Toro 75747 Operator's Manual

FormNo.3448-905RevB

TimeCutter

MyRIDE42in,50in,

and54inRidingMower

ModelNo.75747—SerialNo.400000000andUp ModelNo.75747TA—SerialNo.400000000andUp ModelNo.75747W—SerialNo.400000000andUp ModelNo.75756—SerialNo.400000000andUp ModelNo.75758TA—SerialNo.400000000andUp ModelNo.75761TA—SerialNo.400000000andUp

Registeratwww.T oro.com. OriginalInstructions(EN)

*3448-905*

ItisaviolationofCaliforniaPublicResourceCode Section4442or4443touseoroperatetheengineon anyforest-covered,brush-covered,orgrass-covered landunlesstheengineisequippedwithaspark arrester,asdenedinSection4442,maintainedin effectiveworkingorderortheengineisconstructed, equipped,andmaintainedforthepreventionofre.

GrossorNetTorque:Thegrossornettorque ofthisenginewaslaboratoryratedbytheengine manufacturerinaccordancewiththeSocietyof AutomotiveEngineers(SAE)J1940orJ2723.As conguredtomeetsafety,emission,andoperating requirements,theactualenginetorqueonthisclass ofmowerwillbesignicantlylower.Pleasereferto theenginemanufacturer’sinformationincludedwith themachine.

Gotowww.Toro.comtoviewspecicationsonyour model.

Theenclosedengineowner'smanualissupplied forinformationregardingtheUSEnvironmental ProtectionAgency(EPA)andtheCaliforniaEmission ControlRegulationofemissionsystems,maintenance, andwarranty.Replacementsmaybeorderedthrough theenginemanufacturer.

itsintendedusecouldprovedangeroustoyouand bystanders.

Readthisinformationcarefullytolearnhowtooperate andmaintainyourproductproperlyandtoavoid injuryandproductdamage.Youareresponsiblefor operatingtheproductproperlyandsafely .

Visitwww.T oro.comforproductsafetyandoperation trainingmaterials,accessoryinformation,helpnding adealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or additionalinformation,contactanAuthorizedService DealerorToroCustomerServiceandhavethemodel andserialnumbersofyourproductready.Figure1 identiesthelocationofthemodelandserialnumbers ontheproduct.Writethenumbersinthespace provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if equipped)toaccesswarranty,parts,andother productinformation.

WARNING

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Batteryposts,terminals,andrelated

accessoriescontainleadandlead

compounds,chemicalsknownto

theStateofCaliforniatocause

cancerandreproductiveharm.Wash

handsafterhandling.

Useofthisproductmaycauseexposure

tochemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

g297763

Figure1

Undertheseat

1.Modelandserialnumberlocation

Writetheproductmodelandserialnumbersinthe spacebelow:

ModelNo.

SerialNo.

Introduction

Thisrotary-blade,ridinglawnmowerisintendedtobe usedbyhomeownersinresidentialapplications.Itis designedprimarilyforcuttinggrassonwell-maintained lawns.Usingthisproductforpurposesotherthan

Thismanualuses2wordstohighlightinformation. Importantcallsattentiontospecialmechanical informationandNoteemphasizesgeneralinformation worthyofspecialattention.

Thesafety-alertsymbol(Figure2)appearsbothin thismanualandonthemachinetoidentifyimportant safetymessagesthatyoumustfollowtoavoid

Contactusatwww.Toro.com.

PrintedintheUSA

AllRightsReserved

accidents.Thissymbolwillappearwiththeword Danger,Warning,orCaution.

•Dangerindicatesanimminentlyhazardous

situationwhich,ifnotavoided,willresultindeath orseriousinjury.

•Warningindicatesapotentiallyhazardous

situationwhich,ifnotavoided,couldresultin deathorseriousinjury.

•Cautionindicatesapotentiallyhazardoussituation

which,ifnotavoided,mayresultinminoror moderateinjury.

Figure2

1.Safety-alertsymbol

Contents

Safety.......................................................................4

GeneralSafety...................................................4

SlopeIndicator...................................................5

SafetyandInstructionalDecals..........................6

ProductOverview....................................................11

Controls...........................................................12

BeforeOperation.................................................13

BeforeOperationSafety...................................13

AddingFuel......................................................14

PerformingDailyMaintenance..........................15

BreakinginaNewMachine..............................15

UsingtheSafety-InterlockSystem....................15

PositioningtheSeat..........................................16

AdjustingtheMyRide®Suspension

System..........................................................16

AdjustingtheMotion-ControlLevers.................16

DuringOperation.................................................17

DuringOperationSafety...................................17

OperatingtheMowerBlade-ControlSwitch

(PTO)............................................................19

OperatingtheThrottle.......................................20

OperatingtheChoke.........................................20

StartingtheEngine...........................................20

ShuttingOfftheEngine.....................................21

UsingtheMotion-ControlLevers.......................21

DrivingtheMachine..........................................21

UsingtheSmartSpeed

System..........................................................22

UsingtheSideDischarge.................................23

AdjustingtheHeightofCut...............................23

AdjustingtheAnti-ScalpRollers........................24

OperatingTips.................................................25

AfterOperation....................................................26

AfterOperationSafety......................................26

Control

CleaningtheMachine.......................................26

PushingtheMachinebyHand..........................26

TransportingtheMachine.................................27

Maintenance...........................................................29

MaintenanceSafety..........................................29

RecommendedMaintenanceSchedule(s)...........30

Pre-MaintenanceProcedures..............................30

RaisingtheMachine.........................................30

Lubrication..........................................................31

GreasingtheBearings......................................31

EngineMaintenance...........................................32

EngineSafety...................................................32

ServicingtheAirCleaner..................................32

ServicingtheEngineOil....................................33

ServicingtheSparkPlug...................................35

sa-black

CleaningtheBlowerHousing............................36

FuelSystemMaintenance...................................36

ReplacingtheIn-LineFuelFilter.......................36

ElectricalSystemMaintenance...........................37

ElectricalSystemSafety...................................37

ServicingtheBattery.........................................37

ServicingtheFuses..........................................39

DriveSystemMaintenance..................................39

CheckingtheTirePressure...............................39

ReleasingtheElectricBrake.............................40

AdjustingtheTracking......................................40

BeltMaintenance................................................41

InspectingtheBelts..........................................41

ReplacingtheMowerBelt.................................41

MowerMaintenance.............................................42

BladeSafety.....................................................42

ServicingtheCuttingBlades.............................42

LevelingtheMowerDeck..................................45

RemovingtheMowerDeck...............................48

InstallingtheMowerDeck.................................48

ReplacingtheGrassDeector..........................49

Cleaning..............................................................50

WashingtheUndersideoftheMower

Deck..............................................................50

DisposingofWaste...........................................50

Storage...................................................................51

StorageSafety..................................................51

CleaningandStorage.......................................51

StoringtheBattery............................................52

Troubleshooting......................................................53

Schematics.............................................................55

Safety

Thismachinehasbeendesignedinaccordancewith ANSIB71.1-2017.

GeneralSafety

Thisproductiscapableofamputatinghandsand feetandofthrowingobjects.Alwaysfollowallsafety instructionstoavoidseriouspersonalinjuryordeath.

•Readandunderstandthecontentsofthis

Operator’sManualbeforestartingtheengine.

•Keepbystandersandchildrenaway.

•Donotallowchildrenoruntrainedpeopleto

operateorservicethemachine.Allowonlypeople whoareresponsible,trained,familiarwiththe instructions,andphysicallycapabletooperateor servicethemachine.

•Donotoperatethemachineneardrop-offs,

ditches,embankments,water,orotherhazards,or onslopesgreaterthan15°.

•Donotputyourhandsorfeetnearmoving

componentsofthemachine.

•Donotoperatethemachinewithoutallguards,

safetyswitches,andothersafetyprotective devicesinplaceandfunctioningproperly.

•Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe operator’sposition.Allowthemachinetocool beforeservicing,adjusting,fueling,cleaning,or storingit.

SlopeIndicator

Figure3

Youmaycopythispageforpersonaluse.

1.Themaximumslopeyoucanoperatethemachineonis15degrees.Usetheslopecharttodeterminethedegreeofslopeof hillsbeforeoperating.Donotoperatethismachineonaslopegreaterthan15degrees.Foldalongtheappropriateline tomatchtherecommendedslope.

2.Alignthisedgewithaverticalsurface,atree,building,fencepole,etc.

3.Exampleofhowtocompareslopewithfoldededge

g011841

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

BatterySymbols

Someorallofthesesymbolsareonyourbattery .

Decal99-3943isformodelswith127cm(50inch)or 137cm(54inch)decksonly .

decalbatterysymbols

1.Explosionhazard6.Keepbystandersaway

2.Nore,opename,or smoking

3.Causticliquid/chemical burnhazard

4.Weareyeprotection.9.Flusheyesimmediately

5.ReadtheOperator's Manual.

fromthebattery .

7.Weareyeprotection; explosivegasescan causeblindnessandother injuries.

8.Batteryacidcancause blindnessorsevereburns.

withwaterandgetmedical helpfast.

10.Containslead;donot discard

Manufacturer'sMark

1.Thismarkindicatesthatthebladeisidentiedasapart fromtheoriginalmachinemanufacturer.

decal99-3943

99-3943

1.Beltrouting

2.Engine

Decal105-7015isformodelswith107cm(42inch) decksonly.

decaloemmarkt

93-7009

1.Warning—donotoperatethemowerwiththedeectorup orremoved;keepthedeectorinplace.

2.Cutting/dismembermenthazardofhandorfoot,mower blade—stayawayfrommovingparts.

decal93-7009

decal105-7015

105-7015

1.Beltrouting

Decal1 12-9840isformodelswith127cm(50inch)or 137cm(54inch)decksonly .

decal132-0872

132-0872

1.ReadtheOperator's Manual.

2.Heightofcut

112-9840

3.Removetheignitionkey andreadtheinstructions beforeservicingor performingmaintenance.

1.Thrownobject hazard—keepbystanders

decal112-9840

awayfromthemachine.

2.Thrownobjecthazard, raiseddeector—donot operatethemachinewith anopendeck;usea baggeroradeector .

3.Severinghazardofhand orfoot—keepawayfrom movingparts.

4.Entanglement hazard—keepaway frommovingparts;keep allguardsandshieldsin place.

Decal138-6074ismoldedintothefueltank.

decal138-2456

138-6074

1.ReadtheOperator’s Manual.

2.Parkthemachineona levelsurfacewhenlling thefueltank.

3.Donotoverllthefuel tank.

1.Bypassleverpositionfor pushingthemachine

decal121-2989b

121-2989

2.Bypassleverpositionfor operatingthemachine

decal139-2388

139-2388

1.Slow

3.Fast

2.Hauling

Decal139-2391isformodelswithoutanhourmeter.

decal139-2391

139-2391

1.Fast

2.Slow

139-2392

139-2394

1.Tractioncontrols4.Neutral

2.Fast5.Reverse

3.Slow

decal139-2392

decal139-2394

6.Parkingbrake

139-2395

1.Parkingbrake4.Neutral

2.Fast5.Reverse

3.Slow

6.Tractioncontrols

139-2397

Decal140-2717isformodelswithanhourmeter.

decal139-2395

decal139-2397

decal140-2717

140-2717

1.Fast

2.Slow

decal142-5864

142-5864

132-0869

Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum

recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineintheconditionson thatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.

decal132-0869

1.Warning—readthe Operator'sManual.

2.Warning—readthe Operator'sManualbefore performingmaintenance; engagetheparkingbrake, removethekey ,and disconnectthesparkplug.

3.Cutting/dismemberment hazardofthehand,mower blade;entanglement hazardofthehand, belt—stayawayfrom movingparts;keepall guardsandshieldsinplace.

4.Thrownobject hazard—keepbystanders away;pickupdebris beforeoperating;keepthe deectorinplace.

5.Tippinghazard—donot usedualrampswhen loadingontoatrailer;use 1rampwideenoughfor themachine;usearamp withaslopelessthan15°; backuptherampwhen loadingthemachineand driveforwardofftheramp whenunloading.

6.Runoverhazard—donot carrypassengers;look behindyouwhenmowing inreverse.

7.Tippinghazard—donotuse themachineneardrop-offs oronslopesgreaterthan 15°;onlyoperateacross slopeslessthan15°.

ProductOverview

1.Engine4.Motion-controllevers

2.Operatorseat

3.Fuel-tankcap

5.Frontcasterwheel

6.Deck-liftpedal(certain modelsonly)

Figure4

7.SmartSpeed™lever

8.Height-of-cutlever11.Controlpanel

9.Deector

g367815

10.Reardrivewheel

12.MyRide™adjustmentlever

Controls

Motion-ControlLevers

Becomefamiliarwithallthecontrolsbeforeyoustart theengineandoperatethemachine.

ControlPanel

Figure5

1.Throttlecontrol4.Keyswitch

2.Chokecontrol5.Hourmeter(ifequipped)

3.Blade-controlswitch (powertakeoff)

Usethemotion-controlleverstodrivethemachine forward,reverse,andturneitherdirection(Figure4).

ParkPosition

Movethemotion-controlleversoutwardfromthe centertothePARKpositionwhenexitingthemachine toengagetheelectricbrake(Figure20).Always positionthemotion-controlleversintothePARK positionwhenyoustopthemachineorleaveit unattended.

MyRide®AdjustmentLever

UsetheMyRide®adjustmentlevertoadjusttheseat suspension(Figure4).

g368287

SmartSpeed™ControlSystem Lever

TheSmartSpeed™Control-Systemlever,located belowtheoperatingposition,givesyouachoiceto drivethemachineat3speedranges—trim,tow,and mow(Figure4).

KeySwitch

Thekeyswitch,usedtostartandshutofftheengine, has3positions:OFF,RUN,andSTART(Figure5).

ThrottleControl

Thethrottlecontrolstheenginespeed,andithasa continuous-variablesettingfromtheSLOWtoFAST position(Figure5).

ChokeControl

Usethechokecontroltostartacoldengine(Figure5).

Blade-ControlSwitch(Power Takeoff)

Theblade-controlswitch,representedbya power-takeoff(PTO)symbol,engagesand disengagespowertothemowerblades(Figure5).

HourMeter(IfEquipped)

Fuel-PresenceWindow

Youcanusethefuelwindow,locatedontheleftside ofthemachine,toverifythepresenceoffuelinthe tank(Figure6).

g292100

Figure6

1.Fuel-presencewindow

Thehourmeterrecordsthenumberofhoursthe enginehasoperated.Itoperateswhentheengine isrunning.Usethesetimesforschedulingregular maintenance(Figure5).

Height-of-CutLever

Usetheheight-of-cutlevertolowerandraisethedeck fromtheseatedposition.Movingtheleverup(toward you)raisesthedeckfromthegroundandmovingthe leverdown(awayfromyou)lowersthedecktoward theground.Adjusttheheight-of-cutonlywhilethe machineisnotmoving(Figure4).

Operation

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

FootPedalDeck-LiftSystem

CertainModelsOnly

Thefootpedaldeck-liftsystemallowsyoutolowerand raisethedeckfromtheseatedposition.Youcanuse thefootpedaltoliftthedeckbrieytoavoidobstacles orassistinadjustingtheheightofcut(Figure4).

Attachments/Accessories

AselectionofT oroapprovedattachmentsand accessoriesisavailableforusewiththemachine toenhanceandexpanditscapabilities.Contact yourAuthorizedServiceDealerorauthorizedT oro distributororgotowww.Toro.comforalistofall approvedattachmentsandaccessories.

Toensureoptimumperformanceandcontinuedsafety certicationofthemachine,useonlygenuineT oro replacementpartsandaccessories.Replacement partsandaccessoriesmadebyothermanufacturers couldbedangerous,andsuchusecouldvoidthe productwarranty.

BeforeOperationSafety

GeneralSafety

•Donotallowchildrenoruntrainedpeopleto

operateorservicethemachine.Localregulations mayrestricttheageoftheoperator.Theowner isresponsiblefortrainingalloperatorsand mechanics.

•Inspecttheareawhereyouwillusethemachine,

andremoveallobjectsthatcouldinterferewith theoperationofthemachineorthatthemachine couldthrow.

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Checkthatoperator-presencecontrols,safety

switches,andguardsareattachedandworking properly.Donotoperatethemachineunlessthey arefunctioningproperly.

•Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe operator’sposition.Allowthemachinetocool beforeservicing,adjusting,fueling,cleaning,or storingit.

•Beforemowing,inspectthemachinetoensure

thatthecuttingassembliesareworkingproperly .

•Evaluatetheterraintodeterminetheappropriate

equipmentandanyattachmentsoraccessories requiredtooperatethemachineproperlyand safely.

•Wearappropriateclothing,includingeye

protection;longpants;substantial,slip-resistant footwear;andhearingprotection.Tiebacklong hairanddonotwearlooseclothingorloose jewelry.

•Donotcarrypassengersonthemachine.

•Keepbystandersandpetsawayfromthemachine

duringoperation.Shutoffthemachineand attachment(s)ifanyoneentersthearea.

•Donotoperatethemachineunlessallguardsand

safetydevices,suchasthedeectorsandthe entiregrasscatcher,areinplaceandfunctioning properly.Replacewornordeterioratedpartswhen necessary.

FuelSafety

•Fuelisextremelyammableandhighlyexplosive.

Areorexplosionfromfuelcanburnyouand othersandcandamageproperty.

–Topreventastaticchargefromignitingthe

fuel,removethemachinefromthetruckor trailerandrefuelitontheground,awayfrom allvehicles.Ifthisisnotpossible,placea portablefuelcontainerontheground,away fromallvehicles,andllit;thenrefuelthe machinefromthefuelcontainerratherthan fromafuel-dispensernozzle.

–Fillthefueltankoutdoorsonlevelground,in

anopenarea,andwhentheengineiscold. Wipeupanyfuelthatspills.

–Donothandlefuelwhensmokingoraroundan

openameorsparks.

–Donotremovethefuelcaporaddfueltothe

tankwhiletheengineisrunningorhot.

–Ifyouspillfuel,donotattempttostartthe

engine.Avoidcreatingasourceofignitionuntil thefuelvaporshavedissipated.

–Storefuelinanapprovedcontainerandkeep

itoutofthereachofchildren.

•Fuelisharmfulorfatalifswallowed.Long-term

exposuretovaporscancauseseriousinjuryand illness.

–Avoidprolongedbreathingofvapors.

–Keepyourhandsandfaceawayfromthe

nozzleandthefuel-tankopening.

–Keepfuelawayfromyoureyesandskin.

•Donotstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such asonawaterheateroronotherappliances.

•Donotoperatethemachinewithouttheentire

exhaustsysteminplaceandinproperworking condition.

AddingFuel

RecommendedFuel

TypeUnleadedgasoline

Minimumoctanerating

Ethanol

MethanolNone

MTBE(methyltertiarybutyl ether)

OilDonotaddtothefuel

Useonlyclean,fresh(nomorethan30daysold),fuel fromareputablesource.

UsingStabilizer/Conditioner

Usefuelstabilizer/conditionerinthemachinetokeep thefuelfreshlongerwhenusedasdirectedbythe fuel-stabilizermanufacturer.

Important:Donotusefueladditivescontaining

methanolorethanol.

Addtheamountoffuelstabilizer/conditionertofresh fuelasdirectedbythefuel-stabilizermanufacturer.

FillingtheFuelTank

1.Parkthemachineonalevelsurface.

2.Movethemotion-controlleversoutwardtothe PARKposition.

3.Shutofftheengineandremovethekey.

4.Cleanaroundthefuel-tankcap.

5.Fillthefueltanktothebottomofthellerneck (Figure7).Donotllthefueltankcompletelyfull

87(US)or91(research octane;outsidetheUS)

Nomorethan10%byvolume

Lessthan15%byvolume

•Keepthefuel-dispensernozzleincontactwith

therimofthefueltankorcontaineropeningat alltimesuntilfuelingiscomplete.Donotusea nozzlelock-opendevice.

•Ifyouspillfuelonyourclothing,changeyour

clothingimmediately.

•Donotoverllthefueltank.Replacethefuelcap

andtightenitsecurely.

•Cleangrassanddebrisfromthecuttingunit,

mufer,drives,grasscatcher,andengine compartmenttohelppreventres.Cleanupoilor fuelspills.

Understandingthe Safety-InterlockSystem

Thesafety-interlocksystemisdesignedtopreventthe enginefromstartingunless:

•Theblade-controlswitch(PTO)isdisengaged.

•Themotion-controlleversareinthePARKposition.

Thesafety-interlocksystemalsoisdesignedtoshut offtheenginewheneverthecontrolleversareoutof thePARKpositionandyourisefromtheseat.

TestingtheSafety-Interlock System

Testthesafety-interlocksystembeforeyouusethe machineeachtime.Ifthesafetysystemdoesnot operateasdescribedbelow,haveanAuthorized ServiceDealerrepairthesafetysystemimmediately .

Figure7

PerformingDaily Maintenance

Beforestartingthemachineeachday ,performthe EachUse/DailyprocedureslistedinMaintenance

(page29).

BreakinginaNewMachine

Newenginestaketimetodevelopfullpower.Mower decksanddrivesystemshavehigherfrictionwhen new,placingadditionalloadontheengine.Allow 40to50hoursofbreak-intimefornewmachinesto developfullpowerandbestperformance.

UsingtheSafety-Interlock

g293796

1.Sitontheseat,movethemotion-controllevers inthePARKposition,andmovetheblade-control switchtotheONposition.Trystartingthe engine;theengineshouldnotcrank.

2.Sitontheseatandmovetheblade-controlswitch totheOFFposition.Moveeithermotion-control levertothecenter,unlockedposition.Try startingtheengine;theengineshouldnotcrank. Repeatwiththeothermotion-controllever.

3.Sitontheseat,movetheblade-controlswitch totheOFFposition,andlockthemotion-control leversinthePARKposition.Starttheengine. Whiletheengineisrunning,engagethe blade-controlswitch,andriseslightlyfromthe seat;theengineshouldshutoff.

4.Sitontheseat,movetheblade-controlswitch totheOFFposition,andlockthemotion-control leversinthePARKposition.Starttheengine. Whiletheengineisrunning,movethe motion-controlleverstothecenter,unlocked positionandriseslightlyfromtheseat;the engineshouldshutoff.

System

WARNING

Ifthesafety-interlockswitchesare disconnectedordamaged,themachinecould operateunexpectedly,causingpersonal injury.

•Donottamperwiththeinterlockswitches.

•Checktheoperationoftheinterlock switchesdailyandreplaceanydamaged switchesbeforeoperatingthemachine.

PositioningtheSeat

Theseatcanmoveforwardandbackward.Position theseatwhereyouhavethebestcontrolofthe machineandaremostcomfortable(Figure8).

Figure8

g292102

Figure9

1.MyRideadjustmentlever3.Firmersuspension

2.Softersuspension

g027632

Adjustingthe Motion-ControlLevers

AdjustingtheMyRide® SuspensionSystem

YoucanadjusttheMyRide®suspensionsystemfora smoothandcomfortableride.Theslotsforadjusting thesuspensionhavedetentpositionsforreference, rangingfromasofttoarmride(Figure9).

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Stepoffthemachine.

4.Whilestandingontherightsideofthemachine, movetheadjustmentleverlefttowardthe– symbolforasoftersuspension.

Movetheadjustmentleverrighttowardthe+ symbolforarmersuspension.

AdjustingtheHeight

Youcanadjustthemotion-controllevershigheror lowerformaximumcomfort(Figure10).

g333847

Figure10

AdjustingtheTilt

Youcanadjustthemotion-controlleversforwardor rearwardforyourcomfort.

1.Loosentheupperboltholdingthecontrollever tothecontrol-armshaft.

2.Loosenthelowerboltjustenoughtopivotthe controlleverforwardorrearward.

•Donotmowinreverseunlessitisabsolutely

necessary.Alwayslookdownandbehindyou beforemovingthemachineinreverse.

•Useextremecarewhenapproachingblind

corners,shrubs,trees,orotherobjectsthatmay blockyourview.

•Stopthebladeswheneveryouarenotmowing.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey (ifequipped),andwaitforallmovingpartstostop beforeexaminingthemachinefordamage.Make allnecessaryrepairsbeforeresumingoperation.

Figure11

3.Tightenbothboltstosecurethecontrolleverin thenewposition.

4.Repeattheadjustmentfortheothercontrollever.

DuringOperation

DuringOperationSafety

GeneralSafety

•Theowner/operatorcanpreventandisresponsible

foraccidentsthatmaycausepersonalinjuryor propertydamage.

•Useyourfullattentionwhileoperatingthe

machine.Donotengageinanyactivitythat causesdistractions;otherwise,injuryorproperty damagemayoccur.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Contactingthebladecanresultinseriouspersonal

injury.Shutofftheengine,removethekey,and waitforallmovingpartstostopbeforeleavingthe operatingposition.Whenyouturnthekeytothe OFFposition,theengineshouldshutoffandthe bladeshouldstop.Ifnot,stopusingyourmachine immediatelyandcontactanAuthorizedService Dealer.

•Operatethemachineonlyingoodvisibilityand

appropriateweatherconditions.Donotoperate themachinewhenthereistheriskoflightning.

•Keepyourhandsandfeetawayfromthecutting

units.Keepclearofthedischargeopening.

•Donotmowwiththedischargedeector

raised,removed,oralteredunlessthereisa grass-collectionsystemormulchkitinplaceand workingproperly.

g333846

•Slowdownandusecautionwhenmakingturns

andcrossingroadsandsidewalkswiththe machine.Alwaysyieldtheright-of-way.

•Beforeyouleavetheoperatingposition,dothe

following:

–Parkthemachineonalevelsurface.

–Disengagethepowertakeoffandlowerthe

attachments.

–Engagetheparkingbrake.

–Shutofftheengineandremovethekey.

–Waitforallmovingpartstostop.

•Operatetheengineonlyinwell-ventilatedareas.

Exhaustgasescontaincarbonmonoxide,which islethalifinhaled.

•Neverleavearunningmachineunattended.

•Attachtowedequipmenttothemachineonlyat

thehitchpoint.

•Donotoperatethemachineunlessallguardsand

safetydevices,suchasthedeectorsandthe entiregrasscatcher,areinplaceandfunctioning properly.Replacewornordeterioratedpartswhen necessary.

•Useonlyaccessoriesandattachmentsapproved

byToro.

•Thismachineproducessoundlevelsinexcess

of85dBAattheoperator’searandcancause hearinglossthroughextendedperiodsof exposure.

g229846

Figure12

1.Wearhearingprotection.

•Cleangrassanddebrisfromthecuttingunit,

drives,mufer,andenginetohelppreventres.

•Starttheenginewithyourfeetwellawayfromthe

blades.

•Beawareofthemowerdischargepathanddirect

thedischargeawayfromothers.Avoiddischarging materialagainstawallorobstructionbecausethe materialmayricochetbacktowardyou.

•Stoptheblades,slowdownthemachine,anduse

cautionwhencrossingsurfacesotherthangrass orwhentransportingthemachinetoandfromthe operatingarea.

•Donotchangetheenginegovernorspeedor

overspeedtheengine.

•Childrenareoftenattractedtothemachineand

themowingactivity.Neverassumethatchildren willremainwhereyoulastsawthem.

•Keepchildrenoutoftheoperatingareaandunder

thewatchfulcareofaresponsibleadultotherthan theoperator.

•Bealertandshutoffthemachineifchildrenenter

theoperatingarea.

•Beforebackinguporturningthemachine,look

downandallaroundforsmallchildren.

•Donotcarrychildrenonthemachine,evenwhen

thebladesarenotmoving.Childrencouldfall offandbeseriouslyinjuredorpreventyoufrom safelyoperatingthemachine.Childrenwhohave beengivenridesinthepastcouldappearinthe operatingareawithoutwarningandberunoveror backedoverbythemachine.

machinecouldsuddenlyrolloverifawheelgoes overtheedgeortheedgecollapses.Keepasafe distance(twicethewidthofthemachine)between themachineandanyhazard.Useawalk-behind machineorahandtrimmertomowthegrassin theseareas.

•Avoidstarting,stopping,orturningthemachineon

slopes.Avoidmakingsuddenchangesinspeedor direction;turnslowlyandgradually.

•Donotoperateamachineunderanyconditions

wheretraction,steering,orstabilityisinquestion. Beawarethatoperatingthemachineonwet grass,acrossslopes,ordownhillmaycausethe machinetolosetraction.Lossoftractiontothe drivewheelsmayresultinslidingandalossof brakingandsteering.Themachinecanslideeven ifthedrivewheelsarestopped.

•Removeormarkobstaclessuchasditches,holes,

ruts,bumps,rocks,orotherhiddenhazards.T all grasscanhideobstacles.Uneventerraincould overturnthemachine.

•Useextracarewhileoperatingwithaccessoriesor

attachments,suchasgrass-collectionsystems. Thesecanchangethestabilityofthemachine andcausealossofcontrol.Followdirectionsfor counterweights.

•Ifpossible,keepthedeckloweredtotheground

whileoperatingonslopes.Raisingthedeckwhile operatingonslopescancausethemachineto becomeunstable.

SlopeSafety

•Slopesareamajorfactorrelatedtolossofcontrol

androlloveraccidents,whichcanresultinsevere injuryordeath.Theoperatorisresponsiblefor safeslopeoperation.Operatingthemachineon anysloperequiresextracaution.Beforeusingthe machineonaslope,dothefollowing:

–Reviewandunderstandtheslopeinstructions

inthemanualandonthemachine.

–Useanangleindicatortodeterminethe

approximateslopeangleofthearea. –Neveroperateonslopesgreaterthan15°. –Evaluatethesiteconditionsofthedayto

determineiftheslopeissafeformachine

operation.Usecommonsenseandgood

judgmentwhenperformingthisevaluation.

Changesintheterrain,suchasmoisture,can

quicklyaffecttheoperationofthemachineon

aslope.

•Identifyhazardsatthebaseoftheslope.Do

notoperatethemachineneardrop-offs,ditches, embankments,water,orotherhazards.The

1.SafeZone—usethe machinehereonslopes lessthan15°oratareas.

2.DangerZone—usea walk-behindmowerand/or ahandtrimmeronslopes greaterthan15°andnear drop-offsorwater.

3.Water

g22911 1

Figure13

4.W=Widthofthemachine

5.Keepasafedistance (twicethewidthofthe machine)betweenthe machineandanyhazard.

TowingSafety

•Donotattachtowedequipmentexceptatthehitch

point.

•Donotusethemachineasatowingvehicleunless

ithasahitchinstalled.

•Donotexceedtheweightlimitsfortowed

equipmentandtowingonslopes.Thetowed weightmustnotexceedtheweightofthemachine andoperator.

•Neverallowchildrenorothersnearthetowed

equipment.

•Onslopes,theweightofthetowedequipmentmay

causelossoftraction,increasedriskofrollover, andlossofcontrol.Reducethetowedweightand slowdown.

OperatingtheMower Blade-ControlSwitch(PTO)

Theblade-controlswitch(PTO)startsandstopsthe mowerbladesandanypoweredattachments.

EngagingtheBlade-Control Switch(PTO)

•Thestoppingdistancemayincreasewiththe

weightofatowedload.Travelslowlyandallow extradistancetostop.

•Makewideturnstokeeptheattachmentclearof

themachine.

g008945

Figure14

Note:Alwaysengagethebladeswiththethrottlein

theFASTposition(Figure15).

g295538

Figure15

DisengagingtheBlade-Control Switch(PTO)

g009174

Figure16

OperatingtheThrottle

StartingtheEngine

YoucanmovethethrottlecontrolbetweentheFAST andSLOWpositions(Figure17).

AlwaysusetheFASTpositionwhenengagingthePTO.

Figure17

OperatingtheChoke

Usethechoketostartacoldengine.

1.Pullupthechokeknobtoengagethechoke beforeusingthekeyswitch(Figure18).

Note:Awarmorhotenginemaynotrequirechoking.

Important:Donotengagethestarterformore

than5secondsatatime.Engagingthestarter motorformorethan5secondscandamagethe startermotor.Iftheenginefailstostart,wait10 secondsbeforeoperatingtheenginestarteragain.

g295539

Note:Ensurethatyoufullyengagethechoke.

Youmayneedtoholdtheknobupwhenyou usethekeyswitch.

2.Pushdownthechoketodisengagethechoke aftertheenginehasstarted(Figure18).

g295541

Figure19

Figure18

1.ONposition2.OFFposition

g295540

ShuttingOfftheEngine

DrivingtheMachine

1.Disengagethebladesbymovingthe blade-controlswitchtotheOFFposition.

2.Movethemotion-controlleversoutwardtothe PARKposition.

3.Movethethrottlecontroltobetweenthehalfand fullthrottleposition.

4.TurnthekeytotheOFFpositionandremove thekey.

CAUTION

Childrenorbystandersmaybeinjuredifthey moveorattempttooperatethemachinewhile itisunattended.

Alwaysremovethekeyandengagethe parkingbrakewhenleavingthemachine unattended.

UsingtheMotion-Control Levers

Thedrivewheelsturnindependently,poweredby hydraulicmotorsoneachaxle.Youcanturn1side inreversewhileyouturntheotherforward,causing themachinetospinratherthanturn.Thisgreatly improvesthemachinemaneuverabilitybutmay requiresometimeforyoutoadapttohowitmoves.

Thethrottlecontrolregulatestheenginespeedas measuredinrpm(revolutionsperminute).Place thethrottlecontrolintheFASTpositionforbest performance.Alwaysoperateinthefullthrottle positionwhenmowing.

WARNING

Themachinecanspinveryrapidly.You maylosecontrolofthemachineandcause personalinjuryordamagetothemachine.

•Usecautionwhenmakingturns.

•Slowthemachinedownbeforemaking sharpturns.

DrivingForward

Figure20

1.Motion-control lever—PARKposition

2.Center,unlockedposition5.Frontofmachine

3.Forward

4.Backward

Note:Alwaysusecautionwhenbackingupand

turning.

1.Movetheleverstothecenter,unlockedposition.

2.Togoforward,slowlypushthemotion-control leversforward(Figure21).

g004532

Figure21

g008952

DrivingBackward

1.Movetheleverstothecenter,unlockedposition.

2.Togobackward,slowlypullthemotion-control leversrearward(Figure22).

2.Disengagetheblade-controlswitch.

3.Adjustthelevertothedesiredposition.

Thefollowingareonlyrecommendationsforuse. Adjustmentsvarybygrasstype,moisturecontent, andtheheightofthegrass.

Figure22

UsingtheSmartSpeed ControlSystem

TheSmartSpeed belowtheoperatingposition(Figure23),givesthe operatorachoicetodrivethemachineat3ground speedranges—trim,tow,andmow.

Control-Systemlever,located

Suggested uses:

ParkingX

Heavy,wet grass

TrainingX

Trimming grass

BaggingX

MulchingX

Towing attachments

Normal mowing

Movingthe

g008953

machine

TrimT owMow

Trim

Thisisthelowestspeed.Thesuggestedusesforthis

speedareasfollows:

•Parking

•Heavy,wetgrassmowingconditions

•Training

•Trimminggrass

Tow

Figure23

1.Smart-speedlever

Tochangespeeds,dothefollowing:

1.Movethemotion-controlleverstoneutraland outwardtothePARKposition.

Thisisthemediumspeed.Thesuggestedusesfor thisspeedareasfollows:

•Bagging

•Mulching

•Towingattachments

Mow

Thisisthefastestspeed.Thesuggestedusesforthis speedareasfollows:

•Normalmowing

g293338

•Movingthemachine

UsingtheSideDischarge

AdjustingtheHeightofCut

Themowerhasahingedgrassdeectorthat dispersesclippingstothesideanddowntowardthe turf.

DANGER

Withoutagrassdeector,dischargecover,or acompletegrass-catcherassemblymounted inplace,youandothersareexposedtoblade contactandthrowndebris.Contactwith rotatingmowerblade(s)andthrowndebris willcauseinjuryordeath.

•Neverremovethegrassdeectorfromthe mowerdeckbecausethegrassdeector routesmaterialdowntowardtheturf.Ifthe grassdeectoriseverdamaged,replaceit immediately.

•Neverputyourhandsorfeetunderthe mowerdeck.

•Nevertrytoclearthedischargearea ormowerbladesunlessyoumovethe blade-controlswitch(PTO)totheOFF position,rotatethekeyswitchtotheOFF position,andremovethekeyfromthekey switch.

Note:Thetransportpositionisthehighest

height-of-cutpositionorcuttingheightat114mm (4-1/2inches)asshowninFigure24.

Youcanadjusttheheightofcutfrom38to114mm (1-1/2to4-1/2inches)in13mm(1/2inch)increments. Theheightofcutiscontrolledbytheleverlocatedto therightoftheoperatingposition(Figure24).

•Makesurethatthegrassdeectorisinthe downposition.

g296586

Figure24

AdjustingtheAnti-Scalp Rollers

Machineswith107cm(42-inch) MowerDecks

Wheneveryouchangetheheightofcut,adjustthe heightoftheanti-scalprollers.

Note:Adjusttheanti-scalprollerssothattherollers

donottouchthegroundinnormal,atmowingareas.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Adjusttheanti-scalprollersto1ofthefollowing positions:

•Upperhole—usethispositionwiththemower

deckinthe63mm(2-1/2inches)andbelow theheight-of-cutpositions(Figure25).

Machineswith127cm(50-inch)or 137cm(54-inch)MowerDecks

Wheneveryouchangetheheightofcut,adjustthe heightoftheanti-scalprollers.

Note:Adjusttheanti-scalprollerssothattherollers

donottouchthegroundinnormal,atmowingareas.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Adjusttheanti-scalprollers(Figure26)tomatch theclosestheight-of-cutposition.

•Lowerhole—usethispositionwiththemower

deckinthe76mm(3inches)andabovethe height-of-cutpositions(Figure25).

Figure25

1.Anti-scalproller4.Upperhole—themower

2.Lowerhole—themower deckinthe76mm(3 inches)andabovethe height-of-cutpositions

3.Flangenut

deckinthe63mm(2-1/2 inches)andbelowthe height-of-cutpositions

5.Bolt

g010233

Figure26

1.Anti-scalproller3.Flangenut

2.Bolt4.Holespacing

g019929

OperatingTips

MaximizingAirCirculation

Forbestmowingandmaximumaircirculation,operate theengineattheFASTposition.Airisrequiredto thoroughlycutgrassclippings,sodonotsetthe height-of-cutsolowastototallysurroundthemower deckinuncutgrass.Alwaystrytohave1sideofthe mowerdeckfreefromuncutgrass,whichallowsair tobedrawnintothemowerdeck.

CuttingaLawnfortheFirstTime

Cutgrassslightlylongerthannormaltoensurethat thecuttingheightofthemowerdeckdoesnotscalp anyunevenground.However,thecuttingheight usedinthepastisgenerallythebestonetouse. Whencuttinggrasslongerthan15cm(6inches)tall, youmaywanttocutthelawntwicetoensurean acceptablequalityofcut.

CuttingaThirdoftheGrassBlade

Itisbesttocutonlyaboutathirdofthegrassblade. Cuttingmorethanthatisnotrecommendedunless grassissparse,oritislatefallwhengrassgrows moreslowly.

StoppingtheMachine

Ifyoumuststoptheforwardmotionofthemachine whilemowing,aclumpofgrassclippingsmay dropontoyourlawn.Toavoidthis,moveontoa previouslycutareawiththebladesengagedoryou candisengagethemowerdeckwhilemovingforward.

KeepingtheUndersideofthe MowerDeckClean

Cleanclippingsanddirtfromtheundersideofthe mowerdeckaftereachuse.Ifgrassanddirtbuildup insidethemowerdeck,cuttingqualitywilleventually becomeunsatisfactory.

MaintainingtheBlade(s)

Maintainasharpbladethroughoutthecuttingseason becauseasharpbladecutscleanlywithouttearingor shreddingthegrassblades.Tearingandshredding turnsgrassbrownattheedges,whichslowsgrowth andincreasesthechanceofdisease.Checkthe mowerbladesaftereachuseforsharpness,and foranywearordamage.Filedownanynicksand sharpenthebladesasnecessary .Ifabladeis damagedorworn,replaceitimmediatelywitha genuineT ororeplacementblade.RefertoServicing

theCuttingBlades(page42).

AlternatingtheMowingDirection

Alternatethemowingdirectiontokeepthegrass standingstraight.Thisalsohelpsdisperseclippings, whichenhancesdecompositionandfertilization.

MowingatCorrectIntervals

Grassgrowsatdifferentratesatdifferenttimesof theyear.Tomaintainthesamecuttingheight,mow moreofteninearlyspring.Asthegrassgrowthrate slowsinmidsummer,mowlessfrequently .Ifyou cannotmowforanextendedperiod,rstmowata highcuttingheight,thenmowagain2dayslaterata lowerheightsetting.

MowingatSlowerSpeeds

Incertainconditions,mowingataslowerground speedcanimprovecutquality.

AvoidingCuttingTooLow

Whenmowinguneventurf,raisethecuttingheight toavoidscalpingtheturf.

AfterOperation

PushingtheMachineby Hand

AfterOperationSafety

GeneralSafety

•Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe operator’sposition.Allowthemachinetocool beforeservicing,adjusting,fueling,cleaning,or storingit.

•Cleangrassanddebrisfromthecuttingunit,

mufer,drives,grasscatcher,andengine compartmenttohelppreventres.Cleanupoilor fuelspills.

•Removethekeybeforestoringortransportingthe

machine.

CleaningtheMachine

ServiceInterval:Aftereachuse

Important:Youcanwashthemachinewithamild

detergentandwater.Donotpressurewashthe machine.Avoidexcessiveuseofwater,especially nearthecontrolpanel,undertheseat,aroundthe engine,hydraulicpumps,andmotors.

Thismachinehasanelectric-brakemechanism, andtopushthemachine,thekeymustbeinthe

RUNposition.Thebatteryneedstobechargedand

functioningtodisengagetheelectricbrake.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengineandwaitforallmovingparts tostopbeforeleavingtheoperatingposition.

3.Locatethebypassleversontheframeonboth sidesoftheengine.

4.Movebothbypassleversforwardthroughthe slottedholeanddowntolocktheminplace (Figure27).

WARNING

Contactwithhotsurfacesmaycause personalinjury.

Keepyourhands,feet,face,clothing andotherbodypartsawaytheengine, muferandotherhotsurfaces.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengineandwaitforallmovingparts tostopbeforeleavingtheoperatingposition.

3.Cleangrassanddebrisfromcuttingunit,mufer, drives,grasscatcher,andengine.

Note:RefertoWashingtheUndersideofthe

MowerDeck(page50)forinformationonusing

thedeck-washouttting.

WARNING

Themachinecouldunintentionallymove whilethebypassleversarelocked forwardintheslotandinjureyouor bystanders.

Lockthebypassleversrearwardafter movingthemachine.

TransportingtheMachine

Useaheavy-dutytrailerortrucktotransportthe machine.Useafull-widthramp.Ensurethatthetrailer ortruckhasallthenecessarybrakes,lighting,and markingasrequiredbylaw.Pleasecarefullyreadall thesafetyinstructions.Knowingthisinformationcould helpyouorbystandersavoidinjury.Refertoyour localordinancesfortrailerandtie-downrequirements.

WARNING

Drivingonthestreetorroadwaywithout turnsignals,lights,reectivemarkings,ora slow-moving-vehicleemblemisdangerous andcanleadtoaccidents,causingpersonal injury.

Donotdrivethemachineonapublicstreet orroadway.

Figure27

1.Bypass-leverlocations

2.Leverpositionfor

operatingthemachine

5.TurntheignitionkeytotheRUNpositionand disengagetheparkingbrakebymoving1 motion-controlleveroutofthePARKposition.

3.Leverpositionforpushing themachine

Note:Donotstartthemachine.

6.Movethemachineasrequired.

Important:Alwayspushthemachineby

hand.Donottowthemachine,because towingmaydamageit.

7.Movethemotion-controlleversoutwardtothe PARKposition.

8.TurnthekeytotheOFFpositionandremoveitto avoiddrainingthebatterycharge.

9.Movebothbypassleversrearwardanddown throughtheslottedholetolocktheminplace.

g333873

SelectingaTrailer

WARNING

Loadingamachineontoatrailerortruck increasesthepossibilityoftip-overandcould causeseriousinjuryordeath(Figure28).

•Useonlyafull-widthramp;donotuse individualrampsforeachsideofthe machine.

•Donotexceeda15-degreeanglebetween therampandthegroundorbetweenthe rampandthetrailerortruck.

•Ensurethatthelengthoftherampisat least4timesaslongastheheightofthe trailerortruckbedtotheground.This ensuresthattherampangledoesnot exceed15degreesonatground.

1.Ifyouareusingatrailer,connectittothetowing vehicleandconnectthesafetychains.

2.Ifapplicable,connectthetrailerbrakesand lights.

3.Lowertheramp,ensuringthattheangle betweentherampandthegrounddoesnot exceed15degrees(Figure28).

4.Backthemachineuptheramp(Figure29).

Figure29

g027995

1.Full-widthrampinstowed position

2.Sideviewoffull-width rampinloadingposition

3.Notgreaterthan 15degrees

LoadingtheMachine

Figure28

4.Rampisatleast4times aslongastheheightof thetrailerortruckbedto theground

5.H=heightofthetraileror truckbedtotheground

6.Trailer

1.Backthemachineupthe ramp.

2.Drivethemachineforward downtheramp.

5.Shutofftheengine,removethekey,andmove themotion-controlleversoutwardtothePARK position.

6.Tiedownthemachinenearthefrontcaster wheelsandtherearframewithstraps,chains, cable,orropes(Figure30).Refertolocal

g027996

regulationsfortie-downrequirements.

g027708

Figure30

1.Tie-downpoints

WARNING

Loadingamachineontoatrailerortruck increasesthepossibilityoftip-overandcould causeseriousinjuryordeath.

•Useextremecautionwhenoperatinga machineonaramp.

•Backthemachineuptherampanddriveit forwarddowntheramp.

•Avoidsuddenaccelerationordeceleration whiledrivingthemachineonarampas thiscouldcausealossofcontrolora tip-oversituation.

UnloadingtheMachine

1.Lowertheramp,ensuringthattheangle betweentherampandthegrounddoesnot exceed15degrees(Figure28).

2.Drivethemachineforwarddowntheramp (Figure29).

Maintenance

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

MaintenanceSafety

•Ifyouleavethekeyintheswitch,someonecould

accidentlystarttheengineandseriouslyinjureyou orotherbystanders.Removethekeyfromthe switchbeforeyouperformanymaintenance.

•Beforeyouleavetheoperator’sposition,dothe

following:

–Parkthemachineonalevelsurface.

–Disengagethedrives.

–Engagetheparkingbrake.

–Shutofftheengineandremovethekey.

–Allowmachinecomponentstocoolbefore

performingmaintenance.

•Donotallowuntrainedpersonneltoservicethe

machine.

•Keepyourhandsandfeetawayfrommoving

partsorhotsurfaces.Ifpossible,donotmake adjustmentswiththeenginerunning.

•Carefullyreleasepressurefromcomponentswith

storedenergy.

•Checktheparkingbrakeoperationfrequently.

Adjustandserviceitasrequired.

•Nevertamperwithsafetydevices.Checktheir

properoperationregularly.

•Cleangrassanddebrisfromthecuttingunit,

mufer,drives,grasscatcher,andengine compartmenttopreventres.

•Cleanupoilorfuelspillsandremovefuel-soaked

debris.

•Donotrelyonhydraulicormechanicaljacksto

supportthemachine;supportthemachinewith jackstandswheneveryouraisethemachine.

•Keepallpartsingoodworkingcondition

andallhardwaretightened,especiallythe blade-attachmenthardware.Replaceallwornor damageddecals.

•Disconnectthecablefromthenegativeterminalof

thebatterybeforerepairingthemachine.

•Toensureoptimumperformance,useonly

genuineT ororeplacementpartsandaccessories. Replacementpartsandaccessoriesmadeby othermanufacturerscouldbedangerous,and suchusecouldvoidtheproductwarranty.

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Beforeeachuseordaily

Aftereachuse

Every25hours

Every100hours

Every100hoursoryearly,

whichevercomesrst

Every200hours

MaintenanceProcedure

•Checkthesafety-interlocksystem.

•Checktheengine-oillevel.

•Inspecttheblades.

•Inspectthegrassdeectorfordamage.

•Cleangrassanddebrisfromthecuttingunit,mufer,drives,grasscatcher,and engine.

•Cleanthemower-deckhousing.

•Cleangrassanddebrisfromthecuttingunit,mufer,drives,grasscatcher,and engine.

•Greasethecasterwheelbearings(moreofteninsandysoilconditions).

•Cleantheair-cleanerfoamelement(moreoftenindusty,dirtyconditions).

•Checktirepressure.

•Checkthebeltsforwearorcracks.

•Replacetheair-cleanerfoamelement(moreoftenindusty,dirtyconditions).

•Removeandcleantheblowerhousingandanyothercoolingshrouds(moreoften underextremelydusty,dirtyconditions).

•Replacethein-linefuellter.

•Replacethepaperair-cleanerelement(moreoftenindirtyordustyconditions).

•Changetheengineoilandoillter(moreoftenindirtyordustyconditions).

•Checkthesparkplug(s).

•Replacethesparkplug(s).

•Chargethebatteryanddisconnectthebatterycables.

Beforestorage

•Performallmaintenanceprocedureslistedabovebeforestorage.

•Paintanychippedsurfaces.

Important:Refertoyourengineowner'smanualforadditionalmaintenanceprocedures.

CAUTION

Ifyouleavethekeyintheswitch,someonecouldaccidentlystarttheengineandseriously injureyouorotherbystanders.

Shutofftheengineandremovethekeyfromtheswitchbeforeyouperformanymaintenance.

Pre-Maintenance Procedures

RaisingtheMachine

Usejackstandstosupportthemachinewhenyou raiseit.

WARNING

Supportingthemachineonthelowermufer shield(Figure31)maydamagetheshieldand causethemachinetofall,injuringyouor bystanders.

Donotusethelowermufershieldtoliftor supportthemachine.

Figure31

Lubrication

GreasingtheBearings

ServiceInterval:Every25hours—Greasethecaster

wheelbearings(moreofteninsandy soilconditions).

GreaseType:No.2lithiumgrease

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait

g299647

forallmovingpartstostopbeforeleavingthe operatingposition.

1.Lowermufershield

3.Cleanthegreasettings(Figure32)witharag.

Note:Scrapeanypaintoffthefrontofthe

tting(s).

g032432

Figure32

1.Frontcastertire

4.Connectagreaseguntoeachtting(Figure32).

5.Pumpgreaseintothettingsuntilgreasebegins tooozeoutofthebearings.

6.Wipeupanyexcessgrease.

EngineMaintenance

EngineSafety

•Keepyourhands,feet,face,otherbodyparts,

andclothingawayfromthemuferandotherhot surfaces.Allowenginecomponentstocoolbefore performingmaintenance.

•Donotchangetheenginegovernorspeedor

overspeedtheengine.

ServicingtheAirCleaner

ServiceInterval:Every25hours—Cleanthe

air-cleanerfoamelement(more oftenindusty,dirtyconditions).

Every100hours—Replacetheair-cleanerfoam element(moreoftenindusty,dirtyconditions).

Note:Servicetheaircleanermorefrequently(every

fewhours)ifoperatingconditionsareextremelydusty orsandy.

RemovingtheFoamandPaper

5.Separatethefoamandpaperelements(Figure

34).

g333887

Figure34

1.Paperelement2.Foamelement

ServicingtheFoamElement

1.Washthefoamelementinliquidsoapand warmwater.Whentheelementisclean,rinse itthoroughly.

2.Drytheelementbysqueezingitinacleancloth.

Important:Replacethefoamelementifit

istornorworn.

Elements

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Cleanaroundtheair-cleanercovertoprevent dirtfromgettingintotheengineandcausing damage.

4.Rotatethelatchesoutwardandremovethe covertoaccesstheair-cleanerelements.

3.Lightlyoilthefoamelementusingnewengineoil andsqueezeoutanyexcessoil.

Figure33

1.Latch3.Air-cleanerelements

2.Engine4.Air-cleanerbase

g333875

ServicingthePaperAir-Cleaner

CheckingtheEngine-OilLevel

Element

ServiceInterval:Every100hoursoryearly,

whichevercomesrst—Replacethe paperair-cleanerelement(more oftenindirtyordustyconditions).

1.Cleanthepaperelementbytappingitgentlyto removedust.

Note:Ifitisverydirty,replacethepaper

elementwithanewone.

2.Inspecttheelementfortears,anoilylm,or damagetotherubberseal.

3.Replacethepaperelementifitisdamaged.

Important:Donotcleanthepaperlter.

InstallingtheAirCleaner

1.Installthefoampre-cleanerelementoverthe paperelement.

Note:Ensurethatyoudonotdamagethe

elements.

ServiceInterval:Beforeeachuseordaily

Note:Checktheoilwhentheengineiscold.

Important:Ifyouoverllorunderlltheengine

crankcasewithoilandruntheengine,youmay damagetheengine.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

Note:Ensurethattheengineiscoolsothatthe

oilhashadtimetodrainintothesump.

3.Tokeepdirt,grassclippings,etc.,outofthe engine,cleantheareaaroundtheoil-llcapand dipstickbeforeremovingit(Figure36).

2.Installtheair-cleanerelementsontothe air-cleanerbase.

3.Installthecoverandsecureitwiththelatches (Figure33).

ServicingtheEngineOil

Engine-OilSpecications

OilType:Detergentoil(includingsynthetic)ofAPI

serviceSJorhigher

CrankcaseCapacity:1.9L(64oz)withoillter

Viscosity:Seethetablebelow.

Figure35

g017552

Figure36

g365791

ChangingtheEngineOilandOil Filter

ServiceInterval:Every100hoursoryearly,

whichevercomesrst—Changethe engineoilandoillter(moreoften indirtyordustyconditions).

1.Parkthemachineonalevelsurfacetoensure thattheoildrainscompletely.

2.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

3.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

4.Draintheoilfromtheengine(Figure37).

Figure37

g027477

Figure38

6.Slowlypourapproximately80%ofthespecied oilintothellertubeandslowlyaddthe additionaloiltobringittotheFullmark(Figure

39).

g225280

5.Changetheengine-oillter(Figure38).

Note:Ensurethattheoil-ltergaskettouches

theengineandthenturnthelteranextra3/4 turn.

ServicingtheSparkPlug

ServiceInterval:Every100hoursoryearly,

whichevercomesrst—Checkthe sparkplug(s).

Every200hours/Every2years(whichever comesrst)—Replacethesparkplug(s).

Ensurethattheairgapbetweenthecenterandside electrodesiscorrectbeforeinstallingthesparkplug. Useasparkplugwrenchforremovingandinstalling thesparkplugandagappingtoolorfeelergaugeto checkandadjusttheairgap.Installanewsparkplug ifnecessary.

Figure39

7.Disposeoftheusedoilatarecyclingcenter.

Type:Champion

Airgap:0.76mm(0.03inch)

XC12YC

RemovingtheSparkPlug

1.Parkthemachineonalevelsurface,disengage

g365790

theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.Allowtheenginetocool.

3.Cleantheareaaroundthebaseoftheplugto keepdirtanddebrisoutoftheengine.

4.Removethesparkplug(Figure40).

Figure40

CheckingtheSparkPlug

Important:Donotcleanthesparkplug(s).

Alwaysreplacethesparkplug(s)whenithasa blackcoating,wornelectrodes,anoilylm,or cracks.

Ifyouseelightbrownorgrayontheinsulator,the engineisoperatingproperly.Ablackcoatingonthe insulatorusuallymeanstheaircleanerisdirty .

Setthegapto0.75mm(0.03inch).

g027478

Figure41

InstallingtheSparkPlug

FuelSystem Maintenance

DANGER

Incertainconditions,fuelisextremely

g206628

ammableandhighlyexplosive.Areor explosionfromfuelcanburnyouandothers andcandamageproperty.

RefertoFuelSafety(page14)foracomplete listoffuelrelatedprecautions.

ReplacingtheIn-LineFuel Filter

ServiceInterval:Every100hours—Replacethe

in-linefuellter.

Neverinstalladirtylterafterremovingitfromthe fuelline.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

Figure42

CleaningtheBlower Housing

ServiceInterval:Every100hours/Yearly(whichever

comesrst)

Toensurepropercooling,ensurethatthegrass screen,coolingns,andotherexternalsurfacesofthe enginearekeptcleanatalltimes.

Cleanthecoolingnsandexternalsurfacesas necessary.Makesurethatthecoolingshroudsare installed.Torquetheblowerhousingscrewsto7.5 N∙m(5.5ft-lb).

Important:Operatingtheenginewithablocked

grassscreen,dirtyorpluggedcoolingns,and/or coolingshroudsremoved,causesenginedamage duetooverheating.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.Allowtheenginetocool.

g027480

3.Replacethelter(Figure43).

Note:Ensurethattheow-directionarrowon

thereplacementlterpointstowardtheengine.

ElectricalSystem Maintenance

g365941

ElectricalSystemSafety

•Disconnectthecablefromthenegativeterminalof

thebatterybeforerepairingthemachine.

•Chargethebatteryinanopen,well-ventilated

area,awayfromsparksandames.Unplugthe chargerbeforeconnectingordisconnectingthe battery.Wearprotectiveclothinganduseinsulated tools.

ServicingtheBattery

RemovingtheBattery

WARNING

Batteryterminalsormetaltoolscouldshort againstmetalmachinecomponents,causing sparks.Sparkscancausethebatterygasses toexplode,resultinginpersonalinjury.

•Whenremovingorinstallingthebattery, donotallowthebatteryterminalstotouch anymetalpartsofthemachine.

Figure43

•Donotallowmetaltoolstoshortbetween thebatteryterminalsandmetalpartsofthe machine.

g027518

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Raisetheseattoaccessthebattery.

4.Disconnectthenegative(black)groundcable fromthebatterypost(Figure44).

Note:Retainallfasteners.

WARNING

Incorrectlyremovingthecablesfrom batterycoulddamagethemachineand cables,causingsparks.Sparkscan causethebatterygassestoexplode, resultinginpersonalinjury .

•Alwaysdisconnectthenegative (black)batterycablebefore disconnectingthepositive(red) cable.

•Alwaysconnectthepositive(red) batterycablebeforeconnectingthe negative(black)cable.

5.Slidetherubbercoveroffthepositive(red) cable.

6.Disconnectthepositive(red)cablefromthe batterypost(Figure44).

Note:Retainallfasteners.

7.Removethebatteryhold-down(Figure44),and liftthebatteryfromthebatterytray.

ChargingtheBattery

ServiceInterval:Beforestorage—Chargethebattery

anddisconnectthebatterycables.

1.Removethebatteryfromthechassis;referto

RemovingtheBattery(page37).

2.Chargethebatteryforaminimumof1hourat 6to10A.

Note:Donotoverchargethebattery .

3.Whenthebatteryisfullycharged,unplug thechargerfromtheelectricaloutlet,then disconnectthechargerleadsfromthebattery posts(Figure45).

Figure44

1.Battery

2.Positive(+)batterypost

3.Bolt,washer,andnut7.Batteryhold-down

4.Terminalboot

5.Negative(–)batterypost

6.Wingnut,washer,andbolt

g000538

Figure45

1.Positive(+)batterypost3.Red(+)chargerlead

2.Negative(–)batterypost4.Black(–)chargerlead

InstallingtheBattery

1.Positionthebatteryinthetray(Figure44).

2.Usingthefastenerspreviouslyremoved,install thepositive(red)batterycabletothepositive (+)batteryterminal.

g293472

3.Usingthefastenerspreviouslyremoved,install thenegativebatterycabletothenegative(-) batteryterminal.

4.Slidetheredterminalbootontothepositive (red)batterypost.

5.Securethebatterywiththehold-down(Figure

44).

6.Lowertheseat.

ServicingtheFuses

DriveSystem

Theelectricalsystemisprotectedbyfuses.Itrequires nomaintenance;however,ifafuseblows,checkthe component/circuitforamalfunctionorshort.

Fusetype:

•Main—F1(25A,blade-type)

•ChargeCircuit—F2(15A,blade-type)

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Raisetheseattoaccessthefuses.

4.Toreplaceafuse,pulloutthefusetoremove it(Figure46).

Maintenance

CheckingtheTirePressure

ServiceInterval:Every25hours—Checktire

pressure.

Maintaintheairpressureinthefrontandreartiresas specied.Uneventirepressurecancauseanuneven cut.Checkthepressureatthevalvestem(Figure47). Checkthetireswhentheyarecoldtogetthemost accuratepressurereading.

Inatethefrontcasterwheeltiresto206kPa(30psi) orthepressureindicatedonthesidewall,whichever islower.

Inatethereardrive-wheeltiresto90kPa(13psi).

Figure46

1.Chargecircuit(15A)2.Main(25A)

5.Lowertheseat.

g000554

Figure47

1.Valvestem

g293931

ReleasingtheElectric Brake

Youcanmanuallyreleasetheelectricbrakeby rotatingthelinkarmsforward.Oncetheelectricbrake isenergized,thebrakeresets.

1.TurnthekeytotheOFFpositionandremove thekey.

2.Disconnectthebattery.

3.Locatetheshaftontheelectricbrakewherethe brakelinkarmsareconnected(Figure48).

4.Rotatetheshaftforwardtoreleasethebrake.

5.Connectthebatteryaftermovingthemachine.

4.Rotatethebolttodecreasethespeedforthat particularwheel.

Note:Rotatetheboltasmallamounttomake

minoradjustments.

Figure48

1.Brake-linkarmontheelectricbrakecontrolmodule

2.Left,reartire

AdjustingtheTracking

Whendrivingthemachineforwardfullspeedacross aat,levelsurface,ifthemachinepullsto1side, adjustthetracking.

Ifthemachinepullstotheleft,adjusttheright motion-controllever;ifthemachinepullstotheright, adjusttheleftmotion-controllever.

Note:Youcanadjustthetrackingonlyfordriving

forward.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

g294417

g294926

Figure49

1.Bolt

5.Startthemachineanddriveforwardacrossa at,levelsurfacewiththemotion-controllevers fullyforwardtocheckifthemachinetracks straight.Repeattheprocedureasneeded.

3.Locatethetracking-adjustmentboltnearthe motion-controlleverontheparticularsidethat needsadjusting(Figure49).

Note:Raisetheseatforeasieraccesstothe

adjustmentbolt.

BeltMaintenance

InspectingtheBelts

ServiceInterval:Every25hours—Checkthebelts

forwearorcracks.

Replacethebeltifitisworn.Thesignsofawornbelt includesquealingwhilethebeltisrotating;theblades slippingwhilecuttinggrass;andfrayededges,burn marks,andcracksonthebelt.

ReplacingtheMowerBelt

Thesignsofawornbeltincludesquealingwhilethe beltisrotating,bladesslippingwhilecuttinggrass, andfrayededges,burnmarks,andcracksonthebelt. Replacethemowerbeltifanyoftheseconditionsare evident.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Settheheightofcutatthelowestcuttingposition (38mm(1-1/2inches).

4.Removethehairpincotterandpushinthetab onthecovertoremovethepulleycovers(Figure

50).

Figure51

1.Wireform

2.Nut

3.Idlerpulley

6.Usingaspring-removaltool(T oroPartNo. 92-5771),removetheidlerspringfromthedeck hooktoremovetensionontheidlerpulley,and rollthebeltoffthepulleys(Figure52orFigure

53).

WARNING

Thespringisundertensionwhen installedandcancausepersonalinjury .

Becarefulwhenremovingthebelt.

g336421

Figure50

1.Cover

2.Hairpincotter

5.Fordeckswith3blades,loosenthenutsecuring thewireformtotheidlerpulley(Figure51).

g332328

Figure52

Mowerdeckswith2blades

1.Idlerpulley

2.Mowerbelt5.Enginepulley

3.Outsidepulley6.Spring-removaltool

4.Spring

g298025

MowerMaintenance

BladeSafety

•Inspectthebladesperiodicallyforwearordamage.

•Usecarewhencheckingtheblades.Wrapthe

bladesorweargloves,andusecautionwhen servicingtheblades.Onlyreplaceorsharpenthe blades;neverstraightenorweldthem.

•Onmulti-bladedmachines,takecareasrotating

onebladecancauseotherbladestorotate.

•Replacewornordamagedbladesandboltsinsets

topreservebalance.

ServicingtheCutting

Figure53

Mowerdeckswith3blades

1.Idlerpulley

2.Mowerbelt

3.Outsidepulley6.Spring-removaltool

7.Routethenewbeltaroundtheenginepulleyand mowerpulleys(Figure52orFigure53).

8.Usingaspring-removaltool(T oroPartNo. 92-5771),installtheidlerspringoverthedeck hookandplacetensionontheidlerpulleyand themowerbelt(Figure52orFigure53).

9.Fordeckswith3blades,tightenthenutsecuring thewireformtotheidlerpulley.

4.Spring

5.Enginepulley

Note:Positionthewireformagainsttheidler

armasshowninFigure51.

10.Installthepulleycovers.

g298026

Blades

Toensureasuperiorqualityofcut,keeptheblades sharp.Forconvenientsharpeningandreplacement, keepextrabladesonhand.

BeforeInspectingorServicingthe Blades

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch,andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey,and disconnectthespark-plugwiresfromthespark plugs.

InspectingtheBlades

ServiceInterval:Beforeeachuseordaily

1.Inspectthecuttingedges(Figure54).

2.Iftheedgesarenotsharporhavenicks,remove andsharpentheblade;refertoSharpeningthe

Blades(page44).

3.Inspecttheblades,especiallyinthecurvedarea.

4.Ifyounoticeanycracks,wear,oraslotforming inthisarea,immediatelyinstallanewblade (Figure54).

Figure54

g006530

1.Cuttingedge3.Wear/slotforming

2.Curvedarea4.Crack

CheckingforBentBlades

Note:Themachinemustbeonalevelsurfacefor

thefollowingprocedure.

1.Raisethemowerdecktothehighest height-of-cutposition.

2.Whilewearingthicklypaddedgloves,orother adequatehandprotection,slowlyrotatethe bladeintoapositionthatallowsyoutomeasure thedistancebetweenthecuttingedgeandthe levelsurfacethemachineison(Figure55).

Figure55

1.Deck3.Blade

2.Spindlehousing

3.Measurefromthetipofthebladetotheat surface(Figure56).

g014973

Figure56

1.Blade(inpositionformeasuring)

2.Levelsurface

3.Measureddistancebetweenbladeandthesurface(A)

4.Rotatethesameblade180degreessothat theopposingcuttingedgeisnowinthesame position(Figure57).

g014974

Figure57

1.Blade(sidepreviouslymeasured)

2.Measurement(positionusedpreviously)

3.Opposingsideofbladebeingmovedintomeasurement

g014972

position

5.Measurefromthetipofthebladetotheat surface(Figure58).

Note:Thevarianceshouldbenomorethan

3mm(1/8inch).

Figure58

1.Oppositebladeedge(inpositionformeasuring)

2.Levelsurface

3.Secondmeasureddistancebetweenbladeandsurface(B)

A.IfthedifferencebetweenAandBisgreater

than3mm(1/8inch),replacethebladewith anewblade;refertoRemovingtheBlades

(page44)andInstallingtheBlades(page

45).

g014973

g027833

Figure59

1.Sailareaoftheblade3.Curvedwasher

2.Blade4.Bladebolt

SharpeningtheBlades

1.Usealetosharpenthecuttingedgeatboth endsoftheblade(Figure60).

Note:Ifabentbladeisreplacedwitha

newblade,andthedimensionobtained continuestoexceed3mm(1/8inch),the bladespindlecouldbebent.Contactan AuthorizedServiceDealerforservice.

B.Ifthevarianceiswithinconstraints,moveto

thenextblade.

6.Repeatthisprocedureoneachblade.

RemovingtheBlades

Replacethebladesiftheyhitasolidobject,orifthe bladeisoutofbalanceorbent.

1.Holdthebladeendusingaragorthicklypadded glove.

2.Removethebladebolt,curvedwasher,and bladefromthespindleshaft(Figure59).

Note:Maintaintheoriginalangle.

Note:Thebladeretainsitsbalanceifthesame

amountofmaterialisremovedfrombothcutting edges.

g000552

Figure60

1.Sharpenatoriginalangle.

2.Checkthebalanceofthebladebyputtingitona bladebalancer(Figure61).

Note:Ifthebladestaysinahorizontalposition,

thebladeisbalancedandcanbeused.

Note:Ifthebladeisnotbalanced,lesome

metalofftheendofthesailareaonly(Figure60).

Figure61

1.Blade2.Balancer

3.Repeatthisprocedureuntilthebladeis balanced.

g000553

InstallingtheBlades

1.Installthebladeontothespindleshaft(Figure

59).

Important:Thecurvedpartoftheblade

mustbepointingupwardtowardtheinside ofthemowertoensurepropercutting.

2.Installthecurvedwasher(cuppedsidetoward theblade)andthebladebolt(Figure59).

3.Torquethebladeboltto81to108N∙m(60to 80ft-lb).

LevelingtheMowerDeck

Checktoensurethatthemowerdeckislevelanytime youinstallthemowerorwhenyouseeanunevencut onyourlawn.

Checkthemowerdeckforbentbladespriorto leveling,andremoveandreplaceanybentblades; refertotheServicingtheCuttingBlades(page42) beforecontinuing.

1.Bladessidetoside

2.Outsidecuttingedges

g294044

Figure62

MowerDeckswith2Blades

3.Measurefromthetipofthe bladetotheatsurface here.

Levelthemowerdeckside-to-siderst;thenyoucan adjustthefront-to-rearslope.

Requirements:

•Themachinemustbeonalevelsurface.

•Alltiresmustbeproperlyinated;refertoChecking

theTirePressure(page39).

CheckingtheSide-to-SideLevel

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch(PTO),andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Settheheightofcutto76mm(3inches).

4.Carefullyrotatethebladessidetoside.

5.Measurebetweentheoutsidecuttingedgesand theatsurface(Figure62andFigure63).

Note:Ifbothmeasurementsarenotwithin5

mm(3/16inch),anadjustmentisrequired;refer toLevelingfromSidetoSide(page46).

Figure63

MowerDeckswith3Blades

1.Bladessidetoside

2.Outsidecuttingedges

3.Measurefromthetipofthe bladetotheatsurface here.

CheckingtheFront-to-RearBlade Slope

Checkthefront-to-rearbladelevelanytimeyouinstall themower.Ifthefrontofthemowerismorethan

7.9mm(5/16inch)lowerthantherearofthemower, adjustthebladelevel.

g296913

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch(PTO),andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Settheheightofcutto76mm(3inches).

4.Carefullyrotatethebladessotheyarefacing fronttorear(Figure64).

5.Measurefromthetipofthefrontbladetotheat surfaceandthetipoftherearbladetotheat surface(Figure64orFigure65).

Note:Ifthefrontbladetipisnot1.6to7.9mm

(1/16to5/16inch)lowerthantherearblade tip,continuetotheAdjustingtheFront-to-Rear

BladeSlope(page47)procedure.

LevelingfromSidetoSide

1.Movetotheleftsideofthemachine.

2.Settheanti-scalprollerstothetopholesor removethemcompletelyforthisprocedure;refer toAdjustingtheAnti-ScalpRollers(page24).

3.Settheheight-of-cutlevertothe76mm(3inch) position;refertoAdjustingtheHeightofCut

(page23).

4.Place2blocks,eachhavingathicknessof6.6 cm(2-5/8inches),undereachsideofthefront edgeofthedeckbutnotundertheanti-scalp rollerbrackets(Figure66orFigure67).

5.Place2blocks,eachhavingathicknessof7.3 cm(2-7/8inches),undertherearedgeofthe cuttingdeckskirt,1oneachsideofthecutting deck(Figure66orFigure67).

Figure64

MowerDeckswith2Blades

1.Bladesfronttorear3.Measurefromthetipofthe bladetotheatsurface here.

2.Outsidecuttingedges

Figure65

MowerDeckswith3Blades

g294046

g298027

Figure66

MowerDeckswith2Blades

1.Woodblock—6.6cm (2-5/8inches)thick

g296914

2.Woodblock—7.3cm (2-7/8inches)thick

1.Bladesfronttorear3.Measurefromthetipofthe bladetotheatsurface here.

2.Outsidecuttingedges

Figure69

g294195

Figure67

MowerDeckswith3Blades

1.Woodblock—6.6cm

(2-5/8inches)thick

2.Woodblock—7.3cm (2-7/8inches)thick

6.Removethehairpincotterandwasherfromthe lowerlift-armpin(Figure68).

g298028

8.Installthewasherandhairpincotter(Figure69).

9.Repeatsteps6through8fortheothersideof themachine.

10.Checktheside-to-sidelevelagain;repeatthis procedureuntilthemeasurementsarecorrect.

11.Continuelevelingthemowerdeckbychecking thefront-to-rearbladeslope;refertoChecking

theFront-to-RearBladeSlope(page45).

AdjustingtheFront-to-RearBlade Slope

1.Rotatetheadjustmentnutinthefrontofthe mower(Figure70).

Figure68

1.Height-of-cutplate

2.Hairpincotter

3.Washer

7.Rotatetheheight-of-cutplatetoadifferenthole sothatitsupportstheweightofthemowerdeck afteryouinstalltheplate(Figure69).

g294197

g294471

Figure70

1.Adjustingrod3.Adjustmentnut

2.Adjustingblock

2.T oraisethefrontofthemowerdeck,tightenthe adjustmentnut.

3.T olowerthefrontofthemowerdeck,loosenthe adjustmentnut.

4.Afteradjustment,checkthefront-to-rearslope again,continueadjustingthenutuntilthefront bladetipis1.6to7.9mm(1/16to5/16inch) lowerthantherearbladetip;refertoChecking

theFront-to-RearBladeSlope(page45).

5.Whenthefront-to-rearbladeslopeiscorrect, checktheside-to-sidelevelofthemowerdeck again;refertoLevelingfromSidetoSide(page

46).

RemovingtheMowerDeck

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch(PTO),andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Lowertheheight-of-cutlevertothelowest position.

4.Removethehairpincotterfromthefrontsupport rod,andremovetherodfromthedeckbracket (Figure71).

Figure72

1.Liftarm

2.Hairpincotter

3.Washer

7.Removetheliftarmfromthedeckpin(Figure

72).

8.Repeatsteps6and7fortheothersideofthe machine.

9.Slidethemowerdeckrearwardtoremovethe mowerbeltfromtheenginepulley.

10.Slidethemowerdeckoutfromunderneaththe machine.

g295768

Figure71

1.Frontsupportrod2.Deckbracket

5.Carefullylowerthefrontofthemowerdeckto theground.

6.On1sideofthemachine,removethewasher andhairpincotterfromthedeckpin(Figure72).

Note:Retainallpartsforfutureinstallation.

InstallingtheMowerDeck

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch(PTO),andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

g366001

3.Slidethemowerunderthemachine.

4.Lowertheheight-of-cutlevertothelowest position.

5.On1sideofthemachine,lifttherearofthe mowerdeckandinstalltheliftarmtothedeck pin(Figure72).

6.Installtheliftarmusingthewasherandhairpin cotter(Figure72).

7.Repeatsteps5and6fortheothersideofthe machine.

8.Attachthefrontsupportrodtothemowerdeck withtheclevispinandhairpincotter(Figure71).

7.Slidetherodthroughthesecondgrass-deector pivot(Figure73).

9.Installthemowerbeltontotheenginepulley; refertoReplacingtheMowerBelt(page41).

ReplacingtheGrass Deector

ServiceInterval:Beforeeachuseordaily—Inspect

thegrassdeectorfordamage.

WARNING

Anuncovereddischargeopeningcouldallow themachinetothrowobjectstowardyouor bystanders,resultinginseriousinjury.Also, contactwiththebladecouldoccur.

Neveroperatethemachinewithoutthe grassdeector,thedischargecover,orthe grass-collectionsysteminplace.

1.Removethenut(3/8inch)fromtherodunder themower(Figure73).

8.Inserttherodatthefrontofthegrassdeector intothebracketonthedeck.

9.Securetherearendoftherodintothemower withanut(3/8inch)asshowninFigure73.

Important:Thegrassdeectormustbe

spring-loadedinthedownposition.Liftthe deectoruptotestthatitsnapsintothe full-downposition.

Figure73

1.Mowerdeck4.Rod

2.Grass-deectorpivot5.Spring

3.Grassdeector6.Nut(3/8inch)

2.Slidetherodoutofthedeckbracket,spring,and grassdeector(Figure73).

3.Removethedamagedorworngrassdeector.

4.Installthenewgrassdeector(Figure73).

5.Slidethestraightendoftherodthroughtherear grassdeectorpivot.

6.Placethespringontherod,withendwires down,andbetweenthegrassdeectorbrackets.

g296957

Cleaning

7.Disengagetheblade-controlswitch,shutoffthe engine,removethekey,andwaitforallmoving partstostop.

WashingtheUndersideof theMowerDeck

ServiceInterval:Aftereachuse—Cleanthe

mower-deckhousing.

Important:Youcanwashthemachinewithamild

detergentandwater.Donotpressurewashthe machine.Avoidexcessiveuseofwater,especially nearthecontrolpanel,undertheseat,aroundthe engine,hydraulicpumps,andmotors.

Washtheundersideofthemowerdeckaftereachuse topreventgrassbuildupforimprovedmulchaction andclippingdispersal.

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch(PTO),andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Attachthehosecouplingtotheendofthe mowerwashouttting,andturnthewateron high(Figure74).

Note:Spreadpetroleumjellyonthewashout

ttingO-ringtomakethecouplingslideon easierandprotecttheO-ring.

8.Turnthewateroffandremovethecouplingfrom thewashouttting.

Note:Ifthemowerisnotcleanafter1washing,

soakitandletitstandfor30minutes.Then repeattheprocess.

9.Runthemoweragainfor1to3minutesto removeexcesswater.

WARNING

Abrokenormissingwashouttting couldexposeyouandotherstothrown objectsorbladecontact.Contactwitha bladeorthrowndebriscancauseinjury ordeath.

•Replacebrokenormissingwashout ttingimmediately,beforeusing machineagain.

•Neverputyourhandsorfeetunder themowerorthroughopeningsinthe machine.

DisposingofWaste

Engineoil,batteries,hydraulicuid,andengine coolantarepollutantstotheenvironment.Disposeof theseaccordingtoyourstateandlocalregulations.

Figure74

1.Washouttting3.O-ring

2.Hose

4.Lowerthemowertothelowestheight-of-cut.

5.Sitontheseatandstarttheengine.

6.Engagetheblade-controlswitchandletthe mowerrunfor1to3minutes.

4.Coupling

g020098

Storage

StorageSafety

•Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeyouleavethe operator’sposition.Allowthemachinetocool beforeadjusting,servicing,cleaning,orstoringit.

•Donotstorethemachineorfuelnearamesor

drainthefuelindoorsorinsideanenclosedtrailer.

•Donotstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such asonawaterheateroronotherappliances.

Note:Runthemachinewiththeblade-control

switch(PTO)engagedandtheengineathigh idlefor2to5minutesafterwashing.

12.Checktheconditionoftheblades;referto

ServicingtheCuttingBlades(page42).

13.Preparethemachineforstorageforover 30daysasfollows:

A.Addfuelstabilizer/conditionertofreshfuel

inthetank.Followmixinginstructionsfrom thefuelstabilizermanufacturer.Donot useanalcohol-basedstabilizer(ethanolor methanol).

B.Runtheenginetodistributeconditionedfuel

throughthefuelsystemfor5minutes.

CleaningandStorage

1.Parkthemachineonalevelsurface,disengage theblade-controlswitch(PTO),andmovethe motion-controlleversoutwardtothePARK position.

2.Shutofftheengine,removethekey ,andwait forallmovingpartstostopbeforeleavingthe operatingposition.

3.Removegrassclippings,dirt,andgrimefromthe externalpartsoftheentiremachine,especially theengineandhydraulicsystem.Clean dirtandchafffromtheoutsideoftheengine cylinder-headnsandblowerhousing.

Important:Youcanwashthemachine

withmilddetergentandwater.Donot pressure-washthemachine.Avoid excessiveuseofwater,especiallynearthe controlpanel,engine,hydraulicpumps,and motors.

4.Checktheparkingbrakeoperation;refertoPark

Position(page12).

5.Servicetheaircleaner;refertoServicingtheAir

Cleaner(page32).

6.Greasethemachine;refertoLubrication(page

31).

7.Changethecrankcaseoil;refertoServicingthe

EngineOil(page33).

C.Shutofftheengine,allowittocool,and

drainthefueltankusingapumptype syphonoroperateengineuntilitshutsoff.

D.Disposeoffuelproperly.Recyclethefuel

accordingtolocalcodes.

Important:Donotstorefuelcontaining

stabilizer/conditionerlongerthan thedurationrecommendedbythe fuel-stabilizermanufacturer.

14.Removeandchecktheconditionofthespark plug(s);refertoServicingtheSparkPlug(page

35).Withthesparkplug(s)removedfromthe

engine,pour30ml(2tablespoons)ofengine oilintothesparkplughole.Usethestarterto cranktheengineanddistributetheoilinsidethe cylinder.Installthesparkplug(s).Donotinstall thewireonthesparkplug(s).

15.Checkandtightenallfasteners.Repairor replaceanypartthatisdamaged.

16.Paintallscratchedorbaremetalsurfaces.Paint isavailablefromyourAuthorizedServiceDealer.

17.Storethemachineinaclean,drygarageor storagearea.Removethekeyfromtheswitch andkeepitoutofreachofchildrenorother unauthorizedusers.Coverthemachineto protectitandkeepitclean.

8.Checkthetirepressure;refertoCheckingthe

TirePressure(page39).

9.Chargethebattery;refertoChargingtheBattery

(page38).

10.Ifstoringthemachinewiththebatteryinstalled, disconnectthenegative(black)cablefromthe battery.

11.Scrapeanyheavybuildupofgrassanddirt fromtheundersideofthemower,thenwashthe machinewithagardenhose.

StoringtheBattery

1.Fullychargethebattery .

2.Letthebatteryrestfor24hours,thencheckthe batteryvoltage.

Note:Ifthebatteryvoltageisbelow12.6V ,

repeatsteps1and2.

3.Disconnectthecablesfromthebattery.

4.Checkthevoltageperiodicallytoensurethatthe voltageis12.4Vorhigher.

Note:Ifthebatteryvoltageisbelow12.4V ,

repeatsteps1and2.

BatteryStorageTips

Ifyouarestoringthebatteryoutsidethemachine,do thefollowing:

•Storethebatteryinacool,dryareainanupright

position.

•Donotstackbatteriesdirectlyontopofeachother,

unlesstheyareincartons.

•Donotstackmorethan3batteries(only2ifthe

batterytypeiscommercial).

•T estawetbatteryevery4to6monthsandcharge

it,ifnecessary .

•Alwaystestandchargethebatterybefore

installation.

Troubleshooting

Problem

Thefueltankisshowingsignsofcollapsing orthemachineisfrequentlyshowingsigns ofrunningoutoffuel.

Theengineoverheats.

Thestarterdoesnotcrank.

Theenginedoesnotstart,startshard,or failstokeeprunning.

PossibleCauseCorrectiveAction

1.Theair-cleanerpaperelementclogged.

1.Theengineloadisexcessive.1.Reducethegroundspeed.

2.Theoillevelinthecrankcaseislow.2.Addoiltothecrankcase.

3.Thecoolingnsandairpassages undertheengine-blowerhousingare plugged.

4.Theaircleanerisdirty.

5.Dirt,water,orstalefuelisinthefuel system.

1.Theblade-controlswitchisengaged.1.Disengagetheblade-controlswitch.

2.Themotion-controlleversarenotin thePARKposition.

3.Thebatteryisdead.

4.Theelectricalconnectionsare corrodedorloose.

5.Afuseisblown.5.Replacethefuse.

6.Arelayorswitchisdamaged.

1.Thefueltankisempty.1.Fillthefueltank.

2.Thechoke(ifapplicable)isnoton.

3.Theaircleanerisdirty.

4.Thespark-plugwire(s)islooseor disconnected.

5.Thesparkplug(s)ispitted,fouled,or thegapisincorrect.

6.Thereisdirtinfuellter.6.Replacethefuellter.

7.Dirt,water,orstalefuelisinfuel system.

8.Thereisincorrectfuelinthefueltank.

9.Theoillevelinthecrankcaseislow.9.Addoiltothecrankcase.

1.Cleanthepaperelement.

3.Removetheobstructionfromthe coolingnsandairpassages.

4.Cleanorreplacetheair-cleaner element.

5.ContactanAuthorizedServiceDealer

2.Movethemotion-controllevers outwardtothePARKposition.

3.Chargethebattery.

4.Checktheelectricalconnectionsfor goodcontact.

6.ContactanAuthorizedServiceDealer.

2.MovethechokelevertotheON position.

3.Cleanorreplacetheair-cleaner element.

4.Installthewire(s)onthesparkplug.

5.Installanew,correctlygappedspark plug(s).

7.ContactanAuthorizedServiceDealer.

8.Drainthetankandreplacethefuelwith thepropertype.

Theenginelosespower.

1.Theengineloadisexcessive.1.Reducethegroundspeed.

2.Theaircleanerisdirty.

3.Theoillevelinthecrankcaseislow.3.Addoiltothecrankcase.

4.Thecoolingnsandairpassages undertheengineblowerhousingare plugged.

5.Thesparkplug(s)ispitted,fouled,or thegapisincorrect.

6.Thefuel-tankventisblocked.6.ContactanAuthorizedServiceDealer .

7.Thereisdirtinthefuellter.7.Replacethefuellter.

8.Dirt,water,orstalefuelisinthefuel system.

Thereisincorrectfuelinthefueltank.

2.Cleantheair-cleanerelement.

4.Removetheobstructionfromthe coolingnsandairpassages.

5.Installanew,correctlygappedspark plug(s).

ContactanAuthorizedServiceDealer.

Problem

PossibleCauseCorrectiveAction

Themachinedoesnotdrive.

Themachinevibratesabnormally .

Thecuttingheightisuneven.

1.Thebypassvalvesareopen.

2.Thetractionbeltsareworn,loose,or broken.

3.Thetractionbeltsareoffthepulleys.3.ContactanAuthorizedServiceDealer.

4.Thetransmissionhasfailed.4.ContactanAuthorizedServiceDealer.

1.Thecuttingblade(s)is/arebentor unbalanced.

2.Theblademountingboltisloose.2.Tightentheblademountingbolt.

3.Theenginemountingboltsareloose.3.Tightentheenginemountingbolts.

4.Theenginepulley ,idlerpulley,orblade pulleyisloose.

5.Theenginepulleyisdamaged.

6.Thebladespindleisbent.

7.Themotormountislooseorworn.

1.Theblade(s)isnotsharp.1.Sharpentheblade(s).

2.Acuttingblade(s)is/arebent.2.Installanewcuttingblade(s).

3.Themowerisnotlevel.

4.Ananti-scalproller(ifapplicable)isnot setcorrectly .

5.Theundersideofthemowerdeckis dirty.

6.Thetirepressureisincorrect.6.Adjustthetirepressure.

7.Abladespindleisbent.

1.Closethetowvalves.

2.ContactanAuthorizedServiceDealer.

1.Installnewcuttingblade(s).

4.Tightentheappropriatepulley.

5.ContactanAuthorizedServiceDealer.

6.ContactanAuthorizedServiceDealer.

7.ContactanAuthorizedServiceDealer.

3.Levelthemowerfromside-to-sideand front-to-rear.

4.Adjusttheanti-scalpwheelheight.

5.Cleantheundersideofthemower deck.

7.ContactanAuthorizedServiceDealer.

Thebladesdonotrotate.

1.Thedrivebeltisworn,looseorbroken.1.Installanewdrivebelt.

2.Thedrivebeltisoffofthepulley .

3.Thepower-takeoff(PTO)switchor PTOclutchisfaulty.

4.Themowerbeltisworn,loose,or broken.

2.Installthedrivebeltandcheckthe adjustingshaftsandbeltguidesforthe correctposition.

3.ContactanAuthorizedServiceDealer.

4.Installanewmowerbelt.

Schematics

ElectricalDiagram139-2356(Rev.A)

g307974

CaliforniaProposition65WarningInformation

Whatisthiswarning?

Youmayseeaproductforsalethathasawarninglabellikethefollowing:

WARNING:CancerandReproductiveHarm—www.p65Warnings.ca.gov.

WhatisProp65?

Prop65appliestoanycompanyoperatinginCalifornia,sellingproductsinCalifornia,ormanufacturingproductsthatmaybesoldinorbroughtinto California.ItmandatesthattheGovernorofCaliforniamaintainandpublishalistofchemicalsknowntocausecancer,birthdefects,and/orother reproductiveharm.Thelist,whichisupdatedannually,includeshundredsofchemicalsfoundinmanyeverydayitems.ThepurposeofProp65isto informthepublicaboutexposuretothesechemicals.

Prop65doesnotbanthesaleofproductscontainingthesechemicalsbutinsteadrequireswarningsonanyproduct,productpackaging,orliteraturewith theproduct.Moreover,aProp65warningdoesnotmeanthataproductisinviolationofanyproductsafetystandardsorrequirements.Infact,the CaliforniagovernmenthasclariedthataProp65warning“isnotthesameasaregulatorydecisionthataproductis‘safe’or‘unsafe.’”Manyofthese chemicalshavebeenusedineverydayproductsforyearswithoutdocumentedharm.Formoreinformation,gotohttps://oag.ca.gov/prop65/faqs-view-all

AProp65warningmeansthatacompanyhaseither(1)evaluatedtheexposureandhasconcludedthatitexceedsthe“nosignicantrisklevel”;or(2) haschosentoprovideawarningbasedonitsunderstandingaboutthepresenceofalistedchemicalwithoutattemptingtoevaluatetheexposure.

Doesthislawapplyeverywhere?

Prop65warningsarerequiredunderCalifornialawonly.ThesewarningsareseenthroughoutCaliforniainawiderangeofsettings,includingbutnot limitedtorestaurants,grocerystores,hotels,schools,andhospitals,andonawidevarietyofproducts.Additionally,someonlineandmailorder retailersprovideProp65warningsontheirwebsitesorincatalogs.

HowdotheCaliforniawarningscomparetofederallimits?

Prop65standardsareoftenmorestringentthanfederalandinternationalstandards.TherearevarioussubstancesthatrequireaProp65warning atlevelsthatarefarlowerthanfederalactionlimits.Forexample,theProp65standardforwarningsforleadis0.5μg/day,whichiswellbelow thefederalandinternationalstandards.

Whydon’tallsimilarproductscarrythewarning?

•ProductssoldinCaliforniarequireProp65labellingwhilesimilarproductssoldelsewheredonot.

•AcompanyinvolvedinaProp65lawsuitreachingasettlementmayberequiredtouseProp65warningsforitsproducts,butothercompanies

makingsimilarproductsmayhavenosuchrequirement.

•TheenforcementofProp65isinconsistent.

•CompaniesmayelectnottoprovidewarningsbecausetheyconcludethattheyarenotrequiredtodosounderProp65;alackofwarningsfora

productdoesnotmeanthattheproductisfreeoflistedchemicalsatsimilarlevels.

WhydoesToroincludethiswarning?

Torohaschosentoprovideconsumerswithasmuchinformationaspossiblesothattheycanmakeinformeddecisionsabouttheproductstheybuyand use.T oroprovideswarningsincertaincasesbasedonitsknowledgeofthepresenceofoneormorelistedchemicalswithoutevaluatingthelevelof exposure,asnotallthelistedchemicalsprovideexposurelimitrequirements.WhiletheexposurefromToroproductsmaybenegligibleorwellwithinthe “nosignicantrisk”range,outofanabundanceofcaution,TorohaselectedtoprovidetheProp65warnings.Moreover ,ifT orodoesnotprovidethese warnings,itcouldbesuedbytheStateofCaliforniaorbyprivatepartiesseekingtoenforceProp65andsubjecttosubstantialpenalties.

RevA

Toro 75747 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
