Thermador T30IF900SP User Manual
USE & CARE GUIDE
Model/Modele/Modelo
T18IF900SP
GUIDE
D’UTILISATION
ET D’ENTRETIEN
MANUAL DE USO
Y CUIDADO
T24IF900SP
T30IF900SP
T36IF900SP
Freezer
en-us
enTable of Contents
en Instruction manual
( Important safety instructions . . . . . . . . . . . . 3
Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About these instructions . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Explosion hazard. . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Risk of electric shock . . . . . . . . . . . . . . . . . . . . . . . 3
Risk of cold burns . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Risk of injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Danger due to refrigerants . . . . . . . . . . . . . . . . . . . 4
Avoiding risks for children: . . . . . . . . . . . . . . . . . . . 4
Damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
State of California Proposition 65 Warnings . . . . . . 4
M Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Door alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
W Freezer compartment. . . . . . . . . . . . . . . . . . 13
Fully utilizing the freezer volume. . . . . . . . . . . . . . 13
Purchasing frozen food. . . . . . . . . . . . . . . . . . . . . 13
When loading products . . . . . . . . . . . . . . . . . . . . 14
Freezing fresh food. . . . . . . . . . . . . . . . . . . . . . . . 14
Thawing frozen food . . . . . . . . . . . . . . . . . . . . . . . 14
= Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Freezer compartment . . . . . . . . . . . . . . . . . . . . . . 15
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7 Environmental protection. . . . . . . . . . . . . . . . 4
Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Old appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5 Installation and connection . . . . . . . . . . . . . . 5
Scope of supply . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing the appliance . . . . . . . . . . . . . . . . . . . . . . 5
Built-in cut-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Side-by-side installation . . . . . . . . . . . . . . . . . . . . . . 5
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Before using for the first time . . . . . . . . . . . . . . . . . 7
Water connection . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . 7
* Getting to know your appliance. . . . . . . . . . . 8
Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Operating controls. . . . . . . . . . . . . . . . . . . . . . . . . . 8
Fittings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1 Operating the appliance . . . . . . . . . . . . . . . . 11
Switching the appliance on . . . . . . . . . . . . . . . . . . 11
Switching off and disconnecting the appliance . . . 11
Setting the language . . . . . . . . . . . . . . . . . . . . . . . 11
Setting the temperature unit . . . . . . . . . . . . . . . . . 11
Setting the temperature . . . . . . . . . . . . . . . . . . . . . 11
Super freezing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Automatic door opening . . . . . . . . . . . . . . . . . . . . 12
Eco mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Switching ice cube production on and off . . . . . . . 12
Resetting water filter counter. . . . . . . . . . . . . . . . . 12
Theater mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
D Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
> Noises . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Normal noises . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preventing noises . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Faults – what to do? . . . . . . . . . . . . . . . . . . . 16
Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Ice maker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4 Customer service . . . . . . . . . . . . . . . . . . . . . 17
Appliance self-test . . . . . . . . . . . . . . . . . . . . . . . . 17
Repair order and advice on faults . . . . . . . . . . . . 17
2
9 Important safety instructions
READ INSTRUCTIONS - DO NOT DISCARD!
(Important safety instructions
Important safety instructions
READ INSTRUCTIONS - DO NOT DISCARD!
Important safety instructions en-us
Definitions
9 WARNING
Non-observance of this warning could
result in death or serious injuries.
9 CAUTION!
Non-observance of this warning could
result in slight or moderately serious
injuries.
NOTICE:
Non-observance of this information could
damage the appliance.
Note: This indicates important information
and/or tips.
About these instructions
■ Read and follow the operating and
installation instructions. They contain
important information on how to install,
use and maintain the appliance.
■ The manufacturer is not liable if you
disregard the instructions and warnings
in the operating and installation
instructions.
■ Retain all documents for subsequent use
or for the next owner.
Explosion hazard
■ Never use electric devices inside the
appliance (e.g. heaters or electric ice
makers).
■ Do not store products which contain
flammable propellants (e.g. spray cans)
or explosive substances in the appliance.
■ Store high-proof alcohol tightly closed
and standing up.
Risk of electric shock
Improper installations and repairs may put
the user at considerable risk.
■ Never cut through or remove the third
(ground) conductor of the power cord.
■ Never use adapters.
■ Never defrost or clean the appliance with
a steam cleaner. The steam can
penetrate electrical parts and cause a
short circuit.
■ If the power cord is damaged:
Immediately disconnect appliance from
the power supply.
■ Have the appliance, cable and
accessories repaired or replaced only by
the manufacturer, customer service or a
similarly qualified person.
■ Only use original parts supplied by the
manufacturer.
The manufacturer guarantees that these
parts satisfy the safety requirements.
■ A power cord extension may only be
purchased from customer service.
Introduction
■ This appliance complies with the relevant
safety regulations for electrical
appliances and is fitted with interference
suppression.
■ The refrigeration circuit has been
checked for leaks.
Risk of cold burns
■ Never put frozen food straight from the
freezer compartment into your mouth.
■ Avoid prolonged contact of skin with
frozen food, ice and the tubes in the
freezer compartment.
3
en-us Intended use
9 Intended use
READ INSTRUCTIONS - DO NOT DISCARD!
Risk of injury
Containers which contain carbonated drinks
may burst.
Do not store containers which contain
carbonated drinks in the freezer
compartment.
Danger due to refrigerants
The tubes of the refrigeration circuit contain
a small quantity of the environmentally
friendly refrigerant R134a. It does not
damage the ozone layer and does not
increase the greenhouse effect. If
refrigerant escapes, it may injure your eyes.
■ Do not damage the tubes.
If the tubes are damaged:
■ Ventilate the room.
■ Switch off the appliance and pull out the
mains plug.
■ Call customer service.
Avoiding risks for children:
■ Never allow children to play with the
appliance.
■ Ensure that children have understood the
hazards.
■ A person responsible for safety must
supervise or instruct children as soon as
they are old enough to use the appliance.
■ Supervise children while using the
appliance, especially during cleaning and
maintaining.
Risk of suffocation
■ If the appliance features a door lock:
keep the key out of the reach of children.
■ Keep children away from the packaging
and its parts.
Weight
The appliance is very heavy. The appliance
should always be transported and set up by
at least 2 persons.
~ "Installation and connection" on page 5
State of California Proposition 65 Warnings
9 WARNING
This product contains chemicals known
to the State of California to cause
cancer, birth defects or other
reproductive harm.
8Intended use
Intended use
Use this appliance
■ only for freezing food, making ice and dispensing
drinking water.
■ only in the home and in the home environment.
■ only according to these operating instructions.
This appliance is intended for use at an elevation of
no more than 2000 meters above sea level.
7Environmental protection
Environmental protection
Packaging
All materials are environmentally safe and
recyclable:
■ Dispose of packaging in an environmentally
friendly manner.
■ Please ask your dealer or inquire at your local
authority about current means of disposal.
Damage
To prevent damage:
■ Do not stand or support yourself on the
base, runners or doors.
■ Keep plastic parts and door seals free of
oil and grease.
■ Pull the mains plug – not the power cord.
4
Installation and connection en-us
Old appliances
Valuable raw materials can be reclaimed by
recycling old appliances.
9 WARNING
CHILDREN MAY BECOME LOCKED IN THE APPLIANCE AND SUFFOCATE!
BEFORE DISPOSING OF YOUR OLD APPLIANCE:
■ Remove the door.
■ Leave shelves and containers in the
appliance to prevent children from climbing
in.
■ Keep children away from the redundant
appliance.
9 CAUTION!
REFRIGERANT AND HARMFUL GASES MAY ESCAPE.
Do not damage the tubes of the refrigeration
circuit and insulation.
1. Pull out the mains plug.
2. Cut through the power cord.
3. Have the appliance disposed of properly.
Technical data
Refrigerant, cubic capacity and further technical
specifications can be found on the rating plate.
~ "Getting to know your appliance" on page 8
Installing the appliance
Installation location
The weight of the appliance may be up to 460 kg
depending on the model. The base must be
sufficiently stable and should not give. If necessary,
reinforce the bottom.
Built-in cut-out
The cut-out must fulfil these criteria:
■ min. 24" (610mm) deep
■ rectangular
■ stable – the side panels and the top must be min.
5/8" (16mm) thick and securely attached to the
bottom or wall
■ shortened side panels must be min. 4" (100mm)
deep
Side-by-side installation
Side-by-side installation is only possible as follows:
5Installation and
connection
Installation and connection
Scope of supply
After unpacking all parts, check for any damage
during transport.
If you have any complaints, please contact the
dealer from whom you purchased the appliance or
our customer service.
~ "Customer service" on page 17
The delivery consists of the following parts:
■ Built-in appliance
■ Fittings (depending on model)
■ Installation material
■ Instruction manual
■ Installation instructions
■ Customer service booklet
■ Warranty enclosure
■ Information on the energy consumption and
noises
If you wish to install appliances in a different manner,
there must be a partition wall between them. This
partition wall must be min. 5/8" (16mm) in width.
5
en-us Installation and connection
Saving energy
If you follow the instructions below, your appliance will use less power.
Note:
The arrangement of the fittings does not affect the energy consumption of the appliance.
Installing the appliance
Keep the appliance out of direct sunlight. The appliance needs to cool less frequently at low ambient tempera-
Install the appliance as far away as possible from heating elements,
cooker and other heat sources:
1¼" (3cm) to electric or gas cookers
11¾" (30cm) to oil or solid-fuel cookers
Note: If this is not possible, attach an insulating plate between the ap-
pliance and heat source.
Select an installation location at a room temperature of approx. 68 °F
(20 °C).
Use a niche depth of 24" (61cm).
9 CAUTION!
Risk of burns!
Individual parts on the back of the appliance become hot during
operation. Touching these parts may result in burns.
tures and therefore consumes less power.
The air on the back panel of the appliance does not warm up so
intensely. The appliance consumes less power if the warm air can
escape.
Do not cover or block the ventilation openings.
Ventilate the room daily.
Using the appliance
Open the appliance door only briefly. The air in the appliance does not warm up so intensely. The appliance
Transport purchased food in a cool bag and place quickly in the appliance.
Allow warm food and drinks to cool down before placing in the appliance.
Defrost frozen food in the cooling compartment in order to utilize the
low temperature of the frozen food.
Always leave a space between the food and the back panel. The air can circulate and the humidity will remain constant. The appli-
Pack food airtight.
Vacuum the back of the appliance once a year. The air on the back panel of the appliance does not warm up so
Do not cover or block the ventilation openings.
--------
needs to cool less frequently and therefore consumes less power.
ance needs to cool less frequently and therefore consumes less
power.
intensely. The appliance consumes less power if the warm air can
escape.
6
Loading...
