Timeguard TG24B User Manual

24 HOUR SEGMENT

TIMESWITCH

Cat. No TG24 (Single)

TG44 (Twin), TG64 (Triple)

Operating Instructions

instructiOns

Operating

TG24 (Single) / TG44 (Twin) / TG64 (Triple)
24 Hour Segment Timeswitch

Tough flame
retardant
casing

Time of day

1

setting ring

Appliance
socket

Time control segments 1 segment = 15 minutes
Push all segments downwards for ON, leave in
upward position for OFF.

Time of day

pointer

Manual

override

switch

ON segments

(pushed down)

Programming

Segment shown in OFF
(upper) position

Segment shown in ON
(lower) position

1 Decide what times you would like the TG24/TG44 to switch

2

ON and OFF.

2 Push all the segments downwards for the complete duration

of an ON period and leave them all in the upper position for
an OFF period (see diagram above left).
The minimum switching interval is 15 minutes and this can
be increased in 15 minute steps.

3 Ensure that the override switch is in the timed ( ) position

as shown in the diagram above right.

Override
switch

Permanently

ON

Timed
