THOMSON ST7G, ST790, DV7213 Reference Manual

Thomson ST7G/DV7213/ST790

CLI Reference Guide

Thomson ST7G/DV7213/
ST790

CLI Reference Guide
R6.2

Copyright

Copyright ©1999-2007 THOMSON. All rights reserved.

Distribution and copying of this document, use and communication of its contents is not permitted without written authorization
from THOMSON. The content of this document is furnished for informational use only, may be subject to change without notice,
and should not be construed as a commitment by THOMSON. THOMSON assumes no responsibility or liability for any errors or
inaccuracies that may appear in this document.

Thomson Telecom Belgium
Prins Boudewijnlaan, 47
B-2650 Edegem
Belgium

http://www.thomson-broadband.com

Trademarks

The following trademarks are used in this document:

> DECT is a trademark of ETSI.
> Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
> Ethernet™ is a trademark of Xerox Corporation.
> Wi-Fi® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. "Wi-Fi CERTIFIED", "Wi-Fi ZONE", "Wi-Fi Alli-

ance", their respective logos and "Wi-Fi Protected Access" are trademarks of the Wi-Fi Alliance.

> UPnP™ is a certification mark of the UPnP™ Implementers Corporation.
> Microsoft®, MS-DOS®, Windows® and Windows NT® are either registered trademarks or trademarks of Microsoft Corpo-

ration in the United States and/or other countries.

> Apple® and Mac OS® are registered trademarks of Apple Computer, Incorporated, registered in the United States and

other countries.

> UNIX® is a registered trademark of UNIX System Laboratories, Incorporated.
> Adobe®, the Adobe logo, Acrobat and Acrobat Reader are trademarks or registered trademarks of Adobe Systems, Incor-

porated, registered in the United States and/or other countries.

Other brands and product names may be trademarks or registered trademarks of their respective holders.

Document Information

Status: v2.0 (May 2007)
Reference: E-DOC-CTC-20061027-0009
Short Title: CLI Reference Guide ST7G/DV7213/ST790 R6.2
Software Build: R 6.2.H.5

Contents

About this CLI Reference Guide ............................................... 1

1 Root Commands ..........................................................................3

ping.......................................................................................................................................................... 4

traceroute ................................................................................................................................................5

2 ADSL Commands......................................................................... 7

adsl config............................................................................................................................................... 8

adsl info................................................................................................................................................... 9

adsl debug bitloadinginfo....................................................................................................................11

adsl debug deltconfig...........................................................................................................................12

adsl debug deltinfo...............................................................................................................................13

adsl debug modemoptioninfo.............................................................................................................14

adsl debug modemoption ................................................................................................................... 15

adsl debug traceconfig......................................................................................................................... 16

3 ATM Commands ........................................................................17

atm flush ...............................................................................................................................................19

atm ifadd ............................................................................................................................................... 20

atm ifattach ...........................................................................................................................................21

atm ifconfig ........................................................................................................................................... 22

atm ifdelete ...........................................................................................................................................24

atm ifdetach .......................................................................................................................................... 25

atm iflist.................................................................................................................................................26

atm bundle add.....................................................................................................................................27

atm bundle attach................................................................................................................................. 28

atm bundle config ................................................................................................................................ 29

atm bundle clear...................................................................................................................................30

atm bundle delete.................................................................................................................................31

atm bundle detach................................................................................................................................32

atm bundle flush...................................................................................................................................33

atm bundle ifadd ..................................................................................................................................34

atm bundle ifconfig ..............................................................................................................................35

atm bundle ifdelete .............................................................................................................................. 36

atm bundle list ...................................................................................................................................... 37

atm cac config.......................................................................................................................................38

atm cac list ............................................................................................................................................39

atm cac overbooking............................................................................................................................40

E-DOC-CTC-20061027-0009 v2.0

i

Contents

atm debug aal5stats ............................................................................................................................. 41

atm debug gstats..................................................................................................................................42

atm debug portstats .............................................................................................................................43

atm oam config.....................................................................................................................................44

atm oam list .......................................................................................................................................... 45

atm oam modify ...................................................................................................................................46

atm oam ping........................................................................................................................................48

atm oam cc list......................................................................................................................................49

atm oam cc modify...............................................................................................................................50

atm oam cc send .................................................................................................................................. 51

atm oam vclb add.................................................................................................................................52

atm oam vclb del ..................................................................................................................................53

atm oam vclb list ..................................................................................................................................54

atm phonebook add .............................................................................................................................55

atm phonebook autolist.......................................................................................................................56

atm phonebook delete .........................................................................................................................57

atm phonebook flush ...........................................................................................................................58

atm phonebook list...............................................................................................................................59

atm qosbook add..................................................................................................................................60

atm qosbook config..............................................................................................................................61

atm qosbook ctdadd.............................................................................................................................62

atm qosbook ctddelete......................................................................................................................... 64

atm qosbook ctdlist .............................................................................................................................. 65

atm qosbook delete..............................................................................................................................66

atm qosbook flush................................................................................................................................67

atm qosbook list ................................................................................................................................... 68

4 Config Commands ..................................................................... 69

config delete ......................................................................................................................................... 70

config dump.......................................................................................................................................... 71

config flush ........................................................................................................................................... 72

config list...............................................................................................................................................73

config load ............................................................................................................................................ 74

config save ............................................................................................................................................ 76

5 Connection Commands............................................................. 77

connection appconfig...........................................................................................................................78

connection appinfo...............................................................................................................................80

ii

E-DOC-CTC-20061027-0009 v2.0

Contents

connection applist ................................................................................................................................81

connection bind.................................................................................................................................... 82

connection bindlist............................................................................................................................... 83

connection clean...................................................................................................................................84

connection clear ...................................................................................................................................85

connection config................................................................................................................................. 86

connection debug................................................................................................................................. 87

connection describe .............................................................................................................................88

connection flush ................................................................................................................................... 89

connection info..................................................................................................................................... 90

connection list.......................................................................................................................................91

connection refresh................................................................................................................................92

connection stats....................................................................................................................................93

connection timerclear .......................................................................................................................... 94

connection timerconfig........................................................................................................................95

connection unbind................................................................................................................................96

6 CWMP Commands..................................................................... 97

cwmp config .........................................................................................................................................98

cwmp debug traceconfig ...................................................................................................................100

cwmp server config............................................................................................................................101

7 Debug Commands ................................................................... 103

debug exec..........................................................................................................................................104

8 DHCP Commands .................................................................... 105

dhcp client flush ................................................................................................................................. 107

dhcp client ifadd .................................................................................................................................108

dhcp client ifattach .............................................................................................................................109

dhcp client ifconfig.............................................................................................................................110

dhcp client ifdelete .............................................................................................................................111

dhcp client ifdetach ............................................................................................................................112

dhcp client iflist...................................................................................................................................113

dhcp client ifrenew.............................................................................................................................115

dhcp client debug clear......................................................................................................................117

dhcp client debug stats......................................................................................................................118

dhcp client debug traceconfig...........................................................................................................119

dhcp client rqoptions add ..................................................................................................................120

E-DOC-CTC-20061027-0009 v2.0

iii

Contents

dhcp client rqoptions delete ..............................................................................................................121

dhcp client rqoptions list ...................................................................................................................122

dhcp client rqoptions optionlist ........................................................................................................123

dhcp client txoptions add ..................................................................................................................124

dhcp client txoptions delete ..............................................................................................................125

dhcp client txoptions list....................................................................................................................126

dhcp client txoptions optionlist.........................................................................................................127

dhcp relay add .................................................................................................................................... 128

dhcp relay debug stats....................................................................................................................... 129

dhcp relay debug traceconfig............................................................................................................ 130

dhcp relay config................................................................................................................................ 131

dhcp relay delete ................................................................................................................................132

dhcp relay flush .................................................................................................................................. 133

dhcp relay ifconfig..............................................................................................................................134

dhcp relay iflist ................................................................................................................................... 136

dhcp relay list......................................................................................................................................137

dhcp relay modify...............................................................................................................................138

dhcp relay ruleadd..............................................................................................................................139

dhcp relay ruledelete..........................................................................................................................140

dhcp rule add ...................................................................................................................................... 141

dhcp rule debug traceconfig..............................................................................................................142

dhcp rule delete .................................................................................................................................. 143

dhcp rule flush .................................................................................................................................... 144

dhcp rule list ....................................................................................................................................... 145

dhcp server config..............................................................................................................................146

dhcp server flush ................................................................................................................................147

dhcp server policy ..............................................................................................................................148

dhcp server debug clear ....................................................................................................................149

dhcp server debug stats..................................................................................................................... 150

dhcp server debug traceconfig..........................................................................................................152

dhcp server lease add ........................................................................................................................ 153

dhcp server lease delete .................................................................................................................... 155

dhcp server lease flush ...................................................................................................................... 156

dhcp server lease list.......................................................................................................................... 157

iv

dhcp server option flush....................................................................................................................158

dhcp server option instadd................................................................................................................ 159

dhcp server option instdelete............................................................................................................ 161

dhcp server option instlist ................................................................................................................. 162

E-DOC-CTC-20061027-0009 v2.0

Contents

dhcp server option tmpladd .............................................................................................................. 163

dhcp server option tmpldelete .......................................................................................................... 164

dhcp server option tmpllist................................................................................................................ 165

dhcp server pool add .........................................................................................................................166

dhcp server pool config .....................................................................................................................168

dhcp server pool delete ..................................................................................................................... 170

dhcp server pool flush ....................................................................................................................... 171

dhcp server pool list...........................................................................................................................172

dhcp server pool optadd....................................................................................................................173

dhcp server pool optdelete................................................................................................................ 174

dhcp server pool rtadd....................................................................................................................... 176

dhcp server pool rtdelete................................................................................................................... 177

dhcp server pool ruleadd...................................................................................................................178

dhcp server pool ruledelete............................................................................................................... 179

9 DNS Commands ......................................................................181

dns client config ................................................................................................................................. 182

dns client dnsadd ............................................................................................................................... 183

dns client dnsdelete ...........................................................................................................................184

dns client dnslist.................................................................................................................................185

dns client flush.................................................................................................................................... 186

dns client nslookup ............................................................................................................................187

dns server config ................................................................................................................................188

dns server flush ..................................................................................................................................189

dns server debug clear....................................................................................................................... 190

dns server debug stats....................................................................................................................... 191

dns server debug spoof clear ............................................................................................................ 192

dns server debug spoof getaddress ................................................................................................. 193

dns server debug spoof getflags.......................................................................................................194

dns server debug spoof list ............................................................................................................... 195

dns server debug spoof update ........................................................................................................ 196

dns server host add............................................................................................................................ 197

dns server host delete........................................................................................................................ 198

dns server host flush.......................................................................................................................... 199

dns server host list .............................................................................................................................200

dns server route add ..........................................................................................................................201

dns server route delete ...................................................................................................................... 203

dns server route flush ........................................................................................................................ 204

E-DOC-CTC-20061027-0009 v2.0

v

Contents

dns server route list............................................................................................................................ 205

10 DSD Commands....................................................................... 207

dsd config............................................................................................................................................208

dsd debug config................................................................................................................................209

dsd debug connection list.................................................................................................................. 210

dsd debug proxy................................................................................................................................. 211

dsd debug recycling ...........................................................................................................................212

dsd debug stats .................................................................................................................................. 213

dsd intercept config............................................................................................................................ 214

dsd syslog config................................................................................................................................ 215

dsd syslog list .....................................................................................................................................216

dsd urlfilter config ..............................................................................................................................217

dsd urlfilter rule add........................................................................................................................... 218

dsd urlfilter rule delete....................................................................................................................... 219

dsd urlfilter rule flush......................................................................................................................... 220

dsd urlfilter rule list ............................................................................................................................ 221

dsd urlfilter rule modify ..................................................................................................................... 222

11 DynDNS Commands................................................................ 225

dyndns add .........................................................................................................................................226

dyndns delete .....................................................................................................................................227

dyndns flush .......................................................................................................................................228

dyndns list........................................................................................................................................... 229

dyndns modify.................................................................................................................................... 230

dyndns host add ................................................................................................................................. 232

dyndns host delete ............................................................................................................................. 233

dyndns host flush............................................................................................................................... 234

dyndns host list .................................................................................................................................. 235

dyndns service list..............................................................................................................................236

dyndns service modify....................................................................................................................... 238

12 Env Commands........................................................................ 241

env flush..............................................................................................................................................242

vi

env get.................................................................................................................................................243

env list ................................................................................................................................................. 244

env set .................................................................................................................................................245

env unset.............................................................................................................................................246

E-DOC-CTC-20061027-0009 v2.0

Contents

13 Eth Commands ........................................................................ 247

eth ifadd .............................................................................................................................................. 249

eth ifattach .......................................................................................................................................... 250

eth ifconfig ..........................................................................................................................................251

eth ifdelete .......................................................................................................................................... 252

eth ifdetach ......................................................................................................................................... 253

eth iflist................................................................................................................................................254

eth flush...............................................................................................................................................255

eth bridge clear...................................................................................................................................256

eth bridge list ......................................................................................................................................257

eth bridge add..................................................................................................................................... 258

eth bridge delete................................................................................................................................. 259

eth bridge select .................................................................................................................................260

eth bridge config ................................................................................................................................ 261

eth bridge dynvlan actlist ..................................................................................................................262

eth bridge dynvlan add ......................................................................................................................263

eth bridge dynvlan config.................................................................................................................. 264

eth bridge dynvlan delete .................................................................................................................. 265

eth bridge dynvlan flush ....................................................................................................................266

eth bridge dynvlan list .......................................................................................................................267

eth bridge flush...................................................................................................................................268

eth bridge ifadd ..................................................................................................................................269

eth bridge ifattach ..............................................................................................................................270

eth bridge ifconfig ..............................................................................................................................271

eth bridge ifdelete ..............................................................................................................................273

eth bridge ifdetach .............................................................................................................................274

eth bridge iflist....................................................................................................................................275

eth bridge ifflush ................................................................................................................................ 276

eth bridge igmpsnooping config....................................................................................................... 277

eth bridge igmpsnooping list ............................................................................................................ 278

eth bridge igmpsnooping ifconfig ....................................................................................................279

eth bridge igmpsnooping iflist..........................................................................................................280

eth bridge igmpsnooping clear.........................................................................................................281

eth bridge macadd .............................................................................................................................282

eth bridge macdelete .........................................................................................................................284

eth bridge maclist...............................................................................................................................286

eth bridge mcdadd .............................................................................................................................287

eth bridge mcddelete .........................................................................................................................288

E-DOC-CTC-20061027-0009 v2.0

vii

Contents

eth bridge mcdlist............................................................................................................................... 289

eth device ifconfig ..............................................................................................................................290

eth device iflist....................................................................................................................................292

14 Expr Commands ......................................................................295

expr add .............................................................................................................................................. 296

expr delete .......................................................................................................................................... 300

expr flush ............................................................................................................................................ 302

expr list................................................................................................................................................303

expr modify.........................................................................................................................................307

15 Firewall Commands................................................................. 311

firewall config .....................................................................................................................................312

firewall clear........................................................................................................................................314

firewall list...........................................................................................................................................315

firewall chain add ...............................................................................................................................317

firewall chain delete ...........................................................................................................................319

firewall chain flush .............................................................................................................................321

firewall chain list.................................................................................................................................322

firewall debug clear............................................................................................................................323

firewall debug stats ............................................................................................................................324

firewall debug traceconfig.................................................................................................................325

firewall level add ................................................................................................................................ 326

firewall level delete ............................................................................................................................ 327

firewall level flush .............................................................................................................................. 328

firewall level list..................................................................................................................................329

firewall level modify...........................................................................................................................330

firewall level set..................................................................................................................................331

firewall rule add..................................................................................................................................332

firewall rule delete..............................................................................................................................333

firewall rule flush................................................................................................................................334

firewall rule list ...................................................................................................................................335

firewall rule modify ............................................................................................................................337

firewall rule debug clear .................................................................................................................... 338

viii

firewall rule debug stats ....................................................................................................................340

firewall rule debug traceconfig ......................................................................................................... 342

16 GRP Commands....................................................................... 343

E-DOC-CTC-20061027-0009 v2.0

Contents

grp config ............................................................................................................................................ 344

grp flush .............................................................................................................................................. 345

grp rtlist ............................................................................................................................................... 346

grp rip config ...................................................................................................................................... 347

grp rip flush.........................................................................................................................................350

grp rip ifconfig ....................................................................................................................................351

grp rip show........................................................................................................................................353

17 Hostmgr Commands ............................................................... 355

hostmgr add........................................................................................................................................356

hostmgr clear......................................................................................................................................358

hostmgr config ................................................................................................................................... 359

hostmgr delete.................................................................................................................................... 360

hostmgr flush......................................................................................................................................361

hostmgr list ......................................................................................................................................... 362

18 IDS Commands ........................................................................363

ids clear ............................................................................................................................................... 364

ids config............................................................................................................................................. 365

ids parser list.......................................................................................................................................366

ids parser modify................................................................................................................................367

ids pattern clear .................................................................................................................................. 369

ids pattern list .....................................................................................................................................370

ids pattern stats ..................................................................................................................................371

ids signature list ................................................................................................................................. 372

ids signature modify .......................................................................................................................... 373

ids threshold clear ..............................................................................................................................374

ids threshold list ................................................................................................................................. 375

ids threshold modify ..........................................................................................................................376

19 IGMP Commands..................................................................... 377

igmp host config.................................................................................................................................378

igmp host flush...................................................................................................................................379

igmp host list ......................................................................................................................................380

igmp host ifconfig .............................................................................................................................. 381

igmp host iflist .................................................................................................................................... 382

igmp host debug clear .......................................................................................................................383

igmp host debug stats .......................................................................................................................384

E-DOC-CTC-20061027-0009 v2.0

ix

Contents

igmp proxy config ..............................................................................................................................385

igmp proxy flush ................................................................................................................................ 387

igmp proxy grouplist.......................................................................................................................... 388

igmp proxy ifconfig ............................................................................................................................389

igmp proxy iflist..................................................................................................................................390

igmp proxy mbslist ............................................................................................................................ 391

igmp proxy debug clear..................................................................................................................... 392

igmp proxy debug stats .....................................................................................................................393

igmp proxy debug traceconfig..........................................................................................................394

20 Interface Commands ...............................................................395

interface list.........................................................................................................................................396

21 IP Commands ...........................................................................399

ip arpadd ............................................................................................................................................. 401

ip arpdelete .........................................................................................................................................402

ip arplist...............................................................................................................................................403

ip config...............................................................................................................................................404

ip flush................................................................................................................................................. 406

ip ifadd.................................................................................................................................................407

ip ifattach.............................................................................................................................................408

ip ifconfig ............................................................................................................................................409

ip ifdelete.............................................................................................................................................411

ip ifdetach............................................................................................................................................412

ip iflist ..................................................................................................................................................413

ip ifwait................................................................................................................................................ 414

ip ipadd................................................................................................................................................415

ip ipconfig ...........................................................................................................................................416

ip ipdelete............................................................................................................................................417

ip iplist .................................................................................................................................................418

ip mcast rtadd ..................................................................................................................................... 419

ip mcast rtdelete ................................................................................................................................. 420

ip mcast rtlist ...................................................................................................................................... 421

ip mcast flush......................................................................................................................................422

ip rtadd ................................................................................................................................................ 423

ip rtdelete ............................................................................................................................................ 425

ip rtlist..................................................................................................................................................426

ip auto flush ........................................................................................................................................427

x

E-DOC-CTC-20061027-0009 v2.0

Contents

ip auto ifadd ........................................................................................................................................ 428

ip auto ifattach .................................................................................................................................... 429

ip auto ifconfig....................................................................................................................................430

ip auto ifdelete .................................................................................................................................... 432

ip auto ifdetach ...................................................................................................................................433

ip auto iflist ......................................................................................................................................... 434

ip debug httpprobe.............................................................................................................................435

ip debug sendto..................................................................................................................................436

ip debug stats .....................................................................................................................................438

ip debug traceconfig .......................................................................................................................... 439

22 IPQoS Commands.................................................................... 441

ipqos config ........................................................................................................................................442

ipqos list .............................................................................................................................................. 445

ipqos ef config ....................................................................................................................................446

ipqos ef list..........................................................................................................................................447

ipqos ef stats.......................................................................................................................................448

ipqos queue clear ...............................................................................................................................449

ipqos queue config.............................................................................................................................450

ipqos queue list .................................................................................................................................. 452

ipqos queue stats ............................................................................................................................... 453

23 Label Commands .....................................................................455

label add.............................................................................................................................................. 456

label delete.......................................................................................................................................... 457

label flush............................................................................................................................................ 458

label list ............................................................................................................................................... 459

label modify ........................................................................................................................................ 460

label chain add....................................................................................................................................463

label chain delete................................................................................................................................464

label chain flush..................................................................................................................................465

label chain list..................................................................................................................................... 466

label rule add ...................................................................................................................................... 467

label rule delete ..................................................................................................................................470

label rule flush .................................................................................................................................... 472

label rule list........................................................................................................................................473

label rule modify.................................................................................................................................475

label rule debug clear......................................................................................................................... 476

E-DOC-CTC-20061027-0009 v2.0

xi

Contents

label rule debug stats.........................................................................................................................478

label rule debug traceconfig.............................................................................................................. 479

24 Language Commands ............................................................. 481

language config .................................................................................................................................. 482

language delete ..................................................................................................................................483

language list........................................................................................................................................484

25 MBUS Commands ................................................................... 485

mbus client config .............................................................................................................................. 486

mbus client exec.................................................................................................................................487

mbus client register............................................................................................................................ 489

mbus debug stats ............................................................................................................................... 490

mbus debug clearstats.......................................................................................................................491

mbus debug traceconfig ....................................................................................................................492

mbus listobjects..................................................................................................................................493

mbus listtypes.....................................................................................................................................494

mbus listenums ..................................................................................................................................495

mbus listcontexts ............................................................................................................................... 496

mbus listsubscriptions....................................................................................................................... 497

mbus debug loadobjects ................................................................................................................... 498

mbus debug unloadobjects..............................................................................................................499

mbus pluginevent...............................................................................................................................500

mbus unregister ................................................................................................................................. 501

mbus client unregister .......................................................................................................................502

26 MEMM Commands.................................................................. 503

memm debug lock traceconfig..........................................................................................................504

memm debug traceconfig .................................................................................................................505

memm debug clearstats .................................................................................................................... 506

memm debug lock stats..................................................................................................................... 507

memm listobjects ............................................................................................................................... 508

memm stats ........................................................................................................................................509

xii

27 NAT Commands....................................................................... 511

nat config ............................................................................................................................................ 512

nat flush...............................................................................................................................................513

nat ifconfig ..........................................................................................................................................514

E-DOC-CTC-20061027-0009 v2.0

Contents

nat iflist................................................................................................................................................515

nat mapadd ......................................................................................................................................... 516

nat mapdelete .....................................................................................................................................520

nat maplist .......................................................................................................................................... 521

nat tmpladd.........................................................................................................................................522

nat tmpldelete.....................................................................................................................................526

nat tmpllist ..........................................................................................................................................527

nat tmplinst ......................................................................................................................................... 528

28 PPP Commands........................................................................ 529

ppp flush .............................................................................................................................................530

ppp ifadd ............................................................................................................................................. 531

ppp ifattach .........................................................................................................................................533

ppp ifconfig ......................................................................................................................................... 535

ppp ifdelete .........................................................................................................................................540

ppp ifdetach ........................................................................................................................................ 542

ppp iflist...............................................................................................................................................544

ppp ifscan............................................................................................................................................ 545

ppp rtadd.............................................................................................................................................546

ppp rtdelete.........................................................................................................................................548

ppp relay flush .................................................................................................................................... 550

ppp relay ifadd....................................................................................................................................551

ppp relay ifconfig................................................................................................................................ 552

ppp relay ifdelete................................................................................................................................553

ppp relay iflist .....................................................................................................................................554

ppp relay sesslist................................................................................................................................ 555

29 PPTP Commands .....................................................................557

pptp ifadd ............................................................................................................................................ 558

pptp flush ............................................................................................................................................559

pptp list................................................................................................................................................560

pptp profadd .......................................................................................................................................561

pptp profdelete ...................................................................................................................................563

pptp proflist.........................................................................................................................................564

30 Script Commands ....................................................................565

script add.............................................................................................................................................566

script delete.........................................................................................................................................567

E-DOC-CTC-20061027-0009 v2.0

xiii

Contents

script flush...........................................................................................................................................568

script list .............................................................................................................................................. 569

script run .............................................................................................................................................571

31 Service Commands.................................................................. 573

service host assign .............................................................................................................................574

service host config ............................................................................................................................. 575

service host add.................................................................................................................................. 576

service host delete.............................................................................................................................. 577

service host disable............................................................................................................................578

service host flush................................................................................................................................ 579

service host list ...................................................................................................................................580

service host stats ................................................................................................................................ 581

service host triggerlist........................................................................................................................ 582

service host rule add ..........................................................................................................................583

service host rule delete ......................................................................................................................584

service system ifadd........................................................................................................................... 585

service system ifdelete....................................................................................................................... 586

service system ipadd.......................................................................................................................... 587

service system ipdelete...................................................................................................................... 588

service system list ..............................................................................................................................589

service system mapadd ..................................................................................................................... 591

service system mapdelete ................................................................................................................. 592

service system modify ....................................................................................................................... 593

32 SNTP Commands..................................................................... 595

sntp add...............................................................................................................................................596

sntp config .......................................................................................................................................... 597

sntp delete...........................................................................................................................................598

sntp flush.............................................................................................................................................599

sntp list ................................................................................................................................................ 600

33 Software Commands .............................................................. 601

software cleanup ................................................................................................................................602

xiv

software deletepassive ......................................................................................................................603

software download............................................................................................................................. 604

software duplicate ..............................................................................................................................605

software setpassive............................................................................................................................606

E-DOC-CTC-20061027-0009 v2.0

Contents

software switch...................................................................................................................................607

software upgrade ............................................................................................................................... 608

software version .................................................................................................................................609

34 System Commands .................................................................611

system config......................................................................................................................................612

system flush........................................................................................................................................614

system locale ......................................................................................................................................615

system reboot ..................................................................................................................................... 617

system reset........................................................................................................................................618

system timedreboot ...........................................................................................................................620

system debug autosave .....................................................................................................................621

system debug stats ............................................................................................................................622

system ra config .................................................................................................................................623

system rtc synchronize ......................................................................................................................624

system rtc settime ..............................................................................................................................625

35 Systemlog Commands............................................................ 627

systemlog flush .................................................................................................................................. 628

systemlog show.................................................................................................................................. 629

systemlog send................................................................................................................................... 631

systemlog DBG dbg_syslog...............................................................................................................632

systemlog DBG dbg_long_mess ....................................................................................................... 633

systemlog DBG dbg_burst................................................................................................................. 634

systemlog DBG dbg_contents...........................................................................................................635

36 TLS Commands........................................................................ 637

tls acs-client config.............................................................................................................................638

tls acs-client cert add.......................................................................................................................... 639

tls acs-client cert delete......................................................................................................................640

tls acs-client cert list ...........................................................................................................................641

tls https-server config ........................................................................................................................ 642

tls https-server cert add ..................................................................................................................... 643

tls https-server cert delete ................................................................................................................. 644

tls https-server cert list....................................................................................................................... 645

tls self cert list .................................................................................................................................... 646

37 UPnP Commands..................................................................... 647

E-DOC-CTC-20061027-0009 v2.0

xv

Contents

upnp config ......................................................................................................................................... 648

upnp flush ........................................................................................................................................... 649

upnp list...............................................................................................................................................650

38 User Commands ......................................................................651

user add...............................................................................................................................................652

user config .......................................................................................................................................... 654

user delete...........................................................................................................................................656

user flush.............................................................................................................................................657

user list ................................................................................................................................................ 658

user rights ........................................................................................................................................... 660

39 MLP Commands ...................................................................... 661

mlp flush .............................................................................................................................................662

mlp import .......................................................................................................................................... 663

mlp debug export ............................................................................................................................... 664

mlp debug stats .................................................................................................................................. 665

mlp debug traceconfig.......................................................................................................................666

mlp privilege add................................................................................................................................ 667

mlp privilege addzone........................................................................................................................ 669

mlp privilege config ........................................................................................................................... 670

mlp privilege delete............................................................................................................................ 671

mlp privilege list ................................................................................................................................. 673

mlp privilege removezone .................................................................................................................675

mlp role add........................................................................................................................................ 676

mlp role addpriv ................................................................................................................................. 678

mlp role config....................................................................................................................................679

mlp role delete....................................................................................................................................680

mlp role list .........................................................................................................................................681

mlp role removepriv........................................................................................................................... 682

40 Voice Commands..................................................................... 683

voice config.........................................................................................................................................684

voice state ...........................................................................................................................................685

xvi

voice cac config ..................................................................................................................................686

voice codec dynamic list....................................................................................................................687

voice codec dynamic config ..............................................................................................................688

voice country config........................................................................................................................... 689

E-DOC-CTC-20061027-0009 v2.0

Contents

voice country list ................................................................................................................................ 690

voice dectport config.......................................................................................................................... 691

voice dialplan add .............................................................................................................................. 692

voice dialplan delete .......................................................................................................................... 694

voice dialplan modify.........................................................................................................................695

voice dialplan list................................................................................................................................696

voice dialplan flush ............................................................................................................................ 697

voice phonebook add.........................................................................................................................698

voice phonebook delete.....................................................................................................................699

voice phonebook list ..........................................................................................................................700

voice profile add .................................................................................................................................701

voice profile delete .............................................................................................................................702

voice profile modify ........................................................................................................................... 703

voice profile list .................................................................................................................................. 704

voice profile flush ............................................................................................................................... 705

voice qos list .......................................................................................................................................706

voice qos config.................................................................................................................................. 707

voice dectport config.......................................................................................................................... 708

voice numbtransl config ....................................................................................................................709

41 Wireless Commands................................................................ 711

wireless ifconfig.................................................................................................................................. 713

wireless reset ......................................................................................................................................715

wireless debug stats........................................................................................................................... 717

wireless debug txpower..................................................................................................................... 718

wireless macacl add ...........................................................................................................................719

wireless macacl config....................................................................................................................... 720

wireless macacl delete ....................................................................................................................... 721

wireless macacl flush .........................................................................................................................722

wireless macacl list ............................................................................................................................723

wireless macacl modify .....................................................................................................................724

wireless macacl register ....................................................................................................................725

wireless multiuni add......................................................................................................................... 726

wireless multiuni delete..................................................................................................................... 727

wireless multiuni flush.......................................................................................................................728

wireless multiuni list ..........................................................................................................................729

wireless multiuni scanresults............................................................................................................730

wireless qos config............................................................................................................................. 731

E-DOC-CTC-20061027-0009 v2.0

xvii

Contents

wireless qos apacconfig.....................................................................................................................732

wireless qos staacconfig.................................................................................................................... 733

wireless secmode config ...................................................................................................................734

wireless secmode wep....................................................................................................................... 735

wireless secmode wpa-psk................................................................................................................ 736

wireless secmode wpa....................................................................................................................... 737

wireless stations list ...........................................................................................................................738

wireless wds add ................................................................................................................................739

wireless wds config............................................................................................................................ 740

wireless wds delete ............................................................................................................................741

wireless wds flush ..............................................................................................................................742

wireless wds list .................................................................................................................................743

wireless wds scanresults ................................................................................................................... 744

wireless mssid iflist ............................................................................................................................745

wireless mssid ifadd........................................................................................................................... 746

wireless mssid ifdelete....................................................................................................................... 747

wireless mssid ifconfig ......................................................................................................................748

wireless mssid ifattach....................................................................................................................... 749

wireless mssid ifdetach...................................................................................................................... 750

42 Abbreviations........................................................................... 751

43 System Logging Messages..................................................... 755

Auto-PVC Module ............................................................................................................................... 756

Configuration Module........................................................................................................................756

DHCP Client Module...........................................................................................................................756

DHCP Relay Module ...........................................................................................................................757

DHCP Server Module .........................................................................................................................757

Dyndns Module .................................................................................................................................. 758

Firewall Module .................................................................................................................................. 758

LOGIN Module .................................................................................................................................... 759

Kernel Module .................................................................................................................................... 759

Linestate Module ................................................................................................................................ 759

NAPT Module......................................................................................................................................759

xviii

PPP Module......................................................................................................................................... 760

PPTP Module.......................................................................................................................................760

RIP Module.......................................................................................................................................... 761

Routing Module .................................................................................................................................. 762

E-DOC-CTC-20061027-0009 v2.0

Contents

Session Module .................................................................................................................................. 762

SNTP Module......................................................................................................................................762

Software Module ................................................................................................................................ 763

UPnP Module ...................................................................................................................................... 763

VOIP Module ....................................................................................................................................... 763

.............................................................................................................................................................763

44 Supported Key Names ............................................................765

Supported IP Protocols ...................................................................................................................... 766

Supported TCP/UDP Port Names......................................................................................................767

Supported ICMP Type Names...........................................................................................................770

Supported Facilities........................................................................................................................... 771

Supported Severities......................................................................................................................... 772

IP Precedence......................................................................................................................................772

Differentiated Services Code Point (DSCP) ......................................................................................773

E-DOC-CTC-20061027-0009 v2.0

xix

Contents

xx

E-DOC-CTC-20061027-0009 v2.0

About this CLI Reference Guide

About this CLI Reference Guide

Used Symbols

A note provides additional information about a topic.

i

A caution warns you about potential problems or specific precautions that need to be taken.

!

Terminology

Generally, the Thomson ST7G/DV7213/ST790 will be referred to as Thomson ST in this CLI Reference Guide .

Typographical Conventions

Following typographical convention is used throughout this manual:

> Sample text indicates a hyperlink to a Web site.

Example: For more information, visit us at www.thomson-broadband.com

.

> Sample text indicates an internal cross-reference.

Example: For more information, see “ About this CLI Reference Guide” on page 1.

> Sample text indicates an important content-related word.

Example: To enter the network, you must authenticate yourself.

> Sample text indicates a CLI command to be input after the CLI prompt.

Example: To obtain a list of all available command groups, type

help at the top level.

> Sample text indicates input in the CLI interface.
> Sample text indicates comment explaining output in the CLI interface.

Documentation and software updates

THOMSON continuously develops new solutions, but is also committed to improving its existing products.

For suggestions regarding this document, please contact [email protected]

For more information on THOMSON's latest technological innovations, documents and software releases,
visit us at http://www.thomson-broadband.com

.

.

E-DOC-CTC-20061027-0009 v2.0

1

About this CLI Reference Guide

2

E-DOC-CTC-20061027-0009 v2.0

Chapter 1

1 Root Commands

From the root prompt, you can choose one of the following commands:

Command Description

help Displays the help information.

?

menu Displays the menu.

exit Exits the shell.

.. Exits group selection.

saveall Saves current configuration.

ping Send ICMP ECHO_REQUEST packets.

traceroute Send ICMP/UDP packets to trace the ip path.

i

EXAMPLE:

<Administrator>=>help firewall
Following commands are available :

config : Display/Modify firewall configuration.
list : Display firewall configuration.
clear : Clear firewall configuration.

Following command groups are available :

chain debug level rule

<Administrator>=>

To obtain help on a specific command group:

> type help, followed by the name of the command group, and then press ENTER, or
> type the name of the command group, press ENTER, and then type help.

E-DOC-CTC-20061027-0009 v2.0

3

ping

Send ICMP ECHO_REQUEST packets.

SYNTAX:

ping proto = <{ip|atm}>

addr = <ip-address>
dest = <string>
[count = <number{0-1000000}>]
[size = <number{28-20028}>]
[interval(ms) = <number{100-1000000}>]
[DF-bit = <{disabled|enabled}>] [srcaddr = <ip-address>]

where:

Chapter 1

proto The interface type to be used.

addr The destination IP address. REQUIRED

dest The destination address for the request. REQUIRED

count A number between 1 and 1000000.

size A number between 0 and 20000.

interval A number between 100 and 1000000.

DF-bit Set the Don't Fragment bit (or leave unset) in the IP header of ping.

scraddr The IP source address to use. OPTIONAL

EXAMPLE:

=>:ping proto=ip addr=192.168.1.70
Legend : Ping successful(!)

!!!!!

--- ping statistics --­5 packet(s) transmitted, 5 successful, 0% loss
rtt min/avg/max = 1 / 2 / 4 ms
=>

REQUIRED

Choose between:

> ip
> atm

OPTIONAL
Represents the number of pings to send.
The default is 5.

OPTIONAL
Represents the size of the ping payload(s).

OPTIONAL
Represents the interval in milliseconds between packets.
The default is 100.

OPTIONAL
The default is disabled.

Ping Timeout(.)

Hit ctrl-g to abort...

4

E-DOC-CTC-20061027-0009 v2.0

Chapter 1

traceroute

Send ICMP/UDP packets to trace the IP path.

SYNTAX:

traceroute addr = <ip-address>

where:

[count = <number{1-10}>]
[size = <number{1-20000}>]
[interval = <number{1000-60000}>]
[maxhops = <number{1-255}>]
[dstport = <number{1-65535}>]
[maxfail = <number{0-255}>]
[type = <{icmp | udp}>]
[utime = <{disabled | enabled}>]

addr The destination IP address. REQUIRED

count A number between 1 and 10.

Represents the number of times to reissue a traceroute request with the
same TTL.
The default is 3.

size A number between 1 and 20000 (bytes).

Represents the size of the traceroute packet(s).
The default is 1.

interval A number between 1000 and 60000 (milliseconds).

Represents the intermediate interval between two packets.
The default is 1000.

maxhops A number between 1 and 255.

Represents the maximum number of routers through which a packet can
pass.
The default is 30.

dstport A number between 1 and 65535.

Represents the UDP destination port number to send to.

maxfail A number between 0 and 255.

Represents the maximum number of consecutive timeouts allowed
before terminating a traceroute request.
The default is 5.

type The type of traceroute packet(s).

Choose between:

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

> icmp
> udp.

The default is icmp.

utime Display time in useconds (enabled) or not (disabled).

The default is enabled.

OPTIONAL

E-DOC-CTC-20061027-0009 v2.0

5

EXAMPLE:

=>traceroute addr = 192.193.195.250 count=3 size=1 interval=1000 maxhops=30 dstport=33433

maxfail=5 type=icmp utime=yes
:traceroute addr=192.193.195.250
ttl=1 192.193.195.250 676 us 1351 us 648 us

=>

Chapter 1

6

E-DOC-CTC-20061027-0009 v2.0

Chapter 2

2 ADSL Commands

Introduction

This chapter describes the commands of the adsl command group.

Contents

This chapter covers the following commands:

adsl config Show/set the Asymmetric Digital Subscriber Line (ADSL)

configuration.

adsl info Display the ADSL statistics and information about the DSL line

status.

adsl debug bitloadinginfo Displays the number of bits per tone. 11

adsl debug deltconfig Enable/disable the Dual Ended Line Testing Interface (DELT) 12

adsl debug deltinfo Display Dual Ended Line Testing Interface (DELT) results 12

adsl debug

modemoptioninfo

adsl debug

modemoption

adsl debug traceconfig Configure the ADSL tracelevel. 16

Displays the modem options bitmap 14

Configure the modem options bitmap 15

8

9

E-DOC-CTC-20061027-0009 v2.0

7

adsl config

Show/set the Asymmetric Digital Subscriber Line (ADSL) configuration.

SYNTAX:

adsl config [opermode = <{multimode | multi_adsl2 | multi_readsl2

| multi_adsl2plus}>]

[trace = <{disabled | enabled}>]

where:

Chapter 2

opermode The operational mode of the Thomson ST.

Choose between:

> multimode
> multi_adsl2
> multi_readsl2
> multi_adsl2plus

The default is multi_adsl2plus.

trace Enable or disable ADSL tracing.

The default is enabled.

EXAMPLE:

The example below shows the default configuration for a Thomson ST ADSL/POTS variant:

=>adsl config
ADSL configuration:
opermode = multi_adsl2plus
trace = on
modemoption = 00:00:00:00:00:00:00:00:00:00:00:00:00:00:00:00
=>

OPTIONAL

OPTIONAL

8

E-DOC-CTC-20061027-0009 v2.0

Chapter 2

adsl info

Display the ADSL statistics and information about the DSL line status.

Although the same command is used for both Thomson ST ADSL/POTS and Thomson ST ADSL/ISDN
variants, the command features specific output parameters and counters per variant.

SYNTAX:

adsl info

E-DOC-CTC-20061027-0009 v2.0

9

EXAMPLE (for a Thomson ST ADSL/POTS variant):

=>adsl info
Modemstate : up
Operation Mode : G.992.1 Annex A
Channel Mode : interleaved
Number of resets : 1

Vendor Local Remote

Country : 0f 00

Vendor : TMMB

VendorSpecific : 0000 0000

StandardRevisionNr : 00 00

Chapter 2

Margin [dB] : 26.0 18.0
Attenuation [dB] : 0.0 2.0
OutputPower [dBm] : 4.0 11.5

Available Bandwidth Cells/s Kbit/s

Downstream : 14490 6144

Upstream : 1509 640

Transfer statistics

Errors

Received FEC : 0
Received CRC : 0
Received HEC : 0
Transmitted FEC : 0
Transmitted CRC : 0
Tranmsitted HEC : 0

Near end failures since reset

Loss of frame: 0 failures
Loss of signal: 0 failures
Loss of power: 0 failures
Errored seconds: 0 seconds

Near end failures last 15 minutes

Loss of frame: 0 seconds
Loss of signal: 0 seconds
Loss of power: 0 seconds
Errored seconds: 0 seconds

Near end failures current day

Errored seconds: 0 seconds

Near end failures previous day

Errored seconds: 0 seconds

=>

Downstream Upstream

10

E-DOC-CTC-20061027-0009 v2.0

Chapter 2

adsl debug bitloadinginfo

Displays the number of bits per tone.

Syntax

adsl debug bitloadinginfo

E-DOC-CTC-20061027-0009 v2.0

11

adsl debug deltconfig

Enable/disable the Dual Ended Line Testing Interface (DELT)

Syntax

adsl debug deltconfig [state = <{disabled|enabled}>]

where:

state enable or disable DELT REQUIRED

Chapter 2

12

E-DOC-CTC-20061027-0009 v2.0

Chapter 2

adsl debug deltinfo

Display Dual Ended Line Testing Interface (DELT) results

Syntax

adsl debug deltinfo

E-DOC-CTC-20061027-0009 v2.0

13

adsl debug modemoptioninfo

Displays the modem options bitmap

Syntax

adsl debug modemoptioninfo

Chapter 2

14

E-DOC-CTC-20061027-0009 v2.0

Chapter 2

adsl debug modemoption

Configure the modem options bitmap

Syntax

adsl debug modemoption [config = <hexbitmap>]

where:

config The modem options bitmap REQUIRED

E-DOC-CTC-20061027-0009 v2.0

15

adsl debug traceconfig

Configure the ADSL tracelevel.

Syntax

adsl debug traceconfig [level = <number{0-2}>]

where:

Chapter 2

level Trace Level:

> 0=disable tracing;
> 1=enable dsl manager tracing;
> 2=enable dsl driver tracing)

REQUIRED

16

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

3 ATM Commands

Introduction

This chapter describes the commands of the atm command group.

Contents

This chapter covers the following commands:

atm flush Flush all Asynchronous Transfer Mode (ATM) interfaces. 19

atm ifadd Create a new ATM interface. 20

atm ifattach Attach a ATM interface. 21

atm ifconfig Configure an ATM interface. 22

atm ifdelete Delete an ATM interface. 24

atm ifdetach Detach an ATM interface. 25

atm iflist Display the ATM interfaces. 26

atm bundle add Add a new bundle of interfaces. 27

atm bundle attach Attach a bundle of interfaces. 28

atm bundle config Modify a bundle of interfaces. 29

atm bundle clear Clear the bundle statistics. 30

atm bundle delete Delete a bundle of interfaces. 31

atm bundle detach Detach a bundle of interfaces. 32

atm bundle flush Flush all bundles. 33

atm bundle ifadd Add an interface on a bundle. 34

atm bundle ifconfig Configure an interface from a bundle. 35

atm bundle ifdelete Remove an interface from a bundle. 36

atm bundle list Display the current bundles. 37

atm cac config Configure the ATM connection admission control. 38

atm cac list Display all the CAC parameters. 39

atm cac overbooking Configure ATM overbooking parameters. 40

atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics. 41

atm debug gstats Display ATM global statistics. 42

atm debug portstats Display port specific ATM statistics. 43

atm oam config Modify the ATM Operation and Maintenance (OAM) settings. 44

atm oam list Display the ATM OAM settings. 45

atm oam modify Modify the ATM OAM data blocking mode. 46

atm oam ping Send ATM loopback cells. 48

atm oam cc list Display Continuity Check (CC) configuration. 49

atm oam cc modify Modify CC on the connection. 50

atm oam cc send Send CC activate/deactivate to connection.

51

E-DOC-CTC-20061027-0009 v2.0

17

Chapter 3

atm oam vclb add Create a loopback connection for VC. 52

atm oam vclb del Delete a loopback connection for VC. 53

atm oam vclb list List all VC loopback connections. 54

atm phonebook add Add a new phonebook entry. 55

atm phonebook

autolist

atm phonebook delete Delete an existing phonebook entry. 57

atm phonebook flush Flush all the phonebook entries. 58

atm phonebook list Display the current phonebook. 59

atm qosbook add Add a new QoS book entry. 60

atm qosbook config Modify the QoS book configuration. 61

atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD). 62

atm qosbook ctddelete Delete a CTD. 64

atm qosbook ctdlist Display all CTDs. 65

atm qosbook delete Delete a QoS book entry. 66

atm qosbook flush Flush all the QoS book entries. 67

atm qosbook list Display the QoS book. 68

Show the auto PVCs. 56

18

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm flush

Flush all Asynchronous Transfer Mode (ATM) interfaces.

SYNTAX:

atm flush

E-DOC-CTC-20061027-0009 v2.0

19

atm ifadd

Create a new ATM interface.

SYNTAX:

atm ifadd intf = <string>

where:

Chapter 3

intf The name for the new ATM interface.

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

=>
=>atm ifadd intf = RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

RtPPPoA_atm: dest : (none)

=>

REQUIRED

Note If not specified, the destination parameter must be specified. In this

case the name of the destination will double as interface name.

Retry : 10 QoS : default Encaps : vcmux Fcs : disabled Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : vcmux Fcs : disabled Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : ip
Connection State : not-connected

RELATED COMMANDS:

atm ifdelete Delete an ATM interface.

atm iflist Display the ATM interfaces.

20

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm ifattach

Attach a ATM interface.

SYNTAX:

atm ifattach intf = <string>

where:

intf The name of the ATM interface to be attached. REQUIRED

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : not-connected

=>atm ifattach intf=RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

=>

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

RELATED COMMANDS:

atm ifdetach Detach an ATM interface.

E-DOC-CTC-20061027-0009 v2.0

21

atm ifconfig

Configure an ATM interface.

The interface to be configured must not be connected at the time of configuration. If this should be

i

the case, use the command :atm ifdetach before using the command :atm ifconfig.

SYNTAX:

atm ifconfig intf = <string>

[dest = <string>]
[qos = <string>]
[clp = <{0|1|classification}>]
[clpthresh = <number{0-15}>]
[encaps = <{llc | vcmux}>]
[retry = <number{0-65535}>]
[fcs = <{disabled | enabled | auto}>]
[ulp = <{ip | mac | ppp}>]

Chapter 3

where:

intf The name of the ATM interface to be configured. REQUIRED

dest The WAN destination for this ATM interface.

Typically, an ATM phonebook entry.

qos The name of the Quality of Service (QoS) book entry to apply on this ATM

interface.
The default is default.

clp The mode used to determine the CLP bit value OPTIONAL

clpthresh Priority class threshold where CLP becomes 0 (for all classes >= threshold) OPTIONAL

encaps The type of encapsulation to be used for this ATM interface.

Choose between:

OPTIONAL

OPTIONAL

OPTIONAL

> llc: Logical Link Control (LLC) / Sub Network Access Protocol (SNAP)
> vcmux: Virtual Channel MUltipleXing (VCMUX).

The default is llc.

fcs Enable or disable the inclusion of the Ethernet Frame Check Sequence

(FCS) in the packet header on the WAN side (only used for llc
encapsulation for mac).
The default is disabled.

Note This parameter is normally left disabled.

retry A number between 0 and 65535.

Represents the number of times the Thomson ST retries to set up a WAN
connection before giving up.
The default is 10.

OPTIONAL

OPTIONAL

22

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

ulp Select the Upper Layer Protocol (ULP) for this interface.

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

atm_8_35 : dest : atm_pvc_8_35

=>
=>atm ifconfig intf=atm_8_35 dest=atm_pvc_8_35 encaps=vcmux ulp=ppp
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

OPTIONAL

Choose between:

> ip (for a Routed IPoA interface).
> mac (for a Bridged Ethernet, Routed ETHoA, Bridged PPP over

Ethernet (PPPoE), Routed PPPoE or a PPPoE Relay interface).

> ppp (for a Routed PPP over ATM (PPPoA) interface).

The default is ip.

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac
Connection State : not-connected

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac
Connection State : connected

atm_8_35 : dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : disabled Ulp : ppp
Connection State : not-connected

=>

E-DOC-CTC-20061027-0009 v2.0

23

atm ifdelete

Delete an ATM interface.

SYNTAX:

atm ifdelete intf = <string>

where:

intf The name of the ATM interface to be deleted. REQUIRED

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

Chapter 3

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>
=>atm ifdelete intf=RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

=>

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RELATED COMMANDS:

atm ifadd Create a new ATM interface.

atm iflist Display the ATM interfaces.

24

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm ifdetach

Detach an ATM interface.

SYNTAX:

atm ifdetach intf = <string>

where:

intf The name of the ATM interface to be detached. REQUIRED

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>
=>atm ifdetach intf=RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

RtPPPoA_atm: dest : RtPPPoA

=>

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : not-connected

RELATED COMMANDS:

atm ifattach Attach a ATM interface.

E-DOC-CTC-20061027-0009 v2.0

25

atm iflist

Display the ATM interfaces.

SYNTAX:

atm iflist [intf = <string>]

where:

Chapter 3

intf The name of the ATM interface to be shown.

Note If not specified, all the ATM interfaces are shown.

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>atm iflist intf=RtPPPoA_atm
RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>

RELATED COMMANDS:

atm ifadd Create a new ATM interface.

atm ifdelete Delete an ATM interface.

OPTIONAL

26

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm bundle add

Add a new bundle of interfaces.

SYNTAX:

atm bundle add name = <string>

where:

name The name of the new bundle. REQUIRED

EXAMPLE:

=>atm bundle add name=myBundle
=>atm bundle list
myBundle: Connection state : not-connected

=>

Retry: 10 Policy: priority Propagate: disabled
TX requested bytes: 0 requested frames: 0
TX bytes: 0 frames: 0
RX bytes: 0 frames: 0

RELATED COMMANDS:

atm bundle delete Delete a bundle of interfaces.

atm bundle list Display the current bundles.

E-DOC-CTC-20061027-0009 v2.0

27

atm bundle attach

Attach a bundle of interfaces.

SYNTAX:

atm bundle attach name = <string>

where:

name The name of the bundle to be attached. REQUIRED

EXAMPLE:

=>atm bundle attach name=myBundle
=>atm bundle list
myBundle: Connection state : connected

Retry: 10 Policy: priority Propagate: disabled
TX requested bytes: 0 requested frames: 0
TX bytes: 0 frames: 0
RX bytes: 0 frames: 0

=>

Chapter 3

RELATED COMMANDS:

atm bundle detach Detach a bundle of interfaces.

28

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm bundle config

Modify a bundle of interfaces.

The bundle of interfaces to be configured must not be connected at the time of configuration. If this
should be the case, use the command :atm bundle detach before using the command :atm

i

bundle config.

SYNTAX:

atm bundle config name = <string>

where:

name The name of the bundle to be configured. REQUIRED

policy The traffic handling policy of the bundle.

propagate Enable or disable propagation of packets.

retry A number between 0 and 65535.

[policy = <{priority | connection}>]
[propagate = <{disabled | enabled}>]
[retry = <number{0-65535}>]

OPTIONAL

Choose between:

> priority: lower layer ATM interfaces can be configured for a certain

priority range, marked packets will be sent on the corresponding
interface.

> connection: all the packets of the same connection will be sent via

the same interface.

The default is priority.

OPTIONAL
When propagation is enabled, packets are sent via the first interface
configured for that traffic. If the interface goes down, the next interface in
the bundle will be used.
The default is disabled.

OPTIONAL
Represents the number of connection setup retries before giving up.
The default is 10.

EXAMPLE:

=>atm bundle list
myBundle: Connection state : not-connected

Retry: 10 Policy: priority Propagate: disabled
TX requested bytes: 0 requested frames: 0
TX bytes: 0 frames: 0

RX bytes: 0 frames: 0
=>atm bundle config name=myBundle policy=connection retry=15
=>atm bundle list
myBundle: Connection state : not-connected

Retry: 15 Policy: connection Propagate: disabled

TX requested bytes: 0 requested frames: 0

TX bytes: 0 frames: 0

RX bytes: 0 frames: 0
=>

E-DOC-CTC-20061027-0009 v2.0

29

atm bundle clear

Clear the bundle statistics.

SYNTAX:

atm bundle clear [name = <string>]

where:

Chapter 3

name The name of the bundle for which the statistics must be cleared.

Note If not specified, the statistics for all the bundles will be cleared.

OPTIONAL

30

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm bundle delete

Delete a bundle of interfaces.

SYNTAX:

atm bundle delete name = <string>

where:

name The name of the bundle to be deleted. REQUIRED

RELATED COMMANDS:

atm bundle add Add a new bundle of interfaces.

atm bundle list Display the current bundles.

E-DOC-CTC-20061027-0009 v2.0

31

atm bundle detach

Detach a bundle of interfaces.

SYNTAX:

atm bundle detach intf = <string>

where:

intf The name of the bundle to be detached. REQUIRED

RELATED COMMANDS:

atm bundle attach Attach a bundle of interfaces.

Chapter 3

32

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm bundle flush

Flush all bundles.

SYNTAX:

atm bundle flush

E-DOC-CTC-20061027-0009 v2.0

33

atm bundle ifadd

Add an interface on a bundle.

Up to 8 interfaces or (sub-)bundles can be added to one bundle.

i

SYNTAX:

atm bundle ifadd name = <string>

intf = <string>
[index = <number{0-6}>]

where:

name The name of the bundle to which an ATM interface must be added. REQUIRED

intf The name of the ATM interface to be added. REQUIRED

index A number between 0 and 6.

Represents the index of the ATM interface.

Chapter 3

OPTIONAL

EXAMPLE:

=>atm bundle ifadd name=myBundle intf=myATMintf
=>atm bundle list
myBundle: Connection state : not-connected

Retry: 15 Policy: connection

TX requested bytes: 0 requested frames: 0

TX bytes: 0 frames: 0

RX bytes: 0 frames: 0

Interface: myATMintf State: enabled Selector: 0-15

=>

RELATED COMMANDS:

atm bundle ifdelete Remove an interface from a bundle.

TX bytes: 0 frames: 0
RX bytes: 0 frames: 0
RX discarded bytes: 0 discarded frames: 0
Disconnects: 0

34

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm bundle ifconfig

Configure an interface from a bundle.

The interface to be configured must not be connected at the time of configuration. If this should be
the case, use the command :atm bundle ifdetach before using the command :atm bundle

i

ifconfig.

SYNTAX:

atm bundle ifconfig name = <string>

where:

intf = <string>
[state = <{disabled | enabled}>]
[low = <number{0-15}>]
[high = <number{0-15}>]

name The name of the bundle from which an ATM interface must be configured. REQUIRED

intf The name of the ATM interface to be configured. REQUIRED

state Enable or disable the ATM interface.

The default is enabled.

low A number between 0 and 15.

Represents the low selector value.

Note This parameter must only be configured when the policy of the

bundle is set to priority (see “ atm bundle config” on page 29).

high A number between 0 and 15.

Represents the high selector value.

Note This parameter must only be configured when the policy of the

bundle is set to priority (see “ atm bundle config” on page 29).

OPTIONAL

OPTIONAL

OPTIONAL

E-DOC-CTC-20061027-0009 v2.0

35

atm bundle ifdelete

Remove an interface from a bundle.

SYNTAX:

atm bundle ifdelete name = <string>

intf = <string>

where:

name The name of the bundle from which an ATM interface must be removed. REQUIRED

intf The name of the ATM interface to be removed. REQUIRED

EXAMPLE:

Chapter 3

=>atm bundle iflist
Test : dest : (none)

Retry : 10 QoS : default Encaps : llc Fcs : off Ulp : ip
Connection State : not-connected

=>atm bundle ifdelete intf=Test
=>atm bundle iflist

=>

RELATED COMMANDS:

atm bundle ifadd Add an interface on a bundle.

36

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm bundle list

Display the current bundles.

SYNTAX:

atm bundle list

EXAMPLE:

=>atm bundle list
Test : Connection state : not-connected

=>

Retry: 10 Policy: priority

TX requested bytes: 0 requested frames: 0

TX bytes: 0 frames: 0

RX bytes: 0 frames: 0

Interface: Test State: enabled Selector: 0-15

TX bytes: 0 frames: 0
RX bytes: 0 frames: 0
RX discarded bytes: 0 discarded frames: 0
Disconnects: 0

RELATED COMMANDS:

atm bundle add Add a new bundle of interfaces.

atm bundle delete Delete a bundle of interfaces.

E-DOC-CTC-20061027-0009 v2.0

37

atm cac config

Configure the ATM connection admission control.

SYNTAX:

atm cac config config port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or

number>
state = <{disabled|enabled}>

where:

Chapter 3

config
port

state Enable/disable CAC for an ATM port. REQUIRED

The port for which CAC is configured. REQUIRED

EXAMPLE:

{Administrator}=>atm cac config
port = dsl0
state = enabled
:atm cac config port=dsl0 state=enabled
{Administrator}=>

RELATED COMMANDS:

atm cac list Display all the CAC parameters.

atm cac overbooking Configure ATM overbooking parameters.

38

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm cac list

Display all the CAC parameters.

SYNTAX:

atm cac list

EXAMPLE:

{Administrator}[atm cac]=>list
CAC: port: dsl0 state: enabled
CAC: port: dsl1 state: enabled
CAC: port: atm2 state: enabled
CAC: port: aal5 state: disabled
CAC: port: atm5 state: disabled
Overbooking: realtime: 0% non-realtime: 0%.
{Administrator}[atm cac]=>

RELATED COMMANDS:

atm cac config Configure the ATM connection admission control.

atm cac overbooking Configure ATM overbooking parameters.

E-DOC-CTC-20061027-0009 v2.0

39

atm cac overbooking

Configure ATM overbooking parameters.

SYNTAX:

atm cac overbooking rt = <number{0-1000}>

nrt = <number{0-1000}>

where:

Chapter 3

rt A number between 0 and 1000.

nrt A number between 0 and 1000.

EXAMPLE:

{Administrator}[atm cac]=>overbooking rt 20 nrt 500
{Administrator}[atm cac]=>list
CAC: port: dsl0 state: enabled
CAC: port: dsl1 state: enabled
CAC: port: atm2 state: enabled
CAC: port: aal5 state: disabled
CAC: port: atm5 state: disabled
Overbooking: realtime: 20% non-realtime: 500%.
{Administrator}[atm cac]=>

RELATED COMMANDS:

atm cac config Configure the ATM connection admission control.

atm cac list Display all the CAC parameters.

REQUIRED

The realtime overbooking percentage.

REQUIRED

The non-realtime overbooking percentage.

40

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm debug aal5stats

Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics.

SYNTAX:

atm debug aal5stats port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number>

where:

vpi = <number{0-15}>
[vci = <number{0-511}>]
[clear = <{disabled | enabled}>]

port The port number for which statistics will be retrieved.

Choose between:

> DSL0
> DSL1
> ATM 2
> ATM 3
> AAL5
> ATM 5

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the Virtual Path Identifier (VPI) number for which statistics will
be retrieved.

vci A number between 0 and 511.

Represents the Virtual Channel Identifier (VCI) number for which statistics
will be retrieved.

clear Enable or disable clearing of the statistics after request. OPTIONAL

RELATED COMMANDS:

atm debug gstats Display ATM global statistics.

atm debug portstats Display port specific ATM statistics.

REQUIRED

REQUIRED

OPTIONAL

E-DOC-CTC-20061027-0009 v2.0

41

atm debug gstats

Display ATM global statistics.

SYNTAX:

atm debug gstats [clear = <{disabled | enabled}>]

where:

clear Enable or disable clearing of the statistics after request. OPTIONAL

EXAMPLE:

{admin}[atm debug]=>gstats
# of received octets = 1802.
# of transmitted octets = 4346.
# of received cells = 34.
# of transmitted cells = 82.
# of unknown cells = 0.
# of errors on the input = 0.
# of errors on output = 0.
{admin}[atm debug]=>

Chapter 3

RELATED COMMANDS:

atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics.

atm debug portstats Display port specific ATM statistics.

42

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm debug portstats

Display port specific ATM statistics.

SYNTAX:

atm debug portstats port = <{dsl0} or number>

where:

[clear = <{disabled | enabled}>]

port The port number for which statistics will be retrieved.

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

clear Enable or disable clearing of the statistics after request. OPTIONAL

EXAMPLE:

=>atm debug portstats port=dsl0
# of received octets = 1961.
# of transmitted octets = 4717.
# of received cells = 37.
# of transmitted cells = 89.
# of unknown cells = 0.
# of errors on the input = 0.
# of errors on output = 0.
=>

RELATED COMMANDS:

atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics.

atm debug gstats Display ATM global statistics.

REQUIRED

E-DOC-CTC-20061027-0009 v2.0

43

atm oam config

Modify the ATM Operation and Maintenance (OAM) settings.

SYNTAX:

atm oam config [clp = <number{0-1}>]

[loopbackid = <string>]

where:

Chapter 3

clp A number (0 or 1).

Represents the Cell Loss Priority (CLP) bit value of the OAM cells.
The default is 1.

loopbackid A hexadecimal string.

Represents the loopback ID for processing of segment loopback cells.
The default is 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a.

RELATED COMMANDS:

atm oam list Display the ATM OAM settings.

atm oam modify Modify the ATM OAM data blocking mode.

atm oam ping Send ATM loopback cells.

OPTIONAL

OPTIONAL

44

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm oam list

Display the ATM OAM settings.

SYNTAX:

atm oam list

EXAMPLE:

=>atm oam list

-------------------

OAM config dump

CLP bit value : 1
Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a

OAM data blocking mode

--------------------------

Port dsl0: blocking
Port dsl1: blocking
Port atm2: blocking
Port atm3: blocking
Port aal5: blocking

=>

Port atm5: blocking

RELATED COMMANDS:

atm oam config Modify the ATM Operation and Maintenance (OAM) settings.

atm oam modify Modify the ATM OAM data blocking mode.

atm oam ping Send ATM loopback cells.

E-DOC-CTC-20061027-0009 v2.0

45

atm oam modify

Modify the ATM OAM data blocking mode.

SYNTAX:

atm oam modify port = <{dsl0} or number>

blocking = <{disabled | enabled}>

where:

Chapter 3

port The port for which OAM blocking is configured.

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

blocking Enable or disable the OAM data blocking mode on this port.

The default is enabled.

REQUIRED

REQUIRED

46

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

EXAMPLE:

=>atm oam list

-------------------

--------------------------

=>atm oam modify port=dsl1 blocking=disabled
=>:atm oam list

-------------------

OAM config dump

CLP bit value : 1
Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a

OAM data blocking mode

Port dsl0: blocking
Port dsl1: blocking
Port atm2: blocking
Port atm3: blocking
Port aal5: blocking
Port atm5: blocking

OAM config dump

CLP bit value : 1
Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a

OAM data blocking mode

--------------------------

Port dsl0: blocking
Port dsl1: non blocking
Port atm2: blocking
Port atm3: blocking
Port aal5: blocking
Port atm5: blocking

=>

RELATED COMMANDS:

atm oam config Modify the ATM Operation and Maintenance (OAM) settings.

atm oam list Display the ATM OAM settings.

atm oam ping Send ATM loopback cells.

E-DOC-CTC-20061027-0009 v2.0

47

atm oam ping

Send ATM loopback cells.

SYNTAX:

atm oam ping dest = <string>

[count = <number{1-1000000}>]
[interval = <number{100-1000000}>]

where:

Chapter 3

dest The destination address for the request.

count A number between 1 and 1000000.

interval A number between 100 and 1000000 (milliseconds).

EXAMPLE:

=>atm oam ping dest=atm_ph_8_35 count=10 interval=1000
loopback: successful, sequence: 1 time: 37890 usec
loopback: successful, sequence: 2 time: 39118 usec
loopback: successful, sequence: 3 time: 39116 usec
loopback: successful, sequence: 4 time: 39187 usec
loopback: successful, sequence: 5 time: 38605 usec
loopback: successful, sequence: 6 time: 38764 usec
loopback: successful, sequence: 7 time: 38752 usec
loopback: successful, sequence: 8 time: 38813 usec
loopback: successful, sequence: 9 time: 38848 usec
loopback: successful, sequence: 10 time: 38941 usec

--- loopback statistics --­10 loopbacks transmitted, 10 successful, 0% loss, time 1390 ms
rtt min/avg/max = 37890/38803/39187
=>

REQUIRED

This can be any ATM phonebook entry.

OPTIONAL

Represents the number of pings to send.

OPTIONAL

Represents the interval between packets.

RELATED COMMANDS:

atm oam config Modify the ATM Operation and Maintenance (OAM) settings.

atm oam list Display the ATM OAM settings.

atm oam modify Modify the ATM OAM data blocking mode.

48

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm oam cc list

Display Continuity Check (CC) configuration.

SYNTAX:

atm oam cc list

EXAMPLE:

=>atm oam cclist
PORT = 0 VPI = 15 VCI = 16 End2End Mode = Auto Segment Mode = Auto
PORT = 0 VPI = 0 VCI = 35 End2End Mode = Auto Segment Mode = Auto
PORT = 0 VPI = 8 VCI = 35 End2End Mode = Auto Segment Mode = Auto
PORT = 0 VPI = 0 VCI = 16 End2End Mode = Auto Segment Mode = Auto
=>

RELATED COMMANDS:

atm oam cc modify Modify CC on the connection.

atm oam cc send Send CC activate/deactivate to connection.

E-DOC-CTC-20061027-0009 v2.0

49

atm oam cc modify

Modify CC on the connection.

SYNTAX:

atm oam modify port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number>

vpi = <number{0-15}>
[vci = <number{0-511}>]
[transmit = <{disabled | enabled}>]
[receive = <{disabled | enabled}>]
[auto = <{disabled | enabled}>]
[span = <{segment | end2end}>]

where:

Chapter 3

port The ATM port number.

Choose between:

REQUIRED

> DSL0
> DSL1
> ATM 2
> ATM 3
> AAL5
> ATM 5

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the VPI.

vci A number between 0 and 511.

Represents the VCI.

Note For a Virtual Path (VP) cross-connection, use 0 or do not specify.

transmit Enable or disable transmission of CC cells. OPTIONAL

receive Enable or disable loss of continuity. OPTIONAL

auto Enable or disable remote CC activation/deactivation. OPTIONAL

span Select the CC span.

Choose between:

REQUIRED

OPTIONAL

OPTIONAL

> end2end: monitoring occurs on the entire VC between two ATM end

stations.

> segment: monitoring occurs on a VC segment between the

Thomson ST and a first-hop ATM switch.

RELATED COMMANDS:

atm oam cc list Display Continuity Check (CC) configuration.

atm oam cc send Send CC activate/deactivate to connection.

50

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm oam cc send

Send CC activate/deactivate to connection.

SYNTAX:

atm oam cc send port = <{dsl0} or number>

where:

vpi = <number{0-15}>
[vci = <number{0-511}>]
[span = <{segment | end2end}>]
[action = <{activate | deactivate}>]
[direction = <{source | sink | both}>]

port The ATM port number.

Choose between:

> DSL0.

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the VPI.

vci A number between 0 and 511.

Represents the VCI.

Note For a VP cross-connection, use 0 or do not specify.

span Select the CC span.

Choose between:

> end2end: monitoring occurs on the entire VC between two ATM end

stations.

> segment: monitoring occurs on a VC segment between the

Thomson ST and a first-hop ATM switch.

action Activate or deactivate CC.

The default is deactivate.

direction Indicates the direction of CC activity.

Choose between:

> source
> sink
> both.

The default is both.

REQUIRED

REQUIRED

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

RELATED COMMANDS:

atm oam cc list Display Continuity Check (CC) configuration.

atm oam cc modify Modify CC on the connection.

E-DOC-CTC-20061027-0009 v2.0

51

atm oam vclb add

Create a loopback connection for VC.

SYNTAX:

atm oam vclb add port = <{dsl0} or number>

vpi = <number{0-15}>
[vci = <number{0-511}>]

where:

Chapter 3

port The ATM port number.

vpi A number between 0 and 15.

vci A number between 0 and 511.

EXAMPLE:

=>atm oam vclb add port=dsl0 vpi=0 vci=36
=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
=>atm oam vclb add port=dsl1 vpi=0 vci=37
=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
PORT = 1 VPI = 0 VCI = 37
=>

REQUIRED

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

REQUIRED

Represents the VPI.

OPTIONAL

Represents the VCI.

Note For a VP cross-connection, use 0 or do not specify.

RELATED COMMANDS:

atm oam vclb del Delete a loopback connection for VC.

atm oam vclb list List all VC loopback connections.

52

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm oam vclb del

Delete a loopback connection for VC.

SYNTAX:

atm oam vclb del port = <{dsl0} or number>

where:

vpi = <number{0-15}>
[vci = <number{0-511}>]

port The ATM port number.

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the VPI.

vci A number between 0 and 511.

Represents the VCI.

Note For a VP cross-connection, use 0 or do not specify.

EXAMPLE:

=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
PORT = 1 VPI = 0 VCI = 37
=>atm oam vclb del port=dsl1 vpi=0 vci=37
=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
=>

RELATED COMMANDS:

REQUIRED

REQUIRED

OPTIONAL

atm oam vclb add Create a loopback connection for VC.

atm oam vclb list List all VC loopback connections.

E-DOC-CTC-20061027-0009 v2.0

53

atm oam vclb list

List all VC loopback connections.

SYNTAX:

atm oam vclb list

EXAMPLE:

=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
PORT = 1 VPI = 0 VCI = 37
=>

Chapter 3

RELATED COMMANDS:

atm oam vclb add Create a loopback connection for VC.

atm oam vclb del Delete a loopback connection for VC.

54

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm phonebook add

Add a new phonebook entry.

SYNTAX:

atm phonebook add name = <string>

where:

addr = <atmchannel : PVC syntax is [port.]vpi.vci

port=dsl0 | ...>

name The name of the new phonebook entry.

addr The ATM address for this destination.

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
=>atm phonebook add name=RtPPPoA addr=8.35
=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>

REQUIRED

This name can be freely chosen, however two limitations apply:

> The name of a phonebook entry intended for the Relayed PPPoA

(PPPoA-to-PPTP Relaying) packet service may not start with capital P or
capital T

> The name of a phonebook entry intended for the PPP-to-DHCP

spoofing packet service must start with DHCP (for example
DHCP_Spoof01).

REQUIRED
It is composed of a VPI and a VCI identifying ATM virtual channels. In most
cases the values are provided by the Service Provider.
Accepted VPI: a number between 0 and 15.
Accepted VCI: a number between 0 and 511.

RELATED COMMANDS:

atm phonebook delete Delete an existing phonebook entry.

atm phonebook list Display the current phonebook.

E-DOC-CTC-20061027-0009 v2.0

55

atm phonebook autolist

Show the auto PVCs.

Auto PVCs are only shown if they are supported by the Central Office DSLAM.

i

SYNTAX:

atm phonebook autolist

EXAMPLE:

=>atm phonebook autolist

8.35
=>

Chapter 3

RELATED COMMANDS:

atm phonebook list Display the current phonebook.

56

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm phonebook delete

Delete an existing phonebook entry.

This command is only applicable for phonebook entries that are not used (in other words, not

i

configured for any packet service).

SYNTAX:

atm phonebook delete name = <string>

where:

name The name of the phonebook entry to be deleted.

Tip Use the command :atm phonebook list to check whether the

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>atm phonebook delete name=RtPPPoA
=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
=>

RELATED COMMANDS:

atm phonebook add Add a new phonebook entry.

atm phonebook list Display the current phonebook.

entry is in use (

Use=1

) or not (

Use=0

REQUIRED

).

E-DOC-CTC-20061027-0009 v2.0

57

atm phonebook flush

Flush all the phonebook entries.

1. Phonebook entries that areinuse,cannotbeflushed.

i

2. This command does not impact previously saved configurations.

SYNTAX:

atm phonebook flush

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>
=>atm phonebook flush
Some phonebook entries are still in use. Entries that are in use cannot be deleted.
=>
=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
=>

Chapter 3

58

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm phonebook list

Display the current phonebook.

SYNTAX:

atm phonebook list

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>

RELATED COMMANDS:

atm phonebook add Add a new phonebook entry.

atm phonebook autolist Show the auto PVCs.

atm phonebook delete Delete an existing phonebook entry.

E-DOC-CTC-20061027-0009 v2.0

59

atm qosbook add

Add a new QoS book entry.

SYNTAX:

atm qosbook add name = <string>

[txctd = <string>]
[rxctd = <string>]

where:

name The name of the new QoS entry. REQUIRED

txctd The name of the Conformance Traffic Descriptor (CTD) for the transmit

(upstream) direction.

rxctd The name of the CTD for the receive (downstream) direction. OPTIONAL

Chapter 3

OPTIONAL

EXAMPLE:

=>atm qosbook list
Name Ref Tx CTD Rx CTD
default 3 default default
=>

RELATED COMMANDS:

atm qosbook delete Delete a QoS book entry.

atm qosbook list Display the QoS book.

60

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm qosbook config

Modify the QoS book configuration.

SYNTAX:

atm qosbook config [format = <{bytes | cells}>]

where:

format The input/output format of the QoS book.

EXAMPLE:

=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
=>atm qosbook config format=cells
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
=>

OPTIONAL
Choose between:

> bytes: the output is shown in Kbits or bytes.
> cells: the output is shown in cps or cells.

The default is bytes.

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

(cps) (cps) (cells) (cps) (cells)

E-DOC-CTC-20061027-0009 v2.0

61

atm qosbook ctdadd

Add a Connection Traffic Descriptor (CTD).

SYNTAX:

atm qosbook ctdadd name = <string>

conformance = <{UBR | CBR | VBR }>
[peakrate = <number{0-27786}>]
[sustrate = <number{0-27786}
[maxburst = <number{0-12240}>]
[realtime = <{enabled | disabled}>]

where:

name The name of the new CTD. REQUIRED

conformance The ATM service conformance definition. REQUIRED

peakrate A number between 0 and 27786.

Represents the peak rate (in kilobits per second).
The default is 0 (indicates linerate for UBR).

sustrate A number between 0 and 27786.

Represents the sustainable rate (in kilobits per second) (VBR only).
The default is 0.

maxburst A number between 48 and 12240.

Represents the maximum burst size (in bytes) (VBR or GFR).
The default is 0.

realtime Enable or disable realtime traffic (VBR only).

The default is disabled.

Chapter 3

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

EXAMPLE:

=>atm qosbook ctdadd name=High conformance=CBR peakrate=27786
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
High 0 CBR 27786 0 0 0 0 0 disabled disab
led
=>

62

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

IMPORTANT NOTE:

The Thomson ST always rounds up specified burst sizes to a multiple of 48 bytes (a multiple of ATM cells).

Example:

In the example below a burst size of 100 bytes is specified (maxburst=100). The Thomson ST will round up
the burst size to the closest matching multiple of 48 bytes, as can be seen when displaying the profile via the
command :atm qosbook ctdlist (burst=144).

=>atm qosbook ctdadd name=Medium conformance=VBR peakrate=27786 sustrate=20000 maxburst=100
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disabled
Medium 0 VBR 27786 20000 144 0 0 0 disabled disabled
=>

RELATED COMMANDS:

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

atm qosbook ctddelete Delete a CTD.

atm qosbook ctdlist Display all CTDs.

E-DOC-CTC-20061027-0009 v2.0

63

atm qosbook ctddelete

Delete a CTD.

SYNTAX:

atm qosbook ctddelete name = <string>

[force = <{disabled | enabled}>]

where:

name The name of the CTD entry to be deleted. REQUIRED

force Enable or disable to force delete the entry even when it is still in use.

The default is disabled.

Chapter 3

OPTIONAL

EXAMPLE:

=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
High 0 CBR 27786 0 0 0 0 0 disabled disab
led
=>atm qosbook ctddelete name=High
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
=>

RELATED COMMANDS:

atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD).

atm qosbook ctdlist Display all CTDs.

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

64

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm qosbook ctdlist

Display all CTDs.

SYNTAX:

atm qosbook ctdlist

EXAMPLE:

=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
High 0 CBR 27786 0 0 0 0 0 disabled disab
led
=>

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

RELATED COMMANDS:

atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD).

atm qosbook ctddelete Delete a CTD.

E-DOC-CTC-20061027-0009 v2.0

65

atm qosbook delete

Delete a QoS book entry.

SYNTAX:

atm qosbook delete name = <string>

[force = <{disabled | enabled}>]

where:

name The name of the QoS book entry to be deleted. REQUIRED

force Enable or disable to force delete the entry even when it is still in use.

The default is disabled.

Chapter 3

OPTIONAL

EXAMPLE:

=>atm qosbook list
Name Ref Type TX peak sust burst RX peak sust burst framediscard

default 3 ubr linerate 0 0 linerate 0 0 disabled
TestVBR 0 vbr-nrt 1500 1000 144 1500 1000 144 enabled
=>atm qosbook delete name=TestVBR
=>atm qosbook list
Name Ref Type TX peak sust burst RX peak sust burst framediscard

default 3 ubr linerate 0 0 linerate 0 0 disabled
=>

RELATED COMMANDS:

atm qosbook add Add a new QoS book entry.

atm qosbook list Display the QoS book.

(Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes)

(Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes)

66

E-DOC-CTC-20061027-0009 v2.0

Chapter 3

atm qosbook flush

Flush all the QoS book entries.

The flush command does not impact previously saved configurations.

i

SYNTAX:

atm qosbook flush

E-DOC-CTC-20061027-0009 v2.0

67

atm qosbook list

Display the QoS book.

SYNTAX:

atm qosbook list

EXAMPLE:

=>atm qosbook list
Name Ref Type TX peak sust burst RX peak sust burst framediscard

default 3 ubr linerate 0 0 linerate 0 0 disabled
TestVBR 0 vbr-nrt 1500 1000 144 1500 1000 144 enabled
=>

Chapter 3

(Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes)

RELATED COMMANDS:

atm qosbook add Add a new QoS book entry.

atm qosbook delete Delete a QoS book entry.

68

E-DOC-CTC-20061027-0009 v2.0

Chapter 4

4 Config Commands

Introduction

This chapter describes the commands of the config command group.

Contents

This chapter covers the following commands:

config delete Delete a user configuration file. 70

config dump Show the saved configuration file. 71

config flush Flush the loaded configuration. 72

config list Show the current configuration set. 73

config load Load complete saved (backup) or default configuration file. 74

config save Store the current configuration in a backup file. 76

E-DOC-CTC-20061027-0009 v2.0

69

config delete

Delete a user configuration file.

SYNTAX:

config delete [filename = <string>]

where:

Chapter 4

filename Name of the user configuration file to be deleted.

Note If not specified, all the user configuration files that were saved in

RELATED COMMANDS:

config dump Show the saved configuration file.

OPTIONAL

the Thomson ST permanent storage will be deleted.

70

E-DOC-CTC-20061027-0009 v2.0

Chapter 4

config dump

Show the saved configuration file.

SYNTAX:

config dump [sections = <string>]

where:

sections Sections to be dumped OPTIONAL

RELATED COMMANDS:

config delete Delete a user configuration file.

E-DOC-CTC-20061027-0009 v2.0

71

config flush

Flush the loaded configuration.

1. This flush command combines all the possible flush commands.

i

2. This command does not affect saved configurations.

SYNTAX:

config flush [flush_ip = <{enabled | disabled}>]

where:

Chapter 4

flush_ip Flush IP settings (enabled) or not (disabled).

The default is enabled.

Note Not keeping the IP settings could cause lost IP connectivity in the

LAN.

OPTIONAL

72

E-DOC-CTC-20061027-0009 v2.0

Chapter 4

config list

Show the current configuration set.

SYNTAX:

config list [templates = <{disabled | enabled}>]

where:

templates List the template files (disabled) or not (enabled).

The default is disabled.

RELATED COMMANDS:

config load Load complete saved (backup) or default configuration file.

config save Store the current configuration in a backup file.

OPTIONAL

E-DOC-CTC-20061027-0009 v2.0

73

config load

Load complete saved (backup) or default configuration file.

Use the command :config flush before loading a configuration file.

i

SYNTAX:

config load [load_ip = <{enabled | disabled}>]

[defaults = <{enabled | disabled}>]
[flush = <{enabled | disabled}>]
[echo = <{disabled | enabled}>]
[filename = <string>]

where:

Chapter 4

load_ip Load IP settings (enabled) or not (disabled).

Note Not keeping the IP settings could cause lost IP connectivity in the

LAN.

defaults Load default configuration (enabled) or saved configuration (disabled).

Note If not specified, the saved configuration will be loaded.

flush Flush the current configuration before loading a new configuration

(enabled) or not (disabled).

echo Echo each command string when loaded (enabled) or not (disabled). OPTIONAL

filename Name of the configuration file to be loaded. OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

74

E-DOC-CTC-20061027-0009 v2.0

Chapter 4

EXAMPLE:

=>ip rtlist

=>config load flush_ip=no
=>ip rtlist

=>config load flush=yes
=>ip rtlist

=>

Destination Source Gateway Intf Mtrc

10.0.0.0/24 10.0.0.0/24 10.0.0.140 eth0 0

172.16.0.5/32 0.0.0.0/0 172.16.0.5 cip1 0

10.0.0.140/32 0.0.0.0/0 10.0.0.140 eth0 0

127.0.0.1/32 0.0.0.0/0 127.0.0.1 loop 0

172.16.0.0/24 0.0.0.0/0 172.16.0.5 cip1 1

Destination Source Gateway Intf Mtrc

10.0.0.0/24 10.0.0.0/24 10.0.0.140 eth0 0

10.0.0.140/32 0.0.0.0/0 10.0.0.140 eth0 0

127.0.0.1/32 0.0.0.0/0 127.0.0.1 loop 0

Destination Source Gateway Intf Mtrc

10.0.0.0/24 10.0.0.0/24 10.0.0.140 eth0 0

10.0.0.140/32 0.0.0.0/0 10.0.0.140 eth0 0

172.16.0.5/32 0.0.0.0/0 172.16.0.5 cip1 0

127.0.0.1/32 0.0.0.0/0 127.0.0.1 loop 0

172.16.0.0/24 0.0.0.0/0 172.16.0.5 cip1 1

RELATED COMMANDS:

config list Show the current configuration set.

config save Store the current configuration in a backup file.

E-DOC-CTC-20061027-0009 v2.0

75

config save

Store the current configuration in a backup file.

All the existing configurations and modifications entered by the user are saved.

The backup file is saved in the Thomson ST permanent storage. This file can be downloaded via the
Thomson ST web pages or via an FTP session.

SYNTAX:

config save filename = <string>

where:

filename The filename for the backup file of the current configuration. REQUIRED

Chapter 4

RELATED COMMANDS:

config list Show the current configuration set.

config load Load complete saved (backup) or default configuration file.

76

E-DOC-CTC-20061027-0009 v2.0
