Radio
EN
37
Operating the Radio
The receiver has a built-in tuner that allows for FM/MW/LW
radio function.
Manual tuning
1. Connect the FM and AM antenna accordingly (see
"Connecting the Antenna" on page 5 section for details)
2. Press POWER on the main unit.
3. Press SOURCE until tuner mode is selected or press
tuner on the remote control.
4. To select band, press the BAND/APP on the main unit or
tuner button on the remote again to toggle between FM
stereo / FM mono / MW / LW / FM stereo mode.
When an FM station broadcast Stereo sound, ST is
displayed.
5. Tune the stations by pressing TUNING + or - on the
main unit or UP or DOWN arrows on the remote control
repeatedly until the desired station is found.
Alternatively, you can press and hold the respective buttons
for about one second to activate the automatic SEARCH
function. In this mode the receiver will automatically tune
frequencies until it finds a station
6. Repeat steps 5 to tune another radio station.
Select sound effect if needed by pressing SURROUND or
theater mode sound (see "Advance sound section" on
page 15 and 16 for details)
mp3
SOURCE
PRESET - PRESET +
SURROUND
TV
SAT/
CAB
VIDEO/
VCR
ok
POWER
/ ECO
DIGITAL
TREBLE
TUNE - TUNE +
BAND/APP
RPT/PGM
AL
BAND/APP
RPT/PGM
TREBLE
TUNE - TUNE +
TV
SAT/
CAB
VIDEO/
VCR
ok
DIGITAL
PRO.LOGIC
INTRORANDOM
LCR
LS
LFE
RS
DVD
VCD
CD
MP3
NOTE
1. If there is interference, modify the location
of the antenna until the optimal sound is heard.
TV and other electronic devices could be the
cause of interferences so try to position the
antenna away from them.
2. Weak signal can affect the "auto Search
function". Adjust the antenna for better reception for more efficient search.
SURROUND
/
ECO
SOURCE
PRESET - PRESET +
SAT/
CAB
VIDEO/
VCR
ok
SAT/
CAB
VIDEO/
VCR
ok
NOTE
The remote control selector must be set
on hifi.
Radio
38
Storing radio stations:
The receiver can store up to 30 radio stations in memory.
You can enter radio station yourself or the receiver can
store all available radio station automatically in an
ascending order.
Automatic preset storing :
1. Press BAND/APP on the main unit or tuner repeatedly
on the remote control to select the FM band.
2- Press and hold
BAND/APP/RPT/PGM for 3
seconds to start automatic
preset programming.
Radio frequencies will be browsed and radio stations
stored automatically. When all available radio stations are
stored or if all 30 memory locations are full, the auto preset will stop.
Manual preset
1. Select the band by pressing tuner repeatedly
2. Tune to a radio station (see "Manual tuning" on page 37
above for details)
3. Press MEMO on the remote control. "PROG" will appear
on the display
4. While the word "PROG " is still flashing, input your
desired preset number (1-30) using the numeric keys on the
remote control to store the radio station.
Retrieving preset stations
1. Press SOURCE on the unit or tuner on the remote
control to enter tuner mode
2. Press PRESET + or PRESET - on the unit or pr+ or pr -
on the remote control to tune up or down preset channels.
IGITAL
TREBLE
TUNE - TUNE +
BAND/APP
RPT/PGM
NOTE
Weak signal can affect the "Automatic Preset
Storing function" efficiency. Adjust the antenna
for the best reception for more efficient search.
DIGITAL
TREBLE
TUNE - TUNE +
BAND/APP
RPT/PGM
DIGITAL
PRO.LOGIC
INTRORANDOM
LCR
LS
LFE
RS
DVD
VCD
CD
MP3
DIGITAL
PRO.LOGIC
INTRORANDOM
LCR
LS
LFE
RS
DVD
VCD
CD
MP3
SURROUND
m
p
SOURCE
PRESET - PRESET +
SAT/
CAB
VIDEO/
VCR
ok
