T-FAL FP412113 User Manual

c

d1

d2

A/D

C/H

e

E

G

f

i2

i1g1

g2

g3

g4

i3

i4

h1

h2

h3

b2

b1

b3

a1

a2

j

k

fig.1a fig.1b

fig.1c

fig.2a fig.2b fig.2c

fig.3 fig.4

fig.7fig.6 fig.8

2

3

2

3

4

1

1

6

5

6

3

2

3

4

5

2

3

4

2

1

1

1

2

4

3

4

4

1

6

2

3

1

fig.5

1

6

4

5

5

5

2

3

5

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and/or injury to persons, including the following:

1. Read all instructions carefully before using the appliance.

2. To protect against risk of electrical shock, do not immerse cord, plug or appliance in
water or other liquids.

3. Close supervision is necessary when any appliance is used near children.

4. This appliance is not intended for use by children.

5. Unplug from outlet when not in use, before putting on or taking off parts, and before
cleaning.

6. Avoid contact with moving parts.

7. Do not operate any appliance with a damaged cord or plug. If the appliance
malfunctions or has been damaged in any manner, return it to the nearest
authorized T-fal service facility for examination, repair or adjustment.

8. The use of accessory attachments not recommended by T-fal may cause injuries.

9. Do not use outdoors.

10. Keep hands and utensils out of blender jar while blending to reduce the risk of severe
injury to persons or damage to the blender. A scraper may be used but must be used
only when the blender is not running.

11. Blades are sharp. Handle them with care.

12. Always operate blender with cover in place.

13. When blending hot liquids, remove measuring cup (center piece of cover) to allow
steam to escape.

14. Make certain the voltage of the appliance is in accordance with your domestic supply.

15. Never use the appliance on a hot surface or near fire.

16. Do not place ingredients bigger than one inch into the appliance. They could stop
the blade and overheat the appliance.

17. Do not place the blender jar in a microwave oven.

18. Keep fingers away from all moving parts.

19. Never feed food by hand. Always use food pusher.

20. Keep hands and utensils away from moving blades or discs while processing food to
reduce the risk of severe injury to persons or damage to the food processor. A scraper
may be used but must be used only when the food processor is not running.

21. To reduce the risk of injury, never place cutting blade or discs on base without first
putting bowl properly in place.

22. Be certain cover is securely locked in place before operating appliance.

23. Do not attempt to defeat the cover interlock mechanism.

24. Keep hands and utensils away from the cutting blade while chopping food to reduce
the risk of severe injury to persons or damage to the food chopper. A scraper may be
used but only when the food chopper is not running.

25. Always make sure juicer cover is clamped securely in place before motor is turned on.
Do not unfasten clamps while juicer is in operation.

1

E

26. Be sure to turn switch to OFF position after each use of your juicer. Make sure the
motor stops completely before disassembling.

27. Do not put your fingers or other objects into the juicer opening while it is in
operation. If food becomes lodged in opening, use food pusher or another piece of
fruit or vegetable to push it down. When this method is not possible turn the motor
off and disassemble juicer to remove the remaining food.

28. Do not use the appliance if the rotating sieve is damaged.

29. Keep hands, hair, clothing, as well as spatulas and other utensils away from beaters
during operation to reduce the risk of injury to persons, and/or damage to the mixer.

30. Remove beaters from mixer before washing.

31. In liquid mixers: Never add to container while appliance is operating.

32. Container must be properly in place before operating appliance.

33. Do not let cord hang over edge of table or counter or touch hot surfaces.

34. Do not place on or near a hot gas or electric burner or in a heated oven.

35. Extreme caution must be used when moving an appliance containing hot oil or other
hot liquids.

36. Always attach plug to appliance and check that the control is OFF before plugging
cord into wall outlet. To disconnect, turn the control to OFF, then remove plug from
wall outlet.

37. Do not use appliance for other than intended use.

SAVE THESE INSTRUCTIONS

CAUTION: Read instructions before using.

•

BLENDER - CAUTION: Do not operate without this cover in place.

•

FOOD-PROCESSOR - CAUTION: Sharp blade - Always use food pusher.
Moving parts - Keep fingers out of feed opening.
Do not open until blades stop.

•

JUICE EXTRACTOR - CAUTION:

Unplug before cleaning and before assembling or removing part.
Sharp tool - Always use food pusher.

CAUTION: This appliance is for household use only. Any servicing other than cleaning
and user maintenance should be performed by the nearest authorized T-fal Service
Center. Do not immerse base in water.

2

SPECIAL CORD INSTRUCTIONS

A. A short power-supply cord has been provided to reduce the risks resulting from

becoming entangled in or tripping over a longer cord.

B. A longer detachable power-supply cord or extension cord are available and should be

used with caution.

C. If a long extension is used, (1) the marked electrical rating of extension cord should

be at least as great as the electrical rating of the appliance, (2) if the appliance is of
the grounded type, the extension cord should be of a grounded type, and (3) the
longer cord should be arranged so that it will not drop over the counter top or table
top where it can be pulled on by children or tripped over.

D. This appliance has a polarized plug (one blade is wider than the other). To reduce the

risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to modify the plug in any way.

3

Thank you for choosing a T-FAL product exclusively designed for food preparation.

Safety recommendations

• Read the instructions for use carefully before using your appliance for the first time: T-fal does not
accept responsibility for use that does not comply with the instructions.

• Do not leave the appliance running unsupervised, especially when young children or disabled people
are present.

• Make sure that the power your appliance uses corresponds to your electrical supply system.

• Any error in connection will cancel the warranty.Your appliance is designed for indoor home use only.

• Unplug the appliance when you have finished using it (even in case of a power failure) and when you
clean it.

• Do not use the appliance if it is not working properly or if it has been damaged. If this problem
occurs, please contact our consumer service department (1-800-418-3325 M-Th 8:30am - 5pm & Fr
8:30am - 4pm EST).

• All interventions other than cleaning and everyday upkeep by the customer must be performed by an
authorized T-fal service center.

• Do not immerse the appliance, power cord or plug in water or any other liquid.

• Do not leave the power cord hanging within reach of children.

• The power cord must never be close to or in contact with the hot parts of your appliance, near a
source of heat or over a sharp edge.

• Do not use the appliance if the power cord or plug is damaged. The power cord must be replaced by
an authorized T-fal service center to avoid danger.

• Do not use the appliance if the juicer unit is damaged.

• For your safety, use only T-fal accessories and spare parts designed for your appliance.

• Always use the pusher to guide food in the feeder tube, never use your fingers, a fork, a spoon, a
knife or any other object.

• Handle the metal blade, the blender blade, and the vegetable cutting discs with care: they are
extremely sharp. You must remove the metal blade (9) from its spindle (8) before emptying the bowl
of its content.

• Never run your appliance empty.

• Always use your blender with the lid on.

• Never touch any moving parts; wait for the appliance to come to a complete stop before removing
accessories.

• Do not use the accessories as storage containers (for freezing - cooking - heat sterilization).

• Do not pull on the storage drawer to move your appliance.

• The maximum power of your appliance is reached with the food chopper attachment (available
online at www.t-fal.ca).

The accessories
contained in
the model that
you have
purchased are
represented on
the label found
on the top of
the packaging.

4

Description

a Motor unit

a1 Motor unit power outlet
a2 Speed selector: position 0-1-2-Pulse

(intermittent operation)

b Transparent bowl assembly

b1 Pusher with measuring marks
b2 Lid with feeder tube
b3 Bowl

c Spindle

ACCESSORIES DEPENDING ON MODEL :

d

d1 Metal blade
d2 Plastic kneading blade

e Vegetable cutting disc

- A/D : fine grating / thin slicing

(reversible)

- C/H : coarse grating / thick slicing

(reversible)

- E : french fries cutting disc

- G : grating disc for hard foods such as

parmesan and coconut

f Emulsifying disc

g Citrus press

g1 Cone
g2 Filter
g3 Juice collector
g4 Citrus press spindle

h Blender

h1 Measuring cap
h2 Lid
h3 Jug

i Juice extractor

i1 Pusher
i2 Lid
i3 Filter ring
i4 Filter basket

j Spatula

k Storage drawer for accessories

5

Getting Started

• Before using for the first time, wash all accessory parts in hot, soapy
water then dry thoroughly.
Or place them in the dishwasher.

• Set the motor unit on a clean, dry flat surface.

• Plug in your appliance.

• For Pulse (intermittent operation): turn the button (a2) to the
position and use in short bursts for better control of certain
preparations.

• For continuous operation: turn the button (a2) to the 1 or 2 position.

• To stop: turn the button (a2) to the 00position.

PPuullssee

The paragraph numbering
corresponds to the numbers
in the diagrams.

1. Assembling the Bowl and the Lid

ACCESSORIES USED

• Bowl unit (b).

ASSEMBLING THE ACCESSORIES

• Place the bowl (b3) on the motor unit (a), with the bowl handle positioned slightly to the right of the speed
selector.

• Place the lid (b2) on the bowl (b3) with the long tab to the left of the handle.

• As arrow indicates, turn lid to the right. Long tab fits into handle and locks in place.

• Lock the whole assembly by turning it toward the right.

NNoottee:: TThhee lliidd mmuusstt bbee lloocckkeedd oonnttoo tthhee bboowwll bbeeffoorree lloocckkiinngg tthhee aasssseemmbbllyy oonnttoo tthhee mmoottoorr uunniitt ((aa))..

2. Removing the Bowl and the Lid

• Unlock by turning the assembly toward the left.

• Unlock the lid by turning toward the left to free it from the bowl handle.

• Now you can lift and remove your lid.

3. Mix / Chop / Knead / Blend (depending on model)

ACCESSORIES USED

• Bowl unit (b).

• Spindle (c).

• Metal blade (d1) for chopping and mixing.

• Plastic dough hook (d2) for kneading or mixing (selon le modèle).

ASSEMBLING THE ACCESSORIES

• Place the bowl (b3) on the motor unit (a) without locking it.

• Place the spindle (c) over the motor shaft.

• Slide the metal blade (d1) or plastic dough hook (d2) onto the spindle.

• Place the ingredients in the bowl.

• Put on the lid (b2) and lock it onto the bowl (b3), then turn the assembly toward the right to the locked position.

• To remove the bowl-lid assembly: turn the assembly to the left to release it and unlock the lid.

6

KNEADING / MIXING (depending on model)

• Use the metal blade (d1) or plastic dough hook (d2).

Turn the speed selector (a2) to the 2 position to start.

• You can knead up to:

- 2 lbs. of heavy dough, such as: white bread dough, pastry, etc. in 40 seconds.

- 1.5 lbs. of special bread dough such as: rye bread, whole wheat bread, multigrain bread, etc. in 40 seconds.

• You can mix up to:

- 2.5 lbs. of mixture, such as: biscuits, sponge cake, etc. in 1 to 3 min.

• You can also mix up to 4 cups of pancake batter, pudding, waffle batter, etc. in 1 min to 1 1/2 min.

CHOPPING

• Use the metal blade (d1).

• Turn the speed selector (a2) to the 2 position to start, or, for better control use the pulse position.

• You can chop up to 1 lb. of foods such as:

- raw or cooked meat (bone and gristle removed, and cut into cubes).

- hard products: cheese, dried fruits and nuts, certain vegetables (carrots, celery, etc.).

- soft products: certain vegetables (onions, spinach, etc.).

BLENDING

• Use the metal blade (d1).

• Turn the speed selector (a2) to the 2 position to start.

• You can blend up to 4 cups of soup or stewed fruit in 20 seconds. To blend soups to a fine, smooth texture use

the blender attachment (h).

4. Grate / slice

ACCESSORIES USED

• Bowl unit (b).

• Spindle (c).

• Disc as desired (e) (depending on model)

ASSEMBLING THE ACCESSORIES

1. Place the bowl (b3) on the motor unit (a) without locking it.

2. Lock the selected disc (e) onto the spindle (c).

3. Position the assembly on the motor shaft (a1).

4. Put on the lid (b2) and lock it on the bowl (b3).

5 Turn the assembly to the right to the locked position.

6. To remove the bowl-lid assembly: turn the assembly to the left to release it and unlock the lid.

USAGE AND PRACTICAL TIPS

• Cut food into pieces to fit the height and width of the feed tube.

• Insert the food through the feed tube in the lid and guide it with the pusher (b1).

• Turn the speed selector (a2) to the 1 position to slice or to the 2 position to grate.

• You can use the discs for:

- coarse grating (C) / fine grating (A): zucchini, potatoes, carrots, cheese, etc.

- thick slicing (H) / thin slicing (D): potatoes, onions, cucumbers, beets, apples, carrots, cabbage, etc.

- french fries cutting disc (E): for thin chips, etc.

- grating disc for hard foods (G): for parmesan, coconut, etc

7
