Form No. 3321-871

Dingo

320-D

Traction Unit

Model Number 22303—990001 & Up

Operator’s Manual

Domestic English (EN)

Introduction

Thank you for purchasing a Toro product. All of us at Toro want you to be completely satisfied

with your new product, so feel free to contact your local Authorized Service Dealer for help with service, genuine replacement parts, or other information you may require.

Whenever you contact your Authorized Service Dealer or the factory, always know the model and serial numbers of your product. These numbers will help the Service Dealer or Service Representative provide exact information about your specific product. The two numbers are stamped into a plate mounted on left rear side of frame.

For your convenience, write the product model and serial numbers in the space below.

Model No:

Serial No.

Read this manual carefully to learn how to operate and maintain your product correctly. Reading this manual will help you and others avoid personal injury and damage to the product. Although we design, produce and market safe, state-of-the-art products, you are responsible for using the product properly and safely. You are also responsible for training persons, who you allow to use the product, about safe operation.

The warning system in this manual identifies potential hazards and has special safety messages that help you and others avoid personal injury, even death. DANGER, WARNING and CAUTION are signal words used to identify the level of hazard. However, regardless of the hazard, be extremely careful.

DANGER signals an extreme hazard that will cause serious injury or death if the recommended precautions are not followed.

WARNING signals a hazard that may cause serious injury or death if the recommended precautions are not followed.

CAUTION signals a hazard that may cause minor or moderate injury if the recommended precautions are not followed.

The Toro Company – 1999

8111 Lyndale Ave. South Bloomington, MN 55420–1196

Two other words are also used to highlight information. “Important” calls attention to special mechanical information and “Note” emphasizes general information worthy of special attention.

The left and right side of the machine is determined by standing on the platform in the normal operator’s position.

The engine exhaust from this product

contains chemicals known to the State of

California to cause cancer, birth defects,

or other reproductive harm.

Printed in the USA

Contents

Page

Safety 2.

Assembly 7

Specifications 10

Before Operating 12

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safe Operating Practices 2 Slope Chart 5 Safety and Instruction Decals 6

Loose Parts 7 Installing the Valve Lever 7 Activating the Battery 7

Attachments 10 Stability Data 11

Adding Fuel 12 Draining Water from the Fuel Filter 13 Checking the Oil Level 13 Checking the Cooling System 14 Removing Debris from the Traction Unit 14 Checking the Hydraulic Fluid 15 Tire pressure 15

. . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . .

. . . . . . . . . .

. . . . . . . . . . . . .

. . . . . . . . . . . . . . . .

. . . . .

. . . . . . . . . . . . . . .

. . . . . . . . . .

Page

Operation 17

Maintenance 25

Troubleshooting 36 Warranty

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Traction Unit Overview 17 Controls 18 Indicator Lights 20 Starting and Stopping the Engine 20 Driving Forward or Backward 21 Stopping the Traction Unit 21 Moving a Non-functioning Traction Unit 22 Using the Cylinder Locks 22 Installing and Removing Attachments 23 Securing the Traction Unit for Transport 24

Service Interval Chart 25

Opening the Access Covers26. . . . . . . . . . . .

Servicing the Air Cleaner 27 Servicing the Engine Oil 28 Greasing the Traction Unit 29 Changing the Fuel Filter 30 Bleeding the Fuel System 31 Draining the Fuel Tank 31 Servicing the Hydraulic System 32 Servicing the Battery 33 Cleaning and Storage 34

. . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . .

. . . . . . .

. . . . . . . . . .

. . . . . . . . . . . . .

. . . .

. .

. . . . . . . . . . . . . . . .

. . . . . . . . . . . . . .

. . . . . . . . . . . . .

. . . . . . . . . . . . . .

. . . . . . . . . . . . .

. . . . . . . . . . . . . . .

. . . . . . . . .

. . . . . . . . . . . . . . . . .

Back Cover

                  

                          

Safety

Improper use or maintenance by the operator or owner can result in injury. To reduce the potential for injury, comply with these safety instructions and always pay attention to the safety alert symbol, which means CAUTION, WARNING, or DANGER—“personal safety instruction.” Failure to comply with the instruction may result in personal injury or death.

Safe

This product is capable of amputating hands and feet. Always follow all safety instructions to avoid serious injury or death.

Operating Practices

POTENTIAL HAZARD

• Engine exhaust contains carbon monoxide,

which is an odorless, deadly poison.

WHAT CAN HAPPEN

• Carbon monoxide can kill you and is also

known to the State of California to cause birth defects.

•

Always wear long pants and substantial shoes. Wearing safety glasses, safety shoes, hearing protection, and a hard hat are advisable and may be required by some local ordinances and insurance regulations.

• Ensure that the area is clear of other people

before operating the traction unit. Stop the traction unit if anyone enters the area.

• Never carry passengers on attachments or on the

traction unit.

• Always look down and behind before and while

backing.

• Do not place your feet under the platform.

• Slow down before turning. Sharp turns on any

terrain may cause loss of control.

• Never leave a running traction unit unattended.

Always lower the loader arms, stop the engine, and remove the key before dismounting.

• Do not exceed the rated operating capacity, as

the traction unit may become unstable which may result in loss of control.

HOW TO AV

OID THE HAZARD

• Do not run engine indoors or in an enclosed

area.

General Operation

• Read, understand, and follow all instructions in

the operator’s manual, in the video, and on the traction unit before starting. Also, read all attachment manuals where supplied

• Allow only responsible adults who are familiar

with the instructions to operate the traction unit.

• Do not carry a load with the arms raised. Always

carry loads close to the ground. Do not step off of the platform with the load raised.

• Do not over-load the attachment and always

keep the load level when raising the loader arms. Logs, boards, and other items could roll down the loader arms, injuring you.

• Never jerk the control levers; use a steady

motion.

• Keep your hands, feet, hair, and loose clothing

away from any moving parts.

• Operate only in daylight or good artificial light.

• Do not operate the traction unit while under the

influence of alcohol or drugs.

Safety

• Watch for traffic when operating near or crossing

roadways.

• Use extra care when loading or unloading the

traction unit onto a trailer or truck.

• Do not touch parts which may be hot from

operation. Allow them to cool before attempting to maintain, adjust, or service.

Slope Operation

Slopes are a major factor related to loss-of-control and tip-over accidents, which can result in severe injury or death. All slopes require extra caution.

• Do not operate the traction unit on hillsides or

slopes exceeding the angles recommended in the Stability Data section, page 11, and those in the attachment operator’s manual. See also the slope chart on page 5.

• Operate up and down slopes with the heavy

end of the traction unit uphill. Weight

distribution changes. An empty bucket will make the rear of the traction unit the heavy end, and a full bucket will make the front of the traction unit the heavy end. Most other attachments will make the front of traction unit the heavy end.

• Use slow speed on slopes. Before starting the

engine, put the pump selector lever in the slow (turtle) position so that you will not have to stop or shift while on the slope.

• Follow the recommendations in the attachment

manuals for the use of counterweights to improve stability.

• Use only Toro approved attachments.

Attachments can change the stability and the operating characteristics of the traction unit. Warranty may be voided if used with unapproved attachments.

• Keep all movements on slopes slow and gradual.

Do not make sudden changes in speed or direction.

• Avoid starting or stopping on a slope. If tires

lose traction, proceed slowly, straight down the slope.

• Check for overhead clearances (i.e. branches,

doorways, electrical wires) before driving under any objects and do not contact them.

• Avoid turning on slopes. If you must turn, turn

slowly and keep the heavy end of the traction unit uphill.

• Raising the loader arms on a slope will affect the

stability of the machine. Whenever possible, keep the loader arms in the lowered position when on slopes.

• Removing an attachment on a slope will make

the rear of the traction unit heavy. Refer to the Stability Data section, page 11, to determine whether the attachment can be safely removed on the slope.

• Remove obstacles such as rocks, tree limbs, etc.

from the work area. Watch for holes, ruts, or bumps, as uneven terrain could overturn the traction unit. T

all grass can hide obstacles.

• Do not operate near drop-offs, ditches, or

embankments. The traction unit could suddenly turn over if a wheel goes over the edge of a cliff or ditch, or if an edge caves in.

• Do not operate on wet grass. Reduced traction

could cause sliding.

• Do not park the traction unit on a hillside or

slope without lowering the attachment to the ground and chocking the wheels.

• Do not try to stabilize the traction unit by putting

your foot on the ground.

Safety

Children

Tragic accidents can occur if the operator is not alert to the presence of children. Children are often attracted to the traction unit and the work activity. Never assume that children will remain where you last saw them.

• Keep children out of the work area and under the

watchful care of another responsible adult.

• Be alert and turn the traction unit off if children

enter the area.

• Before and while backing, look behind and down

for small children.

• Never carry children. They may fall off and be

seriously injured or interfere with safe traction unit operation.

• Never allow children to operate the traction unit.

• Use extra care when approaching blind corners,

shrubs, trees, the end of a fence, or other objects that may obscure vision.

• Use extra care when handling fuel. It is

flammable and vapors are explosive.

• Use only an approved container.

• Never remove the fuel cap or add fuel when

the engine is running. Allow the engine to cool before refueling. Do not smoke.

• Never refuel the traction unit indoors.

• Never store the traction unit or fuel

container inside where there is an open flame, such as near a water heater or furnace.

• Never fill a container while it is inside a

vehicle, trunk, pick–up bed, or any surface other than the ground.

• Keep container nozzle in contact with the

tank during filling.

• Stop and inspect the equipment if you strike an

object. Make any necessary repairs before restarting.

Service

• Stop the engine before performing any service,

repairs, maintenance, or adjustments.

• If any maintenance or repair requires the loader

arms to be in the raised position, secure the arms in the raised position with the hydraulic cylinder locks included with traction unit.

• Never run a traction unit inside a closed area.

• Keep nuts and bolts tight. Keep equipment in

good condition.

• Never tamper with safety devices. Check safety

systems for proper operation before each use.

• Keep the traction unit free of grass, leaves, or

other debris build-up. Clean up oil or fuel spillage. Allow the traction unit to cool before storing.

• Use only genuine replacement parts to ensure

that original standards are maintained.

• Battery acid is poisonous and can cause burns.

Avoid contact with skin, eyes, and clothing. Protect your face, eyes, and clothing when working with a battery.

• Battery gases can explode. Keep cigarettes,

sparks and flames away from the battery.

• Keep your body and hands away from pin hole

leaks or nozzles that eject high pressure hydraulic fluid. Use cardboard or paper to find hydraulic leaks. Hydraulic fluid escaping under pressure can penetrate skin and cause injury requiring surgery within a few hours by a qualified surgeon or gangrene may result.

Safety

Slope

Chart



Safety

Safety and Instruction Decals

Safety decals and instructions are easily visible to the operator and are located near any area of potential danger. Replace any decal that is damaged or lost.

# 98-8219

# 98-4677

# 98-8235

# 98–8220

# 98-9051

# 93-7814

# 85-4730

# 93-6680

# 98-4682

# 93-9084

# 93-6681

# 80-8010

1. Fast

2. Traction

3. Slow

drive

Entanglement hazard

5. Stay

away

from moving parts

Figure 1

6. Use

only diesel fuel

Lift point

# 99-3157

Engine speed Cutting hazard—moving fan

Assembly

Loose

Parts

Note: Use the chart below to verify that all parts have been shipped.

DESCRIPTION QTY. USE

raction Unit

alve Lever

Key 2

Installing

the V

alve Lever

1. Thread the lever into the pump selector valve

(Fig. 2).

1 1

Install valve lever

Start engine

Activating

the Battery

The traction unit is shipped with a dry battery. Bulk electrolyte with 1.260 specific gravity must be purchased from a local battery supply outlet.

Note: The lever should be installed with the

bend toward the operator.

1. Remove the four bolts securing the battery cover

and remove the cover (Fig. 3)

2. Tighten the jam nut on the lever to lock it in

position.

2. Remove the nuts and bars securing the battery

(Fig. 3).

1. Pump

selector lever

Figure 2

m–3883

1. Battery

2. Bolt

3. Battery

4. Bars

cover

Figure 3

5. Nut

Positive cable

Negative cable

m–4391

Assembly

3. Lift the battery off of its platform.

POTENTIAL HAZARD

• Battery electrolyte contains sulfuric acid

which is a deadly poison and it causes severe burns.

WHAT CAN HAPPEN

• If you drink electrolyte you could die, or, if

it gets onto your skin, you will be burned.

HOW TO AV

OID THE HAZARD

• Do not drink electrolyte and avoid contact

with skin, eyes or clothing. Wear safety glasses to shield your eyes and rubber gloves to protect your hands.

• Fill the battery where clean water is always

available for flushing the skin.

• Follow all instructions and comply with all

safety messages on the electrolyte container.

4. Remove the filler caps from the battery.

5. Slowly pour electrolyte into each cell until the

electrolyte level is up to the lower part of the tube (Fig. 4).

1254

1. Positive

Negative post

post

Figure 5

Charger red (+) wire

Charger black (–) wire

7. Charge the battery at a rate of 4 amperes or less

for 4 hours (12 volts).

1262

Figure 4

1. Filler

2. Electrolyte

caps

Lower part of the tube

6. Leave the covers off and connect a 3 to 4 amp

battery charger to the battery posts (Fig. 5).

POTENTIAL HAZARD

• Charging the battery pr

oduces gasses.

WHAT CAN HAPPEN

• Battery gasses can explode.

HOW TO AV

OID THE HAZARD

• Keep cigarettes, sparks, and flames away

from the battery.

8. When the battery is fully charged, disconnect the

charger from the electrical outlet and from the negative and positive battery posts (Fig. 5).

9. Slowly pour electrolyte into each cell until the

level is once again up to the upper line on the battery case (Fig. 4) and install the covers.

10. Install the battery onto its platform (Fig. 3).

11. Secure the battery in the chassis with the bars

and nuts removed previously (Fig. 3).

12. Connect the positive (red) cable to the

positive (+) battery post (Fig. 3). Slide the rubber cover over the battery post.

13. Connect the negative (black) cable to the

negative (–) battery post (Fig. 3). Note: Ensure that the battery cables do not

contact any sharp edges or each other.

14. Install the battery cover (Fig. 3).

Assembly

Specifications

Note: Specifications and design are subject to change without notice.

Width Length Height Weight Operating capacity (with a 200 lb operator) T

ipping capacity (with a 200 lb operator) Wheelbase Dump height (with standard bucket) Reach—fully raised (with the standard bucket) Height to hinge pin (with the standard bucket fully raised)

Attachments

Many attachments are available for use with the traction unit. These attachments allow you to to perform many different functions with the traction unit such as hauling materials, digging holes, grading, and more. Contact your Toro dealer for a list of all approved SiteW accessories.

ork Systems attachments and

40.5 inches (103 cm) 60 inches (152 cm) 49 inches (125 cm) 1722 lbs (781 Kg) 515 lbs (234 Kg) 1030 lbs (467 Kg) 28 inches (71 cm)

48.75 inches (124 cm) 26 inches (66 cm) 66 inches (168 cm)

IMPORTANT: Use only Toro approved attachments.

Check Before Operating

Stability

Data

The following table lists the maximum slope recommended for the traction unit in the positions listed in the table. Slopes over the listed degree may cause the traction unit to become unstable. The data in the table assumes that the loader arms are fully lowered and that the factory installed tires are on the traction unit, inflated to the recommended pressure; raised arms and other tire types or pressure may affect the stability.

Maximum Recommended Slope

when Operating with:

Front Uphill

Configuration

raction unit without attachment

raction unit with counterweight, without attachment

raction unit with an attachment rated with one of the following

stability ratings for each slope position:*

A 25° 25° 20° B 18° 19° 18°

7° 20° 17° 5° 21° 17°

Rear Uphill

Side Uphill

C 15° 16° 14° D 10° 10° 9° E 5° 5° 5°

* In each attachment manual is a set of three stability ratings, one for each hill position. To determine the maximum slope you can traverse with the attachment installed, find the degree of slope that corresponds to the stabilities ratings of the attachment.

Example: If the attachment installed on the traction unit has a Front Uphill rating of B, a Rear Uphill rating of D, and a Side Uphill rating of C, then you could drive forward up an 18

° slope, rearward up a 10° slope, or

sideways on a 14° slope, as listed in the above table.

Before Operating

Before operating, check the fuel and oil level, remove debris from the traction unit, and check the tire pressure. Also, ensure that the area is clear of people and debris. You should also know and have marked the locations of all utility lines.

Adding

The engine runs on clean, fresh diesel fuel with a minimum cetane rating of 40. Purchase fuel in quantities that can be used within 30 days to ensure fuel freshness.

Use summer grade diesel fuel (No. 2–D) at temperatures above 20 F (–7 C) and winter grade diesel fuel (No. 1–D or No. 1–D/2–D blend) below 20 F (–7 C). Use of winter grade diesel fuel at lower temperatures provides lower flash point and pour point characteristics, allowing easier starts and lessening the chances of chemical separation of the fuel due to lower temperatures.

Use of summer grade diesel fuel above 20 F (–7 C) will contribute toward longer life of the fuel pump components.

IMPORTANT: Do not use ker gasoline in place of diesel fuel. Failure to observe this caution will damage the engine.

1. Park the traction unit on a level surface, lower

the loader arms, and stop the engine.

Fuel

osene or

5. Install the fuel tank cap securely. Wipe up any

fuel that may have spilled.

If possible, fill the fuel tank after each use. This will minimize possible buildup of condensation inside the fuel tank.

POTENTIAL HAZARD

• Under certain conditions fuel is extremely

flammable and highly explosive.

WHAT CAN HAPPEN

• A fire or explosion from fuel can burn you,

others, and cause property damage.

HOW TO AV

OID THE HAZARD

• Fill the fuel tank outdoors, in an open area,

when the engine is cold. Wipe up any fuel that spills.

• Do not fill the fuel tank completely full.

Add fuel to the fuel tank until the level is 1/4 to 1/2 in. (6 to 13 mm) below the bottom of the filler neck. This empty space in the tank allows fuel to expand.

• Never smoke when handling fuel, and stay

away from an open flame or where fuel fumes may be ignited by a spark.

• Store fuel in an approved container and

keep it out of the reach of children. Never buy more than a 30-day supply.

2. Remove the key and allow the engine to cool.

3. Clean around the fuel tank cap and remove the

cap.

4. Use a funnel and add diesel fuel to the fuel tank,

until the level is 1/4 to 1/2 inch (6 mm to 13 mm) below the bottom of the filler neck.

Note: This space in the tank allows fuel to

expand. Do not fill the fuel tank completely full.

Check Before Operating

Draining Water from the Fuel Filter

Drain water or other contaminants from the fuel filter daily.

1. Stop the engine and remove the key.

2. Open the rear access cover; refer to Opening the

Rear Access Cover

3. Turn the drain valve until the water runs out of

the filter (Fig. 6). Note: The fuel filter is located near the

bottom of the fuel tank.

, page 26.

3. Open the rear access cover; refer to Opening the

Rear Access Cover

, page 26.

4. Clean around the oil dipstick (Fig. 7).

5. Pull out the dipstick and wipe the metal end

clean (Fig. 7).

6. Slide the dipstick fully into the dipstick tube

(Fig. 7).

7. Pull the dipstick out and look at the metal end.

8. If the oil level is low, clean around the oil filler

cap and remove the cap (Fig. 7).

9. Slowly pour only enough oil into the valve cover

to raise the level to the F (full) mark.

IMPORTANT: If you overfill the crankcase with oil, the excess oil may damage the engine.

10. Replace the filler cap and dipstick.

1. Fuel

filter

Figure 6

Drain valve

m–3708

4. Close the valve.

Close the rear access cover

Checking

the Oil Level

1. Park the traction unit on a level surface, lower

the loader arms, and stop the engine.

2. Remove the key and allow the engine to cool.

m–4594 m–3219

1. Oil

dipstick

Filler cap

Figure 7

3. V

alve cover

Metal end

11. Close the rear access cover.

Check Before Operating

Checking

The cooling system is filled with a 50/50 solution of water and permanent ethylene glycol anti–freeze. Check the level of coolant at the beginning of each day, before starting the engine.

POTENTIAL HAZARD

the Cooling System

• Coolant is hot and pressurized.

WHAT CAN HAPPEN

• Discharge of hot pressurized coolant can

cause sever

HOW TO AV

e burns.

OID THE HAZARD

• Do not remove the radiator cap when the

engine is hot. Always allow the engine to cool at least 15 minutes or until the radiator cap is cool enough to touch without burning your hand before removing it.

m–4591

Figure 8

1. Filler

Removing T

1. Park the traction unit on a level surface, raise the

Cap

Debris from the

raction Unit

IMPORTANT: Operating the engine with a blocked radiator, may result in engine damage from overheating.

loader arms, and install the cylinder locks; refer to Using the Cylinder Locks, page 22.

1. Park the traction unit on a level surface, lower

the loader arms, and stop the engine. Remove the key.

2. Allow the engine to cool.

3. Remove the radiator filler cap and check the

coolant level (Fig. 8). The coolant should be up to filler neck.

4. If coolant level is low, replenish the system. IMPORTANT: Do not over fill the radiator.

5. Replace the radiator filler cap, ensuring that it is

tightly sealed.

2. Stop the engine and remove the key.

3. Remove the front access cover, refer to

Removing the Front Access Cover, page 26.

4. Clean any debris from the grill.

5. Open the rear access cover; refer to Opening the

Rear Access Cover

6. Wipe away debris from the air cleaner.

7. Clean any debris build–up on the engine with a

brush or blower before each use.

IMPORTANT: It is preferable to blow dirt out, rather than washing it out. If water is used, keep it away from electrical items and hydraulic valves. Do not use a high-pressure washer. High-pressure washing can damage the electrical system and hydraulic valves or deplete grease.

8. Replace and secure the front and rear access

covers.

, page 26.

9. Remove and store the cylinder locks (refer to

Using the Cylinder Locks, page 22), and lower the loader arms.

Checking

Check the hydraulic fluid level before the engine is first started and after every 25 operating hours.

Hydraulic Tank Capacity: 17.25 gal. (67 l) Use only Group 1 ISO type 46/68 anti–wear

hydraulic fluids, recommended for ambient temperatures consistently below 100_F (38_C), such as Toro Hy–Pro, Mobil Fluid 424, or other equivalent fluid.

the Hydraulic Fluid

Check Before Operating

m–4596

Figure 9

1. Filler

7. If the level is low, add enough fluid to raise it to

neck cap

the proper level.

2. Dipstick

IMPORTANT: Use only the group 1 ISO type 46/68 anti–wear hydraulic fluids. Other fluids could cause system damage.

1. Remove the attachment, if one is installed; refer

to Removing an Attachment, page 24.

2. Park the traction unit on a level surface, raise the

loader arms, and install the cylinder locks; refer to Using the Cylinder Locks, page 22.

3. Stop the engine and remove the key.

4. Remove the front access cover, refer to

Removing the Front Access Cover, page 26.

5. Clean the area around the filler neck of the

hydraulic tank (Fig. 9).

6. Remove the cap from the filler neck and check

the fluid level on the dipstick (Fig. 9). The fluid level should be 1/2 to 3/8 inches (10 to

15 mm) below the mark on the dipstick when the loader arms are raised. If the loader arms are lowered, the fluid level should be at the mark on the dipstick.

8. Install the cap on the filler neck.

9. Install the front access cover.

10. Remove and store the cylinder locks (refer to

Using the Cylinder Locks, page 22) and lower the loader arms.

Tire

pressure

Maintain the air pressure in the tires as specified. Check the tires when they are cold to get the most accurate reading.

Pressure: 15–20 psi (103–138 kPa)

Note: Use a lower tire pressure (15 psi/

103 kPa) when operating in sandy soil conditions to provide better traction in the loose soil.

Check Before Operating

Figure 10

1. Valve

m–1872

stem

Operation

Traction

Unit Overview

Figure 11 contains a front and back view of the traction unit. Familiarize yourself with all of the traction unit components listed in Figure 11.

Fuel tank

7. Wheel

Lift cylinder

Operator platform

m-4592

Figure 1

10.

Rear access cover (open)

11. Engine

12.

Air filter

13.

Control panel

14.

Lift points

15. Handle

16. Battery

17.

Indicator lights

m-4599

1. Mount

2. T

plate

ilt cylinder Auxiliary hydraulic couplers Loader arms Front access cover

POTENTIAL

HAZARD

• The operator could fall off of the platform.

WHAT CAN HAPPEN

• The operator could be seriously injured.

HOW TO AV

• Do not move any of the contr

unless standing with both feet on the platform and with hands holding the handles.

OID THE HAZARD

ol levers

Operation

Controls

Become familiar with all the controls (Fig. 12) before you start the engine and operate the traction unit.

1. Traction

control levers Attachment tilt lever Loader arm lever Auxiliary hydraulics lever

Figure 12

Key Switch

The key switch, used to start and stop the engine, has three positions: stop, run, and start.

To start the engine, rotate the key to the start position. Release the key when engine starts and it will move automatically to the run position.

To stop the engine, rotate the key to the stop position.

Throttle Lever

m–4388

Speed selector lever Throttle lever Key switch

To turn, move the lever located on the side you want to turn back toward the neutral position while keeping the other lever engaged.

The farther you move the traction control levers in either direction, the faster the traction unit will move in that direction.

To slow or stop, move the traction control levers to neutral.

Attachment Tilt Lever

To tilt the attachment forward, slowly push the attachment tilt lever forward.

To tilt the attachment rearward, slowly pull the attachment tilt lever rearward.

Loader Arm Lever

To lower the loader arms, slowly push the loader arm lever forward.

To raise the loader arms, slowly pull the loader arm lever rearward.

Auxiliary Hydraulics Lever

To operate a hydraulic attachment in a forward direction, slowly pull the auxiliary hydraulics lever rearward.

Move the control forward to increase the engine speed and rearward to decrease speed.

Traction Control Levers

To move forward, move the traction control levers forward. To move rearward, move the traction control levers rearward.

To go straight, move both traction control levers equally.

To operate a hydraulic attachment in a reverse direction, slowly push the auxiliary hydraulics lever forward.

Speed Selector Lever

Move the speed selector lever to the fast (rabbit) position to set the traction drive, loader arms, and attachment tilt to high speed and the auxiliary hydraulics to low speed.

Operation

Move the speed selector lever to the slow (turtle) position to set the auxiliary hydraulics to high speed and the traction drive, loader arms, and attachment tilt to low speed.

POTENTIAL HAZARD

• If the speed selector lever is moved while

the traction unit is in motion, the traction unit will either stop suddenly or accelerate quickly.

• If the traction unit is operated with the

speed selector lever in an intermediate position, the traction unit will operate erratically and may be damaged.

WHAT CAN HAPPEN

• You could be thrown forward or

backwards, resulting in injury.

• If the traction unit accelerates quickly, you

could loose control of the traction unit and injure bystanders or yourself.

• You could loose control of the traction unit,

severely injuring yourself or others.

• The traction unit could be damaged.

HOW TO AV

OID THE HAZARD

• Do not move the speed selector lever when

the traction unit is in motion.

• Do not operate the traction unit when the

speed selector is in any intermediate position (i.e., any position other than fully forward or fully rearward).

Flow Divider Control

The traction unit hydraulics (i.e., the traction drive, loader arms, and attachment tilt) work on a separate hydraulic circuit from the auxiliary hydraulics for powering attachments; however, the two systems share the same hydraulic pumps. Using the flow divider control (Fig. 13), you can vary the speed of the traction unit hydraulics by diverting hydraulic flow to the auxiliary hydraulics circuit. The flow divider allows you to divide the flow of fluid in varying degrees to slow the traction unit. Thus, the

more hydraulic flow you divert to the auxiliary hydraulics, the slower the traction unit hydraulics will move.

Note: The flow divider position (i.e., 9–12

o’clock) is determined when standing in the normal operator’s position. Figure 13 shows the flow divider from the front.

Figure 13

1. Flow

2. Knob

divider control

12 o’clock position

10 to 1

1 o’clock position

9 o’clock position

• Move the flow divider control to the

twelve–o’clock position to provide maximum speed to the traction unit hydraulics.

Use this setting for fast operation of the traction unit.

• Move the flow divider control between the

twelve–o’clock and nine–o’clock positions to slow the traction unit hydraulics and fine tune the speed.

Use a setting in this range with attachments with hydraulics where you need to both run the attachment and move the traction unit hydraulics, such as the auger, boring unit, hydraulic blade, and tiller.

• Move the control to the nine–o’clock position to

transfer all hydraulic flow to the auxiliary hydraulics of the attachment.

In this setting, the traction unit hydraulics will not work. Use this setting with hydraulic attachments that do not required the traction unit hydraulics. There are currently no attachments that require the nine–o’clock position; however,

Operation

the trencher does work best if you set it close to nine–o’clock so that the traction unit will creep slowly when trenching.

Note: The flow divider control can be fixed

in place by turning the knob on the control clockwise until it contacts the dial (Fig. 13).

Indicator

Lights

The indicator lights warn you in the case of a system malfunction and, in the case of the glow plug light, indicate that the glow plugs are on. Figure 14 illustrates the four indicator lights.

m–4603

down. Check the oil level and fill the crankcase with oil as needed. If the problem persists, contact your Authorized Toro Dealer for diagnostics and repair.

Battery Light

This light is on for a few seconds whenever you start the engine. If the battery light is on while the engine is running, the alternator, battery, or electrical system is broken. Contact your Authorized Toro Dealer for diagnostics and repair.

Glow Plug Light

This light is on when the key is turned to run before starting the engine. The glow plug light will remain on for up to 10 seconds, indicating that the glow plugs are warming the engine. If the glow plug light is on while the engine is running, the glow plugs are broken. Contact your Authorized Toro Dealer for diagnostics and repair.

Figure 14

1. Engine

temperature light

Oil pressure light

Battery light

Glow plug light

Engine Temperature Light

If the engine temperature light is on, the engine is overheating. Stop the engine and allow the traction unit to cool down. Check the coolant level and the belts to the fan and water pump. Fill the coolant as required and replace any worn or slipping belts. If the problem persists, contact your Authorized Toro Dealer for diagnostics and repair.

Oil Pressure Light

This light is on for a few seconds whenever you start the engine. If the oil pressure light is on while the engine is running, the engine oil pressure is low. Stop the engine and allow the traction unit to cool

Starting

and Stopping the

Engine

Starting the Engine

1. Stand on the platform.

2. Move the auxiliary hydraulics valve lever to

neutral.

3. Move the throttle lever midway between slow

(turtle) and fast (rabbit) positions.

4. Insert the key into the ignition and turn it to the

run position. Note: The battery, oil pressure, and glow

plug lights will come on.

5. When the glow plug light turns off, turn the key

to the start position. When the engine starts, release the key.

Operation

Note: A warm or hot engine may be started

without waiting for the light to turn off.

IMPORTANT: Do not engage the starter for more than 10 seconds at a time. If the engine fails to start, allow a 30 second cool-down period between attempts. Failure to follow these instructions can burn out the starter motor.

6. Move the throttle lever to the desired setting. IMPORTANT: If the engine is run at high

speeds when the hydraulic system is cold (i.e., when the ambient air temperature is around freezing or lower), hydraulic system damage could occur. When starting the engine in cold conditions, allow the engine to run in the middle throttle position for 2 to 5 minutes before moving the throttle to fast (rabbit).

Stopping the Engine

To drive the traction unit, complete the following actions as necessary:

• To move forward, move the traction control

levers forward.

• To move rearward, move the traction control

levers rearward.

• To go straight, move both traction control levers

equally.

• To turn, move the lever located on the side you

want to turn toward the neutral position while keeping the other lever engaged.

• To slow or stop, move the traction control levers

to neutral. Note: The farther you move the traction

control levers in either direction, the faster the traction unit will move in that direction.

1. Move the throttle lever to the slow (turtle) position.

2. Lower the loader arms to the ground.

3. Turn the ignition key to the stop position. Note: If the engine has been working hard or

is hot, let it idle for a minute before stopping it. This helps to cool the engine. In an emergency, the engine may be stopped immediately.

Driving

The throttle control regulates the engine speed as measured in rpm (revolutions per minute). Place the throttle lever in the fast (rabbit) position for best performance.

Note: You can use a slower throttle position

Forward or Backward

to operate the traction unit at slower speeds.

Stopping

To stop the traction unit, move the traction control levers to neutral and the throttle lever to slow (turtle), lower loader arms to the ground, and stop the engine. Remove the key.

POTENTIAL HAZARD

the T

raction Unit

• Someone could move or attempt to operate

the traction unit while it is unattended.

WHAT CAN HAPPEN

• Children or bystanders may be injured if

they use the traction unit.

HOW TO AV

•

Always r leaving the traction unit, even if just for a few seconds.

OID THE HAZARD

emove the ignition key when

Operation

Moving T

raction Unit

a Non-functioning

IMPORTANT: Never tow or pull the traction unit. Rotating the wheels manually will cause damage to the hydraulic wheel motors.

1. Stop the engine.

2. Lift the traction unit off the ground, using the

two lift points (Fig. 15), and move it onto a trailer.

m–4389

Figure 15

1. Lift

points

2. Raise the loader arms to the fully raised position.

3. Stop the engine.

4. Position a loader arm cylinder lock over each lift

cylinder rod (Fig. 16).

5. Secure each loader arm cylinder lock with a

clevis pin and cotter pin (Fig. 16).

1. Cylinder

Lift cylinder

Hairpin cotter

Figure 16

lock

Clevis pin

Lift cylinder rod

m–4398

6. Start the engine.

Using

POTENTIAL

the Cylinder Locks

HAZARD

• The loader arms may lower when in the

raised position.

WHAT CAN HAPPEN

• Anyone under the loader arms may be

injured or crushed.

HOW TO AV

OID THE HAZARD

• Always install the cylinder locks when

doing maintenance that requir loader arms.

es raised

Installing the Cylinder Locks

7. Slowly lower the loader arms until cylinder

locks contact the cylinder body and rod end.

8. Stop the engine.

Removing/Storing the Cylinder Locks

1. Start the engine.

2. Raise the loader arms to the fully raised position.

3. Stop the engine.

4. Remove the clevis pin and cotter pin securing

each cylinder lock.

5. Remove the cylinder locks.

6. Lower the loader arms.

7. Install the cylinder locks over the hydraulic

hoses and secure them with the clevis pins and cotter pins (Fig. 17).

1. Start the engine.

Operation

m–4601

1. Hydraulic

Cylinder locks

hoses

Installing

Figure 17

Hairpin cotter

Clevis pin

and Removing

Attachments

Connecting an Attachment

IMPORTANT: Use only Toro approved attachments. Attachments can change the stability and the operating characteristics of the traction unit. The warranty of the traction unit may be voided if used with unapproved attachments.

IMPORTANT: Before installing the attachment, ensure that the mount plates are free of any dirt or debris.

1. Position the attachment on a level surface with

enough space behind it to accommodate the traction unit.

2. Move the speed selector lever to the turtle position.

3. Start the engine.

4. Slowly push the attachment tilt lever forward to

tilt the attachment mount plate forward.

5. Position mount plate into the upper lip of the attachment receiver plate (Fig. 18).

plate

Figure 18

Receiver plate

1. Mount

m–4055

6. Raise the loader arms while tilting back the

mount plate at the same time.

IMPORTANT: The attachment should be raised enough to clear the ground, and the mount plate should be tilted all the way back.

7. Stop the engine.

8. Engage the quick attach pins (Fig. 19).

9. Ensure that the cam collars are seated on top of

the cast pin brackets (Fig. 19).

1. Quick

Cam collars

Figure 19

attach pins (shown in engaged position)

m–4056

Connecting the Hydraulic Hoses

If the attachment requires hydraulics for operation, connect the hydraulic hoses as follows:

1. Stop the engine.

2. Move the auxiliary hydraulics lever forward,

backward, and back to neutral to relieve pressure at the hydraulic couplers.

Operation

IMPORTANT: Ensure that all foreign matter is cleaned from the hydraulic connections before making connections.

3. Remove the protective covers from the hydraulic

couplers on the traction unit. Connect the covers together to prevent contamination during operation.

4. Slide the collars back on the hydraulic couplers

and connect the attachment couplers to the traction unit couplers.

POTENTIAL HAZARD

• Hydraulic fluid escaping under pressure

can penetrate skin and cause injury.

WHAT CAN HAPPEN

• Fluid accidentally injected into the skin

must be surgically removed within a few hours by a doctor familiar with this form of injury or gangrene may result.

HOW TO AV

OID THE HAZARD

• Keep body and hands away from pin hole

leaks or nozzles that eject high pressure hydraulic fluid.

• Use cardboard or paper to find hydraulic

leaks, never use your hands.

5. Confirm that the connection is secure by pulling

on the hoses.

5. If the attachment uses hydraulics, slide the collar

back on the hydraulic couplers and disconnect them.

IMPORTANT: Connect the attachment hoses together to prevent hydraulic system contamination during storage.

6. Install the protective covers onto the hydraulic

couplers on the traction unit.

7. Start the engine, tilt the mount plate forward,

and back the traction unit away from the attachment.

Securing

the T

raction Unit for

Transport

When transporting the traction unit on a trailer, always use the following procedure:

IMPORTANT: Do not operate or drive the traction unit on roadways.

1. Lower the loader arms.

2. Stop the engine.

3. Secure the traction unit to the trailer with chains

or straps using the operator platform support openings to secure the rear of the traction unit and the loader arms/mount plate to secure the front of the traction unit.

Removing an Attachment

1. Lower the attachment to the ground

2. Stop the engine.

3. Disengage the quick attach pins by turning them

to the outside.

4. If the attachment uses hydraulics, move the

auxiliary hydraulics lever forward, backward, and back to neutral to relieve pressure at the hydraulic couplers.

Maintenance

Service

Hydraulic Fluid—check level

Hydraulic Fluid—change Hydraulic Filter—change Engine Oil—check level

Engine Oil—change

Engine Oil Filter—change (150 hours or every other oil change)

Wheel Nuts—tighten Chassis—grease Primary Air Filter—clean

or replace Safety Air Filter—replace Engine RPM (idle & full

throttle)—check Fuel—drain Hydraulic lines—check Battery–-check electrolyte Battery—charge,

disconnect cables Fuel Filter—replace Fan and Water Pump

Belt—check Radiator Coolant

Level—check Radiator—flush & change

coolant T

ires—check pressure Fasteners—check/tighten X Chipped Surfaces—paint

present, 5 Replace moving lines every 2 years or 1500 operating hours, 5 Refer to your engine Operator’s Manual or contact you Authorized T

Interval Chart

Operation

often in dusty

, dirty conditions, 2 Immediately after

oro Dealer for service.

Each

Use8Hours25Hours

Initial X

Initial

Initial X

every washing, 3 Storage Service, 4 Immediately if water is

75 Hours

(Initial at

50)

100

Hours

150 hrs

X X

200

Hours

400

Hours

Yearly

600 hrs

Maintenance

POTENTIAL

HAZARD

• If you leave the key in the ignition switch, someone could start the engine.

WHAT CAN HAPPEN

• Accidental starting of the engine could seriously injure you or other bystanders.

HOW TO AV

OID THE HAZARD

• Remove the key from the ignition switch and and disconnect negative battery cable

from battery before you do any maintenance.

Opening

the Access Covers

Removing the Front Access Cover

1. Raise the loader arms and install the cylinder

locks; refer to Using the Cylinder Locks, page 22.

Note: In the case that you need to remove the

front access cover without raising the loader arms, be very careful not to damage the cover or hydraulic hoses as you maneuver the cover out from under the arms.

2. Stop the engine and remove the key.

Figure 20

1. Front access cover 2.

m–4595

Locking tabs

3. Release the four locking tabs (Fig. 20).

4. Pull the cover off of the traction unit (Fig. 20).

5. When finished, replace the front access cover

and secure it with the four locking tabs.

Opening the Rear Access Cover

1. Stop the engine and remove the key.

2. Release the two locking tabs on top of the rear

access cover (Fig. 21).

3. Grasping the handle, pull the cover up and back

to swing it open (Fig. 21).

Maintenance

5. Gently slide the primary filter out of the air

cleaner body (Fig. 22). Avoid knocking the filter into the side of the body. Do not remove the safety filter, unless you intend to replace it as well.

m-4597

Figure 21

1. Rear access cover 2.

Locking tabs

4. When finished, close the rear access cover by

swinging it up and seating it in place. Secure it with the two locking tabs.

Servicing

the Air Cleaner

Primary Filter: Clean or replace every 200 operating hours.

Safety Filter: Replace after every 600 operating hours.

Note: Service the air cleaner more frequently

if operating conditions are extremely dusty or sandy.

6. Inspect the primary filter for damage by looking

into the filter while shining a bright light on the outside of the filter. Holes in the filter will appear as bright spots. If the filter is damaged, discard it; otherwise, clean it.

IMPORTANT: Never attempt to clean the safety filter. If the safety filter is dirty, then the primary filter is damaged and you should replace both filters.

m–4387

1. Latches

2. Air

cleaner cover

Air filter body

Figure 22

Primary filter Safety filter

Removing the Filter

1. Lower the loader arms and stop the engine.

Remove the key.

2. Open the rear access cover; refer to Opening the

Rear Access Cover

3. Release the latches on the air cleaner and pull the

air cleaner cover off of the air cleaner body (Fig. 22).

4. Clean the inside of the air cleaner cover with

compressed air

, page 26.

Cleaning the Primary Filter

Blow compressed air from the inside to the outside of the primary filter.

IMPORTANT: Do not exceed 100 psi (689.5 kPa) and keep the hose at least 2 inches (5 cm) from the filter.

Installing the Filters

1. If installing new filters, check each filter for

shipping damage. Do not use a damaged filter.

Maintenance

2. If the safety filter is being replaced, carefully

slide it into the filter body (Fig. 22).

3. Carefully slide the primary filter over the safety

filter (Fig. 22). Ensure that it is fully seated by pushing on the outer rim of the filter while installing it.

IMPORTANT: Do not press on the soft inside area of the filter.

4. Install the air cleaner cover with the side

indicated as UP facing up and secure the latches (Fig. 22).

Close the rear access cover

Servicing

the Engine Oil

Change oil after the first 50 operating hours and then every 75 operating hours thereafter.

Note: Change oil more frequently when

operating conditions are extremely

dusty or sandy. Oil Type: MIL-L-2104C (API service CD or higher) Crankcase Capacity: w/filter, 0.84 gal. (3.2 l) Viscosity: See table below

USE THESE SAE VISCOSITY OILS

10W–30, 10W–40

Changing the Oil

1. Start the engine and let it run for five minutes.

This warms the oil so it drains better.

2. Park the traction unit so that the drain side is

slightly lower than the opposite side to ensure that the oil drains completely.

3. Lower the loader arms, chock the wheels, and

stop the engine. Remove the key.

POTENTIAL HAZARD

• Components will be hot if the traction unit

has been running.

WHAT CAN HAPPEN

• Touching hot components can cause burns.

HOW TO AV

OID THE HAZARD

• Allow the traction unit to cool before

performing maintenance or touching any components.

4. Place a pan under the oil drain tube (Fig. 23).

5. Loosen the clamp and remove the plug (Fig. 23).

6. When the oil has drained completely, replace the

plug and tighten the clamp. Note: Dispose of the used oil at a certified

recycling center.

5W–20, 5W–30

–20 0 20

–30°–20 –10

40 60

01020

80 100

30 40

m-4593

1. Clamp

2. Oil

drain tube

Figure 23

3. Plug

7. Open the rear access cover; refer to Opening the

Rear Access Cover

, page 26.

Maintenance

4. Allow a minute or two for the oil to be absorbed

by filter material, then pour off the excess oil.

5. Apply a thin coat of new oil to the rubber gasket

on the replacement filter (Fig. 24).

m–1256

8. Remove the oil fill cap and slowly pour

approximately 80% of the specified amount of oil in through the valve cover.

9. Check the oil level; refer to Checking the Oil

Level, page 13.

10. Slowly add additional oil to bring the level to the

F (full) mark on the dipstick.

11. Replace the fill cap.

12.

Close the rear access cover

Changing the Oil Filter

Replace the oil filter every 150 hours or every other oil change.

Note: Change the oil filter more frequently

when operating conditions are extremely hot, dusty, or sandy.

Figure 24

1. Oil

filter

2. Gasket

3. Adapter

6. Install the replacement oil filter to the filter

adapter. Turn the oil filter clockwise until the rubber gasket contacts the filter adapter, then tighten the filter an additional 1/2 turn (Fig. 24).

7. Fill the crankcase with the proper type of new

oil; refer to Changing the Oil, page 28.

Close the rear access cover

Greasing

the T

raction Unit

Grease all pivot joints every 8 operating hours and immediately after every washing.

Grease Type: General-purpose grease.

1. Drain the oil from the engine; refer to Changing

the Oil, page 28.

2. Open the rear access cover; refer to Opening the

Rear Access Cover

, page 26.

3. Remove the old filter and wipe the filter adapter

(Fig. 24) gasket surface.

1. Lower the loader arms and stop the engine.

Remove the key.

2. Clean the grease fittings with a rag.

3. Connect a grease gun to each fitting

(Fig 25 and 26).

Maintenance

Figure 25

m–4396

Never re-install a dirty filter.

1. Lower the loader arms and stop the engine.

Remove the key.

2. Shut off the fuel valve on the bottom of the fuel

tank (Fig. 29).

3. Open the rear access cover; refer to Opening the

Rear Access Cover

, page 26.

4. Open the drain valve (Fig. 27) and drain the fuel

from the fuel filter into a suitable container and dispose of it properly.

5. Remove the fuel filter with a filter wrench

(Fig. 27).

m–4056

Figure 26

4. Pump grease into the fittings until grease begins

to ooze out of the bearings (approximately 3 pumps).

5. Wipe up any excess grease.

Changing

the Fuel Filter

Change the fuel filter after every 200 operating hours or yearly, whichever occurs first.

Figure 27

1. Drain

valve

Fuel filter

6. Clean the mounting surface.

7. Lubricate the gasket on the new filter with clean

engine oil. Screw on the new filter by hand until the gasket contacts the housing. Then tighten it another 1/2 turn.

8. Open the fuel valve on the bottom of the fuel

tank (Fig. 29).

9. Bleed the fuel system; refer to Bleeding the Fuel

System, page 31.

10.

Close the rear access cover

11. Start the engine and check for leaks.

Maintenance

Bleeding

the Fuel System

Bleeding the air from the fuel system in any of the following situations:

• Initial start up of a new traction unit or a traction

unit that has been stored.

• After the engine has ceased running due to lack

of fuel.

• After maintenance has been performed on the

fuel system components.

1. Open the rear access cover; refer to Opening the

Rear Access Cover

, page 26.

2. Open the bleed screw on top of the fuel filter to

fill the bowl with fuel (Fig. 28).

Draining

POTENTIAL

the Fuel T

HAZARD

ank

• In certain conditions fuel is extremely

flammable and highly explosive.

WHAT CAN HAPPEN

• A fire or explosion from fuel can burn you,

others, and cause property damage.

HOW TO AV

OID THE HAZARD

• Drain fuel from the fuel tanks when the

engine is cold. Do this outdoors in an open area. Wipe up any fuel that spills.

• Never drain fuel near an open flame or

where fumes may be ignited by a spark.

• Never smoke while handling fuel.

1. Park the traction unit on a level surface, to

ensure that the fuel tanks drain completely.

2. Lower the loader arms and stop the engine.

Remove the key.

Figure 28

1. Fuel

filter

Bleed screw

3. Use the ignition to crank the engine until fuel

comes out of the bleed screw in a steady stream.

Close the bleed screw

5. On left side of the engine, locate the air vent

plug on top of the fuel injection pump and open it.

6. Use the ignition to crank the engine until fuel

comes out of the vent plug in a steady stream.

7. Close the vent plug.

Close the rear access cover

m–3708

3. Shut off the fuel valve on the bottom of the fuel

tank (Fig. 29).

m–4390

Figure 29

1. Fuel

valve

4. Open the rear access cover; refer to Opening the

Rear Access Cover

, page 26.

5. Loosen the hose clamp at the fuel filter and slide

it up the fuel line away from the filter.

6. Pull the fuel line off of the fuel filter, open the

fuel valves, and allow the fuel to drain into a fuel can or drain pan.

Maintenance

Note: Now is the best time to install a new

fuel filter because the fuel tank is

empty.

7. Install the fuel line onto the fuel filter.

8. Slide the hose clamp close to the fuel filter to

secure the fuel line.

Close the rear access cover

10. Open the fuel valve on the bottom of the fuel

tank.

Servicing

the Hydraulic

System

Replacing the Hydraulic Filter

Change the hydraulic filter:

• After the first 8 operating hours.

8. Install the replacement hydraulic filter onto the

filter adapter. Tighten it clockwise until the rubber gasket contacts the filter adapter, then tighten the filter an additional 1/2 turn (Fig. 30).

9. Clean up any spilled fluid.

10. Start the engine and let it run for about two

minutes to purge air from the system.

11. Stop the engine and check for leaks.

12. Check the fluid level in the hydraulic tank (refer

to Checking the Hydraulic Fluid, page 15) and add fluid to raise the level to the mark on the dipstick. Do not over fill the tank.

• After every 200 operating hours.

1. Position traction unit on a level surface.

2. Raise the loader arms and install the cylinder

locks; refer to Using the Cylinder Locks, page 22.

3. Stop the engine and remove the key.

4. Remove the front access cover, refer to

Removing the Front Access Cover, page 26.

IMPORTANT: Do not substitute an automotive oil filter or severe hydraulic system damage may result.

5. Place a drain pan under the filter.

6. Remove the old filter and wipe the filter adapter,

gasket surface clean.

7. Apply a thin coat hydraulic fluid to the rubber

gasket on the replacement filter (Fig. 30).

Figure 30

1. Hydraulic

2. Gasket

filter

3. Adapter

13. Install the front access cover.

14. Remove and store the cylinder locks (refer to

Using the Cylinder Locks, page 22) and lower the loader arms.

Changing the Hydraulic Fluid

Change the hydraulic fluid after every 400 operating hours.

1. Position traction unit on a level surface.

2. Raise the loader arms and install the cylinder

locks; refer to Using the Cylinder Locks, page 22.

3. Stop the engine and remove the key.

4. Remove the front access cover, refer to

Removing the front access cover, page 26.

Maintenance

IMPORTANT: Do not substitute automotive oil or severe hydraulic system damage may result.

5. Place a large drain pan under the traction unit

that can hold at least 17 gal. (67 l).

6. Remove the drain plug from the bottom of the

hydraulic tank and allow the fluid to completely drain out.

7. Install the drain plug.

8. Fill the hydraulic tank with Toro Hy-Pro, Mobil

Fluid 424, or equivalent; refer to Checking the Hydraulic Fluid, page 15.

Note: Dispose of used oil at a certified

recycling center.

9. Install the front access cover

10. Remove and store the cylinder locks (refer to

Using the Cylinder Locks, page 22) and lower the loader arms.

Checking Hydraulic Lines

After every 100 operating hours, check the hydraulic lines and hoses for leaks, loose fittings, kinked lines, loose mounting supports, wear, weather, and chemical deterioration. Replace all moving hydraulic hoses every 1500 hours or 2 years, which ever comes first. Make necessary repairs before operating.

POTENTIAL HAZARD

• Hydraulic fluid escaping under pressure

can penetrate skin and cause injury.

WHAT CAN HAPPEN

• Fluid accidentally injected into the skin

must be surgically removed within a few hours by a doctor familiar with this form of injury or gangrene may result.

HOW TO AV

OID THE HAZARD

• Keep body and hands away from pin hole

leaks or nozzles that eject high pressure hydraulic fluid.

• Use cardboard or paper to find hydraulic

leaks, never use your hands.

Servicing

Check the electrolyte level in the battery every 100 hours. Always keep the battery clean and fully charged. Use a paper towel to clean the battery case. If the battery terminals are corroded, clean them with a solution of four parts water and one part baking soda. Apply a light coating of grease to the battery terminals to reduce corrosion.

Voltage: 12 v, 435 Cold Cranking Amps

the Battery

Checking the Electrolyte Level

1. Remove the battery cover (Fig. 3).

2. Open covers to see into the cells. The electrolyte

must be up to the lower part of the tube (Fig. 31).

IMPORTANT: Do not allow the electrolyte to get below the plates. (Fig. 31).

Maintenance

1. Filler

caps

Lower part of tube

Figure 31

3. Plates

1262

3. If the electrolyte is low, add the required amount

of distilled water; refer to Adding Water to the Battery, below.

Adding Water to the Battery

The best time to add distilled water to the battery is just before you operate the traction unit. This lets the water mix thoroughly with the electrolyte solution.

1. Clean the top of the battery with a paper towel.

2. Remove the filler caps from the battery and

connect a 3 to 4 amp battery charger to the battery posts. Charge the battery at a rate of 4 amperes or less for 4 hours (12 volts). Do not overcharge the battery.

POTENTIAL HAZARD

• Charging the battery pr

oduces gasses.

WHAT CAN HAPPEN

• Battery gasses can explode.

HOW TO AV

OID THE HAZARD

• Keep cigarettes, sparks, and flames away

from the battery.

3. Install the filler caps after the battery is fully

charged.

4. Replace the battery cover.

2. Lift off the filler caps (Fig. 31).

3. Slowly pour distilled water into each battery cell

until the level is up to the lower part of the tube (Fig. 31).

IMPORTANT: Do not overfill the battery because electr sever

e corr

olyte (sulfuric acid) can cause

osion and damage to the chassis.

4. Press the filler caps onto the battery.

Charging the Battery

IMPORTANT: Always keep the battery fully charged (1.260 specific gravity). This is especially important to prevent battery damage when the temperature is below 32°F (0°C).

1. Check the electrolyte level; refer to Checking

Electrolyte Level, page 33.

Cleaning

and Storage

1. Lower the loader arms and stop the engine.

Remove the key.

2. Remove dirt and grime from the external parts of

the entire traction unit, especially the engine. Clean dirt and chaff from the outside of the engine.

IMPORTANT: You can wash the traction unit with mild detergent and water. Do not pressure wash the traction unit. Avoid excessive use of water

, especially near the control panel, engine, hydraulic pumps, and motors.

3. Service the air cleaner; refer to Servicing the Air

Cleaner, page 27.

4. Grease the traction unit; refer to Greasing the

Traction Unit, page 29.

5. Change the crankcase oil; refer to Servicing the

Engine Oil, page 28.

6. Check the tire pressure; refer to Tire Pressure,

page 15.

7. Charge the battery; refer to Servicing the Battery,

page 33.

8. Flush the fuel tank with fresh, clean diesel fuel

9. Check and tighten all bolts, nuts, and screws.

Repair or replace any part that is damaged.

10. Paint all scratched or bare metal surfaces. Paint

is available from your Authorized Service Dealer.

11. Check anti–freeze protection and fill the radiator

with a 50/50 solution of water and permanent ethylene glycol anti–freeze.

12. Store the traction unit in a clean, dry garage or

storage area. Remove the key from the ignition switch and keep it in a memorable place.

Maintenance

13. Cover the traction unit to protect it and keep it

clean.

Troubleshooting

PROBLEM

The starter does not crank.

The engine cranks, but will not start.

POSSIBLE CAUSES

The electrical connections are corroded or loose.

A fuse is blown or loose.

The relay or switch is damaged.

The battery is discharged.

A damaged starter or starter solenoid.

Seized internal engine components.

Incorrect starting procedure.

The fuel tank is empty

The fuel shut-of closed.

Dirt, water, stale fuel, or incorrect fuel is in the fuel system.

f valve is

. 2.

CORRECTIVE ACTION

Check the electrical connections for good contact.

Correct or replace the fuse.

Contact your Authorized Service Dealer

Charge the battery or replace it.

Contact your Authorized Service Dealer

Refer to Starting and Stopping the Engine, page

20. Fill with fresh fuel.

Open the fuel shut-of

Drain and flush the fuel system; add fresh fuel.

f valve.

Clogged fuel line.

There is air in the fuel

Inoperative glow plugs.

Clean or replace.

Bleed the nozzles and check for air leaks at the fuel hose connections and fittings between the fuel tank and engine.

Check the fuse, glow plugs and wiring.

Troubleshooting

PROBLEM

The engine cranks, but will not start (continued).

POSSIBLE CAUSES

Slow cranking speed.

The air cleaner element is dirty.

10.

Low compression.

11.

The injection nozzles are damaged.

12.

The fuel filter is clogged.

13.

The injections pump timing is incorrect.

14.

The injection pump is broken.

15.

Improper fuel grade for cold weather use.

CORRECTIVE ACTION

Check the battery viscosity and starting motor (contact your Authorized Service Dealer).

Clean or replace.

10.

Contact your Authorized Service Dealer

11.

Contact your Authorized Service Dealer

12.

Replace the fuel filter

13.

Contact your Authorized Service Dealer

14.

Contact your Authorized Service Dealer

15.

Drain the fuel system and replace the fuel filter fresh fuel of proper grade for ambient temperature conditions. Y warm the entire traction unit.

ou may need to

, oil

. Add

The engine starts, but does not keep running.

16.

The ETR solenoid is broken.

The fuel tank vent is restricted.

Dirt or water is in the fuel system.

The fuel filter is clogged.

The fuel pump is damaged.

There is air in the fuel.

Improper fuel grade for cold weather use.

16.

Contact your Authorized Service Dealer

Loosen the cap. If the engine runs with the cap loosened, replace the cap.

Drain and flush the fuel system; add fresh fuel.

Replace the fuel filter

Contact your Authorized Service Dealer

Bleed the nozzles and check for air leaks at fuel hose connections and fittings between the fuel tank and engine.

Drain the fuel system and replace the fuel filter fresh fuel of proper grade for ambient temperature conditions.

. Add

Troubleshooting

PROBLEM

The engine runs, but knocks or misses.

POSSIBLE CAUSES

Dirt, water, stale fuel, or incorrect fuel is in the fuel system.

Engine overheating.

There is air in the fuel.

The injection nozzles are damaged.

Low compression

The injection pump timing is incorrect.

Excessive carbon build–up.

Internal wear or damage.

CORRECTIVE ACTION

Drain and flush the fuel system; add fresh fuel.

See ENGINE OVERHEA

Bleed nozzles and check for air leaks at the fuel hose connections and fittings between the fuel tank and engine.

Contact your Authorized Service Dealer

TS.

The engine will not idle.

The fuel tank vent is restricted.

Dirt, water, stale fuel, or incorrect fuel is in the fuel system.

The fuel pump is damaged.

Low compression.

The air cleaner element is dirty.

The fuel filter is clogged.

There is air in the fuel.

Loosen the cap. If the engine runs with the cap loosened, replace the cap.

Drain and flush the fuel system; add fresh fuel.

Contact your Authorized Service Dealer

Clean or replace.

Replace the fuel filter

Bleed the nozzles and check for air leaks at the fuel hose connections and fittings between the fuel tank and engine.

Troubleshooting

PROBLEM

The engine overheats.

The engine loses power

POSSIBLE CAUSES

More coolant is needed.

Restricted air flow to the radiator.

The crankcase oil level is incorrect.

Excessive loading.

The thermostat is damaged.

The fan belt is loose or broken.

Incorrect fuel is in the fuel system.

Injection timing is incorrect.

Coolant pump is damaged.

The crankcase oil level is incorrect.

CORRECTIVE ACTION

Check and add coolant.

Inspect and clean the radiator screen with every use.

Fill or drain to the full mark.

Reduce load; use lower ground speed.

Contact your Authorized Service Dealer

Drain and flush the fuel system; add fresh fuel.

Contact your Authorized Service Dealer

Fill or drain to the full mark.

The air cleaner element is dirty.

Dirt, water, stale fuel, or incorrect fuel is in the fuel system.

The engine is overheated.

Low compression.

The fuel tank vent is restricted.

The engine load is excessive.

There is air in the fuel.

The injection pump timing is incorrect.

10.

The injection pump is damaged.

Clean or replace.

Drain and flush the fuel system; add fresh fuel.

See ENGINE OVERHEA

Contact your Authorized Service Dealer

Reduce ground speed.

Bleed the nozzles and check for air leaks at the fuel hose connections and fittings between the fuel tank and engine.

Contact your Authorized Service Dealer

10.

Contact your Authorized Service Dealer

TS.

Troubleshooting

e aust

PROBLEM

Excessive black smoke from exhaust.

Excessive white smoke from exhaust.

POSSIBLE CAUSES

The air cleaner element is dirty.

The injection pump timing is incorrect.

Incorrect fuel is in the fuel system.

The injection nozzles are damaged.

The injection pump is damaged.

Excessive loading.

The key was turned to the start position before the glow plug light turned of

The engine temperature is

2. low.

The glow plugs are inoperative.

CORRECTIVE ACTION

Clean or replace.

Contact your Authorized Service Dealer

Drain the fuel system and refill with specified fuel.

Contact your Authorized Service Dealer

Reduce load; use lower ground speed.

1. T

urn the key to the run

position and allow the glow

plug light to turn of starting the engine.

Check the thermostat.

Check the fuse, glow plugs and wiring.

f before

raction unit does not drive.

The fuel injection nozzles are damaged.

The injection pump timing is incorrect.

Low compression.

1. T

raction pump drive coupler

is loose or broken.

Hydro fluid level low

Pump and/or wheel motor is damaged.

Control valve is damaged.

Relief valve is damaged.

Flow divider valve lever is in 9 o’clock position.

Contact your Authorized Service Dealer

Contact Authorized Service Dealer.

Add hydro fluid to reservoir

Contact your Authorized Service Dealer

Move lever to 12 o’clock to 10 o’clock position.

Troubleshooting

  T   

   

The Toro Company warrants your Toro SiteWorkT Systems Product (“Product”) to be free from defects in materials repair on

or workmanship for the period of time listed below

the Product at no cost to you including diagnosis, labor

. Where a warrantable condition exists, T

, parts, and transportation. This warranty begins

the date the Product is delivered to the original retail purchaser

oro will

Warranty

Owner

Responsibilities:

As the Product owner, you are responsible for required maintenance and adjustments stated in your Owner’s Manual. Failure to perform required maintenance and adjustments can be grounds for disallowing a warranty claim.

Instructions for Obtaining W

You

are responsible for notifying the T Distributor from whom you purchased the Product as soon as you believe

If you need help locating a Toro SiteWorkT Systems Distributor or Authorized Dealer, or if you have questions regarding contact us at:

Maintenance

Parts (“Maintenance up

or Authorized T

a warrantable condition exists.

your warranty rights or

oro LCE Division

T 811

1 L

yndale A

Minneapolis, MN, 55420–1

elephone: (612) 888–8801

T Facsimile: (612) 887–8258

Parts:

scheduled for replacement as required

Parts”), are warranted

to the scheduled replacement time for that part.

Duration: One year or 500 operational hours, whichever occurs first.

arranty Service:

oro SiteW

venue South

oro SiteW

orkT

responsibilities, you may

196

for the period of time

ork Systems

Systems

maintenance

Dealer

Items/Conditions Not Covered:

Not

all product failures or malfunctions that occur during the warranty period are defects in materials or workmanship. The

items

/ conditions listed below are not covered by this

warranty:

D Product failures which result from the use of non–Toro

replacement parts, or from installation and use of add–on, modified, or unapproved accessories are not covered.

D Product failures which result from failure to perform

required maintenance and/or adjustments are not covered.

D Product

failures which in an abusive, negligent or reckless manner are not covered.

result from operating the Product

D This warranty does not apply to parts subject to

consumption Examples of parts which are consumed, or used up, during normal Product operation include, but are not limited chains, etc.

through use unless found to be defective.

to, digging teeth, tines, spark

plugs, tires, filters,

D This warranty does not apply to failures caused by

outside influence. Items considered to be outside influence practices, contamination, use of unapproved coolants, lubricants,

D This

items. to, etc.

Other

The

above remedy of product defects through repair by an authorized distributor or dealer is the purchaser’s sole remedy rights, state to state.

Except applicable, there is no other express warranty. All implied warranties of merchantability and fitness for

are limited to the duration of the express warranty

use

Some warranty

The Toro Company is not liable for indirect, incidental consequential damages in connection with the use the

Product, including any cost or expense of substitute Product or service during periods of malfunction or non–use.

Some states do not allow the exclusion of incidental or consequential damages, so the above exclusion may not apply to you.

include,

warranty does not apply to normal “wear and tear”

Normal “W

worn painted surfaces, scratched decals or windows,

but are not limited to, weather

additives, or chemicals, etc.

ear and T

ear” includes, but is not limited

, storage

Legal Disclaimers:

for any defect. This

and you may also have other rights which vary from

for the Emissions warranty referenced below

states do not allow limitations on how long an implied

lasts, so the above limitation may not apply to

warranty gives you specific legal

, if

you.

providing

Note to California residents: The Emissions Control

System on your Product may be covered by a separate warranty meeting requirements established by the U.S. Environmental Protection Agency (EPA), or the California Air

Resources Board (CARB). The hour limitations set forth above do not apply to the Emissions Control System Warranty. Statement the

Refer to

engine manufacturer’s documentation for details.

the California Emission Control W

printed in your Owner’s Manual

arranty

or contained in

Rev 1/25/1999

Toro 22303 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
