Page 1
TWC24UL
COOK
LIKE
A
GOD
24 INCH SINGLE ZONE WINE COOLER
USE & CARE MANUAL
Page 2
USE AND CARE MANUAL
24 INCH SINGLE ZONE
WINE COOLER
TWC24UL
thorkitchencom
#OOKLIKEAOD
Page 3
Thank you for choosing THOR KITCHEN. This appliance has been manufactured by Thor International,
4651 E Airport Drive, Ontario, CA 91761. This manual contains all the information you will need to
install / use the appliance correctly and safely. Please read all the instructions prior using the appliance,
and keep this manual in a secure place for future reference. Do not remove the attached adhesive
identification label containing code, model number, manufacturer and other information from the
appliance. This label will be used by the THOR KITCHEN authorized service representative in the event
that your appliance needs servicing.
Page 4
TABLE OF CONTENTS
IMPORTANT SAFETY INFORMATION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
1�1 Appliance safety � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2
1�2 Information for proper disposal � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3
1�3 Explanation of symbols � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
1�4 Signal symbol/word definitions� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
INTENDED USE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
APPLIANCE DESCRIPTION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
3�1 Overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
3�2 Control panel description� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
3�3 Display indicators � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
BEFORE FIRST USE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
4�1 Tools needed � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
4�2 Location requirements � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
4�3 Leveling the appliance� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
4�4 Cleaning � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
INSTALLATION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
5�1 Installing the door handle� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
5�2 Built-in installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
5�3 Installing the floor mounted anti-tip brackets
USE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
6�1 Switching on and off� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
6�2 Arranging and placing bottles� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
6�3 Adjusting controls and settings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 11
6�4 Alarms and error codes � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
6�5 Wine storage tips � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
CLEANING� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 13
MAINTENANCE � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 14
TRANSPORTATION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
DISPOSAL � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
FREQUENTLY ASKED QUESTIONS � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
APPLIANCE SPECIFICATIONS � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
WARRANTY � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
1
Page 5
IMPORTANT SAFETY INFORMATION
1.1 Appliance safety
When using electrical appliances, basic safety precautions should always be followed to reduce the risk
of fire, electric shock, injury and/or death including the following:
WARNING
WARNING
WARNING
WARNING
WARNING
This appliance is not intended for use by persons (including children) with reduced physical, sensory
•
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety�
Children should be supervised to ensure that they do not play with the appliance�
•
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
•
qualified persons in order to avoid a hazard�
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear
of obstruction�
Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer�
When positioning the appliance, ensure the supply cord is not trapped or damaged�
Do not locate multiple portable socket outlets or portable power supplies at the rear of
the appliance�
Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer�
The appliance must be plugged into its own dedicated 115 Volt, 60 Hz, 15 Amp, AC only electrical
•
socket outlet� The supply cord of the appliance is equipped with a three prong grounding plug for
your protection against electrical shock hazards� It must be plugged directly into a properly grounded
three prong socket outlet� The socket outlet must be installed in accordance with local codes
and ordinances� Consult a qualified electrician� Avoid connecting the appliance to a Ground Fault
Interrupter (GFI) circuit� Do not use an extension cord or adapter plug�
Allow disconnection of the appliance from the supply after installation� The disconnection may be
•
achieved by having the plug accessible or by incorporating a switch in the fixed wiring in accordance
with the wiring rules�
Never unplug the appliance by pulling on the power cord� Always grip the plug firmly, and pull straight
•
out from the socket outlet to prevent damaging the power cord�
Unplug the appliance before cleaning to avoid electrical shock�
•
Performance may be affected if the voltage varies by 10% or more� Operating the appliance with
•
insufficient power can damage the compressor� Such damage is not covered under your warranty�
Do not plug the appliance into an electrical socket outlet controlled by a wall switch or pull cord to
•
prevent the appliance from being turned off accidentally�
2
Page 6
IMPORTANT SAFETY INFORMATION
Do not store explosive substances such as aerosol cans with a flammable propellant in the appliance�
•
The fumes can create a fire hazard or explosion�
Use two or more people to move and install the appliance� Failure to do so can result in back or other
•
injury�
This appliance is intended to be used in household and similar applications such as
•
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications�
The maximum weight capacity for each shelf is 55 lbs (25 kg)�
•
Do not pull out more than one shelf at a time to prevent the appliance tipping over�
•
The built-in LED of this appliance is not replaceable by the user� When the LED reaches its end of life,
•
continue to use the appliance as normal�
Never clean refrigerator parts with flammable fluids� The fumes can create a fire hazard�
•
The flammable refrigerant isobutene (R600a) is contained within the refrigerant circuit of the
•
appliance, a natural gas with a high level of environmental compatibility, which is nevertheless
flammable� During transportation and installation of the appliance, ensure that none of the
components of the refrigerant circuit becomes damaged�
1.2 Information for proper disposal
WARNING
Risk of child entrapment. Before you throw away your old appliance:
Take off the doors�
•
• Leave the shelves in place so that children may not easily climb inside�
WARNING
Risk of fire! Flammable materials� This appliance uses refrigerant R-600a
and must be disposed of by a qualified service technician with knowledge
of appropriate gas reclamation methods�
3
Page 7
IMPORTANT SAFETY INFORMATION
1.3 Explanation of symbols
The following symbols are used in this user manual, on the appliance, or on the packaging�
WARNING! Risk of fire/flammable materials.
The ETL Listed Mark is proof that the appliance has been independently tested and
meets the applicable published standard�
1.4 Signal symbol/word definitions
The following symbols are used in this user manual�
Indicates a potentially hazardous situation which, if not avoided, will result in
DANGER
WARNING
CAUTION
NOTICE
death or serious injury�
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury�
Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury�
Indicates installation, operation or maintenance information which is important
but not hazard-related�
INTENDED USE
This appliance is intended for storing and chilling up to 45 wine bottles inside a kitchen, pantry,
•
basement, garage and similar spaces�
This appliance is designed for built-in or freestanding installation�
•
This appliance is not intended for storing food or biological substances�
•
For household and residential use only�
•
4
Page 8
3.1 Overview
APPLIANCE DESCRIPTION
1 2 43
8
7
Housing
1
Door pins
2
Door handle
3
Door
4
Lock
5
Ventilation opening
6
Leveling feet
7
Supply cord with plug
8
Control panel
9
Shelf brackets
10
9
15
14
13
6
5
16
19
Glass panel
11
Door gasket
12
Anti-tip bracket slots
13
Shelves
14
Interior light
15
End caps x 2
16
Door keys x 2
17
Hex key
18
Anti-tip brackets x 2
19
Stud anchors x 2
20
17 18
1110
12
20
3.2 Control panel description
A B C D E F G
5
Page 9
APPLIANCE DESCRIPTION
Button/Part Description
A
B
C
D
E
F
G
3.3 Display indicators
Fan
indicator
Lock/unlock control panel buttons
Mute/unmute door and temperature alarms and button sounds
Switch light on/off
Change temperature unit (°F/°C)
Display
Increase temperature
Decrease temperature
Switch appliance on/off
Set
temperature
Light
indicator
Actual
temperature
Lock/
unlock
indicator
Temperature
unit
BEFORE FIRST USE
DANGER
Remove and dispose of all packaging materials�
•
Check the appliance for any damage or broken parts�
•
Check that all components are included�
•
Let the appliance stand upright for at least 24 hours to allow the refrigerant to settle after transport�
•
Let the appliance reach the set temperature before placing any wine bottles inside�
•
Risk of suffocation! Keep all packaging materials away from children and pets� These
materials pose a threat of suffocation�
6
Page 10
4.1 Tools needed
BEFORE FIRST USE
Ø9.5 mm
3/8"
Ø9.5 mm
3/8"
4.2 Location requirements
WARNING
The appliance should be installed near a grounded, non-GFCI, electrical socket outlet� Do not use an
•
extension cord or an adapter plug�
Risk of fire!
Do not block the ventilation opening (6)� Insufficient ventilation could cause the
•
appliance to overheat and cause fire� Leaked refrigerant may cause fire and explosion�
Accumulated dust on the plug may cause fire� Choose a location that prevents dust
•
accumulation or allows access for cleaning the plug�
Place the appliance on a level, strong enough floor that can support a fully loaded appliance� On
•
carpet or vinyl flooring, it is recommended to place a plastic mat underneath�
Place the appliance out of direct sunlight and away from heat sources such as the dishwasher or
•
range�
Do not install the appliance in a poorly insulated or heated area to avoid affecting cooling performance
•
or creating external condensation on the appliance�
Leave at least 2 in (5 cm) of space behind the appliance and at least 0�8 in (2 cm) from the sides and
•
top of the appliance for adequate air flow� Make sure there is enough space at the front to allow the
door to fully open�
Keep the appliance away from hazardous or combustible substances�
•
4.3 Leveling the appliance
The appliance must rest firmly on a level surface in order to function properly� If the appliance is not
leveled, the door (4) may be misaligned when installed� This can lead to cooling and moisture issues if the
door (4) does not completely close�
1� Place a carpenter's level on top of the appliance to check if it needs leveling�
2� Turn the leveling feet (7) clockwise to lower the appliance or counter-clockwise to raise the appliance
until the carpenter's level shows the appliance is level�
7
Page 11
BEFORE FIRST USE
4.4 Cleaning
1� Wipe the interior surfaces and shelves (14) with lukewarm water and a soft, clean cloth�
2� Wipe dry with a soft, clean cloth�
INSTALLATION
5.1 Installing the door handle
1� Attach the end caps (16) to both ends of the door
1
2
handle (3)�
2� Place the assembled door handle (3) onto the
door pins (2) (Fig� 1)�
1
3� Tighten the pre-installed screws inside the end
caps (16) with the hex key (18) (Fig� 1)� Do not
overtighten the screws�
3
5.2 Built-in installation
CAUTION
NOTICE
Make sure the installation area has adequate space for the appliance (Fig� 2)�
Risk of injury! Keep fingers out of the "pinch point" areas� Clearances between the
door (4) and housing (1) are necessarily small� Be careful closing door (4) when children
are in the area�
Adjust the leveling feet (7) as needed before placing the appliance in a recessed location (see
chapter "Leveling the appliance")� The leveling feet adjustment range is 0 - 0�4” (0 - 1 cm)�
2
24 in
(61 cm)
23 9/16 in
(59.6 cm)
23 7/16 in
(59.6 cm)
21 7/16 in
(54.5 cm)
16
18
2
24 7/16 in
(62 cm)
34 5/8 in
(88 cm)
8
25 15/16 in
(65.8 cm)
34 1/4 in
(87 cm)
Page 12
5.3 Installing the floor mounted anti-tip brackets
INSTALLATION
CAUTION
CAUTION
NOTICE
1� Position the anti-tip brackets (19) 6” (15�2 cm) apart on the floor� Mark the location of the mounting
holes on the floor (Fig� 3)� Make sure there is at least 2 in (5 cm) of space behind the appliance�
2� Drill two mounting holes over the marked locations 1 7/16” (3�7 cm) deep using a 3/8” (9�5 mm) drill
bit (Fig� 4)�
Risk of injury! Wear appropriate protective gear to avoid injury�
Risk of property damage! Make sure there are no gas pipes, water pipes, or electrical
wires underneath the floor�
For installation on tiled floors: for porcelain tiles, use a carbide-tipped drill bit; for natural
•
stone, use a diamond-tipped drill bit�
To prevent natural stone surfaces from overheating during drilling, drip some water on top
•
of the mounting hole location�
Place masking tape around the surrounding surface to prevent scratching the area if the
•
drill bit slips�
Drill at a slow speed to avoid cracking the tile�
•
For wood and concrete flooring, use a standard drill bit�
•
If in doubt about floor installation, contact a qualified professional�
•
3
4
19
>2”
6”
Rear wall
3� Insert the stud anchors (20) inside the holes (Fig� 5)�
4� Remove the nuts from the stud anchors (20) (Fig� 6)�
15.2 cm)
>5 cm)
5
20
9
6
20
Page 13
INSTALLATION
5� Place the anti-tip brackets (19) on the stud anchors (20), then refit and tighten the nuts onto the stud
anchors (20) (Fig� 7)�
6� Slide the appliance toward the anti-tip brackets (19) so that the brackets insert and lock completely
into the anti-tip bracket slots (13) (Fig� 8)�
7
19
20
8
19
13
USE
6.1 Switching on and off
1� Connect the plug (8) to a suitable socket outlet� The appliance switches on automatically and the
display (D) lights up�
2� The display (D) shows the default temperature setting, +46 °F (+8 °C)�
6.2 Arranging and placing bottles
CAUTION
Extend one shelf (14) at a time and place bottles flat evenly across and throughout the top and bottom
•
of the housing (1)� Do not overload the shelves (14)�
Do not let the bottles touch the back of the housing (1) to allow adequate air circulation�
•
Remove a shelf (14) to create extra space for oversized or oddly shaped bottles, or for vertical
•
storage (Fig� 9)� To refit a shelf (14), align it inside the shelf bracket (10), then push until there is a
click noise�
The actual wine bottle capacity depends on the size, shape and layout of the bottles�
•
Risk of damage or injury! Remove bottles from the shelves (14) before rearranging the
shelf layout�
10
Page 14
9
10 14
6.3 Adjusting controls and settings
USE
NOTICE
The appliance's internal memory stores the last used settings� If the appliance is switched off
or loses power, the previous settings appear on the display (D) when the appliance is switched
back on�
Temperature
NOTICE
•
•
The temperature setting ranges from +41 °F (+5 °C) to +64 °F (+18 °C)�
Press the button (E) to increase the temperature by +1 °F/+1 °C� The set value blinks for
5 seconds�
Press the button (F) to decrease the temperature by +1 °F/+1 °C� The set value blinks for
5 seconds�
Interior light
NOTICE
•
•
If the interior light (15) is switched on, it stays on until it is manually switched off�
Press the button (C) once to switch the interior light (15) on or off�
Press and hold the button (C) for 3 seconds to toggle the temperature unit between Fahrenheit
and Celsius�
Mute and unmute alarms and sounds
Press the button (B) once to mute the door alarm and temperature alarm�
•
Press and hold the button (B) for 3 seconds to mute the control panel buttons' sound�
•
Lock/unlock
NOTICE
Press and hold the
The control panel buttons (except for the
buttons are pressed on the control panel (9)�
button (A) for 3 seconds to lock or unlock the control panel buttons�
button (A)) lock automatically after 1 minute if no
11
Page 15
USE
Power
Press and hold the button (G) for 1 second to switch the appliance on�
•
Press and hold the button (G) for 3 seconds to switch the appliance off�
•
Demo mode
NOTICE
Demo mode is for display purposes only� The compressor, fan and door alarm do not work in
•
demo mode�
The LED light remains on while the door (4) is closed�
•
Press and hold the
mode�
6.4 Alarms and error codes
Door alarm
NOTICE
•
•
Temperature alarms
NOTICE
•
•
The compressor and fan stop running if the door (4) is open for more than 1 minute� They
•
resume once the door (4) is closed�
If the door alarm is muted, the display (D) keeps flashing to signal that the door (4) is open�
•
An alarm sounds when the door (4) is open for more than 1 minute� The display (D) flashes�
Close the door (4) to silence the alarm� The display (D) stops flashing�
If the temperature alarm is muted, the display (D) keeps flashing to signal that the temperature
has changed beyond the set temperature�
If the temperature inside the housing (1) is +39 °F (+4 °C) lower than the set temperature for over
1 hour, an alarm sounds� The display (D) shows and flashes�
If the temperature inside the housing (1) is +39 °F (+4 °C) higher than the set temperature for over
24 hours, an alarm sounds� The display (D) shows and flashes�
button (E) and button (F) at the same time for 3 seconds to turn on demo
Error code guide
When the display (D) shows or , the compressor, fan and defrosting system shut down�
•
When the display (D) shows or , the compressor and fans shut down for 5 minutes, then
•
resume immediately after�
12
Page 16
Code Error
Internal temperature sensor has a broken circuit
Internal temperature sensor short-circuited
Defrosting sensor has a broken circuit
Defrosting sensor short-circuited
High temperature alarm
Low temperature alarm
Display flashes Door open alarm
6.5 Wine storage tips
Store bottles with corks horizontally to prevent the corks from drying out� For bottles with other
•
closures, such as screw caps, vertical storage is acceptable�
Set the appropriate temperature for the wine� In general, wine should be kept between +52 °F (+11 °C)
•
to +57 °F (+14 °C)�
USE
Wine Storage temperature range
Full-bodied red wine +63 °F to +66 °F (+17 °C to +19 °C)
Light-to medium-bodied red wine +54 °F to +61 °F (+12 °C to +16 °C)
Dry white wine +46 °F to +54 °F (+8 °C to +12 °C)
Sweet wine +51 °F to +59 °F (+11 °C to +15 °C)
Champagne +43 °F (+6 °C)
CLEANING
Switch the appliance off and disconnect the plug (8) from the socket outlet�
•
Wipe away any dust from the exterior of the appliance with a soft, dry cloth�
•
Remove all items and the shelves (14) from the appliance�
•
Wipe away any condensation with a soft, absorbent cloth�
•
Never use corrosive detergents, wire brushes, abrasive scourers, or metal/sharp utensils to clean the
•
appliance�
Stainless steel surfaces
Use a cleaner intended for stainless steel as needed to keep the stainless steel surfaces free from dust,
fingerprints and other residue� Follow the manufacturer's instructions for best results�
13
Page 17
CLEANING
Glass panel
Use a cleaner intended for glass as needed to keep the glass panel (11) free from dust, fingerprints
•
and other residue� Follow the manufacturer's instructions for best results�
Avoid applying the glass cleaner on the surrounding stainless steel surface�
•
Interior surfaces
1� Prepare a cleaning solution of 2 tablespoons of baking soda and 1 quart (0�95 l) of water�
2� Wipe the interior surfaces with the prepared cleaning solution and a soft, clean cloth�
3� Wipe remaining residue with a soft cloth and clean water� Wipe dry with a soft, clean cloth�
4� Wipe the control panel (9) with a soft cloth and clean water� Wipe dry with a soft, clean cloth�
Shelves
1� Remove all items and the shelves (14) from the appliance�
2� Wipe the shelves (14) with a mild cleaning detergent and warm water�
3� Wipe the shelves (14) dry with a soft, clean cloth before refitting them onto the shelf brackets (10)�
Door gasket
Wipe the door gasket (12) when visibly dusty or dirty with a soft, damp cloth�
MAINTENANCE
For any servicing other than mentioned in this user manual, contact a qualified service technician for
repairs and maintenance�
Defrosting
The appliance defrosts automatically�
•
The compressor stops temporarily while the fans circulate air around the coils to melt the ice�
•
Power failure
In case of power failure, avoid opening the door (4) to maintain a consistent temperature until the
•
power is restored�
If the plug (8) is disconnected or if the appliance is switched off, wait at least 5 minutes before
•
switching the appliance on again� This avoids damaging the compressor�
14
Page 18
Vacation and periods of absence
MAINTENANCE
WARNING
If leaving the appliance unused for several months:
Switch the appliance off and disconnect the plug (8) from the socket outlet�
•
Remove all items and the shelves (14) from the appliance�
•
Clean the appliance (see chapter "CLEANING")�
•
Prop the door (4) slightly open to prevent odor and mold�
•
Risk of child entrapment. If leaving the door (4) open, make sure children cannot climb
inside the appliance and become entrapped�
TRANSPORTATION
If moving or transporting the appliance:
Switch the appliance off and disconnect the plug (8) from the socket outlet�
•
Remove wine bottles and clean the appliance (see chapter "CLEANING")�
•
Tape the shelves (14) securely in place inside the appliance to prevent damage�
•
Tape the door (4) closed�
•
Wrap the appliance with a protective cover, such as a blanket or bubble wrap�
•
During transport, secure the appliance in an upright position so it does not slide or tip over�
•
Dispose of the appliance according to local regulations�
•
This appliance contains refrigerants and gases in the insulation� These must be removed
•
and recycled by a qualified service technician�
Make sure that the refrigerant tubing is not damaged prior to disposal�
•
DISPOSAL
15
Page 19
FREQUENTLY ASKED QUESTIONS
Problem Solution
Check if the plug (8) is properly connected to the socket outlet�
The appliance does not
switch on�
The appliance is not cold
enough�
Interior light (15) does not
work�
The compressor and fan
switch on and off frequently�
•
Check if the socket outlet is operational�
•
Adjust the set temperature lower�
•
Reduce the amount of bottles inside the appliance�
•
Open the door (4) only when necessary�
•
Make sure the door (4) closes completely�
•
Clean the door gasket (12)�
•
Check if the plug (8) is properly connected to the socket outlet�
•
Press the button (C) to switch the interior light (15) on�
•
The circuit breaker may be tripped or there is a blown fuse�
•
The ambient temperature may be higher than normal� If possible,
•
adjust the ambient temperature�
Reduce the amount of bottles inside the appliance�
•
Open the door (4) only when necessary�
•
Make sure the door (4) closes completely�
•
Clean the door gasket (12)�
•
Make sure the appliance is on stable and level ground� Adjust the
•
leveling feet (7) if necessary�
The appliance makes
unusual noise�
Condensation builds up
inside and outside the
appliance and door (4)�
Move the appliance to make sure it does not touch surrounding
•
objects or walls�
Gurgling noises are a result of refrigerant flowing through the
•
refrigerant system� This is normal�
The ambient temperature may be higher than normal� If possible,
•
adjust the ambient temperature�
Open the door (4) only when necessary�
•
Make sure the door (4) closes completely�
•
16
Page 20
APPLIANCE SPECIFICATIONS
Rated voltage 115 V AC, 60 Hz
Rated power 100 W, 2�8 A
Protection class I
Cooling temperature range +41 °F to +64 °F (+5 °C to +18 °C)
3
Maximum capacity 5�3 ft
Refrigerant type R-600a, 1�2 oz (33 g)
(152 L), 45 bottles
Foaming agent Cyclopentane (C
Cooling system Compressor cooling
Climate type SN
IP rating IPX4
Net weight 129 lbs (59 kg)
Dimensions (W x D x H) 23 7/16 x 23 7/16 x 34 1/4” (59�6 x 59�5 x 87 cm)
5H10
)
WARRANTY
Warranty&Service
This appliance has been manufactured by Thor International, 4651 E Airport Drive, California 91761
For Customer Service, please call (877) 288 - 8099
For the most up to date warranty and service policy, please refer to our website
WWW�THORKITCHEN�COM/WARRANTY-REGISTRATION
For in-warranty service requests, please visit our website at
WWW�THORKITCHEN�COM/SERVICE
Please Note: You must provide proof of purchase or installation date for any in-warranty service requests
17
Page 21
WELCOME
TO THE CLUB
You chose THOR Kitchen to enhance your culinary journey and
we’re stoked to have you in the club. Think of it as a secret society
of really savvy people, such as yourself, choosing professional
power and performance at an affordable price.
Register your product by following the steps below.
WARRANTY REGISTRATION
01
Scan the QR code or visit
thorkitchen.com/warranty
02
Input your product info
and select register
03
You’re done.
Let’s get cookin’.
WARRANTY NEED PARTS?
thorkitchencom
#OOKLIKEAOD
Loading...
