FormNo.3359-102RevA

22inRecycler®LawnMower

ModelNo.20068—SerialNo.280000001andUp

Operator'sManual

Introduction

Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoidinjury
andproductdamage.Youareresponsibleforoperating
theproductproperlyandsafely.

YoumaycontactTorodirectlyatwww.Toro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.

Wheneveryouneedservice,genuineToroparts,
oradditionalinformation,contactanAuthorized
ServiceDealerorToroCustomerServiceandhave
themodelandserialnumbersofyourproductready.
Figure1identiesthelocationofthemodelandserial
numbersontheproduct.

Figure2

1.Safetyalertsymbol

Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.

Warning

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,

orotherreproductiveharm.

Important:Thisengineisnotequippedwitha
sparkarrestermufer.ItisaviolationofCalifornia
PublicResourceCodeSection4442touseoroperate
theengineonanyforest-covered,brush-covered,or
grass-coveredland.Otherstatesorfederalareas
mayhavesimilarlaws.

Figure1

1.Modelandserialnumberplate

Writetheproductmodelandserialnumbersinthespace
below:

ModelNo.

SerialNo.

Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycauseserious
injuryordeathifyoudonotfollowtherecommended
precautions.

©2007—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Registeratwww.Toro.com.

ThissparkignitionsystemcomplieswithCanadian
ICES-002.

Theenclosed

Engine Owner’ s Man ual

issupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCalifornia
EmissionControlRegulationofemissionsystems,
maintenance,andwarranty.Replacementsmaybe
orderedthroughtheenginemanufacturer.

Formodelswithstatedenginehorsepower,thegross
horsepoweroftheenginewaslaboratoryratedbythe
enginemanufacturerinaccordancewithSAEJ1940.
Asconguredtomeetsafety,emission,andoperating
requirements,theactualenginehorsepoweronthisclass
oflawnmowerwillbesignicantlylower.

OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved

Safety

ThislawnmowermeetsorexceedstheCPSCblade
safetyrequirementsforwalk-behindrotarylawnmowers
andtheB71.1specicationsoftheAmericanNational
StandardsInstituteineffectatthetimeofproduction.

Readandunderstandthecontentsofthismanual
beforeyoustarttheengine.

Thesafetyalertsymbol(Figure2)isusedtoalertyou
topotentialpersonalinjuryhazards.Obeyallsafety
messagesthatfollowthissymboltoavoidpossibleinjury
ordeath.Improperlyusingormaintainingthismower
couldresultininjuryordeath.Toreducethispotential,
complywiththefollowingsafetyinstructions.

Thefollowinginstructionshavebeenadaptedfromthe
ANSI/OPEIstandardB71.1-2003.

Thiscuttingmachinecanamputatehandsandfeet
andthrowobjects.Failuretoobservethefollowing
safetyinstructionscouldresultinseriousinjuryor
death.

GeneralOperation

•Read,understand,andfollowallinstructionsonthe
machineandinthemanual(s)beforestarting.

•Donotputhandsorfeetnearorunderthemachine.
Keepclearofthedischargeopeningatalltimes.

•Onlyallowresponsibleadults,whoarefamiliarwith
theinstructions,tooperatethismachine.

•Cleartheareaofobjectssuchasrocks,wire,toys,
etc.,whichcouldbethrownbytheblade.Stay
behindthehandlewhentheengineisrunning.

•Besuretheareaisclearofbystandersbefore
operating.Stopmachineifanyoneentersthearea.

•Donotoperatemachinebarefootedorwhilewearing
sandals.Alwayswearsubstantialfootwear.

•Donotpullmachinebackwardunlessabsolutely
necessary.Alwayslookdownandbehindbeforeand
whilemovingbackward.

•Neverdirectdischargedmaterialtowardanyone.
Avoiddischargingmaterialagainstawallor
obstruction.Materialmayricochetbacktoward
theoperator.Stopthebladewhencrossinggravel
surfaces.

•Donotoperatemachinewithouttheentiregrass
catcher,dischargeguard,rearguard,orothersafety
protectivedevicesinplaceandworking.

•Neverleavearunningmachineunattended.

•Stoptheengineandwaituntilthebladecomes
toacompletestopbeforecleaningthemachine,

removinggrasscatcher,oruncloggingthedischarge
guard.

•Operatemachineonlyindaylightorgoodarticial
light.

•Donotoperatemachinewhileundertheinuence
ofalcoholordrugs.

•Neveroperatemowerinwetgrass.Alwaysbesure
ofyourfooting;walk;neverrun.

•Disengagethedrivesystem,ifsoequipped,before
startingtheengine.

•Ifthemachineshouldstarttovibrateabnormally,
stoptheengineandcheckforthecauseimmediately.
Vibrationisgenerallyawarningoftrouble.

•Alwaysweareyeprotectionwhenoperatingmachine.

•Seemanufacturer’sinstructionsforproperoperation
andinstallationofaccessories.Onlyuseaccessories
approvedbythemanufacturer.

SlopeOperation

Slopesareamajorfactorrelatedtoslipandfallaccidents,
whichcanresultinsevereinjury.Operationonallslopes
requireextracaution.Ifyoufeeluneasyonaslope,do
notmowit.

•Mowacrossthefaceofslopes;neverupanddown.
Exerciseextremecautionwhenchangingdirection
onslopes.

•Watchforholes,ruts,bumps,rocks,orotherhidden
objects.Uneventerraincouldcauseaslipandfall
accident.Tallgrasscanhideobstacles.

•Donotmowonwetgrassorexcessivelysteepslopes.
Poorfootingcouldcauseaslipandfallaccident.

•Donotmowneardrop-offs,ditches,or
embankments.Youcouldloseyourfootingor
balance.

Children

Tragicaccidentscanoccuriftheoperatorisnotalertto
thepresenceofchildren.Childrenareoftenattractedto
themachineandthemowingactivity.Neverassume
thatchildrenwillremainwhereyoulastsawthem.

•Keepchildrenoutofthemowingareaandunder
thewatchfulcareofaresponsibleadultotherthan
theoperator.

•Bealertandturnmoweroffifachildentersthearea.

•Neverallowchildrentooperatethemachine.

•Useextracarewhenapproachingblindcorners,
shrubs,trees,orotherobjectsthatmayblockyour
viewofachild.

2

Service

SafeHandlingofGasoline

Toavoidpersonalinjuryorpropertydamage,use
extremecareinhandlinggasoline.Gasolineis
extremelyammableandthevaporsareexplosive.

•Extinguishallcigarettes,cigars,pipes,andother
sourcesofignition.

•Useonlyanapprovedgasolinecontainer.

•Neverremovegascaporaddfuelwiththeengine
running.Allowenginetocoolbeforerefueling.

•Neverrefuelthemachineindoors.

•Neverstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlightsuchas
onawaterheateroronotherappliances.

•Neverllcontainersinsideavehicleoronatruck
ortrailerbedwithaplasticliner.Alwaysplace
containersonthegroundawayfromyourvehicle
beforelling.

•Removegas-poweredequipmentfromthetruck
ortrailerandrefuelitontheground.Ifthisisnot
possible,thenrefuelsuchequipmentwithaportable
container,ratherthanfromagasolinedispenser
nozzle.

•Keepthenozzleincontactwiththerimofthefuel
tankorcontaineropeningatalltimesuntilfuelingis
complete.Donotuseanozzlelock-opendevice.

•Iffuelisspilledonclothing,changeclothing
immediately.

•Neveroverllfueltank.Replacegascapandtighten
securely.

Exhaustcontainscarbonmonoxide,an
odorless,deadlypoisonthatcankillyou.

Donotruntheengineindoorsorinanenclosed
area.

GeneralService

•Neveroperatemachineinaclosedarea.

•Keepallnutsandboltstighttobesuretheequipment
isinsafeworkingcondition.

•Nevertamperwithsafetydevices.Checktheir
properoperationregularly .

•Keepmachinefreeofgrass,leaves,orotherdebris
build-up.Cleanupoilorfuelspillageandremove
anyfuel-soakeddebris.Allowmachinetocool
beforestoring.

•Ifyoustrikeaforeignobject,stopandinspectthe
machine.Repair,ifnecessary,beforestarting.

•Nevermakeanyadjustmentsorrepairswiththe
enginerunning.Disconnectthesparkplugwire
andgroundagainstenginetopreventunintended
starting.

•Checkgrasscatchercomponentsandthedischarge
guardfrequentlyandreplacewithmanufacturer’ s
recommendedparts,whennecessary.

•Mowerbladesaresharp.Wrapthebladeorwear
gloves,anduseextracautionwhenservicingthem.

•Donotchangetheenginegovernorsettingor
overspeedtheengine.

•Maintainorreplacesafetyandinstructionlabels,as
necessary.

SafetyandInstructionalDecals

Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamaged

decals.

Manufacturer’sMark

1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.

94-8072

3

104-7402

104-7953

1.Warning—readtheOperator’sManualforinformationonchargingthebattery;containslead;donotdiscard.

2.ReadtheOperator’sManual.

108-4791

108-8117

104-7403

4

1.Engine—stop3.Engine—start

2.Engine—run

112-8759

1.Warning—readthe

Operator’sManual.

2.Thrownobject
hazard—keepbystanders
asafedistancefromthe
machine.

3.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—removethe
wirefromthesparkplug,
andreadtheinstructions
beforeservicingor
performingmaintenance.

4.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—stayaway
frommovingparts.

5.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—donot
operateupanddown
slopes;operatesideto
sideonslopes;stopthe
enginebeforeleavingthe
operatingposition;and
lookbehindyouwhen
backing.

108-9751

112-8867

1.Lock2.Unlock

5

Setup

Important:Removeanddiscardtheprotective

plasticsheetthatcoverstheengine.

1.InstallingtheBladeControl
Bar

Procedure

Installthebladecontrolbarintotheupperhandle

Figure3).

(

Figure3

2.UnfoldingtheHandle

Figure4

2.Tightenthehandleknobs(Figure5).

Figure5

3.Rotatethehandlerearward(asshown)untilitclicks
intoplace(Figure6).

Procedure

Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.

•Donotdamagethecableswhenfoldingor
unfoldingthehandle.

•Ifacableisdamaged,contactanAuthorized
ServiceDealer.

1.Carefullymovetheupperhandleforwarduntilthe
handlehalvesareinlineandnesttogetherasshown
(Figure4).

Figure6

3.FillingtheEnginewithOil

Procedure

Yourmowerdoesnotcomewithoilintheengine,butit
doescomewithabottleofoil.

1.Removethedipstick(Figure7).

6

Figure8

2.Insertthefuseintothefuseholder(Figure9).

Figure7

2.Slowlypouroilintotheoillltubeuntiltheoillevel
reachestheFulllineonthedipstick(Figure7).Do
notoverll.(Max.ll:20oz.(0.59l),type:SAE
30WdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.)

3.Installthedipsticksecurely.

Important:

5 operating hour s

RefertoChangingtheEngineOil.

Change the engine oil after the r st

;changeityearlythereafter.

4.InstallingtheFuse

Procedure

Yourmowercomeswitha40-ampfusethatprotectsthe
electricstarter.

Important:Y oucannotstartthemowerwiththe
electricstarterorchargethebatteryunlessyou
installthefuse.

Figure9

Note:Yourmowercomeswithafuseintheowner’s

packetandanotherfuseinthebatterybox.

3.Installthebatterycover.

5.ChargingtheBattery

Procedure

RefertoChargingtheBatteryintheMaintenance
section.

1.Unclipbothendsofthebatterycoverandremoveit
(Figure8).

7

ProductOverview

Operation

FillingtheFuelTank

Gasolineisextremelyammableandexplosive.
Areorexplosionfromgasolinecanburnyou
andothers.

•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormower
directlyonthegroundbeforelling,notina
vehicleoronanobject.

•Fillthetankoutdoorswhentheengineis
cold.Wipeupspills.

•Donothandlegasolinewhensmokingor
aroundanopenameorsparks.

•Storegasolineinanapprovedfuelcontainer,
outofthereachofchildren.

Figure10

1.Cuttingheightlever

2.Fueltankcap

3.Recoilstarthandle9.Battery

4.Controlbarlock

5.Bladecontrolbar

6.Handle

Figure11

1.Grassbag

2.Sidedischargechute

7.Ignitionkey

8.Oilll/Dipstick

10.Washoutport

11.Sparkplug

12.Airlter

3.Batterycharger

Fillthefueltankwithfreshunleadedregulargasoline
fromamajorname-brandservicestation(

Figure12).

Note:Neverusemethanol,gasolinecontaining
methanol,orgasoholcontainingmorethan10%ethanol
becausethefuelsystemcouldbedamaged.Donotmix
oilwithgasoline.

Important:Toreducestartingproblems,add
fuelstabilizertothefuelallseason,mixingitwith
gasolinelessthan30daysold.

Figure12

8

CheckingtheEngineOilLevel

ServiceInterval:Beforeeachuseordaily

1.Removethedipstick,wipeitclean,andfullyinstall
thedipstick(Figure13).

Figure13

2.Removethedipstickandchecktheoillevel
(Figure13).IftheoillevelisbelowtheAddmarkon
thedipstick,slowlypouroilintotheoillltubeto
raisetheoilleveltotheFullmarkonthedipstick.
Donotoverll.(Max.ll:20oz.(0.59l),type:SAE
30WdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.)

3.Installthedipsticksecurely.

9

AdjustingtheCuttingHeight

Adjustingthecuttingheightmaybringyouintocontactwiththemovingblade,causingseriousinjury.

•Stoptheengineandwaitforallmovingpartstostop.

•Donotputyourngersunderthehousingwhenadjustingthecuttingheight.

Iftheenginehasbeenrunning,themuferwillbehotandcanseverelyburnyou.Keepawayfrom
thehotmufer.

Adjustthecuttingheightasdesired.Setthefrontwheelstothesameheightastherearwheels(Figure14).

Figure14

10

StartingtheEngine

1.Turntheignitionkey(Figure15)orpulltherecoil
starthandle(Figure16).

Figure17

Figure15

Figure16

2.Ifthemowerdoesnotstartin1or2pulls(orwithin
5secondsusingtheelectricstarter),presstheprimer
button1or2timesandtrystartingitagain.

Note:Youcanself-propelthemowerwiththeblade
engagedordisengaged.

StoppingtheEngine

1.TurntheignitionkeytotheOffposition.

2.Removetheignitionkeywhenyouleavethemower.

EngagingtheBlade

Whenyoustartyourengine,thebladedoesnotturn.
Youmustengagethebladetomow.

1.Pullthecontrolbarlockback(Figure18).

Note:Ifthemowerstilldoesnotstart,contactan
AuthorizedServiceDealer.

UsingtheSelf-propelDrive

Tooperatetheself-propeldrive,simplywalkwithyour
handsontheupperhandleandyourelbowsatyour
sides,andthemowerwillautomaticallykeeppacewith

Figure17).

you(

Figure18

2.Pullthebladecontrolbartothehandle(Figure19).

11

Figure19

1.Bladecontrolbar

3.Holdthebladecontrolbaragainstthehandle
(Figure20).

Figure20

DisengagingtheBlade

Releasethebladecontrolbar(Figure21).

Figure21

UsingtheGrassBag

ServiceInterval:Beforeeachuseordaily

Youcanusethegrassbagtoperformanadditionaltest
tocheckthebladebrakeclutch.

1.Installtheemptygrassbagonthemower.

2.Starttheengine.

3.Engagetheblade.

Note:Thebagshouldbegintoinate,indicating
thatthebladeisengagedandrotating.

4.Releasethebladecontrolbar.

Note:Ifthebagdoesnotimmediatelydeate,the
bladeisstillrotating.Thebladebrakeclutchmaybe
deterioratingand,ifignored,couldresultinanunsafe
operatingcondition.Havethemowerinspectedand
servicedbyanAuthorizedServiceDealer.

5.Stoptheengineandwaitforallmovingpartstostop.

NotUsingtheGrassBag

1.Movethemowerontoapavedsurfaceina
non-windyarea.

2.Setall4wheelstothe2-3/4inch(7cm)cutsetting.

3.Takeahalfsheetofnewspaperandcrumpleitinto
aballsmallenoughtogounderthemowerhousing
(about3inchesor7.6cmindiameter).

4.Placethenewspaperballabout5inches(13cm)in
frontofthemower.

5.Starttheengine.

6.Engagetheblade.

7.Releasethebladecontrolbar.

8.Immediatelypushthemoweroverthenewspaper
ball.

9.Stoptheengineandwaitforallmovingpartstostop.

10.Gotothefrontofthemowerandcheckthe
newspaperball.

Important:Whenyoureleasethebladecontrol
bar,thebladeshouldstopwithin3seconds.If
itdoesnotstopproperly,stopusingyourmower
immediatelyandcontactanAuthorizedService
Dealer.

CheckingtheBladeBrake
ClutchOperation

Checkthecontrolbarbeforeeachusetoensurethatthe
bladebrakeclutchsystemisoperatingproperly.

Note:Ifthenewspaperballdidnotgounderthe
mower,repeatsteps4through10.

11.Ifthenewspaperisunravelledorshredded,the
bladedidnotstopproperly,whichcouldresultinan
unsafeoperatingcondition.ContactanAuthorized
ServiceDealer.

RecyclingtheClippings

Yourmowercomesfromthefactoryreadytorecyclethe
grassandleafclippingsbackintothelawn.

Ifthegrassbagisonthemower,removeit(referto
RemovingtheGrassBag)beforerecyclingtheclippings.

12

Ifthesidedischargechuteisonthemower,removeit
andlockthesidedischargedoor(refertoRemovingthe
SideDischargeChute)beforerecyclingtheclippings.

BaggingtheClippings

Usethegrassbagwhenyouwanttocollectgrassand
leafclippingsfromthelawn.

Aworngrassbagcouldallowsmallstones
andothersimilardebristobethrowninthe
operator’sorbystander’sdirectionandresultin
seriouspersonalinjuryordeathtotheoperator
orbystanders.

Checkthegrassbagfrequently.Ifitis
damaged,installanewTororeplacementbag.

Ifthesidedischargechuteisonthemower,removeit
andlockthesidedischargedoor(refertoRemovingthe
SideDischargeChute)beforebaggingtheclippings.

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Stoptheengineandwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.

InstallingtheGrassBag

1.Raiseandholdupthereardoor(Figure22).

Figure23

3.Lowerthereardoor.

RemovingtheGrassBag

Toremovethebag,reversethestepsabove.

Figure22

2.Installthegrassbag(Figure23).

13

Side-dischargingtheClippings

Usethesidedischargeforcuttingverytallgrass.

Ifthebagisonthemower,removeitbefore
side-dischargingtheclippings.

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Stoptheengineandwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.

InstallingtheSideDischargeChute

1.Unlockthesidedischargedoor(Figure24).

Figure24

2.Installthesidedischargechute(Figure25).

Figure25

RemovingtheSideDischargeChute

Toremovethesidedischargechute,reversethesteps
above.

Important:Lockthesidedischargedoorafteryou
closeit(Figure26).

14

Figure26

•Beawareofapotentialrehazardinverydry
conditions,followalllocalrewarnings,andkeep
themowerfreeofdrygrassandleafdebris.

•Alternatethemowingdirection.Thishelpsdisperse
theclippingsoverthelawnforevenfertilization.

•Ifthenishedlawnappearanceisunsatisfactory,try
oneormoreofthefollowing:

–Replacethebladeorhaveitsharpened.

–Walkataslowerpacewhilemowing.

–Raisethecuttingheightonyourmower.

–Cutthegrassmorefrequently.

OperatingTips

GeneralMowingTips

•Cleartheareaofsticks,stones,wire,branches,and
otherdebristhatthebladecouldhit.

•Avoidstrikingsolidobjectswiththeblade.Never
deliberatelymowoveranyobject.

•Ifthemowerstrikesanobjectorstartstovibrate,
immediatelystoptheengine,disconnectthewire
fromthesparkplug,andexaminethemowerfor
damage.

•Forbestperformance,installanewbladebeforethe
cuttingseasonbegins.

•ReplacethebladewhennecessarywithaToro
replacementblade.

CuttingGrass

•Cutonlyaboutathirdofthegrassbladeatatime.
Donotcutbelowthe2-inch(51mm)settingunless
thegrassissparseoritislatefallwhengrassgrowth
beginstoslowdown.RefertoAdjustingtheCutting
Height.

•Whencuttinggrassover6inches(15cm)tall,mow
atthehighestcuttingheightsettingandwalkslower;
thenmowagainatalowersettingforthebestlawn
appearance.Ifthegrassistoolong,themowermay
plugandcausetheenginetostall.

•Mowonlydrygrassorleaves.Wetgrassandleaves
tendtoclumpontheyardandcancausethemower
toplugortheenginetostall.

–Overlapcuttingswathsinsteadofcuttingafull

swathwitheachpass.

–Setthecuttingheightonthefrontwheelsone

notchlowerthantherearwheels.Forexample,
setthefrontwheelsat2inches(51mm)andthe
rearwheelsat2-3/8inches(60mm).

CuttingLeaves

•Aftercuttingthelawn,ensurethathalfofthelawn
showsthroughthecutleafcover.Youmayneedto
makemorethanonepassovertheleaves.

•Iftherearemorethan5inches(13cm)ofleaves
onthelawn,setthefrontcuttingheightoneortwo
notcheshigherthantherearcuttingheight.

•Slowdownyourmowingspeedifthemowerdoes
notcuttheleavesnelyenough.

Wetgrassorleavescancauseseriousinjuryif
youslipandcontacttheblade.Mowonlyindry
conditions.

15

Maintenance

Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.

RecommendedMaintenanceSchedule(s)

MaintenanceService

Interval

Aftertherst5hours

Beforeeachuseordaily

Every25hours

Beforestorage

Yearly

Important:Refertoyour

MaintenanceProcedure

•Changetheengineoil.

•Checktheengineoillevel.

•Checkthebladebrakeclutchoperation.

•Cleangrassclippingsanddirtfromunderthemower.

•Replacetheairlter;replaceitmorefrequentlyindustyoperatingconditions.

•Chargethebatteryfor24hours.

•Emptythefueltankbeforerepairsasdirectedandbeforeannualstorage.

•Changetheengineoil.

•Lubricatethewheelgears.

•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).

•RefertoyourEngineOperator’sManualforanyadditionalyearlymaintenance
procedures.

Engine Operator’ s Man ual

PreparingforMaintenance

1.Stoptheengineandwaitforallmovingpartstostop.

2.Disconnectthesparkplugwirefromthesparkplug
andhookitontotheretainingpost(Figure27)
beforeperforminganymaintenanceprocedure.

foradditionalmaintenanceprocedures.

handfuelpumptoremovethefuel.Alwaystip
themowerontoitsside,withtheairlterup.

Tippingthemowermaycausethefueltoleak.
Gasolineisammable,explosiveandcancause
personalinjury.

Figure27

3.Afterperformingthemaintenanceprocedure(s),
connectthesparkplugwiretothesparkplug.

Important:Beforetippingthemowertochange
theoilorreplacetheblade,allowthefueltank
torundrythroughnormalusage.Ifyoumust
tipthemowerpriortorunningoutoffuel,usea

Runtheenginedryorremovethegasolinewith
ahandpump;neversiphon.

ReplacingtheAirFilter

ServiceInterval:Every25hours

Replacetheairlteryearly;replaceitmorefrequently
industyoperatingconditions.RefertoPreparingfor
Maintenance.

1.Useascrewdrivertoopentheairltercover
(Figure28).

16

Figure28

2.Replacetheairlter(Figure29).

Figure29

3.Installthecover.

ChangingtheEngineOil

ServiceInterval:Aftertherst5hours

Yearly

Figure30

3.Tipthemowerontoitssidewiththeairlterup
todraintheusedoiloutthroughtheoillltube
(Figure31).

Changetheengineoilaftertherst5operating
hours;changeityearlythereafter.

Runtheengineafewminutesbeforechangingtheoil
towarmit.Warmoilowsbetterandcarriesmore
contaminants.

1.RefertoPreparingforMaintenance.

2.Removethedipstick(

Figure30).

Figure31

4.Slowlypouroilintotheoillltubeuntiltheoillevel
reachestheFulllineonthedipstick(Figure30).Do
notoverll.(Max.ll:20oz.(0.59l),type:SAE
30WdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.)

5.Installthedipsticksecurely.

6.Disposeoftheusedoilproperlyatalocalrecycling
center.

17

ChargingtheBattery

ServiceInterval:Every25hours

Warning

CALIFORNIA

Proposition65Warning

Batteryposts,terminals,andrelated

accessoriescontainleadandleadcompounds,

chemicalsknowntotheStateofCalifornia

tocausecancerandreproductiveharm.

Washhandsafterhandling .

Figure33

Chargethebatteryfor24hoursinitially,thenmonthly
(every25starts)orasneeded.Alwaysusethecharger
inashelteredareaandchargethebatteryatroom
temperature(70°or22°C)wheneverpossible.

1.Connectthechargertothemowerwireharness
locatedbelowtheignitionkey(

Figure32

2.Plugthechargerintoawalloutlet.

Note:Whenthebatterynolongerholdsacharge,
recycleordisposeofthelead-acidbatteryaccording
tolocalcodes.

Figure32).

3.Installtherearwheels.

ReplacingtheBlade

ServiceInterval:Yearly

Important:

the blade pr oper l y

wrenchorareuncomfortableperformingthis
procedure,contactanAuthorizedServiceDealer.

Examinethebladewheneveryourunoutofgasoline.If
thebladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpenedor
replaceit.

Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.

Weargloveswhenservicingtheblade.

Y ou will need a torque wr ench to install

.Ifyoudonothaveatorque

ReplacingtheFuse

Ifthebatterydoesnotchargeortheenginedoesnotrun
withtheelectricstarter,thefusemaybeblown.Replace
itwitha40-ampplug-intypefuse.RefertoInstalling
theFuse.

LubricatingtheWheelGears

ServiceInterval:Yearly

1.Removethewheelboltsontherearwheelsand
removetherearwheels.

2.Applyalubricatingoiltotheinnerandoutersides
ofthegearasshowninFigure33.

1.Disconnectthesparkplugwirefromthesparkplug.
RefertoPreparingforMaintenance.

2.Tipthemowerontoitssidewiththeairlterup.

3.Removethe2bladenutsandthestiffener(Figure34).

18

Figure34

1.Bladenuts

2.Stiffener

4.Removetheblade(Figure34).

5.Installthenewblade(Figure34).

6.Installthestiffeneryoupreviouslyremoved.

7.Installthebladenutsandtorquethemto15to

27ft-lb(20to37N⋅ ⋅⋅m).

7.Brushorblowoutdebrisfromtheinsideofthe
shieldandaroundalltheparts.

8.Installthebladebrakeclutchshieldthatyou
previouslyremoved.

9.Installthebladedriverthatyoupreviouslyremoved.

10.Installthebladeandthestiffenerthatyoupreviously
removed(Figure35).

11.Installthebladenutsandtorquethemto15to

27ft-lb(20to37N⋅ ⋅⋅m).

AdjustingtheSelf-propelDrive
Cable

Wheneveryouinstallanewself-propelcableorif
theself-propeldriveisoutofadjustment,adjustthe
self-propeldrivecable.

1.Loosenthecablesupportnut(

Figure36).

CleaningtheBladeBrake
ClutchShield

Cleanthebladebrakeclutchshieldyearlytopreventthe
bladefromstallingwhileyoumow .

1.Disconnectthesparkplugwirefromthesparkplug.
RefertoPreparingforMaintenanceonpage18.

2.Tipthemowerontoitssidewiththeairlterup.

3.Removethe2bladenutsandthestiffener(Figure35).

Figure36

2.Pulldownthecablejacket(towardthemower)until
thereisnoslackinthecable(Figure37).

Figure35

1.Bladenuts4.Bladedriver

2.Stiffener

3.Blade6.Bladebrakeclutchshield

5.Disk

4.Removetheblade(Figure35).

5.Removethebladedriveranddisk(Figure35).

6.Removethebladebrakeclutchshield(Figure35).

Figure37

3.Tightenthenutonthecablesupport.

19

CleaningtheMower

ServiceInterval:Beforeeachuseordaily

Themowermaydislodgematerialfromunder
themowerhousing.

•Weareyeprotection.

•Stayintheoperatingposition(behindthe
handle)whentheengineisrunning.

Storage

Storethemowerinacool,clean,dryplace.

PreparingtheMowerfor
Storage

Gasolinevaporscanexplode.

•Donotallowbystandersinthearea.

Forbestresults,cleanthemowersoonafteryouhave
completedmowing.

1.Lowerthemowertoitslowestcuttingheightsetting.
RefertoAdjustingtheCuttingHeight.

2.Movethemowerontoaatpavedsurface.

3.Attachagardenhosethatisconnectedtoawater
supplytothewashoutportonthemowerhousing

Figure38).

(

•Donotstoregasolinemorethan30days.

•Donotstorethemowerinanenclosurenear
anopename.

•Allowtheenginetocoolbeforestoringit.

1.Onthelastrefuelingoftheyear,addfuelstabilizer
tothefuelasdirectedbytheenginemanufacturer.

2.Disposeofanyunusedfuelproperly.Recycleit
accordingtolocalcodes,oruseitinyourautomobile.

Note:Oldfuelinthefueltankistheleadingcause
ofhardstarting.Donotstorefuelwithoutstabilizer
morethan30days,anddonotstorestabilizedfuel
morethan90days.

3.Runthemoweruntiltheenginestopsfromrunning
outoffuel.

4.Primetheengineandstartitagain.

5.Allowtheenginetorununtilitstops.Whenyoucan
nolongerstarttheengine,itissufcientlydry.

6.Disconnectthewirefromthesparkplugandconnect
thewireontotheretainingpost.

Figure38

4.Turnthewateron.

5.Starttheengineandrunituntiltherearenomore
clippingsthatcomeoutfromunderthemower
housing.

6.Stoptheengine.

7.Shutoffthewateranddisconnectthegardenhose
fromthemower.

8.Starttheengineandrunitforafewminutestodry
thehousingtopreventitfromrusting.

7.Removethesparkplug,add1oz.(30ml)ofoil
throughthesparkplughole,andpullthestarterrope
slowlyseveraltimestodistributeoilthroughoutthe
cylindertopreventcylindercorrosionduringthe
off-season.

8.Looselyinstallthesparkplug.

9.Tightenallnuts,bolts,andscrews.

10.Chargethebatteryfor24hours,thenunplugthe
batterychargeranstorethemowerinanunheated
area.Ifyoumuststorethemowerinaheatedarea,
youmustchargethebatteryevery90days.

20

FoldingtheHandle

Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.

•Donotdamagethecableswhenfoldingor
unfoldingthehandle.

•Ifacableisdamaged,contactanAuthorized
ServiceDealer.

1.Removetheignitionkey .

2.Loosenthehandleknobsuntilyoucanmovethe
upperhandlefreely.

3.FoldtheupperhandleforwardasshowninFigure39.

Important:Routethecablestotheoutsideof
thehandleknobsasyoufoldtheupperhandle.

Figure39

4.Tounfoldthehandle,reversethestepsabove.

RemovingtheMowerfrom
Storage

1.Removethesparkplugandspintheenginerapidly
usingthestartertoblowtheexcessoilfromthe
cylinder.

2.Installthesparkplugandtightenitwithatorque
wrenchto15ft-lb(20N⋅m).

3.Chargethebatteryfor24hours.

4.Connectthewiretothesparkplug.

21

Notes:

22

Notes:

23

22in Recycler®
Walk Power Mowers

The Toro Total Coverage Guarantee

A Two -Year Full Warranty (Limited for Commercial Use)

and

The Toro Starting Guarantee on GTS-2 (Guaranteed to Start) Engines

A Two -Year Full Warranty (Not applicable for Commercial Use)

Conditions and Products Covered under The Toro Total Coverage Guarantee

The Toro Company and its affiliate, Toro Warranty Company, pursuant to an agreement between them, jointly promise to repair any Toro Product, when used for residential purposes*, if defective in
materials or workmanship or if it stops functi oni ng du e to the failure of a component. The following time periods apply from the date of original purchase:

Products

• All Products and attachments

• Batteries

Warranty Period

• 2 year full warranty

• 1 year full warranty

Limited Warranty for Commercial Use

Toro Products used for commercial, institutional, or rental use are warranted against defects in materials or workmanship for the following time periods from the original date of purchase:

All Products and attachm e nts

This warranty covers the cost of parts and labor, but you must pa y transportation costs. This warranty applies to all Toro Recycler walk power mowers and their attachments.

Products

Warranty Period

45 day limited warranty

Conditions and Products Covered Under the Toro Starting Guarantee

The Toro Company and its affiliate, Toro Warranty Company, pursuant to an agreement between them, jointly guarantee that your Toro GTS-2 Engine, when used for residential purp oses*, will start
on the first or second pull for two years from the date of original purchase, if you provide the routine maintenance it requires, or we will fix it free of charge.

This warranty covers the cost of parts and labor, but you must pa y transportation costs. This warranty applies to all Toro Recycler walk power mowers.
The Toro Starting Guarantee does not apply when the product is used commercially. Use at more than one location is considered commercial use.

The following applies to both the Toro Total Coverage Guarantee & the Toro Starting Guarantee:

Items and Conditions Not Covered

There is no other express warranty except for special emission sy stem coverage on some products. This express warranty does not cover the following:

• Cost of regular maintenance service or parts, such as fil ters, fuel, lubricants, oil changes, air filter, blade sharpening/worn blade on mowers, cable/linkage adjustments, or brake and clutch

adjustments

• Any product or part which has been altered or misused and requires replacement or repair due to accidents or lack of proper maintenance

• Repairs necessary due to improper battery care, electrical supply irregularities, failure to use fresh fuel (less than one month old), or failure to properly prepare the unit prior to any period of

non-use over one month

• Pickup and delivery charges

• Operational misuse, neglect, or accidents

• Repairs or attempted repairs by anyone other than an A uthorized Toro Service Dealer

• Repairs or adjustments to correct starting difficulties due to the following:

- Failure to follow proper maintenance procedures

- Rotary mower blade striking an object

- Contaminants in the fuel system

- Improper fuel (consult your Operator’s Manual if in doubt)

- Failure to drain the fuel system prior to any period of non-use over o ne month

• Special operational conditions where starting may require more than two pulls:

- First time starts after extended period of non-use over one month or seasonal storage

- Cool temperature starts such as those found in early spring and late autumn (applies to rotary mowers only)

If you are having difficulty starting your unit, please check the Operator’s Manual to ensure that you are using the correct starting procedures. This can save an unnecessary visit to a Service Dealer.

You must maintain your Toro Product by following the maintenance procedures described in the Operator’s Manual. Such routine maintenance, whether performed by a dealer or by you, is at your
expense.

If you think that your Toro Product contains a defect in materials or workmanship, or if a normal, able-bodied adult can no longer start your product’s engine in one or two pulls, follow this procedure:

1. Contact any Authorized Toro Service Dealer to arrange service at their dealership. To locate a dealer convenient to you, refer to the Yellow Pages of your telephone directory (look under “Lawn

2. Bring the product and your proof of purchase (sales receipt) to the Service Dealer. The dealer will diagnose the problem and determine if it is to be covered under warranty.

3. If for any reason you are dissatisfied with the Service Dealer’s analysis or with the assistance provided, contact us at: Customer Care Department -Consumer, Toro Warranty Company, 8111

All repairs covered by these warranties must be performed by an Authorized Toro Service Dealer using Toro approved replacement parts.

Neither The Toro Company nor Toro Warranty Company is liable for indirect, incidental, or consequential damages in connection with the use of the Toro Products covered by these
warranties, including any cost or expen se of providing substitute equipment or service during reasonable periods of malfunction or non-use pending completion of repairs under these
warranties.

Some states do not allow exclusions of incidental or consequential damages, so the above exclusions and limitations may not apply to you. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.

Customers who have purchased Toro products exported from the United States or Canada should contact their Toro Distributor (Dealer) to obtain guarantee policies for your country, province, or state. If
for any reason you are dissatisfied with your Distributor’s service or have difficulty obtaining guarantee information, contact the Toro impor ter. If all other remedies fail, you may contact us at Toro
Warranty Company.

- Improper starting procedures

Owner Responsibilities

Instructions for Obtaining Warranty Service

Mowers”) or access our website at www.Toro.com. U.S. Customers may also call the number listed in item #3 to use our 24-hour Toro dealer locator system.

Lyndale Avenue South, Bloomington, MN 55420-1196; or call us toll free at 1-866-214-9807 (U.S. customers) or 1-866-214-9808 (Canada customers).

General Conditions

Countries Other than the United States or Canada

* Residential purposes means use of the product on the same lot as your home. Use at more than one location is considered commercial use, and the commercial use warranty would apply.

374-0052 Rev B
