E101B SINGLE 7/22/07 10:02 PM Page 1
MLI-203(REVA)
TABLE OF CONTENTS
Section Page
Installation Instructions and
Capabilities . . . . . . . . . . . . . . . . . . . . 1
Key Functions . . . . . . . . . . . . . . . . . . . . 2
1.0 To Set The Clock . . . . . . . . . . . . . . . . . . 3
1.1 To Modify Clock . . . . . . . . . . . . . . . . . . 3
(After previously Set)
2.0 To Set Date . . . . . . . . . . . . . . . . . . . . . . 3
2.1 To Modify Date . . . . . . . . . . . . . . . . . . . 4
(After previously Set)
3.0 Daylight Saving Time . . . . . . . . . . . . . . 4
3.1 Modify Daylight Saving Time . . . . . . . . . 5
4.0 Scheduling ONs, OFFs . . . . . . . . . . . . . 5
5.0 Review, Modify, Delete schedules . . . . . 6
6.0 Manual Override . . . . . . . . . . . . . . . . . . 6
7.0 Clear All Memory . . . . . . . . . . . . . . . . . 7
Blank Schedule sheets . . . . . . . . . . . . . 8
E101B SINGLE 7/22/07 10:02 PM Page 2
TORK MODELS E101B / E103B / E120B
24 HOUR DIGITAL TIME SWITCH
READ INSTR
UCTIONS CAREFULLY BEFORE
ATTEMPTING T
O INSTALL TIME SWITCH. SEE
W
ARNING ON FRONT PANEL
– Failure to comply
with instructions could result in personal injury and/or
property damage.
INSTALLATION:
UNIT IS TO BE INSTALLED BY A LICENSED ELECTRICIAN
1. To remove unit from enclosure: Push the tab on right
to swing unit the left and remove.
2. Mount the enclosure at eye level using screws or
other suitable fastening device. Bring supply and load
wires in through or side knockouts. DO NOT USE
TOP.
3. Unit should be programmed with AC power only and
not while on super cap back up power.
4. Reinstall unit by reversing step #1 above and con-
necting wires to units as per suggested wiring diagrams. See illustration and warning on back page.
5. To reset the timer, insert a paperclip on the small hole
next to the EVENT key. This procedure will allow you
to reset the time but will not clear the memory.
CAPABILITIES
- 24 Hour Day scheduling.
- ON and OFF set points
Total # - 20 per day
- Minimum setting: 1 minute
FEATURES
Daylight Saving Automatic (can be adjusted).
Leap Year Automatic compensation.
Display LCD
Manual Override Until the next schedule ON or OFF.
Automatic operation then resumes.
Power Outage Permanent schedule retention.
Supercapacitor maintains real time
up to 4 days.
1
E101B SINGLE 7/22/07 10:02 PM Page 3
KEY FUNCTIONS:
Unit should be program with AC power. Do not program on super cap back up power.
Mode: Press to go to the next mode.
Enter: Stores or saves current entry.
DAY/YEAR:
a. Press to set the year in the DATE mode.
b. Selects the desired day of the week in the DST
(Daylight Savings Time) mode.
OVR:
a. Press to change the load status in the AUTO (auto-
matic) and the MAN (manual) mode.
DEL/PREV:
a. Press to delete the displayed entry.
b. Decrement the last selected entry.
HOUR/MONTH:
a. Press to set hour in CLK (clock) mode and the SCH
(schedule) mode.
b. Press to set month in the DATE mode and DST
(Daylight Savings Time) mode.
MINUTE/DATE:
a. Press to set minutes in CLK (clock) mode and SCH
(schedule) mode.
b. Press to set date in the DATE mode.
c. Press to select the week of the month in DST
(Daylight Savings Time).
ENTER:
a. Press to store the displayed information into memory.
Information will not be stored until the ENTER key
is pressed.
Note: During settings, each press of the key will
advance one number. For rapid advance hold key in.
EVENT:
a. Press to select ON/OFF in the schedule.
b. Press to update the load status In the AUTO (auto-
matic) mode.
2
E101B SINGLE 7/22/07 10:02 PM Page 4
PROGRAMMING YOUR E101B / E103B / E120B
NOTE: AFTER MAKING ANY CHANGES TO THE
PROGRAM, PRESS MODE TO GO TO RUN
MODE AND THEN PRESS EVENT TO UPDATE
THE LOAD STATUS.
AT POWER UP:
When powering up the unit for the first time,
12:00 will flash on the display. NOTE: Allow 1-2
minutes for the supercap to charge before any
display is shown.
Press the MODE key to go to the CLK mode. After
pressing the MODE key the display will show:
1.0 TO SET CLOCK
Press HOUR and MIN to advance to the present
hour and mins. Check AM/PM, and press ENTER.
1.1 TO MODIFY CLOCK
Press MODE until the display shows: CLK. Press
HOUR and MIN. to modify clock and press
ENTER.
2.0 TO SET DATE
If you are setting for the first time, display will
show:
3
E101B SINGLE 7/22/07 10:02 PM Page 5
MO TU WE TH FR SA SU ASTRO
CH1 MOM AM PM OFFSET CH2
CLK DATE SCH AUTO MAN
MO TU WE TH FR SA SU ASTRO
CLK DATE SCH AUTO MAN
Press MONTH, DATE, and YEAR key to advance
to the desired Month, date and year, then press
ENTER.
NOTE: The day of the week will be automatically
set once the date is set.
2.1 TO MODIFY DATE
Press MODE until the display shows DATE. Press
MONTH, DATE and YEAR to modify present set-
tings and then press ENTER.
4
E101B SINGLE 7/22/07 10:02 PM Page 6
3.0 DAYLIGHT SAVING TIME
After setting or modifying the date, display will
show:
ON
OFF
For standard USA daylight savings (DSt), press MODE
then go to step 4.0. For dates other than standard USA
dates, press MONTH and go to step 3.1. If daylight
saving time (DSt) is NOT required, press DEL display
will show:
OFF
Press ENTER then go to step 4.0.
4.0 SCHEDULE SET MODE
Press MODE until display shows:
5
E101B SINGLE 7/22/07 10:02 PM Page 7
3.1 TO MODIFY STANDARD USA
DAYLIGHT SAVINGS DATES
MO TU WE TH FR SA SU ASTRO
Press MONTH and DATE, to modify S (starting) DST
settings. NOTE: DATE will choose the week of the month
to be assigned. Choices are 01 (1st), 02 (2nd), 03 (3rd)
or L (Last) week of the month. The default day in SU
(Sunday). Pressing DAY changes default day. EXAMPLE:
04:01 SU S represents the first Sunday in April.
Press ENTER and the display will show:
MO TU WE TH FR SA SU ASTRO
Press MONTH and DATE, to modify E (ending) DST
settings. NOTE: DATE will choose the week of the
month to be assigned. Choices are 01 (Ist), 02 (2nd),
03 (3rd) or L (Last) week of the month. The default day
is SU (Sunday). Pressing DAY changes default day.
EXAMPLE: 10:L SU E represents last Sunday in
October.
Press ENTER and the display will show the modified
DSt starting date.
Press MODE to go to step 4.0.
CLK DATE SCH AUTO MAN
4.1 SETTING HOURS AND MINUTES
Press HOUR and MIN to set desired time. Press
EVENT to set desired event (ON/OFF) and then
press ENTER. The display will show:
Follow the same procedures above to set more
schedule entries.
5.0 REVIEW, MODIFY AND DELETE
Press MODE to advance to any of the following
MODES:
1. CLOCK MODE: Press HOUR and MIN to mod-
ify existing settings. Press ENTER.
2. DATE MODE: Press MONTH, DATE and YEAR
to modify existing settings. Press ENTER. DAY
is automatically adjusted.
3. DST Daylight Saving Time: To review press
ENTER. To modify press MONTH, DATE and
DAY to change existing setting. Press ENTER.
4. SCHEDULE MODE: Press HOUR, MIN and
EVENT to modify time settings. Press DEL to
delete. Press ENTER after each modification.
5. RUN MODE: The time, day, seconds, the load
status and AUTO is displayed.
6.0 OVERRIDE
OVR (Override) is effective in the AUTO mode
and the manual mode. OVR on the AUTO
mode is effective until the next event. OVR on
the manual mode is effective indefinitely.
6
E101B SINGLE 7/22/07 10:02 PM Page 8
CLK DATE SCH AUTO MAN
7.0 NOTES:
1. MAN mode: Under this mode the unit disre-
gards the settings in the schedule mode and
remains in its manually set status ON or OFF.
NOTE: To resume regular schedule execution
press the mode key to return to AUTO mode.
2. Unit will go to RUN MODE automatically
(except on the MAN mode) if no key is pressed
for five minutes.
3. Clear all memory. All memory can be cleared
using the following procedure:While in the RUN
mode, press ENTER, display will show:
Use EVENT key to display:
Now press ENTER briefly and everything in the
timer memory will be erased, including real time
and date. NOTE: Unit has permanent memory
and will not be erased unless done through procedure above.
5. Upon powering up your E101B/103B/120B the
display will show at what frequency the unit is
operating, 50 will determine 50Hz or 60 for
60Hz. NOTE: While in the AUTO mode, if AC
power is absent, the display will show a PF
(power failure) instead of the seconds scrolling
up.
6. A “Lo” on the display indicates that the super
cap has run low and the unit needs to be powered with AC. A minimum of 8 hours is required
to fully charge the super cap.
7
E101B SINGLE 7/22/07 10:02 PM Page 9
ON
OFF
CLK DATE SCH AUTO MAN
ON
OFF
CLK DATE SCH AUTO MAN
8
NOTE: AFTER MAKING ANY CHANGES TO THE
PROGRAM, PRESS MODE TO GO TO RUN MODE
AND THEN PRESS EVENT TO UPDATE THE LOAD
STATUS.
E101B SINGLE 7/22/07 10:02 PM Page 10
Sch.#
OFFONTimeLoad Description
9
