Toro 76601 Operator's Manual

FormNo.3449-597RevA

60inTITAN

ModelNo.76601—SerialNo.400000000andUp
ModelNo.76602—SerialNo.400000000andUp

®

MAXRidingMower

Registeratwww.T oro.com.
OriginalInstructions(EN)

*3449-597*

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.

GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto
theenginemanufacturer’sinformationincludedwith
themachine.

Gotowww.Toro.comtoviewspecicationsonyour
model.

Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.

itsintendedusecouldprovedangeroustoyouand
bystanders.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely .

Visitwww.Toro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.

WARNING

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Batteryposts,terminals,andrelated

accessoriescontainleadandlead

compounds,chemicalsknownto

theStateofCaliforniatocause

cancerandreproductiveharm.Wash

handsafterhandling.

Useofthisproductmaycauseexposure

tochemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Introduction

Thisrotary-blade,ridinglawnmowerisintendedtobe
usedbyhomeownersinresidentialapplications.Itis
designedprimarilyforcuttinggrassonwell-maintained
lawns.Usingthisproductforpurposesotherthan

g233854

Figure1

1.Modelandserialnumberlocation

ModelNo.

SerialNo.

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

Thesafety-alertsymbol(Figure2)appearsbothin
thismanualandonthemachinetoidentifyimportant
safetymessagesthatyoumustfollowtoavoid
accidents.Thissymbolwillappearwiththeword
Danger,Warning,orCaution.

•Dangerindicatesanimminentlyhazardous

situationwhich,ifnotavoided,willresultindeath
orseriousinjury.

©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Contactusatwww.Toro.com.

2

PrintedintheUSA

AllRightsReserved

•Warningindicatesapotentiallyhazardous

situationwhich,ifnotavoided,couldresultin
deathorseriousinjury.

•Cautionindicatesapotentiallyhazardoussituation

which,ifnotavoided,mayresultinminoror
moderateinjury.

Figure2

1.Safety-alertsymbol

Contents

Safety.......................................................................4

GeneralSafety...................................................4

SlopeIndicator...................................................5

SafetyandInstructionalDecals..........................6

ProductOverview....................................................11

Controls............................................................11

Specications..................................................13

Attachments/Accessories.................................13

BeforeOperation.................................................14

BeforeOperationSafety...................................14

AddingFuel......................................................15

PerformingDailyMaintenance..........................15

BreakinginaNewMachine..............................15

UsingtheRollover-ProtectionSystem

(ROPS).........................................................16

UsingtheSafety-InterlockSystem....................17

PositioningtheSeat..........................................18

DuringOperation.................................................18

DuringOperationSafety...................................18

EnteringtheOperator’sPosition.......................20

OperatingtheParkingBrake.............................21

OperatingtheMowerBlade-ControlSwitch

(PTO)............................................................21

OperatingtheThrottle.......................................21

OperatingtheChoke........................................22

StartingtheEngine...........................................22

ShuttingOfftheEngine.....................................23

UsingtheMotion-ControlLevers.......................23

DrivingtheMachine..........................................24

UsingtheSideDischarge.................................25

AdjustingtheHeightofCut...............................25

AdjustingtheAnti-ScalpRollers........................26

OperatingTips.................................................27

AfterOperation....................................................28

AfterOperationSafety......................................28

UsingtheFuel-ShutoffValve.............................28

UsingtheDrive-WheelReleaseValves.............29

TransportingtheMachine.................................30

Maintenance...........................................................32

MaintenanceSafety..........................................32

RecommendedMaintenanceSchedule(s)...........32

Lubrication..........................................................33

GreasingtheMachine.......................................33

EngineMaintenance...........................................34

EngineSafety...................................................34

ServicingtheAirCleaner..................................34

ServicingtheEngineOil....................................35

ServicingtheSparkPlug...................................38

FuelSystemMaintenance...................................39

sa-black

ReplacingtheIn-LineFuelFilter.......................39

ServicingtheFuelT ank.....................................39

ElectricalSystemMaintenance...........................40

ElectricalSystemSafety...................................40

ServicingtheBattery.........................................40

ServicingtheFuses..........................................41

DriveSystemMaintenance..................................42

CheckingtheSeatBelt.....................................42

AdjustingtheTracking......................................42

CheckingtheTirePressure...............................43

CheckingtheWheelLugNuts...........................43

CoolingSystemMaintenance..............................43

CleaningtheEngineScreen.............................43

BrakeMaintenance.............................................44

AdjustingtheParkingBrake..............................44

BeltMaintenance................................................45

InspectingtheBelts..........................................45

ReplacingtheMowerBelt.................................45

ReplacingtheHydraulicPump-Drive

Belt................................................................46

ControlsSystemMaintenance.............................47

AdjustingtheControl-HandlePosition..............47

AdjustingtheMotion-ControlLinkage...............48

HydraulicSystemMaintenance...........................49

HydraulicSystemSafety...................................49

HydraulicFluidSpecications...........................49

CheckingtheHydraulicFluidLevel...................50

ChangingtheHydraulicFluidand

Filters............................................................50

BleedingtheHydraulicSystem.........................52

MowerDeckMaintenance....................................52

BladeSafety.....................................................52

ServicingtheCuttingBlades.............................52

AdjustingtheSide-to-SideLevelingandthe

BladeSlope..................................................55

RemovingtheMowerDeck...............................57

InstallingtheMowerDeck.................................57

ReplacingtheGrassDeector..........................58

Cleaning..............................................................59

CleaningundertheMowerDeck.......................59

DisposingofWaste...........................................59

Storage...................................................................60

StorageSafety..................................................60

CleaningandStorage.......................................60

Troubleshooting......................................................61

Schematics.............................................................63

3

Safety

Thismachinehasbeendesignedinaccordancewith
ANSIB71.1-2017.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjuryordeath.

•Readandunderstandthecontentsofthis

Operator’sManualbeforestartingtheengine.

•Keepbystandersandchildrenaway.

•Donotallowchildrenoruntrainedpeopleto

operateorservicethemachine.Allowonlypeople
whoareresponsible,trained,familiarwiththe
instructions,andphysicallycapabletooperateor
servicethemachine.

•Alwayskeeptherollbarinthefullyraisedand

lockedpositionandusetheseatbelt.

•Donotoperatethemachineneardrop-offs,

ditches,embankments,water,orotherhazards,or
onslopesgreaterthan15°.

•Donotputyourhandsorfeetnearmoving

componentsofthemachine.

•Donotoperatethemachinewithoutallguards,

safetyswitches,andothersafetyprotective
devicesinplaceandfunctioningproperly.

•Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe
operator’sposition.Allowthemachinetocool
beforeservicing,adjusting,fueling,cleaning,or
storingit.

4

SlopeIndicator

Figure3

Youmaycopythispageforpersonaluse.

1.Themaximumslopeyoucanoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslopeof
hillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline
tomatchtherecommendedslope.

2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.

3.Exampleofhowtocompareslopewithfoldededge

5

g011841

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

Manufacturer'sMark

1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer.

BatterySymbols

Someorallofthesesymbolsareonyourbattery .

decaloemmarkt

decalbatterysymbols

1.Explosionhazard6.Keepbystandersaway

2.Nore,opename,or
smoking

3.Causticliquid/chemical
burnhazard

4.Weareyeprotection.9.Flusheyesimmediately

5.ReadtheOperator's
Manual.

fromthebattery .

7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.

8.Batteryacidcancause
blindnessorsevereburns.

withwaterandgetmedical
helpfast.

10.Containslead;donot
discard

106-5517

1.Warning—donottouchthehotsurface.

decal107-3069

107-3069

1.Warning–thereisnorolloverprotectionwhentherollbaris
down.

2.Toavoidinjuryordeathfromarolloveraccident,keepthe
rollbarintheraisedandlockedpositionandweartheseat
belt.Lowertherollbaronlywhenabsolutelynecessary;do
notweartheseatbeltwhentherollbarisdown.

3.ReadtheOperator'sManual;driveslowlyandcarefully .

decal106-5517

decal109-6014

109-6014

6

1.Tractionbeltrouting

decal115-9625

115-9625

1.Parking

2.Parkingbrake—engaged

brake—disengaged

116-5610

1.Hourmeter4.Neutral

2.Powertake-off(PTO)5.Operatorpresenceswitch

3.Parkingbrake6.Battery

decal117-1 194

117-1194

1.Beltrouting

2.Engine

decal116-5610

133-8062

decal133-8062

116-8588

1.ReadtheOperator’sManual.

2.Rotatethedrivereleaseknobtoloosen,slidetheknob,
andtighten.

3.Pushthemachine.

decal126-4363

126-4363

1.Cutting/dismembermenthazard,fanandentanglement
hazard,belt.Shutofftheengineandremovethekeybefore
adjusting,servicingorcleaningthemachine.

decal116-8588

7

decal130-0765

130-0765

1.Heightofcut

1.ReadtheOperator's
Manual.

3.Removethekeybefore
performingmaintenance.

2.Height-of-cutselection

decal126-4784

126-4784

decal132-0872

132-0872

1.Thrownobject
hazard—keepbystanders
awayfromthemachine.

2.Thrownobjecthazard,
raiseddeector—donot
operatethemachinewith
anopendeck;usea
baggeroradeector .

decal126-9939

3.Severinghazardofhand
orfoot—keepawayfrom
movingparts.

4.Entanglement
hazard—keepaway
frommovingparts;keep
allguardsandshieldsin
place.

126-9939

1.ReadtheOperator’s
Manual

1.Warning—thrownobject
hazard;keepthedeector
shieldinplace.

2.Filltobottomofllerneck;
warning–donotoverllthe
tank

130-0731

2.Cuttinghazardofhandor
foot,mowerblade—keep
awayfrommovingparts.

decalptosymbols

PTOSwitchSymbols

decal130-0731

1.PTO–disengage2.PTO–engage

8

TransportLock

Decal137-9240isformachinesnotequippedwith
theoptionalworklights.

decaltransportlock

1.Heightofcut

126-6194

1.Tractioncontrol4.Neutral

2.Fast5.Reverse

3.Slow

2.Pulluptounlockthe
transportlock.

decal137-9240

137-9240

1.Choke

2.Worklight

3.Fast

4.Slow

Decal145-4618isformachinesequippedwithwork
lights.

decal126-6194

decal145-4618

145-4618

1.Choke

2.Worklight

3.Fast

4.Slow

9

decal126-6183

126-6183

1.Tractioncontrol4.Neutral

2.Fast5.Reverse

3.Slow

126-8383

Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum

recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas
wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineintheconditionson
thatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.

decal126-8383

1.Warning—readtheOperator’sManual;donotoperatethis
machineunlessyouaretrained;wearhearingprotection.

2.Cutting/dismembermenthazardofthehand,mowerblade;
entanglementhazardofthehand,belt—stayawayfrom
movingparts;keepallguardsandshieldsinplace.

3.Ramphazard—donotusedualrampswhenloadingontoa
trailer;use1rampwideenoughforthemachine;usearamp
withaslopelessthan15°;backuptherampwhenloadingthe
machineanddriveforwardofftherampwhenunloading.

4.Runover/backoverhazard—donotcarrypassengers;look
behindyouwhenmowinginreverse.

5.Thrownobjecthazard—keepbystandersaway .

6.Tippinghazard—donotusethemachineneardrop-offsor
onslopesgreaterthan15°;onlyoperateacrossslopesless
than15°.

10

ProductOverview

Controls

Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.

ControlPanel

g368671

Figure5

Figure4

1.Height-of-cutdeck-lift
pedal

2.Height-of-cutpositions

3.Transportlock9.Parking-brakelever

4.Controls

5.Motion-controllevers

6.Rollbar

7.Worklights(standardon
Model76602;optionalkit
onModel76601)

8.Fuelcap

10.Mowerdeck

11.Casterwheel

1.Keyswitch

2.Blade-controlswitch
(powertakeoff)

g368672

3.Hourmeter

4.Throttlecontrol

5.Chokecontrol

6.Lightswitch(standardon
Model76602;optionalkit
onModel76601)

7.Positionforoptionalpower
point

KeySwitch

Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andST ART.Referto

StartingtheEngine(page22).

ChokeControl

Usethechokecontroltostartacoldengine.

ThrottleControl

Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure5).

Blade-ControlSwitch(Power
Takeoff)

Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure5).

11

LightSwitch

Motion-ControlLevers

ApplicableModelsOnly

Pressthelightswitchforwardtoturnonthework
lights(Figure5).

Pressthelightswitchrearwardtoturnoffthework
lights.

HourMeter

Thehourmeterrecordsthenumberofhoursthe
enginehasoperated.Itoperateswhentheengine
isrunning.Usethesetimesforschedulingregular
maintenance(Figure6).

Usethemotion-controlleverstodrivethemachine
forward,reverse,andturneitherdirection(Figure4).

Neutral-LockPosition

Movethemotion-controlleversoutwardfromthe
centertotheNEUTRAL-LOCKpositionwhenexiting
themachine(Figure23).Alwayspositionthe
motion-controlleversintotheNEUTRAL-LOCKposition
whenyoustopthemachineorleaveitunattended.

Parking-BrakeLever

Wheneveryoushutofftheengine,engagetheparking
braketopreventaccidentalmovementofthemachine.

Fuel-ShutoffValve

Closethefuel-shutoffvalvewhentransportingor
storingthemachine;refertoUsingtheFuel-Shutoff

Valve(page28).

Figure6

1.Safety-interlocksymbols

2.Hourmeter

3.Batterylight

Safety-InterlockIndicators

Therearesymbolsonthehourmeterthatindicate
withablacktrianglethattheinterlockcomponentis
positionedcorrectly(Figure6).

Battery-IndicatorLight

IfyouturnthekeyswitchtotheONpositionfora
fewseconds,thebatteryvoltagedisplaysinthearea
wherethehoursarenormallydisplayed.

Thebatterylightturnsonwhenthekeyswitchis
turnedonandwhenthechargeisbelowthecorrect
operatinglevel(Figure6).

g187133

12

Specications

Note:Specicationsanddesignaresubjectto

changewithoutnotice.

Width

Withoutmowerdeck

Deectorup160cm(63-1/8inches)

Deectordown191cm(75-5/16inches)

134cm(52-13/16inches)

Length

Length

209cm(82-3/16inches)

Height

RollBar—Up

RollBar—Down

180cm(70-11/16inches)

116cm(45-3/4inches)

Weight

Weight

397kg(876lb)

Attachments/Accessories

AselectionofT oroapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedT oro
distributororgotowww.Toro.comforalistofall
approvedattachmentsandaccessories.

Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.

13

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

BeforeOperationSafety

GeneralSafety

•Donotallowchildrenoruntrainedpeopleto

operateorservicethemachine.Localregulations
mayrestricttheageoftheoperator.Theowner
isresponsiblefortrainingalloperatorsand
mechanics.

•Inspecttheareawhereyouwillusethemachine,

andremoveallobjectsthatcouldinterferewith
theoperationofthemachineorthatthemachine
couldthrow.

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Checkthatoperator-presencecontrols,safety

switches,andguardsareattachedandworking
properly.Donotoperatethemachineunlessthey
arefunctioningproperly.

•Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe
operator’sposition.Allowthemachinetocool
beforeservicing,adjusting,fueling,cleaning,or
storingit.

•Beforemowing,inspectthemachinetoensure

thatthecuttingassembliesareworkingproperly .

•Evaluatetheterraintodeterminetheappropriate

equipmentandanyattachmentsoraccessories
requiredtooperatethemachineproperlyand
safely.

•Wearappropriateclothing,includingeye

protection;longpants;substantial,slip-resistant
footwear;andhearingprotection.Tiebacklong
hairanddonotwearlooseclothingorloose
jewelry.

•Donotcarrypassengersonthemachine.

•Keepbystandersandpetsawayfromthemachine

duringoperation.Shutoffthemachineand
attachment(s)ifanyoneentersthearea.

•Donotoperatethemachineunlessallguardsand

safetydevices,suchasthedeectorsandthe
entiregrasscatcher,areinplaceandfunctioning
properly.Replacewornordeterioratedpartswhen
necessary.

FuelSafety

•Fuelisextremelyammableandhighlyexplosive.

Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.

–Topreventastaticchargefromignitingthe

fuel,removethemachinefromthetruckor
trailerandrefuelitontheground,awayfrom
allvehicles.Ifthisisnotpossible,placea
portablefuelcontainerontheground,away
fromallvehicles,andllit;thenrefuelthe
machinefromthefuelcontainerratherthan
fromafuel-dispensernozzle.

–Fillthefueltankoutdoorsonlevelground,in

anopenarea,andwhentheengineiscold.
Wipeupanyfuelthatspills.

–Donothandlefuelwhensmokingoraroundan

openameorsparks.

–Donotremovethefuelcaporaddfueltothe

tankwhiletheengineisrunningorhot.

–Ifyouspillfuel,donotattempttostartthe

engine.Avoidcreatingasourceofignitionuntil
thefuelvaporshavedissipated.

–Storefuelinanapprovedcontainerandkeep

itoutofthereachofchildren.

•Fuelisharmfulorfatalifswallowed.Long-term

exposuretovaporscancauseseriousinjuryand
illness.

–Avoidprolongedbreathingofvapors.

–Keepyourhandsandfaceawayfromthe

nozzleandthefuel-tankopening.

–Keepfuelawayfromyoureyesandskin.

•Donotstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

•Donotoperatethemachinewithouttheentire

exhaustsysteminplaceandinproperworking
condition.

•Keepthefuel-dispensernozzleincontactwith

therimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.Donotusea
nozzlelock-opendevice.

•Ifyouspillfuelonyourclothing,changeyour

clothingimmediately.

•Donotoverllthefueltank.Replacethefuelcap

andtightenitsecurely.

•Cleangrassanddebrisfromthecuttingunit,

mufer,drives,grasscatcher,andengine
compartmenttohelppreventres.Cleanupoilor
fuelspills.

14

AddingFuel

RecommendedFuel

TypeUnleadedgasoline

Minimumoctanerating

Ethanol

MethanolNone

MTBE(methyltertiarybutyl
ether)

OilDonotaddtothefuel

Useonlyclean,fresh(nomorethan30daysold),fuel
fromareputablesource.

UsingStabilizer/Conditioner

Usefuelstabilizer/conditionerinthemachinetokeep
thefuelfreshlongerwhenusedasdirectedbythe
fuel-stabilizermanufacturer.

Important:Donotusefueladditivescontaining

methanolorethanol.

87(US)or91(research
octane;outsidetheUS)

Nomorethan10%byvolume

Lessthan15%byvolume

Addtheamountoffuelstabilizer/conditionertofresh
fuelasdirectedbythefuel-stabilizermanufacturer.

FillingtheFuelTank

1.Parkthemachineonalevelsurface.

2.Movethemotion-controlleversoutwardtothe
PARKposition.

3.Shutofftheengineandremovethekey.

4.Cleanaroundthefuel-tankcap.

5.Fillthefueltanktothebottomofthellerneck
(Figure7).Donotllthefueltankcompletelyfull

g036751

Figure7

PerformingDaily
Maintenance

Beforestartingthemachineeachday ,performthe
EachUse/DailyprocedureslistedinMaintenance

(page32).

BreakinginaNewMachine

Newenginestaketimetodevelopfullpower.Mower
decksanddrivesystemshavehigherfrictionwhen
new,placingadditionalloadontheengine.Allow
40to50hoursofbreak-intimefornewmachinesto
developfullpowerandbestperformance.

15

Usingthe
Rollover-ProtectionSystem
(ROPS)

WARNING

Toavoidinjuryordeathfromrollover,keep
therollbarinthefullyraised,lockedposition
andusetheseatbelt.

Ensurethattheseatissecuredtothe
machine.

g004954

Figure8

WARNING

Thereisnorolloverprotectionwhentheroll
barisinthedownposition.

•Lowertherollbaronlywhenabsolutely
necessary.

•Donotweartheseatbeltwhentherollbar
isinthedownposition.

•Driveslowlyandcarefully.

•Raisetherollbarassoonasclearance
permits.

•Checkcarefullyforoverheadclearances
(i.e.,branches,doorways,electricalwires)
beforedrivingunderanyobjectsanddo
notcontactthem.

LoweringtheRollBar

Important:Lowertherollbaronlywhen

absolutelynecessary.

1.Full-downposition2.Downpositionwiththe
baggerinstalled

Important:Ensurethatyousecuretherear

partoftheseatwiththeseatlatch.

RaisingtheRollBar

Important:Alwaysusetheseatbeltwiththeroll

barintheraisedposition.

1.Removethehairpincottersandremovethe2

pins(Figure9).

2.Raisetherollbartotheuprightposition,install

the2pins,andsecurethemwiththehairpin
cotters(Figure9).

1.Removethehairpincottersandremovethe2
pins(Figure9).

2.Lowertherollbartothedownposition(Figure

8).

Note:Thereare2downpositions;referto

Figure8.

3.Installthe2pinsandsecurethemwiththe
hairpincotters(Figure9).

g004955

Figure9

1.Rollbar3.Pin

2.Raisedposition4.Hairpincotter

16

UsingtheSafety-Interlock
System

Testthesafety-interlocksystembeforeyouusethe
machineeachtime.Ifthesafetysystemdoesnot
operateasdescribedbelow,haveanAuthorized
ServiceDealerrepairthesafetysystemimmediately .

WARNING

Ifthesafety-interlockswitchesare
disconnectedordamaged,themachinecould
operateunexpectedly,causingpersonal
injury.

•Donottamperwiththeinterlockswitches.

•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.

Understandingthe
Safety-InterlockSystem

Thesafety-interlocksystemisdesignedtopreventthe
enginefromstartingunlessthefollowingoccurs:

•Theparkingbrakeisengaged.

•Theblade-controlswitch(PTO)isdisengaged.

•Themotion-controlleversareintheNEUTRAL-LOCK

position.

Thesafety-interlocksystemalsoisdesignedtoshut
offtheenginewhenthemotion-controlleversare
movedfromtheNEUTRAL-LOCKpositionwiththe
parkingbrakeengagedorifyourisefromtheseat
whenthePTOisengaged.

Thehourmeterhasindicatorstonotifytheuserwhen
theinterlockcomponentisinthecorrectposition.
Whenthecomponentisinthecorrectposition,an
indicatordisplaysonthescreen.

1.Sitontheseat,engagetheparkingbrake,and
movetheblade-controlswitch(PTO)totheON
position.Trystartingtheengine;theengine
shouldnotstart.

2.Sitontheseat,engagetheparkingbrake,and
movetheblade-controlswitch(PTO)totheOFF
position.Moveeithermotion-controlleverout
oftheNEUTRAL-LOCKposition.Trystartingthe
engine;theengineshouldnotstart.Repeatfor
theothercontrollever.

3.Sitontheseat,engagetheparkingbrake,
movetheblade-controlswitch(PTO)totheOFF
position,andmovethemotion-controllevers
totheNEUTRAL-LOCKposition.Nowstartthe
engine.Whiletheengineisrunning,disengage
theparkingbrake,engagetheblade-control
switch(PTO),andriseslightlyfromtheseat;the
engineshouldshutoff.

4.Sitontheseat,engagetheparkingbrake,
movetheblade-controlswitch(PTO)totheOFF
position,andmovethemotion-controllevers
totheNEUTRAL-LOCKposition.Nowstartthe
engine.Whiletheengineisrunning,center
eithermotioncontrolandmove(forwardor
reverse);theengineshouldshutoff.Repeatfor
othermotioncontrol.

5.Sitontheseat,disengagetheparkingbrake,
movetheblade-controlswitch(PTO)totheOFF
position,andmovethemotion-controllevers
totheNEUTRAL-LOCKposition.Trystartingthe
engine;theengineshouldnotstart.

Figure10

1.Indicatorsdisplaywhentheinterlockcomponentsareinthe
correctposition

TestingtheSafety-Interlock
System

ServiceInterval:Beforeeachuseordaily

g187670

17

PositioningtheSeat

Theseatcanmoveforwardandbackward.Position
theseatwhereyouhavethebestcontrolofthe
machineandaremostcomfortable(Figure11).

Figure11

DuringOperation

DuringOperationSafety

GeneralSafety

•Theowner/operatorcanpreventandisresponsible

foraccidentsthatmaycausepersonalinjuryor
propertydamage.

•Useyourfullattentionwhileoperatingthe

machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Donotmowinreverseunlessitisabsolutely

necessary.Alwayslookdownandbehindyou
beforemovingthemachineinreverse.

•Useextremecarewhenapproachingblind

corners,shrubs,trees,orotherobjectsthatmay
blockyourview.

•Stopthebladeswheneveryouarenotmowing.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey
(ifequipped),andwaitforallmovingpartstostop
beforeexaminingthemachinefordamage.Make
allnecessaryrepairsbeforeresumingoperation.

•Slowdownandusecautionwhenmakingturns

andcrossingroadsandsidewalkswiththe
machine.Alwaysyieldtheright-of-way.

•Beforeyouleavetheoperatingposition,dothe

following:

–Parkthemachineonalevelsurface.
–Disengagethepowertakeoffandlowerthe

g027632

attachments.
–Engagetheparkingbrake.
–Shutofftheengineandremovethekey.
–Waitforallmovingpartstostop.

•Operatetheengineonlyinwell-ventilatedareas.

Exhaustgasescontaincarbonmonoxide,which
islethalifinhaled.

•Neverleavearunningmachineunattended.

•Attachtowedequipmenttothemachineonlyat

thehitchpoint.

•Donotoperatethemachineunlessallguards

andsafetydevices,suchasthedeectors,arein
placeandfunctioningproperly.Replacewornor
deterioratedpartswhennecessary.

•Useonlyaccessoriesandattachmentsapproved

byToro.

•Thismachineproducessoundlevelsinexcess

of85dBAattheoperator’searandcancause
hearinglossthroughextendedperiodsof
exposure.

•Contactingthebladecanresultinseriouspersonal

injury.Shutofftheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.Whenyouturnthekeytothe
OFFposition,theengineshouldshutoffandthe
bladeshouldstop.Ifnot,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.

•Operatethemachineonlyingoodvisibilityand

appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflightning.

•Keepyourhandsandfeetawayfromthecutting

units.Keepclearofthedischargeopening.

g229846

Figure12

1.Wearhearingprotection.

•Cleangrassanddebrisfromthecuttingunit,

drives,mufer,andenginetohelppreventres.

•Starttheenginewithyourfeetwellawayfromthe

blades.

18

•Beawareofthemowerdischargepathanddirect

thedischargeawayfromothers.Avoiddischarging
materialagainstawallorobstructionbecausethe
materialmayricochetbacktowardyou.

distance(twicethewidthofthemachine)between
themachineandanyhazard.Useawalk-behind
machineorahandtrimmertomowthegrassin
theseareas.

•Stoptheblades,slowdownthemachine,anduse

cautionwhencrossingsurfacesotherthangrass
orwhentransportingthemachinetoandfromthe
operatingarea.

•Donotchangetheenginegovernorspeedor

overspeedtheengine.

•Childrenareoftenattractedtothemachineand

themowingactivity.Neverassumethatchildren
willremainwhereyoulastsawthem.

•Keepchildrenoutoftheoperatingareaandunder

thewatchfulcareofaresponsibleadultotherthan
theoperator.

•Bealertandshutoffthemachineifchildrenenter

theoperatingarea.

•Beforebackinguporturningthemachine,look

downandallaroundforsmallchildren.

•Donotcarrychildrenonthemachine,evenwhen

thebladesarenotmoving.Childrencouldfall
offandbeseriouslyinjuredorpreventyoufrom
safelyoperatingthemachine.Childrenwhohave
beengivenridesinthepastcouldappearinthe
operatingareawithoutwarningandberunoveror
backedoverbythemachine.

•Avoidstarting,stopping,orturningthemachineon

slopes.Avoidmakingsuddenchangesinspeedor
direction;turnslowlyandgradually.

•Donotoperateamachineunderanyconditions

wheretraction,steering,orstabilityisinquestion.
Beawarethatoperatingthemachineonwet
grass,acrossslopes,ordownhillmaycausethe
machinetolosetraction.Lossoftractiontothe
drivewheelsmayresultinslidingandalossof
brakingandsteering.Themachinecanslideeven
ifthedrivewheelsarestopped.

•Removeormarkobstaclessuchasditches,holes,

ruts,bumps,rocks,orotherhiddenhazards.T all
grasscanhideobstacles.Uneventerraincould
overturnthemachine.

•Useextracarewhileoperatingwithaccessoriesor

attachments,suchasgrass-collectionsystems.
Thesecanchangethestabilityofthemachine
andcausealossofcontrol.Followdirectionsfor
counterweights.

•Ifpossible,keepthedeckloweredtotheground

whileoperatingonslopes.Raisingthedeckwhile
operatingonslopescancausethemachineto
becomeunstable.

SlopeSafety

•Slopesareamajorfactorrelatedtolossofcontrol

androlloveraccidents,whichcanresultinsevere
injuryordeath.Theoperatorisresponsiblefor
safeslopeoperation.Operatingthemachineon
anysloperequiresextracaution.Beforeusingthe
machineonaslope,dothefollowing:

–Reviewandunderstandtheslopeinstructions

inthemanualandonthemachine.

–Useanangleindicatortodeterminethe

approximateslopeangleofthearea.

–Neveroperateonslopesgreaterthan15°.

–Evaluatethesiteconditionsofthedayto

determineiftheslopeissafeformachine
operation.Usecommonsenseandgood
judgmentwhenperformingthisevaluation.
Changesintheterrain,suchasmoisture,can
quicklyaffecttheoperationofthemachineon
aslope.

•Identifyhazardsatthebaseoftheslope.Do

notoperatethemachineneardrop-offs,ditches,
embankments,water,orotherhazards.The
machinecouldsuddenlyrolloverifawheelgoes
overtheedgeortheedgecollapses.Keepasafe

1.SafeZone—usethe
machinehereonslopes
lessthan15°oratareas.

2.DangerZone—usea
walk-behindmowerand/or
ahandtrimmeronslopes
greaterthan15°andnear
drop-offsorwater.

3.Water

g221745

Figure13

4.W=Widthofthemachine

5.Keepasafedistance
(twicethewidthofthe
machine)betweenthe
machineandanyhazard.

19

RolloverProtectionSystem
(ROPS)Safety

•TheROPSisanintegralsafetydevice.Donot

removeanyoftheROPScomponentsfromthe
machine.

•Ensurethattheseatbeltisattachedandthatyou

canreleaseitquicklyinanemergency.

•Keeptherollbarinthefullyraisedandlocked

positionandalwayswearyourseatbeltwhenever
therollbarisup.

•Checkcarefullyforoverheadobjectsbeforeyou

driveunderthem,anddonotcontactthem.

•ReplacedamagedROPScomponents.Donot

repairoralterthem.

•Thereisnorolloverprotectionwhentherollbar

isdown.

EnteringtheOperator’s
Position

Usethemowerdeckasasteptogetintothe
operator’sposition(Figure14).

•Wheelsdroppingoveredges,oversteepbanks,or

intowatercancausearollover,whichmayresult
inseriousinjuryordeath.

•Donotweartheseatbeltwhentherollbarisdown.

•Lowertherollbaronlywhenabsolutelynecessary;

raiseitassoonasclearancepermits.

•Intheeventofarollover,takethemachinetoan

AuthorizedServiceDealertoinspecttheROPS.

•UseonlyToroapprovedaccessoriesand

attachmentsfortheROPS.

g029797

Figure14

1.Stephere.

20
