Single Station Waterproof Timer
712345
6
Single Station Waterproof Timer
Installation and Programming Guide
Installation and Programming Guide
Features
• Up to four irrigation cycles per day
• Easy installation and programming
• Battery powered
• Waterproof and weather resistant
1234
AM
PM
24
SSMTWT
F
Part No.: 53887
i
Page 2
Table of Contents
Parts Identication ................................................................................................................ 1
Battery Installation ................................................................................................................ 2
Attaching the SST to a Valve ................................................................................................. 3
LCD Display Overview ......................................................................................................... 4
Programming the SST ........................................................................................................... 5
AM/PM or 24-Hour .............................................................................................................. 5
Set Clock ............................................................................................................................... 6
Set Current Day .................................................................................................................... 6
Set Run Time ........................................................................................................................ 7
Set Start Time ....................................................................................................................... 7
Set Watering Days ................................................................................................................ 8
O Mode .............................................................................................................................. 9
Sleep Mode ........................................................................................................................... 9
Manual Operation ................................................................................................................ 10
Stopping the Current Irrigation Cycle .................................................................................. 10
Installing a Rain Sensor ........................................................................................................ 11
e Reset Button .................................................................................................................. 12
Troubleshooting Guide ......................................................................................................... 13
ii
ii
Page 3
1
1
2
2
3
3
5
5
4
4
Parts Identification
Congratulations on purchasing a Toro® Single
Station Timer (SST). You have a powerful
but easy to use battery-operated valve
controller that ts most common valves*.
e SST comes with a DC-Latching solenoid
attached, making connecting to your valve
simple and easy.
Please review the graphic to the right to
familiarize yourself with all components.
1. Top cover
2. Timer display
3. Timer control panel
4. Solenoid (DC-Latching)
5. Valve (not included)
* The SST is not recommended for use with Lawn Genie
valve model 54048 at pressures above 130 psi.
1
Page 4
Battery Installation
Battery installation should take place before attaching the SST to a valve. If you have
already attached the SST to a valve, you will need to detach it.
1. Place the SST face down. e battery
compartment is sealed with four (4) screws.
2. Unscrew all screws and remove the battery
compartment lid using a Phillips screw driver.
3. Install one 9-volt battery (not included).
Observe the polarity of the picture.
4. Reattach the lid and screws, ensuring the
rubber sealing gasket is in place.
e battery should be replaced as part of
yearly maintenance. e controller will
maintain time/day/program for 32 minutes
without a battery installed.
2
9V
Page 5
Attaching the SST to a Valve
e SST includes a pre-wired DC-latching solenoid*. e existing solenoid on your valve
is not necessary. Follow the directions below to attach the SST to your valve:
1. Turn water o to the valve.
2. Unscrew the existing solenoid
and discard.
3. Screw in the included adapter
(if necessary) (Figure 1).
4. Screw the Toro solenoid onto
the adapter (Figure 1).
5. Mount the SST onto the
solenoid (Figure 2).
6. Turn water back on.
* e included DC-latching solenoid is not compatible with Hunter® brand valves. Use of the SST with Hunter valves
requires a Hunter DC-latching solenoid (sold separately).
Hunter is a trademark of Hunter Industries.
Figure 1
Figure 2
3
Page 6
LCD Overview
712345
6
1234
AM
PM
24
1
1
3
3
2
2
4
4
10
6
6
5
5
7
7
9
9
8
8
1. Low battery indicator. If the icon is ashing, the battery is low and should be
changed. If the icon is solid, the controller will not operate. Replace the battery.
2. Set current time indicator
3. Digital display. Shows the current time
or run-time during programming.
4. Day of week indicator
5. Start time of the program indicated
6. Indicates if the controller is OFF (solid)
or rain sensor delay is active (ashing)
7. Active irrigation icon
8. Manual program indicator
9. Active start time (ere are four available start times.)
10. Clock format (12 or 24 hour)
4
Page 7
Programming the SST
Every programming operation begins by pressing the MODE button.
A long press (>2 seconds) turns the controller o. A short press (<2
seconds) advances the controller through the dierent programming
functions in the order that follows.
Programming the Controller during active irrigation is not possible. Stop the irrigation
cycle rst (page 10).
When in Programming mode, the controller will revert to the Home screen after 15
seconds of inactivity.
AM/PM or 24-Hour
1. Press the Mode button for <2 seconds until the AM / PM / 24 and icon
shows.
2. Press the or buttons to select AM/PM or 24-hour mode.
3. Press the button once to set and advance to the next programming option.
e Mode Button
5
Page 8
Set Clock
1. e icon shows. e hour number (12:00 or 00:00 depending on mode
chosen above) will ash. Press or to cycle to the correct hour.
If in AM/PM mode, AM or PM will be set in Step 5.
2. Press to enter selection.
3. e minute number (00:00) will ash. Press or to cycle to the correct
minute.
4. 24-hour mode: Press once to set and advance to the next programming option.
5. AM/PM mode: Press or to select AM or PM. Press once to set and
advance to the next programming option.
Set Current Day
1. A day number will ash. Press or to cycle to the
6
correct day. Monday is day #1, Tuesday is day #2, etc.
2. Press once to set and advance to the next programming option.
6
712345
Page 9
1234
Set Run Time
1. e icon shows. e default run time per program is 10 minutes.
2. Press or to adjust the hours. Press .
3. Press or to adjust the minutes.
4. Press once to set and advance to the next programming option.
Set Start Time
is setting has 4 possible start times to allow watering up to four times a day.
1. e icon shows and “1” ashes.
Press to select desired start time (
).
2. If the Start Time is not set, --:-- will ash. Press or to activate start time.
Press to set.
3. e hour number (12:00 or 00:00 depending on mode chosen above) will ash.
7
Page 10
Press or to cycle to the correct start time hour. Press to set.
71
2
3
4
5
6
4. e minute number (00:00) will ash. Press or to advance to the correct
start time minute. Press to set.
5. If in AM/PM mode, press or to select AM or PM. Press to set.
6. Repeat steps 2 through 5 to set additional start times, or press to advance
through the remaining start times.
Set Watering Days
1. e day numbers show. “1” is ashing.
2. Press to activate irrigation for the day or to make it a non-watering day.
3. Press to move to the next day.
4. Repeat steps 2 and 3 to program the entire week.
5. Press to set. e controller display will
return to the Home screen.
If irrigation starts on a watering day and runtime carries over into a non-watering
8
A boxed number is a watering day. A number
without a box is a non-watering day.
Page 11
day, irrigation will run past midnight.
Off Mode
OFF mode turns o the watering program. Active Day boxes disappear. e time display
and “OFF” toggle back and forth on the display. e current day ashes.
1. Press for >2 seconds to activate OFF mode.
2. Press again to cancel the OFF mode and return to active watering.
Sleep Mode
e Display goes to sleep after 5 minutes of inactivity. is is to save battery life.
Nothing is shown in the display, but the controller will still irrigate on schedule. If
is pushed, the display will come on.
9
Page 12
Manual Operation
1. To turn on the valve manually,
press and together.
2. e valve will run for the programmed run-time
(page 8).
3. To prematurely STOP a manual operation,
press and together.
Stopping the Current Irrigation Cycle
It is possible to stop the current irrigation cycle. is might be done due to rainfall, a
broken valve, or any number of reasons.
1. Press for >2 seconds to stop the current irrigation cycle.
2. Press again for >2 seconds to return to normal operation.
10
Page 13
Installing a Rain Sensor
2
2
1
1
yellow wire
It is possible to connect a wired Toro® RainSensor™ to the SST. Other normally closed
sensors can be installed as well. Wired polarity is not observed for the sensor.
1. Cut the wire loop (yellow) from the SST.
(See Figure 1.)
2. Strip 1/2˝ (1.25 cm) of insulation from the
wires. Connect the SST wires to the rain
sensor wires using water-sealed / proof wire
connectors (not included).
(See Figure 2.)
11
Page 14
The Reset Button
e Reset button resets the controller to erase all
watering programs.
1. Remove the battery compartment lid and
battery.
2. In the upper left corner, you will see a
black button with a refresh symbol. Using a
screwdriver, press that button.
3. Reinstall the battery.
4. Reattach the lid and screws, ensuring black
rubber sealing gasket is in place.
The Reset button
12
Page 15
Troubleshooting Guide
Problem Possible Cause Solution
Controller does not
display anything.
Water does not turn ON. 1. Faulty control valve wire connections.
Water does not turn OFF. 1. Valve is blocked by dirt or debris. 1. Inspect, clean, and/or replace the valve.
Controller does not
irrigate as scheduled.
Controller displays “Err” 1. Shorted solenoid or valve wire. 1. Test solenoid and connections. Correct
1. e battery is dead.
2. Controller is in Sleep mode.
2. Faulty solenoid.
3. Program run time is set to 0.
4. Low battery
1. Water at main water supply is shut o.
2. Controller is set to OFF.
3. Overlapping run times on the programs.
1. Install a new 9V battery.
2. Press MODE to activate screen.
1. Check all wire connections.
2. Replace solenoid.
3. Increase program run time. (p.8)
4. Install a new 9V battery.
1. Check the main supply valve.
2. Turn controller on. (Press Mode.)
3. Check program and clock settings.
any shorted condition. Press MODE
>2 seconds until error message clears.
13
Page 16
Warranty Statement
The Toro Company and its afliate, Toro Warranty Company, pursuant to an agreement between them, jointly warrants, to the owner, against defects
in material and workmanship for a period of two years from the date of purchase. Neither The Toro Company nor Toro Warranty Company is liable for
failure of products not manufactured by them even though such products may be sold or used in conjunction with Toro products. During such warranty
period, we will repair or replace, at our option, any part found to be defective. Return the defective part to the place of purchase. Our liability is limited
solely to the replacement or repair of defective parts. There are no other express warranties. This warranty does not apply where equipment is used, or
installation is performed, in any manner contrary to Toro’s specications and instructions, nor where equipment is altered or modied. Neither The Toro
Company nor Toro Warranty Company is liable for indirect, incidental or consequential damages in connection with the use of equipment, including but
not limited to: vegetation loss, the cost of substitute equipment or services required during periods of malfunction or resulting non-use, property damage
or personal injury resulting from installer’s negligence. Some states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you. All implied warranties, including those of merchantability and tness for use, are limited to the
duration of this express warranty. Some states do not allow limitations of how long an implied warranty lasts, so the above limitation may not apply to
you.This warranty gives you specic legal rights and you may have other rights which vary from state to state. Toro is committed to developing and
producing the highest quality, best performing, most dependable products on the market. Because your satisfaction is our rst priority, we have provided
the Toro Helpline. Please call toll-free 1-800-367-8676 or e-mail support@toro.com if you have any questions or problems.
FEDERAL COMMUNICATIONS COMMISSION STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
14
©2012 e Toro Company • www.toro.com • Part No. 373-0736 Rev. A
e Toro Company
Irrigation Division
5825 Jasmine Street
Riverside, CA 92504-1183
Loading...
