D51
User guide
2
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 2
1. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Connecting the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Installing the telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Getting to grips with your telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. CONFIGURING THE BASE'S LINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Line priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Choosing the ringing group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Ringing priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3. USING THE TELEPHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Making an internal call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.3 Receiving a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4 Displaying the duration of the call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.5 Transferring a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.6 Redialling one of the last numbers called (bis) . . . . . . . . . . . . . . . . . . . . . 10
3.7 Mute (cuts off the micro) / put on hold function . . . . . . . . . . . . . . . . . . . . . 10
3.8 Calling from the log of calls (list of the last 50 calls received) . . . . . . . . . . 11
3.9 Shuttling between an external and internal call . . . . . . . . . . . . . . . . . . . . . 11
3.10 3-way conference (2 internal correspondents and 1 external) . . . . . . . . . . 12
3.11 Managing 2 simultaneous external calls on the same telephone . . . . . . . . 12
3.12 Activating / deactivating hands-free mode during a call . . . . . . . . . . . . . . . 13
3.13 Locking the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4. YOUR PHONE BOOK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 Programming the 6 direct memories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Creating a contact page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.3 Using the phone book to make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.4 Modifying a contact page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.5 Deleting a contact page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5. CUSTOMISING YOUR TELEPHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 Adjusting the keytones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Choosing a melody and adjusting the volume . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Emergency number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.4 Naming a telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.5 Selecting the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.6 Changing the telephone's PIN number . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.7 Returning to default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.8 Adjusting the automatic line seizure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6. ASSOCIATING / DISASSOCIATING A TELEPHONE WITH THE BASE . 20
6.1 Associating an extra telephone with the base . . . . . . . . . . . . . . . . . . . . . . 20
6.2 Removing (disassociating) a telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7. BASE SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.1 Dialling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.2 Call barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.3 Setting the flashing time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7.4 Setting the pause time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8. TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10. WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
11. ENVIRONMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12. SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3
The package contains the following items:
- docking station,
- an electrical power supply unit for the docking station,
- a battery unit,
- the user guide.
Please read this guide carefully to get to know the main features of the
.
English
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 3
D51
Telephone keys
Confirm/Intercom key/On/Off
Menu key/
Select key
Direct
memories
Log of
calls key
Phone book
Return/delete/
put on hold key
Recall key
3-way
conference key
Display and associated icons
Battery charge level: flashes when charging
Hands-free activated
Battery full
Direct memories
Recall last
numbers dialled
Increase/decrease
hands-free volume
key
Hands-free key
Line seized when handset picked up
* DECT is a trade mark registered by the ETSI.
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 4
1. INSTALLATION
1.1 PRECAUTIONS
The quality of communication depends on the location and environment of the
base.
Your telephone must be kept away from sources of excessi-
D51
ve heat (radiators, direct sunlight, etc.) and protected against vibrations and
dust. Never allow your telephone to come into contact with water or other
liquids or with aerosols.
To reduce the risk of interference and optimise reception, take particular care
to keep it away from the immediate vicinity of windows, large metal objects,
reinforced concrete, televisions, music centres, halogen lamps or heating devices, fluorescent lighting, burglar alarms, microwave ovens, computers, etc.
To clean your telephone, use a lightly moistened antistatic cloth.
Informative note: your telephone is a DECT™* standard
D51
certified item of equipment. It is meant for transmitting and receiving telephone
calls and for connection to the public switched telephone network.
1.2 CONNECTING THE TELEPHONE
Connect the handset to the telephone.
4
l Connect the power supply cable as indicated at the rear of the base.
l Plug the mains adaptor into a 230 V / 50 Hz electric socket.
1.3 INSTALLING THE TELEPHONE
Charge up the battery unit for the first time
Insert the battery unit in the compartment at the rear of the telephone.
Before using for the first time, we recommend that you leave the telephone to
charge up for 24 hours in order to optimise the performance and longevity of
the battery unit.
The icon flashes during charging.
Seize the line by picking up the handset.
After charging up the battery unit, you can disconnect the mains adaptor.
!
Only use rechargeable batteries with exactly the same specifications as those supplied with the product.
Using non-rechargeable or non-conforming batteries (see the
"Safety" chapter) can damage the product and presents a health
hazard.
Failure to comply with this recommendation will invalidate the
manufacturer's warranty.
The batteries could split or leak if incorrectly inserted, opened or
exposed to heat.
Never dispose of batteries in a fire: risk of explosion.
5
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 5
1.4 GETTING TO GRIPS WITH YOUR TELEPHONE
1.4.1 Navigating through the menus
It's easy to adjust and customise your DECT cordless telephone using the
scrolling menu.
l To access the menu: press the key.
l Press the and keys to find your way to the option you want to
select. The options succeed each other in a loop.
l To validate an option, press .
l To return to the previous menu, press .
l To quit the menu and return to the idle screen, press and hold the
key.
Note: When an option is proposed, the current setting is displayed first.
1.4.2 Telephone On/Off
In idle mode:
l To switch off the telephone (mains adaptor disconnected), press and hold
for at least 2 seconds.
l The display goes out. You can no longer call. The telephone will not ring if
you receive calls.
l To switch on the telephone, press the key (hold it down).
6
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 6
2. CONFIGURING THE BASE'S LINES
(supplied with pack)
You can configure the base's lines according to your requirements.
2.1 LINE PRIORITY
You have the following options for managing the outgoing calls for each telephone:
- Alternative (Line 1 or Line 2): default setting
- Line 1 First: line 1 takes priority and if this line is busy, line 2 will be used
- Line 2 First: line 2 takes priority and if this line is busy, line 1 will be used
- Line 1 Only (line 1): line 1 authorized and no access to line 2
- Line 2 Only (line 2): line 2 authorized and no access to line 1
- No Ext (internal calls only)
This line priority has no effects on the reception of incoming calls.
l Press to enter the menu.
l Select "BS Setting" and press to confirm.
l Enter the "MASTER PIN:" 1590 (by default) and press to confirm.
l Select "Select Line" and press to confirm.
l
Use the and keys to choose the telephone you want from the
list and press to confirm (HS1 = telephone 1).
l Choose the line priority from the 6 options given above and press to
confirm.
2.2 CHOOSING THE RINGING GROUP
Each telephone may receive a call on line 1 and/or line 2.
For example, you may decide that
telephone
s 1, 3 and 5 will be associated
with line 1 and ring on line 1 and that
telephone
s 2 and 4 will be associated
with line 2 and ring on line 2.
l Press to enter the menu.
l Select "BS Setting" and press to confirm.
l Enter the "MASTER PIN:" 1590 (by default) and press to confirm.
7
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 7
D150
l Select "Ring Group" and press to confirm.
l Use the and keys to choose one of the lines and press to
confirm.
l Choose the
telephone
s you want using the keyboard and press to
confirm.
The
telephone
s which are not available will be indicated by an "X".
2.3 RINGING PRIORITY
You can choose the handset that will ring first when an incoming call is received. You can also set the number of rings on the priority
telephone
s before the
others ring.
l Press to enter the menu.
l Select "BS Setting" and press to confirm.
l Enter the "MASTER PIN:" 1590 (by default) and press to confirm.
l Select "Ring Prior" and press to confirm.
l Select "Line 1" or "Line 2" and press to confirm.
l Use the and keys to choose the
number of the
telephone
that should ring
first and press to confirm.
l Now use the and keys to choo-
se the number of rings on the priority
tele-
phone
before the other handsets ring and
press to confirm.
l To cancel the ringing priority for a telephone, select "off" with the and
keys and press to confirm.
8
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 8
HS No. : 2
HS No. : 2
Ring Cnt : 4
3. USING THE TELEPHONE
3.1 MAKING A CALL
Before you make a call, you can see on the screen if lines 1 and 2 are busy.
Direct dialling
l Pick up the handset.
l Dial the number to be called.
l To hang up after finishing a call, place the handset on the base.
Pre-dialling
With the pre-dialling feature you can enter and modify a number before making
the call.
l Dial a number of up to 25 digits.
l Press to correct an input error.
l Pick up the handset to make the call and hang up at the end of the conver-
sation.
Note: You can insert a pause with a long press on .
3.2 MAKING AN INTERNAL CALL
If you have registered more than one
telephone
, you can make internal calls.
l Press .
l Dial the number of the handset you want to
call.
"
You will call your internal correspondent.
3.3 RECEIVING A CALL
!
If you subscribe to your network operator's service, the screen of
your telephone can display the caller's number.
To pick up the call:
l Pick up the handset.
l Press to increase the volume or to decrease it (9 volume
levels).
l To hang up after finishing a call, place the handset on the base.
9
STD51_AU_Ed01.pdf 29/12/04 12:00 Page 9
