Timex T117 User Manual

Model T117

Travel Alarm Clock

With Flashlight

For Models That Require More Than One Battery

• Do not mix with used or other battery types/brands • Do not heat above 75ºC (167ºF)

• Replace all batteries at the same time • Do not expose contents to water

• Do not open batteries • Do not charge or recharge

• Do not dispose of in fire • Do not install backwards

Thank you for purchasing this Timex model T117 Travel Alarm Clock with Flashlight.
Please read this instruction manual carefully and completely to insure that you
understand the proper operation of your new alarm clock, and that you get the
maximum benefit from all the advanced features included in this model.

For additional information, online registration,
and exclusive special offers visit our website:

www.timexaudio.com

For questions or comments regarding this or other

products, please call our toll-free number 1-800-888-4491.

LED Flashlight
(pull out to turn on,
push in to turn off)

Fig. 2

(battery cover removed)

Controls and Their Functions

Fig.1

Front of Unit

Reverse Set

Rear of Unit

12/24 Hour Button

Forward Set

Alarm / Clock
Setting Turn Knob
(pull out for clock
setting)

12/24 HR

Snooze/Light Button

Snooze /
Alarm Off Switch

Battery Installation

Installing the Batteries

Remove the battery compartment cover by pressing on both of the locking tabs
together and lifting the cover upward.

Insert 4 “AAA” batteries in the battery compartment located at rear. We recommend
using a well-known brand of alkaline batteries for longest life and best performance.
Be sure to insert the batteries according to the polarity markings engraved in the
compartment. If the batteries are inserted incorrectly the unit will not work.

Replace the battery compartment cover and make sure it is securely locked.

Battery Door

Battery Compartment
