Toro 51563 Operator's Manual

UltraBlower/Vacuum

ModelNo.51563—SerialNo.314000001andUp

Thisproductishandheldelectricblowerandvacuum.Itis
intendedforresidentialuseforblowingdirt,debris,andloose
materialsandforvacuuminglightorganicmatter,suchasgrass
andleaves.Itisnotintendedforuseinenclosedorhighlydusty
areas,forstartingres,orforvacuuminghardobjects.Product
Weight:4.8kg(10.5lb).

ThisproductcomplieswithallrelevantEuropeandirectives,for
detailspleaseseetheseparateproductspecicDeclarationof
Conformity(DOC)sheet.

IMPORTANTSAFETY
INSTRUCTIONS

Whenusinganelectricalappliance,basicprecautionsshould
alwaysbefollowed,includingthefollowing:

READALLINSTRUCTIONS

FormNo.3384-354RevA

Operator'sManual

•Wearprotectivegoggleswhileoperating.

•Topreventdustirritation,wearafacemask.

•Beforeusing,checkthesupplyandextensioncordforsigns

ofdamageandaging.Donotusetheapplianceifthecordis
damagedorworn.

•Neveroperatetheappliancewithdefectiveguardsorshields,

orwithoutsafetydevicesinplace,suchasthevacuum
bag/vacuumtubeorblowertube/inletcover .

•OnlyuseaCEapproved,weatherproofextensioncordtted

withtheproperplugforyourlocation,accordingtolocal
ordinances.

BEFOREUSINGTHISAPPLIANCE

WARNING—Toreducetheriskofre,electric

shock,orinjury,followthesesafetyinstructions.

Toensuremaximumsafety,bestperformance,andtogain
knowledgeoftheappliance,itisessentialthatyouoranyother
operatoroftheappliancereadandunderstandthecontentsofthis
manualbeforeoperatingtheappliance.Payparticularattentionto
thesafetyalertsymbol
DANGER-personalsafetyinstruction.Readandunderstandthe
instructionbecauseithastodowithsafety.Failuretocomply

withtheseinstructionsmayresultinpersonalinjury,riskor
re,orelectricalshock.

Important:Thisapplianceisforhouseholduseonly.

Training

•Readtheinstructionscarefully .Befamiliarwiththecontrols

andtheproperuseoftheappliance.

•Neverallowchildrentousetheappliance.

•Neverallowpeopleunfamiliarwiththeseinstructionstouse

theappliance.Localregulationsmayrestricttheageofthe
operator.

•Neveroperatetheappliancewhilepeople,especiallychildren,

orpetsarenearby .

•Theoperatororuserisresponsibleforaccidentsorhazards

occurringtootherpeopleortheirproperty.

Preparation

•Whileoperatingtheappliance,alwayswearsubstantial

footwearandlongtrousers.

•Donotwearlooseclothingorjewelrythatcanbedrawninto

theairinlet(refertothefollowinggure).Keeplonghairaway
fromtheairinlets.

whichmeansCAUTION,WARNINGor

Operation

•Donotusetheapplianceonwetsurfaces.Donotexposeit

torain.Storeitindoors.

•Donothandleplugorappliancewithwethands.

•Alwaysdirectthecordtotherearawayfromtheappliance.

•Ifacordbecomesdamagedduringuse,disconnectthesupply

cordfromthemainsimmediately .Donottouchthecord

beforedisconnectingthesupply.

•Donotcarrytheappliancebythecord,usethecordasa

handle,closeadooronthecord,orpullthecordaroundsharp
edgesorcorners.Keepthecordawayfromheatedsurfaces.

•Turnoffallcontrolsbeforeunplugging.

•Donotunplugbypullingoncord.Tounplug,grasptheplug,

notthecord.

•Disconnecttheappliancefromthepowersourceasfollows:

–Wheneveryouleavethemachine

–Beforeclearingablockage

–Beforechecking,cleaning,orworkingontheappliance

–Iftheappliancestartstovibrateabnormally

•Operatetheapplianceonlyindaylightoringoodarticiallight.

•Donotoverreachandkeepyourbalanceatalltimes.

•Alwaysbesureofyourfootingonslopes.

•Walk,neverrun.

•Keepallcoolingairinletsclearofdebris.Donotputany

objectintoopenings.Donotusewithanyopeningblocked.

•Neverblowdebrisinthedirectionofbystanders.

•Useextracarewhencleaningonstairs.

•Donotusetovacuumupammableorcombustibleliquids,

suchasgasoline,oruseinareaswheretheymaybepresent.

©2014—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Registeratwww.Toro.com.

OriginalInstructions(EN)

PrintedinMexico.

AllRightsReserved

*3384-354*A

•Donotvacuumanythingthatisburningorsmoking,suchas

cigarettes,matches,orhotashes.

•Thisapplianceisprovidedwithdoubleinsulation(i.e.,

Class2device).Useonlyidenticalreplacementparts.
SeeinstructionsforservicingofDouble-Insulated(Class2)
appliances.

SoundPressure

Thisunithasasoundpressurelevelattheoperator’searof93
dBA,whichincludesanUncertaintyValue(K)of1dBA.

Soundpressurelevelwasdeterminedaccordingtotheprocedures
outlinedinENISO11201.

•Lightningcancausesevereinjuryordeath.Iflightningisseen

orthunderisheardinthearea,donotoperatethemachine;
seekshelter.

Maintenanceandstorage

•Keepallnuts,bolts,andscrewstighttobesuretheappliance

isinsafeworkingcondition.

SoundPower

Thisunithasaguaranteedsoundpowerlevelof102dBA,which
includesanUncertaintyV alue(K)of1dBA.

Soundpowerlevelwasdeterminedaccordingtotheprocedures
outlinedinISO1 1094.

•Checkthevacuumbagfrequentlyforwearordeterioration.

•Replacewornordamagedparts.

•Ifapplianceisnotworkingasitshould,hasbeendropped,

damaged,leftoutdoors,ordroppedintowater,returnitto
aservicedealer.

•Useonlygenuinereplacementpartsandaccessories.

•Storetheapplianceinadryplace.

Vibration

•Measuredvibrationlevel=2.4m/s

•UncertaintyValue(K)=1.0m/s

Measuredvaluesweredeterminedaccordingtotheprocedures
outlinedinENISO20643.

WasteofElectrical/ElectronicEquipment(WEEE)

2

2

•EUdirective2002/96/ECclassiesthisproductasanelectricalorelectronictool.

•DoNotdisposeofthistoolasunsortedmunicipalwaste.

•Disposeofthistoolatacollectionorrecyclingcenteraccordingtolocalandnationallaw.

•Theconsumerhasanimportantroleinreducingthedisposalofwastebyreturningwasteelectronic/electrical
toolsforrecycling.

•Recyclingavoidsthedispersionofhazardousmaterialsintothemunicipalwastestream.

•Thecrossed-outbinsymbolremindstheusernottodisposeofthisproductasunsortedmunicipalwaste.

2

SafetyandInstructional
Decals

Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamagedorlostdecals.

127–2293

1.ReadtheOperator'sManual.

2.Electricshockhazard—keepthebloweroutoftherainand
otherwetconditions.

3.Warning—disconnecttheblowerfromthepoweroutlet
andreadtheinstructionsbeforeservicingorperforming
maintenance.

1.Cutting/dismembermenthazard,impeller—stayawayfrommovingparts.

2.Warning—disconnecttheblowerfromthepoweroutletandreadtheinstructionsbeforeservicingorperformingmaintenance.

4.Thrownobjecthazard—weareyeprotection.

5.Thrownobjecthazard—keepbystandersasafedistancefrom
themachine.

6.Containsrecyclablematerials,donotdiscard.

110-7434

3

Setup

2

1

AssemblingtheBlower

Partsneededforthisprocedure:

1Blowertube

1Inletcover

Procedure

Installtheblowertubeandthentheinletcoverontotheblower
housing.

Important:Youmustinstalltheblowertubebefore
installingtheinletcover,becausetheinletcoverhooks
ontotheblowertube.Theblowershouldnotrunwithout
thebottominletcoverlockedinplace.

Note:Iftheblowerrunswithouttheinletcoverinplace,do
notusetheblower.ReturnittoaToroservicedealer.

ConvertingfromBlowerto Vacuum

Partsneededforthisprocedure:

1Vacuumtube

1Vacuumbag

Procedure

WARNING

Theimpellerrotatesforafewsecondsafteryouturn
offtheblowerandcancutorinjurengers.

Donotremovethebottominletcoverwhenthemotoris
runningorwhentheunitispluggedintoapoweroutlet.

1.Removetheinletcoverandtheblowertubefromtheblower
housing.

2.Installthevacuumtubeontotheblowerhousingandconnect
thelowervacuumtubetotheuppertube,securingitwith
thesuppliedfastener.

Important:Theblowershouldnotrunwithoutthe
bottominletcoverlockedinplace.

Note:Note:Iftheblowerrunswithouttheinletcover
inplace,donotusetheblower.ReturnittoaToro
servicedealer.

Note:Youmayneedtopushtheconnectorrmlyto
ensurethatitseatsallthewayintothevacuumtube.

4
