Toro 130-6850 Installation Instructions

FormNo.3383-520RevA

ROPSConversionKit

TITAN

ModelNo.130-6850

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

®

Zero-Turn-RadiusRidingMower

WARNING

CALIFORNIA

Proposition65Warning

causecancer,birthdefects,orreproductiveharm.

InstallationInstructions

Installation

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

Description

Pivotbracket4
Rubberbumper2
Spacer
Roundspacer2
Pinassembly2
Nut(5/16inch)

InstallingtheROPSParts

1.RemovetheexistingsidebracketsontheROPS.Save
thenutsandboltsforinstallingthenewbrackets.

2.Installtherubberbumperstothelowerpartofthe
ROPSwith2nuts(5/16inch)(Figure1).

3.Installthepivotbracketsandspacerstotheupperpart
oftheROPSwiththepreviouslyremovednutsand

Figure1).

bolts(

4.InstalltheupperpartoftheROPS,roundspacer,and
pinassemblytothelowerpartoftheROPSwiththe
previouslyremovednutsandbolts(Figure1).

Qty.

Use

4

2

InstalltheROPSParts

5.Torqueallnutsandboltsto40.7to49.7N-m(360to
440in-lb).

©2014—TheT oro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420

Registeratwww.T oro.com.

OriginalInstructions(EN)

PrintedintheUSA.

AllRightsReserved

*3383-520*A

Figure1

1.UpperpartoftheROPS

2.Rubberbumper6.Bolt

3.Spacer

4.Pivotbracket8.Pinassembly

5.Washer

7.Roundspacer

9.LowerpartoftheROPS

10.Nut(5/16inch)

2

Operation

G015034

G015035

1

2

3

2

UsingtheRolloverProtection System(ROPS)

WARNING

Toavoidinjuryordeathfromrollover:keepthe
rollbarintheraisedlockedpositionandusethe
seatbelt.

3.Installthelockingpins.Securethepinsbyinstallingthe
haircotterpin(Figure3).

Figure3

WARNING

Thereisnorolloverprotectionwhentherollbaris
inthedownposition.

•Lowertherollbaronlywhenabsolutely
necessary.

•Donotweartheseatbeltwhentherollbaris
inthedownposition.

•Driveslowlyandcarefully.

•Raisetherollbarassoonasclearancepermits.

•Checkcarefullyforoverheadclearances(i.e.
branches,doorways,electricalwires)before
drivingunderanyobjectsanddonotcontact
them.

Important:Lowertherollbaronlywhenabsolutely
necessary.

1.Toraisetherollbar,removethehaircotterpinand
removethelockingpins.

2.Raisetherollbartotheuprightposition(

Figure2).

1.HoleinROPS

2.Lockingpin

4.Tolowertherollbar,removethehaircotterpinand
removethelockingpin(Figure3).

5.Lowertherollbartothedownposition.

6.Usethe2lockingandcotterpinstosecurethebar.

3.Hairpincotter

Figure2

Important:Alwaysusetheseatbeltwiththeroll

barintheraisedposition.

3
