FormNo.3377-610-ASMRevA
TimeMaster30inLawnMower
ModelNo.20199—SerialNo.313000001andUp
ModelNo.20200—SerialNo.313000001andUp
Operator'sManual
Introduction
Thisrotary-blade,walk-behindlawnmowerisintendedto
beusedbyresidentialhomeowners.Itisdesignedprimarily
forcuttinggrassonwell-maintainedlawnsonresidential
properties.Itisnotdesignedforcuttingbrushorfor
agriculturaluses.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orotherreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Figure1
1.Modelandserialnumberplate
Writetheproductmodelandserialnumbersinthespace
below:
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.
Important:Thisengineisnotequippedwithaspark
arrestermufer.ItisaviolationofCaliforniaPublic
ResourceCodeSection4442touseoroperatetheengine
onanyforest-covered,brush-covered,orgrass-covered
land.Otherstatesorfederalareasmayhavesimilarlaws.
ThissparkignitionsystemcomplieswithCanadianICES-002.
Theenclosed
EngineOwner'sManual
issuppliedfor
informationregardingtheUSEnvironmentalProtection
Agency(EPA)andtheCaliforniaEmissionControl
Regulationofemissionsystems,maintenance,and
warranty.Replacementsmaybeorderedthroughthe
enginemanufacturer.
Formodelswithstatedenginehorsepower,thegross
horsepoweroftheenginewaslaboratoryratedbytheengine
manufacturerinaccordancewithSAEJ1940.Ascongured
tomeetsafety,emission,andoperatingrequirements,the
actualenginehorsepoweronthisclassoflawnmowerwill
besignicantlylower.
OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved
*3377-610-ASM*A
Contents
Readandunderstandthecontentsofthismanualbefore
youstarttheengine.
Introduction..................................................................1
GeneralOperation..................................................2
SlopeOperation......................................................3
Children.................................................................3
Service...................................................................3
SafetyandInstructionalDecals.................................4
Setup............................................................................5
1AssemblingtheHandle..........................................5
2InstallingtheBlade-controlBar...............................6
3FillingtheEnginewithOil......................................6
4ChargingtheBattery..............................................7
ProductOverview..........................................................7
Operation.....................................................................8
FillingtheFuelTank................................................8
CheckingtheEngineOilLevel..................................9
AdjustingtheCuttingHeight....................................9
AdjustingtheHandleHeight....................................10
StartingtheEngine.................................................10
UsingtheSelf-propelDrive......................................11
StoppingtheEngine...............................................11
EngagingtheBlade.................................................11
DisengagingtheBlade.............................................12
CheckingtheBlade-stopSystemOperation................12
RecyclingtheClippings...........................................13
BaggingtheClippings.............................................13
Side-dischargingtheClippings..................................14
OperatingTips......................................................14
Maintenance.................................................................15
RecommendedMaintenanceSchedule(s)......................15
PreparingforMaintenance.......................................16
ServicingtheAirFilter............................................16
ChangingtheEngineOil.........................................16
ChargingtheBattery...............................................17
ReplacingtheFuse..................................................18
ReplacingtheBattery..............................................18
AdjustingtheSelf-propelDriveCable........................19
ServicingtheBlade-driveSystem..............................19
ServicingtheCuttingBlades.....................................20
CheckingforBentBlades........................................21
RemovingtheBlades..............................................21
InstallingtheBlades................................................22
CleaningundertheMachineHousing........................22
Storage........................................................................23
GeneralInformation...............................................23
PreparingtheFuelSystem.......................................23
PreparingtheEngine..............................................24
RemovingtheMachinefromStorage.........................24
Safety
ThislawnmowermeetsorexceedstheCPSCbladesafety
requirementsforwalk-behindrotarylawnmowersandthe
B71.1specicationsoftheAmericanNationalStandards
Instituteineffectatthetimeofproduction.
Thesafetyalertsymbol(Figure2)isusedtoalertyouto
potentialpersonalinjuryhazards.Obeyallsafetymessages
thatfollowthissymboltoavoidpossibleinjuryordeath.
Improperlyusingormaintainingthismowercouldresultin
injuryordeath.Toreducethispotential,complywiththe
followingsafetyinstructions.
Thefollowinginstructionshavebeenadaptedfromthe
ANSI/OPEIstandardB71.1-2003.
Thiscuttingmachinecanamputatehandsandfeetand
throwobjects.Failuretoobservethefollowingsafety
instructionscouldresultinseriousinjuryordeath.
GeneralOperation
•Read,understand,andfollowallinstructionsonthe
machineandinthemanual(s)beforestarting.
•Donotputhandsorfeetnearorunderthemachine.
Keepclearofthedischargeopeningatalltimes.
•Onlyallowresponsibleadults,whoarefamiliarwiththe
instructions,tooperatethismachine.
•Cleartheareaofobjectssuchasrocks,wire,toys,etc.,
whichcouldbethrownbytheblade.Staybehindthe
handlewhentheengineisrunning.
•Besuretheareaisclearofbystandersbeforeoperating.
Stopmachineifanyoneentersthearea.
•Donotoperatemachinebarefootedorwhilewearing
sandals.Alwayswearsubstantialfootwear.
•Donotpullthemachinebackwardunlessitisabsolutely
necessary.Alwayslookdownandbehindbeforeand
whilemovingbackward.
•Neverdirectdischargedmaterialtowardanyone.Avoid
dischargingmaterialagainstawallorobstruction.
Materialmayricochetbacktowardtheoperator.Stopthe
bladewhencrossinggravelsurfaces.
•Donotoperatemachinewithouttheentiregrasscatcher,
dischargeguard,rearguard,orothersafetyprotective
devicesinplaceandworking.
•Neverleavearunningmachineunattended.
•Stoptheengineandwaituntilthebladescometoa
completestopbeforecleaningthemachine,removingthe
grasscatcher,oruncloggingthedischargeguard.
•Operatemachineonlyindaylightorgoodarticiallight.
•Donotoperatemachinewhileundertheinuenceof
alcoholordrugs.
•Neveroperatethemachineinwetgrass.Alwaysbesure
ofyourfooting;walk;neverrun.
•Disengagethedrivesystem,ifsoequipped,before
startingtheengine.
•Ifthemachineshouldstarttovibrateabnormally,stop
theengineandcheckforthecauseimmediately.Vibration
isgenerallyawarningoftrouble.
2
•Alwaysweareyeprotectionwhenoperatingthemachine.
•Seethemanufacturer'sinstructionsforproperoperation
andinstallationofaccessories.Useonlyaccessories
approvedbythemanufacturer.
SlopeOperation
Slopesareamajorfactorrelatedtoslip-and-fallaccidents,
whichcanresultinsevereinjury.Operationonallslopes
requireextracaution.Ifyoufeeluneasyonaslope,donot
mowit.
•Mowacrossthefaceofslopes;neverupanddown.
Exerciseextremecautionwhenchangingdirectionon
slopes.
•Watchforholes,ruts,bumps,rocks,orotherhidden
objects.Uneventerraincouldcauseaslip-and-fall
accident.Tallgrasscanhideobstacles.
•Donotmowonwetgrassorexcessivelysteepslopes.
Poorfootingcouldcauseaslip-and-fallaccident.
•Donotmowneardrop-offs,ditches,orembankments.
Youcouldloseyourfootingorbalance.
•Neverllcontainersinsideavehicleoronatruckor
trailerbedwithaplasticliner.Alwaysplacecontainerson
thegroundawayfromyourvehiclebeforelling.
•Removegas-poweredequipmentfromthetruckortrailer
andrefuelitontheground.Ifthisisnotpossible,then
refuelsuchequipmentwithaportablecontainerrather
thanfromagasolinedispensernozzle.
•Keepthenozzleincontactwiththerimofthefueltank
orcontaineropeningatalltimesuntilfuelingiscomplete.
Donotuseanozzlelock-opendevice.
•Iffuelisspilledonclothing,changeclothingimmediately.
•Neveroverllthefueltank.Replacethefueltankcap
andtightenitsecurely.
WARNING
Exhaustcontainscarbonmonoxide,anodorless,
deadlypoisonthatcankillyou.
Donotruntheengineindoorsorinanenclosed
area.
Children
Tragicaccidentscanoccuriftheoperatorisnotalerttothe
presenceofchildren.Childrenareoftenattractedtothe
machineandthemowingactivity.Neverassumethatchildren
willremainwhereyoulastsawthem.
•Keepchildrenoutofthemowingareaandunderthe
watchfulcareofaresponsibleadultotherthanthe
operator.
•Bealertandturnmoweroffifachildentersthearea.
•Neverallowchildrentooperatethemachine.
•Useextracarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayblockyourviewofachild.
Service
SafeHandlingofGasoline
Toavoidpersonalinjuryorpropertydamage,use
extremecareinhandlinggasoline.Gasolineisextremely
ammableandthevaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andothersources
ofignition.
•Useonlyanapprovedgasolinecontainer.
•Neverremovethefueltankcaporaddfuelwiththe
enginerunning.Allowtheenginetocoolbeforerefueling.
•Neverrefuelthemachineindoors.
•Neverstorethemachineorfuelcontainerwherethereis
anopename,spark,orpilotlightsuchasonawater
heateroronotherappliances.
GeneralService
•Neveroperatethemachineinanenclosedarea.
•Keepallnutsandboltstighttoensurethattheequipment
isinsafeworkingcondition.
•Nevertamperwithsafetydevices.Checktheirproper
operationregularly.
•Keepmachinefreeofgrass,leaves,orotherdebris.Clean
upoilorfuelspillsandremoveanyfuel-soakeddebris.
Allowmachinetocoolbeforestoring.
•Ifyoustrikeaforeignobject,stopandinspectthe
machine.Repair,ifnecessary,beforestarting.
•Nevermakeanyadjustmentsorrepairswiththeengine
running.Disconnectthespark-plugwireandground
againstenginetopreventunintendedstarting.
•Checkgrasscatchercomponentsandthedischarge
guardfrequentlyandreplacethemwithmanufacturer's
recommendedparts,whennecessary.
•Mowerbladesaresharp.Wrapthebladesorweargloves,
anduseextracautionwhenservicingthem.
•Donotchangetheenginegovernorsettingoroverspeed
theengine.
•Maintainorreplacesafetyandinstructionlabelsas
necessary.
3
SafetyandInstructionalDecals
Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamageddecals.
Manufacturer'sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
114-7982
1.Warning—readtheOperator'sManual.
2.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine.
3.Cutting/dismembermenthazardofhandorfoot,mower
blade—removetheignitionkeyandreadtheinstructions
beforeservicingorperformingmaintenance.
4.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
5.Cutting/dismembermenthazardofhandorfoot,mower
blade—donotoperateupanddownslopes;operatesideto
sideonslopes;stoptheenginebeforeleavingtheoperating
position;andlookbehindyouwhenbackingup.
94-8072
Electric-startmodelonly
1.Engine—stop3.Engine—start
2.Engine—run
117-2718
108-8117
120-9570
1.Warning—stayawayfrommovingparts,keepallguards
andshieldsinplace.
108-9751
4
104-7953
Electric-startmodelonly
1.Warning—readtheOperator'sManualforinformationonchargingthebattery;containslead;donotdiscard.
2.ReadtheOperator'sManual.
Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengine.
1
AssemblingtheHandle
NoPartsRequired
Procedure
WARNING
Assemblingandunfoldingthehandleimproperly
candamagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenunfoldingthe
handle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Rotatetheupperhandlesothatitneststogetherwith
thelowerhandle(Figure3),andtightenbothknobson
thehandletolocktheupperhandleinplace(Figure4).
1.Upperhandle
Figure3
2.Knob(2)
Figure4
1.Handle-locklever
2.Releasethehandle-locklever(Figure4).
3.Pullthehandlerearwardandlockitintoposition
(Figure4).
5
2
3
InstallingtheBlade-control
Bar
NoPartsRequired
Procedure
Installtheblade-controlbarintotheupperhandle(Figure5).
Figure5
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmachine
theengine.Beforestartingtheengine,lltheengine
withoil.
Max.ll:20oz(0.59l),type:SAE30detergentoilwithan
APIserviceclassicationofSF,SG,SH,SJ,SL,orhigher.
Note:Whenthecrankcaseisempty,pourabout3/4of
thecrankcasecapacityofoilinthecrankcase,thendothe
following:
1.Movethemachinetoalevelsurface.
2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure6).
doesnot
comewithoilin
Figure6
3.Wipethedipstickcleanwithacleancloth.
4.Insertthedipstickfullyintotheoil-lltube,then
removethedipstick.
5.Readtheoillevelonthedipstick(Figure6).
6
Figure7
2
14
1
13
3
4
5
6
7
8
9
10
11
12
g016439
15
16
ProductOverview
1.Theoillevelistoolow;
addoiltothecrankcase.
2.Theoillevelistoohigh;
removeoilfromthe
crankcase.
3.Theoilleveliscorrect.
•Iftheoillevelistoolow,slowlypourasmall
amountofoilintotheoil-lltube,wait3minutes,
andrepeatsteps3through5untiltheoillevelon
thedipstickiscorrectasshowninFigure7.
•Iftheoillevelistoohigh,draintheexcess
oiluntilyouobtainthecorrectoillevelon
thedipstick.Todraintheexcessoil,referto
ChangingtheEngineOil(page16).
Important:Iftheoillevelinthecrankcaseistoo
lowortoohighandyouruntheengine,youmay
damagetheengine.
6.Installthedipsticksecurely.
Important:
operatinghours
toChangingtheEngineOil(page16).
Changetheengineoilaftertherst5
;changeityearlythereafter.Refer
4
ChargingtheBattery
Figure8
1.Side-dischargedeector
2.Sparkplug10.Battery(electric-start
3.Oilll/dipstick(notshown)
4.Recoil-starthandle
5.Fuel-tankcap13.Fuse
6.Handle-locklever
7.Handleknob(2)
8.Upperhandle16.Frontcutting-heightlever
9.Ignitionswitch
(electric-startmodelonly)
ortoggleswitch(standard
modelonly)
modelonly;notshown)
11.Rearcutting-heightlever
12.Rear-dischargedeector
14.Airlter
15.Washoutport
NoPartsRequired
Procedure
Electric-startmodelonly
RefertoChargingtheBattery(page17).
7
Figure9
Upperhandle
1.Traction-assisthandle3.Blade-controlbar
2.Blade-controlbarlock4.Ignitionswitch
(electric-startmodelonly)
ortoggleswitch(standard
modelonly)
Operation
FillingtheFuelTank
DANGER
Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.
•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
directlyonthegroundbeforelling,notina
vehicleoronanobject.
•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.
•Donothandlegasolinewhensmokingoraround
anopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.
•Forbestresults,useonlyclean,fresh,unleadedgasoline
withanoctaneratingof87orhigher((R+M)/2rating
method).
Figure10
1.Grassbag3.Side-dischargechute
2.Rear-dischargeplug
(installed)
4.Batterycharger
(electric-startmodelonly)
•Oxygenatedfuelwithupto10%ethanolor15%MTBE
byvolumeisacceptable.
•Donotuseethanolblendsofgasoline,suchasE15
orE85,withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemayresult,
whichmaynotbecoveredunderwarranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorinfuel
containersoverthewinterunlessfuelstabilizerhasbeen
addedtothefuel.
•Donotaddoiltogasoline.
Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold.
1.Cleanaroundthefuel-tankcap,andremovethecap
fromthetank(Figure11).
8
5.Readtheoillevelonthedipstick(Figure13).
Figure13
Figure11
2.Fillthefueltank,leavingatleast1/4inch(6mm)from
thebottomoftheneckemptytoallowthegasoline
roomtoexpand(Figure11).
3.Installthefueltankcapandtightenitsecurelybyhand.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Note:Max.ll:20oz(0.59l),type:SAE30detergentoil
withanAPIserviceclassicationofSF,SG,SH,SJ,SL,or
higher.
1.Movethemachinetoalevelsurface.
2.Removethedipstick(Figure12).
1.Theoillevelistoolow;
addoiltothecrankcase.
2.Theoillevelistoohigh;
removeoilfromthe
crankcase.
3.Theoilleveliscorrect.
•Iftheoillevelistoolow,slowlypourasmall
amountofoilintotheoil-lltube,wait3minutes,
andrepeatsteps3through5untiltheoillevelis
correctasshowninFigure13.
•Iftheoillevelistoohigh,draintheexcess
oiluntilyouobtainthecorrectoillevelon
thedipstick.Todraintheexcessoil,referto
ChangingtheEngineOil(page16).
Important:Iftheoillevelinthecrankcaseistoo
lowortoohighandyouruntheengine,youmay
damagetheengine.
6.Installthedipsticksecurely.
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblade,causingserious
injury.
Figure12
3.Wipethedipstickcleanwithacleancloth.
4.Insertthedipstickfullyintotheoil-lltube,then
removethedipstick.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
Adjustthecuttingheightasdesired;refertoFigure14and
Figure15.
Note:Toraisethemachine,movethefrontandrearcutting
heightleversforward;tolowerthemachine,movethecutting
heightleversrearward.Setthefrontandrearwheelstothe
sameheightunlessspecialcircumstancesrequireotherwise;
refertoOperatingTips(page14).
9
Figure14
Frontcutting-heightlever
1.A:4-1/4in(10.8cm)5.E:2-1/4in(5.7cm)
2.B:3-3/4in(9.5cm)6.F:1-3/4in(4.4cm)
3.C:3-1/4in(8.3cm)7.G:1-1/4in(3.2cm)
4.D:2-3/4in(7.0cm)
AdjustingtheHandleHeight
Youcanraiseorlowerthehandletoapositionmore
comfortableforyou.
1.Liftthehandleslightlyandpullthehandle-locklever
rearwardtodisengagethehandle-lockpins(Figure16).
Figure16
1.Handle-locklever3.Notches
2.Handle-lockpin(2)
2.Rotatethehandleandalignthedesirednotchin
thehandlebrackettothehandle-lockpins;referto
Figure16.
1.A:4-1/4in(10.8cm)5.E:2-1/4in(5.7cm)
2.B:3-3/4in(9.5cm)6.F:1-3/4in(4.4cm)
3.C:3-1/4in(8.3cm)7.G:1-1/4in(3.2cm)
4.D:2-3/4in(7.0cm)
Figure15
Rearcutting-heightlever
3.Releasethehandle-locklevertosecurethehandlein
place.
StartingtheEngine
StandardModel
Pulltherecoilhandleslowlyuntilyoufeelresistance,thenpull
itsharply.Allowtheropetoreturntotheengineslowly.
Note:Ifthemachinedoesnotstartafterseveralattempts,
contactanAuthorizedServiceDealer.
Electric-startModel
Youcanstarttheengineonanelectric-startmodelbyusing
eithertheignitionkeyortherecoil-starthandle.
•IgnitionKey:
TurnandholdtheignitionkeytotheStartposition
(Figure17);whentheenginestarts,releasethekey.
Important:Donotattempttostarttheenginewith
theblade-controlbarengaged;otherwise,youmay
blowthefuse.
Note:DonotholdtheignitionkeyintheStartposition
forlongerthan5secondstopreventburningoutthe
startermotor.
10
Figure17
StoppingtheEngine
StandardModel
Pressthetoggleswitch(Figure19)totheStoppositionand
holdituntiltheenginestops.
•Recoil-startHandle:
1.TurntheignitionkeytotheRunposition
(Figure17).
2.Pulltherecoilhandleslowlytotherearuntilyou
feelresistance,thenpullsharply.Allowtheropeto
returntotheengineslowly.
UsingtheSelf-propelDrive
Tooperatetheself-propeldrive,simplywalkwithyourhands
ontheupperhandleandyourelbowsatyoursides,andthe
machinewillautomaticallykeeppacewithyou(Figure18).
Note:Youcanself-propelthemachinewiththeblades
engagedordisengaged.
Figure19
1.Toggleswitch
Electric-startModel
1.TurnthekeytotheOffposition(Figure20).
Figure18
Note:Usethetraction-assisthandleinsituationswhenyou
needmorecontrolthanyouhavewiththeself-propeldrive
alone.
Figure20
2.Whentheenginestops,removetheignitionkeyand
takeitwithyouwhenyouleavethemachine.
EngagingtheBlade
Whenyoustartyourengine,thebladedoesnotturn.You
mustengagethebladetomow.
1.Pulltheblade-control-barlockbacktotheblade-control
bar(Figure21).
11
CheckingtheBlade-stop
SystemOperation
ServiceInterval:Beforeeachuseordaily
Checkthatthebladesstopwithin3secondsofreleasingthe
blade-controlbar.
UsingtheGrassBag
Figure21
1.Blade-controlbarlock2.Blade-controlbar
2.Slowlypulltheblade-controlbarbacktothehandle
(Figure21).
3.Holdtheblade-controlbaragainstthehandle
(Figure22).
Figure22
DisengagingtheBlade
Releasetheblade-controlbar(Figure23).
Figure23
Important:Whenyoureleasetheblade-controlbar,
thebladeshouldstopwithin3seconds.Ifitdoesnot
stopproperly,stopusingyourmachineimmediatelyand
contactanAuthorizedServiceDealer.
Youcanusethegrassbagtochecktheblade-stopsystem.
1.Removetherear-dischargeplug.
2.Installtheemptygrassbagonthemachine.
3.Starttheengine.
4.Engagetheblade.
Note:Thebagshouldbegintoinate,indicatingthat
thebladesarerotating.
5.Whilewatchingthebag,releasetheblade-controlbar.
Note:Ifthebagdoesnotdeatewithin3secondsof
releasingtheblade-controlbar,theblade-stopsystem
maybedeterioratingand,ifignored,couldresultin
anunsafeoperatingcondition.Havethemachine
inspectedandservicedbyanAuthorizedService
Dealer.
6.Stoptheengineandwaitforallmovingpartstostop.
NotUsingtheGrassBag
1.Movethemachineontoapavedsurfaceinanon-windy
area.
2.Setall4wheelstothe3-1/2inch(89mm)cutting
heightsetting.
3.Takeahalfsheetofnewspaperandcrumpleitintoa
ballsmallenoughtogounderthemachinehousing
(about3inchesor76mmindiameter).
4.Placethenewspaperballabout5inches(13cm)in
frontofthemachine.
5.Starttheengine.
6.Engagetheblade.
7.Releasetheblade-controlbarandbegincountingout3
seconds.
8.Onthecountof3,pushthemachinequicklyforward
overthenewspaper.
9.Stoptheengineandwaitforallmovingpartstostop.
10.Gotothefrontofthemachineandcheckthe
newspaperball.
Note:Ifthenewspaperballdidnotgounderthe
machine,repeatsteps4through10.
11.Ifthenewspaperisunravelledorshredded,theblades
didnotstopproperly,whichcouldresultinanunsafe
operatingcondition.ContactanAuthorizedService
Dealer.
12
RecyclingtheClippings
Thismachinecomesfromthefactoryreadytorecyclegrass
andleafclippingsbackintothelawn.Topreparethemachine
torecycle,dothefollowing:
•Iftheside-dischargechuteisonthemachine,remove
itandlowertheside-dischargedeector;referto
RemovingtheSide-dischargeChute(page14).
•Ifthegrassbagisonthemachine,removeit;referto
RemovingtheGrassBag(page13).
•Iftherear-dischargeplugisnotinstalled,gripitbythe
handle,raisethereardeector,andinsertitintothe
rear-dischargechuteuntilthelatchlocksintoplace;refer
toFigure24.
Iftheside-dischargechuteisonthemower,
removeitbeforebaggingtheclippings;referto
RemovingtheSide-dischargeChute(page14).
InstallingtheGrassBag
1.Raiseandholdupthereardeector(Figure25).
Figure25
Figure24
1.Reardeector
2.Inserttherear-discharge
plug
3.Therear-dischargeplug
installed
WARNING
Ensurethattherear-dischargeplugisinplace
beforeyourecycletheclippings.Neverengagethe
bladeswithouteithertherear-dischargeplugorthe
grassbaginstalled.
BaggingtheClippings
1.Reardeector
2.Rear-dischargeplug
2.Removetherear-dischargeplugbypullingdownonthe
latchwithyourthumbandpullingtheplugoutfrom
themachine(Figure25).
3.Installthebagrodintothenotchesatthebaseofthe
handleandrockthebagbackandforthtoensurethat
therodisseatedatthebottomofbothnotches;refer
toFigure26.
3.Latch
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
WARNING
1.Bagrod
Figure26
2.Notch(2)
Aworngrassbagcouldallowsmallstonesandother
similardebristobethrowntowardtheoperatoror
4.Lowerthereardeectoruntilitrestsonthegrassbag.
bystandersandresultinseriouspersonalinjuryor
death.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
RemovingtheGrassBag
Toremovethebag,reversethestepsin
InstallingtheGrassBag(page13).
13
Side-dischargingtheClippings
Usethesidedischargeforcuttingverytallgrass.
Ifthebagisonthemachine,removeit
andinserttherear-dischargeplug;referto
RemovingtheGrassBag(page13)beforeside-discharging
theclippings.
Important:Ensurethattherear-dischargeplugisin
placebeforeyourecycletheclippings(Figure24).
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheSide-dischargeChute
1.Liftopentheside-dischargedeector(Figure27).
Figure28
RemovingtheSide-dischargeChute
Toremovetheside-dischargechute,reversethestepsin
InstallingtheSide-dischargeChute(page14).
OperatingTips
GeneralMowingTips
•Cleartheareaofsticks,stones,wire,branches,andother
debristhatthebladecouldhit.
•Avoidstrikingsolidobjectswiththeblade.Never
deliberatelymowoveranyobject.
•Ifthemachinestrikesanobjectorstartstovibrate,
immediatelystoptheengine,disconnectthewirefrom
thesparkplug,andexaminethemachinefordamage.
•Forbestperformance,installanewbladebeforethe
cuttingseasonbegins.
•ReplacethebladewhennecessarywithaToro
replacementblade.
Figure27
1.Side-dischargedeector2.Side-dischargechute
2.Installtheside-dischargechuteasshownin
Figure27andFigure28,andclosethedeectoronto
thechute.
CuttingGrass
•Cutonlyaboutathirdofthegrassbladeatatime.Donot
cutbelowthe2-inch(51mm)settingunlessthegrassis
sparseoritislatefallwhengrassgrowthbeginstoslow
down.RefertoAdjustingtheCuttingHeight(page9).
•Whencuttinggrassover6inches(15cm)tall,mowatthe
highestcuttingheightsettingandwalkslower;thenmow
againatalowersettingforthebestlawnappearance.If
thegrassistoolong,themachinemayplugandcause
theenginetostall.
•Mowonlydrygrassorleaves.Wetgrassandleavestend
toclumpontheyardandcancausethemachinetoplug
ortheenginetostall.
WARNING
Wetgrassorleavescancauseseriousinjuryif
youslipandcontacttheblade.Mowonlyindry
conditions.
14
•Beawareofapotentialrehazardinverydryconditions,
followalllocalrewarnings,andkeepthemachinefree
ofdrygrassandleafdebris.
•Alternatethemowingdirection.Thishelpsdispersethe
clippingsoverthelawnforevenfertilization.
•Ifthenishedlawnappearanceisunsatisfactory,tryone
ormoreofthefollowing:
–Replacethebladeorhaveitsharpened.
–Walkataslowerpacewhilemowing.
–Raisethecuttingheightonyourmachine.
–Cutthegrassmorefrequently.
–Setthecuttingheightonthefrontwheelsonenotch
lowerthantherearwheels.Forexample,setthefront
wheelsat2-inch(51mm)andtherearwheelsat2-1/2
inches(64mm).
CuttingLeaves
•Aftercuttingthelawn,ensurethathalfofthelawnshows
throughthecutleafcover.Youmayneedtomakemore
thanonepassovertheleaves.
•Iftherearemorethan5inches(13cm)ofleavesonthe
lawn,setthefrontcuttingheight1or2notcheshigher
thantherearcuttingheight.
–Overlapcuttingswathsinsteadofcuttingafullswath
witheachpass.
•Slowdownyourmowingspeedifthemachinedoesnot
cuttheleavesnelyenough.
Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
Interval
Aftertherst5hours
Beforeeachuseordaily
Every25hours
Every50hours
MaintenanceProcedure
•Changetheengineoil.
•Checktheengineoillevel.
•Checktheblade-brake-clutchoperation.
•Checktheaircleanerandcleanorreplaceit,ifnecessary.
•Checkthecuttingblades.
•Cleangrassclippingsanddirtfromunderthemachinehousing.
•Chargethebattery(electric-startmodelonly).
•Changetheengineoil.
•Servicetheblade-drivesystem.
•Servicetheairlter;replaceitmorefrequentlyindustyoperatingconditions.
•Changetheengineoil.
Yearly
Yearlyorbeforestorage
Important:Refertoyourengineoperator'smanualforadditionalmaintenanceprocedures.
•Servicethecuttingblades.
•Refertoyourengineoperator'smanualforanyadditionalyearlymaintenance
procedures.
•Chargethebattery(electric-startmodelonly).
•Emptythefueltankbeforerepairsasdirectedandbeforeyearlystorage.
15
PreparingforMaintenance
ServicingtheAirFilter
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthespark-plugwirefromthesparkplug
(Figure29).
Figure29
1.Spark-plugwire
3.Afterperformingthemaintenanceprocedure(s),
connectthesparkplugwiretothesparkplug.
Important:Beforetippingthemachinetochange
theoilorreplacetheblade,allowthefueltankto
rundrythroughnormalusage.Ifyoumusttip
themachinepriortorunningoutoffuel,usea
handfuelpumptoremovethefuel.Alwaystipthe
machineontoitsside,withthedipstickdown.
WARNING
Tippingthemachinemaycausethefueltoleak.
Gasolineisammable,explosive,andcancause
personalinjury.
ServiceInterval:Beforeeachuseordaily
Yearly
1.Loosenthefastenerandremovetheairltercover
(Figure30).
Figure30
1.Cover
2.Fastener4.Base
2.Removeandinspectthelter.
3.Filter
•Ifthelterisdamagedoriswetwithoilorfuel,
replaceit.
•Ifthelterisdirty,tapitonahardsurfaceseveral
timesorblowthedebrisoutwardfromtheinterior
ofthelterusingcompressedairatlessthan30
psi(207kPa).
Note:Donotbrushorblowdirtfromtheoutside
ofthelter;eitherforcesdirtintothebers.
3.Cleantheairlterbodyandcoverusingadamprag.
Keepdirtawayfromtheairopening.
4.Installthelterontothebase.
5.Installthecoverandscrewthefastenerdownsecurely.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
16
Every50hours
Yearly
Note:Runtheengineafewminutesbeforechangingthe
oiltowarmit.Warmoilowsbetterandcarriesmore
contaminants.
1.Ensurethatthefueltankcontainslittleornofuelso
thatfueldoesnotleakoutwhenyoutipthemachine
ontoitsside.
2.Movethemachinetoalevelsurface.
3.Disconnectthewirefromthesparkplug.Referto
PreparingforMaintenance(page16).
4.Tipthemachineontoitsside,withthedipstickdown,
untiltheupperhandlerestsontheground.
5.Setanoil-drainpanunderthedipstick.
6.Removethedipstickanddraintheusedoilintothe
oil-drainpan(Figure31).
Figure31
Important:Iftheoillevelinthecrankcaseistoo
lowortoohighandyouruntheengine,youmay
damagetheengine.
13.Installthedipsticksecurely.
14.Recycletheusedoilproperly.
ChargingtheBattery
ServiceInterval:Every25hours
Yearlyorbeforestorage
Electric-startmodelonly
WARNING
Batteryposts,terminals,andrelatedaccessories
containleadandleadcompounds,chemicals
knowntotheStateofCaliforniatocausecancerand
reproductiveharm.
thebattery.
Washyourhandsafterhandling
7.Afterdrainingtheusedoil,returnthemachinetothe
operatingposition.
8.Pourabout3/4ofthecrankcasecapacityofoilinthe
crankcase.
Note:Max.ll:20oz.(0.59l),type:SAE30
detergentoilwithanAPIserviceclassicationofSF ,
SG,SH,SJ,SL,orhigher.
9.Waitabout3minutesfortheoiltosettleinthe
crankcase.
10.Wipethedipstickcleanwithacleancloth.
11.Insertthedipstickfullyintotheoil-lltube,then
removethedipstick.
12.Readtheoillevelonthedipstick(Figure32).
Figure32
1.Theoillevelistoolow;
addoiltothecrankcase.
2.Theoillevelistoohigh;
removeoilfromthe
crankcase.
3.Theoilleveliscorrect.
Chargethebatteryfor24hoursinitially,thenmonthly(every
25starts)orasneeded.Alwaysusethechargerinasheltered
area,andchargethebatteryatroomtemperature(about70°
F,or22°C)wheneverpossible.
Note:Themachineisequippedwithanalternatorcharging
system.
1.Connectthechargertothewireharness,whichis
locatedbelowtheignitionkey(Figure33).
Figure33
2.Plugthechargerintoawalloutlet.
Note:Yourbatterychargermayhavea2-colorLED
displaythatindicatesthefollowingstatesofcharging:
•Iftheoillevelistoolow,slowlypourasmall
amountofoilintotheoil-lltube,wait3minutes,
andrepeatsteps10through12untiltheoillevelis
correctasshowninFigure32.
•Iftheoillevelistoohigh,draintheexcessoiluntil
youobtainthecorrectoillevelonthedipstick.
•Aredlightindicatesthatthechargerischarging
thebattery.
•Agreenlightindicatesthatthechargerisfully
chargedorisdisconnectedfromthebattery.
•Aashinglightthatalternatesbetweenredand
greenindicatesthatthebatteryisnearlyfully
17
charged.Thisstatelastsonlyafewminutesuntil
thebatteryisfullycharged.
Note:Whenthebatterynolongerholdsacharge,
recyclethelead-acidbatteryaccordingtolocalcodes.
ReplacingtheFuse
Electric-startmodelonly
Ifthebatterydoesnotchargeortheenginedoesnotturn
withtheelectricstarter,thefusemaybeblown;replaceitwith
a40-ampplug-intypefuse.
Important:Youcannotstartthemachinewiththe
electricstarterorchargethebatteryunlessaworking
fuseisinstalled.
1.Openthesealedfuseholderandreplacethefuse
(Figure34).
Figure35
1.Rear-deectorandhandle-lockleverassembly
8.Removethecoverfromthebattery.
9.Disconnecttheleadsfromthebattery.
10.Removeandbatteryandrecycleit.
Note:Recyclethebatteryaccordingtoyourstateand
localregulations.
Figure34
1.Fuseholder
2.Closethecovertothefuseholder,andensurethatit
issealedtightly.
ReplacingtheBattery
Electric-startmodelonly
RemovingtheOldBattery
1.ContactanAuthorizedToroPartsDealertoobtaina
replacementbattery.
2.Removethebeltcover;refertostep1ofServicingthe
Blade-driveSystem(page20).
3.Removetherear-dischargeplug.
4.Movethehandletotheverticalposition.
5.Removethe4smallboltsthatholdtherear-deector
andhandle-lockleverassemblyinplace.
6.Foldthehandleallthewayforward.
7.Removetherear-deectorandhandle-locklever
assembly(Figure36).
InstallingtheNewBattery
1.Cleanthebattery-holdingareaonthemachinehousing.
2.Setthenewbatteryinplaceonthemachinehousing.
3.Connecttheleadstothenewbattery.
Note:Ensurethatyouconnecttheblack(negative)
wiretothenegative(-)terminalandthered(positive)
wiretothepositive(+)terminal.
4.Installthecoverontothebattery.
Note:Ensurethatthecovertsproperlyoverthe
wiringharness.
5.Installtherear-deectorandhandle-lockleverassembly
ontothemachine.
6.Raisethehandletotheverticalposition.
7.Securetheshroudwiththe4small
boltsthatyouremovedinstep5of
RemovingtheOldBattery(page18).
8.Installtherear-dischargeplug.
9.Returnthehandletotheoperatingposition.
18
AdjustingtheSelf-propelDrive
ServicingtheBlade-drive
Cable
Wheneveryouinstallanewself-propelcableorifthe
self-propeldriveisoutofadjustment,adjusttheself-propel
drivecable.
1.Loosenthecable-supportnut(Figure36).
Figure36
2.Pulldownthecablejacket(towardthemachine)until
thereisnoslackinthecable(Figure37).
System
ServiceInterval:Every50hours
1.Removetheblade-drivesystemcover(Figure38).
Figure38
1.Bolts
2.Brushorblowoutdebrisfromtheinsideoftheshield
andaroundalltheparts.
3.Holda0.010-inchfeelergauge,apieceofpaper,ora
notecardagainstthewallandslideitdownbehindthe
belttensionspring.
2.Cover
Note:Ifthereisavisiblegapbetweenthegaugeand
thespring,tightentheadjustingboltandthenutuntil
thepaperbarelyslidesfreelyinandoutofthegap
(Figure39).
Figure37
3.Tightenthenutonthecablesupport.
Figure39
1.Belt-tensionspring4.Adjustingnut
2.Adjustingbolt5.Blade-drivebelt
3.Gap
Important:Donotovertightentheadjustingbolt.
Thiscoulddamagetheblade-drivebelt.
4.Installtheblade-drivesystemcoverthatyoupreviously
removed.
6.Wall
19
ServicingtheCuttingBlades
WARNING
ServiceInterval:Yearly
Important:
bladesproperly.
areuncomfortableperformingthisprocedure,contact
anAuthorizedServiceDealer.
Examinethebladesforsharpnessandanywearordamage
wheneveryourunoutofgasoline.Ifthebladeedgesare
dullornicked,havethemsharpenedorreplacetheblades.
Ifabladeisworn,bent,damagedorcracked,replaceit
immediatelywithagenuineTororeplacementblade.
Youwillneedatorquewrenchtoinstallthe
Ifyoudonothaveatorquewrenchor
DANGER
Awornordamagedbladecanbreak,andapiece
ofthebladecouldbethrowntowardtheoperator
orabystander,resultinginseriouspersonalinjury
ordeath.
•Inspectthebladesperiodicallyforwearor
damage.
•Replaceawornordamagedblade.
Note:Maintainsharpbladesthroughoutthecuttingseason,
becausesharpbladescutcleanlywithouttearingorshredding
thegrassblades.
PreparingtoServicetheCuttingBlades
1.Lockthehandleintheverticalposition(Figure40);
refertoAdjustingtheHandleHeight(page10).
Thebladesaresharp;contactingabladecould
resultinseriouspersonalinjury.
•Disconnectthewirefromthesparkplug .
•Weargloveswhenservicingtheblade.
InspectingtheBlades
ServiceInterval:Beforeeachuseordaily
1.Inspectthecuttingedges(Figure41).Iftheedgesare
notsharporhavenicks,removethebladesandhave
themsharpenedorreplacethem.
Figure41
1.Cuttingedge3.Wear/slotforming
2.Curvedarea4.Crack
2.Inspectthebladesthemselves,especiallythecurved
area(Figure41).Ifyounoticeanydamage,wear,ora
slotforminginthisarea,immediatelyreplaceitwith
anewblade.
DANGER
Figure40
1.Handlelockedintheverticalposition
2.Tipthemachineontoitsside,withthedipstickdown,
untiltheupperhandlerestsontheground.
Ifyouallowabladetowear,aslotwillform
betweenthesailandatpartoftheblade.
Eventuallyapieceoftheblademaybreak
offandbethrownfromunderthehousing,
possiblyresultinginseriousinjurytoyouor
bystanders.
•Inspectthebladeperiodicallyforwearor
damage.
•Nevertrytostraightenabladethatisbent
orweldabrokenorcrackedblade.
•Replaceawornordamagedblade.
3.Checkforbentblades;referto
CheckingforBentBlades(page21).
20
CheckingforBentBlades
RemovingtheBlades
1.RotatethebladestothepositionshowninFigure42.
Figure42
1.Frontofcuttingdeck3.Measurefromthecutting
edgetoasmooth,level
surface
2.MeasureatlocationsA
andB
2.Measurefromalevelsurfacetothecuttingedges
atlocationsAandB(Figure42),andrecordboth
dimensions.
Replacethebladeswhenthemachinehitsasolidobjector
whenabladeisoutofbalanceorbent.Useonlygenuine
Tororeplacementblades.
1.Useablockofwoodtoholdeachbladesteadyandturn
thebladeboltcounterclockwiseasshowninFigure43.
Figure43
2.RemoveeachbladeasshowninFigure44.
3.Rotatethebladessothattheiroppositeendsareat
locationsAandB(Figure42).
4.Repeatthemeasurementsinstep2andrecordthem.
Note:IfthedifferencebetweenthedimensionsA
andBobtainedinsteps2and4exceeds1/8in(3
mm),thebladeisbentandyouwillneedtoreplace
it.RefertoRemovingtheBlades(page21)and
InstallingtheBlades(page22).
WARNING
Abladethatisbentordamagedcouldbreakapart
andcouldseriouslyinjureorkillyouorbystanders.
•Alwaysreplaceabentordamagedbladewith
anewblade.
•Neverleorcreatesharpnotchesintheedges
orsurfacesofablade.
Figure44
1.Spindle(2)3.Blade(2)
2.Bladedriver(2)4.Bladebolt(2)
3.Inspectthepinsonthebladedriversforwearand
damage.
21
InstallingtheBlades
1.Installtherstbladesothatitishorizontal,alongwith
allmountinghardwareasshowninFigure44.
Note:Tightentheboltwithyourngers.
Important:Positionthecurvedendsoftheblades
topointtowardthemachinehousing.Besureto
nesttheraisedareasoneachbladedriverwiththe
recessesintheheadofitscorrespondingspindle,
andthepinsontheothersideofeachbladedriver
withtheholesinitscorrespondingblade.
2.Steadyeachbladewithaboardandturnthebladebolt
clockwisewithatorquewrenchasshowninFigure45;
torquethebladeboltto60ft-lb(82N-m).
Important:Abolttorquedto60ft-lb(82N-m)is
verytight.Putyourweightbehindthewrenchand
tightentheboltsecurely.Thisboltisverydifcult
toovertighten.
Figure46
1.Blade(2)
4.Tightenthesecondblade;refertostep2.
5.Rotatethebladesbyhandafull360°turntoensure
thattheydonottouch.
Note:Ifthebladestoucheachother,theyarenot
mountedcorrectly.Repeatsteps1through3,untilthe
bladesnolongertoucheachother.
WARNING
Incorrectlyinstallingthebladescoulddamagethe
machineorcauseaninjurytotheoperatororto
bystanders.
CleaningundertheMachine
Housing
ServiceInterval:Beforeeachuseordaily
1.Movethemachinetoalevelsurface.
2.Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
Figure45
3.Rotatetheinstalledblade1/4turnuntilitisvertical,
andinstalltheotherbladeinthesamemannerasthe
rst(refertostep1).
Note:Thebladesshouldbeperpendicular,forming
aninverted“T”asshowninFigure46.
3.Lowerthemachinetoitslowestcuttingheightsetting.
RefertoAdjustingtheCuttingHeight(page9).
4.Attachahosetothewashouttting,andturnthewater
onhigh(Figure47).
Note:Spreadpetroleumjellyonthewashouttting
O-ringtomakethecouplingslideoneasierandprotect
theO-ring.
22
Storage
Storethemachineinacool,clean,dryplace.
GeneralInformation
1.Performtherecommendedannualmaintenance
procedures;refertoMaintenance(page15).
2.Cleanunderthemachinehousing;referto
CleaningundertheMachineHousing(page22).
3.Removechaff,dirt,andgrimefromtheexternalparts
oftheengine,theshrouding,andthetopofthe
machine.
Figure47
1.Washouttting3.O-ring
2.Hose
5.Starttheengine,engagetheblade-controllever,andlet
themachinerunfor1to3minutes.
6.Disengagetheblade-controllever,stoptheengine,and
waitforallmovingpartstostop.
7.Shutoffthewaterandremovethecouplingfromthe
washouttting.
Note:Ifthemachineisnotcleanafterasingle
washing,soakitandletitstandfor30minutes.Then
repeattheprocess.
8.Runthemachineagainandengagethebladesfor1to3
minutestoremovetheexcesswater.
4.Coupling
WARNING
Abrokenormissingwashoutttingcouldexpose
youandotherstothrownobjectsorbladecontact.
Contactwithabladeorthrowndebriscancause
injuryordeath.
•Replaceabrokenormissingwashouttting
immediately,beforeusingthemachineagain.
•Neverputyourhandsorfeetunderthemachine
orthroughopeningsinthemachine.
4.Checktheconditionoftheblades;referto
InspectingtheBlades(page20).
5.Servicetheairlter;referto
ServicingtheAirFilter(page16).
6.Tightenallnuts,bolts,andscrews.
7.Touchupallrustedorchippedpaintsurfaceswith
paintavailablefromanAuthorizedServiceDealer.
8.Chargethebatteryfor24hours,thenunplugthe
batterychargerandstorethemachineinanunheated
area.Ifyoumuststorethemachineinaheatedarea,
youmustchargethebatteryevery90days(electric-start
modelonly).
9.Foldthehandleforstorage;referto
AdjustingtheHandleHeight(page10).
PreparingtheFuelSystem
WARNING
Gasolinecanvaporizeifyoustoreitoverlong
periodsoftimeandexplodeifitcomesintocontact
withanopename.
•Donotstoregasolineoverlongperiodsoftime.
•Donotstorethemachinewithgasolineinthe
fueltankorthecarburetorinanenclosurewith
anopename.(Forexample,afurnaceora
waterheaterpilotlight.)
•Allowtheenginetocoolbeforestoringitinany
enclosure.
Onthelastrefuelingoftheyear,addfuelstabilizertothefuel
asdirectedbytheenginemanufacturer.Emptythefueltank
whenmowingthelasttimebeforestoringthemachine.
1.Runthemachineuntiltheenginestopsfromrunning
outoffuel.
2.Starttheengineagain.
3.Allowtheenginetorununtilitstops.Whenyoucan
nolongerstarttheengine,itissufcientlydry.
23
PreparingtheEngine
1.Whiletheengineisstillwarm,changetheengineoil;
refertoChangingtheEngineOil(page16).
2.Removethesparkplug.
3.Usinganoilcan,addabout1oz(30ml),ofmotoroil
totheenginethroughthespark-plughole.
4.Slowlypullthestarterropeseveraltimestodistribute
oilthroughoutthecylinder.
5.Installthesparkplugbutdonotconnectthewireto
thesparkplug.Securethewiresothatitdoesnotcome
intocontactwiththesparkplug.
RemovingtheMachinefrom
Storage
1.Unfoldthehandle;referto
AdjustingtheHandleHeight(page10).
2.Checkandtightenallfasteners.
3.Removethesparkplugandspintheenginerapidly
usingthestartertoblowexcessoilfromthecylinder.
4.Inspectthesparkplugandreplaceitifitisdirty,worn,
orcracked;refertotheengineoperator’smanual.
5.Installthesparkplugandtightenittotherecommended
torqueof180in-lb(20N-m).
6.Performanyneededmaintenanceprocedures;referto
Maintenance(page15).
7.Checktheengineoillevel;referto
CheckingtheEngineOilLevel(page9).
8.Fillthefuelinthefueltankwithfreshgasoline;referto
FillingtheFuelTank(page8).
9.Chargethebattery(electric-startmodelonly);referto
ChargingtheBattery(page17).
10.Connectthewiretothesparkplug.
24
Notes:
25
Notes:
26
