Theta Digital Intrepid User Manual

THETA DIGITAL

CORPORATION

Intrepid

Owner’s Manual

PREFACE

CONGRATULATIONS

You have just acquired one of the most advanced and versatile components for the amplification of audio ever
to have been developed.

IMPORTANT

Save all packaging in a dry place away from fire hazards. Your Intrepid is a precision electronic instrument
and should be properly packaged any time shipment is made. In the unlikely event that you have to return
your Intrepid to the factory for service or updating, the original packaging will best protect the unit from
shipping damage.

In order to achieve the fullest flexibility and enjoyment from your Intrepid, we at Theta recommend that you
read this manual in full before connecting the unit to your audio/video system.

Note: It is imperative that the Intrepid be operated in a well-ventilated environment and that the immediate
external temperature be maintained as specified. External cooling fans may be required in some cases. Do
not stack any equipment directly above or below the Intrepid to protect it from overheating, as well as to
protect the continued functionality of equipment near and around it.

Warning: Each channel is a balanced bridge amplifier, thus the negative speaker terminal is NOT
and cannot be connected to a system ground or a loudspeaker system with a common ground. Consult your
speaker manufacturer to ensure that any speaker in your system that will be connected to the Intrepid does

NOT

have internal circuitry with a common ground.

WARNING

United States law prohibits disposition of these commodities to Libya, Laos, North Korea, Cambodia or Cuba
unless otherwise authorized by the United States.

 2000 Theta Digital Corporation. All rights reserved.

Written and Illustrated by Glenn Buckley.

This manual is also available for download as a PDF file at Theta Digital’s website. http://www.thetadigital.com

No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, for any purpose, without the express written permission of Theta Digital Corporation.

a ground,

The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
significant magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the product.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE

CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THE AC (POLARIZED) PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.

Extension cords are not recommended for use with this product.

ii

Intrepid Identification Record

This information is for your records and for future identification of the Intrepid. Please take a moment to fill
out all pertinent data now, and as upgrades and/or options are installed. Whenever upgrades, inquiries

and/or changes are requested, the serial number will be required.

SERIAL NUMBER

DATE PURCHASED

DEALER’S NAME

DEALER’S ADDRESS/PHONE

INSTALLED CARDS/OPTIONS

(Date of installation)

(Date of installation)

(Date of installation)

iii

SAFETY PRECAUTIONS

Please carefully read each item of the operating instructions and safety precautions before installing and
using this product. Use extra care to follow the warnings written on the product itself and/or in the operating
instructions. Keep the operating instructions and safety precautions for future reference.

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE ANY OF THE COVER
PANELS.

NO USER-SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED SERVICE
PERSONNEL ONLY.

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT ALLOW LIQUIDS TO SPILL OR OBJECTS TO FALL
INTO ANY OPENINGS OF THE PRODUCT.

THIS UNIT IS SUPPLIED WITH A 3 PIN GROUNDED AC PLUG. ALWAYS INSERT THE AC PLUG INTO
A GROUNDED OUTLET. DO NOT REMOVE THE GROUND PIN OR DISABLE THE GROUND FOR ANY
PURPOSE.

BEFORE MAKING ANY CONNECTIONS TO THE INTREPID, FIRST TURN OFF THE POWER AND THEN
DISCONNECT THE AC POWER CORD.

WHEN INSTALLING THE INTREPID IN YOUR SYSTEM, MAKE CERTAIN TO ALLOW A MINIMUM OF ½
INCH OF VENTILATION ON EACH SIDE OF THE UNIT. ALSO ALLOW AT LEAST 3 INCHES OF
VENTILATION SPACE ABOVE THE UNIT. IMPROPER VENTILATION OF THE UNIT MAY CAUSE
OVERHEATING, WHICH MAY DAMAGE THE UNIT AND CAUSE A FIRE. PLACE THE UNIT ON A
SOLID SURFACE ONLY. I.E. NOT ON CARPET, ETC.

DO NOT PLACE THE INTREPID NEAR HEAT SOURCES SUCH AS DIRECT SUNLIGHT, STOVES, HEAT
REGISTERS, RADIATORS OR OTHER HEAT PRODUCING EQUIPMENT.

TO PREVENT DAMAGE TO THE ANALOG OUTPUT CIRCUITRY, BE CERTAIN NOT TO SHORT THE
OUTPUT SIGNAL TO GROUND. ENSURE THAT YOUR AUDIO OUTPUT CABLES DO NOT HAVE ANY
INTERNAL SHORTS BEFORE CONNECTING THEM TO THE INTREPID.

IF REPLACEMENT OF THE AC LINE FUSE AND/OR ANY INTERNAL FUSE BECOMES NECESSARY,
REPLACE ONLY WITH SAME VALUE AND TYPE OF FUSE. NEVER BYPASS THE FUSE.

IF THE AC CORD BECOMES DAMAGED, DO NOT USE IT. IMMEDIATELY REPLACE IT WITH A NEW
ONE OF THE SAME OR BETTER RATING.

IT IS IMPERATIVE THAT THE INTREPID BE OPERATED IN A WELL VENTILATED ENVIRONMENT AND
THE IMMEDIATE EXTERNAL TEMPERATURE BE MAINTAINED AS SPECIFIED. EXTERNAL COOLING
FANS MAY BE REQUIRED IN SOME CASES. DO NOT STACK ANY EQUIPMENT DIRECTLY ABOVE
OR BELOW THE INTREPID AS TO PROTECT IT FROM OVERHEATING, AS WELL AS THE
CONTINUED FUNCTIONALITY OF ANY EQUIPMENT NEAR AND AROUND IT.

EACH CHANNEL IS A BALANCED BRIDGE AMPLIFIER, THUS THE NEGATIVE SPEAKER TERMINAL
IS NOT
SYSTEM WITH A COMMON GROUND. CONSULT YOUR SPEAKER MANUFACTURER TO ENSURE
THAT ANY SPEAKER IN YOUR SYSTEM THAT WILL BE CONNECTED TO THE INTREPID DOES NOT
HAVE INTERNAL CIRCUITRY WITH A COMMON GROUND.

AFTER MARKET and THIRD PARTY MODIFICATIONS

Please note that any after market and/or third party modifications will void the warranty. In the case of
changing the feet on a unit, in order to prevent any damage (which will also not be covered under warranty),
please verify that the screws being used to secure non-Theta feet do not screw any deeper into the chassis
than the original ones. The original screw is 1/4-20 by 1/2 and goes into the chassis 1/4 inch.

A GROUND, AND CANNOT BE CONNECTED TO A SYSTEM GROUND OR LOUDSPEAKER

iv
