PERSONAL ALARM
WITH TORCH LIGHT
Cat No. TGAM25
INSTRUCTIONS
INSTALLATION & OPERATING
TGAM25 Personal Alarm with
Torch Light
Please read the instructions before using the
product and retain for future use.
Key ring
Chain
Pin
Push button
activates light
Front View
LED
lamp
Tough, impact
resistant case
Alarm
sounder
Positive
end (+)
Negative
end (-)
Fixing screw
hole for
battery cover
Battery
compartment
(cover removed)
Rear View
Tongues
Battery cover
Screw hole
Introduction
The TGAM25 Personal Alarm produces a
piercing 90dB alarm when the pin is pulled
from the body of the unit. The alarm continuing
until the pin is replaced.
This will provide an alarm when the user
considers his or her personal safety is at risk.
An additional function is available by using the
push button on the front of the unit. When
pressed this provides a light from the bottom of
the unit to enable the user to find keyholes in
the dark, amongst other uses.
Battery Insertion/Replacement
Remove the screw holding the battery cover in
place, then remove the battery cover
disengaging the tongues from the case.
Four silver oxide batteries are required. Types
SR44, 357, SR44W, RW24, SG13, SR1154, V303,
A are all compatible.
Remove the old batteries if necessary. Insert the
batteries as shown in the product rear view on
4
page 2.
Replace the battery cover by engaging the two
tongues on the cover with the matching slots in
the case, then pressing the cover into place
before inserting and tightening the fixing screw.
Alarm Operation
Pull the pin from the case by holding the case
and pulling at the key ring and chain. The
alarm will start immediately and continue until
the pin is replaced or the batteries are flat.
Note: Guard against situations where the pin
may be removed inadvertently by, for example,
keys attached to the key ring becoming
entangled with other objects in a bag.
Light Operation
Press the button on the front face to turn the
light on. The light is illuminated for as long as
the button is pressed.
Specifications
THREE YEAR
GUARANTEE
3
Alarm: 90dB
Batteries: Silver Oxide, 4 x SR44 or similar*.
*357, SR44W, RW24, SG13, SR1154,
V303, A.
Not to be immersed in water.
6
3 Year Guarantee
In the unlikely event of this product
becoming faulty due to defective material
or manufacture within 3 years of the date
of purchase, please return it to your supplier
in the first year with proof of purchase and
it will be replaced free of charge.
For the second and third years or any
difficulty in the first year telephone the
helpline on 020 8450 0515.
HELPLINE
020-8450-0515
For a product brochure please contact:
Timeguard Ltd.
Victory Park, 400 Edgware Road,
London NW2 6ND
or email csc@timeguard.com
020-8452-1112
