Thomson ST516, ST536, ST546 User Manual

Power

Ethernet

DSL

Internet

Thomson ST516/536/546

CLI Reference Guide

Thomson ST516/536/546

CLI Reference Guide
R6.2

Copyright

Copyright ©1999-2007 THOMSON. All rights reserved.

Distribution and copying of this document, use and communication of its contents is not permitted without written authorization
from THOMSON. The content of this document is furnished for informational use only, may be subject to change without notice,
and should not be construed as a commitment by THOMSON. THOMSON assumes no responsibility or liability for any errors or
inaccuracies that may appear in this document.

Thomson Telecom Belgium
Prins Boudewijnlaan, 47
B-2650 Edegem
Belgium

http://www.thomson-broadband.com

Trademarks

The following trademarks are used in this document:

> DECT is a trademark of ETSI.
> Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc.
> Ethernet™ is a trademark of Xerox Corporation.
> Wi-Fi® and the Wi-Fi logo are registered trademarks of the Wi-Fi Alliance. "Wi-Fi CERTIFIED", "Wi-Fi ZONE", "Wi-Fi Alli-

ance", their respective logos and "Wi-Fi Protected Access" are trademarks of the Wi-Fi Alliance.

> UPnP™ is a certification mark of the UPnP™ Implementers Corporation.
> Microsoft®, MS-DOS®, Windows® and Windows NT® are either registered trademarks or trademarks of Microsoft Corpo-

ration in the United States and/or other countries.

> Apple® and Mac OS® are registered trademarks of Apple Computer, Incorporated, registered in the United States and

other countries.

> UNIX® is a registered trademark of UNIX System Laboratories, Incorporated.
> Adobe®, the Adobe logo, Acrobat and Acrobat Reader are trademarks or registered trademarks of Adobe Systems, Incor-

porated, registered in the United States and/or other countries.

Other brands and product names may be trademarks or registered trademarks of their respective holders.

Document Information

Status: v2.0 (May 2007)
Reference: E-DOC-CTC-20061027-0003
Short Title: CLI Reference Guide ST516/536/546 R6.2
Software Build: R 6.2.H.5

Contents

About this CLI Reference Guide ................................................ 1

1 Root Commands ..........................................................................3

ping.......................................................................................................................................................... 4

traceroute ................................................................................................................................................5

2 ADSL Commands......................................................................... 7

adsl config............................................................................................................................................... 8

adsl info................................................................................................................................................... 9

adsl debug bitloadinginfo....................................................................................................................11

adsl debug deltconfig...........................................................................................................................12

adsl debug deltinfo...............................................................................................................................13

adsl debug modemoptioninfo.............................................................................................................14

adsl debug modemoption ................................................................................................................... 15

adsl debug traceconfig......................................................................................................................... 16

3 ATM Commands ........................................................................ 17

atm flush ...............................................................................................................................................19

atm ifadd ............................................................................................................................................... 20

atm ifattach ...........................................................................................................................................21

atm ifconfig ........................................................................................................................................... 22

atm ifdelete ...........................................................................................................................................24

atm ifdetach ..........................................................................................................................................25

atm iflist.................................................................................................................................................26

atm bundle add.....................................................................................................................................27

atm bundle attach................................................................................................................................. 28

atm bundle config ................................................................................................................................ 29

atm bundle clear...................................................................................................................................30

atm bundle delete.................................................................................................................................31

atm bundle detach................................................................................................................................32

atm bundle flush...................................................................................................................................33

atm bundle ifadd ..................................................................................................................................34

atm bundle ifconfig ..............................................................................................................................35

atm bundle ifdelete .............................................................................................................................. 36

atm bundle list ...................................................................................................................................... 37

atm cac config.......................................................................................................................................38

atm cac list ............................................................................................................................................39

atm cac overbooking............................................................................................................................40

E-DOC-CTC-20061027-0003 v2.0

i

Contents

atm debug aal5stats ............................................................................................................................. 41

atm debug gstats..................................................................................................................................42

atm debug portstats .............................................................................................................................43

atm oam config.....................................................................................................................................44

atm oam list ..........................................................................................................................................45

atm oam modify ...................................................................................................................................46

atm oam ping........................................................................................................................................48

atm oam cc list......................................................................................................................................49

atm oam cc modify...............................................................................................................................50

atm oam cc send .................................................................................................................................. 51

atm oam vclb add.................................................................................................................................52

atm oam vclb del ..................................................................................................................................53

atm oam vclb list ..................................................................................................................................54

atm phonebook add .............................................................................................................................55

atm phonebook autolist.......................................................................................................................56

atm phonebook delete .........................................................................................................................57

atm phonebook flush ...........................................................................................................................58

atm phonebook list...............................................................................................................................59

atm qosbook add..................................................................................................................................60

atm qosbook config..............................................................................................................................61

atm qosbook ctdadd.............................................................................................................................62

atm qosbook ctddelete......................................................................................................................... 64

atm qosbook ctdlist .............................................................................................................................. 65

atm qosbook delete..............................................................................................................................66

atm qosbook flush................................................................................................................................67

atm qosbook list ...................................................................................................................................68

4 AutoPVC Commands................................................................. 69

autopvc config ......................................................................................................................................70

autopvc list............................................................................................................................................72

5 Config Commands ..................................................................... 73

config delete ......................................................................................................................................... 74

config dump.......................................................................................................................................... 75

config flush ........................................................................................................................................... 76

config list...............................................................................................................................................77

config load ............................................................................................................................................ 78

config save ............................................................................................................................................ 80

ii

E-DOC-CTC-20061027-0003 v2.0

Contents

6 Connection Commands............................................................. 81

connection appconfig...........................................................................................................................82

connection appinfo...............................................................................................................................84

connection applist ................................................................................................................................85

connection bind.................................................................................................................................... 86

connection bindlist............................................................................................................................... 87

connection clean...................................................................................................................................88

connection clear ...................................................................................................................................89

connection config................................................................................................................................. 90

connection debug................................................................................................................................. 91

connection describe .............................................................................................................................92

connection flush ................................................................................................................................... 93

connection info..................................................................................................................................... 94

connection list.......................................................................................................................................95

connection refresh................................................................................................................................96

connection stats....................................................................................................................................97

connection timerclear .......................................................................................................................... 98

connection timerconfig........................................................................................................................99

connection unbind..............................................................................................................................100

7 CWMP Commands................................................................... 101

cwmp config ....................................................................................................................................... 102

cwmp server config............................................................................................................................104

8 Debug Commands ................................................................... 105

debug exec..........................................................................................................................................106

9 DHCP Commands .................................................................... 107

dhcp client flush ................................................................................................................................. 109

dhcp client ifadd .................................................................................................................................110

dhcp client ifattach .............................................................................................................................111

dhcp client ifconfig.............................................................................................................................112

dhcp client ifdelete .............................................................................................................................113

dhcp client ifdetach ............................................................................................................................114

dhcp client iflist...................................................................................................................................115

dhcp client ifrenew.............................................................................................................................117

dhcp client debug clear......................................................................................................................119

dhcp client debug stats......................................................................................................................120

E-DOC-CTC-20061027-0003 v2.0

iii

Contents

dhcp client debug traceconfig...........................................................................................................121

dhcp client rqoptions add ..................................................................................................................122

dhcp client rqoptions delete ..............................................................................................................123

dhcp client rqoptions list ...................................................................................................................124

dhcp client rqoptions optionlist ........................................................................................................125

dhcp client txoptions add ..................................................................................................................126

dhcp client txoptions delete ..............................................................................................................127

dhcp client txoptions list....................................................................................................................128

dhcp client txoptions optionlist.........................................................................................................129

dhcp relay add .................................................................................................................................... 130

dhcp relay debug stats....................................................................................................................... 131

dhcp relay debug traceconfig............................................................................................................ 132

dhcp relay config................................................................................................................................ 133

dhcp relay delete ................................................................................................................................134

dhcp relay flush .................................................................................................................................. 135

dhcp relay ifconfig..............................................................................................................................136

dhcp relay iflist ................................................................................................................................... 138

dhcp relay list......................................................................................................................................139

dhcp relay modify...............................................................................................................................140

dhcp relay ruleadd..............................................................................................................................141

dhcp relay ruledelete..........................................................................................................................142

dhcp rule add ...................................................................................................................................... 143

dhcp rule debug traceconfig..............................................................................................................144

dhcp rule delete .................................................................................................................................. 145

dhcp rule flush .................................................................................................................................... 146

dhcp rule list ....................................................................................................................................... 147

dhcp server config..............................................................................................................................148

dhcp server flush ................................................................................................................................149

dhcp server policy ..............................................................................................................................150

dhcp server debug clear ....................................................................................................................151

dhcp server debug stats..................................................................................................................... 152

dhcp server debug traceconfig..........................................................................................................154

dhcp server lease add ........................................................................................................................ 155

dhcp server lease delete .................................................................................................................... 157

iv

dhcp server lease flush ...................................................................................................................... 158

dhcp server lease list.......................................................................................................................... 159

dhcp server option flush....................................................................................................................160

dhcp server option instadd................................................................................................................ 161

E-DOC-CTC-20061027-0003 v2.0

Contents

dhcp server option instdelete............................................................................................................ 163

dhcp server option instlist ................................................................................................................. 164

dhcp server option tmpladd .............................................................................................................. 165

dhcp server option tmpldelete .......................................................................................................... 166

dhcp server option tmpllist................................................................................................................ 167

dhcp server pool add .........................................................................................................................168

dhcp server pool config .....................................................................................................................170

dhcp server pool delete ..................................................................................................................... 172

dhcp server pool flush ....................................................................................................................... 173

dhcp server pool list...........................................................................................................................174

dhcp server pool optadd....................................................................................................................175

dhcp server pool optdelete................................................................................................................ 176

dhcp server pool rtadd....................................................................................................................... 178

dhcp server pool rtdelete................................................................................................................... 179

dhcp server pool ruleadd...................................................................................................................180

dhcp server pool ruledelete............................................................................................................... 181

10 DNS Commands ...................................................................... 183

dns client config ................................................................................................................................. 184

dns client dnsadd ............................................................................................................................... 185

dns client dnsdelete ...........................................................................................................................186

dns client dnslist.................................................................................................................................187

dns client flush.................................................................................................................................... 188

dns client nslookup ............................................................................................................................189

dns server config ................................................................................................................................190

dns server flush ..................................................................................................................................191

dns server debug clear....................................................................................................................... 192

dns server debug stats....................................................................................................................... 193

dns server debug spoof clear ............................................................................................................ 194

dns server debug spoof getaddress ................................................................................................. 195

dns server debug spoof getflags.......................................................................................................196

dns server debug spoof list ............................................................................................................... 197

dns server debug spoof update ........................................................................................................ 198

dns server host add............................................................................................................................ 199

dns server host delete........................................................................................................................ 200

dns server host flush.......................................................................................................................... 201

dns server host list .............................................................................................................................202

dns server route add ..........................................................................................................................203

E-DOC-CTC-20061027-0003 v2.0

v

Contents

dns server route delete ...................................................................................................................... 205

dns server route flush ........................................................................................................................ 206

dns server route list............................................................................................................................ 207

11 DSD Commands....................................................................... 209

dsd config............................................................................................................................................210

dsd debug config................................................................................................................................211

dsd debug connection list.................................................................................................................. 212

dsd debug proxy................................................................................................................................. 213

dsd debug recycling ...........................................................................................................................214

dsd debug stats .................................................................................................................................. 215

dsd intercept config............................................................................................................................ 216

dsd syslog config................................................................................................................................ 217

dsd syslog list .....................................................................................................................................218

dsd urlfilter config ..............................................................................................................................219

dsd urlfilter rule add........................................................................................................................... 220

dsd urlfilter rule delete....................................................................................................................... 221

dsd urlfilter rule flush......................................................................................................................... 222

dsd urlfilter rule list ............................................................................................................................ 223

dsd urlfilter rule modify ..................................................................................................................... 224

12 DynDNS Commands................................................................ 227

dyndns add .........................................................................................................................................228

dyndns delete .....................................................................................................................................229

dyndns flush .......................................................................................................................................230

dyndns list........................................................................................................................................... 231

dyndns modify.................................................................................................................................... 232

dyndns host add ................................................................................................................................. 234

dyndns host delete ............................................................................................................................. 235

dyndns host flush............................................................................................................................... 236

dyndns host list .................................................................................................................................. 237

dyndns service list..............................................................................................................................238

dyndns service modify....................................................................................................................... 240

vi

13 Env Commands........................................................................ 243

env flush..............................................................................................................................................244

env get.................................................................................................................................................245

env list .................................................................................................................................................246

E-DOC-CTC-20061027-0003 v2.0

Contents

env set .................................................................................................................................................247

env unset.............................................................................................................................................248

14 Eth Commands ........................................................................ 249

eth ifadd .............................................................................................................................................. 252

eth ifattach .......................................................................................................................................... 253

eth ifconfig ..........................................................................................................................................254

eth ifdelete .......................................................................................................................................... 255

eth ifdetach ......................................................................................................................................... 256

eth iflist................................................................................................................................................257

eth flush...............................................................................................................................................258

eth bridge clear...................................................................................................................................259

eth bridge list ......................................................................................................................................260

eth bridge add..................................................................................................................................... 261

eth bridge delete................................................................................................................................. 262

eth bridge select .................................................................................................................................263

eth bridge config ................................................................................................................................ 264

eth bridge dynvlan actlist ..................................................................................................................265

eth bridge dynvlan add ......................................................................................................................266

eth bridge dynvlan config.................................................................................................................. 267

eth bridge dynvlan delete .................................................................................................................. 268

eth bridge dynvlan flush ....................................................................................................................269

eth bridge dynvlan list .......................................................................................................................270

eth bridge flush...................................................................................................................................271

eth bridge ifadd ..................................................................................................................................272

eth bridge ifattach ..............................................................................................................................273

eth bridge ifconfig ..............................................................................................................................274

eth bridge ifdelete ..............................................................................................................................276

eth bridge ifdetach .............................................................................................................................277

eth bridge iflist....................................................................................................................................278

eth bridge ifflush ................................................................................................................................ 279

eth bridge igmpsnooping config....................................................................................................... 280

eth bridge igmpsnooping list ............................................................................................................ 281

eth bridge igmpsnooping ifconfig ....................................................................................................282

eth bridge igmpsnooping iflist..........................................................................................................283

eth bridge igmpsnooping clear.........................................................................................................284

eth bridge macadd .............................................................................................................................285

eth bridge macdelete .........................................................................................................................287

E-DOC-CTC-20061027-0003 v2.0

vii

Contents

eth bridge maclist...............................................................................................................................289

eth bridge mcdadd .............................................................................................................................290

eth bridge mcddelete .........................................................................................................................291

eth bridge mcdlist............................................................................................................................... 292

eth bridge rule add .............................................................................................................................293

eth bridge rule delete .........................................................................................................................294

eth bridge rule flush ...........................................................................................................................295

eth bridge rule list .............................................................................................................................. 296

eth bridge vlan ifadd ..........................................................................................................................297

eth bridge vlan ifconfig ......................................................................................................................298

eth bridge vlan ifdelete ...................................................................................................................... 299

eth bridge vlan iflist............................................................................................................................ 300

eth device ifconfig ..............................................................................................................................301

eth device iflist....................................................................................................................................303

eth switch group flush .......................................................................................................................304

eth switch group list...........................................................................................................................305

eth switch group move ...................................................................................................................... 306

eth switch mirror capture ..................................................................................................................307

eth switch mirror egress ....................................................................................................................308

eth switch mirror ingress................................................................................................................... 309

eth switch share add ..........................................................................................................................310

eth switch share delete ...................................................................................................................... 311

eth switch share list............................................................................................................................ 312

eth switch info .................................................................................................................................... 313

eth switch qos config ......................................................................................................................... 314

eth switch qos ifconfig .......................................................................................................................315

eth switch qos list............................................................................................................................... 316

eth switch qos weights ......................................................................................................................317

eth switch shaper config.................................................................................................................... 318

eth switch shaper ifconfig.................................................................................................................. 319

eth switch shaper iflist ....................................................................................................................... 320

eth switch storm ifconfig ................................................................................................................... 321

eth switch storm iflist......................................................................................................................... 322

eth vlan add ........................................................................................................................................323

viii

eth vlan delete ....................................................................................................................................324

eth vlan flush ...................................................................................................................................... 325

eth vlan list..........................................................................................................................................326

E-DOC-CTC-20061027-0003 v2.0

Contents

15 Expr Commands ...................................................................... 327

expr add .............................................................................................................................................. 328

expr delete .......................................................................................................................................... 332

expr flush ............................................................................................................................................ 334

expr list................................................................................................................................................335

expr modify.........................................................................................................................................339

16 Firewall Commands................................................................. 343

firewall config .....................................................................................................................................344

firewall clear........................................................................................................................................346

firewall list...........................................................................................................................................347

firewall chain add ...............................................................................................................................349

firewall chain delete ...........................................................................................................................351

firewall chain flush .............................................................................................................................353

firewall chain list.................................................................................................................................354

firewall debug clear............................................................................................................................355

firewall debug stats ............................................................................................................................356

firewall debug traceconfig.................................................................................................................357

firewall level add ................................................................................................................................ 358

firewall level delete ............................................................................................................................ 359

firewall level flush .............................................................................................................................. 360

firewall level list..................................................................................................................................361

firewall level modify...........................................................................................................................362

firewall level set..................................................................................................................................363

firewall rule add..................................................................................................................................364

firewall rule delete..............................................................................................................................365

firewall rule flush................................................................................................................................366

firewall rule list ...................................................................................................................................367

firewall rule modify ............................................................................................................................369

firewall rule debug clear .................................................................................................................... 370

firewall rule debug stats ....................................................................................................................372

firewall rule debug traceconfig ......................................................................................................... 374

17 GRP Commands....................................................................... 375

grp config ............................................................................................................................................ 376

grp flush .............................................................................................................................................. 377

grp rtlist ............................................................................................................................................... 378

grp rip config ...................................................................................................................................... 379

E-DOC-CTC-20061027-0003 v2.0

ix

Contents

grp rip flush.........................................................................................................................................382

grp rip ifconfig ....................................................................................................................................383

grp rip show........................................................................................................................................385

18 Hostmgr Commands ...............................................................387

hostmgr add........................................................................................................................................388

hostmgr clear......................................................................................................................................390

hostmgr config ................................................................................................................................... 391

hostmgr delete.................................................................................................................................... 392

hostmgr flush......................................................................................................................................393

hostmgr list ......................................................................................................................................... 394

19 IDS Commands ........................................................................395

ids clear ............................................................................................................................................... 396

ids config............................................................................................................................................. 397

ids parser list.......................................................................................................................................398

ids parser modify................................................................................................................................399

ids pattern clear .................................................................................................................................. 401

ids pattern list .....................................................................................................................................402

ids pattern stats ..................................................................................................................................403

ids signature list ................................................................................................................................. 404

ids signature modify .......................................................................................................................... 405

ids threshold clear ..............................................................................................................................406

ids threshold list ................................................................................................................................. 407

ids threshold modify ..........................................................................................................................408

20 IGMP Commands..................................................................... 409

igmp host config.................................................................................................................................410

igmp host flush...................................................................................................................................411

igmp host list ......................................................................................................................................412

igmp host ifconfig .............................................................................................................................. 413

igmp host iflist .................................................................................................................................... 414

igmp host debug clear .......................................................................................................................415

igmp host debug stats .......................................................................................................................416

igmp proxy config ..............................................................................................................................417

igmp proxy flush ................................................................................................................................ 419

igmp proxy grouplist.......................................................................................................................... 420

igmp proxy ifconfig ............................................................................................................................421

x

E-DOC-CTC-20061027-0003 v2.0

Contents

igmp proxy iflist..................................................................................................................................422

igmp proxy mbslist ............................................................................................................................ 423

igmp proxy debug clear..................................................................................................................... 424

igmp proxy debug stats .....................................................................................................................425

igmp proxy debug traceconfig..........................................................................................................426

21 Interface Commands ...............................................................427

interface list.........................................................................................................................................428

22 IP Commands ...........................................................................431

ip arpadd .............................................................................................................................................433

ip arpdelete .........................................................................................................................................434

ip arplist...............................................................................................................................................435

ip config...............................................................................................................................................436

ip flush................................................................................................................................................. 438

ip ifadd.................................................................................................................................................439

ip ifattach.............................................................................................................................................440

ip ifconfig ............................................................................................................................................441

ip ifdelete.............................................................................................................................................443

ip ifdetach............................................................................................................................................444

ip iflist ..................................................................................................................................................445

ip ifwait................................................................................................................................................ 446

ip ipadd................................................................................................................................................447

ip ipconfig ...........................................................................................................................................448

ip ipdelete............................................................................................................................................449

ip iplist .................................................................................................................................................450

ip mcast rtadd ..................................................................................................................................... 451

ip mcast rtdelete ................................................................................................................................. 452

ip mcast rtlist ...................................................................................................................................... 453

ip mcast flush......................................................................................................................................454

ip rtadd ................................................................................................................................................ 455

ip rtdelete ............................................................................................................................................457

ip rtlist..................................................................................................................................................458

ip auto flush ........................................................................................................................................459

ip auto ifadd ........................................................................................................................................ 460

ip auto ifattach .................................................................................................................................... 461

ip auto ifconfig....................................................................................................................................462

ip auto ifdelete .................................................................................................................................... 464

E-DOC-CTC-20061027-0003 v2.0

xi

Contents

ip auto ifdetach ...................................................................................................................................465

ip auto iflist ......................................................................................................................................... 466

ip debug httpprobe.............................................................................................................................467

ip debug sendto..................................................................................................................................468

ip debug stats .....................................................................................................................................470

ip debug traceconfig .......................................................................................................................... 471

23 IPQoS Commands.................................................................... 473

ipqos config ........................................................................................................................................474

ipqos list .............................................................................................................................................. 477

ipqos ef config ....................................................................................................................................478

ipqos ef list..........................................................................................................................................479

ipqos ef stats.......................................................................................................................................480

ipqos queue clear ...............................................................................................................................481

ipqos queue config.............................................................................................................................482

ipqos queue list .................................................................................................................................. 484

ipqos queue stats ............................................................................................................................... 485

24 Label Commands .....................................................................487

label add.............................................................................................................................................. 488

label delete.......................................................................................................................................... 489

label flush............................................................................................................................................ 490

label list ............................................................................................................................................... 491

label modify ........................................................................................................................................ 492

label chain add....................................................................................................................................495

label chain delete................................................................................................................................496

label chain flush..................................................................................................................................497

label chain list..................................................................................................................................... 498

label rule add ...................................................................................................................................... 499

label rule delete ..................................................................................................................................502

label rule flush .................................................................................................................................... 504

label rule list........................................................................................................................................505

label rule modify.................................................................................................................................507

label rule debug clear......................................................................................................................... 508

xii

label rule debug stats.........................................................................................................................510

label rule debug traceconfig.............................................................................................................. 511

25 Language Commands ............................................................. 513

E-DOC-CTC-20061027-0003 v2.0

Contents

language config .................................................................................................................................. 514

language delete ..................................................................................................................................515

language list........................................................................................................................................516

26 MBUS Commands ...................................................................517

mbus client config .............................................................................................................................. 518

mbus client exec.................................................................................................................................519

mbus client register............................................................................................................................ 521

mbus debug stats ............................................................................................................................... 522

mbus debug clearstats.......................................................................................................................523

mbus debug traceconfig ....................................................................................................................524

mbus listobjects..................................................................................................................................525

mbus listtypes.....................................................................................................................................526

mbus listenums ..................................................................................................................................527

mbus listcontexts ............................................................................................................................... 528

mbus listsubscriptions....................................................................................................................... 529

mbus debug loadobjects ................................................................................................................... 530

mbus debug unloadobjects..............................................................................................................531

mbus pluginevent...............................................................................................................................532

mbus unregister ................................................................................................................................. 533

mbus client unregister .......................................................................................................................534

27 MEMM Commands.................................................................. 535

memm debug lock traceconfig..........................................................................................................536

memm debug traceconfig .................................................................................................................537

memm debug clearstats .................................................................................................................... 538

memm debug lock stats..................................................................................................................... 539

memm listobjects ............................................................................................................................... 540

memm stats ........................................................................................................................................541

28 MLP Commands ...................................................................... 543

mlp flush .............................................................................................................................................544

mlp import .......................................................................................................................................... 545

mlp debug export ............................................................................................................................... 546

mlp debug stats .................................................................................................................................. 547

mlp debug traceconfig.......................................................................................................................548

mlp privilege add................................................................................................................................ 549

mlp privilege addzone........................................................................................................................ 551

E-DOC-CTC-20061027-0003 v2.0

xiii

Contents

mlp privilege config ........................................................................................................................... 552

mlp privilege delete............................................................................................................................ 553

mlp privilege list ................................................................................................................................. 555

mlp privilege removezone .................................................................................................................557

mlp role add........................................................................................................................................ 558

mlp role addpriv .................................................................................................................................560

mlp role config....................................................................................................................................561

mlp role delete....................................................................................................................................562

mlp role list .........................................................................................................................................563

mlp role removepriv........................................................................................................................... 564

29 NAT Commands....................................................................... 565

nat config ............................................................................................................................................ 566

nat flush...............................................................................................................................................567

nat ifconfig ..........................................................................................................................................568

nat iflist................................................................................................................................................569

nat mapadd ......................................................................................................................................... 570

nat mapdelete .....................................................................................................................................574

nat maplist .......................................................................................................................................... 575

nat tmpladd.........................................................................................................................................576

nat tmpldelete.....................................................................................................................................580

nat tmpllist ..........................................................................................................................................581

nat tmplinst ......................................................................................................................................... 582

30 PPP Commands........................................................................ 583

ppp flush .............................................................................................................................................584

ppp ifadd .............................................................................................................................................585

ppp ifattach .........................................................................................................................................587

ppp ifconfig ......................................................................................................................................... 589

ppp ifdelete .........................................................................................................................................594

ppp ifdetach ........................................................................................................................................ 596

ppp iflist...............................................................................................................................................598

ppp ifscan............................................................................................................................................ 599

ppp rtadd.............................................................................................................................................600

xiv

ppp rtdelete.........................................................................................................................................602

ppp relay flush .................................................................................................................................... 604

ppp relay ifadd....................................................................................................................................605

ppp relay ifconfig................................................................................................................................ 606

E-DOC-CTC-20061027-0003 v2.0

Contents

ppp relay ifdelete................................................................................................................................607

ppp relay iflist .....................................................................................................................................608

ppp relay sesslist................................................................................................................................ 609

31 PPTP Commands ..................................................................... 611

pptp ifadd ............................................................................................................................................ 612

pptp flush ............................................................................................................................................613

pptp list................................................................................................................................................614

pptp profadd .......................................................................................................................................615

pptp profdelete ...................................................................................................................................617

pptp proflist.........................................................................................................................................618

32 Script Commands ....................................................................619

script add.............................................................................................................................................620

script delete.........................................................................................................................................621

script flush...........................................................................................................................................622

script list .............................................................................................................................................. 623

script run .............................................................................................................................................625

33 Service Commands.................................................................. 627

service host assign .............................................................................................................................628

service host config ............................................................................................................................. 629

service host add.................................................................................................................................. 630

service host delete.............................................................................................................................. 631

service host disable............................................................................................................................632

service host flush................................................................................................................................ 633

service host list ...................................................................................................................................634

service host stats ................................................................................................................................ 635

service host triggerlist........................................................................................................................ 636

service host rule add ..........................................................................................................................637

service host rule delete ......................................................................................................................638

service system ifadd........................................................................................................................... 639

service system ifdelete....................................................................................................................... 640

service system ipadd.......................................................................................................................... 641

service system ipdelete...................................................................................................................... 642

service system list ..............................................................................................................................643

service system mapadd ..................................................................................................................... 645

service system mapdelete ................................................................................................................. 646

E-DOC-CTC-20061027-0003 v2.0

xv

Contents

service system modify ....................................................................................................................... 647

34 SNMP Commands ................................................................... 649

snmp config ........................................................................................................................................650

snmp get .............................................................................................................................................651

snmp getnext ...................................................................................................................................... 652

snmp walk ........................................................................................................................................... 653

snmp community add ........................................................................................................................654

snmp community delete....................................................................................................................655

snmp community list .........................................................................................................................656

snmp community modify .................................................................................................................. 657

snmp ifadd .......................................................................................................................................... 658

snmp ifdelete ......................................................................................................................................659

snmp ifattach ......................................................................................................................................660

snmp ifdetach .....................................................................................................................................661

snmp ifconfig ...................................................................................................................................... 662

snmp iflist............................................................................................................................................663

35 SNTP Commands..................................................................... 665

sntp add...............................................................................................................................................666

sntp config .......................................................................................................................................... 667

sntp delete...........................................................................................................................................668

sntp flush.............................................................................................................................................669

sntp list ................................................................................................................................................ 670

36 Software Commands .............................................................. 671

software upgrade ............................................................................................................................... 672

software version ................................................................................................................................. 673

37 System Commands .................................................................675

system config......................................................................................................................................676

system flush........................................................................................................................................678

system locale ......................................................................................................................................679

system reboot ..................................................................................................................................... 681

xvi

system reset........................................................................................................................................682

system timedreboot ...........................................................................................................................684

system debug autosave .....................................................................................................................685

system debug stats ............................................................................................................................686

E-DOC-CTC-20061027-0003 v2.0

Contents

system ra config .................................................................................................................................687

system rtc synchronize ......................................................................................................................688

system rtc settime ..............................................................................................................................689

38 Systemlog Commands............................................................ 691

systemlog flush .................................................................................................................................. 692

systemlog show.................................................................................................................................. 693

systemlog send................................................................................................................................... 695

systemlog DBG dbg_syslog...............................................................................................................696

systemlog DBG dbg_long_mess ....................................................................................................... 697

systemlog DBG dbg_burst................................................................................................................. 698

systemlog DBG dbg_contents...........................................................................................................699

39 Upgrade Commands ............................................................... 701

upgrade config....................................................................................................................................702

upgrade start.......................................................................................................................................703

upgrade debug traceconfig ...............................................................................................................704

upgrade debug sesslist ......................................................................................................................705

upgrade profile add............................................................................................................................ 706

upgrade profile modify ...................................................................................................................... 707

upgrade profile delete........................................................................................................................708

upgrade profile list .............................................................................................................................709

upgrade ifadd......................................................................................................................................710

upgrade ifattach.................................................................................................................................. 711

upgrade ifconfig ................................................................................................................................. 712

upgrade ifdelete..................................................................................................................................713

upgrade ifdetach.................................................................................................................................714

upgrade iflist ....................................................................................................................................... 715

40 UPnP Commands..................................................................... 717

upnp config ......................................................................................................................................... 718

upnp flush ........................................................................................................................................... 719

upnp list...............................................................................................................................................720

41 User Commands ......................................................................721

user add...............................................................................................................................................722

user config .......................................................................................................................................... 724

user delete...........................................................................................................................................726

E-DOC-CTC-20061027-0003 v2.0

xvii

Contents

user flush.............................................................................................................................................727

user list ................................................................................................................................................ 728

user rights ...........................................................................................................................................730

42 Abbreviations........................................................................... 731

43 System Logging Messages..................................................... 735

Auto-PVC Module ............................................................................................................................... 736

Configuration Module........................................................................................................................736

DHCP Client Module...........................................................................................................................736

DHCP Relay Module ...........................................................................................................................737

DHCP Server Module .........................................................................................................................737

Dyndns Module .................................................................................................................................. 738

Firewall Module .................................................................................................................................. 738

LOGIN Module .................................................................................................................................... 739

Kernel Module .................................................................................................................................... 739

Linestate Module ................................................................................................................................ 739

NAPT Module......................................................................................................................................739

PPP Module......................................................................................................................................... 740

PPTP Module.......................................................................................................................................740

RIP Module.......................................................................................................................................... 741

Routing Module .................................................................................................................................. 742

Session Module .................................................................................................................................. 742

SNTP Module......................................................................................................................................742

Software Module ................................................................................................................................ 743

UPnP Module ...................................................................................................................................... 743

.............................................................................................................................................................743

44 Supported Key Names ............................................................745

Supported IP Protocols ...................................................................................................................... 746

Supported TCP/UDP Port Names......................................................................................................747

Supported ICMP Type Names...........................................................................................................750

Supported Facilities........................................................................................................................... 751

Supported Severities......................................................................................................................... 752

xviii

IP Precedence......................................................................................................................................752

Differentiated Services Code Point (DSCP) ......................................................................................753

E-DOC-CTC-20061027-0003 v2.0

About this CLI Reference Guide

About this CLI Reference Guide

Used Symbols

A note provides additional information about a topic.

i

A caution warns you about potential problems or specific precautions that need to be taken.

!

Terminology

Generally, the Thomson ST516/536/546 will be referred to as Thomson ST in this CLI Reference Guide.

Typographical Conventions

Following typographical convention is used throughout this manual:

> Sample text indicates a hyperlink to a Web site.

Example: For more information, visit us at www.thomson-broadband.com

.

> Sample text indicates an internal cross-reference.

Example: If you want to know more about guide, see “1 Introduction” on page 7”.

> Sample text indicates an important content-related word.

Example: To enter the network, you must authenticate yourself.

> Sample text indicates a CLI command to be input after the CLI prompt.

Example: To obtain a list of all available command groups, type

help at the top level.

> Sample text indicates input in the CLI interface.
> Sample text indicates comment explaining output in the CLI interface.

Documentation and software updates

THOMSON continuously develops new solutions, but is also committed to improving its existing products.

For suggestions regarding this document, please contact [e-mail]

For more information on THOMSON's latest technological innovations, documents and software releases,
visit us at http://www.thomson-broadband.com

.

.

E-DOC-CTC-20061027-0003 v2.0

1

About this CLI Reference Guide

2

E-DOC-CTC-20061027-0003 v2.0

Root Commands

1 Root Commands

From the root prompt, you can choose one of the following commands:

Command Description

help Displays the help information.

?

menu Displays the menu.

exit Exits the shell.

.. Exits group selection.

saveall Saves current configuration.

ping Send ICMP ECHO_REQUEST packets.

traceroute Send ICMP/UDP packets to trace the ip path.

i

EXAMPLE:

<Administrator>=>help firewall
Following commands are available :

config : Display/Modify firewall configuration.
list : Display firewall configuration.
clear : Clear firewall configuration.

Following command groups are available :

chain debug level rule

<Administrator>=>

To obtain help on a specific command group:

> type help, followed by the name of the command group, and then press ENTER, or
> type the name of the command group, press ENTER, and then type help.

E-DOC-CTC-20061027-0003 v2.0

3

ping

Send ICMP ECHO_REQUEST packets.

SYNTAX:

ping proto = <{ip|atm}>

addr = <ip-address>
dest = <string>
[count = <number{0-1000000}>]
[size = <number{28-20028}>]
[interval(ms) = <number{100-1000000}>]
[DF-bit = <{disabled|enabled}>] [srcaddr = <ip-address>]

where:

Root Commands

proto The interface type to be used.

addr The destination IP address. REQUIRED

dest The destination address for the request. REQUIRED

count A number between 1 and 1000000.

size A number between 0 and 20000.

interval A number between 100 and 1000000.

DF-bit Set the Don't Fragment bit (or leave unset) in the IP header of ping.

scraddr The IP source address to use. OPTIONAL

EXAMPLE:

=>:ping proto=ip addr=192.168.1.70
Legend : Ping successful(!)

!!!!!

--- ping statistics --­5 packet(s) transmitted, 5 successful, 0% loss
rtt min/avg/max = 1 / 2 / 4 ms
=>

REQUIRED

Choose between:

> ip
> atm

OPTIONAL
Represents the number of pings to send.
The default is 5.

OPTIONAL
Represents the size of the ping payload(s).

OPTIONAL
Represents the interval in milliseconds between packets.
The default is 100.

OPTIONAL
The default is disabled.

Ping Timeout(.)

Hit ctrl-g to abort...

4

E-DOC-CTC-20061027-0003 v2.0

Root Commands

traceroute

Send ICMP/UDP packets to trace the IP path.

SYNTAX:

traceroute addr = <ip-address>

where:

[count = <number{1-10}>]
[size = <number{1-20000}>]
[interval = <number{1000-60000}>]
[maxhops = <number{1-255}>]
[dstport = <number{1-65535}>]
[maxfail = <number{0-255}>]
[type = <{icmp | udp}>]
[utime = <{disabled | enabled}>]

addr The destination IP address. REQUIRED

count A number between 1 and 10.

Represents the number of times to reissue a traceroute request with the
same TTL.
The default is 3.

size A number between 1 and 20000 (bytes).

Represents the size of the traceroute packet(s).
The default is 1.

interval A number between 1000 and 60000 (milliseconds).

Represents the intermediate interval between two packets.
The default is 1000.

maxhops A number between 1 and 255.

Represents the maximum number of routers through which a packet can
pass.
The default is 30.

dstport A number between 1 and 65535.

Represents the UDP destination port number to send to.

maxfail A number between 0 and 255.

Represents the maximum number of consecutive timeouts allowed
before terminating a traceroute request.
The default is 5.

type The type of traceroute packet(s).

Choose between:

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

> icmp
> udp.

The default is icmp.

utime Display time in useconds (enabled) or not (disabled).

The default is enabled.

OPTIONAL

E-DOC-CTC-20061027-0003 v2.0

5

EXAMPLE:

=>traceroute addr = 192.193.195.250 count=3 size=1 interval=1000 maxhops=30 dstport=33433

maxfail=5 type=icmp utime=yes
:traceroute addr=192.193.195.250
ttl=1 192.193.195.250 676 us 1351 us 648 us

=>

Root Commands

6

E-DOC-CTC-20061027-0003 v2.0

ADSL Commands

2 ADSL Commands

Introduction

This chapter describes the commands of the adsl command group.

Contents

This chapter covers the following commands:

adsl config Show/set the Asymmetric Digital Subscriber Line (ADSL)

configuration.

adsl info Display the ADSL statistics and information about the DSL line

status.

adsl debug bitloadinginfo Displays the number of bits per tone. 11

adsl debug deltconfig Enable/disable the Dual Ended Line Testing Interface (DELT) 12

adsl debug deltinfo Display Dual Ended Line Testing Interface (DELT) results 12

adsl debug

modemoptioninfo

adsl debug

modemoption

adsl debug traceconfig Configure the ADSL tracelevel. 16

Displays the modem options bitmap 14

Configure the modem options bitmap 15

8

9

E-DOC-CTC-20061027-0003 v2.0

7

ADSL Commands

adsl config

Show/set the Asymmetric Digital Subscriber Line (ADSL) configuration.

SYNTAX:

adsl config [opermode = <{multimode | multi_adsl2 | multi_readsl2

| multi_adsl2plus}>]

[trace = <{disabled | enabled}>]

where:

opermode The operational mode of the Thomson ST.

Choose between:

> multimode
> multi_adsl2
> multi_readsl2
> multi_adsl2plus

The default is multi_adsl2plus.

trace Enable or disable ADSL tracing.

The default is enabled.

EXAMPLE:

The example below shows the default configuration for a Thomson ST ADSL/POTS variant:

=>adsl config
ADSL configuration:
opermode = multi_adsl2plus
trace = on
modemoption = 00:00:00:00:00:00:00:00:00:00:00:00:00:00:00:00
=>

OPTIONAL

OPTIONAL

8

E-DOC-CTC-20061027-0003 v2.0

ADSL Commands

adsl info

Display the ADSL statistics and information about the DSL line status.

Although the same command is used for both Thomson ST ADSL/POTS and Thomson ST ADSL/ISDN
variants, the command features specific output parameters and counters per variant.

SYNTAX:

adsl info

E-DOC-CTC-20061027-0003 v2.0

9

EXAMPLE (for a Thomson ST ADSL/POTS variant):

=>adsl info
Modemstate : up
Operation Mode : G.992.1 Annex A
Channel Mode : interleaved
Number of resets : 1

Vendor Local Remote

Country : 0f 00

Vendor : TMMB

VendorSpecific : 0000 0000

StandardRevisionNr : 00 00

ADSL Commands

Margin [dB] : 26.0 18.0
Attenuation [dB] : 0.0 2.0
OutputPower [dBm] : 4.0 11.5

Available Bandwidth Cells/s Kbit/s

Downstream : 14490 6144

Upstream : 1509 640

Transfer statistics

Errors

Received FEC : 0
Received CRC : 0
Received HEC : 0
Transmitted FEC : 0
Transmitted CRC : 0
Tranmsitted HEC : 0

Near end failures since reset

Loss of frame: 0 failures
Loss of signal: 0 failures
Loss of power: 0 failures
Errored seconds: 0 seconds

Near end failures last 15 minutes

Loss of frame: 0 seconds
Loss of signal: 0 seconds
Loss of power: 0 seconds
Errored seconds: 0 seconds

Near end failures current day

Errored seconds: 0 seconds

Near end failures previous day

Errored seconds: 0 seconds

=>

Downstream Upstream

10

E-DOC-CTC-20061027-0003 v2.0

ADSL Commands

adsl debug bitloadinginfo

Displays the number of bits per tone.

Syntax

adsl debug bitloadinginfo

E-DOC-CTC-20061027-0003 v2.0

11

adsl debug deltconfig

Enable/disable the Dual Ended Line Testing Interface (DELT)

Syntax

adsl debug deltconfig [state = <{disabled|enabled}>]

where:

state enable or disable DELT REQUIRED

ADSL Commands

12

E-DOC-CTC-20061027-0003 v2.0

ADSL Commands

adsl debug deltinfo

Display Dual Ended Line Testing Interface (DELT) results

Syntax

adsl debug deltinfo

E-DOC-CTC-20061027-0003 v2.0

13

adsl debug modemoptioninfo

Displays the modem options bitmap

Syntax

adsl debug modemoptioninfo

ADSL Commands

14

E-DOC-CTC-20061027-0003 v2.0

ADSL Commands

adsl debug modemoption

Configure the modem options bitmap

Syntax

adsl debug modemoption [config = <hexbitmap>]

where:

config The modem options bitmap REQUIRED

E-DOC-CTC-20061027-0003 v2.0

15

adsl debug traceconfig

Configure the ADSL tracelevel.

Syntax

adsl debug traceconfig [level = <number{0-2}>]

where:

ADSL Commands

level Trace Level:

> 0=disable tracing;
> 1=enable dsl manager tracing;
> 2=enable dsl driver tracing)

REQUIRED

16

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

3 ATM Commands

Introduction

This chapter describes the commands of the atm command group.

Contents

This chapter covers the following commands:

atm flush Flush all Asynchronous Transfer Mode (ATM) interfaces. 19

atm ifadd Create a new ATM interface. 20

atm ifattach Attach a ATM interface. 21

atm ifconfig Configure an ATM interface. 22

atm ifdelete Delete an ATM interface. 24

atm ifdetach Detach an ATM interface. 25

atm iflist Display the ATM interfaces. 26

atm bundle add Add a new bundle of interfaces. 27

atm bundle attach Attach a bundle of interfaces. 28

atm bundle config Modify a bundle of interfaces. 29

atm bundle clear Clear the bundle statistics. 30

atm bundle delete Delete a bundle of interfaces. 31

atm bundle detach Detach a bundle of interfaces. 32

atm bundle flush Flush all bundles. 33

atm bundle ifadd Add an interface on a bundle. 34

atm bundle ifconfig Configure an interface from a bundle. 35

atm bundle ifdelete Remove an interface from a bundle. 36

atm bundle list Display the current bundles. 37

atm cac config Configure the ATM connection admission control. 38

atm cac list Display all the CAC parameters. 39

atm cac overbooking Configure ATM overbooking parameters. 40

atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics. 41

atm debug gstats Display ATM global statistics. 42

atm debug portstats Display port specific ATM statistics. 43

atm oam config Modify the ATM Operation and Maintenance (OAM) settings. 44

atm oam list Display the ATM OAM settings. 45

atm oam modify Modify the ATM OAM data blocking mode. 46

atm oam ping Send ATM loopback cells. 48

atm oam cc list Display Continuity Check (CC) configuration. 49

atm oam cc modify Modify CC on the connection. 50

atm oam cc send Send CC activate/deactivate to connection.

51

E-DOC-CTC-20061027-0003 v2.0

17

ATM Commands

atm oam vclb add Create a loopback connection for VC. 52

atm oam vclb del Delete a loopback connection for VC. 53

atm oam vclb list List all VC loopback connections. 54

atm phonebook add Add a new phonebook entry. 55

atm phonebook

autolist

atm phonebook delete Delete an existing phonebook entry. 57

atm phonebook flush Flush all the phonebook entries. 58

atm phonebook list Display the current phonebook. 59

atm qosbook add Add a new QoS book entry. 60

atm qosbook config Modify the QoS book configuration. 61

atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD). 62

atm qosbook ctddelete Delete a CTD. 64

atm qosbook ctdlist Display all CTDs. 65

atm qosbook delete Delete a QoS book entry. 66

atm qosbook flush Flush all the QoS book entries. 67

atm qosbook list Display the QoS book. 68

Show the auto PVCs. 56

18

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm flush

Flush all Asynchronous Transfer Mode (ATM) interfaces.

SYNTAX:

atm flush

E-DOC-CTC-20061027-0003 v2.0

19

atm ifadd

Create a new ATM interface.

SYNTAX:

atm ifadd intf = <string>

where:

ATM Commands

intf The name for the new ATM interface.

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

=>
=>atm ifadd intf = RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

RtPPPoA_atm: dest : (none)

=>

REQUIRED

Note If not specified, the destination parameter must be specified. In this

case the name of the destination will double as interface name.

Retry : 10 QoS : default Encaps : vcmux Fcs : disabled Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : vcmux Fcs : disabled Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : ip
Connection State : not-connected

RELATED COMMANDS:

atm ifdelete Delete an ATM interface.

atm iflist Display the ATM interfaces.

20

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm ifattach

Attach a ATM interface.

SYNTAX:

atm ifattach intf = <string>

where:

intf The name of the ATM interface to be attached. REQUIRED

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : not-connected

=>atm ifattach intf=RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

=>

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

RELATED COMMANDS:

atm ifdetach Detach an ATM interface.

E-DOC-CTC-20061027-0003 v2.0

21

atm ifconfig

Configure an ATM interface.

The interface to be configured must not be connected at the time of configuration. If this should be

i

the case, use the command :atm ifdetach before using the command :atm ifconfig.

SYNTAX:

atm ifconfig intf = <string>

[dest = <string>]
[qos = <string>]
[clp = <{0|1|classification}>]
[clpthresh = <number{0-15}>]
[encaps = <{llc | vcmux}>]
[retry = <number{0-65535}>]
[fcs = <{disabled | enabled | auto}>]
[ulp = <{ip | mac | ppp}>]

ATM Commands

where:

intf The name of the ATM interface to be configured. REQUIRED

dest The WAN destination for this ATM interface.

Typically, an ATM phonebook entry.

qos The name of the Quality of Service (QoS) book entry to apply on this ATM

interface.
The default is default.

clp The mode used to determine the CLP bit value OPTIONAL

clpthresh Priority class threshold where CLP becomes 0 (for all classes >= threshold) OPTIONAL

encaps The type of encapsulation to be used for this ATM interface.

Choose between:

OPTIONAL

OPTIONAL

OPTIONAL

> llc: Logical Link Control (LLC) / Sub Network Access Protocol (SNAP)
> vcmux: Virtual Channel MUltipleXing (VCMUX).

The default is llc.

fcs Enable or disable the inclusion of the Ethernet Frame Check Sequence

(FCS) in the packet header on the WAN side (only used for llc
encapsulation for mac).
The default is disabled.

Note This parameter is normally left disabled.

retry A number between 0 and 65535.

Represents the number of times the Thomson ST retries to set up a WAN
connection before giving up.
The default is 10.

OPTIONAL

OPTIONAL

22

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

ulp Select the Upper Layer Protocol (ULP) for this interface.

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

atm_8_35 : dest : atm_pvc_8_35

=>
=>atm ifconfig intf=atm_8_35 dest=atm_pvc_8_35 encaps=vcmux ulp=ppp
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

OPTIONAL

Choose between:

> ip (for a Routed IPoA interface).
> mac (for a Bridged Ethernet, Routed ETHoA, Bridged PPP over

Ethernet (PPPoE), Routed PPPoE or a PPPoE Relay interface).

> ppp (for a Routed PPP over ATM (PPPoA) interface).

The default is ip.

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac
Connection State : not-connected

Retry : 10 QoS : default Encaps : llc Fcs : disabled Ulp : mac
Connection State : connected

atm_8_35 : dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : disabled Ulp : ppp
Connection State : not-connected

=>

E-DOC-CTC-20061027-0003 v2.0

23

atm ifdelete

Delete an ATM interface.

SYNTAX:

atm ifdelete intf = <string>

where:

intf The name of the ATM interface to be deleted. REQUIRED

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

ATM Commands

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>
=>atm ifdelete intf=RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

=>

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RELATED COMMANDS:

atm ifadd Create a new ATM interface.

atm iflist Display the ATM interfaces.

24

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm ifdetach

Detach an ATM interface.

SYNTAX:

atm ifdetach intf = <string>

where:

intf The name of the ATM interface to be detached. REQUIRED

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>
=>atm ifdetach intf=RtPPPoA_atm
=>
=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

RtPPPoA_atm: dest : RtPPPoA

=>

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : not-connected

RELATED COMMANDS:

atm ifattach Attach a ATM interface.

E-DOC-CTC-20061027-0003 v2.0

25

atm iflist

Display the ATM interfaces.

SYNTAX:

atm iflist [intf = <string>]

where:

ATM Commands

intf The name of the ATM interface to be shown.

Note If not specified, all the ATM interfaces are shown.

EXAMPLE:

=>atm iflist
atm_0_35 : dest : atm_pvc_0_35

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : mac
Connection State : connected

RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>atm iflist intf=RtPPPoA_atm
RtPPPoA_atm: dest : RtPPPoA

Retry : 10 QoS : default Encaps : vcmux Fcs : off Ulp : ppp
Connection State : connected

=>

RELATED COMMANDS:

atm ifadd Create a new ATM interface.

atm ifdelete Delete an ATM interface.

OPTIONAL

26

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm bundle add

Add a new bundle of interfaces.

SYNTAX:

atm bundle add name = <string>

where:

name The name of the new bundle. REQUIRED

EXAMPLE:

=>atm bundle add name=myBundle
=>atm bundle list
myBundle: Connection state : not-connected

Retry: 10 Policy: priority Propagate: disabled
TX requested bytes: 0 requested frames: 0
TX bytes: 0 frames: 0

=>

RX bytes: 0 frames: 0

RELATED COMMANDS:

atm bundle delete Delete a bundle of interfaces.

atm bundle list Display the current bundles.

E-DOC-CTC-20061027-0003 v2.0

27

atm bundle attach

Attach a bundle of interfaces.

SYNTAX:

atm bundle attach name = <string>

where:

name The name of the bundle to be attached. REQUIRED

EXAMPLE:

=>atm bundle attach name=myBundle
=>atm bundle list
myBundle: Connection state : connected

Retry: 10 Policy: priority Propagate: disabled
TX requested bytes: 0 requested frames: 0
TX bytes: 0 frames: 0
RX bytes: 0 frames: 0

=>

ATM Commands

RELATED COMMANDS:

atm bundle detach Detach a bundle of interfaces.

28

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm bundle config

Modify a bundle of interfaces.

The bundle of interfaces to be configured must not be connected at the time of configuration. If this
should be the case, use the command :atm bundle detach before using the command :atm

i

bundle config.

SYNTAX:

atm bundle config name = <string>

where:

name The name of the bundle to be configured. REQUIRED

policy The traffic handling policy of the bundle.

Choose between:

> priority: lower layer ATM interfaces can be configured for a certain

> connection: all the packets of the same connection will be sent via

The default is priority.

propagate Enable or disable propagation of packets.

When propagation is enabled, packets are sent via the first interface
configured for that traffic. If the interface goes down, the next interface in
the bundle will be used.
The default is disabled.

retry A number between 0 and 65535.

Represents the number of connection setup retries before giving up.
The default is 10.

[policy = <{priority | connection}>]
[propagate = <{disabled | enabled}>]
[retry = <number{0-65535}>]

OPTIONAL

priority range, marked packets will be sent on the corresponding
interface.

the same interface.

OPTIONAL

OPTIONAL

EXAMPLE:

=>atm bundle list
myBundle: Connection state : not-connected

Retry: 10 Policy: priority Propagate: disabled
TX requested bytes: 0 requested frames: 0
TX bytes: 0 frames: 0

RX bytes: 0 frames: 0
=>atm bundle config name=myBundle policy=connection retry=15
=>atm bundle list
myBundle: Connection state : not-connected

Retry: 15 Policy: connection Propagate: disabled

TX requested bytes: 0 requested frames: 0

TX bytes: 0 frames: 0

RX bytes: 0 frames: 0
=>

E-DOC-CTC-20061027-0003 v2.0

29

atm bundle clear

Clear the bundle statistics.

SYNTAX:

atm bundle clear [name = <string>]

where:

ATM Commands

name The name of the bundle for which the statistics must be cleared.

Note If not specified, the statistics for all the bundles will be cleared.

OPTIONAL

30

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm bundle delete

Delete a bundle of interfaces.

SYNTAX:

atm bundle delete name = <string>

where:

name The name of the bundle to be deleted. REQUIRED

RELATED COMMANDS:

atm bundle add Add a new bundle of interfaces.

atm bundle list Display the current bundles.

E-DOC-CTC-20061027-0003 v2.0

31

atm bundle detach

Detach a bundle of interfaces.

SYNTAX:

atm bundle detach intf = <string>

where:

intf The name of the bundle to be detached. REQUIRED

RELATED COMMANDS:

atm bundle attach Attach a bundle of interfaces.

ATM Commands

32

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm bundle flush

Flush all bundles.

SYNTAX:

atm bundle flush

E-DOC-CTC-20061027-0003 v2.0

33

atm bundle ifadd

Add an interface on a bundle.

Up to 8 interfaces or (sub-)bundles can be added to one bundle.

i

SYNTAX:

atm bundle ifadd name = <string>

intf = <string>
[index = <number{0-6}>]

where:

name The name of the bundle to which an ATM interface must be added. REQUIRED

intf The name of the ATM interface to be added. REQUIRED

index A number between 0 and 6.

Represents the index of the ATM interface.

ATM Commands

OPTIONAL

EXAMPLE:

=>atm bundle ifadd name=myBundle intf=myATMintf
=>atm bundle list
myBundle: Connection state : not-connected

Retry: 15 Policy: connection

TX requested bytes: 0 requested frames: 0

TX bytes: 0 frames: 0

RX bytes: 0 frames: 0

Interface: myATMintf State: enabled Selector: 0-15

=>

RELATED COMMANDS:

atm bundle ifdelete Remove an interface from a bundle.

TX bytes: 0 frames: 0
RX bytes: 0 frames: 0
RX discarded bytes: 0 discarded frames: 0
Disconnects: 0

34

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm bundle ifconfig

Configure an interface from a bundle.

The interface to be configured must not be connected at the time of configuration. If this should be
the case, use the command :atm bundle ifdetach before using the command :atm bundle

i

ifconfig.

SYNTAX:

atm bundle ifconfig name = <string>

where:

intf = <string>
[state = <{disabled | enabled}>]
[low = <number{0-15}>]
[high = <number{0-15}>]

name The name of the bundle from which an ATM interface must be configured. REQUIRED

intf The name of the ATM interface to be configured. REQUIRED

state Enable or disable the ATM interface.

The default is enabled.

low A number between 0 and 15.

Represents the low selector value.

Note This parameter must only be configured when the policy of the

bundle is set to priority (see “ atm bundle config” on page 29).

high A number between 0 and 15.

Represents the high selector value.

Note This parameter must only be configured when the policy of the

bundle is set to priority (see “ atm bundle config” on page 29).

OPTIONAL

OPTIONAL

OPTIONAL

E-DOC-CTC-20061027-0003 v2.0

35

atm bundle ifdelete

Remove an interface from a bundle.

SYNTAX:

atm bundle ifdelete name = <string>

intf = <string>

where:

name The name of the bundle from which an ATM interface must be removed. REQUIRED

intf The name of the ATM interface to be removed. REQUIRED

EXAMPLE:

ATM Commands

=>atm bundle iflist
Test : dest : (none)

Retry : 10 QoS : default Encaps : llc Fcs : off Ulp : ip
Connection State : not-connected

=>atm bundle ifdelete intf=Test
=>atm bundle iflist

=>

RELATED COMMANDS:

atm bundle ifadd Add an interface on a bundle.

36

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm bundle list

Display the current bundles.

SYNTAX:

atm bundle list

EXAMPLE:

=>atm bundle list
Test : Connection state : not-connected

Retry: 10 Policy: priority

TX requested bytes: 0 requested frames: 0

TX bytes: 0 frames: 0

RX bytes: 0 frames: 0

Interface: Test State: enabled Selector: 0-15

=>

TX bytes: 0 frames: 0
RX bytes: 0 frames: 0
RX discarded bytes: 0 discarded frames: 0
Disconnects: 0

RELATED COMMANDS:

atm bundle add Add a new bundle of interfaces.

atm bundle delete Delete a bundle of interfaces.

E-DOC-CTC-20061027-0003 v2.0

37

ATM Commands

atm cac config

Configure the ATM connection admission control.

SYNTAX:

atm cac config config port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or

number>
state = <{disabled|enabled}>

where:

config
port

state Enable/disable CAC for an ATM port. REQUIRED

The port for which CAC is configured. REQUIRED

EXAMPLE:

{Administrator}=>atm cac config
port = dsl0
state = enabled
:atm cac config port=dsl0 state=enabled
{Administrator}=>

RELATED COMMANDS:

atm cac list Display all the CAC parameters.

atm cac overbooking Configure ATM overbooking parameters.

38

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm cac list

Display all the CAC parameters.

SYNTAX:

atm cac list

EXAMPLE:

{Administrator}[atm cac]=>list
CAC: port: dsl0 state: enabled
CAC: port: dsl1 state: enabled
CAC: port: atm2 state: enabled
CAC: port: aal5 state: disabled
CAC: port: atm5 state: disabled
Overbooking: realtime: 0% non-realtime: 0%.
{Administrator}[atm cac]=>

RELATED COMMANDS:

atm cac config Configure the ATM connection admission control.

atm cac overbooking Configure ATM overbooking parameters.

E-DOC-CTC-20061027-0003 v2.0

39

atm cac overbooking

Configure ATM overbooking parameters.

SYNTAX:

atm cac overbooking rt = <number{0-1000}>

nrt = <number{0-1000}>

where:

ATM Commands

rt A number between 0 and 1000.

nrt A number between 0 and 1000.

EXAMPLE:

{Administrator}[atm cac]=>overbooking rt 20 nrt 500
{Administrator}[atm cac]=>list
CAC: port: dsl0 state: enabled
CAC: port: dsl1 state: enabled
CAC: port: atm2 state: enabled
CAC: port: aal5 state: disabled
CAC: port: atm5 state: disabled
Overbooking: realtime: 20% non-realtime: 500%.
{Administrator}[atm cac]=>

RELATED COMMANDS:

atm cac config Configure the ATM connection admission control.

atm cac list Display all the CAC parameters.

REQUIRED

The realtime overbooking percentage.

REQUIRED

The non-realtime overbooking percentage.

40

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm debug aal5stats

Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics.

SYNTAX:

atm debug aal5stats port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number>

where:

vpi = <number{0-15}>
[vci = <number{0-511}>]
[clear = <{disabled | enabled}>]

port The port number for which statistics will be retrieved.

Choose between:

> DSL0
> DSL1
> ATM 2
> ATM 3
> AAL5
> ATM 5

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the Virtual Path Identifier (VPI) number for which statistics will
be retrieved.

vci A number between 0 and 511.

Represents the Virtual Channel Identifier (VCI) number for which statistics
will be retrieved.

clear Enable or disable clearing of the statistics after request. OPTIONAL

RELATED COMMANDS:

atm debug gstats Display ATM global statistics.

atm debug portstats Display port specific ATM statistics.

REQUIRED

REQUIRED

OPTIONAL

E-DOC-CTC-20061027-0003 v2.0

41

atm debug gstats

Display ATM global statistics.

SYNTAX:

atm debug gstats [clear = <{disabled | enabled}>]

where:

clear Enable or disable clearing of the statistics after request. OPTIONAL

EXAMPLE:

{admin}[atm debug]=>gstats
# of received octets = 1802.
# of transmitted octets = 4346.
# of received cells = 34.
# of transmitted cells = 82.
# of unknown cells = 0.
# of errors on the input = 0.
# of errors on output = 0.
{admin}[atm debug]=>

ATM Commands

RELATED COMMANDS:

atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics.

atm debug portstats Display port specific ATM statistics.

42

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm debug portstats

Display port specific ATM statistics.

SYNTAX:

atm debug portstats port = <{dsl0} or number>

where:

[clear = <{disabled | enabled}>]

port The port number for which statistics will be retrieved.

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

clear Enable or disable clearing of the statistics after request. OPTIONAL

EXAMPLE:

=>atm debug portstats port=dsl0
# of received octets = 1961.
# of transmitted octets = 4717.
# of received cells = 37.
# of transmitted cells = 89.
# of unknown cells = 0.
# of errors on the input = 0.
# of errors on output = 0.
=>

RELATED COMMANDS:

atm debug aal5stats Display ATM Adaptation Layer 5 (AAL5) port specific ATM statistics.

atm debug gstats Display ATM global statistics.

REQUIRED

E-DOC-CTC-20061027-0003 v2.0

43

atm oam config

Modify the ATM Operation and Maintenance (OAM) settings.

SYNTAX:

atm oam config [clp = <number{0-1}>]

[loopbackid = <string>]

where:

ATM Commands

clp A number (0 or 1).

Represents the Cell Loss Priority (CLP) bit value of the OAM cells.
The default is 1.

loopbackid A hexadecimal string.

Represents the loopback ID for processing of segment loopback cells.
The default is 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a.

RELATED COMMANDS:

atm oam list Display the ATM OAM settings.

atm oam modify Modify the ATM OAM data blocking mode.

atm oam ping Send ATM loopback cells.

OPTIONAL

OPTIONAL

44

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm oam list

Display the ATM OAM settings.

SYNTAX:

atm oam list

EXAMPLE:

=>atm oam list

OAM config dump

-------------------

CLP bit value : 1
Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a

OAM data blocking mode

--------------------------

Port dsl0: blocking
Port dsl1: blocking
Port atm2: blocking
Port atm3: blocking
Port aal5: blocking

=>

Port atm5: blocking

RELATED COMMANDS:

atm oam config Modify the ATM Operation and Maintenance (OAM) settings.

atm oam modify Modify the ATM OAM data blocking mode.

atm oam ping Send ATM loopback cells.

E-DOC-CTC-20061027-0003 v2.0

45

atm oam modify

Modify the ATM OAM data blocking mode.

SYNTAX:

atm oam modify port = <{dsl0} or number>

blocking = <{disabled | enabled}>

where:

ATM Commands

port The port for which OAM blocking is configured.

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

blocking Enable or disable the OAM data blocking mode on this port.

The default is enabled.

REQUIRED

REQUIRED

46

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

EXAMPLE:

=>atm oam list

OAM config dump

-------------------

CLP bit value : 1
Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a

OAM data blocking mode

--------------------------

Port dsl0: blocking
Port dsl1: blocking
Port atm2: blocking
Port atm3: blocking
Port aal5: blocking

Port atm5: blocking
=>atm oam modify port=dsl1 blocking=disabled
=>:atm oam list

OAM config dump

-------------------

CLP bit value : 1

Loopback id : 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a 6a

OAM data blocking mode

--------------------------

Port dsl0: blocking

Port dsl1: non blocking

Port atm2: blocking

Port atm3: blocking

Port aal5: blocking

Port atm5: blocking
=>

RELATED COMMANDS:

atm oam config Modify the ATM Operation and Maintenance (OAM) settings.

atm oam list Display the ATM OAM settings.

atm oam ping Send ATM loopback cells.

E-DOC-CTC-20061027-0003 v2.0

47

atm oam ping

Send ATM loopback cells.

SYNTAX:

atm oam ping dest = <string>

[count = <number{1-1000000}>]
[interval = <number{100-1000000}>]

where:

ATM Commands

dest The destination address for the request.

count A number between 1 and 1000000.

interval A number between 100 and 1000000 (milliseconds).

EXAMPLE:

=>atm oam ping dest=atm_ph_8_35 count=10 interval=1000
loopback: successful, sequence: 1 time: 37890 usec
loopback: successful, sequence: 2 time: 39118 usec
loopback: successful, sequence: 3 time: 39116 usec
loopback: successful, sequence: 4 time: 39187 usec
loopback: successful, sequence: 5 time: 38605 usec
loopback: successful, sequence: 6 time: 38764 usec
loopback: successful, sequence: 7 time: 38752 usec
loopback: successful, sequence: 8 time: 38813 usec
loopback: successful, sequence: 9 time: 38848 usec
loopback: successful, sequence: 10 time: 38941 usec

--- loopback statistics --­10 loopbacks transmitted, 10 successful, 0% loss, time 1390 ms
rtt min/avg/max = 37890/38803/39187
=>

REQUIRED

This can be any ATM phonebook entry.

OPTIONAL

Represents the number of pings to send.

OPTIONAL

Represents the interval between packets.

RELATED COMMANDS:

atm oam config Modify the ATM Operation and Maintenance (OAM) settings.

atm oam list Display the ATM OAM settings.

atm oam modify Modify the ATM OAM data blocking mode.

48

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm oam cc list

Display Continuity Check (CC) configuration.

SYNTAX:

atm oam cc list

EXAMPLE:

=>atm oam cclist
PORT = 0 VPI = 15 VCI = 16 End2End Mode = Auto Segment Mode = Auto
PORT = 0 VPI = 0 VCI = 35 End2End Mode = Auto Segment Mode = Auto
PORT = 0 VPI = 8 VCI = 35 End2End Mode = Auto Segment Mode = Auto
PORT = 0 VPI = 0 VCI = 16 End2End Mode = Auto Segment Mode = Auto
=>

RELATED COMMANDS:

atm oam cc modify Modify CC on the connection.

atm oam cc send Send CC activate/deactivate to connection.

E-DOC-CTC-20061027-0003 v2.0

49

ATM Commands

atm oam cc modify

Modify CC on the connection.

SYNTAX:

atm oam modify port = <{dsl0|dsl1|atm2|atm3|aal5|atm5} or number>

vpi = <number{0-15}>
[vci = <number{0-511}>]
[transmit = <{disabled | enabled}>]
[receive = <{disabled | enabled}>]
[auto = <{disabled | enabled}>]
[span = <{segment | end2end}>]

where:

port The ATM port number.

Choose between:

REQUIRED

> DSL0
> DSL1
> ATM 2
> ATM 3
> AAL5
> ATM 5

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the VPI.

vci A number between 0 and 511.

Represents the VCI.

Note For a Virtual Path (VP) cross-connection, use 0 or do not specify.

transmit Enable or disable transmission of CC cells. OPTIONAL

receive Enable or disable loss of continuity. OPTIONAL

auto Enable or disable remote CC activation/deactivation. OPTIONAL

span Select the CC span.

Choose between:

REQUIRED

OPTIONAL

OPTIONAL

> end2end: monitoring occurs on the entire VC between two ATM end

stations.

> segment: monitoring occurs on a VC segment between the Thomson

ST and a first-hop ATM switch.

RELATED COMMANDS:

atm oam cc list Display Continuity Check (CC) configuration.

atm oam cc send Send CC activate/deactivate to connection.

50

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm oam cc send

Send CC activate/deactivate to connection.

SYNTAX:

atm oam cc send port = <{dsl0} or number>

where:

vpi = <number{0-15}>
[vci = <number{0-511}>]
[span = <{segment | end2end}>]
[action = <{activate | deactivate}>]
[direction = <{source | sink | both}>]

port The ATM port number.

Choose between:

> DSL0.

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the VPI.

vci A number between 0 and 511.

Represents the VCI.

Note For a VP cross-connection, use 0 or do not specify.

span Select the CC span.

Choose between:

> end2end: monitoring occurs on the entire VC between two ATM end

stations.

> segment: monitoring occurs on a VC segment between the Thomson

ST and a first-hop ATM switch.

action Activate or deactivate CC.

The default is deactivate.

direction Indicates the direction of CC activity.

Choose between:

> source
> sink
> both.

The default is both.

REQUIRED

REQUIRED

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

RELATED COMMANDS:

atm oam cc list Display Continuity Check (CC) configuration.

atm oam cc modify Modify CC on the connection.

E-DOC-CTC-20061027-0003 v2.0

51

atm oam vclb add

Create a loopback connection for VC.

SYNTAX:

atm oam vclb add port = <{dsl0} or number>

vpi = <number{0-15}>
[vci = <number{0-511}>]

where:

ATM Commands

port The ATM port number.

vpi A number between 0 and 15.

vci A number between 0 and 511.

EXAMPLE:

=>atm oam vclb add port=dsl0 vpi=0 vci=36
=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
=>atm oam vclb add port=dsl1 vpi=0 vci=37
=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
PORT = 1 VPI = 0 VCI = 37
=>

REQUIRED

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

REQUIRED

Represents the VPI.

OPTIONAL

Represents the VCI.

Note For a VP cross-connection, use 0 or do not specify.

RELATED COMMANDS:

atm oam vclb del Delete a loopback connection for VC.

atm oam vclb list List all VC loopback connections.

52

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm oam vclb del

Delete a loopback connection for VC.

SYNTAX:

atm oam vclb del port = <{dsl0} or number>

where:

vpi = <number{0-15}>
[vci = <number{0-511}>]

port The ATM port number.

Choose between:

> DSL0

Or specify a port number (dsl0 has port number 0).

vpi A number between 0 and 15.

Represents the VPI.

vci A number between 0 and 511.

Represents the VCI.

Note For a VP cross-connection, use 0 or do not specify.

EXAMPLE:

=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
PORT = 1 VPI = 0 VCI = 37
=>atm oam vclb del port=dsl1 vpi=0 vci=37
=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
=>

RELATED COMMANDS:

REQUIRED

REQUIRED

OPTIONAL

atm oam vclb add Create a loopback connection for VC.

atm oam vclb list List all VC loopback connections.

E-DOC-CTC-20061027-0003 v2.0

53

atm oam vclb list

List all VC loopback connections.

SYNTAX:

atm oam vclb list

EXAMPLE:

=>atm oam vclb list
PORT = 0 VPI = 0 VCI = 36
PORT = 1 VPI = 0 VCI = 37
=>

ATM Commands

RELATED COMMANDS:

atm oam vclb add Create a loopback connection for VC.

atm oam vclb del Delete a loopback connection for VC.

54

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm phonebook add

Add a new phonebook entry.

SYNTAX:

atm phonebook add name = <string>

where:

addr = <atmchannel : PVC syntax is [port.]vpi.vci

port=dsl0 | ...>

name The name of the new phonebook entry.

addr The ATM address for this destination.

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
=>atm phonebook add name=RtPPPoA addr=8.35
=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>

REQUIRED

This name can be freely chosen, however two limitations apply:

> The name of a phonebook entry intended for the Relayed PPPoA

(PPPoA-to-PPTP Relaying) packet service may not start with capital P or
capital T

> The name of a phonebook entry intended for the PPP-to-DHCP

spoofing packet service must start with DHCP (for example
DHCP_Spoof01).

REQUIRED
It is composed of a VPI and a VCI identifying ATM virtual channels. In most
cases the values are provided by the Service Provider.
Accepted VPI: a number between 0 and 15.
Accepted VCI: a number between 0 and 511.

RELATED COMMANDS:

atm phonebook delete Delete an existing phonebook entry.

atm phonebook list Display the current phonebook.

E-DOC-CTC-20061027-0003 v2.0

55

atm phonebook autolist

Show the auto PVCs.

Auto PVCs are only shown if they are supported by the Central Office DSLAM.

i

SYNTAX:

atm phonebook autolist

EXAMPLE:

=>atm phonebook autolist

8.35
=>

ATM Commands

RELATED COMMANDS:

atm phonebook list Display the current phonebook.

56

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm phonebook delete

Delete an existing phonebook entry.

This command is only applicable for phonebook entries that are not used (in other words, not

i

configured for any packet service).

SYNTAX:

atm phonebook delete name = <string>

where:

name The name of the phonebook entry to be deleted.

Tip Use the command :atm phonebook list to check whether the

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>atm phonebook delete name=RtPPPoA
=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
=>

RELATED COMMANDS:

atm phonebook add Add a new phonebook entry.

atm phonebook list Display the current phonebook.

entry is in use (

Use=1

) or not (

Use=0

REQUIRED

).

E-DOC-CTC-20061027-0003 v2.0

57

atm phonebook flush

Flush all the phonebook entries.

1. Phonebook entries that areinuse,cannotbeflushed.

i

2. This command does not impact previously saved configurations.

SYNTAX:

atm phonebook flush

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>
=>atm phonebook flush
Some phonebook entries are still in use. Entries that are in use cannot be deleted.
=>
=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
=>

ATM Commands

58

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm phonebook list

Display the current phonebook.

SYNTAX:

atm phonebook list

EXAMPLE:

=>atm phonebook list
Name Use Address
atm_pvc_0_35 1 0.35
RtPPPoA 0 8.35
=>

RELATED COMMANDS:

atm phonebook add Add a new phonebook entry.

atm phonebook autolist Show the auto PVCs.

atm phonebook delete Delete an existing phonebook entry.

E-DOC-CTC-20061027-0003 v2.0

59

atm qosbook add

Add a new QoS book entry.

SYNTAX:

atm qosbook add name = <string>

[txctd = <string>]
[rxctd = <string>]

where:

name The name of the new QoS entry. REQUIRED

txctd The name of the Conformance Traffic Descriptor (CTD) for the transmit

(upstream) direction.

rxctd The name of the CTD for the receive (downstream) direction. OPTIONAL

ATM Commands

OPTIONAL

EXAMPLE:

=>atm qosbook list
Name Ref Tx CTD Rx CTD
default 3 default default
=>

RELATED COMMANDS:

atm qosbook delete Delete a QoS book entry.

atm qosbook list Display the QoS book.

60

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm qosbook config

Modify the QoS book configuration.

SYNTAX:

atm qosbook config [format = <{bytes | cells}>]

where:

format The input/output format of the QoS book.

EXAMPLE:

=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
=>atm qosbook config format=cells
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
=>

OPTIONAL
Choose between:

> bytes: the output is shown in Kbits or bytes.
> cells: the output is shown in cps or cells.

The default is bytes.

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

(cps) (cps) (cells) (cps) (cells)

E-DOC-CTC-20061027-0003 v2.0

61

atm qosbook ctdadd

Add a Connection Traffic Descriptor (CTD).

SYNTAX:

atm qosbook ctdadd name = <string>

conformance = <{UBR | CBR | VBR }>
[peakrate = <number{0-27786}>]
[sustrate = <number{0-27786}
[maxburst = <number{0-12240}>]
[realtime = <{enabled | disabled}>]

where:

name The name of the new CTD. REQUIRED

conformance The ATM service conformance definition. REQUIRED

peakrate A number between 0 and 27786.

Represents the peak rate (in kilobits per second).
The default is 0 (indicates linerate for UBR).

sustrate A number between 0 and 27786.

Represents the sustainable rate (in kilobits per second) (VBR only).
The default is 0.

maxburst A number between 48 and 12240.

Represents the maximum burst size (in bytes) (VBR or GFR).
The default is 0.

realtime Enable or disable realtime traffic (VBR only).

The default is disabled.

ATM Commands

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

EXAMPLE:

=>atm qosbook ctdadd name=High conformance=CBR peakrate=27786
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
High 0 CBR 27786 0 0 0 0 0 disabled disab
led
=>

62

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

IMPORTANT NOTE:

The Thomson ST always rounds up specified burst sizes to a multiple of 48 bytes (a multiple of ATM cells).

Example:

In the example below a burst size of 100 bytes is specified (maxburst=100). The Thomson ST will round up
the burst size to the closest matching multiple of 48 bytes, as can be seen when displaying the profile via the
command :atm qosbook ctdlist (burst=144).

=>atm qosbook ctdadd name=Medium conformance=VBR peakrate=27786 sustrate=20000 maxburst=100
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disabled
Medium 0 VBR 27786 20000 144 0 0 0 disabled disabled
=>

RELATED COMMANDS:

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

atm qosbook ctddelete Delete a CTD.

atm qosbook ctdlist Display all CTDs.

E-DOC-CTC-20061027-0003 v2.0

63

atm qosbook ctddelete

Delete a CTD.

SYNTAX:

atm qosbook ctddelete name = <string>

[force = <{disabled | enabled}>]

where:

name The name of the CTD entry to be deleted. REQUIRED

force Enable or disable to force delete the entry even when it is still in use.

The default is disabled.

ATM Commands

OPTIONAL

EXAMPLE:

=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
High 0 CBR 27786 0 0 0 0 0 disabled disab
led
=>atm qosbook ctddelete name=High
=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
=>

RELATED COMMANDS:

atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD).

atm qosbook ctdlist Display all CTDs.

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

64

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm qosbook ctdlist

Display all CTDs.

SYNTAX:

atm qosbook ctdlist

EXAMPLE:

=>atm qosbook ctdlist
Name Ref Conf Peak Sust Burst Minrate Frame Cdvt RT FD

default 2 UBR linerate 0 0 0 0 0 disabled disab
led
High 0 CBR 27786 0 0 0 0 0 disabled disab
led
=>

(Kbits) (Kbits) (bytes) (Kbits) (bytes)

RELATED COMMANDS:

atm qosbook ctdadd Add a Connection Traffic Descriptor (CTD).

atm qosbook ctddelete Delete a CTD.

E-DOC-CTC-20061027-0003 v2.0

65

atm qosbook delete

Delete a QoS book entry.

SYNTAX:

atm qosbook delete name = <string>

[force = <{disabled | enabled}>]

where:

name The name of the QoS book entry to be deleted. REQUIRED

force Enable or disable to force delete the entry even when it is still in use.

The default is disabled.

ATM Commands

OPTIONAL

EXAMPLE:

=>atm qosbook list
Name Ref Type TX peak sust burst RX peak sust burst framediscard

default 3 ubr linerate 0 0 linerate 0 0 disabled
TestVBR 0 vbr-nrt 1500 1000 144 1500 1000 144 enabled
=>atm qosbook delete name=TestVBR
=>atm qosbook list
Name Ref Type TX peak sust burst RX peak sust burst framediscard

default 3 ubr linerate 0 0 linerate 0 0 disabled
=>

RELATED COMMANDS:

atm qosbook add Add a new QoS book entry.

atm qosbook list Display the QoS book.

(Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes)

(Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes)

66

E-DOC-CTC-20061027-0003 v2.0

ATM Commands

atm qosbook flush

Flush all the QoS book entries.

The flush command does not impact previously saved configurations.

i

SYNTAX:

atm qosbook flush

E-DOC-CTC-20061027-0003 v2.0

67

atm qosbook list

Display the QoS book.

SYNTAX:

atm qosbook list

EXAMPLE:

=>atm qosbook list
Name Ref Type TX peak sust burst RX peak sust burst framediscard

default 3 ubr linerate 0 0 linerate 0 0 disabled
TestVBR 0 vbr-nrt 1500 1000 144 1500 1000 144 enabled
=>

ATM Commands

(Kbits) (Kbits) (bytes) (Kbits) (Kbits) (bytes)

RELATED COMMANDS:

atm qosbook add Add a new QoS book entry.

atm qosbook delete Delete a QoS book entry.

68

E-DOC-CTC-20061027-0003 v2.0

AutoPVC Commands

4 AutoPVC Commands

Introduction

This chapter describes the commands of the autopvc command group.

Contents

This chapter covers the following commands:

autopvc config Configure autopvc. 70

autopvc list Show the retrieved information. 72

E-DOC-CTC-20061027-0003 v2.0

69

autopvc config

Configure autopvc.

SYNTAX:

autopvc config [mode = <{pseudo | passive | active}>]

[type = <{bridge | pppoerelay | ipoa | ethoa | pppoa | pppoe
}>]
[overwrite = <{disabled | enabled}>]
[peakrate = <number{0-27786}>]

where:

AutoPVC Commands

mode Select the autopvc mode:

> pseudo: only pseudo-ILMI (VP/VC 15/16) is enabled. When the

connection parameters are written to the MIB, this information is
displayed on CLI or web interface but these parameters are not used
for configuration.

> passive: both ILMI (VP/VC 0/16) and pseudo-ILMI (VP/VC 15/16) are

enabled. When the connection parameters are written to the MIB, this
information is displayed on CLI or web interface but these parameters
are not used for configuration.

> active: both ILMI (VP/VC 0/16) and pseudo-ILMI (VP/VC 15/16) are

enabled. When the connection parameters are written to the MIB,
these parameters are used to configure phonebook entries, qosbook
profiles and bind bridge or PPPoE interfaces on top.

The default is passive.

type Select the type of autopvc.

Choose between:

> bridge
> pppoerelay: an ETHoA interface will be created, will be bound to the

ILMI Permanent Virtual Channel (PVC) and will be added to the PPPoE
relay as relay port.

> ipoa
> ethoa
> pppoa
> pppoe.

overwrit
e

peakrate A number between 0 and 27786.

Enable or disable UBR peak rate overwrite.
The default is disabled.

Represents the UBR peak rate (in kilobits per second).
The default is 0 (indicates the linerate).

OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

70

E-DOC-CTC-20061027-0003 v2.0

AutoPVC Commands

EXAMPLE:

=>autopvc config
Autopvc mode : passive
Autopvc type :
Autopvc standard: unknown
Autopvc pseudo : unknown
UBR overwrite : disabled
UBR peak rate : linerate
=>

E-DOC-CTC-20061027-0003 v2.0

71

autopvc list

Show the retrieved information.

SYNTAX:

autopvc list [table = <{Port | AtmLayer | Vpc | Vcc | Address

| AddressRegistrationAdmin | AtmServiceType
| AtmServiceConnectionInfo | AAL1Profile |
| AAL34Profile | AAL5Profile | AAL2CommonProfile
| AAL2TrunkingProfile | AAL2LESProfile
| AtmServiceConnInfoExtension |
| AtmServiceTypeExtension |

AAL5ProfileExtension}>]

where:

AutoPVC Commands

table Select the autopvc table for which the information must be shown.

Choose between:

> Port
> AtmLayer
> Vpc
> Vcc
> Address
> AddressRegistrationAdmin
> AtmServiceType
> AtmServiceConnectionInfo
> AAL1Profile
> AAL34Profile
> AAL5Profile
> AAL2CommonProfile
> AAL2TrunkingProfile
> AAL2LESProfile
> AtmServiceConnInfoExtension
> AtmServiceTypeExtension
> AAL5ProfileExtension.

OPTIONAL

EXAMPLE:

=>autopvc list
Address Type BestEff Par1 Par2 Par3 Par4 Par5

8.35 ubr Enabled Tx: 451 0 0 0 0

=>

72

Rx: 7923 0 0 0 0

E-DOC-CTC-20061027-0003 v2.0

Config Commands

5 Config Commands

Introduction

This chapter describes the commands of the config command group.

Contents

This chapter covers the following commands:

config delete Delete a user configuration file. 74

config dump Show the saved configuration file. 75

config flush Flush the loaded configuration. 76

config list Show the current configuration set. 77

config load Load complete saved (backup) or default configuration file. 78

config save Store the current configuration in a backup file. 80

E-DOC-CTC-20061027-0003 v2.0

73

config delete

Delete a user configuration file.

SYNTAX:

config delete [filename = <string>]

where:

Config Commands

filename Name of the user configuration file to be deleted.

Note If not specified, all the user configuration files that were saved in

RELATED COMMANDS:

config dump Show the saved configuration file.

OPTIONAL

the Thomson ST permanent storage will be deleted.

74

E-DOC-CTC-20061027-0003 v2.0

Config Commands

config dump

Show the saved configuration file.

SYNTAX:

config dump [sections = <string>]

where:

sections Sections to be dumped OPTIONAL

RELATED COMMANDS:

config delete Delete a user configuration file.

E-DOC-CTC-20061027-0003 v2.0

75

config flush

Flush the loaded configuration.

1. This flush command combines all the possible flush commands.

i

2. This command does not affect saved configurations.

SYNTAX:

config flush [flush_ip = <{enabled | disabled}>]

where:

Config Commands

flush_ip Flush IP settings (enabled) or not (disabled).

The default is enabled.

Note Not keeping the IP settings could cause lost IP connectivity in the

LAN.

OPTIONAL

76

E-DOC-CTC-20061027-0003 v2.0

Config Commands

config list

Show the current configuration set.

SYNTAX:

config list [templates = <{disabled | enabled}>]

where:

templates List the template files (disabled) or not (enabled).

The default is disabled.

RELATED COMMANDS:

config load Load complete saved (backup) or default configuration file.

config save Store the current configuration in a backup file.

OPTIONAL

E-DOC-CTC-20061027-0003 v2.0

77

config load

Load complete saved (backup) or default configuration file.

Use the command :config flush before loading a configuration file.

i

SYNTAX:

config load [load_ip = <{enabled | disabled}>]

[defaults = <{enabled | disabled}>]
[flush = <{enabled | disabled}>]
[echo = <{disabled | enabled}>]
[filename = <string>]

where:

Config Commands

load_ip Load IP settings (enabled) or not (disabled).

Note Not keeping the IP settings could cause lost IP connectivity in the

LAN.

defaults Load default configuration (enabled) or saved configuration (disabled).

Note If not specified, the saved configuration will be loaded.

flush Flush the current configuration before loading a new configuration

(enabled) or not (disabled).

echo Echo each command string when loaded (enabled) or not (disabled). OPTIONAL

filename Name of the configuration file to be loaded. OPTIONAL

OPTIONAL

OPTIONAL

OPTIONAL

78
