RearTineTiller
58603
Motocultor
58603
Motoculteuràdentsarrière
58603
FormNo.3445-373RevB
www.T oro.com.
*3445-373*

FormNo.3443-831RevA
RearTineTiller
ModelNo.58603—SerialNo.321000001andUp
Registeratwww.T oro.com.
OriginalInstructions(EN)
*3443-831*

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
WARNING
CALIFORNIA
Proposition65Warning
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
g356747
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
Thistillerisintendedtobeusedbyresidential
homeownersorprofessional,hiredoperatorsto
breakthroughhardsoilconditionsforplantingand
cultivatinggardens.Usingthisproductforpurposes
otherthanitsintendedusecouldprovedangerousto
youandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely .
Visitwww.Toro.comformoreinformation,including
safetytips,trainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Contactusatwww.Toro.com.
2
PrintedintheUSA
AllRightsReserved

Contents
Safety
Safety.......................................................................3
GeneralSafety...................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................6
1AssemblingtheMachine..................................7
2AddingOiltotheEngine...................................9
ProductOverview...................................................10
Controls...........................................................10
Specications...................................................11
BeforeOperation.................................................12
BeforeOperationSafety...................................12
AddingFuel......................................................13
AdjustingtheHandlebarHeight........................13
DuringOperation.................................................14
DuringOperationSafety...................................14
StartingtheMachine.........................................15
ShuttingOfftheEngine.....................................15
AdjustingtheDragStake..................................15
OperatingTips.................................................16
AfterOperation....................................................16
AfterOperationSafety......................................16
Maintenance...........................................................17
MaintenanceSafety..........................................17
RecommendedMaintenanceSchedule(s)...........17
Pre-MaintenanceProcedures..............................18
PreparingforMaintenance...............................18
Lubrication..........................................................18
GreasingtheMachine.......................................18
EngineMaintenance...........................................19
ServicingtheAirCleaner..................................19
ServicingtheEngineOil....................................20
ServicingtheSparkPlug...................................21
BeltMaintenance................................................22
CheckingandAdjustingtheDrive
Belts..............................................................22
ReplacingtheBelts...........................................23
Cleaning..............................................................26
CleaningtheMachine.......................................26
Storage...................................................................26
StorageSafety..................................................26
StoringtheMachine..........................................26
Troubleshooting......................................................28
Thismachinehasbeendesignedinaccordancewith
ANSIB71.8-2016.
DANGER
Theremaybeburiedutilitylinesinthework
area.Diggingintothemmaycauseashock
oranexplosion.
Havethepropertyorworkareamarkedfor
buriedlinesanddonotdiginmarkedareas.
Contactyourlocalmarkingserviceorutility
companytohavethepropertymarked(for
example,intheUS,call811forthenationwide
markingservice).
GeneralSafety
Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjuryordeath.
•Read,understand,andfollowtheinstructions
andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.
•Bethoroughlyfamiliarwiththecontrolsandthe
properuseoftheequipment.Knowhowtostop
themachineanddisengagethecontrolsquickly .
•Donotputyourhands,feet,otherbodyparts,or
clothingnearorundertherotatingtinesorother
movingpartsofthemachine.
•Donotoperatethemachinewithoutallproper
shields,guards,andothersafetyprotective
devicesinplaceandfunctioningproperlyonthe
machine.
•Keepbystanders,especiallysmallchildren,and
petsoutoftheoperatingarea.
•Donotallowchildrentooperatethemachine.
Allowonlypeoplewhoareresponsible,trained,
familiarwiththeinstructions,andphysically
capabletooperatethemachine.
•Shutoffthemachineandwaitforallmovingparts
tostopbeforeyouleavetheoperator’sposition.
Disconnectthespark-plugwire,keepitawayfrom
theplugtopreventaccidentalstarting,andallow
themachinetocoolbeforeadjusting,fueling,
unclogging,servicing,cleaning,orstoringthe
machine.
Improperlyusingormaintainingthismachinecan
resultininjury .T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol,which
meansCaution,Warning,orDanger—personalsafety
3

instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
133-8062
decal133-8062
1.Engine—shutoff
decal144-4853
144-4853
1.Forwardlever
144-4861
decal144-4861
decal144-4862
144-4862
1.Reverselever
decal144-4857
144-4857
1.Entanglementhazard,belt—stayawayfrommovingparts;
keepallguardsinplace.
4

144-4864
1.Drivemodeselector;Standard-RotatingTines;Drive;Counter-RotatingTines;Neutral.
144-4866
decal144-4864
decal148-4868
1.Warning—readtheOperator’sManual.
6.Warning—lookbehindyouwhenoperatingthemachinein
reverse.
2.Warning—alloperatorsshouldbetrainedbeforeoperating
7.Warning—donotoperateoverburiedlines.
themachine.
3.Warning—keepbystandersaway.
4.Warning—stayawayfrommovingparts;keepallguardsin
place.
8.Warning—keepfeetawayfrommovingparts.
9.Warning—shutofftheengine,disconnectthesparkplug,and
readtheOperator’sManualbeforeperformingmaintenance.
5.Entanglementhazard,belt—stayawayfrommovingparts.
144-4867
1.Tostartthemachine,movetheswitchtotheONposition,movethefuel-valvelevertoopen,movethethrottlelevertothe
FASTposition,engagethechoke,placeonehandonthemachineandpulltherecoilhandle,andmovethechokelevertothe
RUNposition.
decal144-4867
5

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
1
2
Qty.
Tillerassembly1
Handlebarassembly1
Handlebartube1
Wheel2
Lowerpulleyguard1
Pulleyguardplate1
Dragstake1
Bolt(M8x85mm)
Bolt(M6x65mm)
Bolt(M8x16mm)
Bolt(M6x14mm)
Nut(M8)
Nut(M6)
Screw
Pin2
Lockpin1
Engineoil1Addoiltotheengine.
1
2
2
4
1
4
4
Assemblethemachine.
Use
6

1
AssemblingtheMachine
4.Removethewheels.
Partsneededforthisprocedure:
1Tillerassembly
1Handlebarassembly
1Handlebartube
2Wheel
1Lowerpulleyguard
1Pulleyguardplate
1Dragstake
1
Bolt(M8x85mm)
2
Bolt(M6x65mm)
2
Bolt(M8x16mm)
4
Bolt(M6x14mm)
1
Nut(M8)
4
Nut(M6)
4
Screw
2Pin
1Lockpin
5.Assemblethepulleyguards.
1.Screw(4)
2.Pulleyguardplate
g361871
Figure4
g361864
Figure5
3.Lowerpulleyguard
Procedure
1.Removetheloosepartsfromthetopofthebox.
2.Closethebox,turnitupside-down,andcutit
openatthecorners.
3.Cut,remove,anddiscardtherectangleshown
onbothsidesofthefoam.
Figure3
1.Cuthere.
6.Installtheguardstothetillerassembly.
g361866
Figure6
g361865
1.Bolt—M6x14mm(4)2.Nut—M6(2)
7

7.Foreachwheel,slideinthepinandsecurethe
wheelwiththebolt.
Figure7
1.Bolt—M8x16mm(2)2.Pin(2)
8.Turnthemachineoverandremovethefoam.
9.Installthehandlebartubeasfollows:
A.Rotatethespreaderboltclockwise.
B.Insertthehandlebartubeintothered
bracketandsecureitasshown.
g361868
g361867
Figure9
1.Spreaderbolt
1.Nut(M8)3.Bolt(M8x85mm)
2.Handlebartube
C.Removeanddiscardthespreaderbolt.
D.Tightenthefastenersuntilthehandlebar
tubeissnug.
10.Onthehandlebarassembly,connectthecables
tothedriveleversiftheyarenotattached.
g361872
Figure8
Figure10
1.Reardrivelevercable2.Frontdrivelevercable
8
g361873

11.Installthehandlebarassemblyandadjust
theheightasdesired;refertoAdjustingthe
HandlebarHeight(page13).
2
AddingOiltotheEngine
Partsneededforthisprocedure:
1Engineoil
Procedure
1.Movethemachinetoalevelsurface.
Figure11
1.Nut—M6(2)3.Bolt—M6x65mm(2)
2.Wireharnessconnectors
12.Connectthe2wireharnessconnectors.
13.Installthedragstake.
g361870
2.Removethedipstick.
g360549
Figure13
1.Fillertube3.Upperlimit
2.Dipstick4.Lowerlimit
3.Slowlyaddoilintothellertubeuntilitis
overowing.
4.Installthedipstickandtightenit.
Figure12
1.Dragstake2.Lockpin
g361869
9

ProductOverview
Controls
EngineOn/OffSwitch
UsetheengineOn/Offswitchtoshuttheengineoff.
EnsurethattheswitchisintheONpositionbefore
startingtheengine.
Fuel-ValveLever
MovetheleverforthefuelvalvetotheONposition
beforeattemptingtostarttheengine.Afteroperation,
shutofftheengineandmovethefuel-valveleverto
theOFFposition.
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesetting.
Operatethemachineusingfullthrottleforbest
performance.
Figure14
1.Engineon/offswitch
2.Forwardcontrollever8.Fuelcap
3.Rearcontrollever9.Enginecontrols
4.Cableadjustment10.Oil-llcap
5.Drive-modeselectorlever11.Dragstake
6.Recoilhandle
7.Handlebarheight
adjustment
ChokeLever
MovethechokeleverontheenginetotheCHOKE
positionwheninitiallystartingacoldengine,then
moveitintotheRUNpositiononcestarted.
Drive-ModeSelector
Shiftthedrive-modeselectorlevertothedesired
modetochangethetransmission.
g356778
Important:Donotshiftthedrive-modeselector
leverwhileengagingtheforwardorreverse
controllevers.
•Standard-rotatingtines(SRT):Thewheelsand
tinesarebothengagedwiththeengine;thetines
spininthesamedirectionasthewheels.Usethis
modeforestablishedgardenbedsandtillingin
softsoilconditions.
g356990
Figure15
10

•Drive:Onlythewheelsareengagedwiththe
engine;thetinesaredisengaged.Usethismode
forpoweredtransportationwhendrivingupsteep
inclinesandmovingthemachinetoandfromyour
garden.
Drive-ControlLevers
Pulldowntheforwardlevertoengagethetransmission
intheforwarddirection;pulluponthereverseleverto
engagethetransmissioninthereversedirection.
Releasetheleverstodisengagethetransmission.
Important:Donotattempttoengagetheforward
andreverseleversatthesametime.
WARNING
Contactwithmovingtinescanresultin
personalinjury.
Figure16
•Counter-rotatingtines(CRT):Thewheelsand
tinesarebothengagedwiththeengine;thetines
spinintheoppositedirectionofthewheels.Use
thismodewhenbreakingnewgroundortillingin
compactedsoilconditions.
Figure17
•Neutral:Thewheelsandtinesareboth
disengagedfromtheengine.Usethismodefor
storageandnon-poweredtransportation.
g356988
Whenmovingthemachineinreverse,watch
forobstaclesbehindyouandkeepyourfeet
awayfromthetines.
g357052
Figure19
g356987
1.Forwardlever2.Reverselever
Specications
Specicationsanddesignaresubjecttochange
withoutnotice.
Figure18
Height
Length
Width
Weight
Tillingwidth
Tillingdepth
g356989
Toensureoptimumperformanceandcontinuedsafety
103.1cm(40.6inches)
158.8cm(62.5inches)
50.8cm(20.0inches)
72.6kg(160lb)
43.2cm(17inches)
28cm(1 1inches)
certicationofthemachine,useonlygenuineT oro
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
11

Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
BeforeOperation
•Donotllthefueltankindoors.
•Donotoverllthefueltank.Replacethefuelcap
andtightenitsecurelyafterfueling.Cleanup
spilledfuelbeforestartingtheengine.
•Donotllcontainersinsideavehicleoronatruck
ortrailerbedwithaplasticliner.Alwaysplace
containersontheground,awayfromthevehicle
beforelling.
BeforeOperationSafety
GeneralSafety
•Donotallowchildrenoruntrainedadultstooperate
orservicethemachine.Localregulationsmay
restricttheageoftheoperator.
•Usingthismachineisstrenuous.Youmustbein
goodphysicalconditionandmentallyalert.Ifyou
haveanyconditionthatmightbeaggravatedby
strenuouswork,checkwithyourdoctorbefore
operatingthemachine.
•Shutoffthemachineandwaitforallmovingparts
tostopbeforeyouleavetheoperator’sposition.
Disconnectthespark-plugwire,keepitawayfrom
theplugtopreventaccidentalstarting,andallow
themachinetocoolbeforeadjusting,fueling,
unclogging,servicing,cleaning,orstoringthe
machine.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Checkthatallguardsandsafetydevices,suchas
deectors,areinplaceandfunctioningproperly.
Donotoperatethemachineunlesstheyare
functioningproperly.
•Knowhowtoshutofftheenginequickly.
•Keepbystanders,especiallysmallchildren,and
petsoutoftheoperatingarea.
•Thoroughlyinspecttheareawhereyouwilluse
themachineandremoveallobjectsthatcould
interferewiththeoperationofthemachineorthat
themachinecouldthrow.
•Removethemachinefromthetruckortrailer
beforellingthefueltank.Ifthisisnotpossible,
thenaddfuelfromaportablecontainerratherthan
fromafuel-dispensernozzle.
•Keepthefuel-dispensernozzleincontactwith
therimofthefueltankorcontaineropeningat
alltimesuntilfuelingiscomplete.Donotusea
nozzlelock-opendevice.
•Ifyouspillfuelonyourclothing,changeyour
clothingimmediately.
•Ifyouspillfuel,donotattempttostarttheengine;
movethemachineawayfromthespillandavoid
creatingasourceofignitionuntilthefuelvapors
havedissipated.
•Ifyoumustdrainthefueltank,doitoutdoors.
•Storefuelinafuelcontainerandkeepitoutofthe
reachofchildren.
•Donotstorethemachinewithfuelinthefueltank
orfuelcontainerwherethereisanopename,
spark,orpilotlight,suchasonawaterheateror
otherappliance.Allowtheenginetocoolbefore
storingthemachineinanyenclosure.
•Fuelisharmfulorfatalifswallowed.Long-term
exposuretovaporscancauseseriousinjuryand
illness.
–Avoidprolongedbreathingofvapors.
–Keepyourhandsandfaceawayfromthe
nozzleandthefuel-tankopening.
–Keepfuelawayfromyoureyesandskin.
FuelSafety
•Useextremecareinhandlingfuel.Itisextremely
ammableanditsvaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.
•Useonlyanapprovedfuelcontainer.
•Donotremovethefuelcaporaddfueltothetank
whiletheengineisrunningorhot.
•Allowtheenginetocoolbeforellingthefueltank.
12

AddingFuel
FuelSpecications
TypeUnleadedgasoline
Minimumoctanerating
Ethanol
MethanolNone
MTBE(methyltertiarybutyl
ether)
OilDonotaddtothefuel
Useonlyclean,fresh(nomorethan30daysold),fuel
fromareputablesource.
UsingStabilizer/Conditioner
Usefuelstabilizer/conditionerinthemachinetokeep
thefuelfreshlongerwhenusedasdirectedbythe
fuel-stabilizermanufacturer.
Important:Donotusefueladditivescontaining
methanolorethanol.
Addtheamountoffuelstabilizer/conditionertofresh
fuelasdirectedbythefuel-stabilizermanufacturer.
87(US)or91(research
octane;outsidetheUS)
Nomorethan10%byvolume
Lessthan15%byvolume
FillingtheFuelTank
FillthefueltankasshowninFigure20.
g230458
Figure20
AdjustingtheHandlebar
Height
Thehandlebarhas3heightpositionstoaccommodate
varyinguserheights.Whenadjustingtheheight,
notethatduringnormaltillingoperation,theactual
handlebarpositiondropsupto25cm(10inches)from
normalheight.
Removethehardwarefromthehandlebarassembly,
rotatetheassemblytomatchtheholesatthedesired
position,andinstallthehardware.
•Lowheight:UseholesBandC.
•Middleheight:UseholesCandD.
•Highheight:UseholesAandD.
Figure21
g357053
13

DuringOperation
•Donotoverloadthemachinecapacityby
attemptingtotillorcultivatetoodeepandattoo
fastarate.
DuringOperationSafety
GeneralSafety
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Wearappropriateclothing,includingeye
protection;longpants;substantial,slip-resistant
footwear;hearingprotection;andgloves.Tieback
longhairanddonotwearlooseclothingorloose
jewelry.
•Keepyourhands,feet,otherbodyparts,and
clothingawayfromrotatingtinesandmovingparts
ofthemachine.Thetinesbeginrotatingwhen
youstarttheengineandmaycontinuetorotate
momentarilyafteryoushutofftheengine.
•Starttheenginecarefullyaccordingtoinstructions
inthisOperator’sManualandwithyourfeetwell
awayfromthetines.
•Useextremecautionwhenreversingorpulling
themachinetowardyou.T oavoidgettingpinned
againstastructure,allowenoughdistanceto
reversedirectionnearawallorfence.
•Keepbystandersoutoftheoperatingarea.Keep
smallchildrenoutoftheoperatingareaandunder
thewatchfulcareofaresponsibleadultwhois
notoperatingthemachine.Stopthemachineif
anyoneentersthearea.
•Beforeyoustarttheengine,ensurethatalldrives
areinneutralandyouareintheoperatingposition.
•Operatethemachineonlyingoodvisibilityand
appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflightning.
•Donotattempttoadjustthemachinewhilethe
engineisrunning.
•Ifthemachinestrikesanobjectorstartstovibrate
abnormally,immediatelyshutofftheengine,wait
forallmovingpartstostop,anddisconnectthe
wirefromthesparkplugbeforeexaminingthe
machinefordamage.Vibrationisoftenawarning
signoftrouble.Makeallnecessaryrepairsbefore
resumingoperation.
•Donotpickuporcarryamachinewhiletheengine
isrunning.
•Exercisecautionandbesureofyourfooting,
especiallywhenbackingup,toavoidslippingor
falling.
•Becarefulwhenoperatingthemachineinhard
ground.Thetinescancatchinthegroundand
propelthemachineforward.Ifthisoccurs,letgo
ofthemachine;donottrytorestrainit.
•Exerciseextremecautionwhencrossinggravel
surfaces.Stayalertforhiddenhazardsortrafc.
•Donotleavearunningmachineunattended.
•Shutoffthemachineandwaitforallmovingparts
tostopbeforeyouleavetheoperator’sposition.
Disconnectthespark-plugwire,keepitawayfrom
theplugtopreventaccidentalstarting,andallow
themachinetocoolbeforeadjusting,fueling,
unclogging,servicing,cleaning,orstoringthe
machine.
•Operatetheengineonlyinwell-ventilatedareas.
Exhaustgasescontaincarbonmonoxide,whichis
anodorless,deadlypoison.
•Useonlyaccessoriesandattachmentsapproved
byTheT oro®Company.
•Donotchangetheenginegovernorsettingsor
overspeedtheengine.
•Alwaysbesureofyourfooting;keeparmholdon
thehandleandwalk,neverrun.
•Allowthemuferandengineareatocoolbefore
touchingthem.
•Thetinesshouldnotrotatewhentheengineis
idling;iftheydorotate,contactyourAuthorized
ServiceDealer.
•Ifanobjectbecomeslodgedinthetines,shutoff
theengine,disconnectthewirefromthespark
plug,andallowtheenginetocoolbeforeremoving
theobject.
•Donotoperatethemachineonsteepslopes.T o
preventoverturning,operatethemachineupand
downtheslope.
•Donotoperatethemachineathightransport
speedsonhardorslipperysurfaces.
•Lookbehindanddownandusecarewhen
reversing.
14

StartingtheMachine
AdjustingtheDragStake
1.Movetheengineon/offswitchtotheONposition.
2.Movethefuel-valvelevertotheOPENposition.
3.MovethethrottlelevertotheFASTposition.
4.MovethechokelevertotheCHOKEposition.
Note:Awarmorhotenginemaynotrequire
choking.
5.Pullthestarterhandlelightlyuntilyoufeel
resistance,thenpullthehandlebriskly.Return
thestarterhandlegently.
6.Aftertheenginestarts,graduallymovethe
chokelevertotheRUNpositionandthethrottle
levertotheFASTposition.
ShuttingOfftheEngine
1.Releasethedrive-controllevers.
2.MovethethrottlelevertotheSLOWposition.
3.Movetheengineon/offswitchtotheOFF
position.
4.Movethefuel-valvelevertotheCLOSEDposition.
Adjustthedragstakeasneededforthedrivemode.
•CRTmode:Thedragstakehelpsregulatetilling
depthduringCRTmode.Lowerthedragstake
toreducethetillingdepth;raisethedragstaketo
increasethetillingdepth.
•SRTmode:Thedragstakelimitstheforward
speedduringSRTmode.Lowerthedragstaketo
reducetheforwardspeedorifthemachinejerks
forward
•Driveorneutralmode:Raisethedragstake
whentransportingthetiller.
1.Movethemachinetoalevelsurface,shutoffthe
engine,andwaitforallmovingpartstostop.
2.Removethelockpin.
3.Positionthedragstaketothedesireddepth.
Note:Adjustthedragstake1holeatatimeand
testthetilleroperationaftereachadjustment.
Raisingthedragstaketoohighcanresultinloss
ofcontrolofthetiller.
4.Securethedragstakewiththelockpin.
5.Waitforallmovingpartstostopbeforeleaving
theoperatingposition.
g357054
Figure22
1.Lockpin3.Dragstake—shallowtilling
2.Dragstake—deeptilling
15

OperatingTips
•Inspecttheareawhereyouwillusethemachine
andremoveallobjectssuchaslargerocks,trash,
andbranchesbeforetillingtopreventequipment
damage.
•Donotplaceexcessivebodyweightonthe
machine.Usetheweightofthemachinetotillthe
soilmoreefciently.
•Whentilling,beginwithashallowcutontherst
passandthenincreasethedepthby2.5to5.1cm
(1to2inches)oneachsuccessfulpathuntilyou
reachthedesireddepth.
•Plantgardenrows51to56cm(20to22inches)
aparttoalloweaseofturningattheendofeach
row.
•Whennottilling,movethethrottleleverbetween
halfthrottleandtheSLOWpositiontoextendengine
life,conservefuel,andreducesoundlevels.
AfterOperation
AfterOperationSafety
GeneralSafety
•Shutoffthemachineandwaitforallmovingparts
tostopbeforeyouleavetheoperator’sposition.
Disconnectthespark-plugwire,keepitawayfrom
theplugtopreventaccidentalstarting,andallow
themachinetocoolbeforeadjusting,fueling,
unclogging,servicing,cleaning,orstoringthe
machine.
•Cleandebrisfromthemachinetohelpprevent
res.Cleanupoilorfuelspills.
HaulingSafety
•Disconnectthewirefromthesparkplugbefore
loadingthemachineforhauling.
•Usecarewhenloadingorunloadingthemachine.
16

Maintenance
MaintenanceSafety
•Inspectthemachinefrequentlytoensurethatit
isinsafeworkingconditionandthatshearbolts,
engine-mountingbolts,andotherfastenersare
properlytightened.
•Shutoffthemachineandwaitforallmovingparts
tostopbeforeyouleavetheoperator’sposition.
Disconnectthespark-plugwire,keepitawayfrom
theplugtopreventaccidentalstarting,andallow
themachinetocoolbeforeadjusting,fueling,
unclogging,servicing,cleaning,orstoringthe
machine.
•Wearglovesandeyeprotectionwhenservicing
themachine.
RecommendedMaintenanceSchedule(s)
•Nevertamperwithsafetydevices.Checktheir
properoperationregularly.
•Toensureoptimumperformanceofthemachine,
useonlygenuineT ororeplacementpartsand
accessories.Replacementpartsandaccessories
madebyothermanufacturerscouldbedangerous,
andsuchusecouldvoidtheproductwarranty.
•Replacetinesthatarebent,damaged,orloose;do
notrepairoralterthem.
•Keepthemachine,attachments,andaccessories
insafeworkingcondition.
•Donotattempttorepairthemachineunless
youhavethepropertoolsandinstructionsfor
disassembling,assembling,andrepairingthe
machine.
MaintenanceService
Interval
Aftertherst5hours
Beforeeachuseordaily
Every10hours
Every25hours
Every50hours
Yearly
MaintenanceProcedure
•Changetheengineoil.
•Checktheengine-oillevel.
•Cleandebrisfromthemufer,controls,andair-intakegrille.
•Cleanthetineandwheelshafts
•Lubricatemovingparts.
•Checkthebelttension.
•Servicetheaircleaner(moreoftenindirtyordustyconditions).
•Cleanthepre-cleanerelement.
•Changetheengineoil(moreoftenindustyconditions).
•Replacethebelts.
•Checkthemuferandsparkarrester.
•Replacethepre-cleanerelement.
•Replacethefuellter.
•Replacethesparkplug.
•Checkthebelttension.
•Cleantheengineair-coolingsystem(moreoftenindustyconditions).
Important:Refertoyourenginemanualforadditionalmaintenanceprocedures
17

Pre-Maintenance
Lubrication
Procedures
GreasingtheMachine
PreparingforMaintenance
1.Movethemachinetoalevelsurface,shutoffthe
engine,andwaitforallmovingpartstostop.
2.Disconnectthespark-plugwirefromthespark
plug.
Figure23
1.Spark-plugwire
3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.
Important:Beforetippingthemachine,
allowthefueltanktorundrythroughnormal
usage.Ifyoumusttipthemachinepriorto
runningoutoffuel,useahandfuelpumpto
removethefuel.
Greasetype:Whitelithiumgrease
Greasethemachineatthefollowinglocations:
•Forwardandreversearmassemblies
•Forwardandreverseengagementlevers
•Forwardandreversecables.
g361695
18

EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Every25hours/Yearly(whichever
comesrst)—Servicetheair
cleaner(moreoftenindirtyordusty
conditions).
Every25hours/Yearly(whichevercomes
rst)—Cleanthepre-cleanerelement.
ServicingtheFoamElement
1.Removethefoampre-cleanerfromthepaper
element.
2.Washthepre-cleanerwithwarmwateranda
milddetergent.
3.Rinsethepre-cleanerandallowittoairdry.
Important:Replacethefoampre-cleanerifitis
tornorworn.Donotoilthepre-cleaner.
Yearly—Replacethepre-cleanerelement.
RemovingtheAirCleaner
Elements
1.Cleanaroundtheair-cleanercovertoprevent
dirtfromgettingintotheengineandcausing
damage.
2.Loosenthefasteneronthecover.
3.Removethecover.
4.Removethefastenerontheelements.
5.Carefullyremovethefoampre-cleanerand
paperelementfromthebase.
ServicingthePaperElement
1.Cleanthepaperelementbytappingitgentlyto
removedust.
Note:Ifitisverydirty,replacethepaper
elementwithanewone.
2.Inspecttheelementfortears,anoilylm,or
damagetotherubberseal.
3.Replacetheelementifitisdamaged.
Important:Donotcleanthepaperelement.
Figure24
1.Cover
2.Fastener
3.Pre-cleaner6.Air-cleanerbase
4.Paperelement
5.Stud
g359988
19

InstallingtheAirCleanerElements
1.Installthefoampre-cleanerelementoverthe
paperelement.
Note:Ensurethatyoudonotdamagethe
elements.
2.Installtheair-cleanerelementsontothe
air-cleanerbaseandontothestud.
3.Securetheelementsusingthefastener.
4.Installthecoverandsecureitwiththefastener.
ServicingtheEngineOil
Engine-OilSpecications
Engineoilcapacity
OilviscosityRefertothechartbelow.
APIserviceclassicationSJorhigher
0.54to0.59L(18to20oz)
Figure26
g359987
Figure25
1.Cover
2.Fastener
3.Pre-cleaner6.Air-cleanerbase
4.Paperelement
5.Stud
CheckingtheEngine-OilLevel
ServiceInterval:Beforeeachuseordaily
1.Movethemachinetoalevelsurface.
2.Removethedipstickandwipetheendclean.
g359988
Figure27
1.Fillertube3.Upperlimit
2.Dipstick4.Lowerlimit
3.Insertthedipstickfullyintotheoil-lltube,but
donotturnortightenit.
20
g360042

4.Removethedipstickandchecktheengine-oil
level.EnsurethattheoilisatthetopoftheFull
indicatoronthedipstick..
7.Ensurethattheoilisatthecorrectlevelonthe
dipstick;refertoCheckingtheEngine-OilLevel
(page20).
5.Iftheoillevelislow,slowlyaddoilintotheller
tubeuntilitisoverowing.
6.Installthedipstickandtightenit.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours/Afterthe
rstmonth(whichevercomes
rst)—Changetheengineoil.
Every50hours—Changetheengineoil(more
oftenindustyconditions).
Note:Runtheengineafewminutesbeforechanging
theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.
1.Movethemachinetoalevelsurface.
2.RefertoPreparingforMaintenance(page18).
3.Placeapanunderthedrainplugtocatchtheoil.
4.Removetheoil-llplugandallowtheoiltodrain.
Note:Disposeoftheusedoilatacertied
recyclingcenter.
8.Wipeupanyspilledoil.
ServicingtheSparkPlug
ServiceInterval:Yearly
Ensurethattheairgapbetweenthecenterandside
electrodesiscorrectbeforeinstallingthesparkplug.
Useasparkplugwrenchforremovingandinstalling
thesparkplug(s)andagappingtool/feelergaugeto
checkandadjusttheairgap.Installanewspark
plug(s)ifnecessary.
Type:BriggsandStratton797235
Airgap:0.75mm(0.03inch)
RemovingtheSparkPlug
1.Disconnectthespark-plugwirefromthespark
plug.
Figure28
5.Installtheoil-llplug.
6.Slowlypouroilintotheoil-llholeuntilthe
oilisatthecorrectlevel;refertoEngine-Oil
Specications(page20).
g361695
Figure29
1.Spark-plugwire
g360043
2.Cleanaroundthesparkplugstopreventdirt
fromenteringtheengineandpotentiallycausing
damage.
3.Removethesparkplug.
g031623
21

CheckingtheSparkPlug
Important:Donotcleanthesparkplug(s).
Alwaysreplacethesparkplug(s)whenithasa
blackcoating,wornelectrodes,anoilylm,or
cracks.
Ifyouseelightbrownorgrayontheinsulator,the
engineisoperatingproperly.Ablackcoatingonthe
insulatorusuallymeanstheaircleanerisdirty .
BeltMaintenance
CheckingandAdjustingthe
DriveBelts
ServiceInterval:Every10hours
Yearly
Setthegapto0.75mm(0.03inch).
Figure30
InstallingtheSparkPlug
Thebelttensionmaydecreaseovertime.Y oumay
needtoadjustthebeltwithinthersthalfhourof
operationduetoinitialbeltstretch.
Important:Checkthebelttensionregularly.
Improperbelttensionmaycauseprematurebelt
wear.
Thebeltmayneedadjustmentifthereisaconstant
squealingsoundwhilethetinesareengagedorifthe
g027479
beltslipsandthewheelsandtinesdonotturn.
CheckingandAdjustingthe
ForwardDriveBeltTension
1.Withtheforwarddrive-controlleverintheneutral
position,measurethelengthofthespringonthe
forwarddrivecable.
2.Pulldowntheforwardleverandmeasurethe
lengthoftheextendedspring.Thedifference
shouldbe5mm(3/16inch).
Figure31
g027480
g357813
Figure32
1.Springonforwarddrive
cable
2.Stretchdifferenceof5mm
(3/16inch)
3.Ifthebeltneedsadjustment,loosentheupper
jamnut,thentightenthelowerjamnutin0.32
cm(1/8inch)increments.Checkthetension
again,andrepeatasnecessary
3.Lowerjamnut
4.Upperjamnut
Note:Ifthetensionisincorrectandyoucannot
adjustthejamnutsfurther,replacethebelt.
22

AdjustingtheReverseDriveBelt
Tension
Ifthemachinedoesnotoperateinreversewhenthe
reversedrive-controlleverisengaged,adjustthejam
nutsonthereversedrivecable1turnatatimeuntil
thereversedrivecontrolfunctionsproperly.
Note:Ifthemachinedoesnotoperateinreverse
andyoucannotadjustthejamnutsfurther,replace
thebelt.
ReplacingtheBelts
ServiceInterval:Every50hours
6.Pullthereversearmawayfromtheengine
pulley.Use2wrenches(13mm)toloosenthe
idlerpulleyonthearmsothatyoucanremove
thereversedrivebelt.
RemovingtheBelts
1.Parkthemachineonalevelsurface,shutoff
theengine,andwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
2.Removethesparkplugwire.
3.Shiftthedrive-modelevertotheNEUTRAL
position.
4.Removethewheels,upperpulleyshrouds,and
lowerpulleyguards.
g356686
Figure34
1.Reversearm3.Wirebeltguide
2.Idlerpulley4.Reversedrivebelt
7.Gentlyrotatethetransmissionpulleyandforce
theforwarddrivebeltoutofthegrooveand
awayfromthepulley.
Figure33
5.Detachtheforwardandreversedrivecables
fromthedrivecontrollevers.
g356685
Figure35
g357906
23

8.Pushuponthebelt,andpullitoffandaway
fromthepulley.
Figure36
InstallingtheBelts
1.Placethereversedrivebeltinthetransmission
pulleygroove.
g356684
9.Removethereversedrivebeltfromthe
transmissionpulley.
Figure37
g356683
Figure38
2.Placetheforwarddrivebeltintheenginepulley
groove,betweenthewireguides.
g356683
g356682
Figure39
1.Wireguide
24

3.Gentlyrotatethetransmissionpulleyandforce
theforwarddrivebeltintothegroove.
Figure40
4.Slidethereversedrivebeltontothereversearm
idlerpulley,betweenthewirebeltguides,and
intothegroove.
7.Installtheuppershroudsandlowerpulley
guards.
g356685
g357906
Figure42
8.Installthewheels.
9.Installthesparkplugwire.
Figure41
1.Reversearm3.Wirebeltguide
2.Idlerpulley4.Reversedrivebelt
5.Tightentheidlerpulleysothatthewirebelt
guidesdonotcontactthebeltwhenthereverse
driveleverisengaged.
6.Connecttheforwardandreversedrivecablesto
thedrivecontrollevers.
g356686
25

Cleaning
Storage
CleaningtheMachine
Beforeeachuseordaily
1.Tipthetillertowardtheengineandblockitinto
positionsothatitrestsonthelowerpulleyguard
andthetinesareexposed.
2.Removealldebrisontheaxlebetweenthetines
andtransmissionhousing.
Note:Toassistcleaning,removethetines;
loosenandremovetheboltandnutonthetine
shaftandslidethetinesofftheshaft.
3.Tipthetillertoalevelposition.
4.Removealldebrisontheaxlesbetweenthe
wheelsandtransmissionhousing.
Toassistcleaning,removethewheelsas
follows:
A.Raisethemachinesothatthewheelsdo
notsupporttheweightofthemachine.
B.Loosentheboltonthewheelshaft.
C.Slidethewheelsoff,ensuringtonotlose
thewheelpinontheshaft.
Note:Ifthewheelsaredifculttoremove,
threadabolt(M10x25mm,orlonger)into
thewheelhubandrotateitclockwiseuntil
thewheelreleasesfromtheshaft.
StorageSafety
•Shutoffthemachineandwaitforallmovingparts
tostopbeforeyouleavetheoperator’sposition.
Disconnectthespark-plugwire,keepitawayfrom
theplugtopreventaccidentalstarting,andallow
themachinetocoolbeforeadjusting,fueling,
unclogging,servicing,cleaning,orstoringthe
machine.
•Runtheenginedryorremovethefuelwithahand
pump;neversiphonthefuel.Ifyoumustdrainthe
fueltank,doitoutdoors.
•FollowtheinstructionsinthisOperator’sManual
tosafelyunload,transport,andstorethemachine.
•Donotstorethemachinewithfuelinthefuel
tankinsideabuildingwhereignitionsourcesare
present,suchashotwaterandspaceheatersand
clothesdryers.Allowtheenginetocoolbefore
storingthemachineinanenclosure.
•AlwaysrefertotheOperator’sManualfor
importantdetailsifthemachineistobestoredfor
anextendedperiod.
StoringtheMachine
1.Parkthemachineonalevelsurface,shutoff
theengine,andwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
2.Removedebrisfromthetines,axle,transmission
housing,andengine;refertoCleaningthe
Machine(page26).
5.Tipthetillertoalevelposition.
Figure43
Important:Youcanwashthemachine
withmilddetergentandwater.Donot
pressure-washthemachine.Avoid
excessiveuseofwater,especiallynearthe
engineandtransmission.
3.Coattheaxleslightlywithaxlegrease.
4.Servicetheairlter;refertoServicingtheAir
Cleaner(page19).
5.Changetheengineoil;refertoServicingthe
EngineOil(page20).
g360526
6.Preparethemachineforstorageforover
30daysasfollows:
A.Addfuelstabilizer/conditionertofreshfuel
inthetank.Followmixinginstructionsfrom
thefuelstabilizermanufacturer.Donot
useanalcohol-basedstabilizer(ethanolor
methanol).
B.Runtheenginetodistributeconditionedfuel
throughthefuelsystemfor5minutes.
C.Shutofftheengine,allowittocool,and
drainthefueltank.
26
