Titan SF210JSL Safety And Operating Manual
8” Laser sLiding Compound mitre saw sF210JsL
saFetY and operating manuaL
8” Laser sLiding Compound mitre saw sF210JsL
GUARANTEE
This product carries a guarantee of 12 months. If your product develops a fault
within this period, you should,in the first instance contact the retailer where the item
was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
For further technical advice, spare parts or repair service (outside of guarantee) please
contact the customer helpline number on 0845 607 6380
Congratulations on your purchase of a
power tool from Titan Power
Tools (UK) Ltd. We want you to continue getting the best performance from
it so this handbook includes information on safety, handling and care. Please
retain this handbook in case you need to refer to any of the information in
the future.
Your
power tool comes with a 12-month guarantee,so should it develop
a fault within this period contact your retailer.
SAFETY INSTRUCTIONS
WARNING! To ensure safe operation when using your Sliding Mitre Saw with
Laser, make sure you follow basic safety principles to reduce risk of personal
injury, electric shock and fire. Please read the following instructions prior to
operating this product and keep for future use.
SAVE THESE INSTRUCTIONS
Safety instructions
1. Keep the work area clean.
Cluttered areas and benches invite injuries.
2. Consider work area environment.
Do not expose power tools to rain. Do not use power tools in damp or wet locations.
Keep the work area well lit. Do not use power tools where there is risk to cause fire
or explosion.
3. Guard against electric shock.
Avoid body contact with earthed or grounded surfaces (e.g. Pipes, radiators,
ranges, refrigerators, other metal surfaces).
4. Keep children away.
Do not let visitors touch the tool or extension cord. All visitors should be away
from area.
5. Store idle tools.
When not in use, tools should be stored in a dry, high or locked up place, out of
reach of children.
6. Do not force the tool.
It will do the job better and safer at the rate for which it was intended.
7. Use the right tool.
Do not force small tools or attachments to do the job of a heavy-duty tool. Do not
use tools for purposes not intended, for example, do not use circular saws to cut
tree limbs or logs.
8. Dress properly.
Do not wear loose clothing or jewellery, they can be caught in moving parts.
Rubber gloves and non-skid footwear are recommended when working outdoors.
Wear protecting hair covering to contain long hair.
9. Use safety glasses.
Also use face or dust mask if the cutting operation in dusty.
10. Connect dust extraction equipment.
If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used.
11. Do not abuse the cord.
Never carry the tool by the cord or yank it to disconnect it from the socket. Keep the
cord away from heat, oil and sharp edges.
12. Secure work.
Use clamp or a vice to hold the work. It is safer than using your hand and frees
both hands to operate the tool.
13. Do not overreach.
Keep proper footing and balance at all times.
8” Laser sLiding Compound mitre saw sF210JsL
14. Maintain tool with care.
Keep cutting tools sharp and clean for better and safer performance. Follow
instructions for lubrication and changing accessories. Inspect tool cord periodically
and if damaged have it replaced by an authorised service facility. Inspect extension
cords periodically and replace if damaged. Keep handles dry, clean and free of oil
or grease.
15. Disconnect tools.
When not in use, before servicing and when changing accessories such as blades,
bits and cutters, remove the mains plug from the socket.
16. Remove adjusting keys and wrenches.
Make the habit of checking to see that keys and adjusting wrenches are hat keys
and adjusting wrenches are removed from the tool before turning it on.
17. Avoid unintentional starting.
Do not carry a plugged-in tool with a finger on the switch. Ensure switch is in the
off when plugging in.
18. Use outdoor extension leads.
When tool is used outdoors, use only extension leads approved for outdoor
use.
19. Stay alert.
Watch what you are doing. Use common sense. Do not operate tool when you
are tired or under the influence of drugs or alcohol.
20. Check damaged parts.
Before further use of the tool, a guard or other part that is damaged should
be carefully checked to determine that it will operate properly and perform its
intended function. Check for alignment of moving parts, free running of moving
parts, breakage of parts, mounting and any other conditions that may affect its
operation. A guard or other part that is damaged should be properly repaired
or replaced by an authorised service centre unless otherwise indicated in this
instruction manual. Have defective switches replaced by an authorised service
facility. Do not use the tool if the switch dose not turn it on and off.
21. Warning.
The using of any accessory or attachment, other than those recommended in this
instruction manual may present a risk of personal injury.
22. Have your tools repaired by qualified person.
This electrical tool is in accordance with the relevant safety requirements.
Repairs should only be carried out by qualified persons using original spare
parts, otherwise this may result in considerable danger to the user.
Important note
Never stare directly into the laser beam and never point the beam at
anybody. The laser beam energy is extremely harmful to your eyes.
Remove the mains plug from the socket before carrying out any
adjustment or servicing.
AddITIONAl SAFETY INSTRUCTIONS FOR YOUR SlIdING
MITRE SAw wITh lASER.
1. Only wood or products such as medium density fibre board can be cut with this
saw. Other materials may shatter or cause the blade to grab.
2. Never fit substandard blades to the saw. Only fit correctly sized saw blade.
3. Let the blade reach full speed before commencing the cut.
4. Do not use damaged or worn blades.
5. Ensure that the directional arrow marked on the blade corresponds with the
rotational direction of motor.
6. Ensure that the movable guards operate freely without jamming.
7. Never cut pieces too small to be held securely against the straight guide leave
enough space for the hand to be a safe distance from the blade.
8. Regularly check the blade securing bolt.
9. Do not run the machine with any part of the casing missing or damaged.
10. Do not start the saw when the blade is inserted into the workpiece.
11. Let the blade come to a complete stop before removing any jammed or offcut
material from around the blade area.
Do not attempt to stop the blade by placing sideways pressure on the blade disc.
12. Before cutting let the saw blade run freely for a few seconds. If it makes an unfamiliar
sound or vibration switch it off immediately and disconnect from the power supply.
Investigate cause or consult your dealer.
13. Ensure all securing clamps are tight and check for excessive play.
14. Never try to cut freehand. Always ensure that the workpiece is securely pressed
against the straight guide and table support surface.
15. Disconnect from the mains supply, pull down the handle of the saw. With the
blade in its furthest down position, rotate the blade by hand to ensure it is free from
obstruction. Repeat this procedure at all maximum mitre and bevel positions before
commencing work.
16. Ensure that the workpiece to be cut off has sufficient room to move sideways.
Failure to do so may result in the off cut binding against the blade.
17. Ensure that irregular or round piece to be cut off has sufficient room to move or
twist so that they cannot pinch the blade.
18. Do not forget to remove any adjustment keys, spanners and wrenches before
switching on the tool.
19. When the machine is in operation, keep hands away form the cutting area.
20. Always ensure the safety guard is in working order before use. Should the guard
not close quickly over the saw blade, do not use.
21. Do not tie or wedge open the safety guard.
22. Only use blades with the correct bore size for the spindle.
23. Do not use saw blade which does not comply with the characteristics specified in
these instructions.
24. Do not use saw blades made of high speed steel.
25. Do not cut into screws or nails. Inspect workpiece for nails and screws before use.
26. Keep the power cord well away from the cutting area during use. Always position
the cord so that it will not be caught in the workpiece when the saw is in use.
8” Laser sLiding Compound mitre saw sF210JsL
SAFETY POINTS FOR YOUR LASER
The laser device fitted to this tool is class 2 with a maximum radiation
of 1mW and 650nm wavelength. These lasers do not normally present
an optical hazard although staring at the beam may cause flash blindness. Do
not stare directly at the laser beam. A hazard may exist if you deliberately
stare into the beam, please observe all safety rules as follows:
1. The laser shall be used and maintained in accordance with the
manufacturer’s instructions.
2. Never aim the beam at any person or an object other than the work piece.
3. The laser beam shall not be deliberately aimed at another person and
shall be prevented from being directed towards the eye of a person for
longer than 0.25 seconds.
4. Always ensure the laser beam is aimed at a sturdy work piece without
reflective surfaces, e.g wood or rough coated surfaces are acceptable.
Bright shiny reflective sheet steel or similar is not suitable for laser applications as the
reflective surface may direct the laser beam back at the operator.
5. Do not change the laser device with a different type. Repairs must be
carried out by the manufacturer or an authorised agent.
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help
reduce hand arm vibration syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide indicative vibration test
results to enable users to make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration total values (triax vector sum) determined according to EN 61029:
Work mode description 1 Vibration emission value ah = 1.09m/s²
Uncertainty K = 1.5m/s²
The declared vibration emission value should be used as a minimum level and
should be used with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE
website has further information.
The declared vibration emission been measured in accordance with a standardised
test stated above and may be used to compare one tool with another
The declared vibration emission value may also be used in a preliminary
assessment of exposure.
Warning: The vibration emission value during actual use of the power tool
can differ from the declared value depending on the ways in which the tool is
used dependant on the following examples and other variations on how the tool is
used:How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good
condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed
Warning: identify safety measures to protect the operator that are based on
an estimation of exposure in the actual conditions of use (taking account of
all parts of the operating cycle such as the times when the tool is switched off and
when it is running idle in addition to the trigger time).Note The use of other tools will
reduce the users’ total working period on this tool.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
8” Laser sLiding Compound mitre saw sF210JsL
Maintain this tool in accordance with these instructions and keep well lubricated
(where appropriate)
Avoid using tools in temperatures of 10°C or less
Plan your work schedule to spread any high vibration tool use across a number of
days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to help
identity any vibration related diseases at an early stage, prevent disease progression
and help employees stay in work.
SYMBOlS
Read the manual
Warning
Wear gloves
Wear dust mask
Wear ear protection
Wear eye protection
Loading...
