Toro 37775 Operator's Manual

PowerMax724/826OESnowthrower

g018884

ModelNo.37772—SerialNo.315000001andUp

ModelNo.37775—SerialNo.315000001andUp

WARNING

CALIFORNIA

Proposition65Warning

Thisproductcontainsachemicalorchemicals

knowntotheStateofCaliforniatocausecancer,

birthdefects,orreproductiveharm.

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

FormNo.3385-226RevA

Operator'sManual

Figure1

1.Modelandserialnumberlocation

Introduction

Thismachineisintendedtobeusedbyresidential
homeownersorprofessional,hiredoperators.Itis
designedforremovingsnowfrompavedsurfaces,such
asdrivewaysandsidewalks,andothersurfacesfor
trafconresidentialorcommercialproperties.Itisnot
designedforremovingmaterialsotherthansnow,noris
amodelwithapivotingscraperdesignedforclearingoff
gravelsurfaces.

Readthisinformationcarefullytolearnhowtooperateand
maintainyourmachineproperlyandtoavoidinjuryand
machinedamage.Youareresponsibleforoperatingthe
machineproperlyandsafely.

YoumaycontactTorodirectlyatwww.Toro.comformachine
andaccessoryinformation,helpndingadealer,ortoregister
yourmachine.

Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourmachineready.Figure1identiesthelocationofthe
modelandserialnumbersonthemachine.Writethenumbers
inthespaceprovided.

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.

Figure2

1.Safetyalertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.

Contents

©2014—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Registeratwww.T oro.com.

Introduction..................................................................1

Safety...........................................................................2

Training.................................................................3

Preparation.............................................................3

Operation...............................................................3

ClearingaCloggedDischargeChute..........................4

MaintenanceandStorage..........................................4

ToroSnowthrowerSafety.........................................4

SafetyandInstructionalDecals.................................5

OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

*3385-226*A

Setup............................................................................7

BeforeOperating

?

?

Readandunderstandthecontentsofthis
manualbeforeoperatingthesnowthrower .
Becomefamiliarwithallcontrolsandknow
howtostoptheenginequickly .

Operator 's
Position

Thelow-speedaugerhasamovingpinch
pointclosetotheopening.

Caution:Improperusemayresultin
lossoffingers,hands,orfeet.

Thereisahigh-speed
impellerclosetothe
opening.

1InstallingtheUpperHandle....................................7

2InstallingtheTractionControlLinkage....................8

3InstallingtheChute...............................................9

4InstallingtheChuteControlRod............................10

5CheckingtheEngineOilLevel...............................10

6CheckingtheTirePressure....................................11

7CheckingtheSkidsandScraper..............................11

8CheckingtheTractionDriveOperation...................11

ProductOverview.........................................................12

Operation....................................................................13

FreewheelingorUsingtheSelf-propelDrive...............13

FillingtheFuelTank...............................................13

StartingtheEngine.................................................14

StoppingtheEngine...............................................16

OperatingtheTractionDrive...................................16

OperatingtheSpeedSelector...................................16

OperatingtheAuger/ImpellerDrive.........................17

OperatingtheQuickStick™....................................17

UncloggingtheDischargeChute..............................18

PreventingFreeze-up..............................................18

Safety

OperatingTips......................................................18

Maintenance.................................................................19

RecommendedMaintenanceSchedule(s)......................19

............................................................................19

PreparingforMaintenance.......................................19

CheckingtheEngineOilLevel.................................19

CheckingandAdjustingtheSkidsand

Scraper..............................................................20

CheckingandAdjustingtheTractionCable................20

CheckingandAdjustingtheAuger/Impeller

Cable................................................................21

CheckingtheAugerGearboxOilLevel......................21

ChangingtheEngineOil.........................................22

LubricatingtheHexShaft........................................22

ReplacingtheSparkPlug.........................................23

AdjustingtheDischargeChuteLatch........................24

ReplacingtheDriveBelts.........................................24

Storage........................................................................24

PreparingtheMachineforStorage............................24

RemovingtheMachinefromStorage.........................24

Troubleshooting...........................................................25

ThismachinemeetsorexceedstheB71.3specications
oftheAmericanNationalStandardsInstituteineffect
atthetimeofproduction.

Readandunderstandthecontentsofthismanualbefore
theengineiseverstarted.

Thisisthesafetyalertsymbol.Itisusedtoalertyou
topotentialpersonalinjuryhazards.Obeyallsafety
messagesthatfollowthissymboltoavoidpossibleinjury
ordeath.

Improperlyusingormaintainingthismachinecould
resultininjuryordeath.Toreducethispotential,
complywiththefollowingsafetyinstructions.

2

Training

•Read,understandandfollowallinstructionsonthe

machineandinthemanual(s)beforeoperatingthis
machine.Bethoroughlyfamiliarwiththecontrolsand
theproperuseofthemachine.Knowhowtostopthe
machineanddisengagethecontrolsquickly.

•Neverallowchildrentooperatethemachine.Neverallow

adultstooperatethemachinewithoutproperinstruction.

•Keeptheareaofoperationclearofallpersons,particularly

smallchildren.

•Exercisecautiontoavoidslippingorfalling,especially

whenoperatingthemachineinreverse.

Preparation

•Thoroughlyinspecttheareawherethemachineistobe

usedandremovealldoormats,sleds,boards,wires,and
otherforeignobjects.

•Disengageallclutchesandshiftintoneutralbefore

startingtheengine.

•Donotoperatethemachinewithoutwearingadequate

wintergarments.Avoidloosettingclothingthatcanget
caughtinmovingparts.Wearfootwearthatwillimprove
footingonslipperysurfaces.

•Handlefuelwithcare;itishighlyammable.

–Useanapprovedfuelcontainer.

–Neveraddfueltoarunningengineorhotengine.

–Fillfueltankoutdoorswithextremecare.Neverll

fueltankindoors.

–Neverllcontainersinsideavehicleoronatruckor

trailerbedwithaplasticliner.Alwaysplacecontainers
ontheground,awayfromyourvehicle,beforelling.

–Whenpractical,removegas-poweredmachineryfrom

thetruckortrailerandrefuelitontheground.If
thisisnotpossible,thenrefuelsuchmachineryona
trailerwithaportablecontainer,ratherthanfroma
gasolinedispensernozzle.

–Keepthenozzleincontactwiththerimofthefuel

tankorcontaineropeningatalltimes,untilrefueling
iscomplete.Donotuseanozzlelock-opendevice.

–Replacegasolinecapsecurelyandwipeupspilledfuel.

–Iffuelisspilledonclothing,changeclothing

immediately.

•Useextensioncordsandreceptaclesasspeciedby

themanufacturerforallmachineswithelectricstarting
motors.

•Adjustthecollectorhousingtocleargravelorcrushed

rocksurface.

•Neverattempttomakeanyadjustmentswhiletheengine

isrunning(exceptwhenspecicallyrecommendedby
manufacturer).

•Alwayswearsafetyglassesoreyeshieldsduringoperation

orwhileperforminganadjustmentorrepairtoprotect

eyesfromforeignobjectsthatmaybethrownfromthe
machine.

Operation

•Donotputhandsorfeetnearorunderrotatingparts.

Keepclearofthedischargeopeningatalltimes.

•Exerciseextremecautionwhenoperatingonorcrossing

graveldrives,walks,orroads.Stayalertforhidden
hazardsortrafc.

•Afterstrikingaforeignobject,stoptheengine,remove

theignitionkey ,thoroughlyinspectthemachineforany
damage,andrepairthedamagebeforerestartingand
operatingthemachine.

•Ifthemachineshouldstarttovibrateabnormally,stopthe

engineandcheckimmediatelyforthecause.Vibrationis
generallyawarningoftrouble.

•Stoptheenginewheneveryouleavetheoperating

position,beforeuncloggingtheauger/impellerhousing
ordischargechute,andwhenmakinganyrepairs,
adjustmentsorinspections.

•Whencleaning,repairingorinspectingthemachine,stop

theengineandmakecertaintheauger/impellerandall
movingpartshavestopped.Disconnectthesparkplug
wireandkeepthewireawayfromtheplugtoprevent
someonefromaccidentallystartingtheengine.

•Donotruntheengineindoors,exceptwhenstarting

theengineandfortransportingthemachineinorout
ofthebuilding.Opentheoutsidedoors;exhaustfumes
aredangerous.

•Exerciseextremecautionwhenoperatingonslopes.

•Neveroperatethemachinewithoutproperguards,and

othersafetyprotectivedevicesinplaceandworking.

•Neverdirectthedischargetowardpeopleorareaswhere

propertydamagecanoccur.Keepchildrenandothers
away.

•Donotoverloadthemachinecapacitybyattemptingto

clearsnowattoofastarate.

•Neveroperatethemachineathightransportspeeds

onslipperysurfaces.Lookbehindandusecarewhen
operatinginreverse.

•Disengagepowertotheauger/impellerwhenmachineis

transportedornotinuse.

•Useonlyattachmentsandaccessoriesapprovedbythe

manufacturerofthemachine(suchaswheelweights,
counterweights,orcabs).

•Neveroperatethemachinewithoutgoodvisibilityor

light.Alwaysbesureofyourfooting,andkeeparm
holdonthehandles.Walk;neverrun.

•Nevertouchahotengineormufer.

3

ClearingaCloggedDischarge Chute

WARNING

Handcontactwiththerotatingrotorbladesinside
thedischargechuteisthemostcommoncauseof
injuryassociatedwithmachines.Neveruseyour
handtocleanoutthedischargechute.

Toclearthechute:

•Shuttheengineoff!

•Wait10secondstobesuretherotorbladeshavestopped

rotating.

•Alwaysusethecleanouttoolmountedonthe

snowthrower,notyourhands.

MaintenanceandStorage

•Checkallfastenersatfrequentintervalsforproper

tightnesstobesurethemachineisinsafeworking
condition.

•Neverstorethemachinewithfuelinthefueltankinsidea

buildingwhereignitionsourcesarepresentsuchashot
waterheaters,spaceheaters,orclothesdryers.Allowthe
enginetocoolbeforestoringinanyenclosure.

•AlwaysrefertotheOperator’ sManualforimportantdetails

ifthemachineistobestoredforanextendedperiod.

•Maintainorreplacesafetyandinstructionlabels,as

necessary.

•Runthemachineafewminutesafterthrowingsnowto

preventfreeze-upoftherotorblades.

raisethefrontofthemachineafewinches(centimeters)
offthepavement.Thenliftthehandlesquicklytobump
thefrontofthemachineonthepavement.Repeatif
necessaryuntilastreamofsnowcomesoutthedischarge
chute.

•Ifyoucannotunclogthedischargechutebybumping

thefrontofthemachine,stoptheengine,waitfor

allmovingpartstostop,andusethecleanouttool;
neveruseyourhand.

•Ifashield,safetydevice,ordecalisdamaged,illegible,or

lost,repairorreplaceitbeforebeginningoperation.

•Donotsmokewhilehandlinggasoline.

•Donotusethemachineonaroof.

•Donottouchtheenginewhileitisrunningorsoonafter

ithasstoppedbecausetheenginemaybehotenoughto
causeaburn.

•Performonlythosemaintenanceinstructionsdescribedin

thismanual.Beforeperforminganymaintenance,service,
oradjustment,stoptheengine,removethekey,and
disconnectthewirefromthesparkplug.Ifmajorrepairs
areeverneeded,contactyourAuthorizedServiceDealer.

•Donotchangethegovernorsettingsontheengine.

•Whenstoringthemachineformorethan30days,drain

thefuelfromthefueltanktopreventapotentialhazard.
Storefuelinanapprovedfuelcontainer.Removethekey
fromtheignitionswitchbeforestoringthemachine.

•PurchaseonlygenuineTororeplacementpartsand

accessories.

ToroSnowthrowerSafety

ThefollowinglistcontainssafetyinformationspecictoToro
machinesorothersafetyinformationthatyoumustknow .

•Rotatingauger/impellercanamputateorinjure

ngersorhands.Staybehindthehandlesandawayfrom
thedischargeopeningwhileoperatingthemachine.Keep

yourface,hands,feet,andanyotherpartofyour
bodyorclothingawayfrommovingorrotatingparts.

•Beforeadjusting,cleaning,inspecting,troubleshooting,or

repairingthemachine,stoptheengine,removethekey,

andwaitforallmovingpartstostop.Disconnect
thewirefromthesparkplugandkeepitawayfrom
thesparkplugtopreventsomeonefromaccidentally
startingtheengine.

•Beforeleavingtheoperatingposition,stoptheengine,

removethekey,andwaitforallmovingpartstostop.

•Tounclogthedischargechute,stayintheoperating

positionandreleasethelefthand(traction)lever.While
runningtheauger/impeller,pushdownonthehandlesto

4

SafetyandInstructional
Decals

Important:Safetyandinstructiondecalsarelocated

nearareasofpotentialdanger.Replacedamageddecals.

121–6817

1.Cuttingdismemberment,impellerandcutting
dismemberment,augerhazards—keepbystandersasafe
distancefromthesnowthrower.

121–6823

1.Fast

2.Forwardspeeds4.Reversespeeds

1.Tractiondrive—squeezethelevertoengage;releasethe
levertodisengage.

2.Warning—readtheOperator’sManual.5.Thrownobjecthazard—keepbystandersasafedistancefrom

3.Cutting/dismembermenthazard,impeller—donotplace
yourhandinthechute;stoptheenginebeforeleavingthe
operatingposition,usethetooltoclearthechute.

3.Slow

121–1239

Reorderpartno.121–1215

121–1240

Reorderpartno.120–7194

4.Cuttingdismembermenthazard,impeller—keepaway
frommovingparts;removetheignitionkeyandreadthe
instructionsbeforeservicingorperformingmaintenance.

thesnowthrower.

6.Auger/impellerdrive—squeezethelevertoengage;release
thelevertodisengage.

5

Briggs&StrattonPartNo.273676

1.Stop

2.Slow

3.Fast

Briggs&StrattonPartNo.275949

1.Chokeon(Choke)2.Chokeoff(Run)

Briggs&StrattonPartNo.276925

1.Warning—readthe

Operator'sManual.

2.Warning—rehazard.

3.Warning—toxicgas
inhalationhazard.

4.Warning—hot
surface/burnhazard.

Briggs&StrattonPartNo.277588

1.Primer3.Ignitionkeyout
(Engine—Stop)

2.Ignitionkeyin

(Engine—Run)

Briggs&StrattonPartNo.278866

Briggs&StrattonPartNo.277566

1.Whenstartingacold
engine,closethechoke
andpresstheprimertwo
times.

1.Fuel—On2.Fuel—Off

2.Whenstartingawarm
engine,openthechoke
anddonotpressthe
primer.

6

Setup

g019003

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescription

1

2

3

4
5

6
7
8

Handlebolts2
Curvedwashers
Locknuts2
Hairpincotter2
Flatwasher3
Nut2
Carriagebolt
Flatwasher2
Carriagebolts
Locknuts2

Nopartsrequired

Nopartsrequired

Nopartsrequired

Nopartsrequired

Qty.

Use

2

2

2

–

–

–

–

Installtheupperhandle.

Installthetractioncontrollinkage.

Installthechute.

Installthechutecontrolrod.

Checktheengineoillevel.

Checkthetirepressure.

Checktheskidsandscraper.

Checktheoperationofthetractiondrive.

1

InstallingtheUpperHandle

Partsneededforthisprocedure:

2Handlebolts

2

Curvedwashers

2Locknuts

Procedure

1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).

2.Install2handlebolts,2curvedwashers,and2locknuts
inthelowerhandleholes(Figure3).

Figure3

7

2

g019004

g019378

InstallingtheTractionControl Linkage

Partsneededforthisprocedure:

Figure6

2Hairpincotter

3Flatwasher

Procedure

1.Insertthelowerendoftherodintothelowerlinkarm
sothatthebentendofthespeedcontrolrodfaces
rearward(Figure4).

Figure4

2.Securethelowerendofthespeedcontrolrodwitha
atwasherandahairpincotter(Figure4).

3.Placeaatwasheronthetrunnion(Figure5).

6.Pulluponthespeedcontrolrodandinsertthetrunnion
intotheholeinthespeedselectorlever(Figure5).

Note:Ifthetrunniondoesnottintothehole
whenyouliftuponthespeedcontrolrod,rotatethe
trunnionupwardordownwardonthespeedcontrol
roduntilitts.

7.Securethetrunnionandupperendofthespeedcontrol
rodwithawasherandahairpincotter.

Note:Foreasierinstallation,lookdownthroughthe
openinginthespeedselector(Figure7).

Figure7

1.Speedselector

Figure5

1.Speedselectorlever

2.Trunnion

4.ShiftthespeedselectorleverintoPositionR2.

5.Rotatethelowerlinkarmfullyupward
(counterclockwise)(Figure6).

3.Innerwasher

4.Outerwasher

8

3

3

1

2

g019379

InstallingtheChute

Partsneededforthisprocedure:

2Nut

2

Carriagebolt

2Flatwasher

Procedure

1.Placethechuteontheframeandthealignthedischarge
chutemounttothechutesupport.

Figure8

1.Carriagebolt

2.Flatwasher

2.Securethedischargechutemountusing2bolts,2nuts,
and2atwashers.

3.Nut

9

4

g018885

InstallingtheChuteControl Rod

Partsneededforthisprocedure:

2

Carriagebolts

2Locknuts

Procedure

1.UnwraptheQuickStickandrotateitsothatitis
uprightandinthecenter.

2.Holdthebluetriggercapdownandpulltheleverfully
rearward.

Note:Thedischargechuteanddeectorshouldface
forward.Iftheydonot,holdthebluetriggercap
down(butdonotmovetheQuickStick)androtatethe
dischargechuteuntiltheydo.

3.Aligntheattenedbackendofthelongchutecontrol
rodwiththeattenedfrontendoftheshortrod
thatextendsfromthecontrolpanelsothattheynest
together(Figure9).

Figure10

5.Aligntheholesinthenestedendsoftherodsand
insert2carriagebolts(intheloosepartsbag)through
theshortrodfromtheleftsideofthemachine(from
theoperatingposition).

6.Insertthecableclipthatsupportsthedeectorcable
ontotheforwardcarriagebolt,andsecurethecarriage
boltswithlocknutsfromtheloosepartsbag(Figure

11).

Figure11

1.Cableclip2.Deectorcable

Figure9

1.Shortrod

4.Insertthefrontendoftherodintotheopeningin
thebackofthechutegearcoveruntilitslidesintothe
chutegear(Figure10).

2.Longchutecontrolrod

7.HoldthebluetriggercapdownandrotatetheQuick
Stickinacircletoensurethatthechuteanddeector
operatesmoothly.

5

CheckingtheEngineOilLevel

NoPartsRequired

Procedure

Yourmachinecomeswithoilintheenginecrankcase.

10

Note:Beforestartingtheengine,checktheoilleveland

g019049

g018886

addoilifnecessary.

UseautomotivedetergentoilwithanAPIserviceclassication
ofSF ,SG,SH,SJ,SL,orhigher.Refertoyourengineowner's
manual.

UseFigure12belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:

Figure12

EngineOilCapacities

Model

37771

37772

EngineOilCapacity

18to20oz.(0.53to0.59l)

6

CheckingtheTirePressure

NoPartsRequired

Procedure

Thetiresareoverinatedatthefactoryforshipping.Reduce
thepressureequallyinbothtirestobetween17and20psi
(116and137kPa).

7

CheckingtheSkidsand Scraper

NoPartsRequired

Procedure

RefertoCheckingandAdjustingtheSkidsandScraperin
Maintenance.

1.Removethedipstickandslowlypouroilintotheoil
lltubetoraisetheoilleveltotheFullmarkonthe
dipstick.Donotoverll.(Figure13).

Figure13

2.Installthedipsticksecurely.

Note:Donotspilloilaroundtheoillltube;oilcould
leakontotractionpartsandcausethetractiontoslip.

8

CheckingtheTractionDrive Operation

NoPartsRequired

Procedure

CAUTION

Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.

Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.

Note:Tocheckthetractiondriveoperation,theself-propel
featuremustbeengagedbyensuringthewheelsarepinned
intheaxle.Referto(page).

1.Starttheengine;refertoStartingtheEngine.

2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.

11

3.Squeezethelefthand(traction)levertothehand-grip

g018887

g018888

(Figure14).

Figure14

Themachineshouldmoverearward.Ifthemachine
doesnotmoveormovesforward,completethe
following:

A.Releasethetractionleverandstoptheengine.

B.Disconnectthetrunnionfromthespeedselector

lever(Figure5).

C.Turnthetrunniondownward(clockwise)onthe

speedcontrolrod(Figure5).

D.Connectthetrunniontothespeedselectorlever

(Figure5).

4.Releasethetractionlever.

5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.

6.Squeezethelefthand(traction)levertothehand-grip
(Figure14).

ProductOverview

Figure15

1.Hand-grip(2)

2.Auger/impellerlever10.Scraper

3.Speedselectorlever

4.QuickStick™discharge
chutecontrol

5.Tractionlever13.Electricstarterbutton

6.Fueltankcap14.Electricstarterplug-in

7.Engineoillltube/dipstick15.Snowcleanouttool

8.Chutedeector

9.Dischargechute

11.Auger

12.Skid(2)

Themachineshouldmoveforward.Ifthemachine
doesnotmoveormovesrearward,completethe
following:

A.Releasethetractionleverandstoptheengine.

B.Disconnectthetrunnionfromthespeedselector

lever(Figure5).

C.Turnthetrunnionupward(counterclockwise)on

thespeedcontrolrod(Figure5).

D.Connectthetrunniontothespeedselectorlever

(Figure5).

7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.

Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable)or
takethemachinetoanAuthorizedServiceDealerfor
service.

1.Choke

2.Ignitionswitch

3.Fuelshutoffvalve

4.Throttle

Figure16

5.Recoilstarter

6.Oildrainplug

7.Primer

12

g019015

g019014

FillingtheFuelTank

DANGER

Figure17

1.Snowcleanouttool(attachedtothehandle)

Operation

Note:Determinetheleftandrightsidesofthemachine

fromthenormaloperatingposition.

FreewheelingorUsingthe Self-propelDrive

Youcanoperatethesnowthrowerwiththeself-propelfeature
engagedordisengaged(freewheeling).

Tofreewheel,slidethewheelsinwardandinserttheaxle
pinsthroughtheaxleholes,butnotthroughthewheelhubs
(Figure18).

Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.

•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
onthegroundbeforelling,notinavehicleor
onanobject.

•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.

•Donothandlegasolinewhensmokingoraround
anopenameorsparks.

•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.

•Forbestresults,useonlyclean,fresh,unleadedgasoline

withanoctaneratingof87orhigher((R+M)/2rating
method).

•Oxygenatedfuelwithupto10%ethanolor15%MTBE

byvolumeisacceptable.

•DoNotuseethanolblendsofgasoline(suchasE15

orE85)withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemayresult
whichmaynotbecoveredunderwarranty.

Figure18

Toself-propel,axlepinthroughtheholesinthewheelhubs
andtheinneraxleholes(Figure19).

Figure19

•DoNotusegasolinecontainingmethanol.

•DoNotstorefueleitherinthefueltankorfuelcontainers

overthewinterunlessafuelstabilizerisused.

•DoNotaddoiltogasoline.

Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold.

Do not add oil to the gasoline.

13

g018889

Figure20

g018890

StartingtheEngine

1.Checktheengineoillevel.RefertoCheckingthe
EngineOilLevelinMaintenance.

2.Turnthefuelshutoffvalve1/4turncounterclockwise
toopenit(Figure21).

Figure21

1.1-1/2inch(3.8cm)

3.Inserttheignitionkey(Figure22).

Figure22

1.Ignitionkey

14

4.Firmlypushintheprimerwithyourthumb2times

g018891

g018892

g018893

(15°For-9°Corabove)or4times(below15°For

-9°C),holdingtheprimerinforasecondbefore
releasingiteachtime(Figure23).

7.Startthemachinepullingtherecoilstarterorpressing
theelectric-starterbutton(Figure26).

Figure26

1.Electric-starterbutton3.Recoilstarter

2.Electricstarterplug-in

Figure23

5.RotatethechoketotheChokeposition(Figure24).

Figure24

6.MovethethrottletotheFastposition(Figure25).

Note:Tousetheelectricstarter,connectapower
cordtotheelectricstarterplug-inrstandthentoa
poweroutlet.UseonlyaUL-listed,16-gaugeextension
cordrecommendedforoutdoorusethatisnotlonger
than50feet(15m).

WARNING

Theelectricalcordcanbecomedamaged,
causingashockorre.

Thoroughlyinspecttheelectricalcordbefore
usingthemachine.Ifthecordisdamaged,
donotoperatethemachine.Replaceorrepair
thedamagedcordimmediately.Contactan
AuthorizedServiceDealerforassistance.

Important:Topreventdamagingtheelectric
starter,runitinshortcycles(5secondsmaximum,
thenwaitoneminutebeforetryingtostartit
again).Iftheenginestilldoesnotstart,take
themachinetoanAuthorizedServiceDealerfor
service.

8.Disconnectthepowercordfromthepoweroutletrst
andthenfromthemachine(electricstartonly).

9.Allowtheenginetowarmupforseveralminutes,move
thechoketowardtheRunposition.Waitfortheengine
torunsmoothlybeforeeachchokeadjustment.

Figure25

15

CAUTION

OperatingtheTractionDrive

Ifyouleavethemachinepluggedintoa
poweroutlet,someonecaninadvertentlystart
themachineandinjurepeopleordamage
property.

Unplugthepowercordwheneveryouarenot
startingthemachine.

StoppingtheEngine

1.MovethethrottletotheSlowposition,andthentothe
Stopposition(Figure27).

CAUTION

Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.

Carefullycheckthetractiondriveandadjustit
properly,ifnecessary;refertoCheckingtheTraction
DriveOperationinSetupformoreinformation.

Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable)or
takethemachinetoanAuthorizedServiceDealerfor
service.

Important:Tooperatethetractiondrive,youmust
operatethemachinewiththeself-propelfeature
engaged.RefertoFreewheelingorUsingtheSelf-propel
Drive.

1.Toengagethetractiondrive,squeezethelefthand
(traction)levertothehandgrip(Figure29).

Figure27

2.Waitforallmovingpartstostopbeforeleavingthe
operatingposition.

3.Removetheignitionkey.

4.Closethefuelshutoffvalvebyrotatingitclockwise
(Figure28).

Figure28

Figure29

2.Tostopthetractiondrive,releasethetractionlever.

OperatingtheSpeedSelector

Thespeedselectorhas6forwardand2reversegears.To
changespeeds,releasethetractionleverandshiftthespeed
selectorlevertothedesiredposition(Figure30).Thelever
locksinanotchateachspeedselection.

5.Pulltherecoilstarter3or4times.Thishelpsprevent
therecoilstarterfromfreezingup.

Figure30

16

OperatingtheAuger/Impeller

g018894

Drive

1.Toengagetheauger/impellerdrive,squeezetheright
hand(auger/impeller)levertothehandgrip(Figure

31).

Figure32

Figure31

2.Tostoptheaugerandimpeller,releasetherighthand
lever.

Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerleverdown,
freeingyourrighthand.Toreleasebothlevers,
simplyreleasethelefthand(traction)lever.

3.Iftheaugerandimpellercontinuetorotatewhenyou
releasetheauger/impellerlever,donotoperatethe
machine.Checktheauger/impellercable(referto
CheckingandAdjustingtheAuger/ImpellerCable)
andadjustitifnecessary.Otherwise,takethemachine
toanAuthorizedDealerforservice.

WARNING

Iftheaugerandimpellercontinuetorotate
whenyoureleasetheauger/impellerlever,
donotoperatethemachine,asyoucould
seriouslyinjureyourselforothers.

TakeittoanAuthorizedServiceDealerfor
service.

OperatingtheQuickStick™

HoldthebluetriggercapdowntousetheQuickStickto
movethedischargechuteandthechutedeector.Releasethe
triggercaptolockthedischargechuteandchutedeector
intoposition(Figure32).

MovingtheDischargeChute

HoldthebluetriggercapdownandmovetheQuickStick
tothelefttomovethedischargechutetotheleft;movethe
QuickSticktotherighttomovethedischargechutetothe
right(Figure33).

Figure33

•Ifthechutedoesnotmove,refertoAdjustingthe

DischargeChuteLatch.

•Ifthechutedoesnotturnasfartotheleftasitdoesto

theright,ensurethatthecableisroutedtotheinsideof
thehandles.RefertoInstallingtheUpperHandle.

•Ifthechutedoesnotlockintoplacewhenyoureleasethe

triggercap,refertoAdjustingtheDischargeChuteLatch.

MovingtheChuteDeector

HoldthebluetriggercapdownandmovetheQuickStick
forwardtolowerthechutedeector;moveitrearwardtoraise
thechutedeector(Figure34).

17

UncloggingtheDischarge Chute

WARNING

Figure34

fromfreezing.Stoptheengine,waitforallmovingparts
tostop,andremovealliceandsnowfromthemachine.

•Withtheengineoff,pulltherecoilstarterhandleseveral

timesandpushtheelectric-starterbuttononcetoprevent
therecoilandelectricstartersfromfreezingup.

OperatingTips

DANGER

Whenthemachineisinoperation,theimpellerand
augerrotateandcaninjureoramputatehandsor
feet.

•Beforeadjusting,cleaning,inspecting,
troubleshooting,orrepairingthemachine,stop
theengineandwaitforallmovingpartstostop.
Disconnectthewirefromthesparkplugand
keepitawayfromtheplugtopreventsomeone
fromaccidentallystartingtheengine.

Iftheauger/impellerisrunningbutthereisno
snowcomingoutofthedischargechute,the
dischargechutemaybeclogged.

Neveruseyourhandstoclearacloggeddischarge
chute.Thiscouldresultinpersonalinjury.

•Tounclogthedischargechute,stayintheoperating

positionandreleasethelefthand(traction)lever.While
runningtheauger/impeller,pushdownonthehandlesto
raisethefrontofthemachineafewinches(centimeters)
offthepavement.Thenliftthehandlesquicklytobump
thefrontofthemachineonthepavement.Repeatif
necessaryuntilastreamofsnowcomesoutthedischarge
chute.

•Ifyoucannotunclogthedischargechutebybumping

thefrontofthemachine,stoptheengine,waitforall

movingpartstostop,andusethesnowcleanouttool;
neveruseyourhand.

Important:Uncloggingthedischargechuteby
bumpingthefrontofthemachineonthepavement
maycausetheskidstomove.Adjusttheskidsand
tightentheskidboltssecurely.

•Removeanobstructionfromthedischarge
chute;refertoUncloggingtheDischargeChute.
Ifnecessary,usethesnowcleanouttool,not
yourhands,toremoveanobstructionfromthe
dischargechute.

•Staybehindthehandlesandawayfromthe
dischargeopeningwhileoperatingthemachine.

•Keepface,hands,feet,andanyotherpartof
yourbodyorclothingawayfromconcealed,
moving,orrotatingparts.

WARNING

Theimpellercanthrowstones,toys,andother
foreignobjectsandcauseseriouspersonalinjuryto
theoperatorortobystanders.

•Keeptheareatobeclearedfreeofallobjects
thattheaugercouldpickupandthrow.

•Keepallchildrenandpetsawayfromthearea
ofoperation.

PreventingFreeze-up

•Insnowyandcoldconditions,somecontrolsandmoving

partsmayfreeze.Donotuseexcessiveforcewhen
tryingtooperatefrozencontrols.Ifyouhavedifculty
operatinganycontrolorpart,starttheengineandletit
runforafewminutes.

•Afterusingthemachine,lettheenginerunforafew

minutestopreventmovingpartsfromfreezing.Engage
theauger/impellertoclearanyremainingsnowfrom
insidethehousing.RotatetheQuickSticktopreventit

•AlwayssetthethrottletotheFastpositionwhenthrowing

snow .

•Iftheengineslowsdownunderaloadorthewheelsslip,

shiftthemachineintoalowergear.

•Ifthefrontofthemachineridesup,shiftthemachine

intoalowergear.Ifthefrontcontinuestorideup,liftup
onthehandles.

18

Maintenance

g018886

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Aftertherst2hours

Aftertherst5hours

Beforeeachuseordaily

Yearly

Yearlyorbeforestorage

Important:Youcanndmoreinformationaboutmaintainingandservicingyourmachineatwww.T oro.com.

Important:Refertoyourengineoperator'smanualforadditionalmaintenanceprocedures.Forengineadjustments,

repairs,orwarrantyservicenotcoveredinthismanual,contactanAuthorizedBriggs&StrattonServicingDealer.

MaintenanceProcedure

•Inspectthetractioncableandadjustitifnecessary.

•Inspecttheauger/impellercableandadjustitifnecessary.

•Changetheengineoil.

•

•Checktheengineoillevelandaddoilifnecessary.

•Checktheskidsandthescraperandadjustthemifnecessary.

•Inspectthetractioncableandadjustorreplaceitifnecessary.

•Inspecttheauger/impellercableandadjustorreplaceitifnecessary.

•Checktheaugergearboxoilandaddoilifnecessary.

•Changetheengineoil.

•Lubricatethehexshaft.

•Replacethesparkplug.

•Checktheairpressureinthetiresandinatethemto17–20psi(116–137kPa).

•Drainthegasolineandruntheenginetodryoutthefueltankandthecarburetorat
theendoftheseason.

•HaveanAuthorizedServiceDealerinspectandreplacethetractiondrivebeltand/or
theauger/impellerdrivebelt,ifnecessary.

ServiceInterval:Beforeeachuseordaily

PreparingforMaintenance

1.Movethemachinetoalevelsurface.

2.Stoptheengineandwaitforallmovingpartstostop.

3.Disconnectthesparkplugwire.RefertoReplacing
theSparkPlug.

CheckingtheEngineOilLevel

ServiceInterval:Beforeeachuseordaily—Checktheengine

oillevelandaddoilifnecessary.

1.Removethedipstick,wipeitclean,thenfullyinstall
thedipstick.

2.Removethedipstickandchecktheoillevel(Figure35).
IftheoillevelisbelowtheAddmarkonthedipstick,
addoil.RefertoFillingtheEnginewithOil.

Figure35

19

CheckingandAdjustingthe

g019046

1

3

g019048

4

SkidsandScraper

ServiceInterval:Yearly—Checktheskidsandthescraper

andadjustthemifnecessary.

Checktheskidsandthescrapertoensurethattheaugerdoes
notcontactthepavedorgravelsurface.Adjusttheskidsand
thescraperasneededtocompensateforwear.

1.Checkthetirepressure.RefertoCheckingtheTire
Pressure.

2.Loosenthenutsthatsecurebothskidstotheauger
sidesuntiltheskidsslideupanddowneasily.

Yearly—Inspectthetractioncableandadjustor
replaceitifnecessary.

Ifthemachinedoesnotdriveintheforwardorreversespeeds
oritdriveswhenyoureleasethetractionlever,adjustthe
tractioncable.

Ifthelefthand(traction)cableisnotproperlyadjusted,do
thefollowingsteps:

1.Loosenthejamnut.

2.Engagethetractionleverandholditinplace(Figure

37).

Figure37

Figure36

1.1/8inch(3mm)

Important:Theaugerbladesmustbesupported
abovethegroundbytheskids.

3.Ensurethatthescraperis1/8inch(3mm)aboveand
paralleltoalevelsurface.

Note:Ifthepavementiscracked,rough,oruneven,
adjusttheskidstoraisethescraper.Forgravelsurfaces,
adjusttheskidsfurtherdowntopreventthemachine
frompickinguprocks.

4.Movetheskidsdownuntiltheyareevenwiththe
ground.

5.Firmlytightenthenutsthatsecurebothskidstothe
augersides.

Note:Toquicklyadjusttheskidsiftheyloosen,
supportthescraper1/8inch(3mm)offthepavement,
thenadjusttheskidsdowntothepavement.

Note:Iftheskidsbecomeexcessivelyworn,youcan
turnthemoverandsettheunusedsidetowardthe
pavement.

3.Loosenortightentheturnbuckletoadjustspring
lengthto2.18inches(5.5cm)(Figure38).

Figure38

1.Jamnut

2.Turnbuckle

3.Spring

4.2.18inches(5.5cm)

CheckingandAdjustingthe TractionCable

ServiceInterval:Aftertherst2hours—Inspectthe

tractioncableandadjustitifnecessary.

4.Tightenthejamnut(Figure38),ensuringthereisslight
tensiononthecable.

5.Ifthetractioncableisproperlyadjustedbutaproblem
remains,contactanAuthorizedServiceDealer.

20

CheckingandAdjustingthe

2

1

3

g019047

4

CheckingtheAugerGearbox

Auger/ImpellerCable

ServiceInterval:Aftertherst2hours—Inspectthe

auger/impellercableandadjustitif
necessary.

Yearly—Inspecttheauger/impellercableandadjust
orreplaceitifnecessary.

1.Loosenthejamnut.

2.Engagetheauger/impellerleverandholditinplace
(Figure39).

Figure39

3.Loosenortightentheturnbuckletoadjustthespring
lengthto2.75inches(7cm)(Figure40)

OilLevel

ServiceInterval:Yearly—Checktheaugergearboxoiland

addoilifnecessary.

1.Movethemachinetoalevelsurface.

2.Cleantheareaaroundthepipeplug(Figure41).

Figure41

3.Removethepipeplugfromthegearbox.

4.Checktheoillevelinthegearbox.Theoilshouldbe
3/8inch(9.5mm)belowthelleropening.

Figure40

1.Jamnut

2.Turnbuckle

4.Tightenthejamnut(Figure40),ensuringthereisslight
tensiononthecable.

5.Iftheauger/impellercableisproperlyadjustedbut
aproblemremains,contactanAuthorizedService
Dealer.

3.Spring

4.2.75inches(7cm)

5.Iftheoillevelislow ,addGL-5orGL-6,SAE80-90
EPgearoillubricanttothegearboxuntiltheoillevel
is3/8inchbelowthelleropening.

Note:Donotusesyntheticoil.

6.Installthepipepluginthegearbox.

21

ChangingtheEngineOil

g019049

g019018

g019019

1

LubricatingtheHexShaft

ServiceInterval:Aftertherst5hours—Changetheengine

oil.

Yearly—Changetheengineoil.

Ifpossible,runtheenginejustbeforechangingtheoilbecause
warmoilowsbetterandcarriesmorecontaminants.

UseautomotivedetergentoilwithanAPIserviceclassication
ofSF ,SG,SH,SJ,SL,orhigher.Refertoyourengineowner's
manual.

UseFigure42belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:

ServiceInterval:Y early—Lubricatethehexshaft.

Lightlylubricatethehexshaftyearlywithautomotiveengine
oil(Figure44).

Figure44

1.Hexshaft

2.Steelfrictionpulley

3.Rubberwheel

Important:Donotgetoilontherubberwheelorthe
steelfrictionpulleybecausethetractiondrivewillslip
(Figure44).

Figure42

EngineOilCapacities

Model

37772

37775

EngineOilCapacity

18to20oz.(0.53to0.59l)

1.Cleantheareaaroundtheoildraincap(Figure43).

Figure43

1.Oildraincap

2.Slideanoildrainpanunderthedrainextensionand
removetheoildraincap.

3.Draintheoil.

Note:Disposeoftheusedoilproperlyatalocal
recyclingcenter.

4.Installtheoildraincap.

5.Fillthecrankcasewithoil.RefertoFillingtheEngine
CrankcasewithOil.

1.Drainthegasolinefromthefueltank.

2.Tipthemachineforwardontoitsaugerhousingand
blockitsothatitcannotfall.

3.Removethebackcover(Figure45).

Figure45

1.Screws

4.MovethespeedselectorlevertoPositionR2.

5.Dipyourngerinautomotiveengineoilandlightly
lubricatehexshaft.

6.MovethespeedselectorlevertoPosition6.

7.Lubricatetheotherendofthehexshaft.

8.Movethespeedselectorleverforwardandrearward
afewtimes.

22

9.Installthebackcoverandreturnthemachinetothe
operatingposition.

ReplacingtheSparkPlug

ServiceInterval:Y early—Replacethesparkplug.

UseaChampionQC12YCorequivalentsparkplug.

Note:Toaccessthesparkplug,youmustrstremovethe
uppersnowhood(Figure46).

Figure47

Figure46

1.Chokeknob

2.Uppersnowhood

3.Ignitionkey

4.Screw(2)

1.Removethechokeknobandtheignitionkey(Figure

46).

2.Removethe2screwsthatsecuretheuppersnowhood
tothemachine(Figure46).

3.Slowlyremovetheuppersnowhood,ensuringthat
theprimerbulbhoseandtheignitionwireremain
connected.

4.Removethebracketthumbscrewandthebracket
(Figure47).

1.Spark-plugwire

2.Bracket

3.Thumbscrew

5.Cleanaroundthebaseofthesparkplug(Figure47).

6.Removeanddiscardtheoldsparkplug.

Note:Youwillneedaratchetwrenchextensionto
removethesparkplug.

7.Setthegapbetweentheelectrodesonanewsparkplug
at0.030inch(0.76mm)(Figure48).

Figure48

1.0.030inch(0.76mm)

8.Installthenewsparkplug,tightenitrmly,andattach
theignitionwiretothesparkplug.

9.Installthebracketwiththethumbscrewthatyou
removedinstep4.

10.Ensurethattheprimerbulbhoseandtheignitionwire
areconnectedandclearofthecarburetorbracket.

11.Securetheuppersnowhoodtothemachinewiththe2
screwsthatyoupreviouslyremoved.

12.Alignthetabonthechokecontrolknobwiththeslot
ontheuppersnowhood.

13.Connectthechokecontrolknobtothechokeshafton
thecarburetor.

23

AdjustingtheDischargeChute

g019021

1

2
3

Latch

Storage

Ifthedischargechutedoesnotlockintothedesiredposition
ordoesnotunlocksothatyoucanmoveittoanother
position,adjustthedischargechutelatch.

1.Loosentheclampfasteneronthechutesupportplate
untilthecableisfree.

Figure49

1.Cableconduit3.Clampfastener

2.Cableclamp

WARNING

•Gasolinevaporscanexplode.

•Donotstoregasolinemorethan30days.

•Donotstorethemachineinanenclosurenear
anopename.

•Allowtheenginetocoolbeforestoringit.

PreparingtheMachinefor Storage

1.Onthelastrefuelingoftheyear,addfuelstabilizerto
freshfuelasdirectedbytheenginemanufacturer.

Note:Fuelshouldnotbestoredlongerthansuggested
bythefuelstabilizermanufacturer.

2.Runtheenginefor10minutestodistributethe
conditionedfuelthroughthefuelsystem.

3.Runthemachineuntiltheenginerunsoutoffuel.

4.Primetheengineandstartitagain.

5.Allowtheenginetorununtilitstops.Whenyoucan
nolongerstarttheengine,itissufcientlydry.

6.Stoptheengineandallowittocool.

2.Removeanyslackinthecablebypullingthecable
conduitrearward.

3.Tightentheclampfastenerwhileholdingthecablein
place.

ReplacingtheDriveBelts

Iftheauger/impellerdrivebeltorthetractiondrivebelt
becomesworn,oil-soaked,orotherwisedamaged,havean
AuthorizedServiceDealerreplacethebelt.

7.Removetheignitionkey.

8.Cleanthemachinethoroughly.

9.Touchupchippedsurfaceswithpaintavailablefroman
AuthorizedServiceDealer.Sandaffectedareasbefore
painting,andusearustpreventativetopreventthe
metalpartsfromrusting.

10.Tightenallloosescrews,bolts,andlocknuts.Repairor
replaceanydamagedparts.

11.Coverthemachineandstoreitinaclean,dryplaceout
ofthereachofchildren.

RemovingtheMachinefrom Storage

1.Removethesparkplugandspintheenginerapidly
usingthestartertoblowtheexcessoilfromthe
cylinder.

2.Installthesparkplugandtightenitrmly.

3.Connectthesparkplugwire.

4.Performtheannualmaintenanceproceduresasgiven
intheRecommendedMaintenanceSchedule.

24

Troubleshooting

Problem

Electricstarterdoesnotturn(electric-start
modelsonly)

Enginedoesnotstartorstartshard

PossibleCauseCorrectiveAction

1.Thepowercordisdisconnectedatthe
outletorthemachine.

2.Thepowercordisworn,corroded,or
damaged.

3.Thepoweroutletisnotenergized.

1.Thekeyisnotintheignitionorisinthe
Stopposition.

2.ThechokeisintheOffpositionandthe
primerhasnotbeenpressed.

3.Thefuelshutoffvalveisnotopen.3.Openthefuelshutoffvalve.

4.ThethrottleisnotintheFastposition.4.MovethethrottletotheFastposition.

5.Thefueltankisemptyorthefuel
systemcontainsstalefuel.

6.Thesparkplugwireislooseor
disconnected.

7.Thesparkplugispitted,fouled,orthe
gapisincorrect.

8.Thefuelventcapisrestricted.

9.Theengineoillevelintheengine
crankcaseistoolowortoohigh.

1.Connectthepowercordtotheoutlet
and/orthemachine.

2.Replacethepowercord.

3.Haveaqualiedelectricianenergize
theoutlet.

1.Insertthekeyintotheignitionandturn
ittotheOnposition.

2.MovethechoketotheOnpositionand
presstheprimer3times.

5.Drainand/orllthefueltankwithfresh
gasoline(notmorethan30daysold).
Iftheproblempersists,contactan
AuthorizedServiceDealer.

6.Connectthewiretothesparkplug.

7.Checkthesparkplugandadjustthe
gapifnecessary .Replacethespark
plugifitispitted,fouled,orcracked.

8.Removetheventrestrictionorreplace
thefuelcap.

9.Addordrainoiltoadjusttheoillevelin
theenginecrankcasetotheFullmark
onthedipstick.

Enginerunsrough

1.ThechokeisintheOnposition.1.MovethechoketotheOffposition.

2.Thefuelshutoffvalveisnotcompletely
open.

3.Thefueltankisnearlyemptyor
containsstalefuel.

4.Thesparkplugwireisloose.

5.Thesparkplugispitted,fouled,orthe
gapisincorrect.

6.Theengineoillevelintheengine
crankcaseistoolowortoohigh.

2.Openthefuelshutoffvalve.

3.Drainandllthefueltankwithfresh
gasoline(notmorethan30daysold).
Iftheproblempersists,contactan
AuthorizedServiceDealer.

4.Connectthewiretothesparkplug.

5.Checkthesparkplugandadjustthe
gapifnecessary .Replacethespark
plugifitispitted,fouled,orcracked.

6.Addordrainoiltoadjusttheoillevelin
theenginecrankcasetotheFullmark
onthedipstick.

25

Problem

PossibleCauseCorrectiveAction

Engineruns,butthemachinedischarges
snowpoorlyornotatall

Dischargechuteeitherdoesnotlockinto
placeordoesnotmove

Themachinedoesnotproperlyclearthe
snowoffthesurface

1.ThethrottleisnotintheFastposition
whenthrowingsnow .

2.Themachineismovingtoofasttoclear
thesnow.

3.Y ouaretryingtoremovetoomuch
snowperswath.

4.Y ouaretryingtoremoveextremely
heavyorwetsnow.

5.Thedischargechuteisplugged.5.Unclogthedischargechute.

6.Theauger/impellerdrivebeltisloose
orisoffthepulley .

7.Theauger/impellerdrivebeltisworn
orbroken.

1.Thedischargechutelatchisnot
properlyadjusted.

1.Theskidsand/orscraperarenot
properlyadjusted.

2.Thepressureinthetiresisnotequal.

1.MovethethrottletotheFastposition.

2.Shiftthemachineintoalowergear.

3.Reducetheamountofsnowremoved
perswath.

4.Don'toverloadthemachinewith
extremelyheavyorwetsnow.

6.Installand/oradjusttheauger/impeller
drivebelt;refertowww.T oro.com
forservicinginformationortakethe
machinetoanAuthorizedService
Dealer.

7.Replacetheauger/impellerdrivebelt;
refertowww.T oro.comforservicing
informationortakethemachinetoan
AuthorizedServiceDealer.

1.Adjustthedischargechutelatch.

1.Adjusttheskidsand/orthescraper.

2.Checkandadjustthepressureinone
orbothtires.

26

Notes:

27

Notes:

28

Notes:

29

EmissionControlWarrantyStatement

FortheUnitedStates,California,andCanada

YourWarrantyRightsandObligations

TheCaliforniaAirResourcesBoard(CARB),theU.S.EnvironmentalProtectionAgency(EPA),andTheT oroCompany,arepleasedtoexplainthe
emissioncontrolsystemwarrantyonyour2013–2014smalloff-roadengine/equipment.InCaliforniaandtheUnitedStates,newsmalloff-road
engines/equipmentmustbedesigned,built,andcertiedtomeetstringentanti-smogstandards.TheToroCompanywarrantstheemissioncontrol
systemonyoursmalloff-roadengine/equipmentfortheperiodoftimelistedbelow,providedtherehasbeennoabuse,neglect,orimpropermaintenance
ofyoursmalloff-roadengine/equipment.

Youremissioncontrolsystemmayincludepartssuchasthecarburetor,fuel-injectionsystem,theignitionsystem,catalyticconverter,fueltanks,fuellines,
fuelcaps,valves,canisters,lters,vaporhoses,clamps,connectors,andotherassociatedemission-relatedcomponents.

Whereawarrantableconditionexists,TheT oroCompanywillrepairyoursmalloff-roadengine/equipmentatnocosttoyouincludingdiagnosis,
partsandlabor.

Manufacturer’sWarrantyCoverage

Thisemissioncontrolsystemiswarrantedfortwoyears.Ifanyemission-relatedpartonyourengine/equipmentisdefective,thepartwillberepairedor
replacedbyTheT oroCompany.

OwnerResponsibilities

Asthesmalloff-roadengineowner,youareresponsiblefortheperformanceoftherequiredmaintenancelistedinyourOperator'sManual.Werecommend
thatyouretainallreceiptscoveringmaintenanceonyoursmalloff-roadengine/equipment,butwecannotdenywarrantysolelyforthelackofreceipts.

Asthesmalloff-roadengine/equipmentowner ,youshouldhoweverbeawarethatwemaydenyyouwarrantycoverageifyoursmalloff-road
engine/equipmentoraparthasfailedduetoabuse,neglect,impropermaintenanceorunapprovedmodications.

Youareresponsibleforpresentingyoursmalloff-roadengine/equipmenttoaT oroDistributionCenterorServiceCenterassoonasaproblemexists.The
warrantyrepairsshouldbecompletedinareasonableamountoftime,nottoexceedthirty(30)days.

Ifyouhaveanyquestionsregardingyourwarrantycoverage,contactusat:

CustomerCareDepartment,ConsumerDivision
ToroWarrantyCompany
811 1LyndaleAvenueSouth
Bloomington,MN55420-1196
Tollfreeat800–348–2424(U.S.customers)
Tollfreeat800–544–5364(Canadiancustomers)

GeneralEmissionsWarrantyCoverage

TheT oroCompanyanditsafliate,T oroWarrantyCompany ,jointlywarranttotheinitial
ownerandeachsubsequentpurchaserthatthesmalloff-roadengine/equipmentis:

•Designed,built,andcertiedtoconformwithallapplicableemissionsregulations;and

•Freefromdefectsinmaterialsandworkmanshipthatcouldcausethefailureofawarrantedpart;and

•Identicalinallmaterialrespectstothepartsasdescribedintheapplicationforcertication.

Thewarrantyperiodbeginsonthedatethesmalloff-roadengine/equipmentisdeliveredtoanultimatepurchaser .Thewarrantedperiodistwoyears.

Subjecttocertainconditionsandexclusionsasstatedbelow,thewarrantyonevaporativeemissions-relatedpartsisasfollows:

1.Anywarrantedpartthatisnotscheduledforreplacementasrequiredmaintenanceinthewritteninstructionssupplied,iswarranted
forthewarrantyperiodstatedabove.Ifthepartfailsduringtheperiodofwarrantycoverage,thepartwillberepairedorreplacedby
TheT oroCompany .Anysuchpartrepairedorreplacedunderwarrantywillbewarrantedfortheremainderofthewarrantyperiod.

2.Anywarrantedpartthatisscheduledonlyforregularinspectioninthewritteninstructionssuppliediswarrantedforthewarranty
periodstatedabove.Anysuchpartrepairedorreplacedunderthewarrantywillbewarrantedfortheremainderofthewarrantyperiod.

3.Anywarrantedpartthatisscheduledforreplacementasrequiredmaintenanceinthewritteninstructionssuppliedis
warrantedfortheperiodoftimebeforetherstscheduledreplacementdateforthatpart.Ifthepartfailsbeforetherst
scheduledreplacement,thepartwillberepairedorreplacedbyTheToroCompany .Anysuchpartrepairedorreplaced
underwarrantywillbewarrantedfortheremainderoftheperiodpriortotherstscheduledreplacementpointforthepart.

4.Repairorreplacementofanywarrantedpartunderthewarrantyprovisionshereinmustbeperformedatan
AuthorizedServiceDealeratnochargetotheowner.

5.Notwithstandingtheprovisionsherein,warrantyservicesorrepairswillbeprovidedatallServiceDealers
authorizedtoservicethesubjectenginesorequipment.

6.Thesmalloff-roadengine/equipmentownerwillnotbechargedfordiagnosticlaborthatisdirectlyassociatedwithdiagnosis
ofadefective,emission-relatedwarrantedpart,providedthatsuchdiagnosticworkisperformedatanAuthorizedServiceDealer.

7.TheToroCompanyisliablefordamagestootherengine/equipmentcomponentscausedbyafailureunderwarrantyofanyemissionspart.

8.Throughoutthesmalloff-roadengine/equipmentwarrantyperiodstatedabove,TheT oroCompany
willmaintainasupplyofwarrantedpartssufcienttomeettheexpecteddemandforsuchparts.

9.Manufacturerapprovedreplacementpartsmaybeusedintheperformanceofanywarrantymaintenanceorrepairsand
mustbeprovidedwithoutchargetotheowner.SuchusewillnotreducethewarrantyobligationsofTheT oroCompany .

10.Add-onormodiedpartsthatarenotapprovedbyTheToroCompanymaynotbeused.Theuseofanon-approvedadd-onormodiedparts
bythepurchaserwillbegroundsfordisallowingawarrantyclaim.TheT oroCompanywillnotbeliabletowarrantfailuresofwarrantedparts
causedbytheuseofannon-approvedadd-onormodiedparts.

374-0287RevC

WarrantedParts

Thefollowingemissionwarrantypartsarecovered,totheextentthesepartswerepresentontheT oroengine/equipmentand/orT orosuppliedfuelsystem:

1.FuelSystemParts

•Carburetorandinternalparts

•Coldstartingenrichment(primerorchoke)

•Fuelpump

•Fuelline,ttings,andclamps

•Fueltank,cap,andtether

•Carboncanister

2.AirInductionSystem

•Aircleaner

•Intakemanifold

•Crankcaseventandline(s)

•Purgelineandttings

3.IgnitionSystem

•Sparkplug(s)andwire(s)

•Magnetoignitionsystem

4.CatalyticExhaustSystem

•Catalyticconverter

•Exhaustmanifold

•Airinjectorsystemandvalve(s)

5.MiscellaneousItemsUsedinEmissionControlSystem

•Valves,switches,andlinkages

•Connectors,ttings,andbrackets

374-0287RevC

AThree-Y earLimitedWarranty(45DayLimitedWarrantyforCommercialUse)

TheToroTotalCoverageGuarantee

PowerMaxHDand
PowerMax
Two-StageSnowthrowers

ConditionsandProductsCovered

TheToroCompanyanditsafliate,ToroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetorepairtheT oroProduct
listedbelowifusedforresidentialpurposes*,ifdefectiveinmaterialsor
workmanshiporifitstopsfunctioningduetothefailureofacomponent
fortheperiodlistedbelow.

Thiswarrantycoversthecostofpartsandlabor,butyoumustpay
transportationcosts.

Thefollowingtimeperiodsapplyfromthedateofpurchase:

ProductsWarrantyPeriod`
PowerMaxHDandPowerMaxSnowthrowers

andAttachments
—PowerMaxHDandPowerMaxChuteGuaranteedforLife

—PowerMaxHDandPowerMaxDeectorGuaranteedforLife

—PowerMaxHDandPowerMax
Anti-CloggingSystem

(PlasticImpellerHousingcover)

3years

Warranty(originalowner
only)

Warranty(originalowner
only)

GuaranteedforLife
Warranty(originalowner
only)

LimitedWarrantyforCommercialUse

Gas-poweredT oroProductsusedforcommercial,institutional,orrental
use,arewarrantedfor45daysagainstdefectsinmaterialsorworkmanship.
Componentsfailingduetonormalweararenotcoveredbythiswarranty .

InstructionsforObtainingWarrantyService

IfyouthinkthatyourToroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:

1.ContactanyAuthorizedToroServiceDealertoarrangeserviceattheir
dealership.Tolocateadealerconvenienttoyou,refertotheYellow
Pagesofyourtelephonedirectory(lookunder“LawnMowers”)or
accessourwebsiteatwww.Toro.com.Youmayalsocallthenumbers
listedinitem#3tousethe24-hourToroDealerlocatorsystem.

2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.Thedealerwilldiagnosetheproblemanddetermineif
itiscoveredunderwarranty.

3.IfforanyreasonyouaredissatisedwiththeServiceDealer’s
analysisorwiththeassistanceprovided,contactusat:

CustomerCareDepartment,ConsumerDivision
TheT oroCompany
811 1LyndaleAvenueSouth
Bloomington,MN55420-1196
Tollfreeat866-336-5205(U.S.customers)
Tollfreeat866-854–9033(Canadiancustomers)

OwnerResponsibilities

YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutinemaintenance,
whetherperformedbyadealerorbyyou,isatyourexpense.

ItemsandConditionsNotCovered

Thereisnootherexpresswarrantyexceptforspecialemissionsystem
coverageandenginewarrantycoverageonsomeproducts.Thisexpress
warrantydoesnotcoverthefollowing:

•Costofregularmaintenanceserviceorreplacementofwearparts,

suchasrotorblades(paddles),scraperblades,belts,fuel,lubricants,
oilchanges,sparkplugs,cable/linkageorbrakeadjustments

•Anyproductorpartwhichhasbeenalteredormisusedandrequires

replacementorrepairduetoaccidentsorlackofpropermaintenance

•Repairsnecessaryduetofailuretousefreshfuel(lessthanone

monthold),orfailuretoproperlypreparetheunitpriortoanyperiodof
non-useoveronemonth

•Pickupanddeliverycharges

•Operationalmisuse,neglect,oraccidents

•RepairsorattemptedrepairsbyanyoneotherthananAuthorizedToro

ServiceDealer

GeneralConditions

AllrepairscoveredbythesewarrantiesmustbeperformedbyanAuthorized
ToroServiceDealerusingToroapprovedreplacementparts.Repairbyan
AuthorizedToroServiceDealerisyoursoleremedyunderthiswarranty .

NeitherTheToroCompanynorToroW arrantyCompanyisliablefor
indirect,incidental,orconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythesewarranties,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletionof
repairsunderthesewarranties.

Allimpliedwarrantiesofmerchantability(thattheproductistforordinary
use)andtnessforuse(thattheproductistforaparticularpurpose)are
limitedtothedurationoftheexpressedwarranty .

Somestatesdonotallowexclusionsofincidentalorconsequential
damages,orlimitationsonhowlonganimpliedwarrantylasts,sotheabove
exclusionsmaynotapplytoyou.

Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveother
rightswhichvaryfromstatetostate.

CountriesOtherthantheUnitedStatesorCanada

CustomerswhohavepurchasedT oroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirT oroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheToroimporter.Ifallotherremediesfail,youmaycontactusatToroWarrantyCompany.

AustralianConsumerLaw

AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oroDealer.

*Residentialpurposesmeansuseoftheproductonthesamelotasyourhome.Useatmorethanonelocation,orinstitutionalorrentaluse,isconsidered
commercialuse,andthecommercialusewarrantywouldapply.

374-0251RevD
