Toro 20837 Operator's Manual

FormNo.3419-122RevB

48cmSuperRecycler®LawnMower

20837

48cmSuperRecycler®Rasenmäher

20837

TondeuseSuperRecycler®de48cm

20837

48cmSuperRecycler®gazonmaaier

20837

www.T oro.com.

*3419-122*B

48cmSuperRecycler

ModelNo.20837—SerialNo.401500000andUp

Introduction

Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeowners.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawns
onresidentialproperties.Itisnotdesignedforcutting
brushorforagriculturaluses.

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.

YoumaycontactT orodirectlyatwww.T oro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.

Important:Withyourmobiledevice,youcan

scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.

FormNo.3419-113RevC

®

LawnMower

Operator'sManual

Figure2

Safety-alertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.

GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto
theenginemanufacturer’sinformationincludedwith
themachine.

Donottamperwithordisablesafetydevicesonthe
machine,andchecktheirproperoperationregularly.
Donotattempttoadjustortamperwiththeengine
speedcontrol;doingsomaycreateanunsafe
operatingcondition,resultinginpersonalinjury.

g000502

Figure1

1.Modelandserialnumberlocation

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.

©2019—TheT oro®Company
8111L yndaleAvenueSouth
Bloomington,MN55420

Registeratwww.Toro.com.

Contents

g226629

Introduction...............................................................1

Safety.......................................................................2

GeneralSafety...................................................2

SafetyandInstructionalDecals..........................3

Setup........................................................................4

1UnfoldingtheHandle.......................................4

2InstallingtheRecoil-StarterRopeinthe

RopeGuide.....................................................4

3FillingtheEnginewithOil.................................4

4AssemblingtheGrassBag...............................5

ProductOverview.....................................................6

Specications....................................................6

Operation..................................................................7

BeforeOperation...................................................7

BeforeOperationSafety.....................................7

FillingtheFuelTank............................................7

OriginalInstructions(EN)

PrintedinMexico

AllRightsReserved

*3419-113*C

CheckingtheEngine-OilLevel............................8

AdjustingtheHandleHeight...............................8

AdjustingtheCuttingHeight...............................9

DuringOperation...................................................9

DuringOperationSafety.....................................9

StartingtheEngine...........................................10

UsingtheSelf-PropelDrive...............................10

ShuttingOfftheEngine......................................11

RecyclingtheClippings.....................................11

BaggingtheClippings........................................11

Rear-DischargingtheClippings........................12

OperatingTips.................................................12

AfterOperation....................................................13

AfterOperationSafety......................................13

CleaningundertheMachine.............................13

FoldingtheHandle...........................................14

Maintenance...........................................................15

RecommendedMaintenanceSchedule(s)...........15

MaintenanceSafety..........................................15

PreparingforMaintenance...............................15

ServicingtheAirFilter.......................................16

ChangingtheEngineOil...................................16

ServicingtheSparkPlug...................................17

ReplacingtheBlade..........................................18

Storage...................................................................19

PreparingtheMachineforStorage...................19

RemovingtheMachinefromStorage................19

Safety

Thismachinehasbeendesignedinaccordancewith
ENISO5395:2013.

GeneralSafety

Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury .

Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.

•Read,understand,andfollowtheinstructions

andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.

•Donotputyourhandsorfeetnearmovingpartsof

orunderthemachine.Keepclearofanydischarge
opening.

•Donotoperatethemachinewithoutallguards

andothersafetyprotectivedevicesinplaceand
workingonthemachine.

•Keepbystandersandchildrenasafedistance

awayfromthemachine.Donotallowchildrento
operatethemachine.Allowonlypeoplewhoare
responsible,trained,familiarwiththeinstructions,
andphysicallycapabletooperatethemachine.

•Stopthemachine,shutofftheengine,andwaitfor

allmovingpartstostopbeforeservicing,fueling,
oruncloggingthemachine.

Improperlyusingormaintainingthismachinecan
resultininjury.T oreducethepotentialforinjury ,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.

Youcanndadditionalsafetyinformationwhere
neededthroughoutthismanual.

2

SafetyandInstructionalDecals

Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.

Manufacturer'sMark

decaloemmarkt

1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer .

112-8760

1.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine.

2.Cutting/dismembermentofhandorfoot—stayawayfrom
movingparts.

decal131-4514b

131-4514

1.Warning—readtheOperator'sManual.

2.Cutting/dismembermenthazardofhand,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.

3.Cutting/dismembermenthazardofhand,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.

4.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine;shutofftheenginebeforeleaving
theoperatingposition;pickupanydebrisbeforemowing.

5.Cutting/dismembermenthazardoffoot,mowerblade—do
notoperateupanddownslopes;operatesidetosideon
slopes;lookbehindyouwhenbackingup.

decal112-8760

1.Heightofcut

decal119-2283

119-2283

decal137-9196

137-9196

1.Lock2.Unlock

3

Setup

Important:Removeanddiscardtheprotective

plasticsheetthatcoverstheengineandanyother
plasticorwrappingonthemachine.

g020722

Figure4

1

UnfoldingtheHandle

NoPartsRequired

Procedure

WARNING

Foldingorunfoldingthehandleimproperly
candamagethecables,causinganunsafe
operatingcondition.

•Donotdamagethecableswhenfoldingor
unfoldingthehandle.

•Ifacableisdamaged,contactan
AuthorizedServiceDealer.

1.Loosenthehandleknobs(Figure3).

3.Tightenthehandleknobsrmlybyhand.

4.Rotatethehandlerearwardtotheoperating
position,andlockthehandleatyourdesired
height.RefertoAdjustingtheHandleHeight

(page8).

2

InstallingtheRecoil-Starter
RopeintheRopeGuide

NoPartsRequired

Procedure

Important:Tostarttheenginesafelyandeasily

wheneveryouusethemachine,installthe
recoil-starterropeintheropeguide.

Figure3

1.Handleknobs

2.Carefullymovetheupperhandleforwarduntil
thehandlehalvesareinlineandnesttogether
asshowninFigure4.

Holdtheblade-controlbartotheupperhandleand
pulltherecoil-starterropethroughtheropeguideon
thehandle(Figure5).

g020721

g003251

Figure5

1.Recoil-starterrope2.Ropeguide

4

3

FillingtheEnginewithOil

7.Readtheoillevelonthedipstick(Figure6).

•Iftheoillevelonthedipstickistoolow,

carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps

5through7untiltheoilonthedipstickisat

thecorrectlevel.

NoPartsRequired

Procedure

Important:Yourmachinedoesnotcomewithoil

intheengine.Beforestartingtheengine,llthe
enginewithoil.

EngineOilSpecications

Engineoilcapacity

OilviscositySAE30orSAE10W-30

APIserviceclassicationSJorhigher

1.Movethemachinetoalevelsurface.

2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure6).

0.55L(18.6oz)

detergentoil

•Iftheoillevelonthedipstickistoohigh,drain

theexcessoiluntiltheoilonthedipstickis
atthecorrectlevel;refertoChangingthe

EngineOil(page16).

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

8.Installthedipstickintotheoil-lltubesecurely.

4

AssemblingtheGrassBag

NoPartsRequired

Procedure

1.Slipthegrassbagovertheframeasshownin

Figure7.

Figure6

1.Full3.Low

2.High

3.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.

4.Wait3minutesfortheoiltosettleintheengine.

5.Wipethedipstickcleanwithacleancloth.

6.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.

g238622

g027257

Figure7

1.Handle

2.Frame

Note:Donotslipthebagoverthehandle

(Figure7).

2.Hookthebottomchannelofthebagontothe
bottomoftheframe(Figure8).

5

3.Grassbag

ProductOverview

Figure8

3.Hookthetopandsidechannelsofthebagonto
thetopandsidesoftheframe,respectively
(Figure8).

g014379

Figure9

g027258

1.Bag-on-demandlever7.Blade-controlbar

2.Cutting-heightlever(2)

3.Oil-lltube/dipstick9.Rear-deectordoor

4.Grassbag

5.Recoil-starthandle

6.Upperhandle

8.Traction-assisthandle

10.Fuel-tankcap

11.Airlter

12.Sparkplug

Specications

ModelWeightLengthWidthHeight

2083738kg

(84lb)

152cm

(60

inches)

53cm

(21

inches)

109cm

(43

inches)

6

Operation

–Storefuelinanapprovedcontainerandkeep

itoutofthereachofchildren.

Note:Determinetheleftandrightsidesofthe

machinefromthenormaloperatingposition.

BeforeOperation

BeforeOperationSafety

GeneralSafety

•Becomefamiliarwiththesafeoperationofthe

equipment,operatorcontrols,andsafetysigns.

•Checkthatallguardsandsafetydevices,suchas

deectorsand/orgrasscatcher,areinplaceand
workingproperly.

•Alwaysinspectthemachinetoensurethatthe

blades,bladebolts,andcuttingassemblyarenot
wornordamaged.

•Inspecttheareawhereyouwillusethemachine,

andremoveallobjectsthatcouldinterferewith
theoperationofthemachineorthatthemachine
couldthrow.

•Adjustingthecuttingheightmaybringyouinto

contactwiththemovingblade,causingserious
injury.

–Shutofftheengine,removetheignitionkey

(electric-startmodelonly),andwaitforall
movingpartstostop.

–Donotputyourngersunderthehousing

whenadjustingthecuttingheight.

FuelSafety

•Fuelisharmfulorfatalifswallowed.Long-term

exposuretovaporscancauseseriousinjuryand
illness.

–Avoidprolongedbreathingofvapors.

–Keepyourhandsandfaceawayfromthe

nozzleandthefuel-tankopening.

–Keepfuelawayfromyoureyesandskin.

FillingtheFuelTank

•Forbestresults,useonlyclean,fresh,unleaded

gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).

•Oxygenatedfuelwithupto10%ethanolor15%

MTBEbyvolumeisacceptable.

•Donotuseethanolblendsofgasoline,such

asE15orE85,withmorethan10%ethanolby
volume.Performanceproblemsand/orengine
damagemayresult,whichmaynotbecovered
underwarranty.

•Donotusegasolinecontainingmethanol.

•Donotstorefueleitherinthefueltankorinfuel

containersoverthewinterunlessfuelstabilizer
hasbeenaddedtothefuel.

•Donotaddoiltogasoline.

Fillthefueltankwithfreshunleadedregulargasoline
fromamajorname-brandservicestation(Figure10).

Important:Toreducestartingproblems,add

fuelstabilizertothegasolineallseason.Mixthe
stabilizerwithgasolinelessthan30daysold.

•Fuelisextremelyammableandhighlyexplosive.

Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.

–Topreventastaticchargefromignitingthefuel,

placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.

–Fillthefueltankoutdoors,inanopenarea,

whentheengineiscold.Wipeupanyfuelthat
spills.

–Donothandlefuelwhensmokingoraroundan

openameorsparks.

–Donotremovethefuelcaporaddfueltothe

tankwhiletheengineisrunningorhot.

–Ifyouspillfuel,donotattempttostartthe

engine.Avoidcreatingasourceofignitionuntil
thefuelvaporshavedissipated.

g230458

Figure10

7

CheckingtheEngine-Oil

AdjustingtheHandle

Level

ServiceInterval:Beforeeachuseordaily

1.Movethemachinetoalevelsurface.

2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure11).

Height

Youmayraiseorlowerthehandletoaposition
comfortableforyou.

Rotatethehandlelock,movethehandleto1of3
positions,andlockthehandleintoposition(Figure

12).

Figure11

1.Full3.Low

2.High

3.Wipethedipstickcleanwithacleancloth.

4.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.

5.Readtheoillevelonthedipstick(Figure11).

•Iftheoillevelonthedipstickistoolow

(Figure11),carefullypourasmallamount
ofSAE30orSAE10W-30detergentoilinto
theoil-lltube,wait3minutes,andrepeat
steps3through5untiltheoilonthedipstick
isatthecorrectlevel.

•Iftheoillevelonthedipstickistoohigh

(Figure11),draintheexcessoiluntiltheoil
onthedipstickisatthecorrectlevel;referto

ChangingtheEngineOil(page16).

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

g238622

g007284

Figure12

1.Handlelock2.Handlepositions

6.Installthedipstickintotheoil-lltubesecurely.

8

AdjustingtheCutting
Height

Adjustthecuttingheightasdesired.Setallthe
cutting-heightleverstothesameheight.Toraiseand
lowerthemachine,refertoFigure13.

Figure13

1.Cutting-heightlever

Important:Thecuttingheightsettingsare25mm

(1inch);38mm(1-1/2inch);51mm(2inches);64
mm(2-1/2inches);83mm(3-1/4inches);95mm
(3-3/4inches);108mm(4-1/4inches).

DuringOperation

DuringOperationSafety

GeneralSafety

•Wearappropriateclothing,includingeye

protection;longpants;slip-resistant,substantial
footwear;andhearingprotection.Tiebacklong
hair,securelooseclothing,anddonotwearloose
jewelry.

•Donotoperatethemachinewhileill,tired,or

undertheinuenceofalcoholordrugs.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury.Shutofftheengine,
removetheignitionkey(electric-startmodelonly),

g012130

andwaitforallmovingpartstostopbeforeleaving
theoperatingposition.

•Whenyoureleasetheblade-controlbar,the

engineshouldshutoffandthebladeshouldstop
within3seconds.Ifnot,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.

•Keepbystanders,especiallysmallchildren,outof

theoperatingarea.Stopthemachineifanyone
entersthearea.

•Alwayslookdownandbehindyoubeforemoving

themachineinreverse.

•Operatethemachineonlyingoodvisibilityand

appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflighting.

•Wetgrassorleavescancauseseriousinjuryif

youslipandcontacttheblade.Avoidmowingin
wetconditions.

•Useextremecarewhenapproachingblind

corners,shrubs,trees,orotherobjectsthatmay
blockyourview.

•Watchforholes,ruts,bumps,rocks,orother

hiddenobjects.Uneventerraincouldcausethe
machinetooverturnorcauseyoutoloseyour
balanceorfooting.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey
(ifequipped),waitforallmovingpartstostop,and
disconnectthewirefromthesparkplugbefore
examiningthemachinefordamage.Makeall
necessaryrepairsbeforeresumingoperation.

•Beforeleavingtheoperatingposition,shutoff

theengine,removetheignitionkey(electric-start
modelonly),andwaitforallmovingpartstostop.

•Iftheenginehasbeenrunningthemuferwillbe

hotandcanseverelyburnyou.Keepawayfrom
thehotmufer.

9

•Checkthegrasscatchercomponentsand

thedischargechutefrequentlyforanywear
ordeteriorationandreplacethemwiththe
manufacturer'srecommendedpartswhen
necessary.

•Useaccessoriesandattachmentsapprovedby

TheToro®Companyonly .

SlopeSafety

•Mowacrossthefaceofslopes;neverupand

down.Useextremecautionwhenchanging
directiononslopes.

•Donotmowonexcessivelysteepslopes.Poor

footingcouldcauseaslip-and-fallaccident.

•Mowwithcautionneardrop-offs,ditches,or

embankments.

StartingtheEngine

1.Holdtheblade-controlbaragainstthehandle
(AofFigure14).

2.Pulltherecoil-starthandlelightlyuntilyoufeel
resistance,thenpullitsharply,andallowitto
returntotheropeguideonthehandleslowly(B
ofFigure14).

g003221

Figure15

Note:Ifthemachinedoesnotfreelyrollbackward

afterself-propelling,stopwalking,holdyourhands
inplace,andallowthemachinetorollacoupleof
centimeters(inches)forwardtodisengagethewheel
drive.Youcanalsotryreachingjustundertheupper
handletothemetalhandleandpushingthemachine
forwardacoupleofcentimeters(inches).Ifthe
machinestilldoesnotrollbackwardeasily,contactan
AuthorizedServiceDealer.

Figure14

Note:Ifthemachinedoesnotstartafterseveral

attempts,contactanAuthorizedServiceDealer.

UsingtheSelf-PropelDrive

Tooperatetheself-propeldrive,simplywalkwithyour
handsontheupperhandleandyourelbowsatyour
sides,andthemachinewillautomaticallykeeppace
withyou(Figure15).

g233422

10

ShuttingOfftheEngine

BaggingtheClippings

ServiceInterval:Beforeeachuseordaily

Toshutofftheengine,releasetheblade-controlbar.

Important:Whenyoureleasetheblade-control

bar,theengineshouldshutoffandtheblade
shouldstopwithin3seconds.Iftheydonot,stop
usingyourmachineimmediatelyandcontactan
AuthorizedServiceDealer.

RecyclingtheClippings

Yourmachinecomesfromthefactoryreadytorecycle
thegrassandleafclippingsbackintothelawn.

Note:Thegrassbagmayremainonthemachine

whileyouarerecyclingtheclippings.

Torecycletheclippings,movethebag-on-demand
levertotheRECYCLINGposition(Figure16).

Usethegrassbagtocollectgrassandleafclippings
fromthelawn.

WARNING

Aworngrassbagcouldallowsmallstones
andothersimilardebristobethrowntoward
youorbystanders,resultinginserious
personalinjuryordeath.

Checkthegrassbagfrequently.Ifitis
damaged,installanewTororeplacementbag.

WARNING

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Shutofftheengineandwaitforallmoving
partstostopbeforeleavingtheoperating
position.

1.Shutofftheengineandwaitforallmovingparts
tostop.

Figure16

1.RECYCLINGposition2.BAGGINGposition

2.Installthegrassbag;refertoInstallingtheGrass

Bag(page11)andmovethebag-on-demand

levertotheBAGGINGpositionasshowninFigure

16.

InstallingtheGrassBag

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Raiseandholdupthereardeector,installthe
baginthenotches,andlowerthereardeector
(Figure17).

g012135

g014468

Figure17

11

RemovingtheGrassBag

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Liftupthegrassbagupandawayfromthe
handle.

Note:Tiltthegrassbagslightlybackwardto

preventthecollectedgrassclippingsfromfalling
out.

Rear-Dischargingthe
Clippings

Usethereardischargeforcuttingverytallgrass.

Note:Ifthegrassbagisonthemachine,remove

itbeforerear-dischargingtheclippings;refer
toRemovingtheGrassBag(page12).The
bag-on-demandlevershouldbeintheBAGGING
positionasshowninFigure16.

WARNING

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Shutofftheengineandwaitforallmoving
partstostopbeforeleavingtheoperating
position.

OperatingTips

GeneralMowingTips

•Inspecttheareawhereyouwillusethemachine

andremoveallobjectsthatthemachinecould
throw.

•Avoidstrikingsolidobjectswiththeblade.Never

deliberatelymowoveranyobject.

•Ifthemachinestrikesanobjectorstartstovibrate,

immediatelyshutofftheengine,removethekey
(ifequipped),disconnectthewirefromthespark
plug,andexaminethemachinefordamage.

•Forbestperformance,installanewbladebefore

thecuttingseasonbegins.

•ReplacethebladewhennecessarywithaT oro

replacementblade.

CuttingGrass

•Cutonlyaboutathirdofthegrassbladeatatime.

Donotcutbelow51mm(2inches)unlessthe
grassissparseoritislatefallwhengrassgrowth
beginstoslowdown.

•Whencuttinggrassover15cm(6inches)tall,

mowatthehighestcuttingheightsettingandwalk
slower;thenmowagainatalowersettingforthe
bestlawnappearance.Ifthegrassistoolong,the
machinemayplugandcausetheenginetostall.

•Wetgrassandleavestendtoclumpontheyard

andcancausethemachinetoplugortheengine
tostall.Avoidmowinginwetconditions.

•Beawareofapotentialrehazardinverydry

conditions,followalllocalrewarnings,andkeep
themachinefreeofdrygrassandleafdebris.

•Alternatethemowingdirection.Thishelps

dispersetheclippingsoverthelawnforeven
fertilization.

•Ifthenishedlawnappearanceisunsatisfactory,

try1ormoreofthefollowing:

–Replacethebladeorhaveitsharpened.

–Walkataslowerpacewhilemowing.

–Raisethecuttingheightonyourmachine.

–Cutthegrassmorefrequently.

–Overlapcuttingswathsinsteadofcuttingafull

swathwitheachpass.

CuttingLeaves

•Aftercuttingthelawn,ensurethathalfofthelawn

showsthroughthecutleafcover.Y oumayneed
tomakemorethanasinglepassovertheleaves.

12

•Iftherearemorethan13cm(5inches)ofleaves

onthelawn,mowatahighercuttingheightand
thenagainatthedesiredcuttingheight.

AfterOperation

•Slowdownyourmowingspeedifthemachine

doesnotcuttheleavesnelyenough.

AfterOperationSafety

GeneralSafety

•Cleangrassanddebrisfromthemachinetohelp

preventres.Cleanupoilorfuelspills.

•Allowtheenginetocoolbeforestoringthemachine

inanyenclosure.

•Neverstorethemachineorfuelcontainerwhere

thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.

HaulingSafety

•Removetheignitionkey(ifequipped)before

loadingthemachineforhauling.

•Usecarewhenloadingorunloadingthemachine.

•Securethemachinefromrolling.

CleaningundertheMachine

ServiceInterval:Beforeeachuseordaily

Forbestresults,cleanthemachinesoonafteryou
havecompletedmowing.

1.Lowerthemachinetothelowestcutting-height
setting.RefertoAdjustingtheCuttingHeight

(page9).

2.Movethemachineontoalevelsurface.

3.Attachagardenhosethatisconnectedtoa
watersupplytothewashoutport(Figure18).

Figure18

1.Washoutport

g014538

4.Turnthewateron.

5.Starttheengineandrunituntiltherearenomore
clippingsthatcomeoutfromunderthemachine.

6.Shutofftheengine.

13

7.Shutoffthewateranddisconnectthegarden
hosefromthemachine.

8.Starttheengineandrunitforafewminutesto
drytheundersideofthemachine.

9.Shutofftheengineandallowittocool.

FoldingtheHandle

WARNING

Foldingorunfoldingthehandleimproperly
candamagethecables,causinganunsafe
operatingcondition.

•Donotdamagethecableswhenfoldingor
unfoldingthehandle.

•Ifacableisdamaged,contactan
AuthorizedServiceDealer.

1.Loosenthehandleknobs.

2.Rotatetheentirehandleforward(Figure19).

Important:Routethecablestotheoutside

ofthehandleknobsasyoufoldtheupper
handle.

Figure19

3.Rotatetheupperportionofthehandleback
towardtheengine;refertoFigure20.

g020722

1.Handleknobs

g020721

Figure20

14

Maintenance

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Aftertherst5hours

Beforeeachuseordaily

Every100hours

Yearly

Yearlyorbeforestorage

MaintenanceProcedure

•Changetheengineoil.

•Checktheengine-oillevel.

•Ensurethattheengineshutsoffwithin3secondsafterreleasingtheblade-control
bar.

•Cleangrassclippingsanddirtfromunderthemachine.

•Servicethesparkplug.

•Servicetheairlter.

•Changetheengineoil.

•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).

•Cleantheenginebyremovingdirtanddebrisfromitstopandsides;cleanitmore
frequentlyindustyoperatingconditions.

•Emptythefueltankbeforerepairsasdirectedandbeforeyearlystorage.

Important:Refertoyourengineowner’smanualforadditionalmaintenanceprocedures.

MaintenanceSafety

•Disconnectthespark-plugwirefromthesparkplug

beforeperforminganymaintenanceprocedure.

•Wearglovesandeyeprotectionwhenservicing

themachine.

•Thebladeissharp;contactingthebladecanresult

inseriouspersonalinjury .Weargloveswhen
servicingtheblade.Donotrepairoralterthe
blade(s).

•Nevertamperwithsafetydevices.Checktheir

properoperationregularly .

•Tippingthemachinemaycausethefueltoleak.

Fuelisammableandexplosive,andcancause
personalinjury.Runtheenginedryorremovethe
fuelwithahandpump;neversiphonthefuel.

•Toensureoptimumperformanceandcontinued

safetycerticationofthemachine,useonly
genuineTororeplacementpartsandaccessories.
Replacementpartsandaccessoriesmadeby
othermanufacturerscouldbedangerous,and
suchusecouldvoidtheproductwarranty .

PreparingforMaintenance

1.Shutofftheengineandwaitforallmovingparts
tostop.

g238653

Figure21

1.Spark-plugwire

3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.

Important:Beforetippingthemachineto

changetheoilorreplacetheblade,allowthe
fueltanktorundrythroughnormalusage.If
youmusttipthemachinepriortorunning
outoffuel,useahandfuelpumptoremove
thefuel.Alwaystipthemachineontoits
side,withthedipstickdown.

2.Disconnectthespark-plugwirefromthespark
plug(Figure21).

15

ServicingtheAirFilter

ChangingtheEngineOil

ServiceInterval:Yearly

1.Pressdownonthelatchtabsontopofthe
air-ltercover(Figure22).

ServiceInterval:Aftertherst5hours

Yearly

Note:Runtheengineafewminutesbeforechanging

theoiltowarmit.Warmoilowsbetterandcarries
morecontaminants.

EngineOilSpecications

Engineoilcapacity

OilviscositySAE30orSAE10W-30

APIserviceclassicationSJorhigher

1.Movethemachinetoalevelsurface.

2.RefertoPreparingforMaintenance(page15).

3.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure23).

0.55L(18.6oz)

detergentoil

Figure22

1.Latchtabs

2.Paperairlter

3.Foampre-lter

2.Openthecover.

3.Removethepaperairlterandthefoam
pre-lter(Figure22).

4.Inspectthefoampre-lter,andreplaceitifitis
damagedorexcessivelydirty.

5.Inspectthepaperairlter.

•Iftheairlterisdamagedoriswetwithoil

orfuel,replaceit.

•Iftheairlterisdirty ,tapitonahardsurface

severaltimesorblowcompressedairless
than207kPa(30psi)throughthesideofthe
lterthatfacestheengine.

Note:Donotbrushthedirtoffthelter;

brushingforcesdirtintothebers.

6.Removethedirtfromtheair-lterbodyandthe
coverusingamoistrag.

g011722

g010272

Figure23

4.Tipthemachineontoitsside(sothattheair
lterisup)todraintheusedoilfromtheoil-ll
tube(Figure23).

Important:Donotwipedirtintotheairduct.

7.Installthefoampre-lterandthepaperairlter
intotheairlter.

8.Installthecover.

16

Figure24

1.Full3.Low

2.High

ServicingtheSparkPlug

ServiceInterval:Every100hours

UseaChampionRN9YCsparkplugorequivalent.

1.Shutofftheengineandwaitforallmovingparts
tostop.

2.Disconnectthewirefromthesparkplug(Figure

21).

3.Cleanaroundthesparkplug.

4.Removethesparkplugfromthecylinderhead.

Important:Replaceacracked,fouled,or

dirtysparkplug.Donotcleantheelectrodes
becausegritenteringthecylindercan
damagetheengine.

5.Setthegapontheplugto0.76mm(0.030inch)
asshowninFigure25.

g238622

5.Afterdrainingtheusedoil,returnthemachineto
theoperatingposition.

6.Carefullypourabout3/4oftheenginecapacity
ofoilintotheoil-lltube.

7.Wait3minutesfortheoiltosettleintheengine.

8.Wipethedipstickcleanwithacleancloth.

9.Insertthedipstickintotheoil-lltube,butdonot
screwitin,thenremovethedipstick.

10.Readtheoillevelonthedipstick(Checkingthe

Engine-OilLevel(page8)).

•Iftheoillevelonthedipstickistoolow,

carefullypourasmallamountofoilintothe
oil-lltube,wait3minutes,andrepeatsteps

8through10untiltheoillevelonthedipstick

iscorrect.

•Iftheoillevelonthedipstickistoohigh,

draintheexcessoiluntiltheoillevelonthe
dipstickiscorrect.

Important:Iftheoillevelintheengineistoo

lowortoohighandyouruntheengine,you
maydamagetheengine.

g000533

Figure25

1.Centerelectrodeinsulator3.Airgap(nottoscale)

2.Sideelectrode

6.Installthesparkplug.

7.T orquetheplugto20N∙m(15ft-lb).

8.Connectthewiretothesparkplug.

11.Installthedipstickintotheoil-lltubesecurely.

12.Recycletheusedoilproperly.

17

ReplacingtheBlade

ServiceInterval:Yearly

Important:Youwillneedatorquewrenchto

installthebladeproperly.Ifyoudonothavea

torquewrenchorareuncomfortableperforming
thisprocedure,contactanAuthorizedService
Dealer.

Examinethebladewheneveryourunoutoffuel.Ifthe
bladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpened
andbalanced,orreplaceit.

WARNING

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Weargloveswhenservicingtheblade.

1.RefertoPreparingforMaintenance(page15).

2.Tipthemachineontoitssidewiththeairlterup.

3.Useablockofwoodtoholdthebladesteady
(Figure26).

g231390

Figure27

Important:Positionthecurvedendsofthe

bladetopointtowardthemachinehousing.

Figure26

4.Removetheblade,savingallmountinghardware
(Figure26).

5.Installthenewbladeandallmountinghardware
(Figure27).

6.Useatorquewrenchtotightenthebladebolt

to82N∙m(60ft-lb).

Important:Abolttorquedto82N∙m(60

ft-lb)isverytight.Whileholdingtheblade
withablockofwood,putyourweight
behindtheratchetorwrenchandtightenthe
boltsecurely.Thisboltisverydifcultto
overtighten.

g231389

18

Storage

Storethemachineinacool,clean,dryplace.

PreparingtheMachinefor
Storage

1.Onthelastrefuelingoftheyear,addfuel
stabilizer(suchasToroPremiumFuel
Treatment)tothefuelasdirectedonthelabel.

2.Disposeofanyunusedfuelproperly.Recycle
itaccordingtolocalcodesoruseitinyour
automobile.

Note:Oldfuelinthefueltankistheleading

causeofhardstarting.Donotstorefuelwithout
fuelstabilizermorethan30days,anddonot
storestabilizedfuelmorethan90days.

3.Runthemachineuntiltheengineshutsofffrom
runningoutoffuel.

4.Starttheengineagainandallowittorununtil
itshutsoff.Whenyoucannolongerstartthe
engine,itissufcientlydry.

5.Disconnectthewirefromthesparkplugand
connectthewiretotheretainingpost(if
equipped).

6.Removethesparkplug,add30ml(1oz)of
engineoilthroughthespark-plughole,andpull
thestarterropeslowlyseveraltimestodistribute
oilthroughoutthecylindertopreventcylinder
corrosionduringtheoff-season.

7.Looselyinstallthesparkplug.

8.Tightenallnuts,bolts,andscrews.

RemovingtheMachine
fromStorage

1.Checkandtightenallfasteners.

2.Removethesparkplugandspintheengine
rapidlybypullingtherecoil-starthandletoblow
theexcessoilfromthecylinder.

3.Installthesparkplugandtightenitwithatorque
wrenchto20N∙m(15ft-lb).

4.Performanymaintenanceprocedures;referto

Maintenance(page15).

5.Checktheengine-oillevel;refertoCheckingthe

Engine-OilLevel(page8).

6.Fillthefueltankwithfreshfuel;refertoFilling

theFuelT ank(page7).

7.Connectthewiretothesparkplug.

19

EuropeanPrivacyNotice

TheInformationT oroCollects
ToroWarrantyCompany(Toro)respectsyourprivacy.Inordertoprocessyourwarrantyclaimandcontactyouintheeventofaproductrecall,weaskyou
tosharecertainpersonalinformationwithus,eitherdirectlyorthroughyourlocalT orocompanyordealer .

TheTorowarrantysystemishostedonserverslocatedwithintheUnitedStateswhereprivacylawmaynotprovidethesameprotectionasapplies
inyourcountry.

BYSHARINGYOURPERSONALINFORMA TIONWITHUS,YOUARECONSENTINGTOTHEPROCESSINGOFYOURPERSONALINFORMATION
ASDESCRIBEDINTHISPRIVACYNOTICE.

TheWayToroUsesInformation
Toromayuseyourpersonalinformationtoprocesswarrantyclaims,tocontactyouintheeventofaproductrecallandforanyotherpurposewhichwetell
youabout.ToromayshareyourinformationwithT oro'safliates,dealersorotherbusinesspartnersinconnectionwithanyoftheseactivities.Wewillnot
sellyourpersonalinformationtoanyothercompany .Wereservetherighttodisclosepersonalinformationinordertocomplywithapplicablelawsand
withrequestsbytheappropriateauthorities,tooperateoursystemsproperlyorforourownprotectionorthatofotherusers.

RetentionofyourPersonalInformation
Wewillkeepyourpersonalinformationaslongasweneeditforthepurposesforwhichitwasoriginallycollectedorforotherlegitimatepurposes
(suchasregulatorycompliance),orasrequiredbyapplicablelaw.

Toro'sCommitmenttoSecurityofY ourPersonalInformation
Wetakereasonableprecautionsinordertoprotectthesecurityofyourpersonalinformation.Wealsotakestepstomaintaintheaccuracyandcurrent
statusofpersonalinformation.

AccessandCorrectionofyourPersonalInformation
Ifyouwouldliketorevieworcorrectyourpersonalinformation,[e-mail].

AustralianConsumerLaw

AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oroDealer.

374-0282RevC

48cmSuperRecycler

Modellnr.20837—Seriennr.401500000undhöher

FormNo.3419-115RevC

®

Rasenmäher

Bedienungsanleitung

Einführung

DieserhandgeführteRasenmähermitSichelmessern
solltevonPrivatleutenodergeschultenLohnarbeitern
verwendetwerden.EristhauptsächlichfürdasMähen
vonGrasaufgepegtenGrünächeninPrivatanlagen
gedacht.EristnichtfürdasSchneidenvonBüschen
oderfüreinenlandwirtschaftlichenEinsatzgedacht.

LesenSiedieseInformationensorgfältigdurch,
umsichmitdemordnungsgemäßenEinsatzund
derWartungdesGerätsvertrautzumachenund
VerletzungenundeineBeschädigungdesGerätszu
vermeiden.SietragendieVerantwortungfüreinen
ordnungsgemäßenundsicherenEinsatzdesGeräts.

WendenSiesichhinsichtlichInformationenzu
ProduktenundZubehörsowieAngabenzuIhrem
örtlichenVertragshändleroderzurRegistrierungdes
ProduktesdirektanTorounterwww.T oro.com.

WendenSiesichandenToro-Vertragshändler
oderKundendienst,wennSieeineServiceleistung,
OriginalersatzteilevonT orooderweitere
Informationenbenötigen.HabenSiedafürdieModell­undSeriennummernderMaschinegriffbereit.InBild1
wirdderStandortderModell-undSeriennummernauf
demProduktangegeben.TragenSiehierdieModell­undSeriennummerndesGerätsein.

Wichtig:ScannenSiemitIhremMobilgerätden

QR-CodeaufdemSeriennummernaufkleber(falls
vorhanden),umaufGarantie-,Ersatzteil-oder
andereProduktinformationenzuzugreifen.

IndieserAnleitungwerdenpotenzielleGefahren
angeführt,undSicherheitsmeldungenwerdenvom
Sicherheitswarnsymbol(Bild2)gekennzeichnet,
dasaufeineGefahrhinweist,diezuschweren
odertödlichenVerletzungenführenkann,wenn
SiedieempfohlenenSicherheitsvorkehrungennicht
einhalten.

g000502


Sicherheitswarnsymbol

IndieserAnleitungwerdenzweiBegriffezur
HervorhebungvonInformationenverwendet.Wichtig
weistaufspeziellemechanischeInformationenhin,
undHinweishebtallgemeineInformationenhervor,
dieIhrebesondereBeachtungverdienen.

DiesesProdukterfülltallerelevanteneuropäischen
Richtlinien;weitereDetailsndenSieinder
produktspezischenKonformitätserklärung(DOC).

Brutto-oderNettodrehmoment:DasBrutto­oderNettodrehmomentdiesesMotorswurde
vomMotorherstellerimLaborgemäßSAEJ1940
oderJ2723ermittelt.AufgrundderKonguration
zurErfüllungvonSicherheits-,Emissions­undBetriebsanforderungenistdietatsächliche
MotorleistungindieserKlassederRasenmäher
wesentlichniedriger.WeitereInformationennden
SieinderMotorbedienungsanleitungdesHerstellers,
diemitderMaschineausgeliefertwurde.

1.TypenschildmitModell-undSeriennummer

Modellnr.

Seriennr.

©2019—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420


RegistrierenSieIhrProduktunter

www.T oro.com.

ManipulierenoderdeaktivierenSiekeine
SicherheitsvorrichtungenanderMaschineundprüfen
SiedieeinwandfreieFunktioninregelmäßigen

g226629

Abständen.ModizierenodermanipulierenSienicht
dieBedienelementefürdieMotordrehzahl,dadieszu
unsicherenEinsatzbedingungenundVerletzungen
führenkann.

Inhalt

Einführung................................................................1

Sicherheit..................................................................2

AllgemeineSicherheit.........................................2

Originaldokuments(DE)

AlleRechtevorbehalten

Druck:Mexiko

*3419-115*C

Sicherheits-undBedienungsschilder.................3

Einrichtung................................................................4

1AufklappendesHolms.....................................4

2BefestigendesRücklaufstarterseilsinder

Seilführung......................................................4

3AuffüllendesMotorsmitÖl..............................4

4MontierendesFangkorbs................................5

Produktübersicht.......................................................6

TechnischeDaten..............................................6

Betrieb......................................................................7

VordemEinsatz....................................................7

VordersicherenVerwendung.............................7

Betanken............................................................7

PrüfendesMotorölstands...................................8

EinstellenderHolmhöhe.....................................8

EinstellenderSchnitthöhe..................................9

WährenddesEinsatzes.........................................9

HinweisezurSicherheitwährenddes

Betriebs...........................................................9

AnlassendesMotors........................................10

VerwendendesSelbstantriebs.........................10

AbstellendesMotors.........................................11

Schnittgutrecyclen.............................................11

SammelndesSchnittguts..................................11

HeckauswurfdesSchnittguts...........................12

Betriebshinweise.............................................12

NachdemEinsatz...............................................13

HinweisezurSicherheitnachdem

Betrieb..........................................................13

ReinigenunterdemGerät.................................13

ZusammenklappendesHolms.........................14

Wartung..................................................................15

EmpfohlenerWartungsplan.................................15

Wartungssicherheit...........................................15

VorbereitenfürdieWartung..............................15

WartendesLuftlters........................................16

WechselndesMotoröls....................................16

WartenderZündkerze......................................17

AuswechselndesMessers...............................18

Einlagerung............................................................19

VorbereitenderMaschinefürdie

Einlagerung...................................................19

HerausnehmendesRasenmähersausder

Einlagerung...................................................19

Sicherheit

DieseMaschineerfülltENISO5395:2013.

AllgemeineSicherheit

DiesesProduktkannHändeundFüßeamputieren
undGegenständeaufschleudern.Befolgenimmer
sämtlicheSicherheitshinweise,umschwereoder
tödlicheVerletzungenzuvermeiden.

WenndiesesProduktfüreinenanderenZweck
eingesetztwird,kanndasfürBedienerundandere
Personengefährlichsein.

•Lesen,verstehenundbefolgenSievordem

AnlassendesMotorsalleAnweisungenund
WarnungeninderBedienungsanleitungundan
derMaschine.

•BerührenSiebeweglicheT eileoderdieUnterseite

derMaschinenichtmitdenHändenoderFüßen.
KommenSieAuswurföffnungennichtzunahe.

•SetzenSiedieMaschinenurein,wenn

alleSchutzvorrichtungenundandere
Sicherheitsvorrichtungenmontiertund
funktionsfähigsind.

•HaltenSieUnbeteiligteundKinderineinem

sicherenAbstandzurMaschine.DasFahrzeug
darfniemalsvonKindernbetriebenwerden.
NurverantwortungsbewusstePersonen,die
geschultundmitdenAnweisungenvertrautsind
undkörperlichfähigsind,solltendieMaschine
verwenden.

•HaltenSiedieMaschinean,stellenSieden

MotorabundwartenSie,bisallebeweglichen
TeilezumStillstandgekommensind,bevorSie
Wartungsarbeitendurchführen,Auftankenoder
Verstopfungenentfernen.

DerunsachgemäßeEinsatzoderdiefalscheWartung
dieserMaschinekannzuVerletzungenführen.
DurchdasBefolgendieserSicherheitshinweisekann
dasVerletzungsrisikoverringertwerden.Achten
SieimmeraufdasWarnsymbol.Esbedeutet
Vorsicht,WarnungoderGefahr–Hinweisefürdie
Personensicherheit.WennSiedieseAnweisungen
nichteinhalten,kanneszuVerletzungenggf.
tödlichenVerletzungenkommen.

SiendenweitereSicherheitsinformationenbei
BedarfindieserBedienungsanleitung.

2

Sicherheits-undBedienungsschilder

DieSicherheits-undBedienungsaufklebersindgutsichtbar;siebendensichinderNähe
dermöglichenGefahrenbereiche.T auschenSiebeschädigteoderverlorengegangene
Aufkleberaus.

decaloemmarkt

Herstellermarke

1.DieseMarkegibtan,dassdasMessereinT eildes
HerstellersderOriginalmaschineist.

112-8760

1.GefahrdurchherausgeschleuderteGegenstände:Achten
Siedarauf,dassUnbeteiligtedenSicherheitsabstandzur
Maschineeinhalten.

2.GefahreinerSchnittwundeund/oderderAmputationvon
HändenoderFüßen:BerührenSiekeinebeweglichen
Teilen.

decal112-8760

decal131-4514b

131-4514

1.Warnung:LesenSiedieBedienungsanleitung.

2.Schnitt-bzw.AmputationsgefahrfürHändeam
Mähwerkmesser:BerührenSiekeinebeweglichen
TeileundnehmenSiekeineSchutzblecheund
Schutzvorrichtungenab.

3.Schnitt-bzw.AmputationsgefahrandenHändenbeim
Schnittmesser:ZiehenSiedenZündkerzensteckerabund
lesenSiedieAnweisungen,bevorSieWartungs-oder
Reparaturarbeitenausführen.

4.GefahrdurchherausgeschleuderteGegenstände:
StellenSiesicher,dassUnbeteiligteimmereinen
SicherheitsabstandzurMaschineeinhalten;stellenSieden
Motorab,bevorSiedieBedienerpositionverlassenund
sammelnSieRückständevordemEinsatzderMaschine
auf.

5.Schnitt-bzw.AmputationsgefahrvonHändenam
Mähwerkmesser:MähenSieniehangaufwärtsoder

-abwärts,mähenSieimmerwaagrechtzumHang.Schauen
Sienachhinten,wennSierückwärtsfahren.

decal119-2283

119-2283

1.Schnitthöhe

decal137-9196

137-9196

1.Einrasten2.Ausrasten

3

Einrichtung

Wichtig:NehmenSiedenKunststoffschutz

abundalleanderenKunststoffteileoder
Verpackungenab,mitdenenderMotorabgedeckt
ist.WerfenSiesieab.

g020722


1

AufklappendesHolms

KeineTeilewerdenbenötigt

Verfahren

WARNUNG:

WennSiedenHolmfalschauf-oder
zusammenklappen,könnenSiedie
Bowdenzügebeschädigenunddensicheren
Geräteeinsatzgefährden.

•BeschädigenSiebeimAuf-oder
ZusammenklappendesHolmsnichtdie
Kabel.

•WendenSiesichbeieinembeschädigten
KabelaneinenofziellenVertragshändler.

1.LösenSiedieGriffhandräder(Bild3).

3.ZiehenSiedieGriffhandrädermitderHandfest.

4.DrehenSiedenBügelnachhintenindie
BetriebsstellungundarretierenSieihninder
gewünschtenHöhe.SieheEinstellender

Holmhöhe(Seite8).

2

Befestigendes
Rücklaufstarterseilsin
derSeilführung

KeineTeilewerdenbenötigt

Verfahren

Wichtig:BefestigenSiedasRücklaufstarterseil

inderSeilführung,umdenMotorsicherund
mühelosanzulassen.


1.Griffhandräder

2.SchiebenSiedenoberenGriffvorsichtignach
vorne,bisdieGriffhälftenausgerichtetsindund
enganliegen,sieheBild4.

DrückenSiedenSchaltbügelzumoberenHolm
undziehenSiedasRücklaufstarterseildurchdie
SeilführungamHolm(Bild5).

g020721

g003251


1.Rücklaufstarterseil2.Seilführung

4

3

AuffüllendesMotorsmitÖl

KeineTeilewerdenbenötigt

Verfahren

Wichtig:DieMaschinehatbeiderAuslieferung

keinÖlimMotor.FüllenSiedenMotormitÖl,
bevorSieihnanlassen.

Motorölsorte

Motorölmenge

Ölviskosität

API-KlassikationSJoderhöher

1.StellenSiedieMaschineaufeinerebenen
Flächeab.

2.EntfernenSiedenPeilstab,indemSieden
Deckelnachlinksdrehenundherausziehen
(Bild6).

0,55l

WaschaktivesÖlderSorte
SAE30oderSAE10W-30

5.WischenSiedenPeilstabmiteinemsauberen
Lappenab.

6.SteckenSiedenPeilstabindenÖleinfüllstutzen,
schraubenSieihnjedochnichtein;nehmenSie
denPeilstabdannheraus.

7.LesenSiedenÖlstandamPeilstabab.(Bild6)

•WennderÖlstandamPeilstabzuniedrig

ist,füllenSielangsametwasÖlinden
Öleinfüllstutzen,wartenSiedreiMinutenund
wiederholenSiedanndieSchritte5bis7,bis
derÖlstandamPeilstabrichtigist.

•WennderÖlstandamPeilstabzuhochist,

lassenSieÖlab,bisderÖlstandamPeilstab
richtigist,sieheWechselndesMotoröls

(Seite16).

Wichtig:WennderÖlstandimMotor

zuhochoderzuniedrigistundSieden
Motorlaufenlassen,könnenMotorschäden
auftreten.

8.SteckenSiedenPeilstabfestinden
Öleinfüllstutzen.

4


1.Voll3.Niedrig

2.Hoch

3.GießenSieca.¾derMotorölfüllmengelangsam
indenÖleinfüllstutzen.

4.WartenSiedreiMinuten,damitsichdasÖlim
Motorsetzenkann.

MontierendesFangkorbs

KeineTeilewerdenbenötigt

Verfahren

1.SchiebenSiedenFangkorbaufdenRahmen,
wieinBild7abgebildet.

g238622

g027257


1.Holm3.Fangkorb

2.Rahmen

5
