Toastmaster TMSM350 User Manual

Electric

Stand Mixer

USE AND CARE GUIDE

MODEL TMSM350

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

◆ Read all instructions.

◆ To protect against risk of electrical shock, do not put cord, plugs

or appliance in water or other liquid.

◆ Close supervision is necessary when any appliance is used by or near children.

◆ Unplug from outlet when not in use, before putting on or taking off parts, and before cleaning.

◆ Avoid contacting moving parts.

◆ Do not operate any appliance with a damaged cord or plug or

after the appliance malfunctions, or is dropped or damaged in any manner. Contact Consumer Service.

◆ The use of accessory attachments not recommended or sold by the manufacturer may cause fire, electrical shock or injury.

◆ Do not use outdoors.

◆ Do not let cord hang over edge of table or counter.

◆ Do not let cord contact hot surface, including the stove.

◆ Keep hands, hair, clothing, as well as spatulas and other utensils

away from Beaters during operation to reduce the risk of injury to persons, and/or damage to the Mixer.

◆ Remove Beaters from Mixer before washing.

SAVE THESE INSTRUCTIONS

For Household Use Only

Electric Stand Mixer Use and Care Guide

ADDITIONAL IMPORTANT SAFEGUARDS

◆ All users of this appliance must read and understand this Use and

Care Guide before operating or cleaning this appliance.

◆ The cord to this appliance should be plugged into a 120V AC

electrical outlet only.

◆ Do not leave this appliance unattended during use.

◆ If this appliance begins to malfunction during use, immediately

turn the unit OFF and unplug the cord. Do not use or attempt to repair the malfunctioning appliance.

◆ If this appliance falls or accidentally becomes immersed in water,

unplug it immediately. Do not reach into the water! Do not use this appliance after it has fallen into or becomes immersed in water.

◆ To reduce the risk of injury to persons or property, never use this

appliance in an unstable position.

◆ Do not use this appliance for other than its intended use.

POLARIZED PLUG

Model TMSM350 has a polarized plug, (one blade is wider than the other). To reduce the risk of electrical shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

SHORT CORD INSTRUCTIONS

A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

Do not use an extension cord with this product.

ELECTRIC POWER

If the electrical circuit is overloaded with other appliances, your appliance may not operate properly. It should be operated on a separate electrical circuit from other appliances.

Getting to know your Toastmaster Electronic Stand Mixer

Your product may vary slightly from illustration.

FIGURE 1

13a

14.

1. Eject Button

2. Mixer Head

3. Release Button

4. Mixer Body

5. Power Light

6. Turbo Button

7. Variable Speed Control

8. ON/OFF Power Switch

9. 4-Quart Stainless-Steel Mixing Bowl (P/N 70510)

10. Turntable (P/N 70512)

11. Base

13b

12a

12b

4 5

12. a) Dough Hook with Hexagonal Collar (P/N 70506)

b) Dough Hook

with Round Collar (P/N 70517)

13. a) Round Beater with Hexagonal Collar (P/N 70509)

b) Square Beater

with Round Collar (P/N 70508)

14. Balloon Wire Whisk

(P/N 70820)

3.2.

Electric Stand Mixer Use and Care Guide

Knob

(bottom side of Turntable)

Raising

Lowering

the Mixer

Head

Press Release Button

Small Bowl

(not included)

(can be purchased separately)

Large Bowl

Dough Hook

with Hexagonal Collar

Dough Hook

with Round Collar

Round Beater

with Hexagonal Collar

Nylon

Button

Square Beater

with Round Collar

FIGURE 2 FIGURE 3

FIGURE 4

Wire Whisk

with Round Collar

FIGURE 5

FIGURE 6

Medium Low

Medium High

Minimum

Maximum

Before Using Your Electronic Stand Mixer

Carefully unpack the Mixer and remove all packaging materials. Wipe unit with damp cloth to remove any dust that may have accumulated, wash the Beaters, Dough Hooks, Whisk and Bowl in warm soapy water. Rinse and dry thoroughly.

Read all instructions carefully before using your Stand Mixer. We recommend that you become familiar with this appliance and its attachments before using, see Figures 1-5.

The maximum capacity of the Stainless-Steel Mixing Bowl is 4 quarts.

Use Of Attachments

Beaters Use for blending and beating mixes. Dough

Hooks Wire

Whisk

Use for dough, pie crust, pasta dough and blending large amounts of dry ingredients together.

Use for whipping, egg whites, egg yolks, sauce, souffle, mousse, meringue and salad dressing.

5.4.

Electric Stand Mixer Use and Care Guide

Mixing Guide

Icon

•

Speed

Minimum

Action

Stir/Fold

Use when stirring liquid ingredients or when a gentle action is needed to moisten dry ingredients. Use when folding two portions of a recipe together, like beating an egg white into a batter.

Mixing Procedure

Medium

Low

Mix

Knead

Use when mixing dry ingredients and liquid ingredients together alternately in a recipe or use when recipe calls for kneading until the dough is a dough ball.

•

Medium

High

Blend/Beat

/Cream

Use when creaming sugar and butter together.

Maximum Whip

Use when preparing a frosting from a recipe or a package. Use to whip whipping cream or potatoes. Use when beating egg whites.

Burst

of Power

Use to obtain the Maximum power level from any speed setting for tough mixing tasks.

Turbo

Button

How To Use Your Electronic Stand Mixer

1. Place Stand Mixer on a large stable surface and slide ON/OFF Power Switch to OFF position. Make sure the surface is clean and dry so the feet will hold the unit securely in place.

2. Press and hold the Release Button and pivot the Mixer Head upwards, see FIGURE 2. When the Mixer Head is securely in position you will hear a click. Do not attempt to pivot the Mixer Head without first pressing the Release Button. This could damage the Mixer.

3. Place Turntable onto Mixer platform by placing knob into the large or small bowl slot opening, depending on which size bowl is being used, see Figure 3.

NOTE: Although the TMSM350 Mixer comes with only a 4-Quart Stainless-Steel bowl, you may purchase a smaller 1 1/2 qt. bowl (P/N 70511) to use with the mixer as well. Contact Consumer Service for purchasing information.

4. Insert stem of the Beater or Dough Hook with the Hexagonal Collar into the hexagonal opening on the underside of the Mixing Head, see FIGURE 4. If using the Wire Whisk, insert stem of Whisk into the round opening on the underside of the Mixing Head, see Figure 5. Turn slightly if needed to lock into place.

5. Insert stem of the Beater or Dough Hook with the round collar into the round opening on the underside of the Mixing Head. Turn slightly if needed to lock into place.

NOTE: The Beater and Dough Hooks must be inserted into the correct opening as they are not interchangeable. It is also necessary to insert the Beater and Dough Hooks with the Hexagonal Collar first. Never use a Beater with a Dough Hook as this may damage the unit and may void your warranty.

6. Place Stainless Steel Mixing Bowl onto the Turntable.

7. With Beaters, Wire Whisk, or Dough Hooks properly in place,

grasp handle on Mixer Head, press the Release Button and slowly lower the Mixer Head downward until it locks into place.

7.6.
