Operating
Instructions
Instructions for Installing Auxiliary
Rolls
Holding the material against the angle gauge slide it into the forming head.
Be sure that the material remains against the gauge until work is finished.
Note: This machine will handle sheets 7" and longer. If shorter, leave
on long piece — notch and cut later.
Make "Hold-Down Adjustment" to meet any variation in the material of your
locality. Do not adjust unless material slips, tends to leave gauge, or curls
up at finish.
TO ADJUST:
1. Remove top cover.
2. Tighten hold-down studs until snug and then loosen them, a quarter
turn. (This setting will usually give proper adjustment for all thick
nesses of material.)
3. If the material slips, tighten the studs equally until the condition is
overcome.
If the material curls up after leaving the forming head, or shows
extremely heavy pressure marks, loosen studs slightly.
If a wider or narrower hammer-over edge is desired, the angle gauge on
the right hand side can be moved to give the desired width. When moving
this gauge, be sure to move both ends the same distance, keeping it parallel
to the front edge of the top plate of the machine. DO NOT MOVE ANGLE
GAUGES ON THE LEFT OH FINISHING END OF THE MACHINE. THESE
GAUGES ARE NOT INTENDED TO TOUCH THE MATERIAL AS IT COMES
THROUGH.
It
is
very important that long sheets be fed into the machine flat and against
the angle gauge for the start.
IMPORTANT: If proper care is taken, the small knife edge roll that holds
the pocket of the Pittsburgh Lock open will not break. If burrs and twists
from snip cuts are not flattened out, it will sometimes strike against the
opening roll causing it to break.
ANGLE RANGE ROLLS
1. Remove top cover.
DOUBLE SEAM or STRAIGHT RIGHT
2. Remove rear section of top plate. This will expose the
extended shafts on which the rolls are to be mounted.
3
# Select the first pair of rolls, which are marked "Tl" and
"Bl", and slip them on the shafts at the left, or feed side
of the machine, placing "Tl" on the upper shaft and "Bl"
on the lower. Repeat this procedure with rolls "T2" and
"B2"; "T3" and "B3"; "T4" and "B4"; "T5" and "B5" until
all rolls have been mounted. All rolls marked "T" should
be on the top shafts and "B" rolls on the bottom shafts, in
numerical order, reading from left to right, facing shafts.
THE NUMBERED SIDES MUST FACE OUTWARD, OR
TOWARD THE OPERATOR.
4* Fasten rolls to shafts with capscrews, Woodruff keys and
special washers which are provided.
5. Mount gauge on starting side of machine, using slotted
holes provided in top plate. The position of this gauge is
shown below (Gauge Dimensions). The angle gauge on the
finishing side should not touch the metal as it emerges from
Drive
1. Proceed as instructed for Double Seam Rolls, but leave roll
"T-2" loose. This roll centers itself and should not be held
in place with cap screw. Woodruff keys are used in all
cases, however.
2* Remove the stud from the spacer (this is located between
"B4" and "B5") and place the slide block in position, secur
ing it with the 3" stud furnished. CAUTION: ALWAYS
REMOVE THE SLIDE BLOCK AND REPLACE THE SHORT
STUD WHEN TAKING THE DRIVE CLEAT ROLLS OFF THE
MACHINE.
3« Mount the feed gauge on left
hand side so that it is exactly
parallel with the rolls. THIS IS
VERY IMPORTANT! If it is not
parallel, the cleat will not be
perfect.
Cleat
Rolls
the rolls.
6« Replace back plate and top cover.
7* Hold material against gauge and feed into machine.
4* Tighten small hold-down studs
so that "T5" and "B5" do not
separate when drive cleats
are passing through.
3
a
F3
Lubrication
Check and refill the six grease cups on the under side of the
forming unit at least once a month. The slow speed shafts
do not require lubrication. Check oil in motor occasionally.
If machine is used out of doors an oil or grease film will
prevent rusting of surfaces.
T-4
O
IMPORTANT: Be sure to cut
your material square, and a
full 2Vq“ wide to insure a per
fect cleat.
DRIVE CLEAT
SLIDE BLOCK
STARTING END
ANGLi GAUGE
GAUGE DIMENSIONS
_1
_________
© I
l
SLIDE BLOCK
(FOR DRIVE CLEAT ONLY)
TOP VIEW
STRAIGHT EDGE
FINISHING END
]
Pittsburgh Rolls ............
Double Seam Rolls
Right Angle Flange Rolls
Drive Cleat Rolls ............
The dimension tolerances allow for varying
metal thicknesses. Be sure that the gauges
parallel with the auxiliary rolls.
GAUGE DIMENSIONS:
................2V3"
..........
l»i"—1-3/32
..........1-1/16"
.. 1"—1-1/32"
“
are
Page 3
2218.
2211,
2240
2223
2206
2217
2223
2249
2240
2209
1204
1224
2236
1219
2223
2236
224
226
X- -
2247
2202
2251
2202
2212
2220
2223
2222
2207
2201A.
2255
2218"N
• 2254-x
.
2223
2240
2201
1
SHOWING ROLL SET ”4"
AND STEPPED SPACERS
— "4
Ti.
AND PLAIN
2210
2232
2205
2236
2223
2242
77k
1
z z z
zZz
SHOWING IDLER ROLL SET AND-
IDLER GEAR, STEPPED SPACER
AND HOLD DOWN STUD
X
240
2221
2236
1228
.2214
*2215
.2213
'2246
*2249
•2216
2223
SHOWING ROLL SET "2”
DRIVE GEAR
AND 2nd
F
2246
2239
2250
2237
2215
2208
2203
2249
2224
2216
2225
2224
2219
2236
v
i
u_
-ti
\
SHOWING ROLL SET "5" AND
OPENING ROLL
ft?
225 P*
2202B
2247
2215
2212
2214
2223
2213
2220
2218
2201B
225
_______
\
K
Jt -V_ _
/A
SHOWING ROLL SET "3" AND 1st
DRIVE GEAR
t
-*~3
i
i
/
Z
Z
/
t\
f
SHOWING ROLL SET "1" AND 3rd
DRIVE GEAR
^
----
2246
2239
1250
2240
2227
2244
^1
zy •
tvg
ft
^-3
Parts List and Description
Indicate serial number of machine when ordering parts.
Page 4
Parts List and Description
Indicate serial number of machine when ordering parts.
PART NUMBER
2201A
2201B
2202A
2202B
2203
2204
2205
2206
2207
2208
2209
2210
2211
2212
2213
2214
2215
2216
2217
DESCRIPTION
Lower front plate
Lower back plate
Upper front plate
Upper back plate
Lower first forming roll
Lower second forming roll
Lower third forming roll
Lower fourth forming roll
Lower fifth forming roll
Upper first forming roll
Upper second forming roll
Upper third forming roll
Upper fourth forming roll
Upper fifth forming roll
Lower idler roll
Upper idler roll
Plain spacer drilled for part #2246
Step spacer tapped for part #2246
Step spacer
No. Per Mach.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2 2235
2 2236
PART NUMBER
2218
2219
2220
2221
2222
2223
2224
2225
2226
2227
2228
2229
2230
2231
2232
2233
2234
Plain spacer
3 Vi" Gear with hub, 32 teeth
Opening roll
Pin for idler rolls, Parts #2213-2214
Opening roll holder
Bearing %" shaft diam. x 3A"
Bearing 3A"
Third
drive shaft
Second drive shaft
First drive shaft
Bearing 5
Switch (not illus.)
V-Belt (not illus.)
Angle gauge (not illus.)
6" V-Belt sheave
Motor sheave (not illus.)
Cord connector (not illus.)
#9 Woodruff key (not illus.)
Allen set screw All 5/16" x 5/16"
/s" shaft diam. x 3A"
DESCRIPTION
long
shaft diam. x 3A" long
long
No. Per Mach.
4
2
1
2
1
24
6
1
1
1
2
1
1
2
1
1
1
3
5
PART NUMBER
2237
2238
2239
2240
2241
2242
2243
2244
2245
2246
2247
2248
2249
2250
2251
2252
2253
2254
2255
DESCRIPTION
Locking collar
Flat head screw
Steel washer for part =2246
Stud and lock washer for spacer
Rd. head carriage bolt for angle gauge 4
3A"
Collar for drive shaft
Grease cup
Macit set screw
B-X Connector (not illus.)
%" x 6" holddown stud
3
/s" x 41/2" holddown stud
Extension cord (not illus.)
Steel idler gear, 2" diam., 20 teeth
IV2" O. D. leather washer
W O. D. leather washer
Stand (not illus.)
Forming head cover (not illus.)
%" x 1" set screw for opening roll holder 1
%" spacer washer for rear plates
No. Per Mach.
20
2
4
2
2
6
1
1
2
2
1
4
2
2
1
1
2
Page 5
To Install Power Flanging Attachment
!• Remove present cover.
2. Loosen FRONT CAP SCREWS on Spacers No. 1 and 4.
3. Remove Spacers No. 2 and 3 by taking out front and back
cap screws.
4* Set flanging attachment over the forming head so the com
bination bevel and spur gear meshes with the gear on
Pittsburgh Lock Roll No. 3.
5. Fasten flanging attachment with the cap screws which held
Spacers No. 2 and 3 in place.
CAUTION: BE SURE TO TIGHTEN ALL CAP SCREWS!
REAR CAP SCREWS
I
Q
a
ROLL No. 3
Q
o
SPACER No. 1
L
©
to
2
FRONT CAP SCREWS
3
THU
9
TO
Page 6
To Operate Power Flanging Attachment
Turn gauge adjustment screw all the way in, then back about a quarter
1.
turn. (This setting is usually right for 26 gauge material).
Turn up a* "Starting Flange" on the material before inserting it into the
2.
flanging rolls. This is done by inserting the edge of the piece in the slot
cut in the table top. (Once the operator is accustomed to the Flanger, this
won't be necessary). Slide the piece into the forming head, being careful
to
insert it so that the edge to
ing head. As the metal passes through the forming rolls, be sure to exert
pressure against the piece in the direction indicated by the arrows shown
on the illustration below. This holds the metal to the height gauge, and
results in an even, uniform flange.
After the operator has run a few pieces through, he will become accus
3.
tomed to the "feel" of the machine and will find it easy to hold the metal
to the gauge. The operator should stand in front of the Lockformer for
ease in handling the material.
When flanging straight pieces or pieces having the same radius, the oper
4.
ator
may
set the adjustable guide by running the first piece partly through
the rolls, and then setting the guide against the flanged edge. The guide
should not be set too tight against the flanged edge.
DO NOT HAVE THE GAUGE ADJUSTMENT SCREW TOO TIGHT. It
5.
should be set just tight enough to draw the metal through. Too tight an
adjustment will stretch and wrinkle the material.
Should you fail to turn the flange to its full height, or run off the edge of
6.
the piece you are flanging, do not discard it as being spoiled. Just run it
through the Flanger again.
be flanged will be at right angles to the form
On exceptionally small outer radii, it may be necessary to pass the piece
7.
through the flanging rolls a second time, to straighten up the flange.
IMPORTANT. When flanging small inner radii, such as the throats of
8.
small elbows, grasp the piece in such a way as to have the thumbs on the
under side and the fingers on the upper side of the metal. Then, after hav
ing turned a "starting flange", insert the metal into the rolls and LET GO!
The metal will hold itself to the gauge and produce a perfect flange.
ADJUSTABLE
GAUGE
Loading...
