Operations & Maintenance Manual
https://harrissupplyind.com - To Order Parts Call 608-268-8080
For Commercial Use Only
TORNADO INDUSTRIES, LLC
3101 WICHITA COURT
FORT WORTH, TX 76140
PHONE: 800-VACUUMS
FAX: 817-551-0719
WWW.TORNADOVAC.COM
MODEL NO: 97130 (115V) & 97131 (230V)
Form No. L7130AB 01/17 ©Tornado Industries, LLC. All rights reserved
8 lb. Lightweight Vacuum
1
Long Term Buyer Protection Limited Warranty
https://harrissupplyind.com - To Order Parts Call 608-268-8080
Tornado Industries, LLC. (Tornado) warrants to the end/user customer that the Tornado product(s) will
be free from defects in material and workmanship for the duration(s) described below. This limited
warranty DOES NOT cover machines and/or components subject to normal wear and tear, damage
that occurs in shipping, failures resulting from modication, accident, unsuitable operating environment, misuse, abuse, neglect, or improper maintenance by you. For full details, contact your Authorized Tornado Distributor, Service Center, or the Tornado Technical Service Department. Tornado
sales and service representatives are not authorized to waive or alter the terms of this warranty, or to
increase the obligations of Tornado under the warranty.
10 Years*
Plastic water tanks and Rotationally-molded bodies
2 Years*
Parts on all Tornado cleaning equipment
1 Year*
Labor on all Tornado cleaning equipment
1 Year*
Warranty on batteries, one year prorated
All battery warranties are handled directly by the battery manufacturer, on a one year prorated basis
Terms subject to change without notice
1. Except all Windshears™ Blowers, Storm, TV2SS, Side and Downdraft, Insulation Blowers, CV 30,
CV 38, CK14/1 PRO, CK 14/2 PRO, SWM 31/9, CK LW13/1, CK LW 13/1 ROAM, CV 38/48 Dual,
PV6, PV10, PV6 ROAM, Wall Mount Vacuum and all chargers are warranted for 1 (one) year for both
parts and labor.
2. All non-wear item parts purchased after warranty expiration are warranted for 90 days.
3. Warranty starts from the date of sale to the consumer or, at Tornado’s discretion, 6 months after
the dealer purchased the unit from Tornado, whichever comes rst.
4. The EB 30 is warranted for a period of 90 days for both parts and labor.
5. The warranty on engines used on propane powered equipment is limited to motor manufacturer’s
warranty.
6. Ride-on Scrubbers are warranted for 24 months, parts, 6 months labor or 1,000 hours, whichever
occurs rst.
Note: Tornado, The Latest Dirt, Floorkeeper,
Carpetkeeper, Carpetrinser, Carpetrinser/Dryer,
Headmaster, Taskforce, PAC-VAC, T-Lite, Glazer,
Windshear, Max-Vac and Trot-Mop are trademarks
of Tornado Industries
Website: www.tornadovac.com
Phone 1-800-VACUUMS
Fax 817-551-0719
Address 3101 Wichita Court
Fort Worth, TX 76140
1-800-VACUUMS 90 Years of Cleaning Innovation A Tacony Company
Form F2662.©2017. All rights reserved
NOTES
https://harrissupplyind.com - To Order Parts Call 608-268-8080
Write your machine serial number here:________________________________
This instruction book covers:
MODEL NO. 97130 97131
VOLTS 115 230
SERIES LW 13/1 LW 13/1
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
3
Your new Tornado unit is a high quality, precision-made product. All parts used in the manufacturing of this unit
https://harrissupplyind.com - To Order Parts Call 608-268-8080
have passed rigid quality control standards prior to assembly. Please safeguard the original receipt / invoice. If
you experience any problems with your unit during the warranty period, the original receipt / invoice will act as
proof of purchase. Contact Tornado for any warranty inquiries.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of
least resistance for electric current to reduce the risk electric shock. This machine is equipped with a
cord having an equipment -grounding conductor and grounding plug. The plug must be inserted into
an appropriate outlet that is properly installed and grounded in accordance with all local codes and
ordinances.
WARNING: Improper connection of the equipment-grounding conductor can result in a risk of electric
shock. Check with a qualied electrician or service person if you are in doubt as to whether the outlet
is properly grounded. Do not modify the plug provided with the appliance - if it will not t the outlet,
have a proper outlet installed by a qualied electrician.
This appliance is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the
plug illustrated in sketch A.
4
IMPORTANT SAFETY INSTRUCTIONS
https://harrissupplyind.com - To Order Parts Call 608-268-8080
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS UNIT
Read and understand this owner’s manual and all labels on the unit before operating. Safety is a
combination of common sense,staying alert and knowing how your unit works. Use this unit only as
described in this manual. Use only manufacturer’s recommended attachments. To reduce the risk of
personal injury or damage to your unit use only Tornado recommended accessories.
This machine is intended for commercial use only. It is designed exclusively to pick up dirt, dry debris
and dust in an indoor environment and is not constructed for any other use. The pick up of any type of
uid or dangerous / toxic materials is prohibited. Use only recommended accessories.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
When using an electrical appliance, basic precautions should always be followed, including the following:
SAVE THESE INSTRUCTIONS.
• WARNING! To reduce the risk of re, electric shock, or injury:
• Do not leave appliance unattended when plugged in. Unplug from outlet when not in use and before servicing.
• WARNING: ELECTRIC SHOCK COULD OCCUR IF USED OUTDOORS OR ON WET SURFACES.
• Do not allow to be used as a toy. Close attention is necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return it to a service center.
• Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around sharp
edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Turn off all controls before unplugging.
• Do not put any object into openings. Do not use with any opening blocked, keep free of dust, lint,
hair, and anything that may reduce air ow.
• Keep hair, loose clothing, ngers and all parts of body away from openings and moving parts.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
• Do not use without vacuum bag and / or lters in place.
• Use extra care when cleaning stairs.
• Do not use to pick up ammable or combustible liquids such as gasoline or use in areas where
they may be present.
• Do not attempt to service the unit while appliance is plugged in.
• For grounded models, connect to a properly grounded outlet only. See Grounding Instructions.
• This machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the machine by a person responsible for their safety.
• Keep children and unauthorized persons away from the machine when in use.
5
PRODUCT FEATURES AND BENEFITS
https://harrissupplyind.com - To Order Parts Call 608-268-8080
The Dual Suction System is a lightweight, yet powerful, cleaning system ideal for commercial use on
all types of carpets and oors.
1. Handle – designed for comfort and easy maneuvering.
2. Power Switch – conveniently located in handle.
3. Handle Tube – lightweight, for easy movement and use.
4. Connector Tube – strong lightweight aluminum tube is designed for optimal airow.
5. Dust Tube – large diameter dust tube designed to minimize clogging.
6. Cloth Bag – durable, reinforced material for years of service.
7. Dust Bag – top loading bag for clean and easy bag change.
8. The Post-Motor Filter – helps to reduce motor emissions.
9. Motor – 6 amps of full cleaning power, saves energy.
10. Power Source Plug – grounded for safe, reliable operation.
11. Connector Plug – for enhanced safety.
12. Power Cord – 50 foot heavy-duty, commercial quality for extended reach.
13. Quick Release Cord Hooks – for quick, easy removal of power cord.
14. Powerfoot – twin fan/dual suction design for deeply embedded dirt and superior edge cleaning.
15. Rotating Cleaning Brush – continuous, rotating dual action for thorough cleaning; white, non-mar-
ring bristles.
16. Non-Marring Wheels – safe for use on bare oors.
17. Soft Furniture Protection Guard – helps protect furniture while vacuuming.
18. Hair Cutter – ensures that any long hair or other bers are cut and broken down into lengths that
are manageable for the vacuum. This helps to prevent clogs.
19. Filter Cover – easily removes with one screw for easy access to lter.
20. Dual Cord Storage – wrap cord around the back of the unit, or simply hang cord on the front Cord
Storage Hook.
21. Tube Release Buttons – allows for easy access in the unlikely event of the tube clogging.
22. Bag Tension Spring – keeps the bag secure at the base of the bag.
23. Rubber Collars – designed to seal air path at critical connections, preventing loss of airow.
24. Top Cover – simply removes with 3 screws allowing for easy belt change.
25. Drive Belt – designed for optimal life and performance.
6
https://harrissupplyind.com - To Order Parts Call 608-268-8080
7
WARNING: Plastic bags or lm can be dangerous. To avoid danger of suf-
https://harrissupplyind.com - To Order Parts Call 608-268-8080
focation, keep away from babies and children.
The dual Suction System is packaged for convenience and requires minimal assembly.
The only tool you will need is a Phillips head screwdriver.
1. Slide the handle Tube into the Connector, aligning the hole in the Handle
Tube with the molded hole at the top of the Connector.
2. Hold the hex nut in front of the Connector in the hex shaped cavity while
inserting the screw with your nger from the back. Tighten the screw while
placing your nger over the hex cavity to hold the hex nut in place. After a
few turns, tighten further with a Phillips head screwdriver. Do not overtighten.
3. Slide screw through plastic Cord Hook from the inside of Cloth Bag. Align
screw with hole in Handle Tube. Tighten screw.
4. Remove screw from Filter Cover. Remove Filter Cover. Insert the Con-
nector Plug into the back of the unit at the rear of the Powerfoot – Make
sure the Connector Plug is fully inserted. Replace Filter Cover. Replace
Filter Cover Screw.
Your Vacuum cleaner is now ready to use.
Tip. Before cleaning under low furniture, always check area rst for objects
that might harm the Rotating Cleaning Brush or get caught in the Dust Tube.
Power Supply
The Power Cord is stored at the back of the vacuum cleaner, and is looped
around the Quick Release Cord Hooks. The polarized Power Source Plug
is designed to attach to the Power Cord during storage. Before using, make
sure the Connector Plug is securely attached to the Powerfoot and that the
Power Source Plug is plugged into a polarized outlet.
Power Switch
The Power Switch is located in the Handle of the cleaner. Push down (I) to
turn ON. Push up (O ) to turn OFF.
Power Cord Storage
When you are nished using your vacuum, return it to the upright position.
Make sure the vacuum is turned OFF. Always unplug the vacuum by grasping the Power Source Plug (NOT the Power Cord) and disconnecting from
the outlet. Properly store the Power Cord by winding the cord around the
Quick Release Cord Hooks on the back of the vacuum in a continuous loop,
or by hanging the cord on the Cord Storage Hook located on the front of the
vacuum. Attach the Power Source Plug to the Power Cord.
Operation
This vacuum, with Dual Suction System is designed to effectively and safely
clean all types of carpeting, wood, linoleum, and vinyl oors. Its wide 14-inch
Powerfoot makes cleaning quick and easy.
To place the vacuum in position for use, lightly press your foot on the Powerfoot and tip the Handle backwards.
8
Routine Maintenance
https://harrissupplyind.com - To Order Parts Call 608-268-8080
For maximum performance from your vacuum, check and
maintain vacuum parts regularly.
Replacing the Dust Bag
Check the Dust Bag weekly. Replace the Dust Bag when it is
near full or when cleaning suction diminishes. Never reuse a
Dust Bag.
WARNING: To avoid electrical shock or injury from moving parts, always turn OFF the Power Switch and unplug the
Power Source Plug before performing maintenance
or trouble shooting. Always unplug by grasping the Power
Source Plug; NEVER pulling on the Power Cord to unplug.
Tip: Vacuuming new carpet or vacuuming ne powders may
clog the Dust Bag. Check Dust bag often.
Unplug vacuum by grasping and pulling on the Power Source
Plug.
Unzip Cloth Bag. Remove collar retainer by pressing on the
two tabs and pulling the top towards you. Dispose of Dust Bag.
Slide collar of new Dust Bag completely into collar retainer.
Push collar retainer back into position and secure in place.
Tuck the remainder of the Dust Bag completely inside the
Cloth Bag. Make sure it lays at, top to bottom, without bunching. Zip Cloth Bag.
Cleaning the Dust Tube
The vacuum features Dust Tube designed to optimize cleaning
power. For best performance, routinely check and clear excess
dust and other debris.
Note: Cover oor with newspaper to catch any loose material
or dust removed during cleaning.
Release Bag Tension Spring.
Remove Filter Cover screw and then remove Filter Cover.
Unplug Connector Plug.
Locate the Tube Release Button at the top of the Powerfoot.
The Tube Release
Button is hidden under a Rubber Collar on the side of the Dust
Tube and can be pressed through the Rubber Collar. Lift off
the Dust Tube while pressing on the Tube Release Button.
Use a wire brush to clean out the inside of the Dust Tube and
the top section of the Powerfoot where they connect.
Reconnect the tube with the Powerfoot. It should snap into
place. Make sure that the tube release button on the Tube
lines up with the Tube Release Button on the Rubber Collar.
Plug the Connector Plug back into base of vacuum.
WARNING: To avoid electrical shock or injury from moving parts, always turn OFF the Power Switch and unplug the
Power Source Plug before performing maintenance
or trouble shooting. Always unplug by grasping the Power
Source Plug; NEVER pulling on the Power Cord to unplug.
9
Cleaning the Filter
https://harrissupplyind.com - To Order Parts Call 608-268-8080
The post-motor HEPA lter is located in the Powerfoot of your vacuum cleaner. It should be checked often, and cleaned when the post-motor HEPA lter
becomes dirty.
1. To clean post-motor HEPA lter, remove the screw with a Phillips head
screwdriver.
2. Lift out lter cover.
3. Remove post-motor HEPA lter and blow out with air.
4. Reinstall post-motor HEPA lter.
5. Replace lter cover by sliding in the two tabs at the top of the lter cover
and centering over the screw hole.
6. Replace screw.
Cleaning the Rotating Cleaning
Brush/Replacing the Drive Belt
Check the Rotating Cleaning Brush and Drive Belt regularly for wear or damage. Keep the Rotating Cleaning Brush ends free of string, hair, and carpet
bers. These can become entangled and reduce the vacuum’s cleaning effectiveness.
NOTE: The Rotating Cleaning Brush can most often be cleaned without
removal from the vacuum. If there is an excessive amount of hair and debris,
remove the Rotating Cleaning Brush for proper cleaning.
1. Unplug the vacuum and turn face down on a at surface.
2. Remove all 3 screws from the bottom of the Powerfoot.
3. Grip both the Top Cover and base while turning unit back over. Lift off Top
Cover.
4. Check Drive Belt. If it is broken or damaged, remove Rotating Cleaning
Brush and replace Drive Belt.
WARNING: To avoid electrical shock or injury from moving parts, always turn
OFF the Power Switch and unplug the Power Source Plug before performing maintenance or trouble shooting. Always unplug by grasping the Power
Source Plug; NEVER pulling on the Power Cord to unplug.
5. To remove the Rotating Cleaning Brush, pull the right side of the Rotating
Cleaning Brush toward the front of the Powerfoot as you lift slowly.
6. Clean off Rotating Cleaning Brush as necessary.
7. Place existing or new Drive Belt over Rotating Cleaning Brush and the
motor shaft. Insert the end cap pin on the left of the Rotating Cleaning Brush
into the slot on the Powerfoot and slide the end cap pin on the right end of
the Rotating Cleaning Brush in to the slot in the Powerfoot and lower until it
clicks into place.
8. Make sure the Furniture Protection Guard is still intact.
9. Align the 3 tabs on the Top Cover with the 3 slots in the Powerfoot. Press
into place, making sure the Furniture Protection Guard is on the outside.
10. Turn vacuum cleaner face down.
11. Reinstall the 3 screws beginning with the center screw.
WARNING: To avoid electrical shock or injury from
moving parts, always turn
OFF the Power Switch
and unplug the Power
Source Plug before performing maintenance or
trouble shooting. Always
unplug by grasping the
Power Source Plug;
NEVER pulling on the
Power Cord to unplug.
10
To replace the light bulb.
https://harrissupplyind.com - To Order Parts Call 608-268-8080
1. Unplug the vacuum.
2. Insert a at tipped screwdriver into slot A and remove light lens.
3. Grasp bulb and pull out. Discard old bulb and replace with new one.
4. Replace light lens.
Troubleshooting
Vacuum cleaner won’t run.
Possible Causes Remedies
Vacuum Cleaner is not plugged in
Household fuse/circuit breaker tripped
Vacuum cleaner won’t pick up dirt.
Possible Causes Remedies
Dust Bag is full
Drive Belt not functioning
Rotating Cleaning Brush bristles worn
Rotating Cleaning Brush jammed
Dust Tube is clogged
Accumulation of dust inside Cloth Bag
Possible Cause Remedies
Dust Bag is clogged or dirty
Dust Bag collar retainer not secure
Inlet clogged
Check power Source Plug and Connector Plug
Check/replace fuse – Reset breaker
Replace with new Dust Bag
Realign Drive Belt or replace if damaged
Replace Rotating Cleaning Brush
Remove Rotating Cleaning Brush and clean debris from brush ends; Reinstall Drive Belt
Clean Dust Tube
Replace with new Dust Bag
Secure Dust Bag collar retainer
Shake dust down to bottom of Dust Bag.
11
Please provide additional information on
https://harrissupplyind.com - To Order Parts Call 608-268-8080
Warranty
Registration
Form
Tornado equipment: (Check choices below)
__ Automatic Scrubbers __Sweepers
__Propane Floor Machines __Rotary Floor Machine
__High Speed Burnishers __Carpet Vacuums
__Carpet Extractors & Spotters __Wet/Dry Vacs
__ Steam Cleaners __Jumbo Vacs
__Ride-On Equipment __Pressure Washers
See complete product info at www.tornadovac.com
Selling Dealer:(Required)__________________________
Please Print Clearly
_____________________________________________________________________________
Company/Institution
_____________________________________ ____________________________________
Contact Name Title
_____________________________________ ____________________________________
Address City/State/Zip Code
_____________________________________ ____________________________________
Phone Fax
_____________________________________ ____________________________________
Date of Purchase Email
See white metal plate or sticker on unit for this information.
MACHINE TYPE/MODEL NUMBER: MACHINE SERIAL NUMBER:
1. 1.
2. 2.
3. 3.
4. 4.
Facility Description (please circle all that apply)
1. School 9. Hospital 17. U.S. Govt.
2. Retail Store 10. Nursing Home 18. Other Govt.
3. Restaurant 11. Religious Institution 19. Auto Service
4. Ofce Building 12. Airport 20. Airport
5. Contract Cleaning 13. Warehouse 21. Non-Prot
6. Light Manufacturing 14. Apartment/Condo 22. Other (specify)
7. Heavy Manufacturing 15. Warehouse
8. College/University 16. Supermarket
How did you rst learn about
Tornado cleaning and
maintenance equipment?
Total Hard Floor Area
o Contacted by local dealer
o Previous experience with
Tornado products
o Reputation/
Recommendation
o Advertising
o Direct mail
o Internet
o Other
Damage or defect arising from abuse, neglect or other misuse is excluded from this warranty. Other items
may or may not apply based on your specic machine. If any defect occurs, the warranty is voided if service is
attempted by non-Authorized Tornado Service Centers.
©2017 Tornado Industries. All rights reserved.
X8449-TOR 1/2017
o 0-10,000 (0-930)
o 10-50,000 (930-4,650)
o 50-250,000 (4,650-23,250)
o Over 250,000 (over
23,260)
In square feet (meters)
Total Carpeted Area
Square feet (square meters)
o 0-10,000 (0-930)
o 10-50,000 (930-4,650)
o 50-250,000 (4,650-23,250)
o Over 250,000 (over
23,260)
Return to :
Tornado Industries
3101 Wichita Court
Fort Worth, TX 76140
Fax: 817-551-0719
or online at
www.tornadovac.com
Loading...
