Thomson 28021EE1 Instruction

IntroductIon

CAUTION: When using telephone equipment, there are basic safety instructions that should always be followed. Refer to the IMPORTANT SAFETY INSTRUCTIONS provided with this product and save them for future reference.

IMPORTANT: Because cordless phones operate on electricity, you should have at least one phone in your home that isn’t cordless, in case the power in your home goes out.

NOTE: This unit only supports tone dialing, it does not support pulse dialing.

Before You BegIn

Parts Checklist

(for 28021xx1 model)

Make sure your package includes the items shown here.

ABC

DEF

GHI JKL MNO

PQRS

TUV WXYZ

EXIT

OPER

PAUSE

Model 28021 SerIeS

5.8 gHz cordleSS HandSet SpeakerpHone SYSteM uSer’S guIde

quIpMent approval InforMatIon

Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment published by ACTA.

1 Notiﬁcation to the Local Telephone Company

On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information to your telephone company. The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of devices you may connect to your line as determined by the REN, you should contact your local telephone company. A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details.

Notes

• This equipment may not be used on coin service provided by the telephone company.

• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you are on a party line. Check with your local telephone company.

• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line.

• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this product does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualiﬁed installer.

US Number is located on the cabinet bottom.

REN Number is located on the cabinet bottom.

2 Rights of the Telephone Company

Should your equipment cause trouble on y our line which may harm the telephone network, the telephone company shall, where practicable, notify you that temporary discontinuance of service may be required. Where prior notice is not practicable and the circumstances warrant such action, the telephone company may temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.

4. Insert the battery pack.

5. Close the battery compartment by pushing the door up until it snaps into place.

Base Station

1. Choose an area near an electrical outlet and a telephone wall jack (RJ11C), and place your cordless telephone on a level surface, such as a desktop or tabletop, or you may mount it on the wall.

2. Plug one end of the telephone line cord into the TEL LINE jack on the bottom of the base and the other end into a modular jack.

Programming Functions

The system uses a menu structure to give you access to all of the built-in features. You may program the following items in main menu: Room Monitor and Handset Setup.

Room Monitor (applicable only with additional handsets)

1. Make sure your phone is OFF (not in talk mode).

2. Press the MUTE/PROG button to go to the main menu.

3. Press CALLER ID-VOLUME ( 6 or 5) button to scroll to ROOM MONITOR.

4. Press MUTE/PROG button to enter ROOM MONITOR menu, ROOM MONITOR EXTENSION? shows in the display.

Area Code

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the AREA CODE sub-menu.

2. Press MUTE/PROG button to enter the menu. SET AREA CODE - - - shows in the display. The default setting is - - -.

3. Use the touch-tone pad to enter your 3-digit area code.

4. Press the MUTE/PROG button to conﬁrm. You will hear a conﬁrmation tone and the new area code shows in the display.

NOTE: To restore the default setting to - - -, press and release DELETE when SET AREA CODE shows in the display.

Registration

Your packaged handset(s) are pre-registered and ready to use. It is not recommended that a handset be registered again unless absolutely necessary.

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the REGISTRATION sub-menu.

2. Press the MUTE/PROG button to enter the menu. REGISTRATION 1YES 42NO - - - shows in the display The default setting is 2NO.

3. Use the touch-tone pad to select 1 for YES or 2 for NO. Or use the CALLER ID-VOLUME ( 6 or 5 button to scroll to 1YES or 2NO.

4. If you select 1YES, press the MUTE/PROG button to conﬁrm your selection. HOLD BASE PAGE WAIT FOR BEEP shows in the display. (Your handset should be held near the base during registration process.)

5. Press and hold the page button on the base unit until you hear a tone at the handset. HANDSET X REGISTERED shows in the handset display, where X is the handset number. You may now rename your handset. (Refer to Step 3 & 4 of Handset Name Section)

De-Registration

De-registration cancels registration. During the de-registration process, keep the handset near the base.

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the DEREGISTRATION sub-menu.

2. Press the MUTE/PROG button to enter the menu. DEREGISTRATION 1YES 42NO - - - shows in the display The default setting is 2NO.

3. Use the touch-tone pad to select 1 for YES or 2 for NO. Or use the CALLER ID-VOLUME ( 6 or 5) button to scroll to 1YES or 2NO.

WARNING: It is not recommended that a handset be de-registered unless absolutely necessary because once a handset is de-registered, that handset’s telephone features cannot be used until the handset is re-registered.

4. Select NO, if you do not want to de-register.

5. If you select 1YES, press the MUTE/PROG button and MOVE NEAR TO BASE displays for 2 seconds, then CONFIRM? 1YES 2NO appears in the display.

6. Press the touch-tone pad to select 1YES or 2NO, or use the CALLER ID-VOLUME ( 6 or 5) button to scroll to 1YES or 2NO.

7. If you select YES, press the MUTE/PROG button to conﬁrm. You will hear a conﬁrmation tone. Then HANDSET X DEREGISTERED shows in the display to conﬁrm the handset is deregistered.

NOTE: When you complete the de-registration process, HANDSET NEEDS REGISTRATION shows in the display. To use the handset,

you MUST re-register the handset using the Registration process.

Global De-registration (applicable only with additional handsets)

If one or more handsets becomes lost, you should de-register all handsets to ensure proper system operation. Follow the steps below to de-register all handsets at the same time.

1. Press and hold the page button on the base until the CHARGE/IN USE indicator on the base ﬂashes.

2. Press and hold the page button on the base again until the CHARGE/IN USE indicator on the base ﬂashes rapidly.

3. Press and release the page button on the base once. All handsets are de-registered and HANDSET NEEDS REGISTRATION shows in the display.

Default Setting

As you become familiar with this system, you may prefer to use the system’s original settings. Follow the steps below to return to the factory default settings.

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the DEFAULT SETTING sub-menu.

2. Press the MUTE/PROG button to enter the menu. DEFAULT SETTING 1YES 2NO shows in the display. The default setting is 2NO.

3. Use the touch-tone pad to select 1YES or 2NO, or use the CALLER ID-VOLUME ( 6 or 5) button to move the cursor to 1YES or 2NO.

Thomson Inc.

10330 North Meridian St.

Indianapolis, IN 46290-1024

Trademark(s) ® Registered

Marca(s) Registrada(s)

Model 28021 00007425 (Rev. 2 Dom E) 07-06 Printed in China

Modular

telephone

line jack

Wall plate

SE E M ARK ING ON BO TTO M / BA CK OF PRO DUC T

RISK OF ELECTRIC SHOCK DO NOT OPEN

WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

THE LIGHTNING FLASH AND ARROW HEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU OF “DANGEROUS VOLTAGE” INSIDE THE PRODUCT.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

THE EXCL AMATION POINT W ITHIN THE TRIANGL E IS A WARNING S IGN ALERTIN G YOU OF IMPORTANT INSTRUC TIONS ACCOMPANYI NG THE PRO DUCT.

CAUTION:

Base

Handset

Belt clipTelephone line cordAC power adaptor

Handset

battery pack

Battery compartment

cover

NOTE: If you choose YES all the settings in the programmable menu are returned to factory default setting.

4. Press the MUTE/PROG button to save your selection. You will hear a conﬁrmation tone.

Telephone Operation

Charge/In Use Indicator

The phone is ON when the LED indicator on the handset and the CHARGE/IN USE indicator on the base is lit. The handset and base indicators ﬂash when you receive a call.

Speakerphone Operation

NOTE: If you are using the speakerphone, remain close to handset so the party you are speaking to can hear you.

If you are using the handset and want to switch to the speakerphone, press the SPEAKER button, press SPEAKER again to end conversation.

If you are using the speakerphone and want to switch to the handset, press the TALK/ CALL BACK button, press TALK/CALL BACK again to end conversation.

Making a Call

1. Press the TALK/CALL BACK or SPEAKER button. Dial the desired number.

- OR Dial the number ﬁrst, then press the TALK/CALL BACK or SPEAKER button.

- OR Press the CALLER ID-VOLUME ( 6 or 5) button to select the desired record, then press the

TALK/CALL BACK or SPEAKER button

2. When ﬁnished, press the TALK/CALL BACK or SPEAKER button to hang up.

NOTE: You may enter up to 32 pre-dial digits. NOTE: If you want to delete the pre-dial number you entered, press the

DELETE button until all of the digits are erased.

Answering Calls

1. When the phone rings, press the SPEAKER button on the handset

- OR -

pick up the handset and press the TALK/CALL BACK button.

2. When ﬁnished, press SPEAKER or TALK/CALL BACK to hang up.

NOTE: Adjust the handset volume by pressing the

CALLER ID-VOLUME

( 6 or 5)

button during a call.

Call Timer

After you press the TALK/CALL BACK button on the handset, the built-in call timer shows on the display and counts the length of time of the call in minutes and seconds.

Auto Standby

If you place the handset in the cradle while the handset is off the hook (during a call), the call is automatically disconnected.

Ringer HI/LOW/OFF (Shortcut)

There are two ways to set the ringer to HI/LOW/OFF. One is the traditional way as described in the Programming Functions; Handset Setup; Ringer Volume menus. The other one is this short cut to ringer menu.

1. Make sure the phone is OFF (not in talk mode).

2. Press the #PAUSE/RINGER button to display 1HI 2LOW 3OFF.

3. Use the touch tone pad on the handset to select 1, 2 or 3, or use the CALLER ID-VOLUME ( 6 or 5) button to scroll to your selection. HI is the default setting.

4. Press #PAUSE/RINGER button again to save and display the new selection for a few seconds.

Flash/Call Waiting

If you subscribe to the combined Call Waiting Caller ID service from your local telephone company, you will receive Caller ID information (if available) on Call Waiting calls. During a phone call, you will hear a beep to indicate another call is waiting on the line and Caller ID information for the waiting call shows on the handset display.

• To connect to the waiting call, press the FLASH button on the handset, and your original call is put on hold.

• To switch between the two calls, press the FLASH button.

TIP: Do not press the TALK/CALL BACK button on the handset to activate a custom calling service, such as call waiting, or call will disconnect.

The telephone company may make changes in its communications facilities, equipment, operations or procedures where such action is required in the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes are expected to affect the use or performance of your telephone equipment, the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.

Interference InforMatIon

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

Privacy of Communications may not be ensured when using this product. If this equipment does cause harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the interference).

• Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.

• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected.

If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet, “How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S. Government Printing Ofﬁce, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies.

Notice: The changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

HearIng aId coMpatIBIlItY (Hac)

This telephone system meets FCC standards for Hearing Aid Compatibility.

lIcenSIng

Licensed under US Patent 6,427,009.

fcc rf radIatIon expoSure StateMent

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.”

For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with the belt clip supplied with this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines.

display

TALK/CALL BACK

(button)

CALLER ID-VOLUME

down (button)

CALLER ID-VOLUME

up button)

DELETE

(button)

REDIAL (button)

*EXIT (button)

#PAUSE/RINGER

(button)

FLASH

(button)

FORMAT/CONF (format/

conference button)

MEMORY

(button)

SPEAKER

(button)

MUTE/PROG

(mute/program button)

Your new GE telephone system is EXPANDABLE

up to a total of 4 handsets (by purchase of optional

Model 28001 handset with charge cradle)

Wall mount

bracket

For Model 28021xx2 there will be ONE additional handset, charge cradle, belt clip, battery pack and cover than shown above.

For Model 28021xx3 there will be TWO additional handsets, charge cradles, belt clips, battery packs and covers than shown above.

For Model 28021xx4 there will be THREE additional handsets, charge cradles, belt clips, battery packs and covers than shown above.

Telephone Jack Requirements

To use this phone, you need an RJ11C type modular telephone jack, which might look like the one pictured here, installed in your home. If you don’t have a modular jack, call your local phone company to ﬁnd out how to get one installed.

InStallatIon

Digital Security System

Your cordless phone uses a digital security system to protect against false ringing, unauthorized access, and charges to your phone line.

INSTALLATION NOTE: Some cordless telephones operate at frequencies that may cause or receive interference with nearby TVs, microwave ovens, and VCRs. To minimize or prevent such interference, the base of the cordless telephone should not be placed near or on top of a TV, microwave ovens, or VCR. If such interference continues, move the cordless telephone farther away from these appliances.

Certain other communications devices may also use the 5.8 GHz frequency for communication, and, if not properly set, these devices may interfere with each other and/or your new telephone. If you are concerned with interference, please refer to the owner’s manual for these devices on how to properly set channels to avoid interference. Typical devices that may use the 5.8 GHz frequency for communication include wireless audio/video senders, wireless computer networks, multihandset cordless telephone systems, and some long-range cordless telephone systems.

Important Installation Guidelines

• Avoid sources of noise and heat, such as motors, ﬂuorescent lighting, microwave ovens, heating appliances and direct sunlight.

• Avoid areas of excessive dust, moisture and low temperature.

• Avoid other cordless telephones or personal computers.

• Never install telephone wiring during a lightning storm.

• Never install telephone jacks in wet locations unless the jack is speciﬁcally designed for wet locations.

• Never touch non-insulated telephone wires or terminals, unless the telephone line has been disconnected at the network interface.

• Use caution when installing or modifying telephone lines.

HandSet laYout

INTERCOM

(button)

InStallIng tHe pHone

Installing the Handset Battery

NOTE: You must connect the handset battery before use.

CAUTION: To reduce the risk of ﬁre or personal injury, use only the Thomson Inc. approved Nickel-metal Hydride (Ni-MH) battery model 5-2660, that is compatible with this unit.

1. Locate battery and battery door which are packaged together inside a plastic bag and are separate from the handset.

2. Locate the battery compartment on the back of the handset .

3. Plug the battery pack cord into the jack inside the compartment .

NOTE: To ensure proper battery installation, the connector is keyed and can be inserted only one way.

black wire

red wire

battery

pack

PRESS DOWN

FIRMLY

3. Plug the AC power adaptor into the electrical outlet and the DC connector into the jack on the bottom of the base.

4. Place the handset in the base cradle. The charge/in use indicator turns on, verifying the battery is charging.

5. Allow the phone to charge for 16 hours prior to ﬁrst use. If you don’t properly charge the phone, battery performance is compromised.

CAUTION: To reduce risk of personal injury, ﬁre, or damage use only the 5-2759 power adaptor listed in the user’s guide. This power adaptor is intended to be correctly orientated in a vertical or ﬂoor mount position.

Wall Mounting

1. Turn the base over.

2. Attach the wall mounting pedestal by ﬁrst inserting the tabs on the open edge of the pedestal into the slots on the lower portion of the bottom of the base. Then push down and snap the pedestal into place.

3. Slip the mounting holes (on the back of the base) over the wall plate posts, and slide the unit down into place. (Wall plate not included.)

NOTE : If desired, gather the extra telephone line and power adaptor cord and store inside the wall mounting bracket.

prograMMIng tHe telepHone

Standby Screen

The handset displays the handset number and user name.

Ringer Tone

You may choose from ten different ringer tones and ten different melodies.

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the RINGER TONE sub-menu.

2. Press MUTE/PROG button to enter the menu. SET RINGER TONE 01 shows in the display. The default setting is 01.

3. Use the CALLER ID-VOLUME ( 6 or 5) button to scroll to the desired setting (1 through 20). You will hear a sample of the ringer tone/melody you select.

4. Press the MUTE/PROG button to save your selection. You will hear a conﬁrmation tone and the selected ringer tone shows in the display.

NOTE: You must have the Ringer Volume set to ON for ring tone to signal an incoming call.

Ringer Volume

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the RINGER VOLUME sub-menu.

2. Press MUTE/PROG button to enter the menu. SET RINGER 41HI 2LOW 3OFF shows in the display. The default setting is HI.

Use the touch tone pad on the handset to select 1, 2 or 3, or use the CALLER ID-VOLUME ( 6 or 5) button to scroll to your selection. 4. Press the MUTE/PROG button to save your selection. You will hear a conﬁrmation tone and the new volume setting shows in the display.

NOTE:

If you turn the ringer OFF, the ringer off icon shows in the display.

VIP Melody

This feature allows you to assign a speciﬁc melody to someone you want to get your attention when the person calls. When a VIP melody is assigned and that person calls, the unit rings the normal ring for the ﬁrst ring and then follows with VIP melody ring. You may choose from ten different polyphonic melodies and may store up to 10 VIP records.

NOTE:

This feature ONLY works when the following conditions are met.

1. You have subscribed to Caller ID.

2. You have your Caller ID record previously transferred to the memory. (Refer to Storing CID Records in Internal Memory). NO USER MEMORY will show in the display to remind the user to do CID record transfer ﬁrst.

Storing VIP Melody

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to VIP MELODY sub-menu.

2. Press MUTE/PROG button to select VIP MELODY feature and then display VIP 1 record.

- If VIP1 does NOT contain any speciﬁc number/records, it will display **EMPTY**.

3. Press CALLER ID-VOLUME ( 6 or 5) button to select the speciﬁc VIP melody memory location (10 VIP locations) that does not contain any record.

4. Press MUTE/PROG button to display SELECT MEMORY.

NOTE: If the memory location does not contain any CID memory records and you are trying to mark a speciﬁc record as VIP MELODY, then SELECT MEMORY will not be displayed. Instead, NO USER MEMORY will display in prompt to alert the user.

Press CALLER ID-VOLUME ( 6 or 5) button to view the records from memory to be selected as VIP

6. Press MUTE/PROG button to conﬁrm and then display VIP MELODY 01 to wait for the melody tone selection.

7. Press CALLER ID-VOLUME ( 6 or 5) button to select from melody 01 to melody 10 (a testing tone is generated while making melody selection)

8. Press MUTE/PROG button to conﬁrm.

NOTE: If the desired number/record was previously stored in any one of the ten VIP melody records, DUPLICATE NUMBER shows in the display.

Changing a Stored VIP Melody Record

Use the Storing VIP Melody procedure to change the number of a selected record and replace the old phone number with new phone number.

When REPLACE VIP# ? shows in the display, you must press MUTE/PROG button on the handset to conﬁrm replacement.

Reviewing And Deleting Stored VIP Melody Record

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to VIP MELODY sub-menu.

2. Press MUTE/PROG button to select VIP MELODY feature and then display VIP 1 record.

3. Use the CALLER ID-VOLUME ( 6 or 5) button to scroll to the desired VIP Melody Record.

4. If you want to delete the information, press the DELETE button on the handset while the entry displays. The display shows DELETE VIP# ?.

5. Press DELETE again to conﬁrm. You will hear a conﬁrmation tone and VIP# DELETED shows in the display.

Key Tone

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the KEY TONE sub-menu.

Press MUTE/PROG button to enter the menu. SET KEY TONE 41ON 2 OFF shows in the display. The default setting is 1ON.

3. Use the touch tone pad on the handset to select 1 or 2, or use the CALLER ID-VOLUME ( 6 or 5) button to scroll to your selection.

4. Press the MUTE/PROG button to conﬁrm and the key tone setting shows in the display.

USER NAME

HANDSET X

> ROOM MONITOR

HANDSET SETUP

5. Use the touch tone pad to enter the handset number to be monitored, either 1 or 2.

NOTE: When this phone system is expanded (up to 4 handsets by purchase of optional Model 28001 handset with recharge cradle), handsets are named HANDSET 1, HANDSET 2, HANDSET 3 and HANDSET 4 respectively.

6. The receiving handset will turn on the microphone and the originating handset will turn on the speakerphone to monitor sound from the receiving handset.

NOTE: For room monitoring mode to work, the originating handset must NOT be on the cradle.

NOTE: While in room monitoring mode, the handsets will emit an alert tone approximately every 5 seconds if there is an incoming call. You may press the SPEAKER button to quit room monitor and answer the call.

NOTE: While in room monitoring mode, the originating handset can be switched to monitor by handset earpiece by pressing the TALK/ CALL BACK button once. Switch back to speakerphone by pressing the SPEAKER button once.

NOTE: Press the *EXIT button on the handset to exit room monitor mode.

Handset Setup

1. Make sure your phone is OFF (not in talk mode).

2. Press the MUTE/PROG button to go to the main menu.

3. Press CALLER ID-VOLUME ( 6 or 5) button to scroll to HANDSET SETUP.

4. Press MUTE/PROG button to conﬁrm and you may program the following items: Language, Handset Name, Ringer Tone, Ringer Volume, VIP Melody, Key Tone, Area Code, Registration, Deregistration and Default Setting.

NOTE: During programming, you may press the *EXIT button at any time to exit the sub-menu and return to the menu.

Language

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the SET LANGUAGE sub-menu.

2. Press MUTE/PROG button to enter the menu. SET LANGUAGE 41ENG 2FRA 3ESP shows in the display. The default setting is 1ENG.

3. Use the touch tone pad on the handset to select 1ENG, 2FRA, 3ESP, or use the CALLER IDVOLUME ( 6 or 5) button to scroll to the desired language.

4. Press the MUTE/PROG button to save your selection. You will hear a conﬁrmation tone and the selected language shows in the display.

Handset Name

From the Handset Setup Menu:

1. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the HANDSET NAME sub-menu.

2. Press MUTE/PROG button to enter the menu. HANDSET NAME shows in the display. The default setting is HANDSET #.

3. Use the touch-tone pad to enter a name (up to 15 characters). More than one letter is stored in each of the number keys. For example, to enter Bill Smith, press the 2 key twice for the letter B. Press the 4 key 3 times for the letter I. Press the 5 key 3 times for the letter L. Press the 5 key 3 times for the second letter L, and press the 1 key to insert a space between the ﬁrst and last name. Press the 7 key 4 times for the letter S; press the 6 key once for the letter M; press the 4 key 3 times for the letter I; press the 8 key for the letter T; press the 4 key twice for the letter H.

NOTE: If you make a mistake, use the DELETE button to backspace and delete one character at a time.

4. Press the MUTE/PROG button to save your name. You will hear a conﬁrmation tone and the handset name shows in the display.

LED

(indicator)

Last Number Redial

You may redial a number up to 32 digits long. To quickly redial the last number you dialed:

1. Press the TALK/CALL BACK button.

2. Press the REDIAL button.

-OR-

3. Press the REDIAL button ﬁrst, then use the CALLER ID-VOLUME ( 6 or 5) button to select the desired redial number.

- Press the CALLER ID-VOLUME ( 5) to review the oldest call and scroll toward the most recent calls (higher numbers).

- Press the CALLER ID-VOLUME ( 6 ) to review the newest call and scroll to older calls (lower numbers).

NOTE: You may choose from three last dialed numbers.

4. Press the TALK/CALL BACK button. The number dials automatically.

If you get a busy signal and want to keep dialing the number, press the REDIAL button to quickly redial the number.

Exit

Press the *EXIT button to exit a menu function and return to the standby screen.

Page

The page feature helps you locate a misplaced handset. To send and receive pages, all handsets must be registered. If your handset is not registered, follow the instructions in the Registration section of this manual.

Handset Paging

(applicable only with additional handsets)

1. Make sure the phone is OFF (not in talk mode).

2. Press and release the INTERCOM button on a handset. PAGING EXTENSION? shows in the display.

3. Use the touch-tone pad to enter the handset number you want to page. (1= to page Handset 1, 2=to page handset 2, etc., and 5=to page all handsets)

4. To cancel the page, press the *EXIT or INTERCOM button on the receiving handset, or you may press TALK/CALL BACK on the originating handset.

Base Paging

Use the base-only to page all registered handsets at the same time.

1. Press the page button on the base. All handsets beep for two minutes, and PAGING FROM BASE shows on each handset’s display.

2. To cancel the page, press the page button on the base, or press the TALK/CALL BACK button or the *EXIT button on each handset.

Mute

To have a private, off-line conversation, use the MUTE feature. The party on the telephone line cannot hear you, but you can hear them.

1. Press the MUTE/PROG button. The handset display shows MUTE ON.

2. Press the MUTE/PROG button to cancel and return to your phone conversation.

Receiver Volume Control

When the handset is ON (in talk mode) you may adjust the receiver volume by pressing the CALLER ID-VOLUME ( 6 or 5) button. There are four volume levels to choose from. When the maximum or minimum volume level is reached, the phone beeps twice. VOL 1 is minimum and VOL 4 is maximum.

Do Not Disturb (DND)

DND allows you to mute the ringer on all handsets. In the standby mode, press the DO NOT DISTURB button on the base. The DND indicator will

light and DO NOT DISTURB shows in handset display. To cancel, press the DO NOT DISTURB button again.

Intercom Operation

(applicable only with additional handsets)

The intercom feature allows you to have a conversation with another registered handset without tying up the telephone line, allowing you to still receive incoming calls.

Making an Intercom Call

1. Make sure the handset is OFF (not in talk mode).

2. Press the INTERCOM button on the handset.

3. Use the touch-tone pad to select the handset you want to page.

NOTE: To cancel page, press the INTERCOM button again or the *EXIT button on the sending handset.

4. Wait for the person at the receiving handset to press the INTERCOM button.

NOTE: If the receiving handset does not answer within two minutes, the intercom call is automatically canceled. The originating handset displays NO ANSWER.

ABC

DEF

GHI JKL MNO

PQRS

TUV WXYZ

EXIT

OPER

PAUSE

PAGE

(button)

CHARGE/IN USE

(indicator)

DO NOT

DISTURB

(button)

BaSe laYout

HANDSET NEEDS Indicates you must register a non-registered handset prior to REGISTRATION use.

INCOMPLETE DATA Caller information is interrupted during transmission or the

phone line is excessively noisy.

LINE IN USE Displays on handset while the line is in use. LONG DISTANCE Indicates CID record is from a long distance call. LOW BATTERY Indicates the battery needs to be charged. MESSAGE WAITING Indicates voice mail has not been retrieved from service provider. MSG WAITING OFF Indicates voice mail has been retrieved from service provider. NEW CALL XX XX represents the number of new CID records not reviewed. NO BATTERY Indicates the battery is not properly installed in the handset,

or the battery pack is not properly connected to the jack inside the battery compartment.

NO CALLS Indicates there are no CID records in memory. NO DATA Indicates no CID information was received , you are not

subscribed to CID service, or CID service is not working. NO USER MEMORY

Indicates the memory location contains no user memories and the user is trying to mark a speciﬁc user record for VIP MELODY.

OUT OF RANGE Indicates handset is too far away from the base. Move closer to the base.

ROOM MONITORING.... The audio link between handsets is established.

PAGING or Someone pressed the PAGE button on the base or INTERCOM PAGING FROM

button on the handset

REPT Indicates a repeat call message. Indicates a new call from the same number was received more than once.

SEARCHING Indicates handset is searching for the base. SPKR Indicates the handset is in speakerphone mode. UNKNOWN CALLER/ Indicates incoming call is from an area not serviced by CID or

NAME/NUMBER

the CID information was not sent.

Handset Sound Signals

Signal Meaning

A long warbling tone (with ringer on) Signals an incoming call Three short beeps (several times) Page signal One beep every 7 seconds Low battery warning

Troubleshooting Guide

Telephone Solutions

No dial tone

• Check or repeat installation steps: Make sure the base power cord is connected to a working electrical outlet. Make sure the telephone line cord is connected to the base and the wall jack.

• Connect another phone to the same jack. If it doesn’t work, the problem might be your wiring or local service.

• The handset may be out of range of the base. Move closer to the base.

• Make sure the battery is properly charged (for 16 hours).

• Make sure the battery pack (in the handset) is properly installed.

• The handset should beep when you press the TALK/CALL BACK button, and the charge indicator on the base should be lit when the handset rests in the cradle. If not, the battery may need to be charged.

• Place handset in charge cradle for at least 20 seconds to reset the unit.

Handset does not ring

• Make sure the handset ringer software switch is set to on.

• The handset may be out of range of the base. Move closer to the base.

• You may have too many extension phones on your line. Try unplugging some extensions.

• Check for a dial tone.

You experience static, noise, or fading in and out

• The handset may be out of range of the base. Move closer to base.

• Make sure base is not plugged into an electrical outlet with another household appliance. If necessary, relocate the base.

• Charge the battery (for 16 hours).

Unit beeps

• Clean the charging contacts on the cordless handset and base charge cradle with a soft cloth or an eraser.

• See solutions for “No dial tone ” on previous page.

• Replace the battery.

Memory dialing doesn’t work

• Did you program the memory location keys correctly?

5. When ﬁnished, press the *EXIT button or INTERCOM button on either handset to deactivate the intercom.

NOTE: The system is expandable up to 4 handsets (by purchase of optional Model 28001 handset with recharge cradle). When 4 handsets are registered, the system can handle 2 separate intercom operations at once, for example, 1st handset intercoms with 2nd handset while 3rd handset intercoms with 4th handset.

Receiving an Intercom Call

When you receive an intercom call, your handset beeps. To answer the call press the INTERCOM button or TALK/CALL BACK button.

Advanced Intercom Features

Receiving an Incoming Call During an Intercom Call

If you receive a telephone call during an intercom call, the intercom call is immediately terminated and both handsets ring. Either handset user may press the TALK/CALL BACK button to answer the call.

Using Intercom with External Telephone Calls

During a telephone call, you may use the intercom/paging function to page another handset and have an off line, private (two-way) intercom conversation. You may also have a three-way conversation between the external caller and the handsets, or you may transfer the external telephone call to another handset.

NOTE: Before you intercom/page another handset, you must decide whether you want to create a two-way or a three-way conversation.

Two-Way Calling

1. During an external call, press the INTERCOM button, and use the touch-tone pad to enter the handset number you want to call.

NOTE: The receiving handset presses the INTERCOM button to answer the intercom call. Both intercom users may speak privately. The external caller will not hear the intercom conversation.

2. When ﬁnished, press the *EXIT button or INTERCOM button to end the intercom call, return to the talk mode, and resume your original telephone conversation.

Three-Way Calling

1. During an external call, press the INTERCOM button. LINE ON HOLD EXTENSION? shows in the display.

2. Use the touch-tone pad to select Handset #. You will hear a paging tone and PAGING shows in the originating handset’s display.

NOTE: PAGING FROM... shows in the display on the receiving handset, and the receiving handset presses the INTERCOM or TALK/CALL BACK button to answer the intercom.

3. When the receiving handset connects, press the FORMAT/CONF button on the originating handset to conference with the receiving handset and the external caller. CONFERENCE shows in the display on the originating and receiving handsets.

NOTE: A handset can enter conference mode directly by pressing TALK/ CALL BACK on the second handset during a call.

Transferring External Calls to Other Handsets

During an external call, you may transfer the external call to another handset.

1. Press the INTERCOM button on the originating handset to put an external call on hold, and then page the receiving handset.

2. Use the touch-tone pad on the handset to select Handset #. You will hear a paging tone. PAGING shows on the originating handset’s display, and PAGING FROM... shows on the receiving handset’s display.

3. When the receiving handset connects, press the TALK/CALL BACK button on the originating handset to transfer the call.

-OR-

4. Press the TALK/CALL BACK button on the originating handset to transfer the call. If the receiving handset does not answer within 30 seconds, the originating handset rings back and displays CALLBACK. If the originating handset does not answer within 20 seconds, the call is automatically dropped.

caller Id (cId)

IMPORTANT: In order to use this unit’s Caller ID features, you must subscribe to either the standard Name/Number Caller ID Service or Call Waiting Caller ID Service. To know who is calling while you are on the phone, you must subscribe to Call Waiting Caller ID Service.

This unit receives and displays information transmitted by your local phone company. This information can include the phone number, date, and time; or the name, phone number, date, and time.

Storing the Last Number Dialed

You may transfer all three redial numbers into internal user memory.

1. Make sure the phone in OFF (not in TALK mode).

2. Press REDIAL button to display the most recent redial number.

3. Use the CALLER ID-VOLUME ( 6 or 5) button to scroll to desired redial number.

4. Press MEMORY button to display SELECT MEMORY 01 - 50.

5. Use touch-tone pad to enter two digit desired memory location (01 through 50). Display will show ENTER NAME.

6. Follow step 5 in the “Storing a Name and Number in Memory” section to enter name.

NOTE: If the memory location is occupied, REPLACE MEMO? is displayed, and you must conﬁrm replacement by pressing the MEMORY button.

7. Press MEMORY button to save.

8. To enter another name and number in a different memory location, return to step 2 and repeat the process.

NOTE: If the redial number has more than 20 digits, it cannot be stored in memory.

Inserting a Pause in the Dialing Sequence (of a Stored Number)

Press the #PAUSE/RINGER button on the handset’s touch-tone pad to insert a delay in dialing sequence when a pause is needed to wait for a dial tone (for example, after you dial 9 for an outside line, or to wait for a computer access tone.) Each pause counts as one digit in the dialing sequence.

Reviewing Records Stored in Memory

1. Make sure the phone is OFF (not in talk mode).

2. Press the MEMORY button to display SELECT MEMORY 01-50.

3. Press the CALLER ID-VOLUME ( 6 or 5) buttons to scroll the records, or use the handset’s touch-tone pad to enter the memory location number.

Changing Records Stored in Memory

Follow the procedure for Storing Names and Numbers in Memory, except replace a stored telephone number with a new one.

Deleting Records Stored in Memory

1. Make sure the phone is OFF (not in talk mode).

2. Press the MEMORY button to display SELECT MEMORY 01-50.

3. Press the CALLER ID-VOLUME ( 6 or 5) button to scroll to the record you want to delete or use the touch-tone pad to enter the desired memory location.

4. Press the DELETE button to mark the record for deletion. The display shows DELETE?

5. Press the DELETE button to delete the record. DELETED shows in the display.

NOTE: If you don’t want to change or delete a record, simply press the *EXIT button, or wait for one minute to exit the review mode automatically.

Dialing a Number from Memory

1. Make sure the phone is ON (in talk mode) by pressing the TALK/CALL BACK or SPEAKER button.

2. Press the MEMORY button to display MEMO # - -.

3. Use the touch tone pad to enter the memory location number. The number dials automatically.

-OR-

1. Make sure the phone is OFF (not in talk mode).

2. Press the MEMORY button to display SELECT MEMORY 01-50.

3. Press the memory location for the phone number you want to dial, or use the CALLER IDVOLUME ( 6 or 5) button to scroll to the number you want to dial.

4. Press the TALK/CALL BACK or SPEAKER button. The number dials automatically.

Chain Dialing from Memory

Use this feature to make calls from records stored in memory which require a sequence of numbers, such as a calling card number used for a frequently called long distance number. The following example shows how you can store each part of the dialing sequence and use chain dialing to make a call through a long distance service:

The Number For Memory Location

Long Distance Access Number 7 Authorization Code 8 Frequently called long distance number 9

1. Make sure the phone is ON (in talk mode) by pressing the TALK/CALL BACK or SPEAKER button.

2. Press the MEMORY button, and then press 07.

3. When you hear the access tone, press the MEMORY button, and then press 08.

4. At the next access tone, press the MEMORY button and then 09.

Belt clIp and optIonal HeadSet

Connecting the Belt Clip

1. To attach the belt clip, insert the sides of the belt clip into the slots on each side of the handset.

2. Snap the ends of the belt clip into place.

Connecting an Optional Headset to the Handset

Each handset can be used with an optional headset hands free operation.

1. Connect the headset to the headset jack on the side of the handset. The handset receiver and microphone are disabled when the headset is connected.

2. Adjust the headset to rest comfortably on top of your head and over your ear. Move the microphone to approximately two to three inches from your mouth.

3. Press the TALK/CALL BACK button to answer a call or make calls using the headset.

4. To return to normal operation, unplug the headset from the jack.

cHangIng tHe BatterY

CAUTION: To reduce the risk of ﬁre or personal injury, use only the Thomson Inc. approved Nickel-metal Hydride (Ni-MH) battery model 5-2660, that is compatible with this unit.

1. Make sure the telephone is OFF (not in TALK mode) before you replace battery.

2. Remove the battery compartment door.

3. Disconnect the cord attached to the battery pack and remove the battery pack from the handset.

4. Insert the new battery pack and connect the cord to the jack inside the battery compartment.

5. Put the battery compartment door back on.

6. Place handset in the base or handset charge cradle to charge. Allow the handset

battery to properly charge (for 16 hours) prior to ﬁrst use or when you install a new battery pack. If you do not properly charge the phone, battery performance will be compromised.

Battery Safety Precautions

• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this type, toxic materials could be released which can cause injury.

• To reduce the risk of ﬁre or personal injury, use only the

Nickel-metal Hydride

battery

listed in the User ’s Guide.

• Keep batteries out of the reach of children.

• Remove batteries if storing over 30 days.

• Did you follow proper dialing sequence? Unit locks up and no communication between the base and cordless handset

• Unplug the power adaptor from the electrical outlet and the back of the base. Remove the handset battery. Wait for 30 seconds and plug the power adaptor back into the base and electrical outlet. Reconnect the battery and charge for 16 hours.

Charge Indicator on the Base Flashes

• Provided your phone company offers voice messaging service and you subscribe to it, the charge indicator on the base ﬂashes when the phone is not in use to indicate there is a message waiting. It’s stops ﬂashing after the message has been reviewed.

Caller ID Solutions

No Display

• Charge the battery (for 16 hours). Or replace the battery.

• Make sure the unit is connected to a non-switched electrical outlet. Disconnect the power adaptor from the base and reconnect it.

Caller ID Error Message

• The unit displays this message if it detects anything other than valid Caller ID information during the silent period after the ﬁrst ring. This message indicates the presence of noise on the line.

No Caller ID

• You must be subscribed to the standard Name/Number Caller ID service from your local telephone company to receive CID information.

Battery

If you experience any of the following problems, even after recharging the battery, you may need to replace the battery pack:

• Short talk time

• Poor sound quality

• Limited range

• Charge indicator fails to turn on

General Product Care

To keep your unit working and looking good, follow these guidelines:

• Avoid dropping the handset, as well as other rough treatment to the phone.

• Clean the phone with a soft cloth.

• Never use strong cleaning agents, paint thinner, abrasive powder, alcohol, or other chemical products to clean the unit. Doing so will damage the ﬁnish.

• Retain the original packaging in case you need to ship the phone at a later date.

• Periodically clean the charge contacts on the handset and base with a clean pencil eraser.

Causes of Poor Reception

• Aluminum siding.

• Foil backing on insulation.

• Heating ducts and other metal construction that can shield radio signals.

• You ’re too close to appliances such as microwaves, stoves, computers, etc.

• Atmospheric conditions, such as strong storms.

• Base is installed in the basement or lower ﬂoor of the house.

• Base is plugged into AC outlet with other electronic devices.

• Baby monitor is using the same frequency.

• Handset battery is low.

• You’re out of range of the base.

Service

If trouble is experienced with this equipment, for repair or warranty information, please contact customer service at 1-800-448-0329. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.

This product may be serviced only by the manufacturer or its authorized service agents. Changes or modiﬁcations not expressly approved by Thomson Inc. could void the user’s authority to operate this product. For instructions on how to obtain service, refer to the warranty included in this guide or call customer service at 1-800-448-0329.

Or refer inquiries to:

Thomson Inc. Manager, Consumer Relations P O Box 1976 Indianapolis, IN 46206

Attach your sales receipt to the booklet for future reference or jot down the date this product was purchased or received as a gift. This information will be valuable if service should be required during the warranty period.

Purchase date ______________________________________________________ Name of store ______________________________________________________

Limited Warranty

What your warranty covers:

• Defects in materials or workmanship.

For how long after your purchase:

• One year, from date of purchase. (The warranty period for rental units begins with the ﬁrst rental or 45 days from date of shipment to the rental ﬁrm, whichever comes ﬁrst.)

What we will do:

• Provide you with a new or, at our option, a refurbished unit. The exchange unit is under warranty for the remainder of the original product’s warranty period.

How you get service:

• Properly pack your unit. Include any cables, etc., which were originally provided with the product. We recommend using the original carton and packing materials.

• ”Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the product is within the warranty period, must be presented to obtain warranty service.” For rental ﬁrms, proof of ﬁrst rental is also required. Also print your name and address and a description of the defect. Send via standard UPS or its equivalent to:

Thomson Inc.

11721 B Alameda Ave.

Socorro, Texas 79927

• Pay any charges billed to you by the Exchange Center for service not covered by the warranty.

• Insure your shipment for loss or damage. Thomson Inc. accepts no liability in case of damage or loss.

• A new or refurbished unit will be shipped to you freight prepaid.

What your warranty does not cover:

• Customer instruction. (Your Owner’s Manual provides information regarding operating instructions and user controls. Any additional information, should be obtained from your dealer.)

• Installation and setup service adjustments.

• Batteries.

• Damage from misuse or neglect.

• Products which have been modiﬁed or incorporated into other products.

• Products purchased or serviced outside the USA.

• Acts of nature, such as but not limited to lightning damage.

Product Registration:

• Please complete and mail the Product Registration Card packed with your unit. It will make it easier to contact you should it ever be necessary. The return of the card is not required for warranty coverage.

Limitation of Warranty:

• The warranty stated above is the only warranty applicable to this product. All other warranties, express or implied (including all implied warranties of merchantability or ﬁtness for a particular purpose) are hereby disclaimed. No verbal or written information given by Thomson Inc., its agents, or employees shall create a guaranty or in any way increase the scope of this warranty.

• Repair or replacement as provided under this warranty is the exclusive remedy of the consumer. Thomson Inc. shall not be liable for incidental or consequential damages resulting from the use of this product or arising out of any breach of any express or implied warranty on this product. This disclaimer of warranties and limited warranty are governed by the laws of the state of Indiana. Except to the extent prohibited by applicable law, any implied warranty of merchantability or ﬁtness for a particular purpose on this product is limited to the applicable warranty period set forth above.

How state law relates to this warranty:

• Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts so the above limitations or exclusions may not apply to you.

• This warranty gives you speciﬁc legal rights, and you also may have other rights that vary from state to state.

If you purchased your product outside the USA:

• This warranty does not apply. Contact your dealer for warranty information.

Storing CID Records in Internal Memory

You may also store CID information in the phone’s internal memory.

NOTE:

It is important that you format CID records correctly BEFORE storing in internal memory as you cannot reformat CID records stored in memory.

1. Make sure the phone is OFF (not in talk mode).

2. Use the CALLER ID-VOLUME ( 6 or 5) button to scroll to the desired CID record.

3. Press the Memory button to display SELECT MEMORY 01-50.

4. Use the touch-tone pad to enter a memory location to store the number in that memory location. You will hear a conﬁrmation tone.

NOTE: If the memory location is occupied, REPLACE MEMO? is displayed, and you must conﬁrm replacement by pressing the MEMORY button.

NOTE: Press the *EXIT button once to keep the previous setting (making no changes) and return to the menu.

NOTE: If the selected CID record contains any information that is nonnumeric, the unit will not allow this record to transfer to the internal user memory. The handset will display UNABLE TO STORE.

To Replace a Stored CID Record

1. Repeat steps 1 through 3 in Storing CID Records in Internal Memory. After you enter the memory location, REPLACE MEMO? shows in the display.

2. Press the Memory button again, and the new CID record replaces the old memory in that location. You will hear a conﬁrmation tone.

Deleting a CID Record

1. Make sure the phone is OFF (not in TALK mode).

2. Use the CALLER ID-VOLUME ( 6 or 5) button to display the CID record you want to delete.

3. Press the DELETE button. The display shows DELETE CALL ID?

4. Press the DELETE button to erase the record showing in the display. The display shows DELETED.

NOTE: Press the *EXIT button to return to the standby mode.

Deleting All CID Records

1. Make sure the phone is OFF (not in TALK mode).

2. Use the cid/vol ( - or + ) button to display any Caller ID record.

3. Press and hold the DELETE button until DELETE ALL? shows in the display.

4. Press DELETE button to erase all of the current CID records. The display shows DELETED followed by NO CALLS.

NOTE: Press the *EXIT button to return to the standby mode.

MeMorY

Each handset can store up to ﬁfty 20-digit numbers with up to 15-character names in memory for quick dialing. This memory feature is in addition to the CID memory log, which stores up to 40 CID records in each handset.

Storing a Name and Number in Memory

1. Make sure the phone is OFF (not in talk mode).

2. Press the MEMORY button to display SELECT MEMORY 01-50.

3. Press the desired memory location button (01 through 50) or use the CALLER ID-VOLUME ( 6 or 5) button to scroll to desired the memory location.

NOTE: If the memory location is occupied, the memory location number and stored name and telephone number shows in the display. If the memory location is empty, EMPTY shows in the display.

4. Press the MEMORY button. The display shows ENTER NAME.

5. Use the touch-tone pad to enter a name (up to 15 characters). More than one letter is stored in each of the number keys. For example, to enter Bill Smith, press the 2 key twice for the letter B. Press the 4 key 3 times for the letter I. Press the 5 key 3 times for the letter L. Press the 5 key 3 times for the second letter L, and press the 1 key to insert a space between the ﬁrst and last name. Press the 7 key 4 times for the letter S; press the 6 key once for the letter M; press the 4 key 3 times for the letter I; press the 8 key for the letter T; press the 4 key twice for the letter H.

NOTE: If you make a mistake press the DELETE button to backspace and erase the wrong character(s) or number(s).

6. Press the MEMORY button to conﬁrm and save the record. The display shows ENTER TEL NUMBR.

7. Use the touch-tone pad to enter the telephone number (up to 20 digits, including pauses (press #PAUSE button), and press the MEMORY button again to save the record. The unit beeps to conﬁrm.

NOTE: The system treats PAUSES as delays or spaces in the dialing sequence.

8. To enter another name and number in a different memory location, return to step 2 and repeat the process.

Time call received

Date call received

Number of new calls received

Caller’s nameCaller’s phone number

acceSSorY InforMatIon

To place order, have your Visa, MasterCard, or Discover Card ready and call toll-free 1-800338-0376. A shipping and handling fee will be charged upon ordering. We are required by

law to collect appropriate sales tax for each individual state, country, and locality to which the merchandise is being sent. Items are subject to availability. Prices are subject to change without notice.

DESCRIPTION MODEL NO.

Handset Replacement Battery 5-2660

AC Power adaptor 5-2759

Belt Clip 5-2703

Headset 5-2425

Handset charge cradle 5-2758

Call Waiting Caller ID

Provided you subscribe to Call Waiting Caller ID service from your phone company; if you receive an incoming call and you are using the GE multi handset system, a beep indicates the presence of a Call Waiting call on the line. The Call Waiting Caller ID information will be displayed and stored in the history of all handsets in the system.

• When you hear the call waiting beep in the handset receiver, press the FLASH button to put the current call on hold and answer the incoming call.

Press FLASH again to return to the

original call.

Receiving CID Records

When you receive a call, the Caller ID information is transmitted between the ﬁrst and second ring. The Caller ID information appears on the display while the phone rings, giving you a chance to monitor the information and decide whether or not to answer the call.

Storing CID Records (In CID Memory)

If you are not at home or cannot answer, your telephone’s Caller ID memory stores the data for the 40 most recent calls you received so you can see who called while you were unavailable. When the 41st call is received, the oldest Caller ID record (1st call) is automatically deleted.

You may review the stored information at any time. Calls received since your last review show as NEW in the display. Calls that have not been previously reviewed but were received from the same number more than once show as REPT in the display.

Reviewing CID Records

As calls are received and stored, the display is updated to let you know how many calls have been received. To scroll CID records:

1. Make sure the phone is OFF (not in talk mode).

2. Press the CALLER ID-VOLUME ( 6 ) button to review the newest CID record.

3. Press the CALLER ID-VOLUME ( 5 ) button to review the oldest CID record ﬁrst.

Dialing a CID Number

1. Make sure the phone is OFF (not in TALK mode).

2. Use the CALLER ID-VOLUME ( 6 or 5) button to display the desired record.

3. Press the TALK/CALL BACK or SPEAKER button. The number dials automatically.

NOTE: Depending on (a) how the incoming caller’s phone number is formatted when it is received, and (b) whether or not you previously preprogrammed your local area code into the set up menu, you may need to adjust the format of the incoming caller’s stored phone number before making the call, press the FORMAT/CONF button to adjust the number, and try again.

Available formats include:

Number of digits Explanation Example

Eleven digits long distance code “1 ” 1-317-888-8888 +3-digit area code +7-digit telephone number.

Ten digits 3-digit area code + 317-888-8888 7-digit telephone number.

Seven digits 7-digit telephone number. 888-8888

InStructIonS for optIonal/addItIonal HandSet(S)

This phone is EXPANDABLE up to a total of 4 handsets (by additional purchase of the optional Model 28001 handset with charge cradle).

IMPORTANT:

If you have purchased an extra handset apart from your original purchased unit you may ﬁnd a detailed description of its functions in the

User’s Guide

provided with your original purchased unit.

If you have purchased an extra handset that is not of the same type as your original handset you may still use the original User’s Guide to help explain the new handsets basic functions and options.

Parts Checklist

Make sure your package includes the items shown here.

Installing the Handset Battery

NOTE: You must connect the handset battery before use.

CAUTION: To reduce the risk of ﬁre or personal injury, use only the Thomson Inc. approved Nickel-metal Hydride (Ni-MH) battery model 5-2660, that is compatible with this unit.

1. Locate battery and battery door which are packaged together inside a plastic bag and are separate from the handset.

2. Locate the battery compartment on the back of the handset .

3. Plug the battery pack cord into the jack inside the compartment .

NOTE: To ensure proper battery installation, the connector is keyed and can be inserted only one way.

4. Insert the battery pack.

5. Close the battery compartment by pushing the door up until it snaps into place.

Extra Charging Cradle

1. Plug the AC power adaptor of the extra charging cradle into the electrical outlet.

Handset

Belt clip

Handset

battery pack

Battery

compartment

cover

Charge

Cradle

ABC

DEF

GHI JKL MNO

PQRS

TUV WXYZ

EXIT

OPER

PAUSE

2. Place the handset in the extra charging cradle. The charge indicator turns on, verifying the battery is charging.

3. Allow the phone to charge for 16 hours.

Registration

YOU MUST REGISTER THE HANDSET TO THE MAIN BASE BEFORE USE!

After the optional handset has charged for 16 hours on the extra charger,

HANDSET NEEDS

REGISTRATION shows in the display.

1. Press the MUTE/PROG button. HOLD BASE PAGE WAIT FOR BEEP shows in the display. (Your handset should be held near the base during registration process.)

2. Press and hold the page button on the base unit until you hear a tone at the handset. HANDSET X REGISTERED shows in the handset display, where X is the handset number. You may now rename your handset. (Refer to Step 3 & 4 of Handset Name Section)

CHARGE

(indicator)

Display Messages

The following messages shows the status of the phone, provides Caller ID information, or helps you set up and use your phone.

BLOCKED CALL / Indicates the person is calling from a number which is blocked NAME / NUMBER from transmission.

CHARGING..

. Indicates the handset needs to charge for a period of time before

it can resume normal function.

DELETE ALL? Prompt asking if you want to erase all CID records. DELETE CALL ID? Prompt asking if you want to erase the CID record showing on

the display. DELETE? Prompt asking if you want to erase one of the 50 records

stored in the phone’s memory. DUPLICATE NUMBER Under VIP melody feature, if the desired number/record was

selected in any one of TEN VIP melody records before, DUPLICATE NUMBER shows in the display.

END OF LIST

Indicates that there is no additional information in CID

memory. ENTER NAME Prompt telling you to enter a name in one of the 50 memory

locations. ENTER TEL NUMBR Prompt telling you to enter a telephone number in one of the

50 memory locations.

NEW Indicates call or calls which have not been reviewed. HANDSET NAME Prompt telling you to enter the user name for the registered

handset.

NOTE: The RBRC seal on the battery used in your Thomson Inc. product indicates that we are participating in a program to collect and recycle the rechargeable battery (or batteries). For more information go to the RBRC web site at www.rbrc.org or call 1-800-8-BATTERY or contact a local recycling center.

Thomson 28021EE1 Instruction

Specifications and Main Features

Frequently Asked Questions

User Manual
