Thermador PCG48, PCG36, PCG30 User Manual 2

USE AND CARE GUIDE

THERMADOR PROFESSIONAL® RANGETOPS

GUIDE D'UTILISATION ET D'ENTRETIEN

Tables de cuisson PROFESSIONALmc de THERMADOR

MANUAL DE USO Y CUIDADO

Placas de cocción PROFESSIONAL® de THERMADOR

Models/ Modèles/ Modelos:

PCG30 PCG36 PCG48

Congratulations on your recent THERMADOR® purchase! Whether you are a dedicated chef or simply a connoisseur of the art of cooking, owning a THERMADOR kitchen is the ultimate expression of personal style, good taste and an appreciation for the complete culinary experience. Our award-winning products have been empowering culinary enthusiasts for more than eleven decades.

Before you begin using your new THERMADOR product, please take a moment to review the Use and Care Guide. You will find the answers to all of your questions as well as some very important safety information. Pay special attention to the Important Safety Instructions located at the beginning of the manual. Your THERMADOR product is ready and waiting to be used for your next gourmet creation!

Our products are handcrafted with the highest quality authentic materials to ensure years of reliable service. In the unlikely event that you have a service question, please have your model and serial numbers of your product available. You can find this information beneath the control panel area of the range.

We realize that you have made a considerable investment in your kitchen. Please feel free to share your THERMADOR kitchen photos and remodeling stories with us. Follow us on Twitter or post your kitchen photos on Facebook. We would love to hear from you!

THERMADOR wishes you many years of creative cooking.

Félicitations pour votre récent achat THERMADOR

! Que vous soyez un chef enthousiaste ou un simple connaisseur de l’art culinaire, le fait de posséder une cuisine THERMADOR représente l’expression ultime de votre style personnel, de votre bon goût et de votre intérêt à vivre une expérience culinaire complète. Nos produits primés permettent à des adeptes de la bonne bouffe d’atteindre de nouveaux sommets depuis plus de onze décennies.

Avant de commencer à utiliser votre nouveau produit THERMADOR, veuillez prendre un moment pour examiner ce guide d’utilisation et d’entretien. Vous trouverez des réponses à toutes vos questions ainsi que quelques renseignements essentiels en matière de sécurité. Portez une attention particulière aux Instructions de sécurité importantes se trouvant au début du guide. Votre produit THERMADOR est prêt et n’attend plus que vous l’utilisiez pour votre prochaine création gastronomique!

Nos produits sont fabriqués à la main avec des matériaux authentiques de haute qualité afin d’assurer des années de service fiable. Dans l’éventualité improbable où vous auriez une question relativement à l’entretien, veuillez avoir à la portée de la main le numéro de série et de modèle de votre produit. Ces renseignements se trouvent sous le rebord du bâti de la table de cuisson.

Nous savons bien que vous avez investi une somme considérable dans votre cuisine. N’hésitez pas à partager avec nous les photos de votre cuisine THERMADOR et les anecdotes relatives au remodelage de votre cuisine. Suivez-nous sur Twitter ou affichez des photos de votre cuisine sur Facebook. Nous serions ravis d’avoir de vos nouvelles!

THERMADOR vous souhaite de nombreuses années de gastronomie créative.

¡Enhorabuena por la reciente compra de su THERMADOR®! Que Usted sea un gran jefe de cocina o un simple aficionado del arte culinario, el hecho de poseer una cocina THERMADOR es la última expresión de su estilo personal, de su buen gusto y de su apreciación de una experiencia culinaria completa. Nuestros premiados productos permiten al entusiasta de la cocina explorar este mundo desde hace más de once décadas.

Antes de comenzar a utilizar sur nuevo producto THERMADOR, tómese un momento para echar un vistazo a este manual de uso y mantenimiento. Encontrará respuestas a todas sus preguntas además de informaciones esenciales en materia de seguridad. Ponga especial atención a las Instrucciones de seguridad importantes, situadas al principio del manual. ¡Su producto THERMADOR está listo y solo espera a que Usted lo use para su próxima creación gastronómica!

Nuestros productos se fabrican a mano con materiales auténticos de alta calidad a fin de garantizar años de servicio fiable. En el caso improbable en que Usted tenga una pregunta relativa al mantenimiento, tenga a mano el número de serie y el modelo de su producto. Puede encontrar esta información en la parte inferior del armazón de la placa de cocción.

Nos damos cuenta de que Usted invirtió una suma considerable en su cocina. No dude en compartir con nosotros las fotos de su cocina THERMADOR

y anécdotas acerca de la reforma de su cocina. Síganos en Twitter o publique fotos de su

cocina en Facebook. ¡Estaremos encantados de tener noticias suyas!

¡THERMADOR

le desea varios años de gastronomía creativa!

Table of Contents

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

48” Rangetop Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

30” & 36” Rangetop Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Using the Rangetop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Sealed STAR® Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cookware Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Specialty Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Surface Burner Cooking Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Using the Electric Griddle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Do-It-Yourself Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Rangetop Cleaning Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Cleaning Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Before Calling Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Data Rating Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Statement of Limited Product Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

THERMADOR

Customer Support, Accessories & Parts. . . . . . . back page

This THERMADOR® appliance is made

by BSH Home Appliances Corporation

1901 Main Street, Suite 600

Irvine, CA 92614

Questions?

1-800-735-4328

www.thermador.com

We look forward to hearing from you!

Safety

IMPORTANT SAFETY INSTRUCTIONS

Read and Save These Instructions

PLEASE READ CAREFULLY

WARNING:

If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death.

— Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

— Installation and service must be performed by a

qualified installer, service agency or the gas supplier.

Gas Type Verification

Rangetops are shipped by the factory to operate on natural gas. Verify the type of gas supplied to the location. Ensure that the appliance is connected to the type of gas for which it is certified. All models are certified for use with natural gas. Field conversion of the appliance for use with propane gas supply will require a conversion kit (PLPKIT). Field conversion must be done by qualified service personnel

only.

CAUTION:

When connecting the unit to propane gas, make certain the propane gas tank is equipped with its own highpressure regulator in addition to the pressure regulator supplied with the rangetop. The maximum gas

pressure to this appliance must not exceed 14.0” water column (34.9 mb) from the propane gas tank to the pressure regulator.

IMPORTANT:

When installing against a combustible surface, a Low Backguard is required. A THERMADOR must be purchased separately. See the Installation Manual for backguard and installation information.

Low Backguard

WARNING:

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult a qualified installer, service agency, manufacturer (dealer) or the gas supplier.

For Massachusetts Installations:

1. Installation must be performed by a qualified or licensed contractor, plumber or gas fitter qualified or licensed by the state, province or region where this appliance is being installed.

2. Shut-off valve must be a “T” handle gas cock.

3. Flexible gas connector must not be longer than 36” (914mm).

When using the Flush Island Trim, THERMADOR recommends a minimum 12” (305 mm) rear clearance to a combustible surface (see the Installation Manual for clearance requirements). Clearances from noncombustible materials are not part of the ANSI Z21.1 scope and are not certified by CSA. Clearances of less than 12” (305 mm) must be approved by the local codes and/or by the local authority having jurisdiction.

Before using the rangetop, ensure that it is equipped with a proper backguard. Refer to the Installation Manual accompanying this appliance for more information.

WARNING:

To avoid possible burn or fire hazard, a back guard designed specifically for this rangetop must be installed whenever the rangetop is used.

English 1

IMPORTANT SAFETY INSTRUCTIONS

Read and Save These Instructions

Electrical Requirements

WARNING:

IN CASE OF AN ELECTRICAL FAILURE If for any reason a gas control knob is turned ON and

there is no electrical power to operate the electronic igniters on the rangetop STAR gas control knob and wait 5 minutes for the gas to dissipate before lighting the STAR burner manually.

To light the STAR burners manually, carefully hold a lighted match to the STAR burner ports and turn the gas control knob to HI the standard rangetop STAR burners, but each must be lit with a match.

DO NOT attempt to light the two left XLO® STAR burners manually. These STAR burners are equipped with the ExtraLow

It is the personal responsibility and obligation of you, the user, to have this appliance connected to the electrical power supply by a qualified electrician, in accordance with the National Electrical Code and/or applicable local codes and ordinances.

All rangetop models require an electrical circuit rated at 120 volts, 60 Hz., 10 Amps, except models with electric griddle require 15 Amp circuits.

. During a power failure, you can use

feature and cannot be lit manually.

burners, turn OFF the

Safety Codes and Standards

This appliance complies with the following Standards:

• UL 858, The Standard for the Safety of Household Electric Ranges

• ANSI Z21.1, The American National Standard for Household Cooking Gas Appliances

• CAN 1-1.1-M81, Domestic Gas Ranges

• CSA C22.2 No. 61, Household Cooking Ranges

Check your local building codes for the proper method of installation. In the absence of local codes, this unit should be installed in accordance with the National Fuel Gas Code No. Z223.1 current issue and the National Electrical Code ANSI/NFPA No. 70 current issue or the Can - B149 Installation Codes for Gas Burning Appliances and C22.1 Canadian Electrical Code Part 1.

It is the responsibility of the owner and the installer to determine if additional requirements and/or standards apply to specific installations.

When properly cared for, your new THERMADOR PROFESSIONAL® rangetop has been designed to be a safe, reliable appliance. However, use extreme care when using this restaurant caliber rangetop as this type of appliance provides intense heat. When using kitchen appliances, basic safety precautions must be followed, including the following:

Read this Use and Care Guide carefully before using your new rangetop to reduce the risk of fire, electrical shock, or injury to persons.

CAUTION:

FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE CONNECTED TO A PROPERLY GROUNDED AND POLARIZED ELECTRICAL POWER SUPPLY.

Always disconnect the electrical plug from the wall receptacle before servicing this unit.

See the Installation Manual for electrical requirements and grounding instructions.

English 2

Insure proper installation and servicing. Follow the Installation Manual provided with this product. Have the rangetop installed and electrically grounded by a qualified technician.

Have the installer show you where the electric circuit breaker and the gas supply shut off valve are located so you know how and where to turn off the gas and electricity to the rangetop.

In the event a STAR open a window or a door. DO NOT attempt to use the rangetop until the gas has had time to dissipate. Wait at least 5 minutes before using the rangetop.

DO NOT repair or replace any part of the appliance unless specifically recommended in this manual. All servicing should be referred to a qualified technician.

burner goes out and gas escapes,

IMPORTANT SAFETY INSTRUCTIONS

Read and Save These Instructions

WARNING:

TO REDUCE THE RISK OF INJURY TO PERSONS, IN THE EVENT OF A GREASE FIRE, OBSERVE THE FOLLOWING:

• Smother flames with a close-fitting lid, cookie sheet, or other metal tray, then turn off the gas burner or the electric element. Be careful to prevent burns. If the flames do not go out immediately, evacuate and call the fire department.

• Never pick up a flaming pan — You may be burned.

• DO NOT USE WATER, including wet dish cloths or towels — a violent steam explosion will result.

• Use an extinguisher only if:

• You know you have a class ABC extinguisher

and you already know how to operate it.

• The fire is small and contained in the area where

it started.

• The fire department is being called.

• You can fight the fire with your back to an exit.

Child Safety

When children become old enough to use the appliance, it is the legal responsibility of the parents or legal guardians to ensure that they are instructed in safe operation of the appliance by qualified persons.

WARNING:

DO NOT store items of interest to children above or at the back of the rangetop. If children should climb onto the appliance to reach these items, they could be seriously injured.

DO NOT allow anyone to climb, stand, lean, sit, or hang on any part of an appliance. This can damage the appliance, and the unit may tip over, potentially causing severe injury.

DO NOT allow children to use this appliance unless closely supervised by an adult.

Children and pets should not be left alone or unattended in the area where the appliance is in use. They should never be allowed to play in its vicinity, whether or not the appliance is in use.

NEVER use any part of the rangetop for storage. Flammable materials can catch fire and plastic items may melt or ignite. DO NOT hang articles from any part of the appliance. Some fabrics are quite flammable and may catch on fire.

If the rangetop is near a window, be certain the curtains do not blow over or near the rangetop burners; they could catch on fire.

WARNING:

TO REDUCE THE RISK OF A GREASE FIRE:

• Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings.

• Always turn hood ON when cooking at high heat or when flambéing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).

• Clean hood filters frequently. Grease should not be allowed to accumulate on fan or filter.

• Use proper pan size. Always use cookware appropriate for the size of the rangetop burner.

ALWAYS have a working smoke detector near the kitchen. In the event that personal clothing or hair catches fire, drop

and roll immediately to extinguish flames. Have an appropriate fire extinguisher available nearby,

highly visible, and easily accessible near the cooking appliance.

Smother flames from food fires, other than grease fires, with baking soda. Never use water on cooking fires.

Whenever possible, do not operate the ventilation system during a rangetop fire. However, DO NOT reach through fire to turn it off.

NEVER let clothing, potholders, or other flammable materials come in contact with or too close to any burner or burner grate until it has cooled. Fabric may ignite and result in personal injury.

Use only dry potholders: moist or damp potholders on hot surfaces may cause burns from steam. DO NOT use a towel or other bulky cloth in place of potholders. DO NOT let potholders touch hot burners or burner grates.

English 3

IMPORTANT SAFETY INSTRUCTIONS

Read and Save These Instructions

For personal safety, wear proper apparel. Loose fitting garments or hanging sleeves should never be worn while using this appliance. Some synthetic fabrics are highly flammable and should not be worn while cooking.

DO NOT use aluminum foil to line any part of the rangetop. Use of a foil liner could result in a shock or fire hazard, or the obstruction of the flow of combustion and ventilation air. Foil is an excellent heat insulator and heat will be trapped beneath it. This will upset the cooking performance and can damage the finish of the rangetop.

WARNING:

The appliance is for cooking. Based on safety considerations, never use the rangetop to warm or heat a room. Doing so may result in carbon monoxide poisoning and overheating of the unit. Also, such use can damage the rangetop parts.

When using the rangetop: DO NOT TOUCH THE BURNER GRATES OR THE IMMEDIATE SURROUNDING AREA. Areas adjacent to the burners may become hot enough to cause burns.

Never leave the rangetop unattended when using high flame settings. Boil overs cause smoking and greasy spillovers that may ignite. Also, if the burner flames and igniter are smothered with spillage, unburned gas will escape into the room. See page 1 regarding gas leaks.

Only certain types of glass, heatproof glass-ceramic, ceramic, earthenware, or other glazed cookware are suitable for cooking on the rangetop burners. This type of cookware may break with sudden temperature changes. Use only on low or medium heat settings according to the utensil manufacturer’s directions.

DO NOT heat or warm unopened food containers. Build-up of pressure may cause the container to burst and cause injury.

During cooking, set the burner control so that the flame heats only the bottom of the pan and does not extend beyond the bottom of the pan.

Use caution to insure that drafts like those from forced air vents or fans do not blow flammable material toward the flames or push the flames so that they extend beyond the edges of the pot.

Always use pots and pans that have flat bottoms large enough to cover the burner. The use of undersized pots and pans could expose a portion of the flame and may

result in ignition of clothing.

WARNING:

Avoid using high flame setting with a pan larger than the grate or with one that spans more than one burner, such as a griddle, for prolonged periods of time. This can result in poor combustion that generates harmful byproducts.

To minimize the risk of burns, ignition of flammable materials and unintentional spillage, position handles of pots and pans inward so they do not extend over adjacent work areas, cooking areas, or the edge of the rangetop.

DO NOT use pots or pans on the grill plate accessory (purchased separately). Bakeware, such as large casserole pans, cookie sheets, etc., should never be used on the rangetop.

DO NOT use flammable cleaners to clean the rangetop. Hold the handle of the pan to prevent movement when

stirring or turning food. Remove the optional cutting board or griddle cover

accessory, which is stored on top of the griddle plate, before operating the griddle or any adjacent burners.

GREASE IS FLAMMABLE. Let hot grease cool before attempting to handle it. Avoid letting grease deposits collect. Clean after each use.

For proper lighting and performance of the burners, keep the igniter ports clean. It is necessary to clean the ports when there is a boil over or when the burner does not light even though the electronic igniters activate. See cleaning instructions for the “Brass Burner Base and Cast Iron Cap”.

Clean the rangetop with caution. Avoid steam burns; DO NOT use a wet sponge or cloth to clean the rangetop while it is hot. Some cleaners produce noxious fumes if applied to a hot surface. Follow directions provided by the cleaner manufacturer.

English 4

IMPORTANT SAFETY INSTRUCTIONS

Read and Save These Instructions

WARNING:

After a spill or boil over, turn off the burner and using caution due to possible hot surfaces, clean around the burner and burner ports. After cleaning, check for proper operation.

IMPORTANT SAFETY NOTICE:

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances known to the state to cause cancer, birth defects, or other reproductive harm, and requires businesses to warn customers of potential exposure to such substances.

Be sure all rangetop controls are turned off and the rangetop is cool before using any type of aerosol cleaner on or around the rangetop. The chemical that produces the spraying action could, in the presence of heat, ignite or cause metal parts to corrode.

DO NOT obstruct the flow of combustion or ventilation air.

WARNING:

DO NOT block or obstruct the flow of air

through the ventilation openings. The vent is located at the back of the appliance. The vent needs to be unobstructed and open to provide necessary airflow that is important for proper performance.

Low Back Vent

DO NOT touch vent area while the appliance is on and for several minutes after the appliance is off. Some parts of the vent and surrounding areas become hot enough to cause burns. Allow appliance sufficient time to cool before touching or cleaning vent areas.

The burning of gas cooking fuel can generate some byproducts which are on the list. Exposure to these substances can be minimized by:

1. Providing good ventilation when cooking with gas.

2. Operating the unit according to the instructions in this manual.

DO NOT store or use corrosive chemicals, vapors, flammables, or nonfood products in or near this appliance. It is specifically designed for use when heating or cooking food. The use of corrosive chemicals while heating or cleaning will damage the appliance and could result in

injury.

WARNING:

This appliance should not be installed with a ventilation system that directs air in a downward direction toward the range. This type of ventilation system may cause ignition and combustion problems with the appliance resulting in personal injury, property damage, or unintended operation. Ventilating systems that direct the air upwards do not have any restriction.

DO NOT position plastic or other heatsensitive items on or near the vent. These items could melt or ignite.

Service should only be done by authorized technicians. Technicians must disconnect the power supply before servicing this unit.

To avoid a fire hazard, grease accumulation must be prevented by frequently cleaning the ventilation hood and filters.

In case of fire or when intentionally “flaming” liquor or other spirits on the rangetop, follow manufacturer’s instructions. Use caution when cooking foods with high alcohol content (e.g. rum, brandy, bourbon). Alcohol evaporates at high temperatures. There is a risk of burning as the alcohol vapors may catch fire. Use only small quantities of alcohol in foods.

English 5

Before You Begin

Before using your rangetop for the first time check that you have these items:

Table 1: Rangetop Accessories and Parts

DESCRIPTION 30" 4-Burner

STAR® Burner Caps Burner Grates 2 2 3 3 Center Grate 1 — — —

Titanium Coated Aluminum Griddle — 1 — 1 Flush Island Trim* 1 1 1 1 Product Registration Card 1 1 1 1 Installation Manual 1 1 1 1 Use and Care Guide 1 1 1 1

*All models are supplied with a Flush Island Trim; however, see Warning on page 5 concerning spacing behind the rangetop when using the rangetop with the Flush Island Trim.

Remove all packaging materials and temporary labels from rangetop. Please, recycle the packaging material as all THERMADOR

1. Check that you have the items listed in Table 1.

2. Record the Model and Serial number on page 21. The model and serial numbers are found on the Rating Label Plate. The Rating Label Plate is located on the front, underside of the chassis (see Figure 20 on Page 21). The model and serial number must be provided when calling Customer Support for assistance. Enter this information on the Product Registration Card included with this product then mail it to the indicated address.

3. Optional Accessories: Cutting Board (PA12CHPBLK), Griddle/Grill Cover (PA12CVRJ), Wok Support Ring (PWOKRINGHC), and other accessories may be purchased separately from your THERMADOR® dealer

packaging is recyclable.

Grill Plate (PA12GRILHC), 12”

44 6 6

36" 4-Burner w/ Griddle

The THERMADOR PROFESSIONAL occasionally has a smell or smoke when first used. These smells or smoke comes from the burning off of manufacturing residues and is typical of any new appliance regardless of manufacturer.

Please note that some pets or humans can be sensitive to the odors created during any high heat cooking whether it is a manufacturing residue burn off or food so it is recommended that those potentially affected be removed from the kitchen area.

36" 6-Burner

IMPORTANT:

All knobs must be set to OFF before powering up the rangetop.

To prevent unintended operation at power up, please set all knobs to OFF.

48" 6-Burner w/ Griddle

rangetop

English 6

Description

Model and Parts Identification — 48” Rangetop

6 Burners and Griddle

Model and Parts Identification — 30” and 36” Rangetop

Key

1 – Flush Island Trim or 12” (305 mm)

Low Backguard (ordered

separately) 2 – Burner Grates & Burners 3 – Griddle 4 – Control Knobs, Standard Burners 5 – Control Knob, Griddle Thermostat 6 – Control Knobs, ExtraLow

Burners

4 Burners and Center Grate 6 Burners

4 Burners and Griddle

Key

1 – Flush Island Trim or 12” (305 mm)

Low Backguard (ordered separately)

2 – Burner Grates & Burners 3 – Griddle 4 – Control Knobs, ExtraLow

Burners 5 – Control Knob, Griddle Thermostat 6 – Control Knobs, Standard Burners

7 – Center Grate (shown in top view)

English 7

Using the Rangetop

Star

ExtraLow

Standard

Griddle

Standard

ExtraLow

Standard

Bezel

Knob

Sealed STAR® Burners

Figure 1: STAR Brass Burner Base

The rangetop features four or six gas surface STAR® burners; all burners are rated at 18,000 BTU/HR (15,000 BTU/ HR using Propane).

Each burner has a unique QuickClean allows the burner and area around the burner to be easier to clean.

base feature which

Control Knobs

Typically, a pair of control knobs is located on the control panel, directly in front of the pair of gas STAR burners they control — with one gas burner positioned in front of the other on the rangetop.

OFF

Knob

Figure 3: Standard STAR Burner Control Knob

The symbol near each burner control knob identifies the burner position on the rangetop. The symbols shown in Figure 4 are indicative of 48” rangetop models.

Left Rear

OFF

Center Rear

Bezel

OFF

Right Rear

On all models, the two left burners have the exclusive ExtraLow

feature, any remaining burners are Standard.

Each STAR burner has its own control knob.

Standard

ExtraLow

ExtraLow Standard

ExtraLow

Standard

Griddle

Figure 2: Burner Power Features

Standard

Griddle

Left Front

Center Front

Right Front

Figure 4: Rangetop Symbols

Operation of the STAR Burners

• Press in on the knob and turn it counter-clockwise to the HI setting.

• The igniter for the selected burner sparks to ignite the burner.

• After flame ignition, the igniter stops sparking.

• Rotate the knob to any flame setting between HI and SIM.

• A blue light is positioned between the burner controls. The light turns on when the control knob is rotated to an active mode. It is off when the control knob is in the OFF position.

English 8

ExtraLow Range

BTU Output for Standard STAR

Burners

• HI is equivalent to 18,000 BTU / HR (15,000 BTU / HR using Propane).

• SIM is equivalent to 2,100 BTU / HR.

BTU Output for ExtraLow

STAR® Burners

• HI is equivalent to 18,000 BTU / HR (15,000 BTU / HR using Propane).

• SIM is equivalent to 3,000 BTU / HR.

•XLO

is equivalent to 375 BTU / HR when the control knob is adjusted to the lowest setting in the ExtraLow range.

ExtraLow® STAR

Burners

The controls for the two left burners, front and rear, have flame settings even lower than the standard SIM settings.

Figure 5 shows that the control knob has an additional range between the SIM and XLO settings. When the knob is set within this range, the flame cycles off and on. By varying the length of time the flame is off and on, the heat is reduced even further to cook delicate foods. For example, these very low settings are suitable for simmering and poaching, melting chocolate and butter, holding cooked foods at temperatures without scorching or burning, etc.

ExtraLow

Techniques

• The type and quantity of food affects which setting to use.

• The pan selected affects the setting. Its size, type, material, and whether a lid is used, all affect the consistency of the cooking temperature.

• To maintain a low or simmer heat, bring food to a rolling boil. Stir well, then cover the pan and lower the heat to a setting just below SIM.

• Check periodically to see if the control knob should be turned to another setting.

• If an over-size pan is used, the simmer action may occur mainly in the center of the pan. To equalize the temperature throughout the food, stir the food around the outer edges of the pan into the food in the center.

• It is normal to stir food occasionally while simmering. This is especially important when simmering for several hours, such as for a homemade spaghetti sauce or beans.

• When lowering the flame setting, adjust it in small steps.

• If the setting is too low to hold a simmer, bring the food back to a boil before re-setting to a higher heat.

• It is normal not to see simmer bubbles immediately after the food has been stirred.

• There may be bubbling when the flame cycles on and no bubbles when the flame is off. Even when the flame is off, there will be steam and a slight quiver on the liquid’s surface.

ExtraLow

ExtraLow Range

Range

OFF

XLO

Figure 5: ExtraLow STAR Burner Control Knob

Operation of the ExtraLow

Burner

OFF

XLO

• XLO, the very lowest setting, is achieved by cycling the flame on for approximately 7 seconds and off for 53 seconds of each minute.

• When the knob is rotated just beyond the SIM setting, the flame will cycle on for approximately 54 seconds and off for 6 seconds of each minute.

• To vary the amount of low heat, the control can be set anywhere within the SIM and XLO range marked on the knob.

IMPORTANT:

• For proper combustion, DO NOT use the rangetop without the burner grates in place.

• There is a slight sound associated with gas combustion and ignition. This is normal.

• On rangetops using propane (LP) gas, a slight “pop” sound may be heard from the STAR burner ports a few seconds after the burner has been turned off.

WARNING:

This product contains or, through ordinary use for its intended purpose, facilitates emission of chemicals or other substances known to the State of California to cause cancer and/or birth defects or other reproductive harm. To minimize exposure to these chemicals:

1) The burners should be adjusted by a certified installer or agency to ensure proper combustion.

2) Ensure proper ventilation with an open window or use a ventilation fan or hood when cooking with gas.

3) ALWAYS operate the unit according to the instructions in this manual.

English 9

Checking Burner Cap Placement

Star

Igniter

Burner Cap

Burner Base

• Check each burner to make sure there is no gap between the burner cap and burner base. See Figure 6 and Figure 7 for examples of correct and incorrect placements of the burner cap.

• You may gently try to move the burner caps from side to side to check if the caps are properly placed on the burner bases. When properly placed, each burner cap will rest flat on top of its burner base, and completely cover the star-shape of the burner base when viewed from the top as shown in Figure 6.

Burner Cap Placement

The burner caps must be properly placed on the burner bases for the rangetop to function properly. If the burner cap is not properly placed, one or more of the following problems may occur:

• Burner flames are too high.

• Flames shoot out of burners.

• Burners do not ignite.

• Burner flames light unevenly.

• Burner emits gas odor.

WARNING:

To prevent burns, do not touch burner caps or grates while hot. Turn the rangetop off and allow the burners to cool.

Figure 6: Correct Burner Cap Placement

Electronic Single Point Ignition

Igniter

Figure 8: Igniter

Burner Cap

To prevent flare-ups and avoid the creation of harmful by-products, do not use the rangetop without all burner caps and all burner grates properly positioned.

English 10

Figure 7: Incorrect Burner Cap Placement

WARNING:

Burner Base

Igniter

Figure 9: STAR Burner Components

Dark Blue

Secondary Cone

Light Blue

Primary Cone

Each STAR

burner has its own electronic igniter that sparks when the burner is turned on. Each burner should light in 4 seconds or less. If a burner does not light, check to see that the burner cap is positioned correctly on the base (see Figure 6 and Figure 7).

If a burner fails to ignite, refer to “Before Calling For Service” on page 21.

Automatic Re-Ignition

If any one or more burners blow out, the electronic igniter automatically activates to re-light the flame. DO NOT touch

the STAR burners when the igniters are active.

CAUTION:

DO NOT touch the STAR burners when the igniters are sparking. Ensure that the knobs are set to OFF and the burners and caps have cooled before touching.

Power Failure

Flame Height

• The correct flame height depends on 1) size and material of pan being used; 2) food being cooked; and

3) amount of liquid in the pan.

• Never extend the flame beyond the base of the pan.

• Use a low or medium flame for pan materials that conduct the heat slowly, such as porcelain coated steel or glass-ceramic.

Flame Description

Dark Blue

Secondary Cone

Light Blue

• In the event of a power failure, only the Standard

burners can be manually lit. It is necessary to light each one individually.

• If the rangetop is being used when the power failure occurs, turn all knobs to the OFF position.

• The standard STAR burners can be lit by holding a match at the ports and turning the control knob to the HI position. Wait until the flame is burning all around the burner cap before adjusting the flame to the desired level.

• DO NOT attempt to light the two left XLO

burners manually during a power failure. These burners are equipped with the ExtraLow® feature and cannot be lit manually.

• If an ExtraLow burner is on when a power failure occurs, it cannot be turned back on until the knob is first turned to the OFF position.

• The griddle or grill accessory cannot be used during a power failure.

• If you smell gas, refer to safety precautions listed on page 1.

Primary Cone

Figure 10: Flame Colors

• The burner flame color should be blue with no yellow on the tips. It is common to see orange in the flame color; this indicates the burning of airborne impurities and will disappear with use.

• With propane (LP) gas, slight yellow tips on the

primary

cone are normal.

• The flame should burn completely around the burner cap. If it doesn’t, check that the cap is positioned correctly on the base and that the ports are not blocked.

• The flame should be stable with no excessive noise or fluttering.

WARNING:

In the event of a power failure, turn all knobs to the OFF position. Only the standard burners can be lit manually.

English 11

Cookware Recommendations

WARNING:

To avoid risk of serious injury, damage to appliance or cookware, please observe the following:

• Bakeware, such as large casserole pans, cookie sheets, etc. should never be used on the rangetop.

• Placement of large stock pots should be staggered when used on the rangetop.

• Select the base diameter to match the diameter of the flame. The diameter of the flame should be the same size as the pan base or slightly smaller. Oversize or undersize pans sacrifice cooking performance. A 5½” (140 mm) base size is generally the smallest

recommended.

• Do not let plastic, paper or cloth come in contact with a hot burner grate. They may melt or catch fire.

• Never let a pan boil dry. This can damage your pan and the cooking surface.

• Professional quality pans with metal handles are recommended because plastic handles can melt or blister if the flame extends up the side of the pan. Professional quality pans are found at restaurant supply stores and gourmet specialty shops. All cookware should have these characteristics: good heat conductivity, good balance, correctly sized base diameter, a heavy, flat base, and a proper fitting lid.

• For best cooking results, the flame should be contained under the bottom of the pan.

Figure 11: Base Diameter

• Avoid using high flame setting with a pan larger than the grate or with one that spans more than one burner, such as a griddle, for prolonged periods of time. This can result in poor combustion that generates harmful by-products.

• Balance is important for stability and even cooking. The handle must not be heavier than the pan and tilt it unevenly. A pan must sit level on the grate without

rocking or wobbling.

Figure 13: Flat Base Pan

• Aluminum and copper are pan materials that conduct the heat quickly and evenly. These metals are sometimes attached to the base or in the core between stainless steel.

• A heavy, flat base is more apt to remain flat when heated. Pan bases that are warped, dented, ridged or too lightweight will heat unevenly. Heat and cool pans gradually to avoid sudden temperature changes which tend to distort cookware. Do not add cold water to a hot pan.

• A properly fitting lid will shorten cooking time and make it possible to use lower heat settings.

Figure 12: Balanced Pan

• Food packaged in aluminum foil should not be placed directly on the burner grate. Aluminum foil can melt during cooking.

English 12

Figure 14: Covered Pan

Specialty Cookware

Figure 15: Flat-bottom Wok Pan

Canning Tips:

• A flat base pan is preferred to one with a concave, convex or rippled base.

• When using two canners at the same time, use staggered burners. Do not block air to the burners. A flame needs the right amount of air for complete combustion.

• Use a cover on a canner when bringing the contents to a boil.

• Once the contents have reached a boil on HI, use the lowest flame possible to maintain the boil or pressure.

• Canning produces a large amount of steam. Take precautions to prevent burns.

Suggestions for Using the Recommendations

Use the chart starting on page 14 as a guide. The settings you use will vary depending on the pans selected and the starting temperature of the food.

Figure 16: Round-Bottom Wok in Support Ring

Woks — Either flat-based or round-bottom woks with the

accessory ring can be used on all models. Round bottom woks must be used with a support ring. The Wok pan and the porcelain-coated cast iron wok support ring must be purchased separately (PWOKRINGHC).

Canners and Stock Pots — Select one with a base diameter that extends no more than 2” (51 mm) beyond the grate.

Standard Size Water Bath Canner — 21 to 22 quarts (19.95 to 20.9 liters), with an 11” to 12” base (279–305 mm) and a 9” to 11” depth (229–279 mm).

Standard Size Pressure Canner — 8 to 22 quarts (7.6 to

20.9 liters), with an 8” to 11” base (203–279 mm) and a 6½” to 12” depth (165–305mm).

On the chart, the “Finish Setting” has been separated for the Standard and ExtraLow or may not be a change between the two burner settings.

The ExtraLow setting can be either a cooking or a holding setting.

Raise or lower the flame setting gradually. Allow time for the pan and the food to adjust to the new setting.

STAR® burners. There may

English 13

Surface Burner Cooking Guide

Finish Setting

Food Start Setting

BEVERAGES

Cocoa

BREADS

French Toast, Pancakes, Grilled Sandwiches

BUTTER

Melting

CEREALS

Cornmeal, Grits, Oatmeal

CHOCOLATE

Melting

DESSERTS

Candy Pudding and Pie Filling

Mix

Pudding SIM to MED SIM – bring

EGGS

Cooked in Shell

Fried, Scrambled SIM to MED – melt butter,

Poached HI – bring water to the

MEAT, FISH, POULTRY

Bacon, Sausage Patties

Braising: Swiss Steak, Pot Roast, Stew Meat

Quick Frying: Breakfast Steaks

Frying: Chicken MED HI – heat oil, then

Deep Frying: Shrimp MED HI – heat oil MED to MED HI – to

MED – heat milk, cover SIM – finish heating XLO – keep warm, cover*

MED – preheat skillet SIM to MED – cook Same as for Standard STAR

SIM – to start melting Allow 5 – 10 minutes to melt

HI – cover, bring water to a

boil, add cereal

XLO – may be stirred to hasten melting

SIM to MED – cook following recipe

SIM to MED SIM – cook according to package directions

milk to a boil MED HI – cover eggs with

water, add lid, bring to boil

add eggs

boiling point, add eggs MED HI – until meat starts

to sizzle

MED HI – melt fat, then brown on MED HI, add liquid, cover

MED HI – preheat skillet MED HI – fry quickly Same as for Standard STAR

brown on MED

Standard STAR®

Burners

SIM to MED – finish

cooking according to package directions

SIM to MED Same as for Standard STAR

SIM Same as for Standard STAR

XLO – cook 3 – 4 minutes for

SIM finish cooking Same as for Standard STAR

SIM to MED – finish

heating SIM to MED – finish

cooking

SIM – cover, finish cooking

maintain temperature

Finish Setting ExtraLow®

(XLO

) STAR® Burners

Burners

Same as for Standard STAR Burners

XLO – to hold, cover* XLO – allow 10 – 15 minutes

to melt XLO – to hold*

Burners

soft cooked; or 15 – 20 minutes for hard cooked

Burners

XLO

– to hold for a short

period* Same as for Standard STAR

Burners Same as for Standard STAR

Burners

XLO – Simmer until tender

Burners Same as for Standard STAR

Burners

* These foods should be stirred occasionally.

English 14

Food Start Setting

Finish Setting

Standard STAR

Burners

Finish Setting ExtraLow®

(XLO

) STAR® Burners

Pan Frying: Lamb Chops, Thin Steaks,

MED HI – preheat skillet MED – brown meat Same as for Standard Burners

XLO – to hold

Hamburgers, Link Sausage

Poaching: Chicken, whole or pieces, Fish

Simmering: Stewed Chicken, Corned Beef,

MED HI – Cover, bring liquids to a boil

HI – cover, bring liquid to a boil

To finish cooking

XLO – to simmer slowly XLO – to hold, cover

Tongue, etc.

PASTAS

Macaroni, Noodles,

HI – bring water to a boil, add pasta

MED HI to HI – to maintain a rolling boil

Same as for Standard Burners

Spaghetti

POPCORN

(use a heavy, flat

HI – cover, heat until kernels start to pop

MED HI – finish popping Same as for Standard Burners

bottom pan)

PRESSURE COOKER

Meat Vegetables HI – build up pressure SIM to MED – maintain

MED HI to HI – build up pressure

SIM to MED – maintain pressure

Same as for Standard Burners

pressure

RICE HI – cover, bring water and

rice to a boil

SIM – to maintain Low Boil. Cover and cook until

Same as for Standard Burners XLO – to hold, cover

water is absorbed

SAUCES

Tomato Base White, Cream,

Bernaise,

MED HI – cook meat/ vegetables, follow recipe

MED – melt fat, follow recipe

SIM – to maintain simmer XLO – simmer to thicken

sauce, uncovered

SIM – finish cooking XLO – to hold, cover*

Hollandaise XLO XLO – to hold, lowest setting

for short period, stir frequently

SOUPS, STOCK

HI – cover, bring liquid to a

SIM to maintain simmer Simmer XLO – to hold, cover*

boil

VEGETABLES

Fresh Frozen HI – cover, bring water and

HI – cover, bring water and vegetables to a boil

vegetables to a boil

SIM to MED – cook 10 minutes, or until tender

SIM to MED – cook according to package

Same as for Standard Burners XLO – to hold, cover

Same as for Standard Burners

directions

Deep Frying HI – heat oil MED to MED HI –

Same as for Standard Burners maintain frying temperature

In Pouch HI – bring water and pouch

to a boil

SIM to MED – cook according to package

Same as for Standard Burners directions

Saute HI – heat oil or melt butter,

add vegetables

Stir Fry HI – heat oil, add

vegetables

SIM to MED – cook to desired doneness

HI to MED HI – finish cooking

Same as for Standard Burners

* These foods should be stirred occasionally.

English 15

Using the Electric Griddle (available on some models)

GRIDDLE

Description

The built-in griddle is made of restaurant-quality aluminum that has a non-stick titanium coating. This produces a surface with even heat that is easy to clean.

A maple cutting board cover

(PA12CVRJ) (PA12GRILHC) purchased separately. The maple cutting board and stainless steel cover are sized to fit on top of the surface when the griddle is not being used. The titanium-coated aluminum grill plate accessory is designed to replace the griddle plate. See the instructions that come with the grill plate accessory for more details.

The maple cutting board and stainless steel cover must be removed before turning the griddle on.

• The griddle is electronically controlled with

temperatures marked on the knob from 150 – 500°F (66 – 260°C).

• There are no fixed settings on the knob.

• Press and turn the knob clockwise to the temperature

setting.

• The griddle plate (or grill plate accessory) must always

be in place when the griddle is turned on.

• The electric griddle element is rated 120 volts AC,

1,630 watts.

are available as accessories and are

(PA12CHPBLK)

, and coated-aluminum grill plate

, stainless steel

Figure 17: Griddle Control Knob

Preparing the Griddle

If the rangetop is equipped with an electric griddle, check the griddle frame adjustment by pouring two tablespoons of water on the back of the griddle plate. The water should slowly roll into the grease tray. If not, adjust the two screws under the back of the frame. Start with one half turn counterclockwise (CCW) of the screws. Further adjustment should be made by one-quarter turn until water slowly flows into the grease tray (Figure 18).

CAUTION:

The griddle element is hot after use. Allow sufficient time for griddle components to cool before cleaning.

WARNING:

To avoid risk of injury, NEVER operate griddle without the griddle plate installed. NEVER use griddle in a manner that is not prescribed by the Use and Care Guide.

Move griddle plate to the side and turn leveling screws

Figure 18: Griddle Plate Leveling Screws

The griddle plate should be washed with warm soapy water then rinsed with clear water prior to use. The griddle may be used without any butter, margarine or oil. However, a very small amount may be used to flavor foods.

Any utensil may be used on the griddle surface. Care should be taken that the surface is not gouged when utensils are used. DO NOT cut directly on the griddle plate.

English 16

NOTICE:

Grease Tray

Griddle/Grill performance may vary if there is an excessive amount of airflow in the vicinity of the appliance. The excessive airflow could be from an air-conditioning register or ceiling fan blowing at the rangetop. This could create longer than normal heat-up time, or it could cause the Griddle/Grill temperature to be higher or lower than the knob setting.

NOTE:

Having a properly installed ventilation hood is not considered a source of excessive airflow.

Griddle Cooking Recommendations

Griddle Grease Tray

Grease Tray

FOOD SETTING

Eggs

Bacon, Breakfast Sausage

Toasted Sandwiches

Boneless Chicken Breasts

Boneless Pork Chops, 1" (25.4 mm) thick

Steaks, 1" (25.4 mm) thick

Ground Beef Patties, 6 ounces

Hot Dogs

Ham Slices, ½” (12.7 mm) thick

325°F – 350°F (160°C – 180°C)

375°F – 400°F (190°C – 200°C)

350°F – 375°F (180°C – 190°C)

375°F – 400°F (190°C – 200°C)

400°F – 425°F (200°C – 220°C)

375°F – 400°F (190°C – 200°C)

350°F – 375°F (180°C – 190°C)

Figure 19: Grease Tray

• Clean the tray after every use. When removing the tray, use care when tipping it so that the contents do not spill.

• The griddle plate and its grease tray are dishwasher safe.

• After cooling, pour the grease into a grease-resistant container for disposal.

Cooking on the Griddle

1. Turn the knob to the appropriate cooking temperature to preheat the griddle.

2. Preheat until the griddle light goes off.

3. Add butter, margarine, oil or shortening if desired.

Pancakes, French Toast

Potatoes, Hash Browns

400°F – 425°F (200°C – 220°C)

375°F – 400°F (190°C – 200°C)

English 17

Maintenance and Care

Do-It-Yourself Maintenance

Power Failure

In the event of a power failure, only the standard burners can be lit manually. It is necessary to light each standard burner individually.

If the cooktop is being used when the power failure occurs turn all of the burner control knobs to the OFF position. The standard burners can be lit by holding a match at the ports and turning the control knob to the HI position. Wait until the flame is burning all the way around the burner cap before adjusting the flame to the desired height.

The two ExtraLow® burners on the left side cannot be used during a power failure. Be sure to turn them OFF if a power failure occurs because they will not turn back on until the control knobs are turned OFF and then turned back on again. See “WHAT TO DO IF YOU SMELL GAS” on page 1.

If you have low gas pressure, contact your gas company.

Intermittent or Constant Igniter Sparking

Intermittent or constant sparking of the sealed gas surface burners can result from a number of preventable conditions. Eliminate these conditions as indicated in the following chart.

SYMPTOM CAUSE REMEDY

Intermittent sparking • Ceramic igniter is wet or dirty.

•STAR

burner ports are clogged.

• Carefully dry or clean igniter.

• Clean ports on STAR burner cap with a wire, a needle or straightened paper clip.

More than four clicks of igniter before lighting

Constant Sparking • Rangetop is not properly grounded. • Refer to Installation Manual. Have a

• Improper fit of STAR burner cap onto STAR

• Electrical power supply is incorrectly polarized.

burner base.

• Align STAR STAR

qualified electrician ground the rangetop properly.

• Refer to the Installation Manual. Have a qualified electrician ground the rangetop properly.

burner cap properly on

burner base.

Rangetop Cleaning Tips

• Use the mildest cleaning procedure that will do the job efficiently and effectively. Some cleaners of the same type are harsher than others. Try on a small inconspicuous area first.

• The porcelain enamel finish is acid resistant, but not acid proof. Acidic foods, such as citrus juices, tomatoes, rhubarb, vinegar, alcohol or milk, should be wiped up and not allowed to bake onto the porcelain during the next use.

• Always rub metal finishes in the direction of the polish lines for maximum effectiveness and to avoid marring the surface.

• Use only clean soft cloths, sponges, paper towels, fibrous brushes, plastic, non-metal or steel wool soap pads for cleaning and scouring, as recommended in the chart.

• Most exterior parts of this appliance can be cleaned with hot sudsy water (except the various items specifically identified otherwise). When rinsing is required, rinse thoroughly.

• Always wipe dry immediately to avoid water marks.

English 18

Brand Names

The use of brand names is intended only to indicate a type of cleaner. This does not constitute an endorsement. The omission of any brand name cleaner does not imply its adequacy or inadequacy. Many products are regional in distribution and can be found in local markets. It is imperative that all cleaning products be used in strict accordance with the instructions on its package. The following chart gives directions for cleaning this rangetop.

Cleaning Recommendations

PART/MATERIAL

SUGGESTED

CLEANERS

Brass Burner Base and Cast Iron Cap • Hot sudsy water; rinse and dry

thoroughly.

• Mild abrasive cleansers: Bon-ami

Cameo® Aluminum and Stainless Steel Cleaner, Wright's

All Purpose

Brass Polish.

• Liquid cleaners: Kleen King®.

• Stiff nylon bristle tooth brush to clean port openings.

• After cleaning, make sure that the STAR burner cap is correctly seated on the STAR burner base.

Igniters/Ceramic • Use a cotton swab dampened with

or Fantastic®.

Control Knobs/ Metal Bezels/Chrome

Exterior Finish/ Back Guard

Stainless Steel

water, Formula 409

• Hot sudsy water; rinse and dry immediately.

• Nonabrasive cleaners: hot water and detergent, ammonia, Fantastik Formula 409®. Rinse and dry immediately.

• Cleaner polish: Stainless Steel Magic® to protect the finish from staining and pitting; enhances appearance.

• Hard water spots: household vinegar.

• Mild Abrasive Cleaners: Siege

Stainless Steel and Aluminum Cleaner, Kleen King® Stainless Steel liquid cleaner.

• Heat discoloration: Cameo

, Barkeepers Friend®, Zud®, Wright's® All Purpose Brass Polish.

IMPORTANT REMINDERS

• DO NOT scratch or gouge the port openings of STAR

burner cap.

• DO NOT use sharp tools to scrape the igniters. The igniters are fragile. If an igniter is damaged, it may not light the burner.

• DO NOT soak knobs.

• DO NOT force knobs onto wrong valve shaft.

• Stainless steel resists most food stains and pit marks providing the surface is kept clean and protected.

• NEVER allow food stains or salt to remain on stainless steel for any length of time.

• Rub lightly in the direction of polish lines.

• Chlorine or chlorine compounds in some cleaners are corrosive to stainless steel. Check ingredients on label.

English 19

+ 56 hidden pages
