INSTALLATION & OPERATING
INSTRUCTIONS
1000W DUSK TO DAWN
LIGHT CONTROLLER
Cat No. SLDD1000
1
Introduction
The SLDD1000 features an integral daylight sensing
photocell which will automatically switch connected
lights on at dusk and off at dawn.
It incorporates an adjustable operation delay to prevent
mis-operation due to e.g. car headlamps.
C
To p
Cable
clamp
Mains in Output
LED
Common
Cable clamp
fixing screws
x 2
B
Insert
screwdriver
and twist
Front cover
hinges
upwards
A
2
Parts included
• Photocell (Dusk/Dawn) Switch.
• Instruction manual. Please keep safe for future
reference.
• Accessory Pack.
Tools and parts needed
• 3 core cable
• Electric/hand-held drill & bits.
• Terminal or Electricians screwdriver
• Wire cutters
Unit can be used indoors or outdoors, but is specifically
designed for outdoor use.
Do not attempt to install during wet weather, if you are
suffering from nausea or dizzy spells or if you are
taking any medication with similar side effects.
Do not attempt to install during wet weather, if you are
suffering from nausea or dizzy spells or if you are
taking any medication with similar side effects.
If in any doubt, consult a qualified electrician.
D
Lux
Time delay
View on underside of unit shows adjustments.
