Toro SnowMaster 724 ZXR 36001, 36003, SnowMaster 724 QXE, SnowMaster 824 QXE Operator's Manual

FormNo.3396-366RevA

SnowMaster724ZXRSnowthrower

ModelNo.36001—SerialNo.316000001andUp

Operator'sManual

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemicalorchemicals

knowntotheStateofCaliforniatocausecancer,

birthdefects,orreproductiveharm.

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Introduction

Thismachineisintendedtobeusedbyresidential
homeowners.Itisdesignedforremovingsnowfrom
pavedsurfaces,suchasdrivewaysandsidewalks,and
othersurfacesfortrafconresidentialorcommercial
properties.Itisnotdesignedforremovingmaterials
otherthansnow,norisitdesignedforclearingoffgravel
surfaces.

Readthisinformationcarefullytolearnhowtooperateand
maintainyourmachineproperlyandtoavoidinjuryand
machinedamage.Youareresponsibleforoperatingthe
machineproperlyandsafely.

YoumaycontactTorodirectlyatwww.Toro.comformachine
andaccessoryinformation,helpndingadealer,ortoregister
yourmachine.

Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourmachineready.Figure1identiesthelocationofthe
modelandserialnumbersonthemachine.Writethenumbers
inthespaceprovided.

Figure1

1.Modelandserialnumberlocation

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.

Figure2

1.Safetyalertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.

Formodelswithstatedpower,thenetpoweroftheenginewas
laboratoryratedbytheenginemanufacturerinaccordance
withSAEJ1940.Asconguredtomeetsafety,emission,and
operatingrequirements,theactualenginehorsepoweronthis
classofsnowthrowerwillbesignicantlylower.

©2015—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Registeratwww.T oro.com.

OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

*3396-366*A

Contents

Introduction..................................................................1

Safety...........................................................................2

SafetyandInstructionalDecals.................................3

Setup............................................................................4

1UnfoldingtheHandle............................................4

2InstallingtheDischargeChute................................5

3FillingtheEnginewithOil......................................5

4CheckingtheTirePressure.....................................6

ProductOverview..........................................................7

Operation.....................................................................7

BeforeOperation.......................................................7

Safety.....................................................................7

FillingtheFuelTank................................................7

CheckingtheEngine-OilLevel..................................8

DuringOperation......................................................8

Safety.....................................................................8

StartingtheEngine..................................................9

EngagingtheAuger.................................................9

DisengagingtheAuger.............................................9

Self-PropellingtheMachine......................................9

StoppingtheEngine................................................9

AdjustingtheDischargeChuteandChute

Deector...........................................................10

ClearingaCloggedDischargeChute.........................10

OperatingTips......................................................10

AfterOperation........................................................10

Safety....................................................................10

PreventingFreeze-upafterUse.................................10

Maintenance.................................................................12

RecommendedMaintenanceSchedule(s)......................12

MaintenanceSafety.................................................12

CheckingtheEngineOilLevel.................................12

CheckingandAdjustingtheSkids.............................13

InspectingtheThrowingEdges................................13

ChangingtheEngineOil.........................................13

ReplacingtheSparkPlug.........................................15

AdjustingtheAugerCable.......................................15

AdjustingtheTransmissionCable.............................15

CheckingtheTirePressure......................................16

Storage........................................................................17

StoringtheSnowthrower.........................................17

Safety

ThismachinemeetsorexceedstheB71.3specications
oftheAmericanNationalStandardsInstituteineffect
atthetimeofproduction.

•Readandunderstandthecontentsofthemanualbefore

youstarttheengine.Makesurethateveryoneusingthis
productknowshowtousetheproductandunderstands
thewarnings.

•Donotputyourhandsorfeetnearmovingcomponents

onthemachine.

•Donotoperatethemachinewithoutallguardsandother

safetyprotectivedevicesinplaceandworkingonthe
machine.

•Keepclearofanydischargeopening.Keepbystandersa

safedistancefromthemachine.

•Keepchildrenoutoftheoperatingareaandunderthe

watchfulcareofaresponsibleadultotherthanthe
operator.Neverallowchildrentooperatethemachine.

•Shutthemachineoffbeforeunclogging,servicing,or

fueling.

2

SafetyandInstructionalDecals

Note:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamageddecals.

131–1785

Orderpartno.131–5921

1.Augerdrive—squeezethelevertoengage;releasethelever
todisengage.

4.Thrownobjecthazard—keepbystandersasafedistancefrom
thesnowthrower.

2.Warning—readtheOperator'sManual.5.Self-propeldrive—pushdownonthehandletoengagethe
self-propeldrive.

3.Cutting/dismembermenthazardofhandorfoot,auger—keep

awayfrommovingparts;keepallguardsandshieldsinplace;
stoptheengineandwaitfortheaugertostopbeforeleaving
themachine;removetheignitionkeyandreadtheinstructions
beforeservicingorperformingmaintenance.

131–5914

Orderpartno.131–5916

1.Cutting/dismembermenthazardofhandorfoot,auger—do

notplaceyourhandinthechute;removetheignitionkey
andreadtheinstructionsbeforeservicingorperforming
maintenance.

x 3

1

2

3

4

5

120-9805

120-9805

1.Insertthekey.

2.Primetheengine3times.

3.Engagethechoke.

4.Pullthestartercord.

5.Oncetheengineisrunning,disengagethechoke.

3

Setup

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescription

Qty.

Use

1

Nopartsrequired

–

Unfoldthehandle.

Bolt(1/4–20X1.50inch)

1

2

Washer-facedlocknut(1/4–20inch)

1

Installthedischargechute.

4

Nopartsrequired

–

1

UnfoldingtheHandle

NoPartsRequired

Procedure

Important:Ensurethecablesarenotpinchedwhen

unfoldingthehandle.

Figure3

4

2

InstallingtheDischargeChute

Partsneededforthisprocedure:

1

Bolt(1/4–20X1.50inch)

1

Washer-facedlocknut(1/4–20inch)

Procedure

Insertthechutepostthroughthebracketintothebaseofthe
machineandsecureitusingaboltandalocknut(Figure4).

Figure4

1.Chutepost3.Washer-facedlocknut

(1/4–20inch)

2.Bolt(1/4–20X1.50inch)

4.Bracket

3

FillingtheEnginewithOil

NoPartsRequired

Procedure

Yourmachinecomeswithoilintheengine.

Model

Maxll

36001

17oz(0.5L)

Oiltype:automotivedetergentoilwithanAPIservice
classicationofSJ,SL,orhigher.

UseFigure5belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:

Figure5

1.Movethemachinetoalevelsurface.

2.Cleanaroundtheoilllcap.

3.Checktheoillevelandaddoilifnecessary.

Note:Donottightenthedipstickwhencheckingthe
oillevel.

5

Figure6

1.Lowoillevel—addoil

2.Correctoillevel

4

CheckingtheTirePressure

NoPartsRequired

Procedure

Thetiresareoverinatedatthefactoryforshipping.Reduce
thetirepressureequallyinbothtirestobetween103and137
kPa(15and20psi).

6

ProductOverview

Figure7

1.Augerlever7.Dischargechute

2.Fueltankcap

8.Chutedeector

3.Dipstick

9.Chutedeectorcontrol

4.Skid

10.Dischargechutecontrol

5.Auger11.Upperhandle

6.Scraper

Figure8

1.Fueltankcap

4.Choke

2.Primer5.Recoilstarter

3.Ignitionkey

Operation

BeforeOperation

Safety

•Useextensioncordsandreceptaclesasspeciedby

themanufacturerforallmachineswithelectricstarting
motors.

•Donotoperatethemachinewithoutwearingadequate

wintergarments.Avoidloosettingclothingthatcanget
caughtinmovingparts.Wearslipresistantfootwearthat
willimprovefootingonslipperysurfaces.

•Alwayswearsafetyglassesoreyeshieldsduringoperation

orwhileperforminganadjustmentorrepairtoprotect
eyesfromforeignobjectsthatmaybethrownfromthe
machine.

•Thoroughlyinspecttheareawherethemachineistobe

usedandremovealldoormats,sleds,boards,wires,and
otherforeignobjects.

•Ifashield,safetydevice,ordecalisdamaged,illegible,or

lost,repairorreplaceitbeforebeginningoperation.Also,
tightenanyloosefasteners.

DANGER

Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.

•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
onthegroundbeforelling,notinavehicleor
onanobject.

•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.

•Donothandlegasolinewhensmokingoraround
anopenameorsparks.

•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.

•Donottipthemachineeitherforwardor
backwardwithfuelinthefueltank;otherwise,
fuelmayleakoutofthemachine.

FillingtheFuelTank

RecommendedFuel:

•Forbestresults,useonlyclean,fresh(lessthan30days

old),unleadedgasolinewithanoctaneratingof87or
higher((R+M)/2ratingmethod).

•Ehtanol:Gasolinewithupto10%ethanol(gasohol)

or15%MTBE(methyltertiarybutylether)byvolume
isacceptable.EthanolandMTBEarenotthesame.
Gasolinewith15%ethanol(E15)byvolumeisnot
approvedforuse.Neverusegasolinethatcontainsmore

7

than10%ethanolbyvolume,suchasE15(contains15%
ethanol),E20(contains20%ethanol),orE85(contains
85%ethanol).Usingunapprovedgasolinemaycause
performanceproblemsand/orenginedamagewhichmay
notbecoveredunderwarranty.

•Donotusegasolinecontainingmethanol.

•Donotstorefueleitherinthefueltankorfuelcontainers

overthewinterunlessafuelstabilizerisused.

•Donotaddoiltogasoline.

Figure9

1.Donotllabovethebottomofthefueltankneck.

Note:Forbestresults,purchaseonlythequantityofgasoline
thatyouexpecttousein30days.Otherwise,youmayadd
fuelstabilizertonewlypurchasedgasolinetokeepitfreshfor
upto6months.

CheckingtheEngine-OilLevel

RefertoChangingtheEngineOil(page13).

DuringOperation

Safety

•Rotatingaugerbladescaninjurengersorhands.

Staybehindthehandlesandawayfromthedischarge
openingwhileoperatingthemachine.Keepyourface,

hands,feet,andanyotherpartofyourbodyor
clothingawayfrommovingorrotatingparts.

•Neverdirectthedischargetowardpeopleorareaswhere

propertydamagecanoccur.

•Exercisecautiontoavoidslippingorfalling.Alwaysbe

sureofyourfooting,andkeeparmholdonthehandles.
Walk;neverrun.

•Exerciseextremecautionwhenoperatingonslopes.

•Neveroperatethemachinewithoutgoodvisibilityor

light.

•Lookbehindandusecarewhenbackingupwiththe

machine.

•Whennotactivelyclearingsnow ,disengagepowertothe

rotorblades.

•Useextensioncordsandreceptaclesasspeciedby

themanufacturerforallmachineswithelectricstarting
motors.

•Donotattempttoclearsnowfromagravelorcrushed

rocksurface.Thisproductisintendedforuseonlyon
pavedsurfaces.

•Donotusethemachineonaroof.

•Neverattempttomakeanyadjustmentswhiletheengine

isrunning(exceptwhenspecicallyrecommendedby
manufacturer).

•Stayalertforhiddenhazardsortrafc.

•Afterstrikingaforeignobject,stoptheengine,remove

theignitionkey ,thoroughlyinspectthemachineforany
damage,andrepairthedamagebeforerestartingand
operatingthemachine.

•Ifthemachineshouldstarttovibrateabnormally,stop

theengineandcheckimmediatelyforthecause.

•Donotruntheengineindoors,exceptwhenstarting

theengineandfortransportingthemachineinorout
ofthebuilding.Opentheoutsidedoors;exhaustfumes
aredangerous.

•Donotoverloadthemachinecapacitybyattemptingto

clearsnowattoofastarate.

•Nevertouchahotengineormufer.

•Thoroughlyinspecttheelectricalcordbeforeplugging

itintoapowersource.Ifthecordisdamaged,donot
useittostartthemachine.Replacethedamagedcord
immediately.Unplugthepowercordwheneveryouare
notstartingthemachine.

8

StartingtheEngine

Note:Fullyinsertthekeytostarttheengine.Themiddle

positionwillnotstarttheengine.

Figure10

EngagingtheAuger

Figure11

DisengagingtheAuger

Todisengagetheauger,releasetheaugerlever.

Self-PropellingtheMachine

Tooperatetheself-propeldrive,simplywalkwithyourhands
ontheupperhandleandyourelbowsatyoursides,andthe
machinewillautomaticallykeeppacewithyou(Figure12).

Note:Youcanself-propelthemachinewiththeauger
engagedordisengaged.

Figure12

StoppingtheEngine

Tostoptheengine,removethekeyfromtheignitionormove
thekeytothemiddleposition.

9

AdjustingtheDischargeChute
andChuteDeector

Toraiseorlowertheangleofthechutedeector,pressthe
triggeronthechutedeectorandmovethechutedeector
upordown.

Toadjustthedischargechute,movethechutehandle

Note:Disengagetheaugerbeforeadjustingthechuteor
chutedeector.

Figure13

1.Trigger

2.Chutehandle

ClearingaCloggedDischarge
Chute

Important:Handcontactwiththerotatingaugerinside

thedischargechuteisthemostcommoncauseofinjury
associatedwithsnowthrowers.Neveruseyourhandto
cleanoutthedischargechute.

1.Whileremainingintheoperatingposition,releasethe
self-propelhandle.

2.Engagetheauger.

3.Pushdownonthehandletoraisethefrontofthe
machineafewinches(centimeters)offthepavement.,
thenliftthehandlesquicklytobumpthefrontofthe
machineontothepavement.

4.Disengagetheauger.

5.Repeatsteps1through4,ifnecessary,untilastreamof
snowcomesoutofthedischargechute.

Note:Ifyoucannotunclogthedischargechutebybumping
thefrontofthemachine,stoptheengine,waitforall

movingpartstostop,anduseasnowcleanouttool(not
included);neveruseyourhand.

Important:Uncloggingthedischargechuteby
bumpingthefrontofthemachineonthepavementmay

causetheskidstomove.Adjusttheskidsandtighten
theskidboltssecurely;refertoCheckingandAdjusting

theSkids(page13).

OperatingTips

WARNING

Theaugercanthrowstones,toys,andotherforeign
objectsandcauseseriouspersonalinjurytothe
operatorortobystanders.

•Keeptheareatobeclearedfreeofallobjects
thattherotorbladescouldpickupandthrow.

•Keepallchildrenandpetsawayfromthearea
ofoperation.

•Removethesnowassoonaspossibleafteritfalls.

•Ifthemachinedoesnotpropelitselfforwardonslippery

surfacesorinheavysnow,pushforwardonthehandle,
butallowthemachinetoworkatitsownpace.

•Overlapeachswathtoensurecompletesnowremoval.

•Dischargethesnowdownwindwheneverpossible.

AfterOperation

Safety

•Neverstorethemachinewithfuelinthefueltankinsidea

buildingwhereignitionsourcesarepresent,suchashot
waterheaters,spaceheaters,orclothesdryers.Allowthe
enginetocoolbeforestoringinanyenclosure.

•Whenstoringthemachineformorethan30days,referto

theStoragesectionforimportantdetails.

PreventingFreeze-upafterUse

•Lettheenginerunforafewminutestopreventmoving

partsfromfreezing.Stoptheengine,waitforallmoving
partstostop,andremoveiceandsnowfromthemachine.

•Cleanoffanysnowandicefromthebaseofthechute.

•Rotatethedischargechuteleftandrighttofreeitfrom

anyicebuildup.

•WiththeignitionkeyintheOffposition,pulltherecoil

starterhandleseveraltimesorconnecttheelectricalcord
toapowersourceandthemachineandpushtheelectric
startbuttononcetopreventtherecoilstarterand/orthe
electricstarterfromfreezingup.

•Insnowyandcoldconditions,somecontrolsandmoving

partsmayfreeze.Donotuseexcessiveforcewhen
tryingtooperatefrozencontrols.Ifyouhavedifculty
operatinganycontrolorpart,starttheengineandletit
runforafewminutes.

10

•Donotusethechutecontroltoattempttomoveafrozen

dischargechute.Holddowntheblueknobanduseyour
handstorotatethechute.

•Transportingthemachineinanopentrailerorvehiclecan

causethecontrolsordischargechutetofreeze.

11

Maintenance

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

MaintenanceProcedure

Afterthersthour

•Checkforloosefastenersandtightenthemifnecessary.

Aftertherst2hours

•Changetheengineoil.

•Inspecttheaugercableandadjustitifnecessary.

•Inspectthetransmissioncableandadjustitifnecessary.

Beforeeachuseordaily

•Checktheengineoillevelandaddoilifnecessary.

Every100hours

•Replacethesparkplug.

Yearly

•Checktheskidsandadjustthemifnecessary .

•InspectthethrowingedgesandhaveanAuthorizedServiceDealerreplacethe
throwingedgesandscraperifnecessary.

•Changetheengineoil.

•Inspecttheaugercableandadjustitifnecessary.

•Inspectthetransmissioncableandadjustitifnecessary.

•Checkthetirepressure.

•Checkforloosefastenersandtightenthemifnecessary.

•HaveanAuthorizedServiceDealerinspectthedrivebeltandreplaceitifnecessary.

Yearlyorbeforestorage

•Preparethemachineforstorage.

MaintenanceSafety

Readthefollowingsafetyprecautionsbeforeperformingany
maintenanceonthemachine:

•Beforeperforminganymaintenance,service,or

adjustment,stoptheengineandremovethekey .Ifmajor
repairsareeverneeded,contactanAuthorizedService
Dealer.

•Checkallfastenersatfrequentintervalsforproper

tightnesstobesurethemachineisinsafeworking
condition.

•Maintainorreplacesafetyandinstructionlabels,as

necessary.

•Donotchangethegovernorsettingsontheengine.

•PurchaseonlygenuineTororeplacementpartsand

accessories.

CheckingtheEngineOilLevel

ServiceInterval:Beforeeachuseordaily

1.Removethedipstick,wipeitclean,thenfullyinsertthe
dipstickwithoutthreadingitin.

2.Removethedipstickandchecktheoillevel.

•IftheoillevelisbelowtheAddmarkonthe

dipstick(Figure14),addoil.Referto3Fillingthe

EnginewithOil(page5).

•IftheoillevelabovetheFullmark(),drainthe

excessoiluntiltheoillevelisattheFullmarkon
thedipstick;referto3FillingtheEnginewithOil

(page5).

Figure14

1.Lowoillevel—addoil

2.Correctoillevel

12

CheckingandAdjustingthe
Skids

ServiceInterval:Yearly

Checktheskidstoensurethattheaugerdoesnotcontactthe
pavedsurface.Adjusttheskidsasneededtocompensatefor
wear(Figure15).

1.Loosentheskidbolts.

2.Slidea5mm(3/16inch)boardunderneaththescraper.

Note:Usingathinnerboardwillresultinamore
aggressivescraper.Athickerboardwillresultinaless
aggressivescraper.

3.Lowertheskidstotheground.

Note:Ensuretheskidsareatontheground.

4.Tightentheskidbolts.

Figure15

1.5mm(3/16inch)board2.Ground

InspectingtheThrowing
Edges

ServiceInterval:Yearly—Inspectthethrowingedgesand

haveanAuthorizedServiceDealer
replacethethrowingedgesandscraper
ifnecessary.

Beforeeachsession,inspectthethrowingedgesforwear.
Whenathrowingedgehasworndowntothewearindicator
hole,haveanAuthorizedServiceDealerreplacethethrowing
edges(Figure16).

Figure16

1.Thewearindicatorhole
isintact;youdonotneed
toreplacethethrowing
edges.

2.Thewearindicatorhole
isexposed;replaceboth
throwingedges.

ChangingtheEngineOil

ServiceInterval:Aftertherst2hours

Yearly

Runtheengineafewminutesbeforechangingtheoiltowarm
it.Warmoilowsbetterandcarriesmorecontaminants.

1.Movethemachinetoalevelsurface.

2.Placeanoildrainpanundertheoil-drainplug,remove
theoil-drainplug,andtipthemachinebackwardand
draintheusedoilintheoil-drainpan(Figure17).

13

Figure17

1.Oil-drainplug

3.Afterdrainingtheusedoil,returnthemachinetothe
operatingposition.

4.Installtheoildrainplugandtightenitsecurely.

5.Cleanaroundtheoilllcap.

6.UseFigure18belowtoselectthebestoilviscosityfor
theoutdoortemperaturerangeexpected:

Model

Maxll

36001

17oz(0.5L)

Oiltype:automotivedetergentoilwithanAPIservice
classicationofSJ,SL,orhigher.

Figure18

Figure19

1.Lowoillevel—addoil

2.Correctoillevel

14

ReplacingtheSparkPlug

ServiceInterval:Every100hours—Replacethesparkplug.

WARNING

Replacingthesparkplugwhiletheengineishot
canresultinburns.

Waituntiltheengineiscooltoreplacethespark
plug.

UseaT orosparkplugorequivalent(Champion®RN9YCor
NGKBPR6ES).

1.Removetheboot(Figure20).

Figure20

2.Cleanaroundthebaseofthesparkplug.

3.Removeanddiscardtheoldsparkplug.

Note:Y ouwillneedaratchetwrenchextensionto
removethesparkplug.

4.Setthegapbetweentheelectrodesonanewsparkplug
at0.76mm(0.030inch)(Figure21).

Figure21

1.0.76mm(0.030inch)

AdjustingtheAugerCable

ServiceInterval:Aftertherst2hours

Yearly

Ifthedrivebeltslipsorsquealsunderheavyload,adjustthe
augercable.

1.Loosenthenutonthelowercableclamp,butdonot
removeit(Figure22).

Figure22

1.Nut

3.Connector

2.Cable4.Spring

2.Pullthecableuptoremovesomeslack(Figure22).

Important:Donotremovealltheslackfromthe
cable.Removingalltheslackfromthecablewill
preventtheaugerfromstoppingproperly.

3.Holdthecableinplaceandtightenthenut(Figure22).

AdjustingtheTransmission
Cable

ServiceInterval:Aftertherst2hours

Yearly

Ifthewheelseasilystallout,orifthewheelsdrivewithout
engagingtheself-propelhandle,adjustthetransmissioncable.

1.Loosenthenutontheuppercableclamp,butdonot
removeit(Figure23).

15

Figure23

1.Nut

2.Cable

2.Pullthecabledowntoremovemostoftheslackinthe
cable(Figure23).

Important:Donotremovealltheslackfromthe
cable.Removingalltheslackfromthecablemay
causethewheelstoengagewithoutengagingthe
self-propelhandle.

3.Tightenthenut(Figure23).

CheckingtheTirePressure

ServiceInterval:Yearly

Setthetirepressureequallyinbothtirestobetween103and
137kPa(15and20psi).

16

Storage

StoringtheSnowthrower

WARNING

•Gasolinefumesarehighlyammable,explosive,
anddangerousifinhaled.Ifyoustorethe
machineinanareawithanopename,the
gasolinefumesmayigniteandcausean
explosion.

•Donotstorethemachineinahouse(living
area),basement,oranyotherareawhereignition
sourcesmaybepresent,suchashotwaterand
spaceheaters,clothesdryers,furnaces,and
otherlikeappliances.

•Donottipthemachinebackwardwithfuelin
thefueltank;otherwise,fuelmayleakoutof
themachine.

1.Onthelastrefuelingoftheseason,addfuelstabilizer
tofreshfuelasdirectedbytheenginemanufacturer.

2.Runtheenginefor10minutestodistributethe
conditionedfuelthroughthefuelsystem.

3.Stoptheengine,allowittocool,andsiphonthefuel
tankorruntheengineuntilitstops.

4.Starttheengineandrunituntilitstops.

5.Chokeorprimetheengine,startitathirdtime,and
runtheengineuntilitwillnotstart.

6.Drainthefuelinthecarburetorthroughthecarburetor
drainbolt()intoanapprovedgasolinecontainer.

7.Disposeofunusedfuelproperly.Recycleitaccording
tolocalcodes,oruseitinyourautomobile.

8.Whiletheengineisstillwarm,changetheengineoil.
Referto(page).

9.Removethesparkplug.

10.Squirt2teaspoonsofoilintothesparkplughole.

11.Installthesparkplugbyhandandthentorqueitto
27–30N-m(20–22ft-lb).

12.WiththeignitionkeyintheOffposition,pulltherecoil
starterslowlytodistributetheoilontheinsideofthe
cylinder.

13.Cleanthemachine.

14.Touchupchippedsurfaceswithpaintavailablefroman
AuthorizedServiceDealer.Sandaffectedareasbefore
painting,andusearustpreventativetopreventthe
metalpartsfromrusting.

15.Tightenanyloosefasteners.Repairorreplaceany
damagedparts.

16.Coverthemachineandstoreitinaclean,dryplace
outofthereachofchildren.Allowtheenginetocool
beforestoringitinanyenclosure.

17

*374-0299*

EmissionControlWarrantyStatement

FortheUnitedStates,California,andCanada

YourWarrantyRightsandObligations

TheCaliforniaAirResourcesBoard(CARB),theU.S.EnvironmentalProtectionAgency(EPA),andTheT oroCompany,arepleasedtoexplainthe
emissioncontrolsystemwarrantyonyour2015–2016smalloff-roadengine/equipment.InCaliforniaandtheUnitedStates,newsmalloff-road
engines/equipmentmustbedesigned,built,andcertiedtomeetstringentanti-smogstandards.TheToroCompanywarrantstheemissioncontrol
systemonyoursmalloff-roadengine/equipmentfortheperiodoftimelistedbelow,providedtherehasbeennoabuse,neglect,orimpropermaintenance
ofyoursmalloff-roadengine/equipment.

Youremissioncontrolsystemmayincludepartssuchasthecarburetor,fuel-injectionsystem,theignitionsystem,catalyticconverter,fueltanks,fuellines,
fuelcaps,valves,canisters,lters,vaporhoses,clamps,connectors,andotherassociatedemission-relatedcomponents.

Whereawarrantableconditionexists,TheT oroCompanywillrepairyoursmalloff-roadengine/equipmentatnocosttoyouincludingdiagnosis,
partsandlabor.

Manufacturer’sWarrantyCoverage

Thisemissioncontrolsystemiswarrantedfortwoyears.Ifanyemission-relatedpartonyourengine/equipmentisdefective,thepartwillberepairedor
replacedbyTheT oroCompany.

OwnerResponsibilities

Asthesmalloff-roadengineowner,youareresponsiblefortheperformanceoftherequiredmaintenancelistedinyourOperator'sManual.Werecommend
thatyouretainallreceiptscoveringmaintenanceonyoursmalloff-roadengine/equipment,butwecannotdenywarrantysolelyforthelackofreceipts.

Asthesmalloff-roadengine/equipmentowner ,youshouldhoweverbeawarethatwemaydenyyouwarrantycoverageifyoursmalloff-road
engine/equipmentoraparthasfailedduetoabuse,neglect,impropermaintenanceorunapprovedmodications.

Youareresponsibleforpresentingyoursmalloff-roadengine/equipmenttoaT oroDistributionCenterorServiceCenterassoonasaproblemexists.The
warrantyrepairsshouldbecompletedinareasonableamountoftime,nottoexceedthirty(30)days.

Ifyouhaveanyquestionsregardingyourwarrantycoverage,contactusat:

CustomerCareDepartment,ConsumerDivision
ToroWarrantyCompany
811 1LyndaleAvenueSouth
Bloomington,MN55420-1196
1–952–948–4027(U.S.andCanadiancustomers)
emailCustomerSupportat:www.toro.com

GeneralEmissionsWarrantyCoverage

TheT oroCompanywarrantstotheultimatepurchaserandeachsubsequentpurchaserthatthesmalloff-roadengine/equipmentis:

•Designed,built,andcertiedtoconformwithallapplicableemissionsregulations;and

•Freefromdefectsinmaterialsandworkmanshipthatcouldcausethefailureofawarrantedpart;and

•Identicalinallmaterialrespectstothepartsasdescribedintheapplicationforcertication.

Thewarrantyperiodbeginsonthedatethesmalloff-roadengine/equipmentisdeliveredtoanultimatepurchaser .Thewarrantedperiodistwoyears.

Subjecttocertainconditionsandexclusionsasstatedbelow,thewarrantyonevaporativeemissions-relatedpartsisasfollows:

1.Anywarrantedpartthatisnotscheduledforreplacementasrequiredmaintenanceinthewritteninstructionssupplied,iswarranted
forthewarrantyperiodstatedabove.Ifthepartfailsduringtheperiodofwarrantycoverage,thepartwillberepairedorreplacedby
TheT oroCompany .Anysuchpartrepairedorreplacedunderwarrantywillbewarrantedfortheremainderofthewarrantyperiod.

2.Anywarrantedpartthatisscheduledonlyforregularinspectioninthewritteninstructionssuppliediswarrantedforthewarranty
periodstatedabove.Anysuchpartrepairedorreplacedunderthewarrantywillbewarrantedfortheremainderofthewarrantyperiod.

3.Anywarrantedpartthatisscheduledforreplacementasrequiredmaintenanceinthewritteninstructionssuppliedis
warrantedfortheperiodoftimebeforetherstscheduledreplacementdateforthatpart.Ifthepartfailsbeforetherst
scheduledreplacement,thepartwillberepairedorreplacedbyTheToroCompany .Anysuchpartrepairedorreplaced
underwarrantywillbewarrantedfortheremainderoftheperiodpriortotherstscheduledreplacementpointforthepart.

4.Repairorreplacementofanywarrantedpartunderthewarrantyprovisionshereinmustbeperformedatan
AuthorizedServiceDealeratnochargetotheowner.

5.WarrantyservicesorrepairswillbeprovidedatallServiceDealersauthorizedtoservicethesubjectenginesorequipment.

6.Thesmalloff-roadengine/equipmentownerwillnotbechargedfordiagnosticlaborthatisdirectlyassociatedwithdiagnosis
ofadefective,emission-relatedwarrantedpart,providedthatsuchdiagnosticworkisperformedatanAuthorizedServiceDealer.

7.TheToroCompanyisliablefordamagestootherengine/equipmentcomponentscausedbyafailureunderwarrantyofanywarrantedpart.

8.Throughoutthesmalloff-roadengine/equipmentwarrantyperiodstatedabove,TheToroCompanywillmaintainasupply
ofwarrantedpartssufcienttomeettheexpecteddemandforsuchparts.

9.Manufacturerapprovedreplacementpartsmaybeusedintheperformanceofanywarrantymaintenanceorrepairsand
mustbeprovidedwithoutchargetotheowner.SuchusewillnotreducethewarrantyobligationsofTheT oroCompany .

10.Add-onormodiedpartsthatarenotapprovedbyTheT oroCompanymaynotbeused.Theuseofanon-approvedadd-onormodiedpartsby
thepurchaserwillbegroundsfordisallowingawarrantyclaim.TheT oroCompanywillnotbeliabletowarrantfailuresofwarrantedpartscausedby
theuseofannon-approvedadd-onormodiedparts.

WarrantedParts

Thefollowingemissionwarrantypartsarecovered,totheextentthesepartswerepresentontheT oroengine/equipmentand/orT orosuppliedfuelsystem:

374-0299RevA

1.FuelSystemParts

•Carburetorandinternalparts

•Coldstartingenrichment(primerorchoke)

•Fuelpump

•Fuelline,ttings,andclamps

•Fueltank,cap,andtether

•Carboncanister

2.AirInductionSystem

•Aircleaner

•Intakemanifold

•Crankcaseventandline(s)

•Purgelineandttings

3.IgnitionSystem

•Sparkplug(s)andwire(s)

•Magnetoignitionsystem

4.CatalyticExhaustSystem

•Catalyticconverter

•Exhaustmanifold

•Airinjectorsystemandvalve(s)

5.MiscellaneousItemsUsedinEmissionControlSystem

•Valves,switches,andlinkages

•Connectors,ttings,andbrackets

374-0299RevA

SnowMaster

Single-StageSnowthrowers

TheToroWarranty

AThree-YearLimitedWarranty(45DayLimitedWarrantyforCommercialUse)

ConditionsandProductsCovered

TheToroCompanyanditsafliate,ToroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetorepairtheT oroProduct
listedbelowifusedforresidentialpurposes*,ifdefectiveinmaterialsor
workmanshiporifitstopsfunctioningduetothefailureofacomponent
fortheperiodlistedbelow.

Thiswarrantycoversthecostofpartsandlabor,butyoumustpay
transportationcosts.

Thefollowingtimeperiodsapplyfromtheoriginaldateofpurchase:

ProductsWarrantyPeriod

SnowMasterSnowthrowersandAttachments

3years

—ChuteLifetime(originalowner

only)

1

—DeectorLifetime(originalowner

only)

1

—LowerChuteLifetime(originalowner

only)

1

LimitedWarrantyforCommercialUse

Gas-poweredT oroProductsusedforcommercial,institutional,orrental
use,arewarrantedfor45daysagainstdefectsinmaterialsorworkmanship.
Componentsfailingduetonormalweararenotcoveredbythiswarranty .

InstructionsforObtainingWarrantyService

IfyouthinkthatyourToroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:

1.ContactanyAuthorizedToroServiceDealertoarrangeserviceattheir
dealership.Tolocateadealerconvenienttoyou,refertotheYellow
Pagesofyourtelephonedirectory(lookunder“LawnMowers”)or
accessourwebsiteatwww.Toro.com.Youmayalsocallthenumbers
listedinitem#3tousethe24-hourToroDealerlocatorsystem.

2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.Thedealerwilldiagnosetheproblemanddetermineif
itiscoveredunderwarranty.

3.IfforanyreasonyouaredissatisedwiththeServiceDealer’s
analysisorwiththeassistanceprovided,contactusat:

ToroW arrantyCompany
CustomerCareDepartment,RLCDivision
811 1LyndaleAvenueSouth
Bloomington,MN55420-1196
Tollfreeat866-336-5205(U.S.customers)
Tollfreeat866-854-9033(Canadiancustomers)

OwnerResponsibilities

YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutinemaintenance,
whetherperformedbyadealerorbyyou,isatyourexpense.

ItemsandConditionsNotCovered

Thereisnootherexpresswarrantyexceptforspecialemissionsystem
coverageandenginewarrantycoverageonsomeproducts.Thisexpress
warrantydoesnotcoverthefollowing:

•Costofregularmaintenanceserviceorreplacementofwearparts,

suchasblades,rotorblades(paddles),scraperblades,belts,fuel,
lubricants,oilchanges,sparkplugs,lightbulbs,cable/linkageorbrake
adjustments

•Anyproductorpartwhichhasbeenalteredormisusedorneglected

orrequiresreplacementorrepairduetoaccidentsorlackofproper
maintenance

•Pickupanddeliverycharges

•Operationalmisuse,neglect,oraccidents

•RepairsorattemptedrepairsbyanyoneotherthananAuthorizedToro

ServiceDealer

•Repairsnecessaryduetofailuretofollowrecommendedfuel

procedure(consultOperator'sManualformoredetails)

–Removingcontaminantsfromthefuelsystemisnotcovered

–Useofoldfuel(morethanonemonthold)orfuelwhichcontains

morethan10%ethanolormorethat15%MTBE

–Failuretodrainthefuelsystempriortoanyperiodofnon-use

overonemonth

GeneralConditions

AllrepairscoveredbythesewarrantiesmustbeperformedbyanAuthorized
ToroServiceDealerusingToroapprovedreplacementparts.Repairbyan
AuthorizedToroServiceDealerisyoursoleremedyunderthiswarranty .

NeitherTheToroCompanynorToroW arrantyCompanyisliablefor
indirect,incidental,orconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythesewarranties,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletionof
repairsunderthesewarranties.

Allimpliedwarrantiesofmerchantability(thattheproductistforordinary
use)andtnessforuse(thattheproductistforaparticularpurpose)are
limitedtothedurationoftheexpresswarranty.

Somestatesdonotallowexclusionsofincidentalorconsequential
damages,orlimitationsonhowlonganimpliedwarrantylasts,sotheabove
exclusionsmaynotapplytoyou.

Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveother
rightswhichvaryfromstatetostate.

CountriesOtherthantheUnitedStatesorCanada

CustomerswhohavepurchasedT oroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirT oroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheToroimporter.Ifallotherremediesfail,youmaycontactusatToroWarrantyCompany.

AustralianConsumerLaw

AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oroDealer.

*Residentialpurposesmeansuseoftheproductonthesamelotasyourhome.Useatmorethanonelocation,orinstitutionalorrentaluse,isconsidered
commercialuse,andthecommercialusewarrantywouldapply.

374-0314RevA
