Thomas & Betts ER038 Data Sheet

Family

Catalog Number: ER038
Product ID:
UPC Number:
EAN Number:
Status:

316 Stainless Steel Cable Tie Identification Tag, Length of 11.30mm (0.445 Inches), Width
of 9.52mm (0.375 Inches), Symbol: the Number 3

North American Specifications (UNSPSC)

UNSPSC 39131503 Slip on wire marker
IGCC 5378 Slip on wire marker
Type Identification Tag
Length 0.445 In ; 11.3 mm
Width 0.375 in ; 9.52 mm
Material 316 Stainless Steel
Legend 3
Temperature Rating -112 to 1000 F

European Specifications (ETIM)

ETIM EC001530 Cable coding system
Model Other
Material Stainless steel
Length 11.3mm
Width 9.52mm
Imprint Numbers

7TBG009470R0028
78621009861
05414363019367
A

Packaging

Inner Dimensions (inches) 4x2.8x2.3
Outer Quantity 100
Weight Uom 1.25 lbs. per 1000

Documents / Support Tools

Technical Drawing / Data Sheet US Available on Website
