVD. You may not be able to remove it.

• Please do not use after market accessories, such as

a ring protector, as this may cause trouble with the operation of the TV/DVD.

Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that this TV/DVD will successfully play every disc bearing the DVD and CD logos. If you happen to experience any difficulty playing a DVD or CD on this TV/ DVD, please contact Toshiba Customer Service.

is a trademark of DVD Format/Logo Licensing

Corporation.

(moving

pictures)

(moving

pictures)

Audio

Video

Audio

Video

Audio

Disc

size

playback time

Approx. 4 hours

(single sided disc)

12 cm

Approx. 8 hours

(double sided disc)

Approx. 80 minutes

(single sided disc)

8 cm

(double sided disc)

Approx. 74 minutes

12 cm

(single sided disc)

Approx. 20 minutes

8 cm

(single sided disc)

Approx. 74 minutes

12 cm

(single sided disc)

Approx. 20 minutes

8 cm

(single sided disc)

Maximum

Approx. 160

minutes

FCC Declaration of Conformity Compliance Statement (Part 15):

The Toshiba 15CV100U, 15CV101U, 19CV100U, 22CV100U, 26CV100U and 32CV100U LCD TV/ DVD combinations comply with Part 15 of the FCC

rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

The party responsible for compliance to these rules is: Toshiba America Consumer Products, L.L.C. 82 Totowa Rd. Wayne, NJ 07470. Ph: 1-800-631-3811

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by removing and applying power to the equipment, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV

technician for help.

Caution: Changes or modifications to this equipment not expressly approved by Toshiba could void the users authority to operate this equipment.

ENERGY STAR

ENERGY STAR User Information Statement: the factory default settings of this television meet ENERGY STAR® requirements. Enabling or changing certain features and functionality (e.g. Picture Settings) may increase energy consumption, possibly beyond the limits required for ENERGY STAR qualification.

To ensure your television is operating at optimal energy efficiency, select [Home] mode during initial activation.

ENERGY STAR® qualified TV. Products that earn the ENERGY STAR prevent green house gas emissions by meeting strict guidelines set by the U.S. Environmental Protection Agency. ENERGY STAR and the ENERGY STAR mark are registered U.S. marks.

User Information

Important notes about your LCD TV

The following symptoms are technical limitations of LCD Display technology and are not an indication of malfunction; therefore, Toshiba is not responsible for perceived issues resulting from these symptoms.

1) An afterimage (ghost) may appear on the screen if a fixed, non-moving image is displayed for a long period of time. The afterimage is not permanent and will disappear in a short period of time.

2) The LCD panel contained in this TV is manufactured using an extremely high level of precision technology; however, there may be an occasional pixel (dot of light) that does not operate properly (does not light, remains constantly lit, etc.). This is a structural property of LCD technology, is not a sign of malfunction, and is not covered under your warranty. Such pixels are not visible when the picture is viewed from a normal viewing distance.

CLASS 1 LASER PRODUCT

CERTIFICATION: COMPLIES WITH FDA PERFORMANCE STANDARDS FOR LASER PRODUCTS EXCEPT FOR DEVIATIONS PURSUANT TO LASER NOTICE NO.50, DATED JUNE 24, 2007.

CAUTION:

- THIS PRODUCT EMPLOYS A LASER SYSTEM.

- TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS OWNER’S MANUAL CAREFULLY AND RETAIN FOR FUTURE REFERENCE.

- SHALL THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE CENTER.

- USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

- TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE. VISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM.

Trademark Information

• Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

• HDMI, the HDMI logo and High-Definition

Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

• QSound and [ ] symbol are trademarks of

QSound Labs, Inc.

•

Manufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks and DTS Digital Out and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

Contents

Important Safety Instructions ............................3

Installation, Care, and Service ...........................3

Choosing a location for your LCD TV ............... 5

Notes on discs ....................................................7

Chapter 1: Introduction ....................................12

Features of your new TV ..............................12

Overview of steps for installing, setting up,

and using your new TV ................................12

TV front, top and side panel controls and

connections ..................................................13

TV back panel connections ..........................16

Chapter 2: Connecting your TV .......................17

Overview of cable types ...............................17

About the connection illustrations ................17

Connecting TV to a power source ................17

Connecting a VCR, and antenna, Cable TV .18

Connecting a camcorder ..............................18

Connecting a DVD player with ColorStream®

(component video) ....................................... 19

Connecting a satellite receiver .....................19

Connecting an HDMI or DVI device to the

HDMI™ input ...............................................20

REGZA-LINK® connection ...........................21

Connecting a digital audio system ...............22

Connecting a personal computer (PC) .........23

Chapter 3: Using the remote control ...............24

Preparing the remote control for use ............24

Installing the remote control batteries ..........24

Learning about the remote control ...............25

Chapter 4: Menu layout and navigation ..........27

Main menu layout .........................................27

Setup/Installation menu layout .....................27

Navigating the menu system ........................27

Chapter 5: Setting up your TV .........................28

Initial Setup ..................................................28

Selecting the menu language ......................28

Configuring the antenna input source for the

ANT/CABLE terminal ...................................28

Programming channels into the TV’s

channel memory ..........................................29

Programming channels automatically ...29

Programming channels manually ..........29

Labeling channels ........................................30

Setting the HDMI™ audio mode ..................31

Viewing the digital signal meter ....................32

Setting the Time Zone ..................................32

Viewing the system status ............................32

Reset Factory Defaults .................................32

Chapter 6: Using the TV’s features .................33

Selecting the video input source to view ......33

Labeling the video input sources .................33

Tuning channels ...........................................34

Setting the Channel Tuning Mode .........34

Tuning to the next programmed

channel ................................................. 34

Tuning to a specific channel

(programmed or unprogrammed) ..........35

Switching between two channels using

Channel Return ..................................... 35

Selecting the picture size .............................35

Scrolling the TheaterWide® picture

(TheaterWide 2 and 3 only) ......................... 37

Using the auto aspect ratio feature .............. 37

Selecting the cinema mode .......................... 37

Adjusting the picture ....................................38

Selecting the picture mode .................... 38

Adjusting the picture quality ..................38

Using the closed caption mode ....................39

Base closed captions ............................39

Digital CC Settings ................................ 39

CC Selector ...........................................40

Adjusting the audio ......................................40

Muting the sound ................................... 40

Using the digital audio selector ............. 40

Selecting stereo/SAP broadcasts .......... 40

Adjusting the audio quality .................... 41

Selecting the optical audio output

format .................................................... 41

Using the Dolby® Digital Dynamic

Range Control feature ...........................42

Using the Locks menu ................................. 42

Entering the PIN code ........................... 42

If you cannot remember your

PIN code ...............................................42

Changing your PIN code ....................... 42

Blocking TV programs and movies

by rating (V-Chip) ..................................43

Downloading an additional rating system

for blocking TV programs and movies ... 43

Unlocking programs temporarily ........... 44

Using the input lock feature ................... 45

Using the GameTimer® .........................45

Using the control panel lock feature ...... 45

Using the PC settings feature ......................46

Setting the PC Audio .................................... 46

Setting the sleep timer .................................47

Using REGZA-LINK® ...................................47

REGZA-LINK® playback device

(DVD player, etc.) control ......................47

REGZA-LINK® Player Control menu

functions ................................................ 48

REGZA-LINK® input source selection....48

VOLUME and MUTE controls of

Audio Receiver ......................................48

Other REGZA-LINK® functions .............48

Displaying TV status information ................. 49

Understanding the auto power off feature..... 49

Understanding the last mode memory

feature .......................................................... 49

Chapter 7: Using the TV’s advanced

features ..............................................................50

Using the advanced picture settings

features ........................................................ 50

Using dynamic contrast .........................50

Using the static gamma feature ............ 50

Selecting the color temperature ............ 50

Using CableClear® digital noise

reduction ............................................... 51

Using MPEG noise reduction ................ 51

Using the Game Mode feature .............. 51

Using the Auto Brightness Sensor ............... 51

Using the advanced audio settings

features ........................................................ 52

Using the QSound® sound feature ........52

Using the Media Player ................................52

Media Player Specifications ..................52

Basic Operation .................................... 53

Viewing JPEG files ................................ 53

Listening to MP3 files ............................ 54

Chapter 8: Basic disc playback .......................56

Disc playback ...............................................56

Basic playback (DVD/VCD/CD) ............ 56

Removing a disc ................................... 57

Disc playback reminders ....................... 57

Playback navigation .....................................57

Playing in fast reverse or fast forward

direction (DVD/VCD/CD) .......................57

Playing frame by frame (DVD/VCD) ..... 57

Playing in slow motion (DVD/VCD) ....... 57

Locating a chapter or track (DVD/

VCD/CD) ............................................... 58

Chapter 9: Advanced disc playback ............... 59

Zoom function/Scene navigation ................. 59

Using Zoom (DVD/VCD) .......................59

Locating a specific scene (DVD/

VCD/CD) ............................................... 59

Scene bookmark ..........................................60

Bookmarking a scene (DVD/

VCD/CD) ............................................... 60

Viewing a scene bookmark (DVD/

VCD/CD) ............................................... 60

Repeat playback/A-B repeat ........................ 60

Enabling repeat playback (DVD/VCD) ... 60

Enabling A-B repeat mode (DVD/

VCD/CD) ............................................... 61

Programmed playback/Random playback ... 61

Programming the playback sequence

(VCD) .................................................... 61

Enabling random playback (VCD) .........62

Scene angle/Title selection/DVD menu ....... 62

Changing the scene angle (DVD) ......... 62

Selecting a DVD title (DVD) .................. 62

DVD menu (DVD) ................................. 62

Soundtrack language/Audio channel/

Subtitle ......................................................... 63

Selecting a soundtrack language

(DVD) .................................................... 63

Selecting the audio channel (VCD) ....... 63

Viewing subtitles (DVD) ........................ 63

Playback information/VCD playback

control .......................................................... 63

Viewing the playback info (DVD/VCD) ... 63

Turning off the PBC function (VCD) ...... 64

MP3, WMA, JPEG, and Audio CD

operation ...................................................... 65

MP3/WMA/JPEG/Audio CD information

(CD) ...................................................... 65

About the file browser (CD) .................. 66

Playing an audio file (CD) ..................... 66

Viewing a JPEG file (CD) ...................... 67

Viewing a slide show (CD) .................... 67

MP3, WMA, JPEG and Audio CD

playback modes ........................................... 68

Enabling repeat playback (CD) ............. 68

Enabling random playback (CD) ........... 68

Programming the playback sequence

(CD) ...................................................... 69

Chapter 10: Customizing disc playback .........70

Customizing disc playback .......................... 70

Configuring the disc playback settings

(DVD/VCD/CD) .....................................70

Disc playback setup .............................. 71

Chapter 11: Troubleshooting .......................... 75

General troubleshooting .............................. 75

LED Indication ............................................. 77

Chapter 12: Appendix ...................................... 78

Specifications .............................................. 78

Acceptable signal formats for PC IN and

HDMI terminals ............................................ 79

Limited United States Warranty LCD TV/DVD

Combination – Depot Repair Warranty ........ 80

The GNU General Public License (GPL) ..... 82

The Libpng License Notices ........................ 85

The zlib License ........................................... 86

Chapter 1: Introduction

Features of your new TV

The following are just a few of the many exciting features of your new Toshiba integrated HD, LCD TV/DVD:

• Integrated digital tuning (8VSB ATSC and

QAM) eliminates the need for a separate digital converter set-top box (in most cases).

• 1080p output resolution

• Two HDMI

interfaces with 1080p input support ( Page 20).

• HDMI capabilities

• Lip-Sync feature activates an auto audio/video

display timing adjustment function that allows HDMI source devices to accurately perform synchronization automatically.

• REGZA-LINK

devices from the TV remote control via HDMI connection ( Page 47).

• ColorStream

video input ( Page 19).

• QSound

• Digital Audio Out optical audio connection with

Dolby

22).

• CableClear

Page 51).

• PC IN (Analog RGB) computer terminal (

Page 23).

• Channel Labeling allows you to put the Call

Letters (e.g. ABC, HBO, etc.) on the screen along with the station numbers, so you always know what you’re watching ( Page 30).

• Media Player allows you to view your JPEG

pictures and listen to MP3 music ( Page 52).

• ENERGY STAR

™

digital, high-definition multimedia

allows control of external

HD high-resolution component

audio technologies ( Page 52).

Digital optical output format ( Page

digital picture noise reduction (

qualified

Overview of steps for installing, setting up, and using your new TV

Follow these steps to set up your TV and begin using its many exciting features.

Observe the following when choosing a

location for the TV:

• Read “Important notes about your LCD TV”

( Page 9).

• Place the TV in a proper location ( Page 2-

Do not plug in any power cords until AFTER

you have connected all cables and devices to your TV.

BEFORE connecting cables or devices to the

TV, learn the functions of the TV’s connections and controls ( Page 13-16).

Connect your other electronic device(s) to the

TV ( Page 17-23). See “Chapter 3: Using the remote control” (

Page 24) for an overview of the buttons on the remote control, install the batteries and prepare to operate your other device(s).

AFTER connecting all cables and devices, plug

in the power cords for your TV and other devices.

Note: After you turn on the TV, the Initial Setup menu appears automatically by default.

See “Chapter 4: Menu layout and navigation”

for a quick overview of navigating the TV’s menu system ( Page 27). Program channels into the TV’s channel

memory ( Page 29). For details on using the TV’s features, see

Chapters 6 and 7. For details on disc playback, see Chapter 8 and

9. For help, refer to the Troubleshooting Guide,

see Chapter 11. For technical specifications and warranty

information, see Chapter 12.

Chapter 1: Introduction

TV front, top and side panel controls and connections

15CV100U/15CV101U

Power LED ─ This indicates the TV’s status.

See “LED indication” on Page 77 for additional information.

Remote sensor (embedded) ─ Point the

remote control toward this remote sensor.

Effective range:

Auto Brightness Sensor ─ This sensor

will detect the ambient light conditions to optimize the backlighting levels. See “Using the Auto Brightness Sensor”on Page 51 for additional information.

Disc slot ─ Load the disc into the disc slot

to view or listen.

HDMI 2 ─ High-Definition Multimedia

Interface (HDMI 2) input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device. HDMI connection is necessary to receive 1080p signals.

USB terminal ─ For use when inserting a

USB device.

Headphone jack ─ For use when inserting

a stereo headphone (not supplied) with a 1/8inch (3.5 mm) mini plug.

Note: Connecting a headphone to the TV/ DVD will mute the sound from the built-in speakers.

POWER ─ Press to turn the TV on and off.

If the TV stops responding to the controls on the remote control or TV control panel and you cannot turn off the TV, press and hold the POWER button on the TV control panel for 5 or more seconds to reset the TV.

INPUT/ENTER ─ Repeatedly press to change the source you are viewing (ANT/ CABLE, Video, ColorStream HD, HDMI

1, HDMI 2, PC, DVD).When a menu is on-

screen, the INPUT button on the TV’s control panel functions as the ENTER button.

MENU ─ Press to access the menu system

( Page 27).

STOP/CHANNEL ─ Press to stop the

disc playback in DVD mode; press to change the channel in TV mode.

ARROW

button functions as down menu navigation button.

PLAY/CHANNEL ─ Press to play the

disc in DVD mode; press to change the channel in TV mode.

ARROW ─ When a menu is on-screen, the button functions as up menu navigation button.

VOLUME+/– ─ These buttons adjust the

volume level.

EJECT ─ Press to eject the disc.

─

When a menu is on-screen, the

Chapter 1: Introduction

19CV100U/22CV100U/26CV100U/32CV100U

Power LED ─ This indicates the TV’s

status. See “LED indication” on Page 77 for additional information.

Remote sensor ─ Point the remote control

toward this remote sensor.

Effective range:

Auto Brightness Sensor ─ This sensor

will detect the ambient light conditions to optimize the backlighting levels. See “Using the Auto Brightness Sensor” on Page 51 for additional information.

Note: 22CV100U is used for illustration purposes.

Chapter 1: Introduction

19CV100U/22CV100U

Disc slot ─ Load the disc into the disc slot to

view or listen.

EJECT ─ Press to eject the disc.

VOLUME+/– ─ These buttons adjust the

volume level.

PLAY/CHANNEL ─ Press to play the

disc in DVD mode; press to change the channel in TV mode.

ARROW ─ When a menu is on-screen, the button functions as up menu navigation button.

STOP/CHANNEL ─ Press to stop the

disc playback in DVD mode; press to change the channel in TV mode.

ARROW

─ When a menu is on-screen, the button functions as down menu navigation button.

MENU ─ Press to access the menu system

( Page 27).

INPUT/ENTER ─ Repeatedly press to change the source you are viewing (ANT/ CABLE, Video, ColorStream HD, HDMI 1, HDMI 2, PC, DVD).When a menu is on-

screen, the INPUT button on the TV’s control panel functions as the ENTER button.

POWER ─ Press to turn the TV on and off. If

the TV stops responding to the controls on the remote control or TV control panel and you cannot turn off the TV, press and hold the POWER button on the TV control panel for 5 or more seconds to reset the TV.

26CV100U/32CV100U

HDMI 2 ─ High-Definition Multimedia

USB terminal ─ For use when inserting a

USB device.

Headphone jack ─ For use when inserting

a stereo headphone (not supplied) with a 1/8inch (3.5 mm) mini plug.

Note: Connecting a headphone to the TV/DVD will mute the sound from the built-in speakers.

Note: 22CV100U and 26CV100U are used for illustration purposes.

Adjusting the screen angle (Applicable to 19CV100U/22CV100U)

You can adjust the angle of the TV screen 3° forward or 15° backward from a vertical angle. Hold the base of the TV while adjusting the screen.

Some illustrations in this owner’s manual are for explanation purposes and may differ from the actual unit.

Chapter 1: Introduction

TV back panel connections

For an explanation of cable types and connections see Page 17-23.

AC input jack ─ Connect one end of the

supplied AC power cord into the TV’s AC input jack and the other to a power outlet to turn on and operate the TV.

AUDIO/COLOR STREAM HD ─

ColorStream

high-definition component video inputs (with standard stereo audio inputs) for connecting devices with component video output, such as a Toshiba

DVD player with ColorStream

Note: Component video cables carry only video information; separate audio cables are required for a complete connection.

AUDIO/VIDEO ─ Standard (composite)

video and standard audio inputs plus for connecting devices with composite video.

Note: Standard (composite) video cables carry only video information; separate audio cables are required for a complete connection.

DIGITAL AUDIO OUT ─ Optical audio

output in Dolby Digital or PCM (Pulse-Code Modulation) format for connecting an external Dolby Digital decoder, amplifier, or home theater system with optical audio input.

HDMI 1/PC AUDIO IN ─ PC audio input

terminal is shared with HDMI 1 analog audio input terminal, and its use can be configured in the Audio Setup menu ( Page 46).

PC IN ─ For use when connecting a personal

computer.

HDMI 1 ─ High-Definition Multimedia

Interface (HDMI 1) input receives digital audio and uncompressed digital video from an HDMI device or uncompressed digital video from a DVI device. Also see item 5. HDMI connection is necessary to receive 1080p signals.

TUNER (ANT/CABLE) ─ Input that

supports analog (NTSC) and digital (ATSC) off-air antenna signals and analog and digital Cable TV (QAM) signals.

Note: 22CV100U is used for illustraion purposes.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Chapter 2: Connecting your TV

Overview of cable types

Cables can be purchased from most stores that sell audio/video devices. Before purchasing any cables, be sure of connector types required by your devices and the length of each cable.

Coaxial (F-type) cable

Coaxial (F-type) cable is used for connecting your antenna, cable TV service, and/or cable converter box to the TUNER input on your TV.

Standard A/V cables (red/white/yellow)

Standard A/V cables (composite video) usually come in sets of three and are for use with video devices with analog audio and composite video output. These cables (and the related inputs on your TV) are typically color-coded according to use: yellow for video, red for stereo right audio, and white for stereo left (or mono) audio.

Component video cables (red/green/blue)

Component video cables come in sets of three and are for use with video devices with component

video output. (ColorStream component video.) These cables are typically color-coded red, green, and blue. Separate audio cables are required for a complete connection.

Note: Component video cables provide better picture performance than a standard (composite) video.

HDMI™ cable (with HDMI Logo )

is Toshiba’s brand of

Optical audio cable

Optical audio cable is for connecting receivers with Dolby Digital or PCM (Pulse-Code Modulation) optical audio input to the TV’s

DIGITAL AUDIO OUT terminal ( Page 22).

Analog RGB (15-pin) computer cable

Analog RGB (15-pin) computer cable is for connecting a PC to the TV’s PC IN terminal ( Page 23).

Note: Separate audio cables are required for a complete connection.

About the connection illustrations

You can connect different types and brands of devices to your TV in several different configurations. The connection illustrations in this manual are representative of typical device connections only. The input/output terminals on your devices may differ from those illustrated herein. For details on connecting and using your specific devices, refer to each device’s owner’s manual.

Connecting TV to a power source

To connect AC power:

Connect the AC cord plug into the TV/DVD’s AC input jack and then connect the AC cord into an AC outlet.

AC input jack

120 V, 60 Hz outlet

HDMI (High-Definition Multimedia Interface) cable is for use with devices with an HDMI output. An HDMI cable delivers digital audio and video in its native format. This cable carries both video and audio information; therefore, separate audio cables are not required for a complete HDMI device connection ( Page 20, 21 and 23).

Note: An HDMI cable provides the best audio and picture performance.

AC cord (supplied)

Notes:

• Never connect the AC cord plug to other

than the specified voltage (120 V, 60 Hz). Use the supplied power cord only.

• If you cause a static discharge when touching the TV/DVD and it fails to function, simply unplug the TV/DVD from the AC outlet and plug it back in. The TV/DVD should return to normal operation.

Chapter 2: Connecting your TV

Connecting a VCR, and antenna, Cable TV

Red

Yellow

White

Red

Yellow

White

You will need:

• coaxial cables

• standard A/V cables

Note: When you use a Cable box, you may not be able to use the remote control to program or access certain features on the TV.

To view the antenna or Cable signal:

Select the ANT/CABLE video input source on the TV.

To view basic and premium Cable channels:

Turn OFF the VCR. Select the ANT/CABLE video input source on the TV. channel 3 or 4 (whichever channel the Cable box output is set to). Use the Cable box controls to change channels.

To view the VCR:

Turn ON the VCR. Select the Video video input source on the TV.

* Tune the TV to

Connecting a camcorder

Red

Yellow

White

Yellow

Red

White

You will need:

• standard A/V cables

To view the camcorder video:

Select the Video video input source on the TV.

* To select the video input source, press on the

remote control ( Page 33).

The unauthorized recording, use, distribution, or revision of television programs, videotapes, DVDs, and other materials is prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

* To select the video input source, press on the

remote control ( Page 33).

Chapter 2: Connecting your TV

Connecting a DVD player with ColorStream® (component video)

Green

Blue

Red

White

Red

Green

White

Blue

Red

You will need:

• standard audio cables

• component video cables

– You can connect the component video

cables (plus audio cables) from the DVD player to the COLOR STREAM HD terminal on the TV. The COLOR STREAM HD terminal can be used to display Progressive (480p, 720p) and Interlaced (480i, 1080i). Please check the Owner’s Manual of the DVD player in order to determine the best output signal available.

– If your DVD player does not have

component video, connect a standard A/V cable to AUDIO/VIDEO terminal. If your DVD player has HDMI video, see Page

20.

To view the DVD player:

Turn ON the DVD player. Select the ColorStream HD video input source on the TV.

* To select the video input source, press on the

remote control ( Page 33).

Connecting a satellite receiver

Green

Blue

Red

White

Red

Green

White

Blue

Red

You will need:

• standard audio cables

• component video cables

– You can connect the component video

cables (plus audio cables) from the satellite receiver to the COLOR STREAM

HD terminal on the TV. The COLOR STREAM HD terminal can be used to

display Progressive (480p, 720p) and Interlaced (480i, 1080i). Please check the Owner’s Manual of the satellite receiver in order to determine the best output signal available.

–

If your satellite receiver does not have component video, connect a standard A/V cable to AUDIO/VIDEO terminal.

To view satellite programs using the component video connections:

Turn on the satellite receiver. Select the ColorStream HD video input source on the TV.

* To select the video input source, press on the

remote control ( Page 33).

Chapter 2: Connecting your TV

Connecting an HDMI or DVI device to the HDMITM input

The HDMI input on your TV receives digital audio and uncompressed digital video from an HDMI source device, or uncompressed digital video from a DVI (Digital Visual Interface) source device. This input is designed to accept HDCP (HighBandwidth Digital-Content Protection) program material in digital form from EIA/CEA-861-E compliant a set-top box or DVD player with HDMI or DVI output). The HDMI input can accept and display VGA, SVGA, XGA, WXGA, 480i (60 Hz), 480p (60 Hz), 720p (60 Hz), 1080i (60 Hz), and 1080p (24 Hz/30 Hz/60 Hz) signal formats. For detailed signal specifications, see Page 79. Supported Audio format: Linear PCM, sampling rate 32/44.1/ 48 kHz.

Note: To connect a PC to the HDMI input, see Page 23.

To connect an HDMI device, you will need:

• one HDMI cable per HDMI device

[1]

consumer electronic devices (such as

– For proper operation, it is recommended

that you use an HDMI cable with the HDMI Logo ( ).

– To display a 1080p/60 Hz signal format,

you will need a High Speed HDMI cable. Conventional HDMI/DVI cable may not work properly.

– HDMI cable transfers both video and

audio. Separate analog audio cables are not required (see illustration).

– See “Setting the HDMI

audio mode”

( Page 31).

To view the HDMI device video:

Select the HDMI 1 or HDMI 2 video input source on the TV.

* To select the video input source, press on the

remote control ( Page 33).

To connect a DVI device, you will need:

• one HDMI-to-DVI adapter cable

– For proper operation, the length of an

HDMI-to-DVI adapter cable should not exceed 9.8 ft (3m). The recommended length is 6.6 ft (2m).

• one pair of standard analog audio cables per DVI

device.

– An HDMI-to-DVI adapter cable transfers

video only. Make sure to connect this cable to the HDMI 1 input on the TV. Separate analog audio cables are required (see illustration).

– See “Setting the HDMI

audio mode” (

Page 31).

Red

White

Note: To ensure that the HDMI or DVI device is reset properly, it is recommended that you follow these procedures:

• When turning on your electronic

components, turn on the TV first and then the HDMI or DVI device.

• When turning off your electronic

components, turn off the HDMI or DVI device first and then the TV.

[1] EIA/CEA-861-E compliance covers the

transmission of uncompressed digital video with high-bandwidth digital content protection, which is being standardized for reception of highdefinition video signals. Because this is an evolving technology, it is possible that some devices may not operate properly with the TV.

HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

Chapter 2: Connecting your TV

REGZA-LINK® connection

You can control the basic functions of connected audio/video devices using the TV’s remote control if you connect a REGZA-LINK

compatible audio receiver or playback device. For an explanation of setup and

operations, see Page 47-49.

To connect an audio receiver and playback devices, you will need:

• HDMI cables ( Page 17)

Note:

• If several devices are connected, REGZA-

LINK

feature may not operate properly.

• For proper operation, it is recommended

that you use HDMI cables with the HDMI Logo ( ).

Before controlling the device(s):

• After completing the above connections, set the

REGZA-LINK Setup menu as you desire (

Page 49).

• The connected devices must also be set. For

details, see the operation manual for each device.

• The REGZA-LINK

feature uses the CEC

technology as regulated by the HDMI standard.

• This feature is limited to models incorporating

Toshiba’s REGZA-LINK

. However, Toshiba is not liable for those operations. Refer to the individual instruction manuals for compatibility information.

Note: This feature may not work properly depending on the devices that are connected.

Chapter 2: Connecting your TV

Connecting a digital audio system

The TV’s DIGITAL AUDIO OUT terminal outputs a Dolby

down-mixed PCM (Pulse-Code Modulation) signal for use with an external Dolby

decoder or other external audio system with optical audio input.

If you have a DTS can obtain the full benefit of 5.1 channel DTS encoded soundtracks on DVDs and audio CDs.

You will need:

• optical audio cable (Use an optical audio cable

that has the larger “TosLink” connector and not the smaller “mini-optical” connector.)

To control the audio:

Turn on the TV and the digital audio device.

Press on the remote control and open the

Sound menu. Press or to select Audio Setup and then

press .

* Digital or 2-channel

Digital

* decoder or processor, you

Press or to select either Dolby Digital or

PCM, depending on your device.

( “Selecting the optical audio output format” on Page 41).

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Note:

• Some audio systems may not be compatible

with Dolby Digital bitstream signals. Older audio systems that are not compatible with standard optical out signals may not work properly, creating a high noise level that may damage speakers or headphones. THIS DAMAGE IS NOT COVERED BY YOUR WARRANTY.

• The DIGITAL AUDIO OUT terminal may not

output some digital audio sources because of copy restrictions.

* Manufactured under license from Dolby

Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

** M

anufactured under license under U.S. Patent #: 5,451,942 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks and DTS Digital Out and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

Press or to select Optical Output

Format.

Chapter 2: Connecting your TV

Connecting a personal computer (PC)

With either the PC IN or HDMI connection, you can watch your computer’s display on the TV and hear the sound from the TV’s speakers.

To connect a PC to the PC IN terminal on the TV:

When connecting a PC to the PC IN terminal on the TV, use an analog RGB (15-pin) computer cable and a PC audio cable.

• Signal names for mini D-sub 15-pin connector

Signal

No.

name

1 R 6 Ground 11 Reserved

2 G 7 Ground 12 SDA

3 B 8 Ground 13 H-sync

4 Reserved 9 5V 14 V-sync

5 Ground 10 Ground 15 SCL

Pin No.

Signal name

Pin No.

Signal Name

To connect a PC to the HDMI terminal on the TV:

When connecting a PC to the HDMI terminal on the TV, use an adapter cable and analog audio cables.

If connecting a PC with an HDMI terminal, use an HDMI cable. Separate analog cables are not necessary ( Page 17).

• To use a PC, set the monitor output resolution on

the PC before connecting it to the TV. The PC IN terminal can accept and display VGA, SVGA, XGA, and WXGA signal formats. For detailed signal specifications, see Page 79.

• To display the optimum picture, use the PC

settings feature ( “Using the PC settings feature” on Page 46).

Note:

• The PC audio input terminal on the TV is

shared with the HDMI 1 analog audio input terminal.

• Some PC models cannot be connected to

this TV.

• An adapter is not needed for computers with

a compatible mini D-sub15-pin terminal.

• Depending on the DVD’s title and the

specifications of the PC on which you are playing the DVD-Video, some scenes may be skipped or you may not be able to pause during multi-angle scenes.

The HDMI input can accept and display VGA, SVGA, XGA, WXGA, 480i (60 Hz), 480p (60 Hz), 720p (60 Hz), 1080i (60 Hz), and 1080p (24 Hz/30 Hz/60 Hz) signal formats. For detailed signal specifications, see Page 79.

Note:

• The edges of the images may be hidden.

• If receiving a 480i (HDMI), 480p (HDMI),

720p, 1080i, or 1080p signal program, Native mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

Chapter 3: Using the remote control

Preparing the remote control for use

The remote control can operate your TV/DVD and control the basic functions of connected audio/

video devices if you connect a REGZA-LINK compatible audio receiver or playback device ( Page 47).

Installing the remote control batteries

Remove the battery cover from the back of the

remote control.

Squeeze tab and lift cover

Install two AAA size batteries. Match the + and

– symbols on the batteries to the symbols on the battery compartment.

Close the battery cover on the remote control

until the tab snaps.

Caution: Batteries must not be exposed to excessive heat such as sunshine, fire or the like.

Note:

• Be sure to use AAA size batteries.

• Dispose of batteries in a designated

disposal area.

• Batteries should always be disposed of with

the environment in mind. Always dispose of batteries in accordance with applicable laws and regulations.

• If the remote control does not operate

correctly, or if the operating range becomes reduced, replace batteries with new ones.

• When necessary to replace batteries in the

remote control, always replace both batteries with new ones. Never mix battery types or use new and used batteries in combination.

• Always remove batteries from the remote

control if they are dead or if the remote control is not to be used for an extended period of time. This will prevent battery acid from leaking into the battery compartment.

Chapter 3: Using the remote control

Learning about the remote control

The buttons used for operating the TV/DVD are described here. For the REGZA-LINK

control functions, see the section “Using REGZA-

LINK

” ( Page 47).

Note: The error message “NOT AVAILABLE” may appear if you press a key for a function that is not available.

remote

POWER turns the TV on and off. When the

TV is on, the Power LED indicator on the TV

front will be illuminated in green.

SLEEP accesses the sleep timer ( Page

47).

EJECT ejects the disc from the disc slot.

TV/DVD switches to TV or DVD mode.

Channel Numbers directly tune channels.

JUMP selects or locates a specific point with

the disc playback ( Page 59); tunes to a

digital sub-channel as a “dash”.

DISPLAY displays setting or playback

information ( Page 49, 63).

AUDIO SELECT selects the DVD

soundtrack language or VCD audio channel

( Page 63).

VOL + – adjusts the volume level.

CH cycles through programmed

channels when no menu is on-screen (

Page 34).

SUBTITLE selects the subtitle language or

switches subtitle off ( Page 63).

INPUT/ZOOM selects the video input source

( Page 33); zooms into the center of the

image during disc playback ( Page 59).

PLAY MODE sets the disc playback repeat

mode ( Page 60).

MUTE reduces or turns off the sound (

Page 40).

DVD MENU accesses the DVD menu (

Page 62).

ENTER activates highlighted items in the

main menu system.

Arrow buttons ( ) select or

adjust programming menus when a menu is

on-screen.

EXIT/CANCEL closes on-screen menus.

MENU/SETUP accesses the main TV menu

system ( Page 27); configures the disc

playback settings ( Page 70).

PLAY begins playback of the loaded disc (

Page 56).

PAUSE suspends disc playback temporarily

or plays back disc frame by frame ( Page

56, 57).

STOP stops playback of the loaded disc (

Page 56).

Chapter 3: Using the remote control

CLOSED CAPTION/SKIP accesses

the Closed Caption menu ( Page 39); skips forward to locate later DVD chapters ( Page 58).

CH RTN/SKIP returns to the last

viewed channel or source ( Page 35); skips back to beginning of current DVD chapter or locate previous chapters ( Page 58).

FF fast-forwards playback of the disc

( Page 57). REV fast-reverses playback of the disc ( Page 57).

SLOW slow-reverses playback of the disc

( Page 57).

SLOW slow-forwards playback of the

disc ( Page 57).

MARKER bookmarks specific points in the

playback range for later access ( Page 60).

ANGLE changes the scene angle when

playing back a DVD recorded with multiangle scenes ( Page 62).

REPEAT A-B repeats playback of a specific

section between two set points ( Page 61).

TOP MENU accesses the top menu of DVDs

that contain two or more titles ( Page 62).

RETURN returns to the root directory in

Audio CD playback ( Page 66); returns to previous directory from Media Player subfolder or sub-menu ( Page 53).

GAME displays the Game mode screen when

using the TV as display device for video game consoles ( Page 51).

PIC SIZE cycles through the picture sizes

( Page 35).

Chapter 4: Menu layout and navigation

Main menu layout

To open the main menus (illustrated below), press

on the remote control or MENU on the TV

control panel.

Icon Item Page


Sound

Preferences

Locks

Setup

Mode 38

Picture Settings 38

Noise Reduction 51

Game Mode 51

Theater Settings 35-37

Audio Settings 41

Advanced Audio Settings 52

Audio Setup 40-42

CC and Digital Audio Selectors

Base CC Mode 39

Digital CC Settings 39

Input Labeling 33

Channel Labeling 30

Menu Language 28

REGZA-LINK Player Control

Enable Rating Blocking 43

Edit Rating Limits 43

Input Lock 45

Control Panel Lock 45

GameTimer 45

New PIN Code 42

Installation 28-32

REGZA-LINK Setup 49

Sleep Timer 47

PC Settings 46

Media Player 53

Setup/Installation menu layout

The Installation menu contains the Ter r estria l and System Status menus. To o p e n the Installation menu (illustrated

below), press on the remote control, open the

Setup menu, select Installation, and press .

Icon Item Page

Terrestrial

System Status

Input Configuration 28

Channel Program 29

Channel Options 29

Channel Tuning Mode 34

Time Zone 32

Signal Meter 32

System Information 32

Navigating the menu system

You can use the buttons on the remote control or TV control panel to access and navigate your TV’s on-screen menu system.

• Press to open the menu.

• Press or on the remote control to select the

top menu, and its respective items will appear below.

• To use the items, press or on the remote

control or TV control panel to move up and down through them.

• Press or to adjust settings or press to

enter the sub-menus.

• All menus close automatically if you do not make

a selection within 60 seconds, except the signal meter menu, which closes automatically after about 5 minutes.

• To close a menu instantly, press .

Chapter 5: Setting up your TV

Initial Setup

When you first turn on or reset the TV, the Initial Setup window will appear.

In the Menu Language field, press or

to select your preferred language. Press or to select Time Zone Setup

and set your desired time zone with or and then press . Next, the location setting window will appear.

For normal home use, press or to select Home and then press . Next, ANT/CABLE In setup window will

appear. Press or to select the input source (Cable or Antenna) for the ANT/CABLE input on the TV.

If you select Antenna, the Channel Tuning

Mode setup window will appear. To tune only

digital channels, select Digital. To tune digital channels preferentially over analog when entering channel number directly, select Auto.

For normal tuning, select Standard. Press to continue to Auto Tuning.

Press to select Start Scan and continue

with the Auto Tuning.

Selecting the menu language

You can choose from three different languages (English, French and Spanish) for the on-screen display of menus and messages.

Press to open the menu.

Press or to highlight Preferences

menu. Press or to select Menu Language.

Press or to select your preferred menu

language.

Configuring the antenna input source for the ANT/CABLE terminal

From the Setup menu, press or to

select Installation and then press . Press or to highlight Terrestrial, and

then press or to select Input Configuration and then press . Press or to highlight ANT/CABLE In

and then press or to select the input source (Cable or Antenna) for the input on the TV.

To save your new settings, highlight Done

and then press . To revert to your original settings, highlight Cancel and then press .

Chapter 5: Setting up your TV

Programming channels into the TV’s channel memory

When you press or on the remote control or TV control panel, your TV will stop only on the channels you programmed into the TV’s channel memory.

Follow the steps below to program channels into the TV’s channel memory.

Programming channels automatically

Your TV can automatically detect all active channels in your area and store them in its memory. After the channels are programmed automatically, you can manually add or skip individual channels in the channel memory.

Note:

• You must configure the ANT/CABLE input

source before programming channels ( Page 28).

• The automatic channel programming

process will erase channels that were previously programmed into the TV’s memory.

• To tune the TV to a channel not

programmed in the channel memory, you must use the Channel Number buttons on the remote control.

• Programming channels when the ANT/

CABLE input is configured for Cable will take substantially longer than when the antenna input is configured for Antenna. This is normal; however, once channel programming is finished, you should not have to repeat the programming process again unless your Cable TV service lineup changes significantly.

To program channels automatically:

Configure the ANT/CABLE In input if you

have not already done so ( Page 28). From the Setup menu, press or to

select Installation and then press . Press or to highlight Terrestrial, and

press or to select Channel Program and then press . A screen will appear warning that previous

programs and settings will be deleted.

Press to start channel programming.

The TV will automatically cycle through all the channels, and store all active channels in the channel memory. When Auto Tuning is

finished, press or to view the programmed channels.

Programming channels manually

After automatically programming channels into the channel memory, you can manually programming individual channels.

To skip channels in the channel memory

To prevent certain channels from being viewed, channel positions can be skipped.

From the Setup menu, press or to

select Installation and then press . Press or to highlight Terrestrial, and

press or to select Channel Options and then press . The list of channels will

appear.

Press or to select a channel position to be

skipped and then press the box. To remove the tick, press

To save the setting, press .

Note: Skipped channels cannot be selected with or ; however, they can still be

accessed using the number keys on the remote control.

. A tick will appear in

again.

Chapter 5: Setting up your TV

To block channels in the channel memory:

You can block specific channels. You will not be able to tune blocked channels unless you unlock them.

From the Channel Options menu, press

to move to the channel lock list.

Press or to select a channel position to

be locked and then press . Enter your fourdigit PIN code. A tick will appear in the box.

To remove the tick, press again. To save the setting, press .

To manually add digital subchannels on a physical channel:

Use the Channel Numbers and the Dash ( ) on the remote control to enter the channel number (for example, 56–1).

If the channel is found, the number will be added to the list.

If the channel is not found, a message will appear.

To remove encrypted channels from the channel memory:

If an encrypted channel is accidentally added to the channel list by programming channels, you can remove the unwanted encrypted (non-viewable) channel while you are channel surfing. When you tunes to an encrypted channel, the following message will appear.

Digital Channel Is Encrypted - Press 1 on remote to remove channel

Press while the message is on the screen to

remove the unnecessary channel from the channel list.

Labeling channels

A list of common channel labels (logos) for various channels (ABC, CBS, etc.) will be programmed into the TV. You will be able to view and assign these logos from the Channel Labeling window. If the desired channel label is not provided in the list, you will be able to manually enter/edit labels using the software keyboard.

To assign channel labels:

From the Preferences menu, press or

to select Channel Labeling and then press

The Channel Labeling window opens. Press or to select the channel you want

to label. Press to select the desired

channel label and then press . Repeat steps 2 and 3 for other channels.

To save your settings, highlight Done and

then press .

Note: The maximum number of labels that can be stored is 128.

To remove channel labels:

Open the Channel Labeling window.

Press or to select the channel for which

you want to remove the label. Press to select {No Label} and

then press . Repeat steps 2 and 3 for other channels.

To save your settings, highlight Done and

then press .

Chapter 5: Setting up your TV

To create and assign a custom label:

If the desired channel label is not available from the list of presets, you can create a custom label.

Open the Channel Labeling window.

Press or to select a channel you want to

label. Press or to select Custom and then

press . The software keyboard will appear.

Repeatedly press the corresponding key on the

remote control to highlight the desired character on the on-screen software keyboard.

The highlighted character is entered after you

either press a different key, press , or after a two-second pause.

Repeat steps 4 and 5 until you have entered all

desired text. Press when finished. New labels will be added to the list in

alphabetical order and marked with an icon to indicate that they are custom. Highlight the

new custom label and then press to assign.

To delete the custom label:

Open the Channel Labeling window.

Highlight the label to be deleted and then press

Highlight Yes from the deletion confirmation

window and then press .

Setting the HDMITM audio mode

To set the HDMITM audio mode:

From the Sound menu, press or to

select Audio Setup and then press . Press or to select HDMI 1 Audio and

then press or to select the HDMI 1 audio mode (Auto is the recommended mode). See “Connecting an HDMI or DVI device to the HDMI™ input”( Page 20).

To save your settings, highlight Done and

then press .

Mode Description

When viewing the HDMI 1 input, if digital audio from the HDMI input is

Auto

Digital

Analog

Note: Because the PC and HDMI-1 inputs share the same set of analog audio inputs, the

PC Audio menu setting influences the HDMI 1 Audio menu setting. If PC Audio is set to

“No”, the HDMI 1 Audio setting changes to “Auto”. If PC Audio is set to “Yes”, the HDMI 1 Audio setting is set to “Digital” and is grayed out in the menu. ( “Connecting an HDMI or DVI device to the HDMI™ input” on Page 20.)

available, it will be output. If not, the TV will automatically detect and output analog audio from the PC Audio input.

When viewing the HDMI 1 input, digital audio from the HDMI input will be output.

When viewing the HDMI 1 input, analog audio from the PC Audio input will be output.

Chapter 5: Setting up your TV

Viewing the digital signal meter

You can view the digital signal meter in the ANT/ CABLE digital TV input source only.

To view the digital signal meter:

From the Setup menu, press or to

select Installation and then press . Press or to highlight Terrestrial, and

press or to select Signal Meter and then press . Press to select the antenna input

and digital channel whose signal you want to check.

Note:

• The physical digital channel number

listed in the Signal Meter screen may not correspond to a virtual TV channel number. Contact your local broadcasters to obtain the RF channel numbers for your local digital stations.

• The signal strength does not change

between virtual channels on the same physical channel.

Setting the Time Zone

The Time Zone setup will allow you to specify the correct time zone for your region. This feature will allow the TV status information to show the correct time zone information for your viewing area.

To set the time zone:

From the Setup menu, press or to

select Installation and then press . Press or to highlight Terrestrial, and

press or to select Time Zone and then press . Press and then or to select the region.

3 4

Highlight Done, and then press .

After the time zone has been set, you will be asked to set the current Daylight Saving Time status.

To set the Daylight Saving Time Status:

Press or to select Yes or No, highlight

Done, and then press .

Viewing the system status

From the Setup menu, press or to

select Installation and then press . Press or to highlight System Status,

and press or to select System Information and then press .

Press or to scroll through the menu bar to

select Support Information and view the related information.

Reset Factory Defaults

From the Setup menu, press or to

select Installation and then press . Press or to highlight System Status,

and press or to select System Information and then press .

Press or to scroll through the menu bar to

select Factory Defaults. Enter your PIN code (or 0000 if no PIN code

has been set). Highlight Yes and then press . The TV will

turn off automatically after a few seconds. After the TV turns off, unplug the TV power cord and then plug it in again to complete the reset process.

To cancel the reset:

Highlight No and then press .

Chapter 6: Using the TV’s features

Selecting the video input source to view

Press on the remote control or INPUT/

ENTER on the TV control panel.

And then either:

a) Press 0–6; or b) Repeatedly press or on the remote

control and then press to change the input; or

c) Repeatedly press on the remote control

or INPUT/ENTER on the TV control panel to change the input.

The current signal source displays in the top right corner of the Input Selection screen.

Note:

• You can label the video input sources

according to the specific devices you have connected to the TV ( “Labeling the video input sources” at right).

• Sources can be hidden ( “Labeling the

video input sources” at right).

• “No video signal” will appear randomly on

the screen if no signal is received in video input mode.

• If CEC device is connected to an HDMI

input, the REGZA-LINK icon will appear.

If a REGZA-LINK® device with HDMI switching capability (e.g. Audio Receiver) is connected to the HDMI input:

Press on the remote control or INPUT/ENTER on the TV control panel repeatedly to highlight HDMI 1or HDMI 2. If the connected CEC device has any connected devices, a separate device selection popup window will appear.

HDMI 1 - 1 Audio Receiver

HDMI 1 - 2 Player

Press repeatedly to highlight the desired input

source, and then press .

Note:

• When selecting REGZA-LINK

sources from the popup window using , some REGZA-LINK automatically turn on.

• When selecting input sources using or

, you will have to press to actually

select a particular device from the popup window.

devices may

input

Labeling the video input sources

You can label each video input source according to the type of device you connected to each source, from the following preset list of labels:

• – – (default label)

• Audio Receiver

• Cable

• Compact Disc

• DTV

• DVD

• Game Console

• HDMI Switch (HDMI inputs only)

• Laser Disc

• Satellite/DSS

• VCR

• Video Recorder

• Hide (to hide an unused input in the Input

Selection screen)

Note: If you select PC in the Input Selection screen, you can choose only “– –”, “Game Console” or “Hide” as the label.

To label the video input sources:

From the Preferences menu, press or

to select Input Labeling and then press .

Press or to select the video source you

want to label. Press or to select the desired label for

that input source. If a particular input is not used, you can select Hide as the label, which will cause that input to be “grayed out” in the Input Selection screen and skipped over when you press on the remote control or

INPUT/ENTER on the TV control panel. To save the new input labels, highlight Done

and then press . To revert to the factory default labels, highlight Reset and then press .

Chapter 6: Using the TV’s features

Input labeling example:

The screen below is an example of how you could label the inputs if you connected a VCR to Video, a Video Recorder to HDMI 1, and a DTV set-top box to HDMI 2. Also note that the ColorStream HD input is labeled “Hidden”, which means that

input will be skipped over when is pressed.

To clear the input labels:

From the Preferences menu, press or

to select Input Labeling and then press . Highlight Reset and then press .

Tuning channels

Setting the Channel Tuning Mode

This feature allows you to choose how tuning will be handled for analog and digital channels when the TV is in Antenna mode.

Note: To use this feature, the Input Configuration must be set to Antenna (

Page 28).

The channel tuning mode has three options.

Mode Description

Standard

Auto (Default)

Digital Only digital channels can be tuned.

From the Setup menu, press or to

select Installation and then press . Press or to highlight Terrestrial, and

then press or to select Channel Tuning Mode.

Press or to select your desired mode.

Note: Even if the Channel Tuning Mode is set to Digital, analog channel 3 will still be the default channel to prevent the initial case where no digital channels have been found in prior channel scans.

Tuning to the next programmed channel

To tune to the next programmed channel:

Press or on the remote control or PLAY/ CHANNEL or STOP/CHANNEL on the

TV control panel.

Note: This feature will not work unless you program channels into the TV’s channel memory ( Page 29).

Both analog and digital channels can be tuned normally.

Digital channels will have priority when manually entering a channel number using the Channel Number buttons (0-9) on the remote control, analog channels can still be tuned by

or , if available.

Chapter 6: Using the TV’s features

Tuning to a specific channel (programmed or unprogrammed)

Tuning analog channels:

Press the Channel Number buttons (0–9) on the remote control. For example, to select channel 125, press 1, 2, 5, then .

Tuning digital channels:

Press the Channel Number buttons (0–9) on the remote control, followed by the dash ( ) button

and then the sub-channel number. For example, to select digital channel 125-1, press 1,2, 5, –, 1, then

Note: If a digital channel is not programmed — either through the automatic channel scan ( Page 29) or the channel add/skip function ( Page 29) you will have to tune the RF channel using the Channel Number buttons

and dash ( ) on the remote control.

Switching between two channels using Channel Return

The Channel Return feature allows you to switch between two channels without entering an actual channel number each time.

Select the first channel you want to view.

Select a second channel using the Channel

Number buttons (and the dash ( ) button if selecting a digital channel).

Press on the remote control. The previous

channel will display. Each time you press , the TV will switch back and forth between the

last two channels that were tuned.

Note: If you press from a non-antenna input, the TV will return to the last-viewed

input.

Selecting the picture size

You can view many program formats in a variety of picture sizes—Natural, TheaterWide 1,

TheaterWide 2, TheaterWide 3, Full, 4:3 HD, Native and Dot by Dot (available in PC Mode

Only).

Note: The “picture size” illustrations are examples only. The format of the image (in any of the picture sizes) will vary depending on the format of the signal you are currently watching. Select the picture size that displays the current program the way that looks best to you.

You can save separate picture size preferences for each input on your TV.

To select the picture size using the remote control:

Press on the remote control.

While the Picture Size screen is open, you

can do one of the following to select the desired picture size:

• Repeatedly press .

• Press the corresponding Channel Number

buttons (0–6) while the Picture Size screen is open.

• Press or while the Picture Size

screen is open.

To select the picture size using the menus:

From the Picture menu, press or to

select Theater Settings and then press . Press or to select Picture Size and

then press or to select the desired picture size and then press .

Highlight Done and then press .

Note: Some of the picture sizes may not be available depending on the receiving signal format (those will be “grayed out” in the Picture Size screen).

Using these functions to change the picture size (i.e., changing the height/width ratio) for any purpose other than your private viewing may be prohibited under the Copyright Laws of the United States and other countries, and may subject you to civil and criminal liability.

Note: If you select one of the TheaterWide picture sizes, the top and bottom edges of the picture (including subtitles or captions) may be hidden. To view the hidden edges, either scroll the picture (TheaterWide 2 and 3 only) or try viewing the program in Full or Natural picture size.

Chapter 6: Using the TV’s features

Picture Size

Natural

Some program formats will display with sidebars and/or bars at the top and bottom.

TheaterWide 1 (for 4:3 format programs)

The center of the picture remains close to its original proportion, but the left and right edges are stretched wider to fill the screen.

TheaterWide 2 (for letter box programs)

The top and bottom edges of the picture may be hidden

TheaterWide 3 (for letter box programs with subtitles)

The top and bottom edges are hidden

Full (for 16:9 [480i, 480p] source programs only)

Picture Size

4:3 HD (for 720p, 1080i, and 1080p program sources only)

Picture is not distorted from original size.

Native (for 480i (HDMI), 480p (HDMI), 720p, 1080i, and 1080p signal programs)

• If receiving a 480i (HDMI), 480p (HDMI), 720p,

1080i, or 1080p signal program, Native mode scales the video to display the entire picture within the borders of the screen (i.e. no overscanning).

• This is especially useful for external HD sources

such as DVD, DVHS movies, or PC graphics.

Note:

• This mode is supported only for HDMI

(1080p,1080i, 720p, 480p, and 480i), ColorStream (1080i and 720p), and ANT/ CABLE (digital) inputs (1080p,1080i, and 720p).

• Depending on the input signals, the border

of the picture may be hidden, displayed in black, or noisy.

Dot by Dot (for VGA, SVGA, XGA, and WXGA sources only)

• If receiving a squeezed 4:3 format program, the

picture is stretched wider to fill the width of the screen, but not stretched taller.

• None of the picture is hidden.

The “Dot by Dot” picture is non-scaling display. Depending on the input signal formats, picture is displayed with sidebars and/or bars at the top and bottom. (Example: VGA input source)

* To view the hidden areas (such as subtitles or

captions), see “Scrolling the TheaterWide® picture” ( Page 37).

Chapter 6: Using the TV’s features

Scrolling the TheaterWide® picture (TheaterWide 2 and 3 only)

You can set separate scroll settings for the TheaterWide 2 and TheaterWide 3 modes for each input.

From the Picture menu, press or to

select Theater Settings and then press . In the Picture Size field, select either

TheaterWide 2 or TheaterWide 3 (you

cannot scroll in any other mode). Press to highlight the Picture Scroll field.

Press or to scroll the picture up and

down as needed and then press . To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note: When receiving a signal at 480i resolution, the picture scroll function may have limited adjustment range.

Using the auto aspect ratio feature

When the auto aspect ratio feature is set to On, the TV will automatically select the picture size when one of the following input sources is received:

• A 480i, 480p, 720p, 1080i digital signal from the

ANT/CABLE input

• A 480i signal from the Video input

• A 480i signal from the ColorStream HD input

• A 480i, 480p, 720p, 1080i, 1080p, or VGA

(60Hz) signal from the HDMI 1/2 input

Note: The auto aspect ratio feature is not applicable to the PC input.

To turn on the auto aspect ratio feature:

From the Picture menu, press or to

select Theater Settings and then press . Press or to select Auto Aspect Ratio

and then press or to select On and then press .

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Selecting the cinema mode

When you view a DVD (3:2 pulldown processed) from a DVD player connected to the Video, ColorStream HD (component video), or HDMI inputs on the TV, smoother motion can be obtained by setting the Cinema Mode to Film.

To set the Cinema Mode to Film:

(available for 480i and 1080i signals)

From the Picture menu, press or to

select Theater Settings and then press . Press or to select Cinema Mode and

then press or to select Film and then press .

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

To set the Cinema Mode to Video:

Select Video in step 2 above.

Chapter 6: Using the TV’s features

Adjusting the picture

Selecting the picture mode

You can select your desired picture settings from four different modes, as described below.

Mode Picture Quality

Sports

Standard

Movie

Preference Your personal preferences

Note: PC mode is available for HDMI and PC inputs only (grayed out for other input sources).

Note: The picture mode you select affects the current input only. You can select a different picture mode for each input.

Bright and dynamic picture (factory setting)

Standard picture settings (factory setting)

Lower contrast for darkened room (factory setting)

Designed for viewing of PC tables and documents

From the Picture menu, press or to select Mode and then press .

Press or to select the picture mode you prefer and then press .

Adjusting the picture quality

You can adjust the picture quality (Contrast, Backlight, DynaLight™, Brightness, Color, Tint, and Sharpness) to your personal preferences.

Selection

Contrast lower higher

Backlight

DynaLight

Brightness darker lighter

Color paler deeper

Tint reddish greenish

Sharpness softer sharper

* Backlight

This feature adjusts the brightness of the entire screen. When in video mode and no signal is input, this will automatically be set to 0 (Settings are stored in memory).

** DynaLight

This function automatically strengthens the black coloring of dark areas in the video according to the level of darkness.

From the Picture menu, press or to

select Picture Settings and then press .

Press or to select the picture quality you

want to adjust (Contrast, Backlight, DynaLight, Brightness, Color, Tint, or Sharpness).

Press or to adjust the setting, as

described in the table above and then press . To save the new settings, highlight Done and

then press . You can use any of the picture modes ( “Selecting the picture mode” at left column) as a starting point for adjusting the picture settings. To revert back to the base mode that you began adjusting the picture settings from, highlight Reset and then press .

The picture qualities you adjusted are automatically saved in the Preference mode ( “Selecting the picture mode” at left column) until

Reset is selected.

Pressing Pressing

* darker lighter

** On/Off On/Off

Chapter 6: Using the TV’s features

Using the closed caption mode

Base closed captions

The closed caption mode has two options:

• Captions—An on-screen display of the dialogue,

narration, and sound effects of TV programs and videos that are closed captioned (usually marked “CC” in program guides).

• Text—An on-screen display of information not

related to the current program, such as weather or stock data (when provided by individual stations).

From the Preferences menu, press or

to select Base CC Mode. Press or to select the desired closed

caption mode.

• To view captions:

Highlight CC1, CC2, CC3, or CC4. (CC1 displays translation of the primary language in your area.)

Note: If the program or video you selected is not closed captioned, no captions will display on-screen.

• To view text:

Highlight T1, T2, T3, or T4.

Digital CC Settings

You can customize the closed caption display characteristics by changing the background color, opacity, text size, type, edge, and color.

Note:

• This feature is available for digital channels

only.

• You cannot set the Caption Text and

Background as the same color.

Mode Description

Caption Size Auto, Small, Standard, Large

Auto, Default, Mono w. Serif, Caption Text Typ e

Caption Text Edge

Caption Text Color

Text Foreground Opacity

Background Color

Tex t Background Opacity

Caption Text Edge Color

Prop. w. Serif, Mono w/o Serif,

Prop. w/o Serif, Casual,

Cursive, Small Capitals

Auto, None, Raised,

Depressed, Uniform, Left Drop

Shadow, Right Drop shadow

Auto, Black, White, Red,

Green, Blue, Yellow, Magenta,

Cyan

Auto, Transparent, Translucent,

Flashing, Solid

Auto, Black, White, Red,

Green, Blue, Yellow, Magenta,

Cyan

Auto, Transparent, Translucent,

Flashing, Solid

Auto, Black, White, Red,

Green, Blue, Yellow, Magenta,

Cyan

Note: If text is not available in your area, a black rectangle may appear on screen. If this happens, set the Base CC Mode to Off.

• To turn off the closed caption mode:

Select Off in step 2 above.

Note: A closed caption signal may not display in the following situations:

• When a videotape has been dubbed

• When the signal reception is weak

• When the signal reception is non-standard

To customize the closed captions:

From the Preferences menu, press or

to select Digital CC Settings and then press

Press or to select the characteristic you

want to change, and then press or to select the format for that characteristic (see table above).

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Chapter 6: Using the TV’s features

CC Selector

You can use the CC and Digital Audio Selectors to temporarily override the default

analog caption mode (set in Base CC Mode) for a particular channel. However, once you change to another analog channel, the closed caption setting will automatically change back to the current Base CC Mode setting.

You can also use the CC Selector to select digital closed caption services (if available). When such services are not available, the CC Selector presents a default list of services. If the selected service is not available, the next best service will be used instead.

To select closed cations:

From the Preferences menu, press or

to select CC and Digital Audio Selectors and then press .

Press or to select Closed Caption,

and then press or to select the desired service.

Press .

Adjusting the audio

Muting the sound

Press on the remote control to partially reduce (1/2 MUTE) or turn off (MUTE) the sound. Each

time you press , the mute mode will change in the following order:

If the closed caption mode is set to Off when you select “MUTE” mode, the closed caption feature is automatically activated if the TV program is Closed Captioned. To mute the audio without automatically activating the closed caption feature,

use to set the volume to 0. See “Using the closed caption mode” ( Page 39) for more information on closed caption modes.

Using the digital audio selector

You can use the CC and Digital Audio Selectors to conveniently switch between audio

tracks on a digital channel (for those channels that have multiple audio tracks).

To use the digital audio selector:

From the Preferences menu, press or

to select CC and Digital Audio Selectors and then press .

Press or to select Audio, and then press

or to select the desired service.

Press .

Selecting stereo/SAP broadcasts

The multi-channel TV sound (MTS) feature allows you to output high-fidelity stereo sound. MTS also can transmit a second audio program (SAP) containing a second language, music, or other audio information (when provided by individual stations).

When the TV receives a stereo or SAP broadcast, the word “STEREO” or “SAP” appears on-screen

when is pressed. The MTS feature is only available for analog signals on the ANT/CABLE input.

Chapter 6: Using the TV’s features

To listen to stereo sound:

From the Sound menu, press or to

select Audio Setup and then press . Press or to select MTS, and then press

or to select Stereo.

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note:

• You can typically leave the TV in Stereo

mode because it will automatically output the type of sound being broadcast (stereo or monaural).

• If the stereo sound is noisy, select Mono to

reduce the noise.

To listen to an alternate language on an ATSC digital station (if available):

Highlight the Language field in step 2 above, and then press or to select the language you prefer.

To listen to a second audio program on an analog station (if available):

Select SAP in step 2 above.

Note:

• A second audio program (SAP) can be

heard only on those TV stations that offer it. For example, a station might broadcast another language as a second audio program. If you have SAP on, you will see the current program on the screen but hear the other language instead of the program’s normal audio.

• If you have SAP on and the station you are

watching is not broadcasting a second audio program, the station’s normal audio will be output. However, occasionally there is no sound at all in SAP mode. If this happens, set the MTS feature to Stereo mode.

Adjusting the audio quality

You can adjust the audio quality by adjusting the bass, treble, and balance.

From the Sound menu, press or to

select Audio Settings and then press .

Press or to select the item you want to

adjust (Bass, Trebl e or Balance). Press or to adjust the level.

• makes the bass or treble weaker or

increases the balance in the left channel (depending on the item selected).

• makes the bass or treble stronger or

increases the balance in the right channel (depending on the item selected).

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note: Selecting Speakers in step 2 and setting it to Off will mute the TV’s built-in speakers.

Selecting the optical audio output format

You can use this feature to select the optical audio output format when you connect a Dolby Digital decoder or other digital audio system to the Optical Audio Out terminal on the TV ( “Connecting a digital audio system” on Page 22).

From the Sound menu, press or to

select Audio Setup and then press . Press or to select Optical Output

Format and then press or to select either Dolby Digital or PCM, depending on your

device. To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Chapter 6: Using the TV’s features

Using the Dolby® Digital Dynamic Range Control feature

This dynamic range control feature causes the ATSC dynamic range to be further compressed, allowing you to switch from ATSC to analog broadcasts at the same dynamic range.

From the Sound menu, press or to

select Audio Setup and then press . Press or to select Dolby Digital

Dynamic Range Control and then press or to select Compressed. When Standard is selected, the audio is output with

minimal compression. To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note:

• This item will be grayed out for NTSC

signals, Video, ColorStream, and PC inputs.

• The Dolby Digital Dynamic Range Control

will function in relation to Optical Output Format (PCM mode).

Using the Locks menu

The Locks menu includes the Enable Rating Blocking, Edit Rating Limits, Input Lock, Control Panel Lock, GameTimer and New PIN Code features. You can use these features after entering the correct PIN code.

Entering the PIN code

Press and then press or to highlight

Locks.

Press , which displays the PIN code entry

screen.

• The Lock System screen appears if a PIN

code has not been stored. Press the Channel Number buttons to enter a new four-digit code, enter the code a second time to confirm, and then press .

• The Locks/Active screen appears if the PIN

code is already stored. Use the Channel Number buttons to enter your four-digit code and then press .

If the wrong PIN code is entered, the message “Incorrect PIN code, please try again!” appears. Highlight Retry and then press . Enter the code again and then press .

When the correct PIN code is entered, the Locks menu opens.

If you cannot remember your PIN code

While the PIN code entering screen is displayed, press four times within five seconds. The PIN

code will be cleared and you can enter a new PIN code.

Changing your PIN code

From the Locks menu, press to display the

PIN code entering screen. Enter your four-digit PIN code and then press

Press or to select New PIN Code and

then press . Press the Channel Number buttons to enter a

new four-digit code. Reenter the PIN code to confirm it.

Press . The new PIN code is now active.

Chapter 6: Using the TV’s features

Blocking TV programs and movies by rating (V-Chip)

Some TV programs and movies include signals that classify the content of the program (violence, sex, dialogue, language). The V-Chip feature in this TV detects the signals and blocks the programs according to the ratings you select. (For rating descriptions, see the tables on the next page.)

Note: Rating blocking is a function of the V-Chip feature in this TV, which supports the U.S. V-Chip system only.

To block and unblock TV programs and movies:

From the Locks menu, press to display the

PIN code entering screen. Enter your four-digit PIN code and then press

Press or to select Enable Rating

Blocking. Press or to select On and then press .

Press or to select Edit Rating Limits

and then press . The Edit Rating Limits screen appears.

Press or and then press to

select the level of blocking you prefer. A box with an “X” is a rating that will be blocked. As you highlight a rating, a definition for the rating appears at the bottom of the screen.

When done selecting the ratings you want to

block, highlight Done and then press .

Downloading an additional rating system for blocking TV programs and movies

An additional rating system may be available for use in selectively blocking programs.

Note: The currently tuned station must be receiving a digital signal before an additional rating system can be downloaded.

To download the additional rating system (if available):

Press or to select Enable Rating

Blocking. Press or to select On and then press .

Press or to select Edit Rating Limits

and then press . The Edit Rating Limits screen appears.

Press or to select Alt RS and then press

. The Edit Alternate Ratings screen

appears.

Note:

• The Alt RS button will only be available

if an additional rating system is currently available.

• It may take several minutes for the TV to

download the additional rating system.

• The information displayed in the

Alternate Ratings screen will depend

on the configuration of the additional rating system available at the time of download.

Press or and then press to

select the level of blocking you prefer. A box with an “X” is a rating that will be blocked.

When done selecting the ratings you want to

block, highlight Done and then press . In the Edit Rating Limits screen, highlight

Done and then press .

Note:

• The additional rating system can only be

downloaded one time. You will not be able to download any updates to the rating system should such updates become available.

• The additional rating system is not

designed, transmitted, or controlled by the TV or Toshiba, nor is the availability of an additional rating system determined or controlled by Toshiba. Similarly, the rating of programs in an additional rating system is not determined, transmitted, or controlled by the TV or Toshiba.

• The additional rating system is an evolving

technology; therefore, availability, content, and format may vary.

From the Locks menu, press to display the

PIN code entering screen. Enter your four-digit PIN code and then press

Chapter 6: Using the TV’s features

Independent rating system for broadcasters

Ratings Description and Content themes

Mature Audience Only (This program is specifically designed to be viewed by adults and therefore

TV-MA

TV-14

TV-PG

TV-G

TV-Y7, TV-Y7FV

TV-Y

may be unsuitable for children under 17.) L) Crude or indecent language S) Explicit sexual activity V) Graphic violence

Parents Strongly Cautioned (This program contains some material that many parents would find unsuitable for children under 14 years of age.) D) Intensely suggestive dialog L) Strong, coarse language S) Intense sexual situations V) Intense violence

Parental Guidance Suggested (This program contains material parents may find unsuitable for younger children.) D) Some suggestive dialog L) Infrequent coarse language S) Some sexual situations V) Moderate violence

General Audience (Most parents would find this program suitable for all ages.)

Directed to Older Children (This program is designed for children age 7 and above. Note: Programs in which fantasy violence may be more intense or more combative than other programs in this category are designated TV-Y7FV.)

All Children (This program is designed to be appropriate for all children.)

Independent rating system for movies

Ratings Description and Content themes

X X-rated (For adults only)

NC-17

PG-13

Not intended for anyone 17 and under

Restricted (Under 17 requires accompanying parent or adult)

Parents Strongly Cautioned (Some material may be inappropriate for children under 13)

Parental Guidance Suggested (Some material may not be suitable for children)

General Audience (Appropriate for all ages)

Note:

• If you place an “X” in the box next to “ ‘None’

Rated,” programs rated “None” will be

blocked; however, programs that do not provide any rating information will not be blocked.

• To display the rating of the program you are

watching, press on the remote control. If it is rated “None,” the word “TV-NONE” appears in the display screen (as shown below right). If rating information is not provided, no rating will appear in the display screen.

TV-NONE

Unlocking programs temporarily

If you try to tune the TV to a program that exceeds the rating limits you set, the TV will enter program lock mode and a warning message will appear onscreen.

You can either temporarily unlock the program or select an unlocked program to watch.

Press .

Enter your four-digit PIN code and then press

. If the correct code is entered, the program lock mode is released and the normal picture appears. All locking is disabled until the TV is turned off, and will be enabled when the TV is turned on again.

Chapter 6: Using the TV’s features

Using the input lock feature

You can use the Input Lock feature to lock the video inputs (Video, ColorStream HD, HDMI 1, HDMI 2, and PC) and channels 3 and 4. You will not be able to view the input sources or channels until you unlock the inputs.

From the Locks menu, press to display the

PIN code entering screen. Enter your four-digit PIN code and then press

Press or to select Input Lock.

Press or to select the level of video input

locking you prefer, as described below. Press to exit.

Mode Description

Vid eo

Video+

Off

Using the GameTimer

You can use the GameTimer to set a time limit for playing a video game (30–120 minutes). When the GameTimer expires, the TV enters Input Lock mode and locks out the input source for the video game device.

To set the GameTimer®:

From the Locks menu, press to display the

PIN code entering screen. Enter your four-digit PIN code and then press

Press or to select GameTimer.

Press or to select the length of time until

the Input Lock is activated (30, 60, 90, or 120 minutes).

Press to exit.

Locks Video, ColorStream HD, HDMI 1, HDMI 2, and PC.

Locks Video, ColorStream HD, HDMI 1, HDMI 2, PC and channels 3 and 4.

• Select Video+ if you play

video tapes via an ANT/ CABLE input.

Unlocks all video inputs and channels 3 and 4.

To cancel the GameTimer

Select Off in step 4 above.

To deactivate the Input Lock once the GameTimer

Set the Input Lock to Off ( left column).

Note:

• A message will appear when 10 minutes, 3

minutes, and 1 minute remain on the GameTimer.

• If the TV loses power with time remaining on

the GameTimer, when power is restored, the TV will enter Input Lock mode (as if the GameTimer had been activated) and you will have to deactivate the Input Lock ( left column).

has activated it:

Using the control panel lock feature

You can lock the control panel to prevent your settings from being changed accidentally (by children, for example). When the control panel lock is On, none of the controls on the TV control panel will operate except POWER.

From the Locks menu, press to display the

PIN code entering screen. Enter your four-digit PIN code and then press

. Press or to select Control Panel

Lock. Press or to select On and then press

to exit. When the control panel is locked and any button on the control panel (except POWER) is pressed, the message “NOT AVAILABLE” appears.

To unlock the control panel:

Select Off in step 4 above, or press and hold VOLUME– on the TV control panel for about 10

seconds until the volume icon appears.

Chapter 6: Using the TV’s features

Using the PC settings feature

You can view an image from a PC on the TV screen. When a PC is connected to the TV’s PC IN terminal, you can use the PC Settings feature to make adjustments to the image. If the edges of the picture are cut off, readjust the Horizontal Position and Vertical Position. If the picture is affected by interference, readjust the Clock Phase and Sampling Clock.

Repeatedly press to select PC input mode

( “Selecting the video input source to view” on Page 33).

From the Setup menu, press or to

select PC Settings and then press .

Note: If a PC is not connected or there is no PC input signal, this feature will be grayed out in the Setup menu.

Press or to select the item you want to

adjust. Press or to make the appropriate

adjustments.

Note: The screen is disrupted momentarily when adjusting the PC settings. This is not a sign of malfunction.

Mode Description

Horizontal Position

Vertical Position

Clock Phase

Sampling Clock

Auto Adjust

Moves the picture left/right. The adjustment range is within ±50 from center.

Moves the picture up/down. The adjustment range is within ±10 from center.

Helps to reduce noise and sharpen the picture. The adjustment range is within ±16 from center.

Helps to reduce noise and minimize periodic vertical stripes on the screen.The adjustment range is within ±10 from center.

Highlight this item and then press

to get an optimum adjustment

automatically.

Setting the PC Audio

This function allows you to output or mute the sound from your PC when connecting using the PC IN terminal and an analog RGB cable ( Page

23).

From the Sound menu, press or to

select Audio Setup and then press . Press or to select PC Audio and then

press or to select No or Yes. Yes: When viewing the PC input, the audio

from the PC Audio input can be heard.

No: When viewing the PC input, there will be

no audio.

Note: Because the PC and HDMI 1 inputs share the same set of analog audio inputs, the PC Audio menu setting influences the HDMI 1 Audio menu setting. If PC Audio is set to “No”, the HDMI 1 Audio setting changes to “Auto”. If PC Audio is set to “Yes”, the HDMI 1 Audio setting is set to “Digital” and is grayed out in the menu. ( “Setting the HDMI Page 31.)

audio mode” on

* The default settings may vary depending on the

input signal format.

Chapter 6: Using the TV’s features

Setting the sleep timer

You can set the sleep timer to turn off the TV after a set length of time (maximum of 180 minutes).

To set the sleep timer using the remote control:

Press on the remote control to set the length of time until the TV turns off. Repeatedly press

to increase the time in 10-minute increments, or press or to increase or decrease the time in 10-minute increments, to a maximum of 180 minutes.

To set the sleep timer using the on-screen menus:

From the Setup menu, press or to

select Sleep Timer and then press . Press the Channel Number buttons to enter the

length of time in 10-minute increments. Highlight Done and then press .

Note: When a power failure occurs, the sleep timer setting may be cleared.

To display the remaining sleep time:

Press .

Note: A message will display on-screen when there is one minute remaining on the sleep timer.

To cancel the sleep timer:

Repeatedly press until it is set to 0 minute.

Using REGZA-LINK

This is a new feature that uses CEC technology and allows you to control Toshiba REGZA-LINK

compatible devices from the TV remote via HDMI connection ( Page 21).

When the Enable REGZA-LINK in the REGZA- LINK Setup menu ( Page 49) is set to On, the following REGZA-LINK

functions will be

enabled.

REGZA-LINK

playback device (DVD

player, etc.) control

With your TV’s remote control, or using the REGZA-LINK Player Control menu, you can

control the connected REGZA-LINK device you are watching.

Available remote control key functions:

Button Description

PLAY

STOP

PAUSE

Begins playback.

Stops playback.

Pauses the picture during play or record mode.

LOSED CAPTION

SKIP

CH RTN SKIP

REV FF

ENTER

Skips forward.

Skips backward.

Fast-forwards/Fast-reverses.

Enters contents menu, etc.

playback

EXIT/

CANCEL

Navigates contents menu, etc.

Closes the menu.

Note: These functions depend on the devices connected.

Chapter 6: Using the TV’s features

REGZA-LINK® Player Control menu functions

From the Preferences menu, press or

to select REGZA-LINK Player Control and then press .

Press or to select the item you want to

control and then press .

Item Description

Power Turns the selected device on and

Root Menu Accesses the top menu of the

Contents Menu

Setup Menu

Top Menu

Note:

• These functions depend on the devices that

are connected.

• The REGZA-LINK Player Control item will

be grayed out in the following conditions:

- A non-HDMI input is currently selected.

- The Enable REGZA-LINK item is set to Off.

off.

selected device.

Accesses the contents list when you press . At this time, the

REGZA-LINK Player Control

menu will disappear.

Accesses the setup menu of a DVD player.

Accesses the top menu of a DVD during playback.

Accesses the menu of a DVD during playback.

- The connected CEC device is not a

playback or recording device.

REGZA-LINK® input source selection

If a REGZA-LINK® device with HDMI switching capability (e.g. Audio Receiver) is connected to the HDMI input, you can select another REGZA-

LINK

device that is connected to the master HDMI device using on the remote control or the TV control panel ( Page 33).

VOLUME and MUTE controls of Audio Receiver

With your TV’s remote control, you can adjust or mute the sound volume of the Audio Receiver.

• adjust the volume level.

• turns off the sound.

Note:

• To use this function:

- Set Speaker Preference to Audio Receiver in the REGZA-LINK Setup

menu.

- Confirm that a connected REGZA-LINK device (such as DVD player, etc.) is selected for the Audio Receiver input source.

• You can also use this function when the

audio receiver is connected to the TV’s DIGITAL AUDIO OUT terminal (not HDMI connection). In this case, select a digital audio input mode on the Audio Receiver.

• These functions depend on the device

connected.

Other REGZA-LINK

When the Enable REGZA-LINK and each item in the REGZA-LINK Setup menu are set to On, the following functions will be enabled.

functions

Item Description

If a connected HDMI device TV Auto Input Switch

TV Auto Power On

Device Auto Standby

Speaker Preference

starts playing video or audio, the

TV will automatically switch to

the appropriate HDMI input.

If a device is turned on, the TV

turns on automatically.

If the TV is turned off, the TV

will send a message to turn off all

of the devices connected to the

TV.

From this item, you can set your

audio output preference to the

TV speakers or the audio

receiver speakers. When this

item is set to Audio Receiver,

the TV remote can be used to

adjust or mute the volume of the

audio receiver. This item will be

grayed out unless a REGZA-

LINK

compatible audio

receiver is connected.

Chapter 6: Using the TV’s features

Note: When you turn on the audio receiver,

change its input source, or adjust the sound volume, the sound will be output from the audio receiver’s speakers even if TV Speakers has been selected. Turn the TV off and on again to output the sound from the TV speakers.

To set the REGZA-LINK® Setup:

From the Setup menu, press or to

select REGZA-LINK Setup and then press

Press or to select Enable REGZA-

LINK and then press or to select On.

Note: If you select Enable REGZA-LINK Off, the other items will be grayed out.

Press or to select the REGZA-LINK

Setup item you want to use and then press or to select On or desired mode.

• TV Auto Input Switch: On/Off

• TV Auto Power: On/Off

• Device Auto Standby: On/Off

• Speaker Preference: TV Speakers/Audio

Receiver

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Displaying TV status information

To display TV status information using DISPLAY:

Press on the remote control.

The following information will display (if applicable):

• Current input (ANT/CABLE, Video, etc.)

• If ANT/CABLE is the current input, either

“CABLE” (for cable TV) or “ANT” (for overthe-air broadcasts).

• Channel number (if in ANT/CABLE mode)

• Channel label (if set)

• Digital signal strength indicator (bar graph in

lower right corner of box; for ATSC signal only)

• Stereo, Mono or SAP audio status (when HDMI

input mode, Dolby Digital or PCM)

• Video resolution

• Aspect ratio of incoming video signal (4:3 or

16:9)

• V-Chip rating status

• GameTimer (if set)

To display more TV information:

Press on the remote control again.

The following additional information will display for off air digital channels (if applicable):

• Title

• Duration

• Detailed description

Note: The location of the banner can be moved to the top or bottom of the screen by pressing or while the DISPLAY is onscreen.

Understanding the auto power off feature

The TV will automatically turn itself off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day. This feature functions in ANT/

CABLE mode only.

Understanding the last mode memory feature

If the power is cut off while you are viewing the TV, the Last Mode Memory feature automatically turns on the TV when the power is resupplied.

Note: If it’s possible, and you will be away from the TV for an extended period of time, you should unplug the power cord.

Chapter 7: Using the TV’s advanced features

Using the advanced picture settings features

Using dynamic contrast

When dynamic contrast is set to On, the TV will detect changes in the picture quality that affect the appearance of your contrast settings and then automatically adjust the video.

To select dynamic contrast preferences:

From the Picture menu, press or to

select Picture Settings and then press . Press or to select Advanced Picture

Settings and then press . Press or to select Dynamic Contrast

and then press or to select either Off or On and then press .

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie or PC) and then change the dynamic contrast setting, the picture mode automatically changes to Preference.

Using the static gamma feature

The static gamma feature allows you to adjust the levels of black in the picture.

To adjust the static gamma settings:

From the Picture menu, press or to

select Picture Settings and then press . Press or to select Advanced Picture

Settings and then press . Press or to select Static Gamma and

then press or to adjust the static gamma and then press .

The adjustment range is within ±5 from center.

• If the setting is moved in the minus direction,

the detail of black colors will be decreased.

• If the setting is moved in the plus direction,

the detail of black colors will be increased.

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie or PC) and then change the static gamma setting, the picture mode automatically changes to Preference.

Selecting the color temperature

You can change the quality of the picture by selecting from three preset color temperatures (Cool, Medium, and Warm), as described below.

Mode Picture Quality

Cool blueish

Medium neutral

Warm reddish

To select the color temperature:

From the Picture menu, press or to

select Picture Settings and then press . Press or to select Advanced Picture

Settings and then press . Press or to select Color Temperature

and then press or to select the mode you prefer and then press .

Press or to select either B Drive or G

Drive and then press or to adjust the

settings and then press .

• B Drive: makes the picture blueish.

• G Drive: makes the picture greenish.

Note: The B Drive and G Drive settings are connected to the Color Temperature settings and will change based on which setting is selected in step 3 above.

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note: If you select one of the factory-set picture modes (Sports, Standard, Movie or PC) and then change the color temperature mode, the picture mode automatically changes to Preference.

Chapter 7: Using the TV's advanced features

Using CableClear® digital noise reduction

The CableClear allows you to reduce visible interference in your TV picture. This may be useful when receiving a broadcast with a weak signal (especially a Cable channel) or playing a noisy video cassette or disc.

digital noise reduction feature

To change the CableClear settings:

From the Picture menu, press or to

select Noise Reduction and then press . Press or to select CableClear and then

press or to select your desired setting and then press .

Note:

• If the current input is ANT/CABLE, or

Video, the menu will display the text

“CableClear”. The available selections are Off, Low, Middle, and High.

• If the current input is ColorStream HD,

HDMI 1,or HDMI 2, the menu will display

the text “DNR”. The available selections are Off, Low, Middle, and High. Low, Middle, and High will reduce the noise in varying degrees, from lowest to highest, respectively.

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Using MPEG noise reduction

The MPEG noise reduction feature allows you to reduce visible interference caused by MPEG compression. Choices for MPEG noise reduction are Off, Low, Middle, and High. Off is automatically selected when this feature is disabled (“grayed out”).

To select the MPEG noise reduction level:

From the Picture menu, press or to

select Noise Reduction and then press . Press or to select MPEG Noise

Reduction and then press or to select

either Off, Low, Middle or High and then press .

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Using the Game Mode feature

You can use the Game Mode feature for shorter frame delays when playing a video game requiring split-second timing between the on-screen display and input from the controller (such as music creation and high-action games).

This feature is more effective for 480i and 1080i input signals.

Note: To use the Game Mode feature, the current video input must be Video, ColorStream HD, HDMI 1, or HDMI 2. The Game Mode cannot be turned on when any other video input is selected.

To turn on Game Mode:

From the Picture menu, press or to

select Game Mode. Press or to select On.

To turn off Game Mode:

Select Off in step 2 above, change the video input, or turn the TV off and then on again.

Note: You can change the video input by pressing on the remote control ( Page

33).

Using the Auto Brightness Sensor

When the Auto Brightness Sensor feature is set to On, the TV will automatically optimize the backlighting levels to suit ambient light conditions.

From the Picture menu, press or to

select Picture Settings and then press . Press or to select Advanced Picture

Settings and then press .

Press or to select Auto Brightness

Sensor and then press or to select On

or Off and then press . To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight

Reset and then press .

Chapter 7: Using the TV's advanced features

Using the advanced audio settings features

Using the QSound® sound feature

QSound® is the original name for a positional

three-dimensional (3D) sound processing algorithm from QSound Labs, Inc. that creates 3D audio effects from multiple monophonic sources and sums the outputs to two channels for presentation over regular stereo speakers.

To adjust the QSound® settings:

Set the TV in Stereo mode ( “Selecting

stereo/SAP broadcasts” on Page 40). From the Sound menu, press or to

select Advanced Audio Settings and then press .

Pres or to select the QSound feature

and then press or to turn the QSound effect On or Off.

To save the new settings, highlight Done and

then press . To revert to the factory defaults, highlight Reset and then press .

Note: If the broadcast is monaural, the QSound effect will not work.

Using the Media Player

The TV allows you to enjoy photos and music stored on a USB device.

Note: Do not insert/remove the USB device while in use.

Media Player Specifications

Device

USB device:

USB Mass Storage Class devices (MSC)

Note:

•Connectivity is not guaranteed for all

devices.

•Connect the USB device to the TV

directly.

•Do not use a USB hub.

Supported file system

FAT12, FAT16 and FAT32

Supported photo format:

JPEG Exif ver 2.2 (DCF ver 1.1)

• Maximum viewable resolution: 8192 x 8192

pixels

• Maximum photo size: 9 MB

Note: It may take some time to open a file of large size.

Supported music format:

MPEG-1 (MP3)

• Sampling rate: 32, 44.1, 48 kHz

• ID3: ver.1, ver.2

Folder specifications

• Total number of files: Less than 2000 per folder

You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba cannot and does not grant such permission.

Chapter 7: Using the TV’s advanced features

Basic Operation

To set Auto Start:

From the Setup menu, press or to

select Media Player and then press . Press or to select Auto Start and then

press or to select On.

Auto Start:

Insert USB device into the USB terminal on

the left side of the TV. A prompt will appear. Press or to select

Yes and then press .

Press or to select Photo or Music and

then pres music list will appear.

Note: If Auto Start is set to Off, you can start the Media Player manually.

To set manual Start:

Insert USB device into the USB terminal on

the left side of the TV. From the Setup menu, press or to

select Media Player and then press .

Press or to select Photo or Music and

then pres music list will appear.

To close the Media Player:

Press . The TV will return to the last-viewed channel or video input.

s . The photo thumbnail view or

Viewing JPEG files

To view in Single View mode:

From Media Player menu, press or to

select Photo and then press . When the thumbnail view appears, press

or to select a file or folder.

Note: An incompatible JPEG file will be displayed with an icon.

Press to begin viewing the selected file in

full screen or to open the selected folder. Press to view the next file, or press to

view the previous file.

To view in Slide Show mode:

To switch to the Slide Show mode, press

while in Single View mode. To return to Single View mode, press again.

Press to view the next file, or press to

view the previous file.

To rotate the image:

While viewing the image in Single View mode, press to rotate the image 90 degrees clockwise, or press to rotate the image 90 degrees

counterclockwise.

To return to the thumbnail:

Press while in Single View mode or Slide Show mode.

Chapter 7: Using the TV’s advanced features

To use the photo Quick Menu:

You can select your preferred photo viewing settings from the photo Quick Menu.

From the photo Single View, Slide Show or

thumbnail mode, press to enter the Quick Menu.

Note: The Quick Menu items of thumbnail and Single View/Slide Show modes are different.

Press or to select the item you want to

adjust. Press or to select your preferred setting.

Press to return to the previous photo view

mode.

Item Description

Sort* To set the file sorting preference

in thumbnail view.

• Title: to sort the files by file

name.

• New: to sort the files from new

to old by file date.

• Old: to sort the files from old to

new by file date.

To set a time interval to view

Interval Time

photos at your preferred intervals (3sec, 5sec,10sec, 15sec, 30sec, 60sec, or 90sec).

Repeat

To display photos in the same folder repeatedly (On/Off).

To select background music for Background Music Select

the photo display from the music

stored in the USB device (

right column).

To set the sleep timer to turn off

Sleep Timer

the Media Player, as well as the

TV (up to 180 minutes in 10-

minute increments).

Note: The sleep timer setting in the Media Player Quick Menu or TV Setup Menu will override the previous setting of each other.

* This Quick Menu item is only available for access

from the thumbnail view mode.

** This Quick Menu item is only available for access

from Single View/Slide Show modes.

To set background music for photo mode:

You can select music from the music list stored in the USB device to be played back in photo mode.

From the photo Single View or Slide Show

mode, press to enter the Quick Menu.

Press or to select Background Music

Select and then press .

The available music list will appear. Press or to select your desired music

and then press to play the music. Press repeatedly to return to the previous

photo mode with the selected music on.

Note:The music will be played back in accordance with the repeat setting set in the music Quick Menu ( Page 55).

Listening to MP3 files

Besides viewing JPEG files, you can also listen to the music files stored in the USB device.

From Media Player menu, press or to

select Music and then press .

When the list appears, press or to select

a file or folder. Press to begin playing the selected music

file or to open the selected folder.

To use the remote control button in music playback:

You can use the remote control buttons listed below to control the music playback.

Button Description

PLAY

STOP

PAUSE

LOSED CAPTION

SKIP

CH RTN SKIP

Note: If no button on the remote control or TV control panel is pressed for 60 seconds after starting music playback, the TV will enter screen saver mode. Press any button but POWER to return to music list mode.

Begins music playback.

Stops music playback.

Pauses music playback.

Skips to play next music file.

Skips to play previous music file.

Chapter 7: Using the TV’s advanced features

To use the music Quick Menu:

You can select your preferred music playback settings from the music Quick Menu.

From the music list or music playback mode,

press to enter the Quick Menu.

Note: The Quick Menu items of music list and music playback modes are different.

Press or to select the item you want to

adjust. Press or to select your preferred setting.

Press to return to the previous menu or

music mode.

Item Description

Sort* To set the file sorting preference

Repeat To set preferred music repeat

Audio Settings**

Sleep Timer** To set the sleep timer to turn off

Speaker** To select the audio output

Note:

• The sleep timer setting in the Media Player

Quick Menu or TV Setup Menu will override

the previous setting of each other.

in music list.

• Title: to sort the files by file

name.

• New: to sort the files from new

to old by file date.

• Old: to sort the files from old to

new by file date.

mode.

• 1: to repeat the current playing

music file.

• All: to repeat all the music files

in the folder where the current playing file is.

• Off: to disable music repeat.

To adjust the audio quality

(Bass/Treble/Balance).

the Media Player, as well as the

TV (up to 180 minutes in 10-

minute increments).

preference.

• TV Speakers: to output the

music from the TV’s built-in speakers.

• Audio Receiver: to output the

music from a connected amplifier (if available).

• If Enable REGZA-LINK in the REGZA-

LINK Setup menu is set to Off or no

amplifier is detected, the Speaker item will be grayed out.

* This Quick Menu item is only available for access

from the music list.

** This Quick Menu item is only available for access

from music playback mode.

Chapter 8: Basic disc playback

Disc playback

This section shows you the basics on how to play a disc.

Basic playback (DVD/VCD/CD)*

Press POWER on the TV control panel or on

the remote control. The Power LED on the front of the TV changes to green. It may take approximately 10 seconds for a picture to appear on-screen. When using an amplifier, switch on the amplifier.

Press on the remote control to switch to

DVD mode. The DVD start-up screen will appear on-screen.

Hold the disc by its edges and load it in the

disc slot with the label side facing forward. The prompt “Insert Disc” changes to “Reading” and then playback starts.

Note: DO NOT touch the surface of the disc. This may leave a smudge that can cause playback errors.

If the disc has its own menu, it will be displayed on-screen. Press or on the remote control to navigate the disc menu, then press to implement the selected menu option.

Playback resume function:

Your TV/DVD supports playback resume function. If you stopped the disc playback before it is completed, the TV/DVD records the stop point. “ ” appears on-screen. Press to resume playback on the stop point. If you press twice in quick succession or unload the disc, the TV/DVD will clear the stop point.

Higher quality picture:

High resolution pictures on some discs may occasionally cause noise on the picture display. If this is the case, reduce the Sharpness setting under the Picture Settings menu ( Page 38).

Note:

• Keep your fingers well clear of the disc slot

when a disc is loading or unloading. Failure to do so may cause serious personal injury.

• Do not move the TV during playback. Doing

so may damage the disc.

• When a disc is inserted when the TV is not

in DVD mode, the TV will automatically switch to DVD mode.

* This indicates the kind of disc that can employ the

function described under that heading.

DVD : You can use this function with DVDs. VCD : You can use this function with Video CDs. CD : You can use this function with Audio CDs

and CD-R/RW discs.

To adjust playback volume:

Press .

To temporarily suspend disc playback (still mode):

Press .

To continue playback from still mode:

Press .

To stop playback:

Press .

Chapter 8: Basic disc playback

Removing a disc

Press EJECT on the TV control panel or

on the remote control. Wait for the disc to be ejected and then remove

the disc from the slot.

Disc playback reminders

• If the TV/DVD does not operate properly, static

electricity build-up may be the cause. Turn off the TV/DVD, then disconnect the power cord from the AC outlet. Reconnect the power cord, then press POWER to turn on the TV/DVD again.

• If an incompatible disc is loaded, one of the

following error messages appears on-screen: “Incorrect Disc”, “Disc region incorrect” or “Enter Password”. If this is the case, check your disc again. Go to Page 8 for a list of supported disc formats, and to Page 76 for playback-related troubleshooting instructions.

• In some instances the TV/DVD may take a

minute or so to start disc playback.

• When you load a disc with the playback side

facing backward, “Reading” appears on-screen but it will be replaced by “Incorrect Disc”. Eject the disc and load it again making sure the playback side is now facing forward.

• The playback resume function may not work on

some discs.

• Some DVDs may have fixed playback operations

designed by the DVD manufacturer. Your TV/ DVD follows this fixed playback design. In such cases, some playback features may not be available. You may refer to the instructions accompanying the DVD.

• Do not put any objects other than compatible

discs on the disc slot. Doing so may cause damage to the TV/DVD.

• There may be a few seconds between the action of

pressing a button and the function it activates.

Playback navigation

Playing in fast reverse or fast forward direction (DVD/VCD/CD)

Press REV or FF during playback.

REV : Fast reverse playback FF : Fast forward playback

Each time you press REV or FF , the playback speed changes.

To resume normal playback:

Press .

Note:

• The sound is muted during reverse and

forward scan.

• The playback speed may differ depending

on the disc.

• You can use fast reverse/fast forward

playback for MP3, and WMA CDs.

Playing frame by frame (DVD/VCD)

Press during playback.

Each time you press , the picture advances one frame.

To resume normal playback:

Press .

Note:

• The sound is muted during frame by frame

playback.

Playing in slow motion (DVD/VCD)

Press SLOW or SLOW during playback.

SLOW : Slow reverse playback SLOW : Slow forward playback

Each time you press SLOW or SLOW , the slow motion speed changes.

To resume normal playback:

Press .

Note:

• The sound is muted during slow motion

playback.

Chapter 8: Basic disc playback

Locating a chapter or track (DVD/ VCD/CD)

Press SKIP or SKIP repeatedly to

display the chapter or track number you want to play. SKIP : To locate succeeding chapters or tracks. Playback starts from the beginning of the selected chapter or track.

SKIP : Playback starts from the beginning of the current chapter or track.

When you press SKIP twice in quick succession, playback starts from the beginning of the preceding chapter or track.

Chapter 9: Advanced disc playback

Zoom function/Scene navigation

You can change the viewing scale of a picture by using the Zoom function. Once the image has been

rescaled, use the arrow buttons to pan the image.

Scene navigation options differ depending on the kind of disc. DVDs use the title, chapter or record time to locate the start point for playback. Audio CDs and Video CDs use the record time or track number. To view the discs title/track or chapter/

track list, press .

Using Zoom (DVD/VCD)

Press during playback.

The view will zoom into the center of the image. Each press of will increase the scale

value: 1 (× 1.3), 2 (× 1.5) and 3 (×

2.0).

Press to pan the scene and view

different sections of the picture. To return to normal view, in Zoom mode, press

repeatedly until Off appears.

Note:

• You can use the Pause, Slow and Search

playback functions in Zoom mode.

• Zoom function may not apply to some discs.

Locating a specific scene (DVD/VCD/ CD)

Press during playback, still or stop mode.

Title Chapter Time

Press or to select a navigation option.

Title Chapter Time

Use the Channel Number buttons (0-9) to key

in a value for the navigation option you selected.

Title Chapter Time

If you input a wrong number, press . Refer to the disc package to check the correct

number. Press to start playback.

Note:

• When you use title navigation, playback

starts from the first chapter of the selected title.

• For audio CDs and Video CDs, you can

locate a scene by track number or record time.

• For PBC-enabled VCDs, turn off the PBC

function first before using the Jump function ( Page 64).

• Scene navigation may not apply to some

discs.

Jump

Chapter 9: Advanced disc playback

Scene bookmark

Scene bookmarks refer to specific points in the playback range that have been marked for later access. You can create up to three markers per disc.

Note: The saved scene bookmarks are only accessible during the current session. Once you eject the disc or turn off the TV/DVD, all bookmarks will be cleared.

Bookmarking a scene (DVD/VCD/ CD)

During playback, press at the scene

where you would like to place the bookmark.

Marker1 Marker2 Marker3

Press or to select a blank marker, then

press to bookmark the selected scene.

Marker1 Marker2 Marker3

Press to close the Bookmark window.

To save two more bookmarks, repeat steps 1-3.

Note:

• In some cases, subtitles for the marked

scene may not display.

• Bookmarking a scene may not apply to

some discs.

Viewing a scene bookmark (DVD/VCD/ CD)

Press during playback mode.

Press or to select the saved marker.

Marker1 Marker2 Marker3

Press to start playback on the scene saved

in the selected bookmark.

To delete a scene bookmark:

Perform steps 1 and 2 above, then press .

Repeat playback/A-B repeat

You can choose to repeat DVD playback by title or chapter. For audio CDs and Video CDs, you can repeat a single track or the entire disc.

The A-B repeat function lets you repeat a specific section between two set points. This section will be played repeatedly until you turn off the A-B repeat mode.

Enabling repeat playback (DVD/ VCD)

Press during playback or stop mode.

[DVD]

Press repeatedly to select a repeat mode. It can either be by Chapter or by Title.

The TV/DVD automatically starts repeat playback after finishing the current title or chapter.

Play Mode

Repeat

[VCD] Press to select Repeat, then press

repeatedly to select a repeat mode. It can either be Single or All.

The TV/DVD automatically starts repeat playback after finishing the current track.

Mode

Repeat

Note: If you set the repeat mode during stop mode, press to start Repeat playback.

Press again to close the Play Mode

window.

To resume normal playback:

Select Off in step 2 above.

Note:

• The Repeat mode is canceled when SKIP

or SKIP is pressed.

• The Repeat playback function may not

apply to some discs.

: Off

Play Mode

: Normal

: Off

Chapter 9: Advanced disc playback

Enabling A-B repeat mode (DVD/ VCD/CD)

During playback, press at the point

where you would like the playback loop to begin. This sets your “A” point.

When the playback reaches the point where

you would like the playback loop to stop, press

again. This sets your “B” point.

The section between points A and B will be played repeatedly in a loop until you turn off the Repeat A-B mode.

To resume normal playback:

Press until Off appears on-screen.

Note:

• In some cases, subtitles for the repeated

scene may not display.

• The A-B repeat mode may not apply to

some DVD scenes.

• The A-B repeat mode is not applicable to

interactive DVDs and JPEG CDs.

Programmed playback/Random playback

You can program the playback sequence of tracks on a Video CD. Or you can set the TV/DVD to play tracks at random.

For procedures applicable to audio/MP3/WMA/ JPEG, go to Page 65.

Note:

• The programmed and random playback

modes are not applicable to PBC-enabled Video CDs.

• The programmed and random playback

modes are only applicable during the current session. Once you eject the disc or turn off the TV/DVD, these modes will be disabled.

Programming the playback sequence (VCD)

Press in stop mode.

Press or to select Mode, then press

repeatedly to select Program.

Mode : Program

Repeat : Off

Press or to go to the right column. Press

or to select the playback position, then use the Channel Number buttons (0-9) to input the track for that position. To program other tracks, repeat this step.

If you input a wrong number, press .

Mode : Program

Repeat : Off

Play Mode

Program Playback

Play Mode

1 9

Program Playback

Chapter 9: Advanced disc playback

Press or to return to the left column, then

press or to select Program Playback and press .

Mode : Program

Repeat : Off

Play Mode

Program Playback

1 9

2 3

3 11

Track playback will follow the sequence you set in step 3.

To resume normal playback:

In step 2, set Mode to Normal.

To change the program:

1. Set Mode to Program.

2. Press or to select the playback position you want to change the track input for, then press .

3. Use the Channel Number buttons (0-9) to input the new track for the selected position.

To remove a track from the programmed list:

1. Set Mode to Program.

2. Press or to select the playback position, then press .

To clear all the programs:

On the left column, press or to select Clear Program, then press .

Enabling random playback (VCD)

Press in stop mode.

Press or to select Mode, then press

repeatedly to select Shuffle.

Mode : Shuffle

Repeat : Off

Press to start random playback.

Note: If you set random playback during playback mode, random playback will begin after the current track finished playing.

To resume normal playback:

In step 2, set Mode to Normal.

Play Mode

Program Playback

Scene angle/Title selection/DVD menu

Changing the scene angle (DVD)

When playing back a DVD recorded with multiangle scenes, you can select the scene angle that you prefer.

Press during playback.

Press repeatedly until the preferred scene

angle is displayed.

Note: Depending on the DVD, you may not be able to change the scene angle even if multiangle data are recorded on the disc.

Selecting a DVD title (DVD)

Some DVDs contain two or more titles. If this is the case, you can select a particular title for playback.

Press during playback to display the title

menu. Press to select the preferred title.

Press or to start playback.

Note:

• Title selection may not apply to some DVDs.

• The title menu may simply be referred to a

“menu” or “title” in the instructions supplied with the DVD.

DVD menu (DVD)

Some DVDs have an encoded menu that allows users to select a specific disc content, enable a particular DVD feature (e.g. subtitle or soundtrack language), or choose a particular title (for multititle DVDs).

Press during playback.

Press to select a DVD menu

item, then press or to access it. Use the same keys to enable an option for the selected item. Repeat this step to configure other menu options. Press again to resume playback on the

scene that was playing when you pressed

Note: Depending on the DVD, you may not be able to resume playback from the same scene that was playing when you pressed .

Chapter 9: Advanced disc playback

Soundtrack language/Audio channel/Subtitle

Selecting a soundtrack language (DVD)

You can select the soundtrack language when you play a multilingual DVD.

During playback, press repeatedly until the preferred language track is selected.

Selecting the audio channel (VCD)

During playback, press repeatedly until the preferred audio channel is heard. Options include Stereo, Left, Right, and Mix.

Note:

• If the preferred language option is not heard

after selecting it for several times, that language is not recorded on the disc.

• The soundtrack language selected is only

applicable for the current session. When you stop playback and try to play the disc again, the default language track will be used.

• If you select the DTS option in DVDs with

DTS feature, no sound will be heard from the TV/DVD’s speakers. You need to connect an amplifier equipped with a DTS decoder to the Optical digital audio out jack.

Viewing subtitles (DVD)

When playing back a disc recorded with subtitles, you can select the subtitle language or turn the subtitle off.

To view subtitles:

Press repeatedly during playback until the preferred language is selected.

The Subtitle prompt will disappear after a few seconds.

To disable subtitles:

Press until Off appears.

Note:

• Not all DVDs have encoded subtitles.

• The subtitle selection may revert to the

default language when you stop playback and try to play the DVD again.

• In some cases, the selected subtitle may not

display immediately.

Playback information/VCD playback control

Viewing the playback info (DVD/VCD)

Press during playback.

DVD mode

Elapsed/remaining time for current title

DVD Video

Time TT 00:01:52/00:09:11 CH 00:01:41/00:00:01

Title 1/2

Chapter 2/5

Chapter no.

Audio type Subtitle status (if on, will show language)

1/5 2 Ch Eng

off

1/1

2.205Mbps Bitrate

Bit rate Scene angle status

VCD mode

Elapsed/remaining time for current disc

VCD2.0

Time DISC 00:00:19/00:16:12 Track 00:00:19/00:02:28

Track 1/8

Track no. (if PBC is enabled, “PBC On” will be displayed)

To close the information display:

Press .

Note: Depending on the disc, this operation may not be available.

Elapsed/remaining time for current chapter

Title no.

Elapsed/remaining time for current track

Chapter 9: Advanced disc playback

Turning off the PBC function (VCD)

Press in stop mode.

Press or to select Mode, then press

repeatedly until Normal appears.

Mode : Normal

Repeat : Off

Press to close the screen.

To turn on the PBC function:

Follow steps 1 and 2 above, then press repeatedly until PBC appears.

When enabled, PBC allows interactive Video CD playback using the remote control.

Play Mode

Program Playback

Chapter 9: Advanced disc playback

MP3, WMA, JPEG, and Audio CD operation

This TV/DVD can play MP3, WMA, and JPEG files recorded on a CD-R or CD-RW disc. To create the MP3/ WMA/ JPEG disc, you need a Windows PC with a CD-RW drive and file encoding software. You must use a Windows PC to create the MP3/WMA/JPEG disc.

This TV/DVD requires discs/recordings that meet certain technical standards in order to achieve optimal playback quality. There are many different types of recordable disc formats (including CD-R discs containing MP3 or WMA files). Not all recordable discs will produce optimal playback quality. The technical criteria set forth in this owner’s manual are meant only as a guide. Use of CD-RW discs for recording MP3 files is not recommended.

You must obtain any required permission from copyright owners to download or use copyrighted content. Toshiba

can not and does not grant such permission.

MP3/WMA/JPEG/Audio CD information (CD)

MP3/WMA/JPEG CD playback reminders

• Make sure the file name of the MP3, WMA, and JPEG files in the CD includes the 3-character file extension (“mp3”, “wma”, “jpg”, “div”, and “avi”) to make it compliant with the ISO 9660 standard.

• This TV/DVD can read 2000 files per disc. If a disc has more than 2000 files, it reads the first 2000 files, while the remaining files will be omitted.

• To play the files in sequence based on the recorded order:

– Use an encoding software that records data alphabetically or numerically. – Include a two- or three-digit number prefix on the file name (ex. “01” “02” or “001” “002”). – Refrain from making too many sub-folders.

• It may take more than one minute for this TV/DVD to read MP3, WMA, and JPEG files depending on the disc structure.

• Audio files recorded using the Joliet Recording Specification can be played back in this TV/DVD. The file name is displayed (up to 15 characters). Longer file names will be condensed.

• Music recorded based on the “Joliet Recording Specification” can be played back, the file name is displayed (within 15 letters) on the screen. Long file names will be condensed.

• This TV/DVD does not support data disc burned using the Apple Mac OS (Hierarchical File System, HFS format).

• MP3/WMA/JPEG CDs cannot be used for recording purpose.

File name display reminders

• The maximum number of characters for file name display is 15.

• Only the following characters will be displayed: A through Z (both upper and lower case), 0 through 9, and the underscore symbol (_).

• Non-supported characters will be replaced with a hyphen (-).

MP3/WMA/JPEG CD limitations

• Depending on the recording conditions, some MP3/WMA/JPEG CDs cannot be played back in your TV/DVD.

• Only MP3, WMA, and JPEG files recorded in the CD-R/RW disc will be played. Other files will not be read nor displayed.

MP3/WMA file encoding information

•MP3

– File format: MPEG-1 Audio – Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz – Bit rate: 32 to 320 kbps (constant bit rate or variable bit rate)

The recommended recording setting for high-quality sound is 44.1 kHz sampling frequency and 128 kbps constant bit rate.

•WMA

– File format: WMA version 7 or 8 – Sampling frequency: 32 kHz / 48 kbps, 44.1 kHz / 48 to 92 kbps, 48 kHz / 128 to 192 kbps

A file recorded in mono (48 kHz / 48 kbps) is not supported by this TV/DVD.

Microsoft, Windows Media, and Windows Logo are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.

Chapter 9: Advanced disc playback

About the file browser (CD)

Operation status Scroll bar

3/15 00:00:00

/WMA-11.WMA

MP3-5

MP3-6

File list

WMA-11

WMA-12

Picture-1

Picture-2

Selection highlight

File icons

Music file (MP3/WMA/Audio CD track)

Picture file (JPEG)

If a CD contains a mixture of MP3, WMA and JPEG files, and is pressed without selecting a file, playback automatically begins starting from the first file in the list.

Setting the file type listing

You can choose the type of files listed in the file browser.

Press to move the selection highlight to the

Option panel.

Press or to highlight Select files, then

press . Press or to select a file type from the list

— Audio or Photo. Press to add or remove the check mark

next to each file type. Checked file type will be displayed in the file browser.

Press twice to move the selection highlight

back to the file list.

Viewing image files in thumbnail mode

You can change the browsers view mode from list mode to thumbnail mode. This is convenient when browsing for JPEG files.

Press .

Press to select an image file.

To return the browser to list mode:

Press .

To view the previous or next thumbnail page:

Press SKIP or SKIP .

Filename of selected item

Select files

Music Playing

Preview panel

Option panel

Playing an audio file (CD)

Load an MP3/WMA/Audio CD in the disc

slot. The file browser appears on-screen.

automatically play by composition of an audio file.

Folder-1

Folder-2 MP3-1 MP3-2 MP3-3 WMA-1 WMA-2 WMA-3

Press or to select another audio file for

playback

Folder-1 Folder-2 MP3-1

MP3-2

MP3-3 WMA-1 WMA-2 WMA-3

Press or to start playback.

JPEG Preview

To stop playback:

Press .

The TV/DVD records the stop point. “ ” appears on-screen. Press to resume playback. If you press twice in quick succession or unload the disc, the TV/DVD will clear the stop point.

Note:

• If the current directory has more than eight

files, press or to scroll the file list.

• To see folder contents, select a folder and

then press .

• To return to the root directory, press or

select “Go Up...” then press .

• In thumbnail mode, press repeatedly to

change the thumbnail size.

• The Repeat and Random/Programmed

playback modes can be enabled during MP3 or WMA playback. Refer to Page 68.

It may

Select files

Chapter 9: Advanced disc playback

Viewing a JPEG file (CD)

Load a disc containing JPEG files in the disc

slot. The file browser appears on-screen.

Press or to select an image file for view.

A preview of the selected file is displayed in the Preview panel.

/Picture-01.JPG

Picture-01

Picture-02 Picture-03 Picture-04 Picture-05 Picture-06 Picture-07 Picture-08

Press or .

The selected image is displayed in full-screen mode.

Press SKIP or SKIP to view the previous or next image file in the current directory.

To rotate an image:

Press repeatedly until the preferred angle is obtained. The image angle is adjusted in 90° increments.

The current angle setting is shown on-screen: 90°, 180°, 270°, or No rotation.

To magnify an image:

Press repeatedly until the image is displayed in the preferred scale.

The current zoom setting is indicated by the following icons: 1 (× 1.3), 2 (× 1.5) and 3

(× 2.0).

To return to normal view:

Press repeatedly until Off appears.

Select files

JPEG Preview

W: 2048 H: 1536

Viewing a slide show (CD)

If there are multiple JPEG files in the selected directory, you can view them in a slide show. For instructions on how to enable the slide show feature and set the interval period between pictures, go to Page 72.

Open the file folder containing the JPEG files

you want to include in the slide show. Press or to select the file you want to be

the starting image for the slide show

A preview of the selected file is displayed in the Preview panel.

/Picture-01.JPG

Picture-01

Picture-02 Picture-03 Picture-04 Picture-05 Picture-06 Picture-07 Picture-08

Press or .

The selected image is displayed in full-screen mode. When the slide show is completed, the file browser appears.

To view the previous or next image in the

slide show:

Press SKIP or SKIP .

To temporarily stop the slide show:

Press . “ ” appears briefly on-screen. Press or SKIP to resume the slide show.

❙❙

To stop the slide show:

Press . The file browser appears.

Note:

• The Rotate and Zoom modes are available

in regular JPEG viewing and slide show modes.

• The Jump and A-B repeat modes are not

available when viewing JPEG images.

• During a slide show, the interval time

between images may increase if the file size is too big.

• When an image exceeds 5760 x 3840

pixels, the image display can appear cropped. This applies when viewing the image in the Preview panel of the file browser; or when in the thumbnail, fullscreen, or slide show modes.

Select files

JPEG Preview

W: 2048 H: 1536

Chapter 9: Advanced disc playback

MP3, WMA, JPEG and Audio CD playback modes

You can choose to repeat CD playback by track or the entire disc. You can also program the file playback sequence or set the TV/DVD to play files at random.

Note: These playback modes are only applicable during the current session. Once you eject the disc or turn off the TV/DVD, these modes will be disabled. Pressing SKIP

or SKIP during playback will also

cancel these modes.

Enabling repeat playback (CD)

During stop mode, in the Option panel of the

file browser, press or to select Repeat.

Press repeatedly to select a repeat mode,

Track or All.

Press .

The TV/DVD automatically starts repeat playback after finishing the current track.

To resume normal playback:

Select Off in step 2 above.

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3

Select files

Enabling random playback (CD)

During stop mode, in the Option panel of the

file browser, press or to select Mode.

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3

Press repeatedly to set mode to Shuffle.

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3

Press .

The TV/DVD automatically applies the shuffle mode.

To resume normal playback:

Select Normal in step 2 above.

Note: When the Music Intro mode is enabled, the first 10 seconds of an audio track is played. This is useful if you are simply looking for a particular track in a list.

Edit Mode

Chapter 9: Advanced disc playback

Programming the playback sequence (CD)

In the Option panel of the file browser, press

or to select Edit Mode, then press .

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3

Press to return to the file list and press or

to select a file, then press to mark it for

inclusion in the programmed playlist. A check mark will appear next to the file.

Folder-1 Folder-2

MP3-1

MP3-2 MP3-3

Repeat this step to mark any other files you want to add in the programmed playlist.

In the Option panel, press or to select

Add To Program, then press to add the

marked files in the programmed playlist.

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3

Edit Mode

Program View

Edit Mode

Program View

Edit Mode

Program View

Add To Program

Press or to select Program View, then

press .

MP3-1

MP3-2

MP3-3

WMA-3

Edit Mode

Browser View

Clear Program

Program View

In Program view, only the files you added in step 3 are displayed.

Folder-1

Folder-2

MP3-1

MP3-2

MP3-3

WMA-1

WMA-2

WMA-3

Edit Mode

Program View

Add To Program

Browser View In the programmed file list, press or to

select a file, then press to start playback.

MP3-1

MP3-2

MP3-3

WMA-3

Edit Mode

Browser View

Clear Program

Press or to select Edit Mode, then

press to disable it.

Folder-1 Folder-2 MP3-1 MP3-2 MP3-3

Edit Mode

Program View

To remove a file from the programmed list:

1. Press twice to stop playback.

2. In Program view, press to select

Edit Mode on the Option panel, then press

to enable it.

3. Press to go to the programmed list.

4. Press to select the file you want to remove, then press .

5. Repeat step 4 to mark any other files you want to remove from the list.

6. Press to go to the Option panel.

7. Press or to select Clear Program, then press .

Chapter 10: Customizing disc playback

Customizing disc playback

You can customize the disc playback settings to suit your preferences.

Configuring the disc playback settings (DVD/VCD/CD)

In DVD mode, press during stop mode.

Parental : Off

DRC : Off

E.B.L. : Off

Menu :English

Subtitle :Englis h

Set Password

QSound : On

TV Screen : 4:3

Audio :English

Output : Interlace

Display : On

OSD :English

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Press or to select a setup tab, then press

. The first setup option is highlighted.

Display :Off

Menu : English

Picture Mode :Auto

Set Password

QSound : On

Subtitle : English

JPEG Interval :Off

Output : Interlace

Audio : English

DivX(R) VOD

Press or to select the setup option you

want to customize. Press or to display a list of available

option settings. Press or to select an option setting, then

press to apply and save it. Go to Page 71-74 for list of description for each option setting. To configure another option on the same setup

tab, repeat steps 3–5. To configure an option on another tab, press

, then use or to select a setup tab.

Repeat steps 3–5 to configure the preferred option.

To close the Setup screen, press or .

Disc playback setup

Chapter 10: Customizing disc playback

Tab Option Description

Menu Select the language for the DVD menu display.

Subtitle Select the subtitle language for disc playback.

Audio Select the audio language for disc playback.

OSD Select the language for the Setup screen display.

Display

JPEG Interval

Night Mode Toggle the night mode on or off.

Digital Out

Parental Set the restriction level for allowable disc content. 73

Password

Note: These setup settings are retained in the TV/DVD’s memory. It remains active even if the power is turned off.

Choose whether to show a status display whenever a button is pressed.

Select the interval time between images in a slide show.

Select the format for the digital audio output corresponding to your audio connection.

Change the access password for the parental control setting.

Go to

page

72Picture Mode Select the DVD source content.

Chapter 10: Customizing disc playback

Parental : Off

DRC : Off

E.B.L. : Off

Menu :English

Subtitle :English

Set Password

QSound : On

TV Screen : 4:3

Audio :English

Output : Interlace

Display : On

OSD :English

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Parental : O

DRC : O

Menu : English

Display :On

Picture Mode :Auto

Set Password

QSound : On

Subtitle : English

JPEG Interval :Off

Output : Interlace

Audio : English

DivX(R) VOD

Menu / OSD

Select the language for the DVD and Setup menu display. Options include: English, French, and Spanish.

Subtitle / Audio

Select the language for the subtitle display and audio track output during disc playback.

English The selected language will

French

be heard or seen.

Spanish

Auto (Subtitle) The TV/DVD will display the

subtitle in the disc’s default language.

Off (Subtitle)

There will be no subtitle display.

Note: If the selected language is not available, the default disc language will be used.

Display

Choose whether to show a status display whenever a button is pressed.

Off There will be no on-screen display.

On There will be on-screen display

when any button is pressed.

Picture Mode

The source content of a DVD can either be recorded in: film format (images are recorded at 24 frames per second) or video format (images are recorded at 30 frames per second).

Auto The TV/DVD automatically detects

the type of source content and converts that signal in an appropriate method based on the current aspect ratio of the TV/DVD. This option will normally suit most DVDs.

Film Suitable for playback of DVDs

recorded in a film format.

Video

Suitable for playback of DVDs recorded in a

video format.

Note: If picture appears cut off or doubled, select the “Video” setting.

JPEG Interval

Select the interval time between images during a JPEG slide show.

Off Slide show option is disabled.

5, 10, or 15 seconds

Images will be displayed in a slide show using the selected interval time.

Chapter 10: Customizing disc playback

Night Mode :Off

Parental : O

Menu : English

E.B.L. : O

Digital Out :Bitstream

Set Password

Subtitle : English

TV Screen : 4:3

Output : Interlace

Audio : English

Display : On

DivX(R) VOD

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

DRC : Off

Menu : English

E.B.L. : Off

Parental :Off

QSound : On

Subtitle : English

TV Screen : 4:3

Password :Change

Audio : English

Display : On

Picture Mode : Auto

JPEG Interval : 5 Seconds

Screen Saver : On

Night Mode

Select to toggle the Night Mode feature on or off. When enabled, this function allows for automatic volume level adjustment for audio that may be too low (e.g. whispered dialogues) or too high (e.g. a thunderstorm scene).

Off Audio retains its disc recording

volume level.

On Volume level is automatically

adjusted depending on the scene content.

Note: The Night Mode feature is only applicable to Dolby Digital-featured DVDs. The adjusted sound level depends on the DVD encoding.

Digital Out

Select the sound format of the digital output depending on the enabled signal connection.

Off Disables digital sound output.

Select this option when there’s no equipment connected to the optical DIGITAL AUDIO OUT jack.

PCM Changes Dolby Digital output

to PCM. Select this option when using a two-channel digital stereo amplifier.

Bitstream Select this option to output

the signal in its native format.

Note: MPEG audio will always be in PCM format regardless of the Digital Output setting.

Parental

A DVD is usually encoded with a rating level to indicate the recommended audience age. You have the option to select the content rating level allowed for playback in your TV/DVD.

You will be prompted to key in the system password to access this settings option.

Press or to select the allowable rating level, then press .

Off No playback restriction. All

discs can be played regardless of content rating.

Level 1–5 Discs of varied non-adult ratings

will be played back. The higher the number, the more severe the content is.

Level 6–8 Discs of varied adult only

ratings will be played back.

Note:

• The Parental rating levels correspond to

the US movie ratings.

Level 1 – Kids Safe Level 5 – PG–R

Level 2 – G Level 6 – R

Level 3 – PG Level 7 – NC–17

Level 4 – PG–13 Level 8 – Adult

• Some discs may not have their rating

level encoded on the disc though it’s indicated on the disc jacket. Playback restriction will not apply to these discs so make sure to restrict access to it manually.

Chapter 10: Customizing disc playback

To temporarily cancel the parental restriction:

1) Load the restricted content DVD that you want to play.

2) Use the Channel Number buttons (0–9)

to input the system password after the “Enter Password” message, then press

This suspension of the parental restriction setting applies until disc is ejected.

Password

Select this option to change the access password for the parental control setting.

Press or to select Password, then press .

2) Use the Channel Number buttons

(0–9) to input the current password, then press .

If the password has not been set yet key in “0000”. This is the factory default password.

3) Use the Channel Number buttons

(0–9) to input the new password, then press .

You will be prompted to confirm the new password.

4) Use the Channel Number buttons

(0–9) to input the new password again, then press .

5) Press one last time to confirm the

changed password. Note this new password for future reference.

If you forget the system password:

1) Make sure there is no disc in the disc

slot.

2) Press and hold down “4” on the

remote control, then press VOLUME- on the TV control panel.

The “Initializing” message appears on-screen to indicate that the password has been reset to its default factory setting “0000”. All DVD Setuprelated settings will also be reset to their default factory values.

Chapter 11: Troubleshooting

General troubleshooting

Before calling a service technician, please check this chapter for a possible cause of the problem and some solutions you can try.

Black box on-screen

•

The closed caption feature is set to one of the Text modes (T1, T2, T3, or T4). Set the closed caption feature to Off ( Page 39).

TV stops responding to controls

•

If the TV stops responding to the controls on the remote control or TV control panel and you cannot turn off the TV, press and hold POWER on the TV control panel for 5 or more seconds to reset the TV.

• If you cause a static discharge when touching

the TV and the TV fails to function, simply unplug the TV from the AC outlet and plug it back in. The TV should return to normal operation.
