OWNER’S MANUAL
Class A and Class C Motorhomes
WARNING
Operating, servicing and maintaining a passenger vehicle or offroad vehicle can expose you to chemicals including engine exhaust,
carbon monoxide, phthalates, and lead, which are known to the State
of California to cause cancer and birth defects or other reproductive
harm. To minimize exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a well-ventilated
area and wear gloves or wash your hands frequently when servicing
your vehicle.
For more information go to: www.P65Warnings.ca.gov/passengervehicle
Congratulations on purchasing your new or Motor Coach Recreational Vehicle!
We sincerely thank you for choosing and putting your faith in us. Our goal is to provide you with a quality motorized recreational vehicle at a
reasonable price.
Your motorhome was built following the high standards set by or Motor Coach (TMC), the Recreational Vehicle Industry Association
(RVIA), and (if applicable) the Canadian Standards Association (CSA) as well as complying with the requirements of all applicable state and
federal agencies.
Your motorhome is designed to provide you with carefree, comfortable travel and vacationing. Our hope is to provide you with many years of
enjoyment and great memories.
Our customers are extremely important to us, and we want to assure you that we will always strive to do everything possible to continue to earn
your trust and goodwill.
Welcome to the wonderful world of RVing and to the or Motor Coach family.
Happy Travels!
Made to fit.
PO Box 1486 Elkhart, Indiana 46515 - 1486 (Toll Free) 877.855.2867 thormotorcoach.com
Table of Contents
Introduction
About This Owner's Manual . . . . . . . . . 1
TMC Warranty Guide . . . . . . . . . . . . 1
Owner’s Packet . . . . . . . . . . . . . . . 1
Chassis Packet . . . . . . . . . . . . . . . 2
Online Customer Support . . . . . . . . . 2
Contact . . . . . . . . . . . . . . . . . . . 2
Section 1: Customer Information
Dealer’s Responsibility . . . . . . . . . . . 3
Customer’s Responsibility . . . . . . . . . . 3
Change of Address or Ownership . . . . . 4
How to Obtain Assistance . . . . . . . . . 5
Suggestions for Obtaining Service . . . . . 6
Emergency Weekend or After Business
Hours Warranty Repair Assistance . . . . 7
Obtaining Service Repair at Thor Motor
Coach . . . . . . . . . . . . . . . . . . . 7
Replacement Parts . . . . . . . . . . . . . 8
Cold Weather Usage . . . . . . . . . . . . 8
Extended Stay Usage . . . . . . . . . . . . 8
Thor Diesel Club . . . . . . . . . . . . . . 9
Website Usage Disclaimers . . . . . . . . 10
Website Disclaimer of Warranty . . . . 10
Disclaimer of Endorsement . . . . . . . 10
Reporting Safety Defects . . . . . . . . . 11
In the United States . . . . . . . . . . . 11
In Canada . . . . . . . . . . . . . . . . 12
Section 2: Safety and Vehicle
Identification
Safety Alerts . . . . . . . . . . . . . . . . 13
Vehicle Identification Decals and Plates . . 14
Fire Safety . . . . . . . . . . . . . . . . . 14
Fire Extinguisher . . . . . . . . . . . . . . 16
Operation . . . . . . . . . . . . . . . . 16
Inspection . . . . . . . . . . . . . . . . 16
Replacement . . . . . . . . . . . . . . 17
Smoke Alarm . . . . . . . . . . . . . . . 17
Operation . . . . . . . . . . . . . . . . 17
Test . . . . . . . . . . . . . . . . . . . 18
Maintenance . . . . . . . . . . . . . . . 18
Replacement . . . . . . . . . . . . . . 18
Carbon Monoxide (CO) . . . . . . . . . . 19
Safety Regulations and Propane Gas . . . 20
Combination Carbon Monoxide and
Propane Alarm . . . . . . . . . . . . . 23
What to do if the Alarm Sounds . . . . . 24
Test . . . . . . . . . . . . . . . . . . . 25
Maintenance . . . . . . . . . . . . . . . 25
Replacement . . . . . . . . . . . . . . 25
Exhaust Fuel Fumes . . . . . . . . . . . . 25
Emergency Egress Window . . . . . . . . 26
Operation . . . . . . . . . . . . . . . . 27
Maintenance . . . . . . . . . . . . . . . 27
Seat Belts . . . . . . . . . . . . . . . . . 28
Operation . . . . . . . . . . . . . . . . 29
Inspection and Replacement . . . . . . 29
Child Safety Restraint System . . . . . . . 30
Rear Vision Camera System . . . . . . . 31
Prep Only . . . . . . . . . . . . . . . . 31
Emergency Stopping . . . . . . . . . . . 31
Laws of The Road . . . . . . . . . . . . . 32
Condensation . . . . . . . . . . . . . . . 32
Chemical Sensitivity . . . . . . . . . . . . 33
Formaldehyde . . . . . . . . . . . . . . 34
Ventilation . . . . . . . . . . . . . . . . 34
Do Not Smoke . . . . . . . . . . . . . 35
Medical Advice . . . . . . . . . . . . . 35
Mold . . . . . . . . . . . . . . . . . . . . 35
Section 3: Tires and Wheels
Uniform Tire Quality Grade Standards
(UTQGS) . . . . . . . . . . . . . . . . 37
Treadwear . . . . . . . . . . . . . . . . 37
Traction . . . . . . . . . . . . . . . . . 37
Temperature . . . . . . . . . . . . . . . 38
Tire Safety . . . . . . . . . . . . . . . . . 39
Lug Nut Torque . . . . . . . . . . . . . . . . 40
Tire Inflation . . . . . . . . . . . . . . . . . . 41
Alignment . . . . . . . . . . . . . . . . . 41
Changing a Spare Tire . . . . . . . . . . . . 42
Tire Identification Information . . . . . . . . 43
Section 4: Weighing, Loading, and
Towing
Federal Weight Label . . . . . . . . . . . 45
Motorhome Occupant and Cargo Carrying
Capacity Weight Label . . . . . . . . . 46
Weight Terminology . . . . . . . . . . . 46
Weighing Your Motorhome . . . . . . . . 47
Weight Distribution . . . . . . . . . . . . 48
Loading Tips . . . . . . . . . . . . . . . . 49
Packing For Travel . . . . . . . . . . . . . 49
Towing With Your Motorhome . . . . . . . 50
Electrical Connections to a Towed Vehicle . . 52
Section 5: Chassis
Class A Motorhome Engine Access . . . . 53
Chassis Alternator . . . . . . . . . . . . . 53
Battery Isolation Manager . . . . . . . . . 54
Emergency (Auxiliary) Start Switch . . . . 55
Section 6: Electrical Systems
Shore Line Power Cord . . . . . . . . . . 57
Maintenance . . . . . . . . . . . . . . . 59
Monitor Panel . . . . . . . . . . . . . . . 59
Auxiliary Battery . . . . . . . . . . . . . . 60
Testing the Batteries . . . . . . . . . . . 60
Storing the Batteries . . . . . . . . . . 61
Master Battery Disconnect Switch . . . 61
Converter . . . . . . . . . . . . . . . . . 62
Inspection and Maintenance . . . . . . 62
Inverter . . . . . . . . . . . . . . . . . . 62
Inspection and Maintenance . . . . . . 62
Circuit Breakers . . . . . . . . . . . . . . 63
Maintenance . . . . . . . . . . . . . . . 63
Fuses . . . . . . . . . . . . . . . . . . . 64
Ground Fault Circuit Interrupter (GFCI) . . 65
Inspection . . . . . . . . . . . . . . . . 65
Generator . . . . . . . . . . . . . . . . . 66
Section 7: Fuel Systems
Fuel Cap . . . . . . . . . . . . . . . . . . 69
Fuel Pump Collision Shut-off Switch . . . 70
Fuel Transfer System . . . . . . . . . . . 70
Fuel Transfer System Safety . . . . . . 71
Section 8: Propane System
Propane Gas Safety . . . . . . . . . . . . 73
Propane Leak Test . . . . . . . . . . . . . 75
Propane Gas Tank . . . . . . . . . . . . . 75
Servicing or Filling . . . . . . . . . . . 76
Using the Propane System . . . . . . . . 77
Traveling with Propane . . . . . . . . . . 77
Section 9: Water Systems
Fresh Water System . . . . . . . . . . . . 79
Potable Water Hose . . . . . . . . . . 79
Connecting to an Exterior Water Fill . . 79
To Disconnect From the Outside Water
Source . . . . . . . . . . . . . . . . 79
Filling the Fresh Water Tank . . . . . . 80
Water Pump . . . . . . . . . . . . . . . 81
Operation . . . . . . . . . . . . . . . 81
Water Pump Filter . . . . . . . . . . 81
Sanitizing the Fresh Water System . . . 82
Waste Water System . . . . . . . . . . . 83
Drain Pipes . . . . . . . . . . . . . . . 83
Vents . . . . . . . . . . . . . . . . . . 83
Emptying the Holding Tanks . . . . . . 83
Black Tank Flush . . . . . . . . . . . . 84
Winterizing the Water System . . . . . . 84
De-winterizing Your Motorhome . . . . . . 86
Section 10: Leveling Jacks and
Slideout Systems
Leveling Jacks . . . . . . . . . . . . . . . 87
Stabilizing Jacks . . . . . . . . . . . . . . 89
Slideout Systems . . . . . . . . . . . . . 89
Extending the Slideout . . . . . . . . . 90
Retracting the Slideout . . . . . . . . . 91
Section 11: Interior
Appliances . . . . . . . . . . . . . . . . . 93
Heating/Cooling . . . . . . . . . . . . . . 94
Entertainment System . . . . . . . . . . . 95
Sleeping Areas . . . . . . . . . . . . . . 95
Front Cab Power Drop Down Overhead
Bunks . . . . . . . . . . . . . . . . 95
Rear Garage Elevated Beds . . . . . . 96
Electric Bed Lift Systems . . . . . . . . 97
Use of Bed Rails . . . . . . . . . . . . 97
Section 12: Exterior
Storage Compartments . . . . . . . . . . 99
Exterior Ladder . . . . . . . . . . . . . 100
Roof . . . . . . . . . . . . . . . . . . . 101
Awnings . . . . . . . . . . . . . . . . . 101
Patio Awnings . . . . . . . . . . . . . 101
Ramp Door . . . . . . . . . . . . . . . 102
Sealants . . . . . . . . . . . . . . . . . 102
Storage of the Motorhome . . . . . . . . 103
Section 13: Maintenance
Maintenance Schedule . . . . . . . . . . 104
Maintenance Log . . . . . . . . . . . . 106
Fuel and Oil Log . . . . . . . . . . . . 108
Notes . . . . . . . . . . . . . . . . . . 110
Glossary . . . . . . . . . . . . . . . . . 113
Index . . . . . . . . . . . . . . . . . . . 121
or Motor Coach (TMC) reserves the right to make changes in vehicles built and/or sold at any time without incurring any obligations to
make the same or similar changes on vehicles previously built and/or sold by TMC. Information in this owner's manual is subject to change
without notice and represents information relevant at the time this version was printed. Nothing in this owner's manual creates any warranty,
either expressed or implied. e only warranties oered are those set forth in the or Motor Coach Limited Warranty and in the or Motor
Coach Structural Limited Warranty, as applicable to the motorhome.
Copyright or Motor Coach, Inc. © 10/2018
Introduction
About This Owner's Manual
ank you for choosing or Motor Coach (TMC). is Owner's Manual is intended to help
you better understand the features and general operation of your new motorhome. Please read
and keep it, your TMC Warranty Guide, your Owner’s Packet, and your Chassis Packet in your
recreation vehicle (RV) for future reference.
is Owner's Manual is not intended for use as a service manual, but rather as a guide to help
you become familiar with your motorhome. It is not model specic and is of a general nature
so the illustrations and descriptions provided may dier from the components installed in
your motorhome.
TMC Warranty Guide
e or Motor Coach Limited Warranty and the or Motor Coach Structural Limited
Warranty are printed separately in your TMC Warranty Guide. e TMC Warranty Guide also
contains your TMC Product Warranty Registration Form (this form must be completed by
you and your selling dealer, and returned to us within een (15) days of delivery of your new
motorhome to you).
INTRODUCTION
Owner’s Packet
For more complete instructions regarding warranty, safety, operation, and maintenance
of the component supplier parts installed in your motorhome, please read and follow the
information provided by the various component manufacturers located in your Owner’s
Packet. If you feel you are missing component supplier information, please contact the
component manufacturer using the supplier contact list provided in your TMC Warranty
Guide, your selling dealer, or TMC Customer Care at (877) 855-2867.
TMC Owner's Packet
1THOR MOTOR COACH | MADE TO FIT
INTRODUCTION
Chassis Packet
e Chassis Packet contains important warranty, safety, operation, and maintenance
information from the manufacturer of your motorhome chassis regarding the transmission,
tires, etc. Instructions for registering your applicable warranty using the chassis manufacturer’s
Delayed Warranty Start Form are printed separately in the TMC Warranty Guide.
Online Customer Support
A good working knowledge of your motorhome and how to care for it will help you enjoy
many miles and years of RVing. As an added bonus, we have provided informational 'how-to'
videos on our or Motor Coach YouTube channel:
https://www.youtube.com/user/orMotorCoach
and more information available in the Owner’s Resources section of our website:
https://www.thormotorcoach.com/owners/
Contact
If you are unclear or unfamiliar with any procedure described in this Owner's Manual,
your TMC Warranty Guide, Owner’s Packet, Chassis Packet, or online Customer Support
information, please contact your selling dealer or TMC Customer Care at (877) 855-2867 for
assistance.
2 CUSTOMER CARE | 877.855.2867
Customer Information
Dealer’s Responsibilities
CUSTOMER INFORMATION
Your selling dealer is responsible for inspecting both factory and dealer installed components
for proper operation. is is referred to as a PDI (pre-delivery inspection).
1. Your selling dealer is required to provide a thorough and complete walk through
demonstration and perform a test drive with you. e demonstration should provide you
with a good understanding regarding your new motorhome warranty, safety information,
operation, and maintenance.
2. Your selling dealer should discuss this Owner’s Manual, the Owner's Packet, the Chassis
Packet, and the various individual component supplier documents with you at the time of
sale. eir presentation should include assisting you with completing all warranty cards
and registrations, and reviewing all individual component supplier information, including
warranty, safety, operation, and maintenance information relating to your new motorhome.
3. Your selling dealer is required to complete and return the TMC Product Warranty
Registration Form (located in the TMC Warranty Guide) to or Motor Coach within
een (15) days of delivery of your motorhome to you to activate your or Motor Coach
Limited Warranty, and your or Motor Coach Structural Limited Warranty coverage.
Customer’s Responsibilities
You, as the owner/operator of the motorhome, are responsible for providing proper
maintenance as outlined in this Owner's Manual, the TMC Warranty Guide, the Owner’s
Packet, our On-line Customer Support, the Chassis Packet, and all individual component
suppliers' information. Periodic maintenance is not covered by the or Motor Coach Limited
Warranty and/or the or Motor Coach Structural Limited Warranty.
NOTE: Your applicable Thor Motor Coach
Limited Warranty and Thor Motor Coach
Structural Limited Warranty are activated
after we receive your fully completed TMC
Product Warranty Registration Form from
your selling dealer.
1
1. Read the or Motor Coach Limited Warranty and the or Motor Coach Limited
Structural Warranty before you purchase your motorhome. If you have questions
regarding coverage, contact TMC Customer Care at (877) 855-2867.
2. Inspect the entire motorhome during your PDI and test drive, and note any issues in
writing on the TMC Product Warranty Registration Form. Ask any questions you may
have before leaving the selling dealership.
3THOR MOTOR COACH | MADE TO FIT
CUSTOMER INFORMATION
1
NOTE: Failure to properly maintain your
motorhome could result in loss of warranty
coverage.
3. Complete and return all applicable warranty cards and registrations at the time of sale.
4. Regular and proper maintenance. Be sure to have service performed in a timely manner to
help avoid situations arising from neglect or abuse that are not covered under warranty.
5. Familiarize yourself with your new motorhome.
Follow all TMC, chassis manufacturer, and all individual component suppliers' instructions
regarding the safety, operation, and maintenance of their respective products.
Change of Address or Ownership
e 'National Trac and Motor Vehicle Safety Act of 1966' in the United States, and Transport
Canada require manufacturers to be able to contact vehicle owners when a correction of a
safety-related defect or noncompliance issue becomes necessary.
To enable TMC to contact you (the current purchaser) with important vehicle product and
safety updates, including vehicles with expired warranty coverage, please update your vehiclerelated or ownership information by contacting TMC in writing by faxing (574) 294-3816
(attention: Registrations), or by emailing registrations@tmcrv.com.
INCLUDE THE FOLLOWING:
• Your legal name
• Your current mailing address (include your prior mailing address for change of address
notications)
• Your telephone number
• Your email address
• Your vehicle’s 17-digit chassis vehicle identication number (VIN)
• Your vehicle’s TMC serial number
• Legal proof of purchase (e.g., a legible copy of your bill of sale or insurance card)
• Current motorhome odometer reading
4
CUSTOMER CARE | 877.855.2867
How to Obtain Assistance
CUSTOMER INFORMATION
Should a question or concern arise regarding your motorhome, your rst step is to contact
your selling dealer. eir sales, service, and parts professionals will be glad to assist you.
Customer service is of the utmost importance to your selling dealer, and is just as important
to us.
You can also contact a TMC Customer Care representative, by calling (877) 855-2867.
Questions can also be directed to TMC Customer Care through the or Motor Coach
website. To access this service, you must have a valid email address. is resoruce is available
to you 24/7. You will receive a reply by email, or if you choose, a TMC Customer Care
representative will return a phone call as soon as possible.
We sincerely believe your selling dealer and your TMC Customer Care representative will
be able to solve any concern which may arise. However, if their combined eorts are not
satisfactory please send a letter describing the circumstances to:
Thor Motor Coach
Attn: Customer Care
PO Box 1486
Elkhart IN 46515-1486
INCLUDE THE FOLLOWING:
• Your selling dealer’s name, address, and phone number
1
• Your dealer contact’s name
• Your legal name, current mailing address, phone number, and email address
• Your vehicle’s 17-digit chassis vehicle identication number (VIN)
• Your vehicle’s TMC serial number
• Current motorhome odometer reading
• If applicable, include the individual component supplier's name, part description, model
number, and serial number
5THOR MOTOR COACH | MADE TO FIT
CUSTOMER INFORMATION
Suggestions for Obtaining Service
1
To help ensure your selling dealer provides the level of service you expect, here are some
suggestions we would like to make:
CONTACT YOUR DEALER AT ONCE
Do not wait until you are ready to use your motorhome. Service appointments are made
based on each dealer's schedule, so contact your dealer as soon as possible to have repairs
performed.
PREPARE FOR THE APPOINTMENT
If you are having warranty work performed, be sure to have the right papers with you. Take
your warranty folder and have your vehicle information available. All work to be performed
may not be covered by warranty. Discuss additional charges with the dealer’s service
professionals.
PREPARE A LIST
Provide your dealer with a written list of specic repairs needed. It is important that you
provide any vehicle repair history to the dealer’s service professionals. Keep a maintenance log
of your vehicle’s service history. is can oen provide a clue to the current issue.
BE REASONABLE WITH YOUR REQUESTS
If you leave a list with several items, and you need your motorhome returned back by a
specic time, discuss the situation with the dealer’s service professionals and list your items in
order of priority. is may include making a second appointment for work not completed or
parts that the dealer may need to order.
DON’T EXPECT TO LOOK OVER THE TECHNICIAN’S SHOULDER
Please don’t be oended if you are told you cannot watch the work being done. Some
insurance requirements forbid admission of customers to the service area.
INSPECT THE WORK PERFORMED
Finally, check out the service or repair job when you pick up your motorhome. Notify the
dealer’s service professionals immediately of any dissatisfaction. If you cannot return the
vehicle immediately for repair, make an appointment as soon as possible.
Please be aware that all service shops require notication of any issues with their repairs
within a specied time limit. Make sure you are familiar with their repair policies.
6
CUSTOMER CARE | 877.855.2867
Emergency Weekend or After Business Hours Warranty Repair
Assistance
In an emergency, if an authorized TMC dealer is not located nearby please contact your
selling dealer for assistance. If your selling dealer is closed, contact TMC Customer Care at
(877) 855-2867 (available 24/7) for warranty pre-repair authorization for emergency weekend
and/or aer business hours repair assistance.
Obtaining Service Repair at Thor Motor Coach
CUSTOMER INFORMATION
1
If your motorhome is in need of service repair, and your dealer recommends that the repairs
be made at the TMC Factory Service Center, your motorhome may be returned to us with the
following guidelines:
• You (the current motorhome owner) or your referring dealer must make a conrmed
appointment prior to dropping o your motorhome.
• You are responsible for all transportation costs and hotel accommodations; please be
prepared accordingly.
• Unless prior approval has been obtained from the TMC Factory Service Center, all
personal items must be removed from the area where you are requesting service repair
and the refrigerator emptied. TMC is not responsible for any lost or stolen property,
valuables, or loss of food items.
• Your motorhome holding tanks must be emptied and rinsed. We have a dumping station
available for customer use.
• e propane system and all electrical systems must be shut down and turned OFF. We are
not responsible for discharged batteries or propane tanks.
• During the appropriate season, please ensure your motorhome is winterized.
• You must retake possession of your motorhome within seven (7) days of TMC notifying
you that the repairs have been completed; otherwise, unless a longer storage time has been
agreed to in writing by TMC, you agree to pay daily storage fees to TMC.
NOTE: Please refer to your TMC Factory
Service Appointment Form for additional
important information.
7THOR MOTOR COACH | MADE TO FIT
CUSTOMER INFORMATION
Replacement Parts
1
NOTE: Damage caused by use of your
motorhome in freezing temperatures is
not covered by the Thor Motor Coach
Limited Warranty or the Thor Motor Coach
Structural Limited Warranty.
TMC does not sell parts retail direct. Please contact your selling dealer for assistance in
obtaining replacement parts or accessories. If the original part is no longer available, we will
make every eort to provide an appropriate substitute.
Cold Weather Usage
When RVing in freezing or below freezing temperatures, these precautions should be taken:
• Make proper preparations to avoid freeze-ups of the fresh water and drainage systems.
• Propane gas and sucient power is needed for protection from possible freeze-ups of the
propane gas regulator.
• During cool weather usage, ventilation or addition of a dehumidier (customer supplied)
may be required to reduce condensation.
• To avoid damage, check the outside extrusions for frozen moisture before operating or
using the motorhome compartment doors, locks, slideouts, windows, vents, etc.
Extended Stay Usage
Your motorhome was designed primarily for recreational use and short-term occupancy.
If you expect to occupy the motorhome for an extended period, be prepared to deal with
condensation and the humid conditions that may be encountered.
e relatively small volume and tight compact construction of modern RVs mean that the
normal living activities of even a few occupants will lead to rapid moisture saturation of the
air contained in the motorhome and the appearance of visible moisture, especially in cold
weather.
Just as moisture collects on the outside of a glass of cold water during humid weather,
moisture can condense on the inside surfaces of the motorhome during cold weather when
relative humidity of the interior air is high. is condition is increased because the insulated
8
CUSTOMER CARE | 877.855.2867
CUSTOMER INFORMATION
walls of a recreation vehicle are much thinner than house walls. Estimates indicate that a
family of four can vaporize up to three gallons of water daily through breathing, cooking,
bathing, and washing.
Unless the water vapor is carried outside by ventilation, or condensed by a dehumidier
(customer supplied), it will condense on the inside of the windows and walls as moisture, or
in cold weather as frost or ice. It may also condense out of sight within the walls or the ceiling
where it will manifest itself as warped or stained panels. Appearance of these conditions may
indicate a serious condensation problem.
When using your motorhome, you should at all times take necessary action to minimize the
eects of excessive moisture and condensation. For tips on controlling condensation see the
“Tips To Controlling Condensation” section.
Thor Diesel Club
Discover a whole new level of camaraderie and increase your knowledge of your motorhome
by joining the or Diesel Club. As the owner of a Class A diesel motorhome manufactured
by or Motor Coach you are eligible for membership.
e or Diesel Club is an independently owned and operated entity that uses the or name
under a license agreement. e or Diesel Club is not a principal or agent of or Motor
Coach, Inc.
NOTE: Your motorhome is not designed,
nor intended, for permanent housing.
Use of your motorhome for long term
or permanent occupancy may lead to
premature deterioration of its structure,
interior finishes, fabrics, carpeting, and/or
window treatments, etc. Damage and/or
deterioration due to long term occupancy
is not considered normal, and may under
the terms of the warranty constitute misuse,
abuse, or neglect, and therefore void
certain warranty protections.
NOTE: If you purchased a new qualifying
motorhome, you may be eligible for a free
one year of membership; please contact the
management at Thor Diesel Club for more
details.
1
For more information regarding how you can become a club member, please contact:
Thor Diesel Club
5715 Hwy 85N #557
Crestview, Florida 32536
Website:
www.thordieselclub.org
Email: thordieselclub@gmail.com
9THOR MOTOR COACH | MADE TO FIT
CUSTOMER INFORMATION
Website Usage Disclaimers
1
or Motor Coach (TMC) hereby disclaims and sets forth as follows:
Website Disclaimer of Warranty
e services, information and materials on websites listed in this manual are provided "AS
IS," and TMC shall have absolutely no liability whatsoever in connection with these website
services, information, external links or third party links on these websites. Your use of these
websites are at your own risk. TMC shall have no liability whatsoever for any errors, omissions
or inaccuracies in the information regardless of how caused or for delays or interruptions
in delivery of the information: or any decision made or action taken or not taken in reliance
upon the information furnished.
TMC accepts no responsibility or liability whatsoever with regard to information on these
websites as the information is meant to be of a general nature only and is not intended to
address the specic circumstances of any particular individual or entity.
e information provided is not necessarily comprehensive, complete, accurate or up to date;
the information is sometimes linked to external sites over which TMC has no control and
for which TMC assumes no responsibility: TMC shall have no liability for any loss or injury
caused, in whole or in part, by its actions, omissions or negligence, or for any contingencies
beyond its control in procuring, compiling or delivering any information. e information
is not professional nor does it comprise legal advice (if you need specic advice, you should
always consult a suitably qualied professional).
10
Disclaimer of Endorsement
Any reference within external or third party links to any specic commercial products, process
or service by trade name, trademark, manufacturer or otherwise, does not constitute or imply
it's endorsement, recommendation or favoring by TMC. e appearance of external or third
party links does not constitute endorsement by TMC of the linked web sites or the information,
products or services contained therein. TMC does not exercise any editorial control over the
information you may nd at these locations. External or third party links may be provided
for the convenience of the users of that website. TMC is not responsible for the availability or
content of these external or third party sites and does not endorse, warrant or guarantee any
products, services, information, centers or schools described or oered at these links.
CUSTOMER CARE | 877.855.2867
Reporting Safety Defects
CUSTOMER INFORMATION
In the United States
If you believe that your recreation vehicle has an alleged defect that could cause a crash or
cause injury or death, you should immediately inform the National Highway Trac Safety
Administration (NHTSA) and or Motor Coach.
If NHTSA receives similar complaints, it may open an investigation, and if it nds that a safety
defect exists in a group of vehicles, it may order a recall and remedy campaign. However,
NHTSA cannot become involved in individual problems between you, your selling dealer, or
or Motor Coach.
For additional information, go to the NHTSA website at www.safercar.gov.
To contact NHTSA by phone
Call the Vehicle Safety Hotline at 1-888-327-4236 and a NHTSA representative will record
your complaint information (TTY: 1-800-424-9153 or 1-202-484-5238).
To contact NHTSA by mail
Oce of Defects Investigations/CRD
NVS-216
1200 New Jersey Ave. SE
Washington, DC 20590
1
To contact TMC by phone
Contact TMC Customer Care at 1-877-825-2867.
To contact TMC by mail
or Motor Coach
Attn: Customer Care
PO Box 1486
Elkhart, IN 46515-1486
11THOR MOTOR COACH | MADE TO FIT
CUSTOMER INFORMATION
In Canada
1
If you believe your recreation vehicle has an alleged safety defect, you should contact
Transport Canada and or Motor Coach. Transport Canada prefers to be called instead
of receiving posted mail or email, as it enables their investigators to conrm that your
information is correct and to answer your questions accurately.
For additional information, go to the Transport Canada website at www.tc.gc.ca.
To contact Transport Canada by phone
Call 1-800-333-0510 (or 1-613-993-9851 if you are calling from the Ottawa region) and ask to
speak to a defect investigator.
To contact Transport Canada by mail
Road Safety and Motor Vehicle
Regulation Directorate
Transport Canada
Tower C, Place de Ville
330 Sparks Street
Ottawa, Ontario K1A 0N5
To contact TMC by phone
12
Contact TMC Customer Care at 1-877-825-2867.
To contact TMC by mail
or Motor Coach
Attn: Customer Care
PO Box 1486
Elkhart, IN 46515-1486
CUSTOMER CARE | 877.855.2867
Safety and Vehicle Identification
Safety Alerts
or Motor Coach uses the following signal words to warn you of possible safety concerns
and to provide information to help prevent personal injury and/or damage to the motorhome:
SAFETY AND VEHICLE IDENTIFICATION
NOTE:
Provides helpful information.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death. This symbol may be used
in conjunction with the following signal words and with a color that
corresponds with the associated safety label.
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in death or
serious injury. This alert information is limited to the most extreme situations.
WARNING
Indicates a potentially hazardous situation that, if not avoided, may result in death or
serious injury.
CAUTION
2
Indicates a potentially hazardous situation that, if not avoided, may result in minor or
moderate injury. It may also be used to alert against unsafe practices.
NOTICE
Indicates a potential situation that, if not avoided, may result in property damage or
damage to your motorhome.
13THOR MOTOR COACH | MADE TO FIT
SAFETY AND VEHICLE IDENTIFICATION
Vehicle Identification Decals and Plates
2
NOTE: If any decal, label, or data plate has
been removed, damaged, or painted over,
please contact your selling dealer’s Parts
Department to order and replace it.
DANGER
NO SMOKING
Before dispensing fuel, turn off all
engines, fuel-burning appliances,
and their igniters (see operating
instructions).
Do not dispense fuel within 20ft
(6.1m) of an ignition source.
Can cause ignition of ammable
vapors, which can lead to a re or
explosion and result in death or
serious injury.
e TMC serial number is listed on a label axed to the inside wall of a Class A motorhome,
or on the inside of the passenger’s door of a Class C motorhome. Please refer to the chassis
manufacturer’s owner's manual for the location of your 17-digit chassis VIN.
ere are safety decals and vehicle information labels axed throughout your motorhome.
Read and follow the instructions listed on all decals, labels, or data plates before and during
operation and storage of your motorhome.
Fire Safety
DANGER
Vehicles and equipment powered by internal combustion engines and placed in
recreation vehicles may cause carbon monoxide poisoning or asphyxiation, which
could result in death or serious injury.
The flammable liquids used to power these items can cause a fire or explosion,
which can result in death or serious injury.
TO REDUCE RISK:
1. Do not ride in the vehicle storage area when vehicles are present.
2. Do not sleep in the vehicle storage area when vehicles are present.
3. Close doors and windows in walls of separation (if installed) when any vehicle is
present.
4. Run fuel out of engines or stored vehicles after shutting off fuel at the tank.
5. Do not store, transport, or dispense fuel inside this vehicle.
6. Open the windows, openings, or air ventilation systems provided for venting the
transportation area when vehicles are present.
7. Do not operate propane appliances, pilot lights, or electrical equipment when
motorized vehicles are present.
14 CUSTOMER CARE | 877.855.2867
Fire safety is an important part of owning a motorhome. Make sure that everyone traveling
in the motorhome is familiar with the location of exits, including emergency exit egress
windows, should an emergency arise. e following basic rules of re prevention can help
eliminate the possibility of a re:
• Never store ammable liquids within the motorhome
• Keep cooking surfaces clean
• Never clean with a ammable liquid
• Never leave cooking food unattended
• Never smoke in bed, and always use an ashtray
• Never allow children to play with propane gas or electrical equipment
• Never use an open ame as a ashlight
• Always repair faulty or damaged wiring and electrical components
• Never overload electrical circuits
SAFETY AND VEHICLE IDENTIFICATION
WARNING
DO NOT attempt to use water to
put out an electrical re. Water
can spread some types of re, and
electrocution is possible with an
electrical re.
2
• Locate and repair propane gas leaks immediately
• Don’t allow rubbish to accumulate
• Spray fabrics annually with a ame retardant
If a re does start, make sure to follow these basic rules of safety
1. Evacuate everyone (including pets) from the motorhome immediately!
2. Aer everyone is clear, check the re to see if you can attempt to put it out. If it is too
large, or the re is fuel fed, get clear of the motorhome and have the re department
handle the emergency.
a. Switch the 120 volts AC main circuit breaker to the OFF position
b. Disconnect the negative battery cable(s) at the auxiliary battery and chassis battery
:
15THOR MOTOR COACH | MADE TO FIT
2
SAFETY AND VEHICLE IDENTIFICATION
c. Disconnect the shore line power cord from the shore power receptacle
d. Turn OFF the generator (if so equipped)
3. DO NOT attempt to use water to put out the re. Water can spread some types of re, and
electrocution is possible with an electrical re.
Always have faulty or damaged wiring and electrical components inspected by a certied RV
repair technician, and repaired immediately.
Fire Extinguisher
Fire extinguishers are classied and rated by re type, A, B, and C. ese classications
identify the kinds of res or burning materials they are designed to ght.
Class A - Solid materials such as wood, paper, cloth, rubber, and some plastics.
Class B - Liquids such as grease, cooking oils, gasoline, kerosene or other ammable
liquids.
Class C - Electrical such as electrical wires or other live electrical equipment.
A dry-chemical re extinguisher has been installed by the entrance door. It is suitable for
extinguishing small res of the Class B or C type only.
Operation
Typical Class B-C fire extinguisher
For information on how to use your re extinguisher, refer to the re extinguisher
manufacturer’s owner's manual or the label axed to the side of the re extinguisher.
Inspection
NOTE: Know the location of the fire
extinguisher installed in your motorhome
and become familiar with its operation.
Inspect the extinguisher at least once a week (more frequently if it is exposed to weather
or possible tampering). is should also be done before beginning a vacation or during an
extended trip.
16 CUSTOMER CARE | 877.855.2867
SAFETY AND VEHICLE IDENTIFICATION
Replacement
e re extinguisher must be replaced following the re extinguisher manufacturer’s owner's
manual instructions, and/or expiration date listed on the label axed to the side of the re
extinguisher.
Smoke Alarm
WARNING
This smoke alarm will not alert hearing impaired residents. Special alarms with
ashing strobe lights are recommended for the hearing impaired.
e smoke alarm in your vehicle is listed for use in recreation vehicles. ey only work
properly if they are operational and maintained. ey have a limited life and will wear out
over time. Immediately replace the smoke alarm if it is not working properly, if it displays
any type of problem, or as recommended by the smoke alarm manufacturer. Be sure to read,
understand, and follow the information provided by the smoke alarm manufacturer, including
information on the limited life of smoke alarms.
2
Be aware the smoke alarm is not fool proof and cannot detect res if smoke does not reach it.
Anything preventing smoke from reaching the alarm may delay or prevent an alarm.
ough the alarm horn in this detector meets or exceeds current UL standards, it may not
be heard for reasons that include (but not limited to): a closed or partially closed door, other
noise from electronics, appliances or trac.
Operation
e smoke alarm is operational once the battery is correctly installed. It will not function
if the battery is missing, disconnected, dead, the wrong type, or not installed correctly. It
requires one standard 9V battery. Refer to the smoke alarm manufacturer's owner's manual for
correct battery and installation information.
Typical RV smoke alarm
17THOR MOTOR COACH | MADE TO FIT
2
SAFETY AND VEHICLE IDENTIFICATION
e LED light indicates if the battery is functioning properly. When the production of
combustion is sensed, the smoke alarm sounds a loud alarm that continues until the air is
cleared. e LED light also gives a visual indication of a sounding alarm.
When the battery becomes weak, the alarm will “beep” about once a minute indicating a low
battery. is warning should last for 30 days. To assure continued protection, you MUST
replace the battery once the smoke alarm’s low battery warning (beeping) starts.
Test
WARNING
Test smoke alarm operation after vehicle has been in storage, befoe each trip, and at
least once per week during use.
Failure to do so can result in death or serious injury.
To test, stand at arm’s length from the smoke alarm as the alarm horn is loud and may be
harmful to your hearing. e test button will accurately test all functions. Never use an open
ame to test the smoke alarm.
Maintenance
Vacuum o any dust on the cover of the smoke alarm using a so brush attachment. Test
the smoke alarm once you have vacuumed. Never use water, cleaners or solvents to clean
the smoke alarm as they may damage the alarm. Do not paint the smoke alarm. Refer to the
manufacturer’s owner's manual for detailed maintenance information.
Replacement
Smoke alarms have a limited life and must be replaced following the smoke alarm
manufacturer’s owner's manual instructions, and/or the expiration date listed on the device.
18 CUSTOMER CARE | 877.855.2867
Carbon Monoxide (CO)
SAFETY AND VEHICLE IDENTIFICATION
WARNING
The following symptoms are related to carbon monoxide poisoning and should be
discussed with all members of the household:
Mild exposure
Slight headache, nausea, vomiting, fatigue (often described as “u-like” symptoms)
Medium exposure
Severe throbbing headaches, drowsiness, confusion, fast heart rate
Extreme exposure
Unconsciousness, convulsions, cardio-respiratory failure, death
Carbon monoxide (CO) is an insidious poison. It is a colorless, odorless, and tasteless gas.
Many cases of reported carbon monoxide poisoning indicate while victims are aware they
are not feeling well, they become so disoriented they are unable to save themselves by either
exiting the vehicle or calling for assistance. Young children and household pets may be the
rst aected.
WARNING
CARBON MONOXIDE OR SUFFOCATION DANGER EXISTS
This is a storage area only and not intended for human or animal occupancy. Failure
to follow these instructions could lead to injury or death.
Do not allow children to enter or to play in or around this storage area.
This area is not heated or cooled. Do not store perishables or items in this cargo
area that ay be damaged by heat or by exposure to cold temperatures.
DANGER
Do not use gas cooking appliances
for comfort heating.
Can lead to carbon monoxide
poisoning, which can lead to death
or serious injury.
2
e risk of carbon monoxide poisoning or suocation exists in any conned space. Do not
allow children or pets to play or become entrapped within the storage compartments of your
motorhome.
19THOR MOTOR COACH | MADE TO FIT
2
SAFETY AND VEHICLE IDENTIFICATION
Safety Regulations and Propane Gas
DANGER
IF YOU SMELL PROPANE GAS
1. Extinguish any open ames and all smoking materials.
2. Shut off the propane supply at the container valve(s) or propane supply
connection.
3. Do not touch electrical switches.
4. Open doors and other ventilating openings.
5. Leave the area until the odor clears
6. Have the propane system checked and leakage source corrected before using
again.
Ignition of ammable vapors could lead to a re or explosion and result in death or
serious injury.
DANGER
All pilot lignts, appliances, and their igniters (see operating instructions) shall be
turned off before refueling of motor fuel tanks and/or propane containers.
Can cause ignition of ammable vapors, which can lead to a re or explosion and
result in death or serious injury.
Warning labels are axed throughout your motorhome to provide required information on
propane safety. Read and follow the instructions listed, and exercise proper precautions when
using or around propane and propane appliances.
Warning labels are located in the cooking area to remind you to provide an adequate supply
of fresh air for combustion. Unlike a residential home, the oxygen supply in an RV is limited
20 CUSTOMER CARE | 877.855.2867
due to the size of the RV, and proper ventilation must be utilized when using the cooking
appliances to help avoid the dangers of asphyxiation.
DANGER
Do not use gas cooking appliances for comfort heating. Can lead to carbon
monoxide poisoning, which can lead to death or serious injury.
SAFETY AND VEHICLE IDENTIFICATION
2
WARNING
THIS PROPANE PIPING SYSTEM IS DESIGNED FOR USE WITH PROPANE ONLY.
• Do not connect natural gas to this system.
• Securely cap inlet when not connected for use.
• After turning on propane, except after normal cylinder replacement, test propane
piping and connections to appliances for leakage with soapy water or bubble
solution.
• Do not use products that contain ammonia or chlorine to test for leaks. These
substances may weaken piping components and cause gas leaks, leading to re
or explosion, which could result in death or serious injury.
WARNING
Gas cooking appliances need fresh air for safe operation. Before operating:
• Open vents or windows slightly or turn on exhaust fan prior to using cooking
appliance.
• Gas ames consume oxygen, which should be replaced to ensure proper
combustion.
• Improper use can result in death or serious injury.
WARNING
Do not ll propane container(s) to
more than 80 percent of capacity.
A properly lled container contains
approximately 80 percent of its
volume as liquid propane.
Overlling the propane container(s)
can result in uncontrolled propane
ow, which could lead to a re or
explosion and result in death or
serious injury.
21THOR MOTOR COACH | MADE TO FIT
SAFETY AND VEHICLE IDENTIFICATION
Combination Carbon Monoxide/Propane Alarm
2
WARNING
THE PROPANE DETECTOR
OPERATES ON 12 VOLT HOUSE
POWER. IT WILL BE DISABLED
WHEN HOUSE BATTERIES ARE
DISCONNECTED AND SHORE
POWER IS REMOVED!
Typical combination carbon monoxide/propane
alarm
WARNING
The carbon monoxide (CO) alarm installed is intended for use in ordinary indoor
locations of recreation vehicles.
Do not disconnect the combination carbon monoxide/propane alarm, or its battery.
Individuals with medical problems may consider using warning devices that provide
audible and visual signals for carbon monoxide concentrations under 30 PPM.
This alarm will only indicate the presence of carbon monoxide gas at the sensor.
Carbon monoxide gas may be present in other areas.
Your motorhome is equipped with a combination carbon monoxide/propane alarm that is
listed for use in recreation vehicles. e combination carbon monoxide/propane alarm will
only work if it is operational and maintained.
e combination carbon monoxide/propane alarm is wired directly to the motorhome's 12
volt electrical system, with continuous power being supplied by the auxiliary battery. ere
is no 9-volt battery power supply in the combination carbon monoxide/propane alarm. If
the auxiliary battery cable is disconnected at the battery terminals, the combination carbon
monoxide/propane alarm will not be powered, and therefore, will not function.
is alarm is designed to detect the toxic carbon monoxide fumes that result from incomplete
combustion, such as those emitted from appliances, furnaces, replaces, and auto exhaust. A
carbon monoxide/propane alarm is NOT A SUBSTITUTE for other combustible gas, re or
smoke alarms. is carbon monoxide alarm is designed to detect carbon monoxide gas from
ANY source of combustion.
It is not designed to detect smoke, re or any other gas. Please note that there are hazards
against which carbon monoxide detection may not be eective, such as natural gas leaks or
explosions.
22 CUSTOMER CARE | 877.855.2867
is alarm is designed to sense the presence of carbon monoxide/propane gas, however there
are other combustible fumes or vapors that may be detected by the sensor including (but not
limited to): acetone, alcohol, butane, and gasoline.
ese chemicals can be found in commonly used items such as deodorants, colognes,
perfumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents, and the
propellants of aerosol cans. Be sure to read, understand, and follow the owner’s information
from the manufacturer of the combination carbon monoxide/propane alarm. is includes
information regarding the limited life of the alarm.
What to do if the Alarm Sounds
WARNING
Actuation of this alarm indicates the presence of carbon monoxide, which is a toxic
gas that is colorless and odorless.
1. Operate the RESET/SILENCE button
SAFETY AND VEHICLE IDENTIFICATION
2
2. Call your emergency services (call 911 in the United States or the re department)
3. Immediately move to fresh air (outdoors, or by an open door or window)
4. Do not re-enter the premises or move away from the open door or window until the
emergency service responders have arrived, the premises have been aired out, and your
alarm remains in its normal condition
If your alarm reactivates within a 24-hour period, repeat steps 1-4 and call a qualied
appliance technician to investigate for sources of carbon monoxide from fuel burning
equipment and appliances, and inspect for proper operation of this equipment. Make sure that
motor vehicle(s) are not, and have not been, operating in an attached garage or adjacent to the
motorhome.
If problems are identied during this inspection, have the alarm serviced immediately. Note
any combustion equipment not inspected by the technician and consult the manufacturer’s
instructions or contact the manufacturer directly for more information about carbon
monoxide safety and this alarm.
23THOR MOTOR COACH | MADE TO FIT
2
SAFETY AND VEHICLE IDENTIFICATION
Test
WARNING
Test the combination carbon monoxide/propane alarm after the motorhome has
been in storage, before each trip, and at least once per week during motorhome use.
e TEST switch is located on the front of the alarm. Refer to your Owner’s Packet for more
information from the combination carbon monoxide/propane alarm manufacturer.
Maintenance
Vacuum the alarm cover at least once a year. Clean the cover by hand using a cloth dampened
in clean water. Dry with a so cloth. Do not spray the front panel of the alarm with cleaning
agents or waxes. is action may damage the sensor causing an alarm or cause the alarm to
malfunction. Do not paint the face of the alarm.
Replacement
e combination carbon monoxide/propane alarm has a limited life and must be replaced
following the alarm manufacturer’s instructions and/or the expiration date listed on the
device.
Exhaust Fuel Fumes
WARNING
Avoid inhaling exhaust gases as they contain carbon monoxide, which is a toxic gas
that is colorless and odorless.
24 CUSTOMER CARE | 877.855.2867
SAFETY AND VEHICLE IDENTIFICATION
EXIT
WARNING
If you are in a parked motorhome with either the engine running or the generator
running there is a potential for exhaust fumes to lter back into the motorhome.
To avoid breathing exhaust gases, follow these precautions:
• Do not run the engine in conned areas, such as a closed garage, any longer than needed
to move your motorhome in or out of the area.
• e windows should be closed while driving or running the generator (if so equipped) to
avoid drawing dangerous exhaust gases into the motorhome.
• If you suspect that exhaust fumes are entering the passenger compartment, have the cause
determined and corrected as soon as possible.
• If you must drive under these circumstances, close all the windows and adjust the heating
or cooling system to force outside air into the motorhome (set the blower on high speed).
• e best protection against carbon monoxide entry into the motorhome is a properly
maintained ventilation system and an active carbon monoxide alarm. To allow for proper
operation of the motorhome ventilation system, keep the ventilation inlet grill(s) clear of
snow, leaves or other obstructions at all times.
2
Emergency Egress Window
e emergency egress window ( “exit window”) is designed to allow for a quick exit if the
main entry door is not available. All exit windows have red operational handles or levers.
An exit window may be a large section of an exit window or an entire exit window. It is
important you know how to open and operate the exit window(s) in your motorhome before
an emergency occurs.
• Before traveling in your motorhome, review the locations and instruct all occupants on
how to operate the exit window(s).
Typical emergency egress window exit label
25THOR MOTOR COACH | MADE TO FIT
SAFETY AND VEHICLE IDENTIFICATION
2
NOTE:
• When an exit window does not have a
screen, it is only intended for use as an
exit window and is not intended to be
used for ventilation purposes.
• A top hinged exit window having
a window screen can be used
for ventilation purposes when the
motorhome is parked; however,
DO NOT open the exit window
more than a 45 degree angle as it is
designed to break away from the RV
if opened at an angle greater than 45
degrees to allow for emergency egress
(exit).
• To avoid window damage, the exit
window must be closed tight and
locked when the motorhome is
traveling.
• When pulling into your campsite, make sure the ground below each exit window is solid
and there is a clear escape path directly outside the exit window(s) clear of trees or other
obstacles.
• Plan re escape routes:
Decide who will exit through the exit window(s) rst, and in what order
◦
Place a blanket or heavy coat over the exit window frame to cushion the exit
◦
If there is a re, the last person designated to exit the motorhome should be prepared
◦
to assist those in front
Designate a meeting place safely away from the motorhome
◦
Operation
1. Pull the red colored handles as directed
by the exit window label instructions
to release the latch. Some exit windows
have more than one release latch.
2. Aer releasing the latch as directed,
push the exit window pane out (if so
equipped).
1. Push red
handle and lift
from latch.
2. Rotate red
handle towards
you.
Maintenance
NOTE: Release latch mechanisms will
vary, depending on the exit window design.
The exit window may be hinged at the
top or side, a breakaway, or it may be a
slider window pane. Some models may be
equipped with a window screen; however,
for your safety it is important that you do not
add a window screen to an exit window if
one did not come factory-installed by Thor
Motor Coach.
Open the exit windows at least twice a year
to prevent the rubber seals from sticking.
3. Push red
handle out,
through the
bracket, while
opening window.
26 CUSTOMER CARE | 877.855.2867
Seat Belts
WARNING
All occupants in this vehicle must be seated at a designated seating position and
must wear seat belts at all times while this vehicle is in motion.
Failure to do so can result in serious injury.
WARNING
The sleeping accomodations in this vehicle are designed for occupance only
while vehicle is NOT in motion. All occupants in this vehicle must be seated at a
designated seating position and must wear seat belts at all times while this vehicle
is in motion.
Failure to do so can result in serious injury.
SAFETY AND VEHICLE IDENTIFICATION
2
WARNING
Do not occupy beds or any other seats that are not equipped with seat belts while
the motorhome is in motion.
Seat belts are designed for single occupancy. Do not use a seat belt on more than
one person.
CAUTION
Seat belts and seats can become hot in a vehicle that has been closed up in sunny
weather; they could burn a small child. Check that seat covers and seat belt buckles
are cool to the touch before allowing a child, passenger, or pet near them.
27THOR MOTOR COACH | MADE TO FIT
SAFETY AND VEHICLE IDENTIFICATION
All occupants must be furnished with and use seat belts while the motorhome is moving.
However, it is not intended for all seats to be simultaneously occupied while the vehicle
is in motion without regard to the total loaded weight of your motorhome. e sleeping
accommodations in your motorhome are designed for occupancy only while the vehicle is
parked.
2
Typical seat belt located in dinette seating area
Operation
Pilot and co-pilot seats must be locked in a forward facing position with seat belts fastened
while the motorhome is in motion. Avoid seat rotation while in transit.
• Insert the belt tongue into the proper buckle (the buckle closest to the direction the
tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is
securely fastened in the buckle.
• Adjust the belt to the proper position; snug and as low as possible around the hips, not
around the waist.
• To unfasten, push the release button and remove the tongue from the buckle.
Inspection and Replacement
WARNING
Failure to inspect and if necessary, replace damaged seat belts could result in
severe personal injuries in the event of a collision.
Inspect the seat belts in your motorhome periodically to make sure they work properly and
are not damaged; make sure there are no nicks, tears, or cuts. Replace the motorhome seat
belts as necessary. A qualied service technician should inspect all seat belt assemblies aer
a collision. TMC recommends that all seat belt assemblies used in vehicles involved in a
collision be replaced.
28 CUSTOMER CARE | 877.855.2867
Child Safety Restraint System
DANGER
Never let a passenger hold a child on his or her lap while the motorhome is moving.
You are required by law to use safety restraints for children in the United States and
Canada.
If small children (generally children who are four years old or younger, and weigh 40
lbs. (18 kg.) or less) ride in your motorhome you must put them in safety seats made
especially for children.
DANGER
Rear-facing child seats or infant carriers should never be placed in the front seats of
the motorhome.
SAFETY AND VEHICLE IDENTIFICATION
NOTE: Check with your local and state or
provincial laws for specific requirements
regarding the safety of children in your
motorhome.
2
If your child requires a child safety restraint system (seat), TMC recommends installing
the child safety seat in the forward facing booth dinette position. If your motorhome is not
equipped with a forward facing booth dinette seat, we recommend that small children that
require a child seat not be transported in your motorhome. For rear-facing child seats and
infant carriers, the dinette table can be placed in the DOWN position to allow adequate room
for the rear-facing child seat.
Always follow the instructions and warnings that come with any infant or child safety
restraint system you might use:
• If the child is the proper size, restrain the child in a safety seat. Children who are too large
for child safety seats (as specied by your child safety seat manufacturer) should always
wear seat belts.
• If the shoulder belt portion of a combination lap and shoulder belt can be positioned so it
does not cross or rest in front of the child’s face or neck, the child should wear the lap and
shoulder belt.
• Never use pillows, books, or other objects to boost a child, passenger, or pet.
NOTE: If so equipped, the anchor points for
child safety seat tethers are located behind
the dinette seat back cushions.
29THOR MOTOR COACH | MADE TO FIT
SAFETY AND VEHICLE IDENTIFICATION
Rear Vision Camera System
Generally speaking, the rear vision camera system (if so equipped) is located at the top of
the rear exterior wall. The mating harness and monitor may be factory installed, or available for purchase from your selling dealer.
2
Typical rear vision camera
NOTE: Curves and/or hills may affect the
safe placement of warning indicators.
Prep Only
If your motorhome has rear vision camera prep only, the installation wiring to attach your
customer purchased camera system may be located behind a rear wall top clearance light,
or accessed via the motorhome roof. Please contact your selling dealership for assistance
in locating the installation wires installed on your motorhome.
Emergency Stopping
If an emergency requires you to be stopped, follow these guidelines:
1. Pull o the road as far as possible
2. Put the motorhome in the PARK position and apply the PARKING BRAKE
3. Turn ON the hazard warning ashers
4. Use three red warning indicators such as ares, reectors, or lanterns as required by the
Uniform Vehicle Code and Model Trac Ordinance as follows:
a. Place the rst indicator on the trac side of the motorhome, directed at the nearest
approaching trac
b. Place the second 100 feet behind the motorhome in the center of the lane and toward
approaching trac
c. Place the third 100 feet in front of the motorhome in the center of the lane and away
from the trac approaching from behind
5. Always stand o the road
30 CUSTOMER CARE | 877.855.2867
SAFETY AND VEHICLE IDENTIFICATION
Laws of the Road
It is advisable to contact the Department of Motor Vehicles in each respective state for up-todate information regarding operation and licensing requirements for your motorhome.
e State of California requires operators of motorhomes over 40 feet in length to obtain
a non-commercial class B license. California has also enacted legislation limiting use of
motorhomes in excess of 40 feet, to approved roadways.
You may contact Caltrans at www.dot.ca.gov or by calling (916) 654-5741 for current
information regarding these California statues.
Condensation
Tips for Controlling Condensation
To avoid condensation problems, follow these tips to help alleviate excess moisture:
• Allow excess moisture to escape to the outside when bathing, washing dishes, hair drying,
laundering, and using appliances and non-vented gas burners.
2
• Always use the vent hood when cooking.
• Keep the bathroom door closed and the vent or window open when bathing (and for a
period of time aer you have nished).
• Do not hang wet clothes in the motorhome to dry.
• In hot weather, start the air conditioner early as it removes excess humidity from the air
while lowering the temperature.
• Keep the temperature as reasonably cool during cold weather as possible. e warmer the
motorhome, the more cold exterior temperatures and warm interior temperatures will
collide on wall surfaces, thus creating condensation.
31THOR MOTOR COACH | MADE TO FIT
2
SAFETY AND VEHICLE IDENTIFICATION
• Use a fan to keep air circulating inside the motorhome so condensation and mildew
cannot form in dead air spaces. Allow air to circulate inside closets and cabinets (leave
doors partially open). Please keep in mind that a closed cabinet full of stored goods
prevents circulation and allows the exterior temperature to cause condensation.
• A natural tendency would be to close the motrorhome tightly during cold weather. is
will actually compound the problem. Simply put, you need to remove some of the warm
air and allow some cool outside air to get inside the motorhome, so the furnace will not
recycle the humid interior air.
• Use uorescent or LED ceiling lights and minimize prolonged use of incandescent lights,
which produce heat and contribute to condensation in the roof area above the ceiling lights.
Chemical Sensitivity
WARNING
THIS VEHICLE LIKE OTHER VEHICLES MAY
CONTAIN SMALL AMOUNTS OF ONE OR MORE
SUBSTANCES THAT ARE KNOWN TO THE STATE
OF CALIFORNIA TO CAUSE CANCER, BIRTH
DEFECTS OR OTHER REPRODUCTIVE HARM.
Examples of chemical sensitivity safety labels, California (USA)
This vehicle may include
mercury-containing devices
installed by the manufacturer:
Remove devices before vehicle
disposal. Upon removal of
devices, please reuse, recycle, or
dispose as hazardous waste.
Example of safe disposal of hazardous materials label, Vermont (USA)
High Intensity Discharge Headlamps
Backlit Instruments
Automatic Leveling Jacks
T.V. Antenna Switch
Fluorescent Lamps in Appliances
and Fixtures
Flame sensors in gas appliances
such as hot water heaters & ovens
This product, including its
component parts, may
contain chemicals known to
the State of California to
cause cancer, birth defects,
or other reproductive harm.
WARNING
Smoke alarms
Other
32 CUSTOMER CARE | 877.855.2867
SAFETY AND VEHICLE IDENTIFICATION
Aer you rst purchase your new motorhome and sometimes aer it has been closed up for
an extended period of time you may notice a strong odor and chemical sensitivity. is is not
a defect in your motorhome. Like your home, there are many dierent products used in the
construction of recreational vehicles such as carpet, linoleum, plywood, insulation, upholstery,
etc. Formaldehyde is also the by-product of combustion and numerous household products,
such as some paints, coatings, and cosmetics. However, recreational vehicles are much smaller
than your home and therefore the exchange of air inside a recreational vehicle is signicantly
less than a home. ese products, when new or when exposed to elevated temperatures and/
or humidity, may “o-gas” dierent chemicals, including formaldehyde. is o-gassing,
in combination with the minimal air exchange, may cause you to experience irritation of
the eyes, nose, and throat and sometimes headache, nausea, and a variety of asthma-like
symptoms. Elderly persons and young children, as well as anyone with a history of asthma,
allergies, or lung problems, may be more susceptible to the eects of o-gassing.
Formaldehyde
Most of the attention regarding chemical o-gassing surrounds formaldehyde. Formaldehyde
is a naturally occurring substance. It is also a key industrial chemical used in the manufacture
of the numerous consumer products which we referred to above and used in the construction
of recreational vehicles. Trace levels of formaldehyde are also released from smoking, cooking,
use of soaps and detergents, such as carpet shampoos, cosmetics, and many other household
products. Some people are very sensitive to formaldehyde while others may not have any
reaction to the same levels of formaldehyde. Amounts released decrease over time.
NOTE: Chemical off-gassing is not a
"defect" in your motorhome and is not
covered by the Thor Motor Coach Limited
Product Warranty or the Thor Motor Coach
Structural Limited Warranty. Please follow
the recommendations in this section to
address this concern.
2
Ventilation
To reduce or lessen exposure to chemicals from o-gassing it is of utmost importance that you
ventilate your motorhome. Ventilation should occur frequently aer purchase and at times
when the temperatures and humidity are elevated. Remember o-gassing is accelerated by
heat and humidity. Open windows, exhaust vents, and doors. Operate ceiling and/or other
fans, roof air conditioners, and furnaces. Use a fan to force stale air out and bring fresh air in.
Decreasing the ow of air by sealing the recreational vehicle increases the formaldehyde level
in the indoor air. Please also follow the recommendations contained in this section regarding
tips to avoid condensation problems. Many of the recommendations contained here will assist
in avoiding exposure to chemicals that o-gas.
33THOR MOTOR COACH | MADE TO FIT
SAFETY AND VEHICLE IDENTIFICATION
Do Not Smoke
Finally, we recommend that you do not smoke inside your motorhome. In addition to causing
damage to your motorhome, tobacco smoke releases formaldehyde and other toxic chemicals.
2
NOTE: If using a dehumidifier, please read
and follow all manufacturer instructions and
recommendations to the use and cleaning
of the dehumidifier.
Medical Advice
If you have any questions regarding your health, please consult your doctor or local health
department immediately.
Mold
What are molds?
Molds are microscopic organisms that naturally occur in virtually every environment, indoors
and out. Outdoors, mold growth is important in the decomposition of plants. Indoors,
mold growth is unfavorable. Le unchecked, molds break down natural materials, such as
wood products and fabrics. According to the Center for Disease Control, exposure to damp
and moldy environments may cause a variety of health eects, or none at all. Some people
are sensitive to molds. For these people, molds can cause nasal stuness, throat irritation,
coughing or wheezing, eye irritation, or, in some cases, skin irritation. People with mold
allergies may have more severe reactions. Immune-compromised people and those with
chronic lung illnesses, such as obstructive lung disease, may get serious infections in their
lungs when they are exposed to mold.
What factors contribute to mold growth?
For mold growth to occur, temperatures, indoors or outdoors, must be between 40 degrees
and 100 degrees Fahrenheit and also have a source of moisture, such as humidity, standing
water, damp materials, etc. Indoors, the most rapid growth occurs with warm and humid
conditions.
34 CUSTOMER CARE | 877.855.2867
How can mold growth be inhibited?
By controlling relative humidity, the growth of mold and mildew can be inhibited. In warm
climates, use of the air conditioner will reduce the relative humidity. Vents are located in the
bathing and cooking areas and constant use is advised during food preparation and bathing,
even during colder weather. Additionally, opening a window during these activities will assist
in ventilation. In extremely humid conditions, the use of a dehumidier can be helpful.*
Frequent use of your motorhome or cleaning regularly is an important preventive measure.
Further, any spills should be wiped up quickly and dried as soon as possible. Avoid leaving
damp items lying about. On safe surfaces, use mold or mildew killing cleaning products.
Check sealants regularly, and reseal when necessary to avoid water leaks. Proper preventive
maintenance to the motorhome and its accessories, as described both in this manual and in
accompanying literature, will provide the best protection for your motorhome.
*For more information of controlling moisture in your motorhome, please read, “Tips to
Controlling Condensation,” located in this manual.
SAFETY AND VEHICLE IDENTIFICATION
2
35THOR MOTOR COACH | MADE TO FIT
This page is intentionally left blank
36 CUSTOMER CARE | 877.855.2867
Tires and Wheels
Uniform Tire Quality Grade Standards (UTQGS)
is section of your owner’s manual contains tire safety information as required by the
U.S. Department of Transportation (DOT) National Highway Transportation Safety
Administration’s (NHTSA) 49 CFR 575.6 Uniform Tire Quality Grade Standards (UTQGS).
e UTQGS is intended to aid consumers in making informed choices in the purchase of
passenger car tires.
Tire ratings are located on the sidewall of passenger tires sold in the United States (except
deep tread, winter-type snow tires; space-saver or temporary use spares; tires with normal rim
diameters of 12 inches or less; or limited production tires).
e UTQGS rates tires by treadwear, traction performance, and temperature resistance.
Treadwear
e treadwear grade is a comparative rating based on the wear rate of the tire when tested
under controlled conditions on a specied government test course. For example, a tire graded
150 would under one and a half (1-1/2) times as well on the government course as a tire
graded 100. e relative performance of tires depends upon the actual conditions of their
use, however, and may depart signicantly from the norm due to variations in driving habits,
service practices and dierences in road characteristics and climate.
TIRES AND WHEELS
3
Traction – AA, A, B, and C
WARNING
The traction grade assigned to a tire is based on braking (straight ahead) traction
tests and does not include cornering (turning) traction.
e traction grades from highest to lowest are AA, A, B, and C, and they represent the tire’s ability
to stop on wet pavement as measured under controlled conditions on specied government test
surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
NOTE: Always pay close attention to the
condition of your motorhome's tires
37THOR MOTOR COACH | MADE TO FIT
TIRES AND WHEELS
Traction Grades Asphalt g-Force Concrete g-Force
AA Above 0.54 0.41
A Above 0.47 0.35
B Above 0.38 0.26
C Less Than 0.38 0.26
3
NOTE: NHTSA’s tire rating listings are
located online at https://www.safercar.gov/
Vehicle-Shoppers/Tires-Rating.
NHTSA also has more tire information
located online at https://www.safercar.gov/
tires/index.html.
Temperature – A, B, and C
WARNING
The temperature grade is established for a tire that is properly inated and not
overloaded. Excessive speed, under ination, or excessive loading, either separately
or in combination, can cause heat buildup and possible tire failure.
e temperature grades are A (the highest), B, and C, representing the tire’s resistance to the
generation of heat and its ability to dissipate heat when tested under controlled conditions on
a specied indoor laboratory test wheel. Sustained high temperature can cause the material of
the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire
failure. e grade C corresponds to a level of performance which all passenger car tires must
meet under the Federal Motor Vehicle Safety Standard No. 109. Grades A and B represent
higher levels of performance on the laboratory test wheel than the minimum required by law.
Temperature Grades Speed in Miles per Hour
A Over 115 MPH
B Between 100 and 115 MPH
C Between 85 and 100 MPH
38 CUSTOMER CARE | 877.855.2867
Tire Safety
DANGER
Failure to follow proper ination guidelines may result in tire failure, which, under
certain circumstances can cause loss of vehicle control or accidents that may result
in property damage, bodily injury, and/or death.
WARNING
It is recommended that the tire pressure be checked at the beginning of each trip
to obtain the maximum life of the tire. Follow the instructions listed on the Federal
Certication label to determine the correct tire pressure.
Read and follow the instructions listed below before taking your rst trip in your new motorhome!
TIRES AND WHEELS
NOTE: State of California (USA) Tire chain
notice: YOUR MOTORHOME CAN NOT
BE OPERATED WITH TIRE CHAINS.
3
• Proper care and maintenance of your motorhome tires is essential to ensure your safety, as
well as the safety of others, as you travel.
• Routine maintenance on your motorhome is important, but it cannot be overstated just how
critical proper tire maintenance is to the safety, operation and durability of your new vehicle.
• You must follow the manufacturer’s ination guidelines for maximum load capacity; underination is just as dangerous as over-ination.
• To insure your motorhome tires are operating safely, regular inspection of your tires and
checking tire pressures is absolutely mandatory.
• Examine your motorhome tires frequently for unusual wear. Alignment, balance and
bearing wear will aect tire wear. Make sure to look for cracking, bulging, uneven tread
wear, etc.
39THOR MOTOR COACH | MADE TO FIT
TIRES AND WHEELS
IF YOUR
FRONT
TIRES
LOOK
LIKE THIS
3
NOTE: Do not bleed air from hot tires or
your tires may then become under-inflated.
TIRE
PATTERN
COMMON
CAUSE
Illustration of common tire wear patterns
TOE
VEHICLE
WHEEL
ALIGNMENT
CAMBER CENTER EDGE CUPPING
VEHICLE
WHEEL
ALIGNMENT
TIRE
OVER
INFLATION
TIRE
UNDER
INFLATION
VEHICLE
WORN
SUSPENSION
PATCHY
TIRE
OUT OF
BALANCE
When you are using your motorhome, check the ination pressure of each tire weekly to
insure maximum tire life and travel wear. Tire pressure should only be checked when the tires
are cold. During travel, your tires heat up and the air pressure inside the tire increases.
Lug Nut Torque
Being sure wheel mounting nuts (lug nuts) on the wheels are tight and properly torqued
is an important responsibility that you need to be familiar with, and practice. Inadequate
and/or inappropriate wheel nut torque (tightness) is a major reason that lug nuts loosen in
service. Loose lug nuts can rapidly lead to a wheel separation with potentially serious safety
consequences.
Refer to the chassis manufacturer's information for proper lug-nut torque and tightening
sequence.
40 CUSTOMER CARE | 877.855.2867
Tire Inflation
Your tires and wheels support the entire weight of your motorhome and its contents. Your
tires are also the only contact your motorhome has with the road surface. Determining and
maintaining proper ination is the most important factor in maximizing the life of your tires.
Driving on a tire that does not have the correct ination pressure for the vehicle load is
dangerous and may cause premature wear, tire damage, tread delamination and/or loss of
control of your motorhome.
Underinated tires can lead to disaster. Avoiding this is quick and easy:
• FIND YOUR PSI. Your PSI is the pounds per square inch of air pressure that’s right for
your tires. e correct PSI for your tires is located on your motorhome’s tire information
label – not on the sidewall of your tire.
• CHECK IT MONTHLY. At least once a month, check all your motorhome tires air
pressures (including the spare tire) using an accurate pressure gauge. Bottom line: you
cannot tell if your tires are underinated just by looking.
TIRES AND WHEELS
Tire pressure under-inflation can cause serious
tire failure
3
Alignment
NOTICE
The front suspension and steering system of this motorhome was factory aligned
prior to it being dispatched to the dealership. The alignment is however, greatly
affected by the way the unit is loaded prior to travel. This loading includes how
much cargo, water, and LP are carried as well as the distribution of said cargo. Thor
Motor Coach advises to have the alignment checked in the fully loaded condition
(the way you would normally load the unit to travel). Not having the alignment
checked and reset can result in abnormal tire wear.
NOTE: Toe-in and toe-out (only) are
inspected by TMC prior to shipment to your
selling dealer.
41THOR MOTOR COACH | MADE TO FIT
3
TIRES AND WHEELS
Changing a Spare Tire (if so equipped)
WARNING
Do not use the leveling jack system to support the motorhome while under the
vehicle or changing tires. The leveling system is designed as a leveling system
only. Do not use the leveling jack system as a jack or in conjunction with a jack.
If a tire change is required, it is highly recommended the work be performed by a
knowledgeable trained professional. Attempts to change a tire while supporting the
motorhome with the leveling jack system could result in damage to the motorhome
and risk causing serious injury or death.
WARNING
When replacing a tire, make sure to replace it with a tire of the same size and
specications listed on your motorhome’s Federal Weight label.
WARNING
The motorhome is very heavy. Raising the motorhome to replace the spare tire
should only be done with extreme caution by a qualied technician. The vehicle
could slip, causing personal injury or death. DO NOT ATTEMPT TO DO THIS
YOURSELF.
If you experience a at tire while driving your motorhome, gradually decrease your vehicle
speed (if possible). Hold the steering wheel rmly and direct the motorhome to a safe place
on the side of the road. Please contact a road service provider, a qualied RV service repair
center, or 911 in the U.S. for assistance. It is highly recommended you do not attempt to
change a spare tire or jack the motorhome yourself; this is why a jack handle has not been
included with your motorhome.
42 CUSTOMER CARE | 877.855.2867
Make sure the road service technician reads and is familiar with the Chassis Packet tire
changing information. Make sure the wheel nuts have been tightened to the proper torque as
outlined in your Chassis Packet.
Tire Identification Information
TIRES AND WHEELS
To maintain the load capacity of your motorhome, it is vitally important to only replace
worn or damaged tires with tires with ratings equal to or higher than what was originally
equipped on your vehicle. e illustration, located on the next page, describes important tire
information that is embossed on every tire by the manufacturer.
e Load Index may be indicated with two numbers separated with a forward slash. e rst
number is the load index of the tire congured as a single tire on a single wheel. e second
number indicates the load index of the tire as a dual-wheel conguration. Multiplying the second
number by 2 will give you the total Load Index for the dual wheel conguration.
e load index per tire congured as dual wheel is less than a single tire to provide a margin of
safety for the load-carrying capacity of the tire in the event that one of the dual tires is punctured or
otherwise fails.
NOTE: The tires supplied on your Class C
motorhome carry a "Light Truck" rating.
3
43THOR MOTOR COACH | MADE TO FIT
safercar.gov
Tire Labeling
If Tire Labels Could Talk, Here’s What They’d Say
There’s a ton of information on your tires that tells you about how they work
with your vehicle to aect its performance. Understanding the tire labels for
your passenger vehicle or light truck is important for maintaining and buying
new tires. If labels could talk, here’s what they’d say:
3
TIRES AND WHEELS
R:
R: The “R” stands for radial. Radial tires have been
the industry standard for the past 20 years.
P or LT:
P or LT: The “P” indicates the tire is for
passenger vehicles. “LT” indicates the
tire is for light trucks.
NOMINAL WIDTH: This three-digit
NOMINAL WIDTH:
number gives the width of the tire
in millimeters from sidewall edge
to sidewall edge. The larger the
number, the wider the tire.
MAXIMUM LOAD RATING: This
MAXIMUM LOAD RATING:
number indicates the maximum
load the tire can carry.
MAXIMUM PERMISSIBLE
MAXIMUM PERMISSIBLE
INFLATION PRESSURE: This number
INFLATION PRESSURE:
E
P
M
R
U
T
A
R
E
O
P
2
E
T
A
A
is the greatest amount of air pressure
that should ever be put in the tire. This
is NOT the same as the vehicle manufac-
T
A
O
A
A
E
M
R
E
T
S
W
E
D
I
S
N
O
N
N
O
I
1
+
T
C
A
R
turer’s recommended tire pressure.
TEMPERATURE: The temperature rating
TEMPERATURE:
A
N
E
R
S
I
0
0
1
D
E
E
T
S
2
+
T
R
E
0
2
indicates how well the tire resists heat.
ASPECT RATIO: This two-digit number gives
ASPECT RATIO:
the tire’s ratio of height to width. A number of
50 or lower indicates a short sidewall for improved
steering response and better overall handling.
TRACTION: The traction rating indicates the tire’s
TRACTION:
ability to allow a car to stop on wet pavement in a
shorter distance.
TREADWEAR: The treadwear rating indicates how long the
TREADWEAR:
tire should last. The higher the number, the longer it should
take for the tires to wear down.
M
2
RIM DIAMETER CODE: This two-digit
RIM DIAMETER CODE:
number is the wheel or rim diameter
in inches.
P
E
A
M
T
S
E
R
2
1
5
/
R
P
E
P
O
A
E
6
S
S
2
W
5
5
R
P
S
1
I
5
R
A
D
I
A
8
9
H
T
U
E
E
S
S
D
O
T
F
D
1
F
2
A
0
2
C
T
U
A
R
C
0
E
6
R
T
H
R
E
A
D
T
R
E
A
D
LOAD INDEX: This two- or three-digit
LOAD INDEX:
number is the tire’s load index. It is
an indicator of how much weight
each tire can support. Note: You may
not nd this information on all tires
because it is not required by law.
M
U
+
N
S
A
M
SPEED RATING: The speed
SPEED RATING:
rating tells you the maximum
speed capability of a tire. The
speed ratings include speeds
from 99 mph to above 186
mph. Note: You may not nd
this information on all tires
because it is not required by
law.
M+S: This indicates that the tire
M+S:
has some mud and snow capability.
U.S. DOT TIRE IDENTIFICATION
U.S. DOT TIRE IDENTIFICATION
NUMBER: This number begins with
NUMBER:
the letters “DOT” and indicates that
the tire meets all Federal standards.
The next two or three numbers or
letters are the plant code where the
tire was manufactured. The last four
numbers represent the week and
year the tire was built. For example,
the numbers 3107 means the 31st
week of 2007. The other numbers are
marketing codes used at the manufacturer’s discretion. This information
is for contacting consumers if a tire
defect requires a recall.
44
Illustration courtesy of NHTSA, www.safercar.gov
CUSTOMER CARE | 877.855.2867
Weighing, Loading, and Towing
WARNING
Do not exceed any applicable motorhome weight ratings. Doing so could damage
your motorhome or affect handling and braking characteristics.
Your motorhome’s braking system is designed and rated for operation at the gross
vehicle weight rating (GVWR) listed on the unit’s weight labels, not the gross
combined weight rating (GCWR).
Proper loading is one of the most important considerations when traveling in a motorhome.
Your motorhome is built to withstand a set maximum load (GVWR). Read and follow the
information listed on your motorhome’s Federal Certication Label (located in the driver’s area)
to determine safe load limits. For safety’s sake, NEVER OVERLOAD YOUR MOTORHOME.
Federal Weight Label
WEIGHING, LOADING, AND TOWING
4
MANUFACTURED BY:
GVWR: XXXX KG (XXXXX LB)
INC. VEH. MFG. BY: <Insert Chassis Manufacturer> MODEL: XXXX
GAWR KG(LB) TIRES RIMS SINGLE DUAL
FRONT:
THIS VEHICLE CONFORMS TO ALL APPLICABLE U.S. FEDERAL MOTOR VEHICLE SAFETY
STANDARDS IN EFFECT IN MM/DD/YYYY
V.I.N.:
VEHICLE
Typical Federal Weight Label, including GVWR, GAWR, and tire pressure information
XXXX (XXXX) LT215/85R16
REAR:
XXXX (XXXX) LT215/85R16
TAG:
XXXXXXXXXXXXXXXXX
THOR MOTOR COACH, INC.
5.5 J X 16 XXX KPA(XX PSI)
OFFLINE:
SERIAL:
COLD INFLATION
PRESSURE
5.5 J X 16 XXX KPA(XX PSI)
TYPE: MULTIPURPOSE PASSENGER
XXXXXXXXXXXXXX
MM/YY
e TMC Motorhome Weight Specications label concisely states the occupant and cargo
carrying capacity of your motorhome and meets the requirements of 49 CFR part 571.120 as
issued by the National Highway Trac Safety Administration (NHTSA).
45THOR MOTOR COACH | MADE TO FIT
WEIGHING, LOADING, AND TOWING
Motorhome Occupant and Cargo Carrying Capacity Weight Label
4
NOTE: If a boat, trailer, or other vehicle
is being towed, it should be weighed and
combined with the motorhome’s weight to
ensure the total weight does not exceed the
gross combined weight rating (GCWR).
MOTORHOME OCCUPANT AND CARGO CARRYING CAPACITY
VIN# 1XXXXXXXXXXXXXXXX
THE COMBINED WEIGHT OF OCCUPANTS AND CARGO SHOULD NEVER EXCEED:
XXX kg or XXX lbs
Safety belt equipped seating capacity: X
CAUTION:
A full load of water equals XXX kg or XXX lbs of cargo @ 1kg/L (8.3 lb/gal) and the
tongue weight of a towed trailer counts as cargo
(Serial #: XXXXXXXXXXXXXX)
Typical Motorhome Occupant and Cargo Carrying Capacity Label
e Motorhome Occupant and Cargo Carrying Capacity weight label is axed to the interior side of
the forward-most door of your motorhome on the passenger side, directly below the window screen
for Class A motorhomes, or on the front door jamb for Class C motorhomes. is label indicates
how much weight you can safely carry within the motorhome. e total weight of passengers, cargo,
trailer tongue weight, and water should never exceed the value shown on this label.
Weight Terminology
GROSS VEHICLE WEIGHT RATING (GVWR)
the maximum permissible weight of this motorhome.
UNLOADED VEHICLE WEIGHT (UVW)
the weight of this motorhome as manufactured at the factory with full fuel, engine oil, and coolants.
OCCUPANT AND CARGO CARRYING CAPACITY (OCCC)
equal to the GVWR minus UVW and LP. In other words, OCCC is how much weight in
occupants, cargo, water, and trailer tongue weight that can be added to the motorhome
without exceeding the GVWR.
GROSS COMBINED WEIGHT RATING (GCWR)
the maximum allowable loaded weight of this recreation vehicle with its towed trailer or towed
vehicle.
GROSS AXLE WEIGHT RATING (GAWR)
the value specied as the load carrying capacity of a single axle system, as measured at the tire
ground interfaces.
46 CUSTOMER CARE | 877.855.2867
Weighing Your Motorhome
When loading your cargo, be sure it is distributed evenly to prevent overloading front to
back and side to side. Heavy items should be placed low and as close to the axle positions
as reasonable. Too many items stored on one side of your motorhome may overload a tire.
Periodically weigh your motorhome at a public scale to determine axle loads.
WEIGHING, LOADING, AND TOWING
To weigh your motorhome correctly, measure the fully loaded vehicle axle by axle and wheel
position by wheel position. You can nd certied public or commercial vehicle scales at
moving and storage lots, farm suppliers with grain elevators, gravel pits, recycling companies,
and large commercial truck stops. You can also look in the telephone book under “weighers”
or “weighing”.
Allow adequate time, since the entire weighing process can take around 30 minutes. ere
may be a small fee for each weight taken, but the expense is a worthwhile investment toward
the safe and economical operation of your motorhome.
Your motorhome must be weighed fully loaded. at is with passengers, food, clothing, fuel,
water, propane, supplies etc. Any towed vehicle (car/pickup, boat, or trailer) or item loaded on
brackets on the back of the motorhome should also be included in the weighing.
e following procedure is suggested when using a long platform scale, although any method
recommended by the scale operator which correctly determines weight value is acceptable.
During all measurements, it is important to keep the vehicle as level as possible.
1. Pull onto the scale so that only the front axle is on the platform with the end of the scale
midway between the front and rear axles and record the weight (Reading A).
2. Pull forward until the full unit is on the scale and record the weight (Reading B).
3. Pull forward so that only the rear axle is on the scale and record the weight (Reading C).
Reading A: Front
4
Reading B: Total Coach
Reading C: Back
NOTE: Thick Black Lines in the illustrations
above represent a vehicle weighing scale.
4. To determine the weight of individual wheel positions, repeat the previous three steps, but
this time, use only one side of the motorhome on the scale. Record the weight readings. To
calculate the wheel position weight for the opposite side of the motorhome, subtract these
weight readings from weight readings A, B, and C recorded in steps 1, 2, and 3.
Your motorhome must remain as level as possible on the scale, even though an axle or side
47THOR MOTOR COACH | MADE TO FIT
WEIGHING, LOADING, AND TOWING
is not physically on the scale. To obtain the side-to-side weights, there must be enough
space on either side of the scale to allow the motorhome to be partially o the scale.
4
NOTE: Additional cargo carrying capacity
can be obtained by reducing the amount of
fresh water carried while driving.
For improved accuracy, or Motor Coach recommends using a segmented 4-pad scale, when
possible, to determine individual wheel weights. e corner weights should not exceed half of
the respective Gross Axle Weight Rating (GAWR) or the maximum load rating for the tire or
set of dual tires at the rear, whichever is less.
Individual wheel position weights must not exceed the maximum tire load capacity. e
maximum load rating for the tire can be found embossed on the tire’s sidewall.
If any of the corner weights exceed half of the listed GAWR or tire ratings, relocate the
passengers and redistribute or remove a portion of the cargo until the weight is within the
proper limits for all four corners of the vehicle.
Check your motorhome vehicle weight periodically to obtain optimum mileage from your
tires, and to improve vehicle handling. Tires should always be inated as recommended in the
chassis manufacturer’s instructions or on the tire sidewall (refer to your Chassis Packet).
Weight Distribution
Improper weight distribution or too much weight on your motorhome’s suspension system
can cause spring, shock absorber, or brake failure, handling or steering problems, irregular
tire wear, tire failure, or other damage. An overloaded motorhome is hard to drive and hard
to stop. In cases of serious overloading, brakes can fail completely, particularly on steep
hills. e load a tire will carry safely is a combination of the size of tire, its load range, and
corresponding ination pressure.
48 CUSTOMER CARE | 877.855.2867
Loading Tips
Store and secure all loose items inside the motorhome before traveling. Overlooked items such
as canned goods, or small appliances on the countertop, cooking pans on the range or freestanding furniture items can become dangerous projectiles during a sudden stop. Distribute
cargo side-to-side so the weight on each tire does not exceed one-half of the GAWR for either
axle. For traveling safety, it is important to make sure any tie down straps (if so equipped) on
appliances or furniture are secured.
Packing for Travel
WEIGHING, LOADING, AND TOWING
Pay careful attention to where and what type of ammable materials you store. Certain storage
areas are clearly labeled DO NOT STORE COMBUSTIBLE MATERIALS. Examples of spark
producing areas, depending on the motorhome model, are: base kitchen cabinets, front
dinette base, exterior refrigerator service compartment, as well as refrigerator cabinet. Please
use discretion as to what potentially dangerous products your motorhome contains while
traveling. Be sure all canisters and bottle tops are secure and leak free.
e following checklist will assist your preparing the living quarters for a trip:
• In winter, make sure that the fresh water system is freeze protected.
• Make sure that all storage items are secured, and heavy items are stored low so they do not
fall.
• Make sure all of your motorhome appliances work (if so equipped: stove, oven,
microwave, refrigerator, water heater, water pump, furnace, etc.).
• Check that you have up-to-date and correct paperwork such as an owner’s registration
card, vehicle registration, proof of insurance, valid driver’s license, etc.
• When preparing for your trip, always consider vehicle weight when loading the
motorhome.
• When traveling, you may want to drain the fresh water tank, or keep the quantity of water
in it to a minimum. is reduces the total weight of the motorhome. A full tank of fresh
water can aect the handling and CCC of the motorhome.
4
49THOR MOTOR COACH | MADE TO FIT
4
WEIGHING, LOADING, AND TOWING
Towing With Your Motorhome
WARNING
• An auxiliary braking system may be required for control of a towed vehicle
behind the motorhome. Do not assume the braking capabilities of the
motorhome cover the towed vehicle.
• The designated hitch rating may exceed the GCWR or other towing capacity
limits of the motorhome. It is your responsibility to properly load the
motorhome, while staying within the tow ratings, GCWR, GVWR, and GAWRs of
the motorhome.
• Do not tow loads that cause the motorhome to exceed the Gross Combined
Vehicle Weight Rating (GCWR).
• Do not exceed the vertical hitch load rating (tongue weight) as listed on the hitch
label.
• Consult your owner's manual for additional information regarding towing
guidelines for this motorhome.
• Failure to comply can result in loss of vehicle control resulting in death or
serious injury.
WARNING
A SEPARATE FUNCTIONING BRAKE SYSTEM IS REQUIRED FOR ANY TOWED
VEHICLES OR TRAILERS WEIGHING MORE THAN 1000 LBS WHEN FULLY LOADED.
NEVER EXCEED THE GVWR, OR THE GAWR SPECIFIED ON THE Motorhome
CERTIFICATION LABEL. Also never exceed the weight ratings of the trailer hitch
installed on the motorhome. Failure to heed any part of this warning could result
in loss of control of the motorhome and towed vehicle or trailer and may cause
an accident and serious injury. For specic towed vehicle braking requirements,
consult your chassis owner’s manual.
50 CUSTOMER CARE | 877.855.2867
WARNING
THE Motorhome FULLY LOADED AND THE TRAILER, OR TOWED VEHICLE, MUST
NOT EXCEED THE Motorhome CHASSIS’ GROSS COMBINED WEIGHT RATING
(GCWR). Consult with your selling dealer to determine the GCWR of the motorhome.
Do not exceed the motorhome gross combined weight rating (GCWR) or the hitch
rating. The tongue weight, the weight pushing down on the hitch, must not exceed
10% of the hitch capacity.
WEIGHING, LOADING, AND TOWING
NOTE: Thor Motor Coach accepts no
responsibility for damage to the chassis
and other components resulting from
towing loads greater than its designated
class specifications. Also consider the
gross combined weight rating (GCWR) of
the motorhome before towing a trailer or
vehicle. Towing an object such as a boat,
trailer, or vehicle behind the motorhome
results in added driving considerations that
you must contend with.
WARNING
DO NOT TOW LOADS THAT EXCEED THE GROSS COMBINED VEHICLE WEIGHT
RATING OR OTHER TOW RATINGS OF THIS MOTORHOME.
WARNING
THE DESIGNATED HITCH RATING MAY EXCEED THE GCWR OR OTHER TOWING
CAPACITY LIMITS OF THE MOTORHOME. It is your responsibility to properly load
the motorhome, while staying within the tow ratings, gross combined and gross
vehicle weight ratings.
Always use safety chains between your motorhome and the towed trailer or vehicle. Cross the
chains under the trailer tongue and allow slack for turning corners. Connect the safety chains
to the trailer or vehicle frame or hook retainers. Never attach safety chains to the bumper of a
vehicle.
Tow bars or car dollies generally are made to travel in a forward direction only. Most towing
equipment of this type is not designed for backing. Never attempt short back up distances with
a tow bar or tow dolly. Damage to the motorhome, towed vehicle or towing device will result.
4
51THOR MOTOR COACH | MADE TO FIT
WEIGHING, LOADING, AND TOWING
Electrical Connections to a Towed Vehicle
4
NOTE: Aftermarket adapters are available
to convert the wiring of a 7-way towing
vehicle connector to a 4-way trailer plug.
A 4-way or 7-way trailer plug, supplied by the chassis manufacturer, is prewired to the chassis
electrical system. This plug provides electrical power for running lights, turn signals, stop
lights, and electric trailer brakes. Before connecting your motorhome to any towed vehicle,
verify that the wiring of the towed vehicle plug conforms to your motorhome connector
wiring. Refer to your Chassis Packet for additional information regarding vehicle towing.
Signal Wire Color
Tail & Running Lights Green
12V Power Black
Reverse Lights Yellow
Right Turn & Stop Brown
Left Turn & Stop Red
Brake Controller Output Blue
Ground White
Typical 7-way trailer connection
4-way connectors (towing vehicle side) are typically wired as follows:
Signal Wire Color
Right Turn and Brake Green
Left Turn and Brake Yellow
Running Lights Brown
Ground White
Typical 4-way trailer connection
52 CUSTOMER CARE | 877.855.2867
Chassis
CHASSIS
For information regarding proper maintenance and other important chassis details, refer
to the Chassis Packet information. You, as the owner, are responsible for taking proper
precautions when attempting any repair or maintenance for your motorhome. If you are
not sure what action to take, or are uncomfortable with performing a maintenance or repair
function, contact your selling dealer, or a designated chassis manufacturer servicing dealer for
assistance. Contact your chassis manufacturer for a service dealer near you.
Class A Motorhome Engine Access
WARNING
IF THE ENGINE COVER IS NOT SEATED CORRECTLY, EXHAUST GASES MAY LEAK
INTO THE MOTORHOME, CREATING A DANGEROUS AND POTENTIALLY LETHAL
SITUATION.
Your Class A motorhome’s engine can be accessed for service from inside the motorhome. If
you cannot locate the engine cover, please contact your selling dealer or TMC Customer Care
for assistance. When reinstalling the engine cover, make sure that it is seated correctly without
obstruction from carpet, oor mats, etc.
NOTE: All issues regarding the chassis
warranty, parts and service should be
directed to the chassis manufacturer. Make
sure to follow the recommendations as
outlined in the Chassis Packet information
to ensure proper future performance and
economy.
5
Chassis Alternator
e 12 volts DC chassis alternator supplies power to both the automotive systems as well as
any auxiliary battery if equipped, and directly to the motorhome living quarters while the
vehicle motor is running. e alternator compensates for electrical usage in the vehicle, the
power drawn by lights, fans, and other 12 volt powered items as well as the charging of the
automotive and auxiliary batteries.
53THOR MOTOR COACH | MADE TO FIT
5
CHASSIS
If the alternator is not keeping pace with the draw on your motorhome’s electrical system while
driving down the road, it means it is working in a negative mode: more power is being used
than the alternator is putting out. is means that you are taking power out of the batteries. If
you draw too much power from your batteries there may not be enough power le to start the
motorhome or run any of the 12 volts DC appliances when you stop for a break or for the night.
e alternator will charge at a higher rate right aer the motorhome has been started,
replacing the power used to start the vehicle, but the charging should quickly go back to
“normal” and hold its own even when you turn on lights or appliances.
If the alternator shows a discharge while the motor is running, turn OFF appliances and lights
to see if a charge comes on or if the alternator indicates “neutral”. en apply a drain on the
system to see if a discharge returns. If a discharge persists, contact your dealer.
When stopped at a campsite that allows you use of the shoreline, the 120 volts AC electrical
system will recharge your auxiliary battery. Under heavy usage in warm weather, check the
uid level of those batteries that require attention to uids quite oen. Low battery uid level
is very harmful to the battery’s longevity.
Battery Isolation Manager
CAUTION
Unless you intend to run the vehicle engine, keep the ignition switch in the OFF
position. Doing so will:
1. Reduce the risk of unnecessary chassis battery drain.
2. Allow the Battery Isolation Manager to connect the chassis battery to the house
battery charging system.
When the motorhome engine is not running, the chassis and house battery(ies) are electrically
Typical battery isolation manager. This device
is usually located in the battery compartment of
the motorhome.
54 CUSTOMER CARE | 877.855.2867
isolated by the use of a battery isolation manager. is controller prevents house power
consumption from discharging the chassis battery while the motorhome is parked.
Some additional characteristics of the battery isolation manager include:
CHASSIS
1. e isolator electrically delays connecting the house batteries to the vehicle charging
system for approximately 15 seconds, to allow the alternator time to reach full charging
ability.
2. Aer this initial time delay, the isolator senses the voltage of the vehicle charging system.
e isolator connects the house battery to the vehicle’s charging system only when the
chassis charging system reaches the correct voltage.
3. If the vehicle’s charging voltage drops below 13.2 volts for a period of 4 seconds, due to
low idle speed and/or excessive load, the isolator will disconnect the house batteries until
the vehicle’s charging voltage returns to a level of 13.2 volts or above. For this feature, there
is a built-in delay period of approximately 10 seconds.
4. e isolator allows the chassis battery to be charged by the house charging device (usually
the converter or inverter) when 120 VAC is in use (shore power or generator power).
5. e isolator allows vehicle starting from the house battery(ies) via the Emergency
(Auxiliary) Start Switch.
Emergency (Auxiliary) Start Switch (if so equipped)
Your motorhome may be equipped with an Emergency (auxiliary or Aux) start switch.
Located in the vehicle’s cockpit, near the drivers seating area, this switch connects the house
battery to the vehicle’s starting circuit. is feature is used for situations when the chassis
battery is too depleted to start the vehicle on its own. Connecting the house battery to the
chassis battery may provide the needed energy to start the vehicle’s engine.
NOTE: Do not hold the ignition key in the
start position for more than 30 seconds. Be
careful not to run down the auxiliary battery
as this could leave you without 12 volts DC
power.
5
To operate: Depress the 'EMER START' switch, located on the front driver’s dash, and hold.
Next, use the ignition key to start chassis engine. Release the 'EMER START' switch aer the
engine has started.
It is strongly advised to turn o all 12 volt DC devices before using the emergency start
feature. is will help ensure that all available energy stored in the house battery can be used
for vehicle starting.
Typical emergency start switch
55THOR MOTOR COACH | MADE TO FIT
This page is intentionally left blank
56 CUSTOMER CARE | 877.855.2867
Electrical Systems
WARNING
THIS CONNECTION IS FOR 110-125-VOLT
AC, 60 HZ, 30 AMPERE SUPPLY.
DO NOT EXCEED CIRCUIT RATING.
EXCEEDING THE CIRCUIT RATING MAY
CAUSE A FIRE AND RESULT IN DEATH
OR SERIOUS INJURY.
WARNING
THIS CONNECTION IS FOR
208Y/120-VOLT or 120/240-VOLT
AC, 3-POLE, 4-WIRE, 60 HZ,
50 AMPERE SUPPLY.
DO NOT EXCEED CIRCUIT RATING.
EXCEEDING THE CIRCUIT RATING
MAY CAUSE A FIRE AND RESULT IN
DEATH OR SERIOUS INJURY.
Shore Line Power Cord
Typical 50 amp electrical service label
ELECTRICAL SYSTEMS
Typical 30 amp electrical service label
The campsite 120 volt power receptacle(s) should always be tested for proper
functionality prior to connecting your motorhome's shore line power cord to it. Do
not hook up the shore line power cord to any receptacle until you have veried
proper polarity and grounding.
DO NOT plug the shore line power cord into a campsite receptacle:
• That has reverse polarity
• With non-functioning ground circuits
• That shows outward signs of heat damage
Doing so may result in property damage or serious injury. Damage or injury
resulting from a connection to a malfunctioning or improperly wired power source is
not covered by warranty.
It is the responsibility of the owner of the electrical receptacle to ensure that the
receptacle is properly wired and grounded. Reverse polarity and/or improper
grounding of your motorhome can cause personal injury or death.
WARNING
Typical 50 amp shore line power cord
connection port
6
57THOR MOTOR COACH | MADE TO FIT
6
ELECTRICAL SYSTEMS
NOTE: The shore line power cord should
be unplugged when the motorhome is left
unattended. If something would happen to
the electrical system, this may help limit
potential damage.
WARNING
Do not use any cheater plug, adapter, or extension cord to recongure incoming
alternating current (AC) power or break the continuity of the circuit connected to the
grounding pin.
• Do not connect the shore line power cord into an outlet that is not grounded,
or adapt the power cord plug to connect it to a receptacle for which it is not
designed.
• Do not remove the grounding pin to connect to a non-grounded receptacle.
Removal of the ground pin disables an important safety feature designed to
prevent shock and electrocution hazards.
• Do not connect the shore line power cord to an extension cord. Use of an
improper extension cord will cause overheating of the cord as well as potentially
causing premature failure of the AC equipment.
WARNING
Make sure the breakers at the electrical power source are in the OFF position before
connecting or disconnecting your shore line power cord.
WARNING
The shore line power cord must be fully extended when in use, and not left coiled
in the electrical compartment or on the ground. If the shore line power cord is left
coiled, it may potentially create enough heat to melt its protective casing.
58 CUSTOMER CARE | 877.855.2867
A 30 amp or 50 amp shore line power cord is provided to connect the motorhome to a
grounded 120 volts AC power source. Depending upon your brand and model, the shore line
power cord will either be permanently mounted to a motorhome interior compartment or
detachable. When hooking up to the external power source:
1. Turn OFF the load center main 120 volts AC circuit breaker
2. Carefully extend the entire length of the shore line power cord (approximately 25’-35’)
from the electric cable hatch to the external power source
3. Plug the shore line power cord into the receptacle. Be sure all the prongs are properly
plugged into the receptacle
4. Turn the load center main circuit breaker back ON
When you are ready to leave, reverse the shore line power cord connection process. Use care
to prevent damaging the electrical connection pins when connecting or disconnecting the
shore line power cord. Grasp the plug to remove the shore line power cord from the outlet; do
not unplug it by pulling on the cord.
ELECTRICAL SYSTEMS
Maintenance
Inspect the shore line power cord for cuts, cracks, and worn insulation; replace it immediately
if these symptoms are noticed.
Monitor Panel
Items that may typically be found on the monitor panel include (inclusion and location will
vary by model year, brand and model):
• Lighted holding tank level indictors and switch(es)
• Lighted battery level switch and indicator
• Lighted water heater switches (electric & propane gas)
• Lighted water pump switch
• Generator start / stop switch
6
NOTE: Monitor panel design, features, and
functions vary depending on model year,
make, and model. Motorhomes equipped
with multiplex systems have other features
integrated into the controller. For further
assistance, contact your selling dealer or
TMC Customer Care at (877) 855-2867.
59THOR MOTOR COACH | MADE TO FIT
ELECTRICAL SYSTEMS
Typical Class A motorhome auxiliary battery
compartment
• Fuel tank gauge and hour meter with switches for fuel pump and fuel levels
• Tank heater switches
• Light switches for some interior and exterior lights
• Lighted cargo bed master control switch
• Slideout control switches (press and hold to extend or retract)
• Awning control switches (press and hold to extend or retract)
Auxiliary Battery
Whether factory installed or customer purchased, your auxiliary (house) batteries are typically
located in a separately vented compartment or storage box. Be sure you know the location of
your batteries before leaving your selling dealership. It is important to keep your motorhome
batteries fully charged at all times. We recommend turning OFF lights and other 12 volts DC
(VDC) components when they are not being used. To prevent draining your motorhome
batteries, connect the motorhome to a 120 volts AC power source whenever possible.
6
Testing the Batteries
WARNING
Keep sparks, cigarettes and ames away from the batteries as the hydrogen gas
they create may explode.
Do not connect a booster battery or other power source that outputs more than
14.2-volts DC to the motorhome batteries.
Use adequate ventilation when charging or using batteries in an enclosed space.
Typical Class C motorhome auxiliary battery
location (under entrance step)
60 CUSTOMER CARE | 877.855.2867
Remove metal jewelry and always wear eye protection when working around
batteries.
WARNING
Do not allow battery electrolyte (acid) to come into contact with skin, eyes, fabric
or painted surfaces. Electrolyte is a sulfuric acid solution that could cause serious
personal injury or property damage.
If your hands, eyes, clothes or the painted surface of your motorhome are exposed
to electrolyte, ush the exposed area thoroughly with water.
If electrolyte gets in your eyes, immediately ush them thoroughly with water and
get prompt medical attention.
Storing the Batteries
To prevent auxiliary battery discharge when your motorhome is not connected to an external
power source for an extended period of time, it is recommended you turn OFF the 12 volt
battery DISCONNECT SWITCH, or MAIN POWER SWITCH and disconnect each battery
at the negative battery cable.
During storage, it is important to check battery voltage at least every two weeks and to
recharge them as needed. If you remove the batteries from your motorhome, protect them
from accidental shorting and keep them in a cool, dry, well ventilated area.
ELECTRICAL SYSTEMS
6
Master Battery Disconnect Switch
The 12 volts DC master battery disconnect switch is used to disconnect the motorhome from
auxiliary or “house” battery power during periods of storage or during service. The 12 volt
master battery disconnect switch must be in the ON position in order to maintain charge in
the chassis and auxiliary ("house") batteries, and for the 12 volts DC house electrical system
to operate.
Typical master battery disconnect switch
NOTE: When traveling, the master battery
disconnect switch must be turned ON to
operate the backup camera system and
dash radio (if so equipped).
61THOR MOTOR COACH | MADE TO FIT
ELECTRICAL SYSTEMS
Typical converter: model, features, and
installation location varies, depending on
motorhome model and floorplan.
Converter
e power converter turns 120 volts AC power to useable 12 volts DC power when the
shore line power cord is connected to an external power source. e converter has a built-in
protective thermal breaker that will shut it down should overheating occur. Overheating can
be caused by operating the converter above its maximum power output for an extended period
of time, or by an obstruction to its ventilation air ow.
Inspection and Maintenance
If the power converter is not working check the fuse(s) located on the outer case. ere are no
customer serviceable parts inside the converter case and the manufacturer’s warranty will be
voided if the case has been opened. If you have further concerns please contact your selling dealer.
Inverter
6
WARNING
The factory-installed inverter is not intended for use with medical device(s).
Your motorhome may be equipped with a factory installed inverter that converts 12 volts DC
to useable 120 volts AC. It also supplies continuous AC power to the appliance plugged into
it. It is important that you familiarize yourself with the inverter function and operation. e
Typical inverter: model, features, and
installation location varies, depending on
motorhome model and floorplan.
62 CUSTOMER CARE | 877.855.2867
inverter should be turned OFF when the motorhome is in storage.
Inspection and Maintenance
If the inverter is not functioning check both the circuit breaker protecting the inverter input,
and the fuse located on the inverter. ere are no customer serviceable parts inside the
inverter case and the manufacturer’s warranty will be void if the case has been opened. e
inverter cooling ns and the cooling fan should be kept clear of any obstructions. If you have
further concerns contact your dealer.
Circuit Breakers
WARNING
Replacement circuit breakers must be of the same voltage, amperage rating, and
type. Never use a higher rated replacement circuit breaker; doing so may cause a
re by overheating the motorhome wiring.
120 volts AC circuit breakers protect the 120 volt wiring and components in your motorhome
from circuit overloads and short circuits. Should a circuit overload or short circuit occur,
the circuit breaker protecting the aected circuit will "trip," preventing the ow of electricity
through that circuit.
If a circuit breaker trips, turn OFF the electrical appliance on that circuit and allow the circuit
breaker to cool down. Aer the cool down period, reset the circuit breaker by moving the
switch to the OFF position and then back to the ON position. If the circuit breaker re-trips or
frequently trips, contact your selling dealer’s service department to have the electrical problem
diagnosed and repaired.
A circuit breaker identication label is permanently attached to the inside surface of the 120volt Load Center. e circuit breakers will not oer complete protection of the motorhome
electrical system in the event of a power surge or spike.
ELECTRICAL SYSTEMS
6
Maintenance
Before using your motorhome, inspect the circuit breakers and replace them as needed. Test
each circuit breaker by moving the individual switches to the OFF position, and then back to
the ON position. Circuit breakers may degrade over time and, as part of your motorhome's
maintenance, must be replaced as needed.
63THOR MOTOR COACH | MADE TO FIT
ELECTRICAL SYSTEMS
Typical ATC blade-type fuse
Fuses
WARNING
Replacement fuses must be of the same voltage, amperage rating, and type. Never
use a higher rated replacement fuse as it may cause a re by overheating your
motorhome wiring.
6
NOTE: Refer to the Chassis Packet for
information regarding the chassis fuses and
circuit breakers.
e 12 volts DC fuse panel label indicates fuse sizes, positions, and the electrical components
powered. At the beginning of camping season, inspect all the 12 volt fuses and replace them
as needed. Before replacing a fuse always shut OFF the engine, generator, and all motorhome
electrical systems completely, including making sure the electrical components listed on the
fuse label are in the OFF position:
1. Shut OFF the chassis engine
2. Disconnect the shore line power cord
3. Shut the generator OFF (if so equipped)
4. Turn the inverter OFF (if so equipped)
5. Disconnect the auxiliary battery main negative battery cable
6. Remove the fuse panel cover
7. Make sure the electrical component located on the fuse label is turned OFF
8. Pull the fuse straight out of the fuse block. If inspection of the fuse conrms that it is
not blown, some other electrical problem may exists. Please contact your selling dealer's
Service Department for further repair assistance.
64 CUSTOMER CARE | 877.855.2867
9. Insert a new fuse of the same specied voltage, amperage rating, and type in the original
location. Never use a higher rated replacement fuse
e fuse panel label should be kept permanently axed to your motorhome. e fuses will not
oer complete protection of the motorhome electrical system in the event of a power surge or
spike. Fuses are maintenance components and must be replaced as as needed.
Ground Fault Circuit Interrupter (GFCI)
e ground fault circuit interrupter (GFCI) receptacle is designed to reduce possible injury
caused by electric shock. e GFCI receptacle(s) will not protect against short circuits or
circuit overloads.
Inspection
Test all GFCI receptacles monthly:
• Make sure the circuit breaker is in the ON position (it must be connected to 120 volt
power to reset the GFCI, as needed).
• Push in the GFCI TEST button. e GFCI RESET button should pop out indicating the
GFCI receptacle has been “tripped” and the 120 volts AC power is interrupted.
ELECTRICAL SYSTEMS
6
Typical GFCI receptacle
• en push in the GFCI RESET button to restore 120 volts AC power.
Contact your selling dealer’s service department for repair assistance if the GFCI RESET
button does not restore 120 volt power when it pops back out. All ground faults must be
repaired before using your motorhome.
65THOR MOTOR COACH | MADE TO FIT
ELECTRICAL SYSTEMS
Typical Cummins Onan generator
Generator
DANGER
Operating the generator creates exhaust gases that contain carbon monoxide.
CARBON MONOXIDE IS POISONOUS AND CAN CAUSE UNCONSCIOUSNESS AND
DEATH.
Never operate the generator in an enclosed building or structure where carbon
monoxide gas could accumulate. Always keep the exhaust system of the generator
clear from obstructions.
1. DO NOT operate the generator while sleeping. You would not be aware of exhaust
entering the motorhome, or alert to symptoms of carbon monoxide poisoning.
2. Never store anything in generator compartment. Always keep compartment clean and dry.
3. DO NOT operate the generator in an enclosed building or in a partly enclosed area such
as a garage.
6
66 CUSTOMER CARE | 877.855.2867
4. Review the safety precautions for fuel and exhaust fumes elsewhere in this manual.
5. DO NOT operate the generator when the motorhome is parked in high grass or brush.
Heat from the exhaust could cause a re in dry conditions.
6. Never operate your chassis or generator engine, or the engine of any vehicle, longer than
necessary when the vehicle is parked.
7. DO NOT simultaneously operate generator and a ventilator which could result in the
entry of exhaust gas. When exhaust ventilators are used, we recommend that a window
on the opposite side of the unit “upwind” of exhaust gases be opened to provide cross
ventilation.
8. When parked, orient the vehicle so that the wind will carry the exhaust away from
the vehicle. DO NOT open nearby windows, ventilators, or doors into the passenger
compartment, particularly those which can be “down wind”, even part of the time.
ELECTRICAL SYSTEMS
9. DO NOT operate the generator when parked in close proximity to vegetation, snow,
buildings, vehicles, or any other object could deect the exhaust under or into the vehicle.
10. DO NOT touch the generator when running, or immediately aer shutting OFF. Heat
from the generator can cause burns. Allow the generator to cool before attempting
maintenance or service.
IMPORTANT: MAKE SURE TO READ AND UNDERSTAND THE GENERATOR
OWNER’S MANUAL BEFORE OPERATING THE GENERATOR. Observe all operating
instructions and warnings as well as all recommended maintenance schedules and
procedures.
e onboard generator makes your motorhome fully self-contained. It allows you access to
120 volts AC when there is no shore power available, but keep in mind that carbon monoxide
is deadly! NEVER sleep in the motorhome with the generator running! Before you start and
use the generator, inspect the exhaust system. Do not use it if the exhaust system is damaged.
Test the carbon monoxide alarm every time you use the motorhome. Know that the symptoms
of carbon monoxide poisoning are:
• Dizziness
• Vomiting
• Nausea
NOTE: The diesel generator requires 12
volt DC power from the house auxiliary
batteries to start, and draws diesel fuel
to operator from the chassis fuel tank.
If the fuel level to the chassis fuel tank
drops to or below ¼ full, the generator
will automatically shut OFF and cannot be
restarted until the fuel tank is filled to above
¼ full.
6
• Muscular twitching
• Intense headache
• robbing in the temples
• Weakness and sleepiness
• Inability to think coherently
If you or anyone else experience any of these symptoms get to fresh air immediately. Shut
the generator OFF, and do not operate it until it has been inspected and repaired by an RV
certied technician. If the symptoms persist seek immediate medical attention.
67THOR MOTOR COACH | MADE TO FIT
This page is intentionally left blank
68 CUSTOMER CARE | 877.855.2867
Fuel Systems
FUEL SYSTEMS
DANGER
Potentially explosive fuel vapor may be present at fuel lling stations and during
refueling of equipment with the fuel transfer system. Never enter a fuel lling station
or refuel equipment if your furnace or water heater is operating or if your refrigerator
is operating on propane. Both the ame and the ignitors in the burners of these
appliances are sources of ignition, and could cause an explosion. These appliances
must be turned OFF before entering a fuel lling station or refueling equipment.
Turning OFF the propane main tank valve only is not sufcient. The appliances must
be OFF at their electrical operating switches.
WARNING
Fuel-soaked rags or other materials contain ammable and/or explosive fuel vapors
and other hazardous substances. Clean up materials should be temporarily stored in
a nonammable, vapor-tight container until proper disposal facilities are available.
Do not store ammable clean up rags or materials inside the motorhome, inside any
other vehicle or near any source of ame or ignition.
Be extremely careful when fueling your motorhome. Always shut OFF the engine, do not
smoke, do not use cellular phones, and shut OFF all pilot lights before adding fuel. Fuel spills
represent a serious re hazard, and should be cleaned up immediately. Never restart the
engine or relight pilot lights while raw fuel is present. When the weather gets cold or your
motorhome has not been used for a while, a fuel additive (customer supplied) may be needed.
DANGER
NO SMOKING
Before dispensing fuel, turn off all
engines, fuel-burning appliances,
and their igniters (see operating
instructions).
Do not dispense fuel within 20ft
(6.1m) of an ignition source.
Can cause ignition of ammable
vapors, which can lead to a re or
explosion and result in death or
serious injury.
DANGER
All pilot lignts, appliances, and their
igniters (see operating instructions)
shall be turned off before refueling
of motor fuel tanks and/or propane
containers.
Can cause ignition of ammable
vapors, which can lead to a re or
explosion and result in death or
serious injury.
7
Fuel Cap (if so equipped)
If you should lose your fuel cap, it should be replaced as soon as possible, with a cap
of the same type. Always remove the fuel cap slowly and pay close attention to the fuel
recommendations outlined in the Chassis Packet.
69THOR MOTOR COACH | MADE TO FIT
7
FUEL SYSTEMS
Fuel Pump Collision Shut-Off Switch (if so equipped)
If your motorhome is involved in a collision, it is possible that an inertia switch in the fuel
pump circuit will open, shutting down the ow of fuel to the engine. is is a safety feature
designed to help keep raw fuel from spilling out and creating additional danger. When this
inertia switch has been tripped, it is necessary to manually reset it before the motorhome can
be restarted and moved. Review your Chassis Packet information for the location of the switch
and instructions for resetting.
Fuel Transfer System (if so equipped)
DANGER
Vehicles and equipment powered by internal combustion engines and placed in
recreation vehicles may cause carbon monoxide poisoning or asphyxiation, which
could result in death or serious injury.
The flammable liquids used to power these items can cause a fire or explosion,
which can result in death or serious injury.
TO REDUCE RISK:
1. Do not ride in the vehicle storage area when vehicles are present.
2. Do not sleep in the vehicle storage area when vehicles are present.
3. Close doors and windows in walls of separation (if installed) when any vehicle is
present.
4. Run fuel out of engines or stored vehicles after shutting off fuel at the tank.
5. Do not store, transport, or dispense fuel inside this vehicle.
6. Open the windows, openings, or air ventilation systems provided for venting the
transportation area when vehicles are present.
7. Do not operate propane appliances, pilot lights, or electrical equipment when
motorized vehicles are present.
70 CUSTOMER CARE | 877.855.2867
DANGER
Any motorized equipment powered with ammable liquid can cause re and
explosion or asphyxiation if stored or transported inside the garage. To reduce the
risk of re, explosion, or asphyxiation:
1. Do not allow passengers to ride inside the storage area at any time.
2. Prior to storing vehicles in the garage, run fuel out of the engine after shutting
OFF fuel at the vehicle fuel tank.
3. Do not store or transport any motor fuel inside the garage.
4. Ventilate the interior of the garage to reduce the risk of re, explosion or
asphyxiation. Open the ventilation panels on either side of the cargo area.
5. Do not operate propane appliances, pilot lights, or electrical equipment when
motorized vehicles or motorized equipment are inside the garage. Set the cargo
electrical disconnect switch to OFF.
FUEL SYSTEMS
A fuel transfer system allows you to store gasoline for use in motorcycles, snowmobiles, ATVs,
or other vehicles and equipment while at a campsite. is system consists of a fuel tank, fuel
tank ller, fuel gauge, fuel transfer pump, fuel transfer valve and hose with ll nozzle. A master
pump switch is located on the inside control panel and an emergency shuto switch is located on
the frame rail near the fuel transfer pump. A metal ground clip reduces the possibility of static
electricity discharge between the fuel station and the equipment being fueled.
To ll the tank, remove the fuel ller cap and ll the tank with the grade of gasoline required
by your equipment. When replacing the fuel ll cap, be sure it seats squarely and turn it rmly
to lock it on the ll pipe neck.
Fuel Transfer System Safety
Static electricity-related incidents when refueling are extremely unusual. ey appear to
happen most oen during cool or cold and dry climate conditions. In rare circumstances,
these static related incidents have resulted in a brief ash re occurring at the ll point. You
can minimize these and other potential fueling hazards by following safe refueling procedures.
NOTE: The diesel generator requires 12
volts DC power from the house auxiliary
batteries to start, and draws diesel fuel
to operator from the chassis fuel tank.
If the fuel level to the chassis fuel tank
drops to or below ¼ full, the generator
will automatically shut OFF and cannot be
restarted until the fuel tank is filled to above
¼ full.
7
71THOR MOTOR COACH | MADE TO FIT
FUEL SYSTEMS
A build-up of static electricity can be caused by reentering a vehicle during fueling. If you
return to the fuel ll pump during refueling, the static may discharge at the ll point, causing a
ash re or small sustained re with fuel vapors.
Here are some additional refueling safety guidelines when refueling a vehicle or lling up fuel
storage containers:
• Turn OFF vehicle engine. Disable or turn OFF any auxiliary sources of ignition: the
furnace, water heater, stove, oven, and any pilot lights, etc. Turn OFF the main propane
valve.
• Do not smoke, light matches or lighters while operating the refueling system, or when
using fuel anywhere else.
• Use only the refueling latch provided on the fuel dispenser nozzle.
• Never jam or otherwise try to lock the refueling latch on the fuel ll.
• Do not re-enter your motorhome during refueling. If you cannot avoid re-entering your
vehicle, discharge any static build-up BEFORE reaching for the nozzle, by touching
something metal with a bare hand, such as the vehicle body or frame that is located away
from the nozzle.
• In the unlikely event a static-caused re occurs when refueling, leave the nozzle in the ll
pipe and back away from the vehicle. Turn OFF the fuel pump master switch immediately.
• Do not over-ll or top-o your vehicle tank, which can cause fuel spillage.
7
• Never allow children under licensed driving age to operate the pump.
• Avoid prolonged breathing of gasoline vapors. Use fuel only in open areas that get plenty
of fresh air.
• Keep your face away from the nozzle or container opening.
• Never siphon fuel by mouth. Never put fuel in your mouth for any reason. Fuel can be
harmful or fatal if swallowed. If someone swallows fuel, do not induce vomiting. Contact
an emergency medical service provider immediately.
• Keep fuel away from your eyes and skin; it may cause irritation.
• Remove fuel-soaked clothing immediately.
• Use gasoline as a motor fuel only. Never use gasoline to wash your hands or as a cleaning solvent.
72 CUSTOMER CARE | 877.855.2867
Propane System
Propane or liqueed petroleum (LP) gas is a clean and ecient form of energy when proper
handling and safety precautions are observed. e propane system in your motorhome
furnishes the fuel for cooking, heating, hot water and propane generator (if so equipped).
Propane can also be used as an alternative energy source for refrigeration.
e propane system is comprised of numerous components such as the propane container,
hoses, propane gas regulator, and piping and copper tubing lines to each appliance. Propane
is heavier than air; the gas tends to ow to lower areas and will sometimes pocket in these low
areas, such as the oor.
Propane Gas Safety
PROPANE SYSTEM
DANGER
IF YOU SMELL PROPANE GAS
1. Extinguish any open ames and all smoking materials.
2. Shut off the propane supply at the container valve(s) or propane supply
connection.
3. Do not touch electrical switches.
4. Open doors and other ventilating openings.
5. Leave the area until the odor clears
6. Have the propane system checked and leakage source corrected before using
again.
Ignition of ammable vapors could lead to a re or explosion and result in death or
serious injury.
DANGER
Do not use gas cooking appliances for comfort heating. Can lead to carbon
monoxide poisoning, which can lead to death or serious injury.
DANGER
Do not use gas cooking appliances
for comfort heating.
Can lead to carbon monoxide
poisoning, which can lead to death
or serious injury.
DANGER
All pilot lignts, appliances, and
their igniters (see operating
instructions) shall be turned off
before refueling of motor fuel tanks
and/or propane containers.
Can cause ignition of ammable
vapors, which can lead to a re or
explosion and result in death or
serious injury.
8
73THOR MOTOR COACH | MADE TO FIT
PROPANE SYSTEM
DANGER
Fuel spills represent a serious re hazard, and should be cleaned up immediately.
Never restart an engine or re-light any pilot lights while raw fuel is present.
WARNING
THIS PROPANE PIPING SYSTEM IS DESIGNED FOR USE WITH PROPANE ONLY.
• Do not connect natural gas to this system.
• Securely cap inlet when not connected for use.
• After turning on propane, except after normal cylinder replacement, test propane
piping and connections to appliances for leakage with soapy water or bubble
solution.
• Do not use products that contain ammonia or chlorine to test for leaks. These
substances may weaken piping components and cause gas leaks, leading to re
or explosion, which could result in death or serious injury.
WARNING
Gas cooking appliances need fresh air for safe operation. Before operating:
• Open vents or windows slightly or turn on exhaust fan prior to using cooking
8
74 CUSTOMER CARE | 877.855.2867
appliance.
• Gas ames consume oxygen, which should be replaced to ensure proper
combustion.
• Improper use can result in death or serious injury.
Propane is a colorless and odorless gas that, in the liqueed state, resembles water. An odorant
(usually a sulfur compound) is added as a warning agent. If you smell propane within your
motorhome, quickly and carefully perform the procedure listed on the label to the right.
Continued periodic checks of the propane system periodically (or at least once a year), by a
qualied propane service representative as part of your normal maintenance is recommended.
Hand tighten the propane gas system valves only, do not use a wrench or pliers as over
tightening may damage the valve seals and cause them to leak.
Propane Leak Test
Leaks may be found easily with a soapy water solution. Do not use a solution containing
ammonia or chlorine when locating leaks. ese products are corrosive to copper gas lines
and brass ttings, which could result in deterioration of the copper and brass components.
Apply the soapy solution to the outside of the gas piping ttings. If a leak is present, the soapy
solution will “bubble” at the leak point. If a leak is indicated, shut OFF the propane system
valve(s) and contact a your selling dealer’s service department or qualied propane service
representative immediately.
Propane Gas Tank
PROPANE SYSTEM
WARNING
Do not ll propane container(s) to more than 80 percent of capacity. A properly lled
container contains approximately 80 percent of its volume as liquid propane.
Overlling the propane container(s) can result in uncontrolled propane ow, which
could lead to a re or explosion and result in death or serious injury.
WARNING
If you suspect your propane container has been overlled, contact your selling
dealer or a qualied propane technician for assistance immediately. Do not attempt
to service a propane container overll yourself.
NOTE: Propane tanks are to be installed,
fueled, and maintained in accordance to
country, federal, state, and local codes,
rules, regulations, laws, or guidelines.
8
75THOR MOTOR COACH | MADE TO FIT
PROPANE SYSTEM
Typical propane gas tank
WARNING
Always shut OFF the engine while refueling propane tank. Do not smoke and do not
operate other ignition sources while refueling.
A permanently mounted A.S.M.E. (American Society of Mechanical Engineers) approved
propane container is located under the oor of your motorhome. Propane expands 1½ percent
for every ten degrees of increase in temperature. It is imperative to leave sucient space inside
the container to allow for natural expansion of gas during warmer weather.
Servicing or Filling
Because the propane tank is not removable, the motorhome will need to be driven to a
qualied propane facility for servicing or lling. Only the authorized gas service technician(s)
should be near the motorhome while the propane tank is being lled. e new propane
container must be carefully purged for proper appliance performance and operation. e
propane tank must NEVER BE OVERFILLED.
Never allow your propane tank to be lled above the maximum safe level as indicated by the
xed liquid level gauge. Do not allow the visible gauge to be used for lling. Overlling the
propane container above the liquid capacity indicated on the container, could allow liquid
propane to enter the system that is designed for vapor only creating a hazardous condition.
e following warning label has been placed on the propane tank:
8
76 CUSTOMER CARE | 877.855.2867
Using the Propane System
After your motorhome is completely set up, to operate the propane system:
1. Close ALL burner valves, controls and pilot light valves.
2. Open the main valve in the propane tank slowly to avoid a fast rush of propane vapor
through the excess ow valve causing propane “freeze-up.” If you experience propane
“freeze-up,” close the main valve and wait 15 minutes before trying again.
3. Listen carefully as propane begins to ow. If a hissing noise is heard for more than one or
two seconds, close the main valve and contact your selling dealer’s Service Department to
have the propane system tested.
4. Light the appliances as needed and directed in the appropriate appliance manufacturer
instructions.
Make sure that you read and fully understand ALL safety requirements for handling and
operation of the propane system.
PROPANE SYSTEM
Traveling With Propane
Some states prohibit propane appliances to be operated during travel, especially in
underground tunnels. Make sure you are familiar with the laws for the areas where you travel.
8
77THOR MOTOR COACH | MADE TO FIT
This page is intentionally left blank
78 CUSTOMER CARE | 877.855.2867
Water Systems
Fresh Water System
Potable (drinking) water is supplied throughout your motorhome from the fresh water tank
or from a connection to an outside water source attached to the city water ll. When using
the fresh water tank, water is pressurized and travels through the water lines by means of the
water pump. When utilizing an exterior water source, such as a campsite water spigot, the
water pump is not needed as the campsite water source is already pressurized and will ow
through the water supply lines.
Potable Water Hose
We recommend purchasing and keeping sanitized a water hose whose sole function is for use
with your potable water system. We do not recommend using the same water hose for potable
water, maintenance, or sewer system cleanup, etc.
Connecting to an Exterior Water Fill
1. Set your water heater bypass valves to the correct position listed on your water system
label.
WATER SYSTEMS
2. Remove the cap from the fresh water inlet on the side of the motorhome.
3. Attach one end of your potable (drinking) water hose to the outside source of water.
4. Connect the other end of the hose to the motorhome's city water inlet.
5. Turn ON the outside source of water. Gradually open the hot and cold water at the sinks
and tub to clear air from the lines. Close the faucets when the water is owing freely.
To Disconnect From the Outside Water Source
1. Turn OFF the outside source of water.
2. Disconnect your potable water hose from the supply valve and the fresh water inlet.
3. Remove the water hose and store.
4. Reinstall the cap on the fresh water inlet.
Typical city water fill
9
NOTE: Disconnect from the fresh water
inlet or city water fill if leaving your
motorhome for an extended period longer
than a few hours.
79THOR MOTOR COACH | MADE TO FIT
WATER SYSTEMS
Filling the Fresh Water Tank
NOTICE
Do not leave the motorhome unattended while lling the fresh water tank. Although
the fresh water tank has an overll vent, incoming water volume may exceed the
capacity of the overll vent, creating excessive pressure within the water tank and
possible damage to seals and ttings.
When an outside source of water is unavailable, water can be drawn from the fresh water
storage tank in the motorhome. is can be referred to as dry-camping.
1. Set your water heater bypass valves to the correct position listed on your water system
label
2. If your fresh water tank overow valves are shut OFF or capped:
a. Open the fresh water tank overow shut-o valves, or
Typical fresh water gravity fill
NOTE: It is normal to lose water from the
fresh water tank via the overflow tube while
traveling.
9
b. Unscrew and remove the fresh water tank overow valve caps
3. Remove the water ll cap
4. Water can now be added directly to the fresh water tank through the ll spout by use
of a clean potable water hose or a bucket that used only for this purpose. We do not
recommend using the same bucket to ll your potable (drinking) water tank and perform
maintenance tasks, etc.
5. When the tank is full and water is coming out of the fresh water overow tubes located
under your motorhome:
a. Stop lling the fresh water tank
b. Replace the water ll cap
c. Allow water to continue to ow from the fresh water tank overow tubes until the
water pressure equalizes and there is no more water coming from the overow tubes
To use water from the fresh water tank, turn the water pump ON to pressurize the water in the
80 CUSTOMER CARE | 877.855.2867
lines and to the water heater. When ready, gradually open the hot and cold water at the sinks
and tub to clear air from the lines (it can be normal to see water "spit" from the faucets until
the system is pressurized). Close the faucets when the water is owing freely.
Water Pump
When you are not connected to city water (e.g., campsite water) and want to use water in your
motorhome you will need sucient 12 volts DC power to run the water pump. Once turned
ON at the monitor panel, the water pump (also known as an on-demand pump) will selfprime and provide water.
OPERATION
e water pump is designed for use on an as needed basis. Using the water pump continuously
or with high pressure will shorten its operational life and is not covered by warranty. e
water pump has a check valve that prevents water from back owing into the fresh water tank.
Before operating the water pump:
1. Make sure there is adequate water in the fresh water tank.
2. Be sure the water heater bypass valves are set correctly according to your water system
label.
WATER SYSTEMS
NOTE: Do not turn the water pump ON
if the fresh water tank is empty. Doing so
could cause damage to the water pump, or
blow a fuse.
NOTE: Do not turn ON the water pump
when using water from an external source.
Only run the water pump if using potable
water stored in your fresh water tank.
NOTE: The water pump should be
turned OFF when the motorhome is left
unattended for any amount of time. This
may help limit potential damage should
something fail within the water system.
3. Open all the faucets (rst hot, then cold) including your interior and exterior shower
faucets.
4. Turn the pump switch ON, and allow the water pump to ll the water lines and hot water
tank. Aer water is owing in a steady stream from all your faucets, turn the faucets OFF.
e water pump should stop operation automatically when all faucets are closed. e
pump should now run "on-demand" when a faucet is opened, and stop when the faucet is
closed.
WATER PUMP STRAINER
If so equipped, periodically check the in-line water pump strainer for accumulated debris. To
clean the water pump strainer shut OFF the water pump, unscrew the clear cap, remove the
reusable metal cartridge, clear any debris, and reinstall the strainer and cap.
Water pump
strainer
9
Typical water pump installation
81THOR MOTOR COACH | MADE TO FIT
WATER SYSTEMS
For additional information on the care and operation of the water pump, refer to the water
pump manufacturer’s information.
Sanitizing the Fresh Water System
Sanitize the fresh water system before initial RVing use each year, aer extended periods of
motorhome storage, at least once a year during continuous use, or if you think the fresh water
system has been compromised or contaminated.
1. Remove or by-pass your potable (drinking) water lter (if so equipped).
2. Disconnect and cap (or by-pass) your refrigerator ice maker inlet water line (if so equipped).
3. Disconnect and cap (or by-pass) your dishwasher inlet line (if so equipped).
4. Disconnect and cap (or by-pass) your washer inlet line (if so equipped).
5. If you have a dishwasher, ice maker, or washer follow the appropriate appliance
manufacturer’s instructions pertaining to sanitization.
6. Prepare a solution using a gallon of water and ¼ cup of liquid household bleach (5% sodium
hypo-chlorinate solution). Use one gallon of solution for each 15 gallons of tank capacity.
7. Open your fresh water tank bypass tube shut o valves, or uncap them.
8. With an empty tank and all faucets and drains closed, pump the solution into the fresh water
tank, via the water ll cap using the water pump. Or carefully pour 1/2 cup of bleach (1/4
cup per 15 gallons of capacity) into your potable (drinking) water hose before connecting it
to the water source. e water source pressure will push the chlorine and water into the fresh
water tank, making the correct solution when the fresh water tank is full.
9. Completely ll the fresh water tank with fresh water.
10. Switch ON the water pump. Open all the faucets one at a time until all air is purged, and
the water ows freely.
9
11. Add fresh water to the fresh water tank again, until the water level reaches the ll spout.
12. Allow the solution to stand in the fresh water tank for at least three (3) hours.
13. Drain the fresh water system by opening all faucets and the fresh water tank drain valve
while ushing the system with fresh potable (drinking) water.
82 CUSTOMER CARE | 877.855.2867
14. Continue ushing the system, allowing the water to ow for several minutes.
15. Close the fresh water tank drain valve and the faucets. Rell the system with potable
(drinking) water.
Waste Water System
Depending on your motorhome model year, make, and model, the water and debris from the
sinks and shower (or tub) ow into the gray water (or waste water) holding tank. Water and
debris from the toilet ow into the black water (or sewage) holding tank. Some brands and
models may also have the lavatory, shower, or tub draining into the black water (waste water)
holding tank.
Drain Pipes
WATER SYSTEMS
Drain pipes have P-traps and/or waterless traps (HEPVOs) installed to help prevent drain
odors from escaping into the motorhome. During travel, water within P-traps may displace
and permit odors into the motorhome. Drain-related odors come from decomposing
materials in the holding tank. If odors are detected, place a few cups of water down each drain
and use a RV approved deodorizing agent, which will reduce drain odors and help keep the
drain lines and tanks clean and free owing. Drain chemicals are available at RV supply stores.
Vents
Vent pipes and vents release air from the grey and black water holding tanks. e exterior
vent cap is attached to the roof, and must be kept clear of debris and obstructions to perform
as intended. On some brands and models, the vent pipe may be part of the drainage system
referred to as a “wet vent” (water ows downward as air ows upward in the same pipe).
Emptying the Holding Tanks
1. Remove the cap from the sewer drain and connect your exible sewer drain line.
2. Attach the other end of the exible sewer drain line to the dump station inlet. Be sure both
ends of the exible sewer drain line are securely attached.
NOTICE
Remove the waterless trap before
using mechanical drain-rooting
devices. Otherwise, the waterless
trap can be damaged.
Typical HEPVO valve label (if so equipped)
9
Typical termination valves
83THOR MOTOR COACH | MADE TO FIT
WATER SYSTEMS
NOTE: We recommend wearing gloves and
other protective gear when emptying the
holding tanks.
NOTE: It is important to familiarize yourself
with your motorhome’s waste drainage
system, as some models have two gate
valves on a single black tank.
3. Drain the black water holding tank rst by pulling the termination valve handle away from
the valve body. Be sure to allow sucient time for the black water holding tank to completely
drain, then rinse the black water holding tank with several gallons of water by depressing the
toilet stool pedal, hand ush handle, or use the black tank ush (if so equipped).
4. Drain the gray water holding tank by pulling the termination valve handle away from the
valve body. Draining the gray water holding tank last allows the soapy water in the gray
water holding tank to rinse the sewer drain and exible sewer drain line.
5. When both the black water and gray water tanks are emptied, close the termination valves
by pushing the handles back to the closed positions.
6. Remove the exible sewer drain hose, and wash it thoroughly with clean water. Remove
the other end from the dump station inlet, and replace it in its storage compartment.
7. Replace the sewer drain caps on both the motorhome outlet and the dump station inlet.
Black Tank Flush
CAUTION
Do not use the tank ush valve unless the fullway termination valve is in the open
position.
Can result in an unsanitary condition leading to illness or personal injury.
Typical black tank flush
Winterizing the Water Systems
9
WARNING
Automotive antifreeze (ethylene glycol) and windshield washer antifreeze (methanol)
are poisonous. Never use these products in your fresh water system. These
products are harmful and may be fatal if swallowed.
84 CUSTOMER CARE | 877.855.2867
Preparing for colder weather or storage is very important. e motorhome should be
winterized at the end of the camping season, or when exposed to temperatures that will fall
at or below 32°F (0°C). Repairs due to freezing are not covered by warranty. Add only RV
antifreeze to the fresh water system to ensure freeze protection. It may be easier to winterize
the motorhome with another person assisting you.
1. Level the motorhome and drain the fresh water plumbing system.
2. Remove or by-pass your potable (drinking) water lter (if so equipped).
3. Disconnect and cap (or by-pass) your refrigerator ice maker inlet water line (if so equipped).
4. Disconnect and cap (or by-pass) your dishwasher inlet line (if so equipped).
5. Disconnect and cap (or by-pass) your washer inlet line (if so equipped).
6. If you have a dishwasher, ice maker, or washer follow the appropriate appliance
manufacturer’s instructions pertaining to winterization (and de-winterization).
7. Turn OFF both the 12 volt gas and 120 volt electric water heater switches on the monitor panel.
8. Turn OFF the gas valve at the water heater or shut the tankless water heater switch OFF.
WATER SYSTEMS
9. Turn the water heater bypass valves (if so equipped) to the BYPASS position. (A tankless
water heater may not have bypass valves).
10. Move the valves to the WINTERIZE position, as shown on your water system label.
11. Close the low point drains.
12. Attach a hose to the city water ll and insert the other end of the hose into a gallon
container of RV antifreeze (this quantity should be enough to winterize the motorhome).
To assist the siphoning process, put the container on a surface approximately two feet
above ground level.
13. Turn the water pump ON. If the water pump fails to self-prime, temporarily open the low
point drains. Close the low point drains as soon as the water pump primes (RV antifreeze
will begin draining out), and before continuing to the next step.
14. Open the hot water side on all faucets (kitchen, lavatory, shower, and exterior shower)
until RV antifreeze begins to ow continuously.
9
85THOR MOTOR COACH | MADE TO FIT
WATER SYSTEMS
NOTE: Do not operate the water heater or
use the motorhome plumbing system after
the water system has been winterized.
15. Close the faucet hot water lines and repeat with the cold water lines on all the faucets.
16. Flush the toilet a couple of times until you see antifreeze in the bowl.
When you are done adding RV antifreeze:
17. Remove the water hose from the container of RV antifreeze.
18. To prevent staining, wipe the RV antifreeze out of the sinks, shower (or tub) and toilet
using a so, dry cloth.
De-winterizing Your Motorhome
1. Drain the holding tanks (fresh water, waste water, and sewage).
2. Attach a garden hose to the fresh water ll, and ll the fresh water tank.
3. Turn ON the water pump switch and open the cold water side of all faucets and shower
xtures. Shut OFF the faucet and shower xtures aer the water runs clear (no pink
residue), and repeat for the hot water side.
4. Flush the toilet until clear water runs into bowl.
5. Dump the holding tanks again.
6. Sanitize the water system (refer to Sanitization).
7. If a potable (drinking) water lter has been installed: drain the water lines, remove the
assembly, clean and reinstall using a new potable (drinking) water lter.
8. When ready to use the water heater, open the bypass valve allow water to enter and ll
the water heater tank (remember to shut OFF the water heater bypass mixer valve, if so
equipped).
9
86 CUSTOMER CARE | 877.855.2867
Leveling Jacks and Slideout Systems
DANGER
FAILURE TO ACT IN ACCORDANCE WITH THE FOLLOWING INSTRUCTIONS MAY
RESULT IN SERIOUS PERSONAL INJURY OR DEATH.
READ THE ENTIRE OPERATORS MANUAL AND ALL PRECAUTIONS PRIOR TO
OPERATING THIS EQUIPMENT.
DANGER
Do not attempt to operate the system while the motorhome is in motion. If the
“jacks down” alarm sounds while driving the motorhome, immediately find a safe
place to pull over and stop. Set the parking brake and when it is safe, inspect the
leveling system.
WARNING
LEVELING JACKS AND SLIDEOUT SYSTEMS
DO NOT OPERATE ANY SYSTEM FUNCTIONS WHILE ANYONE IS UNDER THE
MOTORHOME. IF WORK UNDERNEATH YOUR MOTORHOME IS REQUIRED,
SUPPORT BOTH FRONT AND REAR AXLES WITH JACK STANDS. DO NOT RELY ON
THE SUPPORT OF THE LEVELING SYSTEM! FAILURE TO DO SO MANY RESULT IN
PERSONAL INJURY OR DEATH.
WARNING
DO NOT USE THE JACKS TO CHANGE THE TIRES. THE SYSTEM IS DESIGNED
FOR LEVELING AND STABILIZING, AND IS NOT MEANT TO LIFT ALL THE WHEELS
OFF THE GROUND! LIFTING THE WHEELS OFF THE GROUND MAY RESULT IN AN
UNSTABLE VEHICLE CONDITION, WHICH MAY RESULT IN SERIOUS PERSONAL
INJURY OR DEATH.
10
87THOR MOTOR COACH | MADE TO FIT
LEVELING JACKS AND SLIDEOUT SYSTEMS
MAKE SURE THERE ARE NO OBSTRUCTIONS IN THE “EXTEND” OR “RETRACT”
PATHS OF THE JACKS. KEEP ALL PEOPLE AND PETS CLEAR OF THE
MOTORHOME WHILE OPERATING THE LEVELING SYSTEM. ALWAYS VISUALLY
CONFIRM THE JACKS HAVE FULLY RETRACTED BEFORE MOVING THE
MOTORHOME. MOVING THE MOTORHOME WHILE THE JACKS ARE EXTENDED
COULD CAUSE DAMAGE TO THE JACK SYSTEM AND THE MOTORHOME.
NEVER EXPOSE HANDS OR OTHER PARTS OF THE BODY NEAR HYDRAULIC
LEAKS. HIGH-PRESSURE OIL LEAKS MAY CUT AND/OR PENETRATE THE SKIN
CAUSING SERIOUS INJURY.
WARNING
WARNING
10
CAUTION
The motorhome must be level with the leveling jacks in the down position before
operating slideouts.
Leveling Jacks (if so equipped)
Operate the leveling system ONLY under the following conditions:
1. Park the motorhome on a reasonably level surface.
a. Use (customer supplied) jack pads if parked on a so surface.
88 CUSTOMER CARE | 877.855.2867
LEVELING JACKS AND SLIDEOUT SYSTEMS
2. Put the chassis transmission in the:
a. NEUTRAL position for rear mount diesel engine vehicles.
b. PARK position for all front mount gasoline or diesel engine vehicles.
3. Engage the motorhome PARKING BRAKE.
4. Start the chassis engine and keep it running while operating the leveling jack system.
5. Be sure all persons, pets, and property are clear of your motorhome while operating
the leveling system. If you are operating an automatic system with occupants inside the
motorhome, they must stay seated during the leveling process.
Stabilizing Jacks (if so equipped)
If your motorhome is equipped with power rear stabilizing jacks, the operating button is
located inside the motorhome by the stepwell. Be sure the rear power stabilizing jacks are
retracted in the up (travel) position before driving the motorhome.
Slideout Systems
NOTE: If you have an automatic leveling
system, do not allow people to walk around
when attempting to level the motorhome.
Doing so could disrupt the leveling jack’s
sensing mechanism.
NOTE: Stabilizing jacks are not designed or
intended to be used to level the motorhome.
DANGER
Do not move or drive your motorhome with slideout(s) extended.
TMC motorhomes are equipped with hydraulic or electric slideout systems, or a combination
of both. Please refer to the slide mechanism manufacturer’s owner's manual and follow their
safety, operation, and maintenance instructions. If you feel you are missing this information,
please contact your selling dealership, TMC Customer Care, or the slide mechanism
manufacturer for assistance. Or for your convenience, many of our suppliers make their
manuals available for download from their respective websites.
10
89THOR MOTOR COACH | MADE TO FIT
LEVELING JACKS AND SLIDEOUT SYSTEMS
• Remove travel bars or slide-locks if equipped
• Engage emergency brake
• Place driver and front passenger seats in the most forward position and place
The motorhome must be level with the leveling jacks in the down position before
operating slideouts.
Before extending the slideout, check around and above the exterior of the motorhome to be
sure the slideout will not hit anything outside when it is fully extended; also check the interior
of your motorhome to be sure that slideout travel is free from obstructions before operation.
CAUTION
BEORE OPERATING SLIDEOUT ROOMS:
the seat-backs in the upright position, otherwise slideout may contact and
damage these seats
CAUTION
10
Extending the Slideout
Aer completing the exterior and interior inspections prior to slideout operation, next:
1. Put the motorhome transmission in PARK and:
a. Diesel Class A motorhome: apply PARKING BRAKE (engine must be running).
b. Gas Class A motorhome: apply PARKING BRAKE (engine must be OFF, and keys
removed from ignition).
c. Class C motorhome: apply PARKING BRAKE (engine must be OFF, and keys removed
from ignition).
90 CUSTOMER CARE | 877.855.2867
LEVELING JACKS AND SLIDEOUT SYSTEMS
2. Turn the battery disconnect switch ON.
3. Locate the slideout operating switch and:
a. Hydraulic slideout: press and hold the slideout operating switch until the slideout room
is fully extended. en release switch.
b. Electric slideout: extend the slideout out and hold the switch for an additional 3-5
seconds (this allows the slide motors to amp out).
Note: ere is a 30 second delay feature on the tilt a bed rear bed slideout (if so equipped),
to allow time to raise the head of the bed.
4. Aer the room is fully extended, immediately release the button. Failure to do so could
cause damage to the slide assembly.
Retracting the Slideout
Use the same safety precautions as previously stated for extending the slideout, and:
1. Be sure there are no obstructions on the oor of the coach or in the path of the room as it
is coming in.
2. Ensure there is no visible dirt or debris in the track of the slideout or under it. Trapped
dirt or debris could cause damage to your carpet or oor.
3. Locate the slideout operating switch and:
a. Hydraulic slideout: press and hold the switch until the room is completely retracted,
then immediately release the switch.
b. Electric slideout: Fully retract the room, and hold the switch for an additional 3-5
seconds (until the motors amp out). en immediately release the switch.
4. Install the slideout locking devices (if so equipped.).
NOTE: Always check and remove debris on
the roof of the slideout and awnings before
retracting.
NOTE: Always perform an interior and
exterior visual inspection before leaving the
campground or traveling.
10
91THOR MOTOR COACH | MADE TO FIT
This page is intentionally left blank
92 CUSTOMER CARE | 877.855.2867
Loading...
