HD(-M4-1-RM
969 Horsham Road lHorsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 linfo@tonercable.com
Video & Audio IP (Qcoder
High-Definition MPEG 4 (H.264 AVC) Video / Audio Encoding
Emcore’s HDE-M4-1-RM is EMCORE’s advanced high-performance MPEG-4 /
H.264 encoder. It is capable of converting high definition video with audio onto
CATV or IPTV networks.
The HDE-M4-1-RM supports input formats such as HDMI, HD-SDI, SDI,
YPbPr, CVBS, SPDIF and analog audio. Algorithm and compression efficiency
improvements deliver crisp and vibrant video and audio at extremely low bit
Features
Compliant with MPEG-4 / H.264-AVC standard
MPEG 1 layer-II audio encoding
NTSC/PAL SD video format
SMPTE-296/SMPTE-274 HD video format
TS/IP Unicast and multicast output
rates. Multicasting along with an adjustable bit rate are just a couple of the
features that allow delivery of more HD/SD video and audio channels in the
available bandwidth.
The user-friendly HDE-M4-1-RM encoder is an ideal solution for signal
conversion and distribution over IP for the most demanding broadcast or IPTV
applications.
HDMI, HD/ SD-SDI, YPbPr, CVBS inputs
Digital SPDIF audio input
Dolby AC-3 audio encoding (optional)
Supports multiplexing of MPEG-4 video & audio
compressed data streams with DVB packing
Supports SD or HD TS stream output with cor-
responding definition of input signal
SI related editing table
IP output compliant with UDP/RDP protocol
Configuration and monitoring through front
panel or SNMP network manager.
Applications
IPTV Broadcast Systems
HDTV Headend Conversion
MDU Video Distribution
System Design
Enclosed in a ruggedized aluminum housing, the HDE-M4-1-RM is perfectly
suited towards applications that are space contrained and require equipment
with lower power consumption and heat output. The front faceplate has
push-button controls for configuration as well as status LED’s. SNMP network
management support allows remote interfacing for control and system
diagnostics.
Digital Signage & Kiosk Displays
Specifications Subject To Change Without Notice Rev 05-13 ©Toner Cable Equipment, Inc.
969 Horsham Road lHorsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 linfo@tonercable.com
Models
Model Description
HDE-M4-1-RM MPEG-4 (H.264/AVC) Video/Audio Encoder, 1RU Rackmount
Connection Diagram
Video/Stereo Audio Inputs
ASI Outputs
HDE-M4-1-RM
Video & Audio IP Encoder
Inputs
Specifications Values
Video HDMI(1080i HDCP), HD/SD-SDI, YPbPr, CVBS
Audio SPDIF, RCA, SDI embedded audio
Outputs
Specifications Values
DVB-ASI 2 ports, BNC connector
TCP/IP TS/IP 100/1000 Ethernet, RJ-45 connector
Video Encoding
Specifications Values
Compression MPEG-4/H.264 AVC High Profile @ Level 4.0
Resolutions 1920 x 1080i @ 60/50 Hz
Bit Rate SD (2 to 20 Mbps), HD (6 to 20 Mbps)
SD Format NTSC, PAL, SECAM
Broadcast Type Unicast & multicast
1440 x 1080i @ 60/50 Hz
1280 x 720p @ 60/50 Hz
720 x 576i @ 50 Hz
720 x 480p @ 60 Hz
10/100 Ethernet Port
TS/IP Ethernet Port
Compliance
External Ground
Power Input
Audio Encoding
Specifications Values
Compression MPEG-1 Layer II
Sampling 48 KHz
Channels 2 analog (mono or stereo) / 1 SPDIF
Supporting stereo audio
General
Specifications Values
Input Power 90~250 VAC, 50/60 Hz
Power Consumption 30 Watts (max)
Weight 11lbs (5kg)
Dimensions 1.73” (1RU) H x 19” W x 10.79” D
Operating Temperature 32 - 113° F (0 - 45° C)
Operating Humidity 10% - 80% Relative Humidity
Storage Temperature 23 - 122° F (-5 to 50° C)
Storage Humidity 0% - 90% (non-condensing)
(44mm x 484mm x 274mm)
Monitoring & Control
Specifications Values
Front Panel Keyboard, LCD display, Status LED’s
Remote TCP/IP, Network management software for
full control & system diagnostics
