Topfield CRC-2400 User Manual
TOPFIELD
CRC-2400
User Guide
High Definition
Digital Cable Receiver
Personal Video Recorder
CONAX Embedded
ii CONTENTS
Contents
Contents ii
1 Introduction 1
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Controlling the digital receiver . . . . . . . . . . . . . . . . . . 2
1.2.1 Front panel . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2.2 Remote control . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Subscription card information . . . . . . . . . . . . . . . . . . 6
2 Setup 7
2.1 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Rear panel connections . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Connecting up your digital receiver . . . . . . . . . . . . . . . 10
2.4.1 Connecting to the broadcasting cable . . . . . . . . . . 11
2.4.2 Connecting to your television set . . . . . . . . . . . . 11
2.4.3 Connecting to your video recorder . . . . . . . . . . . 13
2.5 Switching on for the first time . . . . . . . . . . . . . . . . . . 13
3 Service Search 16
3.1 Searching for broadcasting services . . . . . . . . . . . . . . . 16
3.2 Resetting to factory settings . . . . . . . . . . . . . . . . . . . 17
3.3 Resetting to user settings . . . . . . . . . . . . . . . . . . . . . 18
3.4 Clearing the services list . . . . . . . . . . . . . . . . . . . . . 18
CONTENTS iii
4 Preference Settings 19
4.1 Language settings . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.1.1 Menu language . . . . . . . . . . . . . . . . . . . . . . 19
4.1.2 Subtitle language . . . . . . . . . . . . . . . . . . . . . 20
4.1.3 Hard of Hearing . . . . . . . . . . . . . . . . . . . . . 20
4.1.4 Audio language . . . . . . . . . . . . . . . . . . . . . . 20
4.2 Video and audio settings . . . . . . . . . . . . . . . . . . . . . 21
4.2.1 High definition television . . . . . . . . . . . . . . . . 21
4.2.2 Television aspect ratio . . . . . . . . . . . . . . . . . . 22
4.2.3 Colour format . . . . . . . . . . . . . . . . . . . . . . . 23
4.2.4 Another video device . . . . . . . . . . . . . . . . . . . 23
4.2.5 Audio mode . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 Local time setting . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.4 Parental control . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.5 Options for recording . . . . . . . . . . . . . . . . . . . . . . . 28
4.6 Options for playback . . . . . . . . . . . . . . . . . . . . . . . 29
4.7 Options for on-screen display . . . . . . . . . . . . . . . . . . 30
4.8 Options for the front display . . . . . . . . . . . . . . . . . . . 31
4.9 Options for Photo Album . . . . . . . . . . . . . . . . . . . . . 31
4.10 Options for standby mode . . . . . . . . . . . . . . . . . . . . 32
5 Every Day Use 33
5.1 Volume control . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.2 Watching television . . . . . . . . . . . . . . . . . . . . . . . . 33
5.2.1 The services list . . . . . . . . . . . . . . . . . . . . . . 33
5.2.2 The favourite service lists . . . . . . . . . . . . . . . . 34
5.2.3 Viewing programme information . . . . . . . . . . . . 35
5.2.4 Selecting audio tracks . . . . . . . . . . . . . . . . . . 36
5.2.5 Selecting subtitle tracks . . . . . . . . . . . . . . . . . 37
5.2.6 Viewing teletext . . . . . . . . . . . . . . . . . . . . . . 37
5.3 Viewing electronic programme guide . . . . . . . . . . . . . . 37
5.4 Using time-shift . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6 Organising Services 41
6.1 Editing the favourite lists . . . . . . . . . . . . . . . . . . . . . 41
6.2 How to use on-screen keyboard . . . . . . . . . . . . . . . . . 43
iv CONTENTS
7 Recording and Playback 44
7.1 Recording a programme . . . . . . . . . . . . . . . . . . . . . 45
7.1.1 Instant recording . . . . . . . . . . . . . . . . . . . . . 45
7.1.2 Timer recording . . . . . . . . . . . . . . . . . . . . . . 47
7.1.3 Scheduling recordings using the programme guide . . 49
7.1.4 Recording a time-shifted programme . . . . . . . . . . 49
7.1.5 Recording a pay service programme . . . . . . . . . . 50
7.2 File archive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
7.2.1 To delete a recording . . . . . . . . . . . . . . . . . . . 51
7.2.2 To sort recordings . . . . . . . . . . . . . . . . . . . . . 51
7.2.3 To lock a recording . . . . . . . . . . . . . . . . . . . . 52
7.2.4 To rename a recording . . . . . . . . . . . . . . . . . . 52
7.2.5 To make a new folder . . . . . . . . . . . . . . . . . . . 52
7.2.6 To move a recording to another folder . . . . . . . . . 52
7.3 Playing back a recording . . . . . . . . . . . . . . . . . . . . . 53
7.3.1 To navigate using the progress bar . . . . . . . . . . . 53
7.3.2 To play in slow motion . . . . . . . . . . . . . . . . . . 54
7.3.3 To play in fast motion . . . . . . . . . . . . . . . . . . . 54
7.3.4 To make a bookmark . . . . . . . . . . . . . . . . . . . 55
7.3.5 To play back recordings in sequence . . . . . . . . . . 55
7.3.6 To play back a scrambled recording . . . . . . . . . . . 56
7.4 Copying a recording . . . . . . . . . . . . . . . . . . . . . . . 56
7.5 Formatting the hard disk . . . . . . . . . . . . . . . . . . . . . 57
8 Entertainment 58
8.1 Configuring the network setting . . . . . . . . . . . . . . . . . 58
8.2 Copying files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
8.3 Playing back MP3 files . . . . . . . . . . . . . . . . . . . . . . 60
8.4 Viewing image files . . . . . . . . . . . . . . . . . . . . . . . . 61
8.5 Playing back a video file . . . . . . . . . . . . . . . . . . . . . 61
8.6 Playing back YouTube contents . . . . . . . . . . . . . . . . . 62
8.7 Sharing image files by Yahoo Flickr . . . . . . . . . . . . . . . 63
8.8 SHOUTcast Internet radio . . . . . . . . . . . . . . . . . . . . 65
8.9 Google weather forecast . . . . . . . . . . . . . . . . . . . . . 66
9 Firmware Update 67
CONTENTS v
9.1 From a memory stick . . . . . . . . . . . . . . . . . . . . . . . 67
9.2 Over the air . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
A Universal Remote Control 69
A.1 Code list for television sets . . . . . . . . . . . . . . . . . . . . 72
A.2 Code list for DVD players . . . . . . . . . . . . . . . . . . . . . 86
A.3 Code list for audio-video receivers . . . . . . . . . . . . . . . 88
1
1
Chapter 1
Introduction
The CRC-2400 digital receiver is fully compliant with the international Digital Video Broadcasting (DVB) standard, and thus
is able to receive digital broadcasts of that standard.
NOTE
In general we equate a channel with a frequency. However,
unlike analogue broadcasts, digital broadcasts are not all
assigned to their own frequencies; instead, multiple television broadcasts are transmitted through a single frequency.
The frequency in digital broadcasting is usually called transponder or multiplex. To reduce confusion in this manual,
the word service is preferably used than channel as a term
to indicate one television or radio broadcast.
1.1 Features
This digital receiver has the following features:
• Can store up to 2,000 television and radio services.
• Can create lists of your favourite services.
2 Introduction
• Can view information about the current television or radio programme.
• Has an electronic programme guide that provides an
overview of scheduled programmes.
• You can record one service while you are currently
watching another.
• You can record many programmes using a built-in hard
drive with large storage capacity.
• Time-shift is a special technical feature available on this
digital receiver. You can pause a programme you are
watching and resume it again at a later time. Then you
can quickly go to any part of the current programme by
fast forward or rewind search.
• If you have an external hard drive connected to the digital receiver via the USB port, you can record television
programmes into it.
• You can play back video files of various formats including DivX.
• You can use various Web services including YouTube.
1.2 Controlling the digital receiver
You can operate the digital receiver with the remote control or
the buttons on the front panel.
NOTE
When the digital receiver is off but plugged into a wall
socket, we say that it is in standby mode; on the other hand,
when it is on, it is in active mode. Even when you are not
using the digital receiver, you should keep it plugged into
a wall socket to be in standby mode so that it can run timer
events at any time.
1
1.2 Controlling the digital receiver 3
1.2.1 Front panel
The front panel of the digital receiver has buttons to control
the digital receiver, specific lights and a display to indicate its
status. The following indicates what they mean.
button switches the digital receiver between standbymode
and active mode.
Front display shows the current time in standby mode, and
displays the current service in active mode.
MENU button displays the main menu. It is also used to return
to the previous menu from a submenu.
OK button displays the services list. See §5.2.1 for more de-
tails. It is also used to select a menu item.
CHANNELc,
a
buttons switch to the previous or next ser-
vice.
VOLUMEb,
d
buttons decrease or increase the volume.
You have to insert your subscription
card into the front slot to watch pay
services. When you insert the subscription card, the side on which the chip is
mounted must face upward.
4 Introduction
1.2.2 Remote control
41
.
.
.
1
button switches the
digital receiver between
standby mode and active
mode.
.
.
.
2
mutes the sound. Press
again to switch it back on.
.
.
.
3
TV switches the remote
control to television mode
to operate your television.
.
.
.
4
PVR switches the remote
control to receiver mode to
operate the digital receiver.
.
.
.
5
AUX switches the remote
control to operate your
audio-video receiver.
.
.
.
6
DVD switches the remote
control to DVD mode to operate your DVD player.
.
.
.
7
Numeric buttons are used
to enter a service number
for service change or to
specify values for menu options.
.
.
.
8
switches over between
the current service and the
previously viewed one.
.
.
.
9
displays the service information box. It is also used
to display more information about a programme.
.
.
.
10
VOLUME− ,
VOLUME+ buttons decrease or increase the
volume.
.
.
.
11
CHANNEL− ,
CHANNEL+ buttons switch to the previous or
1
1.2 Controlling the digital receiver 5
next service.
.
.
.
12
OK displays the services list. See §5.2.1 for more details.
It is also used to select a menu item.
.
.
.
13
Navigation buttons are used to navigate in menus or to
change values for menu options.
.
.
.
14
MENU displays the main menu. It is also used to return to
the previous menu from a submenu.
.
.
.
15
GUIDE displays the electronic programme guide.
.
.
.
16
EXIT is used to exit a menu or to hide on-screen informa-
tion.
.
.
.
17
is used to display the list of recorded programmes that
are stored in the internal hard drive. See §
7.2 for more
details.
.
.
.
18
F1 has different functions per menu.
.
.
.
19
F2 is used to make a bookmark on playback or time-shift.
.
.
.
20
F4 has different functions per menu.
.
.
.
21
F3 is used to jump to next bookmark position.
.
.
.
22
Option has different functions per menu.
.
.
.
23
is used to select a subtitle track.
.
.
.
24
is used to select an audio track and a sound mode.
.
.
.
25
displays teletext.
.
.
.
26
VF changes video resolution. See §4.2.1 for more details.
.
.
.
27
AR changes aspect ratio. See §4.2.2 for more details.
.
.
.
28
switches over between television services and radio
services.
.
.
.
29
is used to set a sleep timer in 10 minute increments.
.
.
.
30
is used to start recording.
.
.
.
31
is used to stop playback, to stop recording, or to jump
back to live television from time-shifted television.
.
.
.
32
M switches the output of the TV SCART socket over be-
tween the digital receiver and the device connected to the
VCR SCART socket. See §4.2.4 for more details.
6 Introduction
.
.
.
33
SAT is not used in this model.
.
.
.
34
is used to start reverse playback. Subsequent presses
increase the rewind speed.
.
.
.
35
pauses live television or playback of a recorded pro-
gramme.
.
.
.
36
is used to start fast forward playback. Subsequent
presses increase the playback speed.
.
.
.
37
resumes normal playback speed, or displays the
progress bar for navigation on playback or time-shift. To
play a recorded programme, see button
.
.
.
17
.
.
.
.
38
is used to jump back to the beginning of the recording
on playback.
.
.
.
39
is used to start slow motion playback. Subsequent
presses change the playback speed.
.
.
.
40
is used to jump to the end of the recording on playback.
.
.
.
41
has different functions per menu.
NOTE
When using the remote control, point it at the remote sensor
on the front panel of the digital receiver.
1.3 Subscription card information
With this digital receiver, you can view pay services scrambled with the CONAX conditional access system. Probably
you have a subscription card. If you would like to view information in detail about your subscription card, select the Infor-
mation > Conditional Access menu. There you can also check
the messages from the broadcasting operator.
2
7
Chapter 2
Setup
2.1 Unpacking
Before going any further, check that you have received the following items with the digital receiver.
• Remote control
• Two batteries for the remote control (AAA 1.5 V)
• One Composite cable (RCA cable)
• A copy of this user guide
NOTE
Accessories may vary according to your local area.
2.2 Safety precautions
Please read carefully the following safety precautions.
• The mains voltage must range between 90 and 250 volts.
Check it before plugging the digital receiver to the wall
socket. For the power consumption of the digital receiver, refer to Table 2.1.
8 Setup
• The wall socket should be near the equipment. Do not
run an extension lead to the unit.
• The mains plug shall remain readily operable so that it
can be removed easily to disconnect the power.
• The digital receiver shall not be exposed to dripping or
splashing water, and no objects filled with liquids, such
as vases, shall be placed on it.
• Do not expose the digital receiver to any moisture. The
digital receiver is designed for indoor use only. Use dry
cloth to clean the digital receiver.
• Place the digital receiver on a firm and level surface.
• Do not place the digital receiver close to heat emitting
units or in direct sunlight, as this will impair cooling.
Do not lay any objects such as magazines on the digital receiver. When placed in a cabinet, make sure there
is a minimum space of 10 centimetres around it. For the
physical specification of the digital receiver, refer to Table 2.2.
• Protect the power cord from being walked on or pinched.
If the cord is damaged, do not use the digital receiver and
get the cord replaced.
• Never open the digital receiver casing under any circumstances, or the warranty will be void.
• Refer all servicing to a qualified service technician.
Table 2.1: Power specification
Input voltage 90 to 250 V AC, 50/60 Hz
Power consumption 47 W at maximum in active
Under 1 W in passive standby
2
2.3 Rear panel connections 9
Table 2.2: Physical specifications
Size 380× 60× 265 mm
Weight 3.1 kg
Operating temperature 0 to 45◦C
Storage relative humidity 5 to 90 %
2.3 Rear panel connections
The CRC-2400 has a wide range of connections on the back.
Check what connections your television set has in comparison
with the digital receiver.
.
.
.
1
CABLE IN Cable broadcasting signal input socket
.
.
.
2
CABLE OUT Cable broadcasting signal output socket
through the CABLE IN socket for another
digital receiver
.
.
.
3
VIDEO Composite video output socket for the tele-
vision set (yellow)
.
.
.
4
AUDIO L/R Stereo audio output socket for the televi-
sion set or the audio-video receiver (white/red)
.
.
.
5
TV Audioand video output socket for the tele-
vision set
.
.
.
6
VCR Audio and video input/output socket for
another device such as a video recorder
.
.
.
7
LAN Local area network port
10 Setup
.
.
.
8
USB USB port for firmware update and data trans-
fer
.
.
.
9
S/PDIF Digital audio output socket for the audio-
video receiver
.
.
.
10
HDMI Audioand video output socket for the high
definition television set
.
.
.
11
ON/OFF Powerswitch (You have to turn on this switch
first to use this digital receiver.)
Table 2.3: Connectors specifications
HDMI High definition video output
Left & right audio output
Digital audio output
TV CVBS/S-Video video output
Left & right audio output
VCR CVBS video output
Left & right audio output
CVBS/S-Video/RGB video input for bypass
Left & right audio input for bypass
VIDEO Composite video (CVBS) output
AUDIO Left & right audio output
S/PDIF Digital audio output
USB 2.0 Host (5 V DC, 500 mA)
LAN 10/100 Ethernet
2.4 Connecting up your digital receiver
There are several ways to set up the digital receiver. Set up the
digital receiver suitably to your television and other devices.
If you have any problem with your setup or need help, contact
your dealer.
2
2.4 Connecting up your digital receiver 11
2.4.1 Connecting to the broadcasting cable
Whatever sort of connection you have between the digital receiver and the television,
you need to connect the digital receiver to the
broadcasting cable so that it can receive digital television broadcasts. Connect the broadcasting cable to the CABLE IN connector. If
you have another digital receiver, you may
link it from the CABLE OUT connector.
2.4.2 Connecting to your television set
For all the following connections of the digital receiver, we recommend you to use the first connector to get the best picture
quality. If your television does not have a matching connector,
then use the next connector in the following order for a better
picture quality.
1. HDMI connector (HDMI)
2. SCART connector (TV)
3. Composite connector (VIDEO)
You should configure audio and video settings after connecting up the digital receiver. See §4.2 for a detailed description.
To use the HDMI output
If you have a high definition television set,
you should use an HDMI cable for best results. Plug one end of the cable into the HDMI
socket on the digital receiver, and plug the
other end into the matching socket on your
television. In this case, you do not have to
make audio connection because it can output
stereo audio or digital audio as well.
12 Setup
To use the SCART output
For best results with a standard television set,
you should use a SCART cable. Plug one end
of the cable into the TV socket on the digital
receiver, and plug the other end into a free
SCART socket on your television.
If you connect with a standard SCART cable, you do not have
to make audio connection because it can output stereo audio
as well. But if you use a conversion cable such as SCART-toComponent, then you have to make audio connection.
NOTE
You cannot view high definition video by means of the
SCART output.
To use the Composite video output
You need to obtain a Composite video cable
(RCA cable) to use the Composite video output. Plug one end of the cable into the VIDEO
(yellow) socket on the digital receiver, and
plug the other end into the matching socket
on your television.
NOTE
You cannot view high definition video by means of the Composite video output.
2
2.5 Switching on for the first time 13
To make the audio connection
You need to obtain an audio cable (RCA cable) to link the audio connectors. Plug one
ends of the cable into the AUDIO L (white)
and AUDIO R (red) sockets on the digital receiver, and plug the other ends into
the matching sockets on your television or
audio-video receiver.
To enjoy Dolby Digital audio, your television
or audio-video receiver must be able to decode Dolby Digital audio, and you need to
obtain an S/PDIF cable.
Plug one end of the cable into the S/PDIF
socket on the digital receiver, and plug the
other end into the matching socket on your
audio-video receiver.
2.4.3 Connecting to your video recorder
The digital receiver can also output video through an auxiliary
SCART connector to another device such as a video recorder.
You need to obtain a SCART cable to link the
auxiliary SCART connector. Plug one end
of the cable into the VCR socket on the digital receiver, and plug the other end into the
matching socket on your video recorder or
suchlike.
2.5 Switching on for the first time
Now that you have your digital receiver connected, you should
plug it into a wall socket. Ensure that your television set is
turned on and on the correct video channel so that you will be
able to see the display from the digital receiver.
14 Setup
Before switching on the digital receiver, you should insert batteries into the remote control. Open the battery compartment
by removing the lid, and then insert the batteries observing the
polarity, which is marked on the base of the battery compartment.
Press the button on the top left corner on the remote control. In a little time, you may see a picture displaying a menu.
If you do not see a picture, try pressing the
VF button on the
remote control. If after several tries you still get no picture,
check that the television is set to the correct input. If the picture
is good, you can skip to §3.1 to search for available television
and radio services. Otherwise, you may need to temporarily
connect the Composite video connector (VIDEO) to your television set so that you can see the menu in order to configure
the video settings.
CAUTION
If the digital receiver no longer reacts properly to the remote
control commands, the batteries may be flat. Be sure to replace only with 1.5 V AAA size batteries, and observe the
following precautions.
• Do not mix different types of batteries, or new and old
batteries.
• Do not use rechargeable batteries.
• Do not recharge the old batteries.
• In order to avoid any risk of explosion, observe the polarities indicated inside the battery compartment.
• Do not subject to excessive heat such as the sun and
fire.
• If you are not using the remote control for a long period of time, remove the batteries. The manufacturer
accepts no liability for the damage resulting from leaking batteries.
2
2.5 Switching on for the first time 15
• Batteries, including those which contain no heavy
metals, may not be disposed with other household
wastes. Please dispose of used batteries in an environmentally sound manner. Find out the legal regulations
which apply in your area.
16 Service Search
Chapter 3
Service Search
After connecting up the digital receiver, you will need to perform a service search.
NOTE
If there is no service stored, you will be not able to access all
menus. A is another name for a .
3.1 Searching for broadcasting services
To perform service search, select the Installation > Searching
menu. You should see a screen
like the left figure.
3
3.2 Resetting to factory settings 17
You should set the Search Mode option to Auto at the first
service search after installing the digital receiver. The digital
receiver will search all available services with the automatic
search mode within the frequency range from the frequency
of the Start Frequency option to the frequency of the End Fre-
quency option. Symbol Rate stands for data transfer rate, and
QAM is a form of modulation used in digital broadcasting.
Broadcasting operators send their services in a symbol rate by
a modulation method. Perhaps you do not have to specify the
Symbol Rate and QAM Mode options since they are seldom
changed. However, you should set the QAM Mode option to
Auto for more certainty. You can specify the Start Frequency,
End Frequency and Symbol Rate options with the numeric
buttons if you want to change them.
To search only one frequency, set the Search Mode option to
Manual and specify your desired frequency at the Frequency
option with the numeric buttons.
It is most recommended that you should set the Search Mode
option to Quick Scan. With this option, you can search every
service rather quickly.
Um den Suchlauf zu starten, bewegen Sie sich zum Punkt
Suchlauf starten und bestätigen Sie den Menüpunkt mit
OK �er
Digitalreceiver beginnt nun mit dem Suchlauf und listet dabei
die gefundenen Fernseh- und Radiosender auf. Je nach Belegung der Kanäle im Kabelnetz, kann es einige Zeit dauern,
bevor die ersten Kanäle gefunden werden. Wenn der Suchlauf beendet ist, wird Ihnen angezeigt, wieviele Fernseh- und
Radiosender gefunden wurden. Drücken Sie die
OK Taste um
die Sender zu speichern.
3.2 Resetting to factory settings
The digital receiver maintains the following data:
• Services list
• Favourite list
18 Service Search
• Timer list
• Preference settings
You can reset all data of the digital receiver. Select the Instal-
lation > System Recovery > Factory Setting menu, and then
you get asked for confirmation. With the choice of Yes, the
services list, favourite list and timer list will all be cleared, and
preference options will be reset to the manufacturer’s factory
settings.
NOTE
A factory reset will not delete any recorded programmes.
However, you have to search services again after a factory
reset.
3.3 Resetting to user settings
You can store your own data including the following:
• Services list
• Favourite lists
• Preference settings
Also you can restore them at any time.
To store your data, select the Installation > System Recovery >
Store System Data menu, then you get asked for confirmation.
If you select Yes, your data will be stored. Whenever you store
your data, they are all overwritten.
To restore your data, select the Installation > System Recovery
> Recover System Data menu, then you get asked for confir-
mation. With the choice of Yes, your data will be restored.
3.4 Clearing the services list
If you only want to clear the services list, select Installation >
System Recovery > Reset Service List, then you get asked for
confirmation. With the choice of Yes, the services list will be
cleared. After this, you have to do service search again.
4
19
Chapter 4
Preference Settings
4.1 Language settings
You can select the language in
which the menu will be displayed. In addition to that, you
can select the language of audio
track and of subtitle track. Select
the Settings > Language menu.
You should see a screen like the
left figure.
4.1.1 Menu language
The digital receiver provides menus in several different languages. Set the Menu Language option to your desired language. Once you select a language, the menu will be immediately displayed in the selected language.
20 Preference Settings
4.1.2 Subtitle language
Set the 1st Subtitle Language option and the 2nd Subtitle Language option to your desired languages. When you watch a
programme, if the programme has a subtitle track of the language that is specified for the 1st Subtitle Language, it will be
displayed. If the first language is not available but the second
language is available, the subtitle of the second language will
be displayed. If there is no available language, no subtitle will
be displayed.
Apart from this setting, you can select a subtitle track with the
button. See §5.2.5 for a detailed description.
4.1.3 Hard of Hearing
Some broadcasters may send a subtitle track dedicated to the
hard-of-hearing. Even when a subtitle track or more is available, that subtitle track will be displayed prior to those you
have specified for the 1st Subtitle Language and the 2nd Sub-
title Language options if the Hard of Hearing option is set to
On.
4.1.4 Audio language
Set the 1st Audio Language option and the 2nd Audio Language option to your desired languages. When you watch a
programme, if the programme has an audio track of the language that is specified for the 1st Audio Language, it will be
output. If the first language is not available but the second language is, the audio of the second language will be output.
Apart from this setting, you can select an audio track with the
button. See §5.2.4 for a detailed description.
4
4.2 Video and audio settings 21
4.2 Video and audio settings
You have to configure the video
and audio settings appropriately
for your television set and other
devices. Select the Settings >
A/V Output menu. You should
see a screen like the left figure.
4.2.1 High definition television
The digital receiver supports various video resolutions from
576 to 1080. In general, a resolution of 720 or more is considered high definition. The higher the resolution is, the better
the quality is. However, if your television set does not support high definition, you cannot enjoy high definition quality
picture.
Set the Video Format option as you desire. If you set this option to 576P, the digital receiver will present even high definition programmes in resolution of 576. On the contrary, if you
set it to 1080I, the digital receiver will present even standard
definition programmes in resolution of 1080.
It is recommended to set it to Auto if you have a high definition
television. With that setting the digital receiver will present a
programme as it is without any resolution conversion. While
watching television you can change the resolution with the
VF
button. Whenever you press it, the video resolution is changed
in turn.
22 Preference Settings
NOTE
You can enjoy only standard definition video with the following video outputs:
• Composite video output (VIDEO)
• SCART output (TV)
4.2.2 Television aspect ratio
If you have a wide-screen television, set the TV Aspect Ratio
option to 16:9.
You can enjoy both wide-screen programmes and normalscreen programmes with your wide-screen television as the
above figures show. To watch normal-screen programmes
in full screen like the left figure, set the Display Format option
to Full. Normal-screen pictures then will be inflated to fit to
the width of the wide screen. Otherwise, to watch them in the
original ratio like the right figure, set it to Center. If you have
a normal-screen television, set the TV Aspect Ratio option to
4:3.
You cannot fully enjoy wide-screen programmes with your
4
4.2 Video and audio settings 23
normal-screen television as the above figures show. The left
figure shows a normal picture displayed in the normal screen.
To watch wide-screen programmes in the shape like the centre figure, set the Display Format option to Letter Box. Widescreen pictures then will be reduced to fit to the width of the
normal screen. Otherwise, to watch them in the shape like the
right figure, set it to Center extract. Then wide-screen pictures
will be cut out on the left and right sides equally to fit to the
width of the normal screen.
4.2.3 Colour format
Through the TV SCART output, the digital receiver is able to
output video in various colour formats. If you have the digital
receiver linked to your television via this output, you should
set the SCART Output option to your desired colour format.
If you have connected via the RCA socket labeled VIDEO on
the back panel, you do not have to set this option because the
digital receiver outputs CVBS video through that RCA output
independently of the SCART output.
In general, it is known that the RGB colour format provides the
best video quality but the CVBS colour format does the least.
So RGB would be the most desirable option for this.
4.2.4 Another video device
You can have the digital receiver linked to another video device like a video recorder or a DVD player via the VCR SCART
output. In this case, the digital receiver will operate differently depending on the setting of the VCR SCART Type op-
tion. If the option is set to Standard, the digital receiver will
pass along the video from the video device to your television
when it starts playback. But if the option is set to External A/V,
the digital receiver will not pass the video automatically. You
have to press the
M button to pass it along. It is impossi-
ble for the digital receiver to record the video from the video
Loading...
