Thomson 32LB220B4-U Schematic

W
W

W
W
W
W
W
W

TV

PARTS LIST
LISTE PIECES DETACHEES
ERSATZTEILLISTE

THOMSON

32LB220B4/U

LISTA PARTI DI RICAMBIO
LISTA DE PIEZAS DE REPUESTO

MODULES

MAIN IFC228-LCD 27/32P

POWE SMPS-300

AUDI AUDIO/AMPLI SUBWOOFERW21354320

SCAL SCALER

UHF SUB PIP

PS PS

IR IR

KB KDB

FAV FAV

21399240

21408840

21410230

21350980

21373080

21361960

21361950

21386670

IV100 VSP9407B-VK-C3 FLAT
IV101 TEA6415CD FLAT
IV200 TA1360AFG FLAT
IV202 74HC4538 FLAT
IX002 DS1811R-10 FLAT
IX003 K4D263238F-QC50 FLAT
IX007 M24C32WMN6 FLAT
IX014 AD9883KST-110 A/D FLAT
IX300 RS232 FLAT
IX400 CXA2171AQ FLAT
IX420 74HC123PW
IX430 74HC1G32 FLAT
IX440 74HC4066PW FLAT

10822350
10315540
10804010
10729090
21348350
10872420
35850060
15769370
21380590
10803170
10760570
10766560
10760580

I

FZX002 TE5-T NO 396 3.15A 125V W
GK01 TFMS5330B
IA001 MSP4411K FLAT
IA300 TS482D FLAT
IA301,302 ESDA14V2L
IA500 TEA6422D FLAT
IP001,IT630, LD1117DT33

IX005
IP002,005, LD1117DT18

IX006
IP003 LF90ABDT
IP004 KF80BDT
IP006 LF50CDT FLAT
IP201,202,203, TL431

204,261,271,
303,351,751

IP251,302,310 TCET1103G W
IP300 L6598
IP710 L4981B
IP985 L4973V5.1
IR001 GENCAM CUT2.1U

IR005 M24C64-WMN6 FLAT
IR006 PCF8574TS FLAT
IR040 NCP303LSN30T1
IR110 MT48LC4M16A2TG-75

IS100 MC33079/D FLAT
IS200,500 TDA7490L
IT502,IX410 FSAV330QSC FLAT
IT503 74HC4053 FLAT
IT504,620 M24C02WMN6 FLAT
IT505 74HCT14T/D FLAT
IT600 SII907B FLAT

For any requests, please contact THOMSON multimedia after sales service area
Pour toutes précisions, contactez votre service apres vente local THOMSON multimedia
Für weitere Auskünfte, wenden Sie sich bitte an die THOMSON multimedia Kundendienste
Per precisazioni, contattare l’assistenza tecnica THOMSON multimedia
Para cualquier pregunta, por favor contactar con el responsable de zona del servicio postventa de THOMSON multimedia

No copying, translation, modification on other use authorized. All rights reserved worldwide. • Tous droits de reproduction, de traduction, d'adaptation et d'exécution réservés pour tous les pays. • Sämtliche Urheberrechte an diesen Texten und Zeichnungen stehen uns zu. Nachdrucke,
Vervielfältigungen - auch auszugsweise - nur mit unserer vorherigen Zustimmung zulässig. Alle Rechte vorbehalten. • I diritti di riproduzione, di traduzione, e esecuzione sono riservati per tutti i paesi. • Derechos de reproduccion, de traduccion, de adaptacion y de ejecucion reservados para todos los paises.

VY22497-2 FLAT

(1M*16*4) FLAT

21210090
20627780
21371570
10750860
10765650
10683950
25516290

10802820

10802840
25486130
10750340
15069010

10547560
21285600
10224630
21406140
10820270

55131810
10807130
10735560
10821350

20760680
21344320
21341360
70130000
35096320
15265870
15883700

T

IX009 NTTS2P02R2 SMD
TH001,TR023, BC846B SMD

062,141,145,
147,149,198,
TS203,204,207,
501,503,TT631,

TV107,108,211,
TX001,002,003,

004,005,101,
102,103,124,
161,162,163,
164,184

TP201,202,203, STP22NF03L (TO220)
2534195A

204,302,751

TP205,223 KTC8550D
TP220 STP6NB90FP
TP222,271,303, BC548B

361,407,752,
753

TP321,322 STP14NK50ZFP
TP495 BC558B
TP720 2SK2837 W
TR015,024,061, BC856B SMD

140,144,146,
148,TS208,
TT632,TV100,
101,102,103,
104,105,106,
200,201,202,
TX441,481,483,
485

TS201,202,502, RN1402 (TE85L/R) SMD
504

TT601,602 PMBF170 SMD
TV109,110,111 BC847PN

21348330
16006260

21039270
25460310
16000930

21286780
16001110
21391880
16006310

10966200

15360250
25441670

Chassis IFC228-LCD

D

DH001,DT510, MMSZ33T1 SMD
511,512,513

DP203,381,382 STPS30150CT
DP204,351,352, SB560

386
DP205,206,247, RGP15G

724,DX002
DP225,226,301, RGP10G

323,325,751,

DX003
DP227 ZPD24
DP230,753 BZX55C8V2
DP233 BZX55B15/ZPD15 2%
DP237,273 BAV21
DP240 BZX55C27
DP250,472 BZX55B3V9
DP252,253,254, GP30M

255,743,744

DP260 BZX55C6V2 500MW
DP361 ZPD30
DP371,372,391, BYW98-200 3.0A

392

DP415,416 BZX55C3V3
DP471 ZPD4,7/BZX55C4V7
DP493 BZX55C9V1
DP720 BZX55C20
DP721 STTH8R06FP 600V
DP808 1N4148
DR800,DS201, LL4148 SMD

202,203,204,
205,DV201,202,

DX164
DT001,002, NSAD500H

IT607,608
DT501,502,503, BAV99

504,505
DT506,507,509, MMSZ6V8T1 SMD

602,603,604,
DV100,101,102,
103,104

DT508 BAV70 SMD
DV200 GDZ2.0B 2.1V SMD
DX111,171,403, BAV103 SMD

407
DX112,113,114, ZMM6,8 SMD

115,172,173,174,
175,401,402

DX161 BZX84B8V2 SMD
GE02 1259-7VRVGW LED

VERSION 1 10 / 2004

VERSION 2 00 / 0000

15580650

21286900
20956430

10272800

10459090

44016504
11073660
80444020
44044407
60447870
60447770
10455410

20475410
44016101
15103710

30948790
20475400
90578100
30948810
21392250
44009209
16012450

16100970

16012300

15580490

25469490
25668970
10155030

70439940

25385640
21393660

35863280

1/3

F

QA001 18M432HZ
QR001 8M0HZ
QV100 20M25HZ
QV260 503K5HZ
QX001 14M31818HZ SMD
QX471 4M0HZ

R

RA010,027 4R7 OHM 5% 0,35W W
RK01 5K62 OHM 1% 0,25W
RK02 1K5 OHM 1% 0,25W
RK03 453R0 OHM 1% 0,250W
RK04 3K32 OHM 1% 0,25W
RK05 681R0 OHM 1% 0,25W
RP001,002 13R0 OHM 5% 3W
RP220 0R68 OHM 5% 2,5W
RP225 10M0 OHM 5% 1W W
RP251 470K0 OHM 5% 1W W
RP328 0R1 OHM 5% 3W
RP414,418,462, 3K92 OHM 1% 0,25W

504,554,588,
853

RP415 2K43 OHM 1% 0,25W
RP416,484 2K1 OHM 1% 0,25W
RP483 0R845 OHM 1% 0,25W
RP723 0R27 OHM 5% 3W
RP729,751 4R7 OHM 5% 10W
RP826,827,828, 301K0 OHM 1% 0,25W

832,833,834
RP837 12K7 OHM 1% 0,25W

C

CP215 2N2F 20% 250V W
CP220 1N5F 10% 1K0V
CP226 330P0F 20% 1K0V
CP233 1N0F 10% 500V
CP236 10UF 20% 250V
CP251,253 100N0F 20% 275V W
CP254,255,256 1N5F 10% 1K0V
CP268 2N2F 2K0V
CP321,322 18N3F 3,5% 1K6V W
CP701 470N0F 10% 400V
CP708 470U0F 20% 400V
CP709 150U0F 20% 400V
CP722,727 2N2F 20% 1K0V

S

LP250,251 25M0H W
LP252 15MI0H W
LP253 TFSMTP27-E50 W
LP300 TFSMTP32-E300 W

10334670
21382440
25639490
15315420
21372530
10047890

10226310
15019670
80437630
15018140
15017270
15020310
90572350
20822410
21090250
21185660
30941770
50883690

11060890
60442260
70431190
13085530
21341600
90572040

90571910

21079000
43402900
14035270
10546570
13039480
40404090
20338740
14036020
15870290
10469630
25351800
13050060
43325400

21264970
20973100
21404640
21403130

OTHER PARTS
AUTRES PIECES
SONSTIGE TEILE
ALTRE PARTI
OTRAS PIEZAS

BA200 CINCH SOCKET 4 ASSY W

ENSEMBLE 4 PRISES CINCH
CHINCH 4 BUCHSEN-EINHEIT
ASSIEME 4 PRESA CINCH
CONJUNTO 4 TOMA CINCH

BJ01 CINCH SOCKET

PRISE CINCH
CINCH-BUCHSE
PRESA CINCH
TOMA CINCH

BJ02 SVHS SOCKET

PRISE SVHS
S-VHS-BUCHSE
PRESA SVHS
TOMA SVHS

BQ01 HEADPHONE SOCKET

PRISE CASQUE
KOPFHOERERBUCHSE
PRESA JACK
TOMA JACK

BS003 CINCH SOCKET 3 ASSY

ENSEMBLE 3 PRISES CINCH
CHINCH 3 BUCHSEN-EINHEIT
ASSIEME 3 PRESA CINCH
CONJUNTO 3 TOMA CINCH

BS004 LOUDSPEAKER SOCKET W

PRISE HAUT PARLEUR
LAUTSPRECHERBUCHSE
PRESA ALTOPARLANTE
TOMA ALTAVOZ

BT502 VGA SOCKET

PRISE VGA
VGA-BUCHSE
PRESA VGA
TOMA VGA

BT600 DVI SOCKET

PRISE DVI
DVI-BUCHSE
PRESA DVI
TOMA DVI

BX110 SCART SOCKET W

PRISE PERITEL
EURO-AV-BUCHSE
EUROPRESA NORMALIZZATA
EUROCONECTOR

BX120 DOUBLE SCART SOCKET

PRISE PERITEL DOUBLE
DOPPELT EURO-AV-BUCHSE
EUROPRESA NORMALIZZATA
DOPPIO
EUROCONECTOR DOBLE

BX400 CINCH SOCKET 5 ASSY

ENSEMBLE 5 PRISES CINCH
CHINCH 5 BUCHSEN-EINHEIT
ASSIEME 5 PRESA CINCH
CONJUNTO 5 TOMA CINCH

FP251 2A5T 250V TIME-LAG FUSE W

2A5T 250V FUSIBLE TEMPO.
2A5T 250V SICHERUNG
2A5T 250V FUSIBILE TEMPO.
2A5T 250V FUSIBLE TEMPO.

FZP20,30 500MA 250V FUSE W

500MA 250V FUSIBLE
500MA 250V SICHERUNG
500MA 250V FUSIBILE
500MA 250V FUSIBLE

FZP20,35 1A 250V FUSE W

1A 250V FUSIBLE
1A 250V SICHERUNG
1A 250V FUSIBILE
1A 250V FUSIBLE

21380950

10037440

20392900

40110900

21371970

21362220

15216260

25609410

21356620

25519670

21252340

10246750

21424710

21424720

FZP20,37,39 3A15 250V FUSE W

3A15 250V FUSIBLE
3A15 250V SICHERUNG
3A15 250V FUSIBILE
3A15 250V FUSIBLE

LJ050 CABLE 4X 400MM TYPE C W

CABLE NAPPE 4X 400MM C
FOLIENKABEL 4X 400MM C
CAVO DI COLLEGAMENTO
4X 400MM TYPE C
CABLE 4X 400MM TYPE C

LJ056 CABLE 5X 400MM TYPE C W

CABLE NAPPE 5X 400MM C
FOLIENKABEL 5X 400MM C
CAVO DI COLLEGAMENTO
5X 400MM TYPE C
CABLE 5X 400MM TYPE C

LJ325 CABLE 14X 250MM TYPE C

CABLE NAPPE 14X 250MM C
FOLIENKABEL 14X 250MM C
CAVO DI COLLEGAMENTO
14X 250MM TYPE C
CABLE 14X 250MM TYPE C

LJ700 CABLE WITH CONNECTOR W

30 PINS 250MM
CABLE AVEC CONNECTEUR
30 VOIES 250MM
KABEL MIT VERBINDER
30 PINS 250MM
CAVO CON CONNETTORE
30 SPINOTTI 250MM
CABLE CON CONECTOR
30 PUNTOS 250MM

NH001 FE6233 TUNER

FE6233 TETE
FE6233 TUNER
FE6233 TUNER
FE6233 SINTONIZADOR

NH002 FE6230A TUNER

FE6230A TETE
FE6230A TUNER
FE6230A TUNER
FE6230A SINTONIZADOR

SK01,02,03, MICROSWITCH
04,05,06 MICRO CONTACTEUR

MIKROSCHALTER
MICROINTERRUTTORE
MICROCONTACTOR

SP400 ON/OFF MICROSWITCH

MICRO CONTACTEUR
MARCHE/ARRET
EIN-AUS MIKROSCHALTER
MICROINTERRUTTORE
ACCESO/SPENTO
MICROCONTACTOR
MARCHA/PARADA

SS001 SWITCH SLIDE

COMMUTATEUR A GLISSIERE
KURVENRADSCHALTER
COMMUTATORE
CONMUTADOR DESLIZANTE

21424730

21373310

21373320

21187860

21408830

21301450

21331530

25380930

20935300

1584279A

32LB220B4 2/3

EQUIPMENT/PRESENTATION
EQUIPEMENT/PRESENTATION
AUSSTATTUNG/GEHAEUSE
PARTI VARIE
EQUIPO/PRESENTACION

DISPLAY LCD 32P TX80D16VCOCACW21407450
ECRAN LCD 32P TX80D16VCOCAC
LCD-ANZEIGE 32P TX80D16VCOCAC
VISUALIZZATORE LCD 32P TX80D16VCOCAC
VISUALIZADOR LCD 32P TX80D16VCOCAC

POWER SUPPLY LEAD
CORDON D’ALIMENTATION
NETZKABEL
CAVO DI ALIMENTAZIONE
CABLE DE ALIMENTACION

POWER SUPPLY LEAD UK
CORDON D’ALIMENTATION UK
NETZKABEL UK
CAVO DI ALIMENTAZIONE UK
CABLE DE ALIMENTACION UK

LOUDSPEAKER GRID BOOMER SI01TH
GRILLE HAUT PARLEUR GRAVES SI01TH
LAUTSPRECHER GITTER TIEFTOENER SI01TH
GRIGLIA ALTOPARLANTE INFERIOR SI01TH
REJILLA ALTAVOZ GRAVES SI01TH

FRONT CABINET ASSY BK20TH
FACADE EQUIPEE BK20TH
FRONTPLATTE KPL BK20TH
MOBILE FRONTALE CPL BK20TH
MUEBLE FRONTAL CPL BK20TH

GLASS PROTECTION BK20TH
VITRE DE PROTECTION BK20TH
GLAS SCHULTZ BK20TH
VETRO DI PROTEZIONE BK20TH
CRISTAL DE PROTECCION BK20TH

BASE PLATE OF THE FOOT SI01TH
EMBASE DU PIED SI01TH
FLACHE BASIS OF THE FUSSBALL SI01TH
BASE DI APPOGGIO DEL PIEDE SI01TH
EMBASE DEL PIE SI01TH

STAND FOOT
MONTANT DU PIED
BETRAG DES FUSSES
PIEDE VERTICALE
PIE VERTICAL

TRAP DOOR HIDING PLACE FOOT SI01TH
TRAPPE CACHE PIED SI01TH
FALLTÜR VERSTECKT FUSS SI01TH
PORTELLO DELLA PRESA DEL PIEDE SI01TH
PUERTA DE LA TRAMPA DEL PIE SI01TH

FOOT SUPPORT AXIS
AXE DE SOUTIEN DU PIED
UNTERSTÜTZUNGSACHSE DES FUSSES
ASSE DI SOSTEGNO DEL PIEDE
EJE DE LA AYUDA DEL PIE

CONNEXTION FLAP SI01TH
VOLET PRISES SI01TH
CONNEXTION-KLAPPE SI01TH
SPORTELLO PRESA SI01TH
PUERTA CONECTOR SI01TH

REAR PANEL SI01TH W
DOS SI01TH
RUECKWAND SI01TH
PANNELLO POSTERIORE SI01TH
TAPA POSTERIOR SI01TH

21416840

21384590

25779660

25779690

25779720

25780850

25780260

25782820

25786750

25779560

25779740

INFRARED WINDOW
GLACE INFRAROUGE
INFRAROTFENSTER
VETRO INFRAROSSO
CRISTAL INFRARROJO

LOGO THOMSON SCENIUM CHROME
LOGO THOMSON SCENIUM CHROME
SCHRIFTZUG THOMSON SCENIUM CHROME
MARCHIO THOMSON SCENIUM CHROME
LOGOTIPO THOMSON SCENIUM CHROME

LOUDSPEAKER GRID RIGHT BK25RC
GRILLE HAUT PARLEUR DROITE BK25RC
LAUTSPRECHERGITTER RECHTS BK25RC
GRIGLIA ALTOPARLANTE DESTRO BK25RC
REJILLA ALTAVOZ DERECHO BK25RC

LOUDSPEAKER GRID LEFT BK25RC
GRILLE HAUT PARLEUR GAUCHE BK25RC
LAUTSPRECHERGITTER LINKS BK25RC
GRIGLIA ALTOPARLANTE SINISTRO BK25RC
REJILLA ALTAVOZ IZQUIERDO BK25RC

AUDIO SOCKET TRIM SI01TH
ENJOLIVEUR PRISES AUDIO SI01TH
AUDIO ZERRAHMEN BUCHSE SI01TH
FINIZIONE PRESA AUDIO SI01TH
EMBELLECEDOR TOMA AUDIO SI01TH

SOCKET TRIM SI01TH
ENJOLIVEUR PRISES SI01TH
ZERRAHMEN BUCHSE SI01TH
FINIZIONE PRESA SI01TH
EMBELLECEDOR TOMA SI01TH

SPEAKER KIT
ENS. HAUT PARLEUR
ZUSAMMEN LAUTSPRECHER
INSIEME ALTOPARLANTE
CONJUNTO ALTAVOZ

SPEAKER BOOMER
HAUT PARLEUR BOOMER
LAUTSPRECHER BOOMER
ALTOPARLANTE BOOMER
ALTAVOZ BOOMER

ON/OFF BUTTON SI01TH
TOUCHE MARCHE/ARRET SI01TH
EIN-AUS TASTE SI01TH
TASTO ACCESO/SPENTO SI01TH
TECLA MARCHA/PARADA SI01TH

CONTROL TRIM SI01TH
ENJOLIVEUR DE COMMANDES SI01TH
ZIERRAHMEN BEDIENTEIL SI01TH
FINIZIONE COMMANDI SI01TH
EMBELLECEDOR DE MANDOS SI01TH

BUTTON STRIP 6T SI01TH
BARRETTE DE TOUCHES 6T SI01TH
TASTENLEISTE 6T SI01TH
ASSIEME TASTI 6T SI01TH
CONJUNTO DE TECLAS 6T SI01TH

MAINS SOCKET W
PRISE SECTEUR
NETZANSCHLUSSBUCHSE
PRESA RETE
TOMA RED

ASSY-FAN CABLE 580MM
VENTILATEUR EQ CABLE 580MM
VENTILATOR KPL. KABEL 580MM
BLOCCO VENTOLA CAVO 580MM
MOTOR VENTILADOR CABLE 580MM

RCT615TCLM1 REMOTE CONTROL
RCT615TCLM1 TELECOMMANDE
RCT615TCLM1 FERNBEDIENUNG
RCT615TCLM1 TELECOMANDO
RCT615TCLM1 TELEMANDO

25745580

25591650

25782790

25782810

25764330

25779610

25784940

25764620

25776060

25779630

25740930

2137192B

21423480

21292080

FOLDING BOX
EMBALLAGE CARTON
KARTON
IMBALLAGGIO CARTONE
EMBALAJE CARTON

PLASTIC PACKING
ENVELOPPE PLASTIQUE
KUNSTSTOFF-VERPACKUNG
IMBALLAGGIO PLASTICO
EMBALAJE PLÁSTICO

FITTING LEFT
CALE GAUCHE
POLSTER LINKS
DISTANZIATORE SINISTRA
CALZO IZQUIERDA

FITTING RIGHT
CALE DROITE
POLSTER RECHTS
DISTANZIATORE DESTRA
CALZO DERECHA

M

32LB220B4/U PARTS LIST
32LB220B4/U LISTE DE PIECES DETACHEES
32LB220B4/U ERSATZTEILLISTE
32LB220B4/U LISTA PARTI DI RICAMBIO
32LB220B4/U LISTA DE PIEZAS DE REPUESTO

IFC228-LCD SERVICE MANUAL
IFC228-LCD DOC TECHNIQUE
IFC228-LCD TECHNISCHE DOKUMENTATION
IFC228-LCD DOCUMENTAZIONE TECNICA
IFC228-LCD DOCUMENTACION TECNICA

23/27/32LB220B4/S4 UM TH
23/27/32LB220B4/S4 NU TH
23/27/32LB220B4/S4 BA TH
23/27/32LB220B4/S4 IU TH
23/27/32LB220B4/S4 IU TH

25770490

25750420

25764750

25764760

35863280

35851340

25769390

32LB220B4 3/3

The description and characteristics given here are of informative significance only, and non committal. To keep up the high quality of our products, we reserve the right to
make any changes or improvement without previous notice. • Les descriptions et caractéristiques figurant sur ce document sont données à titre d'information et non
d'engagement. En effet, soucieux de la qualité de nos produits, nous nous réservons le droit d'effectuer, sans préavis, toute modification ou amélioration. • Die
Beschreibungen und Daten in dieser Anleitung dienen nur zur Information und sind nicht bindend. Um die Qualität unserer Produkte ständig zu verbessern, behalten wir uns
das Recht auf Änderungen vor. • Le descrizioni e le caratteristiche date su questo documento sono fornite a semplice titolo informativo e senza impegno. Ci riserviamo il
diritto di eseguire, senza preavviso, qualsiasi modifica o miglioramento. • Las descripciones y características que figuran en este documento se dan a título de información
y no de compromiso. En efecto, en bien de la calidad de nuestros productos, nos reservamos el derecho de efectuar, sin previo aviso, cualquier modificación o mejora.

THOMSON multimedia Sales Europe - S.A. au capital de 30 000 000 €- Siège : 46, Quai Alphonse Le Gallo 92100 Boulogne FRANCE - RCS NANTERRE B 322 019 464

Television

TECHNICAL INFORMATION

Chassis IFC228 (PLASMA - LCD)

Section :

Power supply

H_Deflection circuit

V_Deflection circuit

HF-IF circuit

Input / Output - Scart

Mechanical

Control panel

Data processing

Audio processing

Video processing

Picture Tube - Display

General

Television

TECHNICAL INFORMATION

Chassis IFC228 (PLASMA - LCD)

Power supply

Symptom description

LCD & PLASMA

Whistle of the power supply in stand-by mode.

LCD

Whistle of the power supply.
Black screen.
Some components are broken on the power supply.
Humming Noise.

PLASMA

Humming Noise.

Television

TECHNICAL INFORMATION

Chassis IFC228 (PLASMA - LCD)

Data processing

Symptom description

PLASMA - LCD

Wrong identification of display mode types in VGA input.
Wrong identification of display mode types in DVI input.

Television

TECHNICAL INFORMATION

Chassis IFC228 (PLASMA - LCD)

Audio processing

Symptom description

LCD

Humming noise in sound (excepted when the mute is on).

Television

TECHNICAL INFORMATION

Chassis IFC228 (PLASMA - LCD)

Video processing

Symptom description

LCD - PLASMA

Compatibility Improvement of the set to the HDCP norm.
Intermittently, absence of one of the primary colors (RVB) or black screen.

PLASMA

Improvements of the video adjustments (PAL/SECAM/RGB/YUV1H/YUV2H).

Television

TECHNICAL INFORMATION

Chassis IFC228 (PLASMA - LCD)

General

Symptom description

LCD

Color change.
Fan noise.

AUDIO BOARD - PLATINE AUDIO - AUDIO GRUNDPLATTE - PIASTRA AUDIO - PLATINA AUDIO

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI
LADO COMPONENTES

SOLDER SIDE - COT

É

CUIVRE - LÖTSEITE - LATO SALDATURE - LADO DEL COBRE

IFC228-LCD

First issue 04 / 05

Y

W

R

SCH FAV IFC228

VIDEO

AGND

AGND

RJ03
82R0

CJ02

220P0

1

2

3

4

5

6

BJ04

4K7

RJ02

CJ01

220P0

R

L

RJ01
4K7

JJ01

1

2

3

4

5

6

BJ01

5

4

1

2

3

BJ02

GND

GND

GND

GND

CROMA

GND

KDB IFC228

KDB IFC228

RK01

2

SK01

1

BQ01

HP JACK

5K62

RK02

SK02

MENU

RQ01

3
2

1

4R7

RQ02

4R7

SCH KDB IFC228

1
2

GND

2

1

3
4

POWER

BK01=>BR002

1K5

RK03

453R0

2

CH-

1

SK03

2

CH+

1

RK04

SK04

2

1

3K32

VOL-

RK05

SK05

2

VOL+

1

681R0

SK06

GND

SK01
PLAY

1

*SCH KDB DVD IFC228

SK02

EJECT

1

SK03

FWD

1

SK04
STOP

1

SK05

REV

1

GND

4

3V3_UP

CQ01

1N0

CQ02

BQ02=>BA300

1

2

1N0

3

AGND

* some models

RK01
5K62

2

RK02

1K5

2

RK03

453R0

2

RK04
3K35

2

RK05

681R0

2

GND

1

2

3

BK03

ADC-IN_1

PUSH SWITCH

GK01A

GK01

TSOP1333TB1

GND

OUT

1

3

2

VS

CK01

10N0

SCH IR IFC228

GND

GND

RK06

1K0

RK07

100R0

CK02

22U0

GNDGND

RK08

GE01

LV5433

1K8

SCH KDB/IR

PUSH SWITCH IFC228

FAV IFC228

GND

JK02

LU5351

JK01

1

2

3

4

5

BK02=>BR001

GE02

GND

IR

5V

LED_G

LED_R

IFC228-LCD

First issue 04 / 05

CUIVRE - LÖTSEITE - LATO SALDATURE - LADO DEL COBRE

É

SOLDER SIDE - COT

LADO COMPONENTES

KDB DVD

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI

KDB DVD

RJ01

CJ01

RJ02

CJ02

KEYBOARD CIRCUIT BOARDS - CIRCUITS IMPRIMES PLATINES COMMANDES - LEITERPLATTE BEDIENTEIL - PIASTRE TASTIERA - PLATINAS MANDOS

CUIVRE - LÖTSEITE - LATO SALDATURE - LADO DEL COBRE

É

SOLDER SIDE - COT

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI

LADO COMPONENTES

FAV IFC228

BJ01

BJ04

BARECODE

21415290

1

RJ03

PCB FAV IFC228

RJ04

IFC228-LCD

First issue 04 / 05

JJ01

BJ02

1

AUDIO 2

AUDIO 2

AUDIO 2

AV1_L_IN

AV1_R_IN

AV2_L_IN

AV2_R_IN

FCB/AV3_L_IN

FCB/AV3_R_IN

COMP1_L_IN

COMP1_R_IN

AV1_R_OUT

22U0

CA252

220R0

RA250

LA250

R_OUT_AV1

AV_IN

47K0

RA251

CA251

CA250

470P0

1N0

GND

GND

RA252

GND

AV1_L_OUT

22U0

CA255

220R0

LA251

L_OUT_AV1

47K0

RA253

CA254

470P0

CA253

CA271

RA271

CA270

330P0

47K

220P0

DVI_L_IN

GND GND GND

LA272

RA272

300

CA273

RA273

4K7

220P0

123

330P0

47K

CA272

Red

VGA_L_IN

GND

GND

4K7

RA280

GND

300

LA281

5

GND

4

6

7

8

BA200

Red

Whi

Whi

CA281

RA281

CA280

330P0

47K

220P0

VGA_R_IN

GND

GND

GND

LA282

RA282

300

CA283

RA283

4K7

CA282

330P0

GNDGNDGND

47K

220P0

18may04

47K0

RA261

CA261

470P0

1N0

CA260

AV2_L_OUT

22U0

CA265

GND

GND

220R0LA261

RA262

GND

L_OUT_AV2

RA263

CA263

AV2_R_OUT

22U0

CA262

GND

220R0

RA260

GND GND

1N0

LA260

R_OUT_AV2

47K0

CA264

1N0

470P0

GND

GND

GND

DVI_R_IN

RA270

300

LA271

4K7

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

4K7

RA200

LA200

L_IN_AV1

AV_IN

300

RA201

47K0

220P0

CA201

220P0

CA200

GND

GND

4K7

RA202

GND

LA201

R_IN_AV1

AUDIO 1

2135261B

IFC228 MAIN E

0

RA224

0

RA225

RA232

LA231

L_IN_FCB

220P0

RA233

47K0

4K7

CA232

300 CA233

220P0

GND

GND

GND

4K7

RA240

300

LA240

R_IN_COMP1

CA241

RA241

CA240

47K

330P0

220P0

GNDGND

GND

RA242

CA243

RA243

4K7

CA242

LA241

300

L_IN_COMP1

330P0

47K

220P0

220P0

CA231

RA231

47K0

220P0

CA230

GND

GND

GND

47K0

GND

GND

GND

RA222

LA221

4K7

300

R_IN_AV3

RA223

CA223

220P0

CA222

220P0

GND

GNDGND

RA230

LA230

4K7

300

R_IN_FCB

47K0

GND

GND

GND

RA220

4K7

LA220

L_IN_AV3

300

RA221

CA221

CA220

220P0

220P0

RA213

RA203

47K0

220P0

CA203

220P0

CA202

300

GND

GND

GND

4K7

RA210

LA210

L_IN_AV2

47K0

RA211

CA211

220P0

CA210

220P0

300

GND

GND

RA212

GND

4K7

300

LA211

R_IN_AV2

CA213

CA212

47K0

220P0

220P0

0B/S

GND

GND

GND

VIDEO SW

IFC228-LCD

First issue 04 / 05

VP/ADC

LY005

10UH

3V3_IO

CY021

CY010

CY023

100N

100UF

100N

CY016

NC7

NC1

DQ8

DQ7

DATA7

DATA8

VDDQ7

VSSQ2

DQ9

DQ6

DATA9

DQ10

DQ5

1011121314

DATA5

DATA10

VSSQ7

VDDQ2

9

DQ11

DQ4

DATA12

DATA11

DQ12

DQ3

DATA3

3V3_A

VDDQ8

VSSQ1

DATA13

DQ13

DQ2

DATA1

DATA14

DQ14

VDDQ1

DQ1

VSSQ8

2345678

DQ15

DQ0

DATA15

VSS4

VDD1

1

DATA0

CY015

CY012

CY018

100UF

CY013

100N

CY011

100N

16V

10UF

100UF

CY014

CY017

CY019

100N

10UH

LY008

10UH

LY007

100N

16V

10UH

LY006

100N

GND

GND

16V

3V3

SDRAM_

100N

ADDR3

DQM

DATA31

DATA30

DATA29

DATA28

DATA27

DATA26

DATA25

CY022

100N

CY020

100N

16V

DATA24

44454647484950515253545556575859606162

VSS1

DQ24

DQ25

DQ26

DQ27

DQ28

DQ29

VDDQ5

VSSQ6

DQ30

VSSQ5

DQ31

VDDQ6

ADDR5

ADDR4

63

A3A4A5

A6

NC4

VSS2

DQM3

CLKIN

470R

RY035

ADDR9

ADDR8

ADDR7

ADDR6

CKE

6465666768697071727374757677787980818283848586

A7A8A9

CKE

CLK

NC5

NC6

VSS3

DQM1

IY002

RASCSNC2

BA0

BA1

A10

DQM0

VDD2WECAS

1920212223

161517

18

DQM

WEN

CASN

RASN

CSN

BA0

RY025

100R

VDDQ3

DQ19

DQ20

VSSQ4

DQ21

DQ22

VDDQ4

DQ23

VDD4

MT48LC2M32B1

DATA18

DATA19

DATA20

DATA21

DATA22

DATA23

DQ17

DQ18

3334353637383940414243

DATA17

VSSQ3

DATA16

DQ16

A1

DQM2A2VDD3

NC3

A0

24

26282729303132

25

BA1

ADDR10

ADDR0

ADDR1

ADDR2

DQM

SINGLE NET

10UH

LY001

0R

RY050

VHS_CSYNC
VVS

RY005

(16/20/24bit output)

100N

CY036

3V3_DAC

CY037

100N

100N

CY038

CY003

16V

10UF

CY002

16V

10UF

0

16V

CY001

10UF

HDFL

RY006

33R

RY004

33R

33R

5
6
7
8

RY003

RY007

5
6
7
8

5
6
7
8

RY002

RY001

RY027

RY033

RY034

RY022

RY039

RY032

10K

10K

RY023

10K

10K

10K

0R

RY020

10K

RY021

RY038

0R

RY037

470R

IIC_CL_2

470R

RY036

IIC_DA_2

123

5V_STBY

470R

SOFT_RESET

GND

RY047

BY001

4

0R

0R

RY046

GENCAM 1

(OPTION)FLI 2300 VIDEO PROCESSOR

IFC228 MAIN EU

RASN

CASN

BA1

BA0

CSN

DQM

VDFL

0R

RY051

5

4
6
7
8

1

33R

4

1

4

1

4

1

4

5
6
7

33R

8

1

4

5
6
7

33R

8

1

4

5
6
7

33R

8

1

0R

4K7

RY028

GND

100N

CY033

CY034

100N

CY035

1V8_CORE

10UH

LY002

CY032

100N

CY009

100N

100UF

SDRAM_CLK

SDRAM_CLKIN

1V8_PLL

GND

16V

LY003

100UF

CY008

105
106
107
108
109
110
111
112
113
114
115
116
117

CTLOUT0

118

CTLOUT1

119
120

CTLOUT4

CLK_OUT
VID_OUT16
VID_OUT17

VID_OUT18
VID_OUT19
VID_OUT20
VID_OUT21
VID_OUT22
VID_OUT23
VID_OUT8
VID_OUT9

VID_OUT10
VID_OUT11
VID_OUT12
VID_OUT13
VID_OUT14
VID_OUT15

VID_OUT0
VID_OUT1
VID_OUT2
VID_OUT3
VID_OUT4
VID_OUT5
VID_OUT6
VID_OUT7
OE

100N

CY028

100N

CY030

CY004

10UH

16V

121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156

CY029

CY031

10UF

GND

100N

100N

16V

LY004

10UH

WEN

ADDR0

ADDR1

ADDR2

ADDR3

ADDR4

ADDR5

ADDR6

ADDR7

ADDR8

ADDR9

ADDR10

DATA31

DATA30

DATA29

DATA28

DATA27

DATA26

DATA25

DATA24

DATA23

DATA22

DATA21

DATA20

DATA19

DATA18

DATA17

DATA16

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

DATA7

DATA6

DATA5

DATA4

99

98

102

104

103

101

100

IY001

FLI 2300

FAROUJA

158

159

157

160

161

169

168

167

166

164

165

163

162

CY006

10UF

100N

CY027

GND

1V8_DAC

170

171

16V

CY026

100N

16V

10UF

CY005

DAC_GOUT

DAC_BOUT

0R

0R

RY040

RY041

173

172

175

174

DAC_ROUT

RY042

180

179

178

177

176

0R

CY007

RY011

47R

RY010

RY009

10UF

47R

185

184

183

182

181

16V

100N

CY025

47R

CY024

186

CY040

CY039

100N

193

192

191

190

189

188

187

XTAL_IN

XTAL_OUT

1M

RY013

Z

33P

13.5MH

QY001

33P

180R

RY014

8R2

RY015

202

203

204

205

206

201

200

199

198

197

196

195

194

1M

RY012

RY043

656IO_0

D1DATA0

8

33R

1

656IO_1

D1DATA2

D1DATA1

656IO_3

656IO_2

D1DATA4

DIDATA3
5

8

4

1

656IO_4

D1DATA6

D1DATA5

656IO_6

656IO_5

D1DATA7

5

4

656IO_7

DATA3

535455565758596061626364656667686970717273747576777879808182838485868788899091929394959697

207

RY044

208

D1_CLK
8

33R

1

52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2

1

D1_VSYNC

D1FID

CLKOUT

D1_HSYNC

5

RY045

4

656VIO

656HIO

33R

RY024

RY030

VSP

10K

DATA2
DATA1
DATA0

10K

RY031

RY029

3V3_IO

10K

10K

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

3V3_UC

1V8_UC

U_BB

Y_GG

V_RR

VP/ADC

IFC228-LCD

First issue 04 / 05

6V

IN

IT630

OUT

LD1117DT33

+3.3V_DVI

GENCAM 1

CT693

220N

330NH

3K3

CT644

10NF

100PF

RT621

10UF

CT647

CT646

GND

16V

10UF

100NF

LT641

16V

330NH

LT642

330NH

RT637

LT643

LT644

CT654

143R

GND

100NF

CT624

GND

CT691

220UF

10V220N

RT635

TT632

RT632

LT611

CT692

100K

BC856B

300R

LT613

CT607

330NH

300R

330NH

100NF

RT633

LT614

LT612

RT631

GND

330NH

330NH

RT634

300R

CT642

RT636

470R

47UF

1M

TT631

100NF
CT604

16V

BC846B

PRE

DVI_DETECT

GND

33K

RT604

CT643

CT645

CT618

10UF

100NF

CT619

CT620

100PF

231

PB0

PB1

VSS

330NH

100PF

CT623

CT625
100PF

CT650

10UF

16V

GND

DVI_B

DVI_G

VGA

DVI_R

VIDEO SW

100NF

CT649

100PF

CT648

0R

IOB

RX2-

5

4

303132

COMP

AGND_2

GND

680NH

29

RSET

RX1+

0R

RT058

RT059

GND

22PF

CT636

LT623

22PF

CT633

75R

RT628

25

26

27

28

IOG

DACVCCG

DACGNDR

DACGNDG

IT600

SII907B

AVCC_1

RX1-

RX0-

RX0+

1234567

52

6

8

5

7

3

1

2

4

IT608

NSAD500H

DACVCCR

AGND_1

RT651

GND

CT653

10UF

16V

100PF

CT651

100NF

CT652

16V

10UF

CT656

GND

100NF

CT655

33

SCLM

34

35

36

37

38

39

40

41

42

43

44

45

46

10UF 16V

GND

DACGNDB

DACGND

SDAM

DACVCC

RESERVED

RESETN

SCDT

DVCC_2

ODCK

DGND_2

DE

GND_3

VCC_3

AGND_3

4748495051

10R

RT650

IT607

NSAD500H

DACVCCB

RX2+

6

8

7

3

1

2

RT057

LT622

222324

IOR

RXC+

10R

0R

CT635

20506520

680NH

22PF

CT632

75R

RT627

21

VCC_2

RXC-

100PF

CT614

22PF

GND_2

AVCC_2

100PF

DVI_B

GND

PD_DAC

VSYNC

HSYNC

DVCC_1

DGND_1

SCLS

SDAS

VCC_1

GND_1

PD

PGND_1

PVCC_1
EXT_RES

CT613

DVI_G

680NH

20

19

18

17

16

15

14

13

12

11

10

9

8

LT621

DVI_R

CT621

RT611

100NCT612

CT634

CT631

RT626

100PF

412R0

22PF

22PF

75R

CT61110UF

33K

RT610

GND

DVI_HSYNC

DVI_VSYNC

100PF

CT626

0R

470R

CT617

CT615

RT056

RT041

100PF

10UF

DVI_VSYNC

100PF

CT622

100NF

CT616

16V

VGA

DVI_HSYNC

0R

RT055

RT622

470R

IFC228 MAIN EU

DIGITAL VISUAL INTERFACE (DVI)

33K

RT609

GND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

4

123

4K7

RT603

7

5

8

6

DT604

+3.3V_DVI

+5V_DVI

IT620

M24CO2-WMN6

MMSZ6V8T1

GND

GND

MMSZ6V8T1

DT602

100NF

MODE /

SDA

SCL

WC

VCC

65847

DT603

MMSZ6V8T1

GND

RT602

RT612

12K

LT601

RT613

330NH

100R

WC

GND

RT614

0R

(to BT501)

100R

RT601

100R

RX1-

RX2+

RX2-

1234567891011121314151617181920212223

DVI_SCL

GND

RX1+

DVI_SDA

+5V

GND

GND

HTPLUG

RX0-

RX0+

CT602

100NF

0

CT608

GND

GND

TXC-

TXC+

24

S

BT600

100R

100R

RT606

RT605

G

PMBF170

G

S

D

TT602

PMBF170

IFC228-LCD

First issue 04 / 05

D

TT601

GM_BUSY

GM_INTERRUPT

IIC_DA_4
IIC_CL_4

IIC_DA_2

IIC_CL_2

GENCAM 1

WE_ROM#

3V3_STBY

IR_OUT

RESET#

AQR_ON

5V_ON_CHECK

UART_IN

UART_OUT

GENCAM 1

0R

JR140

4K7

RR203

39P

CR154

5V_STBY

SAFETY_ENABLE

DVI_DETECT (US)

100R

39P

RR902

39P

CR193

CR155

100R

RR900

100R

RR901

100R

RR903

39P

39P
CR195

CR194

(to 1501)

1

2

3

4

0R

JR800

GND

39P

CR197

39P

CR196

5

6

39P

47N

CR150

CR049

6

5

4

3

2

1

11

10

9

8

7

6

5

4

3

2

1

BV900

BR007

JTAG

(M)

DEBUG

BR006

0R

JR801

3D_FRAME(US)
IIC_DA_2

IIC_CL_2

MASTER_MUTE#

AUDIO_STBY_MUTE#

RESET_AUDIO#

IIC_DA_2

IIC_CL_2

SAFETY_INT

480_ON(US)

FB_OSD

B_OSD

G_OSD

R_OSD

EFC

FW_ADJUST

TUBE_DETECTION

BSVM_BLANK

PO_TR

G2_ADJUST

VDFL

HDFL

INT_DMU

RESET_DMU#

IIC_DA_4

IIC_CL_4

IIC_DA_3

IIC_CL_3

IIC_DA_2

IIC_CL_2

IIC_DA_1

IIC_CL_1

SAFETY_ENABLE

JTIN

JTOUT

JTCLK

JTSEL

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

VIDEO SW TUNER DVI VP/ADC AUDIO 2 COMB

RR023

5V_STBY

1K

RR024

100R

TR024

LED_TOPLIGHT

100R

RR021

TR023

560P

CR024

BC856B

BC846B

DVI_DETECT

IIC_DA_2

IIC_CL_2

3V3_STBY

DVD_KEY

DC_DC_ON#

EXT_ON#

CVBS_TXT_S

IIC_DA_4

IIC_CL_4

IIC_DA_2

IIC_CL_2

RR028

1K

RR022

100R

RR402

RR400

SYNC_ENABLE

RESTART_LED

CVBS_TXT_M

RESTART_LED

2K2

100R

RR029

100R

RR027

100R

RR030

BR001

RESET#

VOLTAGE REGULATOR

1K5

RR015

3V3_STBY

5V_V

5V_STBY

CR065

CR008

47N

0R

JR025

RR025

330R

LED

IR

5V_STBY

GND

12345

TOPLIGHT

56R

47N

RR026

BR200

1

2

LED#

453R

RR017

150R

RR009

RR401

JR010

PO

TR015

10K

56R

0R

1V8_STBY

3V3_STBY

5V_STBY

5V_V

DEGAUSS

AQR_ON

BC856B

0R

JR017

BR002

KEYBOARD

INF_POW_FAIL

ECO_STANDBY#

IR

KEYBOARD

POWER_SWITCH

3V3_STBY

POWER
4

5V_STBY

FRONT-END

IFC228 MAIN EU

1K5

RR117

3V3_STBY

CR006

10N

1%

1K5

CR007

RR005

47N

CR009

39P

CR057

123

KEYBOARD

4K7

RR370

CR370

TR370

BC856B

HDFL

JR080 0R

10N

123456789

(M)

BR005

100P

VDFL

IR_UC

0R

JR081

RR051

IR

CR163

CR164

39P

RR369

1K

39P

10K

to Wired-IR

IRDA_IN

0RJR050

100P

CR365

IIC_DA_4

JR051 0R

RR361

IIC_CL_4

0RJR052

JR053 0R

FE-BOX

TR365

RR365

470R

220R

RR360

BR360

IR

IRDA_OUT

BC846B

1K

5V_STBY

10

RR362

123

RR366

CR362

DR362DR360

CR360

220R

CR161

CR162

CR058

CR185

2K2

39P

ZMM6.8

39P

ZMM6.8

39P

39P

39P

47N

IFC228-LCD

First issue 04 / 05

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

DVI_L_IN

DVI_R_IN

From page 11

RIN_EXT

CA516

1U0

CA500

COMP2_R_IN

From page 1

1N0

CA514

100K0

RA502

1U0

CA515

LIN_EXT

From page 11

1U0

1U0

CA506

1U0

CA501

COMP1_R_IN

BA001

VIDEO_OUT

GND

GND

CA507

1N0

100K0

RA505

1U0

CA502

SW_DETECT

AV1_R_OUT

RA6020RA601

GND

GND

0

JA505

VGA_R_IN

1011121314

PG

RA007

CA080

4U7

JA507

16

17

R6

18

R5

19

R4

20

NC

21

NC

22

R3

23

R2

24

25

26

27

28

JA503

JA500

JA501

RA500

RA501

From page 1

5V_V

SUBWOOFER

CA006

RA506

100R0

AV1_L_OUT

0

0

1U0

CA513

ROUT2

LOUT3

ROUT3

IA500

ADDR

SCL

SDA

0

0

0

JA502

47R0

47R0

GND

MAIN_LEFT

MAIN_RIGHT

1N0

3K3

0

JA001

470P0

CA015

JA504

LOUT2

ROUT1

LOUT1

L6

L5

L4

NC

NC

L3

TEA6422D

L2

L1 R1

VS

CAPA

GND

0

1U0

CA503

L/R_MUTE

SUB_MUTE

GND

100R0

RA006

4U7

CA081

RA009

GND

0

CA522

14 15

13

12

11

10

9

8

7

6

5

4

3

2

1

GND

1U0

CA504

COMP1_L_IN

123456789

AUDIO_STBY

MASTER_MUTE#

1N0

CA005

3K3

RA507

0

JA002

AV2_L_OUT

100R0

0

JA506

1U0

COMP2_L_IN

VGA_L_IN

9V

470P0

CA008

1U0

CA505

IIC_CL_2

RA005

CA518

CA519

CA520

CA521

GND

100R0

CA016

470P0

47UF

100N0

47UF

100N0

IIC_DA_2

1U0

CA517

1N0

CA004

3K3

RA508

4U7

CA082

AV2_R_OUT

GND

GND

GND GND GND GND

RA017

470R0

15U0

LA003

15U0

LA002

470R0

RA015

RA008

0

JA003

470P0

CA007

100R0

RA002

RESET_AUDIO# 47R0

From page 13

L

R

(M)

123

BA300

IA301

ESDA14V2L

GND

LA001

GND

RA012

10U0

CA017

CA018

RA016

8V

1U0

100R0

1U0

RA018

47R0

RA010

!

RA013

47R0

CA009

4R7

1K0

220N0

GND

CA010

100N0

CA019

CA001

GND

CA002

RA302

GND

180P0

47P0

47P0

18K0

RA301

CA011

GND

RA304

100K0

1N0

RA014

GND

GND

GND

300R0

LA301

300R0

LA300

GND

RA303

10K0

CA303

220U0

8

2

3K9

RA300

4U7

CA300

RA004

100R0

RA011

1K0

100R

1

100R0

10U0

CA014

CA020

GND

3

180P0

10U0

4

CA052

CA012

IA300

TS482D

GND

10U0

CA302

1N0

GND

GND

10U0

CA013

GND

1U0

CA025

100R

RA309

220U0

CA305

7

8

5

6

3K9

RA305

4U7

CA304

GND

100R0

RA003

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

GND

1K0

RA019

CA021

FCB/AV3_L_IN

4

CA051

47P0

1N0

GND

10K0

RA308

GND

100K0

RA306

DACA_R
DACA_L

I2S_DA_IN4

VREF2

DACM_R

DACM_L

DACM_C

DACM_SUB

DACM_SR

DACM_SL

SC2_OUT_R

SC2_OUT_L

VREF1

SC1_OUT_R

SC1_OUT_L

CAPL_A

AHVSUP

CAPL_M

SC3_OUT_L

SC3_OUT_R

414243

1K0

RA020

GND

1U0

CA026

FCB/AV3_R_IN

IA302

GND

RA307

CA307

CA306

5V_V

GND

I2S_DA_IN3

AHVSS1

44

CA024

CA022

ESDA14V2L

18K0

GND

100N0

GND

10U0

15K0

1N0

RESETQ

I2S_CL3

I2S_WS3

AHVSS2

AGNDC

NC3

4546474849

4U7

CA023

GND

47P0

GND

From page 1

23

24

25

26

27

28

29

30

31

32

33

RA001

CA003

NC2

SC4_IN_L

100N0

RA021

1U0

CA027

I2S_DA_IN2

SC4_IN_R

1K0

AV2_L_IN

GND

NC22

NC23

NC24

NC25

NC26

NC27

NC28

NC29

NC30

NC31

NC32

DVSS3

ASG1

RA022

22

NC21

RESETQ

34

GND

DVSS2

SC3_IN_L

50

1K0

AV2_R_IN

21

20

NC19

NC20

DVSS

TEST

36

35

CA401

100N0

CA400

DVSS1

DVSUP3

IA001

MSP44XYK

ASG2

SC3_IN_R

CA030

1U0

CA028

19

NC18

DVSUPWSCL

373839

47UF

DVSUP2

SC2_IN_L

535251

47P0

47P0

CA029

NC17

IA400

545556

RA023

CA031

NC14

NC15

NC16

MAD48XYA

DA_IN

40

41

RA401

I2S_DEL_CL

I2S_DEL_WS

I2S_DEL_OUT

SC2_IN_R

ASG3

SC1_IN_L

57

GND

1K0

1K0

RA024

GND

GND

1U0

AV1_L_IN

AV1_R_IN

IFC228 MAIN EU

IFC228 AUDIO MSP°

12

13

1415161718

NC11

NC12

NC13

NC10

NC9

NC8

NC7

NC6

NC5

NC4

NC3

NC2

NC1

NC

SDA

DA_OUT

ADR_SEL

SCL

43

44

42

15K0

4

6789101112131415161718192021222324

I2S_CL

I2C_DA

I2S_WSS

I2S_DEL_IN

I2S_DA_IN1

I2S_DA_OUT

AVSS1

SC5_IN_R

VREFTOP

SC5_IN_L

SC1_IN_R

CA035

100N0

GND

CA033

CA032

47P0

1U0

CA036

10U0

47P0

605859

CA038

CA034

CA037

AVSS

62

61

GND

RA025

1N0

GND

GND

1U0

AM_AF

11

10

9

8

7

6

5

4

3

2

1

RA402

253

I2C_CL

NC4

63

1K0

SIF

15K0

1

NC1

NC5

64

some models°

GND

STANDBYQ

80

ADR_SEL

79

D_CTR_I/O_0

78

D_CTR_I/O_1

77

SPDIF_OUT

76

NC

75

AUD_CL_OUT

74

TP

73

XTAL_OUT

72

XTAL_IN

71

TESTEN

70

ANA_IN2+

69

ANA_IN-

68

ANA_IN1+

67

AVSUP

66

AVSUP1

65

LA006

!

4R7

RA027

10U0

LA004

From page 8

CA039

0

5V_V

QA001

100P0

18M432

CA043

CA042

9V

LA007

CA040

100N0

220UF

CA046

220N0
CA041

100P0

RA026

0

GND

CA047

3P3

47P0

CA045

10N0

CA044

1K0

GND

GND

10V

GND

8V

From page 10

CA050

100N0

GND

CA049

1N0

GND

100U0

CA048

GND

GND

3P3

GND

GND

GND

10U0

LA005

IFC228-LCD

First issue 04 / 05

CT541

22UF

BT001

IIC_DA1

10

IIC_CL1

9

IIC_DA2

8

IIC_CL2

7

6

IIC_CL3

5

IIC_DA4

4

3

2

FACTORY TEST-PORT

GND

1

RED

RT507

150R

RT517

150R

100N

CT504

RT516

4K7

RAIN

4K7

RT527

IIC_DA3

Y/CVBS

BAV99L

DT501

CT542

22UF

GNDGND

DT002

NSAD500H

5
6
7
8

5
6
7
8

NSAD500H

DT001

VGA-RGB

1617

BT502

DB15HD_V

CT505

4K7

RT528

100N

GREEN

617

GND

RT508

150R

150R

RT519

RT518

4K7

GAIN

BAV99L

DT502

68R

RT002

RT001

CSDA

HSYNC

121314

2

3

BAV99L

DT503

GENCAM 1

4
3
2
1

4
3
2
1

0R

RT003

68R

0R

CSCL

VSYNC

15

4118

9

5

10

VGA_GND

BLUE

RT509

150R

150R

RT520

100N

4K7

RT521

4K7

RT529

RT004

IIC_DA_1

IIC_CL_1

IIC_DA_2

IIC_CL_2

IIC_DA_3

IIC_CL_3

IIC_DA_4IIC_CL4

IIC_CL_4

RT523

DT506

10R

DT507

100R

RT510

MMSZ6V8T1

VGA_GND

VGAWC

VGA_GND

IFC228 MAIN EU

VIDEO GRAPHIC ADAPTOR (VGA)

0R

JT503

DT512

33V

RT531

RT530

ZMM33

VGA_GND

47R

47R

33V

DT513

ZMM33

VGA_GND

101112

DT510

141

ZMM33

DT511

33V

13

ZMM33

33V

IT505

74HCT14T/D

234569

RT525

1K

1K

RT526

78

Y/CVBS_FACTORY

AV IN

10R

RT524

100R

RT505

100R

RT504

(TX)

(RX)

GND

DT505

BAV99L

3

RT515

3K3

2

3K3

3

IT504

BAV99L

DT504

CT503

100N

CVCK

8

VCC

24LC21A

PRE

123

VGA_GND

VGA_SCL

VGA_GND

MODE/WC

PB0

SCL

PB1

VGA_SDA

567

SDA

VSS

4

VGA_GND

RT512

0R

MMSZ6V8T1

VGA_GND

2

(4.5V)

G5V

CT543

22UF

CT506

BAIN

DT509

BAV70L

DT508

MMSZ6V8T1

RT514

RT513

3K3

VGA_GND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

GENCAM 1

IIC_CL_3

IIC_DA_3

VGASEL

DVI

DVIVSYNC

DVIHSYNC

CT501

100N

5V_V

1V8_UC

DVIB

DVIR

DVIG

IT502

16

FSAV330

VGASEL

CT544

10UF

VGA_GND

HDCBIN

BAIN

MBLU

14

15

OE_

21345

RAIN

HDCRIN

MRED

CT507

BT501 =>BX003

910111213

B3

Y3

7

8

6

HDYIN

GAIN

MGRNG_OUT

1UF

CT509

CT508

1UF

VGA_GND

R_OUT

VGA_GND

VGA_GND

B_OUT

12345678910111213

DVI_VSYNC

V_OUT

5V_V

VGA_VIN

10911

121314

15

16

VCC

IT503

74HC4053

BYBXCY

1234567

B-COM

A-COM

VGA_HIN

AY

C-COMCXINH

H_OUT

A

AX

DVI_HSYNC

B

100N

CT502

VE E

GND C

100N

CT529

7

VGA_GND

1UF

GND

RX

V_OUT

H_OUT

WC

IIC_CL_3

IIC_DA_3

TX

WC

(to IT620)

14

JT501

VGA_GNDGND

0R

0R

JT502

IFC228-LCD

First issue 04 / 05

1234567

0R

JV800

GND

CV232

100NF

22K0

470R0

RV267

LL42

RV263

DV202

2K2

16

RV262

4R7

CV264

21345

1K

RV260

6K8

RV265

IV202

74HC4538

2K2

RV259

1N

CV261

1N

100R

RV268

CV266

4K7

+9V

BV201

8

(to AD9883A)

(T#20368970)

100NF

CV258

47UF

CV259

10UH

LV203

0R

0R

RV244

RV243

CV228

9V

10P

10P

CV229

1360_GND

RV264

1N

CV263

3_GND

16V

1K

RV258

RV266

LL42

3_GND

DV201

1N

15PF

CV262

100NF

CV265

9101112131415

7

8

6

BC846B

TV211

2K2

RV261

VIDEO PROCESSOR/ADC (VP/ADC)

1K5

IFC228 MAIN EU

TV210

BC856B

+9VA

RV238

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

CV200

RV206

100NF

1K5

RV207

9V

10UH

LV273

10V

220UF

CV231

+9VA

RV209

RV278

RV276

CV208

CV206

BC856B

TV200

0R

JV006

CV201

100NF

BC856B

TV201

0R

JV005

100NF

CV271

RV203

RV200

2_GND

2P2

470R0

0R0

V_R

CV274

JV004

8P2

0R

RV204

RV201

CV202

LV271

2U2H

470R0

0R0

U_B

1K5

1K5

RV208

8P2

CV275

2P2

2U2H

LV270

CV276

U_BB

V_RR

Y_GG

FLI

CV230

1K

100K

TV202

100NF

RV279

100K

470NF

100NF

100K

TV203

RV277

BC856B

LV272

RV205

RV202

BC856B

CV209

1K

CV281

2U2H

470R0

0R0

Y_G

1UF

CV282

3K3

16V

2U2F

RV280

CV234

470N

CV235

6362616059585756555453

64

NC

Y2H

100R0

RV211

65
66

2U2F

CV273

2_GND

8P2

67
68
69
70
71
72
73
74
75
76
77
78
79
80

16V

RV219

9V

RV218

CV205

100NF

100NF

CV203

2P2

CV272

RV228

VSP

16V

1UF

1UF

CV207

VUC
UUC
YUC

NC

NC
NC

NC

VSM

YS1

0R

220R

CV204

100NF

CR2H

VIDEO SW

0R

YC GND

BPHFIL

APLFIL

YC VCC

CB2H

1360_GND

CV213 100NF

Y2H

RV269

GND

LADET FILTER

YS3NCG S/H

YS2

123467589

0R

10NF

CV233

NC

PB2H

PR2H

COLOR LIM

R S/HNCB S/H

CV210 10NF

1_GND

0R

RV303

GND

0R

RV240

NC

NC

HFSW1

VSM FILTER

IV200

TA1360

1K INNCRGBGNDNCROUT

10

11

CV212 10NF

CV211 10NF

2_GND

GND

1UF

CV270

NC

NC

VDIN

HDIN

SYNC IN

GOUT

BOUTNCRGB_VCCNCNCNCRIN

OSD_RIN

RV217

3_GND

0R

RV304

GND

444546484749505152

NC

DEF VCC

OSD_GIN

0R

0R

RV305

434241

NC

HVCO

AFC FILTER

OSD_BIN

2221201918171615141312

23

10NF

3K3

RV270

SW2

24

CV214

RV220

1360_D_GND

1360_GND

503K5
QV260

CV217

CV225

CV224

RV230

10NF

CV218

GENCAM 1

100R

10NF

CV223

CV221

10NF

1360_D_GND

DV200

GDZ2.0V

10P

100NF

CV222

10PF

CV220

10PF

100R

RV229

CV219

10NF

B_OSD

R_OSD

G_OSD

FB_OSD

IIC_CL_2

IIC_DA_2

VIDEO SW

HDFL

RV226

RV227

LV232

LV231

100R0

100R0

VDFL

100NF

CV227

470R

RV271

40

HCURVE

39

FBPIN

38

DEF GND

37

HOUT
NC

36

VOUT

35
34

NC

33

NC

32

VDD

31

SCL

30

NC

29

SDA

28

GND

27

BIN

26

GIN

25

1UF

1UF

CV216

1UF

CV215

0R

2U2H

2U2H

RV231

RV235

RV232

CV236

RV237

1K5

1K5

RV234

JV001

470R

470R

470R

0R

JV002

2P2

CV240

LV230

0R

JV003

1_GND

470R

RV239

8P2

CV237

TV209

BC856B

0R

470R

RV236

2P2

8P2

CV241

TV208

BC856B

470R

RV233

8P2

CV239

2U2H

2P2

CV238

IFC228-LCD

First issue 04 / 05

4

3

2

1

(to BH003)

BH001B

GND_TUNER

1

2

3

4

5

6

7

8

9

10

11

to conn BH001(sub-Tuner Bd.)

12

13

RH012

0R

BH001A

RH016

RH051

91R

12R

16V

100UF

CH016

22N0

CH015

2K2

CH011

1N0

10UH

LH005

CH014

22N0

CH012

33P0

33P0

CH013

RH015

10U0

120P

LH006

LH051

3U3H

CH051

0R

JH001

GND_TUNER

0R

JH002

GND_TUNER

GND

RH014

100R0

TUNER

100R0

RH013

IFC228 MAIN EU

GND_TUNER

120P

CH050

LH050

3U3H

[RESET]

[+3V3]

+5V-IF

FM-IF

VIDEO

(MAIN-TUNER)

GND

SIF
o/p

AUDIO
FM-SW

RF-cable to NH002(Slave Tuner)

NC

IF

+33V

NH001

NC

+5V-T

21301450

FMinput

(int)

+5V-T

SDA

SCL

AS

AGC

US:NH001-FE6243/splitter(21301460),NH002-FE6240(21254230)

EU:NH001-FE6233/splitter(21301450),NH002-FE6230(21254210)

FE6243

CH021

9

8

7

6

5

4

3

2

1

1N0

CH010

10U0

RH050

RH017

1N0

CH001

12R

10UH

RH001

CH020

91R

LH002

1N0

LH004

22N0

CH005

10U0

LH003

1K0

RH003

1N0

CH003

CH009

33P0

0R

CH008

22N0

CH004

CH007

100UF

16V

10U0

LH001

47UF

16V

47UF

20

19

18

17

16

15

14

13

12

11

10

CH002

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

CH017

16V

33P0

100UF

CH006

16V

100UF

TH001

330P0

AM_AF

BC846B

33VCC

RH009

5V_V

SIF

47R0

2K7

AUDIO 2

RH011

1K5

RH010

IIC_CL_2

IIC_DA_2

GENCAM 1

123

BH002

GND

SIF

AF_OUT

[RESET]

20

[+3V3]

19

+5V-IF

18

FM-IF

17

VIDEO

16

FE6240

PIP-TUNER,REV05

GND

15

SIF

14

o/p
AUDIO

13

FM-SW

12

NC

11

IF

10

+33V

9

NC

8

+5V-T

7

+5V-T

6

US:NH001-FE6243/splitter(21301460),NH002-FE6240(21254230)

EU:NH001-FE6233/splitter(21301450),NH002-FE6230(21254210)

SDA

5

SCL

4

AS

NH002

3

FMinput

2

(int)

1

AGC

BH003

123

4

GND

GND

SCH 2T PIP IFC228

BH001

1

2

3

4

5

6

7

8

9

10

11

12

13

GND

to Main board

IFC228-LCD

First issue 04 / 05

VSP

CVBS_IFS

CVBS_IFM

180R0

RH007

16V

0R

RH008

RH006

6K8

CH018

RH005

100R0

100R0

RH004

DH001

ZMM33

33V

50V

1UF

CH019

GND_TUNER

GENCAM 1

9V_1H

EU_US_02

EU_US_03

EU_US_01

AV2_PIN8

Y/CVBS_FACTORY

AV1_PIN8

DVD_KEY

IIC_DA_1

IIC_CL_1

IIC_CL_2

CVBS_TXT_M

IIC_DA_2

CVBS_TXT_S

IIC_DA_4

IIC_CL_4

EXT_ON#

DC_DC_ON#

RESTART_LED

CVBS_IFS

CVBS_IFM

CVBS/Y_M

C_M/FRC

CHROMA_M

FRAME_CV

Y_M/FRC

SYNC_ENABLE

VDFL

HDFL

CR2H

9V

5V_V8V5V_FE

3V3_STBY

Y2H

5V_STBY

CB2H

GND

VSP

5V_STBY

AV_PIN8_OUT

100NCX161

VOLTAGE REGULATOR

RX141

9V_1H

3U3

LX223

RX222

1%

RX524

237R

120Z

LX221

123

BX130=>BJ104

FCB_CVBS/Y

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

AV_LINK

TEA_GND

20V

0R

22P

CX221

1%

237R

165R

RX221

165R

RX528

GND_V

RX162

10135010

RX561

6K8

RX109

33K

RX108

13K7

RX107

RX560

13K7

TEA_GND

1%

1%

456

FCB_CHR

R_IN_FCB

FCB

1%825R

RX161

6K8

AV1_PIN8

10K

220R

RX144

1K8

RX142

3U3

LX224

237R 1%

RX525

LX222

120Z

GND

AGND

AV2_PIN8

10K

RX165

TX161

L_IN_FCB

RX163

BC846B

TX101

RX103

BC856B

TX143

RX224

R_IN_FCB

L_IN_FCB

100K

TX162

TX103

BC846B

8K2

TEA_GND

CX144

CX143

CX222

237R

RX223

165R

RX529

BC846B

BC846B

TX142

47UF

100N

22P

1%

1%

165R

1%

DX164

RX164

DX101

BC846B

16V

RX166

LL4148

47K

DX103

ZMM6.8

2K7

RX104

RX146

RX143

AUDI 0

560R

RX167

100K

LX161

LL4148

TEA_GND

TX102

RX105

1%590R

TEA_GND

JX112

AUDIO 1

BX120

AV3

10K

1U5

RX145

TX141

TX163

RX110

BC846B

15K

CX101

390R

BC856B

0R

BC846B

DX161

22K

DX102

100P

TEA_GNDTEA_GND

RX526

L_IN_AV3

R_IN_AV3

22

R_IN_AV3

BC846B

TX164

82P

CX162

BZX84B8V2

ZMM6.8

12K0

RX106

6K8

RX102

1%

237R

LX133

120Z

GND

AUDIO-GND

RX151

CX151 RX153

RX134

237R

RX133

1%

BLUE-GND

TEA_GND

220R

1K8

100N

1%

165R

L_IN_AV3

AV3/F_CVBS/Y_IN

AV3/F_CHROMA_IN

TX153

BC856B

0R

JX111

1%

165R

RX530

10R

RX124

BC846B

TX152

TEA_GND

1%

237R

RX527

LX131

120Z

30292827262524

31

GREEN-GND

9V_1H

RX125

CX124

1%

RX155

590R

560R

RX152

RX132

RED-GND

100R

CX125

237R

RX131

RX531

TX124

BC846B

100N

16V

47UF

1%

165R

165R

TEA_GND

RGB-GND

390R

RX154

BC856B

TX151

1%

1%

Chroma

AV2_CVBS/Y_IN

1K5

RX127

1K

RX126

TEA_GND

TEA_GND

GND

DX111

JX1100RJX109

CVBS_IN

SYNC/CVBS-GND

SYNC/CVBS-GND

RX116

RX537

DX113

ZMM6.8

BAV103

TEA_GND

0R

42

4123403938373635343332

SHIELD-GND

TEA_GND

100R

100R

RX539

ZMM6.8

GND

GND

AV1

AV1_CVBS/Y_IN

CVBS_AV2_OUT

10K

RX123

CX114

100R

RX540

100R

RX117

100R

DX114

DX112

ZMM6.8

DX115

ZMM6.8

AUDIO 1

R_IN_AV1

R_OUT_AV1

2

R_IN_AV1

L_OUT_AV1

R_OUT_AV1

CVBS_AV1_OUT

18P0

100R

RX118

JX108

L_IN_AV1

L_OUT_AV1

5123461

BLUE-GND

AUDIO-GND

9V_1H

TEA_GND

100R

RX119

100R

RX538

RX115

150R

RX536

150R

0R

RX114

150R

RX535
150R

1011131214151617181920

9

8

7

Blue

SBLK

DATA

Green

L_IN_AV1

GREEN-GND

AV1_R/C

CX113

RX120

RX541

0R

JX105

RX113

150R
RX534
150R

GND

SPARE

AV1_G

18P0

18P0

470R

470R

RX121

RX544

RX543

JX106

0R

RED-GND

RGB-GND

AV1_B

18P0

CX115

CX112

10R

33R

33R

VSP_GND

Red/Chroma

AV1_FB

VSP_GND

TEA_GND

CX111

47R

RX122

47R

RX542

FBLK

SYNC/CVBS-GND

SYNC/CVBS-GND

10R

RX183

18P

JX107

RX112

150R

RX533

150R

RX111
150R

RX532
150R

CVBS_IN

CVBS_OUT

9V_1H

0R

JX104

0R

21

SHIELD-GND

CX184

CX183

GND

BX110

100R

RX184

1K5

RX186

TEA_GND

TEA_GND

RX185

1K

TX184

100N

47UF

BC846B

16V

IFC228 MAIN EU

AUDIO VIDEO INPUT (AV IN)

ZMM6.8

DX175

ZMM6.8

DX174

DX173

DX172

ZMM6.8 ZMM6.8

GND

DX171

BAV103

47R

47R

RX169

RX546

0R

RX231

47R

RX168

47R

RX545

L_IN_AV2

L_OUT_AV2

R_IN_AV2

R_OUT_AV2

TEA_GND

GND

GND

GND

1

AUDIO 1

AV2

R_OUT_AV2

3456789

R_IN

AUDIO-GND

L_OUT_AV2

AV2_B/CB

0RRX191

RX552

100R

RX176 100R

L_IN

BLUE-GND

AV2_G/Y

0RRX193

RX192 10K

RX554

RX553

100R

100R

100RRX177

RX178 100R

101112131415161718

Blue

SBLK

DATA

GREEN-GND

AV2_R/CR

RX194 0R

RX555100R

100RRX179

Green

SPARE

AV2_FB/H

0RRX195

RX556

33R

470R

RX558

RX180 470R

RX175

150R

RX551

150R

RX174
150R

RX550

150R

RED-GND

RGB-GND

RX559

RX557

47R

33R

RX182

10R

RX181

FBLK

Red/Chroma

V_EXT

CVBS_EXT

47R

RX548

150R

150R

RX172

RX171

150R

150R

RX547

0R

JX103

VSP_GND

19220

CVBS_OUT

SYNC/CVBS-GND

SYNC/CVBS-GND

CX175

CX174

CX173CX172

CX171

CVBS_IN

HDD_CVBS

Y_FACTORY

18P0 18P0

18P0

18P018P0

VSP_GND

0R

RX549

150R

RX173

150R

JX100

JX102

21

SHIELD-GND

VSP_GND

0R

RX232

JX101

0R

0R

BX120

AV2_FB/H

AV2_B/CB

AV2_G/Y

AV2_R/CR

AV2R

AV2G

AV2B

AV2FB

VIDEO SW

VGA

Y/CVBS_FACTORY

VSP_GND

GND

IFC228-LCD

First issue 04 / 05

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE
SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE
ESQUEMA DE LA PLATINA PRINCIPAL

(FAN SUPPLY)

BP203

1

2

IP203

KF80BDT

OUT IN

GND

2
CP203
100UF

16V

RP203

0R

GND_PS

13

(stand

off-Bd)

RP001

RP002

6R8 2W

2W6R8

CP001

100UF
16V

IP001

LD1117DT33

OUTIN

1

GND

CP012

220N

JP001

0R

IP002

LD1117DT18C

33

OUTIN

CP013

1
220N
16V

JP002

0R

GND_B

IP006

LF50CDT

2

CP002

100U

16V

GND_A

GND

OUTIN

GND

IP003

CP009

220N

16V

JP005

0R

IP004

KF80BDT

2

JP006

0R

GND_F

LF90ABDT

OUTIN

GND

10VCC

CP004
100U
16V

23

CP011

220N

CP010

220N

16V

CP003
100U

CP014

220N

16V

16V

31

CP028
100U

16V

2

GND_E

31

OUTIN

GND

CP006
100U

16V

31

CP007

220N

16V

CP005

220UF
10V

CP008

220N

16V

9V

8V

3V3_UC

1V8_UC

6V

5V_V

BP001

6V

1

2

10V

3

4

5

6

20V

7

33V

8

5V_STBY

9

10

3V3_STBY

GND_PS

1

2

PO

3

INF_POW_FAIL

4

5

ECO_STBY#

6

DVD_ON

7

AQR

8

GND_PS

RP016

47K

RP015

47K

JP003

0R

GND_C

IP005

LD1117DT18C

CP016

220N

TO252

16V

JP004

0R

GND_D

CP015
220N

16V

1

OUTIN

GND

23

CP018
100U

16V

PO

INF_POW_FAIL

ECO_STANDBY#

AQR

CP017

220N

16V

20V(EU)

33VCC

5V_STBY

3V3_STBY

1V8_STBY

GND_A

GND_B

GND_C

GND_D

GND_E

GND_F

JP007

0R

JP008

0R

JP009

0R

JP010

0R

JP011

0R

JP012

0R

GND

IFC228 MAIN EU

VOLTAGE REGULATOR

BP002

CP023

10N
50V

IFC228-LCD

First issue 04 / 05

CP025

10N

50V

GND_PS

CP024

10N

50V

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

VOLTAGE REGULATOR AV IN

RX474

1K

470N

BC846B

GND

HDFL

11

8

4

1

H_EXT

RX496

VCC

16

IX430

74HC1G32

0R

5V_FE

CXA_GND

470N

CXA_GND

14

CX495

470R

CX

100N

13

15

IC-STD
5

123

BX423

RX494

RCX

1

14

7

HV_GND

RX495

820R

4

&

4

HV_GND

5V_FEE

6

NC

RX301

5V_FE

15K

R

321

5V_FE

RX435

220R

RX463

IIC_4_DA

VSP

0R

RX498

IX440

HV_GND

CX

6

RX493

RX440

RX430 RX439

150R

CXA_GND

GND

GND

0R

RX302

4K7

12

10

6

9

5

3

13

2

74HC4066PW

CX493

150P

5

12

RCX

&

9

7

10

84K5

RX497

CX494

0R

1K

TX432

0R

100R

CXA_GND

RX521

150R

RX421

CXA_GND

150R

RX419

1UF

RX465

CX469

1N

CX468

TX431

BC856B

NC

IIC_4_CL

HV_GND

R

11

100N

CX445

BC856B

150R

220K

100N

RX523

150R

RX519

RX422

12345

NC

VOUT

GND

8

IX420

74HC123PW

470P

CX492

HV_GND

150R

0R

HOUT

HV_GND

HV_GND

HV_GND

CXA_GND

D

CXA_GN

CXA_GND

CXA_GND

150R

RX434

150R

RX420

CXA_GND

CX431

100P

VIDEO SWITCH

IFC228 MAIN EU

36

25

24

37

SONY

CXA2151Q

(topview)

1

48

13

12

DVI_VSYNC

DVI_HSYNC

150R

RX522

DVI_G

DVI_B

150R

RX520

DVI_R

DVI

SYNC_ENABLE

IIC_DA_2

IIC_CL_2
RGB_CMP_SEL

GND

DC_DC_ON#

IIC_DA_4

IIC_CL_4

DVD_KEY
3V3_STBY

GENCAM 1

IFC228-LCD

First issue 04 / 05

COMB

E

CX444

PR2

RX950

VCC1A

68K1

100R

RX459

CX456 1UF

470N

RX512

220K

RX443

CX408

47R

RX408

47R

RX600

PB2

1CEXT

1REXT/CEXT

1B

1RD

2

3

150R

RX447

470N

CX429

0R

131415

4

8V_FE

5V_FE

1Q

1Q

RX414

CX414

CX412

RX412

RX602

47P

12

567

5V_F

CXA_GND

RX448

150R

470N

470N

47R

RX410

47R

RX601

RX507

11

2Q

2Q

CX481

RX481

RX475

RX476

CX479

0R

CX410

47R

47R

150R

100P

2RD

2CEXT

100N

1K

RX431

0R

10K

22P

150R

RX511

CX415

470N

RX425

CX951

10

2B

2REXT/CEXT

0R

CX413

470N

RX515

150R

9

8

CVBS_EXT

V_EXT

AV2_CMP_R

AV2_FB/H

AV2_B/CB

AV2_G/Y

AV2_R/CR

CXA_GND

100N

CX461

5V_FE

CXA_GND

16

IX410

FSAV330

21345

5V_FE

180K

RX616

180K

RX617

1UF

CX451

AV2R

AV2G

AV2B

AV2FB

Y_FACTORY

8V_FE

CX464

CX462

0R

RX461

10UH

LX461

8V

5V_V

DX407

BAV103

DX403

BAV103

470N

CX406

CX405

47R

RX406

RX503

150R

47R

RX500

RX405

150R

RX403

150R

RX504

150R

RX505
150R

RX401
150R

CXA_GND

Pr

Pb

Y

132

DEV

BLUE

GREEN

CMP1

7

6

180K

RX614

1UF

CX454

180K

RX615

82K

82K

RX611

RX610

1UF

CX453

5V_FE

10N

10N

CX463

100N

CX467

47UF

16V

47UF

CX465

0R

10UH

LX462

RX462

DX401

DX402

ZMM6.8

ZMM6.8

1UF 16V

470N

CX404

47R

CX402

RX404

CXA_GND

47R

RX501

RX402

RX502

0R

JX405

5

748

6

RED

WHITE_A

COMP1_L

GND

RED_A

COMP1_R

9101112131415

8

CX466

16V

47R

47R

BX400

CXA_GND

RX613

RX612

CX455

CXA_GND

100N

1

470N

82K

82K

1UF

CXA_GND

GND

BX421

(AUDIO 1)

R_IN_COMP1

L_IN_COMP1

RX456

CXA_GND

0R

RX453

RX451 RX452

RX455

100R 100R

RX454

100R

CXA_GND

(EU)

RX900

10K

82K

82K

RX458

RX457

180K

180K

5V_FE

0R

0R

JX403

GND

HV_GNDGND

0R

JX402

BAV103

DX408

BAV103

DX406

DX405

ZMM6.8

ZMM6.8

DX404

RX407

150R

RX506

150R

RX513

150R

150R

RX411

RX514
150R

RX409

150R

Y2

AV IN(US)

161

IX950

74HC123PW

V PULSE STRETCHER

1UF

CX452

JX404

CXA_GND

CXA_GND

150R

RX413

470N

150R

RX423

CX950 15N

2A

GND

Y2H

VP/ADC

8V_FE

100N

CX482RX483

CXA_GND

1K

BC856B

TX482

CXA_GND

0R

1K5

JX408

RX477

CX483

RX484

CXA_GND

matrix

IN3_Pr

150R

150R

RX517

47P

RX951

CXA_GND

100R

RGB => YUV

YUV

IN3_Pb

RX516

VP_IN

0R

RX952

8V_FE

252627

VUY

YPbPr => YUV

YCbCr => YUV

IN3_H

IN3_Y

470N

CX419

150R

150R

RX417

V_EXT

1K

RX485

IN3_V

54321

5V_FEE

RX471

38

CX418

100N

1K

0R

RX432

10K

clock

39

470N

RX424

TX481

BC856B

CXA_GND

2K7

RX449

100R

RX482

CX472

33P

CX471

4MHZ 0R

QX471

17

21

29

dec

I2C

SCL

SDA

ADDR

303132

100R

100R

RX442

RX441

RX416

150R

RX415

150R

150R

RX508

CX428

10K

RX953

DX950BAV103

HV_GND

8V_FE

CXA_GND

CXA_GND

gen

IN1

IN4_Pr

470N

CX417

150R

CXA_GND

RX486

5V_FE

LX471

10UH

181920

Iref

IX400

IN4_Pb

8

RX509

RIN_EXT

(AUDIO 1)

100N1K

CX484

CXA_GND

RX487

0R

JX406

10135010

RX450

100R

CX474

100UF

CX473

100N

28

40

48

GND

VCC2

VCC1

CXA2171Q

to

IN4_Y

IN4_H

IN4_V

9457

10

11

CX416

150R

BX420

LIN_EXT

470N

CB2H

2K7

16V

IN4

46

CX427

10

CXA_GND

RX488

LX472

CXA_GND

24

GND

47

CX420

47P

LIN_EXT

BC856B

TX484

8V_FE

CXA_GND

100R

5V_FE

10UH

CXA_GND

6

12

GND

VCC3

6dB

select

IN1_R

3334353637

470N

CXA_GND

AGND

RIN_EXT

8V_FE

CXA_GND

1K5

RX478

CX485

RX489

LX473

16V

CX476

100UF

CXA_GND

100N

CX475

CXA_GND

22

H

dummy sync generator

H

existence distinction

H

IN1_B

IN1_G

IN1_H

IN1_V

CX421

150R

RX418

5V_FE

600

LX425

GND

CXA_GND

AGND

R/PR_EXT

CR2H

CXA_GND

100N

CX486

1K

RX491

CXA_GND

100N

CXA_GND

1K

0R

RX433

RX490

5V_FE

10UH

16V

100UF

CX478

CX477

100N

23

V

sync counter

H sync width increase

macrovision processing

V

sync separator

priority ranking

3-state sync detect

V

IN2_R

IN2_B

IN2_G

414243

470N

150R

RX518

TX463

BC846B

CXA_GND

4K7

RX469

600

600

LX424

LX423

VGND

G/Y_EXT

DC_DC_ON#

JX401

TX485

100R

0R

RX472

IN2_H

44

RX468

TX462

PB/B

BC856B

TX486

0R

JX407

BC856B

RX446

CXA_GND

V_EXT

VP_IN

0R

V-PHH-PHYout

Yin

IN2_V

470N

CX422

470R

BC856B

123456789

CVBSIN_EXT

2K7

13 1415 16

BX422

RX479

HV_GND

RX473

RX467

RX466

150R

RX429

CXA_GND

1K5

CXA_GND

RX492

2K2

1UF

CX443

10N

CX442

TX441

470N

CX426

CX423

2K2

1K

100N
CX470

CXA_GND

GND

4

DVD_KEY

CXA_GND

100R

470N

CX441

BC856B

470N

CXA_GND

RX464

RX436

1K

150R

RX510

GND

VDF L

HV_GNDHV_GNDHV_GND

CXA_GND

HV_GND

100N

CX491

HV_GND

HV_GND

RX444

CX425

CX424

TX461

4K7

GND

123

3V3_STBY

AV IN

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

COMB

FRAME_CV

9V_1H

CVBS/Y_M

CHROMA_M

0R

RV156

100N

CV130

10R

RV162

1K5

RV153

RV152

1K5

9V_1H

BC847-NP

TV111

654

470R

RV147

TV110

BC847-NP

654

470R

RV140

1K5

RV138

BC847-NP

TV109

4

321

65

DO NOT USE

RV135

470R

100N

CV129

100N

CV128

CV127

47UF

CV147

100N

CV146

47UF

10UH

LV103

(O/P to sheet 9)

9V

0R

RV157

321

DO NOT USE

TV108

DO NOT USE

16V

10UH

LV105

321

470R

RV146

BC846B

RV133

180R

LV204

TV107

100R

RV137

100R

RV136

TEA_GND

3U3H

RV168

BC856B

470R

RV143

1K5

RV134

10UH

LV102

0R

BC846B

TV106

TV105

RV149

RV148

RV139

470R

CV144

LV104

10UH

to COM FILTER

CV280

120P

RV170

0R

RV161

100R

BC856B

100R

BC856B

1K5

100R

RV141

470R

100R

RV142

TV103

100R

RV132

16V

47UF

CV145

47UF

CV142

0R

1V8_UC

RV158

2K32

RV155

2K32

RV154

100R

TV104

RV151

RV145

RV16375R

BC856B

BC856B

RV131

100R

100N

16V

CV143

RV164

3V3_UC

C_M/FRC

1K

RV160

2K21

2K21

RV150

470R

10K

RV144

CVBS02

CVBS01

TV102

100N

10UH

Y_M/FRC

RV159

CVBS03

0R

LV101

CVBS_AV1_OUT

RV101

10UH

LV100

0R

RV100

HDD_CVBS

to DVD 26pin conn.

MONITOR_OUT

DV103

IV101

100R

RV129

100R

RV128

100R

RV121

VSP_GND

100N

CV157

CV159

100N

0

0R

RV301

AV3/F_CVBS/Y_IN

AV3/F_CHROMA_IN

1UF

CV123

22N

CV124

DV104

100K

MMSZ6V8T1

TEA6415C

VSP_GND

CV10415P

CV10315P

16V

CV10047UF

VSP_GNDGND

100K

RV126

RV127

IN2

IN3

IN1

2

56789

314

I/O 0

I/O 3

I/O 1CPI/O 2

100N

CV155

100N

CV158 100N

CV160 100N

TEA_GND

GND

VCC

CETTCDPECS

16

OUT2

VSP_GND

CV154

CVBS_TXT_S

MRSRCEP

201918171514131211

IN8

1UF

CV117

100N

CV156

20M25

QV100

RV300

0R

CV14147UF

0

100N

CV161

0

0R

RV302

MMSZ6V8T1

100K

RV125

PROG

IN4

I/O 4

GND

U/

OUT4

OUT5

220N

CV118

XOUT
XIN
TCLK

CV163 100N

CVBS_TXT_M

100K

RV124

9V_1H

IN5

I/O 5

I/O 6

RV120

2K43

RV119

2K43

CV119220N

60

61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80

1

CV162 100N

CV164100N

IIC_CL_2

IIC_DA_2

AV2_R/CR

22N

CV125

MMSZ6V8T1

DV102

IN6

10

I/O 7

DV100

OE

IN7

RV116

1K 5

TV101

BC856B

RV118

2K21

RV115

BC856B

TV100

1K5

CV114

CV107

220N

220N

CVBS5

CVBS4

CVBS6

CVBS7

59585756555453

2346758

SDA

656HIO

GENCAM 1

AV2_CVBS/Y_IN

CVBS_AV2_OUT

1UF

CV122

MMSZ6V8T1

100N

CV120

RV117

2K21

0R

RV109

220N

CV115

CVBS3

CVBS2

CVBS1

IV100

VSP9407B-VK-C1

9

10

11

SCL

VSP_GND

656VIO

FLI

100K

RV122

RV123

1UF

CV116

100R

RV114

100R

RV113

VSP_GND

CV153 100N

434241

444546484749505152

201918171615141312

100R

RV106

IIC_DA_3

GENCAM 1

AV1_CVBS/Y_IN

1UF

CV121

100K

CVBS_IFM

RV166

75R

75R

RV165

100R

RV112

220N

0

CV112

CV105220N

CV152 100N

40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21

CV165 100N

CV166 100N

100R

RV107

IIC_CL_3

INT_DM U

DV101

MMSZ6V8T1

CVBS_IFS

220N

CV113

RESET_DMU#

22N

CV126

TUNER

CV132 220N

CV131 1N8

CVBS_EXT

0

0R

RV167

0R

RV108

VSP_GND

V_R

AV2_B/CB

220N

CV109

CV106 220N

0R

U_B

Y_G

AV2_G/Y

220N

CV110

CV151100N

0

CV167100N

RV173

HOUT

VOUT

VP/ADC

AV1_B

AV1_R/C

TEA_GND

V_EXT

AV2_FB/H

RV111

0R

CV111 220N

220NCV108

VSP_GND

0R

RV175

CLKOUT

656IO_7

656IO_6

VIDEO SW

AV1_G

VIDEO SW

0

0R

RV110

0R

RV172

656IO_3

656IO_4

656IO_5

AV1_FB

IFC228 MAIN EU

VIDEO SIGNAL PROCESSOR (VSP)

VSP_GND

656IO_0

656IO_1

656IO_2

FLI

IFC228-LCD

First issue 04 / 05

DVD_KEY

EU_US_03

EXT_ON#

EU_US_01

IIC_DA_4

IIC_CL_4

DC_DC_ON#

CVBS_TXT_S

MASTER_MUTE#

INF_POW_FAIL

R_OSD

CVBS_TXT_M

GM_INTERRUPT

G_OSD

B_OSD

FB_OSD

IIC_CL_3

IIC_DA_3

IIC_CL_2

IIC_DA_2

IIC_CL_1

IIC_DA_1

SYNC_ENABLE

INT_DMU

IR

HV_SWITCH

RESET_DMU#

VGASEL

HDFL

GM_BUSY

VDFL

RESET_AUDIO#

AQR_ON

SOFT_RESET

RESTART_LED

ECO_STANDBY#

AUDIO_STBY

SAFETY_ENABLE

PO

DVI_DETECT

PO_TR

3V3_STBY

1V8_STBY

5V_STBY

5V_V

GND

TXTSEL

SAFETY_INT

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

JR141

RR122

RR121

220R

PO

RESET#

FRONT-END

5V_STBY

GND

4K7

220N

CR003

TR140

3

4K7

RR124

390R

RR131

RR141
470R

TR144

RR145

RR135

1

LR025

RR119

220N

470R

BC856B

GND

RR045

240Z

GND

1K5

470R

470R

RR004

3V3_STBY

4K7

CR025

1%

3K65

RR109

RR140

470R

RR138

1K2

4K7

GND

3V3_STBY

RR046

100N

1%

1K5

GND

GND

5V_V

RR144

IR004

4K7

5V_V

RR003

MC33460SQ

1K

TR149

RR136

IR040

NCP303LSN30T1

CR043
5

4

RR044

JTSEL

JTCLK

JTOUT

JTIN

3V3_STBY

RR191

(EU)

LED#

1%

RR120

3K65

(EU)

AV2_PIN8

AV1_PIN8

(EU)

KEYBOARD

DVD_KEY

POWER_SWITCH

CVBS_TXT_S

CR114

CR118

4N7

CVBS_TXT_M

GND

1N2

CR005

GND

BC856B

RR130

1K8

470R

TR141

BC846B

470R

RR123

TR142

0R

BC856B

9V

FB_OSD

B_OSD

470R

0R

RR134

JR145

TR145

BC846B

5V_V

R_OSD

5
6
7
8

CR109

RR116

RR114

GND

BC846B

470R

33R

1

2

10N

LR030

JR149

4

OUT

IN

GND

RR197

RR194

RR195

RR196

68R

RR339

CR026

3V3_STBY

GND

1K

1K

1K

RR112

0R

GND

3V3_STBY

0R

JR147

TR147

BC846B

GND

0R

47K

47K

47K

3N9

RR250

RR113

CR030

RR149

0R

G_OSD

RESET_DMU#

LED_TOPLIGHT

470N

CR004

876

68R

RR338

123

4
3
2
1

CR027

33R

1K

RR115

100N
CR039

100N
CR038

100N

CR002CR001

RR148

TR148

BC856B

470R

470R
RR139

TR146

BC856B

470R

RR147

470R

RR137

AQR_ON

820P

JR250

DR250

CR031

39P

39P

1K2

DVI_DETECT

5

4

GND

0R

NYD

3N9

1M

RR006

1K2

RR146

5V_V

CR032

RR190

CR192

6V3

220UF

CR250

820P

GND

1K

1N

RR189

12K 100R

RR111

10K

4K7

RR185 RR193

3V3_STBY

CR251

GND

8MHZ

820P100N

3N9

CR011 CR012

CR010

240Z

LR010

5V_ON_CHECK

GND

68R

RR337

GND

3N9

QR001

3V3_STBY

480_ON

ECO_STANDBY#

567

8

432

1

JTIN

121
122
123
124
125
126
127
128
129
130
131
132
133
134

AVSS

135

AVDD

136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160

80Z

LR011

GND

47K

RR010

47K

RR011

RR012

47K

RR013

GENCAM 2

3V3_STBY

5V_STBY

100N

CR113

CR186

GPIO(35)

ADCIN4
ADCIN3
ADCIN2
ADCIN1
ADCIN0

CCVIDEO

OSD_R
OSD_G
OSD_B

OSD_FSW
ADCVD3
ADCVS3

TTVIDEO

ADCREFM

ADCREFP
ADCVS2
ADCVD2
ADCVS1
ADCVD1

OSCIN

OSCOUT

47K

RR151

15K

RR110

1N

PLLBYPASS

PLLB_AVCC

PLLB_AGND
PLLB_DGND

PLLB_DVCC

ADC_REFN

PLLA_AVCC

PLLA_AGND
PLLA_DGND

PLLA_DVCC

CORE_VDD3

CORE_VSS3

SDCLK

AUDIO_STBY

SAFETY_ENABLE

1K8

1K8

RR150

3K3

RR182

3K3

RR181

10K

RR154

4K7

RR180

GNDGNDGNDGND

10N

CR190

1N
CR188

68R

RR336

118

119

120

JTSEL

JTCLK

JTOUT

ANA_G_PWR

OSDDACVSS
OSDDACVDD

EXT_VSS1

SDCLK

EXT_VDD1

123456789

0Z

LR001

8

RR300 68R

1

68R

RR001

SDCKE

SDCS0#

PO_TR

IIC_CL_4

IIC_DA_4

100R

RR199

TR19

0R

JR326

10K

RR198

5V_STBY

0R

JR027

39P

CR181

39P

CR182

876

5

3V3_STBY

123

4

GND

117

EXT_VSS9

SDCKE

GND

567

432

SDCS1#

106

107

108

109

110

111

112

113

114

115

116

MOSI

MISO

TMRIN

SPISSB

SPISCK

RESET_

TMROUT

GPIO(27)

GPIO(34)

EXT_VDD9

EXT_VDD5_1

EXT_VSS2

EXT_VDD2

WE_

ROMCS1_

ROMCS0_

SDA10

SDWE_

SDCAS

SDRAS

SDCS1_

SDCS0_

101112131415161718192021222324252627282930

876

5

8

123

4

68R

RR301

1

68R

RR302

SDA10

SDCAS

SDRAS

WE#

ROMCS1#

ROMCS0#

SDWE#

IIC_CL_3

IIC_DA_3

IRDA_OUT

SOFT_RESET

GM_INTERRUPT

8

BC846B

4K7

RR157

1K8

RR170 RR171

4K7

RR163

47K 1K8

RR161

47K

RR172

5V_STBY

RR175

3K3

876

68R

RR334

123

GND

99989796959493929190898887868584838281

100

101

102

103

104

105

GPIO(20)

GPIO(21)

GPIO(22)

GPIO(26)

GPIO(23)

I2CCLK(2)

I2CCLK(3)

I2CDAT(2)

I2CDAT(3)

CORE_VSS2

CORE_VDD2

IR001

GENCAM CUT2.1

DATA(3)

CORE_VSS0

CORE_VDD0

DATA(2)

DATA(1)

DATA(0)

HBE

SRAMCS_

OE_

DATA(4)

EXT_VDD3

1V8_STBY

8

876

5

567

1

123

4

432

68R

68R

RR304

RR303

82R

RR002

D0

D4

OE#

IRDA_IN

5

4

PWMO0

GPIO(17)

DATA(5)

EXT_VSS3

567

432

RR333

68R

8

1

SIRIN

SIROUT

DATA(7)

DATA(6)

RR305

UART_OUT

5V_STBY

EXT_VSS8

EXT_VDD8

DATA(9)DATA(8)

31

876

123

68R

D10D9D8D7D6D5D3D2D1

10K

47K

RR156

39P

CR171

39P

CR170

220N

100P

CR172 CR175

68R

RR332

567

876

432

123

GND

SDIN

SDOUT

GPIO(13)

EXT_VSS5_0

DATA(13)

DATA(12)

DATA(11)

DATA(10)

5

4

RR306

D11

3K3

3K3

10K

RR183

RR187

GPIO(10)

DATA(14)

8

1

68R

D12

UART_IN

RR159

RR160

5

4

I2CCLK(1)

I2CDAT(1)

EXT_VSS4

EXT_VDD4

403938373635343332

567

432

D15

D14

D13

IIC_CL_2

EXT_ON#

RR335

VSYNC

DATA(15)

IIC_DA_2

68R

8

1

3V3_STBY

LR015

3V3_STBY

DC_DC_ON#

567

432

47K

RR016

820P

CR017

CR015

240Z

100P

CR159

100P

CR160

100P

CR183

5V_STBY

RR056

3V3_STBY

8

1

HSYNC

80

GPIO(07)

79

GPIO(06)

78

GPIO(05)

77

IRIN

76

IROUT

75

EXT_INT(0)

74

I2CCLK(0)

73

I2CDAT(0)

72

EXT_5VTOL

71

ADDR(23)

70

ADDR(22)

69

ADDR(21)

68

ADDR(20)

67

ADDR(19)

66

EXT_VSS6

65

EXT_VDD6

64

ADDR(18)

63

CORE_VSS1

62

CORE_VDD1

61

ADDR(17)

60

ADDR(16)

59

ADDR(15)

58

ADDR(14)

57

ADDR(13)

56

ADDR(12)

55

ADDR(11)

54

ADDR(10)

53

ADDR(9)

52

EXT_VSS5

51

EXT_VDD5

50

ADDR(8)

49

ADDR(7)

48

ADDR(6)

47

ADDR(5)

46

ADDR(4)

45

ADDR(3)

44

ADDR(2)

43

ADDR(1)

42

ADDR(0)

41

CR020

LR020

240Z

3N9

CR016

100N

47K

RR184

10K

RR059

10K

RR058

10K

RR049

10K

4K7

RR053

4K7

RR054

10K

RR152

10K

RR048

100N

CR022

GM_BUSY

RESET_AUDIO#

0R

JR325

567

RR331

432

GND

3N9

CR021

820P

CR042

GND

1V8_STBY

VDFL

AV_PIN8_OUT

68R

5
6
7
8

5
6
7
8

5
6
7
8

5
6
7
8

5
6
7
8

5
6
7
8

GND

CR041

820P

CR040

100N

HDFL

RR330

68R0

3N9

GND

INT_DMU

RESTART_LED

0R

JR18

4

RESTART

876

68R

123

RR312 68R0

4
3
2
1

RR311

4
3
2
1

RR310 68R0

4
3
2
1

RR309 68R0

4
3
2
1

RR308 68R0

4
3
2
1

4
3
2
1

RR307 68R

IR_UC

IR_OUT

100P

CR184

10K

RR153

100K

RR055

18K

RR079

1N

CR048

1N

CR053

10N

CR079

5

4

100N

CR050

3N9

CR051

CR052

820P

A22
A21
A20

A19
A18
A17
A16

A15
A14
A13
A12

A11
A10
A9
A8

CR060

A7
A6
A5
A4

A3
A2
A1
A0

5V_STBY

5V_STBY

5V_STBY

GNDGND

GND

RR060

1N

CR068

RR066

1K

10N

1K

CR165

GND

5V_STBY

220UF

CR055

IR006

PCF8574TS

10K

BC856B

TR061

RR065

100UF

CR106

RR070

16V

TXTSEL

VGASEL

3D_FRAME

SW_DETECT

100P

10K

RR104

3K3

RR105

4K7

RR106

4K7

RR107

567

8

68R

RR341

10V

432

1

182019

P7

P6NCP5

SCLNCA0A1A2

SDA

INT

3

124

RR082

5V_STBY

RR081

100R

5V_STBY

8

VCC

7

WC

6

SCL

IR005

3K3

3K3

RR071

RR072

RR073

1K

RR062

GENCAM 1

470R

RR063

RR069

100K

RR068

1K

RR067

2K4

5K6

RR064

4U7F

CR061

3V3_STBY

CR166

3V3_STBY

VGAWC

GND

SYNC_ENABLE

0R

RR201

RR118

GND

10K

RR108

0R

RR200

876

5

68R

RR340

123

4

11121314151617

P4

P3NCP2

P1

VSS

P0

NC

VDD

6

8

759

10

CR082

39P

47N

CR083

39P

CR081

100R

RR080

47N

CR075

1

E0

2

E1

3

E2

45

VSSSDA

M24C64WMN6

100P

100P

CR070

CR071

220R

220R

IFC228 MAIN EU

1K5

0R

RR057

TR062

BC846B

0R

RR192

DR800

1N4148W

RR800

0R

GND

1V8_STBY

1K

RR167

100UF

16V

CR167

100UF

1V8_STBY

5V_V

MASTER_MUTE#

0R

10K

RR103

10K

RR102

10K

RR101

IIC_DA_2

IIC_CL_2

IIC_DA_1

IIC_CL_1

PG

INF_POW_FAIL

16V

5V_V

5V_STBY

IFC228-LCD

First issue 04 / 05

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE
SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE
ESQUEMA DE LA PLATINA PRINCIPAL

3V3_STBY

TR214

BC857BS

5V_STBY

BC856B

RR210

10K0

RR211

1K0

RR212

10K0

RR213
100K0

RR214

220K0

DR210
BAS20

CR211

100U0

TR211

BC846B

TR213

BC846B

JR210

TR210

BCX56 N

RR209

100R0

TR212

TR216

BSN20 N

G

WE_ROM#

WE#

LR110

TR215

BC856B

TR217

BSN20 N

G

GNDGND

RR217

47K0

RR219

220K0

RR220
4M7

CR117
820P0

CR210
220MI0

TR214

BC857BS

RR216
220K0

100K0

RR215

D

D

S

S

RR218
47K0

LR115

0

CR115
100N0 3N9

GENCAM 1

JR132

JR131

0

47K0

IR130

MX26LV320T

1
A15

A14
A13
A12
A11
A10
A9
A20
A21

JR137

A22

CR137

GND

10N0

A19
A18

A8
A7
A6
A5
A4
A3
A2

3V3_STBY

A155

2

A14

3

A13

4

A12

5

A11

6

A10

7

A9

8

A8

9

A19

10

A20

11

WE

0

12

RESET

13

A211

0JR138

14

WP/ACC

15

RY/BY

16

A18

17

A17

18

A7

19

A6

20

A5

21

A4

22

A3

23

A2

24

A1

240R0

CR130

100N0

LR130

ROM

BYTE

GND1

Q15/A-1

Q14

Q13

Q12

VCC
Q11

Q10

GND2

CR131

3N9

0

GND

CR110

100N0

CR111

3N9

GND GND

CR112
820P0

IR110

MT48LC4M16A2TG-75

1

GND

2
3
4
5
6
7
8
9

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

D15_
D7_

D14_
D6_
D13_
D5_
D12_
D4_

D11_

D3_
D10_
D2_
D9_
D1_

D8_
D0_

VDD

DQ0
VDDQ
DQ1
DQ2
VSSQ
DQ3

DQ4
VDDQ
DQ5
DQ6

VSSQ
DQ7
VDD VSS
DQML
WE#
CAS#

RAS#
CS#
BA0

SDRAM

BA1
A10

A0
A1
A2
A3 A4

IFC228 MAIN EU

D0

D1 D14
D2

D3
D4

D5

D6

D7

A19
SDWE#
SDCAS
SDRAS
SDCS0#
A21
A22
SDA10
A0
A1
A2
A3

CR116

GND

3V3_ROM

48

A16

47
46

GND

45
44

Q7

43
42

Q6

41
40

Q5

39
38

Q4

37
36
35

Q3

34
33

Q2

32

Q9

31

Q1

30

Q8

29

Q0

28

OE

27

GND

26

CE

25

A0

3V3_ROM

CR132

820P0

54

VSS

53

DQ15

52

VSSQ

51

DQ14

50

DQ13

49

VDDQ

48

DQ12

47

DQ11

46

VSSQ

45

DQ10

44

DQ9

43

VDDQ

42

DQ8

41
40

NC

39

DQMH

38

CLK

37

CKE

36

NC

35

A11

34

A9

33

A8

32

A7

31

A6

30

A5

29
28

VSSVDD

A17A16

RR316

D15_
D14_
D13_

D12_
D7_
D6_
D5_
D4_

D11_
D3_
D10_
D2_
D9_

D1_
D8_
D0_

68R0

45

18

RR315

68R0

1

4

RR314

68R0

1

4

RR313

68R0

1

4

GENCAM 2

GND

GND

8

5

8

5

8

5

ROMCS0#

D15

D13

D12
D11

D10

D9

D8

A20
SDCLK
SDCKE

A11

A9
A8
A7
A6
A5
A4

D15
D14
D13
D12

D7
D6
D5
D4

D11

D3

D10

D2
D9
D1
D8
D0

OE#

A1

IFC228-LCD

First issue 04 / 05

GND

GNDGND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

+2.5D1 +2.5D1 +3.3VC +2.5D2 +2.5A2 +2.5A2 +2.5D2 +2.5A1+2.5A1 +3.3VC+2.5A1 +2.5D2

VSP

CC029CC034

4N7100P0

CC030

CC031

100N0

CC033 CC032

100N0 4N7

100P0

CC035

100N0 100N0

CC037 CC036

CC038

100P0 100N0

4N7

CC039

10U0

CC041

+3.3VC

9V_1H

FRAME_CV

Y_M/FRC

9V_1H

C_M/FRC

9V_1H

CVBS/Y_M

CHROMA_M

9V_1H

GND_COMB

RC042

1K5

RC132

100N0

CC132

46 53 81 92 93

45 64 1003831 32

RC056

RC053

RC051

2K2

RC112

CC112

RC133

4K7

1K0

47K0

1K5

100N0

100R0

RC025

DC025

LL4148 100K0

CC055

100N0

TC055

100R0

RC113

GND_COMB

DVDD3

RSTB

AVDD5

AVDD4

AVDD3

DVDD2

AVDD2

AVDD1

DVDD1

DVDDDI0

BC856B

TC051

BC846B

RC050

100R0

RC041

GND_COMB

BC856B

TC132

10U0

CC025

RC024

1K0

637757

45678910111213141516

NSTB

TEST01

TEST02

IC040

UPD64083

DVDDRAM2

DVDDRAM1

ACI

CSI

VRBC

VRTC

96

76

959094

CC053

100N0

CC052

100N0

TC056

BC846B

RC055

470R0

RC054

2K2

220K0

RC052

1U0

220R0

CC051

1N0

CC050

TC040

BC856B

TC112

BC856B

2K2

RC111

2K2

RC110

GND_COMB

2K2

RC131

2
3

TEST03

GND_COMB

DC024

TEST04

CC054

100N0

LT1D73A

TEST05

TEST06

DYCO

10

GND_COMB

9V_1H

2K2

RC130

1
4

TEST07

DYCO 9-0

select

GND_COMB

TEST08

TEST09

LC070

9V_1H

TEST10

CC070

750R0

TEST11

220N0

CC063

RC063

RC061

GND_COMB

TEST12

10

10

delay

CC071

4K7

RC070

CC067

CC066

100N0

15P0

CC065

357R0

2K2

TEST13

AYout

10bit

peaking

noise

10

10

1U0

22P0

8P2

TC065

17

TEST14

coring

10bit

AYin

88

BC846B

9V_1H

GND

EU_US_01

1819202122232425262728

EXTALTF

EXTDYCO0

EXTDYCO1

EXTDYCO2

EXTDYCO3

EXTDYCO4

EXTDYCO5

EXTDYCO6

AC0ut

10bit

YDAC

CDAC

10

CBPF

delay

noise

reduction

reduction

10

mixer

motion

chroma

detection

10

line

filter

comb

10

10bit

YADC

CADC

clamp/bias

ACin

VRBY

VRTY

AYI

91

CC080

100N0

CC081

100N0

GND_COMB

82P0

CC069

TC070

BC856B

12U010U0

LC067

91P0

LC066

27P0

CC064 CC068

619R0

RC067

LC065

RC060

15U0

TC061

100R0

9V_1H

BC856B

VIDEO

RC064

GND_COMB

332R0

GND_COMB

SW

GND_COMB

825R0

RC066

1K1

RC065

BC846B

TC063

100R0

RC062

FRAME_CV

EXTDYCO7

EXTDYCO8

9V_1H

RC107

CC107

DC064

CVBS/Y_M

Y_M/FRC

3334353637

TEST15

TEST16

EXTDYCO9

comp

Y vert

aperture

WCV-ID

4Mbit

VCLY

89

GND_COMB

CC102

CC104

RC104

470R0

TC107

10R0

220N0

LL4148

5V_FE

C_M/FRC

TEST17

TEST18

frame

decoder

frame

CC085

CC084

RC100

8P2

22P0

BC856B

GND_COMB

GND_COMB

CC141

CC140

ID-1

delay

100N0

47U0

4K7

100N0

47U0

CHROMA_M

56

CLK8

TEST19

ID1memory

comb

decoder

357R0

RC101

10U0

LC102

12U0

LC104

100R0

RC103

TC105

CC144

CC142

BC846B

1U0

IIC_DA_2

IIC_CL_2

5V_FE

SENSE_2V5

656667686970717273

61

62

ST0

ST1

DYCO0

DYCO1

DYCO2

DYCO3

encoder

filter

non

standard

detection

HV

sync

counter

separator

AX0

848285

GND_COMB

BC856B

TC100

27P0

CC101

91P0

CC103

82P0

CC105

470R0

RC105

95R3

RC106

47R0

RC108

9V_1H

CC145

100N0

11614118

VDD

13

2

312576

3D_FRAME

GENCAM 1

SENSE_3V3

DYCO4

DYCO5

CBPY

GND_COMB

1U0

6V

DYCO6

DYCO7

CBPC

CC090

100N0

9V_1H

GND_COMB

10R0

RC127

220N0

CC127

CC091

RC124

DYCO8

100N0

CC122

CC124

470R0

TC127

9

75

74

DYCO9

RC120

8P2

22P0

BC856B

GND_COMB

+3.3VC

79

78

KIL

LINE

ALTF

GND_COMB

4K7

357R0

RC121

10U0

LC122

12U0

LC124

100R0

RC123

TC125

BC846B

IC140

10 15 4

10N0

CC146

98

TEST25

CC143

99

RC126

RC128

100N0

TEST26

CC121

CC123

CC125

86R6

47R0

4K7

RC023

58

SLA0

fsc

10bit

8fsc

I2C

ACO

83

BC856B

TC120

27P0

91P0

82P0

470R0

RC125

BA7602F

GND_COMB

generat

PLL fsc-DAC

interface

GND_COMB

JC923

RC022

RC020

237R0

QC022

48

XO

SCL

59

470R0

RC021

GND_COMB

IIC_CL_2

20M0

47

X1

SDA

60

470R0

IIC_DA_2

AGND5

AGND4

AGND3

DGND4

RPLL

DGND3

CKMD

54

FSC1

5250

AGND2

AGND1

49 51 86 87 97

TEST24

TEST23

TEST22

TEST21

FSC0

40 55 802912 3 30

DGND2

TEST200

39 41 42 43 44

DGNDRAM2

DGNDRAM1

TESTIC2

TESTIC1

DGND1

CC020

CC021

+2.5D1

+2.5A2

+2.5A1

22P0

CC023

22P0

CC022

+3.3VC

+2.5D2

100P0

100P0

GND_COMB

CC018

10N0

GND_COMB

15U0

LC016

470R0

RC016

TC015

BC846B

GND_COMB

GND_COMB

100N0

CC012

2700R

LC012

CC011

100N0

LC011

750R0

100N0

CC010

750R0

LC010

+3.3VC

IC001

VOLTAGE

GND_COMB

(OPTION)

IFC228 MAIN EU

1K0

RC017

150P0

CC017CC016

150P0

RC015

470R0

100P0

CC027

10U0

CC026CC013

100N0

750R0

LC013

GND_COMB

IC006

32

LD1117DT25

220N0

CC004

100U0

CC003

2

GND

OUTIN

1

3

LD1117DT33

CC002

6V

REGULATOR

COMB

GND_COMB

GND_COMB

CC009

CC008

CC007

GND

OUTIN

1

CC006

JC001

220N0

1N0

220N0

220N0

0R

100U0

JC002

0R

GND_COMB

GND

GND_COMB

GND

IFC228-LCD

First issue 04 / 05

CA306

RY005

1

RX302

RR180

RA013
+

CA024

RP001

IP002

RY004

CV146

CV141

RV175

CV270

RV259

RR190

RR336

RR250

+
12

44

IA400

+

CV142

RR187

RR302

11

RA014

RY039

1

RR002

CA303

+

1

1

RV900

CR165

RR059

RA019

RY003

CV110

QV260

BR006

RR058

RR335

CA304

CA400

+

CA025

CY022

IV100

CR048

RA020

RX301

21

40

RV218

+

RR049

20

41

RV108

CV111

CR172

RR048

RR334

RA021

CC007

RY032

RY002

RV166

IR040

RR303

QC022

RY033

156

1

RV106

CV109

RR171

+
+

RA022

1

RR170

CA305

RV107

CV112

1

RR304

7

RA305

CA300

RA023

IR004

RR163

+

CA026

+

1

RY042

RV112
CV108

RR161

RR333

+

CA252

1

64

CY036

CV113

CV132

RR172

RR305

8

CA506

+

JV004

25

TV208

CV237

RR136

JR147

TR062

+

+

JV002

RV239

+

+

CA522

RX528
RX524

LX223

TV202

CV241

RR044

CP018

RR067

+

+

JR145

IP006

RV236

RV269

RR192

CA505

+

RA232
CA233
RA230

+

+

+

86

44

+

CV223

TR144

CA231

CV202

CV259

RR045

TR145

DR250

CA017

CP004

CY010

RV208

TV209

RR191

RR116
RR115
RR114

RR113
RR112

JR250

1

+

BX421

BP203

BR007

+

CA502

+

CA516

IY001

RV258

DV200

CR003

QR001

+

CV222

DV201

+

9

LA001

RA010

53

CV209

+

IV202

CA513

IP203

JV005

RV207

DV202

CR166

+

RA262

CA265

1

104

CV201

RV267

RR199

52

RR046

RR182

LR030

9

15

RA003

RA004

RY037

+

RY007

RV268

1

CA013

+

RY036

105

40

9

121

CR251

160

LR001

+

14

CA517

+

+

RY038

CV200

65

8

RR181

1

CA082

1

TV201

RV206

41

TV211

RR339

TR198

+

23

33

CA254

+

CA014

+

64

CV266

RR154
RR110

+

RA009

RY021

RV240

RR001

22

34

IA001

RA012

CP001

+

TV200

RV261

CV262

RR185

CA262

+

JV006

CV265

1

BV900

RR193

CP028

40

IV200

RV260

BA300

+

+

CP203

BY001

RY020

CV282

+

CR113

RR338

1

1

+

RY024

CY013

RV262

25

41

CA012

RY006

+

RR189

CA515

+

24

1

CV264
RV265

RR300

RV264

CV261
CV263

CR186

CR188

8

CA255

CA018

IC006

RP002

RY023

CV234

+

1

16

CR190

RR337

RR301

10

FDU04

X

BA001

CA500

W

CA501

+

+

28

IA500

V

1

+

CA504

CA520

+

+

U

CA081

CA503

CA080

BX130

LA231

T

CA232
LA230
CA230

BP002

1

S

R

Q

P

N

M

L

K

J

H

G

F

RR122
RR121

E

RR140

D

JR184

RR029

+

C

B

A

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

MAIN BOARD - PLATINE PRINCIPALE - CHASSIS GRUNDPLATTE - PIASTRA PRINCIPALE - PLATINA PRINCIPAL

RR130

RR402

LV230

CV238
LV231
CV240

BR005

JR141

CR008

CP100

CR068

TR015

RR064

BP001

1

TR140

RR026

TR023

RR028

RR065

CV231

JV800

BV201

+

1

43

+

TR141

RR068

TV203

RR066

FDU02

+

TR148

CR024

CP023

CP002

IP004

CV239

RV233

IP005

CA518

IP001

RV209

RV211

RV231

1

JR149

CR065

TR024

10

RX222

IY002

CY012

CR163

CR185

TR149

RX525

CP006

1

RV234

JV001

RR138

RR015

CR167

CR061

LX224

CV207

TV210

JV003

24

TR146

RX224

CR164
CR162
CR161

CR058
CR057
RR009

TR061

DR800

RX221

80

TR147

+

8

+

+

IA300
5

RA024

+

+

RY034

20 8

RV202

80

+

157

1

RY001

CV280

RR157

RR332

BR001

+

RA025

DC025

RC025

CP003

RY045

CY025

CY037

CV107

1

CR159
CR184

JR325

50

TC015

RY012

RY041

RR156

7

CC041

LV204

1

65

31

CC025

CY030

CY031

RV111

RR183

IR001

CA302

QY001

CY038

+

CV119

RR331

80

40

1

RA002

30

CR183

CR160

DH001

CH019

4

RA001

LA006

CA036

+

51

1

RY044

CY007
+

CY029

CY004

1

60

TV100

RV115

BR200

RR151

CY005

CY006

+

80

RR306

+

+

CV100

61

RV167

RR184

CC026

1

RV119

RV118

1

CA037

RC021

+

RV201

RV162

RR054

QA001

+

CY011

RV150

RR152

CR053

RR053

CR079

RR312

RR310

RR308

RC020

RR150

RR307

54

6

BH001A

+

IC040

RV160

CV130

RR072

RR330

RR311

RR309

RR316

1

BR002

1

6

CA027

+

+

K

+

CY002

+

RV132

4

IR005

5

RR073

IR130

IR110

+

+

1

TV107

RR313

+

+

+

+

TV102

CH020

RY043

BX423

CR211

24

RR314

CH006

CH007

CH016

CH021

CH017

TC056

25

1

CR071

CR081

X12

TC055

DC024

+

+

CV144

QV100

RV161

1

8

DR210

CA048

CA028

+

CY008

+

RR106

RR107

TC051

CY001

RR082

CR070

BX422

LA004

+

RR341

CR082

1

CA031

+

1

RC042

RC052

CY009

TV105

TV104

CY003

+

20

1

CR083

TR216

80

TC040

BARCODE-STICKER

5

LA005

RA027

CA032

+

CP005

LC013LC010

+
CC084
TC070

100

LC067

RC067

CC068

CC071

CC069

TC100

CC101

LC104

CC103

LC102

81

CC107

RC100

RC101
CC121

TC120

CC123

RC123

LC124

LC122

RC120

PCB MAIN IFC228 (EU)

2139297D

RV128

RV302

DV103
DV102

CV125
RV129

RV981

DV101

1

RV146

RV145

CV127

RX195

RX900

RX456

16

IX410

1

RX617

CX452

CX451

RX453

1

BX420

CX431

RX422

CR055

CR106

RR340

CR210

RR200

11

IR006

10

TR211

TR212

RR211

TR217

TR215

1

RR212

TR213

1

TR214

48

RR315

28

JR210

27

+

CR250

5

IP003

CC105

CC125

LT623

RR213

RR215

TR210

TV111

CX455

TX461

LC066

+

CX453

RT059
CT636

LT622
RT628
CT633

RR210

DC06

CC064

RC125

CC127

TC125

RV147

RX615

9

JV100

RX459

8

RX510

RX430

RX466

LC065

LC070

TC105

1

RX612

1

4

4

RC064

TC107

TV110

RX439

LT621

RC062

RV980

10

RX436

4

TX486

TX431

TC065
TC063

RC126

IV101

RX191

RX193

CX454

RX429

CT650

CT653

CT643

+

CP008

TC127

CC140

DV104

1

CX445

LT643

CT656

RC060

JX407

RX454

TX432

TX462

RT627

CT644

+

LT644

IT502

+

TC061

RX492

TX485

CX444
RX443

+

+

RX442

RX441

RX440

RX469

CT635

8

9

CT632

CT692

IC00 1

TC132

RC128

TV109

RX490

TX463

LT641

IT503

DT509

CX183
20

RX486

RX464

CC145

CX476

LX472

CX470

+

+

CT652

9

RC130

8

9

TX484

RX446

+

LT642

CT655

CT647

CT529

8

BT501

CA042

+

CV128

CV129

11

1

+

CX462

RX488

RX447

CX474

CT634

RT626

CT649

CT648

RT637

RC132

RC133

RV155

+

CV117

JX408

RV154

RX461

RX450

RX482

IX400

CT621

CT654

CT69 1

CT502

1

16

RC113
RC112

CV116

RX448

CT631

+

BH001B

TC112

RC110

+

CV120

+

RV158

RV121
RV133

RX484

TX483

25

36

RT058

RT057

21

CT651

33

CT645
CT646

+

DT501

DT502

DT503

3

3

DV100

RV159

RT609

20

34

24

37

+

RT056

TT631

RT519

TX482

RX449

CX422

CX473

RT041

RT632

RX473

TX481

QX471

LX471

LT614

RT516

+

14

RX472

RX494

RT622

X7

1

BR360

+

RV982

LX461

8

RX496

CT618

RT604

16

RT517

RT520

1

16

CT626

1

CT505

CC144

CX423

RX522

CT619
CT622

CT504

RV157

RX474

CX424

RX434

RT634

CT544

CT506

CC003

IC140

RV114

TV106

IX440

8

9
CX491

RT525

RT631

CT624

RT633

+

14

TX152

IX430

TX151

RX152

1

LX473

TX441

+

+

+

NH001

1

RX107
RX560

RX167

JX121

RX154

7

1

RX493

13

CX425

RX409
RX407

RR362

DR362

RR360
DR360

+

+

RT003

TX101

RX561
RX109

RX108

CX222

CX982

RA211

DX172
DX173

48

CX426

LT613

CT625

2

DX175

DX174

CX494

IX420

12

RT610

CT623

IT505

CT541

CT542

CT543

2

RX162

CA211

RX192

1

14

DX408

CX413

1

RX435

TT632

7

8

RT514

JT501

RX103

CX465

CX478

+

RX523

DX407

DT507

RT001

DX164
TX164

RX155

RX553

CX173

LX462

CX406

CT615

CT616

CT617

RX104

+

LT612

8

46

CT620

+

JT502

RX151

TX153

CX404

CX402

47

TR370

DT504

+

RX124

DX102

TX102

CX161

CX151

RX554

7

CR370

RT002

+

CT612

1

IT607

DT603

IT600

CT642

RR370

CX124

DT602

RR366

4

5

RT515

RX105

DX171

CX414

RX126

DX103

+

RX178

+

CT614

DT505

CA203

RX153

RX527

BX120

RX177

DX950

RX601

DX403

DX402

DX401

1

RT523

RX106

DX101

TX163

CX144

CT611

LT611

RT651

RT650

1

1

14

DT001

CA250
RA250

RA202

TX103

RX120

1

RX953

RX410

RX408

CX405

TR365
RR369

1

DT511

DT512

LX161

IX950

CX412

CX410

RR365

DT506

1

RX412

RX413

CT607

8

DT513

RA201

CX112

DX111

RX602

CX408

CT608

4

5

IT620

DT510

CT503

1

CA202

RX110

DX114

DX406

DX405

DX404

RX511

RT603

TT602

IT504

RT513

RA252

CA201

DX112

RX541

RX544

RX411

TT601

DX115

RX414

RT602

CR365

IT63 0

DT002

FDU06

RA200

RX546

RX169

RX513

RX600

RX512

RT524

BT502

16

IT608

LT601
CT602

CA271

DT508

0

X

W

V

U

RT004

1

BT001

T

BX110

LA250

LA201

LA251
CA253
CA200

S
LA200
RX115

RX539

RX117

RX535

RX114

RX540

RX118

RX168

R

RX545

RX113

RX538

RX534

RX119

DX113

RX121

RX231

CT604

BT600

RT601

1

Q

1

P

N

M

L

K

J

H

G

F

E

D

C

B

A

0

IFC228-LCD

First issue 04 / 05

RX543

98

BX400

DT604

1

8

RA271

BA200

1

CA306

RY005

1

RX302

RR180

RA013
+

CA024

RP001

IP002

RY004

CV146

CV141

RV175

CV270

RV259

RR190

RR336

RR250

+
12

44

IA400

+

CV142

RR187

RR302

11

RA014

RY039

1

RR002

CA303

+

1

1

RV900

CR165

RR059

RA019

RY003

CV110

QV260

BR006

RR058

RR335

CA304

CA400

+

CA025

CY022

IV100

CR048

RA020

RX301

21

40

RV218

+

RR049

20

41

RV108

CV111

CR172

RR048

RR334

RA021

CC007

RY032

RY002

RV166

IR040

RR303

QC022

RY033

156

1

RV106

CV109

RR171

+
+

RA022

1

RR170

CA305

RV107

CV112

1

RR304

7

RA305

CA300

RA023

IR004

RR163

+

CA026

+

1

RY042

RV112
CV108

RR161

RR333

+

CA252

1

64

CY036

CV113

CV132

RR172

RR305

8

CA506

+

JV004

25

TV208

CV237

RR136

JR147

TR062

+

+

JV002

RV239

+

+

CA522

RX528
RX524

LX223

TV202

CV241

RR044

CP018

RR067

+

+

JR145

IP006

RV236

RV269

RR192

CA505

+

RA232
CA233
RA230

+

+

+

86

44

+

CV223

TR144

CA231

CV202

CV259

RR045

TR145

DR250

CA017

CP004

CY010

RV208

TV209

RR191

RR116
RR115
RR114

RR113
RR112

JR250

1

+

BX421

BP203

BR007

+

CA502

+

CA516

IY001

RV258

DV200

CR003

QR001

+

CV222

DV201

+

9

LA001

RA010

53

CV209

+

IV202

CA513

IP203

JV005

RV207

DV202

CR166

+

RA262

CA265

1

104

CV201

RV267

RR199

52

RR046

RR182

LR030

9

15

RA003

RA004

RY037

+

RY007

RV268

1

CA013

+

RY036

105

40

9

121

CR251

160

LR001

+

14

CA517

+

+

RY038

CV200

65

8

RR181

1

CA082

1

TV201

RV206

41

TV211

RR339

TR198

+

23

33

CA254

+

CA014

+

64

CV266

RR154
RR110

+

RA009

RY021

RV240

RR001

22

34

IA001

RA012

CP001

+

TV200

RV261

CV262

RR185

CA262

+

JV006

CV265

1

BV900

RR193

CP028

40

IV200

RV260

BA300

+

+

CP203

BY001

RY020

CV282

+

CR113

RR338

1

1

+

RY024

CY013

RV262

25

41

CA012

RY006

+

RR189

CA515

+

24

1

CV264
RV265

RR300

RV264

CV261
CV263

CR186

CR188

8

CA255

CA018

IC006

RP002

RY023

CV234

+

1

16

CR190

RR337

RR301

10

FDU04

X

BA001

CA500

W

CA501

+

+

28

IA500

V

1

+

CA504

CA520

+

+

U

CA081

CA503

CA080

BX130

LA231

T

CA232
LA230
CA230

BP002

1

S

R

Q

P

N

M

L

K

J

H

G

F

RR122
RR121

E

RR140

D

JR184

RR029

+

C

B

A

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

MAIN BOARD - PLATINE PRINCIPALE - CHASSIS GRUNDPLATTE - PIASTRA PRINCIPALE - PLATINA PRINCIPAL

RR130

RR402

LV230

CV238
LV231
CV240

BR005

JR141

CR008

CP100

CR068

TR015

RR064

BP001

1

TR140

RR026

TR023

RR028

RR065

CV231

JV800

BV201

+

1

43

+

TR141

RR068

TV203

RR066

FDU02

+

TR148

CR024

CP023

CP002

IP004

CV239

RV233

IP005

CA518

IP001

RV209

RV211

RV231

1

JR149

CR065

TR024

10

RX222

IY002

CY012

CR163

CR185

TR149

RX525

CP006

1

RV234

JV001

RR138

RR015

CR167

CR061

LX224

CV207

TV210

JV003

24

TR146

RX224

CR164
CR162
CR161

CR058
CR057
RR009

TR061

DR800

RX221

80

TR147

+

5

8

+

20 8

+

+

IA300

RA024

+

RY034

RV202

80

+

157

1

RY001

CV280

RR157

RR332

BR001

+

RA025

DC025

RC025

CP003

RY045

CY025

CY037

CV107

1

CR159
CR184

JR325

50

TC015

RY012

RY041

RR156

7

CC041

LV204

1

65

31

CC025

CY030

CY031

RV111

RR183

IR001

CA302

QY001

CY038

+

CV119

RR331

80

40

1

RA002

30

CR183

CR160

DH001

CH019

4

RA001

LA006

CA036

+

51

1

RY044

CY007
+

CY029

CY004

1

60

TV100

RV115

BR200

RR151

CY005

CY006

+

80

RR306

+

+

CV100

61

RV167

RR184

CC026

1

RV119

RV118

1

CA037

RC021

+

RV201

RV162

RR054

QA001

+

CY011

RV150

RR152

CR053

RR053

CR079

RR312

RR310

RR308

RC020

RR150

RR307

54

6

BH001A

+

IC040

RV160

CV130

RR072

RR330

RR311

RR309

RR316

1

BR002

1

6

CA027

+

+

K

+

CY002

+

RV132

4

IR005

5

RR073

IR130

IR110

+

+

1

TV107

RR313

+

+

+

+

TV102

CH020

RY043

BX423

CR211

24

RR314

CH006

CH007

CH016

CH021

CH017

TC056

25

1

CR071

CR081

X12

TC055

DC024

+

+

CV144

QV100

RV161

1

8

DR210

CA048

CA028

+

CY008

+

RR106

RR107

TC051

CY001

RR082

CR070

BX422

LA004

+

RR341

CR082

1

CA031

+

1

RC042

RC052

CY009

TV105

TV104

CY003

+

20

1

CR083

TR216

80

TC040

BARCODE-STICKER

5

LA005

RA027

CA032

+

CP005

LC013LC010

+
CC084
TC070

100

LC067

RC067

CC068

CC071

CC069

TC100

CC101

LC104

CC103

LC102

81

CC107

RC100

RC101
CC121

TC120

CC123

RC123

LC124

LC122

RC120

PCB MAIN IFC228 (EU)

2139297D

RV128

RV302

DV103
DV102

CV125
RV129

RV981

DV101

1

RV146

RV145

CV127

RX195

RX900

RX456

16

IX410

1

RX617

CX452

CX451

RX453

1

BX420

CX431

RX422

CR055

CR106

RR340

CR210

RR200

11

IR006

10

TR211

TR212

RR211

TR217

TR215

1

RR212

TR213

1

TR214

48

RR315

28

JR210

27

+

CR250

5

IP003

CC105

CC125

LT623

RR213

RR215

TR210

TV111

CX455

TX461

RT059
CT636

RT628
CT633

RR210

LC066

CC064

TC125

RV147

+

RX459

CX453

RX510

RX430

RX466

LT622

DC06

LC065

TC105

RC125

CC127

1

RX612

RX615

9

JV100

8

1

4

RC064

LC070

TV110

LT621

4

TC107

RV980

10

RX439

RX436

4

RC062

TX486

TX431

TC065
TC063

RC126

IV101

RX191

RX193

CX454

RX429

CT650

CT653

CT643

+

CP008

TC127

CC140

DV104

1

CX445

LT643

CT656

RC060

JX407

RX454

TX432

TX462

RT627

CT644

+

LT644

IT502

+

TC061

RX492

TX485

CX444
RX443

+

+

RX442

RX441

RX440

RX469

CT635

8

9

CT632

CT692

IC00 1

TC132

RC128

TV109

RX490

TX463

LT641

IT503

DT509

CX183
20

RX486

RX464

CC145

CX476

LX472

CX470

+

+

CT652

9

RC130

8

9

TX484

RX446

+

LT642

CT655

CT647

CT529

8

BT501

CA042

+

CV128

CV129

11

1

+

CX462

RX488

RX447

CX474

CT634

RT626

CT649

CT648

RT637

RC132

RC133

RV155

+

CV117

JX408

RV154

RX461

RX450

RX482

IX400

CT621

CT654

CT69 1

CT502

1

16

RC113
RC112

CV116

RX448

CT631

+

BH001B

TC112

RC110

+

CV120

+

RV158

RV121
RV133

RX484

TX483

25

36

RT058

RT057

21

CT651

33

CT645
CT646

+

DT501

DT502

DT503

3

3

DV100

RV159

RT609

20

34

24

37

+

RT056

TT631

RT519

TX482

RX449

CX422

CX473

RT041

RT632

RX473

TX481

QX471

LX471

LT614

RT516

+

14

RX472

RX494

RT622

X7

1

BR360

+

RV982

LX461

8

RX496

CT618

RT604

16

RT517

RT520

1

16

CT626

1

CT505

CC144

CX423

RX522

CT619
CT622

CT504

RV157

RX474

CX424

RX434

RT634

CT544

CT506

CC003

IC140

RV114

TV106

IX440

8

9
CX491

RT525

RT631

CT624

RT633

+

14

TX152

IX430

TX151

RX152

1

LX473

TX441

+

+

+

NH001

1

RX107
RX560

RX167

JX121

RX154

7

1

RX493

13

CX425

RX409
RX407

RR362

DR362

RR360
DR360

+

+

RT003

TX101

RX561
RX109

RX108

CX222

CX982

RA211

DX172
DX173

48

CX426

LT613

CT625

2

DX175

DX174

CX494

IX420

12

RT610

CT623

IT505

CT541

CT542

CT543

2

RX162

CA211

RX192

1

14

DX408

CX413

1

RX435

TT632

7

8

RT514

JT501

RX103

CX465

CX478

+

RX523

DX407

DT507

RT001

DX164
TX164

RX155

RX553

CX173

LX462

CX406

CT615

CT616

CT617

RX104

+

LT612

8

46

CT620

+

JT502

RX151

TX153

CX404

CX402

47

TR370

DT504

+

RX124

DX102

TX102

CX161

CX151

RX554

7

CR370

RT002

+

CT612

1

IT607

DT603

IT600

CT642

RR370

CX124

DT602

RR366

4

5

RT515

RX105

DX171

CX414

RX126

DX103

+

RX178

+

CT614

DT505

CA203

RX153

RX527

BX120

RX177

DX950

RX601

DX403

DX402

DX401

1

RT523

RX106

DX101

TX163

CX144

CT611

LT611

RT651

RT650

1

1

14

DT001

CA250
RA250

RA202

TX103

RX120

1

RX953

RX410

RX408

CX405

TR365
RR369

1

DT511

DT512

LX161

IX950

CX412

CX410

RR365

DT506

1

RX412

RX413

CT607

8

DT513

RA201

CX112

DX111

RX602

CX408

CT608

4

5

IT620

DT510

CT503

1

CA202

RX110

DX114

DX406

DX405

DX404

RX511

RT603

TT602

IT504

RT513

RA252

CA201

DX112

RX541

RX544

RX411

TT601

DX115

RX414

RT602

CR365

IT63 0

DT002

FDU06

RA200

RX546

RX169

RX513

RX600

RX512

RT524

BT502

16

IT608

LT601
CT602

CA271

DT508

0

X

W

V

U

RT004

1

BT001

T

BX110

LA250

LA201

LA251
CA253
CA200

S
LA200
RX115

RX539

RX117

RX535

RX114

RX540

RX118

RX168

R

RX545

RX113

RX538

RX534

RX119

DX113

RX121

RX231

CT604

BT600

RT601

1

Q

1

P

N

M

L

K

J

H

G

F

E

D

C

B

A

0

IFC228-LCD

First issue 04 / 05

RX543

98

BX400

DT604

1

8

RA271

BA200

1

DIGITAL PROCESSING P.C.B. - PLATINE TRAITEMENT DIGITAL
LTPL. DIGITALVERARBEITUNG - PIASTRA ELABORAZIONE DIGITALE
PLATINA TRATAMIENTO DIGITAL

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI

LADO COMPONENTES

FDU03

FDU07

37

48

4

5

1

36

1

CG261

1

1

IF001

1

27

CA107

1

IA100

8

CG161

CA150

CA207

IG104

IA001

25

24

CF011

6

13

12

FDU12

1

BF111

1

BF110

1

1

1

1

1

FDU08

28

1

1

20

1

1

CP113

IA300

BA103

1

1

CA001

54

10

11

FDU09

IF002

72

EF203

33

25

15

5

1

CF115

48

1

73

108

109

25

IH106

1

24

CG167

1

4

8

5

IG128

14

BP100

PCB DMM03S MPEG/FE SLOT TVD008/IFC228

IF006

CH122

BU300

34

30

20

10

2138224A

2

FDU04

1

1

BT106

CP104

1

1

FDU01

BU301

QF001

CF090

CG163

1

FDU06

1

BI303

37

144

FDU05

157

IG100

36

156

208

1

1

1

FDU10

BM104

1

FDU11

8

7

CG262

1

1

24

EV703

EM404

EF260

1

EM405

EM402

1

1

YE216

CV106

BF109

EF261

1

10

BT107

105

52

BV101

104

53

CA151

24

IE215

14

1

1

CG182

12

13

IV400

6

BF112

BF113

FDU02

SOLDER SIDE - COT

6

BF111

1

1

2138224APCB DMM03S MPEG/FE SLOT TVD008/IFC228

1

1

BF110

1

BF112

1

1

1

BF113

É

CUIVRE - LÖTSEITE - LATO SALDATURE - LADO DEL COBRE

1

70

68

67
65

60

55

50

45

40

35

36

69

BU300

1

1

4

BT106

IFC228-LCD

First issue 04 / 05

BA103

BU301

1

1

1

1 BV101

10

9

BM104

1

BI303

1

1

1

1

1

BP100

14

1

1

4

+3.3VE

+5VA

+12V

DGND

+3.3VE

+8V

+5VFE

MEMORY

(OSC, USB)

CE3OERESET

OE

CE3

RESET

CE3

RESET

CHIP-SET

WEO

OE

MADDR[1:21]

WEO

MADDR[1:21]

WEO

MADDR[1:21]

+1.8V

MD[0:15]

+5VFE

MD[0:15]

MD[0:15]

+3.3VE

FLASH_WP

SMI_CLK

FLASH_WP

FLASH_WP

+5VS

SMI_CLK

SMI_CLK

+12V

+5VA

SMI_DQML

SMI_DQMU

SMI_DQML

SMI_DQMU

SMI_DQML

SMI_DQMU

SMI_WE

+3.3VE

SMI_WE

SMI_WE

SMI_CAS

SMI_CAS

SMI_CAS

SMI_RAS

SMI_RAS

SMI_RAS

SMI_CS0

SMI_CS0

SMI_CS0

DD[0:15]

DD[0:15]

DD[0:15]

BA[0:13]

BA[0:13]

BA[0:13]

SPDIF_OUT

LRCLK

PCMCLK

PCMDAT0

27MHZ

SCLK

27MHZ

27MHZ

FCE_RST

FCE_RST

FCE_RST

DGND

FCE_RST_1

FCE_RST_1

FCE_RST_1

DAC_RST

USB_IRQ

USB_IRQ

USB_IRQ

USB_WE0

USB_WE0

USB_WE0

USB_CS

USB_CS

USB_CS

USB_RST

USB_RST

USB_RST

DVD_WAKEUP_1

DVD_WAKEUP

DVD_WAKEUP

DVD_WAKEUP_1

DVD_WAKEUP

DVD_WAKEUP_1

FRONTEND

DISC_EJECT

DISC_IN

SLIDE_IN

SLIDE_OUT

DISC_IN

SLIDE_IN

SLIDE_OUT

DISC_EJECT

DISC_IN

SLIDE_IN

SLIDE_OUT

DISC_EJECT

DISC_CLOSE

FE_RST_1

FE_RST_1

DISC_CLOSE

FE_RST_1

DISC_CLOSE

+3.3VE

I2C_CLK_FE

I2C_CLK_FE

I2C_DATA_FE

I2C_CLK_FE

C_OUT

+8V

+5VFE

I2C_DATA_FE

SRVO_IRQ

SRVO_IRQ

RS_ECCB_START

SRVO_IRQ

I2C_DATA_FE

CV_OUT

I2C_DATA_TV

RS_DATA

RS_ECCB_START

RS_ERROR_EN

RS_DATA

RS_ERROR_EN

RS_DATA

RS_ERROR_EN

RS_ECCB_START

I2C_CLK_TV

PB/B_H_OUT

Y/G_H_OUT

RS_BCLK

RS_BCLK

RS_DVALID

RS_BCLK

PR/R_H_OUT

RS_DVALID

RS_START

RS_START

RS_START

RS_DVALID

DGND

DRVGND

RS_ERROR

RS_ERROR

RS_ERROR

DMM03S MPEG/FE SLOT TVD008/IFC228

DGND

DGNDDRVGND

DGND

MPEG SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE MPEG - SCHALTBILD MPEG - SCHEMA DELLA PIASTRA MPEG- ESQUEMA DE LA PLATINA MPEG

+1.8V

+5VFE

BLOCK DIAGRAM

+3.3VE

+5VS

AUDIO

SPDIF_OUT

SPDIF_OUT

+12V

+5VA

+12V

+5VA

LRCLK

LRCLK

PCMCLK

+3.3VE

+3.3VE

PCMCLK

PCMDAT0

PCMDAT0

SCLK

DAC_RST

SCLK

DAC_RST

DGND

DGND

LIN_EXT

RIN_EXT

RIN_EXT

LIN_EXT

C_OUT

CV_OUT

I2C_DATA_TV

C_OUT

CV_OUT

AV INTERFACE

+12V

+5VA

LIN_EXT

RIN_EXT

+12V

+5VA

I2C_CLK_TV

PB/B_H_OUT

I2C_CLK_TV

I2C_DATA_TV

+1.8V

+3.3VE

+1.8V

+3.3VE

Y/G_H_OUT

PR/R_H_OUT

Y/G_H_OUT

PB/B_H_OUT

+5VFE

+8V

+8V

+5VFE

PR/R_H_OUT

+5VS

+5VS

DGNDDRVGND

DGND

DRVGND

IFC228-LCD

First issue 04 / 05

+1.8V

DGND

+3.3VE

*

(M)

BT107

1

ET600

+1.8V

80R0

LG163

MPEG SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE MPEG - SCHALTBILD MPEG - SCHEMA DELLA PIASTRA MPEG- ESQUEMA DE LA PLATINA MPEG

OE

CE3

+5VS

+5VFE

100U0

CG261

CG260

100N0

(S)

BM104

+3.3VE

NT178

EM400

10K0

DVD_READY

1

DISC_IN

DISC_EJECT

DISC_CLOSE

FRONTEND INTERFACE

DGND

567

8

432

1

DGND

RESET
USB_IRQ

DVD_WAKEUP_1

SRVO_IRQ
WEO

USB_WE0

DGND

CE3

USB_CS

I2C_DATA_TV

I2C_CLK_TV

DGND

EM401

EM403

EM402

987654321

ET605

MD0

MD[0:15]

EM404

I2C_CLK_FE

I2C_DATA_FE

10

ET606

*

68R0

NT183

ET601

ET602

ET603

ET604

68R0

10K0
68R0

MD1

MD2

MD3

DVD_WAKEUP

RG602

EM405

65432

RS_DATA

DGND

876

123

TCK

TMS

DGND

OE

DGND
DGND
27MHZ

MD4

DVD_RESET

1K0

TDI

MD5

CG505

CG503

RS_BCLK

RESET

5

4

TDO

RG515

RG226
RG514

MD6

1N0

1N0

RS_START

RS_ERROR

RS_DVALID

DT161

LL4448

10R0

RT187

DGND

TRESET

10K0
10K0RG182

68R0
10K0

EH446

DGND

DGND

MD10

MD9

MD7

MD8

DGNDDGND

RS_ERROR_EN

100N0

CG191

RG180

RG508
RG225

CG220 100N0

100N0
CG192

100N0
CG219

MD11

SRVO_IRQ

RS_ECCB_START

+1.8V

+3.3VE

MD15

MD13

MD12

MD14

FE_RST_1

105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156

MEMORY

FE_RST

VSS

TRST
TMS

TDO

TDI

TCK

VSS

IRQ2
IRQ1
IRQ0

VSS

VSS

BA[0:13]

DD[0:15]

DD[0:15]

104

103

PIO53

PIO54

PIO55

AUXCLK
VDD3_3

PWM2
PWM1
PWM0

CPU_OE

CPU_PROCLK
VDD2_5
PIX_CLK

VDD_PLL
VSS_PLL

RESET

CPU_BE0
CPU_BE1
CPU_RW

CPU_WAIT
CPU_CE3
CPU_CE2
CPU_CE1
CPU_CE0

VDD3_3

CPU_RAS1
CPU_CAS0
CPU_CAS1

CPU_DATA0
CPU_DATA1
CPU_DATA2
CPU_DATA3
CPU_DATA4
CPU_DATA5
CPU_DATA6
CPU_DATA7

VDD2_5

CPU_DATA8
CPU_DATA9

CPU_DATA10
CPU_DATA11
CPU_DATA12
CPU_DATA13

CPU_DATA14

CPU_DATA15

157

158

CG195

IR

RG600

100K

2

1

BI303

MD[0:15]

DD15

DD14

102

101

SMI_DATA14

SMI_DATA15

VDD3_3

VSS

160

159

100N0

DGND

DGND

MADDR[1:21]

DD13

DD12

DD11

1009998

SMI_DATA12

SMI_DATA13

CPU_ADR1

CPU_ADR2

163

162

161

MADDR1

MADDR2

MADDR3

MADDR[1:21]

100R0

RG249

DD10

97

96

VSS

SMI_DATA10

SMI_DATA11

CPU_ADR3

CPU_ADR4

CPU_ADR5

165

164

MADDR5

MADDR4

+3.3VE

WEO

SMI_CLK

CG257

DD9

DGND

CG218

100N0

93929190898887

95

94

VDD2_5

SMI_DATA9

SMI_CLKOUT

CPU_ADR6

CPU_ADR7

CPU_ADR8

168

167

166

MADDR6

MADDR7

MADDR8

CG105

RG108

RESET

3P0

180R0

RG250

DD8

SMI_DATA8

CPU_ADR9

169

MADDR9

1N0

DD6

DD7

SMI_DATA7

CPU_ADR10

170

171

MADDR10

4K7

G

RG111

FLASH_WP

DD5

SMI_DATA5

SMI_DATA6

VDD2_5

VSS

172

CG193

DGND

DGND

S

10R0

SMI_CLK

SMI_DQMU

DGND

100R0

RG173

DGND

DD4

DD3

DD2

SMI_DATA3

SMI_DATA4

CPU_ADR11

CPU_ADR12

175

174

173

100N0

MADDR11

MADDR12

100P0

CG104

10R0

RG110

D

TG105

PMBF170N

20P0

CG103

I2C_DATA_TV

DD1

86

85

SMI_DATA1

SMI_DATA2

CPU_ADR13

CPU_ADR14

176

MADDR14

MADDR13

IG100

SMI_WE

SMI_DQML

DGND

3P0

CG256

DD0

DGND

100N0

CG190

84

82

83

81

VSS

VDD3_3

SMI_CLKIN

SMI_DATA0

STM5589

CPU_ADR15

CPU_ADR16

CPU_ADR17

CPU_ADR18

180

179

178

177

MADDR15

MADDR18

MADDR17

MADDR16

DGND

DGND

SMI_CAS

SMI_DQML

SMI_DQMU

79

SMI_DQML

SMI_DQMU

CPU_ADR19

CPU_ADR20

182

181

MADDR20

MADDR19

+3.3VE

SMI_RAS

SMI_WE

787680

77

SMI_WE

CPU_ADR21

183

184

MADDR21

SMI_CS0

SMI_CAS

SMI_CAS

VDD3_3

DGND

SMI_RAS

SMI_RAS

VSS

185

CG196

RG104

G

75

SMI_CS1

PIO00

186

100N0

SMI_CS0

74

SMI_CS0

PIO01

187

USB_RST

RS_ERROR

4K7

RG106

SLIDE_IN

OSCILLATOR

BA12

BA13

BA11

BA10

7372717068

SMI_ADR11

SMI_ADR12

SMI_ADR13

PIO02

PIO03

PIO04

191

190

189

188

FLASH_WP

100P0

CG102

10R0

RG107

S

TG106

D

PMBF170N

10R0

20P0

CG101

I2C_CLK_TV

SLIDE_OUT

BA0

69

SMI_ADR0

SMI_ADR10

PIO05

PIO06

192

DGND

BA1

193

DGND

FCE_RST

BA2

BA3

66

67

SMI_ADR1

SMI_ADR2

SMI_ADR3

PIO07

PIO10

PIO11

195

194

I2C_CLK to TV

I2C_DATA to TV

FCE_RST_1

CG217

100N0

65

VSS

PIO12

196

+3.3VE

+5VFE

BA9

DGND

6362616059

64

VDD2_5

PIO13

198

197

27MHZ

BA8

SMI_ADR8

SMI_ADR9

VSS

VDD2_5

199

CG197

DGND

BA7

SMI_ADR7

PIO14

200

100N0

RT202

BA6

SMI_ADR6

PIO15

201

*

RT201

10K0

*BT106

(M)

USB

BA5

SMI_ADR5

TRIGGER_IM

202

+5VFE

TXD

10K0

*

1K0

RT182

EG300

4

USB_IRQ

BA[0:13]

BA4

RA549

57

58

56

SMI_ADR4

SPDIF_OUT

DAC_LRCLK

PIO20

PIO21

TRIGGER_OUT

203

205

204

RXD

USB_WE0

LRCLK

SPDIF_OUT

100R0

100R0

RA556

DAC_PCMCLK

PIO22

206

RG103

*

RT181

USB_CS

PCMCLK

RA555

54

535255

DAC_PCMOUT1

DAC_PCMOUT2

PIO23

PIO24

207

208

10K0

RG200

100R0

*

100P0

CT215

*

CT216

100P0

1K0

EG301

123

USB_RST

CA578

CA580

CA594

100R0

CA593

DVD_READY

DGNDDGND

DGND

DGNDDGND

DGND

DGND

SPDIF_OUT

SCLK

LRCLK

PCMCLK

DAC_RST

PCMDAT0

AV INTERFACE

I2C_CLK_TV

I2C_DATA_TV

Y/G_H_OUT

PB/B_H_OUT

PR/R_H_OUT

C_OUT

CV_OUT

AUDIO

100P0

5P0

33P0

5P0

DMM03S MPEG/FE SLOT TVD008/IFC228

DGND

DAC_PCMOUT0
DAC_SCLK
VSS
VSS_PCM
VDD_PCM
VDD3_3
PIO47
PIO46
PIO45
PIO44
PIO43
PIO42
PIO41
PIO40
VSS
VDD2_5
I_REF_YC
V_REF_YC
CV_OUT
C_OUT
Y_OUT
VSS_YCC
VDD_YCC
I_REF_RG
V_REF_RG
R_OUT
G_OUT
B_OUT
VSS_RGB
VDD_RGB
PIO52
PIO51
PIO50
B_SYNC
B_FLAG
B_BCLK
B_DATA
VSS
VDD2_5
PIO37
PIO36
PIO35
PIO34
PIO33
PIO32
PIO31
PIO30
VSS
VDD3_3
PIO27
PIO26
PIO25

DGND

CG200

100N0

+3.3VE

FCE_RST_1

+3.3VE

PCMDAT0

SCLK

+1.8V

20P0

CA581

DGND

DGND

80R0

LG162

CG262

CA500

100P0

100N0
CG216

DGND

CV_OUT

C_OUT

RS_ECCB_START

RS_ERROR_EN

DGND

DGND

DGND

DGND

RG161

EG304

54

VSS SDA

PR/R_H_OUT

Y/G_H_OUT

PB/B_H_OUT

10R0

100U0

DGND

CG263

100N0

DGND

DAC_RST

DGND

100U0

CG182

CG165

100N0

80R0

LG161

RG227

+3.3VE

WC

RG228

DGND

Location for Development only
*

+3.3VE

10K0

ED101

SLIDE_OUT

SLIDE_IN

ED100

10K0

+3.3VE

FCE_RST

DG504

LL4448

DVD_RESET

DG503

LL4448

100N0

CG502

+3.3VE

+3.3VE

FE_RST

+3.3VE

RG506

5K6

RG507

RESET

DGND

32

1K0

1

DGND

GND

PST42

IG501

VOUT VDD

EG323

DG501

LL4448

5K6

RG503

DG502

LL4448

FE_RST_1

IFC228-LCD

First issue 04 / 05

RA551

150P0

CA579

100R0

51
50

120R

49

RA550

48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11

10
9
8
7
6
5
4
3
2
1

10K0

RG542

DGND

2K2

RG125

5K6

RG124

CG132

100N0

10K0

IG128

M24C16-WMN6

RG301

RG181

I2C_CLK_FE

0

100N0
CG215

100N0

CG187

10K0

RG164

IR

100N0

CG198

CG163

100U0

CG167

I2C_DATA_FE

RG300

WC

DGND

EG302

786

WC

VCC

E0E1E2

DISC_IN

10K0

RG163

0

100R0
RA500

RS_BCLK
RS_DATA

100U0

RG162

EG303

321

RS_START

SCL

DGND

DISC_EJECT

DISC_CLOSE

RS_DVALID

10R0

BU301

432

DGND

USB_D+

USB_D-

1

VBUS

1N0

CU001

1

DGND

1N0

CU002

DGND

*

1N0

+5VA

CU003

DGND

*

9876543202

+3.3VE

10

USB_IRQ

USB_WE0

OE

USB_CS

USB_RST

MADDR1

191817161514131211

MD1

MD0

MD[0:15]

21

MD2

MD3

MD4

MD5

MD6

MD7

MD8

MD9

MD10

MD11

MD12

MD13

MD14

34333231302928272625242322

MD15

BU300

DGND

MADDR[1:21]

+3.3VE

VSD

MEMORY

MPEG SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE MPEG - SCHALTBILD MPEG - SCHEMA DELLA PIASTRA MPEG- ESQUEMA DE LA PLATINA MPEG

OE

WEO

+12V

DGND

VSS3

VDD1

48

47

BYTE

MADDR16

MADDR15

DD15

DQ15

VSSQ4

DQ0

VDDQ1

CG206

DD0

DGND

MD[0:15]

MD15

46

46

45

VSS1

DQ15A_1

MADDR14

MADDR13

DD13

DD14

DQ13

DQ14

DQ1

DQ2

100N0

DD2

DD1

MEMORY

MD[0:15]

IH106

M29KW016E90N1

MADDR17

80R0

FG163

CG161

100U0

545352515027494847464544434241403938373635343332313029

IG104

IC-SDRAM 64M

1

DD[0:15]

RESET

MD7

44

DQ7

MADDR12

DD12

DGND

100N0

CG213

VDDQ

VSSQ

DD3

MADDR[1:21]

MD6

MD14

43

42

DQ6

DQ14

A105A114A123A132A141A15 A16

A9

6

MADDR11

MADDR10

DD11

DQ11

DQ12

DQ3

DQ4

9

8765432

CG207

DD4

CE3

MD5

MD13

41

40

DQ5

DQ13

A19

9

8A87

MADDR20

MADDR9

+12V

DD10

DQ10

VSSQ3

VDDQ2

DQ5

100N0

DD5

DGND

SMI_CLK

SMI_DQMU

FH122

MD4

MD12

39

38

DQ4

DQ12

A20

W

10

MADDR21

RN2402

DD9

DGND

CG212

DQ9

VDDQ3

DQ6

VSSQ1

DD6

SMI_DQML

+3.3VE

80R0

VFL

37

VCC

12RP11

RH135

WEO

RESET

TH101

DD8

100N0

DQ8

DQ7

1413121110

DD7

SMI_WE

MD11

36

DQ11

NC

13

1K0

DGND

VSS2

VDD2

SMI_CAS

SMI_RAS

CH122

100U0

CH130

100N0

MD3

MD10

34

35

DQ

DQ10

RB

VPP/WP

15

14

WP

TH100

RN1402

FLASH_WP

SMI_DQMU

NC2

UDQM

WE

LDQM

171516

SMI_WE

SMI_DQML

SMI_CS0

DGND

DGND

MD9

MD2

33

32

DQ2

DQ9

A1717A18

16

MADDR19

MADDR18

100N0

CH101

10K0

RH104

SMI_CLK

DGND

CG211

CKE

CLK

CAS

RAS

18

SMI_CAS

SMI_RAS

DD[0:15]

MD8

MD1

31

30

DQ1

A7

19

18

MADDR8

MADDR7

BA11

100N0

A11

NC1

CS

BA0

BA12

SMI_CS0

BA[0:13]

MD0

29

DQ0

DQ8

A5

A6

20

MADDR6

DGND

DGND

DGND

BA9

A9

BA1

BA13

BA[0:13]

FLASH_WP

OE

27

28

G

A4

22

21

MADDR5

MADDR4

BA7

BA8

A10/APA0A1

BA0

BA10

VSS

A3

MADDR3

BA6

BA1

26

E

A2

23

DGND

CE3

BA5

25242322212019

DGND

25

A0A1

24

MADDR2

BA4

A2

26

BA2

BA3

OSCILLATOR

MADDR1

28

A4A5A6A7A8

VSS1

A3

VDD3

CG210

100N0

DGND

DGND

DGND

+3.3VE

27MHz

+3.3VE

OSCILLATOR

FCE_RST

FE216

+3.3VE

FCE_RST_1

80R0

100N0

CE218

1N0

CE217

IE215

USB

+5VA

USB_CS

USB_IRQ

USB_RST

USB_WE0

MEMORY

DMM03S MPEG/FE SLOT TVD008/IFC228

27MHZ

24P0

CE254

1K0

RE229

0R

RE230

8

9

DGND

10

1213

7

AC

11

EE150

EE151

DGND

DVD_WAKEUP_1

DGND

246

14

3

1

FCE_RST_1

DVD_WAKEUP

FCE_RST

5

DGND

1M0

RE219

RE231

430R0

CE220

YE216

27M0

CE223

20P0

20P0

DGND DGND

IFC228-LCD

First issue 04 / 05

+3V3A

TF014

BC848C

CF039

RF057

5K6

CF038

1K0

RF056

RF097

TF013

2SC3650

DISC_CLOSE

(M)

1

ED102

20368950

BF113

4

3

DGND

2

1

100N

CF157

(M)

BF112

DGND

3

Y1

2

1

MPEG SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE MPEG - SCHALTBILD MPEG - SCHEMA DELLA PIASTRA MPEG- ESQUEMA DE LA PLATINA MPEG

I2C_CLK_FE

I2C_DATA_FE

10K0

RF078

10K0

RF079

102

103

STB2/PD4

STB3/PD3

TST_ADC

VCCA18

LD1

TF009

1K0

100K

E

RF145

DGND

101

10K0

EESDA

EESCL

99

100

STB4/PD2

INTB1/PD0

INTB2/PD1

TST_PM

TST_SLICE

9876321

10

B

CF060

100P0

CF059

100N0

1K0

RF023

BC848C

DGND

DGND

DGND

REFD

EF251

19220

RF073

100R0

DGND

DGND

10K0

RF144
*

98

97

DMASDA/PE4

SCL/TX/MISO/PE3

IF002

GNDMN

A

B

DGND

A

RF086

10U0

CF004

RF024

DGND

+5VP

RF124

DGND

SRVO_IRQ

RF075

100R0

CF079

EF203

CF077

RF133

100R0

SEL-CD

CF083

100N0

92

939495

96

VDD3-3

VSS-ESD-1

DRVRDY/RECRDY/PE1

INTB5/SCK/HSTRDY/PE0

INTB4/SDA/RX/MOSI/PE2

IC-PROCESS

L6315(ATTBTZ)

REFD

VCC33MN

VCCA18IS

VCCA18MN

D

15

14

131211

C

DGND

DGND

10K0

DGNDDGND

DGND

100R0

SEL-CD

LD-D

10K0

RF125

RF126

4K7

TF022

BC848C

B

C

M5

HF

212223

DGND

DRVGND

+3V3A

100P0

+3V3D

QF001

DGND DGND

CF158

+5VFE

DM-

CF090

1N0

100U0

DGND

100P0
CF053

100N0
CF052

+V1833

20M0

CF045

CF043

CF042 CF044

TM-

FE_RST_1

I2C_CLK_FE

IF006

DGND

DGND
DGND
DGND
DGND

CF055

100N0

DGND

100P0

CF054

+3V3D

1M0

RF062

SREG1

SREG2

LCREF

10N0

VBGFILT

10U0

10N0

1U0

DGND

+5VFE

LIMIT

10K0

RF009

1N0

CF001

LM+
LM-

DM+
DM­TM­TM+

TM+
1

+8 V

+3.3VE

+5VF E

+3.3VE

150P0

RF168

RF167

CF155

LM­1

LF014

1K 100R

CF156

DGND

100N0

+3VXA

+3VXA

5
6
7
8

5
6
7
8

100N

47K

47K

100N

120R0

LF008

CF089

+3V3D

RF065

100P0

CF051

DGND

DGND

CF047

100P0

DGND

56P0

CF150

2U7

TF015

470R

NF101

470R

NF100

DGND

DGND

LIMIT

(M)

65432

BF111

1N0

FE_RST_1

100R0

DGND

DGND

CF041

CF040

18P0

CF152

2SA1037K

EF272

100N0

100P0

LF015

120R0

DGND

CF078

15P0
CF049

15P0
CF048

+3VXA

DGND

DGND

DGND

4
3
2
1

4
3
2
1

DGND

DM+

LF013

120R0

*

1N0

CF088

+V1833

4U7

100N0

CF050

DGND

CF046

DGND

4U7

DGND

2K2

+1V8A1

CF153

6P8

CF151

RF150

RF151

DISCIN_LED

RF169

10K0

EJECT_LED

DGND

DISC_IN

DISC_EJECT

Y2

1

ED103

1

ED104

LM+

(M)

2

BF110

SRVO_IRQ

I2C_DATA_FE

RS_ECCB_START

+5VFE

LF016

120R0

3

LD1117DT

OUT IN

2

+3VXA

DGND
DGND

DGND

DGND
DGND

DGND

DGND

FA+

(M)

1

BF109

RS_BCLK

RS_DATA

RS_ERROR_EN

10U0

CF115

+5VS1

CF114

1

GND

243R0
RF118

10U0

CF113

10N0
CF057

20K0

RF064

+3VXA

LD1
LD2

MD

+5VXA

20R0

RF016

RF012 20R0

EF260

TF004

KTA1664Y

LF001

120R0

10K0

RF121

RF120

100K0

FA-

TA-

TA+

3456789

RS_START

RS_DVALID

10U0

412R0

RF119

+V1833
DGND
+3V3D

+1V8A1
SPINDLE
SLEDGE

REFDAC
FACT
TACT

FREOUT
FREIN

RF013 220R0

1K0

RF010

+5VP

D

MD

SLIDE_IN

RS_ERROR

SLIDE_OUT

DISC_EJECT

DGNDDGND DGND

DGND

VPP_TEST

109

VCCO_BYP

110

VCCO_OUT

111

VSS-2

112

VDD3S-3

113

VSS-ESD-2

114

VDD3-5

115

RESET_N

116

VCC18DAC

117

SPINDLE

118

SLEDGE

119

REFEXT

120

REFGND

121

REFDAC

122

FACT

123

TACT

124

GNDDAC

125

NC-2

126

VCC33DAC

127

NC-3

128

GNDPLL

129

PLLOFF

130

FREOUT

131

FREIN

132

VCCPLL

133

SREG1

134

VCCR33

135

SREG2

136

LD1

137

LD2

138

VCCA33

139

LCREF

140

LMD1

141

LMD2

142

GNDL

143

VBGFILT

144

LD2

RF087

10K0

1K0

RF014

10U0

CF003

TF005

100R0

RF015

BC848C

DF001

DAP202U

DGND

10K0

RF122

RF123

100K

DGNDDGND

TF021

BC848C

G

S

DGND

TF020

2SK3018

LD-C

LD-D

VR-CD

VR-DVD

101112131415161718

DGND

DISC_IN

+3V3D

RF128

DISC_CLOSE

DGND

108

12K7

RF067

DGND

DGND

DGND

TF008

LF002

DGND

+5VP

100K0

D

+5VP

*

47K0

10K0

10K0

RF025

RF077

RF026

EE-WC

107

105

104

106

VDD3-4

VSS_ESD

STB0/PD6

INTB3/SPISSN/PD7

GNDAI

IREF

RFIN

RFSACD

5

4

DGND

+5VXA

RF022

220R0

KTA1664Y

120R0

RF130

10K0

RF129

TF024

BC848C

G

S

TF023

2SK3018

A

D

SW-CD

STB1/PD5

RFOUT

RF020

10K0

RF131

120P0

100P0
CF080

100P0

+3V3D

91

90

OUT_DATA6

OUT_DATA7

1

VCCA33IS

C

D

CF063

100N0

100P0

CF062

10K0

22N

CF120

F

24

DGND

DGND

CF084

100P0

88

89

87

OUT_DATA3

OUT_DATA4

OUT_DATA5

STD

GNDAIS

VCC18SD

VCC33SD

22

20211925181617

EF270

DGND

DGND

100K

DGND

RF127

DGND

DGND

RS_BCLK

RS_ERROR_EN

RS_DATA

RS_ECCB_START

56R0

56R0

56R0

75R0

RF135

RF136

RF080

RF134

LF010

86

85

OUT_CLK

OUT_DATA0

OUT_DATA1

OUT_DATA2

F

GNDSD

VSHEILDIS

E

23

26

DGND

E

F

CF065

100N0

CF064

100P0

+3VXA

PS

10K0

RF028

DRVGND

RS_DVALID

RS_START

RS_ERROR

56R0

56R0

56R0

RF082

RF081

RF132

120R0

828384

OUT_ERR

OUT_SYNC

OUT_DVALID

VCCADC

VDDADC

VSSADC

27

29

DGND

DGND

DRVEN

12K

RF027

DRVGND

*

*

DGND

OUT_REQ

VSS-COMP

GNDADC

30

DGND

+5VFE

10K0

RF108

15P0
CF130

15P0

CF131

15P0

CF109

15P0

15P0

CF108

15P0

15P0

+V1833

7778798081

76

VDD3S-2

RAM_DQ7

NC-1

VSHEILDADC

3235283124

33

47K0

RF070

DGND

CF070

100P0

CF069

100N0

RF029

DRVGND

DGND

CF110

CF107

CF132

CF086

100P0

DGND

100N0

CF085

75

74

73

RAM_DQ4

RAM_DQ5

RAM_DQ6

PCO/S1B/INTA2

VDD3-1

BOOT_MODE/DMASCL

ESD-VSS-1

36

34

CF071

DGND

FG

DGND DGND

RF041

SLEDGE

1K0

RF032

15K0

RF031

1N5

16K5

CF013

8K2

RF047

DGND

SLIDE_OUT
SLIDE_IN

DRVGND

22N0

CF012

100U0

CF011

DRVGND

1N0

CF159

+8V

LM-

30K1

EF261

100N0

CF028

13
14
15
16
17
50
18
19
20
21
22
23
24

CF154

LF012

RF045

DGND

120R0

CF111

1N5

1U0

+5VFE

+5VXA

5P0

CF072

SPINDLE

30K9

20K0

RF110

44K2

RF030

IN5­OUT5
CTL
FWD
REV
SGND
DRVGND2
MUTE12
MUTE34
MUTE5
TSD-M
PVCC2
DO6-

LM+

2N2

CF087

DGND

RAM_DQ3

72

RAM_DQ2

71

RAM_DQ1

70

RAM_DQ0

69

VSS-1

68

VDD3-2

67

VDD_SPL

66

RAM_CLK

65

RAM_A9

64

RAM_A8

63

RAM_A7

62

RAM_A6

61

RAM_A5

60

RAM_A4

59

RAM_A3

58

RAM_A2

57

RAM_A1

56

RAM_A0

55

RAM_A10

54

RAM_A11

53

RAM_A12

52

RAM_A13

51

RAM_RASN

50

RAM_CASN

49

RAM_WEN

48

RAM_DQM

47

VSS_SPL

46

VDD3S-1

45

ESD-VSS-2

44

PC7/INTA5

43

PC6/INTA4

42

PC5

41

PC4/INTA3

40

PC3/S2A

39

PC2/S2B/INTA1

38

PC1/S1A

37

+3V3D

100P0

DGND

9K53

RF042

1K0

RF034

CF014

12

INT5+

DO6+

PGND2

25

DRVGND

EF253

EF252

DGND

DGND

DGND

CF025

20K0

RF043

DGND

RF036

1N5

11

10

IN4+

OUT4

INT4-

OUT3

FAN8035L

D04-

D05-

DO5+

D04+

51

29

282726

TM+

TM-

DM-

DM+

LF003

600R0

CF076

100P0

100N0

CF075

CF074

CF073

100P0

DGND

LIMIT
DRVEN

PS

1N5

RF050

13K3

CF020

DRVGND

49

741354

IN3-

DRVGND1

IF001

D03-

DRVGND3

30

EF255

EF254

+5VXA

+5VP

+3V3D

+V1833

100N0

TACT

17K8

180P0

689

IN3+

D03+

3331323436

DRVGND

EF256

OUT2

PGND1

EF257

100P0

DGND

CF006 CF007

DGNDDGND

CF005

22N0 100P0

FRONTEND

DMM03S MPEG/FE SLOT TVD008/IFC228

DGNDDRVGND

0

0

0

RF170

1K0

RF104

REFDAC

FG

FACT

DGND

22P0

CF029

1K0

12K4

RF044

RF051

DGND

17K8

RF037

CF021

1

2

IN2-

IN1-

IN2+

OUT1

IN1+
OPIN1+
OPIN1-

OPOUT1

SVCC
VREF

DRVGND4

OPIN2+
OPIN2-

OPOUT2

PS

PVCC1

D01+

DO1-

DO2+

DO2-

35

EF258

TA-

TA+

FA+

RF161

CF102

48
47
46
45
44
43
52
42

40
39
38
37

CF030

180P0

CF026

100N0

EF259

2N2

FA-

DGND

180P0

RF162

RF048

RF049

DRVGND

RF102

DGND

17K8

19K1

CF104

FACT

0

RF165

1N5

33K0

DRVGND

90R9
RF105

8K25

RF103

180P0
CF106

RF038

1K0

1K0

0

RF166

Prepared Location

*

DGND

10N0

DGND

CF027

1K0

DGND

RF052

17K8

CF022

180P0

RF095

33K0
RF098

33K0
RF101

RF099

+5VFE

RF106

10K0

RF035

LF006

120R0

+5VFE

CF023

100N0

CF100

237R0

BIAS_IN

2N2

22N0

CF018

1U0

CF017

100P0
CF019

RF011

RF100

RF039

2K55

FG

1K0

20K0

DRVGND

100N0

CF103

REFDRV

100R0
RF107

DRVGND

REFDAC

DGND

DGND

DM+

DM-

IFC228-LCD

First issue 04 / 05

RA103

24K3

+12V_OP

CA105

560P

CA103

120P

CA100

100N

EA007

RA105

DGND

RA101

CA101

RA107

CA107

8

5K6

24K3

1U

100R

10U

DGND

2

LIN_EXT

1

3

CA108

IA100

MC33078

4

5K6

RA106

RA102

24K3

1U

CA102

IA001

+3.3VE

100P0

120P

CA106

560P

CA104

CS4391

RA104

DGND

DGND

DGND

24K3

DGND

LA001

20

18

19

AOUTA-

AOUTA+

AMUTEC

RST4SCLK3SDATA

VL

1

2

10U0

+12V

+5VA

DGND

+3.3VE

EA008

+12V_OP

120P

CA205

24K3

RA203

560P

CA203

+5VA

100U

CA001

DGND

CA002

100N0

DGNDDGND

1U

CA004

16

15

14

13

12

AOUTB+

AOUTB-

BMUTEC

CMOUT

11

FILT+

M09M18M27M36MCLK

10

100N

CA003

17

VA

AGND

LRCK

5

RA205

DGND

RA201

CA201

RA207

CA207

8

5K6

24K3

1U

DGND

100R

10U

6

RIN_EXT

7

5

DGND

DGND

IA100

MC33078

4

RA206

RA202

CA202

1U

CA005

CA006

CA208

CA206

5K6

24K3

1U

100N

LIN_EXT

RIN_EXT

100P0

120P

RA204

560P

CA204

DGND

24K3

DGND DGND

DGND

+12V

DGND

DGND

DAC_RST

+12V +12V_OP

SCLK

PCMDAT0

100K

RA150

10U

LA150

LRCLK

PCMCLK

CA151

RA151

47U

CA150

SPDIF_OUT

100U

100K

DGND

DGND

DGND

+5VA

+3.3VE

CA303

10N0

CA220

IA300

100N

AUDIO

(M)

BA103

1

EA010

DGND

12UH

LA300

DGND

5

74VHC1G04

3

2

DGND

27P

CA300

DGND

5P0

CA302

DGND

560R

RA300

4

321

DGND

MPEG SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE MPEG - SCHALTBILD MPEG - SCHEMA DELLA PIASTRA MPEG- ESQUEMA DE LA PLATINA MPEG

EA009

DAC_RST

EA002

EA003

SCLK

PCMDAT0

EA004

LRCLK

PCMCLK

EA005

SPDIF_OUT

IFC228-LCD

First issue 04 / 05

C_OUT

+5VS

#

IV400

0R0

RV120

MM1621

CV107

CV108

LP100

Y/G_H_OUT

+5VS

RV112

10U0

100N0

+5VS

10U

+5VA

@

100R0

CV100

VCC1

VCC2

24 1

@

RV121

RV100

1U0

RV124

CP113

0R0

162R0

2

23

DGND

DGND

75R0

100U0

C_IN

C_OUT

#

RV101

RV122

1K0

322

MUTE1

GND2

DGND

@

CV101

DGND

#

RV125

DGND

0R0

470N0

4

NC

CVBS_OUT

21

0R0

RV129

75R0

CV_OUT

@

TV100

RV103

DGND

5

GND1

CVBS_SAG

20

@

RV130

RV115

DGND

EV706

RV123

BC858C

1M0

0R0

75R0

RV102

6

Y_IN

GND2

19

DGND

CV

0R0

162R0

CV106

22U0

DGND

718

BIAS

Y_OUT

DGND

8

GND1

Y_SAG

17

#

EV704

DGND

DGND

CV104

DGND

RV117

PR/R_H_OUT

1U0

9

CB_IN

GND2

161415 10

DGND

75R0

Y/G

MUTE2

CB_OUT

EV705

RV118

11

CR_IN

75R0

PR/R

+12V

PB/B_H_OUT

RV111

1U0

CV105

DGND

1213

GND2

CR_OUT

GND2

DGND

RV119

EV703

RV110

75R0

+5VA

162R0

162R0

PB/B

+3.3VE

DGND

DGND

*
*

*
*

*
*

*
*

+1.8V

RV128

CV110

CV112

RV127

CV113

CV114

RV126

75R0

+8V

+5VS

+5VFE

inserted for US models

#

SYMBOL DESCRIPTION

75R0

DGND

47P0

DGND

47P0

DGND

75R0

47P0

DGND DGND

47P0

DGND

DGND

DGND

DRVGND

AV INTERFACE

Prepared Location

inserted for EUROPE models

**

@

+5VA

+12V

POWER

EP550

DGND

1

(M)

BP100

LIN_EXT

RIN_EXT

Y/G_H_OUT

PB/B_H_OUT

PR/R_H_OUT

LIN_EXT

RIN_EXT

(S)

2101

BV101

+3.3VE

TV_POWER_ON/DC_OC_ON

1N0

CP109

1N0

CP114

1N0

CP106

1N0

CP107

1N0

CP108

EP552

EP553

DGND

EP551

C_OUT

CV_OUT

PR/R

EP554

DGND

DGNDDGNDDGND

DGND

DRVGND

I2C_CLK_TV

CP103

I2C_DATA_TV

DGND

Y/G

PB/B

TV_POWER_ON/DC_OC_ON

1N0

9876543

+5VFE

+8V

+1.8V

EP556

EP555

141312111098765432

CV

CP117

CP110

CP104

CP112

CP115

CP111

1N0

1N0

100U0

1N0

1N0

1N0

DGND

DGND

DGND

DRVGND DGNDDRVGND

MPEG SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE MPEG - SCHALTBILD MPEG - SCHEMA DELLA PIASTRA MPEG- ESQUEMA DE LA PLATINA MPEG

IFC228-LCD

First issue 04 / 05

RX303

9

RX302

RX802

16

IX300

CX30 4

8

CX303

1

CX300

BX012

5

6

1

2

4

7

FDU03

RX253

RX256

CX213CX21 2

1

8

LX030

BX013

FDU04

CX027

14

16

CX070

+

15

RX354

RX377

RX025
RX026

RX027

QX001

BX003

BX004

RX376

CX003

CX004
CX005

CX071

FDU07

+

A1

IX001

1

SX001

CX100CX092 CX087

+

CX21 5

RX25

1

85

RX158

RX038

1

CX21 4

RX255

RX156

1

RX150

RX153

20

10 0

LX03

RX258

CX217

RX157

RX148

80

21

RX217

CX174

RX147

RX155

CX181

CX182

+

CX216

RX149

RX209

LX032

FDU09

61

40

81

1

60

41

FDU14

IX014

CX185

RX216

80

RX25

1

2

13

14

BX008

RX218

CX037

1

CX038

+

1

2

CX053

+

CX16

4

IX007

RX159

+

9

+

RX208

RX211

+

RX212

RX215
RX213
RX353

+

CX054

RX151

RX152

RX181
RX180
RX179
RX178
RX177
RX176

1

16

FDU06

1

BX002

4

1

BX005

4

+

1

4

5

FDU05

+

30

29

32

RX041 RX040 RX039

IX004

RX046

50

RX049
RX050
CX010

51

IX003

17

13

14

IX015

21

LX016

20

CX029CX192

LX010

RX196

RX001

RX205

RX109

RX203

RX359

RX191

RX200

RX195

+

+

CX105

CX109

RX006

RX204

RX206

RX268

RX270

T3.15A,125V

BX001

RX192

RX199

CX01 1

RX364

RX365

RX368

PCB SCALER IFC228

2

+

DX003

1

CX030

FZX002

+

+

CX032

IX005IX006

RX386
RX801

6

DX002

+

CX033

RX110

BX017

9

+

TX004

2

CX002

3

IX301

4

30

CX001

4

IX009

5

+

1

8

1

6

1

FDU08

+

+

+

CX01 2

RX366

RX367

RX369

2138804C

30

FDU1 3

CX03 4

31

CX113

CX114

FDU02

BX007

FDU01

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

SCALER BOARD - PLATINE SCALER - SCALER GRUNDPLATTE - PIASTRA SCALER - PLATINA SCALER

29

1

IFC228-LCD

First issue 04 / 05

VCC

GND

OUT

TTT

GM1501

SYSTEM

FSCLK+ AND FSCLK-SHOULD BE ROUTED LIKE A DIFFERENTIAL PAIR

PPWR

PBIAS

IFC228

TCLK

XTAL

to LCD PANEL

LAYOUT IMPORTANT NOTES:

PLACE SERIES TERMINATION RESISTORS ON BIDIRECTIONAL LINES FSDATA AND FSDQS MIDWAY BETWEEN GM1501 AND K4D263238M

MAX TRACE LENGTH FOR FS ( DATA, ADDR AND OTHER FS ) IS 2.5 INCHES

MINIMIZE TRACE LENGTH DIFFERENCE BETWEEN FSDQS AND FSDATAS AND AMONG DATA LINES

PLACE SERIES TERMINATION RESISTORS ON ALL FSADDRESS AND FS CONTROL LINES NEAR K4D263238M

UNLOADED TRACE IMPEDANCE ONTHIS INTERFACE IS 90 OHM , LOADED TRACE IMPEDANCE WITH DRAM LOAD IS 65 OHM

CATER FOR EXT RESET

SCALER MODULE

CATER FOR 8BIT INPUT

CATER AS GPIO (INPUT) PORT

OCMADDR(0..19)OCMDATA(0..7)

SV_INPUT

TMDS

FSADDR(0..11)

FS

FSDATA(0..31)

DVI/VGA_INPUT

24_BIT_ADC

PLACE NEAR IX001

PLACE NEAR BX004

EDID

SV_INPUT

CIRCUIT DIAGRAM SCALER BD

2135258C

SCALER_GM1501 IFC228

RX001 0R

RX002

0R

3V3

TXB0-

1

2

BX017

UXGA CONNECTOR

2

1

SX001

RESET

GND

12345678910111213

14

BX003

1

10111213141516

2345678

9

BX004

RX115

0R

DVI_SDA

VCC_PANEL

GND

VGA_SCL

RX376

0R

TXD

RXD

RX374

0R

EDID

EDID

RX116

0R

TXB1 +

RX3730R

RX3720R

RX3710R

TXB0 -

RX3700R

RX3560R

GND

RX3690R

DOBLU7

RX3680R

RX3670R

RX3640R

RX3660R

DOBLU4

RX36 50R

TXA0 -

TXA0 +

RX3630R

RX3620R

RX3610R

TXAC-

RX3600R

DORED4

RX3590R

RX3580R

RX3570R

DVSYNC

DCLK

TXA3 +

DENABLE

DHSYNC

IX001

DOBLU5

DOGRN5

TXAC+

DORED2

FSBKSEL1_

RX355

0R

AD10
AE10

AF9

AE9

AD9

AC9

AF8

AE8

DOBLU9

DOBLU8

DOBLU6

DOBLU3

DOBLU2

TXA1 -

TXA1 +

TXA2 -

TXA2 +

DORED3

DORED5

TXA3 -

RX354

0R

DVI_SCL

RX353

0R

GND

RX005

0R

RX282

0R

RX283

0R

RX004

0R

5V0

AT005

FCT150

FCT150

AT004

AT003

FCT150

3V3_LBADC

TXB2-

TXA0-

TXA0+

TXA2-

9

87654

30

3

29

2827

2625

2423

2221

20

2

19

1817

1615

1413

1211

10

1

BX001

2CH LVDS

AE4

AF5

AC5

SOG_ADC

V_CLAMP

VHS_CSYNC

VVS

VODD

DGG0

DGR7

DGR6

DGR5

DGR4

DGR3

DGR2

DGR1

DGR0

DGB4

RX219

0R

GND

RX028

249R0 1%

RX26 7

0R

AF4

AF4
AE4

AE5

AD5

AE7

RX270

0R

RX26 9

0R

RX26 8

0R

RX207

0R

AE5

AF5

AD5

RX250

10K

RX251

10K

RX021

2K7

RX190

10K

12345678910111213

14

BX008

ADIN2

ADIN 2

RX211

0R

ADIN1

RX210

0R

3V3_DIG

BLUE-

ADIN 1

1

2

3

4

BX005

67186011

UART

RX212

0R

QX001

14.318MHZ

AC5

RX033

10K

GND

GND

GND

1

2

3

4

BX002

JTAG

CX007

10NF

SOG

CX006

10NF

CX195

10NF

CX194

10NF

RX246

75R

RX245

22R

RX244

22R

RX243

22R

RX242

75R

RX241

75R

RED+

GREEN+

SOG

RX029

470R0

BLUE+

CX005

10NF

AE10

GND

GND

2

3

1

IX002

DS1811R-10

RX027

56R0

CX003

10NF

CX004

10NF

RX0060RRX109

0R

RX024

33R0

RX215

0R

SVCLK

RX218

0R

RX213

0R

RX025

56R0

RX026

56R0

CX008

22PF

RX032

3K3

RX030

5K6

RX198

0R

RX022

2K7

RX023

3K3

RX205

0R

RX206

0R

RX204

0R

RX197

0R

RX203

0R

RX202

0R

RX201

0R

RX200

0R

RX199

0R

RX196

0R

RX195

0R

RX194

0R

RX193

0R

RX192

0R

RX191

0R

RX175

0R

RX183

10K

RX179

0R

CX009

22PF

RX189

10K

RX188

10K

RX187

10K

RX186

10K

RX185

10K

RX184

10K

RX182

0R

RX181

0R

RX180

0R

RX178

0R

RX177

0R

RX176

0R

3V3_DVI

5V0

3V3_PLL

SVDV

SVDATA0

SVHSYNC

SVVSYNC

SVODD

SVDATA3

SVDATA1

SVDATA2

SVDATA4

SVDATA5

SVDATA6

SVDATA7

AD14

AE13

AE11

AD11

AC11

AF10

AD1

AF9

AE

AD9

AC9

AE8

AF8

FSDQS

FSD2

FSD1

FSD8

FSD9

DGB3

AE11

TXBC+

DGG4

DGG3

DVI_SCL

OCMDATA7

OCMDATA6

OCMDATA5

OCMADDR11

OCMADDR10

OCMADDR9

OCMADDR8

OCMADDR19

OCMADDR18

OCMADDR17

OCMADDR16

OCMADDR15

OCMADDR14

OCMADDR13

OCMADDR12

BLUE+

GREEN+

RED+

VGA_SC L

AHSYNC

AVSYNC

VGA_SDA

DGG6

DGG1
DGG2

DGG5

DGG7
DGB0
DGB1
DGB2

DGB5
DGB6
DGB7

VCLK

SVDATA5

SVDATA2

SVDATA0
SVDATA1

SVDV

SVDATA3
SVDATA4

SVDATA6
SVDATA7

SVODD
SVVSYNC
SVHSYNC
SVCLK

OCMDATA4

OCMDATA3

OCMDATA2

OCMDATA1

OCMDATA0

AE7

AE13

TXB0 +

TXB1 -

TXB2 -

TXB2 +

AD14

TXBC-

TXB3 -

TXB3 +

AD11

AC11

AF10

FSD16

FSD0

FSD19

FSD3

FSD4

FSD5

FSD6

FSD7

FSD10

FSD11

FSD12

FSD13

FSD14

FSD15

FSD17

FSD18

FSD20

FSD21

FSD22

FSD23

FSD24

FSD25

FSD26

FSD27

FSD28

FSD29

FSD30

FSD31

DOGRN2

FSBKSEL0_

/FSWE_

FSCKE_

/FSRAS_

/FSCAS_

FSDQM0_

FSDQM3_

FSDQM2_

FSDQM1_

FSAD0
FSAD1
FSAD2
FSAD3
FSAD4
FSAD5
FSAD6
FSAD7
FSAD8

FSAD9
FSAD1 0
FSAD1 1

FSCLK+

FSCLK-

3V3_LBADC

1V8_CORE

GREEN-

RED-

PWM0

MSTR_SC L

MSTR_SD A

/OCM_WE

/OCM_RE

/ROM_CS

GM_INTERRUP T

2V5_DDR1

3V3_LVDSB

3V3_LVDSA

3V3_LVDS

FSVREF

1V8_DVI

3V3_DVI

1V8_ADC

3V3_ADC

3V3_PLL

PPWR

JTAG_TMS

JTAG_TDI/SDA

PBIAS

JTAG_TDO

3V3_DIG

JTAG_TCK/SC L

GND

CX001

22UF

CX002

100N

TXAC+

TXAC-

TXA1+

TXA1-

TXBC-

TXBC+

TXB2+

TXB0+

TXB3-

TXB1-

TXA3-

TXA2+

TXB3+

TXB1+

TXA3+

GND

GM_BUSY

RX377 0R

VGA_SDA

DVI_SDA

GND

OCMADDR7

OCMADDR6

OCMADDR5

OCMADDR4

OCMADDR3

OCMADDR2

OCMADDR1

OCMADDR0

3V3_DIG

UART_TX_ 1

AVSYNC

AHSYNC

UART_RX_1

D_GND_1

D_GND_10

D_GND_11

D_GND_12

D_GND_13

D_GND_14

D_GND_15

D_GND_16

D_GND_17

D_GND_18

D_GND_19

D_GND_2

D_GND_20

D_GND_21

D_GND_22

D_GND_23

D_GND_24

D_GND_25

D_GND_26

D_GND_27

D_GND_28

D_GND_29

D_GND_3

D_GND_30

D_GND_31

D_GND_32

D_GND_33

D_GND_34

D_GND_35

D_GND_36

D_GND_37

D_GND_38

D_GND_39

D_GND_4

D_GND_40

D_GND_41

D_GND_42

D_GND_43

D_GND_44

D_GND_45

D_GND_46

D_GND_47

D_GND_5

D_GND_6

D_GND_7

D_GND_8

D_GND_9

OCMADDR0

OCMADDR1

OCMADDR10

OCMADDR11

OCMADDR12

OCMADDR13

OCMADDR14

OCMADDR15

OCMADDR16

OCMADDR17

OCMADDR18

OCMADDR19

OCMADDR2

OCMADDR3

OCMADDR4

OCMADDR5

OCMADDR6

OCMADDR7

OCMADDR8

OCMADDR9

OCMDATA0

OCMDATA1

OCMDATA10

OCMDATA11

OCMDATA12

OCMDATA13

OCMDATA14

OCMDATA15

OCMDATA2

OCMDATA3

OCMDATA4

OCMDATA5

OCMDATA6

OCMDATA7

OCMDATA8

OCMDATA9

VSSA18_DLL

P11

M14

P13

U13

R14

R12

R16

K13

M16

N15

K15

T14

K25

T15

P14

L14

K12

R15

P15

M15

L15

A13

AD4

AF3

AE3

AD3

R10

AF2

N10

N17

P16

R11

N11

M11

U15

T12

P12

N12

M12

M13

L12

K14

T10

T13

L10

R13

N13

L13

U12

Y1

V4

U1U2U3

U4

T1T2T3

Y2

Y3

W1W2W3

V1V2V3

AB1

AB2

AB3

AA1

AA2

AA3

AE2

AD2

AF1

AE1

AD1

AC1

AC2

AC3

U14

N14

B13

N16

A0+
A0-

A1+
A1-

A2+
A2-

A3+
A3­AC+
AC-

ADC_AGND_1

ADC_AGND_2

ADC_AGND_3

ADC_AGND_4

ADC_AGND_5

ADC_DGND_1

ADC_DGND_2

B0+
B0-

B1+
B11

B2+
B2-

B3+
B3­BC+
BC-

DCLK

DEBLU0

DEBLU1

DEGRN0

DEGRN1

DEN

DERED0

DERED1

DERED2
DERED3
DERED4
DERED5
DERED6
DERED7
DERED8
DERED9

DHS

DOBLU2
DOBLU3
DOBLU4
DOBLU5
DOBLU6
DOBLU7
DOBLU8
DOBLU9

DOGRN1

DOGRN2
DOGRN5

DORED2
DORED3
DORED4
DORED5

DVI_GND_1

DVI_GND_2

DVI_GND_3

DVI_GND_4

DVI_GND_5

DVI_GND_6

DVI_GND_7

DVS

D_GND

D_GND_48

D_GND_49

D_GND_50

D_GND_51

D_GND_52

D_GND_53

FSADDR0
FSADDR1

FSADDR10
FSADDR11

FSADDR2
FSADDR3
FSADDR4
FSADDR5
FSADDR6
FSADDR7
FSADDR8
FSADDR9

FSBKSEL0
FSBKSEL1

FSCAS

FSCKE

FSRAS

FSVREFVSS_1

FSVREFVSS_2

FSWE

JTAG_CLK

JTAG_MODE

JTAG_RESET

JTAG_TDI

JTAG_TDO

LBADC_GND

LVDSB_GND_1

LVDSB_GND_2

LVDSB_GND_3

NC

OEXTR

PBIAS

PPWR

SHIELD-0
SHIELD-1
SHIELD-2
SHIELD-3

SHIELD-4
SHIELD-5

VSSA33A_LVDS_1

VSSA33A_LVDS_2

VSSA33A_LVDS_3

VSSA33_DDDS

VSSA33_FPLL

VSSA33_RPLL

VSSA33_SDDS

VSSD33_DDDS

VSSD33_LVDS

VSSD33_PLL

VSSD33_SDDS

AB24

AC26

AB25

Y24

AA26

AA25

AA24

AB26

AC25

AC24

AD26

AD25

V25
V24
W26

V26

Y26

Y25

AD1

8

AE18
AF18

AC1

8

AF19
AE20
AF20

AE19

AD22
AE21
AF21

AD21

AF22
AE23
AF23

AE22

AD24
AE24
AF24

AD23

AF26
AE25
AE26

AF25

AF8
AC9
AD9

AE8

AF9
AD10
AE10
AF10
AC11
AD11

AF11
AF12

AF13

AE9

AD14
AF14
AE14
AF15
AE15
AF16
AE16
AC7
AF17
AD16
AD7

AE13

AF7
AE7
AF6
AE6
AD6
AF
AE5
AD5
AC5
AF4
AE4

AD8

B26
AC17

K4

J4
H2
H4
G2

A26

B5
D11
A11
D7
C7
B7
A7
E4
C4
E1
A5

D13

D4
B4
W24
K26
AD17
AD19
AC20
AC19
AC15
AC14

L17

R17

P17

P10

AC13

E2

F3

AD15

AE12

AE11

J2

AC16

M10
M17

ADC_1.8_1

ADC_1.8_2

ADC_3.3_1

ADC_3.3_2

ADC_3.3_3

ADC_3.3_4

DVI_1.8_1

DVI_1.8_2

DVI_1.8_3

DVI_1.8_4

DVI_3.3_1

DVI_3.3_2

DVI_3.3_3

DVI_3.3_4

DVI_3.3_5

FSCLKN

FSCLKP

FSDATA0

FSDATA1

FSDATA10

FSDATA11

FSDATA12

FSDATA13

FSDATA14

FSDATA15

FSDATA16

FSDATA17

FSDATA18

FSDATA19

FSDATA2

FSDATA20

FSDATA21

FSDATA22

FSDATA23

FSDATA24

FSDATA25

FSDATA26

FSDATA27

FSDATA28

FSDATA29

FSDATA3

FSDATA30

FSDATA31

FSDATA4

FSDATA5

FSDATA6

FSDATA7

FSDATA8

FSDATA9

FSDQM0

FSDQM1

FSDQM2

FSDQM3

FSDQS

FSVREF_1

FSVREF_2

FS_2.5_1

FS_2.5_10

FS_2.5_11

FS_2.5_12

FS_2.5_13

FS_2.5_14

FS_2.5_15

FS_2.5_2

FS_2.5_3

FS_2.5_4

FS_2.5_5

FS_2.5_6

FS_2.5_8

FS_2.5_8

FS_2.5_9

LBADC_33

LVDSA_3.3_1

LVDSA_3.3_2

LVDSA_3.3_3

LVDSB_3.3_1

LVDSB_3.3_2

LVDSB_3.3_3

VDDA33_DDDS_1

VDDA33_DDDS_2

VDDA33_FPLL

VDDA33_PLL

VDDA33_RPLL

VDDA33_SDDS_1

VDDA33_SDDS_2

VDDD33_LVDS

L26

U23

U24

U25

U26

T24

T25

F26

F25

F24

G25

G23

H25

J26

K24

R24

R26

P25

N23

M24

M26

L24

M25

N26

N24

P26

P24

J25

H24

H26

G24

G26

N25

E24

L25

J1J3H1H3G1F2F4E3D3B3A2A4C6C8C10

C11

D10D9D8D6W25

J24

AE17

AC21

AC22

AD20

AD13

AD12

F23

W23

AB23

AA23

Y23

R23

V23

T23

L23

P23

M23

J23

H23

C13

AC12A3E23

C9

R25

T26

E25

E26

AC23

/OCM_CS0

/OCM_CS1

/OCM_CS2

/OCM_INT1

/OCM_INT2

/OCM_RE

/OCM_WE

/RESET

/ROM_CS

ACS_RSET_HD

AHSYNC
AVSYNC

BLUE+

BLUE-

CORE_1.8_1

CORE_1.8_10
CORE_1.8_11
CORE_1.8_12
CORE_1.8_13

CORE_1.8_2
CORE_1.8_3
CORE_1.8_4
CORE_1.8_5
CORE_1.8_6
CORE_1.8_7
CORE_1.8_8
CORE_1.8_9

DVI_SCL
DVI_SDA

EXTCLK

GREEN+

GREEN-

IO_3.3_1

IO_3.3_10
IO_3.3_11

IO_3.3_2
IO_3.3_3
IO_3.3_4
IO_3.3_5
IO_3.3_6
IO_3.3_7
IO_3.3_8
IO_3.3_9

IR0

IR1

LBADC_IN1

LBADC_IN2

LBADC_IN3

LBADC_RETURN

MSTR_SCL
MSTR_SDA

NC_1
NC_2

NC_3

NC_4
NC_5

OCM_TIMER1

OCM_UDI

OCM_UDO

PWM0
PWM1
PWM2

RED+

RED-

REXT

RX0+
RX0­RX1+
RX1­RX2+
RX2­RXC+
RXC-

SOG

SVCLK

SVDATA0
SVDATA1
SVDATA2
SVDATA3
SVDATA4
SVDATA5
SVDATA6
SVDATA7
SVDV

SVHSYNC

SVODD
SVVSYNC

TCLK

VBLU0
VBLU1
VBLU2
VBLU3
VBLU4
VBLU5
VBLU6
VBLU7

VCLAMP

VCLK

VDDA18_DLL

VDV

VGA_SCL
VGA_SDA

VGRN0
VGRN1
VGRN2
VGRN3
VGRN4
VGRN5
VGRN6
VGRN7

VHS_CSYNC

VODD

VRED0
VRED1
VRED2
VRED3
VRED4
VRED5
VRED6
VRED7

VVS

XTAL

Y4

AB4

W4

AA4

D22

AC10

AC8

AC6

AC4

D23

K16

U16

U11

L1

T16

T17

L11

K10

K17

U17

T11

K23
K11

L1

R1

R2

R3

P3

P4

M3

M4

K1

M2

D16

C14

B14

A14

M1

D14

A15

C15

D15

A17

B16

C16

D12

C12

B12

A16

A12

B15

D26
D25

C26

B17

D19

C20

C25

A20

B23

C23

A24

B24

B20

D24

A25

B25

A21

D20

C21

B22

C22

B21

C17

A18

B18

D18

A23

B9

B8

B19

C19

N1

K2

K3

F1

G3

G4

R4

L3

L4

N2

A1

C5

D5

B6

A6

B10

A10

C3

D2

D1

C2

C1

B2

B1

B11

A8

A9

T4

P1

P2

A19

N4
N3

A22

L2

D21

C18

C24

D17

U10

SCALER SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE SCALER - SCHALTBILD SCALER - SCHEMA DELLA PIASTRA SCALER - ESQUEMA DE LA PLATINA SCALER

IFC228-LCD

First issue 04 / 05

1V8_ADC

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

CX038

CX037

CX11 6

CX11 5

CX052

CX051

CX050

CX049

CX048

CX047

CX046

CX045

CX044

CX043

CX042

CX041

CX040

CX039

22UF 10V

22UF 10V

GND

3V3_LBADC

GND

100N

CX196

100N

CX069

100N

CX068

CX067

100N

CX066

100N

CX065

100N

CX064

100N

CX063

100N

100N

CX062

CX061

100N

CX060

100N

CX059

100N

CX058

100N

CONNECT CAP FROM EACH GM1501 SUPPLY PIN BALL TO GROUND

CX057

100N

CX056

100N

CX055

100N

22UF 10V

CX054

22UF 10V

CX053

1V8_DVI

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

CX071

CX070

CX086

CX085

CX084

CX083

CX082

CX080

CX081

CX079

CX078

CX077

CX076

CX075

CX074

CX073

CX072

22UF 10V

22UF 10V

FSVREF

GNDGND

100N

CX11 4

100N

CX11 3

100N

CX099

100N

CX098

100N

CX097

100N

CX096

100N

CX095

100N

CX094

100N

CX093

22UF 10V

3V3_PLL

CX092

100N

CX197

100N

CX091

100N

CX090

100N

CX089

100N

CX088

22UF 10V

CX087

GND

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

CX109

CX105

CX100

CX11 7

CX11 2

CX11 1

CX11 0

22UF 10V

CX108

CX107

CX106

22UF 10V

CX104

CX103

CX102

CX101

22UF 10V

DIFFERENTIAL PAIR
BE ROUTED LIKE A

to IC

/FSCAS

/FSCAS_

/FSRAS

/FSRAS_

FSCKE

5

4

FSCKE_

RX046

876

123

33R

50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26

FSBKSEL1

FSBKSEL0

5

4

_

FSBKSEL0_

FSBKSEL1

RX045

FSCLK-

FSCLK+ AND FSCLK-SHOULD

33R

RX044

FSDQS

FSCLK+

33R

FSVREF

FSADDR0
876

123

FSAD0

FSADDR1

FSAD1

10K 1%

RX049

FSADDR10

FSADDR11

FSADDR2

FSADDR3

876

5

123

4

FSAD2

FSAD3

FSAD10

FSAD11

FSADDR(0..11

RX050 10K 1%

FSADDR9

FSADDR4
5

4

FSAD9

FSAD4

100N

33R

RX043

143R

GND

76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95

FSDATA29

FSDATA28

876

123

FSD28

FSD29

FSDATA31

FSDATA30

5

4

FSD30

FSD31

96
97
98
99
100

FSDATA4

FSDATA6

FSDATA5

FSDATA3

FSDATA2

FSDATA1

FSDATA0

876

876

5

33R

33R

33R

RX038

RX039

RX037

123

123

4

FSD3

FSD4

FSD5

FSD6

FSD2

FSD0

FSD1

GND

FSDATA27

FSDATA26

FSDATA25

FSDATA24

FSDATA14

FSDATA10

FSDATA11

FSDATA12

FSDATA13

FSDATA15

FSDATA8

FSDATA9

33R

876

5

876

5

876

5

33R

GND

123

RX034

FSD10

FSD9

FSD8

33R

RX036

RX035

123

4

4

123

4

FSD27

FSD11

FSD13

FSD15

FSD14

FSD12

FSD25

FSD26

FSD24

FSDATA(0..31

)

IX003

123456789

FSDATA16

FSDATA7

876

5

33R

RX040

123

4

FSD16

FSD7

(DDRAM)

TQFP-100

K4D263238M-QC55

FSDATA20

FSDATA21

FSDATA22

FSDATA23

FSDATA19

FSDATA18

FSDATA17

876

5

5

33R

RX041

123

4

4

FSD23

FSD19

FSD18

FSD17

FSD20

FSD21

FSD22

MIDWAY IN BETWEEN IX001 AND IX003
PLACE RX024, RX034 - RX041 IN

OCMADDR1 4

292827

101112131415161718192021222324

OCMADDR8

OCMADDR9

OCMADDR1 3

26

RX048

close

place

**

51525354555657585960616263646566676869707172737475

25

FSDQM3

FSDQM1

FSDQM0

FSDQM2

/FSWE

876

876

5

33R

RX047

123

123

4

FSDQM0_

FSDQM2_

FSDQM1_FSDQM3_

/FSWE_

FS

MAX LENGTH FOR FS (DATA, ADDR AND FS LINES) IS 2.5 INCHES

MINIMIZE LENGTH DIFF. BETWEEN FSDQS,FSDATAS AND DATA LINES

PLACE RESISTORS RX042-RX047 NEAR IX003

/OCM_RE

/ROM_CS

OCMDATA7

OCMADDR1 0

OCMADDR1 1

2122232425

CX010

FSADDR5

FSADDR6

876

123

FSAD5

FSAD6

FSADDR7

FSAD7

)

FSADDR8
5

4

FSAD8

RX042

33R

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

100N

CX01 2

CX01 1

2V5_DDR2

CX026

CX025

CX024

CX023

CX022

CX021

CX020

CX01 9

CX01 8

CX01 7

CX01 6

CX01 5

CX01 4

CX01 3

22UF

22UF

GND

1V8_CORE

SCALER BOARD REGULATOR/POWER

SCALER SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE SCALER - SCHALTBILD SCALER - SCHEMA DELLA PIASTRA SCALER - ESQUEMA DE LA PLATINA SCALER

3V3_DVI

3V3_ADC 3V3_LVDSA 3V3_LVDSB 3V3_LVDS

LX01 0

3V3_DIG

2U2 0.5A

RX260 2K2

1V8_DVI

LX01 4

2U2 0.5A

TX003

BC846B

RX0612K2

2K2

RX261

1V8_ADC

LX01 5

2U2 0.5A

RX2380R

0R

RX350

RX351 100K

GND GND

TX002

RX05910K

1V8_CORE

LX01 6

BC846B

BC846B

RX06210K

TX005

RX058

FB 3AMP

RX06410K

100K

RX352

TX001

4K7

RX0604K7

BC846B

100N

30

OCMADDR1 7

31

/OCM_WE

32

3V3_DIG

1

PBIA S

PWM0

OCMADDR1 8

2

OCMADDR1 6

3

OCMADDR1 5

4

OCMADDR1 2

IX01 5

25407730

32 PIN PLCC SOCKET

SOCKET FOR FLASH PL 032 PACKAGE

RX01 20R

RX220

10K

56789

OCMADDR7

RX226

RX222

10K

OCMADDR6

10K

OCMADDR5

RX227

10

11

12

13

OCMADDR1

OCMADDR0

OCMADDR2

OCMADDR3

OCMADDR4

10K

RX228

10K

RX223

OCMDATA0

10K

3V3_DIG

10K

RX224

10K

20

OCMDATA6

19

OCMDATA5

18

OCMDATA4

17

OCMDATA3

16

15

OCMDATA2

14

OCMDATA1

OVERLAPPING WITH IX004 ( FLASH MEMORY )

32 PIN PLCC SOCKET TO BE PLACED

CIRCUIT DIAGRAM SCALER BD

SCALER_GM1501 IFC228

SCALER MODULE

/ROM_CS

/OCM_RE

/OCM_WE

CX028

100N

22UF

CX027

RX225

10K

10K

CX035

10K

RX235

RX252

RX233

10K

RX232

RX231

10K

OCMADDR11

10K

OCMADDR10

10K

RX234

OCMADDR8

OCMADDR9

OCMADDR18

OCMADDR16

OCMADDR15

OCMADDR14

OCMADDR13

OCMADDR10

OCMADDR19

OCMADDR9

OCMADDR11

OCMADDR8

VAL?

RX221

10K

RX055

RX230

10K

RX229

10K

RX056

OCMADDR12

OCMADDR17

OCMADDR19

0R

RX262

100N

CX200

OCMADDR13

OCMADDR14

OCMADDR(0..19)

IX004

OCMADDR17

AM29LV040B

32

FLASH MEMORY

1234567

OCMADDR18

OCMADDR15

OCMADDR12

OCMADDR16

2728293031

OCMADDR6

OCMADDR7

8

OCMADDR5

OCMADDR4

OCMADDR3

242625

9

10111213141516

OCMADDR1

OCMADDR2

OCMADDR0

OCMDATA0

OCMDATA1

OCMDATA2

17181920212223

GND

OCMDATA7

OCMDATA3

OCMDATA4

OCMDATA5

OCMDATA6

OCMDATA(0..7)

IFC228-LCD

First issue 04 / 05

3V3_DVI

2U2 0.5A

LD1117DT1 8

RGP15G

3V3_DIG

3V3_PLL

LX005

2U2 0.5A

100UF

100UF

100UF

IN OUT

CX034

CX033

CX032

LX006

470N

3V3_LVDS A

2U2 0.5A

CX031

47UF

CX029

47UF

CX192

10UF

CX030

123456789

LX007

GND GN D

3V3_LVDSB

2U2 0.5A

LX008

3V3_LVDS

2U2 0.5A

GND

3V3_LBADC

LX009

2U2 0.5A

RX06310K

3V3

GND

2V5_DDR1

3V3_ADC

2V5_DDR 1

2V5_DDR 2

LX01 2

2U2 0.5A

LX024

3V3

RX057

IX005

2U2 0.5A

LX01 3

2U2 0.5A

39R 0.25W

LD1117DT33

5V0

LX004

1V8

IN OUT

IX006

LX01 1

2U2 0.5A

2V5

DX003

RGP10G

PANEL_V

DX002

RX801 0R

RX386 0R

6V0

4V0

PANEL_V

BX007

SCALER SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE SCALER - SCHALTBILD SCALER - SCHEMA DELLA PIASTRA SCALER - ESQUEMA DE LA PLATINA SCALER

!

3.15A

3.15A,125V

PANEL_V

5V0

FZX002

IX009

NTTS2P02R2

RX065

100N

CX036

IX007

M24C32-WMN

8

S
1

CX160

2K7

RX066

VCCA0

21348360

1

D

47K

1UF

2K7

7863254

WP

A1

RX111

MSTR_SCL

SCK

A2

VCC_PANEL

24_BIT_ADC

VODD

V_CLAMP

DGR7

DGR6

DGR5

DGR4

DGR3

DGR2

DGR1

SVDV

1

47 R

RX148

4

1

RX147

47R

8

8

5

0R

RX208

VAL?

RX209

0R

RX216

SCALER MODULE

567

DDD

SSG

432

MSTR_SDA

SI

VS S

DGR0

4

5

TX004

BC846B

VCLK

VHS_CSYNC

RX110

RX149

IX301

PPWR

VVS

1

47R

8

DEV?

4K7

SOG_ADC

D

S

GND

GND

4

5

MSTR_SDA

MSTR_SCL

PANEL_V

678

DDD

SSG
321

5V0

RS232 LINE DRIVER/RECEIVER

DGG6

DGG7

RX150

ADCK
ADHS

ADVS

GM_INTERRUPT

GM_BUSY

BX012

100N

CX305

0R

RX802

16

IX300

RS232 DRIVER/RECEIVER

21345

100N

100N

CX300

DGG3

DGG4

DGG5

4

1

47R

5

8

1

80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61

60

100N

CX191

100R0
RX158

100R0

RX159

RX156

100R0

SDA_ADC

65432

CX301

DGG2

2

100N

DGG1

SDA

GREFBYP

RX157

SCL_ADC

TXD

RXD

6

100N

CX303

DGG0

1

47R

RX151

8

53545556575859

A0

SCL

GRIN

1UF

CX190

0R

RX255

100R0

GND

1

TO GENCAM IC

UART_TX_1

UART_RX_1

0R

0R

RX303

RX302

9101112131415

7

8

CX304

DGB5

DGB6

DGB7

4

4

1

5

5

8

121314151617181920

11109857643

IX014

21341310

AD9883A

525150494748464544

GGIN

GSOGIN

1UF

CX187

1N

CX189

0R

RX254

RX152

RX253

47R

CX186

0R

DVI_VGA_AUD

BX015

VGA_R_IN

4K7

RX259

GND

DGB0

DGB1

DGB2

DGB3

DGB4

4

1

47R

RX153

5

8

RX217
21
22
23
24
25
26
27
28
29

GCOAST
30
31
32
33

GFILT
34

PVDD
35
36
37

GMIDV
38

CLAMP
39

AVDD
40

414243

GBIN

CX185

100N

1UF

2P2F

CX212

2P2F

CX214

2P2F

2U2H

LX032

CX216

RED_IN

GREEN_IN

1

CX204

330P0

RX263

100K0

220P0

CX200

0R

LX0312U2H

BLUE_IN

TO MAIN BOARD

BX013

LX0302U2H

VSYNC

VGA_L_IN

GNDGND

GND

HSYNC

8765432

54321

RX260

3V3

330P0

CX205

100K0

RX264

4K7

CX201

220P0

1234567

Red

GND

100N

CX170

CX173

RX155

CX183

CX213

CX215

CX217

GND

DVI_L_IN

GNDGND GND

4K7

RX261

GND

8

BX016

Red

Whi

Whi

DVI_VGA_AUD

10UH

10UH

10UH

LX021

LX022

LX023

V33_3V3

DVDD_3V3

AVDD_3V3

47UF

CX169

CX171

100N

CX172

100N

100N

3N9

CX181

3K3

39N

CX182

100N

100N

CX184

33PF

VAL?

RX256

VAL?

33PF

RX257

33PF

VAL?

RX258

CX174

CX175

CX176

CX177

CX178

CX179

CX180

330P0

100K0

220P0

47UF

100N

100N

100N

100N

100N

100N

CX206

RX265

CX202

DVI_R_IN

GND GND GND

GND

CX207

330P0

RX266

100K0

GND GND

4K7

RX262

GND

220P0

CX203

IFC228

SCALER_GM1501 IFC228

CIRCUIT DIAGRAM SCALER BD

Some Models

USE IFC228 CI ( 028 ) ONLY

IFC228-LCD

First issue 04 / 05

3.3VSTBY

3V9

DP250

(3,5)

T1.0A_125V

FZP207

GND

220uF

CP206

GND

P

10.5V

845R0

RP483

RP484

2K1

2K2

RP401

10N0F

CP483

2,5

3,5

TP201

5,6

STP22NF03L

IP201

(5,6)

TL431

(6,4)

6,5

COLD

HOT

Utilice solo piezas originales

Pieza de seguridad

To LP008 PFC coil (Europe)

Bei Ersatz nur Originalteil verwenden

Sicherheitsbauteil

Per la riparazione utilizzare solo componenti originali

Componenti di sicurezza

Safety Part

When repairing, use original part only

Pièce de securité

N'utilisez que les pièces d'origine

Universal

NEUTRAL

EARTH

connector

mains

T# 21371920

LIVE

6V

P

T3.15A_125V

FZP203

6VA

20V

6

GND

2K2

RP417

GND

TP203

STP22NF03L

6.5V

C

DP203

A2 A1

STPS30150CT

GND

2N2

CP215

H

BP008B

BP008A

WP235A

10M

RP225

BP251A

BP251B

FROM MAINS CORD

T3.15A_125V

FZP201
P

CP485

10N0F

CP202

1500uF/35V

CP203

RP419

1500uF/35V

JP201

GND

GND

DP218

DP201

6K2

GND

SR560

SR560

2,4

IP203

GND

4V

TL431

RAW_B+

DP252

DP253

BP006B

1MI0

CP201

CP208

3k92

RP418

BP226

(TVD ONLY)

CP255

GP30M

CP254

GP30M

3

4

220uF

GRAY

BP226C

1

2

BLACK

BP226A

255

1N5

1N5F

VAL

CP251

2

1

25mH

LP250

*

100N0

CP250

GND

GND

GND

RP404

GND

TO DVD

INTERFACE

1

2

1

2

*

CP259

CP258
*

CP256

DP255

GP30M

DP254

GP30M

VAL

RP251

5VSTBY

P

T1.0A_125V

FZP208

10.5V

5,4

(5,4)

2K2

CP484

TP202

STP22NF03L

12

(11,8)

10.5V

RED

BP226B

GND

47uF

HH

270uF

1N5

H

BP006A

6V2

DP260

220uF

CP207

+5VE

2K43

RP415

RP416

10N0F

7,4

IP202

TL431

(7,4)

RP258

180K

(EUROPE)

FP251

T2.5AL_250V

T5.0AL_250V(PLASMA)

5.0A_125V(US)

TO FAN MODULE

GND

2

GND

2

220uF

GND

3K92

RP414

GND

IP214

TL431XX

1MI0

5

6

3U3H

LP225

12

DP226

DP225

RGP10G

RGP10G

18,2

RP495

(16,3)

*

CP225

CP224

POWER_FAIL

0R

RP448

DP247

RGP15G

GND

GND

4

33N

CP226

470P0

CP493

22K0

DP227

BZX55B27

22U0

22U0

CP247

20.5V

3

4u7F

RP494

DP493

TP495

H

H

H

10V

JP416

BZT55C3V3

DP416

1

GND

BP204

JP415

GND

DP415

BZT55C3V3

1

BP203

GND

2K1

CP209

18K0

RP412

GND

CP486

20V

10N0F

12

(0)

2K2

(0)

RP413

TP204

17,3

STP22NF03L

CP204

(11,8)

DP204

SR560

P

T3.15A_125V

FZP204

GND

10111213141516

LP253

SMT_P50

*

7

89

H

V_PRI

RP257

180K

VCC1

BP400

PUSH SWITCH MODULE

SP400

(EUROPE ONLY)

GND

TP205

DP205

FZP205

2

10K0

BZT52C8V2

BC858B

RP227

550Vpp

20V

JP420

(0)
21

KTC8550D

RGP15G

P

T0.5A_125V

1

3K3

21,2

RP205

CP237

RP293

CP210

3K9

RP485

(23)

390R/2W

CP205

1N5

22K0

22uF

20,4

(23)

22uF

CP239

DP237

JP453

2

SWITCH

TO PUSH

LP220

1n5

CP220

1U5H

33V

GND

4K7

RP209

45.0V

GND

CP236

DP206

RGP15G

P

T0.5A_125V

FZP206

180P0

CP438

H

BAV21

RP238

1

BP253

MODULE

22R0

RP221

12

H

TP220

3K3

RP208

10uF

20.5V

180P0

470R0

2,1

6N90

(EU)

(US)10N60

(0,7)

RP492

TP407

GND

RP467

DP240

RP240

RP441

2K2

2K2

RP207

BC848B

2K7

BZX55B27

2K2

47K0

KTC8550D

TP223

1,9

DP233

PO

20.5V

RP486

1N5

CP481

10.5V

6.5V

1

4

10U0

CP240

(0,1)

BZX55B15

47K0

RP233

1nF

CP233

RP472

2K2

22K0

RP468

A

C

IP251

DP230

RP230

22U0

CP271

RP473

GND

GND

GND

5K6

K

E

TCET1103G

BZX55C8V2

H

1K0

(0)
0,1

10R0

RP231

23

2K2

DP472

DP471

BZT52C3V9

BZT52C4V7

22K0

RP471

25,3

(23,6)

BAV21

DP273

2K2

RP470

17-02-05

C

+5VE

10K

RP465

CCT_DIAG_SMPS_100G_IFC228

4K7

8V2

DP261

RP464

2K2

RP463

TP261

BC548

6K2

RP461

2n2

3K92

CP268

RP462

IP261

TL431

RP226

2K7

(0)

0,4

(0,1)

RP228

22R0

1,8

TP222

BC548B

S

μ

25

0R68

RP220

RP476

0,2

TP271

GND

GND

CP222

6.5V

33K

IP271

(0,2)

BC548B

RP466

RP469

470P0

H

100K

TL431

RP475

RP474

22K0

GND

GND

GND GND

SMPS_100G

BURST

100R

2K2

10N

CP461

GND

* VALUE MAY CHANGE ACCORDING TO SPECIFIC REQUIREMENT

H

Attenzione :

misure nell'alimentatore primario

- usare massa alimentazione primario (H).

Cuidado :

H

Medida en el bloque de alimentacion

8Vpp

Note :

Power Supply primary circuit measurements.

- Use only (H) connection point.

Attention :

Mesure dans la partie primaire de l'alimentation

Use isolating mains transformer.

Utiliser un transformateur isolateur du secteur.

Einen Trenntrafo verwenden.

Utilizar un transformador aislador de red.

Utilizzare un transformatore per isolarvi dalla rete.

Part of board connected to mains supply.

Partie du châssis reliée au secteur.

Primärseite des Netzteils.

Parte dello châssis collegata alla rete.

Parte del chassis conectar a la red.

- Utilizar la masa del bloque de alimentacion (H).

Achtung :

Bei Messungen im Primärnetzteil

- Primärnetzteilmasse verwenden (H).

- Utiliser la masse du bloc alimentation (H).

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

IFC228-LCD

First issue 04 / 05

To

board

BP001

board

signal

To

GND

GND

123456789

BP220

20V

33V

5VSTBY

GND

3.3VSTBY

10

6V

6V

10V

GND

To

8

PO

GND

board

signal

BURST

SAFETY#

ECO_STBY#

POWER_FAIL

JP452

BP002

1234567

BP220A

JP451

scaler

To

123456789

BP222

GND

GND

VBRI

*

VON/OFF

board

4V

JP426
*

BP320

6VA

GND

JP425
*

Inverter

To

123456789

VBRI

VSEL

+VSSIN

+VSSIN

+VSSIN

JP501

board

VON/OFF

101112

GND

GND

GND

Audio

123

4

BP321

-UA

+UA

GND

GND

COLD

HOT

(0)

12

TP302

STP22NF03L

18

(16,3)

DP301

RGP10G

CP302

RP302

CP301

13,8

3K9

RAW_B+

22uF

15K

RP503

22uF

H

CP503

IP303

RP301

H

S

μ

15

10N0F

TL431

22K

(292)

225

DP325

RP504

0

(0)

RGP10G

110K

RP515

3K92

TP503

BC848B

DP391

BYW98-200

LP300

SMT_P200

*

250Vpp

175

H

H

+14,8

FZP371

T3.15A_125V

DP371

BYW98-200

10911

7

8

TP322

14NK50

(0)

170

RP326

10K0

DP326

(PREP)

39R

RP325

CP325

100nF

1234567

4u7

CP315

CP516

27K

RP517

+UA

+VSSIN

(+0,7)

19

(2,2)

1000uF/25V

CP371

GND

P

JP301

C

DP381

STPS30150CT

12

131415

4

5

6

TP321

14NK50

(0)

5,2

39R

DP323

RP323

RGP10G

0

5,3

10K0

RP521

10111213141516

IP300

L6598

89

680pF

33K

RP519

4K3

39K

RP511

RP516

*

A2 A1

RP510

CP518

BURST

CP382

CP381

*

0

RP324

DP324

1500uF/35V

1500uF/35V

DP372

GND

3

10K0

(PREP)

H

5K1

100nF

GND

GND

T3.15A_125V

FZP391

BYW98-200

2

RP328

R100/3W

*DP328

2.Diode_2V7

1K

RP327

22uF

*CP328

H

-UA

-14,8

16

1

P

(-0,3)

CP391

DP392

BYW98-200

H

HH

1000uF/25V

GND

*

16N8

CP322

16N8

CP321
*

S

μ

15

0

6VA

H

H

10V

3K9

RP551

IP310

TCET1103G

56K

RP512

15Vpp

6VA

CCT_DIAG_SMPS_100G_IFC228

4V

*

26K7

RP553

RP555

100n

CP551

3K3

RP552

A

1

K

2

3

4

E

C

2n2F

CP512

3K92/1%

RP554

GND

0R

TL431

IP351

HH

GND

2K2

RP361

IP302

TCET1103G

K

A

1

4

C

E

23" TVD Hannstar

23" TVD LG

TOROID 40mH TOROID 40mH

D-ZENER 24V D-ZENER 24V

Plasma LCD

TF-MF 25M0 H TF-MF 25M0H

D-ZENER 27V D-ZENER 27V

23" LCD

LP250

DP227

Pos

+VSSIN

DP361

BZX55B30

*

4K7

RP562

TP561

GND

2

3

H

TFSMT P23-E200

CE68uF CE68uF

CE270uF CE270uF

TFSMT P23-E201

TFSMT P22-E50 TFSMT P22-E50

CE47uF

CE150uF

TFSMT PLASMA-P1

CE68uF

CE270uF

TFSMT P23-E201

TFSMT P27-E50 TFSMT P27-E50

CP259

CP258

LP300

LP253

10K0

BC848B

16n8 16n8

16n8 16n8

12nF

Nil

16n8

16n8

CP322

CP321

RP563

CE22uF CE22uF

CE10uF

CE22uF

CP328

GND

CE 1MI5F CE 1MI5F

CE 1MI5F CE 1MI5F

Nil

Nil

CE 1MI5F

CE 1MI5F

CP382

CP381

D-ZENER 27V

6W L=300mm

D-ZENER 30V

9W L=300mm

Nil Nil

D-ZENER 24V

6W L=600mm

D-ZENER 2V7

Nil

D-ZENER 30V

9W L=300mm

DP361

BP222

DP328

26K7

Nil

Jumper

36K

Jumper

24K

Nil

36K

Jumper

Nil Nil Nil

RP553

JP426

JP425

* VALUE MAY CHANGE ACCORDING TO SPECIFIC REQUIREMENT

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

FZP301

T0.5A_125V

V_PRI

P

IFC228-LCD

First issue 04 / 05

FZP207

T1.00A 250V

!

10.5V

2K2

RP401

TP201

STP22NF03L

3.3VSTBY

DP250

BZX55B3V9

CP206

220UF

RP483

845R0

CP483

S

G

1

D

SecondaryPrimary

10N0F

3

GND GND

IP201

2

6.5V

RP484

TL431

2K1

6VA

GND

2K2

RP417

GND

TP203

DP203

STPS30150CT

6V

FZP203

T3.15A 250V

!

20V

STP22NF03L

CP215

DP352

SR560

DP351

SR560

FZP351

T1.00A 250V

!

CP485

S

G

D

!

2N2

!

4V

RP419

1

CP203

1500U/35V

GND

CP351

6K2

10N0F

!

H

220U

CP208

3

IP203

CP202

220UF

3K92

RP418

2

TL431

1500U/35V

GND

GND

TP202

STP22NF03L

GND

GND

GND

FZP208

!

GND

RP404

S

D

BP226C

2
1

BP226A

5VSTBY

T1.00A 250V

10,5V

2K2

G

10.5V

1
2

BP226B

1

2

DP260

BZX55B6V2

220UF

CP207

RP415

CP484

1

2K43

10N0F

GND

LP253

3

!

GND GND

RP416

IP202

TL431

2

TFSMT60

2K1

GND

GND

TP204

STP22NF03L

FZP204

T3.15A 250V

!

9

10V

S

10

DP415

RP413

D

DP204

DP416

BZX55B3V3

BZX55B3V3

CP209

18K

RP412

20V

2K2

G

!

CP204

SR560

GND

11

1

BP204BP203

1

220UF

CP486

3

1

1MIO

12

RP414

10N0F

2

2

GND

3K92

IP204

TL431

2

131514

GNDGND

POWER_FAIL

15K

RP448
*

GND

DP247

RGP15G

GND

GND

CP247

4U7F

20.5V

DP205

16

JP420

TP205

KTC8550D

GND

RGP15G

!

20V

RP205

FZP205

CP210

22U0F

3K9

RP485

2W

390R0

45V

RP209

DP206

FZP206

CP205

22U0F

T0.50A 250V

20.5V

33V

GND

4K7/1W

RGP15G

T0.50A 250V
!

GND

20.5V

RP467

RP208

!

2K7

3K3

CP236

10U0F

20.5V

6.5V

IP251

!

2K2

RP207

TP407

GND

2K2

RP472

RP468

1

TCET1103G

4

PO

1N5F

CP481

RP461

5K6

23

BC548B

6K2

RP486

CP271

RP473

RP471

22K

22U0F

2K2

22K0

CP268

2N2F

1

H

H

GNDGND

6.5V

Attention :

Mesure dans la partie primaire de l'alimentation

- Utiliser la masse du bloc alimentation ( ).

Attenzione :

misure nell'alimentatore primario

GND

33K0

RP476

100K0

RP475

GNDGNDGND

GND

DP471

BZT55C4V7

RP462

3

IP261

TL431

2

3K92

IP271

DP472

GND

TL431

1

BZT55C3V9

TP271

BC548B

GND

2K2

RP470

3

2

22K0

RP474

GND

Note :

DP273

BAV21

- usare massa alimentazione primario ( ).

H

H

H

Achtung :

Bei Messungen im Primärnetzteil

- Primärnetzteilmasse verwenden ( ).

Power Supply primary circuit measurements.

- Use only ( ) connection point.

Cuidado :

Medida en el bloque de alimentacion

- Utilizar la masa del bloque de alimentacion ( ).

Part of board connected to mains supply.

Partie du châssis reliée au secteur.

Primärseite des Netzteils.

Parte dello châssis collegata alla rete.

Parte del chassis conectar a la red.

Utilice solo piezas originales

Pieza de seguridad

Bei Ersatz nur Originalteil verwenden

Sicherheitsbauteil

Safety Part

When repairing, use original part only

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

EARTH

Use isolating mains transformer.

Utiliser un transformateur isolateur du secteur.

Einen Trenntrafo verwenden.

Utilizar un transformador aislador de red.

Utilizzare un transformatore per isolarvi dalla rete.

Per la riparazione utilizzare solo componenti originali

Componenti di sicurezza

Pièce de securité

N'utilisez que les pièces d'origine

POWE

LIVE

NEUTRAL

1

2

BP251B

!

FP251

T2.5AL 250V

!

CP253

BP251A

WP235A

!

100NF

EARTH

1

2

3
4

BP251

7

5

6

8

AC1

1N5F

!

!

CP251

100NF

!

470K

RP251

LP252

!

8

7

6
5

!

LP251

!

GP30M

!

657

CP252

100NF

H

AC2

RP257

4

CP256

1N5

DP255

GP30M

!!

DP254

8

123

LP225

220K

1U5

V_PRI

RP258

220K

!

GND

1N5

CP255

DP252

GP30M

!

CP254

DP253

GP30M

!

10M

RP225

!

*

GND

8

1

7

2

6

3

5

4

!

LP250

4

DP226

RGP10G

VCC1

3

DP225

!

2

RGP10G

CP493

RP495

DP227

BZX55B24

CP225

CP224

22K0

22U0

22U0

470P0

1

330P0

CP226

DP493

BZX55C9V1

TP495

RP494

BC858B

H

10K

CP237

RP293

LP253_P1

RAW_B+

180P0

CP239

1N5

BAV21

DP237

H

22K0

3K3

RP227

1

BP253

TO PUSH SWITCH MODULE

3U3

LP220

1N5

CP220

JP453

2

H

CP438

RP238

3

180P0

470R0

RP221

D

22R0

TP220

2

G

S

(EU)6N90

2K2

RP492

RP233

CP233

1

(US) 10N60

DP240

BZX55B27

2K2

RP240

47K0

RP441

TP223

15V

DP233

47K0

1N0

KTC8550D

RP231

CP240

10R0

10U0

DP230

H

!

BZX55C8V2

RP226

RP228

0R68

RP220

*

1K0

RP230

SMPS 300 IFC228

CIRCUIT DIAGRAM SMPS 300 IFC228

* VALUE MAY CHANGE ACCORDING TO SPECIFIC REQUIREMENT

CP222

2K7

22R0

470P0

H

H

TP222

BC548B

H

IFC228-LCD

First issue 04 / 05

POWE

IACVPCA_OUT

LFF

VRMS

MULT_OUT

ISENSE

SGND

VREF

SS

VA_OUT

VFEED

UVLO

FREQ_MOD

ROSC

COSC

VCC

GDRV

PGND

IPK

!

!

CSSCFOPOUT

RFMIN

OPIN+

EN1

VBOOT

HVG

RFSTART

OUT

N.C.

VS

EN2

OPIN-

LVG

GND

!

!

!

!

!

!

G

S

D

G

S

D

G

S

D

G

D

S

G

D

S

!

!

!

!

!

!

!

!

!

!

!

!

SecondaryPrimary

( To Inverter Board)

CIRCUIT DIAGRAM SMPS 300 IFC228

RP381

390R/3W

RP382

390R/3W

RP519

5K1

1N0

CP518

1N0

CP328

RP856

22K

RP328

R100/3W

RP324

10K

CP586

22N

CP589

1UF

CP587

470NF

CP588

220N

CP388

1000U

35V

RP587

5K6

RP588

3K92

RP555

0R

RP553

36K

RP551

3K9

RP552

3K3

3K92/1%

RP554

T3.15A 250V

FZP391

RP586

9K1

20K

RP585

CP551

4N7

RP363

VAL

RP362

0R

RP837

12K7/1%

RP839

2K1

33K

RP722

RP831

10K

RP814

10K

CP322

18N3

CP321

18N3

RP729

4R7,10W

RP751

4R7,10W

RP562

4K7

RP361

2K2

GND

GND

RP510

5K1

DP386

SR560

LP385

125U

GND

CP386

560N

RP834

301K

RP833

301K

RP832

301K

RP828

301K

RP827

301K

RP826

301K

CP385

470UF

35V

CP391

1000U/25V

25

T3.15A 250V

FZP371

16

876

5

123

4

9101112131514

LP700

FZP301

T0.5A 250V

RP721

47R

123456789

101112131415161718

IP985

CP315

4U7

LP300_P6

LP300_P2

CP371

1000U/25V

25V

CP390

220UF

16V

CP584

330P

CP585

2N7

CP382

1500U/35V

CP381

1500U/35V

CP709

150U

400V

16

876

5

123

4

9101112131514

LP300_P14

LP300_P15

LP300_P1

1

LP300_P10

CP708

470U

400V

CP512

2N2

LP722

3U3

16

876

5

123

4

9101112131514

CP727

2N2

STPS30150CT

DP381

CP819

10N

STP22NF03L

TP751

STP22NF03L

TP302

H

H

DP392

BYW98-200

DP744_A

TP321

14NK50

DP361

BZX55830

BC548B

TP361

RP563

10K0

1

2

3

4

DP391

BYW98-200

DP371

BYW98-200

DP372

BYW98-200

TP720

2SK2837

DP721

STTH8R06FP

LP721

3U3

CP722

2N2

GP30M

DP744DP743

GP30M

DP720

BZX55C20

DP724

RGP15G

LP716

3U3

CP741

10U

CP812

4N7

RP812

12K

RP843

33K

RP818

39K

CP818

220N

RP840

22K

1N4148

DP808

CP814

100N

CP711

1U

50V

RP844

220K

RP806

22K

CP806

100N

RP813

4K7

RP847

56K

RP816

82K

CP816

47N

RP817

4K7

CP813

10N

RP804

100K

RP723

0R27 ; 3W

RP803

330K

RP802

330K

RP801

330K

CP701

470N

RP807

330K

RP808

330K

RP809

330K

1

23

4

RP512

56K

1

2

3

IP351

TL431

DP326

(PREP)

RP325

39R

DP325

RGP10G

CP325

100N

RP521

10K

DP323

RGP10G

RP323

39R

DP324

(PREP)

DP328

(PREP)

RP326

10K

TP322

14NK50

CP751

22U0F

RP851

22K

BC548B

TP752

RP852

3K9

1

2

3

IP751

TL431

CP852

10N0

RP853

3K92

RP854

15K

DP751

RGP10G

DP301

RGP10G

CP301

22U0F

RP301

22K

1

2

3

IP303

TL431

BC548B

TP303

RP302

3K9

CP503

10N0

CP302

22U0F

RP503

15K

RP504

3K92

DP753

8V2

CP753

22U0F

CP855

10N0

RP855

22K

TP753

BC548B

RP516

4K3

RP511

39K

CP516

680P

RP517

27K

123

4

1

2345678

9

1234567

8

123456789

10

H

12345

6

GND

GND

GND

GND

H

CP817

220P

CP803

220N

RP327

1K

RP515

110K

PO

H

H

H

H

H

H

GND

H

GND

GND

H

H

H

H

H

H

H

H

H

GND

GND

H

GND

GND

DP382

STPS30150CT

H

GND

GND

HH

1

2

HH

1

2

GND

H

H

H

LP300_P14

LP300_P15

LP300_P11

LP300_P10

LP300_P2

LP300_P6

GND

CP383

1500U/35V

GND

GND

GND

GND

GND

1

35647

8

16

152141312911

10

GND

3

6

8

11121314151617

182019

759

124

10

DP744_C

GND

GND

HH

1

2

HH

1

2

HEATSINK HEATSINK

L6598

PFC200

HEATSINKHEATSINK

( To Scaler Board)

(To Signal Board BP002)

(To Signal Board BP001)

( To Audio Board)

V12

L4973V5.1

DP203A

LP301

TFSMT26E250

+UA

TP720A

LP300

TFSMT26E250

TP322A

IP302

TCET1103G

AC2

L4891B

IP710

IP310

TCET1103G

IP300

BP321 BP222 BP220A BP220

DP381A

BP320

V_PRI

RAW_B+

+VSSIN

4V

RAW_B+

RAW_B+

AC1

+VSSIN

-UA

6V

V12

33V

4V

VON/OFF

VBRI

ECO_STBY

SAFETY

POWER_FAIL

3.3VSTBY

5VSTBY

20V

10V

-UA

+UA

6V

+VSSIN

VBRI

VON/OFF

VON/OFF

+VSSIN

Part of board connected to mains supply.

Partie du châssis reliée au secteur.

Primärseite des Netzteils.

Parte dello châssis collegata alla rete.

Parte del chassis conectar a la red.

Use isolating mains transformer.

Utiliser un transformateur isolateur du secteur.

Einen Trenntrafo verwenden.

Utilizar un transformador aislador de red.

Utilizzare un transformatore per isolarvi dalla rete.

Achtung :

Bei Messungen im Primärnetzteil

- Primärnetzteilmasse verwenden ( ).

Note :

Power Supply primary circuit measurements.

- Use only ( ) connection point.

Attention :

Mesure dans la partie primaire de l'alimentation

- Utiliser la masse du bloc alimentation ( ).

Attenzione :

misure nell'alimentatore primario

- usare massa alimentazione primario ( ).

Cuidado :

Medida en el bloque de alimentacion

- Utilizar la masa del bloque de alimentacion ( ).

Safety Part

When repairing, use original part only

Pièce de securité

N'utilisez que les pièces d'origine

Utilice solo piezas originales

Bei Ersatz nur Originalteil verwenden

Sicherheitsbauteil

Pieza de seguridad

Per la riparazione utilizzare solo componenti originali

Componenti di sicurezza

H

H

H

H

H

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

IFC228-LCD

First issue 04 / 05

1

CP203

DP203A

DP203

S

TP203

DG

FZP201

T3.15A_125V

IP203

DP247

T3.15A_125V

CP204

FZP203

CP208

CP209

RP412

IP214

1

G

DP260

CP207

T1.0A_125V

IP271

BP220

FZP208

T1.0A_125V

FZP207

BP220A

IFC228 (SMPS 100G)

1

C

B

E

WP235A

TP271

1

CP391

FZP391

T3.15A_125V

DP391

JP227

S

D

DP250

CP271

BP222

1

CP210

CP206

RP207

JP211

CP381

CP202

JP226

1

CP247

1

BP203

TP204

RP208

DP204

TP205

BP320

9

(RED)

BP226B

(BLACK)

BP226A

1

BP204

EB C

TP202

SDG

CP215

DP218

JP235

JP222

CP201

T0.5A_125V

1

BP226C

CP205

RP205

DP206

SDG

TP201

DP361

BC

E

DP261

IP261

DP201

FZP204

T3.15A_125V

FZP205

(GRAY)

DP205

FZP206

T0.5A_125V

RP209

CP236

IP202

PCB SMPS 100G IFC228

IP201

2140480C

12

JP313

JP311

TP261

DP273

D

TP220

D

TP321

D

RP361

CP268

LP220

CP233

G

TP322

S

1

1

RP231

S

G

S

G

TP322A

LP253

IP302

RP230

RP228

RP226

IP251

DP230

C

B

JP302

CP224

CP225

C

RP233

CP302

DP227

E

B

RP221

RP32 6

DP326

TP222

E

TP223

1

DP233

DP325

RP325

CP325

DP323

RP323

RP324

DP324

RP328

BP253

DP328

RP240

CP222

RP227

RP220

IP300

JP304

JP303

CP240

CP226

DP240

DP225

LP225

CP315

DP226

DP237

CP328

RP327

1

RP258

LP300

CP220

RP302

RP301

RP293

RP238

CP237

CP239

FZP301

T0.5A_125V

CP301

IP303

TP302

DP301

SDG

RP257

CP259

JP306

BARCODE

CP258

CP254CP256

DP371

BP321

T3.15A_125V

FZP371

1

RP225

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

POWER SUPPLY CIRCUIT BOARD - CIRCUIT IMPRIME DE L’ALIMENTATION - LEITERPLATTE NETZTEIL - PIASTRA DEI CIRCUITI DI ALIMENTAZIONE - PLATINA ALIMENTACIÓN

BP251

BP251B BP251A

JP301

DP381A

DP372
DP392

CP371

DP381

CP382

JP312

IP351

CP250

LP250

FP251 AFP251B

5.0A_125V(US_LCD)
T2.5AL_250V(EU_LCD)
T5.0AL_250V(EU_PLASMA)

FP251

JP315

1

IP310

JP201

BP008B

BP008A

RP251

BP006B

BP006A

CP251

BP006

CP255

DP253

DP252

CP321

DP255

CP322

DP254

IFC228-LCD

First issue 04 / 05

Part of board connected to mains supply.

Partie du châssis reliée au secteur.

Primärseite des Netzteils.

Parte dello châssis collegata alla rete.

Parte del chassis conectar a la red.

Use isolating mains transformer.

Utiliser un transformateur isolateur du secteur.

Einen Trenntrafo verwenden.

Utilizar un transformador aislador de red.

Utilizzare un transformatore per isolarvi dalla rete.

Achtung :

Bei Messungen im Primärnetzteil

- Primärnetzteilmasse verwenden ( ).

Note :

Power Supply primary circuit measurements.

- Use only ( ) connection point.

Attention :

Mesure dans la partie primaire de l'alimentation

- Utiliser la masse du bloc alimentation ( ).

Attenzione :

misure nell'alimentatore primario

- usare massa alimentazione primario ( ).

Cuidado :

Medida en el bloque de alimentacion

- Utilizar la masa del bloque de alimentacion ( ).

Safety Part

When repairing, use original part only

Pièce de securité

N'utilisez que les pièces d'origine

Utilice solo piezas originales

Bei Ersatz nur Originalteil verwenden

Sicherheitsbauteil

Pieza de seguridad

Per la riparazione utilizzare solo componenti originali

Componenti di sicurezza

EARTH

BP251A

BP251B

6.5V

LP253_P1

BP251

BP226B

BP226C

VCC1

6V

V_PRI

BP226A

33V

20.5V

20V

AC2

RAW_B+

20V

10.5V

45V

20.5V

6.5V

20.5V

6.5V

PO

5VSTBY

POWER_FAIL

3.3VSTBY

AC1

10.5V

10V

20V

BURST

5VSTBY

10.5V

!

!

!

!

!

!

!

!

!

!

!

!

!

!

!

!

!

!

!

!!

G

D

S

G

D

S

G

D

S

G

D

S

G

D

S

!

!

!

SMPS 200 IFC228

*

*

(US) 10N60

*

TO PUSH SWITCH MODULE

SecondaryPrimary

* VALUE MAY CHANGE ACCORDING TO SPECIFIC REQUIREMENT

WP235A

LIVE

NEUTRAL

16

7

5

2

3

4

9

10

11

12

131514

6

1

8

LP253

TFSMT60

CP225

22U0

T1.00A 125V

FZP207

CP209

220UF

CP207

220UF

CP208

220UF

CP206

220UF

CP268

2N2F

BC548B

TP407

BC548B

TP222

CP236

10U0F

1

2

BP204

DP260

BZX55B6V2

DP414

BZT55C8V2

RP414

10k

RP413

2K2

1

2

3

IP202

TL431

TP495

BC858B

LP250

CP253

100NF

FP251

T2.5A 250V

1

2

3

4

6
5

7

8

LP251

STP22NF03L

TP202

CP438

180P0

RP486

22K

CIRCUIT DIAGRAM SMPS 200 IFC228

STP22NF03L

TP204

STP22NF03L

TP203

STP22NF03L

TP201

1

3

2

(EU)6N90

TP220

RP220

0R68

DP254

GP30M

1

2

123

4

657

8

LP252

RP257

220K

T0.50A 125V

FZP206

BC548B

TP271

TP205

KTC8550D

DP250

BZX55B3V9

RP401

2K2

RP483

845R0

RP484

2K1

CP483

10N0F

1

2

3

IP201

TL431

T3.00A 125V

FZP203

RP419

6K2

RP418

3K92

RP417

2K2

CP485

10N0F

1

2

3

IP203

TL431

CP203

1500U/35V

CP202

1500U/35V

1

2

T1.00A 125V

FZP208

RP415

2K43

RP416

2K1

RP404

2K2

CP484

10N0F

1

2

BP203

CP204

1MIO

1
2

DP204

SR560

RP448

15K

CP247

4U7F

DP247

RGP15G

T3.00A 125V

FZP204

RP209

4K7

1W

DP206

RGP15G

RP207

2K2

CP481

1N5F

RP208

3K3

JP420

CP210

22U0F

RP485

3K9

RP205

390R0

2W

DP205

RGP15G

CP205

22U0F

T0.50A 125V

FZP205

RP471

22K0

RP472

2K2

RP473

2K2

CP271

22U0F

DP471

BZT55C4V7

DP472

BZT55C3V9

RP475

100K0

RP476

33K0

1

2

3

IP271

TL431

RP474

22K0

RP461

6K2

1

2

3

IP261

TL431

RP462

3K92

DP273

BAV21

RP470

2K2

RP468

5K6

RP467

2K7

1

2

3

4

IP251

TCET1103G

DP230

BZX55C8V2

RP230

1K0

CP220

1N5

LP220

3U3

CP233

1N0

RP233

47K0

DP233

15V

RP231

10R0

RP228

22R0

RP492

2K2

RP221

22R0

RP227

3K3

1

2

BP253

TP223

KTC8550D

RP226

2K7

CP222

470P0

CP240

10U0

RP441

47K0

RP240

2K2

DP240

BZX55B27

DP237

BAV21

RP293

22K0

RP238

470R0

CP239

180P0

CP237

1N5

CP224

22U0

DP227

BZX55B24

RP495

22K0

DP493

BZT55C8V2

CP493

470P0

RP494

10K

CP226

330P0

DP225

RGP10G

DP226

RGP10G

LP225

1U5

RP258

220K

DP255

GP30M

CP256

1N5

CP255

1N5

DP252

GP30M

CP254

1N5F

DP253

GP30M

CP251

100NF

RP251

470K

CP252

100NF

RP225

10M

GND

GND

GND

GND

GND

GND

GNDGND

GND

GND

GND

GND

GND

GND

GND

GND

GND

GND

1
2

CP215

2N2

JP453

GND

H

10.5V

H

GND

H

H

H

H

H

H

H

GND GND

GND

GND

GND

GND

GND GND

GND

GND

GND

GND

GND

GND

GND

GND

CP209

220UF

GND

DP203

STPS30150CT

CP486

10NOF

GND

BC548B

TP261

RP464

4K7

DP261

BZX55C8V2

RP463

2K2

RP462

CP461

10N0F

RP469

2K2

RP465

10K

RP466

100R0

GND

GND

GND

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

IFC228-LCD

First issue 08 / 04

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

5VA

4K7

RP588

2K7

RP587

220UF

CP388

125U

LP385

8

IP385

L4978

532

20K

RP585

4

671

100N

CP587

2N7

CP585

220N

CP386

CP385

100N

CP588

9K1

RP586

220U/35V

DP386

SR560

CP586

Secondary

+VSSIN

Primary

Utilice solo piezas originales

Pieza de seguridad

Bei Ersatz nur Originalteil verwenden

Sicherheitsbauteil

Per la riparazione utilizzare solo componenti originali

Componenti di sicurezza

Safety Part

When repairing, use original part only

Pièce de securité

N'utilisez que les pièces d'origine

Use isolating mains transformer.

Utiliser un transformateur isolateur du secteur.

Einen Trenntrafo verwenden.

Utilizar un transformador aislador de red.

Utilizzare un transformatore per isolarvi dalla rete.

RAW_B+

S

TP302

STP22NF03L

D

DP301

RGP10G

!

V_PRI

DP325

RGP10G

RP515

15K

RP503

G

RP302

CP301

FZP301

T0.5A 125V

TP322

110K

CP302

CP503

3K9

22U0F

22N

14NK50

D

22U0F

10N0

RP301

GND

RP325

22K

GND

DP391

G

39R

IP300

1

H

FZP371

T3,00A 125V

DP371

BYW98-200

BYW98-200

LP300_P15

16

LP300

!

TFSMT26E250

123

LP300_P2

S

10K

RP326

DP326

(PREP)

100N

CP325

16

152141312911

HVGRFSTART

VBOOT

L6598

CSSCFOPOUT
1

4U7

CP315

27K

RP517

H

RP504

IP303

3

TL431

2

BC548B

TP303

!

25V

+UA

CP371

1000U/25V

!

DP372

BYW98-200

LP300_P14

4

DP323

OUT

N.C.

RFMIN

35647

CP516

680P

39K

RP511

3K92

GND

5

RGP10G

VS

RP519

H

-UA

GND

DP392

BYW98-200

LP300_P11

LP300_P10

LP300_P6

TP321

D

RP323

10

GND

OPIN+

OPIN- LVG

33K

H

DP751

RGP10G

!

DP381

9101112131514

876

14NK50

G

39R

EN2

EN1

8

25

CP391

1000U/25V

STPS30150CT

S

RP324

H

10K

RP521

4K3

RP516

2K2

RP856

8V2

DP753

TP751

STP22NF03L

10K

DP324

S

D

(PREP)

+VSSIN

GND

DP382

STPS30150CT

!

RP510

CP518

CP753

15K

RP854

G

3K9

RP852

CP751

22U0F

!

CP321

5K1

100N

TP753

22U0F

CP382
!

CP381

!

CP322

16N8

1K

RP327

BC548B

RP855

CP855

22K

RP851

1500U/35V

1500U/35V

16N8

RP328

R100/3W

(PREP)

DP328

22U0F

CP328

22K

10N0

10N0

CP852

1

IP751

H

RP551

H

H

3

TL431

GND

3K9

1

IP310

TCET1103G

4

!

H

H

3K92

RP853

2

BC548B

TP752

JP351

RP553

RP552

5VB

26K7

3K3

23

RP512

6V

56K

DP351

0R

RP555

CP512

1N5822

JP352

2N2

4V

H

DP352

5VA

CP551

100N

112

IP351

DP744

DP743

1N5822

3

TL431

H

GP30M

GP30M

CP351

220UF

RP554

3K92/1%

DP744_CDP744_A

!

AC1

AC2

GND

GND

GND

IP302

!

RP729

4R7,10W

CP722

2N2

16

PFC200

LP700

123

RAW_B+

4V

RP361

2K2

TP361

1

2

TCET1103G

3

4

3U3

LP721

DP721

STTH8R06FP

2N2

CP727

H

4

H

330K

RP828

330K

RP827

330K

RP826

DP361

RP562

BC548B

5

+VSSIN

BZX55830

4K7

LP722

12K

RP831

RP751

3U3

RP563

GND

H

4R7,10W

DP724

9101112131514

876

!

10K0

RAW_B+

D

RGP15G

330K

RP809

330K

RP808

330K

RP807

470N

CP701

RP844

TP322A

GND

!

TP720

G

RP721

220K

IP710

CP819

RP801

( To Signal Board BP001)

HH

2

HEATSINK

1

DP381A

HEATSINK

TP720A

HEATSINK

470U

CP708

400V

H

RP832

330K

RP833

330K

2SK2837

H

S

DP720

BZX55C20

1K

RP722

4R7

RP812

10U

CP741

3U3

LP716

4N7

CP812

182019

VCC

COSC

ROSC

GDRV

L4891B

H

IACVPCA_OUT

PGND

IPK

3

124

47N

CP816

82K

10N

RP816

56K

RP847

330K

330K

RP802

10

6V

GND

33V

20V

10V

8

PO

GND

SAFETY

POWER_FAIL

4V

GND

5VB

ECO_STBY

GND

(To Signal Board BP002)

5VA

( To Scaler Board)

2

6

GND

( To Inverter Board)

DP203A

HEATSINK

330K

RP834

H

H

33K

RP843

UVLO

VFEED

LFF

VRMS

6

759

RP813

8K2

330K

VBRI

VON/OFF

4

+UA

( To Audio Board)

H

13K7/1%

RP837

RP839

100R0

39K

RP818

CP818

1U

CP711

11121314151617

SS

VREF

VA_OUT

MULT_OUT

ISENSE

SGND

8

10

RP817

RP806

4K7

CP806

100K

RP804

CP803

!

RP723

220N

RP840

DP808

CP814

50V

H

CP813

4K7

CP817

22K

100N

220N

0R27 ; 3W

1

2

12K

FREQ_MOD

RP814

RP803

123456789

5VSTBY

3.3VSTBY

1234567

BURST

Part of board connected to mains supply.

Partie du châssis reliée au secteur.

Primärseite des Netzteils.

Parte dello châssis collegata alla rete.

Parte del chassis conectar a la red.

123456789

BP222 BP220A BP220

VBRI

VON/OFF

12345

BP320

+VSSIN

SMPS 200 IFC228

123

BP321

GND

22K

1N4148

100N

10N

220P

-UA

Attention :

H

Note :

CIRCUIT DIAGRAM SMPS 200 IFC228

H

Mesure dans la partie primaire de l'alimentation

- Utiliser la masse du bloc alimentation ( ).

Attenzione :

misure nell'alimentatore primario

- usare massa alimentazione primario ( ).

Achtung :

Bei Messungen im Primärnetzteil

- Primärnetzteilmasse verwenden ( ).

Power Supply primary circuit measurements.

- Use only ( ) connection point.

Cuidado :

Medida en el bloque de alimentacion

- Utilizar la masa del bloque de alimentacion ( ).

IFC228-LCD

First issue 08 / 04

IFC228 (SMPS 300)

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

POWER SUPPLY CIRCUIT BOARD - CIRCUIT IMPRIME DE L’ALIMENTATION - LEITERPLATTE NETZTEIL - PIASTRA DEI CIRCUITI DI ALIMENTAZIONE - PLATINA ALIMENTACIÓN

IFC228-LCD

First issue 04 / 05

AUDIO BOARD - PLATINE AUDIO - AUDIO GRUNDPLATTE - PIASTRA AUDIO - PLATINA AUDIO

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI
LADO COMPONENTES

SOLDER SIDE - COT

É

CUIVRE - LÖTSEITE - LATO SALDATURE - LADO DEL COBRE

IFC228-LCD

First issue 08 / 04

1

SS001

EXT_SPK

INT_SPK

JS002

15N

220N

CS227

GNDP

330P

CS236

RS210

10K0

RS209

15

T2

OSC

TDA7490L

-5V

1

16

100N

GNDP

GNDP

123456

GNDP

LS202

22K

-VCC1

CS205

33UH

TS203

23

OUT2

25

RS214

100N

RN1402

2

CS218

10V

CS203

CS291

INT_SPK_R

RS011

RS223

33N

21

+VCC1

BOOT2

FEED3 NC -VCC2

IN2

FEED4

18

0R

1UF

220N

GNDP

22R

CS219

0R

1N

BS001

(M)

GNDP

GNDP

SW_DETECT

15N

CS231

CS230

470N

CS220

CS237

22241719 20

CS223

100N

GNDP

CS224

1N0

CS204

4K7

RS291

GND

0R

RS224

GNDP

IFC228 AUDIO AMP BOARD

220N

GNDP

1N

+UA

470P

GNDP

RS211

!

GNDP

!

100R

CS221

CS222

CS225

RS212

470P

2MI2F

2MI2F

68K

TS204

RS213

51K

RS227

-UA

GNDP

GNDP

4K7

RN1402

GNDP

-UA

1

1MI0F

CS238

CS213

10

1UF

1N

NODE

IN1

JS001

33N

BOOT1

GNDP

3

OUT1

CS207

12

100N

LS201

CS215

+5V

CS202

RS290

(M)

RS222

CS216

33UH

330P

11

T1

1N0

4K7

BS002

22R

470N

24P

CS232

RS208

13

2

INT_SPK_L

12 11 10 9 8 7

CS228

22K

8

IS200

GND

CS206

123

4

BS004

RIGHTCENTERLEFT

W

CS012

RS010

Y

354

VIDEO

1N0

100K0

GND

GND

LS003

RS005

W

L_VAR

300R0

470R0

CS007

RS006

L_FIX

1N0

678

100K0

R_VAR

GND

GND

R

LS004

RS008

CS008

220R

4U7F

R

9

R_FIX

300R0

BS003

CS010

470P0

CS009

47K0

RS007

GND

RS402

CS401

470U0

LS001

300R0

GND

1N0

GND

GND

470R0

RS001

150R

DS401

RS401

VIDEO_OUT

CS002

RS002

ZMM6.8

1K0

1N0

100K0

RS403

150R

654231

BS003A

GND

GND

DS402

ZMM6.8

GND

1UF

CD002

TD001

BC856B

100R

RD003

CD001

220N0

10U

LD001

LS002

300R0

CS005

1N0

220R

RS004

GND

GND

CS003

4U7F

CS004

RS003

470P0

47K0

GND

+5VS
123

BD001

RD002

1K8

RD001

GND GND GND

Br

1

2

SUB_VAR

LS005

300R0

RS009

470R0

EXT_SPK_CONECTER

DS306

ZMM6.8

-UA

1K0

GND GND

GND

!

GNDP

JS004

+UA

GNDP

RS205

GNDP

RS204

!

68K

4K7

RS207

CS211

CS210

DS305

100R

2MI2F

2MI2F

CS209

LEFT_SPK

RIGHT_SPK

ZMM6.8

470P

RS203

30K

10K0

RS202

RS225

100R

+UA

RS206

130K

CS212

CS280

DS303

RS226

100N

470P

TS201

ZMM6.8

CS001

1N

CS214

51K

4U7F

CS208

RN1402

DS304

1MI0F

4214

976

ZMM6.8

CS006

5

+VCC

-VCC

CURREF

FEED2

FEED1

GNDP

CS201

220N

CS290

AUDIO AMPLIFIER SCHEMATIC DIAGRAM - SCHEMA DE L’AMPLIFICATEUR AUDIO - AUDIO ENDVERSTÄRKER - SCHEMA AMPLIFICATORE AUDIO - ESQUEMA DEL AMPLICADOR AUDIO

IN4148

RS201

PG

SUBWOOFER

10K0

5V_V

DS202

GND

MAIN_LEFT

DS201

IN4148

MAIN_RIGHT

L/R_MUTE

TS202

RN1402

2K2

RS215

4U7

CS226

DS203

AUDIO_STBY

MASTER_MUTE

12345678910111213

GNDP

IN4148

RS216

2K2

CS229

4U7

RS218

RS217

GNDP

2K2

GNDP

2K2

TS210

RS219

BC856B

10K

+UA

RS280

10K

RS282

1K

RS221

22K

RS220

5V_V

TS206

RN1402

RS281

10K

JS005

GNDP

TS207

BC846B

220N0

GNDP

CS235

+UA

220N0

-UA

47K

CS234

PG

JS003

BS007

432

1

IFC228-LCD

First issue 08 / 04

47K0

47K0

GND

CS112

0R

4U7

100K0

CS111

CS107

RS112

CS106

1K0

GND

1N0

GND

1N0

GND

-UA

VIDEO_OUT

SW_DETECT

AV1_L_OUT

AV1_R_OUT

14

BS006

1

4

2

3

JS104

1N0

47K0

RS115

47K0

RS116

11

RS102

CS108

47K0

IS100

MC33079

1N0

GND

RS103

GND

7

4

11

6

5

3K3

CS103

8

4

11

1N0

10K0

RS105

RS104

100K0

4U7

10K0

CS109

RS107

9

10

3K3

RS106

GND

4U7

CS104

GND

RS117

RS108

3K3

100K0

CS110

1N0

GND

RS109

14

4

11

10K0

RS111

13

12

RS110

3K3

3K3

RS118

GND

4U7

CS105

GNDGND

1N0

CS102

4U7

CS101

RS114

1K0

RS101

RS113

+UA

BS003

LS005

RS009

470R0

1

300R0

Br

2

SUB_VAR

CS012

100K0

RS010

1N0

Y

354

VIDEO/SPDIF

300R0

LS003

GND

GND

470R0

RS005

W

L_VAR

CS007

RS006

1N0

100K0

W

678

L_FIX

300R0

LS004

GND

220R

RS008

GND

4U7F

CS008

R

R_VAR

CS010

RS007

1N0

CS009

47K0

470P0

R

9

R_FIX

LS001

300R0

GND

GND

GND

GND

-UA

GNDP

RS002

RS001

RS505

CS002

470R0

RS509

30K

RS504

1N0

100K0

100R

RS507

10K0

68K

+UA

+UA

TS502

LS002

RS004

GND

GND

213

CS507

CS510

CS503

300R0

220R

1N

100N

470P

RN1402

CS502

4U7F

RS402

CS003

CS508

RS508

RS403

CS005

RS003

4U7F

1N

CS504

150R

150R

47K0

130K

470P

1N0

CS004

470P0

RIGHTCENTERLEFT

CS509

4214

976

654

RS511

RS510

33N

5

RS501

GND

GND

GND

51K

4K7

NODE FEED1 FEED2 CURREF -VCC +VCC

GNDP

10

2K2

BS003A

GND

CS512

33UH

LS501

CS511

3

11

OUT1

BOOT1

IN1

+5V

12

CS528

100N

1UF

CS530

DS401

ZMM6.8

1K0

RS401

CS401

470U0

VIDEO_OUT

CS513

220N

T1

CS529

RS502

470N

RS514

RS512

RS513

330P

13

1N0

3K3

RD003

LD001

CS583

10R

22K

15K

IS500

GND

DS402

GND

100R

10U

+5VS

1MI0F

RS515

GNDP

24P

CS514

CS515

8

OSC

TDA7490L

-5V

16

CS527

100N

GNDP

GNDP

GND

ZMM6.8

1UF

CD002

CD001

15

CS517

10R

RS516

T2

1

GNDP

100N

1

22K

330P

-VCC1

-UA

470N

CS516

CS526

2

220N

23

RS521

100N

CS518

OUT2

10V

25

CS581

GND

RD001

123

(M)

BS008

33UH

LS502

33N

21

BOOT2

FEED3 NC -VCC2 +VCC1

IN2

18

6R8

100N

TD001

MMBT3906LT1

470R

SUPERWOOFER

51K

RS517

1N

CS519

+UA

222417

CS521

100N

20

CS523

GNDP

470P

CS524

FEED4

19

1N

CS580

GND

GND

560R

RD002

GND

BD001

!

2MI2F

-UA

GNDP

GNDP

CS520

CS522

!

CS525

1N

2MI2F

470P

RS207

GNDP

RS518

GNDP

RS519

100R

+UA

1

234

BS004

LEFT_SPK

EXT_SPK_CONECTER

100R

GNDP

68K

1N

CS214

!

CS211

2MI2F

2MI2F

CS210

!

GNDP

68K

RS205

GNDP

4K7

RS204

30K

RS203

RS202

RIGHT_SPK

TS503

BC846B

-UA

1N

CS238

+UA

CS209

10K0

TS201

CS212

470P

DS303

DS305

51K

RS226

100N

130K

RS206

CS280

CS208

RN1402

ZMM6.8

ZMM6.8

RS522

470P

4U7F

TS202

ZMM6.8

ZMM6.8

10K0

4214

9

7

6

RN1402

DS304

DS306

CS533

5

CS201

CS290

RS215

NODE FEED1 FEED2 CURREF -VCC +VCC

1UF

24P

220N

2K2

10

GNDP

GNDP

GNDP

CS213

BOOT1

IN1

33N

GNDP

GNDP

CS207

1

GNDP

INT_SPK EXT_SPK

CS228

15N

220N

CS227

CS216

470N

GNDP

10K0

RS209

22K

15

T2

OSC

TDA7490L

-5V

1

16

100N

CS006

RS210

-VCC1

GNDP

BS001

123456

1MI0F

GNDP

330P

CS236

22K

(M)

23

25

RS214

CS205

2

OUT2

10V

CS203

CS291

INT_SPK_R

RS284

CS231

RS223

CS220

33UH

LS202

CS219

33N

CS218

21

BOOT2

IN2

18

6R8

100N

1UF

220N

2K2

RS217

RS011

22R

FEED4 FEED3 NC -VCC2 +VCC1

0R

0R

15N

470N

1N

CS237

2224

20

17

1N

19

TS204

GNDP

SCH STEREO/SUBWOOFER AMP IFC228

SW_DETECT

GNDP

GND

0R

0R

RS224

RS283

220N

CS230

GNDP

100R

RS211

-UA

!

+UA

GNDP

2MI2F

CS221

!

2MI2F

CS222

100N

CS223

GNDP

GNDP

68K

RS212

470P

51K

CS225

RS227

470P

CS224

4K7

RS213

1N0

CS204

GNDP

GNDP

-UA

4K7

RS291

GNDP

5K6

RS218

GNDP

BC846B

TS501

TS203

GNDP

BC846B

BC846B

1

2

(M)

BS002

INT_SPK_L

SS001

12 11 10 9 8 7

CS001

1MI0F

22R

RS222

33UH

LS201

24P

CS232

CS215

330P

RS208

8

3

11

T1

OUT1

IS200

+5V

GND

12

13

CS206

100N

1N0

CS202

GNDP

4K7

RS290

GNDP

5K6

RS216

AUDIO AMPLIFIER SCHEMATIC DIAGRAM - SCHEMA DE L’AMPLIFICATEUR AUDIO - AUDIO ENDVERSTÄRKER - SCHEMA AMPLIFICATORE AUDIO - ESQUEMA DEL AMPLICADOR AUDIO

GNDGND

STEREO

WITH SUBWOOFER - AVEC SUBSUBWOOFER - MIT BASSLAUTSPRECHER - CON SUBWOOFER

CS101

CS102

4U7

1N0

RS101

TS208

RS220

BC856B

PG

RS221

1K

47K

-UA

BS007

1

RS225

DS202

RS281

CS234

10K

IN4148

220K

220N0

GNDP

RS282

432

TS207

10K

CS235

BC846B

220N0

+UA

RS280

5V_V

22K

IFC228-LCD

First issue 08 / 04

TS504

5V_V

10K0

RS201

DS204

IN4148

MAIN_LEFT

GND

RN1402

DS205

IN4148

DS201

IN4148

SUB_MUTE

L/R_MUTE

MAIN_RIGHT

GNDP

DS203

4U7

MASTER_MUTE

AUDIO_STBY

12345678910111213

IN4148

CS226

CS229

10K

RS219

4U7

+UA

10K0

CS105

4U7

CS107

GNDGND

10K0

0R

14

AV1_R_OUT

SW_DETECT

RS523

4U7

CS501

PG

AV1_L_OUT

SUBWOOFER

1N0

CS106

1K0

RS112

1N0

CS111

-UA

GND

4U7

JS501

BS006

VIDEO_OUT

0R

JS104

CS108

7

11

4

GND

5

6

1N0

3K3

RS103

RS113

GND

1

4

11

100K

RS102

2

3

1N0

CS112

47K0

RS114

1K0

IS100

IS100

MC33079

MC33079

MC33079

+UA

RS104

47K0

10K0

RS105

100K0

CS103

8

4

1N0

CS109

9

10

3K3

RS106

GND

GND

CS104

4U7

4U7

1N0

14

CS110

11

RS107

RS117

4

100K0

GND

RS118

RS109

3K3

11

RS111

13

12

3K3

100K0

RS110

GND

10K0

RS108

3K3

AUDIO AMPLIFIER SCHEMATIC DIAGRAM - SCHEMA DE L’AMPLIFICATEUR AUDIO - AUDIO ENDVERSTÄRKER - SCHEMA AMPLIFICATORE AUDIO - ESQUEMA DEL AMPLICADOR AUDIO

DVI_L_IN

DVI_R_IN

From page 11

RIN_EXT

CA516

1U0

CA500

COMP2_R_IN

From page 1

1N0

CA514

100K0

RA502

1U0

CA515

LIN_EXT

From page 11

1U0

1U0

CA506

1U0

CA501

COMP1_R_IN

BA001

VIDEO_OUT

GND

GND

CA507

1N0

100K0

RA505

1U0

CA502

SW_DETECT

AV1_R_OUT

RA6020RA601

GND

GND

0

JA505

16

17

18

19

20

21

22

23

24

25

26

27

28

VGA_R_IN

1011121314

PG

SUBWOOFER

100R0

RA007

CA080

4U7

0

0

JA507

R6

R5

R4

NC

NC

R3

R2

SCL

SDA

0

JA503

0

JA500

JA501

47R0

RA500

47R0

RA501

From page 1

5V_V

MAIN_LEFT

CA006

1N0

3K3

RA506

0

JA001

AV1_L_OUT

1U0
CA513

ROUT2

LOUT3

ROUT3

IA500

TEA6422D

ADDR

0

0

JA502

GND

MAIN_RIGHT

470P0

CA015

LOUT2

ROUT1

LOUT1

L6

L5

L4

NC

NC

L3

L2

L1 R1

VS

CAPA

GND

CA503

SUB_MUTE

GND

100R0

RA006

4U7

CA081

GND

0

JA504

14 15

13

12

11

10

9

8

7

6

5

4

3

2

1

1U0

COMP1_L_IN

L/R_MUTE

AUDIO_STBY

100R0

RA009

JA506

1U0

CA522

GND

1U0

CA504

COMP2_L_IN

123456789

MASTER_MUTE#

1N0

CA005

3K3

RA507

RA005

0

JA002

AV2_L_OUT

470P0

CA008

0

9V

1U0

CA505

IIC_CL_2

VGA_L_IN

GND

100R0

CA016

CA518

CA519

CA520

CA521

470P0

1U0

CA517

47UF

100N0

47UF

100N0

IIC_DA_2

CA004

3K3

RA508

4U7

CA082

AV2_R_OUT

GND

GND

GND GND GND GND

RA017

470R0

15U0

LA003

15U0

LA002

470R0

RA015

1N0

RA008

100R0

GND

0

JA003

470P0

CA007

RA002

RESET_AUDIO# 47R0

From page 13

LA001

GND

RA012

10U0

CA017

CA018

RA016

8V

1U0

100R0

RA013

1U0

RA018

47R0

CA009

RA010

!

1K0

47R0

4R7

220N0

IA301

GND

CA010

CA019

ESDA14V2L

GND

RA302

GND

100N0

180P0

47P0

CA001

47P0

CA002

18K0

RA301

CA011

GND

RA304

100K0

1N0

RA014

GND

GND

R

L

(M)

123

BA300

GND

300R0

LA301

3

GND

180P0

10U0

IA300

4

CA302

CA052

CA012

TS482D

GND

10U0

CA304

1N0

RA003

GND

GND

10U0

CA013

GND

1U0

CA025

FCB/AV3_L_IN

CA305

RA305

4U7

100R0

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

GND

RA309

220U0

8

6

3K9

GND

100R

7

RA019

300R0

5

1K0

CA021

LA300

GND

100R

RA303

10K0

CA303

220U0

1

8

2

3K9

RA300

4U7

CA300

RA004

100R0

RA011

100R0

10U0

CA014

1K0

CA020

4

CA051

47P0

1N0

GND

10K0

RA308

GND

100K0

RA306

DACA_R

DACA_L

I2S_DA_IN4

VREF2

DACM_R

DACM_L

DACM_C

DACM_SUB

DACM_SR

DACM_SL

SC2_OUT_R

SC2_OUT_L

VREF1

SC1_OUT_R

SC1_OUT_L

CAPL_A

AHVSUP

CAPL_M

SC3_OUT_L

SC3_OUT_R

414243

1K0

RA020

GND

1U0

CA026

FCB/AV3_R_IN

IA302

GND

18K0

RA307

CA307

CA306

5V_V

GND

RESETQ

I2S_DA_IN3

AHVSS1

AHVSS2

44

CA024

CA022

ESDA14V2L

GND

100N0

GND

23

24

25

10U0

26

27

28

29

30

31

32

33

15K0
RA001

1N0

CA003

NC2

I2S_CL3

I2S_WS3

AGNDC

NC3

SC4_IN_L

4546474849

4U7

CA023

100N0

GND

RA021

47P0

GND

CA027

From page 1

I2S_DA_IN2

SC4_IN_R

1K0

1U0

AV2_L_IN

GND

22

NC22

NC23

NC24

NC25

NC26

NC27

NC28

NC29

NC30

NC31

NC32

GND

DVSS3

ASG1

RA022

21

NC21

NC19

TEST

RESETQ

35

34

CA401

DVSS1

DVSS2

IA001

SC3_IN_R

SC3_IN_L

50

1K0

CA028

AV2_R_IN

19

20

NC20

NC18

IA400

DVSUPWSCL

DVSS

36

373839

100N0

47UF

CA400

DVSUP2

DVSUP3

MSP44XYK

SC2_IN_L

ASG2

535251

47P0

CA030

47P0

CA029

1U0

CA031

NC15

NC16

NC17

MAD48XYA

DA_IN

40

I2S_DEL_CL

I2S_DEL_WS

I2S_DEL_OUT

SC2_IN_R

ASG3

SC1_IN_L

545556

1K0

RA023

RA024

GND

GND

1U0

AV1_L_IN

IFC228 MAIN EU

IFC228 AUDIO MSP°

12

13

1415161718

NC11

NC12

NC13

NC14

SDA

DA_OUT

ADR_SEL

SCL

43

44

42

41

15K0

RA401

4

6789101112131415161718192021222324

I2S_CL

I2S_WSS

I2S_DEL_IN

I2S_DA_IN1

I2S_DA_OUT

AVSS1

SC5_IN_R

VREFTOP

SC5_IN_L

SC1_IN_R

61

605859

57

100N0

CA035

10U0

CA036

GND

GND

1N0

1K0

CA038

47P0

CA033

47P0

GND

CA034

GND

1U0

1U0

CA037

CA032

AV1_R_IN

AM_AF

NC10

NC9

NC8

NC7

NC6

NC5

NC4

NC3

NC2

NC1

NC

62

GND

RA402

I2C_DA

AVSS

RA025

11

10

9

8

7

6

5

4

3

2

1

253

63

1K0

15K0

I2C_CL

NC4

SIF

1

NC1

NC5

64

some models°

GND

STANDBYQ

80

ADR_SEL

79

D_CTR_I/O_0

78

D_CTR_I/O_1

77

SPDIF_OUT

76

NC

75

AUD_CL_OUT

74

TP

73

XTAL_OUT

72

XTAL_IN

71

TESTEN

70

ANA_IN2+

69

ANA_IN-

68

ANA_IN1+

67

AVSUP

66

AVSUP1

65

LA006

!

4R7

RA027

LA004

From page 8

0

10U0

QA001

CA039

5V_V

100P0

18M432

CA043

CA042

9V

LA007

CA040

100N0

220UF

220N0
CA041

0

CA046

100P0

RA026

10V

3P3

CA044

1K0

GND

8V

CA050

CA049

CA048

GND

GND

3P3

CA047

GND

47P0

CA045

GND

10N0

GND

GND

10U0

LA005

GND

From page 10

100N0

1N0

100U0

GND

GND

GND

IFC228-LCD

First issue 08 / 04

*

* Some Models

IFC 228 SIGNAL BLOCK DIAGRAM EU (Rev 04)

BLOCK DIAGRAM - SCHEMA SYNOPTIQUE - BLOCKSCHALTBILD - SCHEMA A BLOCCHI - ESQUEMA DE BLOQUES

IFC228-LCD

First issue 04 / 05

*

* Some Models

IFC 228 SIGNAL BLOCK DIAGRAM EU (Rev 04)

BLOCK DIAGRAM - SCHEMA SYNOPTIQUE - BLOCKSCHALTBILD - SCHEMA A BLOCCHI - ESQUEMA DE BLOQUES

IFC228-LCD

First issue 04 / 05

IFC 228 SIGNAL BLOCK DIAGRAM EU (Rev 04)

BLOCK DIAGRAM - SCHEMA SYNOPTIQUE - BLOCKSCHALTBILD - SCHEMA A BLOCCHI - ESQUEMA DE BLOQUES

IFC228-LCD

First issue 08 / 04

RK01

Y

W

R

SCH FAV IFC228

VIDEO

AGND

AGND

RJ03
82R0

CJ02

220P0

1

2

3

4

5

6

BJ04

4K7

RJ02

CJ01

220P0

R

L

RJ01

4K7

JJ01

1

2

3

4

5

6

BJ01

5

4

1

2

3

BJ02

GND

GND

GND

GND

CROMA

GND

2

SK01

1

5K62

MENU

RK02

SK02

KDB IFC228

1
2

GND

1K5

RK03

453R0

2

2

RK04

2

3K32

RK05

681R0

2

SK06

CH-

1

SK03

1

CH+

SK04

VOL-

1

SK05

1

VOL+

GND

2

1

3
4

POWER

BK01=>BR002

BQ01

HP JACK

GK01A

GK01

TSOP1333TB1

GND

OUT

RQ01

3
2

1

4R7

RQ02

4R7

SCH KDB IFC228

1

GND

3

2

VS

CK01

10N0

GND

SCH IR IFC228

BQ02=>BA300

1N0

1

2

3

AGND

CQ01

1N0

CQ02

PUSH SWITCH

RK06

1K0

RK07

100R0

CK02

22U0

GNDGND

RK08

1K8

GE01

LV5433

SCH KDB/IR

PUSH SWITCH IFC228

GND

JK02

LU5351

JK01

1

2

3

4

5

BK02=>BR001

GE02

GND

IR

5V

LED_G

LED_R

FAV IFC228

IFC228-LCD

First issue 08 / 04

CA306

RA013
+

CA024

RP001

+
12

11

44

IA400

RA014

IP002

RY039

7

CA303

RA305

+

CA304

+

CA300

+

1

CA400

CA305

+

CA252

64

RA021

RA022

RA020

RA023

RA019

+

+

CA026

CA025

+

CC007

QC022

CY022

RY033
RY032

1

8

CA506

+

+

+

CA522

RX528
RX524

LX223

9

1

1

BA300

CA515

CA262

+

CA513

+

CA505

+

+

+

CA017

+

CA502

RA232
CA233
RA230

CA231

+

+

CA516

BX421

1

LA001

RA010

+

15

22

23

14

33

34

+

CA254

CA517

CA255

24

RA003

25

RA004

+

+

IA001

CA082

40

RA009

41

RA012

RA262

+

CA018

CA012

+

+

CA265

CA013

+

+

CA014

IC006

RP002

CP002

+

+

CP001

BY001

1

+

RY038

CP004

86

RY020

RY023

RY036

52

RY024

RY021

RY037

53

10

X

FDU04

BA001

CA500

W

CA501

+

+

28

IA500

V

1

+

CA504

CA520

+

+

UT

CA081

CA503

CA080

BX130

LA231
CA232
LA230
CA230

BP002

1

S

R

Q

P

CP023

+

CA518

RX222

RX525

IP001

LX224

CP006

RX221

RX224

IP004

IY002

1

BP001

N

IY001

M

L

CV231

K

LV230

CV238

LV231

CV240

J

JV800

H

G

BV201

1

BR005

F

JR141

RR122
RR121

RR130

E

TR140

RR140

TR015

CR008

RR026

TR023

D

RR028

JR184

RR402
RR029

IP005

+

BC

CP018

CR068

RR065

RR068

A

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

MAIN BOARD - PLATINE PRINCIPALE - CHASSIS GRUNDPLATTE - PIASTRA PRINCIPALE - PLATINA PRINCIPAL

43

+

TR141

RR061

TV203

FDU02

TR148

CR024

RR066
RR064

RV211

1

CV239
RV233

JR149

CR065

10

CY012

RV209

RV231

CR163

CR185

TR149

TR024

1

RV234

JV001

RR138

RR015

CV207

TV210

JV003

CR167

CR061

24

CR164
CR162
CR161

CR058
CR057
RR009

TR146

TR061

80

CV237
RV239

TR147

TR062

+

JV004

25

TV208

JV002

RR136

JR147

+

TV202

CV241

RR044

RR067

+

RV269

JR145

IP006

+

CV223

RV236

TR144

DR250

JR250

RR192

44

TV209

CV259

RR045

TR145

CY010

RV208

RV218

RR191
RR116
RR115
RR114
RR113
RR112

QR001

CV202

DV200

RV258

DV201

BR007

CR003

CV209

+

CV222

+

9

RV207

DV202

CR166

CP028

104

JV005

CV201

RV267

RR199

+

RY007

RV268

IV202

1

RR046

RR182

CR251

LR030

LR001

RY003

156

RY005

1

1

41

+

TV200

RV261

CV262

CV265

1

BV900

RR185

RR193

JV006

RV240

IV200

RV260

CY013

CV234

+

RV262

CR113

RR338

RY006

+

RR189

RV264

CV264

RV265

+

CV263

CR188

1

CR186

CV141

RX302

RV175

16

RR180

CR190

RR337

1

RY004

CV146

CV270

RV259

RR190

RR336

+

CV142

CV261

RR187

1

RV900

RR059

21

40

IV100

CV110

QV260

CR165

BR006

CR048

RR058

RR335

1

RX301

+

RR049

41

20

RV108

CV111

CR172

RR048

RR334

RV166

IR040

CV109

RR171

1

RR170

RY002

IR004

RR163

1

RY042

RV107

RV106

CV112

RR161

RR333

CV113
RV112
CV108

CV132

105

TV201

RV206
CV200

CV282
64

65

40

CV266

TV211

8

9

RR154

RR181

RR110

RR339

TR198

121

160

1

RR001

RR301

RR302

RR002

RR304

RR303

RR300

+

RR250

+

8

+

5

8

1

RA024

+

RY034

CY025

CY036

RR172

RR332

RR305

+

+

IA300

+

80

+

+

CP003

208

157

1

RY001

RV202

CV107

CV280

RR157

BR001

JR325

RA025

TC015

DC025
RC025

RY045

1

CR159
CR184

CC041

50

RY012

RY041

CY030

CY031

LV204

1

RR156

7

CA302

RA002

65

31

CC025

QY001

CY037

CY038

+

CV119

RV111

RR183

CR160

RR331

80

40

IR001

DH001

CH019

4

1

LA006

30

51

RY044

+

1

TV100

CR183

RA001

CA036

+

1

CY007

CY006

CY029

CY004

60

RV115

BR200

RR151

RR306

CY005

+

+

80

RV167

RR184

+

CV100

61

1

CA037

CC026

1

RV119

RV118

RR054

+
RC021

+

RV201

RV162

RR152

RR053

RV150

QA001

RC020

CR053

CR079

RR312

RR308

6

BH001A

+

CA027

+

IC040

+

K

+

CY002

+

RV132

RV160

CV130

RR150

IR005

RR073

RR072

RR330

RR311

IR130

RR310

RR309

RR313

RR316

RR307

54

1

IR110

BR002

1

6

5

+

CH020

+

CH006

+

CH007

+

CH016

+

CH021

+

CH017

LA004

CA048

CA031

CA028

+

+

LC013LC010

1

80

TC056

TC120

TC055

TC040

RC042

DC024

RC052

TC051

1

CY008

RY043

+

CY009

TV105

TV104

CY003

+

+

CY001

CY011

+

CV144

QV100

BARCODE-STICKER

TV102

RV161

TV107

BX423

1

+

RR106

RR341

1

RR107

4

20

RR082

8

5

1

CR070

CR083

CR071
CR081

CR082

DR210

CR211

TR216

24

RR314

25

X12

BX422

5

4

IP003

LA005

RC067

CC103

CC107

CV127

RX456

CP005

LC104

CX452

RX453

+

CC105

RC123

RV128

RX422

CC125

TV111

CX455

TX461

RR210

RR213

RR215

TR210

RT059
CT636

LT623
RT628
CT633

DC06

LC066

LC070

CC064

RC125

CC127

TC125

CV123

1

+

RV147

+

RX612

RX615

9

8

CX453

RX510

RX430

RX466

LT622

CR250

CP008

4

RC060

RC064

LC065

RC062

TC065

TC063

TC105

TC107

RC126

CC140

2139297A

10

IV101

TV110

1

TX486

RX191

RX193

CX454

RX454

RX429

RX439

CX445

TX431

RX436

LT621

CT650

CT653
LT643

CT643

+

CT656

TC127

JX407

RX490

TX432

TX462

RT627

CT644

+

LT644

+

+

TC061

RC128

DV104

RX492

TX485

CX444

RX443
RX442
RX441
RX440

RX469

IT502

IC00 1

TC132

+

20

TV109

TX463

CT635

CT632

LT641

CT692

IT503

DT509

8

9

RC130

CC145

RX488

RX486

CX476

LX472

CX470

RX464

+

+

CT652

RA027

CA032

+

+
CC084
TC070

100

LC067

CC068

CC071

CC069

TC100

CC101

LC102

81

RC100

RC101

CC121

CC123

LC124

LC122

RC120

PCB MAIN IFC228 (EU)

RV302

DV103
DV102

CV125
RV129

CV122

DV101

1

RV146

RV145

RX195

RX900

16

IX410

1

RX617

CX451

1

BX420

CX431

CR055

CR106

RR340

CR210

RR200

11

IR006

10

TR211

TR212

RR211

TR217

TR215

1

RR212

TR213

1

TR214

48

RR315

28

JR210

27

1

BT501

4

CX183

TX484

RX446

+

CT655

CT647

CT529

CA042

CV128
CV129

11

CX462

RX447

RT626

LT642

CT649

CT648

RT637

8

9
+

1

CX474

8

9

RC132

CV117

+

JX408

CT634

RC133

RV154

RV155

+

CT654

CT69 1

1

16

BH001B

RC113
RC112

RC110

+

CV120

+

CV116

RV158

RX461

RX484

RX450

TX483

RX482

IX400

RX448

RT058

RT057

CT631

21

CT621

CT651

33

CT645
CT646

+

+

CT502

DT501

DT502

3

TC112

RV121
RV133

34

DT503

3

DV100

RV159

25

36

RT609

20

RT519

CV121+

+

TX482

RX449

24

37

CX473
+

RT056

RT041

RT632

TT631

CX422

LX471

+

RX473
RX472

RX494

RX496

TX481

QX471

RT622

LT614

BR360

1

16

RT516

+

LX461

CX423

CT618

RT604

RT517

CT505

RT520

1

16

8

14

CX491

CX424
RX522

CT619

CT626

CC144

RX434

CT622

CT544

CT504

CT506

CC003

IC140

RV114

TV106

RV157

IX440

RX474

9

RT634

8

RT631

RT525

+

TX152

48

CT624

RX152

IX430

+

RT633

+

NH001

1

RT003

TX101

RX107
RX560

RX108

RX167

RX154

RX132

DX172
DX173

7

1

1

LX473

TX441

13

CX425

CX426

RX409
RX407

LT613

CT625

+

RR362

1

DR362

RR360

DR360

+

+

2

RX561
RX109

TX151

RA211

DX174

12

1

RT610

IT505

2

DX175

CX494

1

IX420
14

DX408

RX435

CT541

CT542

CT543

RX103

RX162

CA211

RX192

RX493

RX523

TT632

DT507

JT501

RT514

RX155

RX553

LX462

+

CX413

CX406

DX407

CT617

7

8

RT001

DX164
TX164

CX173

CT615

CT616

CT623

+

LT612

8

46

CT620

+

RX104

CX404

JT502

RX124

RX151

TX153

RX554

CX402

7

47

TR370

DT504

+

DX102
TX102

CX161

CX151

+

1

DT603

IT600

CT642

RR370

CR370

RT002

RX105

CT612

IT607

CX124

+

DT602

RR366

4

5

RX126

RX527

RX178

CX465

CX414

+

CT614

RT515

DT505

CA203

RX153

RX177

DX171

DX101

TX163

BX120

RX601

DX403

DX402

DX401

LT611

1

1

1

14

RT523

RX106

RX120

CX144

RX408

CX405

CT611

RT651

RT650

TR365
RR369

DT512

DT001

RA250

RA202

TX103

CX478

RX410

DT506

1

LX161

CX412

CX410

RR365

8

CT503

DT511

1

DX103

RX412

CT607
CT608

DT513

RA201

RX110

CX112

DX111

RX602

DX406

CX408

DX404

RX413

4

5

IT620

RT603

IT504

RT513

DT510

1

CA250

DX114

DX405

RX511

CA201

DX112

RX541
RX544

RX411

TT602

TT601

CA200

RT602

IT63 0

DT002

FDU06

CA202

RA200
DX115

RX169

RX546

RX513

RX600

RX414

RX512

IT608

LT601
CT602

CA271

CR365

RT524

BT502

DT508

1

RA252

RX538
RX119

RX543

1

8

LA201

LA251

RX168

RX231

BX400

DT604

CT604

RT601

1

BT600

RA271

BA200

0

X

W

V

RT004

1

BT001

TU

BX110

LA250

CA253

LA200

S

RX115

RX539

RX117

RX535

RX114

RX540

RX118

R

RX545

RX113

RX534

DX113

RX121

Q

1

P

N

M

L

K

J

H

G

F

E

D

C

B

A

0

IFC228-LCD

First issue 08 / 04

CA306

RA013
+

CA024

RP001

+
12

11

44

IA400

RA014

IP002

RY039

7

CA303

RA305

+

CA304

+

CA300

+

1

CA400

CA305

+

CA252

64

RA021

RA022

RA020

RA023

RA019

+

+

CA026

CA025

+

CC007

QC022

CY022

RY033
RY032

1

8

CA506

+

+

+

CA522

RX528
RX524

LX223

9

1

1

BA300

CA515

CA262

+

CA513

+

CA505

+

+

+

CA017

+

CA502

RA232
CA233
RA230

CA231

+

+

CA516

BX421

1

LA001

RA010

+

15

22

23

14

33

34

+

CA254

CA517

CA255

24

RA003

25

RA004

+

+

IA001

CA082

40

RA009

41

RA012

RA262

+

CA018

CA012

+

+

CA265

CA013

+

+

CA014

IC006

RP002

CP002

+

+

CP001

BY001

1

+

RY038

CP004

86

RY020

RY023

RY036

52

RY024

RY021

RY037

53

10

X

FDU04

BA001

CA500

W

CA501

+

+

28

IA500

V

1

+

CA504

CA520

+

+

UT

CA081

CA503

CA080

BX130

LA231
CA232
LA230
CA230

BP002

1

S

R

Q

P

CP023

+

CA518

RX222

RX525

IP001

LX224

CP006

RX221

RX224

IP004

IY002

1

BP001

N

IY001

M

L

CV231

K

LV230

CV238

LV231

CV240

J

JV800

H

G

BV201

1

BR005

F

JR141

RR122
RR121

RR130

E

TR140

RR140

TR015

CR008

RR026

TR023

D

RR028

JR184

RR402
RR029

IP005

+

BC

CP018

CR068

RR065

RR068

A

COMPONENT SIDE - COTÉ COMPOSANTS - BESTÜCKUNGSSEITE - LATO COMPONENTI - LADO COMPONENTES

MAIN BOARD - PLATINE PRINCIPALE - CHASSIS GRUNDPLATTE - PIASTRA PRINCIPALE - PLATINA PRINCIPAL

43

+

TR141

RR061

TV203

FDU02

TR148

CR024

RR066
RR064

RV211

1

CV239
RV233

JR149

CR065

10

CY012

RV209

RV231

CR163

CR185

TR149

TR024

1

RV234

JV001

RR138

RR015

CV207

TV210

JV003

CR167

CR061

24

CR164
CR162
CR161

CR058
CR057
RR009

TR146

TR061

80

CV237
RV239

TR147

TR062

+

JV004

25

TV208

JV002

RR136

JR147

+

TV202

CV241

RR044

RR067

+

RV269

JR145

IP006

+

CV223

RV236

TR144

DR250

JR250

RR192

44

TV209

CV259

RR045

TR145

CY010

RV208

RV218

RR191
RR116
RR115
RR114
RR113
RR112

QR001

CV202

DV200

RV258

DV201

BR007

CR003

CV209

+

CV222

+

9

RV207

DV202

CR166

CP028

104

JV005

CV201

RV267

RR199

+

RY007

RV268

IV202

1

RR046

RR182

CR251

LR030

LR001

RY003

156

RY005

1

1

41

+

TV200

RV261

CV262

CV265

1

BV900

RR185

RR193

JV006

RV240

IV200

RV260

CY013

CV234

+

RV262

CR113

RR338

RY006

+

RR189

RV264

CV264

RV265

+

CV263

CR188

1

CR186

CV141

RX302

RV175

16

RR180

CR190

RR337

1

RY004

CV146

CV270

RV259

RR190

RR336

1

1

1

RY002

RY042

+

RV107

RX301

RV106

20

21

40

RV900

IV100

41

RV108

CV112

CV142

CV110

CV109

CV113
RV112
CV108

RV166

CV111

QV260

CV261

CV132

CR165

IR004

IR040

+

1

BR006

CR172

CR048

RR161

RR048

RR163

RR171

RR170

RR059

RR187

RR058

RR049

RR335

RR334

RR333

105

TV201

RV206
CV200

CV282
64

65

40

CV266

TV211

8

9

RR154

RR181

RR110

RR339

TR198

121

160

1

RR001

RR301

RR302

RR002

RR304

RR303

RR300

+

RR250

+

8

+

5

8

1

RA024

+

RY034

CY025

CY036

RR172

RR332

RR305

+

+

IA300

+

80

+

+

CP003

208

157

1

RY001

RV202

CV107

CV280

RR157

BR001

JR325

RA025

TC015

DC025
RC025

RY045

1

CR159
CR184

CC041

50

RY012

RY041

CY030

CY031

LV204

1

RR156

7

CA302

RA002

65

31

CC025

QY001

CY037

CY038

+

CV119

RV111

RR183

CR160

RR331

80

40

IR001

DH001

CH019

4

1

LA006

30

51

RY044

+

1

TV100

CR183

RA001

CA036

+

1

CY007

CY006

CY029

CY004

60

RV115

BR200

RR151

RR306

CY005

+

+

80

RV167

RR184

+

CV100

61

1

CA037

CC026

1

RV119

RV118

RR054

+
RC021

+

RV201

RV162

RR152

RR053

RV150

QA001

RC020

CR053

CR079

RR312

RR308

6

BH001A

+

CA027

+

IC040

+

K

+

CY002

+

RV132

RV160

CV130

RR150

IR005

RR073

RR072

RR330

RR311

IR130

RR310

RR309

RR313

RR316

RR307

54

1

IR110

BR002

1

6

5

+

CH020

+

CH006

+

CH007

+

CH016

+

CH021

+

CH017

LA004

CA048

CA031

CA028

+

+

LC013LC010

1

80

TC056

TC120

TC055

TC040

RC042

DC024

RC052

TC051

1

CY008

RY043

+

CY009

TV105

TV104

CY003

+

+

CY001

CY011

+

CV144

QV100

BARCODE-STICKER

TV102

RV161

TV107

BX423

1

+

RR106

RR341

1

RR107

4

20

RR082

8

5

1

CR070

CR083

CR071
CR081

CR082

DR210

CR211

TR216

24

RR314

25

X12

BX422

5

4

IP003

LA005

RC067

CC103

CC107

CV127

RX456

CP005

LC104

CX452

RX453

+

CC105

RC123

RV128

RX422

CC125

TV111

CX455

TX461

RR210

RR213

RR215

TR210

RT059
CT636

LT623
RT628
CT633

DC06

LC066

LC070

CC064

RC125

CC127

TC125

CV123

1

+

RV147

+

RX612

RX615

9

8

CX453

RX510

RX430

RX466

LT622

CR250

CP008

4

RC060

RC064

LC065

RC062

TC065

TC063

TC105

TC107

RC126

CC140

2139297A

10

IV101

TV110

1

TX486

RX191

RX193

CX454

RX454

RX429

RX439

CX445

TX431

RX436

LT621

CT650

CT653
LT643

CT643

+

CT656

TC127

JX407

RX490

TX432

TX462

RT627

CT644

+

LT644

+

+

TC061

RC128

DV104

RX492

TX485

CX444

RX443
RX442
RX441
RX440

RX469

IT502

IC00 1

TC132

+

20

TV109

TX463

CT635

CT632

LT641

CT692

IT503

DT509

8

9

RC130

CC145

RX488

RX486

CX476

LX472

CX470

RX464

+

+

CT652

RA027

CA032

+

+
CC084
TC070

100

LC067

CC068

CC071

CC069

TC100

CC101

LC102

81

RC100

RC101

CC121

CC123

LC124

LC122

RC120

PCB MAIN IFC228 (EU)

RV302

DV103
DV102

CV125
RV129

CV122

DV101

1

RV146

RV145

RX195

RX900

16

IX410

1

RX617

CX451

1

BX420

CX431

CR055

CR106

RR340

CR210

RR200

11

IR006

10

TR211

TR212

RR211

TR217

TR215

1

RR212

TR213

1

TR214

48

RR315

28

JR210

27

1

BT501

4

CX183

TX484

RX446

+

CT655

CT647

CT529

CA042

CV128
CV129

11

CX462

RX447

RT626

LT642

CT649

CT648

RT637

8

9
+

1

CX474

8

9

RC132

CV117

+

JX408

CT634

RC133

RV154

RV155

+

CT654

CT69 1

1

16

BH001B

RC113
RC112

RC110

+

CV120

+

CV116

RV158

RX461

RX484

RX450

TX483

RX482

IX400

RX448

RT058

RT057

CT631

21

CT621

CT651

33

CT645
CT646

+

+

CT502

DT501

DT502

3

TC112

RV121
RV133

34

DT503

3

DV100

RV159

25

36

RT609

20

RT519

CV121+

+

TX482

RX449

24

37

CX473
+

RT056

RT041

RT632

TT631

CX422

LX471

+

RX473
RX472

RX494

RX496

TX481

QX471

RT622

LT614

BR360

1

16

RT516

+

LX461

CX423

CT618

RT604

RT517

CT505

RT520

1

16

8

14

CX491

CX424
RX522

CT619

CT626

CC144

RX434

CT622

CT544

CT504

CT506

CC003

IC140

RV114

TV106

RV157

IX440

RX474

9

RT634

8

RT631

RT525

+

TX152

48

CT624

RX152

IX430

+

RT633

+

NH001

1

RT003

TX101

RX107
RX560

RX108

RX167

RX154

RX132

DX172
DX173

7

1

1

LX473

TX441

13

CX425

CX426

RX409
RX407

LT613

CT625

+

RR362

1

DR362

RR360

DR360

+

+

2

RX561
RX109

TX151

RA211

DX174

12

1

RT610

IT505

2

DX175

CX494

1

IX420
14

DX408

RX435

CT541

CT542

CT543

RX103

RX162

CA211

RX192

RX493

RX523

TT632

DT507

JT501

RT514

RX155

RX553

LX462

+

CX413

CX406

DX407

CT617

7

8

RT001

DX164
TX164

CX173

CT615

CT616

CT623

+

LT612

8

46

CT620

+

RX104

CX404

JT502

RX124

RX151

TX153

RX554

CX402

7

47

TR370

DT504

+

DX102
TX102

CX161

CX151

+

1

DT603

IT600

CT642

RR370

CR370

RT002

RX105

CT612

IT607

CX124

+

DT602

RR366

4

5

RX126

RX527

RX178

CX465

CX414

+

CT614

RT515

DT505

CA203

RX153

RX177

DX171

DX101

TX163

BX120

RX601

DX403

DX402

DX401

LT611

1

1

1

14

RT523

RX106

RX120

CX144

RX408

CX405

CT611

RT651

RT650

TR365
RR369

DT512

DT001

RA250

RA202

TX103

CX478

RX410

DT506

1

LX161

CX412

CX410

RR365

8

CT503

DT511

1

DX103

RX412

CT607
CT608

DT513

RA201

RX110

CX112

DX111

RX602

DX406

CX408

DX404

RX413

4

5

IT620

RT603

IT504

RT513

DT510

1

CA250

DX114

DX405

RX511

CA201

DX112

RX541
RX544

RX411

TT602

TT601

CA200

RT602

IT63 0

DT002

FDU06

CA202

RA200
DX115

RX169

RX546

RX513

RX600

RX414

RX512

IT608

LT601
CT602

CA271

CR365

RT524

BT502

DT508

1

RA252

RX538
RX119

RX543

1

8

LA201

LA251

RX168

RX231

BX400

DT604

CT604

RT601

1

BT600

RA271

BA200

0

X

W

V

RT004

1

BT001

TU

BX110

LA250

CA253

LA200

S

RX115

RX539

RX117

RX535

RX114

RX540

RX118

R

RX545

RX113

RX534

DX113

RX121

Q

1

P

N

M

L

K

J

H

G

F

E

D

C

B

A

0

IFC228-LCD

First issue 08 / 04

AUDIO 2

AUDIO 2

AUDIO 2

AV1_L_IN

AV1_R_IN

AV2_L_IN

AV2_R_IN

FCB/AV3_L_IN

FCB/AV3_R_IN

COMP1_L_IN

COMP1_R_IN

AV1_R_OUT

22U0

CA252

220R0

RA250

LA250

R_OUT_AV1

AV_IN

47K0

RA251

CA251

CA250

470P0

1N0

GND

GND

GND

AV1_L_OUT

22U0

CA255

220R0

RA252

LA251

L_OUT_AV1

47K0

RA253

CA254

470P0

CA253

CA271

RA271

CA270

330P0

47K

220P0

DVI_L_IN

GND GND GND

LA272

RA272

300

CA273

RA273

4K7

220P0

123

330P0

47K

CA272

Red

VGA_L_IN

GND

GND

4K7

RA280

GND

300

LA281

5

GND

4

6

7

8

BA200

Red

Whi

Whi

CA281

RA281

CA280

330P0

47K

220P0

VGA_R_IN

GND

GND

GND

LA282

RA282

300

CA283

RA283

4K7

CA282

330P0

GNDGNDGND

47K

220P0

18may04

47K0

RA261

CA261

470P0

1N0

CA260

AV2_L_OUT

22U0

CA265

GND

GND

220R0LA261

RA262

GND

L_OUT_AV2

RA263

CA264

CA263

AV2_R_OUT

22U0

CA262

GND

220R0

RA260

GND GND

1N0

LA260

R_OUT_AV2

47K0

470P0

1N0

GND

GND

GND

DVI_R_IN

RA270

300

LA271

4K7

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

4K7

RA200

LA200

L_IN_AV1

AV_IN

300

RA201

47K0

220P0

CA201

220P0

CA200

GND

GND

4K7

RA202

GND

LA201

R_IN_AV1

AUDIO 1

2135261B

IFC228 MAIN E

0

RA224

0

RA225

RA232

LA231

L_IN_FCB

220P0

RA233

47K0

4K7

CA232

300 CA233

220P0

GND

GND

GND

4K7

RA240

300

LA240

R_IN_COMP1

CA241

RA241

CA240

47K

330P0

220P0

GNDGND

GND

RA242

CA243

RA243

4K7

CA242

LA241

300

L_IN_COMP1

330P0

47K

220P0

220P0

CA231

RA231

220P0

GND

47K0

GND

CA230

GND

47K0

GND

GND

GND

RA222

LA221

4K7

300

R_IN_AV3

RA223

CA223

CA222

220P0

220P0

GND

GNDGND

RA230

LA230

4K7

300

R_IN_FCB

47K0

GND

GND

GND

RA220

4K7

300

LA220

L_IN_AV3

RA221

CA221

CA220

220P0

220P0

RA213

RA203

47K0

220P0

CA203

GND

220P0

CA202

GND

300

GND

4K7

RA210

LA210

L_IN_AV2

47K0

RA211

CA211

220P0

CA210

220P0

300

GND

GND

RA212

GND

4K7

300

LA211

R_IN_AV2

CA213

CA212

47K0

220P0

220P0

0B/S

GND

GND

GND

VIDEO SW

IFC228-LCD

First issue 08 / 04

VP/ADC

LY005

10UH

3V3_IO

CY021

CY010

CY023

100UF

100N

100N

CY016

NC7

NC1

DQ8

DQ7

DATA7

DATA8

VDDQ7

VSSQ2

DQ9

DQ6

DATA9

DQ10

DQ5

1011121314

DATA5

DATA10

VSSQ7

VDDQ2

9

DQ11

DQ4

DATA12

DATA11

DQ12

DQ3

DATA3

3V3_A

VDDQ8

VSSQ1

DATA13

DQ13

DQ2

DATA1

DATA14

DQ14

VDDQ1

DQ1

VSSQ8

2345678

DATA15

DQ15

DQ0

1

DATA0

VSS4

VDD1

CY015

CY012

CY018

100UF

CY013

100N

CY011

100N

16V

10UF

100UF

CY014

CY017

CY019

100N

10UH

LY008

10UH

LY007

100N

16V

10UH

LY006

100N

GND

GND

16V

3V3

SDRAM_

100N

ADDR3

DQM

DATA31

DATA30

DATA29

DATA28

DATA27

DATA26

DATA25

CY022

100N

CY020

100N

16V

DATA24

44454647484950515253545556575859606162

VSS1

DQ24

DQ25

DQ26

DQ27

DQ28

DQ29

VDDQ5

VSSQ6

DQ30

VSSQ5

DQ31

VDDQ6

ADDR5

ADDR4

63

A3A4A5

A6

NC4

VSS2

DQM3

CLKIN

470R

RY035

ADDR9

ADDR8

ADDR7

ADDR6

CKE

6465666768697071727374757677787980818283848586

A7A8A9

CKE

CLK

NC5

NC6

VSS3

DQM1

IY002

RASCSNC2

BA0

BA1

A10

DQM0

VDD2WECAS

1920212223

161517

18

DQM

WEN

CASN

RASN

CSN

BA0

RY025

100R

VDDQ3

DQ19

DQ20

VSSQ4

DQ21

DQ22

VDDQ4

DQ23

VDD4

MT48LC2M32B1

DATA18

DATA19

DATA20

DATA21

DATA22

DATA23

DQ18

3334353637383940414243

DATA17

DQ17

VSSQ3

DATA16

DQ16

A1

DQM2A2VDD3

NC3

A0

24

26282729303132

25

BA1

ADDR10

ADDR0

ADDR1

ADDR2

DQM

SINGLE NET

10UH

LY001

0R

RY050

VHS_CSYNC
VVS

RY005

(16/20/24bit output)

100N

CY036

3V3_DAC

CY037

100N

100N

CY038

CY003

16V

10UF

CY002

16V

10UF

0

16V

CY001

10UF

HDFL

RY006

33R

RY004

5
6
7
8

33R

33R

RY003

RY007

5
6
7
8

5
6
7
8

RY002

RY001

RY027

RY033

RY034

RY022

RY039

RY032

10K

10K

RY023

10K

10K

10K

0R

RY020

10K

RY021

RY038

0R

RY037

470R

IIC_CL_2

470R

RY036

IIC_DA_2

123

5V_STBY

470R

SOFT_RESET

GND

RY047

BY001

4

0R

0R

RY046

GENCAM 1

(OPTION)FLI 2300 VIDEO PROCESSOR

IFC228 MAIN EU

RASN

CASN

BA1

BA0

CSN

DQM

VDFL

0R

RY051

5

4
6
7
8

1

33R

4

1

4

1

4

1

4

5
6
7

33R

8

1

4

5
6
7

33R

8

1

4

5
6
7

33R

8

1

0R

4K7

RY028

GND

100N

CY033

CY034

100N

CY035

1V8_CORE

10UH

LY002

CY032

CY009

100N

100N

100UF

SDRAM_CLK

SDRAM_CLKIN

1V8_PLL

GND

16V

LY003

100UF

CY008

105
106
107
108
109
110
111
112
113
114
115
116
117

CTLOUT0

118

CTLOUT1

119
120

CTLOUT4

CLK_OUT
VID_OUT16
VID_OUT17

VID_OUT18
VID_OUT19
VID_OUT20
VID_OUT21
VID_OUT22
VID_OUT23
VID_OUT8
VID_OUT9

VID_OUT10
VID_OUT11
VID_OUT12
VID_OUT13
VID_OUT14
VID_OUT15

VID_OUT0
VID_OUT1
VID_OUT2
VID_OUT3
VID_OUT4
VID_OUT5
VID_OUT6
VID_OUT7
OE

100N

CY028

100N

CY030

CY004

10UH

16V

121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156

CY029

CY031

10UF

GND

100N

100N

16V

LY004

10UH

WEN

ADDR0

ADDR1

ADDR2

ADDR3

ADDR4

ADDR5

ADDR6

ADDR7

ADDR8

ADDR9

ADDR10

DATA31

DATA30

DATA29

DATA28

DATA27

DATA26

DATA25

DATA24

DATA23

DATA22

DATA21

DATA20

DATA19

DATA18

DATA17

DATA16

DATA15

DATA14

DATA13

DATA12

DATA11

DATA10

DATA9

DATA8

DATA7

DATA6

DATA5

DATA4

99

98

102

104

103

101

100

IY001

FLI 2300

FAROUJA

158

159

157

160

161

169

168

167

166

164

165

163

162

CY006

10UF

100N

CY027

GND

1V8_DAC

170

171

16V

CY026

100N

16V

10UF

CY005

DAC_GOUT

DAC_BOUT

0R

0R

RY040

RY041

173

172

175

174

DAC_ROUT

RY042

180

179

178

177

176

0R

CY007

RY011

47R

RY010

RY009

10UF

47R

185

184

183

182

181

16V

100N

CY025

47R

CY024

186

CY040

CY039

100N

193

192

191

190

189

188

187

XTAL_IN

XTAL_OUT

1M

RY013

Z

33P

13.5MH

QY001

33P

180R

RY014

8R2

RY015

202

203

204

205

206

201

200

199

198

197

196

195

194

1M

RY012

RY043

656IO_0

D1DATA0

8

33R

1

656IO_1

D1DATA2

D1DATA1

656IO_3

656IO_2

D1DATA4

DIDATA3
5

8

4

1

656IO_4

D1DATA6

D1DATA5

656IO_6

656IO_5

D1DATA7

5

4

656IO_7

DATA3

535455565758596061626364656667686970717273747576777879808182838485868788899091929394959697

207

RY044

208

D1_CLK
8

33R

1

52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2

1

D1_VSYNC

D1FID

CLKOUT

D1_HSYNC

5

RY045

4

656VIO

656HIO

RY024

33R

VSP

10K

RY030

DATA2
DATA1
DATA0

10K

RY031

RY029

3V3_IO

10K

10K

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

3V3_UC

1V8_UC

U_BB

Y_GG

V_RR

VP/ADC

IFC228-LCD

First issue 08 / 04

6V

IN

IT630

OUT

LD1117DT33

+3.3V_DVI

GENCAM 1

CT693

220N

330NH

3K3

CT644

10NF

100PF

RT621

10UF

CT647

CT646

GND

16V

10UF

100NF

LT641

16V

330NH

LT642

330NH

RT637

LT643

LT644

CT654

143R

GND

100NF

CT624

GND

CT691

220UF

10V220N

RT635

TT632

RT632

LT611

CT692

100K

BC856B

300R

LT613

CT607

330NH

300R

330NH

100NF

RT633

LT614

LT612

RT631

GND

330NH

330NH

RT634

300R

CT642

RT636

470R

47UF

1M

TT631

100NF
CT604

16V

BC846B

PRE

DVI_DETECT

GND

33K

RT604

CT643

CT645

CT618

10UF

100NF

CT619

CT620

100PF

231

PB0

PB1

VSS

330NH

100PF

CT623

CT625
100PF

CT650

10UF

16V

GND

DVI_B

DVI_G

VGA

DVI_R

VIDEO SW

100NF

CT649

100PF

CT648

0R

GND

CT653

10UF

16V

100PF

CT651

100NF

CT652

16V

10UF

CT656

GND

100NF

CT655

33

SCLM

34

35

36

37

38

39

40

41

42

43

44

45

46

10UF 16V

GND

DACVCCB

DACGNDB

DACGND

SDAM

DACVCC

RESERVED

RESETN

SCDT

DVCC_2

ODCK

DGND_2

DE

GND_3

VCC_3

AGND_3

4748495051

8

10R

RT650

1

IT607

NSAD500H

RX2+

7

3

2

0R

RT058

RT059

GND

22PF

CT636

680NH

LT623

22PF

CT633

75R

RT628

25

26

27

28

29

303132

IOB

COMP

AGND_2

RX2-

6

5

4

GND

IOG

RSET

DACVCCG

DACGNDG

IT600

SII907B

AVCC_1

RX1-

RX0+

RX1+

1234567

52

8

7

1

2

IT608

NSAD500H

DACGNDR

RX0-

6

5

3

4

DACVCCR

AGND_1

RT651

RT057

LT622

222324

IOR

RXC+

10R

0R

CT635

20506520

680NH

22PF

CT632

75R

RT627

21

VCC_2

RXC-

100PF

CT614

22PF

GND_2

AVCC_2

100PF

DVI_B

GND

PD_DAC

VSYNC

HSYNC

DVCC_1

DGND_1

SCLS

SDAS

VCC_1

GND_1

PD

PGND_1

PVCC_1
EXT_RES

CT613

DVI_G

680NH

20

19

18

17

16

15

14

13

12

11

10

9

8

LT621

DVI_R

CT621

RT611

100NCT612

CT634

CT631

RT626

100PF

412R0

22PF

22PF

75R

CT61110UF

33K

RT610

GND

DVI_HSYNC

DVI_VSYNC

100PF

CT626

0R

470R

CT617

CT615

RT056

RT041

100PF

10UF

DVI_VSYNC

100PF

CT622

100NF

CT616

16V

VGA

DVI_HSYNC

0R

RT055

RT622

470R

IFC228 MAIN EU

DIGITAL VISUAL INTERFACE (DVI)

33K

RT609

GND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

4

123

4K7

RT603

7

5

8

6

DT604

+3.3V_DVI

+5V_DVI

IT620

M24CO2-WMN6

MMSZ6V8T1

GND

GND

MMSZ6V8T1

DT602

100NF

MODE /

SDA

SCL

WC

VCC

65847

DT603

MMSZ6V8T1

GND

RT602

RT612

12K

LT601

RT613

330NH

100R

WC

GND

RT614

0R

(to BT501)

100R

RT601

100R

RX1-

RX2+

RX2-

1234567891011121314151617181920212223

DVI_SCL

GND

RX1+

DVI_SDA

+5V

GND

GND

HTPLUG

RX0-

RX0+

CT602

100NF

0

CT608

GND

GND

TXC-

TXC+

24

S

BT600

100R

100R

RT606

RT605

G

PMBF170

G

S

D

TT602

PMBF170

IFC228-LCD

First issue 08 / 04

D

TT601

GM_BUSY

GM_INTERRUPT

IIC_DA_4
IIC_CL_4

IIC_DA_2

IIC_CL_2

GENCAM 1

WE_ROM#

3V3_STBY

IR_OUT

RESET#

AQR_ON

5V_ON_CHECK

UART_IN

UART_OUT

GENCAM 1

0R

JR140

4K7

RR203

39P

CR154

5V_STBY

SAFETY_ENABLE

DVI_DETECT (US)

100R

RR902

39P

39P

CR193

CR155

100R

100R

RR900

RR901

100R

RR903

39P

39P

CR195

CR194

(to 1501)

1

2

3

4

0R

JR800

GND

39P

CR197

39P

CR196

5

6

39P

47N
CR150

CR049

BV900

BR007

6

5

4

3

JTAG

2

1

(M)

11

10

9

8

7

6

DEBUG

5

4

3

2

1

BR006

0R

JR801

3D_FRAME(US)
IIC_DA_2

IIC_CL_2

MASTER_MUTE#

AUDIO_STBY_MUTE#

RESET_AUDIO#

IIC_DA_2

IIC_CL_2

SAFETY_INT

480_ON(US)

FB_OSD

B_OSD

G_OSD

R_OSD

EFC

FW_ADJUST

TUBE_DETECTION

BSVM_BLANK

PO_TR

G2_ADJUST

VDFL

HDFL

INT_DMU

RESET_DMU#

IIC_DA_4

IIC_CL_4

IIC_DA_3

IIC_CL_3

IIC_DA_2

IIC_CL_2

IIC_DA_1

IIC_CL_1

SAFETY_ENABLE

JTIN

JTOUT

JTCLK

JTSEL

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

VIDEO SW TUNER DVI VP/ADC AUDIO 2 COMB

RR023

5V_STBY

1K

100R

RR024

TR024

LED_TOPLIGHT

100R

RR021

TR023

560P

CR024

BC856B

BC846B

DVI_DETECT

IIC_DA_2

IIC_CL_2

3V3_STBY

DVD_KEY

DC_DC_ON#

EXT_ON#

CVBS_TXT_M

CVBS_TXT_S

IIC_DA_4

IIC_CL_4

IIC_DA_2

IIC_CL_2

RR028

1K

RR022

100R

RR402

RR400

SYNC_ENABLE

RESTART_LED

RESTART_LED

2K2

100R

RR029

100R

RR027

100R

330R

RR030

BR001

RESET#

VOLTAGE REGULATOR

1K5

RR015

3V3_STBY

5V_V

5V_STBY

CR065

CR008

47N

0R

JR025

56R

RR025

TOPLIGHT

GND

IR

5V_STBY

LED

12345

47N

RR026

BR200

1

2

LED#

453R

RR017

150R

RR009

RR401

JR010

PO

TR015

10K

56R

0R

1V8_STBY

3V3_STBY

5V_STBY

5V_V

DEGAUSS

AQR_ON

BC856B

0R

BR002

KEYBOARD

INF_POW_FAIL

ECO_STANDBY#

IR

KEYBOARD

POWER_SWITCH

JR017

POWER

3V3_STBY

4

5V_STBY

FRONT-END

IFC228 MAIN EU

1K5

RR117

3V3_STBY

CR006

10N

1%

1K5

CR007

RR005

47N

CR009

39P

CR057

123

KEYBOARD

4K7

RR370

CR370

TR370

BC856B

HDFL

JR080 0R

10N

123456789

(M)

BR005

100P

VDFL

IR_UC

0R

JR081

CR163

CR164

RR369

RR051

IR

39P

39P

10K

1K

IRDA_IN

0RJR050

100P

CR365

to Wired-IR

IIC_CL_4

IIC_DA_4

0RJR052

JR051 0R

FE-BOX

RR361

470R

RR360

BR360

IRDA_OUT

JR053 0R

TR365

RR365

220R

IR

BC846B

1K

5V_STBY

10

RR362

123

RR366

CR362

DR362DR360

CR360

220R

CR161

CR162

CR058

CR185

2K2

39P

ZMM6.8

39P

ZMM6.8

39P

39P

39P

47N

IFC228-LCD

First issue 08 / 04

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

DVI_L_IN

DVI_R_IN

From page 11

RIN_EXT

1U0

CA500

COMP2_R_IN

From page 1

1N0

CA514

100K0

RA502

1U0

CA515

LIN_EXT

From page 11

1U0

CA516

1U0

CA506

1U0

CA501

BA001

VIDEO_OUT

GND

GND

CA507

1N0

100K0

RA505

1U0

CA502

VGA_R_IN

COMP1_R_IN

1011121314

PG

SW_DETECT

RA007

CA080

AV1_R_OUT

RA6020RA601

GND

GND

JA507

0

JA505

16

17

18

19

20

21

22

23

24

25

26

27

28

From page 1

SUBWOOFER

100R0

4U7

AV1_L_OUT

0

0

1U0

CA513

ROUT2

LOUT3

ROUT3

R6

R5

R4

NC

NC

R3

R2

ADDR

SCL

SDA

0

JA503

0

JA500

0

JA501

47R0

RA500

47R0

RA501

5V_V

MAIN_LEFT

CA006

1N0

3K3

RA506

0

JA001

IA500

TEA6422D

0

JA502

GND

CA015

470P0

CA503

SUB_MUTE

MAIN_RIGHT

GND

100R0

RA006

4U7

CA081

GND

0

JA504

LOUT2

14 15

ROUT1

13

LOUT1

12

L6

11

L5

10

L4

9

NC

8

NC

7

L3

6

L2

5

L1 R1

4

VS

3

CAPA

2

GND

1

1U0

COMP1_L_IN

L/R_MUTE

AUDIO_STBY

100R0

RA009

JA506

1U0

CA522

GND

1U0

CA504

COMP2_L_IN

123456789

MASTER_MUTE#

1N0

CA005

3K3

RA507

0

JA002

AV2_L_OUT

470P0

CA008

0

9V

1U0

CA505

IIC_CL_2

VGA_L_IN

RA005

CA518

CA519

CA520

CA521

GND

100R0

CA016

470P0

47UF

100N0

47UF

100N0

IIC_DA_2

1U0

CA517

1N0

CA004

3K3

RA508

4U7

CA082

AV2_R_OUT

GND

GND

GND GND GND GND

RA017

470R0

15U0

LA003

15U0

LA002

470R0

RA015

RA008

100R0

GND

0

JA003

470P0

CA007

RA002

RESET_AUDIO# 47R0

From page 13

LA001

GND

RA012

10U0

CA017

CA018

8V

1U0

RA016

100R0

1U0

RA018

47R0

RA010

!

RA013

47R0

CA009

4R7

1K0

220N0

IA301

GND

CA010

CA019

CA001

ESDA14V2L

GND

RA302

GND

100N0

180P0

47P0

47P0

CA002

18K0

RA301

CA011

GND

RA304

100K0

1N0

RA014

GND

GND

L

R

(M)

123

BA300

GND

300R0

LA301

300R0

LA300

GND

RA303

10K0

CA303

220U0

8

2

3K9

RA300

4U7

CA300

RA004

100R0

RA011

1K0

100R

1

100R0

10U0

CA014

CA020

GND

3

180P0

10U0

4

CA052

CA012

IA300

TS482D

GND

10U0

CA302

1N0

GND

GND

10U0

CA013

GND

1U0

CA025

100R

RA309

220U0

CA305

7

8

5

6

3K9

RA305

4U7

CA304

GND

100R0

RA003

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

GND

1K0

RA019

CA021

FCB/AV3_L_IN

4

CA051

47P0

1N0

VREF2

VREF1

GND

10K0

RA308

GND

100K0

RA306

DACA_R

DACA_L

I2S_DA_IN4

DACM_R

DACM_L

DACM_C

DACM_SUB

DACM_SR

DACM_SL

SC2_OUT_R

SC2_OUT_L

SC1_OUT_R

SC1_OUT_L

CAPL_A

AHVSUP

CAPL_M

SC3_OUT_L

SC3_OUT_R

414243

1K0

RA020

GND

1U0

CA026

FCB/AV3_R_IN

IA302

GND

RA307

CA307

CA306

5V_V

GND

I2S_DA_IN3

AHVSS1

44

CA024

CA022

ESDA14V2L

18K0

GND

100N0

GND

10U0

15K0

1N0

RESETQ

I2S_CL3

I2S_WS3

AHVSS2

AGNDC

NC3

4546474849

4U7

CA023

GND

47P0

GND

From page 1

23

24

25

26

27

28

29

30

31

32

33

RA001

CA003

NC2

SC4_IN_L

100N0

RA021

1U0

CA027

I2S_DA_IN2

SC4_IN_R

1K0

AV2_L_IN

GND

NC22

NC23

NC24

NC25

NC26

NC27

NC28

NC29

NC30

NC31

NC32

DVSS3

ASG1

RA022

22

NC21

RESETQ

34

GND

DVSS2

SC3_IN_L

50

1K0

AV2_R_IN

21

20

NC19

NC20

DVSS

TEST

36

35

CA401

100N0

CA400

DVSS1

DVSUP3

IA001

MSP44XYK

ASG2

SC3_IN_R

CA030

1U0

CA028

19

NC18

DVSUPWSCL

373839

47UF

DVSUP2

SC2_IN_L

535251

47P0

47P0

CA029

NC17

IA400

545556

RA023

CA031

NC14

NC15

NC16

MAD48XYA

DA_IN

DA_OUT

40

41

RA401

I2S_DEL_IN

I2S_DEL_CL

I2S_DEL_WS

I2S_DEL_OUT

SC2_IN_R

ASG3

SC1_IN_L

SC1_IN_R

57

CA035

GND

1K0

1K0

RA024

GND

GND

1U0

AV1_L_IN

AV1_R_IN

IFC228 MAIN EU

IFC228 AUDIO MSP°

12

13

1415161718

NC11

NC12

NC13

NC10

NC9

NC8

NC7

NC6

NC5

NC4

NC3

NC2

NC1

NC

SDA

ADR_SEL

SCL

43

44

42

6789101112131415161718192021222324

I2S_DA_OUT

SC5_IN_L

605859

10U0

CA036

CA038

47P0

47P0

CA034

1U0

4

I2S_CL

I2S_WSS

AVSS1

SC5_IN_R

61

1N0

GND

GND

1U0

CA037

AM_AF

62

GND

RA402

253

I2C_DA

AVSS

63

RA025

15K0

I2S_DA_IN1

VREFTOP

100N0

GND

CA033

CA032

11

10

9

8

7

6

5

4

3

2

1

I2C_CL

NC4

1K0

SIF

15K0

1

64

some models°

NC1

STANDBYQ

ADR_SEL

D_CTR_I/O_0

D_CTR_I/O_1

SPDIF_OUT

NC

AUD_CL_OUT

TP

XTAL_OUT

XTAL_IN

TESTEN

ANA_IN2+

ANA_IN-

ANA_IN1+

AVSUP

AVSUP1

NC5

!

From page 8

GND

LA006

RA027

LA004

80

79

78

77

76

75

74

73

72

71

70

69

68

67

66

65

4R7

10U0

0

QA001

CA039

5V_V

18M432

100P0

CA043

CA042

9V

LA007

CA040

100N0

220UF

CA046

220N0
CA041

100P0

RA026

0

GND

CA047

3P3

47P0

CA045

10N0

CA044

1K0

GND

GND

10V

GND

8V

From page 10

CA050

100N0

GND

CA049

1N0

GND

100U0

CA048

GND

GND

3P3

GND

GND

GND

10U0

LA005

IFC228-LCD

First issue 08 / 04

CT541

22UF

BT001

10

9

8

7

6

5

4

3

2

FACTORY TEST-PORT

GND

1

RED

RT507

150R

RT517

150R

100N

CT504

RT516

4K7

RAIN

4K7

RT527

IIC_DA1

IIC_CL1

IIC_DA2

IIC_CL2

IIC_DA3

IIC_CL3

IIC_DA4

Y/CVBS

BAV99L

DT501

CT542

22UF

GNDGND

NSAD500H

DT001

VGA-RGB

1617

BT502

DB15HD_V

CT505

4K7

RT528

100N

GREEN

617

GND

RT508

150R

150R

RT519

RT518

4K7

GAIN

BAV99L

DT502

DT002

NSAD500H

5
6
7
8

RT002

5
6
7
8

CSDA

121314

2

BAV99L

DT503

RT001

HSYNC

3

GENCAM 1

4
3
2
1

68R

4
3
2
1

0R

RT003

68R

0R

CSCL

VSYNC

15

4118

9

5

10

VGA_GND

BLUE

RT509

150R

150R

RT520

100N

4K7

RT521

4K7

RT529

RT004

IIC_DA_1

IIC_CL_1

IIC_DA_2

IIC_CL_2

IIC_DA_3

IIC_CL_3

IIC_DA_4IIC_CL4

IIC_CL_4

RT523

DT506

10R

DT507

100R

RT510

MMSZ6V8T1

VGA_GND

VGAWC

VGA_GND

IFC228 MAIN EU

VIDEO GRAPHIC ADAPTOR (VGA)

0R

JT503

DT512

33V

RT531

RT530

ZMM33

VGA_GND

47R

47R

33V

DT513

ZMM33

VGA_GND

101112

DT510

141

ZMM33

DT511

33V

13

ZMM33

33V

IT505

74HCT14T/D

234569

RT525

1K

1K

RT526

78

Y/CVBS_FACTORY

AV IN

10R

RT524

100R

RT505

100R

RT504

(TX)

(RX)

GND

DT505

BAV99L

3

RT515

3K3

2

3K3

3

IT504

BAV99L

DT504

CT503

100N

CVCK

8

VCC

24LC21A

PRE

123

VGA_GND

VGA_SCL

VGA_GND

MODE/WC

PB0

SCL

PB1

VGA_SDA

567

SDA

VSS

4

VGA_GND

RT512

0R

MMSZ6V8T1

VGA_GND

2

(4.5V)

G5V

CT543

22UF

CT506

BAIN

DT509

BAV70L

DT508

MMSZ6V8T1

RT514

RT513

3K3

VGA_GND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

GENCAM 1

IIC_CL_3

IIC_DA_3

VGASEL

DVI

DVIVSYNC

DVIHSYNC

CT501

100N

5V_V

1V8_UC

DVIB

DVIR

DVIG

IT502

16

FSAV330

VGASEL

CT544

10UF

VGA_GND

HDCBIN

BAIN

MBLU

14

15

OE_

21345

RAIN

HDCRIN

MRED

CT507

BT501 =>BX003

910111213

B3

Y3

7

8

6

HDYIN

GAIN

MGRNG_OUT

1UF

CT509

CT508

1UF

VGA_GND

R_OUT

VGA_GND

VGA_GND

B_OUT

12345678910111213

DVI_VSYNC

V_OUT

5V_V

VGA_VIN

10911

1213141516

B

VCC

IT503

74HC4053

BYBXCY

1234567

B-COM

A-COM

VGA_HIN

AY

C-COMCXINH

H_OUT

A

AX

DVI_HSYNC

100N

CT502

VE E

GND C

100N

CT529

7

VGA_GND

1UF

GND

RX

V_OUT

H_OUT

WC

IIC_CL_3

IIC_DA_3

TX

WC

(to IT620)

14

JT501

VGA_GNDGND

0R

0R

JT502

IFC228-LCD

First issue 08 / 04

RV268

100R

CV266

470R0

RV267

1N

LL42

DV202

RV266

LL42

22K0

DV201

3_GND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

RV265

+9V

6K8

(to AD9883A)

4K7

RV264

123456789

100R0

RV246

100R0

RV245

RV248

100R0

100R0

RV247

IIC_CL_4

GM_BUSY

IIC_DA_4

IIC_DA_2

IIC_CL_2

GM_INTERRUPT

GENCAM 1

9V

100NF

CV230

9V

100NF

CV235

470N

65

VUC

66

UUC

67

YUC

68

NC

69
70
71

NC

72

NC

73
74
75

NC

76

VSM

77
78
79

YS1

80

0R

33R

CV204

CR2H

VIDEO SW

0R

RV228

YC GND

BPHFIL

APLFIL
YC VCCC

100NF

RV219

RV218

CB2H

1360_GND

CV234

CV213 100NF

Y2H

GND

10UH

16V

LV273

47UF

CV231

BC856B

TV203

RV206

1K5

LV270

V_RR

CV200

100NF

TV200

2U2H

U_BB

+9VA

BC856B

CV201

RV207

CV275

2P2

Y_GG

1K5

8P2

CV276

100NF

RV208

2_GND

1K5

CV271

2P2

470R0

0R0

V_R

CV274

TV201

RV203

RV200

BC856B

CV202

8P2

LV271

2U2H

470R0

0R0

U_B

RV209

CV209

100NF

100NF

RV201

1UF

CV206

RV204

1K

TV202

16V

CV207

BC856B

LV272

2U2F

CV273

470R0

0R0

Y_G

CV208

2U2H

16V

470NF

RV211

RV202

2_GND

8P2

RV205

100R0

2P2

CV272

CV203

CV205

100NF

FLI

VSP

GND

2U2F 16V

CV233

6362616059585756555453

64

NC

Y2H

PB2H

PR2H

LADET FILTER

YS3NCG S/H

R S/HNCB S/H

YS2

123467589

CV210 10NF

1_GND

0R

RV269

GND

101112

0R

10NF

NC

COLOR LIM

VSM FILTER

IV200

1K INNCRGBGNDNCROUT

CV211 10NF

0R

RV303

0R

RV244

CV232

100NF

RV240

NC

NC

VDIN

HFSW1

SYNC IN

TA1360

GOUT

10

11

CV212 10NF

5V_V

2_GND

0R

RV304

GND

BV201

0R

RV243

10P

CV228

1UF

CV270

434241

444546484749505152

NC

NC

NC

NC

HDIN

DEF VCC

AFC FILTER

BOUTNCRGB_VCCNCNCNCRIN

OSD_BIN

OSD_GIN

OSD_RIN

2221201918171615141312

23

0R

RV217

RV252

5K6

3_GND

0R

RV305

GND

CV229

SW2

HVCO

24

10NF

10P

RV270

3K3

503K5

CV214

CV217

RV220

1360_D_GND

1360_GND

9V

QV260

LV203

1UF

0R

10UH

CV227

8K2

100NF

RV216

100NF

CV258

CV259

1360_GND

HCURVE
FBPIN
DEF GND
HOUT
NC
VOUT

NC
NC
VDD
SCL
NC
SDA
GND
BIN
GIN

47UF

16V

470R

RV271

40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25

1UF

CV216

100R

RV275

1360_GND

3_GND

1N

CV263

2K2

RV263

1K

RV258

2K2

RV259

1N

CV261

10NF

CV225

10NF

CV224

10P

CV223

100NF

CV222

CV220

10PF

CV221

10PF

100R

RV230

100R

RV229

CV219

10NF

10NF

CV218

1UF

CV215

R_OSD

G_OSD

FB_OSD

GENCAM 1

15

16

21345

4R7

RV262

1K

RV260

1360_D_GND

DV200

GDZ2.0V

B_OSD

IIC_DA_2

1N

CV264

13

14

IV202

74HC4538

100R0

IIC_CL_2

HDFL

VIDEO SW

12

RV226

RV227

15PF

CV262

100R0

VDFL

100NF

CV265

91011

7

8

6

BC846B

TV211

RV261

2K2

IFC228 MAIN EU

VIDEO PROCESSOR/ADC (VP/ADC

+9VA

RV238

2U2HLV232

470R

2U2HLV231

1K5

470R

RV231

RV235

RV232

RV237

1K5

1K5

2P2CV236

2P2CV240

RV234

470R

LV230 2U2H

RV239

BC856B

CV238 2P2

BC856B

CV241

TV208

470R

RV236

TV209

470R

CV237

8P2

8P2

RV233

TV210 BC856B

1_GND

470R

CV239

8P2

IFC228-LCD

First issue 08 / 04

4

3

2

1

(to BH003)

BH001B

GND_TUNER

1

2

3

4

5

6

7

8

9

10

11

to conn BH001(sub-Tuner Bd.)

12

13

RH012

0R

BH001A

RH016

RH051

91R

12R

16V

100UF

CH016

22N0

CH015

2K2

CH011

1N0

10UH

LH005

CH014

22N0

CH012

33P0

33P0

CH013

RH015

10U0

120P

LH006

LH051

3U3H

CH051

0R

JH001

GND_TUNER

0R

JH002

GND_TUNER

GND

RH014

100R0

TUNER

100R0

RH013

IFC228 MAIN EU

GND_TUNER

120P

CH050

LH050

3U3H

[RESET]

[+3V3]

+5V-IF

FM-IF

VIDEO

(MAIN-TUNER)

GND

SIF
o/p

AUDIO
FM-SW

RF-cable to NH002(Slave Tuner)

NC

IF

+33V

NH001

NC

+5V-T

21301450

FMinput

(int)

+5V-T

SDA

SCL

AS

AGC

US:NH001-FE6243/splitter(21301460),NH002-FE6240(21254230)

EU:NH001-FE6233/splitter(21301450),NH002-FE6230(21254210)

FE6243

CH021

9

8

7

6

5

4

3

2

1

1N0

CH010

10U0

RH050

RH017

1N0

CH001

12R

10UH

RH001

CH020

91R

LH002

1N0

LH004

22N0

CH005

10U0

LH003

1K0

RH003

1N0

CH003

CH009

33P0

0R

22N0

CH004

CH007

100UF

16V

10U0

LH001

47UF

16V

47UF

20

19

18

17

16

15

14

13

12

11

10

CH002

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

CH017

CH008

16V

33P0

100UF

CH006

16V

100UF

TH001

330P0

AM_AF

BC846B

33VCC

RH009

5V_V

SIF

47R0

2K7

AUDIO 2

RH011

1K5

RH010

IIC_CL_2

IIC_DA_2

GENCAM 1

123

BH002

GND

SIF

AF_OUT

[RESET]

20

[+3V3]

19

+5V-IF

18

FM-IF

17

VIDEO

16

FE6240

PIP-TUNER,REV05

GND

15

SIF

14

o/p
AUDIO

13

FM-SW

12

NC

11

IF

10

+33V

9

NC

8

+5V-T

7

+5V-T

6

US:NH001-FE6243/splitter(21301460),NH002-FE6240(21254230)

EU:NH001-FE6233/splitter(21301450),NH002-FE6230(21254210)

SDA

5

SCL

4

AS

NH002

3

FMinput

2

(int)

1

AGC

BH003

123

4

GND

GND

SCH 2T PIP IFC228

BH001

1

2

3

4

5

6

7

8

9

10

11

12

13

GND

to Main board

IFC228-LCD

First issue 08 / 04

VSP

CVBS_IFS

CVBS_IFM

180R0

RH007

16V

0R

RH008

RH006

6K8

CH018

RH005

100R0

100R0

RH004

DH001

ZMM33

33V

50V

1UF

CH019

GND_TUNER

GENCAM 1

9V_1H

EU_US_02

EU_US_03

EU_US_01

AV2_PIN8

Y/CVBS_FACTORY

AV1_PIN8

DVD_KEY

IIC_DA_1

IIC_CL_1

IIC_CL_2

CVBS_TXT_M

IIC_DA_2

CVBS_TXT_S

IIC_DA_4

IIC_CL_4

EXT_ON#

DC_DC_ON#

RESTART_LED

CVBS_IFS

CVBS_IFM

CVBS/Y_M

C_M/FRC

CHROMA_M

FRAME_CV

Y_M/FRC

SYNC_ENABLE

VDFL

HDFL

CR2H

9V

5V_V8V5V_FE

3V3_STBY

Y2H

5V_STBY

CB2H

GND

VSP

5V_STBY

AV_PIN8_OUT

100NCX161

VOLTAGE REGULATOR

RX141

9V_1H

3U3

LX223

RX222

1%

RX524

237R

120Z

LX221

123

BX130=>BJ104

FCB_CVBS/Y

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

AV_LINK

TEA_GND

20V

0R

22P

CX221

1%

237R

165R

RX221

165R

RX528

GND_V

RX162

10135010

RX561

6K8

RX109

33K

RX108

13K7

RX107

RX560

13K7

TEA_GND

1%

1%

456

FCB_CHR

R_IN_FCB

FCB

1%825R

RX161

6K8

AV1_PIN8

10K

220R

RX144

1K8

RX142

3U3

LX224

237R 1%

RX525

LX222

120Z

GND

AGND

AV2_PIN8

10K

RX165

TX161

L_IN_FCB

RX163

BC846B

TX101

RX103

BC856B

TX143

RX224

R_IN_FCB

L_IN_FCB

100K

TX162

TX103

BC846B

BC846B

8K2

TEA_GND

CX144

CX143

CX222

1%

237R

165R

RX223

165R

RX529

BC846B

TX142

47UF

100N

22P

1%

1%

DX164

RX164

DX101

BC846B

16V

RX166

LL4148

47K

DX103

ZMM6.8

2K7

RX104

RX146

RX143

AUDI 0

560R

RX167

100K

LX161

LL4148

TEA_GND

TX102

RX105

1%590R

TEA_GND

JX112

AUDIO 1

BX120

AV3

10K

1U5

RX145

TX141

TX163

RX110

BC846B

15K

CX101

390R

BC856B

0R

BC846B

DX161

22K

DX102

100P

TEA_GNDTEA_GND

RX526

L_IN_AV3

R_IN_AV3

22

R_IN_AV3

BC846B

TX164

82P

CX162

BZX84B8V2

ZMM6.8

12K0

RX106

6K8

RX102

1%

237R

LX133

120Z

GND

AUDIO-GND

TEA_GND

RX151

CX151 RX153

RX134

237R

RX133

1%

BLUE-GND

220R

1K8

100N

1%

165R

L_IN_AV3

AV3/F_CVBS/Y_IN

AV3/F_CHROMA_IN

TX153

BC856B

0R

JX111

1%

165R

RX530

10R

RX124

BC846B

TX152

TEA_GND

1%

237R

RX527

LX131

120Z

30292827262524

31

GREEN-GND

9V_1H

RX125

CX124

1%

RX155

590R

560R

RX152

RX132

RED-GND

100R

CX125

237R

RX131

RX531

TX124

BC846B

100N

16V

47UF

1%

165R

165R

TEA_GND

RGB-GND

390R

RX154

BC856B

TX151

1%

1%

Chroma

AV2_CVBS/Y_IN

1K5

RX127

1K

RX126

TEA_GND

TEA_GND

GND

DX111

JX1100RJX109

CVBS_IN

SYNC/CVBS-GND

SYNC/CVBS-GND

100R

RX116

100R

RX537

DX113

ZMM6.8

BAV103

TEA_GND

0R

42

4123403938373635343332

SHIELD-GND

TEA_GND

RX539

ZMM6.8

GND

GND

AV1

AV1_CVBS/Y_IN

CVBS_AV2_OUT

10K

RX123

CX114

100R

RX540

100R

RX117

100R

DX114

DX112

ZMM6.8

DX115

ZMM6.8

AUDIO 1

R_IN_AV1

R_OUT_AV1

2

R_IN_AV1

L_OUT_AV1

R_OUT_AV1

CVBS_AV1_OUT

18P0

100R

RX118

JX108

L_IN_AV1

L_OUT_AV1

5123461

BLUE-GND

AUDIO-GND

9V_1H

TEA_GND

100R

RX119

100R

RX538

RX115

150R

RX536

150R

0R

RX114

150R

RX535
150R

1011131214151617181920

9

8

7

Blue

SBLK

DATA

Green

L_IN_AV1

GREEN-GND

AV1_R/C

CX113

RX120

RX541

0R

JX105

RX113

150R
RX534
150R

GND

SPARE

AV1_G

18P0

18P0

470R

470R

RX121

RX544

RX543

JX106

0R

RED-GND

RGB-GND

AV1_B

18P0

CX115

CX112

10R

33R

33R

VSP_GND

Red/Chroma

AV1_FB

VSP_GND

TEA_GND

CX111

47R

RX122

47R

RX542

FBLK

SYNC/CVBS-GND

SYNC/CVBS-GND

10R

RX183

18P

JX107

RX112

150R

RX533

150R

RX111
150R

RX532
150R

CVBS_IN

CVBS_OUT

9V_1H

0R

JX104

0R

21

SHIELD-GND

CX184

CX183

GND

BX110

100R

RX184

1K5

RX186

TEA_GND

TEA_GND

RX185

1K

TX184

100N

47UF

BC846B

16V

IFC228 MAIN EU

AUDIO VIDEO INPUT (AV IN)

ZMM6.8

DX175

ZMM6.8

DX174

DX173

DX172

ZMM6.8 ZMM6.8

GND

DX171

BAV103

47R

47R

RX169

RX546

0R

RX231

47R

RX168

47R

RX545

L_IN_AV2

L_OUT_AV2

R_IN_AV2

R_OUT_AV2

TEA_GND

GND

GND

GND

1

AUDIO 1

AV2

R_OUT_AV2

3456789

R_IN

AUDIO-GND

L_OUT_AV2

AV2_B/CB

0RRX191

RX552

100R

RX176 100R

L_IN

BLUE-GND

AV2_G/Y

0RRX193

RX192 10K

RX554

RX553

100R

100R

100RRX177

RX178 100R

101112131415161718

Blue

SBLK

DATA

GREEN-GND

AV2_R/CR

RX194 0R

RX555100R

100RRX179

Green

SPARE

AV2_FB/H

0RRX195

RX556

33R

470R

RX558

RX180 470R

RX175

150R

RX551

150R

RX174
150R

RX550

150R

RED-GND

RGB-GND

RX559

RX557

47R

33R

RX182

10R

RX181

FBLK

Red/Chroma

V_EXT

CVBS_EXT

47R

RX548

150R

150R

RX172

RX171

150R

150R

RX547

0R

JX103

VSP_GND

19220

CVBS_OUT

SYNC/CVBS-GND

SYNC/CVBS-GND

CX175

18P0 18P0

CX174

18P0

CX173CX172

18P018P0

CX171

CVBS_IN

HDD_CVBS

Y_FACTORY

VSP_GND

0R

RX549

150R

RX173

150R

JX100

JX102

21

SHIELD-GND

VSP_GND

0R

RX232

JX101

0R

0R

BX120

AV2_FB/H

AV2_B/CB

AV2_G/Y

AV2_R/CR

AV2R

AV2G

AV2B

AV2FB

VIDEO SW

VGA

Y/CVBS_FACTORY

VSP_GND

GND

IFC228-LCD

First issue 08 / 04

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE
SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE
ESQUEMA DE LA PLATINA PRINCIPAL

(FAN SUPPLY)

BP203

1

2

IP203

KF80BDT

OUT IN

GND

2
CP203
100UF

16V

RP203

0R

GND_PS

13

(stand

off-Bd)

RP001

RP002

6R8 2W

2W6R8

CP001

100UF
16V

IP001

LD1117DT33

OUTIN

1

GND

CP012

220N

JP001

0R

CP002

GND_A

IP002

LD1117DT18C

33

OUTIN

JP002

0R

1

GND_B

GND

CP013
220N
16V

IP006

LF50CDT

2

100U

16V

OUTIN

GND

IP003

CP009

220N

16V

JP005

0R

IP004

KF80BDT

2

JP006

0R

GND_F

LF90ABDT

OUTIN

GND

10VCC

CP004
100U
16V

23

CP011

220N

CP010

220N

16V

CP003
100U

CP014

220N

16V

16V

31

CP028
100U

16V

2

GND_E

31

OUTIN

GND

CP006
100U

16V

31

CP007

220N

16V

CP005

220UF
10V

CP008

220N

16V

9V

8V

3V3_UC

1V8_UC

6V

5V_V

BP001

6V

1

2

10V

3

4

5

6

20V

7

33V

8

5V_STBY

9

10

3V3_STBY

GND_PS

1

2

PO

3

INF_POW_FAIL

4

5

ECO_STBY#

6

DVD_ON

7

AQR

8

GND_PS

RP016

47K

RP015

47K

JP003

0R

GND_C

IP005

LD1117DT18C

CP016

220N

TO252

16V

JP004

0R

GND_D

CP015
220N

16V

1

OUTIN

GND

23

CP018
100U

16V

PO

INF_POW_FAIL

ECO_STANDBY#

AQR

CP017

220N

16V

20V(EU)

33VCC

5V_STBY

3V3_STBY

1V8_STBY

GND_A

GND_B

GND_C

GND_D

GND_E

GND_F

JP007

0R

JP008

0R

JP009

0R

JP010

0R

JP011

0R

JP012

0R

GND

IFC228 MAIN EU

VOLTAGE REGULATOR

BP002

CP023

10N

50V

IFC228-LCD

First issue 08 / 04

CP025

10N

50V

GND_PS

CP024

10N

50V

5

132

748

6

DEV

RED_A

WHITE_A

RED

BLUE

GREEN

VCC

GND

CX&RR&

RCX

RCX

CX

AUDIO

1

VUY

matrix

GND

GND

VCC3

VCC2

VCC1

Iref

V-PHH-PHYout

select

to

SDA

ADDR

dec

I2C

IN1

IN4

6dB

H

V

Yin

sync separator

priority ranking

3-state sync detect

sync counter

H sync width increase

macrovision processing

H

V

dummy sync generator

gen

clock

GND

existence distinction

YPbPr => YUV

YCbCr => YUV

RGB => YUV

YUV

H

V

IN3_Pr

IN3_Pb

IN3_Y

IN3_H

IN3_V

IN4_Pr

IN4_Pb

IN4_Y

IN4_H

IN4_V

IN1_R

IN1_B

IN1_G

IN1_H

IN1_V

IN2_R

IN2_B

IN2_G

IN2_H

IN2_V

SCL

AUDIO

CMP1

COMP1_R

LIN_EXT

AGND

RIN_EXT

AGND

DC_DC_ON#

DVD_KEY

3V3_STBY

GND

GND

IIC_4_DA

IIC_4_CL

GND

NC

NC

NC

RGB_CMP_SEL

DVI_VSYNC

DVI_HSYNC

AUDIO 1

AUDIO 1

VOLTAGE REGULATOR

AV IN

COMB

VP/ADC

VSP

GENCAM 1

DVI

DVI_G

AV IN

(US)

COMP1_L

(EU)

Pr

Pb

Y

VGND

VIDEO SWITCH

IFC228 MAIN EU

AV2_CMP_R

RX459

100R

V_EXT

JX408

0R

JX407

0R

JX406

0R

TX461

BC846B

4K7

RX464

RX466

1K

4K7

RX469

TX462

BC856B

TX463

BC846B

RX418

150R

RX518

150R

470N

CX421

CX420

470N

CX422

470N

470N

CX423

CX424

470N

470N

CX425

CX426

470N

BC856B

TX441 CX441

470N

1K

RX444

10N

CX442

1UF

CX443

JX401

0R

RX473

2K2

CXA_GND

100R

RX430 RX439

0R

TX432

BC856B

CX445

100N

1K

RX440

100N

CX494

RX493

0R

470P

CX492

RX497

84K5

0R

RX474

4

5

123

IC-STD

IX430

74HC1G32

100N

CX491

11

10

976

12

5

321

15

14

13

4

16

8

IX420

74HC123PW

LX473

10UH

10UH

LX472

0R

RX472

QX471

4MHZ 0R

CX472

33P

CX471

22P

CX479

10K

RX476

RX475

0R

CX456 1UF

CX452 1UF

5V_FE

RX457

180K

180K

RX451 RX452

82K

82K

RX458

RX900

10K

RX613

82K

RX612

82K

CX454

1UF

1UF

CX455

RX611

82K

RX610

82K

RX614

180K

RX615

180K

1UF

CX453

1UF

CX451

RX616

180K

RX617

180K

9101112131415

16

7

8

21345

6

IX410

FSAV330

100N

CX461

100R

RX453

AV2_B/CB

RX454

100R

100R

RX455

RX456

0R

100N

CX482

RX483

1K

BC856B

TX482

RX302

0R

CVBS_EXT

RX301

0R

100N

CX495

4K7

RX498

14

7

4

1

11

8

10

6

9

5

3

2

13

12

IX440

74HC4066PW

CX481

100N

1K

RX481

RX431

0R

100R

RX482

TX481

BC856B

RX449

2K7

RX484

100R

RX477

1K5

CX483

100N

RX485

1K

0R

RX432

100R

RX486

2K7

RX450

100R

RX488

CX484

100N1K

RX487

TX484

BC856B

100N

CX486RX491

1K

BC856B

TX486

1K5

RX479

TX485

BC856B

1K5

RX478

100N

CX485

1K

RX489

RX433

0R

RX446

2K7

RX490

100R

RX492

100R

CX493

150P

RX494

820R

470R

RX496

RX495

15K

16V

100UF

CX478CX477

100N

16V

CX476

100UF100N

CX475

CXA_GND

16V

CX474

100UF

CX473

100N

10UH

LX471

10K

RX471

CXA_GND

RX443

220K

CX444

470N

CXA_GND

GND

GND

BX421

CXA_GND

CXA_GND

L_IN_COMP1

CXA_GND

CXA_GND

GND

CXA_GND

CXA_GND

HV_GND

HV_GND

CXA_GND

2K2

RX467

RX468

470R

CXA_GND

CXA_GND

CXA_GND

CXA_GND

IIC_DA_2

IIC_CL_2

CXA_GND

CXA_GND

CXA_GND

RX419

150R

CXA_GND

HV_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

HV_GNDGND

CX463

100N

GND

JX405

0R

CX416

470N

CX417

470N

470N

CX418

470N

CX419

RX516

150R

150R

RX416

RX417

150R

RX517

150R

47P

CX428

RX508

150R

RX423

150R

RX425

150R

RX507

150R

CX429

47P

12345

6

BX423

123

4

BX422

123456789

10

BX420

BX400

RX401

150R

RX505

150R

RX504

150R

150R

RX403

RX405

150R

RX503

150R

CX405

1UF 16V

470N

CX406

47R

RX406

RX500

47R

BAV103

DX403

DX407

BAV103

ZMM6.8

DX401

ZMM6.8

DX402

CX404470N

RX501

47R

470N

CX402

RX404

47R

10

11

12

13 1415 16

17

181920

21

22

23

24

252627

28

29

303132

3334353637

38

39

40

46

47

48

6

8

9457

414243

44

54321

IX400

CXA2171Q

10N

CX464

CX467

10N

100N

CX466

16V

47UF

CX465

0R

RX462

16V

CX462

47UF

RX461

0R

10UH

LX461

LX462

10UH

JX403

0R

JX404

0R

RX448

0R

RX413

150R

RX511

150R

RX414

150R

RX512

150R

0R

RX447

CX414

470N

JX402

0R

CX413

470N

BAV103

DX408

DX406

BAV103

ZMM6.8 DX405

ZMM6.8

DX404

470N

CX412

RX410

47R

RX601

47R

RX412

47R

CX408

470N

150R

RX407

RX506

150R

RX602

47R

RX408

47R

RX600

47R

RX513

150R

RX411

150R

RX514

150R

Y2

RX409

150R

47P

CX427

LX425

600

CX431

100P

BC856B

TX431

RX422

0R

470N

CX410

470N

CX415

100R

RX441

100R

RX442

150R

RX415

RX515

150R

CXA_GND

CXA_GND

HV_GND

HV_GND

HV_GND

HV_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

150R

RX424

LX424

600

LX423

600

CXA_GND

RX463

220R

CX469

1UF

1N

CX468

RX465

220K

RX435

150R

RX523

150R

RX421

150R

RX521

150R

150R

RX434

RX522

150R

RX520

150R

150R

RX420

RX519

150R

100N
CX470

1K

RX436

RX510

150R

150R

RX429

RX509

150R

GND

GND

GND

GND

CXA_GND

47R

RX402

RX502

47R

R_IN_COMP1

SYNC_ENABLE

CVBSIN_EXT

DVI_B

DVI_R

5V_FE

HV_GND

HV_GNDHV_GNDHV_GND

HV_GND

HV_GND

5V_FE

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

CXA_GND

DC_DC_ON#

IIC_DA_4

IIC_CL_4

PB2

PR2

Y_FACTORY

8V

5V_V

5V_FE

8V_FE

5V_FE

AV2_R/CR

AV2_G/Y

5V_FE

AV2_FB/H

AV2B

AV2G

HDFL

VDFL

H_EXT

5V_FE

5V_FE

DVD_KEY
3V3_STBY

PB/B

G/Y_EXT

VOUT

HOUT

R/PR_EXT

RIN_EXT

LIN_EXT

8V_FE

5V_FE

5V_FE

5V_FE

5V_FE

5V_FE

8V_FE

8V_FE

8V_FE

8V_FE

8V_FE

AV2R

AV2FB

Y2H

CB2H

CR2H

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

IFC228-LCD

First issue 08 / 04

AV IN

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

COMB

FRAME_CV

9V_1H

CVBS/Y_M

CHROMA_M

0R

RV156

100N

CV130

10R

RV162

1K5

RV153

RV152

1K5

9V_1H

BC847-NP

TV111

654

470R

RV147

TV110

BC847-NP

654

470R

RV140

1K5

RV138

BC847-NP

TV109

4

321

65

DO NOT USE

RV135

470R

100N

CV129

100N

CV128

CV127

47UF

CV147

100N

CV146

47UF

10UH

LV103

(O/P to sheet 9)

9V

0R

RV157

321

DO NOT USE

TV108

DO NOT USE

16V

10UH

LV105

321

470R

RV146

BC846B

RV133

180R

LV204

RV168

TV107

100R

RV143

RV137

100R

RV136

TEA_GND

3U3H

BC856B

470R

1K5

RV134

10UH

LV102

0R

BC846B

TV106

TV105

RV149

RV148

RV139

470R

CV144

LV104

10UH

to COM FILTER

CV280

120P

RV170

0R

RV161

100R

BC856B

100R

BC856B

1K5

100R

RV141

470R

100R

RV142

TV103

100R

RV132

16V

47UF

CV145

47UF

CV142

0R

1V8_UC

RV158

2K32

RV155

2K32

RV154

100R

TV104

RV151

RV16375R

BC856B

BC856B

RV131

100R

100N

16V

CV143

RV164

3V3_UC

1K

RV145

RV144

CVBS02

TV102

10UH

C_M/FRC

RV160

RV159

2K21

2K21

CVBS03

RV150

470R

10K

CVBS01

100N

LV101

Y_M/FRC

0R

RV101

LV100

RV100

0R

CVBS_AV1_OUT

10UH

HDD_CVBS

to DVD 26pin conn.

MONITOR_OUT

DV103

IV101

100R

RV129

100R

RV128

100R

RV121

VSP_GND

100N

CV157

CV159

100N

0

0R

RV301

AV3/F_CVBS/Y_IN

AV3/F_CHROMA_IN

1UF

CV123

22N

CV124

DV104

100K

MMSZ6V8T1

TEA6415C

VSP_GND

CV10415P

CV10315P

16V

CV10047UF

VSP_GNDGND

100K

RV126

RV127

IN2

IN3

IN1

2

56789

314

I/O 0

I/O 3

I/O 1CPI/O 2

100N

CV155

100N

CV158 100N

CV160 100N

TEA_GND

GND

VCC

CETTCDPECS

16

OUT2

VSP_GND

CV154

MRSRCEP

201918171514131211

IN8

1UF

CV117

100N

CV156

20M25

QV100

RV300

0R

CV14147UF

0

100N

CV161

0

0R

RV302

MMSZ6V8T1

100K

RV125

PROG

IN4

I/O 4

GND

U/

OUT4

OUT5

220N

CV118

XOUT
XIN
TCLK

CV163 100N

CVBS_TXT_M

CVBS_TXT_S

100K

RV124

9V_1H

IN5

I/O 5

RV120

2K43

RV119

2K43

CV119220N

60

61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80

1

CV162 100N

CV164100N

IIC_CL_2

IIC_DA_2

22N

CV125

MMSZ6V8T1

DV102

IN6

10

I/O 6

I/O 7

OE

IN7

RV116

TV101

BC856B

RV118

BC856B

TV100

CV114

CV107

220N

220N

CVBS5

CVBS6

CVBS7

59585756555453

2346758

656HIO

GENCAM 1

AV2_R/CR

AV2_CVBS/Y_IN

1UF

CV122

DV100

MMSZ6V8T1

100N

CV120

1K 5

RV117

2K21

2K21

RV115

1K5

RV109

220N

CV115

CVBS3

CVBS4

CVBS2

CVBS1

IV100

VSP9407B-VK-C1

9

10

11

SDA

656VIO

FLI

CVBS_AV2_OUT

1UF

CV116

RV114

RV113

0R

CV153 100N

SCL

VSP_GND

RV106

GENCAM 1

100K

100R

100R

444546484749505152

100R

IIC_DA_3

434241

RV122

100K

RV123

VSP_GND

CV152 100N

201918171615141312

IIC_CL_3

AV1_CVBS/Y_IN

CV121

CVBS_IFM

RV166

75R

75R

RV165

100R

RV112

220N

0

CV112

CV105220N

40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21

CV165 100N

CV166 100N

100R

RV107

INT_DM U

1UF

DV101

MMSZ6V8T1

CVBS_IFS

220N

CV113

RESET_DMU#

22N

CV126

TUNER

CV132 220N

CV131 1N8

CVBS_EXT

0

0R

RV167

0R

RV108

VSP_GND

V_R

AV2_B/CB

220N

CV109

CV106 220N

0R

U_B

Y_G

AV2_G/Y

220N

CV110

CV151100N

0

CV167100N

RV173

HOUT

VOUT

VP/ADC

AV1_B

AV1_R/C

TEA_GND

V_EXT

AV2_FB/H

RV111

0R

CV111 220N

220NCV108

VSP_GND

0R

RV175

CLKOUT

656IO_7

656IO_6

VIDEO SW

AV1_G

VIDEO SW

0

0R

RV110

0R

RV172

656IO_3

656IO_4

656IO_5

AV1_FB

IFC228 MAIN EU

VIDEO SIGNAL PROCESSOR (VSP)

VSP_GND

656IO_0

656IO_1

656IO_2

FLI

IFC228-LCD

First issue 08 / 04

DVD_KEY

EU_US_01

EU_US_03

EXT_ON#

IIC_CL_4

DC_DC_ON#

IIC_DA_4

CVBS_TXT_S

MASTER_MUTE#

GM_INTERRUPT

INF_POW_FAIL

R_OSD

CVBS_TXT_M

G_OSD

B_OSD

FB_OSD

IIC_CL_3

IIC_DA_3

IIC_DA_2

IIC_CL_2

IIC_CL_1

IIC_DA_1

SYNC_ENABLE

INT_DMU

IR

HV_SWITCH

RESET_DMU#

VGASEL

HDFL

VDFL

GM_BUSY

AQR_ON

RESET_AUDIO#

SOFT_RESET

SAFETY_ENABLE

RESTART_LED

AUDIO_STBY

PO_TR

ECO_STANDBY#

PO

DVI_DETECT

3V3_STBY

5V_STBY

1V8_STBY

GND

TXTSEL

SAFETY_INT

5V_V

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

FRONT-END

5V_STBY

GND

47N

CR043

IR040

NCP303LSN30T1

5

1
2

3

4

GND

3V3_STBY

GENCAM

IFC228 MAIN EU

4K7

RR044

3V3_STBY

1%

3K65

RR120

4N7

GND

1N2

CR005

GND

470R

JR141

TR141

BC846B

10R

RR142

FB_OSD

B_OSD

0R

JR145

TR145

BC846B

LR025

4K7

RR191

LED#

3K65

RR119

AV2_PIN8

AV1_PIN8

KEYBOARD

DVD_KEY

POWER_SWITCH

CVBS_TXT_S

220N

CR114

CVBS_TXT_M

CR003

3K9

RR140

TR140

0R

BC856B

RR141RR131

470R

TR144

BC856B

470R

RR145RR135

470R

RR045

240Z

1%

220N

470R

JTIN

(EU)

(EU)

(EU)

5V_V

RR134

5V_V

RR130

JTSEL

CR118

JTCLK

JTOUT

470R

R_OSD

4K7

RR004

GND

3V3_STBY

4K7

RR046

100N

CR025

1%

1K5

RR109

470R

RR138

5V_V

1K2

RR144

RESET#

1

IR004

MC33460SQ

2

4K7

5
6
7
8

3N9

CR026

GND

10N

CR109

1K

RR116

1K

RR114

1K

GND

0R

LR030

3V3_STBY

0R

JR149

TR149

BC846B

470R

RR136

TR147

5V_V

LED_TOPLIGHT

33R

RR003

470N

OUT

CR004

4

GND

IN

GND

0R

RR197

47K

RR194

47K

RR195

47K

RR196

68R

RR338

68R

RR339

4
3
2
1

CR027

820P

3V3_STBY

33R

RR250

1K

RR115

1K

RR113

RR112

100N
CR039

100N
CR038

100NCR030

GND

TR148

BC856B

470R

RR149

470R

RR139

TR146

0R

JR147

RR147

BC846B

RR137

G_OSD

AQR_ON

RESET_DMU#

876

5

123

4

GND

0R

JR250

NYD

DR250

3N9

CR031

RR006

39P

CR002CR001

39P

1K2

RR148

RR146

BC856B470R

470R

DVI_DETECT

5V_V

CR032

1M

1K2

RR190

1K

1N

CR192

9

100R

RR18

RR111

RR185 RR193

3V3_STBY

10V

CR250

470UF

GND

820P

GND

8MHZ

820P100N

3N9

CR011 CR012

CR010

240Z

LR010

5V_ON_CHECK

ECO_STANDBY#

GND

12K

10K

4K7

8

68R

RR337

1

GND

3N9

CR251

121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160

QR001

3V3_STBY

480_ON

3V3_STBY

5V_STBY

100N

CR186

567

432

JTIN

GPIO(35)

ADCIN4
ADCIN3
ADCIN2
ADCIN1
ADCIN0

AVSS

AVDD

CCVIDEO

OSD_R
OSD_G

OSD_B

ADCVD3
ADCVS3

TTVIDEO

ADCREFP
ADCVS2
ADCVD2
ADCVS1
ADCVD1

OSCIN

OSCOUT

0Z

80Z

LR011

LR001

GND

47K

RR010

47K

RR011

47K

RR012

47K

RR013

GENCAM 2

RR151

15K

RR110

CR113

1N

1N

PLLBYPASS

PLLB_AVCC

PLLB_AGND
PLLB_DGND

PLLB_DVCC

ANA_G_PWR

ADC_REFN

OSDDACVSS
OSDDACVDD

OSD_FSW

ADCREFM

PLLA_AVCC

PLLA_AGND
PLLA_DGND

PLLA_DVCC

CORE_VDD3

CORE_VSS3

RR300

SDCLK

RR154

10N

1K8

RR150

3K3

3K3

4K7

CR190

CR188

68R

RR001

PO_TR

IIC_CL_4

IIC_DA_4

AUDIO_STBY

SAFETY_ENABLE

1K8

JR326

RR182

RR181

10K

RR180

GNDGNDGNDGND

0R

JR027

39P

CR181

876

5

68R

RR336

123

4

GND

111

112

113

114

115

116

117

118

119

120

MOSI

MISO

JTSEL

JTCLK

JTOUT

SPISSB

SPISCK

GPIO(34)

EXT_VSS9

EXT_VDD9

SDA10

SDWE_

SDCAS

SDRAS

SDCS1_

EXT_VSS1

SDCLK

EXT_VDD1

SDCKE

SDCS0_

123456789

101112131415161718192021222324252627282930

GND

876

5

567

8

123

4

432

1

68R

RR301

68R

SDA10

SDCAS

SDRAS

SDCKE

SDWE#

SDCS1#

SDCS0#

PO

RR199

100R

0R

10K

RR198

5V_STBY

39P

CR182

3V3_STBY

107

108

109

110

TMRIN

RESET_

TMROUT

EXT_VDD5_1

EXT_VDD2

WE_

ROMCS1_

ROMCS0_

8

1

68R

RR302

ROMCS1#

ROMCS0#

106

GPIO(27 )

EXT_VSS2

WE#

IIC_CL_3

IIC_DA_3

SOFT_RESET

GM_INTERRUPT

BC846B

TR198

4K7

RR157

1K8

RR170 RR171

4K7

RR163

47K 1K8

RR161

47K

RR172

RR175

3K3

5V_STBY

876

68R

RR334

123

GND

99989796959493929190898887868584838281

100

101

102

103

104

105

GPIO(20)

GPIO(21)

GPIO(22)

GPIO(26)

GPIO(23)

I2CCLK(2)

I2CCLK(3)

I2CDAT(3)

CORE_VSS2

CORE_VDD2

IR001

GENCAM CUT2.1

DATA(3)

CORE_VSS0

CORE_VDD0

DATA(2)

DATA(1)

DATA(0)

HBE

SRAMCS_

OE_

DATA(4)

1V8_STBY

68R

RR303

8

876

5

567

1

123

4

432

68R

RR304

82R

RR002

D0

OE#

D4

IRDA_IN

IRDA_OUT

5

4

GPIO(17 )

I2CDAT(2)

EXT_VDD3

EXT_VSS3

567

432

PWMO0

DATA(5)

RR333

SIROUT

DATA(6)

RR305

UART_OUT

68R
8

1

SIRIN

EXT_VSS8

DATA(8)

DATA(7 )

31

876

123

68R

5V_STBY

39P

CR171

CR170

220N

100P

CR172 CR175

RR332

567

432

GND

GPIO(13)

EXT_VDD8

EXT_VSS5_0

DATA(11)

DATA(10)

DATA(9)

5

4

D10D9D8D7D6D5D3D2D1

D11

RR156

39P

68R
876

123

SDOUT

DATA(12)

RR306

3K3

3K3

10K

RR183

10K

RR187

47K

SDIN

GPIO(10)

DATA(13)

DATA(14)

8

1

68R

D12

UART_IN

RR159

RR160

5

4

I2CCLK(1)

EXT_VDD4

D14

D13

EXT_ON#

VSYNC

I2CDAT(1)

DATA(15)

EXT_VSS4

403938373635343332

567

432

D15

IIC_CL_2

0

IIC_DA_2

RR335

LR015

DC_DC_ON#

5V_STBY

3V3_STBY

68R

567

8

432

1

47K

RR016

240Z

3V3_STBY

820P

CR017

100N

240Z

CR015

3V3_STBY

8

1

RR331

HSYNC
GPIO(07)
GPIO(06)
GPIO(05)
IRIN
IROUT
EXT_INT(0)
I2CCLK(0)
I2CDAT(0)
EXT_5VTOL
ADDR(23)
ADDR(22)
ADDR(21)
ADDR(20)
ADDR(19)
EXT_VSS6
EXT_VDD6
ADDR(18)
CORE_VSS1
CORE_VDD1
ADDR(17)
ADDR(16)
ADDR(15)
ADDR(14)
ADDR(13)
ADDR(12)
ADDR(11)
ADDR(10)
ADDR(9)
EXT_VSS5
EXT_VDD5
ADDR(8)
ADDR(7)
ADDR(6)
ADDR(5)
ADDR(4)
ADDR(3)
ADDR(2)
ADDR(1)
ADDR(0)

CR021

LR020

3N9

CR016

RR056

68R

CR020

GM_BUSY

100P
CR159

100P
CR160

100P
CR183

47K

RR184

10K

RR059

10K

RR058

10K

RR049

10K

4K7

RR053

4K7

RR054

10K

RR152

10K
RR048

567

432

80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41

3N9

100N

820P

CR022

GND

VDFL

AV_PIN8_OUT

RESET_AUDIO#

0R

JR325

5
6
7
8

GND

5
6
7
8

5
6
7
8

68R0

5
6
7
8

68R0

5
6
7
8

68R0

5
6
7
8

GND

3N9

CR041

CR042

820P

CR040

100N

1V8_STBY

HDFL

RESTART_LED

RESTART

RR330

68R

RR307

GND

IR_UC

IR_OUT

INT_DMU

0R

JR184

100P
CR184

10K

RR153

5

100K

RR05

18K

RR079

1N

CR048

1N

CR053

10N

CR079

876

5

68R

123

4

GNDGND

100N

CR050

3N9

CR051

GND

820P

CR052

4

A22

3

A21

2

A20

1

RR312 68R0

A19

4

A18

3

A17

2

A16

1

RR311 68R0

RR310

RR309

RR308

RR060

A15

4

A14

3

A13

2

A12

1

4

A11

3

A10

2

A9
A8

1

4
3
2
1

1N

CR060

A7
A6
A5
A4

A3

4

A2

3

A1

2

A0

1

5V_STBY

5V_STBY

5V_STBY

CR106

10V

470UF

CR055

IR006

PCF8574TS

10K

5V_STBY

0

RR07

1K

GND

TR061

10N

CR068

1K

RR066

RR065

100UF

CR165

16V

VGASEL

100P

10K

RR104

3K3

RR105

4K7

RR106

4K7

RR107

8

RR341

68R

1

P7

P6NCP5

INT

SCL

124

RR082

5V_STBY

8

VCC

7

WC

6

SCL

5

3K3

RR071

1K

RR062

470R

RR063

BC856B

RR068

1K

RR067

8K2

TXTSEL

3D_FRAME

SW_DETECT

567

432

182019

SDA

NC

3

RR080

RR081

100R

47N

CR075

IR005

3K3

RR072

220R

RR073

220R

10K

RR064

RR069

100K

TR062

RR061

3V3_STBY

CR166

100UF

RR340

P4

VDD

100R

TR060

1K5

BC846B

0R

RR192

100R

16V

0R

RR201

876

68R

123

P3NCP2

VSS

A0A1A2

6

759

39P

CR082

CR081

E0

E1

E2

VSSSDA

100P

CR070

BCR141

HV_SWITCH

SYNC_ENABLE

0R

RR200

5

4

NC

8

47N

20947380

CR083

39P

1

2

3

4

100P

CR071

1V8_STBY

MASTER_MUTE#

10K
RR103

10K
RR102

10K
RR101

5V_STBY

11121314151617

P1

P0

10

IIC_DA_2

IIC_CL_2

M24C64WMN6

IIC_DA_1

IIC_CL_1

PG

INF_POW_FAI L

RR167

1K

CR167

100UF

16V

5V_V

5V_STBY

3V3_STBY

1V8_STBY

5V_V

IFC228-LCD

First issue 08 / 04

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE
SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE
ESQUEMA DE LA PLATINA PRINCIPAL

3V3_STBY

TR214

BC857BS

5V_STBY

BC856B

RR210

10K0

RR211

1K0

RR212

10K0

RR213
100K0

RR214

220K0

DR210
BAS20

CR211

100U0

TR211

BC846B

TR213

BC846B

JR210

TR210

BCX56 N

RR209

100R0

TR212

TR216

BSN20 N

G

WE_ROM#

WE#

LR110

TR215

BC856B

TR217

BSN20 N

G

GNDGND

RR217

47K0

RR219

220K0

RR220
4M7

CR117
820P0

CR210
220MI0

TR214

BC857BS

RR216
220K0

100K0

RR215

D

D

S

S

RR218
47K0

LR115

0

CR115
100N0 3N9

GENCAM 1

JR132

JR131

0

47K0

IR130

MX26LV320T

1
A15

A14
A13
A12
A11
A10
A9
A20
A21

JR137

A22

CR137

GND

10N0

A19
A18

A8
A7
A6
A5
A4
A3
A2

3V3_STBY

A155

2

A14

3

A13

4

A12

5

A11

6

A10

7

A9

8

A8

9

A19

10

A20

11

WE

0

12

RESET

13

A211

0JR138

14

WP/ACC

15

RY/BY

16

A18

17

A17

18

A7

19

A6

20

A5

21

A4

22

A3

23

A2

24

A1

240R0

CR130

100N0

LR130

ROM

BYTE

GND1

Q15/A-1

Q14

Q13

Q12

VCC
Q11

Q10

GND2

CR131

3N9

0

GND

CR110

100N0

CR111

3N9

GND GND

CR112
820P0

IR110

MT48LC4M16A2TG-75

1

GND

2
3
4
5
6
7
8
9

10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

D15_
D7_

D14_
D6_
D13_
D5_
D12_
D4_

D11_

D3_
D10_
D2_
D9_
D1_

D8_
D0_

VDD

DQ0
VDDQ
DQ1
DQ2
VSSQ
DQ3

DQ4
VDDQ
DQ5
DQ6

VSSQ
DQ7
VDD VSS
DQML
WE#
CAS#

RAS#
CS#
BA0

SDRAM

BA1
A10

A0
A1
A2
A3 A4

IFC228 MAIN EU

D0

D1 D14
D2

D3
D4

D5

D6

D7

A19
SDWE#
SDCAS
SDRAS
SDCS0#
A21
A22
SDA10
A0
A1
A2
A3

CR116

GND

3V3_ROM

48

A16

47
46

GND

45
44

Q7

43
42

Q6

41
40

Q5

39
38

Q4

37
36
35

Q3

34
33

Q2

32

Q9

31

Q1

30

Q8

29

Q0

28

OE

27

GND

26

CE

25

A0

3V3_ROM

CR132

820P0

54

VSS

53

DQ15

52

VSSQ

51

DQ14

50

DQ13

49

VDDQ

48

DQ12

47

DQ11

46

VSSQ

45

DQ10

44

DQ9

43

VDDQ

42

DQ8

41
40

NC

39

DQMH

38

CLK

37

CKE

36

NC

35

A11

34

A9

33

A8

32

A7

31

A6

30

A5

29
28

VSSVDD

A17A16

RR316

D15_
D14_
D13_

D12_
D7_
D6_
D5_
D4_

D11_
D3_
D10_
D2_
D9_

D1_
D8_
D0_

68R0

45

18

RR315

68R0

1

4

RR314

68R0

1

4

RR313

68R0

1

4

GENCAM 2

GND

GND

8

5

8

5

8

5

ROMCS0#

D15

D13

D12
D11

D10

D9

D8

A20
SDCLK
SDCKE

A11

A9
A8
A7
A6
A5
A4

D15
D14
D13
D12

D7
D6
D5
D4

D11

D3

D10

D2
D9
D1
D8
D0

OE#

A1

IFC228-LCD

First issue 08 / 04

GND

GNDGND

MAIN SCHEMATIC DIAGRAM - SCHEMA DE LA PLATINE PRINCIPALE - SCHALTBILD HAUPTPLATINE - SCHEMA DELLA PIASTRA PRINCIPALE- ESQUEMA DE LA PLATINA PRINCIPAL

+2.5D1 +2.5D1 +3.3VC +2.5D2 +2.5A2 +2.5A2 +2.5D2 +2.5A1+2.5A1 +3.3VC+2.5A1 +2.5D2

VSP

CC029CC034

4N7100P0

CC030

CC031

100N0

CC033 CC032

100N0 4N7

100P0

CC035

100N0 100N0

CC037 CC036

CC038

100P0 100N0

4N7

CC039

CC041

+3.3VC

9V_1H

FRAME_CV

Y_M/FRC

9V_1H

C_M/FRC

9V_1H

CVBS/Y_M

CHROMA_M

10U0

9V_1H

GND_COMB

RC042

1K5

RC132

100N0

CC132

46 53 81 92 93

45 64 1003831 32

RC056

RC053

RC051

2K2

RC112

CC112

RC133

4K7

1K0

47K0

1K5

100N0

100R0

RC025

DC025

LL4148 100K0

CC055

100N0

TC055

100R0

RC113

GND_COMB

DVDD3

RSTB

AVDD5

AVDD4

AVDD3

DVDD2

AVDD2

AVDD1

DVDD1

DVDDDI0

BC856B

TC051

BC846B

RC050

100R0

RC041

GND_COMB

BC856B

TC132

10U0

CC025

RC024

1K0

637757

45678910111213141516

NSTB

TEST01

TEST02

IC040

UPD64083

DVDDRAM2

DVDDRAM1

ACI

CSI

VRBC

VRTC

96

76

959094

CC053

100N0

CC052

100N0

TC056

BC846B

RC055

470R0

RC054

2K2

220K0

RC052

1U0

220R0

CC051

1N0

CC050

TC040

BC856B

TC112

BC856B

2K2

RC111

2K2

RC110

GND_COMB

2K2

RC131

2
3

TEST03

GND_COMB

DC024

TEST04

CC054

100N0

LT1D73A

TEST05

TEST06

DYCO

10

GND_COMB

9V_1H

2K2

RC130

1
4

TEST07

DYCO 9-0

select

GND_COMB

TEST08

TEST09

LC070

9V_1H

TEST10

CC070

750R0

TEST11

220N0

CC063

RC063

RC061

GND_COMB

TEST12

10

10

delay

CC071

4K7

RC070

CC067

CC066

100N0

15P0

CC065

357R0

2K2

TEST13

AYout

10bit

peaking

noise

10

10

10bit

AYin

1U0

22P0

8P2

TC065

17

TEST14

coring

88

BC846B

9V_1H

GND

EU_US_01

1819202122232425262728

EXTALTF

EXTDYCO0

EXTDYCO1

EXTDYCO2

EXTDYCO3

EXTDYCO4

EXTDYCO5

EXTDYCO6

AC0ut

10bit

YDAC

CDAC

10

CBPF

delay

noise

reduction

reduction

10

mixer

motion

chroma

detection

10

line

filter

comb

10

10bit

YADC

CADC

clamp/bias

ACin

VRBY

VRTY

AYI

91

CC080

100N0

CC081

100N0

GND_COMB

82P0

CC069

TC070

BC856B

12U010U0

LC067

91P0

LC066

27P0

CC064 CC068

619R0

RC067

LC065

RC060

15U0

TC061

100R0

9V_1H

BC856B

VIDEO

RC064

GND_COMB

332R0

GND_COMB

SW

GND_COMB

825R0

RC066

1K1

RC065

BC846B

TC063

100R0

RC062

FRAME_CV

EXTDYCO7

EXTDYCO8

9V_1H

RC107

CC107

DC064

CVBS/Y_M

Y_M/FRC

3334353637

TEST15

TEST16

EXTDYCO9

comp

Y vert

aperture

WCV-ID

4Mbit

VCLY

89

GND_COMB

CC102

CC104

RC104

470R0

TC107

10R0

220N0

LL4148

5V_FE

C_M/FRC

TEST17

TEST18

frame

decoder

frame

CC085

CC084

RC100

8P2

22P0

BC856B

GND_COMB

GND_COMB

CC141

CC140

ID-1

delay

100N0

47U0

4K7

100N0

47U0

CHROMA_M

56

CLK8

TEST19

ID1memory

comb

decoder

357R0

RC101

10U0

LC102

12U0

LC104

100R0

RC103

TC105

CC144

CC142

61

encoder

filter

BC846B

1U0

IIC_DA_2

IIC_CL_2

5V_FE

SENSE_2V5

656667686970717273

62

ST0

ST1

DYCO0

DYCO1

DYCO2

DYCO3

non

standard

detection

HV

sync

counter

separator

AX0

848285

GND_COMB

BC856B

TC100

27P0

CC101

91P0

CC103

82P0

CC105

470R0

RC105

95R3

RC106

47R0

RC108

9V_1H

CC145

100N0

11614118

VDD

13

2

312576

3D_FRAME

GENCAM 1

SENSE_3V3

DYCO4

DYCO5

CBPY

GND_COMB

1U0

6V

DYCO6

DYCO7

CBPC

CC090

100N0

9V_1H

GND_COMB

10R0

RC127

220N0

CC127

CC091

RC124

DYCO8

100N0

CC122

CC124

470R0

TC127

9

75

74

DYCO9

RC120

8P2

22P0

BC856B

GND_COMB

+3.3VC

79

78

KIL

LINE

ALTF

GND_COMB

4K7

357R0

RC121

10U0

LC122

12U0

LC124

100R0

RC123

TC125

BC846B

IC140

10 15 4

10N0

CC146

98

TEST25

CC143

99

RC126

RC128

100N0

TEST26

CC121

CC123

CC125

86R6

47R0

4K7

RC023

58

SLA0

fsc

10bit

8fsc

I2C

ACO

83

BC856B

TC120

27P0

91P0

82P0

470R0

RC125

BA7602F

GND_COMB

generat

PLL fsc-DAC

interface

GND_COMB

JC923

RC022

RC020

237R0

QC022

48

XO

SCL

59

470R0

RC021

GND_COMB

IIC_CL_2

20M0

47

X1

SDA

60

470R0

IIC_DA_2

AGND5

AGND4

AGND3

DGND4

RPLL

DGND3

CKMD

54

FSC1

5250

AGND2

AGND1

49 51 86 87 97

TEST24

TEST23

TEST22

TEST21

FSC0

40 55 802912 3 30

DGND2

TEST200

39 41 42 43 44

DGNDRAM2

DGNDRAM1

TESTIC2

TESTIC1

DGND1

CC020

CC021

+2.5D1

+2.5A2

+2.5A1

22P0

CC023

22P0

CC022

+3.3VC

+2.5D2

100P0

100P0

GND_COMB

CC018

10N0

GND_COMB

15U0

LC016

470R0

RC016

TC015

BC846B

GND_COMB

GND_COMB

100N0

CC012

2700R

LC012

CC011

100N0

LC011

750R0

100N0

CC010

750R0

LC010

+3.3VC

IC001

VOLTAGE

GND_COMB

(OPTION)

IFC228 MAIN EU

1K0

RC017

150P0

CC017CC016

150P0

RC015

470R0

100P0

CC027

10U0

CC026CC013

100N0

750R0

LC013

GND_COMB

IC006

32

LD1117DT25

220N0

CC004

100U0

CC003

2

GND

OUTIN

1

3

LD1117DT33

CC002

6V

REGULATOR

COMB

GND_COMB

GND_COMB

CC009

CC008

CC007

GND

OUTIN

1

CC006

JC001

220N0

1N0

220N0

220N0

0R

100U0

JC002

0R

GND_COMB

GND

GND_COMB

GND

IFC228-LCD

First issue 08 / 04

ES

000046:37

Serial-No.

desconexión

Tecla on/off de

-Stand-by o

(off) con tecla on/off.

IFC228-LCD

MODO SERVICIOMODE SERVICESERVICE MODE SERVICE - MODE SERVICE - MODE

ACCESO AL MODO SERVICIO

1

IT

ACCESSO AL SERVICE MODE

1

DE

Acceso panel control TV

• Con el TV encendido, apagarlo con la tecla “Standby” del

telemando. Asegurarse de que el aparato ha pasado a

“Standby”.

• Pulsar primero, la tecla VOL- y después PR- del teclado del

TV. Mantenerlas pulsadas al mismo tiempo durante unos 8

segundos

• Después del arranque normal, cuando hayan pasado los 8

segundos, aparecerá el menú principal del Modo Servicio

tramite i comandi del televisore

• Posizionare il TV nel modo "Standby" usando il tasto standby

del telecomando.Attendere che il TV si posizioni in standby.

• Premere prima il tasto VOL- e poi il tasto PR- sulla tastiera

del TV Mantenere premuto idue tasti per più di 8 secondi.

• Dopo circa 8 secondi il TV si accenderà mostrando sullo

schermo il menu service.

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

DVD Soft-ver. 3.12 Serial-No.

000046:37

Serial-No.

DVD Soft-ver. 3.12 Serial-No.

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

000046:37

Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

SOUND

MISCELLANEOUS

SCALER

SOUND

MISCELLANEOUS

SCALER

DOWN SELECT

UP

Nota :

En modo servicio:

- Borrar despertador/función sleep/memorias/temporizadores

EPG

- El modo primera instalación es ignorado.

- El zoom y el formato son inicializados a barrido estándar

- El bloqueo del teclado queda cancelado.

- La patilla 8 del SCART es ignorada

- La detecci6n de A V-Link, WSS y "modo buzón"

(autoformato) se desactiva.

- EPG y TELETEXTO son desactivados

- Todas las contraseñas son desactivadas

DOWN SELECT

UP

Nota :

Nel service mode:

- Cancella qualsiasi wake-up/sleep/EPG timers.

- Il primo modo di istallazione è ignorato

- Zoom e Format sono inizializzati alla scansione standard

- Il blocco pannello frontale è stato annullato

- Il piedino 8 della scart è ignorato.

- La rilevazione AV-Link WSS e rilevazione letterbox (formato)

è statà disabilitata.

- EPG e TELEVIDEO sono stati disabilitati.

- Tutte le password sono state disabilitate

MODO SERVICIO

telecomando

SALIDA TEMPORAL DEL MODO SERVICIO

2

- Pulse Salir en el mando a distancia

- Con el botón Menu puede acceder al menú de uso cotidian

USCITA TEMPORANEA DAL SERVICE MODE

2

Al menu di uso quotidiano si accede attraverso il pulsante Menu

- Premere Exit sul telecomando.

-

SALIDA DEL

3

- Puede entrar al Menú Servicio con el botón azul.

Tasto on/off

telecomando

USCIRE DAL SERVICE MODE

3

- É possibile rientrate nel Menu Service tramite il pulsante Blue.

Netzschalter oder Standby

- Modo TV.

- Pulse el botón “>”

- Vaya al punto QUIT del menú

principal de modo Servicio

“off” con il tasto on/off

- Funzione Stand-by o

- Premere “>”

- Andare al punto QUIT nel Modo service

del Menu principale

- Mit Standby-Funktion oder

Netzschalter ausschalten

Los valores o ajustes no se guardan antes de salir del modo

servicio y no se escriben en el NVM

- Modo TV.

Valori e regolazioni non memorizzati prima di uscire dal Modo

service e non vengono scritti nell’NVM

8 First issue 10 / 04

Zugriff über die Tastatur des Fernsehgeräts

EINSTIEG IN DEN SERVICE MODE

1

FR

Accès avec le clavier du téléviseur

ACCES AU MODE SERVICE

1

• Mettre le téléviseur en position “veille” avec la

EN

I - ENTER/EXIT SERVICE MODE - ENTREE/SORTIE DU MODE SERVICE - EIN-AUSTIEG SERVICE MODE - ACCESSO/USCITA ALLA/DALLA FUNZIONE - ENTRADA/SALIDA MODO SERVICIO

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

des Gerätes. Halten Sie beide Tasten für länger als 8

• Schalten Sie das Gerät mit der Fernbedienung in Standby.

• Drücken Sie die VOL- Taste und dann die PR-Taste am

Nahbedienteil

Sekunden gedrückt.

• Nach der normalen Einschaltzeit erscheint auf dem

Bildschirm das Menü des Service-Modes.

000046:37

Serial-No.

le menu principal du Mode Service

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

Maintenir enfoncées ces touches ensemble plus de 8

télécommande utilisateur.

• Appuyer sur la touche VOL- puis sur la touche PR- du clavier

du téléviseur.

secondes.

• Après le temps normal de mise en fonctionnement et lorsque

les 8 secondes sont écoulées,

apparaît.

000046:37

Serial-No.

SOUND

MISCELLANEOUS

SCALER

SOUND

MISCELLANEOUS

SCALER

DOWN SELECT

UP

VORÜBERGEHENDES VERLASSEN DES

Anmerkung:

Im SERVICE MODE :

- werden alle Weck-, Schlummer-, Memo- und EPG-Timer gelöscht.

- Der Erstinstallations-Mode wird vom Service-Mode überlagert.

- Zoom und Bildformat werden auf Standardwerte gesetzt

- Die Bedienteilsperre wird aufgehoben

- wird die SCART - Schaltspannung nicht ausgewertet.

- AV-Link, WSS- und Letterbox-Detektion (Autoformat) sind

abgeschaltet.

- sind Videotext und EPG abgeschaltet.

- werden alle Passworte gelöscht.

DOWN SELECT

UP

Note :

En mode service:

- La programmation des heures “reveil/matin”, mémoire et EPG

est annulée.

- Le premier mode d’installation est ignoré.

- Zoom et format sont initialisés au balayage standard.

- Le verrouillage du bloc de commandes du TV est effacé

(réinitialisé).

- Pin 8 de la prise SCART ignorée.

- AV- Link , la détection WSS et la détection letterbox ne sont

pas validées.

- Les fonctions EPG et Télétexte ne sont pas validées.

- Les mots de passe ne sont pas validés.

2

SORTIE TEMPORAIRE DU MODE SERVICE

2

Fernbedienung

ENDGÜLTIGES VERLASSEN DES SERVICE

SERVICE MODE

- Mit der blauen Taste gelangen Sie zurück in den Service-

- Auf der Fernbedienung EXIT drücken

Mode.

- Mit der Taste MENÜ gelangen Sie zum Menü ÜBERSICHT

MODES

3

Inter M/A ou Stand-by

télécommande

SORTIE DEFINITIVE DU MODE SERVICE

- Utiliser la touche Exit de la télécommande.

- Le menu utilisateur peut être accessible via la touche “Menu.

- Pour entrer à nouveau dans le mode service utliliser la touche

bleue.

3

on/off key or Stand-by

- TV Modus

-Taste “>”drücken

Werte und Einstellungen, die nicht vor dem Verlassen des

- Gehen Sie im Hauptmenü des Service-

Modes mit dem Cursor auf die Zeile QUIT.

“off” par M/A

- Foncion Stand-by ou

- Appuyer sur “>”

- Aller au point “QUIT” dans le menu

principal du mode service.

“off” with on/off key.

- Stand-by function or

Service-Modes gespeichert wurden, werden nicht in den

- Mode TV.

Les valeurs ou réglages non mémorisés avant la sortie ne

Permanentspeicher (EEPROM) übernommen.

7

seront pas écrites en NVM.

TV Control Panel Access

ACCESSING SERVICE MODE

1

Soft-Ver. IFC228_X100

Hold them down for more than 8 seconds.

• After the normal switch on time, when the 8 seconds have

keyboard.

• Switch the TV into “Standby” mode by pressing the Standby

button on the RCU.

elapsed, the main service menu appears on the screen.

Wait till the TV goes into the standby.

• Press the VOL- button and then the PR- button on the TV

QUIT

Config W-----V--P-

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

SOUND

MISCELLANEOUS

SCALER

DOWN SELECT

UP

Note :

In service mode :

- Clear any wake-up/sleep/memo/EPG timers

- First installation Mode is overridden.

- Zoom and format are set to standard scanning

- Front Panel lock mode has to be cancelled.

- Pin 8 of the scart plug has to be ignored.

- AV- Link WSS detection and letterbox detection has to be

disabled (autoformat).

- EPG and TELETEXT have to be disabled.

TEMPORARY EXIT FROM SERVICE MODE

2

- All passwords have to disabled.

- Press Exit on the Remote control.

Remote Control

EXITING FROM SERVICE MODE

- Field Service Menu can be re-entrered via Blue button.

- Everyday use menu can be accessed via Menu button.

3

- Go to the point QUIT in the Field service

Mode main menu.

- Press “>” button

- TV mode.

Values or adjustments are no stored before exiting from service

mode will not be written into the NVM

MENUS DU MODE SERVICE

Soft-Ver. ITC22_P110-0 000002:48

Config. W4-----P- Serial-No. AR9211092

UP

DOWN SELECT

QUIT

TUBE

CHASSIS SETUP

FEATURE SETUP

GEOMETRY

VIDEO

EVENT HISTORY

SOUND

MISCELLANEOUS

Version software

Versión software

Versione software

Software Version

Software Version

Counter

Compteur

Zähler

Contador

Contatore

Receiver composition

Composition du Récepteur

Aufbau des Empfängers

Composizione del ricevitore

Composición del Receptor

Serial Number

Alignment

Alignement

Abgleich

Regolazione

Alineacion

N

°

de série

Serien-Nr.

Numero seriale

N

°

Serie

Navigation inside the Service Mode

Navigation dans le Service Mode

Suche im Service Mode

Opzioni del Service Mode

Búsqueda en el Modo Servicio

VIDEO PAL BG

UP

DOWN SELECT/CHANGE

80

80

80

80

Scaling Contrast

Contrast max

Text Contrast

Full White 4/3

Drive Level

Defaults

Store

Restore

Navigation inside the Service Mode

Navigation dans le Service Mode

Suche im Service Mode

Opzioni del Service Mode

Busquena en el Modo Servicio

Hexadecimal value

Valeur hexadecimale de reglage

Abgleichwerte hexadezimal

Valore di regolazione esadecimale

Valor del ajuste en hexadecimal

Bargraphe de réglage

Bargraph

Bargraph

Barre grafica di regolazione

Barra gráfica del ajuste

Case de validation - Fonction validée si "cochée"

Per inserire la Funzione

Activar una functión

Enable a function

Zum Implementieren einer Funktion

UP

DOWN SELECT

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

000046:37

Serial-No.

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

SOUND

MISCELLANEOUS

SCALER

V - Position

+ 7C

prog.

vol.

III - LITE-MENU FOR FIELD SERVICE MODE -

MAIN MENU - MENU PRINCIPAL - HAUPTMENÜ

1

Display

Hexadecimal value

valeur hexadécimale

Einstellungswert hexadezimal

Valore esadecimale

Valor héxadecimal

00 to FF

Set value

: NVM value

><

VISUALIZACION DEL VALOR DE AJUSTE

VALEURS - ANZEIGE DES EINSTELLUNGSWERTES

VISUALIZZAZIONE DEL VALORE DELLA REGOLAZIONE -

DISPLAYING THE VALUE OF THE SETTING - AFFICHAGE DES

4

Display

Config. W5Z.....V

TV CONFIGURATION - CONFIGURATION DU TV - GERÄTEKONFIGURATION -

CONFIGURAZIONE DEL TV - CONFIGURACIÓN Y TV

Character 2 : Teletext external memory detected: “T”

Character 3 : Ambiant Sensor : “S”= detected, “-” = not

Character 1 : Tube type : “A”= 4:3 , “W” =16:9

(ankreuzen)

NVM value

<

-

➠

NVM value

+ >

➠

COMMUTAZIONE - FUNCION CONMUTACION

EIN-UND AUSSCHALTFUNKTIONEN - FUNZIONI DI

TOGGLE FUNCTIONS - VALIDATION DES FONCTIONS

5

To enable a function check (tick) the box.

Pour valider une fonction cocher la case correspondante

: Implemented function : No implemented function

Zum Implementieren einer Funktion das Kontrollkästchen aktivieren

Per implementare una funzione di verifica, (vistare) la casella

Para poner en fucionamiento una función verifique (señale) la casilla

SERIAL-N° A15...

Character 1 : Factory, A= Angers, B= Tarancon, Z= Zyrardow

Character 2 : Year :, G= 1996, H= 1997 etc. (International code UTEC90511)

Character 3 : Month, from 1= January to 9=September...C=December.

Character 4-9 : Serial N° in the month (from 000000 to 999999)

Character 4 : Chassis variant : “N”=Nicam, “V” =Virtual Dolby, “D”=Dolby digital

Character 6 : Guide module : “G” = detected, “-” = not

Character 7 : Flash memory : “F” = detected, “-” = not

Character 8 : Second Tuner (PIP) : “P” = detected, “-” = not

Character 9 : Comb filter : “C” = detected, “-” = not

Character 5 : Subwoofer: “W” = detected, “-” = not

➠

➠

VALORI - VALORES ALMACENADOS EN LA MEMORIA

STORING VALUES IN MEMORY - MEMORISATION DES

VALEURS - SPEICHERN DER WERTE - MEMORIZZAEZ I

6

Character 10-18 : Factory reserved

TIME COUNTER - COMPTEUR DE TEMPS - ZÄHLER - CONTATORE - CONTADOR

The counter indicates the TV’s number of service hours.It counts from to 0 to 65535 hours.

The display is hexadecimal.

Le compteur de temps indique le nombre d’heures de service du TV. Il compte de 0 à

65535 heures. L’affichage est en hexadécimal.

Der Zähler zeigt an, wieviele Stunden der Fernseher in Betrieb ist. Die Anzeige ist

hexadezimal.

After setting, the values are stored in NVM.

Après réglages les valeurs sont mémorisées en NVM.

Nach dem Einstellen werden die Werte im NVM gespeichert.

Dopo la regolazione i valori vengono memorizzati in NVM.

Después del ajuste, los valores son almacenados en NVM

The box becomes

During alignment, values are temporarily stored in RAM.

En cours d’alignement les valeurs sont mémorisées temporairement en RAM

Während des Abgleichs werden die Werte vorübergehend im RAM gespeichert

Durante l’allineamento i valori vengono memorizzati provvisoriamente sulla RAM

Durante el alineamento, los valores son almacenados temporalmente en RAM

SUBMENU - SOUS-MENU - UNTERMENÜ

2

Il contatore indica il numero di ore di servizio del TV. Puo’ contare da 0 a 65535. La

visualizzazione è esadecimale.

El contador indica el número de horas de servicio de la TV. Cuenta de 0 a 65535 horas. El

visualizador es hexadecimal.

Copies all values from NVM into RAM.

Copîes RAM values into NVM

Copie la valeur RAM en NVM

Kopieren des Wertes von RAM nach NVM

➠

Store

Copie toutes les valeurs des données NVM en RAM

Copiare i valori RAM in NVM

Copiar valores RAM en NVM

➠

Restore

Kopiert alle NVM-Datenwerte in des RAM

Copiare tutti i valori da NVM sulla RAM

Copia todos los valores de NVM a RAM

L’ensemble des valeurs par défaut d’une page courante

est chargé en RAM.

Sämtliche Standardwerte der aktuellen Seite werden ins

RAM geladen

Tutti i valori di default di una pagina in uso vengono

memorizzati sulla RAM

Todos los valores por defecto de la página en curso

All the default values of a page in use are stored in RAM.

están almacenados en RAM.

➠

Default

10

000046:37

Serial-No.

➠

DOWN SELECT

VIDEO

EVENT HISTORY

SOUND

MISCELLANEOUS

➠

SCALER

UP

Naviagation down

VALUE

>

VALUE

<

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

II - NAVIGATION INSIDE THE SERVICE MODE - DEPLACEMENT DANS LE MODE SERVICE

TELECOMANDO - MANDO A DISTANCIA

SUCHE IN SERVICE MODE - OPZIONI NEL SERVICE MODE - BUSQUEDA EN MODO SERVICIO

REMOTE CONTROL - TELECOMMANDE - FERNBEDIENUNG

1

Naviagation up

- Select option

- Option anwählen

- Selezionare l’opzione

- Seleccionar opción

- “Change“ value

- Wert “änden“

- “Cambiare“ valore

- “Cambiar“ valor

000046:37

➠

Serial-No.

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

vol.

000046:37

➠

Serial-No.

FERNSEHGERÄTS - COMANDI DEL TELEVISORE -

TV CONTROL PANEL - CLAVIER TV - TASTATUR DES

2

DVD Soft-ver. 3.12 Serial-No.

Tube

CHASSIS SETUP

FEATURE SETUP

VIDEO

EVENT HISTORY

QUIT

Soft-Ver. IFC228_X100

Config W-----V--P-

SOUND

MISCELLANEOUS

SCALER

prog.

SOUND

MISCELLANEOUS

SCALER

DOWN SELECT

UP

Navigation down

DOWN SELECT

UP

Navigation up

- Select option

- Option anwählen

- Selezionare l’opzione

- Seleccionar opción

- “Change” value

VALUE

VALUE

-

+

Vol.

Vol.

- Wert “änden”

- “Cambiare” valore

- “Cambiar” valor

« »

Changing page - Changement de page

Seitenwechsel - Cambiare Pagina - Cambio de página

- When the highlight is on the bottom line of a menu a press on the

- When the highlight is on the first line of a menu a press on the

MENUS WITH MULTIPLE PAGES - MENUS A PLUSIEURS PAGES

MENÜS MIT MEHREREN SEITEN

3

key display the previous page.

« »

« »

key display the next page.

« »

- Quand la 1ère ligne du menu est en surbrillance, un appui sur la

touche affiche la page précédente.

- Quand la dernière ligne du menu est en surbrillance, un appui sur la

key display the next page.

key display the next page.

- When the highlight is on the bottom line of a menu a press on the

touche affiche la page suivante.

- When the highlight is on the first line of a menu a press on the

key display the previous page.

- When the highlight is on the bottom line of a menu a press on the

- When the highlight is on the first line of a menu a press on the

key display the previous page.

- When the highlight is on the first line of a menu a press on the

key display the next page.

- When the highlight is on the bottom line of a menu a press on the

key display the previous page.

IFC228-LCD

First issue 10 / 04 9

DVI

Valide l'entrée DVI sur les appareils équipés.

DVI input enable

DVI input disable

Enable the DVI input on equiped set.

DVI-Eingang freischalten (wenn vorhanden)

Abilita l'ingresso DVI nei set equipaggiati

Activa la entrada DVI, si disponible.

CHASSIS SETUPTUBE

Return

Tube type

FEATURE SETUP

After setting Store

Press </>: remote control; Vol. +/- : TV keyb.

Return

Subwoofer

After replacing the NVM, the right panel

configuration for the TV must be entered.

The tube type can be 16x9 or 4x3 panel size.

The new values will be stored into NVM only

when the Store feature is selected.

Nach dem Tausch des NVM (EEPROM)

muss das Format des Displays eingegeben

werden. Tube Type kann 16x9 oder 4x3 sein.

Die neuen Werte werden erst mit dem

Aktivieren von „Store“ im NVM gespeichert.

Dopo aver sostituito la NVM si deve

selezionare la configurazione del pannello.

Il tube type può essere 16x9 or 4x3 panel.

I nuovi valori saranno memorizzati nella NVM

solo quando verrà eseguita la funzione store.

Definit la configuration exacte du type

d'écran après changement de NVM.

La nouvelle valeur de tube est mémorisée

en NVM dès que l'option store est sélectionée.

Closes the sub-menu and returns to the

"Main Service Menu"

Retourne au menu principal.

Schließt das Untermenü, und das Haupt-

Menü des Service-Modus erscheint.

Chiude il sottomenu e fa apparire il menu

principale Service Mode.

Cierra el submenú. El menú Field Service

Mode aparece.

Press </>: remote control; Vol. +/- : TV keyb.

Closes the sub-menu and returns to the

"Main Service Menu"

Retourne au menu principal.

Schließt das Untermenü, und das Haupt-

Menü des Service-Modus erscheint.

Chiude il sottomenu e fa apparire il menu

principale Service Mode.

Cierra el submenú. El menú Field Service

Mode aparece.

FEATURE SETUP

Validation du Subwoofer sur les appareils

équipés .

Enable the subwoofer on equiped set.

Einschalten des Subwoofers (wenn vorhanden).

Abilita il subwoofer negli apparecchi

equipaggiati.

Subwoofer enable Subwoofer disable

Validación de que existe el subwoofer.

Toplight

Validation de la fonction "Toplight" sur les

appareils équipés .

Enable the "Toplight" function on equiped set.

Aktivieren der "Toplight"-Funktion bei

entsprechend ausgestatteten Geräten.

Abilitare la funzione “Top Light” nei set

equipaggiati Activa la función "Toplight" en los aparatos

equipados con esta opción.

Toplight enable

* Changes are saved directly into NVM

Tout changement est directement sauvegardé

en NVM.

Die Werte werden direkt im NVM gespeichert

I cambiamenti sono salvati direttamente nella

NVM.

Los cambios son directamente guardados en la

NVM

Toplight disable

Curtains Effect*

Welcome Screen*

Optimised Still Picture*

Enables the "Photo Mode" function in the

user "Picture/Advanced use" menus .

Aktivieren der “Photo-Mode”-Funktion im

Benutzer-Menü "Bildeinstellungen/Weitere

Einstellungen".

Abilitare nel menu "Immagine/Parametri

avanzati" la funzione “Photo Mode”.

Activa la función "Modo Foto" en el menú de

usuario "Imagen/Otros ajustes".

Valide la fonction "Photo Mode" dans le menu

"Image/Autres Réglages" des menus

utilisateurs.

Curtains Effect function active.

Curtains Effect function disactivated

Opt. Still picture active.

Opt. Still picture disactivated

Auto film Mode*

Demo Mode*

Enables the "Film mode" function in the

user "Picture/Advanced use" menus .

Aktivieren der “Filmmode”-Funktion im

Benutzer-Menü "Bildeinstellungen/Weitere

Einstellungen".

Abilitare nel menu "Immagine/Parametri

avanzati" la funzione "Modo film".

Activa la función "Modo Film" en el menú de

usuario "Imagen/Otros ajustes".

Valide la fonction "Mode film" dans le menu

"Image/Autres Réglages" des menus

utilisateurs.

Auto film active.

Auto film disactivated

Enables the "Demo" key on the RCU.

Einschalten die Taste "Demo" auf der

Fernbedienung.

Abilita il tasto "Demo" del telecomando.

Validación de la tecla "Demo" del mando a

distancia.

Valide la touche "Demo" sur la télécommande.

Demo Mode active.

Demo Mode disactivated

Program Info*

Welcome Screen enable

Welcome Screen disable

Enables "Program Info" in the

"Overview" menu of user functions.

Aktivieren der “ProgramInfo”-Funktion im

Benutzer-Menü "Übersicht".

Abilitare nel menu "Sommario" la funzione

“Programm Info”

Activa la opción "Program Info" en el menú

de usuario "Sumario".

Valide "Program Info" dans le menu

"Sommaire" des fonctions utilisateurs.

Program Info enable.

Program Info disable.

VIDEO PAL

VIDEO PAL

Closes the sub-menu and returns to the

"Main Service Menu"

Retourne au menu principal.

Return

Press </>: remote control; Vol. +/- : TV keyb.

Schließt das Untermenü, und das Haupt-

Menü des Service-Modes erscheint.

Chiude il sottomenu e fa apparire il menu

principale Service Mode.

Cierra el submenú. El menú Field Service

Mode aparece.

Factory adjusted

Réservé au réglage usine

Reserviert für Fabrikeinstellungen

Riservato alla regolazione di fabbrica

Ajuste reservado fábricas

Factory adjusted

Réservé au réglage usine

Reserviert für Fabrikeinstellungen

Riservato alla regolazione di fabbrica

Ajuste reservado fábricas

After setting Store (+)

Peak-White**

+

= standard

Peak white test pattern

white =100%

PAL, SECAM, RGB, RGB_AUX, COMP1H,

COMP2H, VIDEO DVI, PC_RGB, PC_DVI

Colourimeter

LCD Panel

[Nits]

LG 23"

Hansar 23"

ChiMei 27"

400

400

400

Hitachi 32"

400

Black Offset RBlack Offset

G

Contrast max

Scalling

Contrast

Factory adjusted

Réservé au réglage usine

Reserviert für Fabrikeinstellungen

Riservato alla regolazione di fabbrica

Ajuste reservado fábricas

Full White 4/3

(16/9)

Drive Level

Set (temporary) the user contrast bargraph to max.

When "Contrast max." is deselected the user

contrast bargraph set back to the previous value.

Setzt (temporär) den User-Kontrast auf Max.Nach

dem Abschalten von 'Contrast max' wird auf der

Bar-Graph auf vorherigen Wert zurückgesetzt

Regolare ( momentaneamente) la barragrafica

del contrasto al massimo.Quando "Contrasto

massimo" viene disinserito la barra grafica

utilizzatore viene regolata al volume precedente.

Ajusta (temporalmente) la barra de contraste del

usuario al máximo. Cuando no esté seleccionado

"Contraste Máximo" la barra de contraste del

usuario vuelve a su valor anterior.

Met (temporairement) le baragraphe du réglage de

contraste utilisateur au maximum.

Lorsque "Contrast max." est déselectionné

Le baragraphe revient à sa valeur initiale.

Contrast max. enable

Contrast max. disable

Note :

* Adjust separate for PAL RF/SECAM RF and

RGB_AUX

** After PEAK white adjustment control whitepoints

setting.

Repeat the adjustments if necessary.

Valide la fonction "Effet de rideau" dans le

menu des préférences utilisateurs.

Aktiviert die Funktion "Jalousie-Effekt" im

Benutzer-Menü "Präferenzen".

Abilita "Effetto Tendina" funzione disponibile

nel menu di preferenze.

Activa la función "Efecto Cortina" en los

menús de preferencia del usuario.

Enables the "Curtains Effect" function in the

user preferences menus.

Determines whether or not a Welcome Screen

is shown during the Installation Mode.

When this checkbox is unchecked the

"Contacts" user Menu will be disabled.

Aktiviert den "Willkommen"-Bildschirm bei de

Installation. Wenn diese Checkbox nicht

markiert ist, wird das Benutzer-Menü

"Contacts" nicht angezeigt.

Determina se lo schermo di Benvenuto viene

mostrato durante il modo installazione.

Se la casella "Contacts" non viene selezionata

il menu utilizzatore sarà disabilitato

Determina si durante el modo instalación se

muestra o no la pantalla de bienvenida.

Cuando no está señalada la casilla el menú

del usuario "Contactos" estará desactivado.

Valide l'écran de bienvenue durant le mode

Installation.

Lorsque la case "Welcome Screen" n'est pas

validée le menu utilisateur "Contacts" n'est pas

valide.

Plasma Panel

[Nits]

Fujitsu H 37"

Fujitsu H 42"

300

300

Scaling Colour*

PAL, SECAM, RGB, COMP1H, COMP2H,

RGB_AUX, VIDEO DVI

75% Colour bar test pattern

+

= standard

Blue output

Videoprocesseur

Main Board index 0 (pin 10/14 BV201)

index d (pin 6/8 BV201)

Main

Board

PAL, SECAM, RGB,RGB_AUX

COMP1H, COMP2H, VIDEO DVI,

Grey scale test pattern

Colorimeter : Adjust to the Color

coordinates at the center:

Whitepoint R*

Whitepoint G*

grey

standard

+

=

white =50%

LCD Panel

x

y

0.282

0.298

Plasma Panel

x

y

0.255

0.270

Factory adjusted

Réservé au réglage usine

Reserviert für Fabrikeinstellungen

Riservato alla regolazione di fabbrica

Ajuste reservado fábricas

Scalling

Brightness

=

+

= standard

+

V=0.5V

Text Contrast 9C

Text

Contrast

Ajuster Text Contrast pour obtenir un niveau de

sortie V=0,5V au point 10/14 (Main Board index 0)

ou au point 6/8 (Main board index d) :

60% V peak white.

Adjust Text Contrast for V=0.5V at pin10/14

(Main Board index 0) or pin 6/8 (Main board

index d) : 60% V peak white.

Stellen Sie mit Text Contrast V=0.5V an der

Pin 10/14 (Main Board index 0) oder Pin 6/8

(Main board index d) : 60% V peak white.

Regolare il guadagno contrast televideo per

ottenere un livello pari a V=0.5V al pin10/14

(Main Board index 0) o pin 6/8

(Main board index d) : 60% V peak white.

Ajuste Text contrast para dejar V=0.5V en

pin10/14 (Main Board index 0) o pin 6/8

(Main board index d) : 60% V peak white.

Al cambiar la NVM, hay que configurar el

tipo de pantalla del TV.

Este puede ser 16x9 ó 4x3.

Los nuevos valores serán grabados en la NVM

después de seleccionar Store.

The TV should be warmed up

at least 60 minutes

Le TV doit avoir un temps de

chauffe de 60 minutes

Vor dem Abgleich sollte der

Geräte mindestens 60

Minuten in Betrieb sein.

Il TV deve avere un tempo di

riscaldamento almeno

di 60 minuti.

El TV debe estar encendido

60 minutos antes.

TUBE

Restore

Return

Tube type 16X9

Store

UP

DOWN SELECT/CHANGE

CHASSIS SETUP

DVI

Return

Subwoofer

Top Light

UP

DOWN SELECT/CHANGE

FEATURE SETUP

Return

Curtains Effect

Opt.Still Pict.

Auto Film Mode

Demo Mode

Welcome Screen

Program Info

UP

DOWN SELECT/CHANGE

VIDEO PAL BG

VIDEO PAL BG

UP

DOWN SELECT/CHANGE

UP DOWN SELECT/CHANGE

Return

Peak White

Black Offset R

Black Offset G

808080

Scaling Colour

Scaling Brightness

Whitepoint R

Whitepoint G

808080

80

80

80

80

80

Scaling Contrast

Contrast max

Text Contrast

Full White 4/3

Drive Level

Defaults

Store

Restore

IFC228-LCD

12 First issue 10 / 04

11

ALIGNMENT PROCEDURE - PROCESSUS DE REGLAGES - ABGLEICH - VISUALIZZAZIONE DEL VALORE DELLA REGOLAZIONE - PROCEDIMIENTO DE ALINEACION

14

1- The last five error codes are stored and

displayed with a time stamp from the run time

counter

2- If an error occurs that is already in the list

the time stamp is updated .

3- The errors are displayed with the most recent

error on top of the list. The others follow with

descending time stamps.

Displaying Error Codes with LED:

1- In addition to storing an error code it must

also be displayed with the TV's Standby LED.

Only the last error that occured is displayed.

2- Decimal error codes from 11 to 99

(with second digit not being 0) are signalled.

3- The error code is displayed as two separate

digits separated by a suitable pause, this is

repeated until the either the TV fixes the fault

or the TV is repaired.

For example Error-code : 23 will be displayed

thus :

2 flashes and a short pause

3 flashes and a long pause

.........

List of Errors Codes : see table

1. Es werden die letzten 5 Fehlercodes mit der

Laufzeit des Auftretens angezeigt.

2. Tritt ein Fehler auf, der schon in der Liste

steht, wird nur die Laufzeitanzeige aktualisiert.

3. Der zuletzt aufgetretene Fehler steht an

erster Stelle. Die vorhergegangenen Fehler

werden nach abnehmender Laufzeit gelistet.

Anzeige des Fehlercodes über die Standby-LED

1- Der Fehlercode wird nach dem Auftreten des

Fehlers zusätzlich über die Standby-LED des

TV-Gerätes durch Blinken angezeigt.

2- Es können die Fehlercodes 11 bis 99 (ohne

diejenigen , die eine Null als zweite Stelle haben)

dargestellt werden.

3- Die beiden Dezimalstellen des Code werden

durch Blinken, getrennt von einer Pause angezeigt.

Dies wird wiederholt, bis der Fehler

nicht mehr auftritt oder das Gerät repariert wird.

Beispiel der Anzeige für den Fehlercode 23:

Zweimaliges Blinken der LED, kurze Pause

Dreimaliges Blinken der LED, lange Pause.

Aufstellung der Fehlercodes: siehe Tabelle

1- Mémorise les cinq derniers codes erreurs.

Le cumul du temps de fonctionnement entre le

démarrage initial du chassis en usine et le moment

où s'est produit l'erreur est indiquée en colonne

"Time stamp".

2. Si une erreur qui est déjà dans la liste survient

de nouveau le temps cumulé (Time stamp) est

mis à jour.

3- Les erreurs les plus récentes sont affichées en

tête de liste. Les autres suivent en descendant.

Affichage des Codes Erreurs par LED:

1- Les Codes erreur sont signalés par le

clignotement de la LED Standby du TV .

Seulement la dernière erreur survenue est

affichée.

2- Les codes Erreurs décimaux vont de 11 à 99.

(le second digit n'est jamais égal à 0) .

3- Le code Erreurs est signalé par deux digits

selon une séquence spécifique

Exemple :

Code Erreurs : 23 affiché

2 flashes, courte pause

3 flashes : longue pause

........

Voir ci-après la liste des codes erreurs

To clear all event codes stored in the

NVM. Action:

Long press (> 2.5sec.).

Clear Event Codes

CODE

Press </>/OK: remote control.

EVENT HISTORY

Closes the sub-menu and returns to the

"Main Service Menu"

Retourne au menu principal.

Return

Press </>: remote control; Vol. +/- : TV keyb.

Schließt das Untermenü, und das Haupt-

Menü des Service-Modes erscheint.

Chiude il sottomenu e fa apparire il menu

principale Service Mode.

Cierra el submenú. El menú Field Service

Mode aparece.

CODE

EVENT HISTORY

Closes the sub-menu and returns to the

"Main Service Menu"

Retourne au menu principal.

Return

Press </>: remote control; Vol. +/- : TV keyb.

Schließt das Untermenü, und das Haupt-

Menü des Service-Modes erscheint.

Chiude il sottomenu e fa apparire il menu

principale Service Mode.

Cierra el submenú. El menú Field Service

Mode aparece.

SOUND SETTINGS

Adjust "Sound settings" registers according

to the TV environments (refer to the below table)

when the NVM memory has been replaced.

On entering this menu the sound mode will be

switched to normal and the "Dynamic Bass"

feature activated.

Wurde das NVM (EEPROM) erneuert, müssen

im Menü "SOUND SETTINGS" die Werte

entsprechend der unten stehenden Tabelle

eingestellt werden.

Beim Aufruf dieses Menüs wird der Sound-Mode

auf Normal gesetzt und „Dynamic Bass“ aktiviert.

Quando viene sostituita la memoria NVM

regolare i registri "Sound setting" in funzione

all'anbientazione TV (riferirsi alla tabella

sottoindicata).

Selezionando questo menu, il suono sarà

commutato su normale e verrà attivata la

caratteristica"Dynamic Bass".

Ajustar los "Parámetros de Sonido" de acuerdo

a las características del modelo de TV

(ver tabla),después de sustituir la memoria NVM.

Entrando en éste menú, el modo de sonido

pasará a normal y se activará el "Dynamic Bass".

Règle le contenu des registres

"Sound settings"

selon l'environnemnt du TV en cas de

remplacement de la NVM. (voir table ci-dessous)

en entrant dans ce menu le mode son est commuté

en normal et les caractéristiques "Dynamic Bass"

sont activées.

Effect Strength (MED) 3F

Effect Strength (HIGH) 43

Low Pass Frequency 08

High Pass Frequency 04

Sub-woofer corner Freq. 14

After setting Store (+) After setting Store (+) After setting Store (+)

1- Gli ultimi cinque codici errore vengono

memorizzati e visualizzati con un time stamp

dal run time counter.

2- Se si manifesta un errore già presente nella

lista il time stamp viene aggiornato

3- Gli errori vengono visualizzati con l’errore più

recente in cima alla lista.

Gli altri errori seguono con sequenza

discendente del time stamp

Lampeggi LED: Trasmissione messaggi

1 Oltre alla memorizzazione il codice errore,

deve anche essere visualizzato dal LED di standby.

2 Gli errori vengono segnalati con codici

decimali da 11 a 99 ( non con 0 al secondo digit )

3 Il codice errore viene visualizzato da due digit

separati da una pausa,

queto viene ripetuto finchè il difetto è presente

o il TV viene riparato

Per esempio il codice errore 23 sarà visualizzato:

2 lampeggi e una breve pausa

3 lampeggi lampeggi e una lunga pausa

.........

Lista Codici Errore: segue tabella

1- Los últimos 5 códigos de error son

almacenados desde el contador de tiempo de

vida y mostrados en la columna "time stamp"

2- Si ocurre un error que ya existe en la lista,

éste se actualizará al último "time stamp"

3- Los errores más recientes son los mostrados

en la parte superior de la lista. Los demás

siguen en orden descendiente de "time stamp"

Códigos de error mostrados con el LED:

1- Además del almacenamiento, los codigos

de error también se muestran con el LED de

standby del TV.

Sólo se muestra el último error ocurrido.

2- Sólo se muestran los códigos de error

decimales del 11 al 99 (dígito de las decenas

empezando por cero, no)

3- El código de error es mostrado como 2

dígitos separados por una pausa corta.

Se repite hasta que se recupere el fallo o el TV

sea reparado.

Por ejemplo, el código de error 23 se mostrará

como:

2 destellos seguidos de una pausa corta

3 destellos seguidos de una pausa larga

.........

Lista de códigos de error: ver tabla

EVENT HISTORY

000000:00

Clear Event Codes

Code Count Time Stamp

Return

15 005 000000:06

00 000 000000:00

00 000 000000:00

00 000 000000:00

UP

DOWN SELECT/CHANGE

SOUND

Return

Effect Strength (MED)

Effect Strength (HIGH)

Low Pass Frequency

High Pass Frequency

809A80

56

Sub-woofer Corner Frequency 80

Store

Restore

Defaults

11 I2C bus_1 data est au niveau bas

12 I2C bus_1 clock est au niveau bas

13/95 I2C bus_2 data est au niveau bas

14/95 I2C bus_2 clock est au niveau bas

15 I2C bus_3 data est au niveau bas

16 I2C bus_3 clock est au niveau bas

17 I2C bus_4 data est au niveau bas

18 I2C bus_4 clock est au niveau bas

19 Erreur de chassis détecté

25 Tuner principal ne répond pas

26 Tuner secondaire (PIP) ne répond pas

27 IX300 (TEA6415C) ne répond pas

28 IV300 (TA1360) ne répond pas

29 Chute de l'alimentation 9V IV300

41 IA001 (MSP) ne répond pas

42 IA001 (MSP) en reset

45 Mauvais MSP monté

48 FI PIP ne répond pas

49 Chute alimentation 5V FI PIP

54 NVM IR005 (M24C64) ne répond pas

55 IR006 (PCF8574) ne répond pas

58 Mauvaise validation de Code erreur

59 Mauvais IR001 monté

61 5V n'apparaît pas au départ

63 Niveau incorrect sur la ligne NMI

69 Synch. H/V (OSD) absente

72 IX400 (CXA2151) ne répond pas

93 IR001 : Problème d'installation des drivers des bus I2C1 et I2C2

94 IR001 : Problème d'installation des drivers des bus I2C3 et I2C4

95 IR001 : Problème d'installation des ports ou des drivers I2C

96 IR001 : Problème d'installation des drivers ADC

97 IR001 : Problème d'installation du driver AV-link

98 Problème du timing SDRAM (IR110)

99 IR001 Watchdog actif

11 I2C Bus_1 Data ist immer L

12 I2C Bus_1 Clock ist immer L

13/95 I2C Bus_2 Data ist immer L

14/95 I2C Bus_2 Clock ist immer L

15 I2C Bus_3 Data ist immer L

16 I2C Bus_3 Clock ist immer L

17 I2C Bus_4 Data ist immer L

18 I2C Bus_4 Clock ist immer L

19 Falsche Chassisvariante

25 Haupttuner/ZF Tunerteil antwortet nicht

26 Zweiter (PIP-)Tuner Tunerteil antwortet nicht

27 IX300 (TEA6415C) antwortet nicht

28 IV300 (TA1360) antwortet nicht

29 Power Down Detection IV300 (9V zu geringe Betriebsspannung)

41 IA001 Audio-MSP antwortet nicht

42 IA001 Audio-MSP Reset-Bit ist aktiv

45 Falscher MSP-Typ eingesetzt

48 Zweiter (PIP-)Tuner ZF-Teil antwortet nicht

49 Power Down Detection ZF-Teil PIP-Tuner/ZF

(5V zu geringe Betriebsspannung)

54 NVM IR005 (M24C64) antwortet nicht

55 IR006 (PCF8574, Portexpander) antwortet nicht

58 Event-Code konnte nicht bestätigt werden

59 Falsche Version des Microcontrollers IR001

61 Geschaltete 5VON nicht vorhanden

63 Unerwarteter Pegel auf POWER_FAIL (NMI-Leitung: z.B.

Überschlag im Bildrohr oder zu niedrige Netzspannung)

69 H/V-Synch für OSD fehlen

72 IX400 (CXA2151, Eingangsschalter AV4) antwortet nicht

93 Soft.problem: IR001 konnte Bustreiber für I2C-Bus_1 und

II2C-Bus_2 nicht korrekt installieren

94 Soft.problem: IR001 konnte Bustreiber für I2C-Bus_3 und

II2C-Bus_4 nicht korrekt installieren

95 Software problem: IR001 konnte Porttreiber für I2C-Busse

nicht korrekt installieren

96 Software problem: IR001 konnte Treiber für den ADC nicht

korrekt installieren

97 Software problem: IR001 konnte AV-Linktreiber nicht

korrekt installieren

98 Software problem: IR001 konnte SDRAM-Timing nicht

korrekt installieren

99 Watchdog-Timer im IR001 hat ausgelöst

11 I2C bus_1 data line held low

12 I2C Bus_1 clock line held low

13/95 I2C Bus_2 data line held low

14/95 I2C Bus 2 clock line held low

15 I2C Bus_3 data line held low

16 I2C Bus 3 clock line held low

17 I2C Bus_4 data line held low

18 I2C Bus 4 clock line held low

19 Invalid chassis detected

25 Main tuner doesn't answer anymore

26 Secondary tuner (PIP) doesn't answer anymore

27 IX300 (TEA6415C) doesn't answer anymore

28 IV300 (TA1360) doesn't answer anymore

29 9V IV300 Power down detection

41 IA001 (MSP) doesn't answer anymore

42 The reset bit IA001 (MSP) is active

45 Wrong MSP is fitted

48 PIP FI doesn't answere anymore

49 5V PIP FI Power down detection

54 NVM IR005 (M24C64) doesn't answer anymore

55 IR006 (PCF8574) doesn't answer anymore

58 Code validation failed

59 Wrong IR001 is fitted

61 5VON not present

63 Unexpected level on NMI line found

69 H/V Synch. for OSD missing

72 IX400 (CXA2151) doesn't answer anymore

93 IR001 : Err_I2C Bus_1 and Err_I2C Bus_2 (Bus drivers)

94 IR001 : Err_I2C Bus_3 and Err_I2C Bus_4 (Bus drivers)

95 IR001 : Err_I2C. Port driver can not be installed

96 IR001 : ADC driver can not be installed

97 IR001 : AV-link driver can not be installed

98 SDRAM (IR110) Problematic SDRAM timing

99 IR001 Watchdog hit

DE

FR

IT

EN

11 Línea Data I2C bus_1 forzada a nivel bajo

12 Línea Clock I2C bus_1 forzada a nivel bajo

13/95 Línea Data I2C bus_2 forzada a nivel bajo

14/95 Línea Clock I2C bus_2 forzada a nivel bajo

15 Línea Data I2C bus_3 forzada a nivel bajo

16 Línea Clock I2C bus_3 forzada a nivel bajo

17 Línea Data I2C bus_4 forzada a nivel bajo

18 Línea Clock I2C bus_4 forzada a nivel bajo

19 Detectado chasis inválido

25 El sintonizador principal no responde

26 El sintonizador secundario (PIP) no responde

27 IX300 (TEA6415C) no responde

28 IV300 (TA1360) no responde

29 Faltan los 9V de IV300

41 A001 (MSP) no responde

42 El bit del reset de IA001 (MSP) está activo

45 MSP averiado

48 La FI del PIP no responde

49 Faltan los 5V de la FI PIP

54 NVM IR005 (M24C64) no responde

55 IR006 (PCF8574) no responde

58 Código de validación fallido

59 IR001 montado, mal o incorrecto

61 Faltan los 5VON

63 Nivel inesperado en la línea NMI

69 Faltan los sincronismos H/V para el OSD

72 IX400 (CXA2151) no responde

93 IR001, Err_I2C Bus_1 y Err_I2C Bus_2 (Bus drivers)

94 IR001, Err_I2C Bus_3 y Err_I2C Bus_4 (Bus drivers)

95 IR001, Err_I2C, Puerto del driver no se puede instalar

96 IR001, driver para ADC no se puede instalar

97 IR001, driver para AV-link no se puede instalar

98 SDRAM (IR110) problemas con el timing

99 IR001 alcanzado Watchdog

ES

11 I2C bus_1 data linea forzata bassa

12 I2C Bus_1 clock linea forzata bassa

13/95 I2C Bus_2 data linea forzata bassa

14/95 I2C Bus 2 clock linea forzata bassa

15 I2C Bus_3 data linea forzata bassa

16 I2C Bus 3 clock linea forzata bassa

17 I2C Bus_4 data linea forzata bassa

18 I2C Bus 4 clock linea forzata bassa

19 Errorre di riconoscimento chassis

25 Main tuner non risponde

26 Tuner secondario (PIP) non risponde

27 IX300 (TEA6415C) non risponde

28 IV300 (TA1360) non risponde

29 9V IV300 Rilevamento Power down

41 A001 (MSP) non risponde

42 Il bit di reset di IA001 (MSP) è attivo

45 E ' stato inserito un MSP sbagliato'

48 PIP FI non risponde

49 5V PIP FI Rilevamento Power down

54 NVM IR005 (M24C64) non risponde

55 R006 (PCF8574) non risponde

58 Non abilita dei codice errore

59 Versione errata di microprocessore IR001

61 5VON non disponibile alla partenza

63 Indesiderato livello sulla linea NMI

69 H/V Synch. for OSD assente

72 X400 (CXA2151) non risponde

93 IR001 : Err_I2C Bus_1 i Err_I2C Bus_2 (Bus drivers)

94 IR001 : Err_I2C Bus_3 i Err_I2C Bus_4 (Bus drivers)

95 IR001 : Err_I2C. Problema di installazione porta drivers IIC

96 IR001 : ADC Porta drivers non può essere installata

97 IR001 : AV-link driver non possono essere installati

98 SDRAM (IR110) Problematica SDRAM timing

99 IR001 Watchdog attivo

ALIGNMENT PROCEDURE - PROCESSUS DE REGLAGES - ABGLEICH -

VISUALIZZAZIONE DEL VALORE DELLA REGOLAZIONE - PROCEDIMIENTO DE ALINEACION

IFC228-LCD

First issue 10 / 04 13

Video settings

o

Displays the video submenu below.

Zeigt das Video-Untermenü an (siehe unten).

Affiche le sous-menu video ci-dessous.

Soft-Ver V1.00*

Visualizzi il sub-menu video sotto.

.

191

190

194

Return

Red

Green

Blue

Muestra el submenú de vídeo debajo.

Peak white adjustment

Depending on user selection, the changes will

either modify PC VGA or PC DVI RGB

settings.

Abhängig von der Wahl des Benutzers werden

die Einstellungen von PC VGA oder PC DVI

RGB beeinflusst.

Dependiendo de la selección del usuario, los

cambios serán entre modificar los ajustes PC

Modifie les valeurs de réglages des

configurations PC VGA ou PC DVI RVB.

VGA o PC DVI RGB.

Modifica i valori delle regolazioni delle

configurazioni PC VGA o PC DVI RGB

If no test pattern is connected and the item

return is selected the message "No signal PC"

is displayed.

To return to the Service menu it's necessary

to press a numeric button and then the

Note :

Blue button

Ist kein Eingangssignal angelegt und es wird "Return"

Si aucune source PC n'est connectée le message

gewählt, kann die Meldung „No signal PC“ erscheinen.

"Pas de signal PC" s'affiche".

Pour revenir au mode service il est nécessaire

d'appuyer sur une touche numérique

et ensuite sur la touche bleue de la télécommande.

Um in das Servicemenü zurückzukehren, muss zuerst

eine Zahlentaste und dann die blaue Taste gedrückt

werden.

Se nessuna sorgente PC è collegata verrà visualizzat

il messaggio " No signal PC."

Per ritornare al modo service è neccessario

premere un tasto numerico e poi premere

Il tasto blu del telecomando.

Si no hay conectada una carta de ajuste y cuando

se selecciona "return" se muestra el mensaje

"No signal PC".

Para volver al Menú de Servicio es necesario

pulsar una tecla numérica y después la tecla Azul

IFC228-LCD

16 First issue 10 / 04

Soft-Ver V1.00

Return

Factory reset ....

Internal ADC Calibration ....

Test Pattern ....

Video settings ....

DOWN SELECT/CHANGE

UP

Reset to factory values.

Factory reset

Scaler PC

Selects the PC field service menu with VGA

MISCELLANEOUS Soft-Ver V1.00*MISCELLANEOUS

Developpement Support

MISCELLANEOUS

alle valori di fabbrica

Reset a los valores de fábrica.

Rücksetzen zu den Fabrikwerten.

Regolare

Reinitialisation aux valeurs usine.

as input source: TV in AV4, PC AV source.

The signal must be connected to VGA port

Factory adjusted

Réservé au réglage usine

Internal ADC Calibration

Triggers the scaler internal ADC alignment routine.

Grey scale test pattern input :

- to VGA port for Scaler PC

- to DVI port for Scaler DVI

When complete the word "Done" is displayed.

Moving the cursor away will automatically

erase the word and ready the system for

Selezionare PC nel menu service con VGA

come sorgente ingr.: TV in AV4, PC AVsorgente.

Sélectionne le menu PC du mode service

avec une source d'entrée VGA : TV en AV4,

source AV PC.

La source d'entrée doit être le port VGA

Dieses aktiviert den PC-Service-Mode mit VGA

Restores the correct "out of box" condition.

Reserviert für Fabrikeinstellungen

Riservato alla regolazione di fabbrica

Ajuste reservado fábricas

Restore Factory Settings

Il segnale si deve collegare alla porta VGA

als Eingangssignal: TV an AV4, PC als AV-Quelle.

Das Eingangssignal muss am VGA-Eingang

anliegen.

Remet les réglages aux valeurs de sortie usine.

Certaines valeurs sont restaurées à partir

d'une zone de mémoire NVM et d'autres

Some settings will be restored from a

à partir des valeurs par défaut de la ROM.

reserved backup NVM area and others will be

defaulted from the ROM.

Entrer une mire d'échelle des gris :

- sur le port VGA pour le Scaler PC

- sur le port DVI pour le Scaler DVI

A la fin du réglage, le mot "Done" est affiché.

Le déplacement du curseur efface

automatiquement le mot et prépare le système

pour un autre réglage.

another calbration is required.

Déclenche la procédure de réglage interne ADC

du scaler.

Seleccionar el menú PC del modo servicio con

la señal de entrada VGA: TV en AV4, PC en AV

La señal debe ser conectada por el puerto VGA.

Überschreibt den jeweiligen Abgleich mit

Werten aus dem ROM und aus besonderen,

reservierten Bereichen des NVMs.

Startet die Abgleichroutine der internen Scaler

ADCs.

Speisen Sie einen Graukeil ein:

- in den VGA-Eingang für Scaler PC

- in den DVI-Eingang für Scaler DVI

Am Ende des Abgleichs wird „Done“ angezeigt.

Das Drücken einer der Cursor-Tasten löscht die

Meldung und bereitet das Gerät für weitere

Scaler DVI

Sélectionne le menu PC du mode service avec

une source d'entrée DVI : TV en AV5, source

AV DVI. La source d'entrée doit être le port DVI

Selects the PC field service menu with DVI as

input source: TV in AV5, DVI AV source.

The signal must be connected to DVI port.

Der Abgleich entspricht dann dem, den das

Gerät beim Verlassen der Produktionsstätte

hatte. Rimettere le regolazioni ai valori di fabbrica

Alcune regolazioni saranno ripristinate da una

zona riservata dalla memoria NVM, altre

regolazioni saranno riprese dalla ROM di

Selezionare PC nel menu service con DVI

come sorgente ingr: TV in AV5, DVI AV sorg.

Dieses aktiviert den PC-Service-Mode mit DVI als

Eingangssignal: TV an AV5, DVI als AV-Quelle.

Das Eingangssignal muss am DVI-Eingang

anliegen.

default. Vuelve a poner los ajustes a los valores de

salida de la fábrica.

Se restauran algunos valores a partir de una

zona de memoria NVM y de otros a partir de

los valores por defecto de la ROM.

Einstellungen vor.

Triggerare lo scaler int. ADC alignment routine.

Inserire all'ingresso un segnale scala di grigi :

- Alla porta VGA per Scaler PC

- Alla porta DVI per Scaler DVI

Quando completata "Done" sarà visualizzato.

Muovendo il cursore verrà automaticamente

cancellata la scritta e preparato il sistema per

un'altra calibrazione se richiesta.

- por el puerto VGA para el scaler del PC

- por el puerto DVI para el scaler DVI

Al terminar, aparece la palabra "Done"

Moviendo el cursor fuera, será

automáticamente borrada la palabra y dispone

Arranca la rutina de ajustes del scaler ADC interno.

Seleccionar el menú PC del modo servicio con la

señal de entrada DVI: TV en AV5, DVI por AV.

La señal debe ser conectada por el puerto DVI.

Il segnale si deve collegare alla porta DVI .

ADC calibration (Ext. ADC)

Start the automatic ADC alignment routine.

Insert a grey test pattern

Select ADC calibration and press left or right

button. Alignment will be carried out automatically.

al sistema para iniciar otro ajuste.

Entrada de carta de ajuste de escala de grises:

When complete the word "done" will be displayed.

Menu service can be re- entred via Blue button.

Démarre la routine de réglage automatique ADC.

Insérer une mire de barres d'échelle des gris.

Selectionner ADC calibration et appuyer sur la touche

gauche ou droite. La procédure démarre

automatiquement.Lorsque elle est complète le

Europe

Asia

Fast Filter (IF / PLL)

Filtre rapide (FI / PLL)

Schnelles filter (ZF / PLL)

Filtro /rapido (IF / PLL)

FFI - Bit

Switch 2nd Tuner to Main

The current signal on the second tuner is

switched to the main screen and the AV1

output.

Changing program/channel on main tuner, the

main screen stays on the second tuner.

Commute le signal du second tuner en

image principale et en sortie AV1.

L'écran reste sur l'image du secont tuner

fter the last pattern the main menu is displayed.

Test pattern

Displays the internal test pattern.

The ">" button toggles through the colour :

White, Black, Red, Green and Blue.

A

Zeigt die internen Testmuster an. Mit ">"

schaltet man die Farben weiter: Weiß, Schwarz,

Rot, Grün und Blau. Nach dem letzten

Testmuster wird wieder das Hauptmenü angezeigt.

Visualizzare il generatore di test interno .

Il tasto ">" seleziona i colori :

Affiche la mire de réglage interne.

Les appuis successifs sur la touche ">"

commute les mires de couleurs : Blanche,

noire, rouge, verte et bleue. Après la dernière

message "done" s'affiche.

On peut entrer à nouveau dans le mode service

en utilisant la touche bleue.

Starten Sie die ADC Abgleichroutine.

malgré tout changement de programme/canal

sur le tuner principal.

Das jeweilige Eingangssignal des zweiten

Tuners wird auf dem Hauptbildschirm

mire le menu principal apparaît.

Speisen Sie einen Graukeil ein. Wählen Sie "ADC

dargestellt und auf den AV1-Aushang geschaltet.

Iniziare la routine automatica ADC alignement .

Calibration" und drücken die Cursortaste "Links "

oder "Rechts". Der Abgleich wird automatisch

vorgenommen. Am Ende des Abgleichs wird "Done"

angezeigt. Das Service-Menü kann wieder mit der

blauen Taste aufgerufen werden.

Commutare il segnale del secondo tuner sullo

schermo e in uscita AV1

Lo schermo resta sull’immagine del secondo

Bei einem Programm/Kanalwechsel auf dem

tuner, malgrado tutti i cambiamenti di

Haupttuner bleibt das Bild des zweiten Tuners

auf dem Hauptbildschirm sichtbar.

Bianco, Nero, Rosso, Verde e Blu. Dopo

Inserire un segnale scala di grigi.

Selezionare ADC calibration premere il tasto left o

right. L'allineamento partirà automaticamente.

Quando sarà completato "done" verrà vizualizzato.

Si può richiamare il menu service con il tasto blu.

progamma/canale sul tuner principale

La señal actual en el segundo sintonizador se

cambia a la pantalla principal y a la salida AV1.

Program/channel que cambia en el

sintonizador principal, la pantalla principal

l'ultimo segnale di test si avrà il main menu

Muestra la carta de ajuste interna.

La tecla ">" conmuta a través de los colores:

Blanco, Negro, Rojo, Verde y Azul. Después

de la última carta de ajuste, sale el menú principal

Arranca la rutina de ajustes del scaler ADC interno.

Insertar una a de barras de esala de grises

Seleccionar calibración ADC y pulsar la tecla dcha

o izda. El ajuste comenzara automáticamente.

Al terminar, aparece la palabra "Done".

Se puede entrar al menú servicio con la tecla azul

Switch 2nd Tuner to Main enable

Switch 2nd Tuner to Main disable

permanece en el segundo sintonizador.

ALIGNMENT PROCEDURE - PROCESSUS DE REGLAGES - ABGLEICH - VISUALIZZAZIONE DEL VALORE DELLA REGOLAZIONE - PROCEDIMIENTO DE ALINEACION

Clear Progs

Default Presets

Return

Bus Quiet

MISCELLANEOUS

Development Support

Restore Factory Settings

FFI-Bit

Switch 2nd Tuner to Main

Scaler PC

Scaler DVI

ADC Calibration

In "Bus Quiet", the NVM can be read, modified

Bus Quiet

DOWN SELECT/CHANGE

UP

Closes the sub-menu and returns to the

Return

MISCELLANEOUS

En mode bus quiet la NVM peut être lue,

modifiée et reprogrammée.

and reprogrammed by means of a NVM

Programmer.

To access "Bus Quiet" : Long press ">".

The TV should remain in "Bus Quiet" mode

until either Exit, Left, Right, Up,Down or

Standby keys on the RCU or local keyboard

are pressed; at which point the TV should

carry out a warmstart in order to prevent

differences between the NVM and RAM

contents.

After returning from Bus Quiet, the software

"Main Service Menu"

Retourne au menu principal.

Schließt das Untermenü, und das Haupt-

Press </>: remote control; Vol. +/- : TV keyb.

Menü des Service-Modes erscheint.

Chiude il sottomenu e fa apparire il menu

principale Service Mode.

Cierra el submenú. El menú Field Service

Mode aparece.

Accès au mode Bus quiet :

checks the NVM content.

If it is not valid, the software perform a new

default writing of the NVM content.

Clear Progs.

Clears all programms stored in memory and

resets all Picture and Sound settings to the factory

defaults. The AUTO INSTALL (out of factory)

Longue pression ">".

Utiliser l'une des touches Exit, Gauche, Droite

Haut, Bas, standby ou une des touches du

clavier pour sortir le téléviseur du mode bus

quiet.

A partir de ce point de sortie le démarrage

du téléviseur s'effectue à chaud pour éviter

toute différence des contenus RAM et NVM.

En sortie de mode bus quiet, le logiciel

contrôle le contenu de la NVM.

S'il n'est pas correct le logiciel exécute une

nouvelle écriture par défaut de celle-ci.

Im "Bus Quiet"-Modus kann der Inhalt des

NVM mittels eines externen NVM-

Programmiergerätes ausgelesen, geändert

oder neu programmiert werden. "Bus Quiet"

wird einem längeren Druck auf ">" aktiviert.

Das Gerät bleibt solange im "Bus Quiet" -

Mode, bis durch Druck auf die EXIT-, LINKS-,

Löscht alle Programmplätze und setzt alle Bild-

und Toneinstellungen auf Fabrikwerte zurück.

Der AUTO-INSTALL-Modus kann durch einen

langen Knopfdruck (>2s) initialisiert werden.

Cancella tutti i programmi in memoria e regola i

Valori analogici SUONO IMMAGINE: ai livelli di

fabbrica.Riportare la TV al modo Selezione:

Efface tous les programmes mémorisés.

Valeurs SON et IMAGES: valeurs usines.

Fonction valide par une longue pression (>2s.)

sur la touche de sélection </>.

mode can be initialised by a long press (>2s.)

of the selection button.

pressione prolungata: 2 sec. su il pulsante </>.

Programa de borrado.

Borra todos los programas almacenados en la

RECHTS-, HOCH-, RUNTER- oder

STANDBY-Taste (am Gerät oder auf der

Fernbedienung) ein Warmstart des Gerätes

veranlaßt wird, um unterschiedliche Daten in

RAM und NVM zu vermeiden.

Es folgt ein Software-Check des NVM-

Inhaltes.

Sollte dieser nicht gültig sein, wird der Inhalt

mit Default-Werten überschrieben.

In Modo Bus Quiet, la memoria NVM può

essere letta, modificata o riprogrammata.

Per accedere al modo Bus Quiet premere a

lungo il tasto ">".

Il TV rimane in modo Bus Quiet

fino a che vengono premuti i tasti Exit, o

Destro Sinistro, Su o Giù o Standby dal

telecomando o dalla tastiera locale; a questo

punto il TV riparte per evitare

Clear Progs disable

Clear Progs enable

memoria.Valores analógicos de

IMAGEN y SONIDO: valores de fábrica.Regreso

a la TV para "salir del modo fábrica".Selección:

Presión larga igual a 2s.

Default Presets

Sets the default (ROM) value for all the factory

sound and picture presets.

Aktiviert die Default- (ROM-) Werte für alle

Ton- und Bildvoreinstellungen.

Initialise aux valeurs par défaut (ROM) les

réglages usine du son et de l'image.

interferenze tra i contenuti della memoria

NVM e della RAM.

All'uscita dal modo Bus Quiet, il software

controlla il contenuto della memoria NVM. Se

tale contenuto non è valido, il software

provvede a una nuova programmazione

della NVM con l'inserimento dei dati di default.

En bus quieto, la NVM puede ser leída,

modificada y reprogramada.

Acceso a bus quieto : Larga presión en ">"

El TV permanecerá en bus quieto hasta que

se pulse cualquiera de las teclas siguientes:

Exit, "<", " ", "V", ">"o Standby del telemando

o del teclado.

En este momento el TV arrancará para evitar

cualquier diferencia entre los contenidos de la

RAM y NVM.

Default Presets disable

Regolare i valori di defoult (ROM) valori di

Default Presets enable

fabbrica per le regolazioni suono e Video

Fija el valor del valor por defecto (ROM) para

todas las precolocaciones del sonido y del cuadro

de la fábrica.

15

Bus quiet enable Bus quiet disable

Al salir del modo bus quieto, el software

comprueba el contenido de la NVM.

Si no coincide, el software ejecuta la escritura

de los datos en la NVM.

3.3VSTBY

3V9

DP250

GND

220uF

CP206

GND

P

FZP207

T1,0A_125V

10.5V

2K2

RP401

TP201

Utilice solo piezas originales

Pieza de seguridad

Bei Ersatz nur Originalteil verwenden

Sicherheitsbauteil

Per la riparazione utilizzare solo componenti originali

Componenti di sicurezza

Safety Part

When repairing, use original part only

Pièce de securité

N'utilisez que les pièces d'origine

CP483

STP22NF03L

COLD

HOT

845R0

RP483

RP484

10N0F

IP201

TL431

To LP008 PFC coil (Europe)

connector

mains

Universal

T# 21371920

NEUTRAL

EARTH

LIVE

6V

P

FZP203

6VA

T13,15A_125V

20V

2K1

2K2

CP485

RP417

GND GND

TP203

STP22NF03L

6.5V

CP203

C

DP203

A2 A1

STPS30150CT

GND

2N2

CP215

H

BP008B

BP008A

WP235A

10M

RP225

*

FROM MAINS CORD

FZP201

T13,15A_125V

P

10N0F

CP202

1500uF/35V

1500uF/35V

JP201

GND

GND

BP251A

BP251B

4V

SR560

DP218

DP201

SR560

6K2

RP419

IP203

GND GND

RAW_B+

TL431

CP201

3k92

RP418

GRAY

BLACK

CP255

DP252

CP254

DP253

*

1MI0

220uF

CP208

BP226C

1

2

BP226A

1N5

GP30M

1N5F

GP30M

CP251

BP006B°

100N0

CP250
*

GNDGND

GND

RP404

GND

TO DVD

INTERFACE

BP226

*

CP259

CP258
*

CP256

100N0

470K

RP251
*

3

4

LP250

23MH

*

5VSTBY

P

FZP208

T1,0A_125V

10.5V

2K2

TP202

STP22NF03L

10.5V

1

2

RED

BP226B

1

GND

2

47uF

HH

270uF

1N5

DP255

GP30M

DP254

GP30M

H

BP006A°

2

1

6V2

DP260

220uF

CP207

5VE

2K43

RP415

10N0F

CP484

IP202

TL431

SMPS 100G°

FP251

T2.5AL_250V (europe)

T5,0AL_125V (US)

T5,0AL_250V (plasma)

10V

POWER_FAIL

JP416

TO FAN MODULE

GND

2

DP416

BZT55C3V3

DP415

BZT55C3V3

BP204

JP415

BP203

CP209

220uF

1

*

RP448

2

GND

1

7

DP24

RGP15G

GND

RP416

GND

GND

GND

2K1

20V

GND

TP204

STP22NF03L

DP204

FZP204

LP253

SMT_P50

2K2

RP413

DP414

BZT52C8V2

SMPS 100 IFC228

GND

10N0F

CP486

GND

10K

RP414

CP204

1MI0

GND

SR560

P

3.15A

GND

1112131415

4

5

621

710

89

H

3U3H

LP225

CP226

330P0

DP225

DP226

RGP10G

RGP10G

V_PRI

470P0

RP495

DP227

CP493

22K0

BZX55B24

RP258

180K

RP257

180K

VCC1

22U0

CP225

22U0

CP224

BP400

(EUROPE ONLY)

PUSH SWITCH MODULE

SP400

15K

4u7F

CP247

20V

TP204

STP22NF03L

3

RP294

DP493

H

H

H

GND

RP412

CP486

RP413

2

10K0

BZT52C8V2

TP495

BC858B

RP227

18K0

10N0F

2K2

3K3

16

1

CP237

RP293

RP414

IP214

1N5

22K0

3K92

TL431XX

GND

CP239

DP237

1

BP253

LP220

2

CP220

20V

JP420

CP210

22uF

TP205

KTC8550D

3K9

RP485

GND

SMPS 100G IFC228

RP205

390R/2W

20.5V

22uF

CP205

DP205

RGP15G

P

FZP205

T0,5A_125V

20.5V

180P0

CP438

180P0

H

BAV21

470R0

RP238

JP453

2

MODULE

SWITCH

TO MAIN

22R0

RP221

1U5H

1

H

6N90

TP220

(EU)

1n5

GND

4K7

RP209

45.0V

DP206

RGP15G

FZP206

T0,5A_125V

RP467

2K7

DP240

BZX55B27

47K0

RP441

TP223

2K2

RP492

(US)10N60

33V

RP208

GND

CP236

P

1

4

2K2

RP240

10U0

CP240

KTC8550D

DP233

BZX55B15

47K0

RP233

1nF

CP233

3K3

10uF

RP468

A

5K6

C

IP251

DP230

RP230

RP231

2K2

RP207

TP407

BC848B

GND

10.5V

6.5V

K

23

E

TCET1103G

BZX55C8V2

H

1K0

10R0

PO

22U0

CP271

2K2

RP473

2K2

RP472

DP471

20.5V

22K0

RP471

RP486

22K0

GNDGND GND

1N5

CP281

5VSTBY

10K

RP465

RP466

4K7

DP261

8V2

RP464

2K2

RP463

TP261

BC548

6K2

RP461

CP268

RP226

RP228

GND

2n2

3K92

RP462

GND

IP261

TL431

* VALUE MAY CHANGE ACCORDING

TO SPECIFIC REQUIREMENT

CP222

2K7

22R0

TP222

BC548B

0R68

RP220
*

6.5V

33K

RP476

100K

RP475

IP271

TL431

22K0

RP474

DP472

BZT52C4V7

BZT52C3V9

TP271

BC548B

BAV21

DP273

2K2

RP470

BURST

100R

2K2

RP469

10N

CP261

GND

CCT_DIAG_SMPS_100/100G_IFC228

470P0

H

Attenzione :

misure nell'alimentatore primario

- usare massa alimentazione primario (H).

H

H

Cuidado :

Note :

Power Supply primary circuit measurements.

- Use only (H) connection point.

Attention :

GND GND GND GND

Use isolating mains transformer.

Utiliser un transformateur isolateur du secteur.

Einen Trenntrafo verwenden.

Utilizar un transformador aislador de red.

Utilizzare un transformatore per isolarvi dalla rete.

Part of board connected to mains supply.

Partie du châssis reliée au secteur.

Primärseite des Netzteils.

Parte dello châssis collegata alla rete.

Parte del chassis conectar a la red.

Medida en el bloque de alimentacion

- Utilizar la masa del bloque de alimentacion (H).

Achtung :

Bei Messungen im Primärnetzteil

- Primärnetzteilmasse verwenden (H).

Mesure dans la partie primaire de l'alimentation

- Utiliser la masse du bloc alimentation (H).

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

IFC228-LCD

First issue 08 / 04

BP001

board

signal

To

10

BP220=>BP001

6V

6V

20V

10V

GND

GND

GND

+UA

123456789

33V

5VSTBY

+VSSIN

3.3VSTBY

BP002

board

signal

To

8

BP220A=>BP002

1234567

PO

GND

GND

BURST

SAFETY#

ECO_STBY#

POWER_FAIL

JP452

BURST

-UA

JP451

scaler

board

To

12345

6

BP222=>BX007

4V

GND

GND

VBRI

VON/OFF

scaler

board

To

BP222

123456789

6V

4V

GN

GN

VBRI

VON/OFF

Inverter

board

VBRI

VON/OFF

To

4

BP321

+UA

101112

GNGNGN

GND

Audio

GND

board

123

-UA

Inverter

board

To

12345

6

6VA

BP320

+VSSIN

+VSSIN

VBRI

VON/OFF

GND

GND

To

BP320

123456789

GN

JP42 6

JP42 5

+VSSIN

+VSSIN

+VSSIN

VSEL

JP50 1

COL D

CP382

1500uF/35V

14NK50

RP521

CP381

A2 A1

4

RP324

39R

RP323

10K0

L6598

IP300

1500uF/35V

GND

3

10K0

DP324

(PREP)

H

DP372

BYW98-200

RP327

GND

GND

P

3.15A

FZP391

15

16

1

2

RP328

R100/3W

DP328

(PREP)

1K

22uF

CP328

1000uF/25V

CP371

GND

P

FZP371

T3,15A-125V

JP301

C

DP391

LP300

SMT_P200

HOT

TP322

14NK50

RAW_B+

DP325

RGP10G

22uF

CP302

H

110K

RP515

RP504

3K92

15K

RP503

DP381

DP371

BYW98-200

BYW98-200

89

RP325

CP325

10

7

10K0

RP326

(PREP)

DP326

39R

100nF

16

V+

VCC

OUT

ImaxINIS

1234567

GND

GND

11

6

DP323

1112131415

RO

GND

GND

STPS30150CT

121314

5

TP321

RGP10G

10

9

C1

CO

C2SE

8

SMPS_100G_IFC228

CP391

1000uF/25V

GND

DP392

BYW98-200

*

16N8

CP322

16N8

CP321

*

H

HH

10V

6VA

26K7

RP553

0R

RP555

3K9

RP551

100n

CP551

3K3

RP552

1

23

TL431

K

A

IP351

IP310

TCET1103G

H

H

56K

RP512

HH

E

C

4

2n2F

CP512

RP554

3K92/1%

6VA

4V

GND

2K2

RP361

GND

IP302

TCET1103G

+VSSIN

CCT_DIAG_SMPS_100_IFC228

CCT_DIAG_SMPS_100G_IFC228

* VALUE MAY CHANGE ACCORDING TO SPECIFIC REQUIREMENT

DP361

BZX55B24

4K7

RP562

10K0

RP563

GND

TP361

BC548B

GND

1

23

K

A

E

C

4

H

POWER SUPPLY - ALIMENTATION - NETZTEIL - ALIMENTAZIONE - ALIMENTACIÓN

TP302

STP22NF03L

DP301

FZP301

V_PRI

RGP10G

P

T0,5A-125V

RP302

CP301

10N0F

CP503

TL431

IP303

H

3K9

22K

RP301

H

22uF

TP303

BC548B

H

4u7

CP315

27K

RP517

680pFCP516

39K

RP511

33K

RP519

4K3

RP516

CP518

RP510

100nF

H

5K1

IFC228-LCD

First issue 08 / 04
